Clevo W510LU, W515LU User guide

V15.1.00

Preface

Notice
The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication. This publication and any accompanying software may not, in whole or in part, be reproduced, translated, trans­mitted or reduced to any machine readable form without prior consent from the vendor, manufacturer or creators of this publication, except for copies kept by the user for backup purposes. Brand and product names mentioned in this publication may or may not be copyrights and/or registered trade­marks of their respective companies. They are mentioned for identification purposes only and are not intended as an endorsement of that product or its manufacturer. ©June 2015
Trademarks
Intel, Pentium and Intel Core are trademarks/registered trademarks of Intel Corporation.
I
Preface
R&TTE Directive
This device is in compliance with the essential requirements and other relevant provisions of the R&TTE Direc­tive 1999/5/EC.
This device will be sold in the following EEA countries: Austria, Italy, Belgium, Liechtenstein, Denmark, Lux­embourg, Finland, Netherlands, France, Norway, Germany, Portugal, Greece, Spain, Iceland, Sweden, Ireland, United Kingdom, Cyprus, Czech Republic, Estonia, Hungary, Latvia, Lithuania, Malta, Slovakia, Poland, Slov­enia.
ErP Off Mode Power Consumption Statement:
The figures below note the power consumption of this computer in compliance with European Commission (EC) regulations on power consumption in off mode:
Off Mode < 0.5W
II
Preface
CE Marking
This device has been tested to and conforms to the regulatory requirements of the European Union and has at­tained CE Marking. The CE Mark is a conformity marking consisting of the letters “CE”. The CE Mark applies to products regulated by certain European health, safety and environmental protection legislation. The CE Mark is obligatory for products it applies to: the manufacturer affixes the marking in order to be allowed to sell his product in the European market.
This product conforms to the essential requirements of the R&TTE directive 1999/5/EC in order to attain CE Marking. A notified body has determined that this device has properly demonstrated that the requirements of the directive have been met and has issued a favorable certificate of expert opinion. As such the device will bear the notified body number 0560 after the CE mark.
The CE Marking is not a quality mark. Foremost, it refers to the safety rather than to the quality of a product. Secondly, CE Marking is mandatory for the product it applies to, whereas most q uality marking s are vo lu ntary.
III
Preface
FCC Statement
(Federal Communications Commission)
You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not in­stalled and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Re orient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the service representative or an experienc ed radio/TV technician for help.
Operation is subject to the following two conditions:
1. This device may not cause interference. And
2. This device must accept any interference, including interfer ence that may cause undesired operation of the
device.
IV
FCC RF Radiation Exposure Statement:
Warning
Use only shielded cables to connect I/O devices to this equipment. You are cautioned that changes or modifications not ex­pressly approved by the manufacturer for compliance with the above standard s could void your authority to operate the equipment.
1. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
2. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.
Preface
V
Preface
IMPORTANT SAFETY INSTRUCTIONS
Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment:
1. Do not use this product near water, for example n ear a ba th tub, wash bowl, kitchen sink or laundry tu b, in a wet
basement or near a swimming pool.
2. Avoid using this equipment with a telephone line (other than a cordless type) during an electrical storm. There
may be a remote risk of electrical shock from lightning.
3. Do not use the telephone to report a gas leak in the vicinity of the leak.
4. Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may
explode. Check with local codes for possible special disposal instructions.
5. This product is intended to be supplied by a Listed Power Unit according to the model’s requirements:
Full Range AC/DC Adapter - AC Input 100 - 240V, 50 - 60Hz, DC Output 19V, 2.1A (40W) minimum.
VI
Preface
Instructions for Care and Operation
The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions:
1. Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged.
Do not expose the computer to any shock or vibration.
Do not place it on an unstable surface.
Do not place anything heavy on the computer.
2. Keep it dry, and don’t overheat it. Keep the computer and power supply away from any kind of heating ele-
ment. This is an electrical appliance. If water or any other liquid gets into it, the computer could be badly dam­aged.
Do not expose it to excessive heat or direct sunlight.
Do not leave it in a place where foreign matter or mois­ture may affect the system.
Don’t use or store the com­puter in a humid environment.
Do not place the computer on any surface that will block the Vents/Fan Intakes.
VII
Preface
3. Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other
strong magnetic fields. These can hinder proper performance and damage your data.
4. Follow the proper workin g procedu res for t he computer. Shut the computer down properly and don’t forget
to save your work. Remember to periodically save your data as data may be lost if the battery is depleted.
Do not turn off the power until you properly shut down all programs.
Do not turn off any peripheral devices when the computer is on.
5. Take care when using peripheral devices.
Use only approved brands of peripherals.
VIII
Do not disassemble the com­puter by yourself.
Unplug the power cord befor e attaching peripheral devices.
Perform routine maintenance on your computer.
Servicing
Bottom Cover Removal Warning
Do not remove any cover(s) and /or screw(s) for the purposes of device upgrade as this may violate the terms of your war­ranty. If you need to replace/remove the hard disk/RAM/optical device etc., for any reason, ple ase contact your distribu tor/ supplier for further information.
Removal Warning
When removing any cover(s) and screw(s) for the purposes of device upg rade, remember to replace the cover(s) and screw(s) before restoring power to the system.
Also note the following when the cover is removed:
Hazardous moving parts.
Keep away from moving fan blades.
Do not attempt to service the computer yourself. Doing so may violate your warranty and may expose you and the computer to electric shock. Refer all servicing to authorized service personnel. Unplug the computer from the power supply. Then refer servicing to qualified service personnel under any of the following conditions:
When the power cord or AC/DC adapter is damaged or frayed.
If the computer has been exposed to rain or other liquids.
If the computer does not work normally when you follow the operating instructions.
If the computer has been dropped or damaged (do not touch the poisonous liquid if the LCD panel breaks).
If there is an unusual odor, heat or smoke coming from your computer.
Preface
IX
Preface
Power Safety Warning
Before you undertake any upgrade proce­dures, make sure that you have turned off the power, and disconnect­ed all peripherals and cables (including tele­phone lines and power cord).
You must also remove your battery in order to prevent accidentally turning the machine on.
Before removing the battery disconnect the AC/DC adapter from the computer.
Power Safety
The computer has specific power requirements:
• Only use a power adapter approved for use with this computer.
• Your AC/DC adapter may be designed for international travel but it still requires a steady, uninterrupted power supply. If you are unsure of your local power specifica­tions, consult your service representative or local power company.
• The power adapter may have either a 2-prong or a 3-prong grounded plug. The third prong is an important safety feature; do not defeat its purpose. If you do not have access to a compatible outlet, have a qualified electrician install one.
• When you want to unplug the powe r co rd, be sure to di sconn ect it b y the plug head , no t by its wire.
• Make sure the socket and any extension cord(s) you use can support the total current load of all the connected devices.
• Before cleaning the computer, make sure it is disconnected from any external power supplies (i.e. AC/DC adapter or car adapter).
Do not plug in the power cord if you are wet.
Do not use the power cord if it is broken.
Do not place heavy objects on the power cord.
X
Preface
Polymer Battery Precautions
Note the following information which is specific to polymer batteries only, and where applicable, this overrides the general battery precaution information overleaf.
Polymer batteries may experience a slight expansion or swelling, however this is part of the battery’s safety mecha­nism and is not a cause for concern.
Use proper handling procedures when using polymer batteries. Do not use polymer batteries in high ambient tempera­ture environments, and do not store unused batteries for extended periods.
See also the general battery precautionary information overleaf for further information.
XI
Preface
Battery Disposal & Caution
The product that you have purchased contains a rechargeable battery. The battery is recyclable. At the end of its useful life, under various state and local laws, it may be illegal to dispose of this battery in to the municipal waste stream. Check with your local solid waste officials for details in your area for recycling options or proper disposal.
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalen t type recommended by the manufacturer. Discard used battery according to the manufacturer’s instructions.
General Battery Precautions
Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer.
Do not remove any batteries from the computer while it is powered on.
Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
If you do not use the battery for an extended period, then remove the battery from the computer for storage.
Recharge the batteries using the notebook’s system. Incorrect recharging may make the battery explode.
Do not try to repair a battery pack. Refer any battery pack repa ir or replacemen t to you r service repre sentati ve or qu al­ified service personnel.
Keep children away from, and promptly dispose of a damaged battery. Always dispose of batteries carefully. Batteries may explode or leak if exposed to fire, or improperly handled or discarded.
Keep the battery away from metal appliances.
Affix tape to the battery contacts before disposing of the battery.
Do not touch the battery contacts with your hands or metal objects.
XII
Cleaning
Removal Warning
When removing any cover(s) and screw(s) for the purposes of device upg rade, remember to replace the cover(s) and screw(s) before restoring power to the system.
Also note the following when the cover is removed:
Hazardous moving parts.
Keep away from moving fan blades.
Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer.
Servicing
Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock. Refer all servicing to authorized service personnel. Unplug the computer from the power supply and then refer servicing to qualified service personnel under any of the following conditions:
When the power cord or AC/DC adapter is damaged or frayed.
If the computer has been exposed to rain or other liquids.
If the computer does not work normally when you follow the operating instructions.
If the computer has been dropped or damaged (do not touch the poisonous liquid if the LCD panel breaks).
If there is an unusual odor, heat or smoke coming from your computer.
Preface
XIII
Preface
Power Off Before Traveling
Make sure that your notebook is completely powered off before putting it into a travel bag (or any such container). Putting a notebook which is powered on in a travel bag may cause the Vents/Fan Intakes to be blocked. To pre vent your computer from overheating make sure nothing blocks the Vent/Fan Intakes while the computer is in use.
Travel Considerations
As you get ready for your trip, run through this list to make sure the system is ready to go:
1. Check that the battery pack and any spares are fully charged.
2. Power off the computer and peripherals.
3. Close the display panel and make sure it’s latched.
4. Disconnect the AC/DC adapter and cables. Stow them in the carrying bag.
5. The AC/DC adapter uses volt ages from 100 to 240 volt s so you won’t need a second volt age adapter. However,
check with your travel agent to see if you need any socket adapters.
6. Put the notebook in its carrying bag and secure it with the bag’s straps.
7. If you’re taking any perip herals (e.g. a printer, mouse or digital camera), pack them and those devices’ adapters
and/or cables.
8. Anticipate customs - Some jurisdictions may have import restrictions or req uire proof of ownersh ip for both hard -
ware and software. Make sure your “papers” are handy.
XIV
Preface
On the Road
In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind:
Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common. Don’t check it with “normal” luggage. Baggage handlers may not be sufficiently careful. Avoid knock­ing the computer against hard objects.
Beware of Electromagnetic fields - Devices such as metal detectors & X-ray machines can damage the com­puter, hard disk, floppy disks, and other media. They may also destroy any stored data - Pass your computer and disks around the devices. Ask security officials to hand-inspect them (you may be asked to turn it on). Note: Some airports also scan luggage with these devices.
Fly safely - Most airlines have regulations about the use of computers and other electronic devices in flight. These restrictions are for your safety, follow them. If you stow the notebook in an overhead compartment, make sure it’s secure. Contents may shift and/or fall out when the compartment is opened.
Get power where you can - If an electrical outlet is available, use the AC/DC adapter and keep your battery(ies) charged.
Keep it dry - If you move quickly from a cold to a warm location, water vapor can condense inside the computer. Wait a few minutes before turning it on so that any moisture can evaporate.
XV
Preface
Developing Good Work Habits
Developing good work habits is important if you need to work in fron t of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints. The following are some tips to reduce the strain:
Adjust the height of the chair and/or desk so that the keyboard is at or slightly below the level of your elbow. Keep your forearms, wrists, and hands in a relaxed position.
Your knees should be slightly higher than your hips. Place your feet flat on the floor or on a footrest if necessary.
Use a chair with a back and adjust it to support your lower back comfortably.
Sit straight so that your knees, hips and elbows form approximately 90-degree angles when you are working.
Take periodic breaks if you are using the computer for long periods of time.
Remember to:
Alter your posture frequently.
Stretch and exercise your body several times a day.
Take periodic breaks when yo u work at the computer for long periods of time. Frequent and short breaks are better than fewer and longer breaks.
XVI
Preface
Lighting
Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders.
Position the display to avoid glare or reflections from overhead lighting or outside sources of light.
Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly.
Position the display directly in front of you at a comfortable viewing distance.
Adjust the display-viewing angle to find the best position.
LCD Screen Care
To prevent image persistence on LCD monitors (caused by the continuous display of graphics on the screen for an extended period of time) take the following precautions:
Set the Windows Power Plans to turn the screen off after a few minutes of screen idle time.
Use a rotating, moving or blank screen saver (this prevents an image from being displayed too long).
Rotate desktop background images every few days.
Turn the monitor off when the system is not in use.
LCD Electro-Plated Logos
Note that in computers featuring a raised LCD electro-plated logo, the logo is covered by a protective adhesive. Due to general wear and tear, this adhesive may deteriorate over time and the exposed logo may develop sharp edges. Be careful when handling the computer in this case, and avoid touching the raised LCD electro-plated logo. Avoid placing any other items in the carrying bag which may rub against the top of the computer during transport. If any such wear and tear develops contact your distributor/supplier.
XVII
Preface
XVIII
Preface

