Preface
R&TTE Directive
This device is in compliance with the essential requirements and other relevant provisions of the R&TTE Directive 1999/5/EC.
This device will be sold in the following EEA countries: Austria, Italy, Belgium, Liechtenstein, Denmark, Luxembourg, Finland, Netherlands, France, Norway, Germany, Portugal, Greece, Spain, Iceland, Sweden, Ireland,
United Kingdom, Cyprus, Czech Republic, Estonia, Hungary, Latvia, Lithuania, Malta, Slovakia, Poland, Slovenia.
CE Marking
This device has been tested to and conforms to the regulatory requirements of the European Union and has attained CE Marking. The CE Mark is a conformity marking consisting of the letters “CE”. The CE Mark applies
to products regulated by certain European health, safety and environmental protection legislation. The CE Mark
is obligatory for products it applies to: the manufacturer affixes the marking in order to be allowed to sell his
product in the European market.
This product conforms to the essential requirements of the R&TTE directive 1999/5/EC in order to attain CE
Marking. A notified body has determined that this device has properly demonstrated that the requirements of the
directive have been met and has issued a favorable certificate of expert opinion. As such the device will bear the
notified body number 0560 after the CE mark.
The CE Marking is not a quality mark. Foremost, it refers to the safety rather than to the quality of a product.
Secondly, CE Marking is mandatory for the product it applies to, whereas most q uality marking s are vo lu ntary.
II
Preface
FCC Statement
(Federal Communications Commission)
You are cautioned that changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
•Re orient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the service representative or an experienc ed radio/TV technician for help.
Operation is subject to the following two conditions:
1.This device may not cause interference.
And
2.This device must accept any interference, including interfer ence that may cause undesired operation of the
device.
III
Preface
Warning
Use only shielded cables to connect I/O devices to this equipment. You are cautioned that changes or modifications not expressly approved by the manufacturer for compliance with the above standard s could void your authority to operate the
equipment.
If your purchase option includes both Wireless LAN and 3.75G modules, then the appropriate antennas will be installed.
Note that In order to comply with FCC RF exposure compliance requirements, the antenna must not be co-located or operate
in conjunction with any other antenna or transmitter.
Important Notice - 3.75G/HSPA & Bluetooth/Wireless LAN Modules
In order to comply with FCC regulations you should NOT operate the 3.75G/HSPA module and the Bluetooth/Wireless LAN
modules at the same time as this may disrupt radio frequency, and cause interference. When the 3.75G/HSPA module is
powered on, make sure that the Bluetooth/Wireless LAN modules are powered off.
FCC RF Radiation Exposure Statement:
1.This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
2.This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator
and your body.
IV
Preface
IMPORTANT SAFETY INSTRUCTIONS
Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury
to persons when using any electrical equipment:
1.Do not use this product near water, for example n ear a ba th tub, wash bowl, kitchen sink or laundry tu b, in a wet
basement or near a swimming pool.
2.Avoid using this equipment with a telephone line (other than a cordless type) during an electrical storm. There
may be a remote risk of electrical shock from lightning.
3.Do not use the telephone to report a gas leak in the vicinity of the leak.
4.Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may
explode. Check with local codes for possible special disposal instructions.
5.This product is intended to be supplied by a Listed Power Unit with an AC Input of 100 - 240V, 50 - 60Hz, DC
Output of 19V, 3.42A or 18V, 3.5A (65 Watts) minimum AC/DC Adapter.
CAUTION
Always disconnect all telephone lines from the wall outlet before servicing or disassembling this equipment.
TO REDUCE THE RISK OF FIRE, USE ONLY NO. 26 AWG OR LARGER, TELE-
COMMUNICATION LINE CORD
This Computer’s Optical Device is a Laser Class 1 Product
V
Preface
Instructions for Care and Operation
The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions:
1.Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged.
Do not expose the computer
to any shock or vibration.
Do not place it on an unstable
surface.
Do not place anything heavy
on the computer.
2.Keep it dry, and don’t overheat it. Keep the computer and power supply away from any kind of heating ele-
ment. This is an electrical appliance. If water or any other liquid gets into it, the computer could be badly damaged.
Do not expose it to excessive
heat or direct sunlight.
Do not leave it in a place
where foreign matter or moisture may affect the system.
Don’t use or store the computer in a humid environment.
Do not place the computer on
any surface that will block the
Vents/Fan Intakes.
VI
Preface
3.Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other
strong magnetic fields. These can hinder proper performance and damage your data.
4.Follow the proper workin g procedu res for t he computer. Shut the computer down properly and don’t forget
to save your work. Remember to periodically save your data as data may be lost if the battery is depleted.
Do not turn off the power
until you properly shut down
all programs.
Do not turn off any peripheral
devices when the computer is
on.
5.Take care when using peripheral devices.
Use only approved brands of
peripherals.
Do not disassemble the computer by yourself.
Unplug the power cord befor e
attaching peripheral devices.
Perform routine maintenance
on your computer.
VII
Preface
Power Safety
Warning
Before you undertake
any upgrade procedures, make sure that
you have turned off the
power, and disconnected all peripherals
and cables (including
telephone lines). It is
advisable to also remove your battery in
order to prevent accidentally turning the
machine on.
Power Safety
The computer has specific power requirements:
•Only use a power adapter approved for use with this computer.
•Your AC/DC adapter may be designed for international travel but it still requires a steady,
uninterrupted power supply. If you are unsure of your local power specifications, consult
your service representative or local power company.
•The power adapter may have either a 2-prong or a 3-prong grounded plug. The third prong
is an important safety feature; do not defeat its purpose. If you do not have access to a compatible outlet, have a qualified electrician install one.
•When you want to unplug the power cord, be sure to disconnect it by the plug head, not by
its wire.
•Make sure the socket and any extension cord(s) you use can support the total current load
of all the connected devices.
•Before cleaning the computer, make sure it is disconnected from any external power supplies (i.e. AC/DC adapter or car adapter).
Do not plug in the power
cord if you are wet.
Do not use the power cord if
it is broken.
Do not place heavy objects
on the power cord.
VIII
Preface
Polymer Battery Precautions
Note the following information which is specific to polymer batteries only, and where applicable, this overrides
the general battery precaution information overleaf.
•Polymer batteries may experience a slight expansion or swelling, however this is part of the battery’s safety mecha-
nism and is not a cause for concern.
•Use proper handling procedures when using polymer batteries. Do not use polymer batteries in high ambient tempera-
ture environments, and do not store unused batteries for extended periods.
See also the general battery precautionary information overleaf for further information.
IX
Preface
Battery Disposal & Caution
The product that you have purchased contains a rechargeable battery. The battery is recyclable. At the end of its useful life,
under various state and local laws, it may be illegal to dispose of this battery in to the municipal waste stream. Check with
your local solid waste officials for details in your area for recycling options or proper disposal.
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalen t type recommended by the
manufacturer. Discard used battery according to the manufacturer’s instructions.
Battery Precautions
•Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer.
•Do not remove any batteries from the computer while it is powered on.
•Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even
if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly
result in fire.
•If you do not use the battery for an extended period, then remove the battery from the computer for storage.
•Recharge the batteries using the notebook’s system. Incorrect recharging may make the battery explode.
•Do not try to repair a battery pack. Refer any battery pack repa ir or replacemen t to you r service repre sentati ve or qu al-
ified service personnel.
•Keep children away from, and promptly dispose of a damaged battery. Always dispose of batteries carefully. Batteries
may explode or leak if exposed to fire, or improperly handled or discarded.
•Keep the battery away from metal appliances.
•Affix tape to the battery contacts before disposing of the battery.
•Do not touch the battery contacts with your hands or metal objects.
X
Cleaning
Removal Warning
When removing any cover(s) and screw(s) for the purposes of device upg rade, remember to replace the cover(s) and
screw(s) before turning the computer on.
Do not apply cleaner directly to the computer; use a soft clean cloth.
Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer.
Servicing
Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the
computer to electric shock. Refer all servicing to authorized service personnel. Unplug the computer from the
power supply. Then refer servicing to qualified service personnel under any of the following conditions:
•When the power cord or AC/DC adapter is damaged or frayed.
•If the computer has been exposed to rain or other liquids.
•If the computer does not work normally when you follow the operating instructions.
•If the computer has been dropped or damaged (do not touch the poisonous liquid if the LCD panel breaks).
•If there is an unusual odor, heat or smoke coming from your computer.
Preface
XI
Preface
Power Off Before Traveling
Make sure that your notebook is completely powered off before putting it into a travel bag (or any such container). Putting a
notebook which is powered on in a travel bag may cause the vent(s)/fan intake(s)/outlet(s) to be blocked. To prev ent your
computer from overheating make sure nothing blocks the vent(s)/fan intake(s)/outlet(s) while the computer is in use.
