MODEL NO.: V460H1
SUFFIX: PS1
Customer:
PRODUCT SPECIFICATION
ϭʳ Tentative Specification ϭʳ Preliminary Specification Ϯʳ Approval Specification
APPROVED BY SIGNATURE
Name / Title
Note
Please return 1 copy for your confirmation with your signature and comments.
Approved By Checked By Prepared By
Chao-Chun Chung Ken wu Edwin
Version 2.0 1 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
PRODUCT SPECIFICATION
CONTENTS
1. GENERAL DESCRIPTION ...........................................................................................................................................4
1.1 OVERVIEW .......................................................................................................................................................... 4
1.2 FEATURES........................................................................................................................................................... 4
1.3 APPLICATION...................................................................................................................................................... 4
1.4 GENERAL SPECIFICATI0NS.............................................................................................................................. 4
2. ABSOLUTE MAXIMUM RATINGS............................................................................................................................... 5
2.1 ABSOLUTE RATINGS OF ENVIRONMENT ....................................................................................................... 5
2.2 PACKAGE STORAGE ......................................................................................................................................... 6
2.3 ELECTRICAL ABSOLUTE RATINGS ................................................................................................................. 6
3. ELECTRICAL CHARACTERISTICS............................................................................................................................ 7
3.1 TFT LCD MODULE .............................................................................................................................................. 7
3.2 BACKLIGHT CONVERTER UNIT .........................................................................................................................
4. BLOCK DIAGRAM OF INTERFACE..........................................................................................................................10
4.1 TFT LCD MODULE ............................................................................................................................................ 10
5.1 TFT LCD MODULE .............................................................................................................................................11
5.2 BLOCK DIAGRAM OF INTERFACE................................................................................................................. 16
5.3 LVDS INTERFACE............................................................................................................................................. 19
5.4 COLOR DATA INPUT ASSIGNMENT ............................................................................................................... 20
5.5 C5.5 FLICKER (Vcom) ADJUSTMENT ............................................................................................................ 19
6. INTERFACE TIMING ..................................................................................................................................................23
6.1 INPUT SIGNAL TIMING SPECIFICATIONS ..................................................................................................... 23
6.2 POWER ON/OFF SEQUENCE .......................................................................................................................... 27
7. OPTICAL CHARACTERISTICS................................................................................................................................. 29
7.1 TEST CONDITIONS........................................................................................................................................... 29
7.2 OPTICAL SPECIFICATIONS.................................................................................................................................
8. DEFINITION OF LABELS .......................................................................................................................................... 33
8.1 CMI MODULE LABEL ....................................................................................................................................... 33
9. PACKAGING ..................................................................................................................................................................
9.1 PACKING SPECIFICATIONS ................................................................................................................................
9.2 PACKING METHOD...............................................................................................................................................
10. INTERNATIONAL STANDARD ................................................................................................................................ 36
10.1 SAFETY.............................................................................................................................................................. 36
10.2 EMC .................................................................................................................................................................... 36
11. PRECAUTIONS ........................................................................................................................................................37
11.1 ASSEMBLY AND HANDLING PRECAUTIONS .............................................................................................. 37
11.2 SAFETY PRECAUTIONS ................................................................................................................................37
12. MECHANICAL CHARACTERISTICS ......................................................................................................................38
Version 0.0 2 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
PRODUCT SPECIFICATION
REVISION HISTORY
Version Date Page(New) Section Description
Ver. 2.0 April. 12, 2011 All All The approval specification was first issued.
Version 0.0 3 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
PRODUCT SPECIFICATION
1. GENERAL DESCRIPTION
1.1 OVERVIEW
V460H1- LS1 is a 46” TFT Liquid Crystal Display module with 4ch-LVDS interface. This module supports
1920 x 1080 Full HDTV format and can display 1.07G colors ( 8-bit+ FRC).
1.2 FEATURES
- Faster response time (Gray to gray average 6.0 ms)
- High color saturation NTSC 72% (72%)
- Ultra wide viewing angle: 176(H)/176(V) (CR≥20) with Super MVA technology
- DE (Data Enable) only mode
- LVDS (Low Voltage Differential Signaling) interface
- Low color shift function
- RoHs compliance
1.3 APPLICATION
- TFT LCD TVs
- Multi-Media Display
1.4 GENERAL SPECIFICATI0NS
Item Specification Unit Note Active Area 1018.08 (H) x 572.67 (V) (46" diagonal) mm Bezel Opening Area 1024.48 (H) x 578.67 (V) mm Driver Element a-si TFT active matrix - Pixel Number 1920 x R.G.B. x 1080 pixel Pixel Pitch (Sub Pixel) 0.1805 (H) x 0.5405 (V) mm Pixel Arrangement RGB vertical stripe - Display Colors 1.07G color Display Operation Mode Transmissive mode / Normally Black -
Surface Treatment
Note (1) Please refer to the attached drawings in chapter 9 for more information about the front and back outlines.
Note (2) Please refer sec 3.1 and 3.2 for more information of Power consumption
Note (3) The spec. of the surface treatment is temporarily for this phase. CMI reserves the rights to change this feature.
Anti-Glare Coating (Haze 11%)
Hard Coating (3H)
-
(1)
Version 0.0 4 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
PRODUCT SPECIFICATION
2. ABSOLUTE MAXIMUM RATINGS
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
Item Symbol
Storage Temperature TST -20 +60 ºC (1) Operating Ambient Temperature T Shock (Non-Operating) S Vibration (Non-Operating) V
Note (1) Temperature and relative humidity range is shown in the figure below.