Contents

Notice .............................................................................................................................................................I
ErP Off Mode Power Consumption Statement: ...........................................................................................II
FCC Statement ............................................................................................................................................IV
FCC RF Radiation Exposure Statement: .....................................................................................................V
Instructions for Care and Operation ......................................................................................................... VII
Servicing .....................................................................................................................................................IX
Power Safety ................................................................................................................................................X
Polymer Battery Precautions ......................................................................................................................XI
General Battery Precautions ..................................................................................................................... XII
Cleaning ...................................................................................................................................................XIII
Servicing ..................................................................................................................................................XIII
Travel Considerations ..............................................................................................................................XIV
Quick Start Guide
Overview ....................................................................................................................................................1-1
Advanced Users .........................................................................................................................................1-2
Beginners and Non-Advanced Users .........................................................................................................1-2
Warning Boxes ..........................................................................................................................................1-2
Not Included ..............................................................................................................................................1-3
System Startup ...........................................................................................................................................1-4
System Software ........................................................................................................................................1-5
XIX
Preface
System Map: LCD Panel Open ..................................................................................................................1-6
LED Indicators ...........................................................................................................................................1-7
Keyboard ....................................................................................................................................................1-8
Keyboard Shortcuts ...................................................................................................................................1-9
Function/Hot Key Indicators ...................................................................................................................1-10
Control Center .........................................................................................................................................1-11
System Map: Front & Left Views ...........................................................................................................1-12
System Map: Right & Rear Views ..........................................................................................................1-13
System Map: Bottom View .....................................................................................................................1-14
Removing the Battery ..............................................................................................................................1-15
Inserting the Battery ................................................................................................................................1-16
Windows 8.1 Control Panel .....................................................................................................................1-17
Windows 8.1 Start Screen & Desktop .....................................................................................................1-20
Apps & Tiles ............................................................................................................................................1-21
Desktop Application ................................................................................................................................1-22
The Charms Bar .......................................................................................................................................1-23
Windows 8.1 Taskbar ..............................................................................................................................1-25
Video Features .........................................................................................................................................1-26
To Configure Displays from Devices (Charms Bar): ..............................................................................1-26
Power Options .........................................................................................................................................1-29
Shut Down, Restart or Sleep (Charms Bar) .............................................................................................1-29
Running Apps ..........................................................................................................................................1-30
XX
Preface
Features & Components
Overview ....................................................................................................................................................2-1
Hard Disk Drive/Solid State Drive ............................................................................................................2-2
Multi-In-1 Card Reader .............................................................................................................................2-3
Touchpad and Buttons/Mouse ...................................................................................................................2-4
Touchpad Sensitivity .................................................................................................................................2-4
Gestures and Device Settings ....................................................................................................................2-6
Audio Features .........................................................................................................................................2-11
Setup for Audio Recording ......................................................................................................................2-12
Power Management
Overview ....................................................................................................................................................3-1
The Power Sources ....................................................................................................................................3-2
AC/DC Adapter .........................................................................................................................................3-2
Battery ........................................................................................................................................................3-2
Turning On the Computer ..........................................................................................................................3-3
Shutting the Computer Down ....................................................................................................................3-4
Power Plans ...............................................................................................................................................3-5
Power-Saving States ..................................................................................................................................3-7
Sleep ..........................................................................................................................................................3-7
Hibernate ....................................................................................................................................................3-8
Shut down ..................................................................................................................................................3-8
XXI
Preface
Configuring the Power Buttons .................................................................................................................3-9
Resuming Operation ................................................................................................................................3-11
Power Conservation Modes .....................................................................................................................3-12
Battery Information .................................................................................................................................3-14
Battery Power ..........................................................................................................................................3-14
Conserving Battery Power .......................................................................................................................3-15
Battery Life ..............................................................................................................................................3-16
New Battery .............................................................................................................................................3-16
Recharging the Battery with the AC/DC Adapter ...................................................................................3-16
Proper handling of the Battery Pack ........................................................................................................3-17
Battery FAQ .............................................................................................................................................3-18
Removing the Battery ..............................................................................................................................3-22
Inserting the Battery ................................................................................................................................3-23
Intel® Dynamic Platform & Thermal Framework ..................................................................................3-24
Intel® DPTF Driver Installation ..............................................................................................................3-24
Configuring Intel® Dynamic Platform & Thermal Framework ..............................................................3-25
Drivers & Utilities
What to Install ............................................................................................................................................4-1
Module Driver Installation ........................................................................................................................4-1
Driver Installation ......................................................................................................................................4-2
Updating/Reinstalling Individual Drivers ..................................................................................................4-5
XXII
Preface
User Account Control ................................................................................................................................4-6
Windows Security Message .......................................................................................................................4-6
New Hardware Found ................................................................................................................................4-6
Driver Installation Procedure .....................................................................................................................4-7
Chipset .......................................................................................................................................................4-7
Video (VGA) .............................................................................................................................................4-7
LAN ...........................................................................................................................................................4-7
CardReader ................................................................................................................................................4-7
TouchPad ...................................................................................................................................................4-7
Airplane Mode ...........................................................................................................................................4-8
USB 3.0 ......................................................................................................................................................4-8
Intel TXE ...................................................................................................................................................4-8
Hot Key ......................................................................................................................................................4-8
Intel® DPTF Driver Installation ................................................................................................................4-8
Audio .........................................................................................................................................................4-8
Optional Drivers ........................................................................................................................................4-9
BIOS Utilities
Overview ....................................................................................................................................................5-1
The Setup Utility ........................................................................................................................................5-2
Failing the POST .......................................................................................................................................5-3
Fatal Errors ................................................................................................................................................5-3
XXIII
Preface
