Preface
Notice
The company reserves the right to revise this publication or to change its contents without notice. Information
contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or
any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear
in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse)
of this publication.
This publication and any accompanying software may not, in whole or in part, be reproduced, translated, transmitted or reduced to any machine readable form without prior consent from the vendor, manufacturer or creators
of this publication, except for copies kept by the user for backup purposes.
Brand and product names mentioned in this publication may or may not be copyrights and/or registered trademarks of their respective companies. They are mentioned for identification purposes only and are not intended
as an endorsement of that product or its manufacturer.
©May 2014
Trademarks
Intel, Pentium and Intel Core are trademarks/registered trademarks of Intel Corporation.
I
Preface
R&TTE Directive
This device is in compliance with the essential requirements and other relevant provisions of the R&TTE Directive 1999/5/EC.
This device will be sold in the following EEA countries: Austria, Italy, Belgium, Liechtenstein, Denmark, Luxembourg, Finland, Netherlands, France, Norway, Germany, Portugal, Greece, Spain, Iceland, Sweden, Ireland,
United Kingdom, Cyprus, Czech Republic, Estonia, Hungary, Latvia, Lithuania, Malta, Slovakia, Poland, Slovenia.
ErP Off Mode Power Consumption Statement:
The figures below note the power consumption of this computer in compliance with European Commission (EC)
regulations on power consumption in off mode:
• Off Mode < 0.5W
II
Preface
CE Marking
This device has been tested to and conforms to the regulatory requirements of the European Union and has attained CE Marking. The CE Mark is a conformity marking consisting of the letters “CE”. The CE Mark applies
to products regulated by certain European health, safety and environmental protection legislation. The CE Mark
is obligatory for products it applies to: the manufacturer affixes the marking in order to be allowed to sell his
product in the European market.
This product conforms to the essential requirements of the R&TTE directive 1999/5/EC in order to attain CE
Marking. A notified body has determined that this device has properly demonstrated that the requirements of the
directive have been met and has issued a favorable certificate of expert opinion. As such the device will bear the
notified body number 0560 after the CE mark.
The CE Marking is not a quality mark. Foremost, it refers to the safety rather than to the quality of a product.
Secondly, CE Marking is mandatory for the product it applies to, whereas most q uality marking s are vo lu ntary.
III
Preface
FCC Statement
(Federal Communications Commission)
You are cautioned that changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Re orient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the service representative or an experienc ed radio/TV technician for help.
Operation is subject to the following two conditions:
1. This device may not cause interference.
And
2. This device must accept any interference, including interfer ence that may cause undesired operation of the
device.
IV
FCC RF Radiation Exposure Statement:
Warning
Use only shielded cables to connect I/O devices to this equipment. You are cautioned that changes or modifications not expressly approved by the manufacturer for compliance with the above standard s could void your authority to operate the
equipment.
1. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
2. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator
and your body.
Preface
V
Preface
IMPORTANT SAFETY INSTRUCTIONS
Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury
to persons when using any electrical equipment:
1. Do not use this product near water, for example n ear a ba th tub, wash bowl, kitchen sink or laundry tu b, in a wet
basement or near a swimming pool.
2. Avoid using this equipment with a telephone line (other than a cordless type) during an electrical storm. There
may be a remote risk of electrical shock from lightning.
3. Do not use the telephone to report a gas leak in the vicinity of the leak.
4. Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may
explode. Check with local codes for possible special disposal instructions.
5. This product is intended to be supplied by a Listed Power Unit according to the model’s requirements:
• Full Range AC/DC Adapter - AC Input 100 - 240V, 50 - 60Hz, DC Output 19V, 3.42A (65W) minimum.
This Computer’s Optical Device is a Laser Class 1 Product
VI
Preface
Instructions for Care and Operation
The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions:
1. Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged.
Do not expose the computer
to any shock or vibration.
Do not place it on an unstable
surface.
Do not place anything heavy
on the computer.
2. Keep it dry, and don’t overheat it. Keep the computer and power supply away from any kind of heating ele-
ment. This is an electrical appliance. If water or any other liquid gets into it, the computer could be badly damaged.
Do not expose it to excessive
heat or direct sunlight.
Do not leave it in a place
where foreign matter or moisture may affect the system.
Don’t use or store the computer in a humid environment.
Do not place the computer on
any surface that will block the
Vents/Fan Intakes.
VII
Preface
3. Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other
strong magnetic fields. These can hinder proper performance and damage your data.
4. Follow the proper workin g procedu res for t he computer. Shut the computer down properly and don’t forget
to save your work. Remember to periodically save your data as data may be lost if the battery is depleted.
Do not turn off the power
until you properly shut down
all programs.
Do not turn off any peripheral
devices when the computer is
on.
5. Take care when using peripheral devices.
Use only approved brands of
peripherals.
VIII
Do not disassemble the computer by yourself.
Unplug the power cord befor e
attaching peripheral devices.
Perform routine maintenance
on your computer.
Servicing
Bottom Cover Removal Warning
Do not remove any cover(s) and /or screw(s) for the purposes of device upgrade as this may violate the terms of your warranty. If you need to replace/remove the hard disk/RAM/optical device etc., for any reason, ple ase contact your distribu tor/
supplier for further information.
Removal Warning (For Service Personnel)
When removing any cover(s) and screw(s) for the purposes of device upg rade, remember to replace the cover(s) and
screw(s) before restoring power to the system.
Also note the following when the cover is removed:
• Hazardous moving parts.
• Keep away from moving fan blades.
Do not attempt to service the computer yourself. Doing so may violate your warranty and may expose you and
the computer to electric shock. Refer all servicing to authorized service personnel. Unplug the computer from
the power supply. Then refer servicing to qualified service personnel under any of the following conditions:
• When the power cord or AC/DC adapter is damaged or frayed.
• If the computer has been exposed to rain or other liquids.
• If the computer does not work normally when you follow the operating instructions.
• If the computer has been dropped or damaged (do not touch the poisonous liquid if the LCD panel breaks).
• If there is an unusual odor, heat or smoke coming from your computer.
Preface
IX
Preface
Power Safety Warning
(For Service
Personnel)
Before you undertake
any upgrade procedures, make sure that
you have turned off the
power, and disconnected all peripherals and
cables (including telephone lines and power
cord).
You must also remove
your battery in order to
prevent accidentally
turning the machine on.
Before removing the
battery disconnect the
AC/DC adapter from
the computer.
Power Safety
The computer has specific power requirements:
• Only use a power adapter approved for use with this computer.
• Your AC/DC adapter may be designed for international travel but it still requires a
steady, uninterrupted power supply. If you are unsure of your local power specifications, consult your service representative or local power company.
X
• The power adapter may have either a 2-prong or a 3-prong grounded plug. The third
prong is an important safety feature; do not defeat its purpose. If you do not have access
to a compatible outlet, have a qualified electrician install one.
• When you want to unplug the powe r co rd, be sure to di sconn ect it b y the plug head , no t
by its wire.
• Make sure the socket and any extension cord(s) you use can support the total current
load of all the connected devices.
• Before cleaning the computer, make sure it is disconnected from any external power
supplies (i.e. AC/DC adapter or car adapter).
Do not plug in the power
cord if you are wet.
Do not use the power cord if
it is broken.
Do not place heavy objects
on the power cord.
Preface
Polymer Battery Precautions
Note the following information which is specific to polymer batteries only, and where applicable, this overrides
the general battery precaution information overleaf.
• Polymer batteries may experience a slight expansion or swelling, however this is part of the battery’s safety mechanism and is not a cause for concern.
• Use proper handling procedures when using polymer batteries. Do not use polymer batteries in high ambient temperature environments, and do not store unused batteries for extended periods.
See also the general battery precautionary information overleaf for further information.
XI
Preface
Battery Disposal & Caution
The product that you have purchased contains a rechargeable battery. The battery is recyclable. At the end of its useful life,
under various state and local laws, it may be illegal to dispose of this battery in to the municipal waste stream. Check with
your local solid waste officials for details in your area for recycling options or proper disposal.
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalen t type recommended by the
manufacturer. Discard used battery according to the manufacturer’s instructions.
General Battery Precautions
• Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer.
• Do not remove any batteries from the computer while it is powered on.
• Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even
if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly
result in fire.
• If you do not use the battery for an extended period, then remove the battery from the computer for storage.
• Recharge the batteries using the notebook’s system. Incorrect recharging may make the battery explode.
• Do not try to repair a battery pack. Refer any battery pack repa ir or replacemen t to you r service repre sentati ve or qu alified service personnel.
• Keep children away from, and promptly dispose of a damaged battery. Always dispose of batteries carefully. Batteries
may explode or leak if exposed to fire, or improperly handled or discarded.
• Keep the battery away from metal appliances.
• Affix tape to the battery contacts before disposing of the battery.
• Do not touch the battery contacts with your hands or metal objects.
XII
Preface
Power Off Before Traveling
Make sure that your notebook is completely powered off before putting it into a travel bag (or any such container). Putting a
notebook which is powered on in a travel bag may cause the Vents/Fan Intakes to be blocked. To pre vent your computer
from overheating make sure nothing blocks the Vent/Fan Intakes while the computer is in use.
Cleaning
Do not apply cleaner directly to the computer; use a soft clean cloth.
Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer.
Travel Considerations
As you get ready for your trip, run through this list to make sure the system is ready to go:
1. Check that the battery pack and any spares are fully charged.
2. Power off the computer and peripherals.
3. Close the display panel and make sure it’s latched.
4. Disconnect the AC/DC adapter and cables. Stow them in the carrying bag.
5. The AC/DC adapter uses volt ages from 100 to 240 volt s so you won’t need a second volt age adapter. However,
check with your travel agent to see if you need any socket adapters.
6. Put the notebook in its carrying bag and secure it with the bag’s straps.
7. If you’re taking any perip herals (e.g. a printer, mouse or digital camera), pack them and those devices’ adapters
and/or cables.
8. Anticipate customs - Some jurisdictions may have import restrictions or req uire proof of ownersh ip for both hard -
ware and software. Make sure your “papers” are handy.
XIII
Preface
Power Off Before Traveling
Make sure that your notebook is completely powered off before putting it into a travel bag (or any such container). Putting a
notebook which is powered on in a travel bag may cause the vent(s)/fan intake(s)/outlet(s) to be blocked. To prev ent your
computer from overheating make sure nothing blocks the vent(s)/fan intake(s)/outlet(s) while the computer is in use.
