Clevo W880CU User guide

V10.3.00

Preface

Notice

The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication. This publication and any accompanying software may not, in whole or in part, be reproduced, translated, transmitted or reduced to any machine readable form without prior consent from the vendor, manufacturer or creators of this publication, except for copies kept by the user for backup purposes. Brand and product names mentioned in this publication may or may not be copyrights and/or registered trademarks of their respective companies. They are mentioned for identification purposes only and are not intended as an endorsement of that product or its manufacturer. ©July 2010

Trademarks

Intel and Intel Core are trademarks/registered trademarks of Intel Corporation.

Preface

R&TTE Directive

This device is in compliance with the essential requirements and other relevant provisions of the R&TTE Directive 1999/5/EC.

This device will be sold in the following EEA countries: Austria, Italy, Belgium, Liechtenstein, Denmark, Luxembourg, Finland, Netherlands, France, Norway, Germany, Portugal, Greece, Spain, Iceland, Sweden, Ireland, United Kingdom, Cyprus, Czech Republic, Estonia, Hungary, Latvia, Lithuania, Malta, Slovakia, Poland, Slovenia.

CE Marking

This device has been tested to and conforms to the regulatory requirements of the European Union and has attained CE Marking. The CE Mark is a conformity marking consisting of the letters “CE”. The CE Mark applies to products regulated by certain European health, safety and environmental protection legislation. The CE Mark is obligatory for products it applies to: the manufacturer affixes the marking in order to be allowed to sell his product in the European market.

This product conforms to the essential requirements of the R&TTE directive 1999/5/EC in order to attain CE Marking. A notified body has determined that this device has properly demonstrated that the requirements of the directive have been met and has issued a favorable certificate of expert opinion. As such the device will bear the notified body number 0560 after the CE mark.

The CE Marking is not a quality mark. Foremost, it refers to the safety rather than to the quality of a product. Secondly, CE Marking is mandatory for the product it applies to, whereas most q uality marking s are vo lu ntary.

Preface

FCC Statement

(Federal Communications Commission)

You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Re orient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the service representative or an experienc ed radio/TV technician for help.

Operation is subject to the following two conditions:

1. This device may not cause interference. And

2. This device must accept any interference, including interfer ence that may cause undesired operation of the

device.

III

Preface



Warning

Use only shielded cables to connect I/O devices to this equipment. You are cautioned that changes or modifications not expressly approved by the manufacturer for compliance with the above standard s could void your authority to operate the equipment.

If your purchase option includes both Wireless LAN and 3.75G modules, then the appropriate antennas will be installed. Note that In order to comply with FCC RF exposure compliance requirements, the antenna must not be co-located or operate in conjunction with any other antenna or transmitter.

Important Notice - 3.75G/HSPA & Bluetooth/Wireless LAN Modules

In order to comply with FCC regulations you should NOT operate the 3.75G/HSPA module and the Bluetooth/Wireless LAN modules at the same time as this may disrupt radio frequency, and cause interference. When the 3.75G/HSPA module is powered on, make sure that the Bluetooth/Wireless LAN modules are powered off.

FCC RF Radiation Exposure Statement:

1. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

2. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This

equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.

Preface

IMPORTANT SAFETY INSTRUCTIONS

Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment:

1. Do not use this product near water, for example n ear a ba th tub, wash bowl, kitchen sink or laundry tu b, in a wet

basement or near a swimming pool.

2. Avoid using this equipment with a telephone line (other than a cordless type) during an electrical storm. There

may be a remote risk of electrical shock from lightning.

3. Do not use the telephone to report a gas leak in the vicinity of the leak.

4. Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may

explode. Check with local codes for possible special disposal instructions.

5. This product is intended to be supplied by a Listed Power Unit with an AC Input of 100 - 240V, 50 - 60Hz, DC

Output of 20V, 6A OR 19V, 9.47A minimum AC/DC Adapter.

CAUTION

Always disconnect all telephone lines from the wall outlet before servicing or disassembling this equipment.

TO REDUCE THE RISK OF FIRE, USE ONLY NO. 26 AWG OR LARGER, TELE-

COMMUNICATION LINE CORD

This Computer’s Optical Device is a Laser Class 1 Product

Preface

Instructions for Care and Operation

The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions:

1. Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged.

Do not expose the computer to any shock or vibration.

Do not place it on an unstable surface.

Do not place anything heavy on the computer.

2. Keep it dry, and don’t overheat it. Keep the computer and power supply away from any kind of heating ele-

ment. This is an electrical appliance. If water or any other liquid gets into it, the computer could be badly damaged.

Do not expose it to excessive heat or direct sunlight.

Do not leave it in a place where foreign matter or moisture may affect the system.

Don’t use or store the computer in a humid environment.

Do not place the computer on any surface that will block the Vents/Fan Intakes.

Preface

3. Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other

strong magnetic fields. These can hinder proper performance and damage your data.

4. Follow the proper workin g procedu res for t he computer. Shut the computer down properly and don’t forget

to save your work. Remember to periodically save your data as data may be lost if the battery is depleted.

Do not turn off the power until you properly shut down all programs.

Do not turn off any peripheral devices when the computer is on.

5. Take care when using peripheral devices.

Use only approved brands of peripherals.

Do not disassemble the computer by yourself.

Unplug the power cord befor e attaching peripheral devices.

Perform routine maintenance on your computer.

VII

Preface



Power Safety

Warning

Before you undertake any upgrade procedures, make sure that you have turned off the power, and disconnected all peripherals and cables (including telephone lines). It is advisable to also remove your battery in order to prevent accidentally turning the machine on.

Power Safety

The computer has specific power requirements:

• Only use a power adapter approved for use with this computer.

• Your AC/DC adapter may be designed for international travel but it still requires a steady, uninterrupted power supply. If you are unsure of your local power specifications, consult your service representative or local power company .

• The power adapter may have either a 2-pr ong or a 3-prong ground ed plug. The third prong is an important safety feature; do not defeat its purpose. If you do not have access to a compatible outlet, have a qualified electrician install one.

• When you want to unplug the power cord, be su re to disconnect it by the plug head, not by its wire.

• Make sure the socket and any extension cord(s) you use can support the total current load of all the connected devices.

• Before cleaning the computer, make sure it is disconnected from any external power supplies (i.e. AC/DC adapter or car adapter).

Do not plug in the power cord if you are wet.

Do not use the power cord if it is broken.

Do not place heavy objects on the power cord.

VIII

Preface

Polymer Battery Precautions

Note the following information which is specific to polymer batteries only, and where applicable, this overrides the general battery precaution information overleaf.

• Polymer batteries may experience a slight expansion or swelling, however this is part of the battery’s safety mechanism and is not a cause for concern.

• Use proper handling procedures when using polymer batteries. Do not use polymer batteries in high ambient temperature environments, and do not store unused batteries for extended periods.

See also the general battery precautionary information overleaf for further information.

Preface



Battery Disposal & Caution

The product that you have purchased contains a rechargeable battery. The battery is recyclable. At the end of its useful life, under various state and local laws, it may be illegal to dispose of this battery in to the municipal waste stream. Check with your local solid waste officials for details in your area for recycling options or proper disposal.

Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalen t type recommended by the manufacturer. Discard used battery according to the manufacturer’s instructions.

Battery Precautions

• Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer.

• Do not remove any batteries from the computer while it is powered on.

• Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.

• If you do not use the battery for an extended period, then remove the battery from the computer for storage.

• Recharge the batteries using the notebook’s system. Incorrect recharging may make the battery explode.

• Do not try to repair a battery pack. Refer any battery pack repa ir or replacemen t to you r service repre sentati ve or qu alified service personnel.

• Keep children away from, and promptly dispose of a damaged battery. Always dispose of batteries carefully. Batteries may explode or leak if exposed to fire, or improperly handled or discarded.

• Keep the battery away from metal appliances.

• Affix tape to the battery contacts before disposing of the battery.

• Do not touch the battery contacts with your hands or metal objects.

Cleaning



Removal Warning

When removing any cover(s) and screw(s) for the purposes of device upg rade, remember to replace the cover(s) and screw(s) before turning the computer on.

Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer.

Servicing

Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock. Refer all servicing to authorized service personnel. Unplug the computer from the power supply. Then refer servicing to qualified service personnel under any of the following conditions:

• When the power cord or AC/DC adapter is damaged or frayed.

• If the computer has been exposed to rain or other liquids.

• If the computer does not work normally when you follow the operating instructions.

• If the computer has been dropped or damaged (do not touch the poisonous liquid if the LCD panel breaks).

• If there is an unusual odor, heat or smoke coming from your computer.

Preface



Power Off Before Traveling

Make sure that your notebook is completely powered off before putting it into a travel bag (or any such container). Putting a notebook which is powered on in a travel bag may cause the vent(s)/fan intake(s)/outlet(s) to be blocked. To prev ent your computer from overheating make sure nothing blocks the vent(s)/fan intake(s)/outlet(s) while the computer is in use.

Travel Considerations

Packing

As you get ready for your trip, run through this list to make sure the system is ready to go:

1. Check that the battery pack and any spares are fully charged.

2. Power off the computer and peripherals.

3. Close the display panel and make sure it’s latched.

4. Disconnect the AC/DC adapter and cables. Stow them in the carrying bag.

5. The AC/DC adapter uses volt ages from 100 to 240 volt s so you won’t need a second volt age adapter. However,

check with your travel agent to see if you need any socket adapters.

6. Put the notebook in its carrying bag and secure it with the bag’s straps.

7. If you’re taking any perip herals (e.g. a printer, mouse or digital camera), pack them and those devices’ adapters

and/or cables.

8. Anticipate customs - Some jurisdictions may have import restrictions or req uire proof of ownersh ip for both hard -

ware and software. Make sure your documents are prepared.

XII

Preface

On the Road

In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind:

Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common. Don’t check it with normal luggage. Baggage handlers may not be sufficiently careful. Avoid knocking the computer against hard objects.

Beware of Electromagnetic fields - Devices such as metal detectors & X-ray machines can damage the computer, hard disk, floppy disks, and other media. They may also destroy any stored data - Pass your computer and disks around the devices. Ask security officials to hand-inspect them (you may be asked to turn it on). Note: Some airports also scan luggage with these devices.

Fly safely - Most airlines have regulations about the use of computers and other electronic devices in flight. These restrictions are for your safety, follow them. If you stow the notebook in an overhead compartment, make sure it’s secure. Contents may shift and/or fall out when the compartment is opened.

Get power where you can - If an electrical outlet is available, use the AC/DC adapter and keep your battery(ies) charged.

Keep it dry - If you move quickly from a cold to a warm location, water vapor can condense inside the computer. Wait a few minutes before turning it on so that any moisture can evaporate.

