Clover Electronics RD435 User Manual
INSTRUCTION
MANUAL
DAY AND NIGHT COLOR CAMERA
MODEL RD435
Copyright © 2008 Clover Electronics U.S.A. All Rights Reserved.
PRECAUTIONS
• To avoid electrical shock, do not open the case of this product.
• Operate this product using only the supplied AC Power supply.
• Do not overload electrical outlets or extension cords; this can result in fire or electric
shock.
• Keep this product away from strong magnetic fields.
• Do not expose this product in direct sunlight or strong reflected rays.
• Refer servicing to qualified personnel only.
• Do not change or modify this product, the warranty will be voided.
FEATURES
• Weatherproof (IP67)
• 1/3” Sony Super HAD CCD
• 420 TV Lines of Resolution
• Rugged Steel Construction
• Total 8 Super Power Infrared LEDs with a CDS sensor
• 60’ IR range (depends on scene reflection)
• Attached Mounting Base (for ceiling & wall) and 100’ cable
• DC12V Power Source
INSTALLATION
1. Attach the mounting bracket (1) to the wall or ceiling, wherever you want to install
the camera. Locate a wall stud or ceiling joist and secure the mounting base using the
supplied screws (2). Attach the camera to the mounting hole (3).
2. How to set angle of view:
Set the desired angle of camera toward objects by moving the camera right /left and
up/down.
3. Connect the one end of 100’ cable (supplied) to the Din jack of 5’ cable attached to
the camera. Make sure that two arrows on the top of them should be aimed at each
other. Connect the other end (BNC or RCA) of cable to the video devices such as
DVR, monitor/TV. Plug the provided AC adapter to the DC jack (red) of the end of
100’ cable.
g
Note:
▪ Apply the provided AC adapter only.
▪ The total len
th of cable must not exceed 200’ including extension
cable.
TROUBLE SHOOTING
If the camera does not function properly, check the following points before contacting the
service center.
Troubles Remedies
No video Check the AC adapter and video cable
between the camera and a monitor
The image on the screen is dark Check the brightness control on the
monitor
The image on the screen is dim Check if the lens is stained. If dirty,
clean it with soft and clean cloth
The camera is not working properly, and
the surface of the camera case is hot
The contrast on the screen is too weak Adjust the contrast feature of the
Check if you have connected the
provided AC adapter
monitor. If the camera is exposed under
too strong light, change the position