Non-Fatal Errors ........................................................................................................................................5-3
Setup Screens .............................................................................................................................................5-4
Booting From a Windows 8.1 DVD ..........................................................................................................5-5
Main Menu .................................................................................................................................................5-6
Advanced Menu .........................................................................................................................................5-8
Security Menu ..........................................................................................................................................5-11
Boot Menu ...............................................................................................................................................5-15
Exit Menu ................................................................................................................................................5-17
Modules & Options
Overview ....................................................................................................................................................6-1
PC Camera Module ....................................................................................................................................6-2
PC Camera Audio Setup ............................................................................................................................6-3
Camera App ...............................................................................................................................................6-4
Camera Options .........................................................................................................................................6-5
Taking Pictures/Capturing Video ..............................................................................................................6-6
Camera Roll ...............................................................................................................................................6-7
Wireless LAN Module .............................................................................................................................6-11
3rd Party WLAN Driver Installation (Version 1) ....................................................................................6-12
Intel® WLAN Driver Installation ............................................................................................................6-12
WLAN Configuration in Windows .........................................................................................................6-13
Bluetooth & WLAN Combo Module ......................................................................................................6-16
XXIV
Preface
3rd Party Bluetooth Combo Driver Installation (Version 1) ...................................................................6-17
Intel Bluetooth Combo Driver Installation ..............................................................................................6-17
Bluetooth Configuration in Windows ......................................................................................................6-18
3G/4G Module .........................................................................................................................................6-21
3G Configuration in Windows .................................................................................................................6-23
Trusted Platform Module .........................................................................................................................6-26
Enabling & Activating TPM ....................................................................................................................6-27
TPM Management in Windows ...............................................................................................................6-28
TPM Actions ............................................................................................................................................6-30
Wireless Display ......................................................................................................................................6-32
Wireless Display Configuration ..............................................................................................................6-33
Troubleshooting
Overview ....................................................................................................................................................7-1
Basic Hints and Tips ..................................................................................................................................7-2
Backup and General Maintenance .............................................................................................................7-3
Viruses .......................................................................................................................................................7-4
Upgrading and Adding New Hardware/Software ......................................................................................7-5
Problems and Possible Solutions ...............................................................................................................7-7
3G/4G Module PIN Code & Power-Saving ............................................................................................7-14
Resolving the “Insert a SIM” issue with the 3G/4G Module (Windows 8.1) .........................................7-16
XXV
Preface
Interface (Ports & Jacks)
Overview ...................................................................................................................................................A-1
Notebook Ports and Jacks .........................................................................................................................A-2
Control Center
Overview ...................................................................................................................................................B-1
Video Driver Controls
Intel Video Driver Installation ..................................................................................................................C-1
Dynamic Video Memory Technology ......................................................................................................C-1
Intel® HD Graphics Control Panel ...........................................................................................................C-2
Display Devices & Options ....................................................................................................................C-16
Attaching Other Displays .......................................................................................................................C-17
Attaching Other Displays - Devices (Charms Bar) ................................................................................C-19
Configuring an External Display In Windows .......................................................................................C-20
HDMI Audio Configuration ...................................................................................................................C-22
Specifications
Processors .................................................................................................................................................D-2
Display ......................................................................................................................................................D-2
Memory .....................................................................................................................................................D-2
Video Adapter ...........................................................................................................................................D-2
XXVI
Preface
Storage ......................................................................................................................................................D-2
Audio ........................................................................................................................................................D-2
Keyboard & Pointing Device ....................................................................................................................D-2
Interface ....................................................................................................................................................D-2
Card Reader ..............................................................................................................................................D-2
Slots ..........................................................................................................................................................D-3
Communication .........................................................................................................................................D-3
Power Management ..................................................................................................................................D-3
Power ........................................................................................................................................................D-3
Indicators ..................................................................................................................................................D-3
BIOS .........................................................................................................................................................D-3
Security .....................................................................................................................................................D-3
Features .....................................................................................................................................................D-3
Operating System ......................................................................................................................................D-3
Environmental Spec ..................................................................................................................................D-3
Dimensions & Weight ..............................................................................................................................D-4
XXVII
Preface
XXVIII
Quick Start Guide

Chapter 1: Quick Start Guide

Overview

This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following:
Chapter 2 A guide to using some of the main features of the computer e.g. the storage devices (hard disk, optical device, Multi-in-1 card reader), TouchPad & Mouse & Audio.
Chapter 3 The computer’s power saving options.
Chapter 4 The installation of the drivers and utilities essential to the operation or improvement of some of the computer’s subsystems.
Chapter 5 An outline of the computer’s built-in software or BIOS (Basic Input Output System).
Chapter 6 A quick guide to the computer’s PC Camera, Wireless LAN and Combo Bluetooth & WLAN modules (some of which may be optional depending on your purchase configuration).
Chapter 7 A troubleshooting guide.
Appendix A Definiti ons of the interface, ports/jacks which allow your computer to c ommun icat e with ex te rnal devices.
Appendix B Information on Control Center.
Appendix C Information on the Video driver controls.
Appendix D The computer’s specification.
1
Overview 1 - 1
1
Notes
Check the light colored boxes with the mark above to find detailed in­formation about the com­puter’s features.
Quick Start Guide

Advanced Users

If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “What to Install” on page 4 - 1 and “BIOS Utilities” on page 5 - 1 in the remainder of the User’s Manual. You may also find the notes marked with a
of interest to you.

Beginners and Non-Advanced Users

If you are new to computers (or do not have an advanced knowledge of them) then the information contained in the Quick Start Guide should be enough to get you up and running. Eventually you should try to look through all the documentation (more detailed descriptions of the functions, setup and system controls are covered in the remainder of the User’s Manual), but do not worry if you do not understand every­thing the first time. Keep this manual nearby and refer to it to learn as you go. You may find it useful to refer to the notes marked with a
as indicated in the margin.
For a more detailed description of any of the interface ports and jacks see “Interface
(Ports & Jacks)” on page A - 1.

Warning Boxes

No matter what your level please pay careful attention to the warning and safety information indicated by the
symbol. Also please note the safety and handling instructions as indicated in the Preface.
1 - 2 Overview
Quick Start Guide
Drivers
If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the drivers listed in “Drivers & Utilities” on page 4 - 1. Drivers are programs which act as an interface between the com- puter and a hardware component e.g. a wireless network module. It is very important that you install the drivers in the order listed. You will be unable to use most advanced controls until the n ecessary drivers an d utilities are properly i nstalled. If your system hasn’t been properly configured (your service representative may have already done that for you); refer to
Chapter 4 for installation instructions.
You will need to attach an optical device dr ive to the computer in order to access the drivers on the Device Drivers & Utilities + User’s Manual disc. This contains the drivers and utilities necessary for the proper operation of the computer.
Ports and Jacks
See “Interface (Ports & Jacks)” on page A - 1 for a description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc.

Not Included

Operating Systems (e.g. Windows 8.1) and applications (e.g. word processing, spreadsheet and database pro­grams) have their own manuals, so please consult the appropriate manuals.
1
Overview 1 - 3
1
130°
Shutdown
Note that you should always shut your computer down by choosing the Shut
Down command in Windows (see p age
1 - 29). This will help
prevent hard disk or system problems.
Quick Start Guide

System Startup

1. Remove all packing materials, and place the computer on a stable surface.
2. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports.
3. Attach the AC/DC adapter to the DC-In jack on the right of the computer, connect the AC power cord to the AC/
DC adapter and then plug the AC power cord into an outlet (make sur e you use the adapter when first setting up the computer).
4. Use one hand to raise the
hand to support the base of the computer (Note: Never lift the computer by the lid/LCD).
lid/LCD to a comfortable viewing angle (
Figure 1 - 1 - Opening the Lid/LCD & Computer with AC/DC Adapter Plugged-In
1 - 4 System Startup
do not exceed 130 degrees
);
use the other
Quick Start Guide
Windows Versions
Note that the information included on the following pages is for Windows 8.1 (64-bit) only.
Windows OS
In order to run Windows 8.1 (64-bit) without limitations or decreased performance, your computer requires a minimum
2GB of system memory (RAM).

