This device complies with Part
15 of the FCC Rules. Operation
is subject to the following two
conditions:
1.This device may not cause
harmful interference.
2. This device must accept any
interference received, including interference that may
cause undesired operation.
This quick guide is a brief introduction to getting your system started. This is a s upplement, and not a substitute for the
expanded English language User’s Manual in Adobe Acrobat format on the Device Drivers & Utilities + User’s Manual
disc supplied with your computer. This disc also contains the drivers and utilities necessary for the proper oper ation of
the computer (Note: The company reserves the right to revise this publication or to change its contents without notice).
Some or all of the computer’s features may already have been setup. If they aren’t, or you are planning to re-configure
(or re-install) portions of the system, refer to the expanded User’s Manual. The Device Drivers & Utilities + User’sManual disc does not contain an operating system.
Regulatory and Safety Information
Please pay careful attention to the full regulatory notices and safety information contained in the expanded User’s Manual on the Device Drivers & Utilities + User’s Manual disc.
Intel, Pentium and Celeron are trademarks/registered trademarks of Intel Corporation.
English
1
Instructions for Care and Operation
The computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions:
• Don’t drop it, or expose it to shock. If the computer falls, the
case and the components could be damaged.
• Keep it dry, and don’t overheat it. Keep the computer and
power supply away from any kind of heating element. This is an
electrical appliance. If water or any other liquid gets into it, the
English
computer could be badly damaged.
• Avoid interfer ence. Keep the computer away from high capacity
transformers, electric motors, and other strong magnetic fields.
These can hinder proper performance and damage your data.
• Follow the proper working procedures for the computer. Shut
the computer down properly and don’t forget to save your work.
Remember to periodically save your data as data may be lost.
Servicing
Do not attempt to service the computer yourself. Doing so may
violate your warranty and expose you and the computer to
electric shock. Refer all servicing to authorized service personnel. Unplug the computer from the power supply. Then refer
servicing to qualified service personnel under any of the fo llowing conditions:
• When the power cord or AC/DC adapter is damaged or frayed.
• If the computer has been exposed to any liquids.
• If the computer does not work normally when you follow the
operating instructions.
• If the computer has been dropped or damaged (do not touch the
poisonous liquid if the LCD panel breaks).
• If there is an unusual odor, heat or smoke coming from your computer.
Safety Information
• Only use an AC/DC adapter approved for use with this computer.
• Use only the power cord and batteries indicated in this manual.
Do not dispose of batteries in a fire. They may explode. Check
with local codes for possible special disposal instructions.
• Do not continue to use a battery that has been dropped, or that
appears damaged (e.g. bent or twisted) in any way. Even if the
computer continues to work with a damaged battery in place, it
may cause circuit damage, which may possibly result in fire.
• Make sure that your computer is completely powered off before
putting it into a travel bag (or any such container).
• Before cleaning the computer, make sure it is disconnected from
any external power supplies, peripherals and cables (including
telephone lines). It is advisable to also remove your battery in
order to prevent accidentally turning the machine on.
• Use a soft clean cloth to clean the computer, but do not apply
cleaner directly to the computer. Do not use volatile (petroleum
distillates) or abrasive cleaners on any part of the computer.
• Do not try to repair a battery pack. Refer any battery pack repair
or replacement to your service representative or qualified service
personnel.
• Note that in computer’s featuring a raised LCD electro-plated
logo, the logo is covered by a protective adhesive. Due to general
wear and tear, this adhesive may deteriorate over time and the
exposed logo may develop sharp edges. Be careful when handling
the computer in this case, and avoid touching the raised LCD
electro-plated logo. Avoid placing any other items in the carrying
bag which may rub against the top of the computer during transport. If any such wear and tear develops contact your service center.
2
Polymer Battery Precautions
Battery Disposal & Caution
The product that you have purchased contains a rechargeable battery. The battery is recyclable. At the end of its useful life, under various state and local laws, it may be illegal
to dispose of this battery into the municipal waste stream.
Check with your local solid waste officials for details in your
area for recycling options or proper disposal.
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended
by the manufacturer. Discard used battery a ccording to the
manufacturer’s instructions.
Note the following information which is specific to polymer
batteries only, and where applicable, this overrides the general
battery precaution information.
• Polymer batteries may experience a slight expansion or swelling,
however this is part of the battery’s safety mechanism and is not a
cause for concern.
• Use proper handling procedures when using polymer batteries.
Do not use polymer batteries in high ambient temperature environments, and do not store unused batteries for extended periods.
English
3
System Startup
130 ゚
Shut Down
Note that you should always shut your computer down by
choosing the Shut down command in Windows (see below). This will help prevent hard disk or system problems.
Click Settings in the Charms Bar (use the WindowsLogo Key+ C key combination to access the
Charms Bar) and choose Shut down from the Power
menu.
Or
Choose Shut down or sign out > Shut down from the
context menu (use the Windows Logo Key + X key
combination to access the context menu).
Figure 1
Opening the Lid/LCD/
Computer with AC/DC
Adapter Plugged-In
1. Remove all packing materials.
2. Place the computer on a stable surface.
3. Insert the battery and make sure it is locked in position.
4. Securely attach any peripherals you want to use with the computer
(e.g. keyboard and mouse) to their ports.
5. Attach the AC/DC adapter to the DC-In jack on the left of the
computer, then plug the AC power cord into an outlet, and connect
English
the AC power cord to the AC/DC adapter (make sure you use the
adapter when first setting up the computer, as to safeguard the
computer during shipping the battery will be locked to not power the
system until first connected to the AC/DC adapter).
6. Use one hand to raise the
not exceed 130 degrees)
Figure 1) to support the base of the computer (Note: Never lift the
computer by the lid/LCD).
7. Press the power button to turn the computer “on”.
System Software
Your computer may already come with system software preinstalled. Where this is not the case, or where you are re-configuring your computer for a different system, you will find
this manual refers to Microsoft Windows 8.1.
lid/LCD to a comfortable viewing angle
;
use the other hand (as illustrated in
(do
4
System Map: Front View with LCD Panel Open
Figure 2 - Front View with
LCD Panel Open
1. PC Camera
2. *PC Camera LED
*When the PC camera is in
use, the LED will be
illuminated in red.
3. Built-In Microphone
4. LCD
5. Power Button
6. Keyboard
7. Clickpad & Buttons
5
7
6
2
1
3
7
4
Wireless Device
Operation Aboard
Aircraft
The use of any portable
electronic transmission
devices aboard aircraft is
usually prohibited.
Make sure the WLAN &
Bluetooth module(s) are
OFF if you are using the
computer aboard aircraft
by putting the system in to
Airplane Mode.
7
Clickpad/Touchpad
Sensitivity
The mouse button
zones at the bottom of
the pad measure
about 15mm from the
bottom of the pad,
and the left and right
buttons are divided
roughly down the middle as illustrated below. Press the left
button zone for a left
click, and right button
zone for a right click
action.
English
5
LED Indicators
The LED indicators on the computer display helpful information about the current status of the computer.
IconColorDescription
English
6
OrangeThe AC/DC Adapter is Plugged In
GreenThe Computer is On
Blinking GreenThe Computer is in Sleep Mode
OrangeThe Battery is Charging
GreenThe Battery is Fully Charged
Blinking OrangeThe Battery Has Reached Critically Low Power Status
Green
GreenThe Hard Disk/Optical Device is in use
Airplane Mode is ON (the WLAN & Bluetooth Modules are OFF)
Table 1 - LED Indicators
Keyboard
Keypad
Function Keys
Num Lk &
Scr Lk
Numeric
Keypad
Fn Key
Windows Logo Key
Menu/Application Key
Figure 3 - Keyboard
Windows Logo Keyboard Shortcut
Use the Windows Logo Key + D key combination to switch from the Start
screen to the Windows Desktop.
Menu/Application Keyboard Shortcut
When the Desktop app is running you can use the Menu/Application key on
the keyboard to act as a mouse right-click. In the Start screen this function is useful
to quickly display the Customize bar.
The keyboard includes a numeric keypad (on the right side of the keyboard) for easy numeric data input. Pressing
Num Lk turns on/off the numeric keypad. It also features function keys to allow you to change operatio nal features
instantly.
English
7
Function Keys & Visual Indicators
The function keys (F1 - F11 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the
basic function key combinations, some visual indicators are available (in the Windows Desktop application only andnot in the Start Screen) when the hot key driver is installed.
The Control Center in Windows 8.1 works under the Desktop app and not under the Start screen. Press the Fn + Esc
key combination, or double-click the icon in the notification area of the taskbar to toggle the Control Center
on/off. The Control Center gives quick access to frequently used controls and enables you to quickly turn the camera/
Touchpad on/off.
Figure 4 - Control Center
English
Click the Control Center icons to toggle the appropriate function, or hold the mouse button down and move the dial
control where applicable. Certain functions will automatically be adjusted when a power mode is selected.
9
Power Modes
You can set a Power Mode by clicking the appropriate icon at the top of the Control Center. Each power mode will
affect the Power Conservation Mode, Airplane Mode, Power Plan and PC camera power etc.
You can click a Control Center icon to set an overall power mode and then click individual icons in the Control Cen-ter to power on/off the Touchpad and PC camera.
English
ModesQuietPower SavingPerformanceEntertainment
Icon
Power Plan
Balanced
Power Conservation ModeEnergy StarPerformance
PC CameraONOFFONON
TouchPadONONONON
Airplane ModeOFFONOFFOFF
Table 3 - Power Modes
Power SaverHigh Performance
Balanced
10
Power Status
The Power Status icon will show whether you are currently powered by the battery, or by the AC/DC adapter
plugged in to a working power outlet. The power status
bar will show the current battery charge state.
Brightness
The Brightness icon will show the current screen brightness level. You can use the slider to adjust the screen
brightness or the Fn + F8/F9 key combinations, or use the
Fn + F2 key combination to turn off the LED backlight
(press any key to turn it on again). Note that screen brightness is also effected by the Power Mode selected.
Volume
The Volume icon will show the current volume level. You
can use the slider to adjust the volume or the Fn + F5/F6
key combinations, or use the Fn + F3 key combination to
mute the volume.
Power Conservation
This system supports Energy Star power management
features that place computers (CPU, hard drive, etc.) into
a low-power sleep mode after a designated period of inactivity. Click either the Performance, Balanced or Ener-gy Star button.
Sleep Button
Click either the Hibernate or Sleep button to have the
computer enter the selected power-saving mode.
Display Switch
Click the Display Switch button to access the menu (or
use the + P key combination) and select the appropriate display mode.
Time Zone
Clicking the Time Zone button will access the Date and
Time Windows control panel.
Desktop Background
Clicking the Desktop Background button will allow you
to change the desktop background picture.
Touchpad/PC Camera
Click either of these buttons to toggle the TouchPad or
camera module’s power status. Note that the power status
of the camera module is also effected by the Power Mode
selected.
English
11
System Map: Front, Left, Right, Rear & Bottom Views
Do not remove any cover(s) and/or
screw(s) for the purposes of device upgrade as this may violate the terms of
your warranty.
If you need to replace/remove the hard
disk/RAM/optical device etc., for any
reason, please contact your distributor/
supplier for further information.
9
12
15
16
15
7
English
12
Windows 8.1 Control Panel
Move the mouse to
the bottom left of the
screen and right-click
the Start button to access the menu.
Figure 6
Context
Menu
Figure 7
Start
Screen
Throughout this manual you will see an instruction to open the Control Panel. Right-click the Start button in the
Desktop app or Start screen (or use the Windows Logo Key + X key combination) to bring up an advanced context
menu of useful features such as Control Panel, Programs and Features, Power Options, Task Manager, Search, File Explorer, Command Prompt, Device Manager and Network Connections etc. and then select Control Panel.
Windows 8.1 Start Screen &
Desktop
The Apps, control panels, utilities and programs within
Windows are accessed from the Start screen and/or
Windows Desktop app. The Desktop (which runs as an
app within the Start screen) can be accessed by clicking
the Desktop item in the Start screen (or by using the
Windows Logo Key + D key combination). The
taskbar is displayed at the bottom of the desktop screen,
and you can see the notification area of the taskbar in the
bottom right of the screen. Click the arrow at the bottom
of the Start screen to access Apps.
13
English
Apps & Tiles
Click the arrow at the bottom of the
screen to access Apps.
The Start screen will contain a number of apps, and many more
will be installed as you add more applications etc. Not all of these
apps can fit on one screen so you will often need use the slider at
the bottom of the screen in order to view all the necessary Apps.
Charms Bar
English
The right side of the screen displays the Charms Bar. The Charms Bar contains the Search, Share, Start, Devices and
Settings menus. To access up the Charms Bar move the cursor to the upper or lower right corners of the screen, and
then hover over one of the items in the Charms Bar to activate it (the bar will be black when it is active), or use the
Windows Logo Key + C key combination.
14
Figure 8 - Start Screen with Charms Bar
Video Features
1
2
2
1
Figure 9
Display
Control
Panel
Screen Resolution for Apps (Windows 8.1)
The minimum resolution in which Apps will run is
1024x768.
The minimum resolution required to support all the features of Windows 8.1 (including multitasking with snap)
is 1366x768.
The system features an Intel integrated GPU. You can
switch display devices, and configure display options,
from the Display control panel in Windows as long as the
video driver is installed.
4. Right-click the desktop (use the Windows Logo Key + D
key combination to access the desktop) and select Screen resolution.
5. Use the dropbox to select the screen resolution .
6. Click Advancedsettings .
To access the Intel® HD Graphics Control Panel:
1. Click the icon (Intel® HD Graphics Control Panel) on the
Apps screen.
OR
2. Right-click the desktop (use the Windows Logo Key + D
key combination to access the desktop) and select Graphics Properties from the menu.
OR
3. Click the icon in the notification area of the Desktop taskbar
and select Graphics Properties from the menu.
Display Devices
Besides the built-in LCD, you can also use an external
VGA monitor (CRT)/external Flat Panel Display or TV
(connected to the external monitor port/HDMI-Out port)
as your display device.
English
15
Using the Windows Logo Key + P Key
Figure 10
+ P (Change Display
Configuration)
Figure 11 - Power Options
Combination to Switch Displays
You can also use the + P key combination (or Fn + F7
) to quickly change display configuration and modes (this
is particularly useful when attaching a projector) in Win-dows.
1. Attach your external display to the external monitor port/HDMI-
English
Out port, and turn it on.
2. Press the + P (or Fn + F7) key combination.
3. An on-screen menu will pop up.
4. Use the cursor keys ( + P) to select the appropriate
configuration from the menu, and press Enter to confirm the
selection.
Power Options
The Power Options (Hardware and Sound menu) control panel icon in Windows allows you to configure power
management features for your computer. You can conserve power by means of power plans and configure the
options for the power button, sleep button (Fn + F4),
computer lid (when closed), display and sleep mode (the
default power saving state) from the left menu. Note that
the Power saver plan may have an affect on computer
performance.
Click to select one of the existing plans, or click Create apower plan in the left menu and select the options to create a new plan. Click Change Plan Settings and click
Change advanced power settings to access further configuration options.
16
Driver Installation
Driver Installation General
Guidelines
As a general guide follow the
default on-screen instructions for each driver (e.g.
Next > Next > Finish) unless
you are an advanced user. In
many cases a restart is required to install the driver.
Make sure any modules (e.g.
WLAN or Bluetooth) are ON
before installing the appropriate driver.
Windows Update
After installing all the drivers
make sure you enable Win-dows Update in order to get
all the latest security updates
etc. (all updates will include
the latest hotfixes from Mi-
crosoft).
Driver Installation & Power
When installing drivers make sure your
computer is powered by the AC/DC
adapter connected to a working power
source. Some drivers draw a significant
amount of power during the installation
procedure, and if the remaining battery
capacity is not adequate this may cause
the system to shut down and cause system problems (note that there is no safety issue involved here, and the battery
will be rechargeable within 1 minute).
Figure 12 - Install Drivers
The Device Drivers & Utilities + User’s Manual disc contains the drivers and utilities
necessary for the proper operation of the computer. This setup will probably have already been done for you. If this is not the case, insert the disc and click Install Drivers
(button), or Option Drivers (button) to access the Optional driver menu. Install the
drivers in the order indicated in Figure 12. Click to select the drivers you wish to
install (you should note down the drivers as you install them). Note: If you need to
reinstall any driver, you should uninstall the driver first
Manual Driver Installation
Click the Browse CD/DVD button in the Drivers Installer application and browse to
the executable file in the appropriate driver folder.
If a
Found New Hardware
Cancel and follow the installation procedure as directed.
wizard appears
during the installation procedure, click
.
English
17
Troubleshooting
ProblemPossible Cause - Solution
The Wireless LAN/Bluetooth
modules cannot be detected.
English
The PC Camera module cannot be
detected.
The captured video files from the PC Camera are taking up too much disk
space.
The modules are off as the computer is in Airplane Mode . Check the LED indicator to
see if it is in Airplane Mode (see Table 1 on page 6). Use the Fn + F11 key combination
to toggle Airplane Mode on/off (see Table 2 on page 8).