Travel Considerations
Packing
As you get ready for your trip, run through this list to make sure the system is ready to go:
1.Check that the battery pack and any spares are fully charged.
2.Power off the computer and peripherals.
3.Close the display panel and make sure it’s latched.
4.Disconnect the AC/DC adapter and cables. Stow them in the carrying bag.
5.The AC/DC adapter uses volt ages from 100 to 240 volt s so you won’t need a second volt age adapter. However,
check with your travel agent to see if you need any socket adapters.
6.Put the notebook in its carrying bag and secure it with the bag’s straps.
7.If you’re taking any perip herals (e.g. a printer, mouse or digital camera), pack them and those devices’ adapters
and/or cables.
8.Anticipate customs - Some jurisdictions may have import restrictions or req uire proof of ownersh ip for both hard -
ware and software. Make sure your documents are prepared.
XII
Preface
On the Road
In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting,
keep these points in mind:
Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very
common. Don’t check it with normal luggage. Baggage handlers may not be sufficiently careful. Avoid knocking the computer against hard objects.
Beware of Electromagnetic fields - Devices such as metal detectors & X-ray machines can damage the computer, hard disk, floppy disks, and other media. They may also destroy any stored data - Pass your computer and
disks around the devices. Ask security officials to hand-inspect them (you may be asked to turn it on). Note:
Some airports also scan luggage with these devices.
Fly safely - Most airlines have regulations about the use of computers and other electronic devices in flight.
These restrictions are for your safety, follow them. If you stow the notebook in an overhead compartment, make
sure it’s secure. Contents may shift and/or fall out when the compartment is opened.
Get power where you can - If an electrical outlet is available, use the AC/DC adapter and keep your battery(ies)
charged.
Keep it dry - If you move quickly from a cold to a warm location, water vapor can condense inside the computer.
Wait a few minutes before turning it on so that any moisture can evaporate.
XIII
Preface
Developing Good Work Habits
Developing good work habits is important if you need to work in fron t of the computer for long periods of time.
Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or
other joints. The following are some tips to reduce the strain:
•Adjust the height of the chair and/or desk so that the keyboard is at or slightly below the
level of your elbow. Keep your forearms, wrists, and hands in a relaxed position.
•Your knees should be slightly higher than your hips. Place yo ur feet flat on th e floor or on
a footrest if necessary.
•Use a chair with a back and adjust it to support your lower back comfortably.
•Sit straight so that your knees, hips and elbows form approximately 90-degree angles
when you are working.
•Take periodic breaks if you are using the computer for long periods of time.
Remember to:
•Alter your posture frequently.
•Stretch and exercise your body several times a day.
•Take periodic breaks when you work at the computer for long periods of time. Frequent
and short breaks are better than fewer and longer breaks.
XIV
Preface
Lighting
Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and
shoulders.
•Position the display to avoid glare or reflections from overhead lighting or outside sources of light.
•Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly.
•Position the display directly in front of you at a comfortable viewing distance.
•Adjust the display-viewing angle to find the best position.
LCD Screen Care
To prevent image persistence on LCD monitors (caused by the continuous display of graphics on the screen for
an extended period of time) take the following precautions:
•Set the Windows Power Plans to turn the screen off after a few minutes of screen idle time.
•Use a rotating, moving or blank screen saver (this prevents an image from being displayed too long ).
•Rotate desktop background images every few days.
•Turn the monitor off when the system is not in use.
This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the
computer and to getting your system started. The remainder of the manual covers the following:
• Chapter 2A guide to using some of the main features of the computer e.g. the storage devices (hard disk,
optical device, 7-in-1 card reader, ExpressCard/34/54), TouchPad & Mouse, Audio & Printer.
• Chapter 3 The computer’s power saving options.
• Chapter 4The installation of the drivers and utilities essential to the operation or improvement of some of the
computer’s subsystems.
• Chapter 5An outline of the computer’s built-in software or BIOS (Basic Input Output System).
• Chapter 6 Instructions for upgrading your computer.
• Chapter 7 A quick guide to the computer’s Bluetooth, Wireless LAN, PC Camera, 3.75G/HSPA and Secu-rity modules (some of which may be optional depending on your purchase configuration).
• Chapter 8 A troubleshooting guide.
• Appendix A Definitions of the interface, ports/jacks which allow your computer to communicate with external
devices.
• Appendix B Information on the Intel Videodriver controls.
• Appendix C The computer’s specification.
1
Overview 1 - 1
1
Notes
Check the light colored
boxes with the mark
above to find detailed information about the computer’s features.
Quick Start Guide
Advanced Users
If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful
to refer to “What to Install” on page 4 - 1, “BIOS Utilities” on page 5 - 1 and “Upgrading The Computer” on
page 6 - 1 in the reminder of the User’s Manual. You may also find the notes marked with a
of interest to you.
Beginners and Not-So-Advanced Users
If you are new to computers (or do not have an advanced knowledge of them) then
the information contained in the Quick Start Guide should be enough to get you up
and running. Eventually you should try to look through all the documentation (more
detailed descriptions of the functions, setup and system controls are covered in the
remainder of the User’s Manual), but do not worry if you do not understand everything the first time. Keep this manual nearby and refer to it to learn as you go. You
may find it useful to refer to the notes marked with a
as indicated in the margin.
For a more detailed description of any of the interface ports and jacks see “Interface
(Ports & Jacks)” on page A - 1.
Warning Boxes
No matter what your level please pay careful attention to the warning and safety information indicated by the
symbol. Also please note the safety and handling instructions as indicated in the Preface.
1 - 2 Overview
Quick Start Guide
Drivers
If you are installing new system software, or are re-configuring your computer for a different system, you will need to install
the drivers listed in “Drivers & Utilities” on page 4 - 1. Drivers are programs which act as an interface between the computer and a hardware component e.g. a wireless network module. It is very important that you install the drivers in the order
listed. You will be unable to use most advanced controls until the necessary drivers and utilities are properly installed. If
your system hasn’t been properly configured (your service representative may have already done that for you); refer to
Chapter 4 for installation instructions.
Ports and Jacks
See Appendix A for a description of the interface (ports & jacks) which allow your computer to communicate with external
devices, connect to the internet etc.
Not Included
Operating Systems (e.g. Windows Vista/Windows XP/Windows 7) and applications (e.g. word processing,
spreadsheet and database programs) have their own manuals, so please consult the appropriate manuals.
1
Overview 1 - 3
1
Shutdown
Note that you should always shut your computer down by choosing the Shut Down command from the Lock Button Menu
in Windows Vista. This will help prevent hard disk or system problems.
Quick Start Guide
System Startup
1.Remove all packing materials.
2.Place the computer on a stable surface.
3.Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports.
4.Attach the AC/DC adapter to the DC-In jack on the left of the computer, then plug the AC power cord into an
outlet, and connect the AC power cord to the AC/DC adapter.
5.Use one hand to raise the
hand (as illustrated in Figure 1 - 1 below) to support the base of the computer (Note: Never lift the computer by
the lid/LCD).
lid/LCD to a comfortable viewing angle (do not exceed 120 degrees);
use the other
Figure 1 - 1 - Opening the Lid/LCD/Computer with AC/DC Adapter Plugged-In
1 - 4 Overview
Quick Start Guide
Windows OS
In order to run Windows Vista/ Windows 7 without limitations or decreased performance, your computer requires a minimum 1GB of system memory (RAM).
Windows Vista Service Pack 2
Make sure you install Windows Vista Service Pack 2 (or a Windows Vista version which includes Service Pack 2) before installing any driver s. Go to the Microsoft website for download details, or contact your service center.
System Software
Your computer may already come with system software pre-installed. Where this is not the case, or where you
are re-configuring your computer for a different system, you will find that this manual refers to the Windows 7
operating system (however where necessary notes are provided on the Windows Vista OS).
1
Overview 1 - 5
1
Figure 1 - 2
LCD Panel Open
1.Built-In PC Camera
2.LCD
3.Power Button
4.Hot Key Buttons
5.Keyboard
6.Built-In Microphone
7.Touchpad &
Buttons
8.LED Indicators
9.Fingerprint Module
(Optional)
8
2
4
1
6
7
3
5
Wireless Device
Operation Aboard Aircraft
The use of any portable electronic
transmission devices aboard aircraft is usually prohibited. Make
sure the module(s) are OFF if you
are using the computer aboard aircraft.
Use the key combinations to toggle
power to the 3.75G/HSPA/WLAN/Bluetooth modules, and check the
LED indicator icon to see if the
modules are powered on or not
(see Table 1 - 4, on page 1 - 10/
Table 1 - 2, on page 1 - 7).
