Clontech PT3139-1 User Manual

Advantage®-HF PCR Kit
User Manual

(PT3139-1)

Catalog #K1909-1, -y

Storage conditions: –20

°C

FOR RESEARCH USE ONLY

(PR76834)

CLONTECH Laboratories, Inc.

page Protocol # PT3139-1 Technical Support TEL:[phone] or 800-662-CLON
2 Version # PR76834 FAX:[phone] or 800-424-1350

Table of Contents

I. Introduction 3

II. List of Components 7

III. Additional Materials Required 8

IV. Advantage-HF PCR Kit Protocol 9

A. General Considerations 9
B. Control PCR Reactions 11
C. Recommended Cycling Parameters 12
D. Amplification of Longer Fragments with the Advantage Buffer 13
E. Recommendations for Electrophoresis 13

V. Troubleshooting Guide 14

VI. References 18

VII. Related Products 19

Notice to Purchaser

A license under U.S. patents 4,683,202, 4,683,195, and 4,965,188 or their foreign counterparts, owned by Hoffmann­La Roche and F. Hoffmann-La Roche Ltd. (“Roche”), has an up-front fee component and a running-royalty
component. The purchase price of this product includes limited, non-transferable rights under the running-royalty
component to use only this amount of the product to practice the Polymerase Chain Reaction (“PCR”) and related
products described in said patents solely for the research and development activities of the purchaser when this
product is used in conjunction with a thermal cycler whose use is covered by the up-front fee component. Rights to
the up-front fee component must be obtained by the end-user in order to have a complete license. These rights under
the up-front fee component may be purchased from Perkin-Elmer or obtained by purchasing an authorized thermal
cycler. No right to perform or offer commercial services of any kind using PCR, including without limitation reporting
the results of purchaser’s activity for a fee or other commercial consideration, is hereby granted by implication or
estoppel. Further information on purchasing licenses to practice the PCR process may be obtained by contacting
the Director of Licensing at the Perkin-Elmer Corporation, 850 Lincoln Centre Drive, Foster City, CA 94404 or at
Roche Molecular Systems, Inc., 1145 Atlantic Avenue, Alameda, CA 94501.

This product is sold under licensing arrangements with F. Hoffmann-La Roche Ltd., Roche Molecular Systems, Inc.,
and the Perkin-Elmer Corporation.

Advantage-HF cDNA Polymerase Mix is covered by U.S. Patent No. 5,436,149. Foreign patents pending.
TaqStart Antibodies are licensed under U.S. Patent No. 5,338,671 and corresponding patents in other countries.

CLONTECH Laboratories, Inc.

TEL:[phone] or 800-662-CLON Technical Support Protocol # PT3139-1 page
FAX:[phone] or 800-424-1350 Version # PR76834 3

I. Introduction

The Advantage®-HF (High-Fidelity) PCR Kit is a KlenTaq-based system de­signed to deliver

Pfu

-like fidelity in the amplification of cDNA or genomic

templates.

High fidelity

and

efficiency

While

Pfu

polymerase is known for its exceptional fidelity, it suffers from subop­timal efficiency that can be problematic in many PCR applications. In contrast, the
Advantage-HF PCR Kit offers

Pfu

-like fidelity combined with the efficiency
required to amplify DNA fragments of up to 2.5 kb. These benefits are the result
of reformulation of several components in CLONTECH’s Advantage PCR
Enzyme Systems. The Advantage-HF Polymerase Mix combines KlenTaq (a 5'­exonuclease-deficient variant of

Taq

polymerase) with a proofreading poly­merase and TaqStartTM Antibody to provide a superior level of specificity.
Advantage-HF thus combines the benefits of

Pfu

and the Advantage Enzyme

System to deliver a high-fidelity enzyme system.

The HF Advantage

The accuracy of Advantage-HF is compared to other enzymes and enzyme mixes
in Figure 1. Using a genetic assay that measures nucleotide misincorporation,
Advantage-HF rivals

Pfu

in fidelity. This fidelity assay is based on amplification of

an

E. coli

ribosomal protein gene (Mo

et al.

, 1991). Mutations in this gene often
confer streptomycin resistance on the host. Upon introduction of the amplified
DNA into

E. coli

, the ratio of total transformants to streptomycin resistant

Figure 1. Comparison of fidelity of Advantage-HF and other PCR systems. The fidelity of
Advantage-HF compares favorably with that of the

Pfu

enzyme and is significantly higher than that of

other enzyme systems. Accuracy assay is based on 25 cycles of amplification (see text).