The module is off. Press the Fn + F10 key comb inati on in order to enab le th e module (see
Table 2 on page 8). Run the camera application to view the camera picture.
Note that capturing high resolution video files requires a substantial amount of disk space
for each file.
Note that the Windows system requires a minimum of 20GB (64bit) of free space on theC: drive system partition. It is recommended that you save the capture video file to a
location other than the C:drive, limit the file size of the captured video or reduce video
resolution.
18
Specifications
Latest Specification Information
The specifications listed in this here
are correct at the time of going to
press. Certain items (particularly processor types/speeds) may be
changed, delayed or updated due to
the manufacturer's release schedule. Check with your service center
for details.
Processor Options
Intel® Pentium™ Processor
N3520 (2.17GHz)
2MB L2 Cache, 22nm, DDR3L-1333MHz,
TDP 7.5W
Intel® Celeron™ Processor
N2920 (1.86GHz)
2MB L2 Cache, 22nm, DDR3L-1066MHz,
TDP 7.5W
N2820 (2.13GHz), N2815 (1.86GHz)
1MB L2 Cache, 22nm, DDR3L-1066MHz,
TDP 7.5W
N2806 (1.60GHz)
1MB L2 Cache, 22nm, DDR3L-1066MHz,
TDP 4.3W
BIOS
64Mb SPI Flash ROM
AMI BIOS
Memory
For N3520, N2920, N2820 & N2815
Processors:
Two 204 Pin SO-DIMM Sockets Supporting
DDR3L1600MHz Memory
Memory Expandable up to 8GB
(The real memory operating frequency
depends on the FSB of the processor.)
For N2806 Processors:
One 204 Pin SO-DIMM Socket Supporting
DDR3L1600MHz Memory
Memory Expandable up to 8GB
(The real memory operating frequency
depends on the FSB of the processor.)
Storage
(Factory Option) One Changeable
9.5mm(h) Optical Device Type Drive (Super
Multi Drive Module)
(Factory Option) Dummy ODD
One Changeable 2.5" 7.0mm/9.5mm (h)
SATA HDD
LCD
17.3" (43.94cm) HD+
Video Adapter
Intel HD Graphics
Dynamic Frequency (Intel Dynamic Video
Memory Technology for up to 1.7GB)
One USB 3.0 Port
Three USB 2.0 Ports
One HDMI-Out Port
One External Monitor Port
One Headphone-Out Jack
One Microphone-In Jack
One RJ-45 LAN Jack
One DC-in Jack
English
19
Communication
Built-In 10/100Mb Ethernet LAN
300K/1.0M HD PC Camera Module
WLAN/ Bluetooth Half Mini-Card
Modules:
(Factory Option) Intel® Wireless-AC 3160
Wireless LAN (802.11ac) + Bluetooth 4.0
English
(Factory Option) Intel® Wireless-N 7260
Wireless LAN (802.11b/g/n) + Bluetooth 4.0
(Factory Option) Third-Party Wireless LAN
(802.11b/g/n)
(Factory Option) Third-Party Wireless LAN
(802.11b/g/n) + Bluetooth 4.0
Diese Kurzanleitung soll einen Überblick über die Schritte geben, die dazu notwendig s ind, das System zu starten. Dieses ist
nur eine Ergänzung und kein Ersatz für das erweiterte englischsprachige Benutzerhandbuch, das auf der mitgelieferten DiscDevice Drivers & Utilities + User's Manual im Adobe-Acrobat-Format vorliegt. Diese Disc enthält auch die Treiber und
Utility-Programme, die für einen einwandfreien Betrieb des Computers notwendig sind (Hinweis: Das Unternehmen behält
sich das Recht vor, diese Publikation ohne Vorankündigung zu überarbeiten und den Inhalt zu verändern).
Einige oder alle Funktionen des Computers sind bereits eingerichtet worden. Falls das nicht der Fall ist oder wenn Sie einzelne Teile des Systems neu konfigurieren (oder neu installieren) möchten, finden Sie eine Anleitung im erweiterten Benut-zerhandbuch. Die Disc Device Drivers & Utilities + User's Manual enthält nicht das Betriebssystem.
Einhaltung gesetzlicher Vorschriften und Sicherheitshinweise
Beachten Sie sorgfältig die Hinweise zu gesetzlichen Vorschriften und zu Sicherheitshinweisen im erweiterten Benutzerhandbuch auf der Disc Device Drivers & Utilities + User's Manual.
Intel, Pentium und Celeron sind warenzeichen/eingetragenes warenzeichen der Intel Corporation.
Deutsch
21
Hinweise zu Pflege und Betrieb
Das Notebook ist zwar sehr stabil, kann aber dennoch beschädigt werden. Damit es nicht dazu kommt, sollten Sie die
folgenden Hinweise beachten:
• Das Gerät darf nicht herunterfallen und in anderer Form Stößen
ausgesetzt werden. Wenn der Computer fällt, können das Gehäuse und
andere Komponenten beschädigt werden.
• Das Gerät darf nicht nass werden und sich nicht überhitzen. Compu-
ter und Netzteil dürfen nicht in der Nähe von Wärmequellen stehen oder
gelagert werden. Dies ist ein elektrisches Gerät. Wenn Wasser oder
andere Flüssigkeiten eindringen, kann der Computer stark beschädigt
werden.
• Vermeiden Sie Interferenzen mit anderen Geräten. Halten Sie den
Computer fern von magnetischen Feldern, die von Stromquellen, Moni-
Deutsch
toren, Magneten etc. erzeugt werden. Die können die Leistung beeinträchtigen und Ihre Daten beschädigen.
• Achten Sie auf die richtige Bedienung des Computers. Schalten Sie
ihn erst aus, wenn alle Programme geschlossen wurden (speichern Sie
Ihre Daten!). Speichern Sie regelmäßig Ihre Daten, da diese verloren
gehen können, wenn der Akku verbraucht ist.
Reparatur
Nehmen Sie vor dem Reinigen des Wenn Sie versuchen, den
Computer selbst zu reparieren , können Ihre Garantieansprüche
verloren gehen. Außerdem besteht Stromschlaggefahr für Ihre
Gesundheit und das Gerät durch frei liegende Teile. Lassen Sie
Reparaturarbeiten nur von qualifizierten Reparaturfachleuten
durchführen, insbesondere wenn folgende Umstände vorliegen:
• Wenn das Netzkabel oder der AC/DC-Adapter beschädigt oder ze rsch l is -
sen sind.
• Wenn der Computer Regen ausgesetzt war oder mit Flüssigkeiten in
Berührung gekommen ist.
• Wenn der Computer unter Beachtung der Bedienungsanweisungen nicht
korrekt arbeitet.
• Wenn der Computer heruntergefallen ist oder beschädigt wurde (berühren Sie nicht die giftige Flüssigkeit des LCD-Bildschirms).
• Wenn ein ungewöhnlicher Geruch, Hitze oder Rauch aus dem Computer
entweicht.
Sicherheitsinformationen
• Verwenden Sie nur einen AC/DC-Adapter, der für die Verwendung mit
diesem Computer zugelassen ist.
• Verwenden Sie nur das Netzkabel und die Akkus, die in diesem Benutzerhandbuch spezifiziert sind
Sie können explodieren. Richten Sie sich nach den regional gültigen Entsorgungsvorschriften.
• Verwenden Sie den Akku nicht mehr, wenn er heruntergefallen ist oder in
anderer Weise beschädigt (z.B. verzogen) ist. Auch wenn der Computer
mit dem beschädigten Akku zu funktionieren schein, können dadurch
Stromkreise beschädigt werden, die schließlich einen Brand verursachen
können.
• Achten Sie darauf, dass Ihr Computer ausgeschaltet ist, wenn Sie es fur
den Transport z.B. wahrend einer Reise in eine Tasche einpakken.
• Nehmen Sie vor dem Reinigen des Computers den Akku heraus, und
trennen Sie es von allen externen Stromquellen, Peripheriegeräten und
Kabeln (einschließlich Telefonkabel) ab.
• Reinigen Sie den Computer mit einem weichen, sauberen Tuch. Tragen
Sie das Reinigungsmittel nicht direkt auf den Computer auf. Verwenden
Sie keine flüchtigen Reinigungsmittel (Petroleumdestillate) oder Scheuermittel zum Reinigen des Computers.
• Versuchen Sie nicht, Akkus zu reparieren. Lassen Sie die Akkupacks
durch den Servicevertreter oder qualifiziertes Fachpersonal reparieren
oder austauschen.
• Beachten Sie, dass das Logo bei den Computern, die über ein galvanisch
beschichtetes LCD-Logo verfügen, von einer Schutzfolie bedeckt ist.
Durch die natürliche Abnutzung kann diese Schutzfolie beschädigt werden oder abgehen und die scharfen Kanten des frei liegenden Logos
freigeben. Seien Sie in solch einem Fall vorsichtig bei der Handhabung
des Computers, und vermeiden Sie es, das herausstehende beschichtete
LCD-Logo zu berühren. Legen Sie keine Gegenstände in die Tragetasche, da diese während des Transports gegen den Computer drücken
können. Wenden Sie sich in einem solchen Fall von Abnutzung an Ihr
Service Center.
.Entsorgen Sie die Akkus nicht in Feuer.
22
Polymer Akku Sicherheitshinweise
Entsorgen der Akkus/ Batterien & Achtung
Das von Ihnen gekaufte Produkt enthält einen aufladbaren
Akku. Dier Akku ist wiederverwertbar. Nach verschiedenen nationalen und regionalen Getzgebungen kann es verboten in,
einen nicht mehr gebrauchsfähigen Akku in den normalen
Hausmüll zu werfen. Informieren Sie sich bei Ihrem regionalen
Entsorgungsunternehmen über Recycling-Möglichkeiten oder
korrekte Entsorgung.
Wenn ein falscher Akku eingesetzt wird, besteht Explosionsgefahr. Tauschen Sie den Akku nur durch den gleichen oder einen
baugleichen Typ aus, der vom Hersteller empfohlen wird. Entsorgen Sie den verbrauchten Akku entsprechend der Anweisungen des Herstellers.
Beachten Sie die folgenden Hinweise, die sich speziell auf Polymer Akkus beziehen. Diese Hinweise haben zudem Vorrang
gegenüber den Allgemeinen Akku Sicherheitshinweisen.
• Polymer Akkus können sich etwas ausdehnen oder anschwellen. Dies ist
Teil des Sicherheitsmechanismus des Akkus und kein Anlass zur Sorge.
• Seien Sie vernünftig im Umgang mit Polymer Akkus. Verwenden Sie
keine Polymer Akkus in Umgebungen mit hohen Temperaturen und
lagern Sie keine ungenutzten Akkus über längere Zeiträume.
Deutsch
23
Schnellstart
130 ゚
Herunterfahren
Bitte beachten Sie, daß der Computer immer mit dem Befehl Herunterfahren in Windows(siehe unten) heruntergefahren werden muß.
Dadurch werden Festplatten- bzw. Systemprobleme vermieden.
Klicken auf Einstellungen in der Charms-Leiste aus (die Charms-
Leiste wird aufgerufen, indem Sie die Windows Logo-Taste
und
gleichzeitig auf C drücken). Wählen Sie dann aus dem
Ein/Aus-Menü
die Option Herunterfahren.
Oder
Wählen Sie aus dem Kontextmenü Herunterfahren oder abmelden
> Herunterfahren (das Kontextmenü wird aufgerufen, indem Sie die
Windows Logo-Taste
und gleichzeitig auf X drücken).
Abb. 1
Öffnen des Deckels/LCD/
Computers mit angeschlossenem AC/DC-
Adapter
1. Entfernen Sie das gesamte Verpackungsmaterial.
2. Legen Sie den Computer auf eine stabile Unterlage.
3. Setzen Sie den Akku ein, und stellen Sie sicher, dass sie fest
sitzt.
4. Schließen Sie alle Peripheriegeräte, die Sie mit dem Computer
verwenden wollen (z. B. Tastatur und Maus), an die
entsprechenden Schnittstellen an.
5. Schließen Sie den AC/DC-Adapter an die DC-Eingangsbuchse
an der linken Seite des Computers an. V erbinden Sie dann das
Netzkabel mit einer Netzsteckdose und dem AC/DC-Adapter
benutzen Sie bei der Ersteinrichtung des Computers den
Adapter, da der Akku des Computers während des Trans-
ports so geschützt ist, dass er den Computer bis zum ersten
Deutsch
Anschluss des AC/DC-Adapter nicht starten kann).
6. Klappen Sie den Deckel/LCD vorsichtig mit einer Hand auf,
und öffnen Sie ihn auf einen angenehmen Sichtwinkel (jedoch
nicht weiter als 130°). Mit der anderen Hand halten Sie das
Unterteil des Computers fest (siehe Abb. 1) (Hinweis: Heben
Sie den Computer niemals am Deckel/LCD hoch).
7. Drücken Sie auf den Netzschalter, um den Computer
einzuschalten.
Systemsoftware
Möglicherweise wurde das Notebook bereits mit vorinstallierter Software ausgeliefert. Ist das nicht der Fall, oder
wenn Sie das Notebook für ein anderes System neu
konfigurieren möchten, finden Sie dazu eine Anleitung in
diesem Handbuch zu Microsoft Windows 8.1.
24
(
Systemübersicht: Ansicht von vorne mit geöffnetem LCD-Bild-
Abb. 2 - Ansicht von vorne mit
geöffnetem LCD-Bildschirm
1. PC-Kamera
2. *LED der PC-Kamera
*Wenn die PC-Kamera verwendet wird, leuchtet die LED
rot.
3. Mikrofon
4. LCD-Bildschirm
5. Netzschalter
6. Tastatur
7. Clickpad mit Tasten
Die Benutzung drahtlos
angeschlossener Geräte in
Flugzeugen
In der Regel ist die Benutzung
jeglicher tragbarer elektronischer Funkgeräte in Flugzeugen verboten.
Stellen Sie sicher, dass das
WLAN- und das Bluetooth-Modul durch Aktivieren des Flugzeugmodus ausgeschaltet
sind, wenn Sie sich an Bord
eines Flugzeugs befinden.
5
7
6
2
1
3
4
Empfindlichkeit des
Clickpads/
Touchpads
Der Maustasten-Bereich befindet sich ca.
15 mm über der unteren Kante des Pads.
Die Trennlinie zwischen der linken und
rechten Maustaste
verläuft ungefähr in
der Mitte (siehe unten). Drükken Sie für
einen Linksklick auf
den linken
Maustastenbereich
und für einen Rechtsklick auf den rechten
Maustastenbereich.
7
schirm
Deutsch
25
LED-Anzeigen
Die LED-Anzeigen auf dem Computer zeigen wichtige Informationen über den aktuellen Status des Computers.
SymbolFarbeBeschreibung
OrangeDer AC/DC-Adapter ist angeschlossen
GrünDer Computer ist angeschaltet
Lampe blinkt grünDas System ist im konfigurierten Energiesparmodus
Deutsch
OrangeDer Akku wird geladen
GrünDer Akku ist voll geladen
Lampe blinkt orangeDer Akku hat einen kritisch niedrigen Stromstatus erreicht
26
Grün
GrünEs wird auf die Festplatte/das optische Laufwerk zugegriffen
Flugzeugmodus ist EIN (das WLAN- und das Bluetooth-Modul ausgeschaltet
sind)
Tabelle 1 - LED-Anzeigen
Tastatur
n Keys
Numeric
Keypad
Keypad
Windows-Logo-Taste
Menü/Anwendungstaste
Fn Taste
Nummemtastatur
Funktionstasten
Num &
Rollen
Abb. 3 - Tastatur
Tastenkürzel Windows-Logo
Drücken Sie gleichzeitig auf die Windows Logo-Taste und die Taste D, um vom
Start-Bildschirm zum Windows-Desktop zu wechseln.
Tastenkürzel Menü/Anwendung
Wenn die Desktop-App läuft, funktioniert die Menü/Anwendungtaste
auf der Ta-
statur wie ein Rechtsklick mit der Maustaste. Auf dem Start-Bildschirm ist diese Funktion
sehr nützlich, um direkt auf die Leiste Anpassen zuzugreifen.
Die Tastatur umfasst eine Nummerntastatur (an der rechten Seite der Tastatur) für die Eingabe von Zahlen. Durch Drücken
auf Num wird die Nummerntastatur ein- und ausgeschaltet. Zusätzlich gibt es Funktionstasten, üb er die Sie direkt zwischen
den Funktionen umschalten können
.
Deutsch
27
Funktionstasten
Wenn die Funktionstasten (F1 - F11) gleichzeitig mit der Fn-Taste gedrückt werden, funktionieren sie wie Hotkeys. Neben
den Tastenkombinationen für die Grundfunktionen gibt es einige visuelle Anzeigen (nur bei der Windows Desktop-An-wendung, aber nicht im Start-Bildschirm), wenn der Hotkey Treiber ins talliert ist.
