1 GENERAL DESCRIPTION
1.1 OVERVIEW
N140B6-L06 is a 14.0” TFT Liquid Crystal Display module with LED Backlight unit and 40 pins LVDS
interface. This module supports 1366 x 768 HD mode and can display 262,144 colors. The optimum
viewing angle is at 6 o’clock direction.
1.2 FEATURES
- Thin and Light weight
- 16:9 HD (1366 x 768 pixels) resolution
- 3.3V LVDS (Low Voltage Differential Signaling) interface with 1 pixel/clock
- Meet RoHS requirement
- LED Backlight
www.panelook.com
Doc No.: 400029639
Issued Date: Aug, 14, 2009
Model No.: N140B6 - L06
Approval
1.3 APPLICATION
- TFT LCD Notebook
1.4 GENERAL SPECIFICATI0NS
Item Specification Unit Note
Active Area 309.40 (H) x 173.95 (V) (14.0” diagonal) mm (1)
Driver Element a-si TFT active matrix - Pixel Number 1366 x R.G.B. x 768 pixel Pixel Pitch 0.2265 (H) x 0.2265 (V) mm Pixel Arrangement RGB vertical stripe - Display Colors 262,144 color Transmissive Mode Normally white - Surface Treatment Hard coating (3H), glare type - -
1.5 MECHANICAL SPECIFICATIONS
Item Min. Typ. Max. Unit Note
Horizontal(H) 319.9 320.4 320.9 mm
Vertical(V) 186.6 187.1 187.6 mm
Module Size
Note (1) Please refer to the attached drawings for more information of front and back outline dimensions.
Vertical(V)
(w/ PCB)
Depth(D) - 3.3 3.6 mm
Weight - 310 325 g
198.1 198.6 199.1 mm
(1)
4 / 29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
Version 2.1
www.panelook.com
Global LCD Panel Exchange Center
A
2 ABSOLUTE MAXIMUM RATINGS
2.1 ABSOLUTE RATINGS OF ENVIRONMENT
Item Symbol
Storage Temperature TST -20 +60 ºC (1)
Operating Ambient Temperature TOP 0 +50 ºC (1), (2)
Shock (Non-Operating) S
Vibration (Non-Operating) V
Note (1) (a) 90 %RH Max. (Ta Љ 40 ºC).
(b) Wet-bulb temperature should be 39 ºC Max. (Ta > 40 ºC).
(c) No condensation.
Note (2) The temperature of panel display surface area should be 0 ºC Min. and 50 ºC Max.
Relative Humidity (%RH)
www.panelook.com
Doc No.: 400029639
Issued Date: Aug, 14, 2009
Model No.: N140B6 - L06
Approval
Value
Min. Max.
- 220/2 G/ms (3), (5)
NOP
- 1.5 G (4), (5)
NOP
Unit Note
100
90
80
60
Operating Range
40
20
10
Storage Range
8060-20 40 0 20 -40
Temperature (ºC)
Note (3) 1 time for ± X, ± Y, ± Z. for Condition (220G / 2ms) is half Sine Wave,.
Note (4) 10 ~ 500 Hz, 30 min/cycle,1cycles for each X, Y, Z axis.
Note (5) At testing Vibration and Shock, the fixture in holding the module has to be hard and rigid
enough so that the module would not be twisted or bent by the fixture.
The fixing condition is shown as below:
t Room Temperature
5 / 29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
Version 2.1
www.panelook.com
Global LCD Panel Exchange Center
2.2 ELECTRICAL ABSOLUTE RATINGS
2.2.1 TFT LCD MODULE
Item Symbol
Power Supply Voltage Vcc -0.3 +4.0 V
Logic Input Voltage VIN -0.3 Vcc+0.3 V
2.2.2 BACKLIGHT UNIT
Item Symbol
LED Light Bar Power Supply Voltage VL -40 28 V
LED Light Bar Power Supply Current IL 0 125 mA
Note (1) Permanent damage to the device may occur if maximum values are exceeded. Function operation
www.panelook.com
Value
Min. Max.
Value
Min. Max.
Unit Note
Doc No.: 400029639
Issued Date: Aug, 14, 2009
Model No.: N140B6 - L06
Approval
(1)
Unit Note
(1), (2)
should be restricted to the conditions described under Normal Operating Conditions.
Note (2) Specified values are for LED (Refer to Section 3.2 for further information).