Touchpad Buttons (valid operation area)
7
8
9
Quick Start Guide
System Map: LCD Panel Open
1 - 6 System Map: LCD Panel Open
Quick Start Guide
1
LED Indicators
The LED indicators on the computer display helpful
information about the current status of the computer.
IconColorDescription
GreenHard Disk Activity
GreenNumber Lock Activated
GreenCaps Lock Activated
Green
Table 1 - 1 - LED Status Indicators
Scroll Lock Activated (to activate
press Fn & Scr Lk)
IconColorDescription
OrangeDC Power is Plugged In
GreenThe Computer is On
Blinking Green
OrangeThe Battery is Charging
GreenThe Battery is Fully Charged
Blinking Orange
Green
Orange
The Computer is in Sleep
Mode
The Battery Has Reached
Critically Low Power Status
The (optional) Wireless LAN
Module is Powered On
The (optional) Bluetooth
Module is Powered On
Table 1 - 2 - LED Power & Communication Indicators
LED Indicators 1 - 7
1
Other Keyboards
If your keyboard is
damaged or you just
want to make a
change, you can use
any standard USB keyboard. The system will
detect and enable it
automatically. However special functions/
hot-keys unique to the
system’s regular keyboard may not work.
NumLk & ScrLk
Hold down the Fn Key
and either NumLk or
ScrLk to enable number or scroll lock, and
check the LED indicator for status.
Special Characters
Some software applications allow the number-keys to be used with Alt to prod uce special characters.
These special characters can only be produced by using the numeric keypad. Regular number keys (in
the upper row of the keyboard) will not work. Make sure that NumLk is on.
Quick Start Guide
Hot Key Buttons & Keyboard
These buttons give instant access to the default Internet browser and e-mail program,
and allow you to toggle the Silent Mode on/off with one quick button press.
1 - 8 Hot Key Buttons & Keyboard
Hot KeyFunction
Activate the Default E-Mail Browser (Note that in Windows 7 this button
will only function after Outlook or Outlook Express are installed)
Activate the Default Internet Program
Toggle *Silent Mode (for power saving)
Table 1 - 3 - Hot Key Buttons
*When enabled, Silent Mode will reduce fan noise and save power consumption.
Note this may reduce computer performance.
Quick Start Guide
Numerical Keypad
Play/Pause Key
Function Keys
NumLk &
ScrLk Keys
Fn Key
Toggle Key
3.75G/HSPA Module
Power
Keyboard
The keyboard has a numerical keypad on the right for easy numeric data input, and features function keys to
allow you to change operational features instantly. See Table 1 - 4, on page 1 - 10 for full function key combination details.
1
Figure 1 - 3 - Keyboard
Keyboard 1 - 9
1
Quick Start Guide
Function/Hot Key Indicators
The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition
to the basic function key combinations; visual indicators are available when the hot key utility is installed.
KeysFunctionKeysFunction
Fn + ~Play/Pause (in Audio/Video Programs)Fn + F7Display Toggle
Fn +
Fn + F1
Fn + F2
Fn + F3
Fn + F4Sleep Toggle
Fn + F5/F6
3.5G Module Power Toggle
TouchPad Toggle
Turn LCD Backlight Off
(Press a key to or use TouchPad to turn on)
Mute Toggle
Volume Decrease/Increase
Table 1 - 4 - Function & Hot Key Indicators
1 - 10 Function/Hot Key Indicators
Fn + F8/F9
Fn + F10
Fn + F11
Fn + F12
*When enabled, Silent Mode will reduce fan noise and save power
Brightness Decrease/Increase
PC Camera Power Toggle
WLAN Module Power Toggle
Bluetooth Module Power Toggle
*Silent Mode Toggle
consumption. Note this ma y red uce computer performance.
System Map: Front & Left Views
Figure 1 - 4
Front & Left Views
1.LED Power & Communication Indicators
2.DC-In Jack
3.External Monitor
Port
4.RJ-45 LAN Jack
5.e-SATA Port
6.HDMI-Out Port
7.Vent/Fan Intake/
Outlet
8.2 * USB 2.0 Ports
9.ExpressCard Slot
(see page 2 - 7)
10. 7-in-1 Card Reader
2
5
4
1
6
3
7-in-1 Card Reader
The card reader allows you to use the most popular digital storage card formats:
MS Pro (Memory Stick Pro) / MS Duo (requires PC adapter) /
Mini SD (requires PC adapter) / RS MMC (requires PC adapter)
\
7
8
9
10
8
1
Quick Start Guide
1
System Map: Front & Left Views 1 - 11
1
Figure 1 - 5
Right & Rear Views
1.S/PDIF-Out Jack
2.Microphone-In
Jack
3.Headphone-Out
Jack
4.USB 2.0 Port
5.Optical Device
Drive Bay (for CD/
DVD Device - see
page 2 - 3)
6.RJ-11 Phone Jack
7.Security Lock Slot
8.Battery
Disk Eject Warning
Don’t try to eject a CD/DVD
while the system is accessing
it. This may cause the system
to “crash”. Stop the disk first
then eject it, or press the stop
button twice.
152
4
8
3
6
7
CD/DVD Emergency Eject
If you need to manually eject a CD/
DVD (e.g. due to an unexpected
power interruption) you may push the
end of a straightened paper clip into
the emergency eject hole. Do not use
a sharpened pencil or any object that
may break and become lodged in the
hole. Don’t try to remove a floppy
disk/CD/DVD while the system is accessing it. This may cause the system to “crash”.
Changing DVD Regional Codes
Go to the Control Panel and double-click Device
Manager (Hardware and Sound), then click the +
next to DVD/CD-ROM drives. Double-click on the
DVD-ROM device to bring up the Properties dialog
box, and select the DVD Region (tab) to bring up
the control panel to allow you to adjust the regional
code.
DVD region detection is device dependent, not OSdependent. You can select your module’s region
code 5 times. The fifth selection is permanent. This
cannot be altered even if you change your operating
system or you use the module in another computer.
Quick Start Guide
1 - 12 System Map: Right & Rear Views
System Map: Right & Rear Views
System Map: Bottom View
Figure 1 - 6
Bottom View
1.Battery
2.RAM & CPU Bay
Cover
3.Vent/Fan Intake/
Outlet
4.Hard Disk Bay
Cover
Note: the 3.75G/HSPA
USIM Card is located under the RAM & CPU Bay
Cover.
2
3
1
4
3
3
Battery Information
Always completely discharge, then fully charge, a
new battery before using it.
Completely discharge and
charge the battery at least
once every 30 days or after
about 20 partial discharges.
See “Battery Information”
on page 3 - 11 for full in-
structions.
CPU
The CPU is not a user serviceable part.
Overheating
To prevent your computer from overheating make sure nothing blocks the Vent/Fan Intake
while the computer is in use.
Quick Start Guide
1
System Map: Bottom View 1 - 13
1
Figure 1 - 7 - Start Menu & Control Panel
Click here to toggle Category View
Quick Start Guide
Windows 7 Start Menu & Control Panel
Most of the control panels, utilities and programs within Windows 7 (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk
drive, and a shortcut will usually be placed in the Start menu and/or the desktop. Right-click the Start menu
icon , and then select Properties if you want to customize the appearance of the Start menu.
In many instances throughout this manual you will see an instruction to open the Control Panel. The ControlPanel is accessed from the Start menu, and it allows you to configure the settings for most of the key features
in Windows (e.g. power, video, network, audio etc.). Windows 7 provides basic controls for many of the features,
however many new controls are added (or existing ones are enhanced) when you install the drivers. To see all
controls it may be necessary to toggle off Category View to view the control panel icons.
1 - 14 Windows 7 Start Menu & Control Panel
Quick Start Guide
Figure 1 - 8 - Start Menu & Control Panel
Click here to toggle Classic View
Windows Vista Start Menu & Control Panel
Windows Vista has a similar Start menu and set of control panels to that of Windows 7. To see all the Windows
Vista controls it may be necessary to toggle to Classic View on.
1
Windows Vista Start Menu & Control Panel 1 - 15
1
122
3
Quick Start Guide
Video Features - Win 7
You can switch display devices, and configure display options, from the Display control panel (in Appearances
and Personalization) in Windows 7. For more detailed video information see “Intel Video Driver Contro ls” on
page B - 1.
To access Display (Control Panel) and Screen Resolution in Windows:
1.Click Start and click Control Panel.
2.Click Display (icon) - In the Appearances and Personalization category.
3.Click Adjust Screen Resolution/Adjus t resolution.
OR
4.Alternatively you can right-click the desktop and select Screen resolution (see right).
5.Use the dropbox to select the screen Resolution (Figure 1 - 9 on page 1 - 17).
6.Click Advancedsettings (Figure 1 - 9 on page 1 - 17) to bring up the Advanced properties tabs.
