Clevo W510TU-L Concise User's Guide

Document Guide - Notebook Series I & II
This manual covers two notebook series, and this document contains two manuals with information relating to both notebook series. The main difference between the two notebook series is in the appearance as illustrated below. Note that your comp uter may l ook s lightly dif­ferent from those pictured throughout either concise user’s guide. See Specifications at the end of each manual for full specification de­tails. If you need any assistance you can contact your distributor/supplier for further help.
Feature
Model
Appearance
Notebook Series I Notebook Series II
1 1.6”(29.46cm) HD (Thickness: 3.6mm)
14.0” (35.56cm) HD (Thickness: 3.6mm)
Contents
About this Concise User Guide ......................................................... 1
System Startup ...................................................................................4
System Map: Front View with LCD Panel Open ..............................5
LED Indicators ................................................................................... 6
Keyboard ............................................................................................ 7
Function Keys & Visual Indicators ...................................................8
Control Center ................................................................................... 9
System Map: Front, Left, Right, Rear & Bottom Views .................12
Windows 8.1 Control Panel ............................................................. 13
Windows 8.1 Start Screen & Desktop ............................................. 13
Apps & Tiles .............. ............... .............. ............... ............... ........... 14
Charms Bar ...................................................................................... 14
Video Features ................................................................................. 15
Power Options ................................................................................. 16
Driver Installation ............................................................................ 17
Troubleshooting ............................................................................... 18
Specifications ................................................................................... 19
Inhalt
Über das Ausführliche Benutzerhandbuch ...................................... 21
Schnellstart ...................................................................................... 24
Systemübersicht: Ansicht von vorne mit geöffnetem
LCD-Bildschirm ............................................................................. 25
LED-Anzeigen ................................................................................. 26
Tastatur ............................................................................................ 27
Funktionstasten ................................................................................ 28
Control Center (Steuerzentrum) ....................................................... 29
Systemübersicht: Ansicht von vorne, links, rechts, hinten und
unten .............................................................................................. 32
Windows 8.1 Systemsteuerung ........................................................33
Windows 8.1 Start-Bildschirm und Desktop ...................................33
Apps und Kacheln ............................................................................34
Charms-Leiste .................................................................................. 34
Grafikfunktionen .............................................................................. 35
Energieoptionen ............................................................................... 36
Installation der Treiber ..................................................................... 37
Fehlerbehebung ................................................................................ 38
Technische Daten .............................................................................39
Sommaire
A propos de ce Guide Utilisateur Concis .........................................43
Guide de démarrage rapide ..............................................................46
Carte du système: Vue de face avec l’écran LCD ouvert ...............47
Indicateurs LED ............................................................................... 48
Clavier .............................................................................................. 49
Touches fonction .............................................................................. 50
Control Center (Centre de contrôle) ................................................51
Carte du système: Vues de face, gauche, droite, arrière et
dessous ...........................................................................................54
Panneau de Configuration de Windows 8.1 ..................................... 55
Écran d'accueil & bureau de Windows 8.1 ...................................... 55
Applications et Vignettes .......... ............... ............... .............. ........... 56
Barre des charmes ............................................................................ 56
Caractéristiques vidéo ...................................................................... 57
Options d’alimentation .................................................................... 58
Installation du pilote ........................................................................59
Dépannage ....................................................................................... 60
Spécifications ...................................................................................61
Contenidos
Acerca de esta Guía del Usuario Concisa ........................................ 65
Guía rápida para empezar ................................................................ 68
Mapa del sistema: Vista frontal con panel LCD abierto ..................69
Indicadores LED ..............................................................................70
Teclado ............................................................................................ 71
Control Center (Centro de control) .................................................. 73
Mapa del sistema: Vistas frontal, izquierda, derecha, posterior
e inferior ..........................................................................................76
Panel de Control de Windows 8.1 ................................................... 77
Pantalla Inicio y escritorio de Windows 8.1 .................................... 77
Apps y Mosaicos .............................................................................. 78
Barra Charms ...................................................................................78
Parámetros de vídeo .........................................................................79
Opciones de energía ......................................................................... 80
Instalación de controladores ............................................................ 81
Solución de problemas ..................................................................... 82
Especificaciones ............................................................................... 83
Sommario
Informazioni su questa guida rapida ................................................ 87
Guida di avvio rapido ...................................................................... 90
Descrizione del sistema: Vista anteriore con pannello
LCD aperto .....................................................................................91
Indicatori LED .................................................................................92
Tastiera ............................................................................................ 93
Tasti funzione ..................................................................................94
Control Center (Centro di controllo) ............................................... 95
Descrizione del sistema: Vista anteriore, sinistra, destra,
posteriore e inferiore ........................................................................ 98
Pannello di controllo di Windows 8.1 .............................................99
Schermata Start e Desktop di Windows 8.1 ....................................99
App & Titoli .................................................................................. 100
Charms Bar .................................................................................... 100
Funzioni video ............................................................................... 101
Opzioni risparmio energia ............................................................. 102
Installazione driver ........................................................................103
Risoluzione dei problemi ............................................................... 104
Specifiche tecniche ........................................................................ 105

About this Concise User Guide

FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1.This device may not cause harmful interference.
2. This device must accept any interference received, includ­ing interference that may cause undesired operation.
This quick guide is a brief introduction to getting your system started. This is a s upplement, and not a substitute for the expanded English language User’s Manual in Adobe Acrobat format on the Device Drivers & Utilities + User’s Manual disc supplied with your computer. This disc also contains the drivers and utilities necessary for the proper oper ation of the computer (Note: The company reserves the right to revise this publication or to change its contents without notice).
Some or all of the computer’s features may already have been setup. If they aren’t, or you are planning to re-configure (or re-install) portions of the system, refer to the expanded User’s Manual. The Device Drivers & Utilities + User’s Manual disc does not contain an operating system.
Regulatory and Safety Information
Please pay careful attention to the full regulatory notices and safety information contained in the expanded User’s Man­ual on the Device Drivers & Utilities + User’s Manual disc.
© May 2014
Trademarks
Intel and Celeron are trademarks/registered trademarks of Intel Corporation.
English
1
Instructions for Care and Operation
The computer is quite rugged, but it can be damaged. To pre­vent this, follow these suggestions:
Don’t drop it, or expose it to shock. If the computer falls, the
case and the components could be damaged.
Keep it dry, and don’t overheat it. Keep the computer and
power supply away from any kind of heating element. This is an electrical appliance. If water or any other liquid gets into it, the
English
computer could be badly damaged.
Avoid interfer ence. Keep the computer away from high capacity
transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data.
Follow the proper working procedures for the computer. Shut
the computer down properly and don’t forget to save your work. Remember to periodically save your data as data may be lost.
Servicing
Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock. Refer all servicing to authorized service person­nel. Unplug the computer from the power supply. Then refer servicing to qualified service personnel under any of the fo l­lowing conditions:
• When the power cord or AC/DC adapter is damaged or frayed.
• If the computer has been exposed to any liquids.
• If the computer does not work normally when you follow the operating instructions.
• If the computer has been dropped or damaged (do not touch the poisonous liquid if the LCD panel breaks).
• If there is an unusual odor, heat or smoke coming from your com­puter.
Safety Information
• Only use an AC/DC adapter approved for use with this computer.
• Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may explode. Check with local codes for possible special disposal instructions.
• Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
• Make sure that your computer is completely powered off before putting it into a travel bag (or any such container).
• Before cleaning the computer, make sure it is disconnected from any external power supplies, peripherals and cables (including telephone lines). It is advisable to also remove your battery in order to prevent accidentally turning the machine on.
• Use a soft clean cloth to clean the computer, but do not apply cleaner directly to the computer. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer.
• Do not try to repair a battery pack. Refer any battery pack repair or replacement to your service representative or qualified service personnel.
• Note that in computer’s featuring a raised LCD electro-plated logo, the logo is covered by a protective adhesive. Due to general wear and tear, this adhesive may deteriorate over time and the exposed logo may develop sharp edges. Be careful when handling the computer in this case, and avoid touching the raised LCD electro-plated logo. Avoid placing any other items in the carrying bag which may rub against the top of the computer during trans­port. If any such wear and tear develops contact your service cen­ter.
2
Polymer Battery Precautions
Battery Disposal & Caution
The product that you have purchased contains a recharge­able battery. The battery is recyclable. At the end of its use­ful life, under various state and local laws, it may be illegal to dispose of this battery into the municipal waste stream. Check with your local solid waste officials for details in your area for recycling options or proper disposal.
Danger of explosion if battery is incorrectly replaced. Re­place only with the same or equivalent type recommended by the manufacturer. Discard used battery a ccording to the manufacturer’s instructions.
Note the following information which is specific to polymer batteries only, and where applicable, this overrides the general battery precaution information.
• Polymer batteries may experience a slight expansion or swelling, however this is part of the battery’s safety mechanism and is not a cause for concern.
• Use proper handling procedures when using polymer batteries. Do not use polymer batteries in high ambient temperature envi­ronments, and do not store unused batteries for extended periods.
English
3

System Startup

130
Shut Down
Note that you should always shut your computer down by choosing the Shut down command in Windows (see be­low). This will help prevent hard disk or system problems.
Click the icon in the Start Screen and choose Shut down from the menu.
Or
Right-click the Start button
at the bottom of the Start
Screen or the Desktop and choose Shut down or sign out > Shut down from the context menu.
1. Remove all packing materials.
2. Place the computer on a stable surface.
3. Insert the battery and make sure it is locked in position.
4. Securely attach any peripherals you want to use with the
computer (e.g. keyboard and mouse) to their ports.
5. Attach the AC/DC adapter to the DC-In jack on the right of the
computer, then plug the AC power cord into an outlet, and
English
connect the AC power cord to the AC/DC adapter.
6. Use one hand to raise the
(do not exceed 130 degrees); use the other hand (as illustrated in Figure 1) to support the base of the computer (Note: Never lift the computer by the lid/LCD).
7. Press the power button to turn the computer “on”.
lid/LCD to a comfortable viewing angle
System Software
Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find this manual refers to Microsoft Windows 8.1 (32- bit).
Figure 1 - Opening the Lid/LCD/Computer with AC/DC
Adapter Plugged-In
4

System Map: Front View with LCD Panel Open

Note that the Touchpad and Buttons valid operational area is that indicated within the red dotted lines above.
Figure 2
Front View with LCD Panel
Open
1. PC Camera (Optional)
2. *PC Camera LED
*When the PC camera is in use, the LED will be illuminated in red.
3. Built-In Microphone
4. LCD
5. Power Button
6. Keyboard
7. Touchpad & Buttons
5
7
6
2
1
3
7
4
Wireless Device
Operation Aboard
Aircraft
The use of any por­table electronic transmission devic­es aboard aircraft is usually prohibited.
Make sure the WLAN & Bluetooth module(s) are OFF if you are using the computer aboard aircraft by putting the system in to Air­plane Mode.
7
English
5

LED Indicators

The LED indicators on the computer display helpful information about the current status of the computer.
Icon Color Description
English
Orange The AC/DC Adapter is Plugged In
Green The Computer is On
Blinking Green The Computer is in Sleep Mode
Orange The Battery is Charging
Green The Battery is Fully Charged
Blinking Orange The Battery Has Reached Critically Low Power Status
6
Green
Green The Hard Disk is in use
Airplane Mode is ON (the WLAN & Bluetooth Modules are OFF)
Table 1 - LED Indicators
Keypad
Keypad
Function Keys
Num Lk & Scr Lk
Numeric Keypad
Fn Key
Windows Logo Key
Menu/Application Key
Windows Logo
Keyboard Shortcut
Use the Windows Logo Key + D key combi-
nation to switch from the Start screen to the Win­dows Desktop.
Menu/Application
Keyboard Shortcut
When the Desktop app is running you can use the
Menu/Application key
on the keyboard to act as a mouse right­click. In the Start screen this function is useful to quickly display the Cus- tomize bar.
Figure 3 - Keyboard

Keyboard

The keyboard has a numeric keypad for easy numeric data input. Pressing Fn + Num Lk turns on/off the numeric keypad. It also features function keys to allow you to change operational features instantly.
English
7

Function Keys & Visual Indicators

The function keys (F1 - F11 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the basic function key combinations, some visual indicators are available (in the Windows Desktop application only and not in the Start Screen) when the hot key driver is installed.
Keys Function/Visual Indicators Keys Function/Visual Indicators
English
Fn +
Fn + Touchpad Toggle Fn +
Fn +
Fn +
Fn +
Fn +
8
Fn +
Fn +
Play/Pause (in Audio/Video Programs)
Turn LCD Backlight Off
(Press a key to or use Touchpad to turn on)
Mute Toggle
Sleep Toggle
Volume Decrease/
Increase
Change Display Configuration (see page 16)
Brightness Decrease/
Increase
Table 2 - Function Keys & Visual Indicators
Fn +
Fn +
Fn +
Fn +
Fn +
PC Camera Power
Toggle
Airplane Mode Tog-
gle
Number Lock Toggle
Scroll Lock Toggle
Caps Lock Toggle
Control Center Toggle (see page 9)
Fan Automatic Con-
trol/ Full Power

Control Center

The Control Center in Windows 8.1 works under the Desktop app and not under the Start screen. Press the Fn + Esc key combination, or double-click the icon in the notification area of the taskbar to toggle the Control Center on/off. The Control Center gives quick access to frequently used controls and enables you to quickly turn the camera/ Touchpad on/off.
Figure 4 - Control Center
English
Click the Control Center icons to toggle the appropriate function, or hold the mouse button down and move the dial control where applicable. Certain functions will automatically be adjusted when a power mode is selected.
9
Power Modes
You can set a Power Mode by clicking the appropriate icon at the top of the Control Center. Each power mode will affect the Power Conservation Mode, Airplane Mode, Power Plan and PC camera power etc.
You can click a Control Center icon to set an overall power mode and then click individual icons in the Control Cen- ter to power on/off the Touchpad and PC camera.
English
Modes Quiet Power Saving Performance Entertainment
Icon
Power Plan
Balanced
Power Conservation Mode Energy Star Performance
PC Camera ON OFF ON ON
TouchPad ON ON ON ON
Airplane Mode OFF ON OFF OFF
Table 3 - Power Modes
Power Saver High Performance
Balanced
10
Power Status
The Power Status icon will show whether you are cur­rently powered by the battery, or by the AC/DC adapter plugged in to a working power outlet. The power status bar will show the current battery charge state.
Brightness
The Brightness icon will show the current screen bright­ness level. You can use the slider to adjust the screen brightness or the Fn + F8/F9 key combinations, or use the Fn + F2 key combination to turn off the LED backlight (press any key to turn it on again). Note that screen bright­ness is also effected by the Power Mode selected.
Volume
The Volume icon will show the current volume level. You can use the slider to adjust the volume or the Fn + F5/F6 key combinations, or use the Fn + F3 key combination to mute the volume.
Power Conservation
This system supports Energy Star power management features that place computers (CPU, hard drive, etc.) into a low-power sleep mode after a designated period of inac­tivity. Click either the Performance, Balanced or Ener-
gy Star button.
Fan Speed
The fan speed will adjust itself automatically to control the heat of the CPU. However you can adjust the setting to maximum if you prefer.
English
Sleep Button
Click either the Hibernate or Sleep button to have the computer enter the selected power-saving mode.
Display Switch
Click the Display Switch button to access the menu (or use the + P key combination) and select the appropri­ate display mode.
Time Zone
Clicking the Time Zone button will access the Date and Time Windows control panel.
Desktop Background
Clicking the Desktop Background button will allow you to change the desktop background picture.
Touchpad/PC Camera
Click either of these buttons to toggle the TouchPad or camera module’s power status. Note that the power status of the camera module is also effected by the Power Mode selected.
11

System Map: Front, Left, Right, Rear & Bottom Views

1
Front
Bottom
Figure 5 - Front, Left, Right, Rear & Bottom Views
1. LED Indicators
2. Security Lock Slot
3. External Monitor Port
4. Vent
5. HDMI-Out Port
6. USB 3.0 Port
7. Microphone-In Jack
8. Headphone-Out Jack
9. USB 2.0 Ports
10. Multi-in-1 Card Reader
11. RJ-45 LAN Jack
12. DC-In Jack
13. Battery
14. Speakers
2
4
6
3
Left
Right
5
Rear
10
11
7
13
Bottom Cover Removal Warning
Do not remove any cover(s) and/or screw(s) for the purposes of device up­grade as this may violate the terms of your warranty.
If you need to replace/remove the hard disk/RAM/optical device etc., for any reason, please contact your distributor/ supplier for further information.
9
12
8
9
13
4
4
4
14
14
English
12

Windows 8.1 Control Panel

Move the mouse to the bottom left of the screen and right-click the Start button to ac­cess the menu.
Figure 6
Context
Menu
Figure 7
Start
Screen
Throughout this manual you will see an instruction to open the Control Panel. Right-click the Start button in the Desktop app or Start screen (or use the Windows Logo Key + X key combination) to bring up an advanced context
menu of useful features such as Control Panel, Programs and Features, Power Options, Task Manager, Search, File Ex­plorer, Command Prompt, Device Manager and Network Connections etc. and then select Control Panel.