6 / 29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
Version 2.1
www.panelook.com
Global LCD Panel Exchange Center
3 ELECTRICAL CHARACTERISTICS
3.1 TFT LCD MODULE
Parameter Symbol
Power Supply Voltage Vcc 3.0 3.3 3.6 V Ripple Voltage VRP - 50 mV Rush Current I
Initial Stage Current IIS 1.0 A (2)
Power Supply Current
LVDS Differential Input High Threshold V
LVDS Differential Input Low Threshold V
LVDS Common Mode Voltage VCM 1.125 1.375 V (5)
LVDS Differential Input Voltage |VID| 100 600 mV (5)
Terminating Resistor RT - 100 - Ohm Power per EBL WG P
Note (1) The ambient temperature is Ta = 25 ± 2 ºC.
White - 230 250 mA (3)a
Black
www.panelook.com
Min. Typ. Max.
- 1.5 A (2)
RUSH
lcc
TH(LVDS)
TL(LVDS)
- 1.82 W (4)
EBL
- 320 350 mA (3)b
+100 mV
-100 mV
Value
Doc No.: 400029639
Issued Date: Aug, 14, 2009
Model No.: N140B6 - L06
Approval
Unit Note
(5),
=1.2V
V
CM
(5)
=1.2V
V
CM
Note (2) I
I
: the maximum current when VCC is rising
RUSH
: the maximum current of the first 100ms after power-on
IS
Measurement Conditions: Shown as the following figure. Test pattern: black.
(High to Low)
(Control Signal)
SW
+12V
+3.3V
R1
47K
R2
1K
47K
VR1
C1
1uF
Q1 2SK1475
C2
0.01uF
Q2
2SK1470
FUSE
C3
1uF
Vcc
(LCD Module Input)
VCC
0V
I
RUSH
470us
0.1Vcc
0.9Vcc
+3.3V
100ms
I
IS
ICC
7 / 29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
Version 2.1
www.panelook.com
Global LCD Panel Exchange Center
|
|
|
|
Note (3) The specified power supply current is under the conditions at Vcc = 3.3 V, Ta = 25 ± 2 ºC, fv = 60
Hz, whereas a power dissipation check pattern below is displayed.
www.panelook.com
Doc No.: 400029639
Issued Date: Aug, 14, 2009
Model No.: N140B6 - L06
Approval
a. White Pattern
Active Area
Note (4) The specified power are the sum of LCD panel electronics input power and the converter input
power. Test conditions are as follows.
(a) Vcc = 3.3 V, Ta = 25 ± 2 ºC, f
(b) The pattern used is a black and white 32 x 36 checkerboard, slide #100 from the VESA file
“Flat Panel Display Monitor Setup Patterns”, FPDMSU.ppt.
(c) Luminance: 60 nits.
= 60 Hz,
v
b. Black Pattern
Active Area
Note (5) The parameters of LVDS signals are defined as the following figures.
CM
V
Single Ended
0V
V
Differential
0V
V
VID
VID
8 / 29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
Version 2.1
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Doc No.: 400029639
Issued Date: Aug, 14, 2009
Model No.: N140B6 - L06
Approval
3.2 BACKLIGHT UNIT Ta = 25 ± 2 ºC
Parameter Symbol
LED light bar Power
Supply Voltage
LED light bar Power
Supply Current
22.4 25.6 28 V
V
L
95 100 105 mA
I
L
Min. Typ. Max.
LED Life Time LBL 12,000 - - Hrs (4)
Power Consumption PL 2.128 2.56 2.94 W (3), IL = 100mA
Note (1) LED light bar configuration is shown as below:
VL,I
Light Bar Feedback
Channels
Value
Unit Note
dc
(1), (2)
L
LED
Light Bar
Note (2) For better LED light bar driving quality, it is recommended to utilize the adaptive boost converter with
current balancing function to drive LED light-bar.
Note (3) P
L
= I
LVL
Note (4) The lifetime of LED is defined as the time when it continues to operate under the conditions at
Ta = 25 2
o
C and IL = 20 mA(Per EA) until the brightness becomes Љ 50% of its original value.