(a) 90 %RH Max. (Ta Љ 40 ºC).
(b) Wet-bulb temperature should be 39 ºC Max. (Ta > 40 ºC).
(c) No condensation.
Note (2) The maximum operating temperature is based on the test condition that the surface temperature of
display area is less than or equal to 65 ºC with LCD module alone in a temperature controlled chamber. Thermal
management should be considered in final product design to prevent the surface temperature of display area
from being over 65 ºC. The range of operating temperature may degrade in case of improper thermal
OP
- 35 G (3), (5)
NOP
- 1.0 G (4), (5)
NOP
Min. Max.
Value
0 50 ºC (1), (2)
Unit Note
management in final product design.
Note (3) 11 ms, half sine wave, 1 time for ± X, ± Y, ± Z.
Note (4) 10 ~ 200 Hz, 10 min, 1 time each X, Y, Z.
Note (5) At testing Vibration and Shock, the fixture in holding the module has to be hard and rigid enough
so that the module would not be twisted or bent by the fixture.
Relative Humidity (%RH)
100 90
80
60
Operating Range
40
20
10
Storage Range
80 60 -20 40 0 20 -40
Temperature (ºC)
Version 0.0 5 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
PRODUCT SPECIFICATION
2.2 PACKAGE STORAGE
When storing modules as spares for a long time, the following precaution is necessary.
(a) Do not leave the module in high temperature, and high humidity for a long time. It is highly recommended to
store the module with temperature from 0 to 35 at normal humidity without condensation.к
(b) The module shall be stored in dark place. Do not store the TFT-LCD module in direct sunlight or fluorescent
light.
2.3 ELECTRICAL ABSOLUTE RATINGS
2.3.1 TFT LCD MODULE
Item Symbol
Power Supply Voltage Vcc -0.3 13.5 V Input Signal Voltage VIN -0.3 3.6 V
Min. Max.
Value
Unit Note
2.3.2 BACKLIGHT UNIT
Item Symbol
Light Bar Voltage VW Ta = 25 к - - 63 V
Converter Input Voltage VBL - 0 - 30 V
Control Signal Level - - -0.3 - 7 V
Note (1) Permanent damage to the device may occur if maximum values are exceeded. Functional operation
Tes t
Condition
Min. Type Max. Unit Note
DC
should be restricted to the conditions described under normal operating conditions.
Note (2) No moisture condensation or freezing.
Note (3) The control signals include On/Off Control.
Version 0.0 6 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
PRODUCT SPECIFICATION
3. ELECTRICAL CHARACTERISTICS
3.1 TFT LCD MODULE
(Ta = 25 ± 2 ºC)
Value
Parameter Symbol
Min. Typ. Max.
Power Supply Voltage VCC 10.8 12 13.2 V (1)
Rush Current I
White Pattern
- - 4.8 A (2)
RUSH
-
7.8 9.24 W
Power
Horizontal Stripe
-
14.4 18 W
Consumption
Power
Supply
Black Pattern
White Pattern
Horizontal Stripe
-
-
-
6.6 7.8 W
- 0.65 0.77 A
- 1.2 1.5 A
Unit Note
(3)
Current
LVDS
interface
Black Pattern
Differential Input High Threshold Voltage
Differential Input Low Threshold Voltage
-
V
+100 - - mV
LVTH
V
- - -100 mV
LVTL
- 0.55 0.65 A
Common Input Voltage VCM 1.0 1.2 1.4 V
Differential input voltage
(single-end)
Terminating Resistor R
|V
| 200 - 600 mV
ID
- 100 - ohm
T
Input High Threshold Voltage VIH 2.7 - 3.3 V CMOS
interface
Input Low Threshold Voltage V
0 - 0.7 V
IL
Note (1) The module should be always operated within the above ranges.
Note (2) Measurement condition:
(4)
Version 0.0 7 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
PRODUCT SPECIFICATION
Vcc rising time is 470us
Vcc
0.9Vcc
0.1Vcc
GND
470us
Note (3) The specified power consumption and power supply current is under the conditions at Vcc = 12 V, Ta =
25 ± 2 ºC, f
= 120 Hz, whereas a power dissipation check pattern below is displayed.
