Arrow 5.1

OOwwnneerr’’ss GGuuiiddee

limited lifetime consumer warranty

Directed Electronics ("Directed") promises to the original purchaser to repair or replace with a comparable reconditioned model any Directed unit (hereafter the "unit"), excluding without limitation the siren, the remote transmitters, the associated sensors and accessories, which proves to be defective in workmanship or material under reasonable use during the lifetime of the vehicle provided the following conditions are met: the unit was professionally installed and serviced by an authorized Directed dealer; the unit will be professionally reinstalled in the vehicle in which it was originally installed by an authorized Directed dealer; and the unit is returned to Directed, shipping prepaid with a legible copy of the bill of sale or other dated proof of purchase bearing the following information: consumer's name, telephone number and address; the authorized dealers name, telephone number and address; complete product description, including accessories; the year, make and model of the vehicle; vehicle license number and vehicle identification number. All components other than the unit, including without limitation the siren, the remote transmitters and the associated sensors and accessories, carry a one-year warranty from the date of purchase of the same. This warranty is non-transferable and is automatically void if: the original purchaser has not completed the warranty card and mailed it within ten (10) days of the date of purchase to the address listed on the card; the unit's date code or serial number is defaced, missing or altered; the unit has been modified or used in a manner contrary to its intended purpose; the unit has been damaged by accident, unreasonable use, neglect, improper service, installation or other causes not arising out of defects in materials or construction. The warranty does not cover damage to the unit caused by installation or removal of the unit. Directed, in its sole discretion, will determine what constitutes excessive damage and may refuse the return of any unit with excessive damage. TO THE MAXIMUM EXTENT ALLOWED BY LAW, ALL WARRANTIES, INCLUDING BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED WARRANTY, WARRANTY OF MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE AND WARRANTY OF NON-INFRINGEMENT OF INTELLECTUAL PROPERTY, ARE EXPRESSLY EXCLUDED; AND DIRECTED NEITHER ASSUMES NOR AUTHORIZES ANY PERSON OR ENTITY TO ASSUME FOR IT ANY DUTY, OBLIGATION OR LIABILITY IN CONNECTION WITH ITS PRODUCTS. DIRECTED DISCLAIMS AND HAS ABSOLUTELY NO LIABILITY FOR ANY AND ALL ACTS OF THIRD PARTIES INCLUDING ITS AUTHORIZED DEALERS OR INSTALLERS. DIRECTED SECURITY SYSTEMS, INCLUDING THIS UNIT, ARE DETERRENTS AGAINST POSSIBLE THEFT. DIRECTED IS NOT OFFERING A GUARANTEE OR INSURANCE AGAINST VANDALISM, DAMAGE OR THEFT OF THE AUTOMOBILE, ITS PARTS OR CONTENTS; AND HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY WHATSOEVER, INCLUDING WITHOUT LIMITATION, LIABILITY FOR THEFT, DAMAGE AND/OR VANDALISM. THIS WARRANTY DOES NOT COVER LABOR COSTS FOR MAINTENANCE, REMOVAL OR REINSTALLATION OF THE UNIT OR ANY CONSEQUENTIAL DAMAGES OF ANY KIND. IN THE EVENT OF A CLAIM OR A DISPUTE INVOLVING DIRECTED OR ITS SUBSIDIARY, THE PROPER VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF CALIFORNIA. CALIFORNIA STATE LAWS AND APPLICABLE FEDERAL LAWS SHALL APPLY AND GOVERN THE DISPUTE. THE MAXIMUM RECOVERY UNDER ANY CLAIM AGAINST DIRECTED SHALL BE STRICTLY LIMITED TO THE AUTHORIZED DIRECTED DEALER'S PURCHASE PRICE OF THE UNIT. DIRECTED SHALL NOT BE RESPONSIBLE FOR ANY DAMAGES WHATSOEVER, INCLUDING BUT NOT LIMITED TO, ANY CONSEQUENTIAL DAMAGES, INCIDENTAL DAMAGES, DAMAGES FOR THE LOSS OF TIME, LOSS OF EARNINGS, COMMERCIAL LOSS, LOSS OF ECONOMIC

OPPORTUNITY AND THE LIKE. NOTWITHSTANDING THE ABOVE, THE MANUFACTURER DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR THE CONTROL MODULE AS DESCRIBED ABOVE. Some states do not allow limitations on how long an implied warranty will last or the exclusion or limitation of incidental or consequential damages. This warranty gives you specific legal rights and you may also have other rights that vary from State to State.

This product may be covered by a Guaranteed Protection Plan ("GPP"). See your authorized Directed dealer for details of the plan or call Directed Customer Service at 1-800-876-0800. Directed security systems, including this unit, are deterrents against possible theft. Directed is not offering a guarantee or insurance against vandalism, damage or theft of the automobile, its parts or contents; and hereby expressly disclaims any liability whatsoever, including without limitation, liability for theft, damage and/or vandalism. Directed does not and has not authorized any person or entity to create for it any other obligation, promise, duty or obligation in connection with this security system.

