CLF Lighting SPECTRUM P2 VARI-WHITE, HERA User Manual
manual
V1.0 May 2018WWW.CLF-LIGHTING.COM
SPECTRUM P2 VARI-WHITE
S
PECTRUM P
2
V-W
table of CONTENTS
WWW.CLF-LIGHTING.COM
Dimensions
1
Safety Informat io n
2
Fixture overvie w
4
Introduction
5
AC power
5
Power voltage
5
Power cables
6
Relaying power to o th er devices
6
Data link
6
Tips for reliable da ta t ransmission
6
Physical instal la tion
7
Fastening the fix tu re to a flat surface
7
Setup
8
Control panel and m en u navigation
8
DMX address setti ng
8
Control Mode
9
Static Color opti on s
10
Auto Show
11
Master / Slave
11
Personality
11
Dimmer speed
11
Dimmer curve
11
Key-Lock
11
Refresh rate
11
LCD brightness
11
DMX HOLD
11
Dimmer mode
12
Information
12
Software type
12
Usage time
12
Temperature
12
UID
12
Factory reset
12
DMX protocols
13
Onboard control m en us
15
Exploded view
16
Specification s
17
Dimensions
All dimensions are in millimeters
WWW.CLF-LIGHTING.COM
1.0
SPECTRUM P2
V-W
106
260
290
Φ203
180
WWW.CLF-LIGHTING.COM
2.0
The fo llowing symbols are used to identi fy important safety informatio n on the product and in this manual:
WARNING!
Read the safety precautions in this section before
installing, powering, operating or servicing this
product
DANGE R!
Safet y ha zard.
Risk of s ev ere
injur y or d eath.
DANGE R!
Hazar do us
volta ge . Risk of
letha l or s evere
elect ri c shock .
WAR NING!
Fire ha za rd.
WAR NING!
LED lig ht
emiss io n. Risk o f
eye inj ur y.
WAR NING!
Burn ha za rd. Hot
surfa ce . Do not
touch .
WAR NING!
Wear pr otect ive
eyewe ar .
WAR NING!
Refer t o us er
manua l.
Warning! Risk Group 3 (high risk) LED product according to EN 62471. Do not look into the beam at a distance
of less than 3 meters from the front surface of the product. Do not view the light output with optical instruments
or any device that may concentrate the beam.
This product is for professional use only. It is not for household use.
This product presents risks of severe injury or death due to fire and burn hazards, electric shock and falls.
Read this manual before installing, powering or servicing the fixture, follow the safety precautions listed below and
observe all warnings in this manual and printed on the fixture. If you have questions about how to operate the fixture
safely, please contact your supplier.
PROTECTION FROM ELECTRIC SHOCK
l Disconnect the fixture from AC power before removing or installing any cover or part and when not in use.
l Always ground (earth) the fixture electrically.
l Use only a source of AC power that complies with local building and electrical codes and has both overload and
ground-fault (earth-fault) protection.
l Before using the fixture, check that all power distribution equipment and cables are in perfect condition and rated for
the current requirements of all connected devices.
l Power input and through out cables must be rated 20A minimum, have three conductors 1.5 mm² (16 AWG) minimum
conductor size and an outer cable diameter of 5 - 15 mm . Cables must be hard usage type (SJT or equivalent) and
heat-resistant to 90° C minimum.
l Use only cable connectors to connect to power input sockets. Use only
® ®
PowerCON TRUE 1 PowerCON TRUE 1
cable connectors to connect to power through put sockets.
l Isolate the fixture from power immediately if the power plug or any seal, cover, cable, or other component is
damaged, defective, deformed, wet or showing signs of overheating. Do not reapply power until repairs have been
completed.
WWW.CLF-LIGHTING.COM
3.0
Do not expose the fixture to rain or moisture
l Refer any service operation not described in this manual to a qualified technician.
l Socket outlets used to supply the fixture with power or external power switches must be located near the fixtures and
easily accessible so that the fixtures can easily be disconnected from power.
PROTECTION FROM BURNS AND FIRE
l Do not operate the fixture if the ambient temperature (Ta) exceeds 40°C.
l The exterior of the fixture becomes hot during use. Avoid contact by persons and materials.
Allow the fixture to cool for at least 10 minutes before handling.
l Keep all combustible materials (e.g. fabric, wood, paper) at least 100 mm away from the fixture.
l Keep flammable materials well away from the fixture.
l Ensure that there is free and unobstructed airflow around the fixture.
l Do not illuminate surfaces within 200 mm of the fixture.
l Do not attempt to bypass thermostatic switches or fuses.
l If you relay power from one fixture to another using power throughput sockets, do not connect more than ten the
fixture in total to each other in an interconnected chain.
l Connect only other the fixture to fixture power throughput sockets. Do not connect any other type of device to these
sockets.
l Do not connect any other type of device to these sockets.
l Do not stick filters, masks or other materials onto any optical component, besides the optional CLF Yara filters.
l Do not modify the fixture in any way not described in this manual.
l Do not use fixture on a dimmer.
PROTECTION FROM INJURY
l Do not look continuously at LEDs from a distance of less than 3 meters from the front surface of the fixture without
protective eyewear such as shade 4-5 welding goggles. At less than this distance, the LED emission can cause eye
injury or irritation. At distances of 3 meters and above, light output is harmless to the naked eye provided that the
eye’s natural aversion response is not overcome.
l Do not look at LEDs with magnifiers, telescopes, binoculars or similar optical instruments that may concentrate the
light output.
l Ensure that persons are not looking at the LEDs from within 3 meters when the product lights up suddenly. This can
happen when power is applied, when the product receives a DMX signal, or when SERVICE menu items are
selected.
l Fasten the fixture securely to a fixed surface or structure when in use.
l Ensure that any supporting structure and/or hardware used can hold at least 10 times the weight of all the devices
they support.
l Allow enough clearance around the fixture to ensure that it cannot collide with an object or another fixture when it
moves.
l Check that all external covers and rigging hardware are fastened securely.
l Block access below the work area and work from a stable platform whenever installing, servicing or moving the
fixture.
l Do not operate the fixture with missing or damaged covers, shields or any optical component.
WWW.CLF-LIGHTING.COM
4.0
fixture overview
Control buttons
Safety cable
attachment point
LCD Display
5P DMX input
5P DMX output
AC mains power
throughput
AC mains power
input
G Clamp with
Quicklock # 875760
(Optional)
Omega bracket with
Quicklock # 520114
(Optional)
3P DMX input (optional)
# CLF-13-453
3P DMX output (optional)
# CLF-13-454
P2
VARI- WHITE
SPECTRUM