v
Version 0.0 8 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
a. White Pattern
Active Area
c. Horizontal Pattern
PRODUCT SPECIFICATION
b. Black Pattern
Active Area
Note (4) The LVDS input characteristics are as follows:
Version 0.0 9 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
4. BLOCK DIAGRAM OF INTERFACE
4.1 TFT LCD MODULE
CNF2: FI-RE41S-HF,JAE,
CH3_0(+/-) CH3_1(+/-) CH3_2(+/-) CH3_3(+/-) CH3_4(+/-) CH3_CLK(+/-)
CH4_0(+/-) CH4_1(+/-) CH4_2(+/-) CH4_3(+/-) CH4_4(+/-)
+
CH1_0(+/-) CH1_1(+/-) CH1_2(+/-) CH1_3(+/-) CH1_4(+/-) CH1_CLK(+/-)
CH2_0(+/-) CH2_1(+/-) CH2_2(+/-) CH2_3(+/-) CH2_4(+/-) CH2_CLK(+/-)
-
INPUT CONNECTOR
or equivalent
TIMING
CONTROLLER
CNF1: FI-RE51S-HF,JAE,
INPUT CONNECTOR
or equivalent
DC/DC CONVERTER
& REFERENCE
VOLTAGE
PRODUCT SPECIFICATION
SCAN DRIVER
TFT LCD PANEL
(1920x3x1080)
DATA DRIVER
SELLVDS
2D/3D
LR
LD_EN
VCC GND
L/R_O
Version 0.0 10 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
PRODUCT SPECIFICATION
5. INTERFACE PIN CONNECTION
5.1 TFT LCD MODULE
CNF1 Connector Pin Assignment: (FI-RE51S-HF(JAE) or equivalent)
Pin Name Description Note
1 N.C. No Connection
2 N.C. No Connection
3 N.C. No Connection
4 N.C. No Connection
5 L/R_O Output signal for Left Right Glasses control
6 N.C. No Connection (1)
7 SELLVDS LVDS Data Format Selection (2)(6)
8 N.C. No Connection
(1)
ʻˌʼ
9 N.C. No Connection
10 N.C. No Connection
11 GND Ground
12 CH1[0]- First pixel Negative LVDS differential data input. Pair 0
13 CH1[0]+ First pixel Positive LVDS differential data input. Pair 0
14 CH1[1]- First pixel Negative LVDS differential data input. Pair 1
15 CH1[1]+ First pixel Positive LVDS differential data input. Pair 1
16 CH1[2]- First pixel Negative LVDS differential data input. Pair l 2
17 CH1[2]+ First pixel Positive LVDS differential data input. Pair 2
18 GND Ground
19 CH1CLK- First pixel Negative LVDS differential clock input.
20 CH1CLK+ First pixel Positive LVDS differential clock input.
21 GND Ground
22 CH1[3]- First pixel Negative LVDS differential data input. Pair 3
(1)
23 CH1[3]+ First pixel Positive LVDS differential data input. Pair 3
24 CH1[4]- First pixel Negative LVDS differential data input. Pair 4
25 CH1[4]+ First pixel Positive LVDS differential data input. Pair 4
26 2D/3D Input signal for 2D/3D Mode Selection (3)(7)
27 L/R Input signal for Left Right eye frame synchronous (4)(7)
Version 0.0 11 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
28 CH2[0]- Second pixel Negative LVDS differential data input. Pair 0
29 CH2[0]+ Second pixel Positive LVDS differential data input. Pair 0
30 CH2[1]- Second pixel Negative LVDS differential data input. Pair 1
31 CH2[1]+ Second pixel Positive LVDS differential data input. Pair 1
32 CH2[2]- Second pixel Negative LVDS differential data input. Pair 2
33 CH2[2]+ Second pixel Positive LVDS differential data input. Pair 2
34 GND Ground
35 CH2CLK- Second pixel Negative LVDS differential clock input.
36 CH2CLK+ Second pixel Positive LVDS differential clock input.
37 GND Ground
38 CH2[3]- Second pixel Negative LVDS differential data input. Pair 3
PRODUCT SPECIFICATION
39 CH2[3]+ Second pixel Positive LVDS differential data input. Pair 3
40 CH2[4]- Second pixel Negative LVDS differential data input. Pair 4
41 CH2[4]+ Second pixel Positive LVDS differential data input. Pair 4
42 LD_EN Input signal for Local Dimming Enable (5)(7)
43 N.C. No Connection (1)
44 GND Ground
45 GND Ground
46 GND Ground
47 N.C. No Connection (1)
48 VCC +12V power supply
49 VCC +12V power supply
50 VCC +12V power supply
51 VCC +12V power supply
Version 0.0 12 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
CNF2 Connector Pin Assignment (FI-RE41S-HF (JAE) or equivalent)