Packing
As you get ready for your trip, run through this list to make sure the system is ready to go:
1. Check that the battery pack and any spares are fully charged.
2. Power off the computer and peripherals.
3. Close the display panel and make sure it’s latched.
4. Disconnect the AC/DC adapter and cables. Stow them in the carrying bag.
5. The AC/DC adapter uses volt ages from 100 to 240 volt s so you won’t need a second volt age adapter. However,
check with your travel agent to see if you need any socket adapters.
6. Put the notebook in its carrying bag and secure it with the bag’s straps.
7. If you’re taking any perip herals (e.g. a printer, mouse or digital camera), pack them and those devices’ adapters
and/or cables.
8. Anticipate customs - Some jurisdictions may have import restrictions or req uire proof of ownersh ip for both hard -
ware and software. Make sure your documents are prepared.
XIV
Preface
On the Road
In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting,
keep these points in mind:
Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very
common. Don’t check it with “normal” luggage. Baggage handlers may not be sufficiently careful. Avoid knocking the computer against hard objects.
Beware of Electromagnetic fields - Devices such as metal detectors & X-ray machines can damage the computer, hard disk, floppy disks, and other media. They may also destroy any stored data - Pass your computer and
disks around the devices. Ask security officials to hand-inspect them (you may be asked to turn it on). Note:
Some airports also scan luggage with these devices.
Fly safely - Most airlines have regulations about the use of computers and other electronic devices in flight.
These restrictions are for your safety, follow them. If you stow the notebook in an overhead compartment, make
sure it’s secure. Contents may shift and/or fall out when the compartment is opened.
Get power where you can - If an electrical outlet is available, use the AC/DC adapter and keep your battery(ies)
charged.
Keep it dry - If you move quickly from a cold to a warm location, water vapor can condense inside the computer.
Wait a few minutes before turning it on so that any moisture can evaporate.
XV
Preface
Developing Good Work Habits
Developing good work habits is important if you need to work in fron t of the computer for long periods of time.
Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or
other joints. The following are some tips to reduce the strain:
• Adjust the height of the chair and/or desk so that the keyboard is at or slightly below the
level of your elbow. Keep your forearms, wrists, and hands in a relaxed position.
• Your knees should be slightly higher than your hips. Place your feet flat on the floor or o n
a footrest if necessary.
• Use a chair with a back and adjust it to support your lower back comfortably.
• Sit straight so that your knees, hips and elbows form approximately 90-degree angles
when you are working.
• Take periodic breaks if you are using the computer for long periods of time.
Remember to:
• Alter your posture frequently.
• Stretch and exercise your body several times a day.
• Take periodic breaks when you work at the computer for long periods of time. Frequent
and short breaks are better than fewer and longer breaks.
XVI
Preface
Lighting
Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and
shoulders.
• Position the display to avoid glare or reflections from overhead lighting or outside sources of light.
• Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly.
• Position the display directly in front of you at a comfortable viewing distance.
• Adjust the display-viewing angle to find the best position.
LCD Screen Care
To prevent image persistence on LCD monitors (caused by the continuous display of graphics on the screen for
an extended period of time) take the following precautions:
• Set the Windows Power Plans to turn the screen off after a few minutes of screen idle time.
• Use a rotating, moving or blank screen saver (this prevents an image from being displayed too long).
• Rotate desktop background images every few days.
• Turn the monitor off when the system is not in use.
LCD Electro-Plated Logos
Note that in computers featuring a raised LCD electro-plated logo, the logo is covered by a protective adhesive.
Due to general wear and tear, this adhesive may deteriorate over time and the exposed logo may develop sharp
edges. Be careful when handling the computer in this case, and avoid touching the raised LCD electro-plated
logo. Avoid placing any other items in the carrying bag which may rub against the top of the computer during
transport. If any such wear and tear develops contact your distributor/supplier.
XVII
Preface
XVIII
Preface
Contents
Notice .............................................................................................................................................................I
ErP Off Mode Power Consumption Statement: ...........................................................................................II
FCC Statement ............................................................................................................................................IV
FCC RF Radiation Exposure Statement: .....................................................................................................V
Instructions for Care and Operation ......................................................................................................... VII
Servicing .....................................................................................................................................................IX
Power Safety ................................................................................................................................................X
Polymer Battery Precautions ......................................................................................................................XI
General Battery Precautions ..................................................................................................................... XII
Cleaning ...................................................................................................................................................XIII
Travel Considerations ..............................................................................................................................XIII
Quick Start Guide
Overview ....................................................................................................................................................1-1
Advanced Users .........................................................................................................................................1-2
Beginners and Not-So-Advanced Users ....................................................................................................1-2
Warning Boxes ..........................................................................................................................................1-2
Not Included ..............................................................................................................................................1-3
System Startup ...........................................................................................................................................1-4
System Software ........................................................................................................................................1-5
Model Differences .....................................................................................................................................1-6
XIX
Preface
System Map: LCD Panel Open ..................................................................................................................1-7
LED Indicators ...........................................................................................................................................1-8
Keyboard ....................................................................................................................................................1-9
Function/Hot Key Indicators ...................................................................................................................1-10
Control Center .........................................................................................................................................1-11
System Map: Front View .........................................................................................................................1-12
System Map: Left View ...........................................................................................................................1-13
System Map: Right View .........................................................................................................................1-14
System Map: Rear View ..........................................................................................................................1-16
System Map: Bottom View (Models A & B) ..........................................................................................1-17
System Map: Bottom View (Models C & D) ..........................................................................................1-18
Windows 7 Start Menu & Control Panel .................................................................................................1-19
Video Features .........................................................................................................................................1-20
Power Options .........................................................................................................................................1-22
Features & Components
Overview ....................................................................................................................................................2-1
Hard Disk Drive .........................................................................................................................................2-2
Optical (CD/DVD) Device ........................................................................................................................2-3
Loading Discs ............................................................................................................................................2-3
Handling CDs or DVDs .............................................................................................................................2-4
DVD Regional Codes ................................................................................................................................2-5
XX
Preface
Multi-In-1 Card Reader .............................................................................................................................2-6
ExpressCard Slot .......................................................................................................................................2-7
Inserting and Removing ExpressCards ......................................................................................................2-7
Smart Card Reader .....................................................................................................................................2-8
Touchpad and Buttons/Mouse ...................................................................................................................2-9
Gestures and Device Settings ..................................................................................................................2-10
Audio Features .........................................................................................................................................2-14
Power Management
Overview ....................................................................................................................................................3-1
The Power Sources ....................................................................................................................................3-2
AC/DC Adapter .........................................................................................................................................3-2
Battery ........................................................................................................................................................3-2
Turning On the Computer ..........................................................................................................................3-3
Power Plans ...............................................................................................................................................3-4
Power-Saving States ..................................................................................................................................3-6
Sleep ..........................................................................................................................................................3-6
Hibernate ....................................................................................................................................................3-7
Shut down ..................................................................................................................................................3-7
Configuring the Power Buttons .................................................................................................................3-8
Resuming Operation ..................................................................................................................................3-9
Power Conservation Modes .....................................................................................................................3-10
XXI
Preface
Battery Information .................................................................................................................................3-11
Conserving Battery Power .......................................................................................................................3-12
Battery Life ..............................................................................................................................................3-13
New Battery .............................................................................................................................................3-13
Recharging the Battery with the AC/DC Adapter ...................................................................................3-13
Proper handling of the Battery Pack ........................................................................................................3-14
Battery FAQ .............................................................................................................................................3-15
Drivers & Utilities
What to Install ............................................................................................................................................4-1
Module Driver Installation ........................................................................................................................4-1
Driver Installation ......................................................................................................................................4-2
Updating/Reinstalling Individual Drivers ..................................................................................................4-5
User Account Control ................................................................................................................................4-5
Windows Security Message .......................................................................................................................4-5
New Hardware Found ................................................................................................................................4-5
Driver Installation Procedure .....................................................................................................................4-6
Chipset .......................................................................................................................................................4-6
Video (VGA) .............................................................................................................................................4-6
LAN ...........................................................................................................................................................4-6
CardReader ................................................................................................................................................4-6
Touchpad ...................................................................................................................................................4-7
XXII
Preface
Hot Key ......................................................................................................................................................4-7
USB 3.0 ......................................................................................................................................................4-7
MEI Driver .................................................................................................................................................4-7
Audio .........................................................................................................................................................4-7
Windows Experience Index .......................................................................................................................4-8
Optional Drivers ........................................................................................................................................4-9
BIOS Utilities
Overview ....................................................................................................................................................5-1
The Setup Utility ........................................................................................................................................5-2
Failing the POST .......................................................................................................................................5-3
Fatal Errors ................................................................................................................................................5-3
Non-Fatal Errors ........................................................................................................................................5-3
Setup Screens .............................................................................................................................................5-4
Main Menu .................................................................................................................................................5-5
System Time & Date (Main Menu) ...........................................................................................................5-5
SATA Port # (Main Menu) ........................................................................................................................5-6
System/Extended Memory: (Main Menu) .................................................................................................5-6
MB Series / BIOS Revision / KBC/EC firmware Revision ......................................................................5-6
Advanced Menu .........................................................................................................................................5-7
Advanced Chipset Control (Advanced Menu) ..........................................................................................5-8
VT-d (Advanced Menu > Advanced Chipset Control) ..............................................................................5-8
XXIII
Preface
Intel Virtualization Technology (Advanced Menu > Advanced Chipset Control) ....................................5-8
Intel TXT(LT) Trusted Execution Technology Support
(Advanced Menu > Advanced Chipset Control) .......................................................................................5-8
