Clevo W310CZ User guide For Windows 8.1

Download

For Windows 8.1

V13.4.00(W81)

Preface

Notice

The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication. This publication and any accompanying software may not, in whole or in part, be reproduced, translated, transmitted or reduced to any machine readable form without prior consent from the vendor, manufacturer or creators of this publication, except for copies kept by the user for backup purposes. Brand and product names mentioned in this publication may or may not be copyrights and/or registered trademarks of their respective companies. They are mentioned for identification purposes only and are not intended as an endorsement of that product or its manufacturer. ©October 2013

Trademarks

Intel and Celeron are trademarks/registered trademarks of Intel Corporation.

Preface

R&TTE Directive

This device is in compliance with the essential requirements and other relevant provisions of the R&TTE Directive 1999/5/EC.

This device will be sold in the following EEA countries: Austria, Italy, Belgium, Liechtenstein, Denmark, Luxembourg, Finland, Netherlands, France, Norway, Germany, Portugal, Greece, Spain, Iceland, Sweden, Ireland, United Kingdom, Cyprus, Czech Republic, Estonia, Hungary, Latvia, Lithuania, Malta, Slovakia, Poland, Slovenia.

ErP Off Mode Power Consumption Statement:

The figures below note the power consumption of this computer in compliance with European Commission (EC) regulations on power consumption in off mode

• Off Mode < 0.5W

Preface

CE Marking

This device has been tested to and conforms to the regulatory requirements of the European Union and has attained CE Marking. The CE Mark is a conformity marking consisting of the letters “CE”. The CE Mark applies to products regulated by certain European health, safety and environmental protection legislation. The CE Mark is obligatory for products it applies to: the manufacturer affixes the marking in order to be allowed to sell his product in the European market.

This product conforms to the essential requirements of the R&TTE directive 1999/5/EC in order to attain CE Marking. A notified body has determined that this device has properly demonstrated that the requirements of the directive have been met and has issued a favorable certificate of expert opinion. As such the device will bear the notified body number 0560 after the CE mark.

The CE Marking is not a quality mark. Foremost, it refers to the safety rather than to the quality of a product. Secondly, CE Marking is mandatory for the product it applies to, whereas most q uality marking s are vo lu ntary.

III

Preface

FCC Statement

(Federal Communications Commission)

You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Re orient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the service representative or an experienc ed radio/TV technician for help.

Operation is subject to the following two conditions:

1. This device may not cause interference. And

2. This device must accept any interference, including interfer ence that may cause undesired operation of the

device.

FCC RF Radiation Exposure Statement:



Warning

Use only shielded cables to connect I/O devices to this equipment. You are cautioned that changes or modifications not expressly approved by the manufacturer for compliance with the above standard s could void your authority to operate the equipment.

If your purchase option includes both Wireless LAN and 3G modules, then the appropriate antenna s will be installed. Note that In order to comply with FCC RF exposure compliance requirements, the antenna must not be co -located or o perate in conjunction with any other antenna or transmitter.

Important Notice - 3G & Bluetooth/Wireless LAN Modules

In order to comply with FCC regulations you should NOT operate the 3G module and the Bl uetoo th/Wirele ss LAN modules at the same time as this may disrupt radio frequency, and cause interference. When the 3Gmodule is powered on, make sure that the Bluetooth/Wireless LAN modules are powered off.

1. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

2. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This

equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.

Preface

IMPORTANT SAFETY INSTRUCTIONS

Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment:

1. Do not use this product near water, for example n ear a ba th tub, wash bowl, kitchen sink or laundry tu b, in a wet

basement or near a swimming pool.

2. Avoid using this equipment with a telephone line (other than a cordless type) during an electrical storm. There

may be a remote risk of electrical shock from lightning.

3. Do not use the telephone to report a gas leak in the vicinity of the leak.

4. Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may

explode. Check with local codes for possible special disposal instructions.

5. This product is intended to be supplied by a Listed Power Unit with an AC Input of 100 - 240V, 50 - 60Hz, DC

Output of 19V, 2.1A (40 Watts) minimum AC/DC Adapter.