To access the Intel(R) Graphics and Media Control Panel:
1.Click Advancedsettings (Figure 1 - 9 on page 1 - 17) in the Screen Resolution control panel in Windows.
2.Click the Intel(R)... tab (Figure 1 - 9 on page 1 - 17) and click Graphics Properties (button).
OR
3.Right-click the desktop and select Graphics Properties from the menu.
OR
4.Access the Intel(R) Graphics and Media Control Panel from the Windows control panel (see “Windows 7
Start Menu & Control Panel” on page 1 - 14).
1 - 16 Video Features - Win 7
Quick Start Guide
1
2
3
1
Figure 1 - 9 - Screen Resolution & Intel® Graphics and Media Control Panel
Video Features - Win 7 1 - 17
1
1
23345
Quick Start Guide
Video Features - Win Vista
You can switch display devices, and configure display options, from the Display Settings control panel (in Personalization) in Windows Vista as long as the appropriate Intel video driver is installed. For more detailed vid-
eo information see “Intel Video Driver Controls” on page B - 1.
To access Display Settings control panel in Windows Vista:
1.Click Start, and click Control Panel (or point to Settings and click Control Panel).
2.Click Adjust screen resolution under the Appearance and Personalization menu (or double-click
Personalization > Display Settings).
3.Move the slider to the preferred setting in Resolution: (Figure 1 - 10 on page 1 - 19).
4.Click the arrow, and scroll to the preferred setting In Colors: (Figure 1 - 10 on page 1 - 19).
5.Click Advanced Settings (button) (Figure 1 - 9 on page 1 - 17) and click Intel(R) GMA Driver for mobile
(tab).
To access the Intel(R) Graphics and Media Control Panel:
1.Click Advancedsettings (Figure 1 - 10 on page 1 - 19) in the Display Settings control panel in Windows.
2.Click Graphics Properties (button) (Figure 1 - 9 on page 1 - 17) to access the Intel GMA control panel.
OR
3.Right-click the desktop and select Graphics Properties from the menu.
OR
4.Click the icon (Figure 1 - 10 on page 1 - 19) in the taskbar and select Graphics Properties from the
menu.
OR
5.Access the Intel(R) Graphics and Media Control Panel from the Windows control p anel in Classic V iew (see
“Windows Vista Start Menu & Control Panel” on page 1 - 15).
1 - 18 Video Features - Win Vista
Quick Start Guide
1
2
4
3
5
1
Figure 1 - 10 - Display Settings & Intel® Graphics and Media Control Panel
Video Features - Win Vista 1 - 19
1
Quick Start Guide
Power Options
The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 1 - 13 ) allows you
to configure power management features for your computer. You can conserve power by means of power plans
and configure the options for the power button, sleep button, computer lid (when closed), display and sleep
mode from the left menu. Note that the Power saver plan may have an affect on computer performance.
Click to select one of the existing plans, or click Create a power plan in the left menu and select the options to
create a new plan. Click Change plan settings and click Change advanced power settings to access further configuration options.
Pay attention to the instructions on battery care in “Battery Information” on page 3 - 11.
1 - 20 Power Options
Figure 1 - 11 - Power Options
Features & Components
Chapter 2: Features & Components
Overview
Read this chapter to learn more about the following main features and components
of the computer:
•Hard Disk Drive
•Optical (CD/DVD) Device
•7-in-1 Card Reader
•ExpressCard Slot
•TouchPad and Buttons/Mouse
•Audio Features
•Adding a Printer
2
Overview 2 - 1
Features & Components
Power Safety
Before attempting to access any of the internal
components of your
computer please ensure
that the machine is not
connected to the AC
power, and that the machine is turned off. Also
ensure that all peripheral cables, including
phone lines, are disconnected from the computer.
Figure 2 - 1
Hard Disk Location
21
3
2
2 - 2 Hard Disk Drive
Hard Disk Drive
The hard disk drive is used to store your data in the computer. The hard disk can be
taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height
of 9.5 mm.
The hard disk is accessible from the bottom of your computer as seen below.For further details see “Upgrading the Hard Disk Drive” on page 6 - 4.
Features & Components
Sound Volume
Adjustment
How high the sound volume can be set depends
on the setting of the volume control within Win-dows. Click the Volume
icon on the taskbar to
check the setting (see
“Audio Features” on
page 2 - 12).
Figure 2 - 2
Optical Device
123
1
2
3
Optical (CD/DVD) Device
There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual device will depend on the module you purchased (see “Storage” on page C - 2). The
optical device is usually labeled “Drive D:” and may be used as a boot device if
properly set in the BIOS (see “Boot Menu” on page 5 - 12).
Loading Discs
To insert a CD/DVD, press the open button and carefully place a CD/DVD onto
the disc tray with label-side facing up (use just enough force for the disc to click onto
the tray’s spindle). Gently push the CD/DVD tray in until its lock “clicks” and you
are ready to start. The busy indicator will light up while data is being accessed,
or while an audio/video CD, or DVD, is playing. If power is unexpectedly interrupted, insert an object such as a straightened paper clip into the emergency eject hole
to open the tray.
2
Optical (CD/DVD) Device 2 - 3
Features & Components
CD Emergency Eject
If you need to manually
eject a CD (e.g. due to
an unexpected power
interruption) you may
push the end of a
straightened paper clip
into the emergency eject
hole. However please
do NOT use a sharpened pencil or similar
object that may break
and become lodged in
the hole.
Disk Eject Warning
Don’t try to remove a
CD/DVD while the system is accessing it. This
may cause the system
to “crash”.
2
2 - 4 Optical (CD/DVD) Device
Handling CDs or DVDs
Proper handling of your CDs/DVDs will prevent them from being damaged. Please
follow the advice below to make sure that the data stored on your CDs/DVDs can be
accessed.
Note the following:
•Hold the CD or DVD by the edges; do not touch the surface of the disc.
•Use a clean, soft, dry cloth to remove dust or fingerprints.
•Do not write on the surface with a pen.
•Do not attach paper or other materials to the surface of the disc.
•Do not store or place the CD or DVD in high-temperature areas.
•Do not use benzene, thinner, or other cleaners to clean the CD or DVD.
•Do not bend the CD or DVD.
•Do not drop or subject the CD or DVD to shock.
Features & Components
Table 2 - 1
DVD Regional Coding
DVD Regional Codes
To change the DVD regional codes see “Changing DVD Regional Codes” on
page 1 - 12.
.
RegionGeographical Location
1USA, Canada
2
3
4
5
6China
Korea, The Philippines, Indonesia,
2
DVD Regional Coding
Western Europe, Japan, South
Africa, Middle East & Egypt
South-East Asia, Taiwan, South
Hong Kong
South & Central America, Mexico,
Australia, New Zealand
N Korea, Russia, Eastern Europe,
India & Most of Africa
Optical (CD/DVD) Device 2 - 5
Features & Components
Card Reader Cover
Make sure you keep the
rubber cover provided in
the card reader when
not in use. This will help
prevent foreign objects
and/or dust getting in to
the card reader.
Figure 2 - 3
Left View
1.Card Reader
•MMC (MultiMedia Card)
•SD (Secure Digital)
•MS (Memory Stick)
•MS Pro (Memory Stick Pro)
•MS Duo (requires PC adapter*)
•Mini SD (requires PC adapter*)
•RS MMC (requires PC adapter*)
1
2
7-in-1 Card Reader
The card reader allows you to use some of the latest digital storage cards. Push the
card into the slot and it will appear as a removable device, and can be accessed in
the same way as your hard disk (s). Make sure you install the Card Reader driver
(see “CardReader” on page 4 - 6).
*Note: The PC adapters are usually supplied with these cards.
2 - 6 7-in-1 Card Reader
Features & Components
ExpressCard
Slot Cover
Make sure you keep the
rubber cover provided in
the ExpressCard slot
when not in use. This
will help prevent foreign
objects and/or dust getting in to the ExpressCard Slot.
Figure 2 - 4
Left View
1.Express Card
Slot
Figure 2 - 5
Inserting &
Removing Express
Cards
1
ExpressCard Slot
The computer is equipped with an ExpressCard/34/54 slot that reads Express Card/
34 and ExpressCard/54 formats. ExpressCards are the successors to PCMCIA (PC
Cards). Make sure you install the Card Reader driver
- 6
).
ExpressCard/54 is used for applications which require a larger interface slot, e.g.
CompactFlash card reader. The number denotes the card width; 54mm for the Express Card/54 and 34mm for the ExpressCard/34.
Inserting and Removing ExpressCards
•Align the ExpressCard with the slot and push it in until it locks into place (as
pictured in the generic figure below).
•To remove an ExpressCard, simply press the card to eject it.