Das Control Center (Steuerzentrum) in Windows 8.1 funktioniert in der Desktop App und nicht auf dem Start-Bildschirm.
Drücken Sie auf die Tastenkombination Fn + Esc, oder doppelklicken Sie auf das Symbol im Infobereich auf derTaskleiste um das Control Center ein-/auszuschalten. Das Control Center bietet den schnellen Zugriff auf häufig verwendete Funktionen, und Sie haben hier die Möglichkeit, das Touchpad/das Kamera-Modul direkt ein-/auszuschalten.
Abb. 4 - Control Center
Deutsch
Klicken Sie auf die Symbole des Control Center, um die entsprechende Funktion zu wählen, oder halten Sie die Maustaste
gedrückt und verschieben Sie den Regler, falls vorhanden. Bestimmte Funktionen werden automatisch angepasst, wenn ein
Strommodus ausgewählt ist.
29
Energiemodi
Sie können einen Energiemodus einstellen, indem Sie im Control Center auf das entsprechende Symbol klicken. Jeder
Energiemodus wird Einfluss auf den Energiesparmodus, Flugzeugmodus, Energiesparpl an und PC Kamerastrom usw. haben.
Klicken Sie auf das Control Center-Symbol, um einen allgemein gültigen Energiemodus einzustellen. Kli cken Sie dann auf
die einzelnen Symbole des Control Centers, um das Touchpad und das Kamera-Modul ein-/auszuschalten.
Das Energiestatus-Symbol zeigt an, ob die Stromversorgung aktuell über den Akku oder über das an das Stromnetz
angeschlossene Netzteil erfolgt. Die Energiestatus-Anzeige
zeigt den aktuellen Akkuladestatus an.
Brightness (Helligkeits)
Das Helligkeits-Symbol zeigt die aktuell eingestellte Bildschirmhelligkeit an.Sie können die Bildschirmhelligkeit entweder mit dem Schieberegler oder mit der
Tastenkombination Fn + F8/F9 ändern. Mit der
Tastenkombination Fn + F2 wird das LED-Hintergrundlicht
ausgeschaltet (drücken Sie auf eine beliebige Taste, um es
wieder einzuschalten). Beachten Sie, dass die Bildschirmhelligkeit auch vom eingestellten Energiemodus abhängt.
Sleep Button (Schaltfläche Schlaf)
Klicken Sie entweder auf die Schaltfläche Ruhezustand
oder Schlaf, um den Computer der aus gewählten Stromsparmodus aufrufen zu lassen.
Display Switch (Anzeige wechseln)
Klicken Sie auf die Taste zum Wechseln des Anzeigegeräts,
um das Menü aufzurufen (Sie können dazu auch die
Tastenkombination + P verwenden), und wählen Sie
einen Anzeigemodus aus.
Time Zone (Zeitzone)
Wenn Sie auf die Schaltfläche Zeitzone klicken, wird das
Windows-Systemsteuerungsfenster Datum und Uhrzeit
aufgerufen.
Deutsch
Volume (Lautstärke)
Das Lautstärke-Symbol zeigt die aktuelle Lautstärke an.Sie
können die Lautstärke entweder mit dem Schieberegler oder
mit der Tastenkombination Fn + F5/F6 einstellen. Mit der
Tastenkombination Fn + F3 wird der Ton ausgeschaltet.
Power Conservation (Strom sparen)
Dieses System unterstützt die Energy Star-Stromsparfunktionen, die Computer (CPU, Festplatte usw.) nach einer
längeren Zeit der Inaktivität in einen Ruhemodus versetzen,
bei dem weniger Strom verbraucht wird. Klicken Sie entweder auf die Taste Performance, Balanced oder EnergyStar.
Desktop Background (Desktop-Hintergrund)
Wenn Sie auf die Schaltfläche Desktop-Hintergrund klikken, können Sie das Bild für den Desktophintergrund einstellen.
Touchpad/PC-Kamera-Modul
Klicken Sie auf eine dieser Tasten, um das Touchpad oder
das Kamera-Modul ein- oder auszuschalten. Beachten Sie,
dass der Energiestatus des Kamera-Moduls auch vom ausgewählten Energiemodus abhängen.
31
Systemübersicht: Ansicht von vorne, links, rechts, hinten und unten
Keine Gehäuseteile entfernen oder
öffnen
Entfernen Sie keine Gehäuseteile und/oder
Schrauben, um das Gerät aufzurüsten, da
anderenfalls Ihre Garantieansprüche verloren gehen.
Ist es erforderlich, die Festplatte, den RAM,
ein optisches Gerät usw. auszuwechseln
oder zu entfernen, wenden Sie sich an Ihren Vertragshändler/Lieferanten.
Abb. 5 - Ansicht von vorne, links, rechts, hinten und unten
1. LED-Anzeigen
2. DC-Eingangsbuchse
3. RJ-45 LAN-Buchse
4. Schnittstelle für externen
Monitor
5. Luftungsoffnung
6. HDMI-Ausgangsanschluss
7. USB 2.0-Anschlüsse
8. USB 3.0-Anschluss
9. Multi-in-1 Kartenleser
10. Mikrofon-Eingangsbuchse
11. Kopfhörer-Ausgangsbuchse
12. Schacht für optisches
Laufwerk
13. Notauswurfloch
14. Sicherheitsschloß-Buchse
15. Akku
16. Lautsprecher
1
14
2
8
4
6
3
5
10
11
7
13
9
12
15
16
5
16
Unterseite
Vorderseite
Linke Seite
Rechte Seite
Hinterseite
15
7
7
Deutsch
32
Windows 8.1 Systemsteuerung
Abb. 6
Kontextmenü
Verschieben Sie die Maus in
die linke untere Ecke des Bildschirms, und klikken Sie mit der
rechten Maustaste auf die
Start-Taste darauf, um das
Menü aufzurufen.
Abb. 7 - Start-Bildschirm
In diesem Handbuch finden Sie eine Anleitung zum Öffnen der Systemsteuerung. Klicken Sie mit der rechten Maustaste
auf die Start-Taste in der Desktop-App oder auf dem Start-Bildschirm (oder verwenden Sie die Tastenkombination
Windows-Logo-Taste + X), um ein erweitertes Kontextmenü der nützlichen Funktionen aufzurufen: Systemsteuerung,
Programme und Funktionen, Energieoptionen, Task-Manager, Suche, Datei-Explorer, Eingabeaufforderung, GeräteManager, Netzwerkverbindungen usw. Wählen Sie dann Systemsteuerung.
Windows 8.1 Start-Bildschirm und
Desktop
Die Apps, Bedienfenster, Dienstprogramme und andere Software erreichen Sie bei Windows über den Start-Bildschirm und/oder die
Windows Desktop-App. Der Desktop (der im Start-Bildschirm eine
App startet) wird geöffnet durch Anklicken des Desktop-Eintrags im
Start-Bildschirm (oder durch Drükken der Tastenkombination
Windows-Logo-Taste + D). Die Taskleiste wird am unteren
Rand des Desktop-Bildschirms angezeigt. Der Infobereich befindet
sich in der rechten unteren Ecke des Bildschirms. Klicken Sie auf den
Pfeil unten auf dem Start-Bildschirm, um auf die Apps zuzugreifen.
33
Deutsch
Apps und Kacheln
Klicken Sie auf den Pfeil unten auf dem
Start-Bildschirm, um auf die Apps zuzugreifen.
Der Start-Bildschirm enthält bereits eine Reihe von Apps, die mit
jeder weiteren Installation erweitert wird. Wenn auf dem Bildschirm nicht ausreichend Platz ist, um alle Apps anzuzeigen, können Sie den Schieberegler am unteren Rand des Bildschirms
verwenden, um das Fenster entsprechend zu verschieben und die
gewünschten Apps sehen zu können.
Charms-Leiste
An der rechten Seite des Bildschirms wird die Charms-Leiste angezeigt. Die Charms-Leiste enthält die Menüs Suchen,
Teilen, Start, Geräte und Einstellungen. Um eines der Menüs aus der Charms-Leiste aufzurufen, bewegen Sie den Cursor
in die unteren rechten Ecken des Bildschirms und dann über den jeweiligen Eintrag in der Charms-Leiste, um diesen zu ak-
Deutsch
tivieren (ein aktivierter Eintrag wird schwarz dargestellt) oder drücken Sie auf die Tastenkombination Windows-Logo-Taste
+ C.
34
Abb. 8 - Start-Bildschirm mit Charms-Leiste
Grafikfunktionen
1
2
2
1
Abb. 9
Ein-
stellfenster
Anzeige
Bildschirmauflösung für Apps (Windows 8.1)
Die Mindestauflösung für Apps ist 1024x768.
Damit alle Funktionen von Windows 8.1 unterstützt werden
(einschließlich Multitasking mit Snap), ist eine Mindestauflösung von 1366x768 erforderlich.
Dieses System verfügt über eine integrierte GPU von Intel.
Wenn der Grafiktreiber installiert ist, können Sie bei
Windows im Einstellfenster Anzeige die Anzeigegeräte
wechseln und Anzeigeoptionen konfigurieren.
So öffnen Sie in Windows das Einstellfenster Anzeige:
1. Rufen Sie die Systemsteuerung auf.
2. Klicken Sie auf Anzeige (Symbol) - im Kategorie Darstellung und Anpassung.
3. Klicken Sie auf Bildschirmauflösung anpassen/Auflösung anpassen.
Oder
4. Klicken Sie mit der rechten Maustaste auf den Desktop (der
Desktop wird aufgerufen, indem Sie die Windows Logo-Taste
und gleichzeitig auf D drücken) und dann die Option
Bildschirmauflösung wählen.
5. Wählen Sie aus dem Drop-down-Menü die Bildschirmauflösung .
6. Klicken Sie auf Erweiterte Einstellungen .
So rufen Sie die Steuerung für Intel® HD-Grafik auf:
1. Klicken Sie auf das Symbol (Steuerung für Intel® HD-Grafik)
auf dem Apps-Bildschirm.
Oder
2. Klicken Sie mit der rechten Maustaste auf den Desktop (der
Desktop wird aufgerufen, indem Sie die Windows Logo-Taste
und gleichzeitig auf D drücken) und dann aus dem Menü die
Option Grafikeigenschaften wählen.
Oder
3. Klicken Sie auf das Symbol im Infobereich auf der Desktop-
Taskleiste und dann aus dem Menü die Option
Grafikeigenschaften wählen.
Anzeigegeräte
Neben dem integrierten LCD-Monitor können Sie auch
einen externen VGA-Monitor/Flachbildschirm oder ein
Fernsehgerät (an die Schnittstelle für externen Monitor oder
an den HDMI-Ausgangsanschluss angeschlossen) als Anzeigegerät anschließen.
Deutsch
35
Wechseln der Anzeigegeräte mit der
Abb. 10
+ P (Ändern der
Anzeigeeinstellungen)
Abb. 11 - Energieoptionen
Windows-Logo-Taste und der Taste P
Wenn Sie gleichzeitig auf die Tasten und P (oder Fn +
F7) drücken, konnen Sie bei Windows schnell und einfach
die Anzeigeeinstellungen und -modi wechseln (was besonders praktisch ist, wenn Sie einen Projektor anschließen).
1. Schließen Sie das externe Anzeigegerät an die Schnittstelle für
externen Monitor oder an den HDMI-Ausgangsanschlussan an,
und schalten Sie es ein.
2. Drücken Sie die Tastenkombination + P (oder Fn + F7).
3. Auf dem Bildschirm erscheint ein Menü.
4. Wählen Sie mit den Cursor-Tasten (oder + P) eine geeignete
Konfiguration aus dem Menü aus, und bestätigen Sie die Auswahl
Deutsch
durch Drücken der Eingabetaste.
Energieoptionen
Die Energieoptionen von Windows ermöglichen Ihnen die
Konfiguration der Optionen für das Energiemanagement des
Computers. Sie können Strom sparen, indem Sie Ener-giesparpläne erstellen und im linken Menü können Sie die
Optionen für den Netzschalter, die Energiespartasten (Fn+ F4) und Zuklappeinstellung (beim Schließen des
Dekkels) und den Anzeige- und Energiesparmodus (die
Standardeinstellung Energie sparen) konfigurieren.
Beachten Sie, dass sich die Energiesparpläne (Ener-giesparmodus) auf die Computerleistung auswirken.
Wählen Sie einen bestehenden Plan aus, oder klicken Sie im
linken Menü auf Energiesparplan erstellen, und wählen Sie
die Optionen, um einen neuen Plan zu erstellen. Klicken Sie
auf Energieplaneinstellungen ändern, und klicken Sie aufErweiterte Energieeinstellungen ändern, um weitere Optionen für die Konfiguration aufzurufen.
36
Installation der Treiber
Allgemeine Hinweise zur
Treiberinstallation
Wenn Sie keine fortgeschrittenen Kenntnisse
haben, folgen Sie für jeden
Treiber den Anweisungen
auf dem Bildschirm (z. B.
Weiter > Weiter > Fertig
stellen). In vielen Fällen
ist es erforderlich, den
Computer nach der
Treiberinstallation neu zu
starten.
Alle Module (z. B. WLAN
oder Bluetooth) müssen
vor der Treiberinstallation
eingeschaltet werden.
Windows Update
Nachdem Sie alle Treiber
installiert haben, sollten
Sie die Funktion WindowsUpdate aktualisieren, um
immer die neuesten Sicherheits-Updates usw. zu
erhalten (die Updates enthalten die neuesten
Fehlerbehebungen von
Microsoft).
Treiberinstallation und Stromversorgung
Während die Treiber installiert werden, muss der
Computer über den AC/DC-Adapter mit Strom versorgt werden. Einige Treiber benötigen für den Installationsvorgang sehr viel Strom. Wenn der Akku
nicht mehr über genügend Strom verfügt, kann sich
das System während der Installation ausschalten,
was zu Systemfehlern führen kann (das ist kein Sicherheitsproblem, und der Akku ist innerhalb von
einer Minute wieder aufladbar).
Abb. 12 - Installation der Treiber
Die Disc Device Drivers & Utilities + User's Manual enthält die Treiber und Hilfspro-
gramme, die für das einwandfreie Funktionieren des Computers notwendig sind. Möglicherweise wurden diese bereits vorinstalliert. Ist das nicht der Fall, legen Sie die Disc ein, und
klicken Sie auf Install Drivers (Schaltfläche) oder Option Drivers (Schaltfläche), um das
Treibermenü Optional aufzurufen.
Reihenfolge. Markieren Sie die Treiber, die installiert werden soll en (notieren Si e zum späteren Nachlesen die Treiber, die Sie installiert haben). Hinweis: Muss ein Treiber neu installiert
werden, sollten Sie den alten Treiber zunächst deinstallieren.
Manuelle Treiber-Installation
Klicken Sie in der Anwendung Drivers Installer auf die Schaltfläche Browse CD/DVD und
navigieren Sie zu der ausführbaren Datei in dem Ordner für Ihren Treiber.
Wenn während des Installationsvorgangs das Fenster Neue Hardware gefunden erscheint,
klicken Sie auf Abbrechen, um das Fenster zu schließen. Befolgen Sie dann die Installationsanweisungen.
Installieren Sie die Treiber in der in Abb. 12 angegebenen
Deutsch
37
Fehlerbehebung
ProblemMögliche Ursache - Lösung
Die Module Wireless-LAN/
Bluetooth können nicht erkannt
werden.
Das PC-Kamera-Modul kann nicht
erkannt werden.
Die mit der PC-Kamera
Deutsch
aufgenommenen Dateien benötigen
zu viel Speicherplatz.
Im Flugzeugmodus sind die Module ausgeschaltet. Prüfen Sie der LED-Anzeige , ob der
Computer im Flugzeugmodus ist (siehe Tabelle 1 auf Seite 26). Mit der Tastenkombination
Fn +F11 können Sie de n Flugzeugmodus ein- oder ausschalten (siehe Tabelle 2 auf Seite
28).
Das ist ausgeschaltet. Mit der Tastenkombination Fn +F10 können Sie das PC-KameraModul einschalten (siehe Tabelle 2 auf Seite 28). Starten Sie die Kamera-Anwend ung, um
das Kamerabild zu sehen.
Videodateien, die mit hoher Auflösung aufgenommen werden, erfordern sehr viel
Speicherplatz.
Beachten Sie, dass das Betriebssystem Windows mindestens 20GB (64bit) freien Speicher
im Laufwerk C: der Systempartition benötigt. Es wird empfohlen, die aufgenommenen
Videodateien in einem anderen Laufwerk als C: zu speichern, die Dateigröße der
Aufnahmedateien zu beschränken oder die Auflösung der Videos zu verringern.
38
Technische Daten
Aktualität der technischen Daten
Die in diesem Teil aufgeführten technischen Daten sind zum Zeitpunkt der
Druckstellung richtig. Bestimmte
Elemente (insbesondere Prozessortypen/-geschwindigkeiten) können im
Rahmen des Entwicklungsplans des
Herstellers zwischenzeitlich geändert
oder aktualisiert werden. Detailinformationen erhalten Sie bei Ihrem Servicezentrum.