Pin Name Description
1 N.C. No Connection
2 N.C. No Connection
3 N.C. No Connection
4 N.C. No Connection
5 N.C. No Connection
6 N.C. No Connection
7 N.C. No Connection
8 N.C. No Connection
9 GND Ground
PRODUCT SPECIFICATION
ˡ˸ʳ
ʻ˄ʼʳ
ʳ
10 CH3[0]- Third pixel Negative LVDS differential data input. Pair 0
11 CH3[0]+ Third pixel Positive LVDS differential data input. Pair 0
12 CH3[1]- Third pixel Negative LVDS differential data input. Pair 1
13 CH3[1]+ Third pixel Positive LVDS differential data input. Pair 1
14 CH3[2]- Third pixel Negative LVDS differential data input. Pair 2
15 CH3[2]+ Third pixel Positive LVDS differential data input. Pair 2
16 GND Ground
17 CH3CLK- Third pixel Negative LVDS differential clock input.
18 CH3CLK+ Third pixel Positive LVDS differential clock input.
19 GND Ground
20 CH3[3]- Third pixel Negative LVDS differential data input. Pair 3
21 CH3[3]+ Third pixel Positive LVDS differential data input. Pair 3
22 CH3[4]- Third pixel Negative LVDS differential data input. Pair 4
23 CH3[4]+ Third pixel Positive LVDS differential data input. Pair 4
ʳ
ʳ
ʳ
ʳ
ʳ
ʳ
ʳ
ʳ
ʳ
ʳ
ʳ
ʳ
ʳ
ʳ
24 GND Ground
25 GND Ground
26 CH4[0]- Fourth pixel Negative LVDS differential data input. Pair 0
27 CH4[0]+ Fourth pixel Positive LVDS differential data input. Pair 0
28 CH4[1]- Fourth pixel Negative LVDS differential data input. Pair 1
29 CH4[1]+ Fourth pixel Positive LVDS differential data input. Pair 1
ʳ
ʳ
ʳ
ʳ
ʳ
ʳ
Version 0.0 13 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
L
www.panelook.com
30 CH4[2]- Fourth pixel Negative LVDS differential data input. Pair 2
31 CH4[2]+ Fourth pixel Positive LVDS differential data input. Pair 2
32 GND Ground
33 CH4CLK- Fourth pixel Negative LVDS differential clock input.
34 CH4CLK+ Fourth pixel Positive LVDS differential clock input.
35 GND Ground
36 CH4[3]- Fourth pixel Negative LVDS differential data input. Pair 3
37 CH4[3]+ Fourth pixel Positive LVDS differential data input. Pair 3
38 CH4[4]- Fourth pixel Negative LVDS differential data input. Pair 4
39 CH4[4]+ Fourth pixel Positive LVDS differential data input. Pair 4
40 GND Ground
PRODUCT SPECIFICATION
ʳ
ʳ
ʳ
ʳ
ʳ
ʳ
ʳ
ʳ
41 GND Ground
CN6 Connector Pin Assignment (LM123S-010-H-TF1-3 (UNE) or equivalent)
1 N.C. No Connection
2 N.C. No Connection
3 N.C. No Connection
4 GND Ground
5 N.C. No Connection
6 L/R_O Output signal for Left Right Glasses control
7 N.C. No Connection
8 N.C. No Connection
9 N.C. No Connection
10 N.C. No Connection
Note (1) Reserved for internal use. Please leave it open.
ʻ˄ʼ
ʻ˄ʼ
ʻˌʼ
ʻ˄ʼ
Note (2) LVDS format selection.
L= Connect to GND , H=Connect to +3.3V or Open
SELLVDS Note
JEDIA Format
H or Open VESA Format
Note (3) 2D/3D mode selection
L= Connect to GND or Open, H=Connect to +3.3V
Version 0.0 14 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
L
g
L
www.panelook.com
2D/3D Note
or Open 2D Mode
H 3D Mode
Note (4) Input signal for Left Right eye frame synchronous
V
Note (5) Local dimming enable selection
=0~0.8 V, VIH=2.0~3.3 V
IL
L/R Note
LRi
H Left synchronous signal
L= Connect to GND or Open, H=Connect to +3.3V
LD_EN Note
or Open Local Dimming Disable
H Local Dimming Enable
ht synchronous signal
PRODUCT SPECIFICATION
Note (6) SELLVDS signal pin connected to the LCM side has the following diagram.
R1 in the system side should be less than 1K Ohm. (R1 < 1K Ohm)
Version 0.0 15 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
g
www.panelook.com
Note (7) 2D/3D, L/R and LD_EN signal pin connected to the LCM side has the following diagram.
R1 in the system side should be less than 1K Ohm. (R1 < 1K Ohm)
PRODUCT SPECIFICATION
Note (8) LVDS 4-port Data Mapping
Port Channel of LVDS Data Stream
1st Port First Pixel 1, 5, 9, ……1913, 1917
2nd Port Second Pixel 2, 6, 10, ….1914, 1918
3rd Port Third Pixel 3, 7, 11, ….1915, 1919
4th Port Fourth Pixel 4, 8, 12, ….1916, 1920
Note (9) The definition of L/R_O signal as follows
L= 0V , H= +3.3V
L/R_O Note
LRi
H Left glass turn on
ht glass turn on
5.2 BLOCK DIAGRAM OF INTERFACE
Version 0.0 16 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
PRODUCT SPECIFICATION
Version 0.0 17 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
AR0~AR9: First pixel R data
AG0~AG9: First pixel G data
AB0~AB9: First pixel B data
BR0~BR9: Second pixel R data
BG0~BG9: Second pixel G data
BB0~BB9: Second pixel B data
DE: Data enable signal
DCLK: Data clock signal
The third and fourth pixel are followed the same rules.
CR0~CR9: Third pixel R data
CG0~CG9: Third pixel G data
CB0~CB9: Third pixel B data
DR0~DR9: Fourth pixel R data
PRODUCT SPECIFICATION
DG0~DG9: Fourth pixel G data
DB0~DB9: Fourth pixel B data
Note (1) A ~ D channel are first, second, third and fourth pixel respectively.
Note (2) The system must have the transmitter to drive the module.
Note (3) LVDS cable impedance shall be 50 ohms per signal line or about 100 ohms per twist-pair line when it is
used differentially.