(see
“CardReader” on page 4
2
ExpressCard Slot 2 - 7
Features & Components
Mouse Driver
If you are using an external mouse your operating system may be
able to auto-configure
your mouse during its
installation or only enable its basic functions.
Be sure to check the
device’s user documentation for details.
Figure 2 - 6
Mouse Properties
2
TouchPad and Buttons/Mouse
The TouchPad is an alternative to the mouse; however, you can also add a mouse to
your computer through one of the USB ports. The TouchPad buttons function in
much the same way as a two-button mouse.
Once you have installed the TouchPad driver (see “TouchPad” on page 4 - 6) you
can configure the functions by double-clicking the TouchPad driver icon on the
taskbar. You may then configure the TouchPad tapping, buttons, scrolling, pointer
motion and sensitivity options to your preferences. You will find further information
at www.synaptics.com.
2 - 8 TouchPad and Buttons/Mouse
Features & Components
Show Video
You can get a clearer
view of the gestures involved by clicking the
Show Video option for
each gesture item.
Select the gesture (Pinch
Zoom, Rotating, Three
Fingers Down and
Three Finger Flick) in the
Device Settings > Settings left tree menu
and click the Show Video
button to see the demonstration video.
For more details on any of
the gestures see the help
in the lower part of the
right menu window.
Figure 2 - 7
Mouse Properties -
Device Settings
Gestures and Device Settings
The Synaptics Gestures Suite application allows you to use a specific gesture (action) on the surface of the TouchPad to perform specific actions to manipulate documents, objects and applications.
You can configure the settings from the Device Settings tab in Mouse Properties:
1.Click
2.Click Mouse (Hardware and Sound).
3.Click Device Settings (tab) and click Settings.
4.Use the menu tree on the left to access the user configurable settings.
Start
, and click
Control Panel
(or point to
Settings
and click
Control Panel
2
).
TouchPad and Buttons/Mouse 2 - 9
Features & Components
Figure 2 - 8
Scrolling Gesture
Figure 2 - 9
Zooming Gesture
2
Scrolling
The Two-Finger scrolling feature works in most scrollable windows an d allows you
to scroll horizontally and vertically. Place two fingers, slightly separated, on the
TouchPad surface and slide both fingers in the direction required (in a straight continuous motion).
Zooming
The Pinch Zoom gesture can be used to perform the same function as a scroll wheel
in Windows applications that support CTRL + scroll wheel zoom functionality.
Place two fingers on the TouchPad (for best results use the tips of the fingers) and
slide them apart to zoom in, or closer together to zoom out.
2 - 10 TouchPad and Buttons/Mouse
Rotating
Figure 2 - 10
Rotating Gesture
Figure 2 - 11
Flick/Press
Gesture
Use the Pivot Rotate gesture to rotate objects (e.g. photos) in 90 degree increments.
Place a finger down on the left “target” zone and keep it stationary. Place another
finger near the middle of the TouchPad and slide it in a circular motion around the
stationary finger (clockwise or counterclockwise) to rotate the object.
Three Finger-Flick/Three Fingers Down (Press)
The Three Finger-Flick gesture may be used to enhance navigation with a variety of
applications such as browsing the Internet or scrolling through a photo viewer. The
Three Fingers Down gesture may be used to launch user-selectable applications.
Features & Components
2
TouchPad and Buttons/Mouse 2 - 11
Features & Components
Sound Volume
Adjustment
The sound volume level
is set using the volume
control within Windows
(and the volume function keys on the computer). Click the volume
icon in the taskbar to
check the setting.
Figure 2 - 12
Realtek Audio
Manager
Right-click the icon
to access the menu
above.
2
Audio Features
You can configure the audio options on your computer from the Sound control
panel in Windows, or from the Realtek HD Audio Manager icon in the taskbar/
control panel (right-click the taskbar icon bring up an audio menu). The volume
may also be adjusted by means of the Fn + F5/F6 key combination.
2 - 12 Audio Features
Features & Components
Parallel Printer
After setting up the printer attach the parallel cable to the printer.
Connect the printer’s
parallel cable to the Parallel to USB converter,
and then plug the converter into the USB port.
Turn ON the printer,
then turn ON the computer.
Windows will identify the
printer and either load
one of its own drivers or
ask you to supply one.
Follow the on-screen instructions.
Adding a Printer
The most commonly used peripheral is a printer. The following conventions will
help you to add a printer; however it is always best to refer to the printer manual for
specific instructions and configuration options.
USB Printer
Most current printers have a USB interface connection. You may use any one of the
ports to connect the printer.
Install Instructions:
1.Set up the printer according to its instructions (unp acking, p aper tr ay, toner/ink car-
tridge etc.).
2.Turn ON the computer.
3.Turn ON the printer.
4.Connect the printer’s USB cable to one of the USB ports on the computer.
5.Windows will identify the printer and either load one of its own drivers or ask you
to supply one. Follow the on-screen instructions.
Parallel Printer
This is still a very common type of printer. The install instructions are in the sidebar,
however you will need to purchase a parallel to USB converter.
2
Adding a Printer 2 - 13
Features & Components
2
2-14
Chapter 3: Power Management
OS Note
Power management
functions will vary slightly depending on your
operating system. For
more information it is
best to refer to the user’s
manual of your operating system.
Power Management
Overview
To conserve power, especially when using the battery, your computer power management conserves power by controlling individual components of the computer
(the monitor and hard disk drive) or the whole system. This chapter covers:
•The Power Sources
•Turning On the Computer
•Power Plans
•Power-Saving States
•Configuring the Power Buttons
•Battery Information
The computer uses enhanced power saving techniques to give the operating system
(OS) direct control over the power and thermal states of devices and processors. For
example, this enables the OS to set devices into low-power states based on user settings and information from applications.
3
Overview 3 - 1
3
Silent Mode
Use the key to toggle Silent Mode to reduce fan noise and save
power consumption.
Note this may reduce
computer performance.
Power Management
The Power Sources
The computer can be powered by either an AC/DC adapter or a battery pack.
AC/DC Adapter
Use only the AC/DC adapter that comes with your computer. The wrong type of AC/
DC adapter will damage the computer and its components.
3 - 2 The Power Sources
1.Attach the AC/DC adapter to the DC-in jack on the left of the computer.
2.Plug the AC power cord into an outlet, and then conne ct the AC power co rd to the
AC/DC adapter.
3.Raise the lid/LCD to a comfortable viewing angle.
4.Press the power button to turn “On”.
Battery
The battery allows you to use your computer while you are on the road or when an
electrical outlet is unavailable. Battery life varies depending on the applications and
the configuration you're using. To increase battery life, let the battery dischargecompletely before recharging (see “How do I completely discharge the battery?”
on page 3 - 15).
We recommend that you do not remove the battery. For more information on the battery, please refer to “Battery Information” on page 3 - 11.
Turning On the Computer
Forced Off
If the system “hangs”,
and the Ctrl + Alt + Del
key combination doesn’t
work, press the power
button for 4 seconds, or
longer, to force the system to turn itself off.
Power Button as
Stand by or
Hibernate Button
You can use the OS’s
“Power Options” control
panel to set the power
button to send the system into Stand by or Hibernate mode (see your
OS’s documentation, or
“Configuring the Power Buttons” on page 3
- 9 for details).
Shut Down
Note that you should always shut your computer down by choosing the Shut Down command from the bottom right of the Start menu in Windows. This will help prevent hard disk
or system problems.
Win 7
Win Vista
Now you are ready to begin using your computer. To turn it on simply press the power button on the front panel.
When the computer is on, you can use the power button as a Stand by/Hibernate/
Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and
holding the power button for longer than this will shut the computer down). Use
Power Options in the Windows control panel to configure this feature.
Power Management
3
Turning On the Computer 3 - 3
Power Management
Resuming
Operation
See Table 3 - 1, on
page 3 - 10 for informa-
tion on how to resume
from a power-saving
state.
Password
It is recommended that
you enable a password
on system resume in order to protect your data.
Figure 3 - 1
Power Plan
Advanced Settings
(Win 7)
Power Plans
The computer can be configured to conserve power by means of power plans. You
3
can use (or modify) an existing power plan, or create a new one.
3 - 4 Power Plans
The settings may be adjusted to set the display to turn off after a specified time, and
to send the computer into Sleep after a period of inactivity.
Click Change plan settings and then click Change advanced power settings to access further configuration options in Advanced Settings.
Each Windowspower plan will also adjust the processor performance of your ma-
Figure 3 - 2
Power Plans (Win 7)
Click to Show/Hide
additional
power plans
chine in order to save power. This is worth bearing in mind if you are experiencing
any reduced performance (especially under DC/battery power).