Prozessor-Optionen
Intel® Pentium™ Prozessor
N3520 (2,17GHz)
2MB L2 Cache, 22nm, DDR3L-1333MHz,
TDP 7,5W
Intel® Celeron™ Prozessor
N2920 (1,86GHz)
2MB L2 Cache, 22nm, DDR3L-1066MHz,
TDP 7,5W
N2820 (2,13GHz), N2815 (1,86GHz)
1MB L2 Cache, 22nm, DDR3L-1066MHz,
TDP 7,5W
N2806 (1,60GHz)
1MB L2 Cache, 22nm, DDR3L-1066MHz,
TDP 4,3W
BIOS
AMI BIOS (64Mb SPI Flash-ROM)
Speicher
Für N3520, N2920, N2820 & N2815 Prozessoren:
Zwei 204-Pin SODIMM-Sockel,
Unterstützung von DDR3L 1600MHz
Speicher
Speicher auf bis zu 8GB erweiterbar
(Die tatsächliche Speicherarbeitsfrequenz
hängt vom FSB des Prozessors ab.)
Für N2806 Prozessoren:
Ein 204-Pin SODIMM-Sockel,
Unterstützung von DDR3L 1600MHz
Speicher
Speicher auf bis zu 8GB erweiterbar
(Die tatsächliche Speicherarbeitsfrequenz
hängt vom FSB des Prozessors ab.)
Speicher
(Werkseitige Option) Ein austauschbares
Super Multi-optisches Laufwerk (9,5mm
Höhe)
(Werkseitige Option) Dummy-Laufwerk
Eine austauschbare SATA-2,5"-Festplatte
(7,0mm/9,5mm Höhe)
LCD
17,3" (43,94cm) HD+
Videoadapter
Intel HD Graphics
Dynamische Frequenz (Intel Dynamic Video
Memory Technology für bis zu 1,7GB)
Kompatibel mit MS DirectX® 11
Audio
High-Definition-Audio-kompatible
Schnittstelle
2 eingebaute Lautsprecher
Eingebautes Mikrofon
Sicherheit
Öffnung für Sicherheitsschloß (Typ
Kensington)
BIOS-Paßwort
(Werkseitige Option) TPM 1.2
Tastatur
"Win Key"-Tastatur in Originalgröße mit
Nummerntastatur
Zeigegerät
Eingebautes Touchpad
39
Deutsch
Schnittstellen
Ein USB 3.0-Anschluss
Drei USB 2.0-Anschlüsse
Ein HDMI-Ausgangsanschluss
Eine Schnittstelle für externen Monitor
Eine Lautsprecher/Kopfhörer-
Ausgangsbuchse
Eine Mikrofon-Eingangsbuchse
Eine RJ-45 LAN-Buchse
Eine DC-Eingangsbuchse
Kommunikation
10Mb/100Mb Ethernet LAN
300K/ 1,0M HD PC-Kamera-Modul
Deutsch
WLAN/ Bluetooth Half Mini-Card Module:
(Werkseitige Option) Intel® Wireless-AC
3160 Wireless LAN (802.11ac) und
Bluetooth 4.0
(Werkseitige Option) Intel® Wireless-N
7260 Wireless LAN (802.11b/g/n) und
Bluetooth 4.0
(Werkseitige Option) Wireless LAN
(802.11b/g/n) (andere Hersteller)
(Werkseitige Option) Wireless LAN
(802.11b/g/n) und Bluetooth 4.0 (andere
Hersteller)
Mini-Card-Steckplatz
Ein Steckplatz für Wireless-LAN-Modul
oder Kombinierte Bluetooth und WLANModul
413 (B) x 273 (T) x 12,7 - 28,5 (H) mm
2,5kg (Barebone mit
und 32WH-Akku)
optischem Laufwerk
40
A propos de ce Guide Utilisateur Concis
Ce guide rapide est une brève introduction à la mise en route de votre système. Il s’agit d’un supplément, et non pas d’une
alternative auManuel de l’Utilisateur en Anglais complet au format Adobe Acrobat s ur le disque Device Drivers & Utilities+ User's Manual fourni avec votre ordinateur . Ce disque contient aussi les pilo tes et utilitaires nécessaires au fonctionnement
correct de votre ordinateur (Remarque: La compagni e se réserve le droit de revoir cette publication ou de modifier son contenu sans préavis).
Certains ou tous les éléments de l’ordinateur peuvent avoir été déjà installés. Si ce n’est pas le cas , ou si vous avez l’intention
de reconfigurer (ou réinstaller) des portions du système, reportez-vous au Manuel de l’Utilisateur complet. Le disq ue DeviceDrivers & Utilities + User’s Manual ne contient pas de système d’exploitation.
Informations de réglementation et de sécurité
Prêtez attention aux avis réglementaires et informations de sécurité contenus dans le Manuel de l'Utilisateur se trouvant sur
le disque Device Drivers & Utilities + User’s Manual.
Intel, Pentium et Celeron sont des marques déposées ou enregistrées d’Intel Corporation.
Français
41
Instructions d’entretien et d’utilisation
L’ordinateur est robuste, mais il peut toutefois être endommagé. Afin d’éviter ceci, veuillez suivre ces recommandations :
• Ne le laissez pastomber. Ne l’exposez à aucun choc ou vibration.
Si l’ordinateur tombe, le boîtier et d’autres éléments pourraient être
endommagés.
• Gardez-le sec. Ne le laisser pas surchauffer. Tenez l’ordinateur et
son alimentation externe à distance de toute source de chaleur. Il
s’agit d’un appareil électrique. Si de l’eau ou tout autre liquide venait
à pénétrer à l’intérieur de votre ordinateur , il pourrait être sérieusement endommagé.
• Evitez les interférences. Tenez l’ordinateur à distance de transfor-
mateurs à haute capacité, moteurs électriques, et autres appareils
générateurs de champs magnétiques importants. Ceux-ci peuvent
gêner ses performances normales et endommager vos données.
• Suivez les procédures appropriées d’utilisation de votre ordina-
teur. Arrêtez l’ordinateur correctement, et fermez tous vos programmes (n’oubliez pas d’enregistrer votre travail). N’oubliez pas
d’enregistrer vos données régulièrement puisqu’elles peuvent être
Français
perdues si la batterie est vide.
Révision
Si vous essayez de réparer l'ordinateur par vous-même, votre
garantie sera annulée et vous risquez de vous exposer et d'exposer l'ordinateur à des chocs électriques. Confiez toute réparation à un technicien qualifié, particulièrement dans les cas
suivants:
• Si le cordon d’alimentation ou l’adaptateur AC/DC est endommagé,
abimé ou effiloché.
• Si votre ordinateur a été exposé à la pluie ou tout autre liquide.
• Si votre ordinateur ne fonctionne pas normalement bien que vous
ayez suivi les instructions de mise en marche à la lettre.
• Si votre ordinateur est tombé par terre ou a été endommagé (si l'écran
LCD est cassé, ne touchez pas le liquide car il contient du poison).
• Si une odeur inhabituel, de la chale ur ou de la fumé e app arais sai t sortant de votre ordinateur.
Informations de sécurité
• Utilisez uniquement un adaptateur AC/DC agréé avec votre ordinateur.
• Utilisez uniquement le cordon d’alimentation et les batteries indiqués
dans ce manuel. Ne jetez pas les batteries dans le feu. Elles peuvent
exploser. Consultez la réglementation locale pour des instructions de
recyclage possibles.
• Ne continuez pas d'utiliser une batterie qui est tombée, ou qui paraît
endommagée (ex: tordue ou vrillée) d'une manière quelconque.
Même si l'ordinateur continue de fonctionner avec la batterie en
place, cela peut détériorer le circuit, pouvant déclencher un incendie.
• Assurez-vous que votre ordinateur est complètement éteint avant de
le mettre dans un sac de voyage (ou tout autre bagage similaire).
• Avant de nettoyer l'ordinateur, retirez la batterie et assurez-vous que
l'ordinateur est débranché de toute alimentation électr iq ue externe,
périphériques et câbles (y compris les lignes téléphoniques).
• Utilisez un chiffon propre et doux pour nettoyer l'ordinateur, mais
n'appliquez pas d'agent de nettoyage directement sur l'ordinateur.
N’utilisez pas de produit de nettoyage volatil (des distillés pétrôle) ou
abrasifs sur aucun des éléments de l’ordinateur.
• N’essayez jamais de réparer la batterie. Au cas où votre batterie
aurait besoin d’être réparée ou changée, veuillez vous adresser à
votre représentant de service ou à des professionnels qualifiés.
• Notez que dans les ordinateurs ayant un logo fixé par dépôt électrolytique, le logo est recouvert par une protection adhésive. À cause de
l’usure générale, cette protection adhésive se détériore avec le temps
et le logo exposé peut former des angles coupants. Faites bien attention lorsque vous manipulez l'ordinateur, et évitez de toucher le logo
fixé par dépôt électrolytique. Dans la sacoche de voyage, ne mettez
pas d’autres objets qui risquent de se frotter contre l’ordinateur pendant le transport. En cas d’une telle usure, contactez votre centre de
services.
42
Précautions concernant les batteries polymères
Elimination de la batterie & avertissement
Le produit que vous venez d’acheter contient une batterie rechargeable. Cette batterie est recyclable. Quand elle n’est plus
utilisable, en fonction des lois locales des différents états et
pays, il peut être illégal de s’en débarrasser en la jetant avec les
ordures ménagères normales. Vérifiez auprès du responsable
local de l’élimination des déchets solides de votre quartier pour
vous informer des possibilités de recyclage ou de la manière appropriée de la détruire.
Il existe un danger d’explosion si la batterie est remise de façon
incorrecte. Remplacez-la uniquement par des batteries de
même type ou de type équivalent, recommandées par le fabricant. Eliminez les batteries usagées selon les instructions du fabricant.
Notez les informations suivantes spécifiques aux batteries polymères, et le cas échéant, celles-ci remplacent les informations générales de précaution sur les batteries.
• Les batteries polymères peuvent présenter une légère dilatation ou
gonflement, mais cela est inhérent au mécanisme de sécurité de la
batterie et ne représente pas une anomalie.
• Manipulez les batteries polymères de façon appropriée lors de leur
utilisation. Ne pas utiliser de batteries polymères dans des environnements présentant une température ambiante élevée, et ne pas stocker
les batteries non utilisées pendant de longues périodes.
Français
43
Guide de démarrage rapide
130 ゚
Arrêt
Veuillez noter que vous devriez toujours éteindre votre ordinateur
en utilisant la commande Arrêter dans Windows (voir ci-dessous). Cette précaution évite des problèmes de disque dur ou de
système.
Cliquez sur Périphériques dans la barre des charmes (utilisez la
combinaison de touches Touche Logo de Windows +
touche C pour accéder à la barre des charmes) et sélectionnez
Arrêter dans el menu Marche/Arrêt.
Ou
Sélectionnez Arrêter ou se déconnecter > Arrêter dans el menu
contextuel (utilisez la combinaison de touches Touche Logo deWindows + touche X pour accéder au menu contextuel).
Figure 1
Ouvrir le couvercle/LCD/
ordinateur avec un adap-
tateur AC/DC branché
1. Enlevez tous les memballages.
2. Posez l’ordinateur sur une surface stable.
3.
Installez la batterie et assurez-vous qu’elle correctement posi-
tionnée.
4. Connectez fermement les périphériques que vous souhaitez
utiliser avec votre ordinateur (par ex. clavier et souris) à leurs
ports respectifs.
5. Branchez l'adaptateur AC/DC à la prise d'entrée DC sur la
gauche de l’ordinateur, branchez ensuite le cordon secteur à
une prise murale, puis à l’adaptateur AC/DC(prenez soin
d'utilisez l'adaptateur lors de la configuration de l'ordinateur, car pour des raisons de sécurité pour l'ordinateur, la batte-
rie sera verrouillée lors de l'expédition afin de ne pas alimenter
le système avant la première connexion à l'adaptateur AC/DC).
6. D'une main, soulevez soigneusement le couvercle/LCD pour
obtenir un angle de vision confortable (ne pas dépasser 130
degrés), de l'autre main (comme illustré dans la Figure 1)
maintenez la base de l'ordinateur (Remarque : Ne soulevez
Français
jamais l'ordinateur par le couvercle/LCD).
7. Pressez le bouton de mise en marche pour allumer.
Logiciel système
Votre ordinateur peut être livré avec un logiciel système préinstallé. Si ce n’est pas le cas, ou si vous re-configurez votre
ordinateur pour un système différent, vous constaterez que ce
manuel fait référence à Microsoft Windows 8.1.
44
Carte du système: Vue de face avec l’écran LCD ouvert
7
Figure 2 - Vue de face avec
l’écran LCD ouvert
1. Caméra PC
2. *Indicateur LED de
caméra PC
*Quand la caméra PC est
en cours d'utilisation le
Indicateur LED sera
illuminé en rouge.
3. Microphone
4. Écran LCD
5. Bouton d'alimentation
6. Clavier
7. Clickpad (Touchpad) et
boutons
Utilisation des appareils
sans fil à bord d'un avion
L'utilisation de tout appareil électronique de transmission est généralement
interdite à bord d'un avion.
Vérifiez que les modules
WLAN & Bluetooth sont
désactivés si vous utilisez
l'ordinateur à bord d'un avion en mettant le système
en Mode Avion.
5
7
6
2
1
3
4
Sensibilité du
Clickpad/Touchpad
Les zones de bouton
de souris au bas du
pavé mesurent environ
15mm à partir du bas
du pavé, et les boutons
gauche et droit sont divisés à peu près au milieu comme illustré cidessous. Appuyez sur
la zone du bouton
gauche pour faire un
clic gauche, et sur la
zone du bouton droit
pour faire un clic droit.
7
Français
45
Indicateurs LED
Les indicateurs LED sur votre ordinateur affichent des informations utiles sur l’état actuel de votre ordinateur.
IcôneCouleurDescription
OrangeL'adaptateur AC/DC est branché
Vert L’ordinateur est allumé
Français
46
Vert
clignotant
OrangeLa batterie est en charge
Vert La batterie est complètement chargée
Orange
clignotant
VertMode Avion activé (les modules WLAN & Bluetooth sont désactivés)
VertLe disque dur/périphérique optique est en cours d'utilisation
Tableau 1 - Indicateurs LED
Le système est dans le mode de Veille configuré
La batterie a atteint le niveau bas critique
Numeric
Keypad
Numeric
Keypad
Figure 3 - Clavier
Touche Logo de Windows
Touche Menu/Application
Touches Fonction
Touche Fn
Pavé
numérique
Verr Num &
ArrêtDét
Raccourci clavier du logo de Windows
Utilisez la combinaison des touches Touche Logo de Windows + D pour passer de
l'écran d'accueil au bureau de Windows.
Raccourci clavier de Menu/Application
Lorsque l'application Bureau est activée, vous pouvez utiliser la touche Menu/Application du clavier pour effectuer un clic droit de souris. Dans l'écran d'accueil cette fonction est utile pour afficher rapidement la barre Personnaliser.
Clavier
Le clavier comporte un pavé numérique (sur le côté droit du clavier) permettant une entrée facile de données numériques.
Le fait d'appuyer sur Verr Num activ e ou désactive le pavé numérique. Il es t également doté de touches fonc tion pour vous
permettre de changer instantanément de mode opérationnel
.
Français
47
Touches fonction
Les touches de fonctions (F1 - F11 etc.) agiront comme touches de raccourci (hot-key) quand pressée en maintenant la touche
Fn appuyée. En plus des combinaisons des touches de fonction de base, des indicateurs visuels sont disponibles (dans l'ap-
plication Bureau de Windows uniquement et pas dans l'écran d'accueil) quand le pilote de touches de raccourci (HotKey
Diminution/Augmentation de
la luminosité de l’écran LCD
48
Activer/Désactiver le
module caméra PC
Activer/Désactiver le Mode
Activer/Désactiver le pavé
numérique
Activer/Désactiver l'arrêt
défilement
Basculer entre majuscule
et minuscule
Activer/Désactiver le Contro l Ce nt e r (C en tr e d e
Contrôle Automatique du
Ventilateur /Pleine Puis-
page 56)
Fn +
Fn +
Fn +
Fn +
Fn +
Tableau 2 - Touches de fonctions & indicateurs visuels
Avion
contrôle) (voir la page 49)
sance
Control Center (Centre de contrôle)
Le Control Center (Centre de contrôle) dans Windows 8.1 fonctionne dans l 'application Bureau et non dans l' écran d'accueil.
Appuyez sur la combinaison de touches Fn + Échap ou double-cliquez sur l'icône dans la zone de notification de labarre des tâches pour activer/désactiver le Control Center. Le Control Center donne un accès rapide aux commandes fré-
quemment utilisées, et vous permet de rapidement d'activer/désactiver le touchpad/le module caméra PC.