System Software

Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find the Windows 8.1 o perating system is sup­ported.
1
System Startup 1 - 5
1
Figure 1 - 2
LCD Panel Open
1. Built-in PC Camera
2. PC Camera LED
3. Built-In Microphone
4. LCD
5. Power Button
6. Keyboard
7. Touchpad & Buttons
7
Note that the Touchpad and Buttons has a valid opera­tional area indicated within the dotted lines above.
3
5
1
7
4
6
2
Wireless Device
Operation Aboard
Aircraft
The use of any porta­ble electronic trans­mission devices aboard aircraft is usu­ally prohibited. Make sure the WLAN &
Bluetooth module(s) are OFF if you are us-
ing the computer aboard aircraft by put­ting the system in to Airplane Mode (see
Table 1 - 3, on page 1
- 10).
Quick Start Guide
1 - 6 System Map: LCD Panel Open

System Map: LCD Panel Open

Quick Start Guide

LED Indicators

The LED indicators on the computer display helpful information about the current status of the computer.
Icon Color Description
Orange DC Power is Plugged In
Green The Computer is On
Blinking Green The Computer is in Sleep Mode
Orange The Battery is Charging
Green The Battery is Fully Charged
Blinking Orange The Battery Has Reached Critically Low Power Status
Off Battery Charging has been Disabled
Green Hard Disk Activity
1
Green Airplane Mode is ON (the WLAN, Bluetooth & 3G Modules are OFF)
Table 1 - 1 - LED Indicators
LED Indicators 1 - 7
1
Other Keyboards
If your keyboard is dam­aged or you just want to make a change, you can use any standard USB keyboard. The system will detect and enable it auto­matically. However spe­cial functions/hot-keys unique to the system’s regular keyboard may not work.
NumLk & Scr Lk
Hold down the Fn Key and either Num Lk or Scr Lk to enable number or scroll lock, and check the LED indicator for status.
Play/Pause
Fn Key / Windows Logo Key
Menu / Applicatio n K ey
Numerical Keypad
Function Keys
Scr LkNumLk
Special Characters
Some software applications allow the number-keys to be used with Alt to produce special characters. These special characters can only be produced by using th e numeric keypad (use the Fn key or NumLK). Regular number keys (in the upper row of the keyboard) will not work. Make sure that Num Lk is on.
Quick Start Guide

Keyboard

The keyboard features function keys to allow you to change operational features in­stantly.
1 - 8 Keyboard
Figure 1 - 3 - Keyboard

Keyboard Shortcuts

Windows Logo
Keyboard Shortcut
Use the Windows logo key + D key com- bination to switch from the Start screen to the Windows Desk­top.
Menu/Application
Keyboard Shortcut
When the Desktop app is running you can use the Menu/Application key on the key­board to act as a mouse right-click. In the Start screen this function is useful to quickly display Cus- tomize Apps.
The following Windows Logo Key (Winkey) keyboard shortcuts are useful for navi­gation/operation in
Windows Logo
Key +
Tap Winkey
CDisplay Charms menu D Switch to the Windows Desktop and toggle show Desktop
E
F Display file Search
I Open the Settings charm
K Open the Connect charm
L Lock the computer and display the Lock screen P Display the Second Screen menu (see Figure 1 - 18 on page 1 - 26) R Switch to the Windows Desktop and display the Run dialog box Z Access the Customize Bar (see Figure 1 - 13 on page 1 - 21)
Windows 8.1
.
Description
Toggle between the Start screen and the foremost running app or the
Windows Desktop
Switch to the Windows desktop and launch Windows Explorer with
Computer displayed
Table 1 - 2 - Keyboard Shortcuts
Quick Start Guide
1
Keyboard 1 - 9
1
Quick Start Guide

Function/Hot Key Indicators

The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the basic function key combinations; some visual indicators are available when the hot key utility is installed.
Keys Function Keys Function
Fn +
Fn +
Fn +
Fn +
Fn +
Fn +
Fn +
Play/Pause (in Audio/Video Programs)
TouchPad Toggle
(Press a key to or use TouchPad to turn on)
Turn LCD Backlight Off
Mute Toggle
Volume Decrease/Increase
Display Switch Menu Caps Lock Toggle
Brightness Decrease/Increase
Table 1 - 3 - Function & Hot Key Indicators
1 - 10 Function/Hot Key Indicators
Fn +
Fn +
Fn +
Fn + NumLK
Fn + Scr LK
PC Camera Power
Toggle
Airplane Mode Toggle
Sleep Toggle
Number Lock Toggle
Scroll Lock Toggle
Quick Start Guide
Control Center Access
To run the Control Center press the Fn + Esc key combina-
tion, or double-click the icon in the notification area of the taskbar.
Close the Control Center by clicking the close icon in the top right of the panel (move the cursor onto the top right corner of the panel to highlight it).

Control Center

When in the Windows Desktop application (not in the Start screen) press the Fn + Esc key combination, or double-click the icon trol Center gives quick access to frequently used controls and enables you to quickly turn the camera/touch pad
on/off (see Appendix B for full details).
in the notification area of the taskbar to toggle the Control Center on/off. The Con-
Figure 1 - 4 - Control Center
Control Center 1 - 11
1
1
Figure 1 - 5
Front & Left Views
1. LED Indicators
2. Security Lock Slot
3. External Monitor Port
4. Vent/Fan Intake/ Outlet
5. HDMI-Out Port
6. USB 3.0 Port
7. Microphone-In Jack
8. Headphone-Out Jack
USB 3.0 Port OR USB 2.0 Port
This model includes 1 * USB 3.0 port and 2 * USB 2.0 ports. The USB 3.0 port is denoted by its blue color; the USB 2.0 ports are colored black.
Optical Device Drives
To install applications and drivers etc. you will need to attach an external optical CD/DVD device to the USB ports.
HDMI Port
Note that the HDMI Port supports video and audio signals to attached external displays.
2
7
4
1
3
6
5
8
1
Quick Start Guide

System Map: Front & Left Views

1 - 12 System Map: Front & Left Views

System Map: Right & Rear Views

Figure 1 - 6
Right & Rear Views
1. DC-In Jack
2. RJ-45 LAN Jack
3. Multi-in-1 Card Reader
4. USB 2.0 Ports
5. Battery
USB 3.0 Port OR USB
2.0 Port
This model includes 1 * USB 3.0 port and 2 * USB 2.0 ports. The USB
3.0 port is denoted by its
blue color; the USB 2.0
ports are colored black.
4
2 1
W255EU
3
Battery Information
Always completely discharge, then fully charge, a new battery before using it. Completely discharge and charge the battery at least once every 30 days or after about 20 partial dis­charges. See “Battery Information” on page 3 - 14 for full instructions.
Multi-In-1 Card Reader
The card reader allows you to use the most popular digital storage card formats:
MMC (MultiMedia Card) / RS MMC
SD (Secure Digital) / Mini SD / SDHC / SDXC
5
4
Quick Start Guide
1
System Map: Right & Rear Views 1 - 13
1
Figure 1 - 7
Bottom View
1. Battery Location
2. Vent/Fan Intake/ Outlet
3. Speakers
Overheating
To prevent your comput­er from overheating make sure nothing blocks the Vent/Fan Intake while the computer is in use.
1
3
Bottom Cover Removal Warning
Do not remove any cover(s) and /or screw(s) for the purposes of device upgrade as this may violate the terms of your warranty.
If you need to replace/remove the hard disk/RAM/optical device etc., for any reason, please contact your distributor/supplier for further information.
3
2
Quick Start Guide

System Map: Bottom View

1 - 14 System Map: Bottom View

Removing the Battery

Bottom Cover
Removal Warning
Do not remove any cov­er(s) and /or screw(s) for the purposes of device upgrade as this may vio­late the terms of your warranty.
If you need to replace/ remove the hard disk/ RAM/optical device etc., for any reason, please contact your distributor/ supplier for further infor­mation.
Figure 1 - 8
Battery Removal
123
2 1
3
We recommend that you do not remove the battery yourself. If you do need to re­move the battery for any reason (e.g. long term storage) see below.
1. Turn the computer off, and turn it over.
2. Slide the latch in the direction of the arrow.
3. Slide the latch in the direction of the arrow, and hold it in place.
4. Slide the battery out in the direction of the arrow .
5. See over for inserting the battery instructions.
Quick Start Guide
1
Removing the Battery 1 - 15
1
Figure 1 - 9
Battery Insertion
123
1
2 3
Quick Start Guide

Inserting the Battery

1. Slide the battery straight into the compartment (note that there are grooves on the side of the battery which should align up with the battery compartment).
2. Lock
3. Lock the battery in place by sliding latch in the direction of the arrow
should lock automatically into place upon insertion.
.
1 - 16 Removing the Battery