0

100

200

300

400

500

19

67

385

435

71

Taq Advantage AdvantageHFPfu

Taq

+

Pwo

Enzyme

Accuracy

(total transformants/strep

r

transformants)

CLONTECH Laboratories, Inc.

page Protocol # PT3139-1 Technical Support TEL:[phone] or 800-662-CLON
4 Version # PR76834 FAX:[phone] or 800-424-1350

I. Introduction

continued

transformants provides a comparative measure of PCR fidelity. The fidelity of
Advantage-HF was confirmed by sequencing (Table I). The high level of fidelity
delivered by the Advantage-HF system increases confidence in sequence de­rived from PCR products and is beneficial in a variety of PCR applications,
including expression studies of amplified full-length cDNAs, generation of cDNA
libraries, RACE, and analysis of homologous genes amplified with degenerate
primers.

TABLE I. FIDELITY OF ADVANTAGE-HF BASED ON SEQUENCING DATA

Error rate

a

Enzyme (per 100,000 bp)

Taq

180

b

Advantage-HF 2.4

a

determined with individual clones after 25 PCR cycles

b

agrees with published data (Ling

et al.

, 1991; Cariello

et al.

, 1991)

High-fidelity amplification of cDNA and Genomic templates

Advantage-HF was used to amplify several cDNA templates of different lengths
(Figure 2). Although amplification of the longest template yielded a reduced
amount of product (Lane 6), this amplified product contains a higher percentage
of accurate copies—nearly 6-fold higher than Advantage, and 20-fold higher than

Taq

, according to Figure 1.

Figure 2. Advantage-HF amplification of cDNA fragments. Several fragments were amplified from
Human Placenta cDNA under standard (Lanes 1, 3 & 5) and high-fidelity PCR conditions (Advantage­HF; Lanes 2, 4 & 6). M: λ/

Hin

d III DNA size markers. Lanes 1 & 2: 0.5-kb fragment of glycerol 3­phosphate dehydrogenase gene. Lanes 3 & 4: 1.3-kb fragment of transferrin receptor gene. Lanes 5
& 6: 2.5-kb fragment of lactoferrin gene. Cycling parameters: 30 sec at 94oC; 30 x (30 sec at 94 oC,
5 min at 68 oC); 5 min at 68 oC.

M123456

kb

4.4-

2.0-

0.56-

CLONTECH Laboratories, Inc.

TEL:[phone] or 800-662-CLON Technical Support Protocol # PT3139-1 page
FAX:[phone] or 800-424-1350 Version # PR76834 5

The Advantage-HF Kit ensures
high-fidelity amplification of ge­nomic as well as cDNA tem­plates. In Figure 3, the Advan­tage HF Kit was used to amplify
a 2.1-kb fragment of the bovine
pancreas trypsin inhibitor gene
from different amounts of total
calf thymus DNA. The fragment
was efficiently amplified from as
little as 25 ng of genomic DNA
(Lane 4).

Increase elongation efficiency
for longer fragments

Two reaction buffers are included
in the Advantage-HF Kit: the HF
Buffer and the original cDNA
Buffer. Use of the HF buffer de­livers the highest possible fidel­ity, as represented in Figure 1.
Fragments of up to ~2.5 kb can
be amplified under these condi­tions. To amplify longer frag­ments, some of the increase in
fidelity can be sacrificed to im­prove elongation efficiency by
combining the HF and cDNA
buffers in varying proportions.

Figure 4, Panel A shows the
fidelity resulting from the use of
varying percentages of the HF
Buffer (see p. 3 for description of
assay). Panel B demonstrates
amplification of a 6.0-kb cDNA
fragment using the indicated con­centrations of HF Buffer. In this
example, the fragment is suc­cessfully amplified in 80% HF
Buffer, conditions allowing a ~3­fold increase in fidelity over the
cDNA buffer. Optimal conditions
for the amplification of other frag­ments should be determined in­dividually.

I. Introduction

continued

Figure 4. The effect of HF Buffer concentration on PCR

fidelity (A) and amplification (B) of a 6.0-kb cDNA
fragment from Human Placenta cDNA. Size markers
are λ/

Hin

d III DNA.

Figure 3. Advantage-HF amplification from genomic
DNA. The indicated amounts of calf thymus DNA were

used to amplify a 2.1-kb fragment of the bovine pan­creas trypsin inhibitor gene. M: λ/

Hin

d III DNA size
markers. Cycling parameters are the same as in Fig­ure 2.

M 1 2345

ng: 100 75 50 25 0

B

200

40

60

80

100

0

0.5

1.0

1.5

2.0

HF Buffer %:

Mutants (%)

A

2.0-

4.4-

CLONTECH Laboratories, Inc.

page Protocol # PT3139-1 Technical Support TEL:[phone] or 800-662-CLON
6 Version # PR76834 FAX:[phone] or 800-424-1350

Automatic hot start with TaqStart Antibodies

Advantage-HF provides hot start PCR by including TaqStartTM Antibody in the
polymerase mix, eliminating the need for additional pipetting or handling steps.
"Hot start" refers to any method for assembling PCR reactions that keeps one or
more of the reaction components physically or functionally separate from the rest
of the components prior to the onset of thermal cycling. This prevents back­ground due to low-level DNA synthesis from nonspecifically primed sites prior to
the onset of thermal cycling. The advantages of hot start PCR have been
demonstrated in many different applications. However, only CLONTECH's
Advantage Polymerase Mixes provide automatic hot start.