Windows 8.1 Start Screen & Desktop

The Apps, control panels, utilities and programs within
Windows are accessed from the Start screen and/or Windows Desktop app. The Desktop (which runs as an
app within the Start screen) can be accessed by clicking the Desktop item in the Start screen (or by using the Windows Logo Key + D key combination). The taskbar is displayed at the bottom of the desktop screen, and you can see the notification area of the taskbar in the bottom right of the screen. Click the arrow at the bottom of the Start screen to access Apps.
13
English

Apps & Tiles

Click the arrow at the bottom of the
screen to access Apps
The Start screen will contain a number of apps, and many more will be installed as you add more applications etc. Not all of these apps can fit on one screen so you will often need use the slider at the bottom of the screen in order to view all the necessary Apps.

Charms Bar

English
The right side of the screen displays the Charms Bar. The Charms Bar contains the Search, Share, Start, Devices and Settings menus. To access up the Charms Bar move the cursor to the upper or lower right corners of the screen, and
then hover over one of the items in the Charms Bar to activate it (the bar will be black when it is active), or use the Windows Logo Key + C key combination.
14
Figure 8 - Start Screen with Charms Bar

Video Features

1
2
2
1
Figure 9
Display
Control
Panel
Screen Resolution for Apps (Windows 8.1)
The minimum resolution in which Apps will run is 1024x768.
The minimum resolution required to support all the fea­tures of Windows 8.1 (including multitasking with snap) is 1366x768.
The system features an Intel integrated GPU. You can switch display devices, and configure display options, from the Display control panel in Windows as long as the video driver is installed.
To access the Display control panel in Windows:
1. Go to the Control Panel.
2. Click Display (icon) - in the Appearances and Personalization category.
3. Click Adjust Screen Resolution/Adjust resolution.
OR
4. Right-click the desktop (use the Windows Logo Key + D key combination to access the desktop) and select Screen resolution.
5. Use the dropbox to select the screen resolution .
6. Click Advanced settings .
To access the Intel® HD Graphics Control Panel:
1. Click the icon (Intel® HD Graphics Control Panel) on the Apps screen.
OR
2. Right-click the desktop (use the Windows Logo Key + D key combination to access the desktop) and select Graphics Properties from the menu.
OR
3. Click the icon in the notification area of the Desktop taskbar
and select Graphics Properties from the menu.
Display Devices
Besides the built-in LCD, you can also use an external VGA monitor (CRT)/external Flat Panel Display or TV (connected to the external monitor port/HDMI-Out port) as your display device.
English
15
Using the Windows Logo Key + P
Figure 10
+ P (Change Display
Configuration)
Figure 11 - Power Options
Key Combination to Switch Displays
You can also use the + P key combination (or Fn + F7 ) to quickly change display configuration and modes (this is particularly useful when attaching a projector) in Win- dows.
1. Attach your external display to the external monitor port/HDMI-
English
Out port, and turn it on.
2. Press the + P (or Fn + F7) key combination.
3. An on-screen menu will pop up.
4. Use the cursor keys ( + P) to select the appropriate configuration from the menu, and press Enter to confirm the selection.

Power Options

The Power Options (Hardware and Sound menu) con­trol panel icon in Windows allows you to configure power management features for your computer. You can con­serve power by means of power plans and configure the options for the power button, sleep button (Fn + F4), computer lid (when closed), display and sleep mode (the default power saving state) from the left menu. Note that the Power saver plan may have an affect on computer performance.
Click to select one of the existing plans, or click Create a power plan in the left menu and select the options to cre­ate a new plan. Click Change Plan Settings and click Change advanced power settings to access further con­figuration options.
16

Driver Installation

Driver Installation General
Guidelines
As a general guide follow the default on-screen instruc­tions for each driver (e.g. Next > Next > Finish) unless you are an advanced user. In many cases a restart is re­quired to install the driver.
Make sure any modules (e.g. WLAN or Bluetooth) are ON before installing the appropri­ate driver.
Windows Update
After installing all the drivers make sure you enable Win- dows Update in order to get all the latest security updates etc. (all updates will include the latest hotfixes from Mi- crosoft).
Driver Installation & Power
When installing drivers make sure your computer is powered by the AC/DC adapt­er connected to a working power source. Some drivers draw a significant amount of power during the installation procedure, and if the remaining battery capacity is not adequate this may cause the system to shut down and cause system problems (note that there is no safety issue involved here, and the battery will be rechargeable within 1 minute).
The Device Drivers & Utilities + User’s Manual disc contains the drivers and utilities necessary for the proper operation of the computer. This setup will probably have al­ready been done for you. If this is not the case, insert the disc and click Install Drivers (button), or Option Drivers (button) to access the Optional driver menu. Install the drivers in the order indicated in Figure 12. Click to select the drivers you wish to install (you should note down the drivers as you install them). Note: If you need to reinstall any driver, you should uninstall the driver first
Manual Driver Installation
Click the Browse CD/DVD button in the Drivers Installer application and browse to the executable file in the appropriate driver folder.
If a
Found New Hardware
Cancel and follow the installation procedure as directed.
wizard appears
Figure 12 - Install Drivers
during the installation procedure, click
.
English
17

Troubleshooting

Problem Possible Cause - Solution
The Wireless LAN/Bluetooth modules cannot be detected.
The PC Camera module cannot be
English
detected.
The modules are off as the computer is in Airplane Mode . Check the LED indicator to see if it is in Airplane Mode (see Table 1 on page 6). Use the Fn + F11 key combination to toggle Airplane Mode on/off (see Table 2 on page 8).
The module is off. Press the Fn + F10 key comb inati on in order to enab le th e module (see
Table 2 on page 8). Run the camera application to view the camera picture.
18

Specifications

Latest Specification Information
The specifications listed in this here are correct at the time of going to press. Certain items (particularly pro­cessor types/speeds) may be changed, delayed or updated due to the manufacturer's release sched­ule. Check with your service center for details.
Processor Options
Intel® Celeron™ Processor N2830 (2.17GHz)
1MB L2 Cache, 22nm, DDR3L-1333MHz, TDP 7.5W
N2807 (1.58GHz)
1MB L2 Cache, 22nm, DDR3L-1333MHz, TDP 4.3W
BIOS
64Mb SPI Flash ROM AMI BIOS
Memory
One 204 Pin SO-DIMM Socket Supporting DDR3L 1600MHz Memory
Memory Expandable up to 2GB (The real memory operating frequency
depends on the FSB of the processor.)
LCD
11.6" (29.46cm) HD (Thickness: 3.6mm)
Video Adapter
Intel HD Graphics
Dynamic Frequency (Intel Dynamic Video Memory Technology for up to 1.7GB)
Microsoft DirectX® 11 Compatible
Storage
One Changeable 2.5" 7.0mm (h) SATA HDD
(Factory Option) One 16GB mSATA Solid State Drive (SSD)
Audio
High Definition Audio Compliant Interface 2 * Built-In Speakers Built-In Microphone
Security
Security (Kensington® Type) Lock Slot BIOS Password
Keyboard
“WinKey” keyboard (with embedded numeric keypad)
Pointing Device
Built-in Touchpad
Interface
Two USB 2.0 Ports One USB 3.0 Port One HDMI-Out Port One External Monitor Port One Headphone-Out Jack One Microphone-In Jack One RJ-45 LAN Jack One DC-in Jack
Mini Card Slots
Slot 1 for WLAN Module or WLAN and
Bluetooth Combo Module
(Factory Option) Slot 2 for mSATA SSD
Card Reader
Embedded Multi-In-1 Card Reader
MMC (MultiMedia Card) / RS MMC SD (Secure Digital) / Mini SD / SDHC/
SDXC MS (Memory Stick) / MS Pro / MS Duo
English
19
Communication
Built-In 10/100Mb Ethernet LAN (Factory Option) 1.0M HD PC Camera
Module/300K Pixels PC Camera Module
WLAN/ Bluetooth Half Mini-Card Modules:
(Factory Option) Third-Party Wireless LAN
English
(802.11b/g/n) (Factory Option) Third-Party Wireless LAN
(802.11b/g/n) + Bluetooth 4.0
Environmental Spec
Temperature
Operating: 5 Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80% Non-Operating: 10% - 90
Power
Full Range AC/DC Adapter AC Input: 100 - 240V, 50 - 60Hz DC Output: 19V, 1.58A (30W)
3 Cell Smart Lithium-Ion Battery Pack, 24WH
(Factory Option) 3 Cell Smart Lithium-Ion Battery Pack, 31WH
Dimensions & Weight
292.4mm (w) * 210.5mm (d) * 22.7mm (h) (Height Excluding Battery Area)
1.3kg (Barebone with 24WH Battery)
°C - 35°C
20

Über das Ausführliche Benutzerhandbuch

Diese Kurzanleitung soll einen Überblick über die Schritte geben, die dazu notwendig s ind, das System zu starten. Dieses ist nur eine Ergänzung und kein Ersatz für das erweiterte englischsprachige Benutzerhandbuch, das auf der mitgelieferten Disc Device Drivers & Utilities + User's Manual im Adobe-Acrobat-Format vorliegt. Diese Disc enthält auch die Treiber und Utility-Programme, die für einen einwandfreien Betrieb des Computers notwendig sind (Hinweis: Das Unternehmen behält sich das Recht vor, diese Publikation ohne Vorankündigung zu überarbeiten und den Inhalt zu verändern).
Einige oder alle Funktionen des Computers sind bereits eingerichtet worden. Falls das nicht der Fall ist oder wenn Sie ein­zelne Teile des Systems neu konfigurieren (oder neu installieren) möchten, finden Sie eine Anleitung im erweiterten Benut- zerhandbuch. Die Disc Device Drivers & Utilities + User's Manual enthält nicht das Betriebssystem.
Einhaltung gesetzlicher Vorschriften und Sicherheitshinweise
Beachten Sie sorgfältig die Hinweise zu gesetzlichen Vorschriften und zu Sicherheitshinweisen im erweiterten Benutzer­handbuch auf der Disc Device Drivers & Utilities + User's Manual.
© Mai 2014
Warenzeichen
Intel und Celeron sind warenzeichen/eingetragenes warenzeichen der Intel Corporation.
Deutsch
21
Hinweise zu Pflege und Betrieb
Das Notebook ist zwar sehr stabil, kann aber dennoch be­schädigt werden. Damit es nicht dazu kommt, sollten Sie die folgenden Hinweise beachten:
Das Gerät darf nicht herunterfallen und in anderer Form Stößen
ausgesetzt werden. Wenn der Computer fällt, können das Gehäuse und andere Komponenten beschädigt werden.
Das Gerät darf nicht nass werden und sich nicht überhitzen. Compu-
ter und Netzteil dürfen nicht in der Nähe von Wärmequellen stehen oder gelagert werden. Dies ist ein elektrisches Gerät. Wenn Wasser oder andere Flüssigkeiten eindringen, kann der Computer stark beschädigt werden.
Vermeiden Sie Interferenzen mit anderen Geräten. Halten Sie den
Computer fern von magnetischen Feldern, die von Stromquellen, Moni-
Deutsch
toren, Magneten etc. erzeugt werden. Die können die Leistung beein­trächtigen und Ihre Daten beschädigen.
Achten Sie auf die richtige Bedienung des Computers. Schalten Sie
ihn erst aus, wenn alle Programme geschlossen wurden (speichern Sie Ihre Daten!). Speichern Sie regelmäßig Ihre Daten, da diese verloren gehen können, wenn der Akku verbraucht ist.
Reparatur
Nehmen Sie vor dem Reinigen des Wenn Sie versuchen, den Computer selbst zu reparieren , können Ihre Garantieansprüche verloren gehen. Außerdem besteht Stromschlaggefahr für Ihre Gesundheit und das Gerät durch frei liegende Teile. Lassen Sie Reparaturarbeiten nur von qualifizierten Reparaturfachleuten durchführen, insbesondere wenn folgende Umstände vorliegen:
• Wenn das Netzkabel oder der AC/DC-Adapter beschädigt oder ze rsch l is -
sen sind.
• Wenn der Computer Regen ausgesetzt war oder mit Flüssigkeiten in
Berührung gekommen ist.
• Wenn der Computer unter Beachtung der Bedienungsanweisungen nicht
korrekt arbeitet.
• Wenn der Computer heruntergefallen ist oder beschädigt wurde (berüh­ren Sie nicht die giftige Flüssigkeit des LCD-Bildschirms).
• Wenn ein ungewöhnlicher Geruch, Hitze oder Rauch aus dem Computer entweicht.
Sicherheitsinformationen
• Verwenden Sie nur einen AC/DC-Adapter, der für die Verwendung mit diesem Computer zugelassen ist.
• Verwenden Sie nur das Netzkabel und die Akkus, die in diesem Benut­zerhandbuch spezifiziert sind Sie können explodieren. Richten Sie sich nach den regional gültigen Ent­sorgungsvorschriften.
• Verwenden Sie den Akku nicht mehr, wenn er heruntergefallen ist oder in anderer Weise beschädigt (z.B. verzogen) ist. Auch wenn der Computer mit dem beschädigten Akku zu funktionieren schein, können dadurch Stromkreise beschädigt werden, die schließlich einen Brand verursachen können.
• Achten Sie darauf, dass Ihr Computer ausgeschaltet ist, wenn Sie es fur den Transport z.B. wahrend einer Reise in eine Tasche einpakken.
• Nehmen Sie vor dem Reinigen des Computers den Akku heraus, und trennen Sie es von allen externen Stromquellen, Peripheriegeräten und Kabeln (einschließlich Telefonkabel) ab.
• Reinigen Sie den Computer mit einem weichen, sauberen Tuch. Tragen Sie das Reinigungsmittel nicht direkt auf den Computer auf. Verwenden Sie keine flüchtigen Reinigungsmittel (Petroleumdestillate) oder Scheu­ermittel zum Reinigen des Computers.
• Versuchen Sie nicht, Akkus zu reparieren. Lassen Sie die Akkupacks durch den Servicevertreter oder qualifiziertes Fachpersonal reparieren oder austauschen.
• Beachten Sie, dass das Logo bei den Computern, die über ein galvanisch beschichtetes LCD-Logo verfügen, von einer Schutzfolie bedeckt ist. Durch die natürliche Abnutzung kann diese Schutzfolie beschädigt wer­den oder abgehen und die scharfen Kanten des frei liegenden Logos freigeben. Seien Sie in solch einem Fall vorsichtig bei der Handhabung des Computers, und vermeiden Sie es, das herausstehende beschichtete LCD-Logo zu berühren. Legen Sie keine Gegenstände in die Trageta­sche, da diese während des Transports gegen den Computer drücken können. Wenden Sie sich in einem solchen Fall von Abnutzung an Ihr Service Center.
. Entsorgen Sie die Akkus nicht in Feuer.
22
Polymer Akku Sicherheitshinweise
Entsorgen der Akkus/ Batterien & Achtung
Das von Ihnen gekaufte Produkt enthält einen aufladbaren Akku. Dier Akku ist wiederverwertbar. Nach verschiedenen na­tionalen und regionalen Getzgebungen kann es verboten in, einen nicht mehr gebrauchsfähigen Akku in den normalen Hausmüll zu werfen. Informieren Sie sich bei Ihrem regionalen Entsorgungsunternehmen über Recycling-Möglichkeiten oder korrekte Entsorgung.
Wenn ein falscher Akku eingesetzt wird, besteht Explosionsge­fahr. Tauschen Sie den Akku nur durch den gleichen oder einen baugleichen Typ aus, der vom Hersteller empfohlen wird. Ent­sorgen Sie den verbrauchten Akku entsprechend der Anwei­sungen des Herstellers.
Beachten Sie die folgenden Hinweise, die sich speziell auf Poly­mer Akkus beziehen. Diese Hinweise haben zudem Vorrang gegenüber den Allgemeinen Akku Sicherheitshinweisen.
• Polymer Akkus können sich etwas ausdehnen oder anschwellen. Dies ist Teil des Sicherheitsmechanismus des Akkus und kein Anlass zur Sorge.
• Seien Sie vernünftig im Umgang mit Polymer Akkus. Verwenden Sie keine Polymer Akkus in Umgebungen mit hohen Temperaturen und lagern Sie keine ungenutzten Akkus über längere Zeiträume.
Deutsch
23