9 / 29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
Version 2.1
www.panelook.com
Global LCD Panel Exchange Center
4 BLOCK DIAGRAM
4.1 TFT LCD MODULE
www.panelook.com
Doc No.: 400029639
Issued Date: Aug, 14, 2009
Model No.: N140B6 - L06
Approval
LVDS Display
Data & Clock
Vcc
GND
Data
EDID
CLK
EDID
V
EDID
Converter
Input Signals
INPUT CONNECTOR
LVDS INPUT /
TIMING CONTROLLER
DC/DC CONVERTER &
REFERENCE VOLTAGE
GENERATOR
EDID
EEPROM
LED
CONVERTER
SCAN DRIVER IC
TFT LCD PANEL
(1366x3x768)
DATA DRIVER IC
BACKLIGHT UNIT
10 / 29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
Version 2.1
www.panelook.com
Global LCD Panel Exchange Center
5 INPUT TERMINAL PIN ASSIGNMENT
5.1 TFT LCD MODULE
Pin Symbol Description Polarity Remark
1 NC No Connection
2 VCCS Power Supply +3.3 V
3 VCCS Power Supply +3.3 V
4 EE_VDD DDC +3.3 V
5 NC No Connection
6 EE_SC DDC Clock
7 EE_SD DDC Data
8 Rx0- LVDS Differential Data Input Negative
9 Rx0+ LVDS Differential Data Input Positive
10 VSS Ground
11 Rx1- LVDS Differential Data Input Negative
12 Rx1+ LVDS Differential Data Input Positive
13 VSS Ground
14 Rx2- LVDS Differential Data Input Negative
15 Rx2+ LVDS Differential Data Input Positive
16 VSS Ground
17 RXC- LVDS Clock Data Input Negative
18 RXC+ LVDS Clock Data Input Positive
19 VSS Ground 20 NC No Connection 21 NC No Connection
22 VSS Ground
23 NC No Connection
24 NC No Connection
25 VSS Ground
26 NC No Connection
27 NC No Connection
28 VSS Ground
29 NC No Connection
30 NC No Connection
31 VSS Ground
32 VSS Ground
33 VSS Ground
34 NC No Connection
35 LED_PWM PWM brightness control
36 LED_EN LED Enable
37 NC No Connection
38 LED_VCCS 7V-20V LED Power
39 LED_VCCS 7V-20V LED Power
40 LED_VCCS 7V-20V LED Power
www.panelook.com
Doc No.: 400029639
Issued Date: Aug, 14, 2009
Model No.: N140B6 - L06
Approval
R0~R5,G0-
G1~G5,B0,B1
-
B2~B5,Hsync,Vsync,DE
LVDS Level Clock
LED Power Input
11 / 29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
Version 2.1
www.panelook.com
Global LCD Panel Exchange Center
Note (1) Connector Part No.: I-PEX 20455-040E-12 or equivalent.
Note (2) User’s connector Part No.: I-PEX 20453-040T-01 or equivalent
Note (3) The first pixel is odd as shown in the following figure.
www.panelook.com
Doc No.: 400029639
Issued Date: Aug, 14, 2009
Model No.: N140B6 - L06
Approval
5.2 TIMING DIAGRAM OF LVDS INPUT SIGNAL
CLK+
T/7
Rxin2
Rxin1
Rxin0
IN20 IN19 IN18 IN17 IN16 IN15 IN14
DE B5 B4 B3 B2 Vsync Hsync
IN13 IN12 IN11 IN10 IN9 IN8 IN7
B1 G4 G3 G2 G1 B0 G5
IN6 IN5 IN4 IN3 IN2 IN1 IN0
G0 R3 R2 R1 R0
R5
R4
Signal for 1 DCLK Cycle (T)
12 / 29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
Version 2.1
www.panelook.com
Global LCD Panel Exchange Center
5.3 COLOR DATA INPUT ASSIGNMENT
The brightness of each primary color (red, green and blue) is based on the 6-bit gray scale data input for
the color. The higher the binary input the brighter the color. The table below provides the assignment of
color versus data input.
Color
R5 R4 R3 R2 R1 R0 G5 G4 G3 G2 G1 G0 B5 B4 B3 B2 B1 B0
Black
Red
Green
Basic
Colors
Gray
Scale
Of
Red
Gray
Scale
Of
Green
Gray
Scale
Of
Blue
Note (1) 0: Low Level Voltage, 1: High Level Voltage
Blue
Cyan
Magenta
Yellow
White
Red(0)/Dark
Red(1)
Red(2)
:
:
Red(61)
Red(62)
Red(63)
Green(0)/Dark
Green(1)
Green(2)
:
:
Green(61)
Green(62)
Green(63)
Blue(0)/Dark
Blue(1)
Blue(2)
:
:
Blue(61)
Blue(62)
Blue(63)
0
0
1
1
0
0
0
0
0
0
1
1
1
1
1
1
0
0
0
0
0
0
:
:
:
:
1
1
1
1
1
1
0
0
0
0
0
0
:
:
:
:
0
0
0
0
0
0
0
0
0
0
0
0
:
:
:
:
0
0
0
0
0
0
www.panelook.com
Doc No.: 400029639
Issued Date: Aug, 14, 2009
Model No.: N140B6 - L06
Approval
Data Signal
Red Green Blue
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
1
1
1
1
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
1
1
1
1
1
1
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
1
1
1
1
1
1
0
0
0
0
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
0
0
0
0
0
0
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
0
0
0
0
0
0
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
1
0
0
0
0
0
0
0
0
0
0
0
0
0
0
1
0
0
0
0
0
0
0
0
0
0
0
0
0
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
1
1
0
1
0
0
0
0
0
0
0
0
0
0
0
0
1
1
1
0
0
0
0
0
0
0
0
0
0
0
0
0
1
1
1
1
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
1
0
0
0
0
0
0
0
0
0
0
0
0
0
0
1
0
0
0
0
0
0
0
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
0
0
0
0
1
1
1
1
0
1
0
0
0
0
0
0
0
0
0
0
1
1
1
1
1
0
0
0
0
0
0
0
0
0
0
0
1
1
1
1
1
1
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
1
0
0
0
0
0
0
0
0
0
0
0
0
0
0
1
0
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
0
0
0
0
0
0
0
0
0
0
1
1
1
1
0
1
0
0
0
0
0
0
0
0
0
0
1
1
1
1
1
0
0
0
0
0
0
0
0
0
0
0
1
1
1
1
1
1
13 / 29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
Version 2.1
www.panelook.com
Global LCD Panel Exchange Center
5.4 EDID DATA STRUCTURE
The EDID (Extended Display Identification Data) data formats are to support displays as defined in the
VESA Plug & Display and FPDI standards.