Make sure you have all of the following information from your dealer:

A clear copy of the sales receipt, showing the following:

Date of purchase

Your full name and address

Authorized dealer's company name and address

Type of alarm installed

Year, make, model and color of the automobile

Automobile license number

Vehicle identification number

All security options installed on automobile

Installation receipts

trademarks and copyrights

Bitwriter™, Clifford®, Code-Hopping™, Directed®, Doubleguard®, ESP™, FailSafe®, Ghost Switch™, Learn Routine

™

, Nite-Lite®, Nuisance Prevention Circuitry®, NPC®, Revenger®, Silent Mode™, Soft

Chirp

, Stealth Coding™, Stinger®, Valet®, Vehicle Recovery System®, VRS®, and Warn Away

are all Trademarks or Registered Trademarks of Directed Electronics, Inc.

iimmppoorrttaanntt!!

Please note that this manual was intended for US consumers

and therefore includes American phrases or words.

limited lifetime consumer warran-

ty . . . . . . . . . . . . . . . . . . . . . . . . . . .i

trademarks and copyrights . . . . .ii

table of contents . . . . . . . . . . . . .1

what is included . . . . . . . . . . . . . .2

important information . . . . . . . . .2

your warranty . . . . . . . . . . . . .3

fcc/id notice . . . . . . . . . . . . . . .3

replacement remote controls . . .4

transmitter functions . . . . . . . . . .6

standard configuration . . . . . . .6

using your system . . . . . . . . . . . . .7

arming . . . . . . . . . . . . . . . . . . .7

disarming . . . . . . . . . . . . . . . . .8

disarming without a transmitter9

remote siren silencing . . . . . . .9

transmitter chirp muting . . . . .9

transmitter sensor disable . . .10

intellistart and smartwindows

sensor bypass . . . . . . . . . . . . .10

auxiliary channel bypass . . . . .11

panic mode with smart door

locking . . . . . . . . . . . . . . . . . .11

valet mode . . . . . . . . . . . . . . .11

transmitter valet mode . . . . . .12

battery saver mode . . . . . . . .13

low battery warning . . . . . . .13

instant auto-arming bypass . .13

multiple event total recall . . . .14

false alarm control technology

(FACT II) . . . . . . . . . . . . . . . . .14

select siren sounds . . . . . . . . . . .15

diagnostics . . . . . . . . . . . . . . . . . .16

arming diagnostics . . . . . . . . .16

disarming diagnostics . . . . . . .17

arm/disarm diagnostic chart . .17

table of zones . . . . . . . . . . . .17

anti-code grabbing (ACG) . . . . .18

smart power up II . . . . . . . . . . . .19

power saver mode . . . . . . . . . . .19

programming options . . . . . . . .20

manual programming instruc-

tions . . . . . . . . . . . . . . . . . . .21

user selectable features . . . . .22

user selectable features descrip-

tions - column one . . . . . . . . .23

user selectable features descrip-

tions - column two . . . . . . . .25

user selectable features descrip-

tions - column three . . . . . . .27

pin programming . . . . . . . . . .29

glossary of terms . . . . . . . . . . . . .30

security & convenience expansions

health check . . . . . . . . . . . . . . . .34

table of contents

what is included

Arrow 5.1 control module and harness

Two three-button transmitters

External antenna/receiver with harness

Pre-wired blue status LED

PlainView 2 Valet switch

504C dual-stage shock sensor with harness

514C neo-siren

Presentation pack

Quick reference card

Two window decal's

important information

Congratulations on the purchase of your state-of-the-art vehicle

security system. It has been designed to provide years of trouble-free

operation. This system must be installed by an authorized dealer.

Installation of this product by anyone other than an authorized dealer

voids the warranty. As verification of authorization, all authorized deal-

ers are provided with preprinted dealer certificates.

In order to maximize the use of this system, please review this owner's

guide carefully prior to using your system. You can print additional or

replacement copies of this owner’s guide by accessing the Clifford web-

site at www.clifford.com.

system maintenance

The system requires no specific maintenance. Your transmitter is pow-

ered by a pair of miniature 3V lithium batteries (CR2016) that will last

approximately one year under normal use. When the battery weakens,

operating range will be reduced and the system will provide a low bat-

tery warning chirps indication when disarming.

your warranty

Your warranty registration must be completely filled out and returned within 10 days of purchase. Your product warranty will not be validated if your warranty registration is not returned. Make sure you receive the warranty registration from your dealer. It is also necessary to keep your proof of purchase, which reflects that the product was installed by an authorized dealer.

fcc/id notice

This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesirable operation.

Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this device.

replacement remote controls

You can purchase replacement remote controls from your

Authorized Dealer or on-line at the following web site:

www.directedstore.com

Once you receive your new remote control, please refer to

instructions included on the remote packaging.

Directed Electronics, Inc.

Tested to Comply

with FCC Standards

DRW-396

transmitter configurations

1. LED Indicator

2. Arm/Disarm Button

3. Trunk Release Button

4. Remote Start Button

transmitter functions

This system uses computer-based code learning to learn the transmitter buttons. This makes it possible to assign any transmitter button to any system function. The transmitter initially comes programmed with standard configuration, but may also be customized using the CliffNet Wizard PC program. The buttons in all of the instructions in this manual correspond to a standard configuration transmitter.

standard configuration

Button

The arming, disarming, and panic function are controlled by this button.

Button

The trunk release or accessory output is controlled by this button.

Button

An optional accessory convenience or expansion function that you have

added to your system can be activated by pressing this button.

and Buttons

When pressed together, these buttons control silent arm and disarm.

and Buttons

When pressed together, these buttons disable the 504C shock sensor.

and Buttons

When pressed together, these buttons control the remote valet.

using your system

The buttons used in the instructions in this manual correspond to the

standard transmitter configuration. If your transmitter has been custom

configured, the icons on your transmitter buttons may not correspond

to the indicated functions.

arming

You can activate, or arm, the system by pressing on your trans-

mitter for one second. When the system arms, you will hear two short

siren sounds, or chirps, and see the parking lights flash twice. The LED

will begin to flash steadily. If the vehicle’s power door locks have been

connected to the system, the doors will lock.

While the system is armed, the LED status indicator will flash approxi-

mately once per second showing that the system is actively protecting

your vehicle. If you hear more than two chirps when arming, refer to

the Diagnostics section of this guide. These extra chirps confirm a mal-

function autobypass.

The security system also can be programmed to arm itself

automatically (called passive arming). If the system is programmed for

passive arming, it will automatically arm 30 seconds after the ignition is

turned off and the system sees you leave the vehicle by opening and

closing a door. Whenever the system is in its 30-second passive-arming

countdown. The siren will chirp twice and the lights will flash twice five

seconds after the last door has been closed. The system is not actually

armed at that point. The system arms and the doors lock (if connected

and programmed for passive locking) at 30 seconds, but the siren will

not chirp. The early chirps provide you with a 25-second warning prior

to arming.

When armed, your vehicle is protected as follows:

The LED will flash as a visible theft deterrent.

Light impacts will trigger the Warning Zone signal. When triggered, the siren will chirp for a few seconds.

Heavy impacts will trigger the system. The triggered sequence is 30, 60, or 90 seconds of constant siren chirping and flashing parking lights.

If a protected entry (door, hood, or trunk) is opened, the system will immediately trigger the siren and flash the parking lights.

The optional immobilizer prevents the vehicle’s starter from cranking.

disarming

To disarm the system, press . You will hear a chirp and the park-

ing lights will flash once. If the power locks are connected to the sys-

tem, the doors will unlock. If the siren chirps three times when disarm-

ing, refer to the Diagnostics section of this guide. This is called Tamper

Alert. If the siren is active when the system is disarmed you will hear

two chirps but the system is not disarmed. (Refer to the Remote Siren

Silencing section of this guide.) However, if the alarm completes the full

trigger cycle when disarmed you will hear three chirps.

nnoottee::

If any protected entry point (a door or a switch-protected trunk or hood) is open, the system will not passively arm. Additionally, each time a protected entry is triggered during the arming countdown, the 30-second countdown starts over.

disarming without a transmitter

This feature allows you to disarm the system without the transmitter

should it be lost, damaged, or disabled. In order to disarm without a

transmitter, you must have the vehicle’s ignition key, know where the

PlainView 2 Valet switch is located, and have the PIN code. Be sure to

check with the installer for the location of the PlainView 2 Valet switch

and instructions for entering the PIN code. Turn the ignition On and

then press the button twice (factory PIN default setting) and the

button once to disarm without a transmitter.

remote siren silencing

This system offers remote siren silencing. Remote siren silencing is a fea-

ture that makes it possible to silence and reset the system when it is

triggering without disarming the system. If the system is triggered and

the siren has been sounding, press on the transmitter to stop the

trigger and return the unit to the armed state. The system will not dis-

arm, but rather reset. This prevents you from disabling the system

should you wish to silence it without visually checking the vehicle. After

resetting the system, press again to disarm the system.

transmitter chirp muting

To temporarily turn off the arm or disarm chirps, use transmitter chirp

muting. Simply press and simultaneously on the trans-

mitter, and the confirmation chirp(s) will be eliminated for that one op-

eration only. The parking lights will flash to confirm the arm/disarm

command. If you want the arm/disarm chirps turned off permanently,

please refer to the User-Selectable Features section of this guide.

transmitter sensor disable

To temporarily disable a sensor input, arm the system, press the

and simultaneously. The lights will flash four times and all warn

away trigger zones three and eight are bypassed. Press the buttons

again; the lights flash four times and both warn away and full trigger

zones three and eight are bypassed until the system is disarmed. This

can be performed anytime the system is armed.