XIII

Preface

Developing Good Work Habits

Developing good work habits is important if you need to work in fron t of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints. The following are some tips to reduce the strain:

• Adjust the height of the chair and/or desk so that the keyboard is at or slightly below the level of your elbow. Keep your forearms, wrists, and hands in a relaxed position.

• Your knees should be slightly higher than your hips. Place yo ur feet flat on th e floor or on a footrest if necessary.

• Use a chair with a back and adjust it to support your lower back comfortably.

• Sit straight so that your knees, hips and elbows form approximately 90-degree angles when you are working.

• Take periodic breaks if you are using the computer for long periods of time.

Remember to:

• Alter your posture frequently.

• Stretch and exercise your body several times a day.

• Take periodic breaks when you work at the computer for long periods of time. Frequent and short breaks are better than fewer and longer breaks.

XIV

Preface

Lighting

Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders.

• Position the display to avoid glare or reflections from overhead lighting or outside sources of light.

• Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly.

• Position the display directly in front of you at a comfortable viewing distance.

• Adjust the display-viewing angle to find the best position.

LCD Screen Care

To prevent image persistence on LCD monitors (caused by the continuous display of graphics on the screen for an extended period of time) take the following precautions:

• Set the Windows Power Plans to turn the screen off after a few minutes of screen idle time.

• Use a rotating, moving or blank screen saver (this prevents an image from being displayed too long ).

• Rotate desktop background images every few days.

• Turn the monitor off when the system is not in use.

NVIDIA 3D Vision Kit Safety

Make sure you read all the enclosed safety instructions and precautions included in the NVIDIA 3D Vision Kit before setting up the 3D Glasses and IR Emitter. Follow the setup instructions provided in the documentation to set up the 3D Vision kit safely and take the “User Vision Test,” which will initiate when you turn on your GeForce 3D Vision for the first time. If you cannot see the image in 3D during the test, you should DISCONTINUE USE IMMEDIATELY. Continued use may result in health-related complications.

Preface

XVI

Contents

Notice .................................................................................I

FCC Statement ................................................................III

FCC RF Radiation Exposure Statement: ........................IV

Instructions for Care and Operation ...............................VI

Power Safety ................................................................ VIII

Polymer Battery Precautions ..........................................IX

Battery Precautions ...................................................... ....X

Cleaning .......................................................................... XI

Servicing .........................................................................XI

Travel Considerations ....................................................XII

Quick Start Guide

Overview ........................................................................1-1

Advanced Users .............................................................1-2

Beginners and Not-So-Advanced Users ........................1-2

Warning Boxes ................................................ ..............1-2

Not Included ..................................................................1-3

System Startup ...............................................................1-4

System Software ................... .... .....................................1-5

RAID & AHCI Setup .....................................................1-5

Model Differences .........................................................1-6

System Map: Front View - Models A & D ....................1-7

System Map: Front View - Models B & C ....................1-8

Preface

LED Indicators ...............................................................1-9

Hot Key Buttons & Keyboard .....................................1-10

Keyboard ......................................................................1-11

Function/Hot Key Indicators .......................................1-12

System Map: Left View ...............................................1-13

System Map: Right View .............................................1-15

System Map: Rear View ..............................................1-16

System Map: Bottom View - Models A & D ..............1-17

System Map: Bottom View - Model B .............. .... ... ...1-18

System Map: Bottom View - Model C .............. .... ... ...1-19

Windows Vista Start Menu & Control Panel ...............1-20

Video Features .............................................................1-21

Power Options ........................................ .... ..................1-23

Features & Components

Overview ........................................................................2-1

Hard Disk Drive .............................................................2-2

Optical (CD/DVD) Device ............................................2-3

Loading Discs ................................................................2-3

Handling CDs or DVDs .................................................2-4

DVD Regional Codes ....................................................2-5

7-in-1 Card Reader .........................................................2-6

ExpressCard Slot ............................................................2-7

XVII

Preface

Inserting and Removing ExpressCards ..........................2-7

TouchPad and Buttons/Mouse .......................................2-8

Gesture Configuration ...................................................2-9

Audio Features .............................................................2-10

Audio Setup for LCD Monitors/

TVs with HDMI Input .................................................2-11

Adding a Printer ...........................................................2-12

USB Printer ..................................................................2-12

Parallel Printer .............................................................2-12

Power Management

Overview ........................................................................3-1

The Power Sources ...................................... .... ..............3-2

AC/DC Adapter .............................................................3-2

Battery ............................................................................3-2

Turning on the Computer ...............................................3-3

Power Plans ...................................................................3-4

Power-Saving States ......................................................3-6

Sleep ..............................................................................3-6

Hibernate ........................................................................3-7

Shut Down .....................................................................3-7

Configuring the Power Buttons .....................................3-8

Resuming Operation ......................................................3-9

Battery Information .....................................................3-10

Battery Power ..............................................................3-10

Conserving Battery Power ...........................................3-11

Battery Life ..................................................................3-12

New Battery .................................................................3-12

Recharging the Battery with the AC/DC Adapter .......3-12

Proper handling of the Battery Pack ............................3-13

Battery FAQ .................................................................3-14

Drivers & Utilities

RAID & AHCI Setup .....................................................4-1

What to Install ........................................................... .....4-1

Module Driver Installation .............................................4 -1

Driver Installation ..........................................................4-2

Updating/Reinstalling Individual Drivers ......................4-4

User Account Control (Win Vista) ................................4-5

Windows Security Message ...........................................4-5

New Hardware Found ....................................................4-5

Driver Installation Procedure ......................................... 4-5

Chipset ...........................................................................4-5

NVIDIA Video ..............................................................4-6

ATI Video ......................................................................4-6

Modem ...........................................................................4-6

LAN ...............................................................................4-6

Firewire (IEEE 1394) .....................................................4-6

CardReader ....................................................................4-7

TouchPad .......................................................................4-7

XVIII

Preface

Hot Key ..........................................................................4-7

USB 3.0 ..........................................................................4-7

Audio .............................................................................4-7

Optional Drivers ............................................................4-8

PC Camera Module ........................................................4-9

Wireless LAN Module ...................................................4-9

Fingerprint Reader Module ............................................4-9

3.75G/HSPA Module (Models A & D Only) ................4-9

TV Tuner Module (Models B & C Only) ......................4-9

NVIDIA 3D Shutter Glasses (Model D Only) ..............4-9

RAID and AHCI Configuration .....................................4-9

BIOS Utilities

Overview ........................................................................5-1

The Power-On Self Test (POST) ................................... 5-2

Failing the POST ...........................................................5-3

Fatal Errors ....................................................................5-3

Non-Fatal Errors ............................................................5-3

The Setup Program ...................................... .... ..............5-4

Entering Setup ...............................................................5-4

Setup Screens .................................................................5-5

Main Menu .....................................................................5-6

System Time & Date (Main Menu) ...............................5-6

SATA Port 1/2/3/4/5 (Main Menu) ...............................5-7

System/Extended Memory (Main Menu) ......................5-7

BIOS Revision/KBC/

EC Firmware Revision (Main Menu) ............................5-7

VGA Card/VBIOS Revision/

VBIOS Build Date (Main Menu) ...................................5-7

Advanced Menu .............................................................5-8

Advanced Chipset Control .............................................5-8

SATA Mode Selection (Advanced Menu) .....................5-9

Legacy USB Support (Advanced Menu) .......................5-9

Boot-time Diagnostic Screen (Advanced Menu) ...........5-9

Legacy OS Boot (Advanced Menu) ...............................5-9

Power On Boot Beep (Advanced Menu) ............... ... .... .5-9

Battery Low Alarm Beep (Advanced Menu) .................5-9

Security Menu ..............................................................5-10

Set Supervisor Password (Security Menu) ..................5-10

Set User Password (Security Menu) ............................5-11

Password on boot (Security Menu) ..............................5-11

Boot Menu ...................................................................5-12

Exit Menu ....................................................................5-13

Upgrading The Computer

Overview ........................................................................6-1

When Not to Upgrade ....................................................6-2

Removing the Battery ....................................................6-3

Upgrading the Hard Disk Drive(s) .................................6-4

Upgrading the Optical (CD/DVD) Device ....................6-8

XIX

Preface

Upgrading the System Memory (RAM) ......................6-11

Modules & Options

Overview ........................................................................7-1

Bluetooth Module ............. .... .... .....................................7-2

Bluetooth Configuration in Windows Vista ..................7-3

PC Camera Module ........................................................7-7

PC Camera Driver Installation .......................................7-8

Wireless LAN Module .................................................7-16

Intel® Wi-Fi Link Series Driver Installation ...............7-17

3rd Party 802.11b/g/n Driver Installation ....................7-17

Connecting to a Wireless Network .............................. 7-18

Windows Mobility Center ...........................................7-21

Fingerprint Reader Module ..........................................7-22

Fingerprint Reader Driver Installation .........................7-22

User Enrollment ...........................................................7-23

Fingerprint Control Center Features ............................7-26

3.75G/HSPA Module ...................................................7-27

USIM Card Installation ................................................7-29

HSPA Modem Interface ..............................................7-31

HSPA Modem Interface Installation ...........................7-31

HSPA Modem Interface ..............................................7-32

Adding a Profile ...........................................................7-34

Contacts .......................................................................7-36

Messages ......................................................................7-37

Settings .........................................................................7-38

Mobile Partner .............................................................7-40

Mobile Partner Application Installation ......................7-40

Mobile Partner Application .........................................7-41

Profile Management .....................................................7-41

TV Tuner Module ........................................................7-45

Consumer Infrared Driver ............................................7-46

Digital TV Broadcast Signal ........................................7-47

TV Recording and Power Plans ...................................7-47

Remote Control Unit ....................................................7-47

NVIDIA 3D Shutter Glasses Kit .................................7-48

Set Up Stereoscopic 3D ...............................................7-49

Setting Up SATA RAID or AHCI Modes ...................7-52

AHCI Mode .................................................................7-52

RAID (Models B & C Only) ........................................7-52

Intel® Matrix Storage Manager ...................................7-52

SATA RAID Setup Procedure (BIOS) ........................7-54

RAID Setup (Intel Matrix) ...........................................7-55

Intel Matrix Driver Installation ....................................7-57

Intel® Matrix Storage Manager ...................................7-57

RAID Volume Data Verification and Repair ..............7-59

Replacing and Reverting Recovery and

Master Volumes ...........................................................7-59

Preface

Troubleshooting

Overview ........................................................................8-1

Basic Hints and Tips ......................................................8-2

Backup and General Maintenance .................................8-3

Viruses ...........................................................................8-4

Upgrading and Adding New Hardware/Software ..........8-5

Problems and Possible Solutions ...................................8-7

Screen Resolution Error ...............................................8-14

Bluetooth Connection Problems ..................................8-16

Interface (Ports & Jacks)