Byte #
(decimal)
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
Byte #
(hex)
Field Name and Comments
0 Header
1 Header
2 Header
3 Header
4 Header
5 Header
6 Header
7 Header
8 EISA ID manufacturer name (“CMO”)
9 EISA ID manufacturer name (Compressed ASCII)
0A ID product code (N140B6-L06) 51
0B ID product code (hex LSB first; N140B6-L06) 14
0C ID S/N (fixed “0”)
0D ID S/N (fixed “0”)
0E ID S/N (fixed “0”)
0F ID S/N (fixed “0”)
10 Week of manufacture (fixed week code)
11 Year of manufacture (fixed year code)
12 EDID structure version # (“1”)
13 EDID revision # (“3”)
14 Video I/P definition (“digital”)
15 Active area horizontal 30.94 cm 1F
16 Active area vertical 17.40 cm 11
17 Display Gamma (Gamma = ”2.2”)
18 Feature support (“Active off, RGB Color”)
19 Red/Green (Rx1, Rx0, Ry1, Ry0, Gx1, Gx0, Gy1, Gy0)
1A Blue/White (Bx1, Bx0, By1, By0, Wx1, Wx0, Wy1, Wy0)
1B Red-x (Rx = “0.580”)
1C Red-y (Ry = “0.343”) 57
1D Green-x (Gx = ”0.330”)
1E Green-y (Gy = ”0.568”)
1F Blue-x (Bx = ”0.155”)
20 Blue-y (By = ”0.125”)
21 White-x (Wx = ”0.313”)
22 White-y (Wy = ”0.329”)
23 Established timings 1
24 Established timings 2
25 Manufacturer’s reserved timings
26 Standard timing ID # 1
27 Standard timing ID # 1
28 Standard timing ID # 2
29 Standard timing ID # 2
www.panelook.com
Doc No.: 400029639
Issued Date: Aug, 14, 2009
Model No.: N140B6 - L06
Approval
Value
(hex)
Value
(binary)
00 00000000
FF 11111111
FF 11111111
FF 11111111
FF 11111111
FF 11111111
FF 11111111
00 00000000
0D 00001101
AF 10101111
01010001
00010100
00 00000000
00 00000000
00 00000000
00 00000000
0C 00001100
13 00010011
01 00000001
03 00000011
80 10000000
00011111
00010001
78 01111000
0A 00001010
BA 10111010
C5 11000101
94 10010100
01010111
54 01010100
91 10010001
27 00100111
20 00100000
50 01010000
54 01010100
00 00000000
00 00000000
00 00000000
01 00000001
01 00000001
01 00000001
01 00000001
14 / 29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
Version 2.1
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Doc No.: 400029639
Issued Date: Aug, 14, 2009
Model No.: N140B6 - L06
Approval
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
2A Standard timing ID # 3
2B Standard timing ID # 3
2C Standard timing ID # 4
2D Standard timing ID # 4
2E Standard timing ID # 5
2F Standard timing ID # 5
30 Standard timing ID # 6
31 Standard timing ID # 6
32 Standard timing ID # 7
33 Standard timing ID # 7
34 Standard timing ID # 8
35 Standard timing ID # 8
Detailed timing description # 1 Pixel clock (“75.44MHz”,
36
According to VESA CVT Rev1.1)
37 # 1 Pixel clock (hex LSB first)
38 # 1 H active (“1366”)
39 # 1 H blank (“194”)
3A # 1 H active : H blank (“1366 : 194”)
3B # 1 V active (”768”)
3C # 1 V blank (”38”)
3D # 1 V active : V blank (”768 :38”)
3E # 1 H sync offset (”31”)
3F # 1 H sync pulse width ("65”)
40 # 1 V sync offset : V sync pulse width (”4 : 12”)
# 1 H sync offset : H sync pulse width : V sync offset : V sync
41
width (”31: 65 : 4 : 12”)
42 # 1 H image size (”309 mm”) 35
43 # 1 V image size (”174 mm”) AE
44 # 1 H image size : V image size (”309 : 174”)
45 # 1 H boarder (”0”)
46 # 1 V boarder (”0”)
# 1 Non-interlaced, Normal, no stereo, Separate sync, H/V pol
47
Negatives
48 Detailed timing description # 2
49 # 2 Flag
4A # 2 Reserved
# 2 FE (hex) defines ASCII string (Model Name “N140B6-L06”,
4B
ASCII)
4C # 2 Flag
4D # 2 1st character of name (“N”) 4E
4E # 2 2nd character of name (“1”) 31
4F # 2 3rd character of name (“4”) 34
50 # 2 4th character of name (“0”) 30
51 # 2 5th character of name (“B”) 42
