CMP CallExtend Versions 3-4 – 3-52 User Manual

CallExtend Programming Guide

CallExtend is programmed by dialing digits on a standard touch-tone phone connected to the ADMIN port. Data is stored in memory banks called PAGES. Eleven PAGES are available: PAGE 0 - PAGE 9 and PAGE *.

You only need to program PAGE 0 and the PAGES that correspond to the first digits your callers will be dialing. For example, if callers can dial

extensions 100, 110, etc. or dial 3 for sales, program PAGES 1 & 3.

Before programming CallExtend, answer each of the following questions and enter your answers into the Programming Log that follows these questions. You

will then be ready to program CallExtend from the Programming Log.

Programming System Settings

What is the hook-flash duration used by your phone system to

transfer calls? From the following chart, select the single digit that represents this duration:

no hook-flash........... 0 600 ms ..............5

250 ms .....................1 750 ms ..............6

300 ms .....................2 900 ms ..............7

400 ms .....................3 1 sec.................. 8

500 ms .....................4 1.5 sec............... 9

Now, turn to PAGE 0 of the Programming Log that follows

these questions. Enter this single digit into ROW 0, Field 1.

After CallExtend has played its greeting to a caller, how many

seconds (0-9) should it give the caller to dial an extension or a menu option, before transferring the call to the receptionist?

Enter this digit on PAGE 0, ROW 0, Field 2.

How should CallExtend supervise call transfers?

Full Supervision

or no answer) to a designated receptionist. To select this mode,

enter the number of rings (2-9) CallExtend should hear before retrieving the call and transferring it to the receptionist. (If you want unanswered calls to be disconnected instead of

transferred to the receptionist, see p. 36, Case B, in the manual.)

- CallExtend will send unanswered calls (busy

__________

  

__________

Busy-Only Supervision

a busy extension to a designated receptionist. Calls to ringing extensions will be cut through. To select this mode, enter a 1.

Unsupervised

extension without looking for busy or ringing. To select this mode, enter a 0.

Enter this digit on PAGE 0, ROW 0, Field 3.

- CallExtend cuts through all calls to the desired

- CallExtend will send calls transferred to

__________

Programming Receptionist Extensions

What extension or phone number do you want CallExtend to use

as the receptionist when callers dial “0” or don’t dial anything from the main greeting? This field MUST be programmed.

Enter this main receptionist extension on PAGE 0, ROW 1.

If you selected Unsupervised mode in Question 3, skip to

Question 6 now. Otherwise, what extension or phone number do you want CallExtend to transfer calls to if the initial extension the caller dials is busy or doesn’t answer?

Enter this busy-don’t-answer receptionist on PAGE

Note: See pages 14-18 in the manual to enter multiple receptionist extensions, to use an 8-16 digit number as a receptionist, or to set up department receptionists.

, ROW 1.

__________

Programming PAGES 1-9

Do you want callers to be able to dial extensions directly? If not,

skip to Question 7.

A. What digit(s) do your extensions begin with?

B. How many digits are in each extension?

In the Programming Log, go to each PAGE number you listed

in 6A. Enter the answer to 6B in ROW 0 of that PAGE.

Example: if your extensions start with either 1 or 2 and are 3

digits long, enter “3” in ROW 0 of PAGES 1 & 2.

Do you want callers to reach a specific extension by dialing a

single digit from the main menu? If not, skip to Question 8.

__________

Use the following chart to enter the extensions you want callers

to reach by dialing the single digit in Column A.

Column A - Digit

Notes: i) You can’t use digits that were entered in Question 6A.

ii) To enter multiple extensions per digit, or to use an extension longer than 8 digits, see pages 21-22 of the manual.

In the Programming Log, go to each PAGE number you used

in Column A (e.g., digit 4 = PAGE 4). Enter a that PAGE. Then, enter the extension listed in Column B for that digit into ROW 1 of that same PAGE.

Example: To transfer callers who dial “4” to ext 215, enter a

in PAGE 4, ROW 0 and enter “215” in PAGE 4, ROW 1.

Do you want callers to have a second menu to choose from after they have dialed

a single digit from the main menu? If so, refer to pages 23-24 of the manual. Also refer to these pages to have CallExtend play an information message (e.g., company address and hours) to callers who dial a digit from the main menu.

Programming Voice Messages

Do you want calls answered by CallExtend’s Port 1 to use the same messages as

calls answered by Port 2? If not, see pages 28 - 29 in the manual.

Design your Main Greeting

answers each call). In the Programming Log, write a brief description of the message in PAGE 0, ROW 7.

10.

Do you want to record a Transfer Message to be heard by callers before each call is

transferred? e.g., “Please hold while I try that extension.” If so, write a brief description of the message in PAGE 0, ROW 6 of the Programming Log.

11.

Do you want to record a Busy - Don’t Answer (BDA) Message to be heard by

callers if the initial call transfer is unsuccessful, before the call is redirected to the receptionist? e.g., “That extension is unavailable - please hold for the receptionist.” If so, write a brief description of the message in PAGE 0, ROW 5 of the Programming Log.

(the first message callers will hear when CallExtend

Column B - Extension(s) 1 __________________________________ 2 __________________________________ 3 __________________________________ 4 __________________________________ 5 __________________________________ 6 __________________________________ 7 __________________________________

in ROW 0 of

12.

If you are having callers dial any single-digits from the main greeting, do you want

them to hear another voice message specific to the digit dialed?

A different Page Message

greeting. These messages can be used for second-level menus and for information, such as directions to the company.

For each digit you want to have its own message, go to that PAGE number

(e.g., if the caller dials “4” from the main greeting, go to PAGE 4). Write a brief description of the message in ROW 7 of that PAGE. Note: If you want to

use any Page Messages, they must be recorded BEFORE the Transfer Message and BDA Message.