TaqStart is a neutralizing monoclonal antibody directed against

Taq

DNA

polymerase. TaqStart recognizes both native

Taq

and N-terminal deletions such
as KlenTaq-1. When premixed with the appropriate polymerase, the antibody
blocks polymerase activity during the set-up of the PCR reactions at ambient
temperatures. Polymerase activity is restored at the onset of thermal cycling
because the antibody is denatured by temperatures greater than 60°C. The loss
of inhibition is complete and irreversible, so the polymerase regains its full
enzymatic activity for PCR.

TaqStart-mediated hot start PCR has been shown to significantly improve the
efficiency and specificity of DNA amplifications (Kellogg

et al

., 1994;

CLONTECHniques,

April 1994). Antibody-mediated hot start with TaqStart has

been proven to be at least as effective as manual hot start (d'Aquila

et al

., 1991)

or wax-bead-mediated hot start (Chou

et al

., 1991). In particular, TaqStart
reduces or eliminates nonspecific amplification products and primer-dimer
artifacts. In some cases, specific products can only be obtained by using
TaqStart.

A PCR system for every application

The Advantage cDNA and Genomic PCR Kits, containing the Advantage cDNA
and Genomic Polymerase Mixes, respectively, are designed for high-efficiency,
long-distance PCR amplification and are the foundation of the Advantage PCR
Enzyme Systems (

CLONTECHniques

, July 1995; Barnes, 1994). These versatile
kits are designed for high-performance amplification in the vast majority of PCR
applications (including all of our PCR-based kits) and have firmly established the
benefits of PCR enzyme mixes containing hot start antibodies. Our other Advan­tage-based kits have been developed for certain specialized applications. The
Advantage-GC cDNA and Genomic PCR Kits and Mixes (

CLONTECHniques

,

January 1997) combine the high efficiency of the Advantage system with a novel
reagent, GC-MeltTM, and an optimized buffer containing DMSO to permit amplifi-

cation of problematic GC-rich templates (up to 90% GC). As the newest addition
to the Advantage line, Advantage-HF allows a new level of fidelity, balanced by

the efficiency that is characteristic of Advantage.

I. Introduction

continued

CLONTECH Laboratories, Inc.

TEL:[phone] or 800-662-CLON Technical Support Protocol # PT3139-1 page
FAX:[phone] or 800-424-1350 Version # PR76834 7

Advantage-HF PCR Kit (#K1909-1[100 rxns], 1909-y [10 rxns])

Store all components at –20°C. Enough reagents are supplied for 100 PCR
reactions of 50 µl each.

II. List of Components

10 rxns 100 rxns

• 10 µl 100 µl 50X Advantage-HF Polymerase Mix

Includes KlenTaq-1 DNA polymerase and TaqStart Antibody
(1.1 µ g/µl) in the following storage buffer.

Concentration 1X
in 50X Component Concentration

50 % Glycerol 1.0 %
40 mM Tris-HCl (pH 7.5) 0.8 mM
50 mM KCl 1.0 mM
25 mM (NH4)2SO

4

0.5 mM

1 mM EDTA 20 µM

5.0 mM β-mercaptoethanol 0.1 mM

0.25 % Thesit 0.005 %

Deep Vent

R

TM

is a minor component of the Advantage-HF

Polymerase Mix.

• 60 µl 600 µl 10X HF PCR reaction buffer

• 60 µl 600 µl 10X cDNA PCR reaction buffer

• 60 µl 600 µl 10X HF dNTP mix

• 400 µl 4 ml Purified Water (Millipore-purified)

• 10 µl 100 µl Control DNA template

λ DNA (0.2 ng/µl)

• 10 µl 40 µl Control primer mix (10 µM each)

The sequences are:

5' primer 5'–TTGGTTGATCGTGGTGCAGAGAACGTTG–3'
3' primer 5'–GAGAAGGTCACGAATGAACCAGGCGATAA–3'

CLONTECH Laboratories, Inc.

page Protocol # PT3139-1 Technical Support TEL:[phone] or 800-662-CLON
8 Version # PR76834 FAX:[phone] or 800-424-1350

III. Additional Materials Required

The following reagents are required but not supplied.

• Mineral oil (We recommend Sigma® Cat. #M-3516.)

• 0.5-ml PCR reaction tubes (We recommend Perkin-Elmer GeneAmp

TM

0.5-ml reaction tubes [Cat. #N801-0737].)