USB Port Power/ Card Reader Power / PCI Express Card Power / (Advanced Menu > Advanced Chipset
Control) ......................................................................................................................................................5-9
Intel Smart Connect Technology (Advanced Menu) .................................................................................5-9
SATA Mode (Advanced Menu) ................................................................................................................5-9
Boot Logo (Advanced Menu) ....................................................................................................................5-9
Power On Boot Beep (Advanced Menu) .................................................................................................5-10
Battery Low Alarm Beep (Advanced Menu) ...........................................................................................5-10
Security Menu ..........................................................................................................................................5-11
Set Supervisor Password (Security Menu) ..............................................................................................5-11
Set User Password (Security Menu) ........................................................................................................5-12
Password on boot (Security Menu) ..........................................................................................................5-12
Secure Boot Support (Security Menu) .....................................................................................................5-12
TPM Configuration (Security Menu) ......................................................................................................5-13
TPM State (Security Menu > TPM Support Enabled) .............................................................................5-14
Pending TPM operation (Security Menu > TPM Support & TPM State Enabled) .................................5-15
Boot Menu ...............................................................................................................................................5-16
Boot Option Priorities (Boot Menu) ........................................................................................................5-17
UEFI Boot (Boot Menu) ..........................................................................................................................5-17
Exit Menu ................................................................................................................................................5-18
XXIV
Preface
Modules & Options
Overview ....................................................................................................................................................6-1
PC Camera Module ....................................................................................................................................6-3
PC Camera Driver Installation ...................................................................................................................6-3
Wireless LAN Module .............................................................................................................................6-11
Intel® WLAN Driver Installation ............................................................................................................6-12
3rd Party WLAN Driver Installation .......................................................................................................6-12
Connecting to a Wireless Network in Windows 7 ...................................................................................6-13
Security Modules (Fingerprint & TPM) ..................................................................................................6-17
Fingerprint Reader Module ......................................................................................................................6-18
Fingerprint Reader Driver Installation .....................................................................................................6-18
BioExcess Application .............................................................................................................................6-19
Bluetooth & WLAN Combo Module ......................................................................................................6-30
Intel Bluetooth Combo Driver Installation ..............................................................................................6-31
3rd Party Bluetooth Combo Driver Installation .......................................................................................6-31
Bluetooth Configuration in Windows 7 ...................................................................................................6-32
Trusted Platform Module .........................................................................................................................6-36
Enabling & Activating TPM ....................................................................................................................6-37
Trusted Platform Module (TPM) Driver Installation ..............................................................................6-39
Initializing TPM .......................................................................................................................................6-40
Infineon Security Platform Settings Tool ................................................................................................6-42
Intel Rapid Storage Technology ..............................................................................................................6-50
XXV
Preface
IRST Driver Installation ..........................................................................................................................6-50
Intel® Smart Connect Technology ..........................................................................................................6-51
Intel® Smart Connect Technology Driver Installation ............................................................................6-51
Intel® Smart Connect Technology Configuration ...................................................................................6-52
Intel® Wireless Display Application .......................................................................................................6-56
Intel® WiDi Application Installation ......................................................................................................6-57
Intel® WiDi Application Configuration ..................................................................................................6-58
Free Fall Data Protection .........................................................................................................................6-61
Free Fall Protection Driver Installation ...................................................................................................6-62
Intel® vPro™ Technology ......................................................................................................................6-65
Accessing the Intel Management Engine ................................................................................................6-65
Intel® Management and Security Status .................................................................................................6-67
Intel® Small Business Advantage ...........................................................................................................6-71
Installing Intel® Small Business Advantage ...........................................................................................6-71
SBA Application Modules .......................................................................................................................6-72
Troubleshooting
Overview ....................................................................................................................................................7-1
Basic Hints and Tips ..................................................................................................................................7-2
Backup and General Maintenance .............................................................................................................7-3
Viruses .......................................................................................................................................................7-4
Upgrading and Adding New Hardware/Software ......................................................................................7-5
XXVI
Preface
Problems and Possible Solutions ...............................................................................................................7-7
Interface (Ports & Jacks)
Overview ...................................................................................................................................................A-1
Notebook Ports and Jacks .........................................................................................................................A-2
Control Center
Overview ...................................................................................................................................................B-1
Video Driver Controls
Video Driver Installation ..........................................................................................................................C-1
Dynamic Video Memory Technology ......................................................................................................C-1
Intel® HD Graphics Control Panel ...........................................................................................................C-2
Display Devices & Options ....................................................................................................................C-13
Attaching Other Displays .......................................................................................................................C-14
Configuring an External Display in Windows 7 .....................................................................................C-18
HDMI Audio Configuration ...................................................................................................................C-21
Specifications
Processors .................................................................................................................................................D-2
Core Logic ................................................................................................................................................D-3
Display ......................................................................................................................................................D-3
Memory .....................................................................................................................................................D-3
XXVII
Preface
Video .........................................................................................................................................................D-3
Storage ......................................................................................................................................................D-3
Audio ........................................................................................................................................................D-3
Keyboard, Pointing Device & Buttons .....................................................................................................D-3
Interface ....................................................................................................................................................D-3
Card Readers ............................................................................................................................................D-3
Slots ..........................................................................................................................................................D-3
Communication .........................................................................................................................................D-4
Power Management ..................................................................................................................................D-4
Power ........................................................................................................................................................D-4
Security .....................................................................................................................................................D-4
BIOS .........................................................................................................................................................D-4
LED Indicators ..........................................................................................................................................D-4
Operating System ......................................................................................................................................D-4
Design Features ........................................................................................................................................D-4
Environmental Spec ..................................................................................................................................D-4
Dimensions & Weight ..............................................................................................................................D-5
XXVIII
Quick Start Guide
Chapter 1: Quick Start Guide
Overview
This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the
computer and to getting your system started. The remainder of the manual covers the following:
• Chapter 2 A guide to using some of the main features of the computer e.g. the storage devices (hard disk,
card reader & ExpressCard), Touchpad & Mouse & Audio.
• Chapter 3 The computer’s power saving options.
• Chapter 4 The installation of the drivers and utilities essential to the operation or improvement of some of the
computer’s subsystems.
• Chapter 5 An outline of the computer’s built-in software or BIOS (Basic Input Output System).
• Chapter 6 A quick guide to the computer’s PC Camera, Wireless LAN, Fingerprint Reader, Bluetooth,
Trusted Platform (TPM) and Intel modules (some of which may be optional depending on your
purchase configuration).
• Chapter 7 A troubleshooting guide.
• Appendix A Definiti ons of the interface, ports/jacks which allow your computer to communicat e with external
devices.
• Appendix B Information on the Control Center .
• Appendix C Information on the video driver controls.
• Appendix D The computer’s specification.
1
Overview 1 - 1
1
Notes
Check the light colored
boxes with the mark
above to find detailed
information about the
computer’s features.
Quick Start Guide
Advanced Users
If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful
to refer to “What to Install” on page 4 - 1 and “BIOS Utilities” on page 5 - 1 in the reminder of the User’s
Manual. You may also find the notes marked with a
of interest to you.
Beginners and Not-So-Advanced Users
If you are new to computers (or do not have an advanced knowledge of them) then
the information contained in the Quick Start Guide should be enough to get you up
and running. Eventually you should try to look through all the documentation (more
detailed descriptions of the functions, setup and system controls are covered in the
remainder of the User’s Manual), but do not worry if you do not understand everything the first time. Keep this manual nearby and refer to it to learn as you go. You
may find it useful to refer to the notes marked with a
as indicated in the margin.
For a more detailed description of any of the interface ports and jacks see “Interface
(Ports & Jacks)” on page A - 1.
Warning Boxes
No matter what your level please pay careful attention to the warning and safety information indicated by the
symbol. Also please note the safety and handling instructions as indicated in the Preface.
1 - 2 Overview
Quick Start Guide
Drivers
If you are installing new system software, or are re-configuring your computer for a different system, you will need to install
the drivers listed in “Drivers & Utilities” on page 4 - 1. Drivers are programs which act as an interface between the computer and a hardware component e.g. a wireless network module. It is very important that you install the drivers in the order
listed. You will be unable to use most advanced controls until the necessary drivers and utilities are properly installed. If
your system hasn’t been properly configured (your service representative may have already done that for you); refer to
Chapter 4 for installation instructions.
Ports and Jacks
See “Notebook Ports and Jacks” on page A - 2 for a description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc.
Not Included
Operating Systems (e.g. Windows 7) and applications (e.g. word processing, spreadsheet and database programs)
have their own manuals, so please consult the appropriate manuals.
1
Overview 1 - 3
1
Shutdown
Note that you should always shut your computer down by choosing the
Shut Down command
from the bottom right of
the Start menu in Win-
dows. This will help prevent hard disk or system
problems.
130°
Quick Start Guide
System Startup
1. Remove all packing materials and place the computer on a stable surface.
2. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports.
3. Attach the AC/DC adapter to the DC-In jack on the left of the computer, connect the AC power cord to the AC/
DC adapter and then plug the AC power cord into an outlet (make sure you use the adapter when first
setting up the computer, as to safeguard the computer during shipping the battery will be locked to not pow er
the system until first connected to the AC/DC adapter).
4. Use one hand to raise the
hand to support the base of the computer (Note: Never lift the computer by the lid/LCD).
5. Press the power button on the top right of the computer for about 2 - 3 seconds to turn the computer on
lid/LCD to a comfortable viewing angle (
Figure 1 - 1 - Opening the Lid/LCD & Computer with AC/DC Adapter Plugged-In
1 - 4 System Startup
do not exceed 130 degrees
);
use the other
Quick Start Guide
Windows Versions
Note that the information included on the following pages is for Windows 7 (64-bit) only.
Windows OS
In order to run Windows 7 (64-bit with Service Pack 1) your computer requires a minimum 2GB of system memory
(RAM).
System Software
Your computer may already come with system software pre-installed. Where this is not the case, or where you
are re-configuring your computer for a different system, you will find the Windows 7 (6 4-bit with Service Pack
1 installed) operating system is supported.
1
System Startup 1 - 5
1
Quick Start Guide
Model Differences
This notebook series includes four different model types that mainly differ as indicated in the table below. Note that
your model may appear slightly different from those pictured in this manual.
Feature Model A Model B Model C Model D
CPUs Supported See “Processors” on page D - 2
Core Logic
Smart Card
Reader Module
Wireless LAN/
WLAN & Bluetooth
Combo Modules
Intel® vPro™
Technology
Dimensions &
Weight
Mobile Intel® QM87
Express Chipset
Supported Supported Not Supported Not Supported
Supported Not Supported Supported Not Supported
340 mm(w) * 242 mm(d) * 30.5mm(h) - height excluding
2.3kg Barebone System with Battery and ODD
1 - 6 Model Differences
Mobile Intel® HM87
Express Chipset
See “Communication” on page D - 4
battery area
Table 1 - 1 - Model Differences
Mobile Intel® QM87
Express Chipset
340 mm(w) * 242 mm(d) * 26.5mm(h) - height excluding
battery area
2.3kg Barebone System with Battery and ODD
Mobile Intel® HM87
Express Chipset
System Map: LCD Panel Open
Figure 1 - 2
LCD Panel Open
1. Built-In PC Camera
(
Optional
)
2. PC Camera LED
3. Built-in Microphone
4. LCD
5. Power Button
6. Keyboard
7. Touchpad &
Buttons
8. Fingerprint Reader
Sensor
Note that the Touchpad and
Buttons valid operational area
is that indicated within the red
dotted lines above.