Schnellstart

Herunterfahren
Bitte beachten Sie, daß der Computer immer mit dem Befehl Herun­terfahren in Windows (siehe unten) heruntergefahren werden muß.
Dadurch werden Festplatten- bzw. Systemprobleme vermieden. Klicken Sie auf das Symbol auf dem Start-
Bildschirm und wählen Sie aus dem Menü die Option Herunterfahren.
Oder
Klicken Sie mit der rechten Maustaste auf die Start-Taste unten auf dem Start-Bildschirmin oder auf den Desktop und wählen Sie aus dem Kontextmenü Herunterfahren oder abmelden > Herun- terfahren.
130
1. Entfernen Sie das gesamte Verpackungsmaterial.
2. Legen Sie den Computer auf eine stabile Unterlage.
3. Setzen Sie den Akku ein, und stellen Sie sicher, dass sie fest
sitzt.
4. Schließen Sie alle Peripheriegeräte, die Sie mit dem Computer
verwenden wollen (z. B. Tastatur und Maus), an die entsprechenden Schnittstellen an.
5. Schließen Sie den AC/DC-Adapter an die DC-Eingangsbuchse
an der rechten Seite des Computers an. Verbinden Sie dann das Netzkabel mit einer Netzsteckdose und dem AC/DC-Adap­ter
.
6. Klappen Sie den Deckel/LCD vorsichtig mit einer Hand auf,
Deutsch
und öffnen Sie ihn auf einen angenehmen Sichtwinkel (jedoch nicht weiter als 130°). Mit der anderen Hand halten Sie das Unterteil des Computers fest (siehe Abb. 1) (Hinweis: Heben Sie den Computer niemals am Deckel/LCD hoch).
7. Drücken Sie auf den Netzschalter, um den Computer
einzuschalten.
Systemsoftware
Möglicherweise wurde das Notebook bereits mit vorin­stallierter Software ausgeliefert. Ist das nicht der Fall, oder wenn Sie das Notebook für ein anderes System neu konfigurieren möchten, finden Sie dazu eine Anleitung in diesem Handbuch zu Microsoft Windows 8.1 (32-bit).
Abb. 1 - Öffnen des Deckels/LCD/Computers mit ange-
schlossenem AC/DC-Adapter
24
Systemübersicht: Ansicht von vorne mit geöffnetem LCD-Bild-
5
7
6
2
1
3
4
Beachten Sie, dass der Funk­tionsbereich des Touchpads und der Tasten innerhalb der rot gepunkteten Linien liegt.
Abb. 2
Ansicht von vorne mit ge-
öffnetem LCD-Bildschirm
1. PC-Kamera (optional)
2. *LED der PC-Kamera
*Wenn die PC-Kamera verwendet wird, leuchtet die LED rot.
3. Mikrofon
4. LCD-Bildschirm
5. Netzschalter
6. Tastatur
7. Touchpad mit Tasten
Die Benutzung
drahtlos
angeschlossener
Geräte in
Flugzeugen
In der Regel ist die Benutzung jeglicher tragbarer elektroni­scher Funkgeräte in Flugzeugen verboten.
Stellen Sie sicher, dass das WLAN- und das Bluetooth-Modul durch Aktivieren des Flugzeugmodus aus­geschaltet sind, wenn Sie sich an Bord eines Flugzeugs befinden.
7
schirm
Deutsch
25

LED-Anzeigen

Die LED-Anzeigen auf dem Computer zeigen wichtige Informationen über den aktuellen Status des Computers.
Symbol Farbe Beschreibung
Orange Der AC/DC-Adapter ist angeschlossen
Grün Der Computer ist angeschaltet
Deutsch
Lampe blinkt grün Das System ist im konfigurierten Energiesparmodus
Orange Der Akku wird geladen
Grün Der Akku ist voll geladen
Lampe blinkt orange Der Akku hat einen kritisch niedrigen Stromstatus erreicht
26
Grün
Grün Es wird auf die Festplatte zugegriffen
Flugzeugmodus ist EIN (das WLAN- und das Bluetooth-Modul ausgeschaltet
sind)
Tabelle 1 - LED-Anzeigen

Tastatur

n Keys
Numeric
Keypad
Keypad
Windows-Logo-Taste
Menü/Anwendungstaste
Fn Taste
Nummemtastatur
Funktionstasten
Num & Rollen
Tastenkürzel Windows-Logo
Drücken Sie gleichzeitig auf die Windows Logo-Taste und die Taste D, um vom Start­Bildschirm zum Windows-Des­ktop zu wechseln.
Tastenkürzel Menü/
Anwendung
Wenn die Desktop-App läuft, funktioniert die Menü/An-
wendungtaste
auf der Ta-
statur wie ein Rechtsklick mit der Maustaste. Auf dem Start­Bildschirm ist diese Funktion sehr nützlich, um direkt auf die Leiste Anpassen zuzugreifen.
Abb. 3 - Tastatur
Die Tastatur hat eine eingebettete Nummerntastatur für einfache Zahleneingabe. Durch Drükken auf Fn + Num wird die Nummerntastatur ein- und ausgeschaltet. Zusätzlich gibt es Funktionstasten, über die Sie direkt zwischen den Funktionen umschalten können.
Deutsch
27

Funktionstasten

Wenn die Funktionstasten (F1 - F11) gleichzeitig mit der Fn-Taste gedrückt werden, funktionieren sie wie Hotkeys. Neben den Tastenkombinationen für die Grundfunktionen gibt es einige visuelle Anzeigen (nur bei der Windows Desktop-An- wendung, aber nicht im Start-Bildschirm), wenn der Hotkey Treiber ins talliert ist.
Tasten Funktion/ Visuelle Anzeigen Tasten Funktion/ Visuelle Anzeigen
Fn +
Fn +
Deutsch
Fn +
Fn +
Fn +
Fn +
Fn +
Fn +
Wiedergabe/Pause (in Audio /Videoprogrammen)
Touchpad aktivieren/
deaktivieren
LCD-Hintergrundlicht ausschalten (zum Ein-
schalten beliebige Taste drücken oder Touchpad
berühren)
Stummschaltung/
Stummschaltung
aufheben
Wechsel Schlaf/Wiederaufnahme
Audio-Lautstärke
verringern/erhöhen
Ändern der Anzeigeeinstellungen (siehe Seite 36)
LCD-Helligkeit ver-
ringern/erhöhen
Tabelle 2 - Funktionstasten & visuelle Anzeigen
Fn +
Fn +
Fn +
Fn +
Fn +
Fn +
PC-Kamera aktivieren/
deaktivieren
Flugzeugmodus ein-/
ausschalten
Ein-/Ausschalten der
Nummerntastatur
Ein-/Ausschalten des
Scroll-Modus
Ein-/Ausschalten der
Feststelltaste
Ein-/Ausschalten des Control Center (Steuerzent-
rum) (siehe Seite 29)
Automatische Lüfter­steuerung/Volle Leis-
tung
28

Control Center (Steuerzentrum)

Das Control Center (Steuerzentrum) in Windows 8.1 funktioniert in der Desktop App und nicht auf dem Start-Bildschirm. Drücken Sie auf die Tastenkombination Fn + Esc, oder doppelklicken Sie auf das Symbol im Infobereich auf der Taskleiste um das Control Center ein-/auszuschalten. Das Control Center bietet den schnellen Zugriff auf häufig ver­wendete Funktionen, und Sie haben hier die Möglichkeit, das Touchpad/das Kamera-Modul direkt ein-/auszuschalten.
Abb. 4 - Control Center
Deutsch
Klicken Sie auf die Symbole des Control Center, um die entsprechende Funktion zu wählen, oder halten Sie die Maustaste gedrückt und verschieben Sie den Regler, falls vorhanden. Bestimmte Funktionen werden automatisch angepasst, wenn ein Strommodus ausgewählt ist.
29
Energiemodi
Sie können einen Energiemodus einstellen, indem Sie im Control Center auf das entsprechende Symbol klicken. Jeder Energiemodus wird Einfluss auf den Energiesparmodus, Flugzeugmodus, Energiesparpl an und PC Kamerastrom usw. haben.
Klicken Sie auf das Control Center-Symbol, um einen allgemein gültigen Energiemodus einzustellen. Kli cken Sie dann auf die einzelnen Symbole des Control Centers, um das Touchpad und das Kamera-Modul ein-/auszuschalten.
Deutsch
Power Conservation Mode
Flugzeugmodus AUS AN AUS AUS
Modi
Symbol
Energiesparplan Ausbalanciert Energiesparmodus Höchstleistung Ausbalanciert
(Stromsparmodus)
PC Kamera AN AUS AN AN
Touchpad AN AN AN AN
Quiet
(Lautlosmodus)
Balanced Energy Star Performance Balanced
Tabelle 3 - Energiemodi
Power Saving
(Stromsparmodus)
Performance
(Leistungsmodus)
Entertainment
(Unterhaltungsmodus)
30
Power Status (Energiestatus) /
Das Energiestatus-Symbol zeigt an, ob die Stromversor­gung aktuell über den Akku oder über das an das Stromnetz angeschlossene Netzteil erfolgt. Die Energiestatus-Anzeige zeigt den aktuellen Akkuladestatus an.
Brightness (Helligkeits)
Das Helligkeits-Symbol zeigt die aktuell eingestellte Bild­schirmhelligkeit an.Sie können die Bildschirmhelligkeit ent­weder mit dem Schieberegler oder mit der Tastenkombination Fn + F8/F9 ändern. Mit der Tastenkombination Fn + F2 wird das LED-Hintergrundlicht ausgeschaltet (drücken Sie auf eine beliebige Taste, um es wieder einzuschalten). Beachten Sie, dass die Bildschir­mhelligkeit auch vom eingestellten Energiemodus abhängt.
Volume (Lautstärke)
Das Lautstärke-Symbol zeigt die aktuelle Lautstärke an.Sie können die Lautstärke entweder mit dem Schieberegler oder mit der Tastenkombination Fn + F5/F6 einstellen. Mit der Tastenkombination Fn + F3 wird der Ton ausgeschaltet.
Power Conservation (Strom sparen)
Dieses System unterstützt die Energy Star-Stromsparfunk­tionen, die Computer (CPU, Festplatte usw.) nach einer längeren Zeit der Inaktivität in einen Ruhemodus versetzen, bei dem weniger Strom verbraucht wird. Klicken Sie entwe­der auf die Taste Performance, Balanced oder Energy Star.
Fan Speed (Lüftergeschwindigkeit)
Die Lüftergeschwindigkeit wird sich automatisch einstellen, um die Temperatur der CPU zu regeln. Sie können die Einstellung nach Bedarf auch auf die maximale Einstellung anpassen.
Sleep Button (Schaltfläche Schlaf)
Klicken Sie entweder auf die Schaltfläche Ruhezustand oder Schlaf, um den Computer der aus gewählten Stromspar­modus aufrufen zu lassen.
Display Switch (Anzeige wechseln)
Klicken Sie auf die Taste zum Wechseln des Anzeigegeräts, um das Menü aufzurufen (Sie können dazu auch die Tastenkombination + P verwenden), und wählen Sie einen Anzeigemodus aus.
Time Zone (Zeitzone)
Wenn Sie auf die Schaltfläche Zeitzone klicken, wird das Windows-Systemsteuerungsfenster Datum und Uhrzeit aufgerufen.
Desktop Background (Desktop-Hintergrund)
Wenn Sie auf die Schaltfläche Desktop-Hintergrund klikken, können Sie das Bild für den Desktophintergrund einstellen.
Touchpad/PC-Kamera-Modul
Klicken Sie auf eine dieser Tasten, um das Touchpad oder das Kamera-Modul ein- oder auszuschalten. Beachten Sie, dass der Energiestatus des Kamera-Moduls auch vom aus­gewählten Energiemodus abhängen.
Deutsch
31

Systemübersicht: Ansicht von vorne, links, rechts, hinten und unten

Keine Gehäuseteile entfernen oder öffnen
Entfernen Sie keine Gehäuseteile und/oder Schrauben, um das Gerät aufzurüsten, da ande­renfalls Ihre Garantieansprüche verloren gehen.
Ist es erforderlich, die Festplatte, den RAM, ein optisches Gerät usw. auszuwechseln oder zu entfernen, wenden Sie sich an Ihren Vertrags­händler/Lieferanten.
Abb. 5 - Ansicht von vorne, links, rechts, hinten und unten
1. LED-Anzeigen
2. Sicherheitsschloß-Buchse
3. Schnittstelle für externen Monitor
4. Luftungsoffnung
5. HDMI-Ausgangsanschluss
6. USB 3.0-Anschluss
7. Mikrofon-Eingangsbuchse
8. Kopfhörer-Ausgangsbuchse
9. USB 2.0-Anschlüsse
10. Multi-in-1 Kartenleser
11. RJ-45 LAN-Buchse
12. DC-Eingangsbuchse
13. Akku
14. Lautsprecher
Unterseite
1
2
4
6
3
5
10
11
7
13
9
12
8
9
Vorderseite
Linke Seite
Rechte Seite
Hinterseite
13
4
4
4
14
14
Deutsch
32

Windows 8.1 Systemsteuerung

Abb. 6
Kontextmenü
Verschieben Sie die Maus in die linke untere Ecke des Bild­schirms, und klikken Sie mit der rechten Maustaste auf die Start-Taste darauf, um das Menü aufzurufen.
Abb. 7 - Start-Bildschirm
In diesem Handbuch finden Sie eine Anleitung zum Öffnen der Systemsteuerung. Klicken Sie mit der rechten Maustaste auf die Start-Taste in der Desktop-App oder auf dem Start-Bildschirm (oder verwenden Sie die Tastenkombination Windows-Logo-Taste + X), um ein erweitertes Kontextmenü der nützlichen Funktionen aufzurufen: Systemsteuerung, Programme und Funktionen, Energieoptionen, Task-Manager, Suche, Datei-Explorer, Eingabeaufforderung, Geräte­Manager, Netzwerkverbindungen usw. Wählen Sie dann Systemsteuerung.

Windows 8.1 Start-Bildschirm und Desktop

Die Apps, Bedienfenster, Dienstprogramme und andere Software er­reichen Sie bei Windows über den Start-Bildschirm und/oder die Windows Desktop-App. Der Desktop (der im Start-Bildschirm eine App startet) wird geöffnet durch Anklicken des Desktop-Eintrags im
Start-Bildschirm (oder durch Drükken der Tastenkombination Windows-Logo-Taste + D). Die Taskleiste wird am unteren
Rand des Desktop-Bildschirms angezeigt. Der Infobereich befindet sich in der rechten unteren Ecke des Bildschirms. Klicken Sie auf den Pfeil unten auf dem Start-Bildschirm, um auf die Apps zuzugreifen.
33
Deutsch

Apps und Kacheln

Klicken Sie auf den Pfeil unten auf dem Start-Bildschirm, um auf die Apps zuzugreifen.
Der Start-Bildschirm enthält bereits eine Reihe von Apps, die mit jeder weiteren Installation erweitert wird. Wenn auf dem Bild­schirm nicht ausreichend Platz ist, um alle Apps anzuzeigen, kön­nen Sie den Schieberegler am unteren Rand des Bildschirms verwenden, um das Fenster entsprechend zu verschieben und die gewünschten Apps sehen zu können.