1. Arm the system.

2. Using the transmitter, bypass the sensor.

3. The lights will flash four times; all warn away zones are now bypassed.

4. Transmit the sensor bypass channel again.

5. The lights will flash four more times; the sensor warn away and full trigger zones are now bypassed.

6. The sensor zones will reset when disarmed.

intellistart and smartwindows sensor bypass

When the system sees a command to start the vehicle via the

Intellistart, it bypasses zones three, seven, and eight, and will continue

bypass these zones until the remote start shuts down. Zone four will

bypass for 5 seconds from the time it remote starts and again for 5 sec-

onds after remote start shut down.

When the system sees a SmartWindows command for up or down

operation, the unit will automatically bypass zones three and eight until

the windows complete their operation.

auxiliary channel bypass

Alarm sensor input zones three and eight will be bypassed while a

pulsed or timed auxiliary Output is active.

panic mode with smart door locking

If you are threatened in or near your vehicle, you can attract attention

by triggering the system with your transmitter! Just press for

two seconds to enter Panic Mode. The siren will sound and the park-

ing lights will flash for the programmed duration. If the ignition is on,

the doors will lock; if the ignition is off, the doors will unlock. To stop

Panic Mode at any time press on the transmitter again.

valet mode

You can prevent your security system from automatically arming by

using Valet Mode. This is very useful when washing the vehicle or hav-

ing it serviced. In Valet Mode, the security system will not arm, even

with the transmitter, but all convenience functions (door locks, trunk

release, etc.) will continue to work normally.

nnoottee::

If the ignition is on, the doors will lock; if off, the doors will

unlock.

nnoottee::

Intellistart and SmartWindows are optional Clifford accessories.

Ask your dealer for more details.

To enter Valet Mode:

1. Turn the ignition on.

2. Enter PIN code (factory setting is 2).

3. After the last digit continue to hold for three seconds.

The LED status indicator will light steadily if you are entering Valet

Mode and will turn off if you are exiting Valet Mode.

To exit Valet Mode:

1. Turn the ignition on.

2. Within 10-seconds press once.

transmitter valet mode

The operations described in this section refer to transmitter buttons.

Remember, the buttons used in all the instructions in this guide corre-

spond to a Standard Configuration transmitter. This may not be how

your transmitter is set up.

To enter Valet Mode, press and simultaneously. The LED

nnoottee::

The pin code can be entered after turning the ignition On and the press

and hold the blank key on the PlainView 2 Valet switch for one second.

status indicator will light solid if you are entering Valet Mode, or will

turn off if you are exiting Valet Mode.

battery saver mode

After 48 hours in the armed state, the LED will decrease the flash rate to

the normal rate; after 96 hours it will decrease to

the normal rate.

low battery warning

When the transmitter battery is low, the system will generate five quick

chirps when disarmed.

instant auto-arming bypass

This will bypass the auto arm feature once only.

1. With the key, turn the ignition on, then off within two seconds.

2. The siren will chirp once to confirm auto arming bypass.

3. The system will not auto arm.

During auto arming bypass the system will not roll up the windows if

SmartWindows is connected, and the accessory output will not auto-

activate when using the remote to arm the system.

nnoottee::

The system will revert to normal auto arming when the system

sees the ignition on for at least three seconds.

nnoottee::

The optional self-powered smart siren will generate a low-pitched tone.

multiple event total recall

This will report the last eight system triggers.

1. Press and hold of the PlainView 2 Valet switch.

2. While still holding , arm and disarm the system, then release the button.

3. The LED will start to blink to indicate the most recent trigger and proceed down to the eighth trigger. If fewer than eight triggers are stored in memory, the LED will blink continuously until the system is armed/disarmed using the transmitter after recalling the final trigger. For more information, please refer to the Table of Zones section of this guide.

false alarm control technology (FACT II)

Your system offers FACT

II, a feature that prevents annoying

repetitive trigger sequences due to a faulty sensor or environmental

conditions such as thunder, jackhammers, airport noise, etc.

Here’s how it works: The alarm triggers three times. If the same sensor

is triggering the alarm and the first and the third triggers are within 60

minutes of each other, FACT

II will interpret this pattern of triggers as

false alarms. After the third trigger, FACT

II ignores, or bypasses, that

sensor (along with any other sensors sharing the same zone) for 60

minutes.