• Thermal cycler (Perkin-Elmer DNA Thermal Cycler 480, 9600, or equivalent)

• Dedicated pipettors (1–2-µl, 1–10-µl, 1–20-µl, 20–200-µl, 200–1000-µl)

• PCR pipette tips suitable for the above pipettors and equipped with

aerosol-barrier filters. Do not autoclave pipette tips.

• DNA size markers (See Section IV.D)

• 5X Stop/loading buffer (Sambrook

et al.

[1989] provides several

recipes.)

CLONTECH Laboratories, Inc.

TEL:[phone] or 800-662-CLON Technical Support Protocol # PT3139-1 page
FAX:[phone] or 800-424-1350 Version # PR76834 9

PLEASE READ ENTIRE PROTOCOL BEFORE STARTING.

A. General Considerations

1. Thermal cycler
The guidelines for cycling parameters in this protocol have been

developed for a Perkin-Elmer DNA Thermal Cycler 480 or 9600 and
Perkin-Elmer GeneAmp 0.5-ml PCR reaction tubes. Newer cyclers

may allow for shorter cycle times and eliminate the need to use oil.
The optimal cycling parameters may vary with different templates,
primers, experimental protocols, tubes, and thermal cyclers.

Refer to the Troubleshooting Guide (Section V) for suggestions on
optimizing PCR conditions.

2. Primer design
Primer design is the single largest variable in PCR applications and the

single most important factor in determining the success or failure of
PCR reactions.

Always check and recheck your primer design before

constructing or ordering primers.

CLONTECH offers PRIMER
PREMIER (#V1072-1, V1079-1), powerful, easy-to-use software that
ensures optimal primer design.

Length and G/C content: The Advantage-HF PCR Kit can be used in
a wide variety of PCR applications, and the constraints on primer
design will vary from one application to the next. In general, however,
primers should have a Tm of at least 70°C to achieve optimal results in
a two-step cycling program with a 68°C annealing/extension step.
Therefore, whenever possible, primers should be

at least

22 nucleotides

(nt) long (25–30-mers are preferred) and have a GC content of 45–60%.

3. Template quality
Because of the exponential nature of PCR amplification, many conven-

tional PCR applications work well with templates of average or even
low quality. However, the longer the target, the more important tem­plate quality becomes. This is because the number of unnicked, full­length targets decreases as the target length increases, so poor quality
DNA will have very few large, unnicked targets. Furthermore, some
depurination occurs when DNA is denatured during thermal cycling,
and this can lead to strand scission. Therefore, it is particularly
important to prepare high-quality, high molecular weight DNA when
amplifying large targets.

Template quality is also important when the highest possible sensitivity
is needed. Furthermore, in cDNA applications such as RACE and other
RT-PCR protocols, incomplete reverse transcription can lead to an
absence of product, shorter than full-length products, or smearing.

For 5' and 3' RACE and general PCR from cDNA, you can ensure the
quality of your cDNA by using Marathon-Ready cDNA from CLONTECH.

IV. Advantage-HF PCR Kit Protocol

CLONTECH Laboratories, Inc.

page Protocol # PT3139-1 Technical Support TEL:[phone] or 800-662-CLON
10 Version # PR76834 FAX:[phone] or 800-424-1350

IV. Advantage-HF PCR Kit

continued

4. Good PCR practices
a. Prepare reactions with dedicated pipettors in a dedicated work space

Due to the tremendous amplification power of PCR, minute amounts
of contaminating DNA can produce nonspecific amplification; in
some instances, contaminants can cause DNA bands even in the
absence of added template DNA. We recommend that you set up
your PCR reactions in a dedicated lab area or noncirculating
containment hood and use dedicated pipettors, PCR pipette tips
with hydrophobic filters, and dedicated solutions.

Perform post-

PCR analysis in a separate area with a separate set of pipettors.

b. Pipetting

Because of the small volumes used in PCR experiments and the
potential for tube-to-tube variation, careful pipetting technique is
extremely important. Always be sure that no extra solution is on the
outside of the pipette tip before transfer. When adding solution to a
tube, immerse the tip into the reaction mixture, deliver the solution,
and rinse the pipette tip by pipetting up and down several times.

c. Use a Master Mix

Using a Master Mix greatly reduces tube-to-tube variation. There­fore, use a Master Mix whenever you set up multiple PCR reactions.
If multiple templates are being tested with the same primers, include
the primers in the Master Mix. If one template is being tested with
multiple primer sets, include the template in the Master Mix. For
several sets of parallel samples, assemble multiple master mixes
(e.g., each with a different set of primers).

The Master Mix should

be thoroughly mixed before use (i.e., vortexed without bubbling).

d. Include positive and negative controls (i.e., H2O instead of DNA

template)

5. Touchdown PCR
We have found that "touchdown" PCR significantly improves the

specificity of many PCR reactions in a wide variety of applications
(Section V.B.; Don

et al.