Overview .......................................................................A-1

NVIDIA Video Driver Controls

NVIDIA Video Driver Installation ............................... B-1

NVIDIA Control Panel .................................................B-2

Display Devices ............................................................B-5

Attaching Other Displays .............................................B-6

HDMI Audio Configuration .......................................B-11

Display Modes ............................................................B-14

Enabling TV Display ..................................................B-17

Changing the TV Signal or HD Format ......................B-18

ATI Video Driver Controls

ATI Video Driver Installation .......................................C-1

ATI Catalyst® Control Center ......................................C-2

Attaching Other Displays ..............................................C-4

Configuring an External Display in Win Vista .............C-7

PowerPlay™ ............................................................... C-10

Specifications

Processor .......................................................................D-2

Processor .......................................................................D-3

Core Logic .................................................................... D-3

Display .......................................................................... D-3

Memory .........................................................................D-3

Video Adapter ...............................................................D-4

BIOS .............................................................................D-4

Storage ..........................................................................D-5

Audio ............................................................................D-5

Keyboard & Pointing Device ........................................D-5

Interface ........................................................................D-5

XXI

Preface

Card Reader .............................. .... .... ............................D-5

Slots ..............................................................................D-5

Communication .............................................................D-6

Power Management ......................................................D-6

Power ............................................................................D-6

Security ......................................................................... D-6

Operating System ..........................................................D-6

Environmental Spec ......................................................D-7

Dimensions & Weight ..................................................D-7

NVIDIA 3D VISION ....................................................D-7

Factory Options for All Models ....................................D-7

Factory Options Per Model ...........................................D-7

Windows 7 Information

DVD Regional Codes................................................... E- 2

Windows 7 Start Menu & Control Panel...................... E- 3

Function/Hot Key Indicators ........................................ E- 4

Hot Key Buttons & Keyboard ...................................... E- 5

Video Features..............................................................E- 6

Attaching Other Displays ........................................... E- 10

The Power Sources................................... .................. E- 13

Turning On the Computer........................................... E- 14

Power Plans ................................................................E- 15

Power-Saving States................................................... E- 17

Configuring the Power Buttons ..................................E- 19

Battery Information..................................................... E- 21

Driver Installation.......................................................E- 27

Bluetooth Module (Win 7)..........................................E- 35

PC Camera Module (Win7)........................ ................ E- 40

Wireless LAN Module (Win 7).................................. E- 46

Fingerprint Reader Module (Win7)............................ E- 52

3.75G/HSPA Module (Win 7).................................... E- 56

Audio Setup for LCD Monitors/TVs

with HDMI Input........................................................ E- 76

XXII

Quick Start Guide

Chapter 1: Quick Start Guide

Overview

This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following:

• Chapter 2 A guide to using some of the main features of the computer e.g. the storage devices (hard disk, optical device, 7-in-1 card reader, ExpressCard 34/54), TouchPad & Mouse, Audio & Printer.

• Chapter 3 The computer’s power saving options.

• Chapter 4 The installation of the drivers and utilities essential to the operation or improvement of some of the computer’s subsystems.

• Chapter 5 An outline of the computer’s built-in software or BIOS (Basic Input Output System).

• Chapter 6 Instructions for upgrading your computer.

• Chapter 7 A quick guide to the computer’s Bluetooth, PC Camera, Wireless LAN, Fingerprint, 3.75G/ HSPA, TV Tuner and RAID modules (some of which may be optional depending on your purchase configuration).

• Chapter 8 A troubleshooting guide.

• Appendix A Definitions of the interface, ports/jacks which allow your computer to communicate with external devices.

• Appendix B Information on the NVIDIA Video driver controls.

• Appendix C Information on the ATI Video driver controls.

• Appendix D The computer’s specification.

• Appendix E Information specific to the W

indows 7 OS.

Overview 1 - 1



Notes

Check the light colored boxes with the mark above to find detailed information about the computer’s features.

Quick Start Guide

Advanced Users

If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “What to Install” on page 4 - 1, “BIOS Utilities” on page 5 - 1 and “Upgrading The Computer” on

page 6 - 1 in the reminder of the User’s Manual. You may also find the notes marked with a

 of interest to you.

Beginners and Not-So-Advanced Users

If you are new to computers (or do not have an advanced knowledge of them) then the information contained in the Quick Start Guide should be enough to get you up and running. Eventually you should try to look through all the documentation (more detailed descriptions of the functions, setup and system controls are covered in the remainder of the User’s Manual), but do not worry if you do not understand everything the first time. Keep this manual nearby and refer to it to learn as you go. You may find it useful to refer to the notes marked with a

 as indicated in the margin.

For a more detailed description of any of the interface ports and jacks see “Interface

(Ports & Jacks)” on page A - 1.

Warning Boxes

No matter what your level please pay careful attention to the warning and safety information indicated by the

 symbol. Also please note the safety and handling instructions as indicated in the Preface.

1 - 2 Overview

Quick Start Guide



Drivers

If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the drivers listed in “Drivers & Utilities” on page 4 - 1. Drivers are programs which act as an interface between the computer and a hardware component e.g. a wireless network module. It is very important that you install the drivers in the order listed. You will be unable to use most advanced controls until the necessary drivers and utilities are properly installed. If your system hasn’t been properly configured (your service representative may have already done that for you); refer to

Chapter 4 for installation instructions.

Ports and Jacks

See Appendix A for a description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc.

Not Included

Operating Systems (e.g. Windows Vista/Windows 7) and applications (e.g. word processing, spreadsheet and database programs) have their own manuals, so please consult the appropriate manuals.

Overview 1 - 3



Shutdown

Note that you should always shut your computer down by choosing the Shut Down command from the bottom right of the Start menu in Windows 7 or from the Lock Button Menu in Windows Vista. This will help prevent hard disk or system

problems.

Quick Start Guide

System Startup

1. Remove all packing materials.

2. Place the computer on a stable surface.

3. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports.

4. Attach the AC/DC adapter to the DC-In jack at the rear of the computer, then plug the AC power cord into an

outlet, and connect the AC power cord to the AC/DC adapter.

5. Use one hand to raise the

hand (as illustrated in Figure 1 - 1 below) to support the base of the computer (Note: Never lift the computer by the lid/LCD).

lid/LCD to a comfortable viewing angle (do not exceed 120 degrees);

use the other

1 - 4 Overview

Figure 1 - 1 - AC/DC Adapter In & Opening the Lid/LCD

System Software



TV Tuner Module

Support

Note that the TV Tuner module (factory option) in Windows is supported by the Windows Media Cen- ter software which comes built-in to the Windows

Vista Home Premium and Ultimate Editions only.

If your purchase includes a TV Tuner option, and you are re-configuring your system for a different system, you should install either

Home Premium or Ultimate Editions of Windows

Vista only. Note that Windows Media Center is not included in Starter or Home Basic versions of

Windows 7.



Windows Vista/Windows 7

This manual refers to the Windows Vista OS. For any information specific to Windows 7 see Ap-

pendix E. Make sure you install Windows Vista Service Pack 2 (or a Windows Vista version which

includes Service Pack 2) before installing any drivers. Go to the Microsoft website for download details, or contact your service center.

Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find the following operating systems are supported.

Operating System & Version Note

Windows Vista - with Service Pack 2 In order to run Windows Vista/Windows 7

Windows 7

without limitations or decreased performance, your computer requires a minimum 1GB of system memory (RAM).

Table 1 - 1 - Operating Systems Supported

RAID & AHCI Setup

Note that setting up a RAID, or AHCI mode, needs to be done prior to installing the Windows OS (see “Setting Up SATA RAID or AHCI Modes” on page 7 - 52).

Quick Start Guide

Overview 1 - 5

Quick Start Guide

Model Differences

This notebook series includes four different model types that mainly differ as indicated in the table below.

Feature Model A Model B Model C Model D

15.6” (39.62cm) HD (1366 *

Display Type

Supported

RAID Supported Not Supported RAID Level 0/1 Supported Not Supported

768) / HD+ (1600 * 900) / FHD (1920 * 1080) 16:9 Wide Screen LED Panel

17.3" FHD (1920 * 1080) / HD+ (1600 * 900) 16:9 Wide Screen LED Backlit Panel

15.6” (39.62cm) HD (1366 *

768) 120Hz panel to support 3D solution with NV

3DVISION shutter glasses

kit, and compatible with GTX

285M and GTS 360M Video

Cards

Mini-Card Slot 2

CPUs & Video

Adapters

Supported

Design

AC/DC Adapter DC Output 20V, 6.0A DC Output 19V, 9.48A DC Output 20V, 6.0A

for UMTS/HSPA 3.75G

Module

See “Specifications” on page D - 1 for a full list of CPUs and video adapters supported by each model.

See “System Map: Front View - Models A & D” on page 1 - 7 and “System Map: Front View - Models B & C” on

page 1 - 8 to help identify your particular model.

for TV Tuner Card

for UMTS/HSPA 3.75G

Module

Table 1 - 2 - Model Differences

1 - 6 Model Differences

System Map: Front View - Models A & D

Figure 1 - 2

Front View

(Model A & D

Computers)

1. Built-In PC Camera (

Optional

)

2. LCD

3. Power Button

4. Speakers

5. LED Hot Key Buttons

6. LED Status Indicators

7. Keyboard

8. Built-In Microphone

9. Touchpad & Buttons

10. LED Power Indicators

Note: The Fingerprint Reader module is optional for Model

A & D computers.



Wireless Device

Operation Aboard Aircraft

The use of any portable electronic transmission devices aboard aircraft is usually prohibited. Make sure the module(s) are OFF if you are using the computer aboard aircraft.

Use the key combinations to toggle power to the 3.75G/HSPA/WLAN/Bluetooth modules, and check the LED indicator icon to see if the modules are powered on or not (see

Table 1 -

6, on page 1 - 12

/ Table 1 - 4, on page 1

- 9

Note that the Touchpad and Buttons valid operational area is that indicated within the red dotted lines above.

Quick Start Guide

System Map: Front View - Models A & D 1 - 7

Figure 1 - 3

Front View

(Model B & C

Computers)

1. Built-In PC Camera (

Optional

)

2. LCD

3. LED Status Indicators

4. LED Hot Key Buttons

5. LED Power Button

6. Speakers

7. Keyboard

8. Built-In Microphone

9. Touchpad & Buttons

10. Consumer Infrared Transceiver (for Optional TV Tuner)

11. LED Power Indicators

Note: The Fingerprint Reader module is optional for Model

B & C computers.



Wireless Device

Operation Aboard Aircraft

The use of any portable electronic transmission devices aboard aircraft is usually prohibited. Make sure the module(s) are OFF if you are using the computer aboard aircraft.