8
3
5
1
4
6
Wireless Device
Operation Aboard
Aircraft
The use of any portable
electronic transmission
devices aboard aircraft is
usually prohibited. Make
sure the module(s) are
OFF if you are using the
computer aboard aircraft.
Use Fn + F11 Airplane
Mode key combination to
toggle Airplane Mode On/
Off, and check the LED indicator for the power status (see Table 1 - 3, on
page 1 - 10).
7
8
2
Quick Start Guide
1
System Map: LCD Panel Open 1 - 7
1
Quick Start Guide
LED Indicators
The LED indicators on the computer display helpful information about the current status of the computer.
Icon Color Description Icon Color Description
Orange AC/DC Power is Plugged In Orange The Battery is Charging
Blinking
Orange
Green The Computer is On
Blinking
Green
White Power Button Green Hard Disk/ODD Activity
The powered USB 3.0 port
key combination.
When the powered USB port is on it will supply power (for charging devices only, not for operating devices) when the system
is off but still powered by the AC/DC adapter plugged into a working outl et, or powered by the battery with a capacity level
above 20% (this may not work with certain devices).
The Powered USB Port is On Green The Battery is Fully Charged
Blinking
Orange
The Computer is in Sleep Mode Green
The Battery has Reached Critically
Low Power Status
Airplane Mode is ON (the WLAN, &
Bluetooth Modules are OFF)
(see Figure 1 - 6 on page 1 - 13) may be toggled on /off by means of the Fn + Power Button
Table 1 - 2 - LED Indicators
1 - 8 LED Indicators
Keyboard
Other Keyboards
If your keyboard is damaged or you just want to
make a change, you can
use any standard USB
keyboard. The system will
detect and enable it automatically. However special functions/hot-keys
unique to the system’s
regular keyboard may not
work.
NumLk & ScrLk
Hold down the Fn Key
and either NumLk or
ScrLk to enable number
or scroll lock, and check
the LED indicator for status.
Numerical Keypad
Play/Pause Key
Function Keys
NumLk &
ScrLk Keys
Fn Key
Windows Logo Key
Menu/Application Key
Special Characters
Some software applications allow the number-keys to be used with Alt to produce special characters.
These special characters can only be produced by using the numeric keypad. Regular number keys (in
the upper row of the keyboard) will not work. Make sure that NumLk is on.
The keyboard has an embedded numerical keypad for easy numeric data input, and
function keys to change operational features instantly.
Figure 1 - 3 - Keyboard
Quick Start Guide
1
Keyboard 1 - 9
1
Quick Start Guide
Function/Hot Key Indicators
The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition
to the basic function key combinations; visual indicators are available when the hot key utility is installed.
Keys Function Keys Function
Fn +
Fn +
Play/Pause (in Audio/Video Programs)
Touchpad Toggle
(Disable toggle by
using the Touchpad
Fn +
Fn +
Brightness
Decrease/
Increase
PC Camera
Power T oggle
Turn LCD Backlight Off
Sleep Toggle Fn + ScrLk
Increase
Display Switch Menu
Fn +
Fn +
Fn +
Fn +
Fn +
(Press a key to or use TouchPad to turn on)
Mute Toggle Fn + NumLk
Volume Decrease/
Table 1 - 3 - Function & Hot Key Indicators
1 - 10 Function/Hot Key Indicators
Fn +
Caps Lock
Fn +
Airplane
Mode T oggle
Number Lock
Toggle
Scroll Lock
Toggle
Caps Lock
Toggle
Fan Control
Toggle -
Maximum /
Automatic
Quick Start Guide
Control Center Access
To run the
Control Center press the
Fn + Esc
key combination, or
double-click
the icon
in the notification area
of the taskbar.
Close the Control Center by clicking the
close icon in the top right of the panel
(move the cursor onto the top right corner
of the panel to highlight it).
Control Center
Press the Fn + Esc key combination, or double-click the icon in the notification area of the taskbar to
toggle the Control Center on/off. The Control Center gives quick access to frequently used controls and enables you to quickly turn the camera/touch pad on/off (see Appendix B for full details).
Figure 1 - 4 - Control Center
Control Center 1 - 11
1
1
Figure 1 - 5
Front View
1. LED Indicators
2. Multi-In-1 Card
Reader
3. ExpressCard Slot
(see page 2 - 7)
USB Port / Card Reader
/ ExpressCard Power
Note that power to the
USB ports, card reader
and ExpressCard may be
enabled/disabled in the
BIOS (see page 5 - 9).
3
1
2
Multi-In-1 Card Reader
The card reader allows you to use the most popular digital storage card formats:
MMC (MultiMedia Card) / RS MMC
SD (Secure Digital) / Mini SD / SDHC / SDXC
MS (Memory Stick) / MS Pro / MS Duo
Simply push the card to insert and eject it, however some cards require an adapter (usually
supplied with the card).
ExpressCard 34 Slot
The ExpressCard Slot accepts either ExpressCard/34 formats.
Quick Start Guide
System Map: Front View
1 - 12 System Map: Front View
System Map: Left View
Figure 1 - 6
Left View
1. DC-In Jack
2. RJ-45 LAN Jack
3. External Monitor
Port
4. Fan Intake/Vent
5. HDMI Out Port
6. USB 3.0 Port
7. AC/DC Powered
USB 3.0 Port
USB Ports
This model includes 3 *
USB 3.0 ports (including
one ACDC Powered USB
3.0 port) and 1* USB 2.0
port. USB 3.0 ports are
denoted by their blue col-
or; USB 2.0 ports are col-
ored black. The USB 3.0
port requires a driver installation (see page 4 - 7)
for Windows 7.
2
5
4
1
3
Multi-In-1 Card Reader
The card reader allows you to use the most popular digital storage card formats:
MMC (MultiMedia Card) / RS MMC
SD (Secure Digital) / Mini SD / SDHC / SDXC
MS (Memory Stick) / MS Pro / MS Duo
Powered USB 3.0 Port
The powered USB 3.0 port can supply power (for charging devices only, not for operating devices) when the system is off but still powered by the AC/DC adapter plugged into
a working outlet, or powered by the batte ry with a capacity level above 20% (this may not
work with certain devices - see page 7 - 11). Toggle power to this port by using Fn + power
button. Power to this port may be enabled/disabled in the BIOS (see page 5 - 9).
7
76
2
5
4
1
3
76
Models A & B
Models C & D
Quick Start Guide
System Map: Left View 1 - 13
1
1
Figure 1 - 7
Right View
1. 1 * Audio Combo
Jack (headphone / microphone in)
2. 2 * USB 2.0 Ports
3. Optical Device
Drive Bay (for
CD/DVD Device)
4. Smart Card
Reader (For
Models A & B
Only)
5. Security Lock Slot
6. Battery
1
2
3
4
2
5
1
2
3
2
5
Models A & B
Models C & D
Combination Headphone/Microphone Headsets for Audio Combo Jack
This system’s audio combo jack uses App le iPhone/iPad compatible combination
headphone/microphone headsets only. When
purchasing a combination headphone/microphone
headset for use with this system make sure that it
is Apple iPhone/iPad comp atible otherwise it will
not function.
Smart Card Orientation
Note that when inserting Smart Cards, the card’s
readable side (with the gold-colored contacts)
should face upwards as illustrated on the right.
Quick Start Guide
System Map: Right View
1 - 14 System Map: Right View
Disk Eject Warning
Don’t try to eject a CD/DVD while the system is accessing it. This may cause the system to “crash”. Stop
the disk first then eject it, or press the stop button
twice.
CD/DVD Emergency Eject
If you need to manually eject a CD/DVD (e.g. due to
an unexpected power interruption) you may push the
end of a straightened paper clip into the emergency
eject hole. Do not use a sharpened pencil or any object that may break and become lodged in the hole.
Don’t try to remove a floppy disk/CD/DVD while the
system is accessing it. This may cause the system to
“crash”.
Changing DVD Regional Codes
Go to the Control Panel and double-click Device
Manager (Hardware and Sound), then click th e +
next to DVD/CD-ROM drives. Double-click on the
DVD-ROM device to bring up the Properties dialog
box, and select the DVD Region (tab) to bring up the
control panel to allow you to adjust the regional code
(see “DVD Regional Codes” on page 2 - 5).
DVD region detection is device dependent, not OSdependent. You can select your module’s region
code 5 times. The fifth selection is pe rmanent. This
cannot be altered even if you change your operating
system or you use the module in another computer.
Quick Start Guide
1
System Map: Right View 1 - 15
1
Figure 1 - 8
Rear View
1. Battery
Battery Information
Always completely discharge, then fully charge, a new battery before using it. Comp letely
discharge and charge the battery at least once every 30 days or after about 20 partial discharges.
1
Quick Start Guide
System Map: Rear View
1 - 16 System Map: Rear View
System Map: Bottom View (Models A & B)
Figure 1 - 9
Bottom View
(Models A & B)
1. mSATA SSD
Module Cover
(not user serviceable)
2. Fan Intake/Vent
3. Speakers
Overheating
To prevent your computer from overheating
make sure nothing
blocks the Vent/Fan Intake while the computer
is in use.
2
1
2
2
3
2
3
2
Bottom Cover Removal Warning
Do not remove any cover(s) and /or screw(s) for the purposes of device upgrade as this may
violate the terms of your warranty.
If you need to replace/remove the hard disk/RAM/optical device etc., for any reason, please
contact your distributor/supplier for further information.
Quick Start Guide
1
System Map: Bottom View (Models A & B) 1 - 17
1
Figure 1 - 10
Bottom View
(Models C & D)
1. Fan Intake/Vent
2. Speakers
Overheating
To prevent your computer from overheating
make sure nothing
blocks the Vent/Fan Intake while the computer
is in use.