Figure 4 - Control Center
Français
Cliquez sur les icônes du Control Center pour activer la fonction correspondante, ou maintenez le bouton de la souris enfoncé et déplacez le curseur à l'endroit approprié. Certaines fonctions sont automatiquement ajustées lorsque le mode d'alimentation est sélectionné.
49
Modes d’alimentation
Vous pouvez définir un Mode d’alimentation en cliquan t sur l'icône appropriée au dessus du Control Center. Chaque mode
d'alimentation aura une incidence sur le mode Economie d'énergie, le mode Avion, la gestion de l'alimentation et l'alimentation de la caméra PC de l'ordinateur, etc.
Vous pouvez cliquer sur l’icône du Control Center pour définir un mode d'alimentation générale, puis cliquer sur les icônes
individuelles dans le Control Center pour activer/désactiver le touchpad et le module caméra PC
L'icône État d'alimentation indique si vous êtes actuellement alimenté par la batterie, ou par l'adaptateur AC/DC
branché à une prise de courant. La barre d’état d’alimentation indiquera l'état de charge actuel de la batterie.
Brightness (Luminosité)
L'icône Luminosité indiquera le niveau de luminosité actuel
de l'écran. Vous pouvez utiliser le curseur pour ajuster la luminosité de l'écran ou les combinaisons de touches Fn + F8/F9, ou utiliser la combinaison de touches Fn + F2 pour
éteindre le rétroéclairage LED (appuyez sur une touche pour
le rallumer). Notez que la luminosité de l'écran est également
affectée par le Mode d'alimentation choisi.
Volume
L'icône Volume indiquera le niveau du volume actuel. Vous
pouvez utiliser le curseur pour régler le volume ou les combinaisons de touches Fn + F5/F6, ou utiliser les combinaisons de touches Fn + F3 pour couper le volume.
Power Conservation (Économie d'énergie)
Ce système prend en charge les fonctionnalités de gestion
d’alimentation Energy S tar qui placent les ordinateurs (CPU,
disque dur, etc.) dans des modes veille à faible consommation
d'énergie après une période d'inactivité donnée. Cliquez sur le
bouton Performance (Performances), Balanced (Equilibré)
ou Energy Star.
Sleep Button (Bouton Veille)
Cliquez sur le bouton Veille Prolongée ou Veille pour que
l'ordinateur entre dans le mode d'économie d'énergie sélectionné.
Display Switch (Permutation d’affichage)
Cliquez sur le bouton Permutation d’affichage pour accéder au menu (ou utilisez la combinaison de touches + P)
et sélectionnez le mode d'affichage joint approprié.
Time Zone (Fuseau horaire)
Cliquer sur le bouton Fuseau horaire permet d’accéder au
panneau de configuration de Date et heure de Windows.
Desktop Background (Fond d'écran du bureau)
Cliquer sur le bouton Fond d'écran du bureau vous permettra de changer l'image du fond d'écran du bureau.
Touchpad/caméra PC
Cliquez sur l’un de ces boutons pour permuter l’état d’alimentation du TouchPad ou du module caméra. Notez que
l'état de l'alimentation du module caméra est également affecté par le mode d'alimentation choisi.
Français
51
Carte du système: Vues de face, gauche, droite, arrière & dessous
Avertissement de retrait du capot
inférieur
Ne pas retirer le(s) capot(s) et/ou la (les)
vis dans le but de mettre à niveau l'appareil car cela pourrait enfreindre les termes
de votre garantie.
Si vous avez besoin de remplacer/supprimer le disque dur/RAM/le dispositif optique etc., pour une raison quelconque,
contactez votre distributeur/fournisseur
pour plus d'informations.
Déplacez la souris vers le
coin inférieur gauche de
l'écran et faites un clic
droit sur le bouton Démarrer pour accéder au
menu.
Figure 7 - Écran d'accueil
Tout au long de ce manuel, vous verrez une instruction pour ouvrir le Panneau de Configuration. Faites un clic droit sur
le bouton Démarrer dans l'appli Bureau ou sur l'écran d'accueil (ou utilisez la combinaison de touches Touche Logo deWindows+ X) pour faire apparaître un menu contextuel avancé de fonctionnalités utiles telles que Panneau de configu-
ration, Programmes et fonctionnalités, Options d'alimentation, Gestionnaire de tâches, Rechercher, Explorateur de fichiers,
Invite de commandes, Gestionnaire de périphériques et Connexions réseau, et plus encore et sélectionnez Panneau de Confi-guration.
Écran d'accueil & bureau de Windows 8.1
Les applications, les panneaux de contrôle, les utilitaires et les programmes
dans Windows sont accessibles depuis l'écran d'accueil et/ou l'applicationBureau de Windows. Le Bureau (qui fonctionne comme une application
dans l'écran d'accueil) est accessible en cliquant sur l'élément Bureau dans
l'écran d'accueil (ou en utilisant la combinaison de touches Touche Logo deWindows+ D). La barre des tâches est affichée au bas de l'écran du bu-
reau, et vous pouvez voir la zone de notification de la barre des tâches en bas
à droite de l'écran. Cliquez sur la flèche en bas de l'écran d'accueil pour accéder à Applications.
Français
53
Applications et Vignettes
Cliquez sur la flèche en bas de
l'écran d'accueil pour accéder à Applications.
L'écran d'accueil contiendra un certain nombre d'applications, et bien
d'autres seront installées lorsque vous ajouterez des applications, etc.
T outes ces applications peuvent tenir sur un seul écran ainsi vous aurez
souvent besoin d'utiliser le curseur au bas de l'écran afin d'afficher
toutes les applications nécessaires.
Barre des charmes
Le côté droit de l'écran affiche la Barre des charmes. La Barre des charmes contient les menus Rechercher, Partager, Accueil, Périphériques et Paramètres. Pour accéder à la Barre des charmes déplacez le curseur vers les coins supérieurs ou
inférieurs à droite de l'écran, puis passez la souris sur l'un des éléments de la Barre des charmes pour l'activer (la barre est
noire quand elle est active), ou utilisez la combinaison de touches Touche Logo de Windows + C.
Français
Figure 8 -Ecran d'accueil avec la Barre des charmes
54
Caractéristiques vidéo
1
2
2
1
Résolution de l'écran des applications (Windows 8.1)
La résolution minimale dans laquelle les applications s'exécuteront est 1024x768.
La résolution minimale requise pour prendre en charge
toutes les fonctionnalités de Windows 8.1 (y compris le multitâche avec ancrage) est 1366x768.
Le système comporte un GPU intégré Intel. Vous pouvez
permuter les dispositifs d'affichage et configurer les options
d'affichage depuis le panneau de contrôle Affichage dans
Windows, à partir du moment où le pilote vidéo est installé.
Pour accéder au panneau de contrôle Affichage:
1. Allez au Panneau de Configuration.
2. Cliquez sur Affichage dan Apparence et personnalisation
(catégorie).
3. Cliquez sur Modifier la résolution de l’écran/Ajuster la réso-lution.
OU
4. Cliquez-droit sur le bureau (utilisez la combinaison de touches
Touche Logo de Windows + touche D pour accéder au
bureau) et sélectionner la Résolution d’écran.
5. Utilisez le menu déroulant pour sélectionner la résolution d’écran
.
6. Cliquez sur Paramètres avancés .
Pour accéder au Panneau de configuration des graphiques
HD Intel®:
1. Cliquez sur l’icône (Panneau de configuration des graphiques
HD Intel®) dans l'écran Applications.
OU
2. Cliquez-droit sur le bureau (utilisez la combinaison de touches
Touche Logo de Windows + touche D pour accéder au
bureau) et sélectionnez Propriétés graphiques dans le menu.
OU
3. Cliquez sur l'icône dans la zone de notification de la barre des
tâches du bureau et sélectionnez Propriétés graphiques dans le
menu.
Français
Périphériques d’affichage
En plus du LCD intégré, vous pouvez aussi utiliser un moniteur VGA externe/écran plat ou TV (connecté au port moniteur externe ou à la prise de sortie HDMI) comme
périphérique d'affichage.
Figure 9 - Panneau de contrôle Affichage
55
Utilisez la combinaison de touches du
Figure 10
+ P (Modifiez la
configuration de l'af-
fichage)
Figure 11 - Options d’alimentation
logo de Windows + P pour changer
d'affichage
Vous pouvez utiliser la combinaison de touches + P (ou
Fn + F7) pour changer rapidement de configuration d'affi-
chage et de mode (ce qui est particulièrement utile lors de la
connexion d'un projecteur) sous Windows.
1. Connectez votre écran externe au port moniteur externe ou à la
prise de sortie HDMI, et allumez-le.
2. Appuyez sur la combinaison de touches + P (ou Fn + F7).
3. Un menu d'écran apparaîtra.
4. Utilisez les touches du curseur (ou + P) pour sélectionner la
configuration appropriée dans le menu, et appuyez sur Entrée
pour confirmer la sélection.
Français
Options d’alimentation
Le panneau de configuration Options d'alimentation de
Windows vous permet de configurer la gestion d'alimentation de votre ordinateur. Vous pouvez économiser de l'énergie à l'aide de modes de gestion de l'alimentation et
configurer les options pour le bouton d'alimentation, bou-
ton de veille (Fn + F4), couvercle de l'ordinateur (lorsqu'il est fermé), mode Affichage et Veille (l'état d'économie
d'énergie par défaut) dans le menu de gauche. Remarquez
que le mode de gestion d'économie d'énergie peut avoir un
impact sur les performances de l'ordinateur.
Cliquez pour sélectionner l'un des modes existants, ou cliquez sur Créer un mode de gestion d'alimentation dans le
menu gauche et sélectionnez les options pour créer un nouveau mode. Cliquez sur Modifier les paramètres du mode
et cliquez sur Modifier les paramètres d'alimentationavancés pour accéder à plus d'options de configuration.
56
Installation du pilote
Directives générales pour
l'installation du pilote
D'une manière générale,
suivez les instructions par
défaut à l'écran pour chaque
pilote (par exemple Suivant
> Suivant > Terminer) à
moins que vous ne soyez un
utilisateur avancé. Dans la
plupart des cas, un redémarrage est nécessaire
pour installer le pilote.
Assurez-vous que les modules (par exemple WLAN
ou Bluetooth) sont allumés
avant d'installer le pilote correspondant.
Windows Update
Après avoir installé tous les
pilotes vérifiez que vous
avez activé WindowsUpdate afin d'obtenir toutes
les dernières mises à jour de
sécurité etc. (toutes les
mises à jour incluront les
derniers correctifs de Microsoft).
Installation des pilotes et alimentation
Lors de l'installation des pilotes assurez-vous
que votre ordinateur est alimenté par l'adaptateur CA/CC connecté à une source d'alimentation. Certains pilotes consomment une quantité
importante d'énergie pendant la procédure
d'installation, et si la capacité restante de la batterie n'est pas suffisante cela peut provoquer
l'arrêt du système et entraîner des problèmes
de système (à noter qu'il n'y a pas ici de problème de sécurité en cause, et la batterie sera
rechargeable en 1 minute).
Figure 12 - Installation du pilote
Le disque Device Drivers & Utilities + User’s Manual contient les pilotes et les utilitaires
nécessaires pour un bon fonctionnement de votre ordinateur. Cette installation aura probablement déjà été faite pour vous. Si ce n'est pas le cas, insérez le disque et cliquez sur Install
Drivers (bouton), ou Option Drivers (bouton) pour accéder au menu des pilotes Option-
nels. Installez les pilotes en respectant l'ordre indiqué dans la Figure 12. Cliquez pour sé-
lectionner les pilotes que vous désirez installer (vous devez noter les pilotes lorsque vous
les installez). Remarque: Si vous devez réinstaller un pilote, vous devez d’abord le désinstaller.
Installation manuelle du pilote
Cliquez le bouton Browse CD/DVD dans l'application Drivers Installer et naviguer jus-
qu'au fichier exécutable dans le dossier de pilote approprié.
Si l’assistant Nouveau matériel détecté apparaît pendant la procédure d'installation, cliquez
sur Annuler pour fermer l’assistant, et suivez la procédure d'installation comme indiqué.
Français
57
Dépannage
ProblèmeCause possible - résolution
Les modules LAN sans fil/
Bluetooth ne peuvent pas être
détectés.
Le module caméra PC ne peut
pas être détecté.
Les fichiers vidéo capturés depuis
la caméra PC prennent trop de
place sur le disque.
Français
Les modules sont désactivés quand l'ordinateur est en Mode Avion. Vérifiez l'indicateur LED
pour voir si l'ordinateur est en Mode Avion (voir le Tableau 1 à la page 46). Utilisez la
combinaison de touches Fn + F11 pour activer ou désactiver le Mode Avion (voir le Tableau 2
à la page 48).
Le module est désactivé. Utilisez la combinaison de touche s Fn + F10 pour activer le module
(voir le Tableau 2 à la page 48). Exécutez l’application Caméra pour voir l'image de l'appareil
photo.
Notez que la capture de fichiers vidéo à haut e résolution nécess ite un esp ace subst antiel sur le
disque pour chaque fichier.
Notez que le système Windows nécessite un minimum de 20Go (64bit)d'espace libre sur la
partition système du lecteur C:. Il vous est recommandé d'enregistrer le fichier vidéo capturé
dans un autre emplacement que le lecteur C:, limitez la taille du fichier de la vidéo capturée ou
réduisez la résolution vidéo.
58
Spécifications
Dernières informations de
spécification
Les spécifications énumérées dans
cette section sont correctes à l'heure de
la mise sous presse. Certains éléments
(particulièrement les types de processeur/vitesse unique) peuvent être modifiés ou mis à niveau en fonction du
calendrier des parutions du fabricant.
Voyez auprès de votre service clientèle
pour les détails.
Options de processeurs
Processeur Intel® Pentium™
N3520 (2,17GHz)
Cache L2 2Mo, 22nm, DDR3L-1333MHz,
TDP 7,5W
Processeur Intel® Celeron
N2920 (1,86GHz)
Cache L2 2Mo, 22nm, DDR3L-1066MHz,
TDP 7,5W
N2820 (2,13GHz), N2815 (1,86GHz)
Cache L2 1Mo, 22nm, DDR3L-1066MHz,
TDP 4,3W
N2806 (1,60GHz)
Cache L2 1Mo, 22nm, DDR3L-1066MHz,
TDP 4,3W
BIOS
AMI BIOS (SPI Flash ROM de 64Mb)
Mémoire
Pour Processeurs N3520, N2920,
N2820 & N2815:
Deux emplacements SODIMM 204
broches, supportant la mémoire DDR3L
1600MHz
Mémoire extensible jusqu’à 8Go
(La fréquence réelle d’opération de la
mémoire dépend du FSB du processeur.)
Pour Processeurs N2806:
Un emplacement SODIMM 204 broches,
supportant la mémoire DDR3L 1600MHz
Mémoire extensible jusqu’à 8Go
(La fréquence réelle d’opération de la
mémoire dépend du FSB du processeur.)
Stockage
™
(Option d’usine) Un module de Super Multi
lecteur optique échangeable
(Option d’usine) Dummy ODD
Un disque dur SATA échangeable de 2,5"
7,0mm/9,5mm (H)
Adaptateur Vidéo
Intel® HD Graphics
Fréquence dynamique (Technologie de
mémoire vidéo dynamique d'Intel jusqu’à
1,7Go)
Compatible avec MS DirectX® 11
Son
Interface conforme HDA (Son Haute
Définition)
2 haut-parleurs intégrés
Microphone intégré
Sécurité
Fente de verrouillage de sécurité (type
Kensington)
413 (l) x 273 (p) x 12,7 - 28,5 (h) mm
2,5kg (Barebone avec lecteur optique &
batterie
32WH)
,
60
Acerca de esta Guía del Usuario Concisa
Esta guía rápida es una breve introducción para poner su sistema en funcionamiento. Es un suplemento y no un sustituto del
Manual del usuario completo en inglés en formato Adobe Acrobat del disco Device Drivers & Utilities + User's Manual
suministrado con el ordenador. En este disco también se encuentran los controladores y utilitarios necesarios para utilizar el
ordenador correctamente (Nota:
previo aviso).
Algunas o todas las características del ordenador pueden haberse configurado de antemano. Si no lo están, o si desea
reconfigurar (o reinstalar) partes del sistema, consulte el Manual del usuario completo. El disco Device Drivers & Utilities+ User’s Manual no contiene un sistema operativo.
Información de regulación y seguridad
Por favor, preste especial atención a todos los avisos de regulación e información de seguridad contenidos en el Manual del
usuario completo del disco Device Drivers & Utilities + User’s Manual.
Intel, Pentium y Celeron son marcas/marcas registradas de Intel Corporation.
La compañía se reserva el derecho a revisar esta publicación o cambiar su contenido sin
Español
61
Instrucciones para el cuidado y funcionamiento
El ordenador portátil es muy robusto, pero puede dañarse. Para
evitar esto, siga estas sugerencias:
• No lo deje caer ni lo exponga a golpes fuertes. Si el ordena dor se
cae, la carcasa y los componentes podrían dañarse.