Charms-Leiste

An der rechten Seite des Bildschirms wird die Charms-Leiste angezeigt. Die Charms-Leiste enthält die Menüs Suchen, Teilen, Start, Geräte und Einstellungen. Um eines der Menüs aus der Charms-Leiste aufzurufen, bewegen Sie den Cursor
in die unteren rechten Ecken des Bildschirms und dann über den jeweiligen Eintrag in der Charms-Leiste, um diesen zu ak-
Deutsch
tivieren (ein aktivierter Eintrag wird schwarz dargestellt) oder drücken Sie auf die Tastenkombination Windows-Logo-Taste
+ C.
34
Abb. 8 - Start-Bildschirm mit Charms-Leiste

Grafikfunktionen

1
2
2
1
Abb. 9
Ein-
stellfenster
Anzeige
Bildschirmauflösung für Apps (Windows 8.1)
Die Mindestauflösung für Apps ist 1024x768. Damit alle Funktionen von Windows 8.1 unterstützt werden
(einschließlich Multitasking mit Snap), ist eine Mindestauflö­sung von 1366x768 erforderlich.
Dieses System verfügt über eine integrierte GPU von Intel. Wenn der Grafiktreiber installiert ist, können Sie bei Windows im Einstellfenster Anzeige die Anzeigegeräte wechseln und Anzeigeoptionen konfigurieren.
So öffnen Sie in Windows das Einstellfenster Anzeige:
1. Rufen Sie die Systemsteuerung auf.
2. Klicken Sie auf Anzeige (Symbol) - im Kategorie Darstellung und Anpassung.
3. Klicken Sie auf Bildschirmauflösung anpassen/Auflösung anpassen.
Oder
4. Klicken Sie mit der rechten Maustaste auf den Desktop (der
Desktop wird aufgerufen, indem Sie die Windows Logo-Taste
und gleichzeitig auf D drücken) und dann die Option
Bildschirmauflösung wählen.
5. Wählen Sie aus dem Drop-down-Menü die Bildschirmauflösung .
6. Klicken Sie auf Erweiterte Einstellungen .
So rufen Sie die Steuerung für Intel® HD-Grafik auf:
1. Klicken Sie auf das Symbol (Steuerung für Intel® HD-Grafik) auf dem Apps-Bildschirm.
Oder
2. Klicken Sie mit der rechten Maustaste auf den Desktop (der
Desktop wird aufgerufen, indem Sie die Windows Logo-Taste
und gleichzeitig auf D drücken) und dann aus dem Menü die
Option Grafikeigenschaften wählen.
Oder
3. Klicken Sie auf das Symbol im Infobereich auf der Desktop-
Taskleiste und dann aus dem Menü die Option
Grafikeigenschaften wählen.
Anzeigegeräte
Neben dem integrierten LCD-Monitor können Sie auch einen externen VGA-Monitor/Flachbildschirm oder ein Fernsehgerät (an die Schnittstelle für externen Monitor oder an den HDMI-Ausgangsanschluss angeschlossen) als An­zeigegerät anschließen.
Deutsch
35
Wechseln der Anzeigegeräte mit der
Abb. 10
+ P (Ändern der
Anzeigeeinstellungen)
Abb. 11 - Energieoptionen
Windows-Logo-Taste und der Taste P
Wenn Sie gleichzeitig auf die Tasten und P (oder Fn + F7) drücken, konnen Sie bei Windows schnell und einfach
die Anzeigeeinstellungen und -modi wechseln (was be­sonders praktisch ist, wenn Sie einen Projektor anschließen).
1. Schließen Sie das externe Anzeigegerät an die Schnittstelle für externen Monitor oder an den HDMI-Ausgangsanschlussan an, und schalten Sie es ein.
2. Drücken Sie die Tastenkombination + P (oder Fn + F7).
3. Auf dem Bildschirm erscheint ein Menü.
4. Wählen Sie mit den Cursor-Tasten (oder + P) eine geeignete
Deutsch
Konfiguration aus dem Menü aus, und bestätigen Sie die Auswahl durch Drücken der Eingabetaste.

Energieoptionen

Die Energieoptionen von Windows ermöglichen Ihnen die Konfiguration der Optionen für das Energiemanagement des Computers. Sie können Strom sparen, indem Sie Ener- giesparpläne erstellen und im linken Menü können Sie die Optionen für den Netzschalter, die Energiespartasten (Fn + F4) und Zuklappeinstellung (beim Schließen des Dekkels) und den Anzeige- und Energiesparmodus (die Standardeinstellung Energie sparen) konfigurieren. Beachten Sie, dass sich die Energiesparpläne (Ener- giesparmodus) auf die Computerleistung auswirken.
Wählen Sie einen bestehenden Plan aus, oder klicken Sie im linken Menü auf Energiesparplan erstellen, und wählen Sie die Optionen, um einen neuen Plan zu erstellen. Klicken Sie auf Energieplaneinstellungen ändern, und klicken Sie auf Erweiterte Energieeinstellungen ändern, um weitere Op­tionen für die Konfiguration aufzurufen.
36

Installation der Treiber

Allgemeine Hinweise zur
Treiberinstallation
Wenn Sie keine fortge­schrittenen Kenntnisse haben, folgen Sie für jeden Treiber den Anweisungen auf dem Bildschirm (z. B.
Weiter > Weiter > Fertig stellen). In vielen Fällen
ist es erforderlich, den Computer nach der Treiberinstallation neu zu starten.
Alle Module (z. B. WLAN oder Bluetooth) müssen vor der Treiberinstallation
eingeschaltet werden.
Windows Update
Nachdem Sie alle Treiber installiert haben, sollten Sie die Funktion Windows Update aktualisieren, um immer die neuesten Si­cherheits-Updates usw. zu erhalten (die Updates ent­halten die neuesten Fehlerbehebungen von Microsoft).
Treiberinstallation und Stromversorgung
Während die Treiber installiert werden, muss der Computer über den AC/DC-Adapter mit Strom ver­sorgt werden. Einige Treiber benötigen für den In­stallationsvorgang sehr viel Strom. Wenn der Akku nicht mehr über genügend Strom verfügt, kann sich das System während der Installation ausschalten, was zu Systemfehlern führen kann (das ist kein Si­cherheitsproblem, und der Akku ist innerhalb von einer Minute wieder aufladbar).
Abb. 12 - Installation der Treiber
Die Disc Device Drivers & Utilities + User's Manual enthält die Treiber und Hilfspro- gramme, die für das einwandfreie Funktionieren des Computers notwendig sind. Möglicher­weise wurden diese bereits vorinstalliert. Ist das nicht der Fall, legen Sie die Disc ein, und klicken Sie auf Install Drivers (Schaltfläche) oder Option Drivers (Schaltfläche), um das Treibermenü Optional aufzurufen. Reihenfolge. Markieren Sie die Treiber, die installiert werden soll en (notieren Si e zum späte­ren Nachlesen die Treiber, die Sie installiert haben). Hinweis: Muss ein Treiber neu installiert werden, sollten Sie den alten Treiber zunächst deinstallieren.
Manuelle Treiber-Installation
Klicken Sie in der Anwendung Drivers Installer auf die Schaltfläche Browse CD/DVD und navigieren Sie zu der ausführbaren Datei in dem Ordner für Ihren Treiber.
Wenn während des Installationsvorgangs das Fenster Neue Hardware gefunden erscheint, klicken Sie auf Abbrechen, um das Fenster zu schließen. Befolgen Sie dann die Installa­tionsanweisungen.
Installieren Sie die Treiber in der in Abb. 12 angegebenen
Deutsch
37

Fehlerbehebung

Problem Mögliche Ursache - Lösung
Die Module Wireless-LAN/ Bluetooth können nicht erkannt
werden.
Das PC-Kamera-Modul kann nicht erkannt werden.
Deutsch
Im Flugzeugmodus sind die Module ausgeschaltet. Prüfen Sie der LED-Anzeige , ob der Computer im Flugzeugmodus ist (siehe Tabelle 1 auf Seite 26). Mit der Tastenkombination Fn + F11 können Sie den Flugzeugmodus ein- oder ausschalten (siehe Tabelle 2 auf Seite
28).
Das ist ausgeschaltet. Mit der Tastenkombination Fn + F10 können Sie das PC-Kamera­Modul einschalten (siehe Tabelle 2 auf Seite 28). Starten Sie die Kamera-Anwendung, um das Kamerabild zu sehen.
38

Technische Daten

Aktualität der technischen Daten
Die in diesem Teil aufgeführten techni­schen Daten sind zum Zeitpunkt der Druckstellung richtig. Bestimmte Elemente (insbesondere Prozessorty­pen/-geschwindigkeiten) können im Rahmen des Entwicklungsplans des Herstellers zwischenzeitlich geändert oder aktualisiert werden. Detailinforma­tionen erhalten Sie bei Ihrem Service­zentrum.
Prozessor-Optionen
Intel® Celeron™ Prozessor N2830 (2,17GHz)
1MB L2 Cache, 22nm, DDR3L-1333MHz, TDP 7,5W
N2807 (1,58GHz)
1MB L2 Cache, 22nm, DDR3L-1333MHz, TDP 4,3W
BIOS
AMI BIOS (64Mb SPI Flash-ROM)
Speicher
Ein 204-Pin SODIMM-Sockel, Unterstützung von DDR3L 1600MHz Speicher
Speicher auf bis zu 2GB erweiterbar (Die tatsächliche Speicherarbeitsfrequenz
hängt vom FSB des Prozessors ab.)
LCD
11,6" (29,46cm) HD (Dicke: 3,6mm)
Videoadapter
Intel HD Graphics
Dynamische Frequenz (Intel Dynamic Video Memory Technology für bis zu 1,7GB)
Kompatibel mit MS DirectX® 11
Speicher
Eine austauschbare SATA-2,5"-Festplatte (7,0 mm Höhe)
(Werkseitige Option) Ein 16GB mSATA- SSD-Laufwerk
Audio
High-Definition-Audio-kompatible Schnittstelle
2 eingebaute Lautsprecher Eingebautes Mikrofon
Sicherheit
Öffnung für Sicherheitsschloß (Typ Kensington)
BIOS-Paßwort
Tastatur
"Win Key"-Tastatur (mit integrierter Nummerntastatur)
Zeigegerät
Eingebautes Touchpad
Schnittstellen
Zwei USB 2.0-Anschlüsse Ein USB 3.0-Anschluss Ein HDMI-Ausgangsanschluss Eine Schnittstelle für externen Monitor Eine Lautsprecher/Kopfhörer-
Ausgangsbuchse Eine Mikrofon-Eingangsbuchse Eine RJ-45 LAN-Buchse Eine DC-Eingangsbuchse
Mini-Card-Steckplätze
Steckplatz 1 für Wireless-LAN-Modul oder Kombinierte Bluetooth und WLAN-Modul
(Werkseitige Option) Steckplatz 2 für mSATA-SSD-Laufwerk
Kartenleser
Festes Multi-in-1 Kartenleser-Modul
MMC (MultiMedia Card) / RS MMC SD (Secure Digital) / Mini SD / SDHC/
SDXC MS (Memory Stick) / MS Pro / MS Duo
39
Deutsch
Kommunikation
10Mb/100Mb Ethernet LAN (Werkseitige Option)
Modul/300K Pixel PC-Kamera-Modul
WLAN/ Bluetooth Half Mini-Card Module:
(Werkseitige Option) Wireless LAN (802.11b/g/n) (andere Hersteller)
(Werkseitige Option) Wireless LAN (802.11b/g/n) und Bluetooth 4.0 (andere Hersteller)
Umgebungsbedingungen
Temperatur
Deutsch
In Betrieb: 5ºC – 35ºC Bei Aufbewahrung: -20ºC – 60ºC
Relative Luftfeuchtigkeit
In Betrieb: 20 – 80 % Bei Aufbewahrung: 10 – 90
Stromversorgung
AC/DC-Adapter für den gesamten Spannungsbereich
AC-Eingang: 100-240 V, 50-60Hz DC-Ausgang: 19V, 1,58A (30W)
3-Zellen Smart Lithium-Ion Akku
(Werkseitige Option)
Lithium-Ion Akku
Abmessungen und Gewicht
292,4 (B) x 210,5 (T) x 22,7 (H) mm (Höhe ohne Akkubereich)
1,3kg (Barebone mit
1,0M HD PC-Kamera-
, 24WH
3-Zellen Smart
, 31WH
24WH-Akku)
40
41
Deutsch
Deutsch
42

A propos de ce Guide Utilisateur Concis

Ce guide rapide est une brève introduction à la mise en route de votre système. Il s’agit d’un supplément, et non pas d’une alternative au Manuel de l’Utilisateur en Anglais complet au format Adobe Acrobat s ur le disque Device Drivers & Utilities + User's Manual fourni avec votre ordinateur . Ce disque contient aussi les pilo tes et utilitaires nécessaires au fonctionnement correct de votre ordinateur (Remarque: La compagni e se réserve le droit de revoir cette publication ou de modifier son conte­nu sans préavis).
Certains ou tous les éléments de l’ordinateur peuvent avoir été déjà installés. Si ce n’est pas le cas , ou si vous avez l’intention de reconfigurer (ou réinstaller) des portions du système, reportez-vous au Manuel de l’Utilisateur complet. Le disq ue Device Drivers & Utilities + User’s Manual ne contient pas de système d’exploitation.
Informations de réglementation et de sécurité
Prêtez attention aux avis réglementaires et informations de sécurité contenus dans le Manuel de l'Utilisateur se trouvant sur le disque Device Drivers & Utilities + User’s Manual.
© Mai 2014
Marques déposées
Intel et Celeron sont des marques déposées ou enregistrées d’Intel Corporation.
Français
43
Instructions d’entretien et d’utilisation
L’ordinateur est robuste, mais il peut toutefois être endomma­gé. Afin d’éviter ceci, veuillez suivre ces recommandations :
Ne le laissez pastomber. Ne l’exposez à aucun choc ou vibration.
Si l’ordinateur tombe, le boîtier et d’autres éléments pourraient être endommagés.
Gardez-le sec. Ne le laisser pas surchauffer. Tenez l’ordinateur et
son alimentation externe à distance de toute source de chaleur. Il s’agit d’un appareil électrique. Si de l’eau ou tout autre liquide venait à pénétrer à l’intérieur de votre ordinateur, il pourrait être sérieuse­ment endommagé.
Evitez les interférences. Tenez l’ordinateur à distance de transfor-
mateurs à haute capacité, moteurs électriques, et autres appareils générateurs de champs magnétiques importants. Ceux-ci peuvent gêner ses performances normales et endommager vos données.
Suivez les procédures appropriées d’utilisation de votre ordina-
teur. Arrêtez l’ordinateur correctement, et fermez tous vos pro­grammes (n’oubliez pas d’enregistrer votre travail). N’oubliez pas d’enregistrer vos données régulièrement puisqu’elles peuvent être
Français
perdues si la batterie est vide.
Révision
Si vous essayez de réparer l'ordinateur par vous-même, votre garantie sera annulée et vous risquez de vous exposer et d'ex­poser l'ordinateur à des chocs électriques. Confiez toute répa­ration à un technicien qualifié, particulièrement dans les cas suivants:
• Si le cordon d’alimentation ou l’adaptateur AC/DC est endommagé,
abimé ou effiloché.
• Si votre ordinateur a été exposé à la pluie ou tout autre liquide.
• Si votre ordinateur ne fonctionne pas normalement bien que vous
ayez suivi les instructions de mise en marche à la lettre.
• Si votre ordinateur est tombé par terre ou a été endommagé (si l'écran
LCD est cassé, ne touchez pas le liquide car il contient du poison).
• Si une odeur inhabituel, de la chale ur ou de la fumé e app arais sai t sor­tant de votre ordinateur.
Informations de sécurité
• Utilisez uniquement un adaptateur AC/DC agréé avec votre ordina­teur.
• Utilisez uniquement le cordon d’alimentation et les batteries indiqués dans ce manuel. Ne jetez pas les batteries dans le feu. Elles peuvent exploser. Consultez la réglementation locale pour des instructions de recyclage possibles.
• Ne continuez pas d'utiliser une batterie qui est tombée, ou qui paraît endommagée (ex: tordue ou vrillée) d'une manière quelconque. Même si l'ordinateur continue de fonctionner avec la batterie en place, cela peut détériorer le circuit, pouvant déclencher un incendie.
• Assurez-vous que votre ordinateur est complètement éteint avant de le mettre dans un sac de voyage (ou tout autre bagage similaire).
• Avant de nettoyer l'ordinateur, retirez la batterie et assurez-vous que l'ordinateur est débranché de toute alimentation électr iq ue externe, périphériques et câbles (y compris les lignes téléphoniques).
• Utilisez un chiffon propre et doux pour nettoyer l'ordinateur, mais n'appliquez pas d'agent de nettoyage directement sur l'ordinateur. N’utilisez pas de produit de nettoyage volatil (des distillés pétrôle) ou abrasifs sur aucun des éléments de l’ordinateur.
• N’essayez jamais de réparer la batterie. Au cas où votre batterie aurait besoin d’être réparée ou changée, veuillez vous adresser à votre représentant de service ou à des professionnels qualifiés.
• Notez que dans les ordinateurs ayant un logo fixé par dépôt électroly­tique, le logo est recouvert par une protection adhésive. À cause de l’usure générale, cette protection adhésive se détériore avec le temps et le logo exposé peut former des angles coupants. Faites bien atten­tion lorsque vous manipulez l'ordinateur, et évitez de toucher le logo fixé par dépôt électrolytique. Dans la sacoche de voyage, ne mettez pas d’autres objets qui risquent de se frotter contre l’ordinateur pen­dant le transport. En cas d’une telle usure, contactez votre centre de services.
44
Précautions concernant les batteries polymères
Elimination de la batterie & avertissement
Le produit que vous venez d’acheter contient une batterie re­chargeable. Cette batterie est recyclable. Quand elle n’est plus utilisable, en fonction des lois locales des différents états et pays, il peut être illégal de s’en débarrasser en la jetant avec les ordures ménagères normales. Vérifiez auprès du responsable local de l’élimination des déchets solides de votre quartier pour vous informer des possibilités de recyclage ou de la manière ap­propriée de la détruire.
Il existe un danger d’explosion si la batterie est remise de façon incorrecte. Remplacez-la uniquement par des batteries de même type ou de type équivalent, recommandées par le fabri­cant. Eliminez les batteries usagées selon les instructions du fa­bricant.
Notez les informations suivantes spécifiques aux batteries po­lymères, et le cas échéant, celles-ci remplacent les informa­tions générales de précaution sur les batteries.
• Les batteries polymères peuvent présenter une légère dilatation ou gonflement, mais cela est inhérent au mécanisme de sécurité de la batterie et ne représente pas une anomalie.
• Manipulez les batteries polymères de façon appropriée lors de leur utilisation. Ne pas utiliser de batteries polymères dans des environne­ments présentant une température ambiante élevée, et ne pas stocker les batteries non utilisées pendant de longues périodes.
Français
45