Windows 8.1 Control Panel

Windows Versions
Note that the informa­tion included on the fol­lowing pages is for the latest updated version of Windows 8.1 only.
Make sure you enable Windows Update in or­der to get all the latest security updates etc. (see “Windows Up-
date” on page 4 - 9).
Move the mouse to the bottom left
Start Screen
Desktop app
of the screen and right-click to access the menu.
Throughout this manual you will see an instruction to open the Control Panel. R
ight-click the lower left hot corner to bring up the context menu (or use the Win-
dows Logo Key + X key combination)
Desktop app or Start screen.
and select Control Panel in both the
Quick Start Guide
1
Figure 1 - 10 - Windows Context Menu
Windows 8.1 Control Panel 1 - 17
1
Keyboard Shortcut to Control Panel
You can also use keyboard shortcuts to access the Contro l Pa nel. Press th e Win dows logo key and X to bring up the context menu, and then press P to bring up the Control Panel. Alternatively press the Windows logo key and R to bring up the Run dialog box, and then type “Control Panel” and press Enter to access the Control Panel.
Quick Start Guide
The Control Panel can be accessed in a number of ways in Windows 8.1.
•Click Search in the Windows Charms Bar (see previous page) and the search pane will pop out. Type
Control Panel and select it from the results to the left.
• Click on This PC (in Apps, or you can to pin This PC to the Start screen), click on Computer in the top menu and select Open Control Panel from the ribbon.
• When in the Desktop app (this does not apply to the Start screen) click on Settings in the Windows Charms Bar and select Control Panel from the menu.
Click the arrow at the bottom of the Start screen and click Control Panel in Apps (Windows System).
• Right-click the Start button to bring up the menu and select Control Panel (see Figure 1 - 11 on page 1
- 19).
1 - 18 Windows 8.1 Control Panel
Right-click the Start button in the Desktop app (or use the Windows Logo Key
Display Most
Recently Used
Apps
If you are in the Start screen, Desktop or an app you can move your mouse to the upper left corner of the screen to get back to the most re­cently used app.
To view all the most re­cently used Apps hover over the top left of the screen and then move the mouse down along the left side of the screen to display the list.
Move the mouse to the bottom left of the screen
and right-click the Start button to access the menu.
+ X key combination) to bring up an advanced context menu of useful features
such as Control Panel, Programs and Features, Power Options, Task Manager, Search, File Explorer, Command Prompt, Device Manager and Network Connec­tions etc.
Figure 1 - 11 - Advanced Context Menu (Right-Click Start Button)
Quick Start Guide
1
Windows 8.1 Control Panel 1 - 19
1
Desktop App
Quick Start Guide

Windows 8.1 Start Screen & Desktop

The Apps, control panels, utilities and programs within Windows are accessed from the Start screen and/or Windows Desktop app. The Desktop (which runs as an app within the Start screen) can be accessed by clicking
the Desktop item in the Start screen (or by using the Windows Logo Key + D key combination). Click the arrow at the bottom of the Start screen to access Apps.
Figure 1 - 12 - Windows Start Screen
1 - 20 Windows 8.1 Start Screen & Desktop
Quick Start Guide
Click the arrow at the bottom of the screen to access All Apps

Apps & Tiles

The Start screen will contain a number of apps, and many more will be installed as you add more applications etc. Not all of these apps can fit on one screen so you will often need use the slider at the bottom of the screen in order to view all the necessary Apps.
Accessing Pining/Unpinning All Apps
You can add and remove the tiles for apps and control panels in the Start screen. Right-click on an app to bring up the context menu and you pin the App to (or unpin from) the Start screen, or to the taskbar.
1
Figure 1 - 13 - Apps
Windows 8.1 Start Screen & Desktop 1 - 21
1
Move the mouse to the bottom left of the screen and click to switch back to the Start screen.
Quick Start Guide

Desktop Application

When the Desktop app is running (click the app in the Start screen or use the Windows Logo Key + D key combination) you can use lower left hot corner to switch between the Start screen and the Windows Desktop app. To do so move your mouse to hover over the bottom left corner of the Desktop app and left-click.
Figure 1 - 14 - Desktop
1 - 22 Windows 8.1 Start Screen & Desktop

The Charms Bar

Move the mouse over a Charms Bar icon to activate the menu
Move the mouse to the top/lower right icons to activate the Charms Bar
Move the mouse to the top/lower right icons to activate the Charms Bar
The right side of the screen (Start or Desktop) displays the Charms Bar. The Charms Bar contains the Search, Share, Start, Devices and Settings menus. To access up the Charms Bar move the cursor to the upper or lower
right corners of the screen, and then hover over one of the items in the Charms Bar to activate it (the bar will be black when it is active), or use the Windows Logo Key + C key combination.
Quick Start Guide
1
Figure 1 - 15 - Start Screen with Charms Bar
Windows 8.1 Start Screen & Desktop 1 - 23
1
Charms Bar - TouchPad Access
To quick access the Charms Bar using the TouchPad:
1. Place your finger off the TouchPad (slightly to the right of the pad resting on the computer).
2. Move your finger across to the left on to the TouchPad.
3. The Charms Bar will then pop-up.
Quick Start Guide
Charms Bar Items
Search : You can search for any file, application, Apps and control panel settings with instantaneous
results.
•Share : This button is used to share information with people via mail or social networks.
•Start : Click to bring up the Start screen (the same function as pressing the Windows Logo Key or click-
ing the bottom left of the screen).
• Devices : Click this button to change connected peripheral device settings e.g. an external display.
Settings : This button gives instant access to the computer settings, such as Network, Audio, Notifica­tions, Power and Keyboard (click Change PC Settings to activate the PC Settings menu).
Figure 1 - 16 - Settings Menu
1 - 24 Windows 8.1 Start Screen & Desktop
Quick Start Guide

Windows 8.1 Taskbar

In many instances throughout this manual you will see an instruction to access the notification area of the task­bar (system tray). In Windows 8.1 the taskbar can be directly accessed from the Desktop application; if you
are in the Start screen you will need to move the cursor to the bottom of the screen to display the taskbar. The taskbar is displayed at the bottom of the screen, and you can see the notification area (system tray) of the
taskbar in the bottom right of the screen. Some of the control panels and applications referred to during the course of this manual can be accessed from here.
1
Figure 1 - 17 - Taskbar & Notification Area (System Tray)
You can pin/unpin apps to/from the taskbar in much the same way as you can to the Start screen (see “Accessing
Pining/Unpinning All Apps” on page 1 - 21).
Windows 8.1 Start Screen & Desktop 1 - 25
1
Quick Start Guide

Video Features

You can switch display devices, and configure display options, from the Display control panel (in Appearances and Personalization) in Windows when running the Desktop app (see “Desktop Application ” on page 1 - 22). It is possible to quickly configure external displays from the Devices menu item in the Charms Bar (see “The
Charms Bar” on page 1 - 23).
To Configure Displays from Devices (Charms Bar):
1. Attach your display to the appropriate port, and turn it on.
2. Go the Charms Bar, select Devices.
3. Click Project (you may need to click Second Screen).
4. Click on any one of the options from the menu to select PC screen only, Duplicate, Extend or Second screen
only.
1 - 26 Video Features
Figure 1 - 18 - Devices (Project)
Quick Start Guide
1
3
2
Right-Click Desktop
App
1. You can right-click the desktop and select Screen reso- lution (Figure 1 -
19).
2. Use the dropbox to select the screen
Resolution
(Figure 1 - 19).
3. Click Advanced settings (Figure
1 - 19) to bring up the
Advanced properties tabs.
123
1
To access Display (Control Panel) and Screen Resolution in Windows:
1. Go to the Control Panel.
2. Click Display (icon) - In the Appearance and Personalization category.
3. Adjust resolution.
Figure 1 - 19 - Screen Resolution
Video Features 1 - 27
1
3
4
4
Quick Start Guide
To access the Intel(R) HD Graphics Control Panel:
1. Click Advanced settings (Figure 1 - 19 on page 1 - 27) in the Screen Resolution control panel in Win­dows.
2. Click the Intel(R)... tab and click Graphics Properties (button) (Figure 1 - 20 on page 1 - 28) .
OR
3. Right-click the desktop and select Graphics Properties from the menu.
OR
4. Click the icon in the notification area of the Desktop taskbar and select Graphics Properties from the menu.
Figure 1 - 20 - Intel Graphics Control Panel
1 - 28 Video Features
Quick Start Guide
Charms Bar Desktop App Start Screen

Power Options

Power Options (Hardware and Sound) can be accessed from the Control Panel. The Power Menu item in Set- tings in the Charms Bar in Windows 8.1 may be used to Shut down or Restart (you can also add Hibernate/ Sleep to the menu - see “Adding Hibernate/Sleep to the Power Menu” on page 3 - 10). You can also use the context menu (Shut down or sign out) shut the computer down/restart etc.
Shut Down, Restart or Sleep (Charms Bar)
1. Go to the Charms Bar and click Settings.
2. Click Power .
3. Select Sleep, Shut Down or Restart.
1
Figure 1 - 21 - Shut Down/Restart
Power Options 1 - 29
1
Screen Resolution for Apps
(Windows 8.1)
The minimum resolution in which Apps will run is 1024x768. The minimum resolution required to support a ll the features of
Windows 8 (including multitasking with snap) is 1366x768. These specs are the minimum screen resolution that supports
all the features of Windows 8.1 on a useful physical size.
Quick Start Guide