1
2 2
Bottom Cover Removal Warning
Do not remove any cover(s) and /or screw(s) for the purposes of device upgrade as this may
violate the terms of your warranty.
If you need to replace/remove the hard disk/RAM/optical device etc., for any reason, please
contact your distributor/supplier for further information.
1
1
Quick Start Guide
System Map: Bottom View (Models C & D)
1 - 18 System Map: Bottom View (Models C & D)
Quick Start Guide
Figure 1 - 11 - Start Menu & Control Panel
Click here to toggle Category View
Windows 7 Start Menu & Control Panel
Most of the control panels, utilities and programs within Windows 7 are accessed from the Start menu. When
you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be
placed in the Start menu and/or the desktop. Right-click the Start menu icon , and th en select Properties to
customize the appearance of the Start menu.
In many instances throughout this manual you will see an instruction to open the Control Panel. The Control
Panel is accessed from the Start menu, and it allows you to configure the settings for most of the key features
in Windows (e.g. power, video, network, audio etc.). Windows 7 provides basic controls for many of the features,
however many new controls are added (or existing ones are enhanced) when you install the drivers. To see all
controls it may be necessary to toggle off Category View to view the control panel icons.
Windows 7 Start Menu & Control Panel 1 - 19
1
1
1
2
1
2
Right-Click Desktop
App
You can also right-click
the desktop and select
Screen resolution
to quickly access the
control panel.
3
3
Quick Start Guide
Video Features
You can switch display devices, and configure display options, from the Display control panel (in Appearances
and Personalization) in Windows 7. For more detailed video information see “Video Driver Controls” on
page C - 1. To access Display (Control Panel) and Screen Resolution in Windows:
1. Click Start and click Control Panel.
2. Click Display (Appearances and Personalization category) and click Adjust resolution.
3. Use the drop box to select the screen Resolution (Figure 1 - 12).
4. Click OK to confirm setting changes.
5. Click Advanced settings (Figure 1 - 12) to bring up the Advanced properties tabs.
Figure 1 - 12 - Screen Resolution
1 - 20 Video Features
Quick Start Guide
245
6
5
4
6
To access the Intel(R) HD Graphics Control Panel:
1. Click Advanced settings (Figure 1 - 12 on page 1 - 20) in the Display Settings control panel in Windows.
2. Click Graphics Properties (button) (Figure 1 - 13) in the Intel(R) HD Graphics Control Panel tab.
OR
3. Right-click the desktop and select Graphics Properties (Figure 1 - 13) from the menu.
OR
4. Click the icon (
OR
5. Access the Intel(R) HD Graphics Control Panel from the Windows control panel in Classic View.
Figure 1 - 13
) in the taskbar notification area and select
Graphics Properties
from the menu.
1
Figure 1 - 13 - Intel(R) HD Graphics Control Panel Access
Video Features 1 - 21
1
Quick Start Guide
Power Options
The Power Options (Hardware and Sound menu) control panel icon in Windows allows you to configure pow-
er management features for your computer. You can conserve power by means of power plans and configure
the options for the power button, sleep button, computer lid (when closed), display and sleep mode from the
left menu. Note that the Power saver plan may have an affect on computer performance.
Click to select one of the existing plans, or click Create a power plan in the left menu and select the options to
create a new plan. Click Change plan settings and click Change advanced power settings to access further configuration options. Pay attention to the instructions on battery care in “Battery Information” on page 3 - 11.
1 - 22 Power Options
Figure 1 - 14 - Power Options
Features & Components
Chapter 2: Features & Components
Overview
Read this chapter to learn more about the following main features and components
of the computer:
•Hard Disk Drive
• Optical (CD/DVD) Device
• Multi-In-1 Card Reader
• ExpressCard Slot
• Smart Card Reader
• Touchpad and Buttons/Mouse
• Audio Features
2
Overview 2 - 1
Features & Components
Bottom Cover
Removal Warning
Do not remove any cover(s) and /or screw(s) for
the purposes of device
upgrade as this may violate the terms of your
warranty.
If you need to replace/
remove the hard disk for
any reason, please contact your distributor/supplier for further
information.
2
Hard Disk Drive
The hard disk drive is used to store your data in the computer. The hard disk can be
taken out to accommodate other serial (SATA) hard disk drives (see “Storage” on
page D - 3 for specification information), however you will need to contact your dis-
tributor/supplier to do this in order to avoid violating the terms of your warranty.
2 - 2 Hard Disk Drive
Features & Components
Sound Volume
Adjustment
How high the sound volume can be set depends
on the setting of the volume control within Win-
dows. Click the Volume
icon on the taskbar to
check the setting.
Figure 2 - 1
Optical Device
123
1
2
3
Optical (CD/DVD) Device
There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual device will depend on the module you purchased (see “Storage” on page D - 3). The
optical device is usually labeled “Drive D:” and may be used as a boot device if
properly set in the BIOS (see “Boot Menu” on page 5 - 16).
Loading Discs
To insert a CD/DVD, press the open button and carefully place a CD/DVD onto
the disc tray with label-side facing up (use just enough force for the disc to click onto
the tray’s spindle). Gently push the CD/DVD tray in until its lock “clicks” and you
are ready to start. The busy indicator will light up while data is being accessed,
or while an audio/video CD, or DVD, is playing. If power is unexpectedly interrupted, insert an object such as a straightened paper clip into the emergency eject hole
to open the tray.
2
Optical (CD/DVD) Device 2 - 3
Features & Components
CD Emergency Eject
If you need to manually
eject a CD (e.g. due to
an unexpected power
interruption) you may
push the end of a
straightened paper clip
into the emergency eject
hole. However please
do NOT use a sharpened pencil or similar
object that may break
and become lodged in
the hole.
Disk Eject Warning
Don’t try to remove a
CD/DVD while the system is accessing it. This
may cause the system
to “crash”.
2
2 - 4 Optical (CD/DVD) Device
Handling CDs or DVDs
Proper handling of your CDs/DVDs will prevent them from being damaged. Please
follow the advice below to make sure that the data stored on your CDs/DVDs can be
accessed.
Note the following:
• Hold the CD or DVD by the edges; do not touch the surface of the disc.
• Use a clean, soft, dry cloth to remove dust or fingerprints.
• Do not write on the surface with a pen.
• Do not attach paper or other materials to the surface of the disc.
• Do not store or place the CD or DVD in high-temperature areas.
• Do not use benzene, thinner, or other cleaners to clean the CD or DVD.
• Do not bend the CD or DVD.
• Do not drop or subject the CD or DVD to shock.
Features & Components
DVD Region Note
DVD region detection is
device dependent, not
OS-dependent. You can
select your module’s region code 5 times. The
fifth selection is permanent. This cannot be altered even if you change
your operating system
or you use the module in
another computer.
Figure 2 - 2
DVD Region Codes
• Region 1 - USA & Canada
• Region 2 - Western Europe, Japan,
South Africa, Middle East & Egypt
• Region 3 - South-East Asia, T aiwan,
South Korea, The Philippines, Indonesia, Hong Kong
• Region 4 - South & Central Amer-
ica, Mexico, Australia, New Zealand
• Region 5 - N Korea, Russia, Eastern
Europe, India & Most of Africa
• Region 6 - China
DVD Regional Codes
To change the DVD regional codes:
1. Go to the Control Panel
2. Double-click Device Manager (Hardware and Sound), then click the + next to
DVD/CD-ROM drives.
3. Double-click on the DVD-ROM device to bring up the Properties dialog box, and
select the DVD Region (tab) to bring up the control p anel to allow you to adjust the
regional code.
2
Optical (CD/DVD) Device 2 - 5
Features & Components
Figure 2 - 3
Front View
1. Card Reader
• MMC (MultiMedia Card) / RS MMC
• SD (Secure Digital) / Mini SD / SDHC / SDXC
• MS (Memory Stick) / MS Pro / MS Duo
1
2
Multi-In-1 Card Reader
The card reader allows you to use some of the latest digital storage cards. Push the
card into the slot and it will appear as a removable device, and can be accessed in
the same way as your hard disk (s). Make sure you install the card reader driver (see
“CardReader” on page 4 - 6.
Note: Some of these cards require PC adapters that are usually supplied with the
cards.
2 - 6 Multi-In-1 Card Reader
Features & Components
Figure 2 - 4
Left View
1. ExpressCard
Slot
1
ExpressCard Slot
The computer is equipped with an ExpressCard/34 slot to read Express Card/34
formats. ExpressCards are the successors to PCMCIA (PC Cards). Make sure you
install the Card Reader driver
Inserting and Removing ExpressCards
• Align the ExpressCard with the slot and push it in until it locks into place (as
pictured in the generic figure below).
• To remove an ExpressCard, simply press the card to eject it.
(see
“CardReader” on page 4 - 6
2
).
ExpressCard Slot 2 - 7
Features & Components
Smart Card Driver
Smart Cards usually require a driver for any
proprietary smart card
system. This driver will
usually be supplied by
your system administrator as applicable to your
particular Smart Card
system.
Card Orientation
Note that when inserting
Smart Cards, the card’s
readable side (with the
gold-colored contacts)
should face upwards as
illustrated on the left.
Figure 2 - 5
Left View
1. Smart Card
Reader
1
2
Smart Card Reader
(For Models A & B Only)
The Smart Card reader reads pocket-sized Smart Cards, chip cards, or integrated circuit cards (ICC) with embedded integrated circuits. Smart Cards can be used for security identification, authentication, data storage and application processing within
large organizations.
A Smart Card uses a gold contact that connects to a tiny microprocessor and memory
chips embedded inside the card. The card is usually used to store authentication data
e.g. a user name and password. The computer’s Smart Card reader communicates
through the gold contact on the card to the microprocessor, and if the data on th e card
matches that stored in the computer, then access is granted. A Smart Card can also
be used to securely encrypt and decrypt individual files on the computer.
2 - 8 Smart Card Reader
Features & Components
Touchpad Scrolling
This computer model series may feature different
Touchpad versions.
These Touchpads may
differ in their vertical
scrolling function in most
scrollable windows.
Some Touchpads require
sliding the finger up and
down on the right of the
Touchpad to scroll the
window. Other versions
require tapping/holding
down the finger at the top
right or bottom right of the
Touchpad to scroll the
window.