Guide de démarrage rapide

130
Arrêt
Veuillez noter que vous devriez toujours éteindre votre ordinateur en utilisant la commande Arrêter dans Windows (voir ci-dessous). Cette précaution évite des problèmes de disque dur ou de système.
Cliquez sur l’icône
sur l'écran d'accueil et
sélectionnez Arrêter dans el menu.
Ou
Cliquez-droit sur le bouton Démarrer en bas de l'écran d'accueil ou du bureau
et sélectionnez Arrêter ou se déconnec-
ter > Arrêter dans el menu contextuel.
1. Enlevez tous les memballages.
2. Posez l’ordinateur sur une surface stable.
3.
Installez la batterie et assurez-vous qu’elle correctement posi-
tionnée.
4. Connectez fermement les périphériques que vous souhaitez
utiliser avec votre ordinateur (par ex. clavier et souris) à leurs ports respectifs.
5. Branchez l'adaptateur AC/DC à la prise d'entrée DC sur la droit
de l’ordinateur, branchez ensuite le cordon secteur à une prise murale, puis à l’adaptateur AC/DC.
6. D'une main, soulevez soigneusement le couvercle/LCD pour
obtenir un angle de vision confortable (ne pas dépasser 130 degrés), de l'autre main (comme illustré dans la Figure 1) maintenez la base de l'ordinateur (Remarque : Ne soulevez jamais l'ordinateur par le couvercle/LCD).
7. Pressez le bouton de mise en marche pour allumer.
Logiciel système
Français
Votre ordinateur peut être livré avec un logiciel système pré­installé. Si ce n’est pas le cas, ou si vous re-configurez votre ordinateur pour un système différent, vous constaterez que ce manuel fait référence à Microsoft Windows 8.1 (32-bit).
Figure 1 - Ouvrir le couvercle/LCD/ordinateur avec un
adaptateur AC/DC branché
46

Carte du système: Vue de face avec l’écran LCD ouvert

5
7
6
2
1
3
4
7
Figure 2
Vue de face avec l’écran
LCD ouvert
1. Caméra PC (optionnelle)
2. *Indicateur LED de caméra PC
*Quand la caméra PC est en cours d'utilisation le Indicateur LED sera illuminé en rouge.
3. Microphone
4. Écran LCD
5. Bouton d'alimentation
6. Clavier
7. Pavé tactile (Touchpad) et boutons
Remarquez que la zone d’utilisa­tion valide du Touchpad et des boutons est celle indiquée à l’in­térieur des lignes en pointillé rouges ci-dessus.
Utilisation des
appareils sans fil à
bord d'un avion
L'utilisation de tout appareil électronique de transmission est généralement inter­dite à bord d'un avion.
Vérifiez que les mo­dules WLAN et Blue­tooth sont désactivés si vous utilisez l'ordi­nateur à bord d'un avion en mettant le système en Mode Avion.
7
Français
47

Indicateurs LED

Les indicateurs LED sur votre ordinateur affichent des informations utiles sur l’état actuel de votre ordinateur.
Icône Couleur Description
Orange L'adaptateur AC/DC est branché
Vert L’ordinateur est allumé
Vert clignotant Le système est dans le mode de Veille configuré
Orange La batterie est en charge
Vert La batterie est complètement chargée
Français
48
Orange clignotant La batterie a atteint le niveau bas critique
Vert Mode Avion activé (les modules WLAN et Bluetooth sont désactivés)
Vert Le disque dur est en cours d'utilisation
Tableau 1 - Indicateurs LED

Clavier

Numeric
Keypad
Numeric
Keypad
Touche Logo de Windows
Touche Menu/Application
Touches Fonction
Touche Fn
Pavé numérique
Verr Num & ArrêtDét
Raccourci clavier du logo
de Windows
Utilisez la combinaison des touches Touche Logo de Windows + D pour pas- ser de l'écran d'accueil au bu­reau de Windows.
Raccourci clavier de Menu/
Application
Lorsque l'application Bureau est activée, vous pouvez utili­ser la touche Menu/Applica- tion du clavier pour effectuer un clic droit de sou­ris. Dans l'écran d'accueil cette fonction est utile pour af­ficher rapidement la barre Personnaliser.
Figure 3 - Clavier
Le clavier est doté d'un pavé numérique intégr é po ur une saisie des données nu mériques plus faci le. Le fai t d'appu yer sur Fn + Verr Num active ou désactive le pavé numérique. Il est également doté de touches fonction pour vous permettre de changer instantanément de mode opérationnel.
Français
49

Touches fonction

Les touches de fonctions (F1 - F11 etc.) agiront comme touches de raccourci (hot-key) quand pressée en maintenant la touche Fn appuyée. En plus des combinaisons des touches de fonction de base, des indicateurs visuels sont disponibles (dans l'ap- plication Bureau de Windows uniquement et pas dans l'écran d'accueil) quand le pilote de touches de raccourci (HotKey
Driver) est installé.
Touches Fonction/ indicateurs visuels Touches Fonction/ indicateurs visuels
Fn +
Fn +
Fn +
Fn + Allume/Éteind le son
Fn + Permutation veille
Français
Fn +
Fn +
Fn +
Lecture/Pause (dans les programmes audio/vidéo)
Activer/Désactiver le
Touchpad
Eteindre le rétroéclairage LCD (Appuyez sur une
touche ou utilisez le Touchpad pour allumer)
Diminution/Augmentation du
volume sonore
Modifiez la configuration de l'affichage (voir la
Diminution/Augmentation de la luminosité de l’écran LCD
50
Activer/Désactiver le
module caméra PC
Activer/Désactiver le Mode
Activer/Désactiver le pavé
numérique
Activer/Désactiver l'arrêt
défilement
Basculer entre majuscule
et minuscule
Activer/Désactiver le Contro l Ce nt e r (C en tr e d e
Contrôle Automatique du
Ventilateur /Pleine Puis-
page 58)
Fn +
Fn +
Fn +
Fn +
Fn +
Fn +
Tableau 2 - Touches de fonctions & indicateurs visuels
Avion
contrôle) (voir la page 51)
sance

Control Center (Centre de contrôle)

Le Control Center (Centre de contrôle) dans Windows 8.1 fonctionne dans l'ap plication Bureau et non dans l'écran d'accueil. Appuyez sur la combinaison de touches Fn + Échap ou double-cliquez sur l'icône dans la zone de notification de la barre des tâches pour activer/désactiver le Control Center. Le Control Center donne un accès rapide aux commandes fré- quemment utilisées, et vous permet de rapidement d'activer/désactiver le touchpad/le module caméra PC.
Figure 4 - Control Center
Français
Cliquez sur les icônes du Control Center pour activer la fonction correspondante, ou maintenez le bouton de la souris en­foncé et déplacez le curseur à l'endroit approprié. Certaines fonctions sont automatiquement ajustées lorsque le mode d'ali­mentation est sélectionné.
51
Modes d’alimentation
Vous pouvez définir un Mode d’al imentation en cliquant sur l'icône appropriée au dessus du Contr ol Cente r. Chaque mode d'alimentation aura une incidence sur le mode Economie d'énergie, le mode Avion, la gestion de l'alimentation et l'alimenta­tion de la caméra PC de l'ordinateur, etc.
Vous pouvez cliquer sur l’i cône du Control Center pour définir un mode d'alimentation générale, puis cliquer sur l es icônes individuelles dans le Control Center pour activer/désactiver le touchpad et le module caméra PC
.
Français
Power Conservation Mode
(Mode Economie d'énergie)
52
Modes
Icône
Mode de gestion de l'ali-
mentation
Caméra PC Activé Désactivé Activé Activé
Touchpad Activé Activé Activé Activé
Mode Avion Désactivé Activé Désactivé Désactivé
Quiet
(Silencieux)
Balanced
Tableau 3 - Modes d’alimentation
Power Saving
(Economie
d’énergie)
Economie d'énergie Performances élevées
Energy Star Performance
Performance
(Performances)
Entertainment
(Divertissement)
Balanced
Power Status (État d'alimentation) /
Fan Speed (Vitesse du ventilateur)
L'icône État d'alimentation indique si vous êtes actuelle­ment alimenté par la batterie, ou par l'adaptateur AC/DC branché à une prise de courant. La barre d’état d’alimenta­tion indiquera l'état de charge actuel de la batterie.
Brightness (Luminosité)
L'icône Luminosité indiquera le niveau de luminosité actuel de l'écran. Vous pouvez utiliser le curseur pour ajuster la lu­minosité de l'écran ou les combinaisons de touches Fn + F8/ F9, ou utiliser la combinaison de touches Fn + F2 pour éteindre le rétroéclairage LED (appuyez sur une touche pour le rallumer). Notez que la luminosité de l'écran est également affectée par le Mode d'alimentation choisi.
Volume
L'icône Volume indiquera le niveau du volume actuel. Vous pouvez utiliser le curseur pour régler le volume ou les com­binaisons de touches Fn + F5/F6, ou utiliser les combinai­sons de touches Fn + F3 pour couper le volume.
Power Conservation (Économie d'énergie)
Ce système prend en charge les fonctionnalités de gestion d’alimentation Energy S tar qui placent les ordinateurs (CPU, disque dur, etc.) dans des modes veille à faible consommation d'énergie après une période d'inactivité donnée. Cliquez sur le bouton Performance (Performances), Balanced (Equilibré) ou Energy Star.
La vitesse du ventilateur s'ajuste automatiquement pour contrôler la chaleur du CPU. Cependant, vous pouvez ajuster le réglage au maximum si vous préférez.
Sleep Button (Bouton Veille)
Cliquez sur le bouton Veille Prolongée ou Veille pour que l'ordinateur entre dans le mode d'économie d'énergie sélec­tionné.
Display Switch (Permutation d’affichage)
Cliquez sur le bouton Permutation d’affichage pour accé­der au menu (ou utilisez la combinaison de touches Fn + F7) et sélectionnez le mode d'affichage joint approprié.
Time Zone (Fuseau horaire)
Cliquer sur le bouton Fuseau horaire permet d’accéder au panneau de configuration de Date et heure de Windows.
Desktop Background (Fond d'écran du bureau)
Cliquer sur le bouton Fond d'écran du bureau vous permet­tra de changer l'image du fond d'écran du bureau.
Touchpad/caméra PC
Cliquez sur l’un de ces boutons pour permuter l’état d’ali­mentation du Touchpad ou du module caméra. Notez que l'état de l'alimentation du module caméra est également af­fecté par le mode d'alimentation choisi.
Français
53

Carte du système: Vues de face, gauche, droite, arrière et dessous

Avertissement de retrait du capot inférieur
Ne pas retirer le(s) capot(s) et/ou la (les) vis dans le but de mettre à niveau l'appareil car cela pourrait enfreindre les termes de votre garantie.
Si vous avez besoin de remplacer/supprimer le disque dur/RAM/le dispositif optique etc., pour une raison quelconque, contactez votre distri­buteur/fournisseur pour plus d'informations.
Dessous
Figure 5 - Vues de face, gauche, droite, arrière et dessous
1. Indicateurs LED
2. Fente de verrouillage de sécurité
3. Port moniteur externe
4. Ventilation
5. Prise de sortie HDMI
6. Port USB 3.0
7. Prise d'entrée de microphone
8. Prise de sortie haut-parleurs/ casque
9. Ports USB 2.0
10. Lecteur de carte multi-en-1
11. Prise réseau RJ-45
12. Prise d’entrée DC
13. Batterie
14. Haut-parleurs
1
2
4
6
3
5
10
11
7
13
9
12
8
9
13
4
4
4
14
14
Face
Gauche
Droit
Arrière
Français
54

Panneau de Configuration de Windows 8.1

Figure 6
Menu
contextuel
Déplacez la souris vers le coin inférieur gauche de l'écran et faites un clic droit sur le bouton Dé­marrer pour accéder au menu.
Figure 7 - Écran d'accueil
Tout au long de ce manuel, vous verrez une instruction pour ouvrir le Panneau de Configuration. Faites un clic droit sur le bouton Démarrer dans l'appli Bureau ou sur l'écran d'accueil (ou utilisez la combinaison de touches Touche Logo de Windows + X) pour faire apparaître un menu contextuel avancé de fonct ionnal ités util es telles que Panneau de configu- ration, Programmes et fonctionnalités, Options d'alimentation, Gestionnaire de tâches, Rechercher, Explorateur de fichiers, Invite de commandes, Gestionnaire de périphériques et Connexions réseau, et plus encore et sélectionnez Panneau de Confi- guration.

Écran d'accueil & bureau de Windows 8.1

Les applications, les panneaux de contrôle, les utilitaires et les programmes dans Windows sont accessibles depuis l'écran d'accueil et/ou l'application Bureau de Windows. Le Bureau (qui fonctionne comme une application dans l'écran d'accueil) est accessible en cliquant sur l'élément Bureau dans l'écran d'accueil (ou en utilisant la combinaison de touches Touche Logo de Windows + D). La barre des tâches est affichée au bas de l'écran du bu- reau, et vous pouvez voir la zone de notification de la barre des tâches en bas à droite de l'écran. Cliquez sur la flèche en bas de l'écran d'accueil pour ac­céder à Applications.
Français
55

Applications et Vignettes

Cliquez sur la flèche en bas de l'écran d'accueil pour accéder à Applications.
L'écran d'accueil contiendra un certain nombre d'applications, et bien d'autres seront installées lorsque vous ajouterez des applications, etc. T outes ces applications peuvent tenir sur un seul écran ainsi vous aurez souvent besoin d'utiliser le curseur au bas de l'écran afin d'afficher toutes les applications nécessaires.