If the bypassed sensor tries to trigger the system while it is being

bypassed, the 60-minute bypass period will start over. This ensures that

a sensor that continually triggers will remain bypassed.

Doors are covered by FACT II differently; if the alarm is triggered by an

open door for three full cycles, the doors will be bypassed until the trig-

ger ceases. FACT

II is programmable. See the Programming Options

section of this guide.

select siren sounds

Selectable siren sounds are available with the optional self-powered

smart siren (515C) only. Contact your local dealer for more information.

The 515C transmits a two-way digital signal between itself and the con-

trol unit. If a thief disconnects power and/or cuts or tampers with any or

all of the siren wires while the system is armed, the siren will sound for

five minutes and then reset. Since this will only occur while the system is

armed, there is no need for a siren override key. Unlike other back-up

battery sirens that constantly drain the car battery, Clifford’s design draws

charging current only when the ignition is on (i.e., engine running). If the

internal battery is discharged, the arm/disarm chirps are muted.

If a self-powered smart siren has been added to your system, please

refer to the selectable siren sounds feature in the User Selectable

Features grid. Once in programming mode, press on the trans-

mitter to begin playback of the available sounds.

nnoottee::

Arming and disarming the system does not reset this function! The only way to reset a bypassed zone is for 60 minutes or to turn on the ignition. If testing your system, it is important to remember that the FACT II programming can cause zones to be bypassed and appear to stop working. If you wish to clear the FACT II memory, turn the ignition key on.

Press on the PlainView 2 Valet switch while playing the desired

sound to add that sound; press while playing the desired sound to

delete that sound.

diagnostics

The microprocessor at the heart of your security system is constantly monitoring all of the switches and sensors that are connected to it. It detects any faulty switches and sensors and prevents them from disabling the entire system. The microprocessor will also record and report any triggers that occurred during your absence.

arming diagnostics

If the system is armed while an input is active (door open, sensor trig-

gering, etc.) the unit will chirp twice when arming and then four more

times five seconds later. This is called Bypass Notification.

The security system will ignore the input that was active when the sys-

tem was armed, until the input goes away. Three seconds later the sys-

tem will monitor that input normally. For example, if your vehicle has

interior light exit delay, and you arm the system before the interior light

goes out, you may hear Bypass Notification chirps. Once the light shuts

off, however, the doors are monitored normally.

disarming diagnostics

Extra disarm chirps are the Tamper Alert. If three chirps are heard when

disarming, the system was triggered in your absence. If three chirps are

heard, the LED status indicator will indicate which zone was involved

(see the Table of Zones section). The system will retain this information

in its memory. Refer to the Multiple Event Total Recall section of this

guide.

arm/disarm diagnostic chart

table of zones

The zone number is the number of LED flashes used by the system to identify a specific input. The standard input assignments are listed below, along with spaces to write in any optional sensors or switches you have had installed. If the Warning Zone response is triggered, the LED will not report it.

Action Chirps Light Flashes Description

Arm 2 2 System armed

Arm 4 4 System armed with hood/

trunk active and bypassed (zones 5 and 6)

Arm 2 (5 sec.) 4 2 (5 sec.) 4 System armed with door

active and bypassed (zone 4)

Arm 2 (10 sec.) 4 2 (10 sec.) 4 System armed with sensor

active and bypassed zones 3 and 8

Disarm 1 1 System disarmed

Disarm 3 3 System disarmed with

tamper alert

Disarm 5 5 System disarmed with low

battery warning

anti-code grabbing (ACG)

This unit features Anti-Code Grabbing (ACG) with Random Code

Encryption. This means the receiver and transmitters each use a math-

ematical formula called an algorithm to change their code each time

the transmitter is used. This technology has been developed to increase

the security of the unit. The control unit knows what the next codes

should be.

Zone - Number Dealer-Installed of LED Flashes Description Options

3 Instant trigger - a heavier

impact detected by the shock sensor

4 Door switch trigger

5 Instant trigger - often used

for hood/trunk pinswitches

7 Ignition trigger

8 Instant trigger - for optional

sensors

10 System Power Reset

smart power up II

This security system will store its current state to non-volatile memory.

If power is lost and then reconnected the system will recall the stored

state from memory. This means if the unit is in Valet Mode and the bat-

tery is disconnected for any reason, such as servicing the car, when the

battery is reconnected the unit will still be in Valet Mode. This applies

to all states of the system including arm, disarm, and Valet Mode.

power saver mode

Your system will automatically enter Power Saver Mode while armed or

in Valet Mode, after a period of time in which no operation has been

performed. This lowers the current draw on the vehicle's battery and

prevents the system from draining the battery. Power Saver Mode takes

over under the following conditions:

Power Saver when the system is armed: After the system has been armed for 48 hours, the LED will flash at half its normal rate, decreasing the system's current draw.