Preface

Instructions for Care and Operation

The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions:

1. Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged.

Do not expose the computer to any shock or vibration.

Do not place it on an unstable surface.

Do not place anything heavy on the computer.

2. Keep it dry, and don’t overheat it. Keep the computer and power supply away from any kind of heating ele-

ment. This is an electrical appliance. If water or any other liquid gets into it, the computer could be badly damaged.

Do not expose it to excessive heat or direct sunlight.

Do not leave it in a place where foreign matter or moisture may affect the system.

Don’t use or store the computer in a humid environment.

Do not place the computer on any surface that will block the Vents/Fan Intakes.

VII

Preface

3. Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other

strong magnetic fields. These can hinder proper performance and damage your data.

4. Follow the proper workin g procedu res for t he computer. Shut the computer down properly and don’t forget

to save your work. Remember to periodically save your data as data may be lost if the battery is depleted.

Do not turn off the power until you properly shut down all programs.

Do not turn off any peripheral devices when the computer is on.

5. Take care when using peripheral devices.

Use only approved brands of peripherals.

VIII

Do not disassemble the computer by yourself.

Unplug the power cord befor e attaching peripheral devices.

Perform routine maintenance on your computer.

Power Safety



Power Safety

Warning

Before you undertake any upgrade procedures, make sure that you have turned off the power, and disconnected all peripherals and cables (including telephone lines and power cord).

You must also remove your battery in order to prevent accidentally turning the machine on. Before removing

the battery disconnect the AC/DC adapter from the computer.

The computer has specific power requirements:

• Only use a power adapter approved for use with this computer.

• Your AC/DC adapter may be designed for international travel but it still requires a

steady , uninterru pted power suppl y. If you are unsure of your local power specifications, consult your service representative or local power company.

• The power adapter may have either a 2-prong or a 3-prong grounded plug. The third

prong is an important safety feature; do not defeat its purpose. If you do not have access to a compatible outlet, have a qualified electrician install one.

• When you want to unplug the power cord, be sure to disconnect it by the plug head, not

by its wire.

• Make sure the socket and any extension cord(s) you use can support the total current

load of all the connected devices.

• Before cleaning the computer, make sure it is disconnected from any external power

supplies (i.e. AC/DC adapter or car adapter).

Do not plug in the power cord if you are wet.

Do not use the power cord if it is broken.

Do not place heavy objects on the power cord.

Preface

Polymer Battery Precautions

Note the following information which is specific to polymer batteries only, and where applicable, this overrides the general battery precaution information overleaf.

• Polymer batteries may experience a slight expansion or swelling, however this is part of the battery’s safety mecha-

nism and is not a cause for concern.

• Use proper handling procedures when using polymer batteries. Do not use polymer batteries in high ambient tempera-

ture environments, and do not store unused batteries for extended periods.

See also the general battery precautionary information overleaf for further information.

Battery Precautions



Battery Disposal & Caution

The product that you have purchased contains a rechargeable battery. The battery is recyclable. At the end of its useful life, under various state and local laws, it may be illegal to dispose of this battery in to the municipal waste stream. Check with your local solid waste officials for details in your area for recycling options or proper disposal.

Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalen t type recommended by the manufacturer. Discard used battery according to the manufacturer’s instructions.

• Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer.

• Do not remove any batteries from the computer while it is powered on.

• Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even

if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.

• If you do not use the battery for an extended period, then remove the battery from the computer for storage.

• Recharge the batteries using the notebook’s system. Incorrect recharging may make the battery explode.

• Do not try to repair a battery pack. Refer any battery pack repa ir or replacemen t to you r service repre sentati ve or qu al-

ified service personnel.

• Keep children away from, and promptly dispose of a damaged battery. Always dispose of batteries carefully. Batteries

may explode or leak if exposed to fire, or improperly handled or discarded.

• Keep the battery away from metal appliances.

• Affix tape to the battery contacts before disposing of the battery.

• Do not touch the battery contacts with your hands or metal objects.

Preface



Removal Warning

When removing any cover(s) and screw(s) for the purposes of device upg rade, remember to replace the cover(s) and screw(s) before restoring power to the system.