Use the key combinations to toggle power to the WLAN/Bluetooth modules, and check the LED indicator icon to see if the modules are powered on or not (see

Table 1 - 6, on page 1 - 12/ Table 1

- 4, on page 1 - 9

6 6

Note that the Touchpad and Buttons valid operational area is that indicated within the red dotted lines above.

Quick Start Guide

System Map: Front View - Models B & C

1 - 8 System Map: Front View - Models B & C

Quick Start Guide

LED Indicators

The LED indicators on the LED strip just below the LCD panel on the computer display helpful information about the current status of the computer when illuminated.

Icon Description

Hard Disk Activity

Number Lock Activated

(to activate press Fn & Num Lk)

Caps Lock Activated

Scroll Lock Activated

(to activate press Fn & Scr Lk)

The (optional) Wireless LAN Module is Powered

The (optional) Bluetooth Module is Powered On

A further two LED power indicators on the front right of the computer provide information on the computer’s power status.

Icon Color Description

Orange DC Power is Plugged In

Green The Computer is On

Blinking Green

Orange The Battery is Charging

Green The Battery is Fully Charged

Blinking Orange

Table 1 - 4 - LED Power Indicators

The Computer is in Sleep

Mode

The Battery Has Reached

Critically Low Power Status

Table 1 - 3 - LED Status Indicators

LED Indicators 1 - 9



Other Keyboards

If your keyboard is damaged or you just want to make a change, you can use any standard USB keyboard. The system will detect and enable it automatically. However special functions/ hot-keys unique to the system’s regular keyboard may not work.

NumLk & ScrLk

Hold down the Fn Key and either NumLk or ScrLk to enable number or scroll lock, and check the LED indicator for status.



Special Characters

Some software applications allow the number-keys to be used with Alt to prod uce special characters. These special characters can only be produced by using the numeric keypad. Regular number keys (in the upper row of the keyboard) will not work. Make sure that NumLk is on.

Quick Start Guide

Hot Key Buttons & Keyboard

The LED hot key buttons give instant access to the default Internet browser and email program, and allow you to toggle Silent Mode with one quick button press.

Hot Key Function

Activate the Default E-Mail Browser (Note that In Windows 7 without Outlook/

Outlook Express installed this button has no function. If Outlook/Outlook Express are installed then the button will activate the application)

Activate the Default Internet Program

Toggle *Silent Mode (for power saving)

Table 1 - 5 - LED Hot Key Buttons

*When enabled, Silent Mode will reduce fan noise and save power consumption. Note this may reduce computer performance.

1 - 10 Hot Key Buttons & Keyboard

Quick Start Guide

Numerical Keypad

Play/Pause Key

Function Keys

NumLk & ScrLk Keys

Fn Key

Keyboard

The keyboard has a numerical keypad on the right for easy numeric data input, and features function keys to allow you to change operational features instantly. See Table 1 - 6, on page 1 - 12 for full function key combination details.

Figure 1 - 4 - Keyboard

Keyboard 1 - 11

Quick Start Guide

Function/Hot Key Indicators

The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the basic function key combinations, visual indicators are available when the hot key utility is installed.

Fn Keys Function Fn Keys Function

Fn + ~ Play/Pause (in Audio/Video Programs) Fn + F5/F6 Volume Decrease/Increase

Fn + _

Fn + F1 Touchpad Toggle Fn + F8/F9

Fn + F2

Fn + F3 Mute Toggle Fn + F11

Fn + F4 Sleep Toggle Fn + F12

3.75G Module Power Toggle*

(Press a key to or use TouchPad to turn on)

*Silent Mode Toggle

Turn LCD Backlight Off

Table 1 - 6 - Function & Hot Key Indicators

1 - 12 Function/Hot Key Indicators

Fn + F7 Display Toggle

Brightness Decrease/

Increase

Fn + F10

*When enabled, Silent Mode will reduce fan noise and save power

consumption. Note this may reduce computer performance.

**Make sure that Wireless is ON in the Windows Mobility Center to ensure

proper wireless function key behavior (see page 3 - 11).

PC Camera Power

Toggle

**WLAN Module Power

Toggle

Bluetooth Module Power

Toggle

System Map: Left View

Figure 1 - 5

Left View

1. RJ-11 Modem Jack

2. USB 2.0 Port

3. Mini-IEEE 1394 Port

4. 7-in-1 Card Reader

5. Optical Device Drive Bay (for DVD Device)

6. Cable (CATV) Antenna Jack

*Enabled with Optional TV Tuner for Models B & C Only.

Note that your model’s color may differ from that pictured.



7-in-1 Card Reader

The card reader allows you to use the most popular digital storage card formats:

MMC (MultiMedia Card) / SD (Secure Digital) / MS (Memory Stick) /

MS Pro (Memory Stick Pro) / MS Duo (requires PC adapter) /

Mini SD (requires PC adapter) / RS MMC (requires PC adapter)

Mini-IEEE 1394 Port

The Mini-IEEE 1394 port only supports SELF POWERED IEEE 1394 devices. Make sure you install the Firewire IEEE 1394 driver (see page 4 - 6).

Models A & D

Models B & C

Quick Start Guide

System Map: Left View 1 - 13



Disk Eject Warning

Don’t try to eject a CD/DVD while the system is accessing it. This may cause the system to “crash”. Stop the disk first then eject it, or press the stop button twice.

CD/DVD Emergency Eject

If you need to manually eject a CD/DVD (e.g. due to an unexpected power interruption) you may push the end of a straightened paper clip into the emergency eject hole. Do not use a sharpened pencil or any object that may break and become lodged in the hole. Don’t try to remove a floppy disk/CD/DVD while the system is accessing it. This may cause the system to “crash”.



Changing DVD Regional Codes

Go to the Control Panel and double-click Device Manager (Hardware and Sound), then click th e +

next to DVD/CD-ROM drives. Double-click on the DVD-ROM device to bring up the Properties dialog box, and select the DVD Region (tab) to bring up the control panel to allow you to adjust the regional code (see “DVD Regional Codes” on page 2 - 5).

DVD region detection is device dependent, not OSdependent. You can select your module’s region code 5 times. The fifth selection is pe rmanent. This cannot be altered even if you change your operating system or you use the module in another computer.

Quick Start Guide

1 - 14 System Map: Left View

System Map: Right View

Figure 1 - 6

Right View

1. Headphone-Out Jack

2. Microphone-In Jack

3. Line-In Jack

4. S/PDIF-Out Jack

5. USB 3.0 Port OR USB 2.0 Port

6. ExpressCard Slot (see page 2 - 7)

7. e-SATA Port

8. DVI-Out Port

9. Security Lock Slot (Models B & C Only)

10. Power Button (Models A & D Only)

152 4

Models A & D



USB 3.0 Port OR USB 2.0 Port

All computer models have either a single USB 3.0 port or USB 2.0 port on the right side of the computer. The USB 3.0 port is denoted by its blue col or; USB 2.0 ports are colored black.

Note that the USB 3.0 port requires a driver i nstallation (see “USB 3.0” on page 4 - 7/ .“USB 3.0” on page E - 31).

Models B & C

1 2 43

Quick Start Guide

System Map: Right View 1 - 15

Figure 1 - 7

Rear View

1. Vent/Fan Intake/ Outlet

2. Security Lock Slot (Models A & D Only)

3. HDMI-Out Port

4. DC-In Jack

5. 2 * USB 2.0 Ports

6. RJ-45 LAN Jack

7. Rear Cover (Models B & C Only)



Overheating

To prevent your computer from overheating make sure nothing blocks the vent(s)/fan intake(s) while the computer is in use.

4 7



HDMI-Out Port

Note that the HDMI-Out Port supports video and audio signals to attached external displays (also see “HDMI Audio Configuration” on page B - 11).

Models A & D

Models B & C

1 1

Quick Start Guide

System Map: Rear View

1 - 16 System Map: Rear View

System Map: Bottom View - Models A & D

Figure 1 - 8

Bottom View

(Model A & D

Computers)

1. Battery

2. Component Bay Cover

3. Vent/Fan Intake/ Outlet

Note: the 3.75G/HSPA USIM Card is located under the Component Bay Cover.



Battery Information

Always completely discharge, then fully charge, a new battery before using it. Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges. See “Battery Information”

on page 3 - 10 for full in-

structions.



CPU

The CPU is not a user serviceable part.

Overheating

To prevent your computer from overheating make sure nothing blocks the Vent/Fan Intake while the computer is in use.

Quick Start Guide

System Map: Bottom View - Models A & D 1 - 17

Figure 1 - 9

Bottom View

(Model B

Computers)

1. Battery

2. Component Bay Cover

3. Vent/Fan Intake/ Outlet

4. Subwoofer



Battery Information

on page 3 - 10 for full in-

structions.



CPU

The CPU is not a user serviceable part.

Overheating

To prevent your computer from overheating make sure nothing blocks the Vent/Fan Intake while the computer is in use.

Quick Start Guide

System Map: Bottom View - Model B

1 - 18 System Map: Bottom View - Model B

System Map: Bottom View - Model C

Figure 1 - 10

Bottom View

(Model C

Computers)

1. Battery

2. Component Bay Cover

3. Vent/Fan Intake/ Outlet

4. Subwoofer



Battery Information

on page 3 - 10 for full in-

structions.



CPU

The CPU is not a user serviceable part.

Overheating

To prevent your computer from overheating make sure nothing blocks the Vent/Fan Intake while the computer is in use.

Quick Start Guide

System Map: Bottom View - Model C 1 - 19

Figure 1 - 11 - Start Menu & Control Panel

Click here to toggle Classic View

Quick Start Guide

Windows Vista Start Menu & Control Panel

Most of the control panels, utilities and programs within Windows Vista (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop. Right-click the Start menu icon , and then select Properties if you want to customize the appearance of the Start menu.

In many instances throughout this manual you will see an instruction to open the Control Panel. The Control Panel is accessed from the Start menu, and it allows you to configure the settings for most of the key features in Windows (e.g. power, video, network, audio etc.). Windows Vista provides basic controls for many of the fea- tures, however many new controls are added (or existing ones are enhanced) when you install the drivers listed in Table 4 - 1, on page 4 - 3. To see all controls it may be necessary to toggle to Classic View on.

1 - 20 Windows Vista Start Menu & Control Panel

Quick Start Guide

123345367

Video Features

This computer features two different (either ATI or NVIDIA) video options. You will be provided with an appropriate driver on the the Display Settings control panel in Windows. To access Display Settings in Windows:

1. Click Start, and click Control Panel (or point to Settings and click Control Panel).

2. Click Adjust screen resolution under the Appearance and Personalization menu (or double-click Personalization > Display Settings).