Barre des charmes

Le côté droit de l'écran affiche la Barre des charmes. La Barre des charmes contient les menus Rechercher, Partager, Ac­cueil, Périphériques et Paramètres. Pour accéder à la Barre des charmes déplacez le curseur vers les coins supérieurs ou
inférieurs à droite de l'écran, puis passez la souris sur l'un des éléments de la Barre des charmes pour l'activer (la barre est noire quand elle est active), ou utilisez la combinaison de touches Touche Logo de Windows + C.
Français
Figure 8 - Ecran d'accueil avec la Barre des charmes
56

Caractéristiques vidéo

1
2
2
1
Résolution de l'écran des applications (Windows 8.1)
La résolution minimale dans laquelle les applications s'exé­cuteront est 1024x768.
La résolution minimale requise pour prendre en charge toutes les fonctionnalités de Windows 8.1 (y compris le mul­titâche avec ancrage) est 1366x768.
Le système comporte un GPU intégré Intel. Vous pouvez permuter les dispositifs d'affichage et configurer les options d'affichage depuis le panneau de contrôle Affichage dans Windows, à partir du moment où le pilote vidéo est installé.
Pour accéder au panneau de contrôle Affichage:
1. Allez au Panneau de Configuration.
2. Cliquez sur Affichage dan Apparence et personnalisation (catégorie).
3. Cliquez sur Modifier la résolution de l’écran/Ajuster la réso- lution.
OU
4. Cliquez-droit sur le bureau (utilisez la combinaison de touches
Touche Logo de Windows + touche D pour accéder au bureau) et sélectionner la Résolution d’écran.
5. Utilisez le menu déroulant pour sélectionner la résolution d’écran
.
6. Cliquez sur Paramètres avancés .
Pour accéder au Panneau de configuration des graphiques HD Intel®:
1. Cliquez sur l’icône (Panneau de configuration des graphiques HD Intel®) dans l'écran Applications.
OU
2. Cliquez-droit sur le bureau (utilisez la combinaison de touches Touche Logo de Windows + touche D pour accéder au bureau) et sélectionnez Propriétés graphiques dans le menu.
OU
3. Cliquez sur l'icône dans la zone de notification de la barre des
tâches du bureau et sélectionnez Propriétés graphiques dans le menu.
Français
Périphériques d’affichage
En plus du LCD intégré, vous pouvez aussi utiliser un moni­teur VGA externe/écran plat ou TV (connecté au port moni­teur externe ou à la prise de sortie HDMI) comme périphérique d'affichage.
Figure 9 - Panneau de contrôle Affichage
57
Utilisez la combinaison de touches du
Figure 10
+ P (Modifiez la
configuration de l'af-
fichage)
Figure 11 - Options d’alimentation
logo de Windows
+ P pour changer
d'affichage
Vous pouvez utiliser la combinaison de touches + P (ou Fn + F7) pour changer rapidement de configuration d'affi-
chage et de mode (ce qui est particulièrement utile lors de la connexion d'un projecteur) sous Windows.
1. Connectez votre écran externe au port moniteur externe ou à la prise de sortie HDMI, et allumez-le.
2. Appuyez sur la combinaison de touches + P (ou Fn + F7).
3. Un menu d'écran apparaîtra.
4. Utilisez les touches du curseur (ou + P) pour sélectionner la configuration appropriée dans le menu, et appuyez sur Entrée pour confirmer la sélection.
Français

Options d’alimentation

Le panneau de configuration Options d'alimentation de Windows vous permet de configurer la gestion d'alimenta­tion de votre ordinateur. Vous pouvez économiser de l'éner­gie à l'aide de modes de gestion de l'alimentation et configurer les options pour le bouton d'alimentation, bou-
ton de veille (Fn + F4), couvercle de l'ordinateur (lors­qu'il est fermé), mode Affichage et Veille (l'état d'économie
d'énergie par défaut) dans le menu de gauche. Remarquez que le mode de gestion d'économie d'énergie peut avoir un impact sur les performances de l'ordinateur.
Cliquez pour sélectionner l'un des modes existants, ou cli­quez sur Créer un mode de gestion d'alimentation dans le menu gauche et sélectionnez les options pour créer un nou­veau mode. Cliquez sur Modifier les paramètres du mode et cliquez sur Modifier les paramètres d'alimentation avancés pour accéder à plus d'options de configuration.
58

Installation du pilote

Directives générales pour
l'installation du pilote
D'une manière générale, suivez les instructions par défaut à l'écran pour chaque pilote (par exemple Suivant > Suivant > Terminer) à moins que vous ne soyez un utilisateur avancé. Dans la plupart des cas, un redé­marrage est nécessaire pour installer le pilote.
Assurez-vous que les mo­dules (par exemple WLAN ou Bluetooth) sont allumés avant d'installer le pilote cor­respondant.
Windows Update
Après avoir installé tous les pilotes vérifiez que vous avez activé Windows Update afin d'obtenir toutes les dernières mises à jour de sécurité etc. (toutes les mises à jour incluront les derniers correctifs de Mi­crosoft).
Installation des pilotes et alimentation
Lors de l'installation des pilotes assurez-vous que votre ordinateur est alimenté par l'adapta­teur CA/CC connecté à une source d'alimenta­tion. Certains pilotes consomment une quantité importante d'énergie pendant la procédure d'installation, et si la capacité restante de la bat­terie n'est pas suffisante cela peut provoquer l'arrêt du système et entraîner des problèmes de système (à noter qu'il n'y a pas ici de pro­blème de sécurité en cause, et la batterie sera rechargeable en 1 minute).
Figure 12 - Installation du pilote
Le disque Device Drivers & Utilities + User’s Manual contient les pilotes et les utilitaires nécessaires pour un bon fonctionnement de votre ordinateur. Cette installation aura proba­blement déjà été faite pour vous. Si ce n'est pas le cas, insérez le disque et cliquez sur Install
Drivers (bouton), ou Option Drivers (bouton) pour accéder au menu des pilotes Option- nels. Installez les pilotes en respectant l'ordre indiqué dans la Figure 12. Cliquez pour sé-
lectionner les pilotes que vous désirez installer (vous devez noter les pilotes lorsque vous les installez). Remarque: Si vous devez réinstaller un pilote, vous devez d’abord le désins­taller.
Installation manuelle du pilote
Cliquez le bouton Browse CD/DVD dans l'application Drivers Installer et naviguer jus- qu'au fichier exécutable dans le dossier de pilote approprié.
Si l’assistant Nouveau matériel détecté apparaît pendant la procédure d'installation, cliquez sur Annuler pour fermer l’assistant, et suivez la procédure d'installation comme indiqué.
Français
59

Dépannage

Problème Cause possible - résolution
Les modules LAN sans fil/ Bluetooth ne peuvent pas être
détectés.
Le module caméra PC ne peut pas être détecté.
Français
Les modules sont désactivés quand l'ordinateur est en Mode Avion. Vérifiez l'indicateur LED
pour voir si l'ordinateur est en Mode Avion (voir le Tableau 1 à la page 48). Utilisez la
combinaison de touches Fn + F11 pour activer ou désactiver le Mode Avion (voir le Tableau 2
à la page 50).
Le module est désactivé. Utilisez la combinaison de touche s Fn + F10 pour activer le module (voir le Tableau 2 à la page 50). Exécutez l’application Caméra pour voir l'image de l'appareil photo.
60

Spécifications

Dernières informations de
spécification
Les spécifications énumérées dans cette section sont correctes à l'heure de la mise sous presse. Certains éléments (particulièrement les types de proces­seur/vitesse unique) peuvent être modi­fiés ou mis à niveau en fonction du calendrier des parutions du fabricant. Voyez auprès de votre service clientèle pour les détails.
Options de processeurs
Processeur Intel® Celeron N2830 (2,17GHz)
Cache L2 1Mo, 22nm, DDR3L-1333MHz, TDP 4,3W
N2807 (1,58GHz)
Cache L2 1Mo, 22nm, DDR3L-1333MHz, TDP 4,3W
BIOS
AMI BIOS (SPI Flash ROM de 64Mb)
Mémoire
Un emplacement SODIMM 204 broches,
supportant la mémoire DDR3L 1600MHz Mémoire extensible jusqu’à 2Go
(La fréquence réelle d’opération de la mémoire dépend du FSB du processeur.)
LCD
11,6" (29,46) HD (é paisseur: 3,6mm)
Adaptateur Vidéo
Intel® HD Graphics
Fréquence dynamique (Technologie de mémoire vidéo dynamique d'Intel jusqu’à 1,7Go)
Compatible avec MS DirectX® 11
Stockage
Un disque dur SATA échangeable de 2,5" 7,0mm (H)
(Option d’usine) Un lecteur SSD 16Go mSATA
Son
Interface conforme HDA (Son Haute Définition)
2 haut-parleurs intégrés Microphone intégré
Sécurité
Fente de verrouillage de sécurité (type Kensington)
Mot de Passe du BIOS
Clavier
Clavier “Win Key” (avec pavé numérique intégré)
Dispositif de pointage
Touchpad intégré
Interface
Deux ports USB 2.0
Un port USB 3.0 Un port de Sortie HDMI
Un port moniteur externe Une prise de sortie haut-parleurs/casque Une prise d'entrée de microphone Une prise réseau RJ-45 Une prise d’entrée en DC
Logements Mini-carte
Logement 1 pour module LAN sans fil ou module combo Bluetooth et LAN sans fil
(Option d’usine) Logement 2 pour lecteur
SSD mSATA
Lecteur de carte
Lecteur de carte multi-en-1
MMC (MultiMedia Card) /RS MMC
SD (Secure Digital) /Mini SD /SDHC / SDXC
MS (Memory Stick) /MS Pro /MS Duo
61
Français
Communication
LAN 10Mb/100Mb Ethernet
(Option d’usine) 1,0M HD caméra PC/ 300K pixel caméra PC
Modules Half Mini-carte LAN sans fil/ Bluetooth:
(Option d’usine) LAN sans fil (802.11b/g/ n) (tiers)
(Option d’usine) Bluetooth 4.0 et LAN sans fil (802.11b/g/n) (tiers)
Spécifications environnementales
Température
En fonction : 5°C- 35°C
Eteint : -20
Humidité relative
En fonction : 20% - 80% Eteint : 10% - 90%
Français
Mise en marche
Adaptateur AC/DC pleine bande Entrée AC: 100-240V, 50-60Hz Sortie DC: 19V, 1,58A (30W)
Batterie Lithium-Ion intelligente à 3 cellules
24WH (Option d’usine)
intelligente à 3 cellules
Dimensions physiques & poids
292,4 (l) x 210,5 (p) x 22,7 (h) mm 1,3kg (Barebone avec batterie 24WH)
°C - 60°C
,
Batterie Lithium-Ion
, 31WH
62
63
Français
Français
64

Acerca de esta Guía del Usuario Concisa

Esta guía rápida es una breve introducción para poner su sistema en funcionamiento. Es un suplemento y no un sustituto del Manual del usuario completo en inglés en formato Adobe Acrobat del disco Device Drivers & Utilities + User's Manual suministrado con el ordenador. En este disco también se encuentran los controladores y utilitarios necesarios para utilizar el ordenador correctamente (Nota: previo aviso).
Algunas o todas las características del ordenador pueden haberse configurado de antemano. Si no lo están, o si desea reconfigurar (o reinstalar) partes del sistema, consulte el Manual del usuario completo. El disco Device Drivers & Utilities + User’s Manual no contiene un sistema operativo.
Información de regulación y seguridad
Por favor, preste especial atención a todos los avisos de regulación e información de seguridad contenidos en el Manual del usuario completo del disco Device Drivers & Utilities + User’s Manual.
© Mayo del 2014
Marcas registradas
Intel y Celeron son marcas/marcas registradas de Intel Corporation.
La compañía se reserva el derecho a revisar esta publicación o cambiar su contenido sin
Español
65
Instrucciones para el cuidado y funcio­namiento
El ordenador portátil es muy robusto, pero puede dañarse. Para evitar esto, siga estas sugerencias:
No lo deje caer ni lo exponga a golpes fuertes. Si el ordena dor se
cae, la carcasa y los componentes podrían dañarse.
Manténgalo seco y no lo sobrecaliente. Mantenga el ordenador y
fuente de alimentación alejados de cualquier tipo de fuente de calor. Esto es un apara to eléctrico. Si se derrama agua u otro líquido en su interior, el ordenador podría dañarse seriamente.
Evite las interferencias. Mantenga el ordenador alejado de trans-
formadores de alta capacidad, motores eléctricos y otros campos magnéticos fuertes. Éstos pueden dificultar el correcto funciona­miento y dañar los datos.
Siga las instrucciones apropiadas de manejo del ordenador.
Apague el ordenador correctamente y no olvide guardar su trabajo. Recuerde guardar periódicamente sus datos, pues los datos pueden perderse si la batería se descarga.
Servicio
Si intenta reparar el ordenador usted mismo, podría anular la garantía y exponerse usted y el ordenador a descarga eléctrica. Deje que sea personal de reparación cualificado el que realice las reparaciones, especialmente bajo cualquiera de estas condi-
Español
ciones:
• Cuando el cable de alimentación o adaptador AC/DC esté dañado o
pelado.
• Si el ordenador ha estado expuesto a la lluvia u otros líquidos.
• Si el ordenador no funciona con normalidad tras seguir las instruc-
ciones de uso.
• Si el ordenador se ha caído o dañado (no toque el líquido venenoso
si el panel LCD se rompe).
• Si hay un olor fuera de lo normal, calor o humo que sale del orde­nador.
Información de seguridad
• Utilice solamente un adaptador de alimentación aprobado para su uso con este ordenador.
• Utilice solamente el cable de corriente y las baterías indicados en este manual. No tire las baterías al fuego. Podrían explotar. Con­sulte los códigos locales para posibles instrucciones para desechos especiales.
• Nunca utilice una batería que se haya caído o que parezca dañada (p. ej. doblada o retorcida). Incluso si el ordenador sigue funcio­nando con una batería dañada, puede provocar daños en el circuito que podrían causar fuego.
• Compruebe que su ordenador esté completamente apagado antes de introducirlo en una bolsa de viaje (o en cualquier funda).
• Antes de limpiar el ordenador, quite la batería y asegúrese de que el ordenador esté desconectado de cualquier fuente de alimentación externa, periféricos y cables (incluyendo la línea telefónica).
• Utilice un trapo limpio y suave para limpiar el ordenador, pero no aplique limpiador directamente en el ordenador. No utilice limpia­dores volátiles (derivados del petróleo) o limpiadores abrasivos en ningún lugar del ordenador.
• No intente reparar baterías. Solicite la reparación o la sustitución a su representante de servicio o a personal de servicio cualificado.
• Tenga en cuenta que en ordenadores con logotipos de LCD etique­tados eléctricamente en relieve, el logotipo está recubierto por un adhesivo protector. Debido al desgaste y rotura normales, este adhesivo puede deteriorarse con el tiempo y en el logotipo expuesto pueden formarse bordes afilados. Tenga cuidado al manipular el ordenador en este caso y evite tocar el logotipo del LCD etiquetado eléctricamente. Evite colocar cualquier elemento en la bolsa de transporte que pueda rozar la parte superior del ordenador durante el transporte Si ocurre un desgaste o rotura, contacte con el centro de servicios.
66
Precauciones para baterías de polímero
Eliminación de la batería & Cuidado
El producto que usted ha comprado contiene una batería recargable. La batería es reciclable Terminada su vida útil, según las leyes locales y estatales, puede ser ilegal desecharla junto con los residuos ordinarios. Verifique con las autoridades locales responsables de los desechos sólidos cuáles son las opciones de eliminación y reciclado existentes en su zona.
Peligro de explosión si la batería está mal colocada. Sustitúyala con un tipo de batería igual o equivalente al recomendado por el fabricante. Elimine la batería usada de conformidad con las instrucciones del fabricante.
Tenga en cuenta la información siguiente específica para bate­rías de polímero; además, donde corresponda, invalida la infor­mación sobre precauciones para baterías normales.
• Las baterías pueden aumentar o hincharse ligeramente, sin embargo, esto es parte del mecanismo de seguridad de la batería y o supone un problema.
• Utilice los procedimientos de manejo apropiados cuando utilice baterías de polímero. No utilice baterías de polímero en entornos con temperatura ambiental alta y no guarde las baterías sin usar durante mucho tiempo.
Español
67

Guía rápida para empezar

Apagar
Por favor, tenga en cuenta que debería siempre apagar el ordena­dor eligiendo la opción Apagar en Windows (ver abajo). Esto le ayudará a evitar problemas con el disco duro o el sistema.
Haga clic en el icono
en la pantalla Inicio y
elige la opción Apagar desde el menú.
O
Haga clic con el botón derecho en el botón Inicio en la parte inferior de la pantalla Inicio o del Escritorio
y elige Apagar o
cerrar
sesión > Apagar en el menú contextual.
130
1. Quite todos los materiales del embalaje.
2. Coloque el ordenador en una superficie estable.
3.
Inserte la batería y asegúrese de que quede bloqueada en su
posición.
4. Conecte el adaptador AC/DC al conector de entrada DC que
está del lado derecho del ordenador, y luego conecte el cable de alimentación AC en un eschufe y al adaptador.
5. Utilice una mano para levantar con cuidado la tapa/LCD a un
ángulo de visión cómodo (no exceder 130 grados), mientras utiliza la otra mano (como se muestra en la Figura 1) para sostener la base del ordenador (Nota: Nunca levante el ordenador por la tapa/LCD).
6. Presione el botón de encendido para “encender”.
Software de sistema
Puede ser que su ordenador tenga instalado un software de sistema. Si no es el caso, o si desea reconfigurarlo con otro sistema, este manual se refiere a Microsoft Windows 8.1 (32-bit).
Español
Figura 1 - Abrir la tapa/LCD/ordenador con el ad aptador
AC/DC enchufado
68

Mapa del sistema: Vista frontal con panel LCD abierto

5
7
6
2
1
3
4
7
Figura 2
Vista frontal con panel
LCD abierto
1. Cámara PC (opcional)
2. *LED de cámara PC
*Cuando la cámara PC esté en uso, el LED se iluminará en rojo.
3. Micrófono incorporado
4. Panel LCD
5. Botón de encendido
6. Teclado
7. Touchpad (almohadilla táctil) y botones
Tenga en cuenta que el área válida de operación del Touchpad y los botones es la indicada dentro de las líneas de puntos de arriba.
Uso de dispositivos
inalámbricos a
bordo
El uso de dispositivos electrónicos portátiles a bordo de un avión suele estar prohibido.
Asegúrese de que los módulos WLAN y Bluetooth estén apagados si utiliza el equipo en un avión ajustando el sistema al Modo de avión.
Español
69