, 1991; Roux, 1995). Briefly, touchdown PCR
involves using an annealing/extension temperature that is several
degrees (typically 3–10°C)

higher

than the Tm of the primers during the
initial PCR cycles (typically 5–10). The annealing/extension tempera­ture is then reduced to the primer Tm for the remaining PCR cycles.

6. TaqStart Antibody provides automatic hot start PCR
Do not use a manual hot start or wax-bead-based hot start when using

Advantage-HF. As discussed in the Introduction, hot start is automatic
with Advantage-HF because the enzyme mix already contains TaqStart
Antibody.

CLONTECH Laboratories, Inc.

TEL:[phone] or 800-662-CLON Technical Support Protocol # PT3139-1 page
FAX:[phone] or 800-424-1350 Version # PR76834 11

7. Use of additives
TaqStart Antibody binds KlenTaq-1 DNA polymerase with high affinity

under the conditions described in this protocol. The addition of 2–5%
DMSO will not interfere with TaqStart function and may improve results
in some instances (see Section V.A.). However, the addition of
formamide or other cosolvents may disrupt TaqStart function. Further­more, excessive glycerol, solutes (e.g., salts), pH extremes, or other
deviations from the recommended reaction conditions may reduce the
effectiveness of the antibody and/or DNA polymerases.

B. Control PCR Reactions

The following PCR reactions can be performed in parallel with your
experiments as controls to ensure that the Advantage-HF Kit is working
properly. A positive control template and primers are provided in the kit.

1. Place all components on ice and allow to thaw completely. Mix each
component thoroughly before use.

2. Combine the following reagents in a 0.5-ml PCR tube.

Positive Negative

Control Control

32 µl37µl Purified H2O

5 µl5µl 10X HF PCR reaction buffer
5 µl --- Control DNA template (~0.2 ng/µl)
2 µl2µl Control primer mix (10 µM ea.)
5 µl5µl 10X HF dNTP mix
1 µl1µl 50X Advantage-HF Polymerase Mix

50 µl50µl Total

3. Mix well and spin the tube briefly to collect all the liquid in the bottom
of the tube.

4. Add 1–2 drops of mineral oil to prevent evaporation during cycling and
cap firmly. A good "capping" of mineral oil should have a well-defined
meniscus between the two phases.

5. Commence thermal cycling. If using a Perkin-Elmer DNA Thermal
Cycler Model 480 or 9600, use the parameters described in Section C
below. 20–22 cycles with a 4-min annealing/extension time is sufficient
for amplification of the positive control template provided in the kit.

6. Transfer a 5-µl sample of your PCR reaction to a fresh tube and add
1 µ l of 5X stop/loading buffer. Analyze your sample(s), along with
suitable DNA size markers, by electrophoresis on a 0.8–1.2 % agarose/
ethidium bromide gel.

Expected results: If you are using the positive control reagents provided
in the kit, the reaction should produce a single major band of 2 kb. No bands
should be generated in the negative (i.e., no DNA template) control.

IV. Advantage-HF PCR Kit

continued

CLONTECH Laboratories, Inc.

page Protocol # PT3139-1 Technical Support TEL:[phone] or 800-662-CLON
12 Version # PR76834 FAX:[phone] or 800-424-1350

IV. Advantage-HF PCR Kit

continued

C. Recommended Cycling Parameters

Use the following guidelines when setting up your initial experiments with
the Advantage-HF Polymerase Mix. These are general guidelines—the
optimal parameters may vary with different thermal cyclers and will depend
on your particular primers and templates, and on other experimental
variables. Note: When using the Advantage-HF Kit with products such as
CLONTECH's MarathonTM cDNA Amplification Kit, Marathon-Ready

TM

cDNAs, or the DeltaTM Differential Display, use the parameters recom­mended in the protocol for that kit.

Cycle Parameters

(PE 480) (PE 9600)

• 94°C for 1 min • 94°C for 15 sec

• 25–35 cycles

a

• 25–35 cycles

a

94°C 30 sec

b

94°C 5–15 sec

b

68°C 4 min

c

68°C 4 min

c

• 68°C for 3 min

d

• 68°C for 3 min

d

• Soak at 15°C • Soak at 15°C

a25 cycles for multiple-copy genes or medium-to-high abundance cDNAs; 30–35

cycles for single- or low-copy-number genes or rare cDNAs. For most applications,
we prefer two-step cycles (denaturation at T1 followed by annealing and extension at
T2) over three-step cycles (denaturation at T1 followed by annealing at T2 followed by
extension at T3). Three-step cycles will be necessary when the Tm of the primers is
less than 60–65°C and in certain special protocols (such as Delta Differential Display).

b

Use the shortest possible denaturation time. Exposure of DNA to high temperatures
causes some depurination of single-stranded DNA during denaturation, which
eventually leads to strand scission. High temperature also leads to gradual loss of
enzyme activity.

cUse the highest possible annealing/extension temperature. See Note a. Shorter

targets may be amplified using shorter extension times.
Some researchers prefer to use an annealing/extension time equal to the expected

target size plus two minutes.

dOptional: This final extension may reduce background in some cases.