Choose High performance (you may need to click Show additional plans to view
the High performance plan) for maximum performance when the computer is powered from an AC power source. Choose the Power saver (bear in mind that this
scheme may slow down the overall performance of the computer in order to save
power) for maximum power saving when the computer is battery (DC power) powered.
Power Management
3
Power Plans3-5
Power Management
Figure 3 - 3
Power Plan
Advanced Settings
(Win Vista)
3
3 - 6 Power Plans
Power-Saving States
You can use power-saving states to stop the computer’s operation and restart where
you left off. Win 7/ Win Vista use the Sleep, Hibernate and Shut Down power-saving states.
Sleep
In Sleep all of your work, settings and preferences are saved to memory before the
system sleeps. When you are not using your computer for a certain length of time,
which you specify in the operating system, it will enter Sleep to save power.
The PC wakes from Sleep within seconds and will return you to where you last left
off (what was on your desktop) without reopening the application(s) and file( s) you
last used.
If your mobile PC in Sleep is running on battery power the system will use only a
minimum amount of power. After an extended period the system will save all the
information to the hard disk and shut the computer down before the battery becomes
depleted.
Power Management
3
Power-Saving States 3 - 7
Power Management
Win Vista Power
Button
The Win Vista Power
Button in the Start
Menu (in Classic View
use the Shut Down button ) can be used to
send the computer into
a power-saving state.
Figure 3 - 4
Start Menu Power
Win 7WinVista
3
Hibernate
Hibernate uses the least amount of power of all the power-saving states and saves
all of your information on a part of the hard disk before it turns the system off. If a
power failure occurs the system can restore your work from the hard disk; if a power
failure occurs when work is saved only to memory, then the work will be lost. Hi-bernate will also return you to where you last left off within seconds. You should
put your mobile PC into Hibernate if you will not use the computer for a period of
time, and will not have the chance to charge the battery.
Shut down
You should Shut down the computer if you plan to install new hardware (don’t forget to remove the battery and follow all the safety instructions in Chapter 6), plan
to be away from the computer for several days, or you do not need it to wake up and
run a scheduled task. Returning to full operation from Shut down takes longer than
from Sleep or Hibernate.
3 - 8 Power-Saving States
Configuring the Power Buttons
Password
Protection
It is recommended that
you enable a password
on wake up in order to
protect your data.
However you can disable this setting from the
Power Options menu
by clicking Require a
password on wakeup
in the left menu, and selecting the options (click
Change settings that
are currently unavailable).
Figure 3 - 5
Power Options
Define Power
Buttons
Win 7
WinVista
The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the
computer in to a power-saving state. Click Choose what the power buttons do on
the left menu in Power Options to bring up the menu.
Power Management
3
Configuring the Power Buttons 3 - 9
Power Management
Closing the Lid
If you have chosen to
send the computer to
Sleep when the lid is
closed, raising the lid
will wake the system up.
Table 3 - 1
Resuming
Operation
3.75G/HSPA
Modules & System
Wake Up
Note that the 3.75G modules
DO NOT
support
system wake up on
3.75G/HSPA modem activity.
Power Button
When the computer is on, you can use the power button as a Sleep/Hibernate/Shut Down
hot key button when it is pressed for less than 4 seconds (pressing and holding the power
button for longer than this will force the computer to shut down).
Resuming Operation
You can resume operation from power-saving states by pressing the power button,
or in some cases pressing the sleep button (Fn + F4 key combo).
3
Power Status
Power OffOffPress the Power Button
SleepBlinking Green
Hibernate
Display Turned OffGreenPress a Key or Move the Mouse/Touchpad
Icon Color
Off (battery)
Orange (AC/DC adapter)
3 - 10 Configuring the Power Buttons
To Resume
Press the Power Button
Press the Sleep Button (Fn + F4 Key Combo)
Press the Power Button
Battery Information
Low Battery
Warning
When the battery is critically low, immediately
connect the AC/DC
adapter to the computer
or save your work, otherwise, the unsaved
data will be lost when
the power is depleted.
Figure 3 - 6
Battery Icon
(Taskbar) & Battery
Advanced Settings
Win 7
WinVista
Follow these simple guidelines to get the best use out of your battery.
Battery Power
Your computer’s battery power is dependent upon many factors, including the programs you are running, and peripheral devices attached. You can set actions to be
taken (e.g. Shut down, Hibernate etc.), and set critical and low battery levels from
power plan Change plan settings > Change advanced power settings (see Figure
3 - 3 on page 3 - 6).
Click the battery icon in the taskbar to see the current battery level and charge
status.
Power Management
3
Battery Information 3 - 11
Power Management
Wireless Hot Keys
The computer’s wireless
function keys will not function properly if Wireless is
turned OFF in the Win-
dows Mobility Center
control panel.
The wireless indicators
may show that
the WLAN module is powered on, however if wireless is OFF in the Mobility
Center, the module will not
be powered on.
Make sure that Wireless is
ON in the Mobility Center to
ensure proper function key
behavior.
Figure 3 - 7
Windows Mobility
Center
Windows Mobility
Center
The Windows Mobility Center control pan-
el provides an easy
point of access for information on battery
status, power plans
used and wireless device status etc.
Make sure Wireless is ON to ensure proper function key behavior.
3
Conserving Battery Power
•Use a power plan that conserves power (e.g Power saver), however note that
this may have an affect on computer performance.
•Lower the brightness level of the LCD display. The system will decrease LCD
brightness slightly to save power when it is not powered by the AC/DC adapter.
•Reduce the amount of time before the display is turned off.
•Close wireless, Bluetooth, modem or co mmunication applications when they are
not being used.
•Disconnect/remove any unnecessary external devices e.g. USB devices,
ExpressCards etc.
3 - 12 Battery Information
Battery Life
Battery life may be shortened through improper maintenance. To optimize the life
and improve its performance, fully discharge and recharge the battery at least
once every 30 days.
We recommend that you do not remove the battery yourself. If you do need to remove the battery for any reason see “Removing the Battery” on page 6 - 3.
New Battery
Always completely discharge, then fully charge, a new battery (see “Battery FAQ”
on page 3 - 15 for instructions on how to do this).
Recharging the Battery with the AC/DC Adapter
The battery pack automatically recharges when the AC/DC adapter is attached and
plugged into an electrical outlet. If the computer is powered on, and in use, it will
take several hours to fully recharge the battery. When the computer is turned off but
plugged into an electrical outlet, battery charge time is less. (Refer to “LED Indica-
tors” on page 1 - 8 for information on the battery charge status, and to “Battery Information” on page 3 - 11 for more information on how to maintain and properly
recharge the battery pack.)
Power Management
3
Battery Information 3 - 13
Power Management
Caution
Danger of explosion if
battery is incorrectly replaced.
Replace only with the
same or equivalent type
recommended by the
manufacturer. Discard
used battery according
to the manufacturer’s instructions.
Damaged Battery Warning
Should you notice any physical defects (e.g. the battery is bent ou t of shape after being
dropped), or any unusual smells emanating from the notebook battery, shut your computer
down immediately and contact your service center. If the battery has bee n d roppe d we do
not recommend using it any further, as even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire . It is
recommended that you replace your computer battery every two years.
Proper handling of the Battery Pack
•DO NOT disassemble the battery pack under any circumstances
•DO NOT expose the battery to fire or high temperatures, it may explode
3
•DO NOT connect the metal terminals (+, -) to each other
3 - 14 Battery Information
Battery FAQ
Figure 3 - 8
Power Plan Create
How do I completely discharge the battery?
Use the computer with battery power until it shuts down due to a low battery. Don’t
turn off the computer even if a message indicates the battery is critically low, just let
the computer use up all of the battery power and shut down on its own.
1.Save and close all files and applications.
2.Create a power plan for discharging the battery and set all the options to Never.
Power Management
3
Battery Information 3 - 15
Power Management
Figure 3 - 9
Change Plan
Settings / Change
Advanced Power
Settings
3
3.Click Change plan settings (after creating it) and click Change plan settings >
Change advanced power settings.
3 - 16 Battery Information
4.Scroll down to Battery and click + to expand the ba ttery options.
Figure 3 - 10
Power Options
Advanced Settings -
Battery
5.Choose the options below (click Yes if a warning appears):
•Low battery levels = 0%
•Critical battery Levels = 0%
•Low battery action = Do Nothing
•Critical battery action (On battery) = Shut Down
•Critical battery action (Plugged in) = Do Nothing
Power Management
3
Battery Information 3 - 17
Power Management
How do I fully charge the battery?
When charging the battery, don’t stop until the LED charging indicator light changes
from orange to green.
3
How do I maintain the battery?
Completely discharge and charge the battery at least once every 30 days or after
about 20 partial discharges.