Power Saver in Valet Mode: When the system enters Valet Mode the LED illuminates steadily. If the vehicle is not used (ignition is not turned on) for a period of one hour while the system is in Valet Mode, the LED will shut off. If the system remains in Valet Mode, the LED will come back on the next time the ignition is turned on and then back off.

programming options

Programming options control what your system does during normal

operation, and require few or no additional parts. However, some may

require additional installation labor.

Following is a list of the program settings, with the factory settings in bold:

Active arming (only with the transmitter) or passive arming (automatic arming 30-seconds after the last door is closed). If programmed for passive arming, a feature called Smart Relocking will occur when the system is disarmed without opening a door, so that the doors will automatically lock when the system passively rearms.

Arming/disarming confirmation siren chirps on or off.

Auto-Lock/Auto-Unlock on or off: With this feature on, the doors will lock three seconds after the ignition is turned on, and unlock when the ignition is turned off. If your installer is programming the security system with the CliffNet®Wizard, ignition lock and unlock are independent features and can be programmed separately.

Passive door locking (with passive arming) or active door locking (only when arming with the transmitter). Passive locking allows the vehicle's doors to lock when the security system passively arms (after the 30 second countdown). This feature only works if passive arming has been programmed.

Panic mode enabled/disabled: Some states have laws against siren capability.

Full trigger response 30, 60, or 90 seconds: This determines how long the full triggered sequence lasts. Some states have laws regulating how long a security system can sound before it is considered a nuisance.

False Alarm Control Technology (FACT II) on or off: Please refer to the FACT II section of this guide for a complete explanation of how FACT II operates. If FACT II is programmed off, the security system will respond to inputs from any sensor indefinitely.

Siren tones and chirp volume: The output of the siren consists of six different tones in sequence. Any of these tones can be eliminated by your dealer, resulting in a unique, easily identifiable siren sound. The siren chirps can be either full volume or 6 decibels quieter than the full alarm blast.

manual programming instructions

Be sure to document changes by taking note of all feature changes

made in programming mode.

To enter the User Selectable Features programming:

1. Ignition on - Turn the ignition to the run position or start the engine.

2. Enter PIN - Enter the factory preset PIN code of 2 by pressing on the PlainView 2 Valet switch twice, then once.

3. Hold/Chirp/Release - After entering the PIN code, press and hold until a chirp is heard and the LED turns on, then release the button. You have now entered the feature selec-

nnoottee::

If the factory preset PIN has been changed, the new PIN must

be entered.

nnoottee::

Because many states have laws regulating security systems, pro-

gramming FACT II off may cause your system to violate state laws.

tion position of the User Selectable Features grid.

4. Column select - Press the same number of times as the desired column. After a pause the siren will chirp the same number of times as the selected column for confirmation.

5. Feature select - Press the same number of times as the desired feature. The siren will chirp with each press. The feature can now be changed using the remote control.

6. Feature change - Press on the transmitter. If the system chirps once, the feature has just turned off; if the system chips twice, the feature has just turned on. If the feature has more than two settings, continue pressing on the transmitter to toggle through the settings.

You can advance to any feature in the same column by pressing within 60 seconds; to program a feature in a different column begin at step 4 within 60 seconds.

7. Exit programming - To exit programming mode turn the ignition off or wait 60 seconds without pressing the PlainView 2 Valet switch. The siren will chirp three times to indicate programming mode has been exited.

user selectable features

nnoottee::

Refer to the

Feature Descriptions

sections of this guide for impor-

tant notes and descriptions of the system features and programming.

* This feature is only available with optional 515C siren. ** This feature is only available with optional IntelliStart connected. *** This feature is only available with optional SmartWindows connected.

user selectable features descriptions - column one

add new remote (auto learn)

Auto-learn new three-button remote controls to the system in the standard button configuration. Once you have entered the feature, press on the transmitter until you hear a confirmation chirp.

auto arm - on/off

Then Press

First Press

Add new remote

(autolearn)

Auto arm

on/off

Chirps

on/off/quiet*

Auto lock

ignition/off/rpm**

Auto unlock

ignition/off

Passive lock

on/off

Siren duration

30/60/90

Autostart/off**

(battery only,

temp only, and

battery and temp)

Set PIN code New remote learn

arm/disarm only

Select siren

sounds*

FACT II on/off New remote learn

Remote valet

on/off

Entry delay on/off New remote learn

Reset to default

(except transmitter

and valet code)

Panic on/off Clear all remotes

Not used Not used

New remote learn

accesory output

silent mode

New remote learn

remote valet

remote start**

New remote learn

window

down/vent***

On: When the system sees the ignition turn off and the last protected entry (door, hood, or trunk) close, it will begin a 30-second countdown before arming itself. After the first five seconds, you will hear two chirps and the lights will flash. The system will arm 25 seconds later.