Version 0.0 18 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
5.3 LVDS INTERFACE
JEIDA Format : SELLVDS = L
VESA Format : SELLVDS = H or Open
VESA Format
AR 0P
AR 0N
AR 1P
AR 1N
AR 2P
AR 2N
AR0
AG1
AB2
AG0 AR5
AB1
DE VS HS AB5 AB4 AB3 AB2
AB0 AG5 AG4 AG3 AG2 AG1
PRODUCT SPECIFICATION
Current Cycle
AR4 AR3 AR2 AR1 AR0
AG0
AB1
DE
AR 3P
AR 3N
AR 4P AR 4N
JEIDA Format
AR 0P
AR 0N
AR 1P
AR 1N
AR 2P
AR 2N
AR 3P
AR 3N
AR 4P AR 4N
AR2
AR6
AR4
AG5
AB6
REV AB7 AB6 AG7 AG6 AR7 AR6
REV AB9 AB8 AG9 AG8 AR9 AR8AR8 REV
AG4 AR7
AB5
DE VS HS AB7 AB6AB9 AB8
REV AB3 AB2 AG3 AG2 AR3 AR2
REV AB1 AB0 AG1 AG0 AR1 AR0AR0 REV
AB4 AG7 AG6 AG5AG9 AG8
AR6 AR5 AR4AR9 AR8
REV
AG4
AB5
DE
REV
AR0~AR9: First Pixel R Data (9; MSB, 0; LSB)
AG0~AG9: First Pixel G Data (9; MSB, 0; LSB)
AB0~AB9: First Pixel B Data (9; MSB, 0; LSB)
DCLK : Data clock signal
DE : Data enable signal
RSV: Reserved
Version 0.0 19 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
PRODUCT SPECIFICATION
5.4 COLOR DATA INPUT ASSIGNMENT
The brightness of each primary color (red, green and blue) is based on the 10-bit gray scale data input for the
color. The higher the binary input, the brighter the color. The table below provides the assignment of the color
versus data input.
Data Signal
Basic
Colors
Color
Black
Red
Green
Blue
Cyan
Magenta
Yellow
R9 R8 R7 R6 R5 R4 R3 R2 R1 R0 G9 G8 G7 G6 G5 G4 G3 G2 G1 G0 B9 B8 B7 B6 B5 B4 B3 B2 B1 B0
0
0
1
1
0
0
0
0
0
0
1
1
1
1
Red Green Blue
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
1
1
1
1
1
1
1
1
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
1
1
1
1
1
1
1
1
1
1
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
1
0
0
0
0
0
0
0
0
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
0
0
0
0
0
0
0
0
0
0
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
1
1
1
1
1
1
1
1
1
1
1
1
0
0
0
0
Gray
Scale
Of
Red
Gray
Scale
Of
Green
White
Red (0) / Dark
Red (1)
Red (2)
:
:
Red (1021)
Red (1022)
Red (1023)
Green (0) / Dark
Green (1)
Green (2)
:
:
Green (1021)
Green (1022)
Green (1023)
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
1
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
1
0
0
0
0
0
0
0
0
0
0
0
0
0
0
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
;
:
:
1
1
1
1
1
1
1
1
0
1
0
0
0
0
0
0
0
0
0
0
0
0
0
1
1
1
1
1
1
1
1
1
0
0
0
0
0
0
0
0
0
0
0
0
0
0
1
1
1
1
1
1
1
1
1
1
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
1
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
1
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
0
0
0
1
0
1
1
1
1
1
1
1
1
0
0
0
0
0
0
0
0
0
0
0
0
0
0
1
1
1
1
1
1
1
1
1
0
0
0
0
0
0
0
0
0
0
0
0
0
1
1
1
1
1
1
1
1
1
1
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
:
:
0
0
0
0
0
0
:
:
0
0
0
0
0
0
0
:
:
:
:
:
:
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
:
:
:
:
:
:
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
:
:
:
:
:
:
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
:
:
:
:
:
:
0
0
0
0
0
0
0
0
0
Gray
Scale
Of
Blue
Blue (0) / Dark
Blue (1)
Blue (2)
:
:
Blue (1021)
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
1
1
1
0
0
0
0
0
0
0
0
:
:
:
:
1
1
0
0
0
0
0
0
0
:
:
:
:
:
:
1
1
1
Version 0.0 20 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
0
0
0
1
1
0
:
:
:
:
0
1
Global LCD Panel Exchange Center
www.panelook.com
Blue (1022)
Blue (1023)
Note (1) 0: Low Level Voltage, 1: High Level Voltage
00000000000000000000000000000000000000001111111111111111110
PRODUCT SPECIFICATION
1
Version 0.0 21 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
5.5 FLICKER (Vcom) ADJUSTMENT
(1) Adjustment Pattern:
Flick pattern was shown as below. If customer need below pattern, please directly contact with
Account FAE.
. Frame N Frame N+1
PRODUCT SPECIFICATION
!
(2) Adjustment method: (VR)
Flicker should be adjusted by turning the volume for flicker adjustment by the ceramic driver. It is
adjusted to the point with least flickering of the center screen. After making it surely overrun at
once, it should be adjusted to the optimum point.
(3) Adjustment method: (Digital V-com)
Programmable memory IC is used for Digital V-com adjustment in this model. CMI provide Auto
Vcom tools to adjust Digital V-com.The detail connection and setting instruction, please directly
contact with Account FAE or refer CMI Auto V-com adjustment OI. Below items is suggested to be
ready before Digital V-com adjustment in customer LCM line.
a. USB Sensor Board.
b. Programmable software.
Version 0.0 22 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
PRODUCT SPECIFICATION
6. INTERFACE TIMING
6.1 INPUT SIGNAL TIMING SPECIFICATIONS
(Ta = 25 ± 2 ºC)
The input signal timing specifications are shown as the following table and timing diagram.