CLONTECH Laboratories, Inc.

TEL:[phone] or 800-662-CLON Technical Support Protocol # PT3139-1 page
FAX:[phone] or 800-424-1350 Version # PR76834 13

IV. Advantage-HF PCR Kit

continued

D. Amplification of Longer Fragments with the Advantage Buffer

The Advantage HF Kit is provided with two buffers—the HF Buffer and the
standard cDNA Buffer. When used with the HF Buffer, this kit delivers the
highest possible fidelity. Fragments of up to ~2.5 kb can be amplified under
these conditions. To amplify longer fragments, some of the increase in
fidelity can be sacrificed to improve elongation efficiency by combining the
HF and cDNA buffers in varying proportions (see Figure 4). To amplify
longer fragments, we recommend replacing the smallest amount of HF
Buffer that allows satisfactory amplification. For example, the 6-kb frag­ment in Figure 4 can be amplified from a cDNA library in a 50-µl PCR
reaction containing 4 µl of 10X HF Buffer (80% final) and 1 µl of 10X cDNA
Buffer. Optimal conditions for the amplification of other fragments should be
determined individually. We recommend initially trying HF Buffer concen­trations in the 50–100% range for fragments up to 10 kb.

E. Recommendations for Electrophoresis

We recommend that you transfer a 5-µl sample of your PCR reaction to a
fresh tube and add 1 µl of 5X stop/loading buffer. (The remaining 45 µl of
the reaction mixture can be subjected to further cycling if you do not see a
product.) Analyze your sample(s), along with suitable DNA size markers,
by electrophoresis on a suitable agarose gel containing 0.1–0.5 µg/ml
ethidium bromide. The percentage agarose and the DNA size markers you
choose will depend on the expected range of insert sizes. You may wish to
refer to the following general guidelines before assembling your gel.

Recommendations for agarose gels:
Expected Recommended Recommended

insert size range % agarose DNA size markers

0.3–1.5 kb 1.5 φX174/

Hae

III

0.5–10 kb 1.2 1-kb DNA ladder
>5 kb 0.8 λ/

Hin

d III

CLONTECH Laboratories, Inc.

page Protocol # PT3139-1 Technical Support TEL:[phone] or 800-662-CLON
14 Version # PR76834 FAX:[phone] or 800-424-1350

The following general guidelines apply to most PCR reactions. However, no
attempt has been made to address troubleshooting for all of the many applica­tions for which the Advantage-HF Kit can be used. When using the kit with
another CLONTECH product, additional, application-specific troubleshooting
information can be found in the relevant User Manual.

A. No product observed

PCR component Use a checklist when assembling reactions. Always
missing or degraded perform a positive control to ensure that each com-

ponent is functional. If the positive control does not
work, repeat the positive control only. If the positive
control still does not work, repeat again replacing
individual components to identify the faulty reagent.

Too few cycles Increase the number of cycles (3–5 additional cycles

at a time).

Annealing temp. Decrease the annealing temperature in increments
too high of 2–4°C.

Suboptimal primer Redesign your primer(s) after confirming the accu­design racy of the sequence information. If the original

primer(s) was less than 22 nt long, try using a longer
primer. If the original primer(s) had a GC content of
less than 45%, try to design a primer with a GC
content of 45–60%.

Not enough Repeat PCR using a higher concentration of DNA
template (after trying more cycles).

Poor template Check template integrity by electrophoresis on a
quality standard TBE-agarose gel. If necessary, repurify

your template using methods that minimize shearing
and nicking.

Denaturation temp. Optimize denaturation temperature by decreasing or
too high or low increasing it in 1°C increments. (A denaturation

temperature that is too high can lead to degradation
of the template, especially for long target sequences.)

Denaturation time Optimize denaturation time by decreasing or increas­too long or too short ing it in 10-sec increments. (A denaturation time that

is too long can lead to degradation of the template,
especially for long target sequences.)

Extension time too (Especially with longer templates) Increase the
short extension time in 1-min increments.

V. Troubleshooting Guide

CLONTECH Laboratories, Inc.

TEL:[phone] or 800-662-CLON Technical Support Protocol # PT3139-1 page
FAX:[phone] or 800-424-1350 Version # PR76834 15

Too little enzyme Advantage-HF Polymerase Mix is 50X for most appli-

cations. Therefore, try to optimize the cycle param­eters as described above before increasing the en­zyme concentration. In rare cases, the yields can be
improved by increasing the concentration of the
enzyme mix. However, increasing the concentration
>2X is likely to lead to higher background levels.