52 # 2 6th character of name (“6”) 36
53 # 2 7th character of name (“-”) 2D
54 # 2 8th character of name (“L”) 4C
55 # 2 9th character of name (“0”)
56 # 2 9th character of name (“6”)
01 00000001
01 00000001
01 00000001
01 00000001
01 00000001
01 00000001
01 00000001
01 00000001
01 00000001
01 00000001
01 00000001
01 00000001
78 01111000
1D 00011101
56 01010110
C2 11000010
50 01010000
00 00000000
26 00100110
30 00110000
1F 00011111
41 01000001
4C 01001100
00 00000000
10 00010000
00 00000000
00 00000000
18 00011000
00 00000000
00 00000000
00 00000000
FE 11111110
00 00000000
30 00110000
36 00110110
00110101
10101110
01001110
00110001
00110100
00110000
01000010
00110110
00101101
01001100
15 / 29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
Version 2.1
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Doc No.: 400029639
Issued Date: Aug, 14, 2009
Model No.: N140B6 - L06
Approval
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
57 # 2 New line character indicates end of ASCII string
58 # 2 Padding with “Blank” character
59 # 2 Padding with “Blank” character
5A Detailed timing description # 3
5B # 3 Flag
5C # 3 Reserved
5D # 3 FE (hex) defines ASCII string (Vendor “CMO”, ASCII)
5E # 3 Flag
5F # 3 1st character of string (“C”)
60 # 3 2nd character of string (“M”)
61 # 3 3rd character of string (“O”)
62 # 3 New line character indicates end of ASCII string
63 # 3 Padding with “Blank” character
64 # 3 Padding with “Blank” character
65 # 3 Padding with “Blank” character
66 # 3 Padding with “Blank” character
67 # 3 Padding with “Blank” character
68 # 3 Padding with “Blank” character
69 # 3 Padding with “Blank” character
6A # 3 Padding with “Blank” character
6B # 3 Padding with “Blank” character
6C Detailed timing description # 4
6D # 4 Flag
6E # 4 Reserved
# 4 FE (hex) defines ASCII string (Model Name“N140B6-L06”,
6F
ASCII)
70 # 4 Flag
71 # 4 1st character of name (“N”) 4E
72 # 4 2nd character of name (“1”) 31
73 # 4 3rd character of name (“4”) 34
74 # 4 4th character of name (“0”) 30
75 # 4 5th character of name (“B”) 42
76 # 4 6th character of name (“6”) 36
77 # 4 7th character of name (“-”) 2D
78 # 4 8th character of name (“L”) 4C
79 # 4 9th character of name (“0”)
7A # 4 9th character of name (“6”)
7B # 4 New line character indicates end of ASCII string
7C # 4 Padding with “Blank” character
7D # 4 Padding with “Blank” character
7E Extension flag
7F Checksum
0A 00001010
20 00100000
20 00100000
00 00000000
00 00000000
00 00000000
FE 11111110
00 00000000
43 01000011
4D 01001101
4F 01001111
0A 00001010
20 00100000
20 00100000
20 00100000
20 00100000
20 00100000
20 00100000
20 00100000
20 00100000
20 00100000
00 00000000
00 00000000
00 00000000
FE 11111110
00 00000000
30 00110000
36 00110110
0A 00001010
20 00100000
20 00100000
00 00000000
31 00110001
01001110
00110001
00110100
00110000
01000010
00110110
00101101
01001100
16 / 29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
Version 2.1
www.panelook.com
Global LCD Panel Exchange Center
www.panelook.com
Issued Date: Aug, 14, 2009
Model No.: N140B6 - L06
6 CONVERTER SPECIFICATION
6.1 ABSOLUTE MAXIMUM RATINGS
Symbol Ratings
LED_VCCS -0.3V ~ 28.0V
LED_PWM, LED_EN -0.3V ~ 5.5V
6.2 RECOMMENDED OPERATING RATINGS
Parameter Symbol
Converter Input power supply voltage
Converter Rush Current
Converter Initial Stage Current
EN Control Level
PWM Control Level
Backlight On 2.3 - 5.5 V
Backlight Off 0 - 0.8 V
PWM High Level 2.3 - 5.5 V
PWM Low Level 0 - 0.15 V
LED_Vccs
ILED
RUSH
ILED
Min. Typ. Max.