Off: The transmitter must be used to arm the system.

chirps - on/off/quiet

On: Chirps will sound when arming/disarming the system.

Off: Chirps will not sound when arming/disarming the system.

Quiet: Chirps will sound when arming/disarming the system but at a lower pitch tone than normal. This feature is only available with the 515C siren.

auto lock - ignition/off/rpm

Ignition: The doors will automatically lock three seconds after the ignition is turned on unless a door is open at that time.

Off: The doors will not lock automatically.

Rpm: The doors will lock when the system sees the engine reach a preprogrammed RPM. This feature is only available with IntelliStart.

auto unlock - ignition/off

Ignition: The doors will automatically unlock as soon as the ignition is turned off.

Off: The doors will not automatically unlock when the ignition is turned off.

passive lock - on/off

On: The doors will lock when the system passively arms. This feature only applies when passive arming is programmed on.

Off: The doors will not lock when the system passively arms.

siren duration - 30/60/90

The system will sound the alarm for the programmed duration (30/60/90 seconds) during an alarm trigger or when the system is put into panic mode.

auto start setting - off/battery only/temp only/battery and temp

This feature is only available with the IntelliStart option.

Off: The vehicle will not autostart.

Battery: The vehicle will only autostart when the car battery gets low.

Temperature: The vehicle will only autostart at a preset low temperature.

Battery and temperature: The vehicle will autostart with a low car battery or low temperature.

user selectable features descriptions - column two

set pin code

This feature allows the setting of the user's personal PIN code. For more information, please refer to the PIN Programming section of this guide.

nnoottee::

Temperature and battery calibration and settings can be made

only with the Cliffnet Wizard Pro.

select siren sounds

The individual sounds the 515C siren produces during an full trigger alarm can be customized for owner recognition of an alarm trigger. For more information, please refer to the Select Siren Sounds section of this guide.

fact II on/off

On: The alarm will bypass for 60 minutes if zones 3, 5, and 8 are triggered three times within a one hour period.

Off: The alarm will respond to zones 3, 5, and 8 inputs indefinitely without bypassing.

remote valet on/off

On: The alarm can be put into valet mode with the remote control.

Off: The alarm can not be put into valet mode with the remote control.

entry delay on/off

On: If the system has passively armed, it will not trigger for 15 seconds after a door is opened allowing the user to enter the vehicle and disarm the system via the PlainView 2 Valet switch.

Off: There is no entry delay when armed. The system will trigger instantly when a door is opened.

reset to default settings

All system settings (except PIN and remote programming) in the User Programming grid will be reset to their default factory setting as indicated in bold lettering.

Press on the transmitter; the siren will chirp twice as confirmation.

panic on/off

On: The panic feature is available.

Off: The panic feature is not available.

user selectable features descriptions - column three

The features in this column pertain to programming individual trans-

mitter channels in custom configurations. Following is an explanation

of the features. To program specific functions to a different button,

enter the function you are programming after the chirp confirmation.

Press the button with which you wish to control that feature; the sys-

tem will chirp to confirm that it has learned the new button.

arm/disarm only

The remote control channel programmed into this feature will arm/disarm the system only.

accessory output

The transmitter channel programmed into this feature will activate the accessory output.

silent mode

The transmitter channel programmed into this feature will arm/disarm the system, but the siren will not chirp.

nnoottee::

When programming a remote control to custom configuration, a transmitter button must first be learned to the arm/disarm channel by pressing the desired button once (one chirp), then again (two chirps). The rest of the features in this column can then be learned by pressing the desired button once. The siren will chirp the same number of times as the feature row as confirmation.

remote valet

The transmitter channel programmed into this feature will make the system enter/exit valet mode.

remote start

This feature is only available with IntelliStart connected

The transmitter channel programmed into this feature will activate or shut down the Intellistart remote start system.

window control

This feature is only available with SmartWindows connected

The transmitter channel programmed into this feature will activate the vent or roll down feature of the SmartWindows system.

clear all remotes

This feature will erase all remote codes from the system memory. This feature is convenient for erasing any transmitters that have been lost, stolen, or incorrectly programmed into the system.

After entering this feature press any button on the transmitter; the siren will chirp to indicate that all transmitters have been erased from memory.

pin programming

A PIN code can have one to four digits; each digit can be from 0-9.

Programming Procedure

1. Enter the feature location in the installer programming grid.

2. Immediately press and release of the PlainView 2 Valet switch.

3. Select each digit by pressing 1-9 times, and then press

to enter the number into the system. To enter a zero,

press only.

To program a PIN code of 1032:

1. Press and release once and once. You will

hear one chirp.

3. Press and release once. You will not hear a chirp

after programming a zero.

5. Press and release three times, and then press

once. You will hear three chirps.

6. Press and release two times, and then press

once. You will hear two chirps.