Signal Item Symbol Min. Typ. Max. Unit Note
F
Frequency
Input cycle to
LVDS
cycle jitter
Receiver
Spread spectrum
Clock
modulation range
Spread spectrum
modulation frequency
clkin
60 74.25 80 MHz
(=1/TC)
T
- - 200 ps (3)
rcl
F
clkin_mod
F
F
SSM
-2% - F
clkin
- - 200 KHz
+2% MHz
clkin
(4)
LVDS
Setup Time Tlvsu 600 - - ps
Receiver
Data
Hold Time Tlvhd 600 - - ps
6.1.1 Timing spec for Frame Rate = 100Hz
Signal Item Symbol Min. Typ. Max. Unit Note
2D mode Fr5 94 100 106 Hz
Frame rate
3D mode F
Total Tv 1090 1350 1395 Th Tv=Tvd+Tvb
Ver t ical
Active
Display
Term
2D Mode
3D Mdoe
Display Tvd 1080 1080 1080 Th
Blank Tvb 10 270 315 Th
Total Tv 1350 Th (6)(8)
Display Tvd 1080 Th (6)
Blank Tvb 270 Th (6)(8)
(5)
100 100 100 Hz (7)
r5
Ё
Ё
Horizontal
Active
2D Mode
Total Th 520 550 670 Tc Th=Thd+Thb
Display Thd 480 480 480 Tc
Ё
Display
Term
3D Mdoe
Blank Thb 40 70 190 Tc
Total Th 520 550 670 Tc Th=Thd+Thb
Display Thd 480 480 480 Tc
Ё
Ё
Version 0.0 23 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Blank Thb 40 70 190 Tc
6.1.2 Timing spec for Frame Rate = 120Hz
Signal Item Symbol Min. Typ. Max. Unit Note
2D mode Fr6 114 120 126 Hz
Frame rate
3D mode F
120 120 120 Hz (7)
r6
Total Tv 1090 1125 1395 Th Tv=Tvd+Tvb
Ver t ical
Active
Display
Term
2D Mode
3D Mdoe
Display Tvd 1080 1080 1080 Th
Blank Tvb 10 45 315 Th
Total Tv 1125 Th (6)(8)
Display Tvd 1080 Th (6)
Blank Tvb 45 Th (6)(8)
PRODUCT SPECIFICATION
Ё
Ё
Ё
Total Th 520 550 670 Tc Th=Thd+Thb
Horizontal
Active
Display
Term
2D Mode
3D Mdoe
Display Thd 480 480 480 Tc
Blank Thb 40 70 190 Tc
Total Th 520 550 670 Tc Th=Thd+Thb
Display Thd 480 480 480 Tc
Blank Thb 40 70 190 Tc
Ё
Ё
Ё
Ё
Note (1) Since the module is operated in DE only mode, Hsync and Vsync input signals should be set to low
logic level. Otherwise, this module would operate abnormally.
Note (2) Please make sure the range of pixel clock has follow the below equation:
F
clkin(max)
F
r
5
ʳ
ʳ
ʳ
ʳ
Њ F
r
6
Ѽ Tv Ѽ Th
Ѽ Tv Ѽ Th Њ F
clkin(min)
ʳ
ʳ
ʳ
ʳ
ʳ
ʳ
Version 0.0 24 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
ʳ
ʳ
ʳ
INPUT SIGNAL TIMING DIAGRAM
T
vd
DE
T
h
PRODUCT SPECIFICATION
T
v
T
vb
DCLK
T
hd
DE
DAT
Note (3) The input clock cycle-to-cycle jitter is defined as below figures. Trcl = I T1 – TI
Valid display data ( 480 clocks)
Version 0.0 25 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Note (4) The SSCG (Spread spectrum clock generator) is defined as below figures.
Note (5) The LVDS timing diagram and setup/hold time is defined and showing as the following figures.
PRODUCT SPECIFICATION
LVDS RECEIVER INTERFACE TIMING DIAGRAM
Tc
RXCLK+/-
RXn+/-
Tlvsu
Tlvhd
1T
14
Note (6) Please fix the Vertical timing (Vertical Total =1350 / Display =1080 / Blank = 270) in 100Hz 3D mode
3T
14
5T
14
7T
14
9T
14
11T
14
13T
14
and Vertical timing (Vertical Total =1125 / Display =1080 / Blank = 45) in 120Hz 3D mode.
Note (7) In 3D mode, the set up Fr5 and Fr6 in Typ. ±3 Hz. In order to ensure that the electric function performance
to avoid no display symptom.(Except picture quality symptom.)
Note (8) In 3D mode, the set up Tv and Tvb in Typ. ±30. In order to ensure that the electric function performance to
avoid no display symptom.(Except picture quality symptom.)
Version 0.0 26 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
PRODUCT SPECIFICATION
6.2 POWER ON/OFF SEQUENCE
6.2.1 POWER ON/OFF SEQUENCE (Ta = 25 ± 2 ºC)
To prevent a latch-up or DC operation of LCD module, the power on/off sequence should be as the diagram
below.