7 12 20 V
- - 1.5 A (2)
IS
- - 1.5 A (2)
PWM Control Duty Ratio 10 - 100 %
PWM Control Permissive Ripple Voltage
PWM Control Frequency f
VPWM_pp
190 210 230 Hz
PWM
- - 100 mV
ILED 326 430 525 mA (1)
LED Power Current
LED_VCCS =Typ. 190 251 306 mA (1)
LED_VCCS =Max.
ILED
114 151 184 mA (1)
Note (1) The specified LED power supply current is under the conditions at “LED_VCCS = Min., Typ., Max.”,
Value
Doc No.: 400029639
Approval
Unit Note
Ta = 25 ± 2 ºC, f
Note (2) ILED
ILED
: the maximum current when LED_VCCS is rising,
RUSH
: the maximum current of the first 100ms after power-on,
IS
= 200 Hz, Duty=100%.
PWM
Measurement Conditions: Shown as the following figure. LED_VCCS = Typ, Ta = 25 ± 2 ºC, f
200 Hz, Duty=100%.
(High to Low)
(Control Signal)
SW=24V
LED_VCCS(Typ)
LED_VCCS(Typ)
C1
1uF
VR1
R1
47K
R2
1K
47K
Q1 IRL3303
0.01uF
FUSE
Q2
IRL3303
C2
C3
1uF
(LED Converter Input)
PWM
=
17 / 29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
Version 2.1
www.panelook.com
Global LCD Panel Exchange Center
0.5ms
www.panelook.com
Doc No.: 400029639
Issued Date: Aug, 14, 2009
Model No.: N140B6 - L06
Approval
VLED rising time is 0.5ms
90%
LED_VCC
LED_PWM
LED_EN
ILED
0V
0V
0V
ILED
10%
Rush
100ms
ILED
IS
18 / 29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
Version 2.1
www.panelook.com
Global LCD Panel Exchange Center
7 INTERFACE TIMING
7.1 INPUT SIGNAL TIMING SPECIFICATIONS
The input signal timing specifications are shown as the following table and timing diagram.
Signal Item Symbol Min. Typ. Max. Unit Note
DCLK Frequency 1/Tc 50 75.44 80 MHz
Vertical Total Time TV 771 806 1008 TH
Vertical Active Display Period TVD 768 768 768 TH
DE
Note (1) Because this module is operated by DE only mode, Hsync and Vsync are ignored
Vertical Active Blanking Period TVB TV-TVD 38 TV-TVD TH
Horizontal Total Time TH 1448 1560 1950 Tc
Horizontal Active Display Period THD 1366 1366 1366 Tc
Horizontal Active Blanking Period THB
www.panelook.com
TH-THD
194
Doc No.: 400029639
Issued Date: Aug, 14, 2009
Model No.: N140B6 - L06
Approval
TH-THD
Tc
DE
DCLK
DE
DATA
INPUT SIGNAL TIMING DIAGRAM
TC
HD
T
19 / 29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
Version 2.1
www.panelook.com
Global LCD Panel Exchange Center
7.2 POWER ON/OFF SEQUENCE
www.panelook.com
Doc No.: 400029639
Issued Date: Aug, 14, 2009
Model No.: N140B6 - L06
Approval
- Power Supply
for LCD, VCCS
- Interface Signal
(LVDS Signal of
Transmitter), V
I
- Power Supply for
LED Converter,
LED_VCCS
- LED Converter
Dimming Signal,
LED_PWM
- LED Converter
Enable Signal,
LED_EN
0V
0V
0V
0V
0V
Power On
90%
10%
Power Off
t1
t2
Valid Data
t6t5
10%
90%
t
A
t
C
tE t
90%
t
B
t
D
F
90%
10%
Restart
t7
10%
t3
10%
t4
Timing Specifications:
0.5Љ t1ʳЉ 10 ms
0 Љ t2ʳЉ 50 ms
0 Љ t3ʳЉ 50 ms
t4ʳЊ 500 ms
t5ʳЊ 200 ms
t6ʳЊ 200 ms
0.5Љ t7ʳЉʳ 10 ms
0.5Љ t
0 Љ t
ʳЉʳ 10 ms
A
ʳЉʳ 10 ms
B
t
ʳЊ 10 ms
C
t
ʳЊ 10 ms
D
t
ʳЊ 10 ms
E
t
ʳЊ 10 ms
F
20 / 29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
Version 2.1
www.panelook.com
Global LCD Panel Exchange Center
8 OPTICAL CHARACTERISTICS
8.1 TEST CONDITIONS
Item Symbol Value Unit
Ambient Temperature Ta 25±2
Ambient Humidity Ha 50±10 %RH
Supply Voltage VCC 3.3 V
Input Signal According to typical value in "3. ELECTRICAL CHARACTERISTICS"
LED Light Bar Input Current I
The measurement methods of optical characteristics are shown in Section 8.2. The following items
should be measured under the test conditions described in Section 8.1 and stable environment shown in
Note (5).