3. Move the slider to the preferred setting in Resolution: (Figure 1 - 12 on page 1 - 22).

4. Click the arrow, and scroll to the preferred setting In Colors: (Figure 1 - 12 on page 1 - 22).

5. Click Advanced Settings (button) (Figure 1 - 12 on page 1 - 22).

To access the NVIDIA Control Panel (See Appendix B for detailed information):

1. Click Advanced Settings (button) (Figure 1 - 12 on page 1 - 22).

2. Click GeForce..... (tab) (Figure 1 - 12 on page 1 - 22).

3. Click Start the NVIDIA Control Panel (Figure 1 - 12 on page 1 - 22) to access the control panel.

To access the ATI Catalyst Control Center (See Appendix C for detailed information):

1. Click Advanced Settings (button) (Figure 1 - 12 on page 1 - 22).

2. Click ATI Catalyst Control Center (tab) (Figure 1 - 12 on page 1 - 22).

3. Click ATI Catalyst Control Center (button) (Figure 1 - 12 on page 1 - 22) to access the control panel.

Device Drivers & Utilities + User’s Manual Disc. You can configure display options, from

Video Features 1 - 21

2 3

Quick Start Guide

1 - 22 Video Features

Figure 1 - 12 - Display Settings & NVIDIA/ATI Controls

Quick Start Guide

Note: Sleep is the default power saving state in Windows Vista

Power Options

The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 1 - 18 ) allows you to configure power management features for your computer. You can conserve power by means of power plans and configure the options for the power button, sleep button, computer lid (when closed), display and sleep mode from the left menu. Note that the Power saver plan may have an affect on computer performance.

Click to select one of the existing plans, or click Create a power plan in the left menu and select the options to create a new plan. Click Change Plan Settings and click Change advanced power settings to access further con- figuration options.

Pay attention to the instructions on battery care in “Battery Information” on page 3 - 10.

Figure 1 - 13 - Power Options

Power Options 1 - 23

Quick Start Guide

1 - 24

Features & Components

Chapter 2: Features & Components

Overview

Read this chapter to learn more about the following main features and components of the computer:

•Hard Disk Drive

• Optical (CD/DVD) Device

• 7-in-1 Card Reader

• ExpressCard Slot

• TouchPad and Buttons/Mouse

• Gesture Configuration

• Audio Features

• Audio Setup for LCD Monitors/TVs with HDMI Input

• Adding a Printer

Overview 2 - 1

Features & Components



Power Safety

Before attempting to access any of the internal components of your computer please ensure that the machine is not connected to the AC power, and that the machine is turned off. Also ensure that all peripheral cables, including phone lines, are disconnected from the computer.

Figure 2 - 1

Hard Disk Location



Pictures

Note that only one model is pictured, however the primary hard disk location is the same for all models.

2 - 2 Hard Disk Drive

Hard Disk Drive

The hard disk drive is used to store your data in the computer. The hard disk can be taken out to accommodate other 2.5" serial (SATA) hard disk drives (see “Storage”

on page D - 5) with a height of 9.5 mm.

The primary hard disk is accessible from the bottom of your computer as seen below. For further details see “Upgrading the Hard Disk Drive(s)” on page 6 - 4.

Features & Components



Sound Volume

Adjustment

How high the sound volume can be set depends on the setting of the volume control within Win- dows. Click the Volume icon on the taskbar to check the setting (see

“Sound Volume Adjustment” on page 2 -

10).

Figure 2 - 2

Optical Device

123

Optical (CD/DVD) Device

There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual device will depend on the module you purchased (see “Storage” on page D - 5). The optical device is usually labeled “Drive D:” and may be used as a boot device if properly set in the BIOS (see “Boot Menu” on page 5 - 12).

Loading Discs

To insert a CD/DVD, press the open button and carefully place a CD/DVD onto the disc tray with label-side facing up (use just enough force for the disc to click onto the tray’s spindle). Gently push the CD/DVD tray in until its lock “clicks” and you are ready to start. The busy indicator will light up while data is being accessed, or while an audio/video CD, or DVD, is playing. If power is unexpectedly interrupted, insert an object such as a straightened paper clip into the emergency eject hole

to open the tray.

Optical (CD/DVD) Device 2 - 3

Features & Components



CD Emergency Eject

If you need to manually eject a CD (e.g. due to an unexpected power interruption) you may push the end of a straightened paper clip into the emergency eject hole. However please do NOT use a sharpened pencil or similar object that may break and become lodged in the hole.

Disk Eject Warning

Don’t try to remove a CD/DVD while the system is accessing it. This may cause the system to “crash”.

2 - 4 Optical (CD/DVD) Device

Handling CDs or DVDs

Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/DVDs can be accessed.

Note the following:

• Hold the CD or DVD by the edges; do not touch the surface of the disc.

• Use a clean, soft, dry cloth to remove dust or fingerprints.

• Do not write on the surface with a pen.

• Do not attach paper or other materials to the surface of the disc.

• Do not store or place the CD or DVD in high-temperature areas.

• Do not use benzene, thinner, or other cleaners to clean the CD or DVD.

• Do not bend the CD or DVD.

• Do not drop or subject the CD or DVD to shock.

Features & Components

Table 2 - 1

DVD Regional Coding

DVD Regional Codes

To change the DVD regional codes see “Changing DVD Regional Codes” on

page 1 - 14.

Region Geographical Location

1 USA, Canada

6China

Korea, The Philippines, Indonesia,

DVD Regional Coding

Western Europe, Japan, South

Africa, Middle East & Egypt

South-East Asia, Taiwan, South

Hong Kong

South & Central America, Mexico,

Australia, New Zealand

N Korea, Russia, Eastern Europe,

India & Most of Africa

Optical (CD/DVD) Device 2 - 5

Features & Components



Card Reader Cover

Make sure you keep the rubber cover provided in the card reader when not in use. This will help prevent foreign objects and/or dust getting in to the card reader.

Figure 2 - 3

Left View

1. Card Reader

• MMC (MultiMedia Card)

• SD (Secure Digital)

• MS (Memory Stick)

• MS Pro (Memory Stick Pro)

• MS Duo (requires PC adapter*)

• Mini SD (requires PC adapter*)

• RS MMC (requires PC adapter*)

Models A & D

Models B & C

7-in-1 Card Reader

The card reader allows you to use some of the latest digital storage cards. Push the card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s). Make sure you install the Card Reader driver (see “CardReader” on page 4 - 7).

*Note: The PC adapters are usually supplied with these cards.

2 - 6 7-in-1 Card Reader

Features & Components



ExpressCard

Slot Cover

Make sure you keep the rubber cover provided in the ExpressCard slot when not in use. This will help prevent foreign objects and/or dust getting in to the ExpressCard Slot.

Figure 2 - 4

Left View

1. Express Card Slot

Figure 2 - 5

Inserting &

Removing Express

Cards

Models A & D Models B & C

ExpressCard Slot

The computer is equipped with an ExpressCard/34/54 slot that reads Express Card/ 34 and ExpressCard/54 formats. ExpressCards are the successors to PCMCIA (PC Cards). Make sure you install the Card Reader driver

- 7

ExpressCard/54 is used for applications which require a larger interface slot, e.g. CompactFlash card reader. The number denotes the card width; 54mm for the Express Card/54 and 34mm for the ExpressCard/34.

Inserting and Removing ExpressCards

• Align the ExpressCard with the slot and push it in until it locks into place (as pictured in the generic figure below).

• To remove an ExpressCard, simply press the card to eject it.

(see

“CardReader” on page 4

ExpressCard Slot 2 - 7

Features & Components



TouchPad Scrolling

This computer model series may feature different TouchPad versions.

These TouchPads may differ in their vertical scrolling function in most scrollable windows.

Some TouchPads require sliding the finger up and down on the right of the TouchPad to scroll the window. Other versions require tapping/holding down the finger at the top right or bottom right of the TouchPad to scroll the window.

Figure 2 - 6

Mouse Properties

TouchPad and Buttons/Mouse

The TouchPad is an alternative to the mouse; however, you can also add a mouse to your computer through one of the USB ports. The TouchPad buttons function in much the same way as a two-button mouse.

Once you have installed the TouchPad driver (see “TouchPad” on page 4 - 7) you can configure the functions by double-clicking the TouchPad driver icon on the taskbar. You may then configure the TouchPad tapping, buttons, scrolling (tap the top and bottom right of the TouchPad to scroll), pointer motion and sensitivity options to your preferences.

2 - 8 TouchPad and Buttons/Mouse

Features & Components



Mouse Driver

If you are using an external mouse your operating system may be able to auto-configure your mouse during its installation or only enable its basic functions. Be sure to check the device’s user documentation for details.

Figure 2 - 7

Mouse Properties -

Gesture

Configuration

Gesture Configuration

The Gesture Configuration control allows you to configure specific gesture function settings on the surface of the TouchPad for various applications.

You can configure Gestures from the Finger-sensing Pad tab in Mouse Properties:

1. Click

2. Click Mouse (Hardware and Sound).

3. Click Finger-sensing Pad (tab) and select Click On Pad from Available

4. Click

Start

information and configuration items.

Configure

, and click

Gesture Configuration

Control Panel

(or point to

to access the user configurable settings.

Settings

and click

Control Panel

TouchPad and Buttons/Mouse 2 - 9

Features & Components



Sound Volume

Adjustment

The sound volume level is set using the volume control within Windows (and the volume function keys on the computer). Click the volume icon in the taskbar to check the setting.

Figure 2 - 8

Realtek Audio

Manager

Right-click the icon to access the menu above.

Audio Features

You can configure the audio options on your computer from the Sound control panel in Windows, or from the Realtek HD Audio Manager icon in the taskbar/ control panel (right-click the taskbar icon bring up an audio menu). The volume may also be adjusted by means of the Fn + F5/F6 key combination.

2 - 10 Audio Features

Features & Components

Figure 2 - 9

Sound

Supported Formats

Audio Setup for LCD Monitors/TVs with HDMI Input

Some LCD monitors/TVs support HDMI input, but DO NOT have built-in digital audio decoders. Where this is the case, when playing DVDs in Windows Media Player/CyberLink Power DVD etc., a background noise can occur. If this situation does arise then please follow the instructions below.

1. Click

2. Click Sound (Hardware and Sound).

3. Double-click Realtek Digital Output.

4. Click Supported Formats (tab).

5. Click to disable (remove the check in the box) DTS Audio and Dolby Digital.

6. Click OK and close the control panels.

Start

, and click

Control Panel

(or point to

Settings

and click

Control Panel

Audio Features 2 - 11

Features & Components



Parallel Printer

After setting up the printer attach the parallel cable to the printer.

Connect the printer’s parallel cable to the Parallel to USB converter, and then plug the converter into the USB port.

Turn ON the printer, then turn ON the computer.