4. Wait for two siren chirps after a five second pause or five seconds after the last digit has been entered if using less than four digit code number.

5. Turn off the ignition; the siren will chirp three times.

6. The programming mode is now exited.

nnoottee::

A PIN code cannot begin with a zero.

PIN Code Confirmation Procedure

Begin this procedure within 15 seconds of finishing the programming

sequence or the new code will not be set.

1. Turn on the ignition.

2. Enter the new PIN code.

3. Press and hold for three seconds.

LED turns on: New PIN code is learned and programming is complete.

LED stays off: New PIN code is not learned and the system reverts to the old PIN code. Redo the programming sequence.

glossary of terms

Control Unit:

The "brain" of your system. Usually hidden underneath

the dash area of the vehicle. It houses the microprocessor which mon-

itors your vehicle and controls all of the system's functions.

Normally Open/Normally Closed Immobilizer

: An automatic switch con-

trolled by the security system which prevents the vehicle’s starter from

cranking whenever the system is armed. The vehicle is never prevented

from cranking when the system is disarmed, in Valet mode, or should

the starter interrupt switch itself fail.

Input

: A physical connection to the system. An input can be provided

by a sensor, pinswitch or through an existing system in the vehicle, such

as ignition or courtesy lights.

LED

: Blue light mounted somewhere in the vehicle. It is used to indi-

cate the status of your system. It is also used to report triggers and

faults in the system or sensors.

Shock Sensor

: This is a sensor mounted in the vehicle that is designed

to pick up impacts to the vehicle.

Siren

: Noise generating device usually installed in the engine compart-

ment of the vehicle. It is responsible for generating the "chirps" you

hear, as well as the six tones you hear while the alarm is triggered.

Transmitter

: Hand-held transmitter which operates the various func-

tions of your system.

Trigger or Triggered Sequence: This is what happens when the alarm

"goes off" or "trips." The triggered response of your system consists

of the siren sounding and parking light flashing for the programmed

duration.

PlainView 2 Valet Switch

: A small two-button switch mounted some-

where inside the vehicle. It is used to override the alarm when a trans-

mitter is lost or damaged, or to enter or exit Valet mode.

Warning Zone Response:

Lighter impacts to the vehicle will generate the

Warning Zone response. It consists of several seconds of siren chirps.

Zone

: A zone is a separate input that the alarm can recognize as

unique. Each input to the system is connected to a particular zone. Two

or more inputs often share the same zone.

security & convenience expansions

Here we have listed only some of the many expansion options avail-

able. Please contact your dealer for a complete list of all the options

available to you.

Backup Battery:

The 520T keeps the system armed, triggers the alarm and

keeps the starter interrupt active if main battery power is disconnected.

Field Disturbance Sensor:

An invisible dome of coverage is established

by installing the 508D "radar" sensor. Your security system can then

react to any intrusions into this field with the triggered sequence.

Glass Tamper Sensor:

Metal on glass, glass cracking, and breaking glass

each produce distinctive acoustic signatures. The 506T glass tamper sen-

sor uses a microphone to pick up sounds, and then analyzes them with

proprietary acoustic software to determine if the glass has been struck.

Power Trunk Release: The button can operate a factory power

release for the vehicle’s trunk or hatch. (An optional relay may be re-

quired.) If the factory release is not power activated, the Directed®'s

522T trunk release solenoid can often be added.

Power Window Control:

Automatic power window control is provided

with the SmartWindows system.

Remote Start System:

For the ultimate in convenience, the IntelliStart

remote start system can start your vehicle, monitor engine functions,

and power your climate control system with a push of a button! Over-

rev protection, open-hood lockout, brake pedal shutoff, and automat-

ic timer shutoff are all included.

Tilt Sensor: The 507M tilt sensor can be added to your system to pro-

tect your car when its parked. It can protect your vehicle from being

lifted to protect your expensive rims.

Ultrasonic Sensor: Providing a field of protection inside your car using

the 509U Ultrasonic sensor to protect your belongings.

health check

Directed Electronics recommends you return to your installing Clifford

dealer to have your system checked for correct operation. The first

check is due one year after the installation date and at yearly intervals

thereafter.

nnoottee::

There may be a small charge incurred for this service.

Vista, CA 92081

www.directed.com

G919595 11-06

The company behind this system is Directed Electronics

Since its inception, Directed®has had one purpose, to provide consumers with the finest vehicle security and car stereo products and accessories available. The recipient of nearly 100 patents and Innovations Awards in the field of advanced electronic technology, Directed

is ISO

9001 registered.

Quality Directed Electronics products are sold and serviced throughout North America and around the world.

E&OE, specification is subject to change without notice. Some vehicles require optional parts/wiring and a few are incompatible with some features.

Directed®is committed to delivering world-class quality products and services

that excite and delight our customers.

Clifford Arrow 5.1 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