Running Apps

To run apps in Windows 8.1 you will need to check that the Screen Resolution and User Account Control Set­tings are compatible with the system requirements.
Screen Resolution Settings
1. Switch to the Windows Desktop (click the app or use the Windows logo key + D key combination).
2. Right-click a blank area of the Windows Desktop and select Screen Resolution. Adjust the Resolution to make sure that it is at least 1024 * 768, although preferably 1366 * 768 or above (see sidebar).
1 - 30 Running Apps
Figure 1 - 22 - Screen Resolution
Quick Start Guide
User Account Control Settings
If your computer meets the minimum screen resolution requirements, and still you can't run apps, then that you have to check the status of User Account Control (UAC). Apps may fail to open when the UAC is turned off. To check whether the UAC is on or off, follow the instructions below.
1. Open the Control Panel.
2. Click on User Accounts and then click on Change User Account Control settings (or click System and Security and click Change User Account Control Settings under Action Center).
3. If the slider is in the Never notify position, then the UAC is disabled.
4. To enable or turn on the UAC, move the slider to Always notify or Notify me when apps try to make changes
to my computer (default) position, and then click OK.
1
Figure 1 - 23 - User Account Control
Running Apps 1 - 31
1
Quick Start Guide
1 - 32
Features & Components

Chapter 2: Features & Components

Overview

Read this chapter to learn more about the following main features and components of the computer:
• Hard Disk Drive/Solid State Drive
• Multi-In-1 Card Reader
• Touchpad and Buttons/Mouse
• Audio Features
2
Overview 2 - 1
Features & Components
Bottom Cover
Removal Warning
Do not remove any cov­er(s) and /or screw(s) for the purposes of device upgrade as this may vio­late the terms of your warranty.
If you need to replace/ remove the hard disk for any reason, please con­tact your distributor/sup­plier for further information.
2

Hard Disk Drive/Solid State Drive

The hard disk drive (HDD) and/or solid state drive (SSD) is used to store your data in the computer. The hard disk can be taken out to accommodate other serial (SATA) hard disk drives (see “Storage” on page D - 2 for specification information), how­ever you will need to contact your distributor/supplier to do this in order to avoid violating the terms of your warranty.
The solid state drive is a factory option for this computer model.
2 - 2 Hard Disk Drive/Solid State Drive
Features & Components
Figure 2 - 1
Right View
1. Card Reader
• MMC (MultiMedia Card) / RSMMC
• SD (Secure Digital) / Mini SD / SDHC / SDXC
1

Multi-In-1 Card Reader

The card reader allows you to use some of the latest digital storage cards. Push the card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s). Make sure you install the card reader driver (see
“CardReader” on page 4 - 7).
*Note: The PC adapters are usually supplied with these cards.
2
Multi-In-1 Card Reader 2 - 3
Features & Components
Touchpad Active
Areas
Note that the pointing active area is clearly defined from the but­ton active area as il-
lustrated.
Figure 2 - 2
Touchpad
Sensitivity
2

Touchpad and Buttons/Mouse

The Touchpad is an alternative to the mouse; however, you can also add a mouse to your computer through one of the USB ports. The Touchpad buttons function in much the same way as a two-button mouse.

Touchpad Sensitivity

The mouse button zones at the bottom of the pad are defined by the line at the bot­tom of the pad, and the left and right buttons are divided roughly down the middle
as illustrated below. The active area of the touchpad is that defined in the diagram below. Press the left button zone for a left click, and right button zone for a right click action.
2 - 4 Touchpad and Buttons/Mouse
Once you have installed the Touchpad driver (see “TouchPad” on page 4 - 7) you
Touchpad Scrolling
This computer model se­ries may feature different Touchpad versions.
These Touchpads may differ in their vertical scrolling function in most scrollable windows.
Some Touchpads require sliding the finger up and down on the right of the Touchpad to scroll the window. Other versions require tapping/holding down the finger at the top right or bottom right of the Touchpad to scroll the window.
Figure 2 - 3
Mouse Properties
can configure the functions by double-clicking the Touchpad driver icon in the notification area of the taskbar. You may then configure the Touchpad tapping, but­tons, scrolling (see sidebar), pointer motion and sensitivity options to your prefer­ences.
Features & Components
2
Touchpad and Buttons/Mouse 2 - 5
Features & Components
Show Video
You can get a clearer view of the gestures in­volved by clicking the Show Video option for each gesture item.
Select the gesture (Pinch
Zoom, Rotating, Three Fingers Down and Three Finger Flick) in the Device Settings > Set­tings left tree menu
and click the Show Video button to see the demon­stration video.
For more details on any of the gestures see the help in the lower part of the right menu window.
Figure 2 - 4
Mouse Properties -
Device Settings
2

Gestures and Device Settings

The Synaptics Gestures Suite application allows you to use a specific gesture (ac­tion) on the surface of the Touchpad to perform specific actions to manipulate doc­uments, objects and applications.
You can configure the settings from the Device Settings tab in Mouse Properties:
1. Click
2. Click Mouse (Hardware and Sound).
3. Click Device Settings (tab) and click Settings.
4. Use the menu tree on the lef t to access the user configurable settings.
Start
, and click
Control Panel
(or point to
Settings
and click
Control Panel
).
2 - 6 Touchpad and Buttons/Mouse
Features & Components
Figure 2 - 5
Mouse Properties
(Disable Touchpad)
Disabling the Touchpad
If you need to disable the Touchpad for any reason (e.g. you may find that when us­ing the computer’s internal keyboard you accidentally trigger the Touchpad when resting your wrists or palms on it) you can do so by using Fn + F1 key combination.
You can also set the system to automatically disable the internal Touchpad when an external USB point device (e.g. a USB mouse) is attached.
1. Go to the Mouse Properties control panel.
2. Click to select Device Settings (tab).
3. Click to place a check in the “Disable internal pointing device when external USB pointing device is attached” check box.
4. Click OK to save the setting.
2
Touchpad and Buttons/Mouse 2 - 7
Features & Components
PalmCheck
In order to improve pad scrolling responsive­ness when using one­finger scrolling, you can adjust the PalmCheck slider towards “Mini­mum” as per your pref­erence.
However bear in mind that adjusting the slider too far towards “Mini­mum” can turn off Palm­Check altogether.
Figure 2 - 6
PalmCheck Slider
2
PalmCheck
The PalmCheck feature helps prevent operating the pad by accident, by recognizing when your palm is resting on it or brushing its surface while you are typing.
2 - 8 Touchpad and Buttons/Mouse
Scrolling
Figure 2 - 7
Scrolling Gesture
Mouse Driver
If you are using an ex­ternal mouse your op­erating system may be able to auto-configure your mouse during its installation or only en­able its basic functions. Be sure to check the device’s user docu­mentation for details.
Figure 2 - 8
Zooming Gesture
The Two-Finger scrolling feature works in most scrollable windows and allows you to scroll horizontally and vertically. Place two fingers, slightly separated, on the Touchpad surface and slide both fingers in the direction required (in a straight con­tinuous motion).
Zooming
The Pinch Zoom gesture can be used to perform the same function as a scroll wheel in Windows applications that support CTRL + scroll wheel zoom functionality. Place two fingers on the Touchpad (for best results use the tips of the fingers) and slide them apart to zoom in, or closer together to zoom out.
Features & Components
2
Touchpad and Buttons/Mouse 2 - 9
Features & Components
Figure 2 - 9
Rotating Gesture
Figure 2 - 10
Flick/Press
Gesture
2
Rotating
Use the Pivot Rotate gesture to rotate objects (e.g. photos) in 90 degree increments. Place a finger down on the left “target” zone and keep it stationary. Place another finger near the middle of the Touchpad and slide it in a circular motion around the stationary finger (clockwise or counterclockwise) to rotate the object.
Three Finger-Flick/Three Fingers Down (Press)
The Three Finger-Flick gesture may be used to enhance navigation with a variety of applications such as browsing the Internet or scrolling through a photo viewer. The Three Fingers Down gesture may be used to launch user-selectable applications.
2 - 10 Touchpad and Buttons/Mouse
Features & Components
Sound Volume
Adjustment
The sound volume level is set using the volume control on the Windows desktop (and the vol-
ume function keys F5/ F6 on the computer).
Click the volume icon in the taskbar to check the setting.
Figure 2 - 11
VIA HD Audio Deck
Right-click the icon to access the menu above.

