Contents
Warning………………………………………………………..2
Caution ……………………………………..…………………3
Main unit Description…………………….………...………...5
Control Panel Button Function ……………….………………5
Front Panel …………………………………………..………..5
TV Terminal Connections …………………………………….6
Remote control……………………………………..………….7
OSD Menu Operation…………………………….……………….9
Main Menu………………………………………...………………9
Other Menu……………………………………………………….23
Multimedia …………………………….......…..…………………25
Personal Video Recorder (PVR)………………...………………..30
Specification ………………………………….…………………..36
1
Warning
RISK OF ELECTRIC SHOCK
CAUTION: TO AVOID THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER- SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This symbol is intended to alert the user to avoid the risk
of electric shock, do not disassemble this equipment by anyone
except a qualified service personnel.
CAUTION
DO NOT OPEN
This symbol is intended to alert the user to the presence
of important operation and maintenance instructions in
the literature accompanying the equipment.
2
Caution
Caution
High voltages are used in the operation of this product.
- Do not open the product's casing. Refer servicing
to qualified service personnel .
Caution
To prevent fire or electrical shock hazard, Do not expose
the main unit to moisture.
Caution
Do not drop or push objects into the television cabinet
slots or openings. Never spill any kind of liquid on the
television receiver.
Caution
Avoid exposing the main unit to direct sunlight and other
directly on other products which give off heat. E. g. video
cassette players, Audio amplifiers. Do not block the
ventilation holes in the back cover. Ventilation is essential
to prevent failure of electrical YPBPR. Do not squash
power supply cord under the main
sources of heat. Do not stand the television receiver
unit or other heavy objects.
3
Caution
Caution
Never stand on, lean on, push suddenly the product
or its stand. You should Pay special attention to
children.
Caution
Do not place the main unit on an unstable cart stand,
shelf or table. Serious injury to an individual, and
damage to the television, may result if it should fall.
Caution
When the product is not used for an extended period
of time, it is advisable to disconnect the AC power
cord from the AC outlet.
Caution
The LED panel used in this product is made of glass.
Therefore, it can break when the product is dropped
or applied with impact. Be careful not to be injured
by broken glass pieces in case the LED panel breaks.
4
Main unit Description
Control Panel Button Function
POWER: ON/OFF button
SOURCE: Select signal input.
MENU: Main Menu display and menu selection.
CH-: Channel down
CH+: Channel up
VOL-: Volume down
VOL+: Volume up
Front Panel
Power/Standby Indicator: Green and red dual-color LED. It shows red when the TV is turned off
and green when turned on.
Remote Control Sensor: Remote Control IR sensor, which receives infrared ray sent by remote
control.
5
TV Terminal Connections
a. RF input terminal.
b. Audio input terminal.
c. CVBS input terminal.
d. Mini YPbPr input terminal.
e. Earphone output terminal.
f. Coaxial Audio output terminal
g. VGA input terminal.
h. PC Audio input terminal .
i. SCART input terminal.
j. HDMI2 input terminal.
k. HDMI1 input terminal.
l. USB input terminal
6
Remote control
POWER: Turn the TV on or off.
MUTE: Press to mute the sound. Press again to regain the
sound.
0-9: Press 0~9 to select a TV channel directly The channel
will change after 2 seconds. Applicable for entering page
number in teletext mode and so on.
-/-- : Press this button firstly when the channel to be selected
is two or three figures
: Return to the previously viewed program
DISPLAY: Press to display the program’s information.
SOURCE: Press to select signal source for TV
◄►▼▲/ENTER: Allows you to navigate the on-screen
menus and adjust the system settings to your preference.
EXIT : Exit from the menu or sub menu
MENU: Allow you to navigate the on-screen menus.
P.MODE : Select the picture mode
S.MODE : Select the sound mode
CH+/-:Press these two buttons to change channels sequence.
VOL+/-: Press these two buttons to increase/decrease the
sound volume
AUDIO: Press to change the language of the audio in DTV
mode.
AUTO: Press this button to adjust picture mode automatically
in PC mode.
SLEEP: Press this button to turn off TV automatically.
ASPECT : Press this button to select the aspect of screen.
RED/GREEN/YELLOW/BLUE: Correspond to different
color buttons on OSD
: Play /pause
: Stop playing
/ : Play fast backward / forward.
/ : Play previous /next media file
7
TEXT: Press to turn the Teletext On and Off
INDEX: Press to return to the index/initial page.
MIX :Press to display the picture and the teletext at the same
time
REVEAL: Reveal or Hide the hidden words.
HOLD : HOLD On or Off for current page display .
SUBPAGE : Display a sub-page of upper options
SIZE : Change the size of display in Teletext mode.
CANCEL: When a page is selected in the mode of text, it
may take some time before it becomes available, pressing the
CANCEL key will return to the TV mode. When the required
page is found, the page number will appear at the top of the
TV picture, press the CANCEL key to return to the mode of
text for you to browse this page.
TIME SHIFT: When the user left, it will auto stop the TV
program and record the program into the remote store device.
User can review the program after back.
REC: Personal video recorder.
FAV-./FA V+.: Scan up or down through the current favorite
channel list.
EPG: Shows Electronic Program Guide.
FAV .: Adds the current channel to your favorite channel list,
or erases the current channel from your favorite list.
SUBTITLE: To display the subtitle.
TV/RADIO: Press to show or hide the picture, only heard the
radio.
8
OSD Menu Operation
1. Main Menu
Main Menu items （from right order CHANNEL –> PICTURE -> SOUND ->
TIME -> OPTION -> LOCK ） at DTV/ATV input source，the first page showed is
CHANNEL。At non DTV/ATV input source，the first page is PICTURE as default。
Currently press ENTER to get in sub menu，submenu is Highlight fixed on，press
button key，the subtopic turns up with full screen.
1.1 CHANNEL:
Note：
1) CHANNEL can be only selected under ATV/DTV condition，others can’t be
used.
1.1.1 Auto Scan：
Enter Auto Scan，it shows the frames of ‘country’ and ‘tune type’ optional.
operation declaration：
Press move to select up and down, press DONE to start scanning. When scanning, the
first 50% processing means ATV tuning, the last 50% processing means DTV tuning.
9
When ATV tuning, you can press menu to skip ATV tuning and start DTV tuning.
1.1.2 DTV manual tuning:
Press enter to confirm tuning（only in DTV condition）。
1.1.3 A TV manual tuning:
1 )function description：
Item Adjust item Description
10
Storage To 1 – 100 Current storage space shows
System BG -> I -> DK -> L
Current CH 1 – 100 Current channel shows
Search Can be searched at full channel condition
Fine-Tune Fine-tune
Frequency
When gray ， no
selected
Default option depends on country
selection
Show the current frequency, and follow
Search or Fine-Tune to adjust.
2）operation instruction: after tuning by hand, make sure to press red key for storage,
otherwise all channels searched would not be stored after switching condition.
1.1.4 Programme Edit :
key operation introduction：
Key range description
CH+ ATV/DTV Page up, can turn page by circle；
CH- ATV/DTV Page down, can turn page by circle
Delete current channel, as follows:
(DELETE) ATV/DTV
11
1) at normal condition, press
2) at DELETE mode，the key can be used as：
to enter DELETE mode；