Indicadores LED

Los indicadores LED en su ordenador muestran una valiosa información sobre el estado actual del ordenador.
Icono Color Descripción
Naranja El adaptador AC/DC está conectado
Verde El ordenador está encendido
Español
70
Verde
parpadeante
Naranja La batería se está cargando
Verde La batería está completamente cargada
Naranja
parpadeante
Verde
Verde El disco duro está en uso
La batería ha alcanzado el estado crítico de poca energía
El Modo de avión está activado (los módulos WLAN y Bluetooth están
Tabla 1 - Indicadores LED
El ordenador está en modo Suspensión
apagados)

Teclado

Numeric
Keypad
Keypad
Tecla de Windows
Tecla Menú/Aplicación
Teclado
Tecla Fn
Teclas de función
numérico
Bloq Num & Bloq Despl
Acceso directo del teclado
al logotipo Windows
Utilice la combinación de te­clas Tecla de Windows + D para cambiar de la pan­talla Inicio al Escritorio de Windows.
Acceso directo del teclado
a Menú/Aplicación
Cuando la app del Escritorio esté en ejecución, puede usar la tecla Menú/Aplica- ción del teclado para que actúe como clic del bo­tón derecho de un ratón. En la pantalla Inicio esta función resulta útil para mostrar rápi­damente la barra Personali- zar.
Figura 3 - Teclado
El teclado tiene un teclado numérico para una entrada fácil de datos numéricos. Al presionar Fn + Bloq Num el teclado numérico se habilita o inhabilita. También incluye las teclas de función para permitirle cambiar las características operacionales al instante.
Español
71
Teclas de función
Las teclas de función (F1 - F11 etc.) actuarán como teclas directas (Hot-Key) cuando se pulsan junto con la tecla Fn. Además de las combinaciones de teclas de función básicas algunos indicadores visuales están disponibles (sólo en la aplicación Escritorio de Windows y no en la pantalla Inicio) cuando el controlador de teclas directas está instalado.
Teclas Función/indicadores visuales Teclas Función/indicadores visuales
Fn +
Reproducir/pausar (en los programas audio/vídeo)
Fn +
Activar/desactivar el
módulo cámara PC
Fn +
Fn +
Fn + Conmutación mudo
Fn + Conmutación dormir
Español
Fn +
72
Fn +
Fn +
Activar/desactivar el
Touchpad
Apagar luz de fondo del LCD (presione una tecla o
utilice el Touchpad para encenderlo)
Reducción/aumento
volumen de sonido
Cambiar la configuración de pant alla (
página 80
Reducción/aumento bri-
llo LCD
)
ver la
Tabla 2 - Teclas de función & indicadores visuales
Fn +
Fn +
Fn +
Fn +
Fn +
Activar/desactivar el
Modo de avión
Activar/disactivar el
teclado numérico
Cambiar el bloqueo de
desplazamiento
Cambio Bloq. Mayús-
culas
Activar/desactivar el Control Center (centro de con-
trol)
(ver la página 73)
Control automático del
ventilador/potencia
completa

Control Center (Centro de control)

El Control Center (Centro de control) en Windows 8.1 funciona bajo la app Escritorio y no en la pantalla Inicio. Presione la combinación de teclas Fn + Esc o haga doble clic en el icono en el área de notificación de la barra de tareas para activar o desactivar el Control Center. El Control Center ofrece un acceso rápido a los controles usados con más frecuencia y le permite activar, y desactivar el touchpad/el módulo cámara rápidamente.
Figura 4 - Control Center
Español
Haga clic en los iconos del Control Center para cambiar a la función apropiada o mant eng a pres ionado el botón del ratón y nueva el control dial a la posición deseada. Algunas funciones serán ajustadas automáticamente al seleccionar un modo de energía.
73
Modos de energía
Puede ajustar el Modo de energía haciendo clic en el icono apropiado en la parte superior del Control Center. Cada modo de energía afectará a Power Conservation Mode (Modo ahorro de energía), Airplane Mode (Modo de avión), Power Plan (Plan de energía) y PC camera power (Energía de cámara PC), etc.
Puede hacer clic en un icono del Control Center para ajustar un modo de energía global y luego hacer clic en iconos individuales en el Control Center para encender o apagar el touchpad y el módulo cámara.
Español
74
Modos
Icono
Plan de energía
Power Conservation Mode
(Modo ahorro de energía)
Cámara PC Activado Desactivado Activado Activado
Touchpad Activado Activado Activado Activado
Modo de avión Desactivado Activado Desactivado Desactivado
Quiet
(Silencioso)
Balanced
Tabla 3 - Modos de energía
Power Saving
(Ahorro de energía)
Economizador Alto rendimiento
Energy Star Performance
Performance
(Rendimiento)
Entertainment
(Entretenimiento)
Balanced
Power Status (Estado de energía) /
Fan Speed (Velocidad del ventilador)
El icono Estado de energía mostrará si la alimentación actual viene dada por la batería o por el adaptador AC/DC enchufado en una toma de corriente. La barra de estado de energía muestra el estado actual de la carga de la batería.
Brightness (Brillo)
El icono Brillo mostrará el nivel actual del brillo de la pantalla. Puede usar el control deslizante para ajustar el brillo de la pantalla o las combinaciones de teclas Fn + F8/F9 o usar la combinación de teclas Fn + F2 para apagar la retroiluminación LED (presione una tecla para volver encenderla). Tenga en cuenta que Modo de energía también puede afectar el brillo de la pantalla.
Volume (Volumen)
El icono Volumen mostrará el nivel actual del volumen. También puede usar el control deslizante para ajustar el volumen o las combinaciones de teclas Fn + F5/F6 o la combinación de teclas Fn + F3 para silenciar el volumen.
Power Conservation (Ahorro de energía)
Este sistema soporta las características de administración de energía Energy Star que hace que los equipos (CPU, disco duro, etc.) entren en modos de ahorro de energía y suspensión tras el período de tiempo de inactividad designado. Haga clic en el botón Performance (Rendimiento), Balanced (Equilibrado) o Energy Star.
Esto ajustará la velocidad del ventilador automáticamente para controlar el calor de la CPU. Sin embargo, puede aj ustar la configuración al máximo si lo desea.
Sleep Button (Botón Suspender)
Haga clic en el botón Hibernate (Hibernar) o Sleep (Suspender) para que el equipo entre en el modo de ahorro de energía seleccionado.
Display Switch (Cambiar pantalla)
Haga clic en el botón Cambiar pantalla para acceder al menú (o utilice la combinación de teclas + P) y seleccione el modo de pantalla apropiado.
Time Zone (Zona horaria)
Si hace clic en el botón Zona horaria accederá al panel de control Fecha y hora de Windows.
Desktop Background (Fondo de pantalla)
Si hace clic en el botón Fondo de pantalla podrá cambiar la imagen del fondo del escritorio.
Touchpad/cámara PC
Haga clic en cualquiera de estos botones para cambiar el estado de energía del Touchpad o del módulo cámara. Tenga en cuenta que el estado de energía del módulo cámara también queda afectado por el Modo de energía seleccionado.
Español
75
Mapa del sistema: Vistas frontal, izquierda, derecha, posterior e
Advertencia sobre quitar la tapa inferior
No quite ninguna tapa y/o tornillo para actualizar el dispositivo, pues podría violar los términos de su garantía.
Si necesita colocar o quitar el disco duro/ RAM/dispositivo óptico, etc. por cualquier razón, contacte con su distribuidor o vendedor para más información.
Cara inferior
Figura 5 - Vistas frontal, izquierda, derecha, posterior e inferior
1. Indicadores LED
2. Ranura del cierre de seguridad
3. Puerto para monitor externo
4. Rejilla
5. Puerto de salida de HDMI
6. Puerto USB 3.0
7. Conector de entrada para micrófono
8. Conector de salida de auriculares
9. Puertos USB 2.0
10. Lector de tarjetas multi-en-1
11. Conector LAN RJ-45
12. Conector de entrada DC
13. Batería
14. Altavoces incorporados
1
2
4
6
3
5
10
11
7
13
9
12
8
9
13
4
4
4
14
14
Parte frontal
Lateral izquierdo
Parte posterior
Lateral derecho
inferior
Español
76

Panel de Control de Windows 8.1

Figura 6
Menú contextual
Mueva el ratón a la esquina inferior izquierda de la pan­talla y haga clic con el botón derecho en el botón Inicio para acceder al menú.
Figura 7 - Pantalla Inicio
A lo largo de este manual verá una instrucción para abrir el Panel de Control. Haga clic con el botón derecho en el botón Inicio en la app del Escritorio o en la pantalla Inicio (o utilice la combinación Tecla de Windows + tecla X) para abrir
un menú contextual avanzado con características útiles como Panel de control, Programas y características, Opciones de energía, Administrador de tareas, Buscar, Explorador de archivos, Símbolo del sistema, Administrador de dispositivos, Conexiones de red, etc y seleccionar Panel de Control.
Pantalla Inicio y escritorio de Windows
8.1
A las apps, paneles de control, utilidades y programas en Windows se accede desde la pantalla Inicio y/o desde la app Escritorio de Windows. Al Escritorio (que se ejecuta como una app dentro de la pantalla Inicio) se puede acceder haciendo clic en Escritorio en la pantalla Inicio (o usando la combinación Tecla de Windows + tecla D). La barra de tareas aparecerá en la parte inferior de la pantalla del escritorio y verá el área de notificación de la barra de tareas en la parte inferior derecha de la pantalla. Haga clic en la flecha en la parte inferior de la pantalla Inicio para acceder a Aplicaciones.
Español
77

Apps y Mosaicos

Haga clic en la flecha en la parte inferior de la pantalla Inicio para acceder a Aplicaciones.
La pantalla Inicio contendrá varias apps y muchas más se instalarán conforme añada más aplicaciones, etc. No todas estas apps caben en una pantalla, por lo que a menudo deberá usar el control deslizante de la parte inferior de la pantalla para ver todas las apps necesarias.

Barra Charms

El lado derecho de la pantalla muestra la barra Charms. La barra Charms contiene los menús Buscar, Compartir, Inicio, Dispositivos y Configuración. Para acceder a la barra Charms, mueva el cursor hacia la esquina superior o inferior derecha
de la pantalla y luego mueva uno de los elementos hacia la barra Charms para activarla (la barra estará en negro cuando esté activa) o utilice la combinación Tecla de Windows + tec la C.
Español
78
Figura 8 - Pantalla Inicio con la barra Charms

Parámetros de vídeo

1
2
2
1
Figura 9 - Panel de control Pantalla
Resolución de pantalla para Apps (Windows 8.1)
La resolución mínima en la que las apps se ejecutarán es de 1024x768.
La resolución mínima necesaria para soportar todas las características de Windows 8.1 (incluyendo multitarea con snap) es de 1366x768.
El sistema incluye una GPU integrada de Intel. Puede cambiar los dispositivos de pantalla y configurar las opciones de pantalla desde el panel de control Pantalla en Windows siempre que tenga instalado el controlador de vídeo.
Para acceder al panel de control Pantalla:
1. Vaya al Panel de Control.
2. Haga clic en Pantalla (icono) - en Apariencia y personalización (categoría).
3. Haga clic en Ajustar resolución de pantalla/Ajustar resolución.
O
4. Haga clic con el botón derecho en el escritorio (utilice la
combinación Tecla de Windows + tecla D para acceder al escritorio) y seleccione Resolución de pantalla.
5. Utilice el cuadro desplegable para seleccionar la resolución de la pantalla .
6. Haga clic en Configuración avanzada .
Para acceder al Panel de control de gráficos HD Intel®:
1. Haga clic en el icono (Panel de control de gráficos HD Intel®) en la pantalla Aplicaciones.
O
2. Haga clic con el botón derecho en el escritorio (utilice la combinación Tecla de Windows + tecla D para acceder al escritorio) y seleccione Propiedades de gráficos en el menú.
O
3. Haga clic en el icono en el área de notificación de la barra
de tareas del escritorio y seleccione Propiedades de gráficos en el menú.
Dispositivos de pantalla
Además del LCD incorporado, también puede utilizar un monitor VGA/pantalla plana o TV (conectado al puerto para monitor externo o al puerto de salida de HDMI) como dispositivo de pantalla.
Español
79
Usar la combinación de teclas del
Figura 10
+ P (Cambiar la
configuración de
pantalla)
Figura 11 - Opciones de energía
logotipo Windows
+ P para cambiar
entre pantallas
Puede usar la combinación de teclas + P (o Fn + F7) para cambiar rápidamente la configuración de pantalla y los modos (esto resulta especialmente útil cuando se coloca un proyector) en Windows.
1. Conecte una pantalla externa al puerto para monitor externo o puerto de salida de HDMI y enciéndala.
2. Pulse la combinación de teclas + P (o Fn + F7).
3. Aparecerá un menú en pantalla.
4. Utilice las teclas del cursor (o + P) para seleccionar la configuración apropiada en el menú y presione Entrar para confirmar la selección.
Español

Opciones de energía

El panel de control de las opciones de energía (menú Hardware y sonido) de Windows permite configurar las funciones de administración de energía del ordenador. Puede ahorrar energía con los planes de energía y configurar las opciones para el botón de encendido, botón de suspensión (Fn + F4), tapa del ordenador (al cerrarla), pantalla y modo de suspensión (el estado de ahorro de energía predeterminado) en el menú de la izquierda. Tenga en cuenta que el plan economizador puede afectar al rendimiento del ordenador.
Haga clic para seleccionar uno de los planes existentes o haga clic en Crear un plan de energía en el menú izquierdo y seleccione las opciones para crear un plan nuevo. Haga clic en Cambiar la configuración del plan y haga clic en Cambiar la configuración avanzada de energía para acceder a más opciones de configuración.
80

Instalación de controladores

Directrices generales
para la instalación del
controlador
Como guía general, siga las instrucciones predeter­minadas en pantalla para cada controlador (p.ej. Si-
guiente > Siguiente > Fi­nalizar) a menos que sea
usuario avanzado. En mu­chos casos necesitará rei­niciar para instalar el controlador.
Asegúrese de que los mó­dulos (p.ej. WLAN o Blue­tooth) estén ENCENDIDOS antes de instalar el controlador apropiado.
Windows Update
Tras instalar todos los con­troladores asegúrese de haber habilitado Windows Update para obtener las últimas actualizaciones de seguridad, etc. (todas las actualizaciones incluirán los últimos parches de Mi­crosoft).
Instalación del controlador y
alimentación
Cuando instale controladores asegúrese de que el ordenador esté alimentado por el adaptador AC/DC conectado a una fuente de corriente activa. Algunos controladores consumen una cantidad significativa de corriente durante el proceso de instalación, y si la batería se consume puede provocar que el sistema se apague, causando problemas en el sistema (tenga en cuenta que esto no supone un problema de seguridad y la batería podrá recargarse en 1 minuto).
Figura 12 - Instalación de controladores
El disco Device Drivers & Utilities + User’s Manual contiene los controladores y utilitarios necesarios para utilizar el ordenador correctamente. Inserte el disco y haga clic en Install Drivers (botón), u Option Drivers (botón) para acceder al menú de controladores opcional. Instale los controladores en el orden indicado en la Figura 12. Haga clic para seleccionar los controladores que desea instalar (debería anotar los controladores conforme lo s instala). Nota: Si necesita reinstalar un controlador, debería desinstalar el controlador antes.
Instalación manual del controlador
Haga clic en el botón Browse CD/DVD en la aplicación Drivers Installer y busque el archivo ejecutable en la carpeta de controladores apropiada.
Si durante el procedimiento de instalación aparece una ventana Nuevo hardware encontrado, haga clic en Cancelar para cerrar la ventana y siga con el procedimiento de instalación.
Español
81

Solución de problemas

Problema Posible causa - Solución
Los módulos WLAN y Bluetooth no pueden detectarse.
El módulo cámara PC no puede detectarse.
Español
Los módulos están apagados cuando el equipo está en Modo de avión. Compruebe el indicador LED para ver si el equipo está en Modo de avión (vea la Tabla 1 en la página 70). Utilice la combinación de teclas Fn + F11 para activar/desactivar el Modo de avión (vea la Tabla 2 en la
página 72).
El módulo está desactivado. Utilice la comb inación de tecl as Fn + F10 para activar el módulo (vea
la Tabla 2 en la página 72). Ejecute la aplicación de la cámara para ver la imagen de la cámara.
82