Figure 2 - 6
Mouse Properties
Touchpad and Buttons/Mouse
The Touchpad is an alternative to the mouse; however, you can also add a mouse to
your computer through one of the USB ports. The Touchpad buttons function in
much the same way as a two-button mouse.
Once you have installed the Touchpad driver (see “Touchpad” on page 4 - 7) you
can configure the functions by double-clicking the Touchpad driver icon in the
notification area. You may then configure the Touchpad tapping, buttons, scrolling
(see sidebar), pointer motion and sensitivity options to your preferences.
2
Touchpad and Buttons/Mouse 2 - 9
Features & Components
Show Video
You can get a clearer
view of the gestures involved by clicking the
Show Video option for
each gesture item.
Select the gesture (Pinch
Zoom, Rotating, Three
Fingers Down and
Three Finger Flick) in the
Device Settings > Settings left tree menu
and click the Show Video
button to see the demonstration video.
For more details on any of
the gestures see the help
in the lower part of the
right menu window.
Figure 2 - 7
Mouse Properties -
Device Settings
2
Gestures and Device Settings
The Synaptics Gestures Suite application allows you to use a specific gesture (action) on the surface of the Touchpad to perform specific actions to manipulate documents, objects and applications.
You can configure the settings from the Device Settings tab in Mouse Properties:
1. Click
2. Click Mouse (Hardware and Sound).
3. Click Device Settings (tab) and click Settings.
4. Use the menu tree on the lef t to access the user configurable settings.
Start
, and click
Control Panel
(or point to
Settings
and click
Control Panel
).
2 - 10 Touchpad and Buttons/Mouse
Features & Components
Figure 2 - 8
Mouse Properties
(Disable Touchpad)
Disabling the Touchpad
If you need to disable the Touchpad for any reason (e.g. you may find that when using the computer’s internal keyboard you accidentally trigger the Touchpad when
resting your wrists or palms on it) you can do so by using Fn + F1 key combination.
You can also set the system to automatically disable the internal Touchpad when an
external USB point device (e.g. a USB mouse) is attached.
1. Go to the Mouse Properties control panel.
2. Click to select Device Settings (tab).
3. Click to place a check in the “Disable internal pointing device when external
USB pointing device is attached” check box.
4. Click OK to save the setting.
2
Touchpad and Buttons/Mouse 2 - 11
Features & Components
Figure 2 - 9
Scrolling Gesture
Mouse Driver
If you are using an external mouse your operating system may be
able to auto-configure
your mouse during its
installation or only enable its basic functions.
Be sure to check the
device’s user documentation for details.
Figure 2 - 10
Zooming Gesture
2
Scrolling
The Two-Finger scrolling feature works in most scrollable windows an d allows you
to scroll horizontally and vertically. Place two fingers, slightly separated, on the
Touchpad surface and slide both fingers in the direction required (in a straight continuous motion).
2 - 12 Touchpad and Buttons/Mouse
Zooming
The Pinch Zoom gesture can be used to perform the same function as a scroll wheel
in Windows applications that support CTRL + scroll wheel zoom functionality.
Place two fingers on the Touchpad (for best results use the tips of the fingers) and
slide them apart to zoom in, or closer together to zoom out.
Rotating
Figure 2 - 11
Rotating Gesture
Figure 2 - 12
Flick/Press
Gesture
Use the Pivot Rotate gesture to rotate objects (e.g. photos) in 90 degree increments.
Place a finger down on the left “target” zone and keep it stationary. Place another
finger near the middle of the Touchpad and slide it in a circular motion around the
stationary finger (clockwise or counterclockwise) to rotate the object.
Three Finger-Flick/Three Fingers Down (Press)
The Three Finger-Flick gesture may be used to enhance navigation with a variety of
applications such as browsing the Internet or scrolling through a photo viewer. The
Three Fingers Down gesture may be used to launch user-selectable applications.
Features & Components
2
Touchpad and Buttons/Mouse 2 - 13
Features & Components
Sound Volume
Adjustment
The sound volume level
is set using the volume
control within Windows
(and the volume function keys on the computer). Click the volume
icon in the taskbar to
check the setting.
Figure 2 - 13
VIA HD Audio Deck
Click Expert Mode to access the Advanced menus
2
Audio Features
You can configure the audio options on your computer from the Sound control
panel in Windows, from the HD VDeck icon on the desktop or VIA HD Audio
Deck control panel .
The volume may also be adjusted by means of the Fn + F5/F6 key combination.
2 - 14 Audio Features
Expert Mode will allow you to access more advanced configuration menus for
Syncing Left & Right
Volume
Balance
If you wish to adjust the left
and right channel volume
levels separately, you will
need to adjust this from the
VIA HD Audio Deck in Expert Mode.
Click Speaker in VIA HD
Audio Deck (in Expert
Mode) and click the Sync
Left and Right volume
button (see left). You can
then adjust the volume sliders independently (this setting also controls the
Balance setting in the Windows Sound control panel).
Figure 2 - 14
VIA HD Audio Deck
(Expert Mode)
Note that to adjust the Left & Right volume ba lance independently click th e Sync
Left and Right Volume icon (it should be faded) and adjust the slider as required.
Speaker, Microphone and Stereo Mix.
Features & Components
2
Audio Features 2 - 15
Features & Components
2
2-16
Chapter 3: Power Management
OS Note
Power management
functions will vary slightly depending on your
operating system. For
more information it is
best to refer to the user’s
manual of your operating system.
(Note: All pictures used
on the following pages
are from the Windows 7
OS.)
Power Management
Overview
To conserve power, especially when using the battery, your computer power management conserves power by controlling individual components of the computer
(the monitor and hard disk drive) or the whole system.
This chapter covers:
• The Power Sources
• Turning On the Computer
• Power Plans
• Power-Saving States
• Configuring the Power Buttons
• Power Conservation Modes
• Battery Information
The computer uses enhanced power saving techniques to give the operating system
(OS) direct control over the power and thermal states of devices and processors. For
example, this enables the OS to set devices into low-power states based on user settings and information from applications.
3
Overview 3 - 1
Power Management
The Power Sources
The computer can be powered by either an AC/DC adapter or a battery pack.
3
AC/DC Adapter
Use only the AC/DC adapter that comes with your computer. The wrong type of AC/
DC adapter will damage the computer and its components.
1. Attach th e AC/DC adapter to the DC-In jack on the left of the computer.
2. Connect the AC power cord to the AC/DC adapter and then plug the AC power
cord into an outlet (make sure you use the adapter when first setting up the
computer, as to safeguard the computer during shipping the battery will be locked
to not power the system until first connected to the AC/DC adapter).
3. Raise the lid/LCD to a comfortable viewing angle.
4. Press the power button on the top left of the computer for about 2 - 3 seconds to
turn the computer “on” (note that the power LED on the front of the computer will
turn from orange to green when the computer powers on).
Battery
The battery allows you to use your computer while you are on the road or when an
electrical outlet is unavailable. Battery life varies depending on the applications and
the configuration you're using. To increase battery life, let the battery discharge
completely before recharging (see “How do I completely discharge the battery?”
on page 3 - 15). For more information on the battery, please refer to “Battery Infor-
mation” on page 3 - 11.
3 - 2 The Power Sources
Turning On the Computer
Forced Off
If the system “hangs”,
and the Ctrl + Alt + Del
key combination doesn’t
work, press the power
button for 4 seconds, or
longer, to force the system to turn itself off.
Power Button as
Stand by or
Hibernate Button
You can use the OS’s
Power Options control
panel to set the power
button to send the system into Stand by or Hibernate mode (see your
OS’s documentation, or
“Configuring the Power Buttons” on page 3
- 8 for details).
Shut Down
Note that you should always shut your computer down by choosing the Shut Down command from the bottom right of the Start menu in Windows. This will help prevent hard disk
or system problems.
Now you are ready to begin using your computer. To turn it on simply press the power button on the front panel.
When the computer is on, you can use the power button as a Stand by/Hibernate/
Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and
holding the power button for longer than this will shut the computer down). Use
Power Options in the Windows control panel to configure this feature.
Power Management
3
Turning On the Computer 3 - 3
Power Management
Resuming
Operation
See Table 3 - 1, on
page 3 - 9 for informa-
tion on how to resume
from a power-saving
state.
Password
It is recommended that
you enable a password
on system resume in order to protect your data.
Figure 3 - 1
Power Plan
Advanced Settings
(Win 7)
Power Plans
The computer can be configured to conserve power by means of power plans. You
3
can use (or modify) an existing power plan, or create a new one.
3 - 4 Power Plans
The settings may be adjusted to set the display to turn off after a specified time, and
to send the computer into Sleep after a period of inactivity.
Click Change plan settings and then click Change advanced power settings to access further configuration options in Advanced Settings.
Each Windows power plan will also adjust the processor performance of your ma-
Figure 3 - 2
Power Plans (Win 7)
Click to Show/Hide
additional
power plans
chine in order to save power. This is worth bearing in mind if you are experiencing
any reduced performance (especially under DC/battery power).
Choose High performance (you may need to click Show additional plans to view
the High performance plan) for maximum performance when the computer is powered from an AC power source. Choose the Power saver (bear in mind that this
scheme may slow down the overall performance of the computer in order to save
power) for maximum power saving when the computer is battery (DC power) powered.
Power Management
3
Power Plans3-5
Power Management
Power-Saving States
You can use power-saving states to stop the computer’s operation and restart where
3
you left off. Win 7 uses the Sleep, Hibernate and Shut Down power-saving states.
Sleep
In Sleep all of your work, settings and preferences are saved to memory before the
system sleeps. When you are not using your computer for a certain length of time,
which you specify in the operating system, it will enter Sleep to save power.
The PC wakes from Sleep within seconds and will return you to where you last left
off (what was on your desktop) without reopening the application(s) and file(s) you
last used.
If your mobile PC in Sleep is running on battery power the system will use only a
minimum amount of power. After an extended period the system will save all the
information to the hard disk and shut the computer down before the battery becomes
depleted.
3 - 6 Power-Saving States
Hibernate
Figure 3 - 3
Start Menu Power
Hibernate uses the least amount of power of all the power-saving states and saves
all of your information on a part of the hard disk before it turns the system off. If a
power failure occurs the system can restore your work from the hard disk; if a power
failure occurs when work is saved only to memory, then the work will be lost. Hi-
bernate will also return you to where you last left off within seconds. You should
put your mobile PC into Hibernate if you will not use the computer for a period of
time, and will not have the chance to charge the battery.
