TOTAL NETWORK SOLUTIONS
Our outdoor CDA-09O Extender Antenna extends the wireless range of 802.11b/g Wireless Broadband Routers and
Access Points to 700 meters. Using UV resistive plastic and stainless steel for mounting pieces has greatly improved
the working life of this antenna. To facilitate outdoor installations and performance, the antenna has options for Wall
or Pipe mounts as well as the capability to adjust the down tilt or up tilt angle. CDA-09O is designed with an N jack
high precision connector for better performance.
KEY FEATURES
•= Weight mounting
•= Compliant with AP/Router with N-Type Connector
•= Extended wireless network coverage up to 650M ~
700M *
•= Easy installation
•= Save space and cabling cost
SPECIFICATIONS
Product Name 9dBi Directional Antenna
Model Name CDA-09O
Frequency Range 2.4GHz ~ 2.5GHz
Gain 9dBi at 2.45GHz
Storage Temp -20 ~ +80
Operation Temp -10 ~ +60
Cable 45cm
Impedance 50Ω
Polarization Linear Vertical
Dimensions 142 x 120 x 47 (mm)
Connector N-Jack
Radiation Pattern Directional
ORDERING INFORMATION
Model
CDA-09O
* The actual range will be affected by real environment
9dBi Directional Antenna
www.cnetusa.com
CDA-09O – 9dbi Directional Antenna
Description
CDA-09O October, 2004
Specifications are subject to change without notice Trademarks & Trade Names belong to their owners