• Manténgalo seco y no lo sobrecaliente. Mantenga el ordenador y
fuente de alimentación alejados de cualquier tipo de fuente de
calor. Esto es un apara to eléctrico. Si se derrama agua u otro líquido
en su interior, el ordenador podría dañarse seriamente.
• Evite las interferencias. Mantenga el ordenador alejado de trans-
formadores de alta capacidad, motores eléctricos y otros campos
magnéticos fuertes. Éstos pueden dificultar el correcto funcionamiento y dañar los datos.
• Siga las instrucciones apropiadas de manejo del ordenador.
Apague el ordenador correctamente y no olvide guardar su trabajo.
Recuerde guardar periódicamente sus datos, pues los datos pueden
perderse si la batería se descarga.
Servicio
Si intenta reparar el ordenador usted mismo, podría anular la
garantía y exponerse usted y el ordenador a descarga eléctrica.
Deje que sea personal de reparación cualificado el que realice
las reparaciones, especialmente bajo cualquiera de estas condi-
Español
ciones:
• Cuando el cable de alimentación o adaptador AC/DC esté dañado o
pelado.
• Si el ordenador ha estado expuesto a la lluvia u otros líquidos.
• Si el ordenador no funciona con normalidad tras seguir las instruc-
ciones de uso.
• Si el ordenador se ha caído o dañado (no toque el líquido venenoso
si el panel LCD se rompe).
• Si hay un olor fuera de lo normal, calor o humo que sale del ordenador.
Información de seguridad
• Utilice solamente un adaptador de alimentación aprobado para su
uso con este ordenador.
• Utilice solamente el cable de corriente y las baterías indicados en
este manual. No tire las baterías al fuego. Podrían explotar. Consulte los códigos locales para posibles instrucciones para desechos
especiales.
• Nunca utilice una batería que se haya caído o que parezca dañada
(p. ej. doblada o retorcida). Incluso si el ordenador sigue funcionando con una batería dañada, puede provocar daños en el circuito
que podrían causar fuego.
• Compruebe que su ordenador esté completamente apagado antes de
introducirlo en una bolsa de viaje (o en cualquier funda).
• Antes de limpiar el ordenador, quite la batería y asegúrese de que el
ordenador esté desconectado de cualquier fuente de alimentación
externa, periféricos y cables (incluyendo la línea telefónica).
• Utilice un trapo limpio y suave para limpiar el ordenador, pero no
aplique limpiador directamente en el ordenador. No utilice limpiadores volátiles (derivados del petróleo) o limpiadores abrasivos en
ningún lugar del ordenador.
• No intente reparar baterías. Solicite la reparación o la sustitución a
su representante de servicio o a personal de servicio cualificado.
• Tenga en cuenta que en ordenadores con logotipos de LCD etiquetados eléctricamente en relieve, el logotipo está recubierto por un
adhesivo protector. Debido al desgaste y rotura normales, este
adhesivo puede deteriorarse con el tiempo y en el logotipo expuesto
pueden formarse bordes afilados. Tenga cuidado al manipular el
ordenador en este caso y evite tocar el logotipo del LCD etiquetado
eléctricamente. Evite colocar cualquier elemento en la bolsa de
transporte que pueda rozar la parte superior del ordenador durante
el transporte Si ocurre un desgaste o rotura, contacte con el centro
de servicios.
62
Precauciones para baterías de polímero
Eliminación de la batería & Cuidado
El producto que usted ha comprado contiene una batería
recargable. La batería es reciclable Terminada su vida útil,
según las leyes locales y estatales, puede ser ilegal
desecharla junto con los residuos ordinarios. Verifique con las
autoridades locales responsables de los desechos sólidos
cuáles son las opciones de eliminación y reciclado existentes
en su zona.
Peligro de explosión si la batería está mal colocada.
Sustitúyala con un tipo de batería igual o equivalente al
recomendado por el fabricante. Elimine la batería usada de
conformidad con las instrucciones del fabricante.
Tenga en cuenta la información siguiente específica para baterías de polímero; además, donde corresponda, invalida la información sobre precauciones para baterías normales.
• Las baterías pueden aumentar o hincharse ligeramente, sin embargo,
esto es parte del mecanismo de seguridad de la batería y o supone un
problema.
• Utilice los procedimientos de manejo apropiados cuando utilice
baterías de polímero. No utilice baterías de polímero en entornos
con temperatura ambiental alta y no guarde las baterías sin usar
durante mucho tiempo.
Español
63
Guía rápida para empezar
130 ゚
Apagar
Por favor, tenga en cuenta que debería siempre apagar el ordenador eligiendo la opción Apagar en Windows (ver abajo). Esto le
ayudará a evitar problemas con el disco duro o el sistema.
Haga clic en Configuración en la Barra Charms (utilice la c ombinación Tecla de Windows
+ tecla C para acceder a la Barra
Charms) y elige la opción Apagar desde el menú Iniciar/Apagar.
O
Elige Apagar o cerrar
sesión > Apagar en el menú contextual (uti-
lice la combinación Tecla de Windows
+ tecla X para acceder
al menú contextual).
Figura 1 - Abrir la tapa/
LCD/ordenador con el
adaptador AC/DC en-
chufado
1. Quite todos los materiales del embalaje.
2. Coloque el ordenador en una superficie estable.
3.
Inserte la batería y asegúrese de que quede bloqueada en su
posición.
4. Conecte el adaptador AC/DC al conector de entrada DC que
está del lado izquierdo del ordenador, y luego conecte el cable
de alimentación AC en un eschufe y al adaptador (asegúrese
de usar el adaptador cuando configure por primera vez el
ordenador, pues para proteger el ordenador durante el envío
la batería estará bloqueada para no alimentar al sistema hasta
que se conecte al adaptador AC/DC por primera vez).
5. Utilice una mano para levantar con cuidado la tapa/LCD a un
ángulo de visión cómodo (no exceder 130 grados), mientras
utiliza la otra mano (como se muestra en la Figura 1) para
sostener la base del ordenador (Nota: Nunca levante el
ordenador por la tapa/LCD).
6. Presione el botón de encendido para “encender”.
Software de sistema
Puede ser que su ordenador tenga instalado un software de
sistema. Si no es el caso, o si desea reconfigurarlo con otro
sistema, este manual se refiere a Microsoft Windows 8.1.
Español
64
Mapa del sistema: Vista frontal con panel LCD abierto
Figura 2
Vista frontal con panel
LCD abierto
1. Cámara PC
2. *LED de cámara PC
*Cuando la cámara PC
esté en uso, el LED se
iluminará en rojo.
3. Micrófono incorporado
4. Panel LCD
5. Botón de encendido
6. Teclado
7. Clickpad y botones
Uso de dispositivos
inalámbricos a bordo
El uso de dispositivos
electrónicos portátiles a
bordo de un avión suele
estar prohibido.
Asegúrese de que los
módulos WLAN y
Bluetooth estén apagados
si utiliza el equipo en un
avión ajustando el sistema
al Modo de avión.
5
7
6
2
1
3
4
Sensibilidad
Clickpad/Touchpad
Las zonas de los botones del ratón de la parte inferior de la
plataforma mide unos
15mm desde la parte
inferior de ésta y los
botones izquierdo y
derecho están divididos por la mitad como
se ilustra a continuación. Presione la zona
del botón izquierdo
para clic izquierdo y la
del botón derecho para
hacer clic derecho.
7
Español
65
Indicadores LED
Los indicadores LED en su ordenador muestran una valiosa información sobre el estado actual del ordenador.
IconoColorDescripción
NaranjaEl adaptador AC/DC está conectado
Verde El ordenador está encendido
Español
66
Verde
parpadeante
NaranjaLa batería se está cargando
VerdeLa batería está completamente cargada
Naranja
parpadeante
VerdeEl Modo de avión está activado (los módulos WLAN y Bluetooth están apagados)
VerdeEl disco duro/dispositivo óptico está en uso
La batería ha alcanzado el estado crítico de poca energía
Tabla 1 - Indicadores LED
El ordenador está en modo Suspensión
Teclado
Numeric
Keypad
Keypad
Tecla de Windows
Tecla Menú/Aplicación
Teclado
Tecla Fn
Teclas de función
numérico
Bloq Num &
Bloq Despl
Figura 3 - Teclado
Acceso directo del teclado al logotipo Windows
Utilice la combinación de teclas Tecla de Windows + D para cambiar de la pan-
talla Inicio al Escritorio de Windows.
Acceso directo del teclado a Menú/Aplicación
Cuando la app del Escritorio esté en ejecución, puede usar la tecla Menú/Aplicación
del teclado para que actúe como clic del botón derecho de un ratón. En la pantalla
Inicio esta función resulta útil para mostrar rápidamente la barra Personalizar.
El teclado incluye un teclado numérico (en la parte derecha del teclado) para una entrada fácil de datos numéricos. Al
presionar
cambiar las características operacionales al instante
Bloq Num el teclado numérico se habilita o inhabilita. También incluye las teclas de función para permitirle
.
Español
67
Teclas de función
Las teclas de función (F1 - F11 etc.) actuarán como teclas directas (Hot-Key) cuando se pulsan junto con la tecla Fn. Además
de las combinaciones de teclas de función básicas algunos indicadores visuales están disponibles (sólo en la aplicaciónEscritorio de Windows y no en la pantalla Inicio) cuando el controlador de teclas directas está instalado.
Tabla 2 - Teclas de función & indicadores visuales
Fn +
Fn +
Fn +
Fn +
Fn +
Activar/desactivar el
módulo cámara PC
Activar/desactivar el
Modo de avión
Activar/disactivar el
teclado numérico
Cambiar el bloqueo de
desplazamiento
Cambio Bloq. Mayús-
culas
Activar/desactivar el Control Center (centro de con-
trol)
(ver la página 69)
Control automático del
ventilador/potencia
completa
68
Control Center (Centro de control)
El Control Center (Centro de control) en Windows 8.1 funciona bajo la app Escritorio y no en la pantalla Inicio. Presione
la combinación de teclas Fn + Esc o haga doble clic en el icono en el área de notificación de la barra de tareas para
activar o desactivar el Control Center. El Control Center ofrece un acceso rápido a los controles usados con más frecuencia
y le permite activar, y desactivar el touchpad/el módulo cámara rápidamente.
Figura 4 - Control Center
Español
Haga clic en los iconos del Control Center para cambiar a la función apropiada o mant eng a pres ionado el botón del ratón y
nueva el control dial a la posición deseada. Algunas funciones serán ajustadas automáticamente al seleccionar un modo de
energía.
69
Modos de energía
Puede ajustar el Modo de energía haciendo clic en el icono apropiado en la parte superior del Control Center. Cada modo
de energía afectará a Power Conservation Mode (Modo ahorro de energía), Airplane Mode (Modo de avión), Power Plan
(Plan de energía) y PC camera power (Energía de cámara PC), etc.
Puede hacer clic en un icono del Control Center para ajustar un modo de energía global y luego hacer clic en iconos
individuales en el Control Center para encender o apagar el touchpad y el módulo cámara.
Power Conservation Mode
(Modo ahorro de energía)
Español
70
Modos
Icono
Plan de energíaEquilibradoEconomizadorAlto rendimientoEquilibrado
Cámara PCActivadoDesactivadoActivadoActivado
TouchpadActivadoActivadoActivadoActivado
Modo de aviónDesactivadoActivadoDesactivadoDesactivado
Quiet
(Silencioso)
BalancedEnergy StarPerformanceBalanced
Tabla 3 - Modos de energía
Power Saving
(Ahorro de energía)
Performance
(Rendimiento)
Entertainment
(Entretenimiento)
Power Status (Estado de energía)/
El icono Estado de energía mostrará si la alimentación
actual viene dada por la batería o por el adaptador AC/DC
enchufado en una toma de corriente. La barra de estado de
energía muestra el estado actual de la carga de la batería.
Brightness (Brillo)
El icono Brillo mostrará el nivel actual del brillo de la
pantalla. Puede usar el control deslizante para ajustar el brillo
de la pantalla o las combinaciones de teclas Fn + F8/F9 o
usar la combinación de teclas Fn + F2 para apagar la
retroiluminación LED (presione una tecla para volver
encenderla). Tenga en cuenta que Modo de energía también
puede afectar el brillo de la pantalla.
Volume (Volumen)
El icono Volumen mostrará el nivel actual del volumen.
También puede usar el control deslizante para ajustar el
volumen o las combinaciones de teclas Fn + F5/F6 o la
combinación de teclas Fn + F3 para silenciar el volumen.
Power Conservation (Ahorro de energía)
Este sistema soporta las características de administración de
energía Energy Star que hace que los equipos (CPU, disco
duro, etc.) entren en modos de ahorro de energía y suspensión
tras el período de tiempo de inactividad designado. Haga clic
en el botón Performance (Rendimiento), Balanced
(Equilibrado) o Energy Star.
Sleep Button (Botón Suspender)
Haga clic en el botón Hibernate (Hibernar) o Sleep
(Suspender) para que el equipo entre en el modo de ahorro
de energía seleccionado.
Display Switch (Cambiar pantalla)
Haga clic en el botón Cambiar pantalla para acceder al
menú (o utilice la combinación de teclas + P) y
seleccione el modo de pantalla apropiado.
Time Zone (Zona horaria)
Si hace clic en el botón Zona horaria accederá al panel de
control Fecha y hora de Windows.
Desktop Background (Fondo de pantalla)
Si hace clic en el botón Fondo de pantalla podrá cambiar la
imagen del fondo del escritorio.
Touchpad/cámara PC
Haga clic en cualquiera de estos botones para cambiar el
estado de energía del Touchpad o del módulo cámara. Tenga
en cuenta que el estado de energía del módulo cámara
también queda afectado por el Modo de energía
seleccionado.
Español
71
Mapa del sistema: Vistas frontal, izquierda, derecha, posterior e
8
7
9
Advertencia sobre quitar la tapa
inferior
No quite ninguna tapa y/o tornillo
para actualizar el dispositivo, pues
podría violar los términos de su
garantía.
Si necesita colocar o quitar el disco
duro/RAM/dispositivo óptico, etc. por
cualquier razón, contacte con su
distribuidor o vendedor para más
información.
Figura 5 - Vistas frontal, izquierda, derecha, posterior e inferior
1. Indicadores LED
2. Conector de entrada DC
3. Conector LAN RJ-45
4. Puerto para monitor externo
5. Rejilla
6. Puerto de salida de HDMI
7. Puertos USB 2.0
8. Puerto USB 3.0
9. Lector de tarjetas multi-en-1
10. Conector de entrada para
micrófono
11. Conector de salida de
auriculares
12. Bahía de dispositivo óptico
13. Orificio de expulsión de
emergencia
14. Ranura del cierre de seguridad
15. Batería
16. Altavoces incorporados
1
14
2
4
6
3
5
10
11
13
12
15
16
5
16
15
Cara inferior
Parte frontal
Lateral izquierdo
Parte posterior
Lateral derecho
77
inferior
Español
72
Panel de Control de Windows 8.1
Figura 6
Menú contextual
Mueva el ratón a la esquina
inferior izquierda de la pantalla y haga clic con el botón
derecho en el botón Inicio
para acceder al menú.
Figura 7 - Pantalla Inicio
A lo largo de este manual verá una instrucción para abrir el Panel de Control. Haga clic con el botón derecho en el botón
Inicio en la app del Escritorio o en la pantalla Inicio (o utilice la combinación Tecla de Windows + tecla X) para abrir
un menú contextual avanzado con características útiles como Panel de control, Programas y características, Opciones de
energía, Administrador de tareas, Buscar, Explorador de archivos, Símbolo del sistema, Administrador de dispositivos,
Conexiones de red, etc y seleccionar Panel de Control.
Pantalla Inicio y escritorio de Windows
8.1
A las apps, paneles de control, utilidades y programas en Windows se
accede desde la pantalla Inicio y/o desde la app Escritorio deWindows. Al Escritorio (que se ejecuta como una app dentro de la
pantalla Inicio) se puede acceder haciendo clic en Escritorio en la
pantalla Inicio (o usando la combinación Tecla de Windows + tecla
D). La barra de tareas aparecerá en la parte inferior de la pantalla del
escritorio y verá el área de notificación de la barra de tareas en la parte
inferior derecha de la pantalla. Haga clic en la flecha en la parte inferior
de la pantalla Inicio para acceder a Aplicaciones.
Español
73
Apps y Mosaicos
Haga clic en la flecha en la parte inferior de
la pantalla Inicio para acceder a Aplicaciones.
La pantalla Inicio contendrá varias apps y muchas más se instalarán
conforme añada más aplicaciones, etc. No todas estas apps caben en una
pantalla, por lo que a menudo deberá usar el control deslizante de la parte
inferior de la pantalla para ver todas las apps necesarias.