3 - 18 Battery Information
Drivers & Utilities
Chapter 4: Drivers & Utilities
This chapter deals with installing the drivers and utilities essential to the operation or improvement of some of
the computer’s subsystems. The system takes advantage of some newer hardware components for which the latest versions of most available operating systems haven’t built in drivers and utilities. Thus, some of the system
components won’t be auto-configured with an appropriate driver or utility during operating system installation.
Instead, you need to manually install some system-required drivers and utilities.
What to Install
The Device Drivers & Utilities + User’s Manual disc contains the drivers and utilities necessary for the proper
operation of the computer.
Module Driver Installation
The procedures for installing drivers for the Wireless LAN, 3.75G/HSPA, Fingerprint and PC Camera modules are provided in “Modules & Options” on page 7 - 1.
Make sure any modules (e.g. WLAN, 3.75G/HSPA or PC Camera) are ON before installing the appropriate driv-
er.
1.Check the driver installation order from Table 4 - 1, on page 4 - 3 (the drivers must be installed in this order)
which is the same as that listed in the Drivers Installer menu.
2.Click to select the driver you wish to install, after installing each driver it will become grayed out. If you need to
reinstall any driver, click the Unlock button (you should uninstall the driver first).
3.Follow the instructions for each individual driver installation procedure as listed on the following pages.
4 - 2 Driver Installation
Driver - Windows 7/Windows Vista(SP2)
Windows Vista Service Pack 2
Make sure you install Windows Vista Service Pack 2
(or a Windows Vista version which includes Service
Pack 2) before installing any drivers. Go to the Microsoft website for download details, or contact your service
center.
Click Browse CD/DVD (button) in the Drivers Installer application and browse to the executable file in the
appropriate driver folder.
Windows Update
After installing all the drivers make sure you enable
Windows Update in order to get all the latest security
updates etc. (all updates will include the latest hotfixes
from Microsoft). See “Windows Update” on page 4 -
7 for instructions.
4
3.75G/HSPA Module
Fingerprint Reader ModulePage 7 - 40
PC Camera ModulePage 7 - 46
Table 4 - 1 - Driver Installation
Page 7 - 24
Page 7 - 33
Driver Installation 4 - 3
Drivers & Utilities
Updating/Reinstalling Individual Drivers
If you wish to update/reinstall individual drivers it
may be necessary to uninstall the original driver.To do
this go to the Control Panel in the Windows OS and
double-click the Programs and Features icon (Pro-
4
grams > Uninstall a program). Click to select the
driver (if it is not listed see below) and click Uninstall,
and then follow the on screen prompts (it may be necessary to restart the computer). Reinstall the driver as
outlined in this chapter.
If the driver is not listed in the Programs and Fea-tures menu:
1.Click Start, and click Control Panel (or point to
Settings and click Control Panel).
2.Double-click Device Manager (Hardware and
Sound > Device Manager).
3.Double-click the device you wish to update/reinstall
the driver for (you may need to click “+” to expand
the selection).
4.Click Driver (tab) and click the Update Driver or
Uninstall button and follow the on screen prompts.
User Account Control (Win Vista)
If a User Account Control prompt appears as part of
the driver installation procedure, click Continue or
Allow, and follow the installation procedure as directed.
Windows Security Message
If you receive a Windows security message as part of
the driver installation process. Just click “Install thisdriver software anyway” or “Install” to continue the
installation procedure.
You will receive this message in cases where the driver has been released after the version of Windows you
are currently using. All the drivers provided will have
already received certification for Windows.
4 - 4 Driver Installation
Drivers & Utilities
Driver Installation General Guidelines
The driver installation procedure outlined in this
Chapter (and in Chapter 7 Options & Modules),
are accurate at the time of going to press.
Drivers are always subject to upgrade and revision
so the exact procedure for certain drivers may differ
slightly. As a general guide follow the default on
screen instructions for each driver (e.g. Next > Next> Finish) unless you are an advanced user. In many
cases a restart is required to install the driver.
New Hardware Found
If you see the message “New Hardware Found” dur-
ing the installation procedure (other than when out-lined in the driver install procedure), click Cancel
to close the window, and follow the installation procedure.
Driver Installation Procedure
Insert the Device Drivers & Utilities + User’s Manual
disc and click Install Drivers (button).
Chipset
1.Click 1.Install Chipset Driver > Yes.
2.Click Next > Yes > Next > Next.
3.Click Finish to restart the computer.
Video
1.Click 2.Install Video Driver > Yes.
2.Click Next > Yes > Next > Next.
3.Click Finish to restart the computer.
Audio
1.Click 3.Install Audio Driver > Yes.
2.Click Next.
3.Click Finish to restart the computer.
4
Driver Installation 4 - 5
Drivers & Utilities
Modem Country Selection
Go to the Phone andModem (Options) control pa nel
(Hardware and Sound) and make sure the modem
country selection is appropriate for you.
Modem
1.Click 4.Install Modem Driver > Yes.
2.Click OK.
3.Click OK to restart the computer.
4.The modem is ready for dial-up configuration.
4
LAN
1.Click 5.Install LAN Driver > Yes.
2.Click Install.
3.Click Finish.
4.The network settings can now be configured.
TouchPad
1.Click 6.Install Touchpad Driver > Yes.
2.Click Next.
3.Click the button to accept the license, and then
click Next.
4.Click Finish > Restart Now to restart the com-
puter.
CardReader
1.Click 7.Install CardReader Driver > Yes.
2.Click Install.
3.Click Finish.
Hot Key
1.Click 8.Install Hotkey Driver > Yes.
2.Click Next > Next.
3.Click Finish > Finish to restart the computer.
It is recommended you now install the MEI Drive (see
over).
4 - 6 Driver Installation
MEI Driver
Windows Update
After installing all the drivers make sure you enable Windows Update in order to get all the latest security up-
dates etc. (all updates will include the latest hotfixes
from Microsoft).
To enable Windows Update make sure you are con-nected to the internet:
1.Click Start, and click Control Panel (or point
to Settings and click Control Panel).
2.Click Check for updates (Security), or
double-click Security Center and click
Windows Update.
3.Double-click Check for updates (button).
4.The computer will now check for updates
(you need to be connected to the internet).
5.Click Install now (button) to install the
updates.
1.Insert the Device Drivers & Utilities + User’s
Manual disc into the CD/DVD drive.
2.Click Option Drivers (button).
3.Click 2.Install MEI Driver > Yes.
4.Click Next > Yes > Next > Next.
5.Click Finish.
Windows Experience Index
After the drivers are installed follow this procedure to
ensure an accurate rating from the Windows Experi-ence Index:
1.Click Start, and click Control Panel.
2.Click Performance Information and Tools
(System and Security > System> Check the Windows Experience Index).
3.Click “Rate this computer”.
4.The computer will take a few minutes to assess
the system performance.
5.Close the control panel.
Drivers & Utilities
4
Driver Installation 4 - 7
Drivers & Utilities
Optional Drivers
See the pages indicated for the driver installation procedures for any modules included in your purchase option.
Note: The operating system is the default setting for
Bluetooth control in Windows Vista, and does not re-
quire a driver. See “Bluetooth Module” on page 7 - 2
for configuration instructions.
Wireless LAN Module
See the introduction in “Wireless LAN Module” on
page 7 - 11, and check the installation procedure.
3.75G/HSPA Module
See the introduction in “3.75G/HSPA Module” on
page 7 - 20, and check the installation procedure.
Fingerprint Reader Module
See the introduction in “Fingerprint Reader Module”
on page 7 - 40, and check the installation procedure.
PC Camera Module
See the introduction in “PC Camera Module” on
page 7 - 45, and check the installation procedure.
4 - 8 Driver Installation
Chapter 5: BIOS Utilities
BIOS Settings
Warning
Incorrect settings can
cause your system to
malfunction. To correct
mistakes, return to Set-
up and restore the Setup Defaults with <F9>.
Overview
This chapter gives a brief introduction to the computer’s built-in software:
Diagnostics: The POST (Power-On Self Test)
Configuration: The Setup utility
If your computer has never been set up, or you are making impo rtant changes to the
system (e.g. hard disk setup), then you should review this chapter first and note the
original settings found in Setup. Even if you are a beginner, keep a record of the settings you find and any changes you make. This information could be useful if your
system ever needs servicing.
There is one general rule: Don’t make any changes unless you are sure of what youare doing. Many of the settings are required by the system, and changing them could
cause it to become unstable or worse. If you have any doubts, consult your service
representative.
BIOS Utilities
5
Overview 5 - 1
BIOS Utilities
POST Screen
1.BIOS information
2.CPU type
3.Memory status
4.Enter Setup prompt
appears only during
POST
Note:
The
POST
screen
as pictured right is for
guideline purposes only.