Windows will identify the printer and either load one of its own drivers or ask you to supply one. Follow the on-screen instructions.

2 - 12 Adding a Printer

Adding a Printer

The most commonly used peripheral is a printer. The following conventions will help you to add a printer; however it is always best to refer to the printer manual for specific instructions and configuration options.

USB Printer

Most current printers have a USB interface connection. You may use any one of the ports to connect the printer.

Install Instructions:

1. Set up the printer according to its instructions (unp acking, p aper tray, toner/ink cartridge etc.).

2. Turn ON the computer.

3. Turn ON the printer.

4. Connect the printer’s USB cable to one of the USB ports on the computer.

5. Windows will identify the printer and either load one of its own drivers or ask you to supply one. Follow the on-screen instructions.

Parallel Printer

This is still a very common type of printer. The install instructions are in the sidebar, however you will need to purchase a parallel to USB converter.

Chapter 3: Power Management



OS Note

Power management functions will vary slightly depending on your operating system. For more information it is best to refer to the user’s manual of your operating system.

(Note: All pictures used on the following pages are from the Windows Vista OS.)

Hibernate Mode In

Windows Vista SP1

If you are using Windows Vista SP1 with

4GB RAM installed, see page 8 - 12 for information on Hibernate.

Power Management

Overview

To conserve power, especially when using the battery, your computer power management conserves power by controlling individual components of the computer (the monitor and hard disk drive) or the whole system. This chapter covers:

• The Power Sources

• Turning on the Computer

• Power Plans

• Power-Saving States

• Configuring the Power Buttons

• Battery Information

The computer uses enhanced power saving techniques to give the operating system (OS) direct control over the power and thermal states of devices and processors. For example, this enables the OS to set devices into low-power states based on user settings and information from applications.

Overview 3 - 1



Silent Mode

Use the key to toggle Silent Mode to reduce fan noise and save power consumption. Note this may reduce computer performance.

Power Management

The Power Sources

The computer can be powered by either an AC/DC adapter or a battery pack.

AC/DC Adapter

Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ DC adapter will damage the computer and its components.

3 - 2 The Power Sources

1. Attach th e AC/DC adapter to the DC-in jack at the rear of the computer.

2. Plug the AC power cord into an outlet, and then conne ct the AC power co rd to the AC/DC adapter.

3. Raise the lid/LCD to a comfortable viewing angle.

4. Press the power button to turn “On”.

Battery

The battery allows you to use your computer while you are on the road or when an electrical outlet is unavailable. Battery life varies depending on the applications and the configuration you're using. To increase battery life, let the battery discharge completely before recharging (see “How do I completely discharge the battery?”

on page 3 - 14).

We recommend that you do not remove the battery. For more information on the battery, please refer to “Battery Information” on page 3 - 10.

Turning on the Computer



Shut Down

Note that you should always shut your computer down by choosing the Shut Down command from the Lock Button

Menu in Windows Vis- ta. This will help prevent

hard disk or system problems.



Forced Off

If the system “hangs”, and the Ctrl + Alt + Del key combination doesn’t work, press the power button for 4 seconds, or longer, to force the system to turn itself off.

Power Button Sleep

Sleep is the default power mode when the power button is pressed for less than 4 seconds. You may configure the options for the power button from the Power Options (Hardware and Sound menu) control panel in Windows Vista (see your OS’s documentation, or

“Configuring the Power Buttons” on page 3 - 8 for details).

Now you are ready to begin using your computer. To turn it on simply press the power button on the front panel.

When the computer is on, you can use the power button as a Sleep/Hibernate hotkey button when it is pressed for less than 4 seconds (pressing and holding the power button for longer than this will force the computer to shut down). Use Power Op- tions (Hardware and Sound menu) control panel in Windows Vista to configure this feature.

Power Management

Turning on the Computer 3 - 3

Power Management



Resuming Operation

See Table 3 - 1, on

page 3 - 9 for informa-

tion on how to resume from a power-saving state.

Password

It is recommended that you enable a password on system resume in order to protect your data.

Figure 3 - 1

Power Plan

Advanced Settings

Power Plans

The computer can be configured to conserve power by means of power plans. You

can use (or modify) an existing power plan, or create a new one.

3 - 4 Power Plans

The settings may be adjusted to set the display to turn off after a specified time, and to send the computer into Sleep after a period of inactivity.

Click Change plan settings and then click Change advanced power settings to access further configuration options in Advanced Settings.

Each Windows power plan will also adjust the processor performance of your ma-

Figure 3 - 2

Power Plans

chine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power).

Choose High performance for maximum performance when the computer is powered from an AC power source. Choose the Power saver (bear in mind that this scheme may slow down the overall performance of the computer in order to save power) for maximum power saving when the computer is battery (DC power) powered.

Power Management

Power Plans3-5

Power Management



Power Button

The Power Button in the Start Menu (in Classic View use the Shut Down button ) can be used to send the computer into a powersaving state.

Sleep Mode &

Mobile PC Battery

A mobile PC in Sleep uses very little battery power.

After an extended period of time the computer will save any open documents and applications to hard disk.

Power-Saving States

You can use power-saving states to stop the computer’s operation and restart where

you left off. Sleep is the default power-saving state in Windows Vista.

3 - 6 Power-Saving States

Earlier versions of Windows used Stand By and Hibernate as system power-saving states. Windows Vista combines the features of Stand By and Hibernate into the default Sleep power-saving state.

Sleep

In Sleep all of your work, settings and preferences are saved to memory before the system sleeps. When you are not using your computer for a certain length of time, which you specify in the operating system, it will enter Sleep to save power.

The PC wakes from Sleep within seconds and will return you to where you last left off (what was on your desktop) without reopening the application(s) and file(s) you last used.

If your mobile PC in Sleep is running on battery power the system will use only a minimum amount of power. After an extended period the system will save all the information to the hard disk and shut the computer down before the battery becomes depleted.

Hibernate



Hibernate Mode In

Windows Vista SP1

If you are using Windows Vista SP1 with

4GB RAM installed, see page 8 - 12 for information on Hibernate.

Figure 3 - 3

Lock Button Menu

Hibernate uses the least amount of power of all the power-saving states and saves all of your information on a part of the hard disk before it turns the system off. If a power failure occurs the system can restore your work from the hard disk; if a power failure occurs when work is saved only to memory, then the work will be lost. Hi- bernate will also return you to where you last left off within seconds. You should put your mobile PC into Hibernate if you will not use the computer for a period of time, and will not have the chance to charge the battery.

Shut Down

You should shut down the computer if you plan to install new hardware (don’t forget to remove the battery and follow all the safety instructions in Chapter 6), plan to be away from the computer for several days, or you do not need it to wake up and run a scheduled task. Returning to full operation from shut down takes longer than from Sleep or Hibernate.

Power Management

Power-Saving States 3 - 7

Power Management



Password

Protection

It is recommended that you enable a password on wake up in order to protect your data.

However you can disable this setting from the Power Options menu by clicking Require a

password on wakeup

in the left menu, and selecting the options (click

Change settings that are currently unavailable).

Figure 3 - 4

Power Options

Define Power

Buttons

Configuring the Power Buttons

The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the computer in to a power-saving state.

3 - 8 Configuring the Power Buttons

Resuming Operation



Closing the Lid

If you have chosen to send the computer to Sleep when the lid is closed, raising the lid will wake the system up.

Table 3 - 1

Resuming Operation



Power Button

When the computer is on, you can use the power button as a Sleep/Hibernate/Shut Down hot key button when it is pressed for less than 4 seconds (pressing and holding the power button for longer than this will force the computer to shut down).

You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (Fn + F4 key combo).

Power Status

Power Off Off Press the Power Button

Sleep Blinking Green

Hibernate

Display Turned Off Green Press a Key or Move the Mouse/Touchpad

Icon Color

Off (battery)

Orange (AC/DC adapter)

Power Management

To Resume

Press the Power Button

Press the Sleep Button (Fn + F4 Key Combo)

Press the Power Button

Configuring the Power Buttons 3 - 9

Power Management



Low Battery

Warning

When the battery is critically low, immediately connect the AC/DC adapter to the computer or save your work, otherwise, the unsaved data will be lost when the power is depleted.

Figure 3 - 5

Battery Icon

(Taskbar) & Battery

Advanced Settings

Battery Information

Please follow these simple guidelines to get the best use out of your battery.

Battery Power

Your computer’s battery power is dependent upon many factors, including the programs you are running, and peripheral devices attached. You can set actions to be taken (e.g. Shut down, Hibernate etc.), and set critical and low battery levels from power plan Advanced Settings (see Figure 3 - 1 on page 3 - 4).

Click the battery icon in the taskbar to see the current battery level and charge status.

3 - 10 Battery Information

Conserving Battery Power



Wireless Hot Keys

The computer’s wireless function keys will not function properly if Wireless is turned OFF in the Win-

dows Mobility Center

control panel.

The wireless indicators

may show that the WLAN module is powered on, however if wireless is OFF in the Mobility Center, the module will not be powered on.

Make sure that Wireless is ON in the Mobility Center to ensure proper function key behavior.

Figure 3 - 6

Windows Mobility

Center



Windows Mobility

Center

The Windows Mobility Center control pan-

el provides an easy point of access for information on battery status, power plans used and wireless device status etc.

Make sure Wireless is ON to ensure proper function key behavior.

•Use a power plan that conserves power (e.g Power saver), however note that

this may have an affect on computer performance.

• Lower the brightness level of the LCD display. The system will decrease LCD brightness slightly to save power when it is not powered by the AC/DC adapter.

• Reduce the amount of time before the display is turned off.

• Close wireless, Bluetooth, modem or communication applications when they are not being used.

• Disconnect/remove any unnecessary external devices e.g. USB devices, ExpressCards etc.

Power Management

Battery Information 3 - 11

Power Management

Battery Life

Battery life may be shortened through improper maintenance. To optimize the life

and improve its performance, fully discharge and recharge the battery at least once every 30 days.

We recommend that you do not remove the battery yourself. If you do need to remove the battery for any reason (e.g. long term storage) see “Removing the Battery”

on page 6 - 3.

New Battery

Always completely discharge, then fully charge, a new battery (see “Battery FAQ”

on page 3 - 14 for instructions on how to do this).

Recharging the Battery with the AC/DC Adapter

The battery pack automatically recharges when the AC/DC adapter is attached and plugged into an electrical outlet. If the computer is powered on, and in use, it will take several hours to fully recharge the battery. When the computer is turned off but plugged into an electrical outlet, battery charge time is less. (Refer to “LED Indica-

tors” on page 1 - 9 for information on the battery charge status, and to “Battery Information” on page 3 - 10 for more information on how to maintain and properly

recharge the battery pack.)