Barra Charms
El lado derecho de la pantalla muestra la barra Charms. La barra Charms contiene los menús Buscar, Compartir, Inicio,
Dispositivos y Configuración. Para acceder a la barra Charms, mueva el cursor hacia la esquina superior o inferior derecha
de la pantalla y luego mueva uno de los elementos hacia la barra Charms para activarla (la barra estará en negro cuando esté
activa) o utilice la combinación Tecla de Windows + tec la C.
Español
74
Figura 8 - Pantalla Inicio con la barra Charms
Parámetros de vídeo
1
2
2
1
Figura 9 - Panel de control Pantalla
Resolución de pantalla para Apps (Windows 8.1)
La resolución mínima en la que las apps se ejecutarán es de
1024x768.
La resolución mínima necesaria para soportar todas las
características de Windows 8.1 (incluyendo multitarea con
snap) es de 1366x768.
El sistema incluye una GPU integrada de Intel. Puede
cambiar los dispositivos de pantalla y configurar las
opciones de pantalla desde el panel de control Pantalla en
Windows siempre que tenga instalado el controlador de
vídeo.
Para acceder al panel de control Pantalla:
1. Vaya al Panel de Control.
2. Haga clic en Pantalla (icono) - en Apariencia y personalización (categoría).
3. Haga clic en Ajustar resolución de pantalla/Ajustar resolución.
O
4. Haga clic con el botón derecho en el escritorio (utilice la
combinación Tecla de Windows + tecla D para acceder al
escritorio) y seleccione Resolución de pantalla.
5. Utilice el cuadro desplegable para seleccionar la resolución de la
pantalla.
6. Haga clic en Configuración avanzada .
Para acceder al Panel de control de gráficos HD Intel®:
1. Haga clic en el icono (Panel de control de gráficos HD Intel®)
en la pantalla Aplicaciones.
O
2. Haga clic con el botón derecho en el escritorio (utilice la
combinación Tecla de Windows + tecla D para acceder al
escritorio) y seleccione Propiedades de gráficos en el menú.
O
3. Haga clic en el icono en el área de notificación de la barra
de tareas del escritorio y seleccione Propiedades de gráficos
en el menú.
Dispositivos de pantalla
Además del LCD incorporado, también puede utilizar un
monitor VGA/pantalla plana o TV (conectado al puerto para
monitor externo o al puerto de salida de HDMI) como
dispositivo de pantalla.
Español
75
Usar la combinación de teclas del logoti-
Figura 10
+ P (Cambiar la
configuración de
pantalla)
Figura 11 - Opciones de energía
po Windows + P para cambiar entre
pantallas
Puede usar la combinación de teclas + P (o Fn + F7) para
cambiar rápidamente la configuración de pantalla y los
modos (esto resulta especialmente útil cuando se coloca un
proyector) en Windows.
1. Conecte una pantalla externa al puerto para monitor externo o
puerto de salida de HDMI y enciéndala.
2. Pulse la combinación de teclas + P (o Fn + F7).
3. Aparecerá un menú en pantalla.
4. Utilice las teclas del cursor (o + P) para seleccionar la
configuración apropiada en el menú y presione Entrar para
confirmar la selección.
Español
Opciones de energía
El panel de control de las opciones de energía (menú
Hardware y sonido) de Windows permite configurar las
funciones de administración de energía del ordenador. Puede
ahorrar energía con los planes de energía y configurar las
opciones para el botón de encendido, botón de suspensión(Fn + F4), tapa del ordenador (al cerrarla), pantalla y
modo de suspensión (el estado de ahorro de energía
predeterminado) en el menú de la izquierda. Tenga en cuenta
que el plan economizador puede afectar al rendimiento del
ordenador.
Haga clic para seleccionar uno de los planes existentes o
haga clic en Crear un plan de energía en el menú izquierdo
y seleccione las opciones para crear un plan nuevo. Haga clic
en Cambiar la configuración del plan y haga clic en
Cambiar la configuración avanzada de energía para
acceder a más opciones de configuración.
76
Instalación de controladores
Directrices generales
para la instalación del
controlador
Como guía general, siga
las instrucciones predeterminadas en pantalla para
cada controlador (p.ej. Si-
guiente > Siguiente > Finalizar) a menos que sea
usuario avanzado. En muchos casos necesitará reiniciar para instalar el
controlador.
Asegúrese de que los módulos (p.ej. WLAN o Bluetooth) estén
ENCENDIDOS antes de
instalar el controlador
apropiado.
Windows Update
Tras instalar todos los controladores asegúrese de
haber habilitado WindowsUpdate para obtener las
últimas actualizaciones de
seguridad, etc. (todas las
actualizaciones incluirán
los últimos parches de Microsoft).
Instalación del controlador y
alimentación
Cuando instale controladores asegúrese de
que el ordenador esté alimentado por el
adaptador AC/DC conectado a una fuente
de corriente activa. Algunos controladores
consumen una cantidad significativa de
corriente durante el proceso de instalación, y
si la batería se consume puede provocar que
el sistema se apague, causando problemas
en el sistema (tenga en cuenta que esto no
supone un problema de seguridad y la
batería podrá recargarse en 1 minuto).
Figura 12 - Instalación de controladores
El disco Device Drivers & Utilities + User’s Manual contiene los controladores y utilitarios
necesarios para utilizar el ordenador correctamente. Inserte el disco y haga clic en InstallDrivers (botón), u Option Drivers (botón) para acceder al menú de controladores opcional.
Instale los controladores en el orden indicado en la Figura 12. Haga clic para seleccionar los
controladores que desea instalar (debería anotar los controladores conforme lo s instala). Nota:
Si necesita reinstalar un controlador, debería desinstalar el controlador antes.
Instalación manual del controlador
Haga clic en el botón Browse CD/DVD en la aplicación Drivers Installer y busque el archivo
ejecutable en la carpeta de controladores apropiada.
Si durante el procedimiento de instalación aparece una ventana Nuevo hardwareencontrado, haga clic en Cancelar para cerrar la ventana y siga con el procedimiento de
instalación.
Español
77
Solución de problemas
ProblemaPosible causa - Solución
Los módulos WLAN y
Bluetooth no pueden
detectarse.
El módulo cámara PC no
puede detectarse.
Los archivos de vídeo
capturados de la cámara PC
ocupan demasiado espacio en
el disco.
Español
Los módulos están apagados cuando el equipo está en Modo de avión. Compruebe el indicador
LED para ver si el equipo está en Modo de avión (vea la Tabla 1 en la página 66). Utilice la
combinación de teclas Fn + F11 para activar/desactivar el Modo de avión (vea la Tabla 2 en la
página 68).
El módulo está desactivado. Utilice la comb inación de tecl as Fn + F10 para activar el módulo (vea
la Tabla 2 en la página 68). Ejecute la aplicación de la cámara para ver la imagen de la cámara.
Tenga en cuenta que capturar archivos de vídeo de alta resolución requiere una cantidad
sustancial de espacio en el disco para cada archivo.
Tenga en cuenta que el sistema Windows requiere un mínimo de 20GB (64bit) de espacio libre
en la partición del sistema unidad C:. Se recomienda que guarde el archivo de vídeo capturado
en una ubicación distinta a la unidad C:, limi te el tamaño de archivo del vídeo capturado o
reduzca la resolución del vídeo.
78
Especificaciones
Información actualizada de
especificaciones
Las especificaciones listadas en esta
sección son correctas en el momento de
publicación. Ciertas opciones (particularmente tipos/velocidades de procesadores) pueden cambiar o actualizarse
según la fecha de lanzamiento del fabricante. Diríjase a su centro de servicios
para más detalles.
Opciones de procesadores
Procesador Intel® Pentium™
N3520 (2,17GHz)
Caché de nivel 2 de 2MB, 22nm, DDR3L1333MHz, TDP 7,5W
Procesador Intel® Celeron®
N2920 (1,86GHz)
Caché de nivel 2 de 2MB, 22nm, DDR3L1066MHz, TDP 7,5W
N2820 (2,13GHz), N2815 (1,86GHz)
Caché de nivel 2 de 1MB, 22nm, DDR3L1066MHz, TDP 7,5W
N2806 (1,60GHz)
Caché de nivel 2 de 1MB, 22nm, DDR3L1066MHz, TDP 4,3W
BIOS
AMI BIOS (SPI Flash ROM de 64Mb)
Memoria
Para Procesadores N3520, N2920,
N2820 & N2815:
Dos zócalos de 204 pins SODIMM, para
memoria DDR3L 1600MHz
Memoria expansible hasta 8GB
(La frecuencia de operación de memoria
real depende del FSB del procesador.)
Para Procesadores N2806:
Un zócalo de 204 pins SODIMM, para
memoria DDR3L 1600MHz
Memoria expansible hasta 8GB
(La frecuencia de operación de memoria
real depende del FSB del procesador.)
Almacenamiento
(Opción de fábrica) Un dispositivo óptico
Super Multi de 9,5mm(h) intercambiable
(Opción de fábrica) ODD falso
Un HDD SATA intercambiable de 2,5"
7,0mm/9,5mm (h)
LCD
17,3" (43,94cm) HD+
Adaptador de vídeo
Intel® HD Graphics
Frecuencia dinámica (Tecnología de
memoria de vídeo dinámica Intel hasta
1,7GB)
Compatible con DirectX® 11
Audio
Interfaz compatible HDA (Sonido Intel de
alta definición)
2 altavoces incorporados
Micrófono incorporado
Seguridad
Ranura para cierre de seguridad (tipo
Kensington®)
En funcionamiento: 5°C - 35°C
Apagado: -20°C - 60°C
Humedad relativa
En funcionamiento: 20% - 80%
Apagado: 10% - 90%
Alimentación
Adaptador de AC/DC autodetector de
corriente
Entrada AC: 100-240V, 50-60Hz
Salida DC: 19V, 1,58A (30W)
Batería de Litio-Ion inteligente de 4
elementos, 32WH
(Opción de fábrica) Batería de Litio-Ion
inteligente de 4 elementos, 44WH
Dimensiones y peso
413 (a) x 273 (l) x 12,7 - 28,5 (h) mm
2,5kgs
(Barebone con unidad óptica &
batería de
32WH)
80
Informazioni su questa guida rapida
Questa guida rapida rappresenta un’introduzione rapida all’avvio del sistema. Si tratta di un supplemento e non di una
sostituzione del Manuale per l'utente completo in lingua inglese nel formato Adobe Acrobat, memorizzato sul disco DeviceDrivers & Utilities + User's Manual fornito a corredo del computer. Inoltre, questo disco con tiene i driver e le utilità necessari
per il corretto uso del computer (Nota: La società si riserva il diritto di revisionare la presente pubblicazio ne o di modificarne
il contenuto senza preavviso).
È possibile che alcune o tutte le funzionalità del computer siano già state configurate. In caso contrari o, o se si sta pianificando
di riconfigurare (o reinstallare) componenti del sistema, fare riferimento al Manuale per l'utente completo. Il disco DeviceDrivers & Utilities + User’s Manual non contiene il sistema operativo.
Informazioni legali e di sicurezza
Prestare particolare attenzione alle informative legali e di sicurezza contenute nel Manuale per l'utente che si trova sul disco
Device Drivers & Utilities + User’s Manual.
Intel, Pentium e Celeron sono marchi/marchi registrati della Intel Corporation.
Italiano
81
Istruzioni per la custodia e il funzionamento
Il computer notebook è abbastanza rigido, ma è possibile che
possa essere danneggiato. Per evitare qualsiasi danno, attenersi
ai seguenti suggerimenti:
• Non lasciarlo cadere ed evitare urti. Se il computer cade, è possi-
bile che il telaio e i componenti possano esserne danneggiati.
• Tenerlo all'asciutto e non provocarne il surriscaldamento. Tenere
il computer e l'alimentazione lontani da ogni tipo di impianto di
riscaldamento. Si tratta di un apparato elettrico. Se acqua o altri
liquidi dovessero penetrarvi, esso potrebbe risultarne seriamente
danneggiato.
• Evitare le interferenze. Tenere il computer lontano da trasformatori
ad alta capacità, motori elettrici e altri intensi campi magnetici. Ciò
ne può impedire il corretto funzionamento e danneggiare i dati.
• Attenersi alle corrette procedure di lavoro con il computer. Spe-
gnere il computer correttamente e non dimenticare di salvare il proprio lavoro. Ricordare di salvare frequentemente i propri dati poiché
essi potrebbero essere persi nel caso in cui la batteria si esaurisse.
Assistenza
Ogni tentativo di riparare da soli il computer può an nullare la
garanzia ed esporre l'utente a scosse elettriche. Per l'assistenza
rivolgersi solo a personale tecnico qualificato, in particolar
modo nelle situazioni seguenti:
• Quando il cavo di alimentazione o l'adattatore AC/DC è danneggiato
o logorato.
• Se il computer è stato esposto alla pioggia o ad altri liquidi.
Italiano
• Se il computer non funziona normalmente dopo aver seguito cor ret-
tamente le istruzioni operative.
• Se il computer è caduto o si è danneggiato (non toccare il liquido
velenoso in caso di rottura dello schermo LCD).
• Se c'è un odore non usuale, calore o fumo che fuoriesce dal computer.
Informazioni di sicurezza
• Utilizzare esclusivamente un adattatore approvato per l'utilizzo di
questo computer.
• Utilizzare solo il cavo di alimentazione e le batterie indicate in questo manuale. Non gettare le batterie nel fuoco, poiché potrebbero
esplodere. Fare riferimento alle normative locali per istruzioni speciali in tema di smaltimento rifiuti.
• Non continuare a usare in alcun modo una batteria che sia caduta in
terra o che sembri danneggiata (es. piegata o torta). Anche se il computer continua a funziona re con una bat teria da nnegg iata, qu esta p uò
provocare danni ai circuiti risultanti in pericolo di incendio.
• Assicurarsi che il computer sia completamente spento prima di inserirlo in una borsa da viaggio (o in un contenitore simile).
• Prima di pulire il computer ricordare sempre di rimuovere la batteria
e di scollegare il computer da qualsiasi fonte di alimentazione
esterna, da periferiche e altri cavi (incluse linee telefoniche).
• Per pulire il computer utilizzare solo un panno morbido e pulito, evitando di applicare detergenti direttamente sul computer. Non utilizzare detergenti volatili (distillati di petrolio) o abrasivi su qualsiasi
parte del computer.
• Non provare a riparare il pacco batteria. Fare riferimento sempre
all'assistenza tecnica o a personale qualificato per la riparazione o la
sostituzione del pacco batteria.
• Si noti che nei computer che hanno un logo elettroimpresso LCD in
rilievo, questo è coperto da un adesivo protettivo. Nell'uso quotidiano e con il passare del tempo, questo adesivo potrebbe deteriorarsi e il logo sottostante potrebbe avere del bordi acuminati. In
questo caso, fare attenzione quando si maneggia il computer ed evitare di toccare il logo elettroimpresso LCD in rilievo. Evitare di inserire altri oggetti nella borsa di trasporto poiché potrebbero sfregare
contro la copertura del computer durante il trasporto. Se si sviluppano parti consumate e logorate, contattare il centro di assistenza.
82
Precauzioni relative alla batteria ai polimeri
Smaltimento della batteria & Attenzione
Il prodotto acquistato contiene una batteria ricaricabile. La
batteria è riciclabile. Al termine della durata di uso, in base
alle diverse leggi locali e statali, può essere illegale smaltire
questa batteria insieme ai rifiuti comuni. Controllare i requisiti
previsti nella propria zona consultando i funzionari locali
addetti allo smaltimento dei rifiuti solidi per le opzioni di riciclo
o lo smaltimento corretto.
Pericolo di esplosione in caso sostituzione errata della
batteria. Sostituire solamente con lo stesso tipo o con uno
analogo raccomandato dal produttore. Eliminare la batteria
usata seguendo le istruzioni del produttore.
Le informazioni seguenti sono molto importanti e si riferiscono
unicamente alle batterie ai polimeri e, ove applicabile, hanno
priorità rispetto alle precauzioni generali relative alle batterie.
• Le batterie ai polimeri possono espandersi o gonfiarsi leggermente,
tuttavia questo fa parte del meccanismo di sicurezza della batteria e
non deve essere causa di preoccupazione.
• Maneggiare le batterie ai polimeri in modo corretto nel loro utilizzo.
Non utilizzare batterie ai polimeri in ambienti con temperature elevate e non conservare le batterie inutilizzate per periodi di tempo prolungati.
Italiano
83
Guida di avvio rapido
127゚
Spegnimento
È importante tenere presente che è sempre necessario spegnere il
computer scegliendo il comando Arresta il sistema in Windows (vedere sotto). In questo modo si evitano problemi al sistema o al disco rigido.
Fare clic su Impostazioni nella barra Charms (utilizzare la combinazio-
ne di tasti Tasto logo Windows + C per accedere alla barra
Charms)
e scegliere il comando Arresta il sistema disponibile dal
menu Arresta.
O
ScegliereChiudi o disconnetti > Arresta il sistema dal menu conte-
stuale (utilizzare la combinazione di tasti Tasto logo Window s +
X per accedere al menu contestuale).