Shut down
You should Shut down the computer if you plan to install new hardware (don’t forget to remove the battery and follow all the safety instructions in Chapter 6), plan
to be away from the computer for several days, or you do not need it to wake up and
run a scheduled task. Returning to full operation from Shut down takes longer than
from Sleep or Hibernate.
Power Management
3
Power-Saving States 3 - 7
Power Management
Password
Protection
It is recommended that
you enable a password
on wake up in order to
protect your data.
However you can disable this setting from the
Power Options menu
by clicking Require a
password on wakeup
in the left menu, and selecting the options (click
Change settings that
are currently unavailable).
Figure 3 - 4
Power Options
Define Power
Buttons
3
Configuring the Power Buttons
The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the
computer in to a power-saving state. Click Choose what the power buttons do on
the left menu in Power Options to bring up the menu.
3 - 8 Configuring the Power Buttons
Resuming Operation
Closing the Lid
If you have chosen to
send the computer to
Sleep when the lid is
closed, raising the lid
will wake the system up.
Table 3 - 1
Resuming
Operation
Power Button
When the computer is on, you can use the power button as a Sleep/Hibernate/Shut Down
hot key button when it is pressed for less than 4 seconds (pressing and holding the power
button for longer than this will force the computer to shut down).
You can resume operation from power-saving states by pressing the power button,
or in some cases pressing the sleep button (Fn + F4 key combo).
Power Status
Power Off Off Press the Power Button
Sleep Blinking Green
Hibernate
Display Turned Off Green Press a Key or Move the Mouse/Touchpad
Icon Color
Off (battery)
Orange (AC/DC adapter)
Power Management
3
To Resume
Press the Power Button
Press the Sleep Button (Fn + F4 Key Combo)
Press the Power Button
Configuring the Power Buttons 3 - 9
Power Management
Power Conservation
Modes
The Energy Star setting
will result in maximum
power saving, but with
the possible loss of
some performance.
Setting the mode to Bal-
ance will give power
saving matched with
performance.
Performance will give
optimum computer performance but with less
power conservation.
Note that the Energy
Star setting will put the
display into sleep after
no more than 15 minutes of user inactivity.
Figure 3 - 5
Control Center
3
Power Conservation Modes
This system supports Energy Star power management features that place computers (CPU, hard drive, etc.) into a low-power sleep modes after a designated period
of inactivity. Adjust Power Conservation Modes from the Control Center:
1. Press the Fn + Esc key combination to toggle the Control Center on/off.
2. Click either the Performance, Balanced or Energy Star button.
3 - 10 Configuring the Power Buttons
Battery Information
Low Battery
Warning
When the battery is critically low, immediately
connect the AC/DC
adapter to the computer
or save your work, otherwise, the unsaved
data will be lost when
the power is depleted.
Figure 3 - 6
Battery Icon
(Notification Area) &
Battery Advanced
Settings
Follow these simple guidelines to get the best use out of your battery.
Battery Power
Your computer’s battery power is dependent upon many factors, including the programs you are running, and peripheral devices attached. You can set actions to be
taken (e.g. Shut down, Hibernate etc.), and set critical and low battery levels from
power plan Change plan settings > Change advanced power settings (see Figure
3 - 1 on page 3 - 4).
Click the battery icon in the notification area to see the current battery level and
charge status.
Power Management
3
Battery Information 3 - 11
Power Management
Windows Mobility
Center
The Windows Mobility
Center control panel
provides an easy point
of access for information
on battery status, power
plans used and wireless
device status etc.
Figure 3 - 7
Windows Mobility
Center
3
Conserving Battery Power
•Use a power plan that conserves power (e.g Power saver), however note that
this may have an affect on computer performance.
• Lower the brightness level of the LCD display. The system will decrease LCD
brightness slightly to save power when it is not powered by the AC/DC adapter.
• Reduce the amount of time before the display is turned off.
• Close wireless, Bluetooth, modem or co mmunication applications when they are
not being used.
• Disconnect/remove any unnecessary external devices e.g. USB devices.
3 - 12 Battery Information
Battery Life
Battery life may be shortened through improper maintenance. To optimize the life
and improve its performance, fully discharge and recharge the battery at least
once every 30 days.
New Battery
Always completely discharge, then fully charge, a new battery (see “Battery FAQ”
on page 3 - 15 for instructions on how to do this).
Recharging the Battery with the AC/DC Adapter
The battery pack automatically recharges when the AC/DC adapter is attached and
plugged into an electrical outlet. If the computer is powered on, and in use, it will
take several hours to fully recharge the battery. When the computer is turned off but
plugged into an electrical outlet, battery charge time is less. (Refer to “LED Indica-
tors” on page 1 - 8 for information on the battery charge status, and to “Battery Information” on page 3 - 11 for more information on how to maintain and properly
recharge the battery pack.)
Power Management
3
Battery Information 3 - 13
Power Management
Damaged Battery Warning
Should you notice any physical defects (e.g. the battery is bent ou t of shape after being
dropped), or any unusual smells emanating from the notebook battery, shut your computer
down immediately and contact your distributor/supplier. If the battery has been dropped we
do not recommend using it any further, as even if the comp uter continues to work with a
damaged battery in place, it may cause circuit damage, which may possibly result in fire. It
is recommended that you replace your computer battery every two years.
Caution
Danger of explosion if
battery is incorrectly replaced.
Replace only with the
same or equivalent type
recommended by the
manufacturer. Discard
used battery according
to the manufacturer’s instructions.
Proper handling of the Battery Pack
• DO NOT disassemble the battery pack under any circumstances.
• DO NOT expose the battery to fire or high temperatures, it may explode.
3
• DO NOT connect the metal terminals (+, -) to each other.
3 - 14 Battery Information
Battery FAQ
Figure 3 - 8
Power Plan Create
How do I completely discharge the battery?
Use the computer with battery power until it shuts down due to a low battery. Don’t
turn off the computer even if a message indicates the battery is critically low, just let
the computer use up all of the battery power and shut down on its own.
1. Save and close all files and applications.
2. Create a power plan for discharging the battery and set all the options to Never.
Power Management
3
Battery Information 3 - 15
Power Management
Figure 3 - 9
Change Plan
Settings / Change
Advanced Power
Settings
3
3. Click Change plan settings (after creating it) and click Change plan settings >
Change advanced power settings.
3 - 16 Battery Information
4. Scroll down to Battery and click + to expand the ba ttery options.
Figure 3 - 10
Power Options
Advanced Settings -
Battery
5. Choose the options below (click Yes if a warning appears):
• Low battery levels = 0%
• Critical battery Levels = 1%
• Low battery action = Do Nothing
• Critical battery action (On battery) = Shut Down
• Critical battery action (Plugged in) = Do Nothing
Power Management
3
Battery Information 3 - 17
Power Management
How do I fully charge the battery?
When charging the battery, don’t stop until the LED charging indicator light changes
from orange to green.
3
How do I maintain the battery?
Completely discharge and charge the battery at least once every 30 days or after
about 20 partial discharges.
3 - 18 Battery Information
Chapter 4: Drivers & Utilities
Driver Installation &
Power
When installing drivers make sure your
computer is powered
by the AC/DC adapter
connected to a working power source.
Some drivers draw a
significant amount of
power during the installation procedure, and if
the remaining battery
capacity is not adequate
this may cause the system to shut down and
cause system problems
(note that there is no
safety issue involved
here, and the battery will
be rechargeable within 1
minute).
This chapter deals with installing the drivers and utilities essential to the operation or
improvement of some of the computer’s subsystems. The system takes advantage of
some newer hardware components for which the latest versions of most available operating systems haven’t built in drivers and utilities. Thus, some of the system components won’t be auto-configured with an appropriate driver or utility during
operating system installation. Instead, you need to manually install some system-required drivers and utilities.
What to Install
The Device Drivers & Utilities + Use r’s Manual disc contains the drivers and util-
ities necessary for the proper operation of the computer. Table 4 - 1, on page 4 - 3
lists what you need to install and it is very important that the drivers are installed
in the order indicated.
Note that the information included on the following pages is for Windows 7 only.
Module Driver Installation
The procedures for installing drivers for the PC Camera, Wireless LAN, Fingerprint, Bluetooth & WLAN Combo, Security and Intel Technology modules are
provided in “Modules & Options” on page 6 - 1.
Drivers & Utilities
4
What to Install 4 - 1
Drivers & Utilities
Driver Installation
Insert the Device Drivers & Utilities + User’s Manual
disc and click Install Drivers (button), or Option Driv-
ers (button) to access the Optional driver menu.
4
Figure 4 - 1 - Drivers Installer Screen 1
1. Check the driver installation order from Table 4 - 1,
on page 4 - 3 (the drivers must be installed in
this order) which is the same as that listed in the
Drivers Installer menu below.
2. Click to select the driver you wish to install, (you
should note down the drivers as you install them).
3. Follow the instructions for each individual driver
installation procedure as listed on the following
pages.
Note: If you need to reinstall any driver, you should uninstall the
driver first.
4 - 2 Driver Installation
Figure 4 - 2 - Drivers Installer Screen 2
Drivers & Utilities
Win 7 (64 bit) Driver Page # Win 7 - Optional Items Page #
Chipset Page 4 - 6 PC Camera Module Page 6 - 3
Video (VGA) Page 4 - 6 Wireless LAN Module Page 6 - 11
LAN Page 4 - 6 Fingerprint Reader Module Page 6 - 18
CardReader Page 4 - 6 Bluetooth & WLAN Combo Module Page 6 - 30
Touchpad Page 4 - 7 Trusted Platform Module Page 6 - 36
Hot Key Page 4 - 7 Intel Rapid Storage Technology Page 6 - 50
USB 3.0 Page 4 - 7 Intel® Smart Connect Technology Page 6 - 51
MEI Driver Page 4 - 7 Intel® Wireless Display Application Page 6 - 56
Audio Page 4 - 7 Free Fall Data Protection Page 6 - 61
All drivers provided are for the
Windows 7 (64-bit with Service
Intel® vPro™ Technology Page 6 - 65
Intel® Management and Security Status Page 6 - 67
Pack 1) operating system.
Intel® Small Business Advantage Page 6 - 71
Table 4 - 1 - Driver Installation
Note that you need to install both the WLAN & Bluetooth drivers for Intel and 3rd party WLAN & Bluetooth
Combo modules.