[Mg2+] is too low KlenTaq-1 DNA polymerase has a broader Mg

2+

optimum than native

Taq

DNA polymerase (i.e., it
performs well over a wider range of [Mg2+] with no
loss of efficiency.) Therefore, as long as you use the
buffers included in the kit, it is unlikely that a lack of
product is due to problems with the Mg++ concentration.
However, if the concentration of EDTA in the cDNA
sample is more than 5 mM, this can reduce the effective
concentration of Mg to below a minimum level. Increas­ing the concentration of Mg2+ can result in lower
fidelity.

[dNTPs] not optimal The Advantage-HF PCR Kit contains a carefully

balanced mixture of the 4 dNTPs. Replacement of
this mixture with a standard dNTP mix (200 µM each)
may improve the DNA yield, but may also result in
lower fidelity.

Difficult target Some targets are inherently difficult to amplify. In

most cases, this is due to unusually high GC content
and/or secondary structure. The Advantage-GC Kits
are recommended in these situations.

B. Multiple products

Too many cycles Reducing the cycle number may eliminate nonspe-

cific bands.

Annealing temp. Increase the annealing/extension temperature in
too low increments of 2–3°C.

Suboptimal primer Redesign your primer(s) after confirming the accu­design racy of the sequence information. If the original

primer(s) was less than 22 nt long, try using a longer
primer. If the original primer(s) had a GC content of
less than 45%, try to design a primer with a GC
content of 45–60%.

V. Troubleshooting Guide

continued

CLONTECH Laboratories, Inc.

page Protocol # PT3139-1 Technical Support TEL:[phone] or 800-662-CLON
16 Version # PR76834 FAX:[phone] or 800-424-1350

Touchdown PCR "Touchdown" PCR significantly improves the speci­needed ficity of many PCR reactions in various applications

(Don

et al.

, 1991; Roux, 1995). Touchdown PCR
involves using an annealing/extension temperature
that is several degrees

higher

than the Tm of the
primers during the initial PCR cycles. The annealing/
extension temperature is then reduced to the primer
Tm for the remaining PCR cycles. The change can be
performed either in a single step or in increments
over several cycles.

Contamination See Section D below.

C. Products are smeared

Too many cycles Reduce the cycle number by 3–5 to see if non-

specific bands go away.

Denaturation temp. Try increasing the denaturation temperature in incre­too low ments of 1°C.

Extension time Decrease the extension time in 1–2-min increments.
too long

Poor template Check template integrity by electrophoresis on a de­quality denaturing agarose gel. Repurify your template if

necessary.

Touchdown PCR See "Touchdown PCR needed" under previous
needed section.

Too much enzyme Advantage-HF Polymerase Mix is 50X for most appli-

cations; however, a 1X final concentration of the
enzyme mix may be too high for some applications.
If smearing is observed, first try optimizing the cycle
parameters as described above, then try reducing
the enzyme concentration to 0.5–0.2X.

[Mg2+] is too high KlenTaq-1 DNA polymerase has a broader Mg

2+

optimum than native

Taq

DNA polymerase (i.e., it
performs well over a wider range of [Mg2+] with no
loss of efficiency.) Therefore, as long as you have
used the buffers supplied in the kit, it is unlikely that
smearing is due to problems with the Mg

2+

concentration. Altering the concentration of Mg++ can
result in lower fidelity.

Too much template Try a lower concentration of DNA template in the

PCR reaction.

Contamination See Section D below.

V. Troubleshooting Guide

continued

CLONTECH Laboratories, Inc.

TEL:[phone] or 800-662-CLON Technical Support Protocol # PT3139-1 page
FAX:[phone] or 800-424-1350 Version # PR76834 17

D. Dealing with contamination

Contamination most often results in extra bands or smearing. It is important
to include an H2O control (i.e., a control using H2O instead of the DNA
template) in every PCR experiment to determine if the PCR reagents,
pipettors or PCR reaction tubes are contaminated with previously amplified
targets.

If possible, set up the PCR reaction and perform the post-PCR analysis in
separate laboratory areas with separate sets of pipettors.

Laboratory benches and pipettor shafts can be decontaminated by
depurination. Wipe surfaces with 1N HCl followed by 1N NaOH. Then
neutralize with a neutral buffer (e.g., Tris or PBS) and rinse with H2O.

It is advisable to use one of the commercially available aerosol-free pipette
tips.

There is an enzymatic method for destroying PCR product carryover
(Longo

et al.

, 1990). It involves incorporation of dUTP into the PCR

products and subsequent hydrolysis with uracil-N-glycosylase (UNG).
When performing PCR directly on phage plaques or bacterial colonies,

failure to isolate single plaques or colonies will also produce multiple bands.

V. Troubleshooting Guide

continued

CLONTECH Laboratories, Inc.

page Protocol # PT3139-1 Technical Support TEL:[phone] or 800-662-CLON
18 Version # PR76834 FAX:[phone] or 800-424-1350

VI. References

Advantage-GC PCR Kits (January 1997)

CLONTECHniques

XII(1):2–3.