Also note the following when the cover is removed:

• Hazardous moving parts.

• Keep away from moving fan blades.

Cleaning

Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer.

Servicing

Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock. Refer all servicing to authorized service personnel. Unplug the computer from the power supply. Then refer servicing to qualified service personnel under any of the following conditions:

• When the power cord or AC/DC adapter is damaged or frayed.

• If the computer has been exposed to rain or other liquids.

• If the computer does not work normally when you follow the operating instructions.

• If the computer has been dropped or damaged (do not touch the poisonous liquid if the LCD panel breaks).

• If there is an unusual odor, heat or smoke coming from your computer.

XII

Preface



Power Off Before Traveling

Make sure that your notebook is completely powered off before putting it into a travel bag (or any such container). Putting a notebook which is powered on in a travel bag may cause the vent(s)/fan intake(s)/outlet(s) to be blocked. To prev ent your computer from overheating make sure nothing blocks the vent(s)/fan intake(s)/outlet(s) while the computer is in use.

Travel Considerations

Packing

As you get ready for your trip, run through this list to make sure the system is ready to go:

1. Check that the battery pack and any spares are fully charged.

2. Power off the computer and peripherals.

3. Close the display panel and make sure it’s latched.

4. Disconnect the AC/DC adapter and cables. Stow them in the carrying bag.

5. The AC/DC adapter uses volt ages from 100 to 240 volt s so you won’t need a second volt age adapter. However,

check with your travel agent to see if you need any socket adapters.

6. Put the notebook in its carrying bag and secure it with the bag’s straps.

7. If you’re taking any perip herals (e.g. a printer, mouse or digital camera), pack them and those devices’ adapters

and/or cables.

8. Anticipate customs - Some jurisdictions may have import restrictions or req uire proof of ownersh ip for both hard -

ware and software. Make sure your documents are prepared.

XIII

Preface

On the Road

In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind:

Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common. Don’t check it with normal luggage. Baggage handlers may not be sufficiently careful. Avoid knocking the computer against hard objects.

Beware of Electromagnetic fields - Devices such as metal detectors & X-ray machines can damage the computer, hard disk, floppy disks, and other media. They may also destroy any stored data - Pass your computer and disks around the devices. Ask security officials to hand-inspect them (you may be asked to turn it on). Note: Some airports also scan luggage with these devices.

Fly safely - Most airlines have regulations about the use of computers and other electronic devices in flight. These restrictions are for your safety, follow them. If you stow the notebook in an overhead compartment, make sure it’s secure. Contents may shift and/or fall out when the compartment is opened.

Get power where you can - If an electrical outlet is available, use the AC/DC adapter and keep your battery(ies) charged.

Keep it dry - If you move quickly from a cold to a warm location, water vapor can condense inside the computer. Wait a few minutes before turning it on so that any moisture can evaporate.

XIV

Preface

Developing Good Work Habits

Developing good work habits is important if you need to work in fron t of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints. The following are some tips to reduce the strain:

• Adjust the height of the chair and/or desk so that the keyboard is at or slightly below the

level of your elbow. Keep your forearms, wrists, and hands in a relaxed position.

• Your knees should be slightly higher than your hips. Place your feet flat on the floor or on

a footrest if necessary.

• Use a chair with a back and adjust it to support your lower back comfortably.

• Sit straight so that your knees, hips and elbows form approximately 90-degree angles

when you are working.

• Take periodic breaks if you are using the computer for long periods of time.

Remember to:

• Alter your posture frequently.

• Stretch and exercise your body several times a day.

• Take periodic breaks when you work at the computer for long periods of time. Frequent

and short breaks are better than fewer and longer breaks.

Preface

Lighting

Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders.

• Position the display to avoid glare or reflections from overhead lighting or outside sources of light.

• Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly.

• Position the display directly in front of you at a comfortable viewing distance.

• Adjust the display-viewing angle to find the best position.