8.2 OPTICAL SPECIFICATIONS
Item Symbol Condition Min. Typ. Max. Unit Note
Contrast Ratio CR 500 650 - - (2), (5)
Response Time
Luminance of White (5P) L
White Variation δW5p - - 1.25 - (5), (6)
Red
Color
Chromaticity
Viewing Angle
Green
Blue
White
Horizontal
Vertical
www.panelook.com
Doc No.: 400029639
Issued Date: Aug, 14, 2009
Model No.: N140B6 - L06
Approval
o
C
L
100
TR - 2 5 ms
- 6 11 ms
T
F
190 220 - cd/m2(4), (5)
AVE
Rx
Ry
Gx
Gy
Bx
By
Wx
Wy
=0° , θY =0°
θ
x
Viewing Normal Angle
Typ.-
0.03
0.580
0.343
0.330
0.568
0.155
0.125
0.313
0.329
Typ.+
0.03
θx+ 40 45 -
- 40 45 -
θ
x
θY+ 15 20 -
-
θ
Y
CR≥10
40 45 -
mA
-
-
-
-
-
-
-
-
Deg. (1), (5)
(3)
(1), (5)
21 / 29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
Version 2.1
www.panelook.com
Global LCD Panel Exchange Center
Note (1) Definition of Viewing Angle (θx, θy):
www.panelook.com
Doc No.: 400029639
Issued Date: Aug, 14, 2009
Model No.: N140B6 - L06
Approval
Normal
θx = θy = 0º
θy- θy+
θX- = 90º
6 o’clock
θ
y- = 90º
x-
y-
Note (2) Definition of Contrast Ratio (CR):
The contrast ratio can be calculated by the following expression.
Contrast Ratio (CR) = L63 / L0
L63: Luminance of gray level 63
L 0: Luminance of gray level 0
CR = CR (5)
θx-
θx+
y+
12 o’clock direction
θ
y+ = 90º
x+
θX+ = 90º
CR (X) is corresponding to the Contrast Ratio of the point X at Figure in Note (6).
Note (3) Definition of Response Time (T
Gray Level 63
100%
90%
Optical
Response
10%
0%
66.67ms
R
T
R
, TF):
Gray Level 0
T
F
66.67m
Gray Level 63
Time
22 / 29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
Version 2.1
www.panelook.com
Global LCD Panel Exchange Center
500
www.panelook.com
Doc No.: 400029639
Issued Date: Aug, 14, 2009
Model No.: N140B6 - L06
Approval
Note (4) Definition of Average Luminance of White (L
Measure the luminance of gray level 63 at 5 points
L
= [L (1)+ L (2)+ L (3)+ L (4)+ L (5)] / 5
AVE
L (x) is corresponding to the luminance of the point X at Figure in Note (6).
Note (5) Measurement Setup:
The LCD module should be stabilized at given temperature for 15 minutes to avoid abrupt
temperature change during measuring. In order to stabilize the luminance, the measurement
should be executed after lighting Backlight for 15 minutes in a windless room.
LCD Module
LCD Panel
USB2000
AVE
):
CS-1000T
Center of the Screen
mm
Note (6) Definition of White Variation (δW):
Measure the luminance of gray level 63 at 5 points
δW = Maximum [L (1), L (2), L (3), L (4), L (5)] / Minimum [L (1), L (2), L (3), L (4), L (5)]
D/4 D/2 3D/4
W/4
W/2
W
Vertical Line
3W/
1 2
3
Horizontal Line
D
5
Light Shield Room
(Ambient Luminance < 2 lux)
X
: Test Point
X=1 to 5
4
Active Area
23 / 29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
Version 2.1
www.panelook.com
Global LCD Panel Exchange Center
9 PRECAUTIONS
9.1 HANDLING PRECAUTIONS
(1) The module should be assembled into the system firmly by using every mounting hole. Be careful not
to twist or bend the module.