3 - 12 Battery Information

Proper handling of the Battery Pack



Caution

Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type recommended by the manufacturer. Discard used battery according to the manufacturer’s instructions.



Damaged Battery Warning

Should you notice any physical defects (e.g. the battery is bent ou t of shape after being dropped), or any unusual smells emanating from the notebook battery, shut your computer down immediately and contact your service center. If the battery has bee n d roppe d we do not recommend using it any further, as even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire . It is recommended that you replace your computer battery every two years.

• DO NOT disassemble the battery pack under any circumstances

• DO NOT expose the battery to fire or high temperatures, it may explode

• DO NOT connect the metal terminals (+, -) to each other

Power Management

Battery Information 3 - 13

Power Management

Figure 3 - 7

Power Plan Create

Battery FAQ

How do I completely discharge the battery?

Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.

1. Save and close all files and application s.

2. Create a power plan for discharging the battery and set all the options to Never.

3. Click Change plan settings (after saving it) and click Change advanced power settings.

3 - 14 Battery Information

4. Scroll down to Battery and click + to expand the ba ttery options.

Figure 3 - 8

Power Options

Advanced Settings -

Battery

5. Choose the options below (click Yes if a warning appears):

• Low battery levels = 0%

• Critical battery Levels = 0%

• Low battery action = Do Nothing

• Critical battery action (On battery) = Shut Down

• Critical battery action (Plugged in) = Do Nothing

Power Management

Battery Information 3 - 15

Power Management

How do I fully charge the battery?

When charging the battery, don’t stop until the LED charging indicator light changes from orange to green.

How do I maintain the battery?

Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.

3 - 16 Battery Information

Chapter 4: Drivers & Utilities

Drivers & Utilities

This chapter deals with installing the drivers and utilities essential to the operation or improvement of some of the computer’s subsystems. The system takes advantage of some newer hardware components for which the latest versions of most available operating systems haven’t built in drivers and utilities. Thus, some of the system components won’t be auto-configured with an appropriate driver or utility during operating system installation. Instead, you need to manually install some system-required drivers and utilities.

RAID & AHCI Setup

Note that setting up a RAID, or AHCI mode, needs to be done prior to installing the Windows OS, and therefore before installing the other drivers listed here (see

“Setting Up SATA RAID or AHCI Modes” on page 7

- 52).

What to Install

The Device Drivers & Utilities + User’s Manual disc contains the drivers and utilities necessary for the proper operation of the computer.

Table 4 - 1, on page 4 - 3 lists what you need to install

and it is very important that the drivers are in- stalled in the order indicated (see “Driver Installa-

tion” on page E - 27 for Windows 7 information).

Module Driver Installation

The procedures for installing drivers for the PC Camera, Wireless LAN, Fingerprint, 3.75G/HSPA, TV Tuner (Consumer Infrared), 3D Shutter Glasses Kit and RAID modules are provided in “Modules &

Options” on page 7 - 1.

What to Install 4 - 1

Drivers & Utilities

Driver Installation

Insert the Device Drivers & Utilities + User’s Manual disc and click Install Drivers/Option Drivers (button).

If you wish to install the drivers manually see overleaf for the driver path information

1. Check the driver installation order from Table 4 - 1,

on page 4 - 3 (the drivers must be installed in

this order) which is the same as that listed in the

Drivers Installer menu below.

2. Click to select the driver you wish to install, (you should note down the drivers as you install them).

3. Follow the instructions for each individual driver installation procedure as listed on the following pages.

Note: If you need to reinstall any driver, you should uninstall the driver first

Figure 4 - 1 - Drivers Installer Screen 1

4 - 2 Driver Installation

Figure 4 - 2 - Drivers Installer Screen 2

Drivers & Utilities

Driver - Windows Vista with Service Pack 2

Chipset Page 4 - 5 PC Camera Module Page 7 - 8 NVIDIA Video

ATI Video Modem Page 4 - 6 Fingerprint Reader Module Page 7 - 22 LAN Page 4 - 6 3.75G/HSPA Module (Models A & D Only) Page 7 - 40 Firewire (IEEE 1394) Page 4 - 6 TV Tuner Module (Models B & C Only) Page 7 - 46 CardReader Page 4 - 7 NVIDIA 3D Shutter Glasses Kit Page 7 - 48

TouchPad Page 4 - 7

Hot Key Page 4 - 7 USB 3.0 Page 4 - 7 Audio Page 4 - 7

Page

Page 4 - 6 Wireless LAN Module Page 7 - 17

Driver - Windows Vista with Service Pack 2

Setting Up SATA RAID or AHCI Modes

(RAID for Models B & C Only)

Page

Page 7 - 52

Table 4 - 1 - Driver Installation

Manual Driver Installation

Click Browse CD/DVD (button) in the Drivers Installer application and browse to the executable file in the appropriate driver folder.

Driver Installation 4 - 3

Drivers & Utilities



Windows Vista Service Pack 2

Make sure you install Windows Vista Service Pack 2 (or a Windows Vista version which includes Service Pack 2) before installing any drivers. Go to the Microsoft website for download details, or contact your service center.

Windows Update

After installing all the drivers make sure you enable Windows Update in order to get all the latest securi ty updates etc. (all updates will include the latest hotfixes from Microsoft). See “Windows Update” on page 4 -

8 for instructions.

4 - 4 Driver Installation

Updating/Reinstalling Individual Drivers

If you wish to update/reinstall individual drivers it may be necessary to uninstall the original driver.To do this go to the Control Panel in the Windows OS and double-click the Programs and Features icon (Pro- grams > Uninstall a program). Click to select the driver (if it is not listed see below) and click Uninstall, and then follow the on screen prompts (it may be necessary to restart the computer). Reinstall the driver as outlined in this chapter.

If the driver is not listed in the Programs and Fea- tures menu:

1. Click Start, and click Control Panel (or point to Settings and click Control Panel).

2. Double-click Device Manager (Hardware and Sound > Device Manager).

3. Double-click the device you wish to update/reinstall the driver for (you may need to click “+” to expand the selection).

4. Click Driver (tab) and click the Update Driver or

Uninstall button and follow the on screen prompts.

User Account Control (Win Vista)



Driver Installation General Guidelines

The driver installation procedure outlined in this Chapter (and in Chapter 7 Options & Modules), are accurate at the time of going to press.

Drivers are always subject to upgrade and revision so the exact procedure for certain drivers may differ slightly. As a general guide follow the default on screen instructions for each driver (e.g. Next > Next > Finish) unless you are an advanced user. In many cases a restart is required to install the driver.

If a User Account Control prompt appears as part of the driver installation procedure, click Continue or Allow, and follow the installation procedure as directed.

Windows Security Message

If you receive a Windows security message as part of the driver installation process. Just click “Install this driver software anyway” or “Install” to continue the installation procedure.

You will receive this message in cases where the driver has been released after the version of Windows you are currently using. All the drivers provided will have already received certification for Windows.

New Hardware Found

If you see the message “New Hardware Found” dur- ing the installation procedure (other than when out- lined in the driver install procedure), click Cancel to close the window, and follow the installation procedure.

Drivers & Utilities

Driver Installation Procedure

Insert the Device Drivers & Utilities + User’s Manual disc and click Install Drivers (button).

Chipset

1. Click 1.Install Chipset Driver > Yes.

2. Click Next > Yes > Next > Next.

3. Click Finish to restart the computer.

Driver Installation 4 - 5

Drivers & Utilities

NVIDIA Video

1. Click 2.Install Video Driver > Yes.

2. Click Next > Next.

3. Click Finish to restart the computer.

ATI Video

1. Click 2.Install Video Driver > Yes.

2. Click Next > Install (button).

3. Click the Express (or Custom if you prefer to

manually configure the driver installation settings) button and click Next.

4. Click Accept (button) and click Yes.

5. Click Finish > Yes to restart the computer.

Modem

1. Click 3.Install Modem Driver > Yes.

2. Click OK.

3. The modem is ready for dial-up configuration.

LAN

Make sure you have plugged the network cable in before installing the driver.

1. Click 4.Install LAN Driver > Yes.

2. Click Next > Install.

3. Click Finish.

4. The network settings can now be configured.

Firewire (IEEE 1394)

1. Click 5.FireWire drivers > Yes.

2. Click Install.

3. Click Finish.

4 - 6 Driver Installation

Drivers & Utilities

CardReader

1. Click 6.Install Cardreader Driver > Yes.

2. Click Install.

3. Click Finish.

TouchPad

1. Click 7.Install Touchpad Driver > Yes.

2. Choose the language you prefer and click OK.

3. Click Next > Finish.

4. Click Restart Now to restart the computer.

Hot Key

1. Click 8.Install Hotkey Utility > Yes.

2. Click Next > Next.

3. Click Finish > Finish to restart the computer.

USB 3.0

1. Click 9.Install USB 3.0 Driver > Yes.

2. Click Next.

3. Click the button to accept the license and then click Next.

4. Click Next > Install.

5. Click Finish.

Audio

1. Click 10.Install Audio Driver > Yes.

2. Click Next.

3. Click Finish to restart the computer.

Note that after installing the audio driver the system will not return to the Drivers Installer screen. To install any of the optional drivers listed overleaf, eject the Device Drivers & Utilities + User’s Manual disc and then reinsert it (or double-click the disc icon in My Computer), and click Option Drivers (button) to access the optional driver menu.

Driver Installation 4 - 7

Drivers & Utilities



Windows Update

After installing all the drivers make sure you enable Windows Update in order to get all the latest security up-

dates etc. (all updates will include the latest hotfixes from Microsoft).

To enable Windows Update make sure you are con- nected to the internet:

1. Click Start, and click Control Panel (or point to Settings and click Control Panel).

2. Click Check for updates (Security), or double-click Security Center and click Windows Update.

3. Double-click Check for updates (button).

4. The computer will now check for updates (you need to be connected to the internet).

5. Click Install now (button) to install the updates.

Optional Drivers

See the pages indicated for the driver installation procedures for any modules included in your purchase option.

4 - 8 Driver Installation

Figure 4 - 3 - Drivers Installer - Option Drivers Menu

Drivers & Utilities

Bluetooth Module

Note: The operating system is the default setting for Bluetooth control in Windows Vista, and does not re-

quire a driver. See “Bluetooth Module” on page 7 - 2 for configuration instructions.

PC Camera Module

See the introduction in “PC Camera Module” on

page 7 - 7, and check the installation procedure.

Wireless LAN Module

See the introduction in “Wireless LAN Module” on

page 7 - 16, and check the installation procedure.

Fingerprint Reader Module

See the introduction in “Fingerprint Reader Module”

on page 7 - 22, and check the installation procedure.

3.75G/HSPA Module (Models A & D Only)

See the introduction in “3.75G/HSPA Module” on

page 7 - 27, and check the installation procedure.