Barnes, W. M. (1994) PCR amplification of up to 35-kb DNA with high fidelity and high yield from λ
bacteriophage templates.

Proc. Natl. Acad. Sci. USA

91:2216–2220.

Cariello, N. F., Swenberg, J. A. & Skopek, T. R. (1991) Fidelity of

Thermococcus litoralis

DNA

polymerase (Vent) in PCR determined by denaturing gradient gel electrophoresis.

Nucleic Acids

Res.

19(15):4193–4198.

Cheng, S., Fockler, C., Barnes, W. M. & Higuchi, R. (1994) Effective amplification of long targets
from cloned inserts and human genomic DNA.

Proc. Natl. Acad. Sci. USA

91:5695–5699.

Chou, Q., Russell, M., Birch, D., Raymond, J. & Bloch, W. (1992) Prevention of pre-PCR mispriming
and primer dimerization improves low-copy-number amplifications.

Nucleic Acids Res.

20:1717–

1723.
d'Aquila, R. T., Bechtel, L. J., Videler, J. A., Eron, J. J., Gorczyca, P. & Kaplan, J. C. (1991)

Maximizing sensitivity and specificity of PCR by preamplification heating.

Nucleic Acids Res.

19:3749.
Don, R. H., Cox, P. T., Wainwright, B. J., Baker, K. & Mattick, J. S. (1991) 'Touchdown' PCR to

circumvent spurious priming during gene amplification.

Nucleic Acids Res.

19:4008.

Frey, B. & Suppmann, B. (1995) Demonstration of the ExpandTM PCR system's greater fidelity and
higher yields with a

lacI

-based PCR fidelity assay.

Biochemica

2:8–9.

Kellogg, D. E., Rybalkin, I., Chen, S., Mukhamedova, N., Vlasik, T., Siebert, P. & Chenchik, A. (1994)
TaqStart Antibody: Hotstart PCR facilitated by a neutralizing monoclonal antibody directed against

Taq

DNA polymerase.

BioTechniques

16:1134–1137.

Ling, L. L., Keohavong, P., Dias, C. & Thilly, W. G. (1991) Optimization of the polymerase chain
reaction with regard to fidelity: modified T7,

Taq

, and Vent DNA polymerases.

PCR Methods Appl.

1:63–69.
Longo, M. C., Berninger, M. S. & Hartley, J. L. (1990) Use of uracil DNA glycosylase to control carry-

over contamination in polymerase chain reactions.

Gene

93:3749.

Mo, J. Y., Maki, H. & Sekiguchi, M. (1991) Mutational specificity of the dnaE173 mutator associated
with a defect in the catalytic subunit of DNA polymerase III of

Escherichia coli. J. Mol. Biol.

222:925–

936.
Nelson, K., Brannan, J. & Kretz, K. (1995) The fidelity of TaqPlusTM DNA Polymerase in PCR.

Strategies Mol. Biol.

8:24–25.

Roux, K. H. (1995) Optimization and troubleshooting in PCR.

PCR Methods Appl

. 4:5185–5194.

Sambrook, J., Fritsch, E. F. & Maniatis, T. (1989)

Molecular Cloning: A Laboratory Manual, Second

Edition

(Cold Spring Harbor Laboratory, Cold Spring Harbor, NY).

CLONTECH Laboratories, Inc.

TEL:[phone] or 800-662-CLON Technical Support Protocol # PT3139-1 page
FAX:[phone] or 800-424-1350 Version # PR76834 19

VII. Related Products

Product Cat. #

• Advantage® cDNA PCR Kit #K1905-1, -y

• Advantage® cDNA Polymerase Mix #8417-1

• Advantage® Genomic PCR Kit #K1906-1, -y

• Advantage® Genomic Polymerase Mix #8418-1

• Advantage®-GC cDNA PCR Kit #K1907-1, -y

• Advantage®-GC cDNA Polymerase Mix #8419-1

• Advantage®-GC Genomic PCR Kit #K1908-1, -y

• Advantage®-GC Genomic Polymerase Mix #8420-1

• Advantage® UltraPure dNTPs (many)

Other Related Products

• TaqStartTM Antibody #5400-1, -2

• TthStartTM Antibody #5401-1

• PRIMER PREMIER many

• Poly A+ RNA many

• Multiple Tissue Northern (MTNTM) Blots many

• UltraPure PCR Deoxynucleotide Mix #4700-1

Advantage®, Advantage®-GC, Advantage®-HF,
DeltaTM, Marathon-ReadyTM, TaqStartTM, and TthStart

TM

are trademarks of CLONTECH Laboratories, Inc.
GeneAmp

TM

is a trademark of Hoffmann-La Roche, Inc.

Deep Vent

R

TM

is a trademark of New England Biolabs,

Inc.

© 1997, CLONTECH Laboratories, Inc. All rights
reserved.