0.1V
cc
T
4
0.5ЉЉЉЉT1ЉЉЉЉ10ms
0ЉЉЉЉT
500ms ЉЉЉЉT
0ЉЉЉЉT
2
ЉЉЉЉ50ms
3
ЉЉЉЉ50ms
0.1V
0V
4
CC
T
T
1
T
2
3
VA L I D
LVDS Signals
0ЉЉЉЉT7ЉЉЉЉT
0ЉЉЉЉT8ЉЉЉЉT
0V
Power On
2
3
T
7
Power Off
T
8
Option Signals
(SELLVDS,2D/3D
L/R,LD_EN
Backlight (Recommended)
500msЉЉЉЉT
100ms
ЉЉЉЉ
T6
)
5
50%
T
5
50%
6
T
Power ON/OFF Sequence
Version 0.0 27 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
PRODUCT SPECIFICATION
6.2.2 2D to 3D SIGNAL SEQUENCE WITHOUT VCC TURN OFF AND TURN ON
0.9V
CC
VCC
0.1V
CC
T
1
T
2
0.5ЉЉЉЉT1ЉЉЉЉ10ms
0ЉЉЉЉT
2
ЉЉЉЉ50ms
0V
Scaler send
LVDS Signals
0ЉЉЉЉT7ЉЉЉЉT2
10msЉЉЉЉT10
0V
Power On
T
7
Black Pattern
T
10
2D/3D
0ЉЉЉЉT9ЉЉЉЉ10ms
10ЉЉЉЉT12ЉЉЉЉ20ms
9
T
T
12
Scaler Black Pattern Insertion
T
Backlight ON/OFF
500msЉЉЉЉT
500msЉЉЉЉT11
5
T
5
Note (1) The supply voltage of the external system for the module input should follow the definition of Vcc.
Note (2) Apply the LED voltage within the LCD operation range. When the backlight turns on before the LCD
operation or the LCD turns off before the backlight turns off, the display may momentarily become
abnormal screen.
11
Note (3) In case of Vcc is in off level, please keep the level of input signals on the low or high impedance. If T2<0,
that maybe cause electrical overstress failure.
Note (4) T4 should be measured after the module has been fully discharged between power off and on period.
Note (5) Interface signal shall not be kept at high impedance when the power is on.
Version 0.0 28 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
PRODUCT SPECIFICATION
7. OPTICAL CHARACTERISTICS
7.1 TEST CONDITIONS
Item Symbol Value Unit
Ambient Temperature Ta
Ambient Humidity Ha
Supply Voltage V
Input Signal According to typical value in "3. ELECTRICAL CHARACTERISTICS"
LED Current I
The LCD module should be stabilized at given temperature for 1 hour to avoid abrupt temperature change during
measuring in a windless room.
CC
L
25±2
50±10
12 V
120±7.2
o
C
%RH
mA
Version 0.0 29 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
7.2 OPTICAL SPECIFICATIONS
PRODUCT SPECIFICATION
The relative measurement methods of optical characteristics are shown as below. The
following items should be measured under the test conditions described in 7.1 and stable
environment shown in 7.1.
Item Symbol Condition Min. Typ. Max. Unit Note
0.643
Rcx
ʳ
-
Red
0.322
Color
Chromaticity
Green
Blue
Rcy
Gcx
Gcy
Bcx
Bcy
Wcx
=0°, θY =0°
θ
x
Viewing Angle at
Normal Direction
Standard light source
“C”
ʳ
0.300
ʳ
0.628
0.147
0.066
ʳ
-
ʳ
ʳ
-
˃ˁ˅ˋ˃ʳ
-
-
-
-
-
-
White
Wcy
˃ˁ˅ˌ˃ʳ
-
(0)
Center Transmittance T%
x
- 5.5 - % (1),(6)
=0°, θY =0°
θ
with CMI module
Response Time
ʳ
ʳ
˚˴ʳʳ
˺˴ʳ
ʳʳ
ˀʳ ˉʳ ˄˅ʳ ʳ
(1),(4)
ʳʳ
Note (0) Light source is the standard light source ”C” which is defined by CIE and driving voltage are
based on
suitable gamma voltages. The calculating method is as following:
1. Measure Module’s and BLU’s spectrum at center point. White is without signal input and
R,G,B are with signal input. BLU is supplied by CMO.
2. Calculate cell’s spectrum.
3. Calculate cell’s chromaticity by using the spectrum of standard light source “C”.
Note (1) Light source is the BLU which supplied by CMI and driving voltage are based on suitable
gamma voltages.
Note (2) Definition of Viewing Angle (θx, θy):
Viewing angles are measured by Autronic Conoscope Cono-80
Version 0.0 30 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Normal
θx = θy = 0º
θy-
θX- = 90º
x-
θx−
6 o’clock
θ
y-
= 90º
y-
Note (3) Definition of Contrast Ratio (CR):
PRODUCT SPECIFICATION
θy+
y+
θx+
12 o’clock
direction
x+
θX+ = 90º
The contrast ratio can be calculated by the following expression.
Contrast Ratio (CR) =
L255: Luminance of gray level 255
L 0: Luminance of gray level 0
CR = CR (5), where CR (X) is corresponding to the Contrast Ratio of the point X at the figure in Note (5).
Note (4) Definition of Response Time (TR, TF):
Gray Level 255
100%
90%
Optical
Response
10%
0%
L255 of Luminance Surface
L0 of Luminance Surface
Gray Level 255
Gray Level 0
T
R
T
F
Time
Note (5) Definition of White Variation (δW):
Version 0.0 31 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Measure the luminance of gray level 255 at 5 points
δW = Maximum [L (1), L (2), L (3), L (4), L (5)] / Minimum [L (1), L (2), L (3), L (4), L (5)]
Horizontal Line
D/4 D/2 3D/4
12
W
W/4
W/2
Vertical Line
3W/4
34
PRODUCT SPECIFICATION
D
: Test Point
5
X
X=1 to 5
Active Area
Note (6) Definition of Transmittance (T%) :
Measure the luminance of gray level 255 at center point of LCD module.