(2) While assembling or installing modules, it can only be in the clean area. The dust and oil may cause
electrical short or damage the polarizer.
(3) Use fingerstalls or soft gloves in order to keep display clean during the incoming inspection and
assembly process.
(4) Do not press or scratch the surface harder than a HB pencil lead on the panel because the polarizer is
very soft and easily scratched.
(5) If the surface of the polarizer is dirty, please clean it by some absorbent cotton or soft cloth. Do not use
Ketone type materials (ex. Acetone), Ethyl alcohol, Toluene, Ethyl acid or Methyl chloride. It might
www.panelook.com
Doc No.: 400029639
Issued Date: Aug, 14, 2009
Model No.: N140B6 - L06
Approval
permanently damage the polarizer due to chemical reaction.
(6) Wipe off water droplets or oil immediately. Staining and discoloration may occur if they left on panel for
a long time.
(7) If the liquid crystal material leaks from the panel, it should be kept away from the eyes or mouth. In
case of contacting with hands, legs or clothes, it must be washed away thoroughly with soap.
(8) Protect the module from static electricity, it may cause damage to the C-MOS Gate Array IC.
(9) Do not disassemble the module.
(10) Do not pull or fold the lamp wire.
(11) Pins of I/F connector should not be touched directly with bare hands.
9.2 STORAGE PRECAUTIONS
(1) High temperature or humidity may reduce the performance of module. Please store LCD module within
the specified storage conditions.
(2) It is dangerous that moisture come into or contacted the LCD module, because the moisture may
damage LCD module when it is operating.
(3) It may reduce the display quality if the ambient temperature is lower than 10 ºC. For example, the
response time will become slowly, and the starting voltage of lamp will be higher than the room
temperature.
9.3 OPERATION PRECAUTIONS
(1) Do not pull the I/F connector in or out while the module is operating.
(2) Always follow the correct power on/off sequence when LCD module is connecting and operating. This
can prevent the CMOS LSI chips from damage during latch-up.
(3) The startup voltage of Backlight is approximately 1000 Volts. It may cause electrical shock while
assembling with converter. Do not disassemble the module or insert anything into the Backlight unit.
9.4 OTHER PRECAUTIONS
(1) When fixed patterns are displayed for a long time, remnant image is likely to occurˁʳ
24 / 29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
Version 2.1
www.panelook.com
Global LCD Panel Exchange Center
10 PACKING
10.1 CARTON
www.panelook.com
Doc No.: 400029639
Issued Date: Aug, 14, 2009
Model No.: N140B6 - L06
Approval
Figure. 10-1 Packing method
25 / 29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
Version 2.1
www.panelook.com
Global LCD Panel Exchange Center
10.2 3$//(7
www.panelook.com
Doc No.: 400029639
Issued Date: Aug, 14, 2009
Model No.: N140B6 - L06
Approval
Figure. 10-2 Packing method
26 / 29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
Version 2.1
www.panelook.com
Global LCD Panel Exchange Center
11 DEFINITION OF LABELS
11.1 CMO MODULE LABEL
The barcode nameplate is pasted on each module as illustration, and its definitions are as following
explanation.
www.panelook.com
Doc No.: 400029639
Issued Date: Aug, 14, 2009
Model No.: N140B6 - L06
Approval
N140B6-L06
(a) Model Name: N140B6 - L06
(b) Revision: Rev. XX, for example: C1, C2 …etc.
(c) Serial ID: X X
(d) Production Location: MADE IN XXXX. XXXX stands for production location.
(e) UL/CB logo: “LEOO” especially stands for panel manufactured by CMO Ningbo satisfying UL/CB
requirement. “LEOO” is the CMO’s UL factory code for Ningbo factory.
X X X X X Y M D X N N N N
MADE IN XXXX
LEOO
Serial No.
CMO Internal Use
Year, Month, Date
CMO Internal Use
Revision
CMO Internal Use
Serial ID includes the information as below:
(a) Manufactured Date: Year: 1~9, for 2001~2009
Month: 1~9, A~C, for Jan. ~ Dec.
Day: 1~9, A~Y, for 1
(b) Revision Code: cover all the change
(c) Serial No.: Manufacturing sequence of production
st
to 31st, exclude I , O and U
27 / 29
Version 2.1
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
www.panelook.com
Global LCD Panel Exchange Center
11.2 CARTON LABEL
www.panelook.com
Doc No.: 400029639
Issued Date: Aug, 14, 2009
Model No.: N140B6 - L06
Approval
(a) Production location: Made in XXXX. XXXX stands for production location.
28 / 29
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
Version 2.1
www.panelook.com
www.panelook.com
www.panelook.com
Global LCD Panel Exchange Center
One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!
Loading...