Figura 1
Apertura del coperchio/LCD/
Computer con alimentatore
AC/DC collegato
130 ゚
1. Eliminare tutti i materiali di imballo.
2. Appoggiare il computer su una superficie stabile.
3.
Inserire la batteria e verificare che sia bloccata in
posizione.
4. Collegare bene le periferiche che si desidera usare con il
computer (per esempio tastiera e mouse) alle porte corrispondenti.
5. Collegare l'adattatore AC/DC al jack di ingresso DC situato
alla sinistra del computer, quindi inserire il cavo di alimentazione AC in una presa e collegare il cavo di alimentazione
AC all'adattatore AC/DC (accertarsi di utilizzare l'adatta-tore nella prima impostazione del computer, poiché, per
proteggere il computer durante la spedizione, la batteria
sarà bloccata e non potrà alimentare il sistema prima di
essere collegata ad un adattatore AC/DC).
6. Con una mano sollevare con cautela il coperchio/LCD fino
a un angolo di visione comodo (non superare i 130 gradi),
mentre con l'altra mano (come illustrato nella Figura 1) si
mantiene la base del computer (Nota: Non sollevare mai il
computer tenendolo dal coperchio/LCD).
7. Premere il pulsante di alimentazione per accendere.
Software del sistema
È possibile che il software sia già pre-installato sul
computer. In caso contrario, oppure in casi di
riconfigurazione del computer per un sistema diverso,
questo manuale si riferisce a Microsoft Windows 8.1.
Italiano
84
Descrizione del sistema: Vista anteriore con pannello LCD aperto
Figura 2
Vista anteriore con pannello
LCD aperto
1. Camera PC
2. *LED della camera PC
*Quando si utilizza la
camera PC, l'indicatore
LED si illumina in rosso.
3. Microfono incorporato
4. Schermo LCD
5. Pulsante di alimentazione
6. Ta stiera
7. Clickpad e pulsanti
Funzionamento del
dispositivo senza fili a
bordo di un aereo
Solitamente l’uso di qualsiasi dispositivo di trasmissione elettronica è proibito
a bordo di un aereo.
Accertarsi che i moduli
WLAN & Bluetooth siano
OFF quando si utilizza il
computer a bordo di un
aereo inserendo il sistema
nella modalità aereo.
5
7
6
2
1
3
4
Sensibilità del clickpad/
touchpad
Le aree pulsanti del mouse nella parte inferiore del
pad misurano circa
15mm dal fondo del pad,
mentre i pulsanti sinistro
e destro sono suddivisi
pressappoco come illustrato, in basso al centro.
Premere nell'area del pulsante sinistro per un clic
sinistro e nell'area del
pulsante destro per un
clic destro.
7
Italiano
85
Indicatori LED
Gli indicatori LED sul computer segnalano importanti informazioni relative allo stato corrente del computer.
IconaColoreDescrizione
ArancioneL'alimentatore è collegato
VerdeIl computer è acceso
Verde lampeggiant eIl computer è in modalità Sospensione
ArancioneLa batteria è in carica
VerdeBatteria completamente carica
Arancione lampeggianteLa batteria ha raggiunto lo stato critico di carica bassa
Italiano
86
Verde
VerdeIl disco rigido/l'unità ottica è in uso
Tabella 1 - Indicatori LED
La modalità aereo è ON (i moduli WLAN & Bluetooth sono OFF)
Tastiera
Numeric
Keypad
Figura 3 - Tastiera
Tasto logo Windows
Tastierino
Tasti funzione
Bloc Num &
Tasto Fn
Bloc Scorr
numerico
Tasto Menu/Applicazione
Scorciatoia da tastiera Windows Logo
Usare la combinazione di tasti Tasto logo Windows + D per passare dalla schermata
Start al Windows Desktop.
Menu/Scorciatoia tastiera applicativo
Quando la Desktop app è in esecuzione potete usare il tasto Menu/Applicazione della
tastiera con la funzione di clic destro del mouse. Nella schermata Start questa funzione è
utile per visualizzare velocemente la barra Personalizza.
La tastiera è dotata di un tastierino numerico (sul lato destro della tastiera) per facilitare l'immissione di dati numerici.
Premere Bloc Num per commutare l’attivazione e la disattivazione della tasti era numerica. Dispone anche di tasti funzione
che consentono di cambiare istantaneamente le funzionalità operative
.
Italiano
87
Tasti funzione
I tasti funzione (da F1 a F11) agiscono come Hot-Key quando premuti tenendo premuto il tasto Fn. In aggiunta alle
combinazioni di tasti funzione base, quando è installato il driver hot key (HotKey Driver) alcuni indicatori visivi sono
disponibili (solo nell'applicazione Windows Desktop e non nella schermata Start).
TastiTasti funzione e indicatori visiviTastiFunzione/indicatori visivi
Fn +
Fn +
Fn +
Fn +
Fn +
Fn +
Italiano
88
Fn +
Fn +
Play/pausa (nei programmi audio/vi deo)
Attiva/disattiva
touchpad
Spegne la retroilluminazione dello schermo LCD (premere un tasto o utilizzare il touchpad per ripristinare lo
schermo)
Commutazione mute
Commutazione Sospendi
Riduzione/Aumento volume
audio
Cambia configurazione di visualizzazione (vedere la
pagina 96)
Riduzione/aumento lumino-
sità LCD
Tabella 2 - Tasti funzione e indicatori visivi
Fn +
Fn +
Fn +
Fn +
Fn +
Attiva/disattiva la
camera PC
Attiva/disattiva la moda-
lità aereo
Attiva/disattiva il tastie-
rino numerico
Attiva/disattiva il
blocco dello scorri-
mento
Attiva/disattiva maiu-
scolo
Attiva disattiva Control Center (Centro di controllo)
(vedere la pagina 89)
Controllo automatico
ventola/pieno power
Control Center (Centro di controllo)
Il Control Center (Centro di controllo) di Windows 8.1 funziona sotto la app Desktop e non sotto la schermata Start. Premere
la combinazione di tasti Fn + Esc oppure fare doppio clic sull'icona nell'area di notifica della barra delle applicazioni
per attivare/disattivare il Control Center. Il Control Center consente di accedere rapidamente ai controlli utilizzati più
frequentemente, e di attivare/disattivare velocemente il touchpad/il modulo camera del computer.
Figura 4 - Control Center
Italiano
Cliccare l'icona Control Center per alternare la funzione appropriata, oppure tenere premuto il pulsante del mouse e spostare
il controllo quadrante dove applicabile. Alcune funzioni saranno regolate automaticamente quando è selezionata una modalità
di alimentazione.
89
Modalità risparmio energia
È possibile impostare una Modalità risparmio energia facendo clic sull'icona corrispondente nella parte superiore del
Control Center. Ogni modalità di alimentazione influirà sulla modalità di risparmio energetico, modalità aereo,
pianificazione energetica e alimentazione camera PC ecc.
È possibile fare clic su un'icona del Control Center per impostare una modalità di risparmio energetico generale e quindi
scegliere le singole icone del Control Center per attivare/disattivare il touchpad e il modulo camera.
L'icona Stato di alimentazione viene visualizzata se
attualmente il computer è alimentatore con la batteria,
oppure mediante l'alimentatore collegato in una presa
funzionante. La barra dello stato di alimentazione mostra la
carica corrente della batteria.
Brightness (Luminosità)
L'icona Luminosità mostra il livello di luminosità corrente
dello schermo. È possibile utilizzare la barra di scorrimento
per regolare la luminosità dello schermo o le combinazioni di
tasti Fn + F8/F9, oppure utilizzare la combinazione di tasti
Fn + F2 per disattivare la retroilluminazione LED (premere
un tasto qualsiasi per riattivarla). Si noti che anche la
luminosità dello schermo viene influenzata dalla Modali tà di
risparmio energetico selezionata.
Volume (Volume)
L'icona Volume mostra il livello di volume corrente. È
possibile utilizzare la barra di scorrimento per regolare il
Volume o le combinazioni di tasti Fn + F5/F6, oppure
utilizzare la combinazione di tasti Fn + F3 per disattivare
totalmente l'audio.
Power Conservation (Conservazione dell'energia)
Il sistema supporta le funzionalità della gestione energetica
Energy Star che pone i computer (CPU, disco rigido ecc.) in
una modalità di sospensione a basso consumo dopo un certo
periodo di inattività impostato. Fare clic sul pulsante
Performance (Prestazioni), Balanced (Bilanciato) o Energy
Star.
Sleep Button (Pulsante Sospensione)
Cliccare il pulsante di Ibernazione o Sospensione per
consentire al computer di attivare la modalità di risparmio
energetico selezionato.
Display Switch (Switch visualizzazione)
Fare clic sul pulsante Switch visualizzazione per accedere al
menu (o utilizzare la combinazione di tasti + P) e
selezionare la modalità di visualizzazione appropriata.
Time Zone (Fuso orario)
Il pulsante Fuso orario consente di accedere al pannello di
controllo di Windows Data e ora.
Desktop Background (Sfondo del desktop)
Il pulsante Sfondo del desktop consente di cambiare
l'immagine sullo sfondo del desktop.
Italiano
Touchpad/camera PC
Fare clic su uno di questi pulsanti per cambiare lo stato di
risparmio energetico del Touchpad o dei moduli. Si noti che
lo stato di risparmio energetico di un modulo e la potenza del
Touchpad viene influenzato anche dalla Modalità dirisparmio energetico selezionata.
91
Descrizione del sistema: Vista anteriore, sinistra, destra, posteriore
8
6
10
11
7
9
7
Avviso di rimozione coperchio
inferiore
Non rimuovere il/i coperchio/i e/o vite/viti
ai fini dell'aggiornamento del dispositivo
poiché così facendo si possono violare i
termini della garanzia.
Se avete necessità di sostituire/rimuovere
hard disk/RAM/dispositivo ottico ecc., per
qualsiasi motivo, per ulteriori informazioni
contattare il vostro distributore/fornitore.
Figura 5 - Vista anteriore, sinistra, destra, posteriore e inferiore
1. Indicatori LED
2. Jack di ingresso DC
3. Jack RJ-45 per LAN
4. Porta per monitor esterno
5. Ventola
6. Porta uscita HDMI
7. Porte USB 2.0
8. Porta USB 3.0
9. Lettore di schede multi-in-1
10. Jack ingresso del microfono
11. Jack uscita delle cuffie
12. Bay unità ottica
13. Foro di espulsione di emergenza
14. Slot blocco di sicurezza
15. Batteria
16. Altoparlanti incorporati
1
14
2
4
3
5
13
12
15
5
16
5
5
16
15
7
Parte inferiore
Lato anteriore
Lato sinistro
Lato destro
Lato posteriore
e inferiore
Italiano
92
Pannello di controllo di Windows 8.1
Figura 6
Menu conte-
stuale
Spostare il mouse in basso
a sinistra dello schermo e
fare clic con il pulsante destro sul pulsante Start per
accedere al menu.
Figura 7- Schermata Start
In questo manuale sarà richiesto di aprire il Pannello di controllo. Fare clic con il pulsante destro del mouse sul pulsante
Start nell'app Desktop o nella schermata Start (o utilizzare la combinazione di tasti Tasto logo Windows + X) per
visualizzare il menu di scelta rapida con utili funzionalità quali Pannello di controllo, Programmi e funzionalità, Opzioni di
risparmio energetico, Gestione attività, Cerca, Esplora comput er, Prompt dei comandi, Gestione periferiche e Connessioni di
rete, ecc e selezionare Pannello di controllo.
Schermata Start e Desktop di Windows 8.1
Le app, i pannelli di controllo, utilità e programmi dentro Win-
dows
sono accessibili dalla schermata Start e/o Windows Desk-
top app. Il Desktop (che viene eseguito come app all'internodella schermata Start) è accessibile cliccando l'oggetto del
Desktop nella schermata Start (o tramite la combinazione di
tasti Tasto logo
viene visualizzata nella parte inferiore della schermata del desktop,
e si può vedere l'area di notifica della barra delle applicazioni in basso a destra dello schermo.
della schermata Start per accedere alle App.
Windows + D). La barra delle applicazioni
Fare clic su lla freccia nella parte inferiore
93
Italiano
App & Titoli
Fare clic sulla freccia nella parte inferiore
della schermata Start per accedere alle App.
La schermata di avvio conterrà un numero di app, e molte altre ancora saranno installate come si aggiungono ulteriori applicazioni ecc. Non tutte
queste applicazioni troveranno posto su uno schermo, così, spesso, per visualizzare tutte le applicazioni necessarie, sarà necessario usare il dispositivo di scorrimento nella parte inferiore dello schermo.
Charms Bar
Il lato destro dello schermo visualizza la Charms Bar. La Charms Bar contiene i menu Ricerca, Condivisione, Start,
Dispositivi e Impostazioni. Per accedere alla Charms Bar spostare il dispositivo di scorrimento negli angoli superiore e
inferiore dello schermo, e quindi passare sopra a uno degli oggetti nella Charms Bar per attivarlo (quando è attiva la barra è
nera), oppure usare la combinazione di tasti Tasto logo Windows + C.
Italiano
94
Figura 8 - Schermata Start con la Charms Bar
Funzioni video
1
2
2
1
Figura 9
Pannello
di control-
lo Scher-
mo
Risoluzione dello schermo per le applicazioni (Windows
8.1)
La risoluzione minima in cui le applicazioni verranno eseguite
è di 1024x768.
La risoluzione minima richiesta per supportare tutte le
funzionalità di Windows 8.1 (incluso il multitasking con
scatto) è 1366x768.
Il sistema è dotato di una GPU integrata Intel. È possibile
selezionare i dispositivi di visualizzazione e configurare le
opzioni dei dispositivi video dal pannello di controllo
Schermo in ambiente Windows, se è installato il driver
video.
Per accedere al pannello di controllo Schermo:
1. Andare al Pannello di controllo.
2. Fare clic sull'icona Schermo - in Aspetto e personalizzazione
(categoria).
3. Fare clic su Modifica risoluzione dello schermo/Modifica
risoluzione.
O
4.
Fare clic con il pulsante destro del mouse sul Desktop (utilizzare
la combinazione di tasti
accedere al Desktop)
5. Utilizzare la casella di riepilogo a discesa per selezionare la
risoluzione dello schermo .
6. Fare clic su Impostazioni avanzate
Tasto logo Windows
e scegliere Proprietà grafiche dal menu.
+ D per
.
Per accedere al Pannello di controllo della Grafica HD
Intel®:
1. Fare clic sull'icona (Pannello di controllo della Grafica HD
Intel®) nella schermata della App.
O
2. Fare clic con il pulsante destro del mouse sul desktop
la combinazione di tasti
accedere al Desktop)
Tasto logo
e scegliere Proprietà grafiche dal menu.
Windows
+
(utilizzare
D
per
O
3. Fare clic sull'icona nell'area di notifica della barra delle
applicazioni desktop
e scegliere Proprietà grafiche dal menu.
Dispositivi di visualizzazione
Oltre allo schermo LCD integrato, è possibile utilizzare un
monitor VGA/LCD a schermo piatto o una TV (collegato
alla porta per monitor esterno o alla porta uscita HDMI)
come periferica di visualizzazione.
95
Italiano
Utilizzo della combinazione di tasti logo di
Figura 10
+ P (Cambia
configurazione di
visualizzazione)
Figura 11 - Opzioni risparmio energia
Windows
+ P per passare da una visua-
lizzazione all'altra
È possibile utilizzare la combinazione di tasti + P (o Fn
+ F7) per cambiare rapidamente la configurazione di
visualizzazione e le modalità (funzione particolarmente utile
quando si collega un proiettore) in Windows.
1. Collegare lo schermo alla porta per monitor esterno o porta
uscita HDMI, quindi accenderlo.
2. Premere la combinazione di tasti + P (o Fn + F7).
3. Viene visualizzato un menu a comparsa.
4. Utilizzare i tasti cursore (o + P) per selezionare la
configurazione appropriata dal menu, quindi premere Invio per
confermare la selezione.
Opzioni risparmio energia
Il pannello di controllo delle Opzioni risparmio energia
(menu Hardware e suoni) di Windows consente la
configurazione delle funzioni di risparmio energetico del
computer. Selezionando Risparmio di energia è possibile
attivare questa funzione e configurare le opzioni relative al
pulsante di alimentazione, pulsante di sospensione (Fn +
F4), coperchio del computer (chiuso), schermo e modalità
sospensione (lo stato di risparmio di energia predefinito).
Nota: la funzione Risparmio di energia può influire sulle
prestazioni del computer.
Fare clic su una delle combinazioni esistenti o su Creacombinazione per il risparmio di energia sul menu di
sinistra e personalizzarla per creare una nuova
combinazione. Fare clic su Modifica impostazioni
combinazione, quindi su Cambia impostazioni avanzate
risparmio energia per accedere a ulteriori opzioni di
configurazione.
Italiano
96
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