Especificaciones

Información actualizada de
especificaciones
Las especificaciones listadas en esta sección son correctas en el momento de publicación. Ciertas opciones (particu­larmente tipos/velocidades de procesa­dores) pueden cambiar o actualizarse según la fecha de lanzamiento del fabri­cante. Diríjase a su centro de servicios para más detalles.
Opciones de procesadores
Procesador Intel® Celeron® N2830 (2,17GHz)
Caché de nivel 2 de 1MB, 22nm, DDR3L­1066MHz, TDP 7,5W
N2807 (1,58GHz)
Caché de nivel 2 de 1MB, 22nm, DDR3L­1066MHz, TDP 4,3W
BIOS
AMI BIOS (SPI Flash ROM de 64Mb)
Memoria
Un zócalo de 204 pins SODIMM, para memoria DDR3L 1600MHz
Memoria expansible hasta 2GB (La frecuencia de operación de memoria
real depende del FSB del procesador.)
LCD
11,6" (29,46cm) HD (espesura: 3,6mm)
Adaptador de vídeo
Intel® HD Graphics
Frecuencia dinámica (Tecnología de memoria de vídeo dinámica Intel hasta 1,7GB)
Compatible con DirectX® 11
Almacenamiento
Un HDD SATA intercambiable de 2,5" 7,0mm (h)
(Opción de fábrica) Una unidad Solid State (SSD) 16GB mSATA
Audio
Interfaz compatible HDA (Sonido Intel de alta definición)
2 altavoces incorporados Micrófono incorporado
Seguridad
Ranura para cierre de seguridad (tipo Kensington®)
Contraseña de BIOS
Teclado
Teclado “Win Key” (con teclado numérico incorporado)
Dispositivo puntero
Touchpad incorporado
Interfaz
Dos puertos USB 2.0 Un puerto USB 3.0 Un puerto de salida de HDMI
Un puerto para monitor externo Un conector de salida de altavoces/
auriculares Un conector de entrada para micrófono Un conector LAN RJ-45 Un conector de entrada DC
Ranuras Mini-Card
Ranura 1 para módulo LAN inalámbrica o módulo combo Bluetooth y LAN
Inalámbrica (Opción de fábrica) Ranura 2 para mSATA
SSD
Español
83
Lector de tarjetas
Módulo lector de tarjetas multi en 1
MMC (MultiMedia Card) / RS MMC SD (Secure Digital) / Mini SD / SDHC/
compatible SDXC MS (Memory Stick) / MS Pro / MS Duo
Comunicaciones
LAN Ethernet de 10Mb/100Mb
(Opción de fábrica) Módulo cámara PC 1,0M HD/módulo cámara PC de 300K píxeles
Módulos Half Mini-Card WLAN/ Bluetooth:
(Opción de fábrica) LAN inalámbrica (802.11b/g/n) (tercera parte)
(Opción de fábrica) Bluetooth 4.0 y LAN Inalámbrica (802.11b/g/n) (tercera parte)
Especificaciones del ambiente
Temperatura
En funcionamiento: 5°C - 35°C Apagado: -20°C - 60°C
Español
Humedad relativa
En funcionamiento: 20% - 80% Apagado: 10% - 90%
Alimentación
Adaptador de AC/DC autodetector de corriente
Entrada AC: 100-240V, 50-60Hz Salida DC: 19V, 1,58A (30W)
Batería de Litio-Ion inteligente de 3 elementos, 24WH (Opción de fábrica) Batería de Litio-Ion inteligente de 3 elementos, 31WH
Dimensiones y peso
292,4 (a) x 210,5 (l) x 22,7(h) mm (Altura
excluyendo el área de la batería)
(Barebone con batería de 24WH)
1,3kgs
84
85
Español
Español
86

Informazioni su questa guida rapida

Questa guida rapida rappresenta un’introduzione rapida all’avvio del sistema. Si tratta di un supplemento e non di una sostituzione del Manuale per l'utente completo in lingua inglese nel formato Adobe Acrobat, memorizzato sul disco Device Drivers & Utilities + User's Manual fornito a corredo del computer. Inoltre, questo disco con tiene i driver e le utilità necessari per il corretto uso del computer (Nota: La società si riserva il diritto di revisionare la presente pubblicazio ne o di modificarne il contenuto senza preavviso).
È possibile che alcune o tutte le funzionalità del computer siano già state configurate. In caso contrari o, o se si sta pianificando di riconfigurare (o reinstallare) componenti del sistema, fare riferimento al Manuale per l'utente completo. Il disco Device Drivers & Utilities + User’s Manual non contiene il sistema operativo.
Informazioni legali e di sicurezza
Prestare particolare attenzione alle informative legali e di sicurezza contenute nel Manuale per l'utente che si trova sul disco Device Drivers & Utilities + User’s Manual.
©
Maggio 2014
Marchi registrati
Intel e Celeron sono marchi/marchi registrati della Intel Corporation.
Italiano
87
Istruzioni per la custodia e il funziona­mento
Il computer notebook è abbastanza rigido, ma è possibile che possa essere danneggiato. Per evitare qualsiasi danno, attenersi ai seguenti suggerimenti:
Non lasciarlo cadere ed evitare urti. Se il computer cade, è possi-
bile che il telaio e i componenti possano esserne danneggiati.
Tenerlo all'asciutto e non provocarne il surriscaldamento. Tenere
il computer e l'alimentazione lontani da ogni tipo di impianto di riscaldamento. Si tratta di un apparato elettrico. Se acqua o altri liquidi dovessero penetrarvi, esso potrebbe risultarne seriamente danneggiato.
Evitare le interferenze. Tenere il computer lontano da trasformatori
ad alta capacità, motori elettrici e altri intensi campi magnetici. Ciò ne può impedire il corretto funzionamento e danneggiare i dati.
Attenersi alle corrette procedure di lavoro con il computer. Spe-
gnere il computer correttamente e non dimenticare di salvare il pro­prio lavoro. Ricordare di salvare frequentemente i propri dati poiché essi potrebbero essere persi nel caso in cui la batteria si esaurisse.
Assistenza
Ogni tentativo di riparare da soli il computer può an nullare la garanzia ed esporre l'utente a scosse elettriche. Per l'assistenza rivolgersi solo a personale tecnico qualificato, in particolar modo nelle situazioni seguenti:
• Quando il cavo di alimentazione o l'adattatore AC/DC è danneggiato
o logorato.
• Se il computer è stato esposto alla pioggia o ad altri liquidi.
Italiano
• Se il computer non funziona normalmente dopo aver seguito corret-
tamente le istruzioni operative.
• Se il computer è caduto o si è danneggiato (non toccare il liquido
velenoso in caso di rottura dello schermo LCD).
• Se c'è un odore non usuale, calore o fumo che fuoriesce dal compu­ter.
Informazioni di sicurezza
• Utilizzare esclusivamente un adattatore approvato per l'utilizzo di questo computer.
• Utilizzare solo il cavo di alimentazione e le batterie indicate in que­sto manuale. Non gettare le batterie nel fuoco, poiché potrebbero esplodere. Fare riferimento alle normative locali per istruzioni spe­ciali in tema di smaltimento rifiuti.
• Non continuare a usare in alcun modo una batteria che sia caduta in terra o che sembri danneggiata (es. piegata o torta). Anche se il com­puter continua a funziona re con una bat teria da nnegg iata, qu esta p uò provocare danni ai circuiti risultanti in pericolo di incendio.
• Assicurarsi che il computer sia completamente spento prima di inse­rirlo in una borsa da viaggio (o in un contenitore simile).
• Prima di pulire il computer ricordare sempre di rimuovere la batteria e di scollegare il computer da qualsiasi fonte di alimentazione esterna, da periferiche e altri cavi (incluse linee telefoniche).
• Per pulire il computer utilizzare solo un panno morbido e pulito, evi­tando di applicare detergenti direttamente sul computer. Non utiliz­zare detergenti volatili (distillati di petrolio) o abrasivi su qualsiasi parte del computer.
• Non provare a riparare il pacco batteria. Fare riferimento sempre all'assistenza tecnica o a personale qualificato per la riparazione o la sostituzione del pacco batteria.
• Si noti che nei computer che hanno un logo elettroimpresso LCD in rilievo, questo è coperto da un adesivo protettivo. Nell'uso quoti­diano e con il passare del tempo, questo adesivo potrebbe deterio­rarsi e il logo sottostante potrebbe avere del bordi acuminati. In questo caso, fare attenzione quando si maneggia il computer ed evi­tare di toccare il logo elettroimpresso LCD in rilievo. Evitare di inse­rire altri oggetti nella borsa di trasporto poiché potrebbero sfregare contro la copertura del computer durante il trasporto. Se si svilup­pano parti consumate e logorate, contattare il centro di assistenza.
88
Precauzioni relative alla batteria ai polimeri
Smaltimento della batteria & Attenzione
Il prodotto acquistato contiene una batteria ricaricabile. La batteria è riciclabile. Al termine della durata di uso, in base alle diverse leggi locali e statali, può essere illegale smaltire questa batteria insieme ai rifiuti comuni. Controllare i requisiti previsti nella propria zona consultando i funzionari locali addetti allo smaltimento dei rifiuti solidi per le opzioni di riciclo o lo smaltimento corretto.
Pericolo di esplosione in caso sostituzione errata della batteria. Sostituire solamente con lo stesso tipo o con uno analogo raccomandato dal produttore. Eliminare la batteria usata seguendo le istruzioni del produttore.
Le informazioni seguenti sono molto importanti e si riferiscono unicamente alle batterie ai polimeri e, ove applicabile, hanno priorità rispetto alle precauzioni generali relative alle batterie.
• Le batterie ai polimeri possono espandersi o gonfiarsi leggermente, tuttavia questo fa parte del meccanismo di sicurezza della batteria e non deve essere causa di preoccupazione.
• Maneggiare le batterie ai polimeri in modo corretto nel loro utilizzo. Non utilizzare batterie ai polimeri in ambienti con temperature ele­vate e non conservare le batterie inutilizzate per periodi di tempo pro­lungati.
Italiano
89

Guida di avvio rapido

Spegnimento
È importante tenere presente che è sempre necessario spegnere il com­puter scegliendo il comando Arresta il sistema in Windows (vedere sotto). In questo modo si evitano problemi al sistema o al disco rigido.
Fare clic sull'icona nella schermata Start e
sce-
gliere
il comando Arresta il sistema disponibile dal
menu.
O
Fare clic con il pulsante destro del mouse sul pulsante Start nel­la parte inferiore della schermata Start o del Desktop e scegliere
Chiudi o disconnetti > Arresta il sistema dal menu contestuale.
130
1. Eliminare tutti i materiali di imballo.
2. Appoggiare il computer su una superficie stabile.
3.
Inserire la batteria e verificare che sia bloccata in
posizione.
4. Collegare bene le periferiche che si desidera usare con il
computer (per esempio tastiera e mouse) alle porte corri­spondenti.
5. Collegare l'adattatore AC/DC al jack di ingresso DC situato
alla destro del computer, quindi inserire il cavo di alimenta­zione AC in una presa e collegare il cavo di alimentazione AC all'adattatore AC/DC.
6. Con una mano sollevare con cautela il coperchio/LCD fino
a un angolo di visione comodo (non superare i 130 gradi), mentre con l'altra mano (come illustrato nella Figura 1) si mantiene la base del computer (Nota: Non sollevare mai il computer tenendolo dal coperchio/LCD).
7. Premere il pulsante di alimentazione per accendere.
Software del sistema
È possibile che il software sia già pre-installato sul computer. In caso contrario, oppure in casi di riconfigurazione del computer per un sistema diverso, questo manuale si riferisce a Microsoft Windows 8.1 (32-bit).
Italiano
Figura 1 - Apertura del coperchio/LCD/Computer con
alimentatore AC/DC collegato
90

Descrizione del sistema: Vista anteriore con pannello LCD aperto

5
7
6
2
1
3
4
7
Figura 2
Vista anteriore con pan-
nello LCD aperto
1. Camera PC (opzionale)
2. *LED della camera PC
*Quando si utilizza la camera PC, l'indicatore LED si illumina in rosso.
3. Microfono incorporato
4. Schermo LCD
5. Pulsante di alimentazione
6. Tastiera
7. Touchpad e pulsanti
Si noti che l'area operativa va­lida del touchpad e dei pulsan­ti è quella indicata all'interno delle linee tratteggiate sopra.
Funzionamento del
dispositivo senza fili
a bordo di un aereo
Solitamente l’uso di qualsiasi dispositivo di trasmissione elettroni­ca è proibito a bordo di un aereo.
Accertarsi che i moduli WLAN & Bluetooth siano OFF quando si utilizza il computer a bordo di un aereo inserendo il sistema nella modalità aereo.
Italiano
91

Indicatori LED

Gli indicatori LED sul computer segnalano importanti informazioni relative allo stato corrente del computer.
Icona Colore Descrizione
Arancione L'alimentatore è collegato
Verde Il computer è acceso
Verde lampeggiante Il computer è in modalità Sospensione
Arancione La batteria è in carica
Verde Batteria completamente carica
Arancione lampeggiante La batteria ha raggiunto lo stato critico di carica bassa
Italiano
92
Verde
Verde Il disco rigido è in uso
Tabella 1 - Indicatori LED
La modalità aereo è ON (i moduli WLAN & Bluetooth sono OFF)

Tastiera

Numeric
Keypad
Tasto logo Windows
Tastierino
Tasti funzione
Bloc Num &
Tasto Fn
Bloc Scorr
numerico
Scorciatoia da tastiera
Windows Logo
Usare la combinazione di tasti
Tasto logo Windows + D per passare dalla scherma-
ta Start al Windows Desktop.
Menu/Scorciatoia tastiera
applicativo
Quando la Desktop app è in esecuzione potete usare il ta- sto Menu/Applicazione della tastiera con la funzione di clic destro del mouse. Nella schermata Start questa fun­zione è utile per visualizzare velocemente la barra Perso-
nalizza.
Tasto Menu/Applicazione
Figura 3 - Tastiera
Nella tastiera è stato integrato un tastierino numerico per un facile inserimento dei numeri. Premere Fn + Bloc Num per commutare l’attivazione e la disattivazione della tastiera numerica. Dispone anche di tasti funzione che consentono di cambiare istantaneamente le funzionalità operative.
Italiano
93

Tasti funzione

I tasti funzione (da F1 a F11) agiscono come Hot-Key quando premuti tenendo premuto il tasto Fn. In aggiunta alle combinazioni di tasti funzione base, quando è installato il driver hot key (HotKey Driver) alcuni indicatori visivi sono disponibili (solo nell'applicazione Windows Desktop e non nella schermata Start).
Tasti Tasti funzione e indicatori visivi Tasti Funzione/indicatori visivi
Fn +
Fn +
Fn +
Fn +
Fn + Commutazione Sospendi
Fn +
Italiano
Fn +
Fn +
Play/pausa (nei programmi audio/vi deo)
Attiva/disattiva
touchpad
Spegne la retroilluminazione dello schermo LCD (pre-
mere un tasto o utilizzare il touchpad per ripristinare lo
schermo)
Commutazione mute
Riduzione/Aumento volume
audio
Cambia configurazione di visualizzazione (vedere la
pagina 102)
Riduzione/aumento lumino-
sità LCD
Tabella 2 - Tasti funzione e indicatori visivi
Fn +
Fn +
Fn +
Fn +
Fn +
Fn +
Attiva/disattiva la
camera PC
Attiva/disattiva la moda-
lità aereo
Attiva/disattiva il tastie-
rino numerico
Attiva/disattiva il
blocco dello scorri-
mento
Attiva/disattiva maiu-
scolo
Attiva disattiva Control Center (Centro di controllo)
(vedere la pagina 95)
Controllo automatico
ventola/pieno power
94

Control Center (Centro di controllo)

Il Control Center (Centro di controllo) di Windows 8.1 funziona sotto la app Desktop e non sotto la schermata Start. Premere la combinazione di tasti Fn + Esc oppure fare doppio clic sull'icona nell'area di notifica della barra delle applicazioni per attivare/disattivare il Control Center. Il Control Center consente di accedere rapidamente ai controlli utilizzati più frequentemente, e di attivare/disattivare velocemente il touchpad/il modulo camera del computer.
Figura 4 - Control Center
Italiano
Cliccare l'icona Control Center per alternare la funzione appropriata, oppure tenere premuto il pulsante del mouse e spostare il controllo quadrante dove applicabile. Alcune funzioni saranno regolate automaticamente quando è selezionata una modalità di alimentazione.
95
Loading...