Audio Features

You can configure the audio options on your computer from the Sound control panel in Windows, or from the Realtek HD Audio Manager icon in the taskbar notification area/control panel (right-click the taskbar notification area icon to bring up an audio menu). The volume may also be adjusted by means of the volume icon in the taskbar or the audio slider in the Settings menu (see sidebar).
2
Audio Features 2 - 11
Features & Components
Disabling Front Jack
Detection
It is recommended that
you do not disable front panel jack detection in
Connector Settings . Disabling front panel jack
detection may cause your internal microphone to become disabled, and audio may continue to play through the sys­tem’s internal speakers even when headphones are plugged-in to the headphone jack (see page 7 - 9).
Figure 2 - 12
Realtek Audio
Manager - Recording
Setup
2

Setup for Audio Recording

To record audio sources on your computer at optimum quality follow the instruc­tions below:
1. Go to the
2. Click Realtek HD Audio Manager (Hardware and Sound), or right-click the taskbar icon and select Sound Manager.
3. Click Microphone Effects (tab) in Microphone (tab), and then click to select Noise Suppression (button), or adjust the Recording Volume level to around 60, to obtain the optimum recording quality.
4. Click OK to close the control panel and save the settings.
Control Panel
.
2 - 12 Audio Features

Chapter 3: Power Management

OS Note
Power management functions will vary slight­ly depending on your operating system. For more information it is best to refer to the user’s manual of your operat­ing system.
(Note: All pictures used on the following pages are from the Windows
8.1 OS.)
Power Options
Power management in Windows is configured from Power Options (Hardware and Sound), which can be accessed from the Con- trol Panel (see page 1 -
17).
Power Management

Overview

To conserve power, especially when using the battery, your computer power man­agement conserves power by controlling individual components of the computer (the monitor and hard disk drive) or the whole system. This chapter covers:
• The Po wer So urces
• Turning On the Computer
• Shutting the Computer Down
• Power-Saving States
• Configuring the Power Buttons
• Battery Information
• Removing the Battery
• Intel® Dynamic Platform & Thermal Framework
The computer uses enhanced power saving techniques to give the operating system (OS) direct control over the power and thermal states of devices and processors. For example, this enables the OS to set devices into low-power states based on user set­tings and information from applications.
3
Overview 3 - 1
Power Management
Forced Off
If the system “hangs”, and the Ctrl + Alt + Del key combination doesn’t work, press the power button for 4 seconds, or longer, to force the sys­tem to turn itself off.
3

The Power Sources

The computer can be powered by either an AC/DC adapter or a battery pack.

AC/DC Adapter

Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ DC adapter will damage the computer and its components.
1. Attach the AC/DC adapter to the DC-In jack on the right of the computer, connect the AC power cord to the AC/DC adapter and then plug the AC power cord into an outlet (make sure you use the adapter when first setting up the computer, as to safeguard the computer during shipping the battery will be locked to not power the system until first connected to the AC/DC adapter).
2. Raise the lid/LCD to a comfortable viewing angle.
3. Press the power button to turn “On”.

Battery

The battery allows you to use your computer while you are on the road or when an electrical outlet is unavailable. Battery life varies depending on the applications and the configuration you're using. To increase battery life, let the battery discharge completely before recharging (see “Battery FAQ” on page 3 - 18).
We recommend that you do not remove the battery. For more information on the bat­tery, please refer to “Battery Information” on page 3 - 14.
3 - 2 The Power Sources

Turning On the Computer

Power Button as Stand by or Hibernate Button
You can use the OS’s “Power Options” control panel to set the power button to send the system into Stand by or Hibernate mode (see your OS’s documentation, or “Configuring
the Power Buttons” on page 3 - 9 for details).
Now you are ready to begin using your computer. To turn it on simply press the pow­er button on the front panel.
When the computer is on, you can use the power button as a Stand by/Hibernate/ Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and holding the power button for longer than this will shut the computer down). Use Power Options (Hardware and Sound) in the Windows control panel to configure this feature.
Power Management
3
Turning On the Computer 3 - 3
Power Management
Figure 3 - 1
Shut Down/Restart
Charms Bar Desktop App Start Screen

Shutting the Computer Down

Note that you should always shut your computer down by choosing the Shut down
3
command as this will help prevent hard disk or system problems. Use the Shut down or sign out item in the Context Menu (right-click the lower left corner of the screen
to bring up the menu). You can also use the Power Menu in Settings in the Windows 8.1 Charms Bar. If
you want to add Hibernate/Sleep to the Power Menu see “Adding Hibernate/Sleep
to the Power Menu” on page 3 - 10.
3 - 4 Shutting the Computer Down

Power Plans

Resuming
Operation
See Table 3 - 1, on
page 3 - 11 for informa-
tion on how to resume from a power-saving state.
Password
It is recommended that you enable a password on system resume in or­der to protect your data.
Figure 3 - 2
Power Plan
Advanced Settings
The computer can be configured to conserve power by means of power plans. You can use (or modify) an existing power plan, or create a new one.
The settings may be adjusted to set the display to turn off after a specified time, and to send the computer into Sleep after a period of inactivity.
Click Change plan settings and then click Change advanced power settings to ac­cess further configuration options in Advanced Settings.
Power Management
3
Power Plans3-5
Power Management
Figure 3 - 3
Power Plans
Click to Show/Hide additional power plans
3
Each Windows power plan will also adjust the processor performance of your ma­chine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power).
Choose High performance (you may need to click Show additional plans to view the High performance plan) for maximum performance when the computer is pow­ered from an AC power source. Choose the Power saver (bear in mind that this scheme may slow down the overall performance of the computer in order to save power) for maximum power saving when the computer is battery (DC power) pow­ered.
3 - 6 Power Plans

Power-Saving States

Wake On LAN
Support
(Windows 8)
Wake-On-LAN is only supported from Sleep or
Hibernate states in Windows 8.
If you require your com­puter to wake up from network activity in Win­dows 8 then make sure that the computer is ei­ther in Sleep or Hiber- nate.
Wake-On-LAN is not supported from Shut­down states in Win- dows 8.
You can use power-saving states to stop the computer’s operation and restart where you left off. Win 8.1 uses the Sleep, Hibernate and Shut Down power-saving states.

Sleep

In Sleep all of your work, settings and preferences are saved to memory before the system sleeps. When you are not using your computer for a certain length of time, which you specify in the operating system, it will enter Sleep to save power.
The PC wakes from Sleep within seconds and will return you to where you last left off (what was on your desktop) without reopening the application(s) and file( s) you last used.
If your mobile PC in Sleep is running on battery power the system will use only a minimum amount of power. After an extended period the system will save all the information to the hard disk and shut the computer down before the battery becomes depleted.
Power Management
3
To add Sleep to the Power Menu see “Adding Hibernate/Sleep to the Power
Menu” on page 3 - 10.
Power-Saving States 3 - 7
Power Management
Figure 3 - 4
Power Menu

Hibernate

Hibernate uses the least amount of power of all the power-saving states and saves
3
all of your information on a part of the hard disk before it turns the system off. If a power failure occurs the system can restore your work from the hard disk; if a power failure occurs when work is saved only to memory, then the work will be lost. Hi- bernate will also return you to where you last left off within seconds. You should put your mobile PC into Hibernate if you will not use the computer for a period of time, and will not have the chance to charge the battery. To add Hibernate to the Power Menu see “Adding Hibernate/Sleep to the Power Menu” on page 3 - 10.

Shut down

You should Shut down the computer if you plan to install new hardware (don’t for­get to remove the battery and follow all the safety instructions in Chapter 6), plan to be away from the computer for several days, or you do not need it to wake up and run a scheduled task. Returning to full operation from Shut down takes longer than from Sleep or Hibernate.
3 - 8 Power-Saving States

Configuring the Power Buttons

Password
Protection
It is recommended that you enable a password on wake up in order to protect your data.
However you can dis­able this setting from the Power Options menu by clicking Require a
password on wakeup
in the left menu, and se­lecting the options (click
Change settings that are currently unavail­able).
Figure 3 - 5
Power Options
Define Power
Buttons
The power/sleep button (Fn + F12 key combo) and closed lid may be set to send the computer in to a power-saving state. Click Choose what the power buttons do on the left menu in Power Options to bring up the menu.
Power Management
3
Configuring the Power Buttons 3 - 9
Power Management
Figure 3 - 6
Power Options
Define Power
Buttons - Shutdown
Settings
3
Adding Hibernate/Sleep to the Power Menu
Add Hibernate/Sleep to the Power Menu as follows.
1. Go to the Power Options (Hardware and Sound) control panel.
2. Click “Change settings that are currently unavailable” .
3. Click Choose what the power buttons do.
4. Click to put a check in the Hibernate/Sleep box under Shutdown settings.
5. Click Save Changes and close the control panel.
3 - 10 Configuring the Power Buttons