TV Tuner Module (Models B & C Only)

See the introduction in “TV Tuner Module” on page 7

- 45, and check the installation procedure for the Con-

sumer Infrared (CIR) driver.

NVIDIA 3D Shutter Glasses (Model D Only)

See the introduction in “NVIDIA 3D Shutter Glasses

Kit” on page 7 - 48. The NVIDIA Video Driver is re-

quired to support the 3D glasses.

RAID and AHCI Configuration

(RAID for Models B & C Only)

See the configuration instructions in “Setting Up

SATA RAID or AHCI Modes” on page 7 - 52.

Driver Installation 4 - 9

Drivers & Utilities

4-10

Chapter 5: BIOS Utilities



BIOS Screens

Note that the BIOS screens pictured on the following pages are intended for guidance in setting up your system’s BIOS.

BIOS versions are subject to constant change and revision, therefore your computer’s actual screens may appear slightly different from those pictured on the following pages.

Overview

This chapter gives a brief introduction to the computer’s built-in software:

Diagnostics: The POST (Power-On Self Test)

Configuration: The Setup utility

If your computer has never been set up, or you are making impo rtant changes to the system (e.g. hard disk setup), then you should review this chapter first and note the original settings found in Setup. Even if you are a beginner, keep a record of the settings you find and any changes you make. This information could be useful if your system ever needs servicing.

There is one general rule: Don’t make any changes unless you are sure of what you are doing. Many of the settings are required by the system, and changing them could cause it to become unstable or worse. If you have any doubts, consult your service representative.

BIOS Utilities

Overview 5 - 1

BIOS Utilities



BIOS Settings

Warning

Incorrect settings can cause your system to malfunction. To correct mistakes, return to Set-

up and restore the Setup Defaults with <F9>.

The Power-On Self Test (POST)

Each time you turn on the computer, the system takes a few seconds to conduct a POST, including a quick test of the on-board RAM (memory).

As the POST proceeds, the computer will tell you if there is anything wrong. If there is a problem that prevents the system from booting, it will display a system summary and prompt you to run Setup.

If there are no problems, the Setup prompt will disappear and the system will load the operating system. Once that starts, you can’t get into Setup without rebooting.

5 - 2 The Power-On Self Test (POST)

Failing the POST

Errors can be detected during the POST. There are two categories, “fatal” and “nonfatal”.

Fatal Errors

These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.

Non-Fatal Errors

This kind of error still allows you to boot. You will get a message identifying the problem (make a note of this message!) followed by the prompt:

• Press <F1> to resume

• <F2> to enter Setup

Press F1 to see if the boot process can continue. It may work, without the correct configuration.

BIOS Utilities

Press F2 to run the Setup program and try to correct the problem. If you still get an error message after you change the setting, or if the “cure” seems even worse, call for help.

The Power-On Self Test (POST) 5 - 3

BIOS Utilities

The Setup Program

The Phoenix Setup program tells the system how to configur e itself and manage ba- sic features and subsystems (e.g. port configuration).

Entering Setup

To enter Setup, turn on the computer and press F2 during the POST. The prompt

(Press F2 to Enter Setup) seen on page 5 - 2 is usually present for a few seconds after you turn on the system. If you get a “Keyboard Error”, (usually because you pressed F2 too quickly) just press F2 again.

If the computer is already on, reboot using the Ctrl + Alt + Delete combination and then hold down F2 when prompted. The Setup main menu will appear.

5 - 4 The Setup Program

Setup Screens



Setup Menus

The Setup menus shown in this section are for reference only. Your computer’s menus will indicate the configuration appropriate for your model and options.

The following pages contain additional advice on portions of the Setup.

Along the top of the screen is a menu bar with menu headings. When you select a heading, a new screen appears. Scroll through the features listed on each screen to make changes to Setup.

BIOS Utilities

Instructions on how to navigate each screen are in the box along the bottom of the screen. If these tools are confusing, press F1 to call up a General Help screen, and then use the arrow keys to scroll up or down the page.

The Item Specific Help on the right side of each screen explains the highlighted item and has useful messages about its options.

If you see an arrow next to an item, press Enter to go to a sub-menu on that subject. The sub-menu screen that appears has a similar layout, but the Enter key may execute a command.

The Setup Program 5 - 5

BIOS Utilities

Figure 5 - 1

Main Menu

System Time & Date (Main Menu)

The hour setting uses the 24-hour system (i.e., ØØ = midnight; 13 = 1 pm). If you can change the date and time settings in your operating system, you will also change these settings. Some applications may also alter data files to reflect these changes.

5-6Main Menu

SATA Port 1/2/3/4/5 (Main Menu)

Pressing Enter opens the sub-menu to show the configuration of an HDD/optical de- vice on the computer’s SATA Port 1/2/3/4/5. Use the Auto (Type:) setting to have the items configured automatically for you.

System/Extended Memory (Main Menu)

This item contains information on the system memory, and is not user configurable. The system will auto detect the amount of memory installed.

BIOS Revision/KBC/EC Firmware Revision (Main Menu)

This item contains information on the current BIOS and firmware versions.

VGA Card/VBIOS Revision/VBIOS Build Date (Main Menu)

This item contains information on the current videos card installed, and on the Video BIOS version.

BIOS Utilities

Main Menu 5 - 7

BIOS Utilities

Advanced Menu

Advanced Chipset Control

The sub-menu here allows you to enable/disable Extreme Edition control, if applicable to your system.

5 - 8 Advanced Menu

SATA Mode Selection (Advanced Menu)



SATA Mode

Selection

If you have installed the Windows Vista operating system with either AHCI or RAID mode enabled, DO NOT disable the set mode (if you wish to disable the set mode you will need to reinstall the Windows VIsta OS).

Figure 5 - 2

Advanced Menu

You may enable/disable SATA RAID or AHCI mode for your hard disks, however you should only enable/disable RAID or AHCI BEFORE installing an operating system, and after you have backed up all necessary files and data (see sidebar).

Legacy USB Support (Advanced Menu)

Choose “Enabled” if you intend to use USB devices in systems which do not normally support USB functionality (e.g. DOS). The default setting is “Enabled” and does not need to be changed if you intend to use your USB devices in Windows.

Boot-time Diagnostic Screen (Advanced Menu)

Use this menu item to enable/disable the Boot-time Diagnostic Screen or Power-On Self Test.

Legacy OS Boot (Advanced Menu)

Enable this item to support only system boot from the Legacy OS (e.g Windows Vista). If disabled the system will attempt to boot from the EFI (Extensible Firmware

Interface) before the Legacy OS.

Power On Boot Beep (Advanced Menu)

Use this menu item to enable/disable the beep as the computer starts up.

Battery Low Alarm Beep (Advanced Menu)

Use this menu item to enable/disable the battery low alarm beep.

BIOS Utilities

Advanced Menu 5 - 9

BIOS Utilities



Security Menu

The changes you make here affect the access to the Setup utility itself, and also access to your machine as it boots up after you turn it on. These settings do not affect your machine or network passwords which will be set in your software OS.

Figure 5 - 3

Security Menu

5 - 10 Security Menu

Set Supervisor Password (Security Menu)

You can set a password for access to the Phoenix SecureCore Setup Utility. This will not affect access to the computer OS, (only the Phoenix SecureCore Setup Utility).

Set User Password (Security Menu)



Password Warning

If you set a boot password (Password on boot is “Enabled“), NEVER forget your password.

The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk.

You can set a password for user mode access to the Phoenix SecureCore Setup Utility. This will not affect access to the computer OS, (only the Setup utility) unless you choose to set a Password on Boot (see below). Many menu items in the Phoenix SecureCore Setup Utility cannot be modified in user mode. You can only set the

user password after you have set the supervisor password.

Password on boot (Security Menu)

Specify whether or not a password should be entered to boot the computer (you may only set a password on boot if a supervisor password is enabled). If “Enabled” is selected, only users who enter a correct password can boot the system (see the warning in the sidebar). The default setting is “Disabled”.

Note: To clear existing passwords press Enter and type the existing password, then

press Enter for the new password (without typing any password entry) and Enter again to confirm the password clearance.

BIOS Utilities

Security Menu 5 - 11

BIOS Utilities

Figure 5 - 4

Boot Menu

When you turn the computer on it will look for an operating system (e.g. Windows Vista) from the devices listed in this menu, and in this priority order. If it cannot

find the operating system on that device, it will try to load it from the next device in the order specified in the Boot priority order. Item specific help on the right is available to help you move devices up and down the order.

5 - 12 Boot Menu

Exit Menu

Figure 5 - 5

Exit Menu

Choosing to Discard Changes, or Exit Discarding Changes, will wipe out any changes you have made to the Setup. You can also choose to restore the original Set- up defaults that will return the Setup to its original state, and erase any previous changes you have made in a previous session.

BIOS Utilities

Exit Menu 5 - 13

BIOS Utilities

5-14

Clevo W880CU User guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Preface

Chapter 1: Quick Start Guide

Overview

Advanced Users

Beginners and Not-So-Advanced Users

Warning Boxes

Not Included

System Startup

System Software

RAID & AHCI Setup

Model Differences

System Map: Front View - Models A & D

System Map: Front View - Models B & C

LED Indicators

Hot Key Buttons & Keyboard

Keyboard

Function/Hot Key Indicators

System Map: Left View

System Map: Right View

System Map: Rear View

System Map: Bottom View - Models A & D

System Map: Bottom View - Model B

System Map: Bottom View - Model C

Windows Vista Start Menu & Control Panel

Video Features

Power Options

Chapter 2: Features & Components

Overview

Hard Disk Drive

Optical (CD/DVD) Device

Loading Discs

Handling CDs or DVDs

DVD Regional Codes

7-in-1 Card Reader

ExpressCard Slot

Inserting and Removing ExpressCards

TouchPad and Buttons/Mouse

Gesture Configuration

Audio Features

Audio Setup for LCD Monitors/TVs with HDMI Input

Parallel Printer

Adding a Printer

USB Printer

Chapter 3: Power Management

Overview

The Power Sources

AC/DC Adapter

Battery

Turning on the Computer

Power Plans

Power-Saving States

Sleep

Hibernate

Shut Down

Configuring the Power Buttons

Resuming Operation

Battery Information

Battery Power

Conserving Battery Power

Battery Life

New Battery

Recharging the Battery with the AC/DC Adapter

Proper handling of the Battery Pack

Battery FAQ

Chapter 4: Drivers & Utilities

RAID & AHCI Setup

What to Install

Module Driver Installation

Driver Installation

Updating/Reinstalling Individual Drivers

User Account Control (Win Vista)

Windows Security Message

New Hardware Found

Driver Installation Procedure

Chipset

NVIDIA Video