Driver Installation 4 - 3
4
Drivers & Utilities
Manual Driver Installation
Click Browse CD/DVD (button) in the Drivers Installer application and browse to the executable file in the appropriate driver folder.
Windows Update
4
After installing all the drivers make sure you enable Windows Update in order to get all the latest security updates etc. (all updates will include the latest hotfixes from Microsoft). See “Windows Update” on page 4 - 8 for
instructions.
4 - 4 Driver Installation
Drivers & Utilities
Updating/Reinstalling Individual Drivers
If you wish to update/reinstall individual drivers it
may be necessary to uninstall the original driver.To do
this go to the Control Panel in the Windows OS and
double-click the Programs and Features icon (Pro-
grams > Uninstall a program). Click to select the
driver (if it is not listed see below) and click Uninstall,
and then follow the on screen prompts (it may be necessary to restart the computer). Reinstall the driver as
outlined in this chapter.
If the driver is not listed in the Programs and Fea-
tures menu:
1. Click Start, and click Control Panel (or point to
Settings and click Control Panel).
2. Double-click Device Manager (Hardware and
Sound > Device Manager).
3. Double-click the device you wish to update/reinstall
the driver for (you may need to click “+” to expand
the selection).
4. Click Driver (tab) and click the Update Driver or
Uninstall button and follow the on screen prompts.
User Account Control
If a User Account Control prompt appears as part of
the driver installation procedure, click Continue/Al-
low, and follow the installation procedure as directed.
Windows Security Message
If you receive a Windows security message as part of
the driver installation process. Just click “Install this
driver software anyway” or Install to continue the in-
stallation procedure.
You will receive this message in cases where the driver has been released after the version of Windows you
are currently using. All the drivers provided will have
already received certification for Windows.
New Hardware Found
If you see the message “New Hardware Found” during the installation procedure (other than when out-
lined in the driver install procedure), click Cancel
to close the window, and follow the installation procedure.
4
Driver Installation 4 - 5
Drivers & Utilities
Driver Installation General Guidelines
The driver installation procedure outlined in this Chapter (and in Chapter 6 Options & Modules), are accurate at the time of going to press.
Drivers are always subject to upgrade and revision so
the exact procedure for certain drivers may differ slightly. As a general guide follow the default on screen instructions for each driver (e.g. Next > Next > Finish)
unless you are an advanced user. In many cases a restart is required to install the driver.
Driver Installation Procedure
Insert the Device Drivers & Utilities + User’s Manual
disc and click Install Drivers (button), or Option Driv-
ers (button) to access the Optional driver menu.
4
Chipset
1. Click 1.Install Chipset Driver > Yes.
2. Click Next > Yes > Next > Next.
3. Click Finish to restart the computer.
Video (VGA)
1. Click 2.Install VGA Driver > Yes.
2. Click Next > Yes > Next > Next.
3. Click Finish to restart the computer.
LAN
1. Click 3.Install LAN Driver > Yes.
2. Click Install Drivers and Software > Next.
3. Click the button to accept the license and click
Next.
4. Click Next > Install.
5. Click Finish.
CardReader
1. Click 4.Install Cardreader Driver > Yes.
2. Click Finish.
4 - 6 Driver Installation
Drivers & Utilities
Touchpad
1. Click 5.Install Touchpad Driver > Yes.
2. Click Next.
3. Click the button to accept the license agreement
and click Next.
4. Click Finish > Restart Now to restart the com-
puter.
Hot Key
1. Click 6.Install Hotkey AP > Yes.
2. Click Next.
3. Click Finish to restart the computer.
USB 3.0
1. Click 7.Install USB 3.0 Driver > Yes.
2. Click Next > Yes > Next > Next.
3. Click Finish to restart the computer .
MEI Driver
1. Click 8.Install MEI Driver > Yes.
2. Click Next > Yes > Next.
3. Click Finish to restart the computer.
4
Audio
1. Click 9.Install Audio Driver > Yes.
2. Click Next.
3. Click the button to agree to the license agree-
ment and click Next.
4. Click Next > Next > Next.
5. Click Finish to restart the computer.
Note that after installing the audio driver the system
will not return to the Drivers Installer screen. To in-
stall any of the optional drivers listed overleaf, eject
the Device Drivers & Utilities + User’s Manual disc
and then reinsert it (or double-click the disc icon in My
Computer), and click Option Drivers (button) to ac-
cess the optional driver menu.
Driver Installation 4 - 7
Drivers & Utilities
Windows Update
After installing all the drivers make sure you enable Windows Update in order to get all the latest security up-
dates etc. (all updates will include the latest hotfixes
from Microsoft).
To enable Windows Update make sure you are con-
nected to the internet:
1. Click Start, and click Control Panel (or point to
Settings and click Control Panel).
2. Click Windows Update (System and Security/
Security).
3. Click Check for updates (button).
4. The computer will now check for updates (you
need to be connected to the internet).
5. Click Install now (button) to begin checking for the
updates.
6. Click Install updates (button) to install the
updates.
It is recommended you now also install the Intel Rapid Storage Technology driver (see “Intel Rapid Stor-
age Technology” on page 6 - 50 - required for AHCI
mode hard disks).
4
4 - 8 Driver Installation
Windows Experience Index
After Video (VGA) driver has been installed, and the
system restarted, the OS will automatically run the
"Winsat.exe" to rate the performance. If you have restarted the system during this time then follow the instructions below to update the information.
After the drivers are installed follow this procedure to
ensure an accurate rating from the Windows Experi-
ence Index (make sure the AC/DC adapter is plugged
in):
1. Click Start, and click Control Panel.
2. Click Performance Information and Tools
(System and Security > System > Check the
Windows Experience Index).
3. Click “Rate this computer/Refresh Now/Re-
run the assessment”.
4. The computer will take a few minutes to assess
the system performance.
5. Close the control panel.
Drivers & Utilities
Optional Drivers
See the pages indicated in Table 4 - 1, on page 4 - 3 for the driver installation procedures for any modules included in your purchase option.
Figure 4 - 3 - Option Drivers
4
Note that you need to install both the WLAN & Bluetooth drivers for Intel and 3rd party WLAN & Bluetooth
Combo modules.
Optional Drivers 4 - 9
Drivers & Utilities
4
4-10
Chapter 5: BIOS Utilities
BIOS Screens
Note that the BIOS
screens pictured on
these pages are intended for guidance in setting up your system’s
BIOS.
BIOS versions are subject to constant change
and revision, therefore
your computer’s actual
screens may appear
slightly different from
those pictured on these
pages.
Overview
This chapter gives a brief introduction to the computer’s built-in software:
If your computer has never been set up, or you are making impo rtant changes to the
system (e.g. hard disk setup), then you should review this chapter first and note the
original settings found in Setup. Even if you are a beginner, keep a record of the settings you find and any changes you make. This information could be useful if your
system ever needs servicing.
There is one general rule: Don’t make any changes unless you are sure of what you
are doing. Many of the settings are required by the system, and changing them could
cause it to become unstable or worse. If you have any doubts, consult your service
representative.
BIOS Utilities
5
Overview 5 - 1
BIOS Utilities
BIOS Settings
Warning
Incorrect settings can
cause your system to
malfunction. To correct
mistakes, return to Set-
up and restore the Optimized Defaults with
<F3>.
UEFI Boot & POST
When UEFI Boot is enabled, then the prompts
to press F2 or F7 will
not appear. However
you can still press F2 to
enter the setup, or F7 to
choose the preferred
boot device, if you press
the key immediately the
system boots up.
The Setup Utility
Each time you turn on the computer the system takes a few seconds to conduct a
POST, including a quick test of the on-board RAM (memory).
5
5 - 2 The Setup Utility
As the POST proceeds, the computer will tell you if there is anything wrong. If there
is a problem that prevents the system from booting, it will display a system summary
and prompt you to run Setup.
If there are no problems, the Setup prompt will disappear and the system will load
the operating system. Once that starts, you can’t get into Setup without rebooting.
The Aptio Setup Utility tells the syst em how to configure itself and manage basic
features and subsystems (e.g. port configuration).
To enter Setup, turn on the computer and press F2 (give the system a few seconds
to enter Setup). If the Boot Logo is enabled the F2 on screen will be highlighted to
illustrate that the system is processing the request during the POST (or press F7 for
boot options). If you get a “Keyboard Error”, (usually because you pressed F2 too
quickly) just press F2 again.
If the computer is already on, reboot using the Ctrl + Alt + Delete combination and
then hold down F2 when prompted. The Setup main menu will appear.
To see the boot options press F7 and choose your preferred boot device.
Failing the POST
Errors can be detected during the POST. There are two categories, “fatal” and “nonfatal”.
Fatal Errors
These stop the boot process and usually indicate there is something seriously wrong
with your system. Take the computer to your service representative or authorized
distributor/supplier as soon as possible.
Non-Fatal Errors
This kind of error still allows you to boot. You will get a message identifying the
problem (make a note of this message!) and you can then press F7 (the F7 on screen
will be highlighted to illustrate that the system is processing the request) for boot
options.
Press F2 (give the system a few seconds to enter Setup; the F2 on screen will be
highlighted to illustrate that the system is processing the request) to run the Setup
program and try to correct the problem. If you still get an error message after you
change the setting, or if the “cure” seems even worse, call for help.
BIOS Utilities
5
The Setup Utility 5 - 3
BIOS Utilities
Setup Menus
The Setup menus
shown in this section are
for reference only. Your
computer’s menus will
indicate the configuration appropriate for your
model and options.
Figure 5 - 1
Navigation Menu
5
Setup Screens
The following pages contain additional advice on portions of the Setup. Along the
top of the screen is a menu bar with menu headings. When you select a heading, a
new screen appears. Scroll through the features listed on each screen to make changes to Setup.
Instructions on how to navigate each screen are in the box at the bottom right side of
the screen.
If these tools are confusing, press F1 to call up a General Help screen, and then use
the arrow keys to scroll up or down the page.
5 - 4 The Setup Utility
The Item Specific Help on the upper right side of each screen explains the highlighted item and has useful messages about its options.
If you see an arrow next to an item, press Enter to go to a sub-menu on that subject. The sub-menu screen that appears has a similar layout, but the Enter key may
execute a command.
Loading...