Resuming Operation

Table 3 - 1
Resuming
Operation
Closing the Lid
If you have chosen to send the computer to Sleep when the lid is closed, raising the lid will wake the system up.
Power Button
When the computer is on, you can use the power button as a Sleep/Hibernate/Shut Down hot key button when it is pressed for less than 4 seconds (pressing and holding the power button for longer than this will force the computer to shut down).
You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (Fn + F12 key combo).
Power Status
Power Off Off Press the Power Button
Sleep Blinking Green
Hibernate
Display Turned Off Green Press a Key or Move the Mouse/Touchpad
Icon Color
Off (battery)
Orange (AC/DC adapter)
To Resume
Press the Power Button
Press the Sleep Button (Fn + F12 Key Combo)
Press the Power Button
Configuring the Power Buttons 3 - 11
Power Management
3
Power Management
Power Conservation
Modes
The Energy Star setting will result in maximum power saving, but with the possible loss of some performance.
Setting the mode to Bal- ance will give power saving matched with performance.
Performance will give optimum computer per­formance but with less power conservation.
Note that the Energy Star setting will put the display into sleep after no more than 15 min­utes of user inactivity.
Figure 3 - 7
Control Center
3

Power Conservation Modes

This system supports Energy Star power management features that place comput­ers (CPU, hard drive, etc.) into a low-power sleep modes after a designated period of inactivity. Adjust Power Conservation Modes from the Control Center:
1. Press the Fn + Esc key combination to toggle the Control Center on/off.
2. Click either the Performance, Balanced or Energy Star button.
3 - 12 Configuring the Power Buttons
Ctrl + Alt + Delete Key Combination
Figure 3 - 8
Ctrl + Alt + Delete
Menu
You can use the CTRL + ALT + DEL key combination from almost any of the Win­dows 8 interfaces/Apps to bring up a full-screen displaying Lock, Switch User, Log
off, Change a password and Task Manager options. If you click the Power icon in the lower right corner of the screen a power management option menu appears to display Sleep, Shut down, and Restart.
Power Management
3
To fully control all the power options (including Hibernate mode) go to the Power Options control panel and configure the power button, sleep button and lid to per-
form the function selected.
Configuring the Power Buttons 3 - 13
Power Management
Low Battery
Warning
When the battery is criti­cally low, immediately connect the AC/DC adapter to the computer or save your work, oth­erwise, the unsaved data will be lost when the power is depleted.
Figure 3 - 9
Battery Icon
(Notification Area) &
Battery Advanced
Settings
3

Battery Information

Follow these simple guidelines to get the best use out of your battery.

Battery Power

Your computer’s battery power is dependent upon many factors, including the pro­grams you are running, and peripheral devices attached. You can set actions to be taken (e.g. Shut down, Hibernate etc.), and set critical and low battery levels from power plan Change plan settings > Change advanced power settings (see Figure
3 - 3 on page 3 - 6).
Click the battery icon in the notification area to see the current battery level and charge status.
3 - 14 Battery Information

Conserving Battery Power

Windows Mobility
Center
The Windows Mobility Center control panel
provides an easy point of access for information on battery status, power plans used and wireless device status etc.
Figure 3 - 10
Windows Mobility
Center
•Use a power plan that conserves power (e.g Power saver), however note that
this may have an affect on computer performance.
• Lower the brightness level of the LCD display. The system will decrease LCD brightness slightly to save power when it is not powered by the AC/DC adapter.
• Reduce the amount of time before the display is turned off.
• Close wireless, Bluetooth, modem or communication applications when they are not being used (e.g. put the system in Airplane Mode).
• Disconnect/remove any unnecessary external devices e.g. USB devices, ExpressCards etc.
Power Management
3
Battery Information 3 - 15
Power Management

Battery Life

Battery life may be shortened through improper maintenance. To optimize the life
3
and improve its performance, fully discharge and recharge the battery at least once every 30 days.
We recommend that you do not remove the battery yourself. If you do need to re­move the battery for any reason (e.g. long term storage) see “Removing the Battery”
on page 1 - 15.

New Battery

Always completely discharge, then fully charge, a new battery (see “Battery FAQ”
on page 3 - 18 for instructions on how to do this).

Recharging the Battery with the AC/DC Adapter

The battery pack automatically recharges when the AC/DC adapter is attached and plugged into an electrical outlet. If the computer is powered on, and in use, it will take several hours to fully recharge the battery. When the computer is turned off but plugged into an electrical outlet, battery charge time is less. Refer to “LED Indica-
tors” on page 1 - 7 for information on the battery charge status, and to “Battery In­formation” on page 3 - 14 for more information on how to maintain and properly
recharge the battery pack.
3 - 16 Battery Information

Proper handling of the Battery Pack

Caution
Danger of explosion if battery is incorrectly re­placed.
Replace only with the same or equivalent type recommended by the manufacturer. Discard used battery according to the manufacturer’s in­structions.
Damaged Battery Warning
Should you notice any physical defects (e.g. the battery is bent ou t of shape after being dropped), or any unusual smells emanating from the notebook battery, shut your computer down immediately and contact your distributor/supplier. If the battery has been dropped we do not recommend using it any further, as even if the comp uter continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire. It is recommended that you replace your computer battery every two years.
• DO NOT disassemble the battery pack under any circumstances
• DO NOT expose the battery to fire or high temperatures, it may explode
• DO NOT connect the metal terminals (+, -) to each other
Power Management
3
Battery Information 3 - 17
Power Management
Figure 3 - 11
Power Plan Create
3

Battery FAQ

How do I completely discharge the battery?
Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
1. Save and close all files and application s.
2. Create a power plan for discharging the battery and set all the options to Never.
3 - 18 Battery Information
3. Click Change plan settings (after creating it) and click Change plan settings >
Figure 3 - 12
Change Plan
Settings / Change
Advanced Power
Settings
Change advanced power settings.
Power Management
3
Battery Information 3 - 19
Power Management
Figure 3 - 13
Power Options
Advanced Settings -
Battery
3
4. Scroll down to Battery and click + to expand the battery options.
5. Choose the options below (click Yes if a warning appears):
• Low battery levels = 0%
• Critical battery Levels = 1%
• Low battery action = Do Nothing
• Critical battery action (On battery) = Shut Down
• Critical battery action (Plugged in) = Do Nothing
3 - 20 Battery Information
How do I fully charge the battery?
When charging the battery, don’t stop until the LED charging indicator light changes from orange to green.
How do I maintain the battery?
Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.
Power Management
3
Battery Information 3 - 21
Power Management
Bottom Cover
Removal Warning
Do not remove any cov­er(s) and /or screw(s) for the purposes of device upgrade as this may vio­late the terms of your warranty.
If you need to replace/ remove the hard disk/ RAM/optical device etc., for any reason, please contact your distributor/ supplier for further infor­mation.
Figure 3 - 14
Battery Removal
123
2 1
3
3

Removing the Battery

We recommend that you do not remove the battery yourself. If you do need to re­move the battery for any reason (e.g. long term storage) see below.
1. Turn the computer off, and turn it over.
2. Slide the latch in the direction of the arrow.
3. Slide the latch in the direction of the arrow, and hold it in place.
4. Slide the battery out in the direction of the arrow .
5. See over for inserting the battery instructions.
3 - 22 Removing the Battery

Inserting the Battery

Figure 3 - 15
Battery Insertion
123
1
2 3
1. Slide the battery straight into the compartment (note that there are grooves on
the side of the battery which should align up with the battery compartment).
2. Lock
3. Lock the battery in place by sliding latch in the direction of the arrow
should lock automatically into place upon insertion.
.
Power Management
3
Removing the Battery 3 - 23
Power Management

Intel® Dynamic Platform & Thermal Framework

The Intel® Dynamic Platform and Thermal Framework (Intel® DPTF) is a hard-
3
ware/software solution for power and thermal management on your computer, and provides multiple power/thermal technologies. Simply install the driver as instruct­ed below and the technology will provide a set of policies to effect the power man­agement of the CPU versus the system temperature.

Intel® DPTF Driver Installation

1. Make sure the system is not in Airplane Mode, and then insert the Device Drivers & Utilities + User’s Manual disc into the DVD drive.
2. Click Option Drivers (button).
3. Click 3.Install DPTF Driver > Yes.
4. Click Next.
5. Click Yes to accept the license.
6. Click Next > Finish.
7. See over for configuration details.
3 - 24 Intel® Dynamic Platform & Thermal Framework

Configuring Intel® Dynamic Platform & Thermal Framework

Figure 3 - 16
Change Plan
Settings / Change
Advanced Power
Settings
1. Go to the Power Options (Hardware and Sound) control panel.
2. Click Change plan settings > Change advance d powe r set ting s alongside one of your power plans.
Power Management
3
Intel® Dynamic Platform & Thermal Framework 3 - 25
Power Management
Figure 3 - 17
Power Options
Advanced Settings -
Intel® Dynamic
Platform & Thermal
Framework
3
3. Scroll down to Intel® Dynamic Platform & Thermal Framework and click + to expand the options.
4. Click the sub-menus to adjust the settings as required (see below and overleaf).
3 - 26 Intel® Dynamic Platform & Thermal Framework
Loading...