CallExtend Programming Log:

can be played after each digit 1-9 is dialed from the main

After answering the previous questions and filling in the Programming Log that follows, you will be ready to begin programming CallExtend.

Program only the ROWS you filled in; the other ROWS will be left blank by default. When programming, you will dial on the ADMIN phone in response to the prompts CallExtend shows on its display:

Enter the Page to be programmed

Enter the Row to

be programmed

Enter the Command

(see table)

Enter Data or

Record Speech

The following table shows the commands used for programming. To enter a Command, hold down the indicated key on the Admin phone for at least one full second (until the Display changes), and then release it.

DATA Commands:

ENTERS Data into a Row on a Page

REVIEWS Data in a Row on a Page

SPEECH Commands:

RECORDS a Message into a Row on a Page

REVIEWS a Message in a Row on a Page

ERASES the last-recorded message from a Row on a Page

ERASES ALL voice messages; use from Page 0, Row

PAGE 0 Programming Log

PAGE * Programming Log

Program the ROWS on this PAGE in the order they are shown, as follows:

1. Go off-hook on the ADMIN phone.

will show on the display.

2. Dial the digits shown for each ROW you filled in when answering the Application Questions. Hold down the command digit (highlighted in gray) for at least 1 second.

3. After dialing your handwritten data, dial # to indicate you are done with that ROW. If you enter 8 digits of data in a ROW, the # isn’t needed.

4. Review the programming by dialing the digits in the “To review” column. Note that the display shows a occurred -- redo that ROW.

as i and blanks as ‘. If you hear a beep and see ’, an error has

Highlighted digit

Hold this key down for at least one full second

ROW 0 -

ROW 1 -

ROW 2 -

ROW 3 -

ROW 4 -

ROW 7 -

Dial:

0 5

1 5

2 5

3 5

4 5

7 1

Record any Page Messages on PAGES 1-9 BEFORE

ROW 6 -

ROW 5 -

recording the following two messages:

Dial:

6 1

Dial:

5 1

Field 1 Field 2 Field 3

________________________

Record your Main Greeting: talk into the ADMIN phone; hang up when done.

To review:

0 7

1 7

2 7

3 7

4 7

7 0

Record the Transfer Msg & hang up.

Record the BDA Message & hang up.

6 0

5 0

To program the ROWS on this PAGE, dial as shown for each ROW.

Highlighted digit

Hold this key down for at least one full second

Field 1 Field 2 Field 3

ROW 0 -

ROW 1 -

ROW 2 -

ROW 3 -

ROW 4 -

Dial:

0 5

1 5

2 5

3 5

4 5

________________________

To review:

0 7

1 7

2 7

3 7

4 7

Programming Log for Optional Features

Appendix B in the manual describes optional features used to customize CallExtend. If you program any of these features, record your programming in the following ROW instead of Questions 1-3 in this Programming Log. Fill in the other fields as indicated in Appendix B of the manual, and use the default values shown for any blank fields. To program, dial as shown on the ADMIN phone:

PAGE 0, ROW 0:

1 2 3 4 5 6 7 8

Dial:

in the ROW 0 shown on the PAGE 0 Programming Log. Fill in Fields 1-3 from

Field Numbers

0 0 0 0 0

Default values

PAGE 1 Programming Log

PAGE 2 Programming Log

To program the ROWS on this PAGE, follow these steps:

1. Go off-hook on the ADMIN phone.

will show on the display.

2. Dial the digits shown for each ROW you filled in when answering the Application Questions. Hold down the command digit (highlighted in gray) for at least 1 second.

3. After dialing your handwritten data, dial # to indicate you are done with that ROW. If you enter 8 digits of data in a ROW, the # isn’t needed.

4. Review the programming by dialing the digits in the “To review” column. Note that the display shows a occurred -- redo that ROW.

as i and blanks as ‘. If you hear a beep and see ’, an error has

highlighted digit

Hold this key down for at least one full second

ROW 0 -

ROW 1 -

ROW 2 -

ROW 3 -

ROW 4 -

ROW 5 -

ROW 6 -

ROW 7 -

ROW 8 -

ROW 9 -

Dial:

To enter data & record speech:

0 5

1 5

2 5

3 5

4 5

5 5

6 5

7 1

8 5

9 5

________________________

To Record a Page Message, speak into the ADMIN phone; hang up when done.

________________________

To review:

0 7

1 7

2 7

3 7

4 7

5 7

6 7

7 0

8 7

9 7

To program the ROWS on this PAGE, follow these steps:

1. Go off-hook on the ADMIN phone.

will show on the display.

2. Dial the digits shown for each ROW you filled in when answering the Application Questions. Hold down the command digit (highlighted in gray) for at least 1 second.

3. After dialing your handwritten data, dial # to indicate you are done with that ROW. If you enter 8 digits of data in a ROW, the # isn’t needed.

4. Review the programming by dialing the digits in the “To review” column. Note that the display shows a occurred -- redo that ROW.

as i and blanks as ‘. If you hear a beep and see ’, an error has

highlighted digit

Hold this key down for at least one full second

ROW 0 -

ROW 1 -

ROW 2 -

ROW 3 -

ROW 4 -

ROW 5 -

ROW 6 -

ROW 7 -

ROW 8 -

ROW 9 -

Dial:

To enter data & record speech:

0 5

1 5

2 5

3 5

4 5

5 5

6 5

7 1

8 5

9 5

________________________

To Record a Page Message, speak into the ADMIN phone; hang up when done.

________________________

To review:

0 7

1 7

2 7

3 7

4 7

5 7

6 7

7 0

8 7

9 7