The
POST
screen on
your computer may appear slightly different. If
you disable the
Boot-
time Diagnostic Screen
,
the POST screen will not
appear.
Figure 5 - 1
POST Screen
1
2
3
4
5
The Power-On Self Test (POST)
Each time you turn on the computer, the system takes a few seconds to conduct a
POST, including a quick test of the on-board RAM (memory).
As the POST proceeds, the computer will tell you if there is anything wrong. If there
is a problem that prevents the system from booting, it will display a system summary
and prompt you to run Setup.
If there are no problems, the Setup prompt will disappear and the system will load
the operating system. Once that starts, you can’t get into Setup without rebooting.
5 - 2 The Power-On Self Test (POST)
Failing the POST
Errors can be detected during the POST. There are two categories, “fatal” and “nonfatal”.
Fatal Errors
These stop the boot process and usually indicate there is something seriously wrong
with your system. Take the computer to your service representative or authorized
service center as soon as possible.
Non-Fatal Errors
This kind of error still allows you to boot. You will get a message identifying the
problem (make a note of this message!) followed by the prompt:
•Press <F1> to resume
•<F2> to enter Setup
Press F1 to see if the boot process can continue. It may work, without the correct
configuration.
BIOS Utilities
5
Press F2 to run the Setup program and try to correct the problem. If you still get an
error message after you change the setting, or if the “cure” seems even worse, call
for help.
The Power-On Self Test (POST) 5 - 3
BIOS Utilities
The Setup Program
The Phoenix Setup program tells the system how to configur e itself and manage ba-
sic features and subsystems (e.g. port configuration).
Entering Setup
To enter Setup, turn on the computer and press F2 during the POST. The prompt
5
(Press F2 to Enter Setup) seen on page 5 - 2 is usually present for a few seconds
after you turn on the system. If you get a “Keyboard Error”, (usually because you
pressed F2 too quickly) just press F2 again.
If the computer is already on, reboot using the Ctrl + Alt + Delete combination and
then hold down F2 when prompted. The Setup main menu will appear.
5 - 4 The Setup Program
Setup Screens
Setup Menus
The Setup menus
shown in this section are
for reference only. Your
computer’s menus will
indicate the configuration appropriate for your
model and options.
The following pages contain additional advice on portions of the Setup.
Along the top of the screen is a menu bar with menu headings. When you select a
heading, a new screen appears. Scroll through the features listed on each screen to
make changes to Setup.
BIOS Utilities
Instructions on how to navigate each screen are in the box along the bottom of the
screen. If these tools are confusing, press F1 to call up a General Help screen, and
then use the arrow keys to scroll up or down the page.
The Item Specific Help on the right side of each screen explains the highlighted
item and has useful messages about its options.
If you see an arrow next to an item, press Enter to go to a sub-menu on that subject. The sub-menu screen that appears has a similar layout, but the Enter key may
execute a command.
5
The Setup Program 5 - 5
BIOS Utilities
Figure 5 - 2
Main Menu
Main Menu
5
System Time & Date (Main Menu)
The hour setting uses the 24-hour system (i.e., ØØ = midnight; 13 = 1 pm). If you
can change the date and time settings in your operating system, you will also change
these settings. Some applications may also alter data files to reflect these changes.
5-6Main Menu
SATA Port 1/2 (Main Menu)
Pressing Enter opens the sub-menu to show the configuration of an HDD/optical de-
vice on the computer’s SATA Port 1/2. Use the Auto (Type:) setting to have the
items configured automatically for you.
System Memory (Main Menu)
This item contains information on the system memory, and is not user configurable.
The system will auto detect the amount of memory installed.
This item contains information on the current BIOS and firmware versions.
BIOS Utilities
5
Main Menu 5 - 7
BIOS Utilities
Figure 5 - 3
Advanced Menu
Advanced Menu
5
Legacy USB Support (Advanced Menu)
Use this menu item to enable/disable the support for Legacy Universal Serial Bus in
non-USB aware operating systems.
5 - 8 Advanced Menu
Boot-time Diagnostic Screen (Advanced Menu)
Use this menu item to enable/disable the Boot-time Diagnostic Screen or Power-On
Self Test (see “The Power-On Self Test (POST)” on page 5 - 2).
Legacy OS Boot: (Advanced Menu)
Enable this item to support only system boot from the Legacy OS (e.g Windows Vista). If disabled the system will attempt to boot from the EFI (Extensible Firmware
Interface) before the Legacy OS.
Battery Low Alarm Beep(Advanced Menu)
Use this menu item to enable/disable the audible warning when the battery has
reached low power status.
BIOS Utilities
5
Advanced Menu 5 - 9
BIOS Utilities
Security Menu
The changes you
make here affect the
access to the Setup
utility itself, and also
access to your machine as it boots up after you turn it on.
These settings do not
affect your machine or
network passwords
which will be set in
your software OS.
Figure 5 - 4
Security Menu
Security Menu
5
5 - 10 Security Menu
Set Supervisor Password (Security Menu)
You can set a password for access to the PhoenixBIOS SetupUtility. This will not
affect access to the computer OS, (only the PhoenixBIOS Setup Utility).
Set User Password (Security Menu)
Password Warning
If you set a boot password (Password on boot
is “Enabled“), NEVER
forget your password.
The consequences of
this could be serious. If
you cannot remember
your boot password you
must contact your vendor and you may lose all
of the information on
your hard disk.
You can set a password for user mode access to the PhoenixBIOS SetupUtility.
This will not affect access to the computer OS, (only the Setup utility) unless you
choose to set a Password on Boot (see below). Many menu items in the Phoenix-BIOS SetupUtility cannot be modified in user mode. You can only set the user
password after you have set the supervisor password.
Password on boot: (Security Menu)
Specify whether or not a password should be entered to boot the computer (you may
only set a password on boot if a supervisor password is enabled). If “Enabled”is selected, only users who enter a correct password can boot the system (see the
warning in the sidebar). The default setting is “Disabled”.
Note: To clear existing passwords press Enter and type the existing password, then
press Enter for the new password (without typing any password entry) and Enter
again to confirm the password clearance.
BIOS Utilities
5
Security Menu 5 - 11
BIOS Utilities
Figure 5 - 5
Boot Menu
Boot Menu
5
When you turn the computer on it will look for an operating system (e.g. Windows
Vista) from the devices listed in this menu, and in this priority order. If it cannot
find the operating system on that device, it will try to load it from the next device in
the order specified in the Boot priority order. Item specific help on the right is
available to help you move devices up and down the order.
5 - 12 Boot Menu
Exit Menu
Figure 5 - 6
Exit Menu
Choosing to Discard Changes, or Exit Discarding Changes, will wipe out any
changes you have made to the Setup. You can also choose to restore the original Set-up defaults that will return the Setup to its original state, and erase any previous
changes you have made in a previous session.
BIOS Utilities
5
Exit Menu 5 - 13
BIOS Utilities
5
5-14
Chapter 6: Upgrading The Computer
Warranty Warning
Please check with your
service representative
before undertaking any
upgrade procedures to
find out if this will VOID
your warranty.
Overview
This chapter contains information on upgrading the computer. Follow the steps outlined to make the desired upgrades. If you have any trouble or problems you can contact your service representative for further help. Before you begin you will need:
•A small crosshead or Phillips screwdriver
•A small regular slotted (flathead) screwdriver
•An antistatic wrist strap
Before working with the internal components you will need to wear an antistatic
wrist strap to ground yourself because static electricity may damage the components.
The chapter includes:
•Removing the Battery
•Upgrading the Hard Disk Drive
•Upgrading the Optical (CD/DVD) Device
•Upgrading the System Memory (RAM)
Please make sure that you review each procedure before you perform it.
Upgrading The Computer
6
Overview 6 - 1
Upgrading The Computer
Power Safety
Warning
Before you undertake
any upgrade procedures, make sure that
you have turned off the
power, and disconnected all peripherals and
cables (including telephone lines). It is advisable to also remove your
battery in order to prevent accidentally turning
the machine on.
Removal Warning
When removing any cover(s) and screw(s) for the purposes of device upgrade, remember
to replace the cover(s) and screw(s) before turning the computer on.
6
When Not to Upgrade
These procedures involve opening the system’s case, adding and sometimes replacing parts.
You should not perform any of these upgrades if:
•Your system is still under warranty or a service contract
•You don’t have all the necessary equipment
•You’re not in the correct environment
•You doubt your abilities
Under any of these conditions, contact your service representative to purchase or re-
place the component(s).
Upgrading the Processor
If you want to upgrade your computer by replacing the existing processor with a faster/new one you will need to contact your customer service representative. We recommend that you do not do this yourself, since if it is done incorrectly you may
damage the processor or mainboard.
6 - 2 Overview