Transmittance (T%) =
module LCD of Luminance
100%
unit backligh of Luminance
×
Version 0.0 32 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
PRODUCT SPECIFICATION
8. DEFINITION OF LABELS
8.1 CMI MODULE LABEL
The barcode nameplate is pasted on each module as illustration, and its definitions are as following explanation.
E207943
V460H1 –PS1 Rev. XX
X X X X X X X Y M D L N N N N
(a) Model Name: V460H1-PS1
(b) Revision: Rev. XX, for example: A0, A1… B1, B2… or C1, C2…etc.
MADE IN TAIWAN
GEMN
(c) Serial ID: X X
Serial ID includes the information as below:
(a) Manufactured Date: Year: 2001=1, 2002=2, 2003=3, 2004=4….2010=0, 2011=1, 2012=2....
Day: 1~9, A~Y, for 1
(b) Revision Code: Cover all the change
(c) Serial No.: Manufacturing sequence of product
X X X X X Y M D L N N N N
Month: 1~9, A~C, for Jan. ~ Dec.
Serial No.
Product Line
Year, Month, Date
CMO Internal Use
CMO Internal Use
Revision
CMO Internal Use
st
to 31st, exclude I ,O, and U.
(d) Product Line: 1 -> Line1, 2 -> Line 2, …etc.
Version 0.0 33 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
9. PACKAGING
9.1 PACKING SPECIFICATIONS
(1) 8 LCD TV Panels / 1 Box
(2) Box dimensions :1238 (L) X 842 (W) X 240(H)
(3) Weight : approximately 38Kg (8 panels per box)
9.2 PACKING METHOD
Figures 9-1 and 9-2 are the packing method
PRODUCT SPECIFICATION
Figure.9-1 packing method
Version 0.0 34 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Sea & Land Transportation
PE Sheet
(L625*50*50mm)
(L1850*50*50mm)
Film
PP Belt
Carton Label
(L1260*W870*H140mm)
Figure.9-2 packing method
PRODUCT SPECIFICATION
Air Transportation
PE Sheet
(L625*50*50mm)
(L1350*50*50mm)
Film
PP Belt
Carton Label
(L1260*W870*H140mm)
Version 0.0 35 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
PRODUCT SPECIFICATION
10. INTERNATIONAL STANDARD
10.1 SAFETY
(1) UL 60950-1, UL 60065: Standard for Safety of Information Technology Equipment Including electrical
Business Equipment.
(2) IEC 60950-1:2005, IEC 60065:2001+ A1:2005 ; Standard for Safety of International Electro-technical
Commission.
(3) EN 60950:2006+ A11:2009, EN60065:2002 + A1:2006 + A11:2008; European Committee for Electrotechnical
Standardization (CENELEC), EUROPEAN STANDARD for Safety of Information Technology Equipment
Including Electrical Business Equipment.
10.2 EMC
(1) ANSI C63.4 Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electrical Equipment in
the Range of 9KHZ to 40GHZ. Ϙ American National standards Institute(ANSI)
(2) C.I.S.P.R ϘLimits and Methods of Measurement of Radio Interface Characteristics of Information
Technology Equipment. Ϙ International Special committee on Radio Interference.
(3) EN 55022 ϘLimits and Methods of Measurement of Radio Interface Characteristics of Information
Technology Equipment. ϘEuropean Committee for Electortechnical Standardization.(CENELEC)
Version 0.0 36 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
PRODUCT SPECIFICATION
11. PRECAUTIONS
11.1 ASSEMBLY AND HANDLING PRECAUTIONS
(1) Do not apply rough force such as bending or twisting to the module during assembly.
(2) It is recommended to assemble or to install a module into the user’s system in clean working areas. The
dust and oil may cause electrical short or worsen the polarizer.
(3) Do not apply pressure or impulse to the module to prevent the damage of LCD panel and backlight.
(4) Always follow the correct power-on sequence when the LCD module is turned on. This can prevent the
damage and latch-up of the CMOS LSI chips.
(5) Do not plug in or pull out the I/F connector while the module is in operation.
(6) Do not disassemble the module.
(7) Use a soft dry cloth without chemicals for cleaning, because the surface of polarizer is very soft and
easily scratched.
(8) Moisture can easily penetrate into LCD module and may cause the damage during operation.
(9) High temperature or humidity may deteriorate the performance of LCD module. Please store LCD
modules in the specified storage conditions.
(10) When ambient temperature is lower than 10ºC, the display quality might be reduced.
11.2 SAFETY PRECAUTIONS
(1) The startup voltage of a backlight is over 1000 Volts. It may cause an electrical shock while assembling
with the converter. Do not disassemble the module or insert anything into the backlight unit.
(2) If the liquid crystal material leaks from the panel, it should be kept away from the eyes or mouth. In case
of contact with hands, skin or clothes, it has to be washed away thoroughly with soap.
(3) After the module’s end of life, it is not harmful in case of normal operation and storage.
Version 0.0 37 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
12. MECHANICAL CHARACTERISTICS
PRODUCT SPECIFICATION
࡛ભሽ՗ٝڶૻֆ׹
CHI MEI
Version 0.0 38 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
PRODUCT SPECIFICATION
࡛ભሽ՗ٝڶૻֆ׹
CHI MEI
Version 0.0 39 DateΚΚΚΚ12 April. 2011
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