LCD Screen Care

To prevent image persistence on LCD monitors (caused by the continuous display of graphics on the screen for an extended period of time) take the following precautions:

• Set the Windows Power Plans to turn the screen off after a few minutes of screen idle time.

• Use a rotating, moving or blank screen saver (this prevents an image from being displayed too long).

• Rotate desktop background images every few days.

• Turn the monitor off when the system is not in use.

LCD Electro-Plated Logos

Note that in computers featuring a raised LCD electro-plated logo, the logo is covered by a protective adhesive. Due to general wear and tear, this adhesive may deteriorate over time and the exposed logo may develop sharp edges. Be careful when handling the computer in this case, and avoid touching the raised LCD electro-plated logo. Avoid placing any other items in the carrying bag which may rub against the top of the computer during transport. If any such wear and tear develops contact your distributor/supplier.

XVI

Preface

Contents

Notice .............................................................................................................................................................I

ErP Off Mode Power Consumption Statement: ...........................................................................................II

FCC Statement ............................................................................................................................................IV

FCC RF Radiation Exposure Statement: .....................................................................................................V

Instructions for Care and Operation ......................................................................................................... VII

Power Safety ...............................................................................................................................................IX

Polymer Battery Precautions .......................................................................................................................X

Battery Precautions .....................................................................................................................................XI

Cleaning .................................................................................................................................................... XII

Servicing ................................................................................................................................................... XII

Travel Considerations ..............................................................................................................................XIII

Quick Start Guide

Overview ....................................................................................................................................................1-1

Advanced Users .........................................................................................................................................1-2

Beginners and Not-So-Advanced Users ....................................................................................................1-2

Warning Boxes ..........................................................................................................................................1-2

Not Included ..............................................................................................................................................1-3

System Software ........................................................................................................................................1-4

Model Differences .....................................................................................................................................1-5

System Startup ...........................................................................................................................................1-6

XVII

Preface

System Map: LCD Panel Open ..................................................................................................................1-7

LED Indicators ...........................................................................................................................................1-8

Keyboard ....................................................................................................................................................1-9

Keyboard Shortcuts .................................................................................................................................1-10

Function/Hot Key Indicators ...................................................................................................................1-11

Control Center .........................................................................................................................................1-12

System Map: Front & Left Views ...........................................................................................................1-13

System Map: Right & Rear Views ..........................................................................................................1-14

System Map: Bottom View .....................................................................................................................1-15

Removing the Battery ..............................................................................................................................1-16

3G Module USIM Card Installation ........................................................................................................1-17

Windows Touch Screen Controls/Gestures .............................................................................................1-18

Touch Keyboard ......................................................................................................................................1-20

Windows 8.1 Control Panel .....................................................................................................................1-22

Windows 8.1 Start Screen & Desktop .....................................................................................................1-24

Apps & Tiles ............................................................................................................................................1-25

Desktop Application ................................................................................................................................1-26

The Charms Bar .......................................................................................................................................1-27

Windows 8.1 Control Panel .....................................................................................................................1-29

Windows 8.1 Taskbar ..............................................................................................................................1-32

Video Features .........................................................................................................................................1-33

Power Options .........................................................................................................................................1-36

XVIII

Preface

Running Apps ..........................................................................................................................................1-37

Features & Components

Overview ....................................................................................................................................................2-1

Hard Disk Drive .........................................................................................................................................2-2

Multi-In-1 Card Reader .............................................................................................................................2-3

Touchpad and Buttons/Mouse ...................................................................................................................2-4

Finger Sensing Pad Configurator ...............................................................................................................2-6

Audio Features .........................................................................................................................................2-15

Power Management

Overview ....................................................................................................................................................3-1

The Power Sources ....................................................................................................................................3-2

AC/DC Adapter .........................................................................................................................................3-2

Battery ........................................................................................................................................................3-2

Turning On the Computer ..........................................................................................................................3-3

Shutting the Computer Down ....................................................................................................................3-4

Power Plans ...............................................................................................................................................3-5

Power-Saving States ..................................................................................................................................3-7

Sleep ..........................................................................................................................................................3-7

Hibernate ....................................................................................................................................................3-8

Shut down ..................................................................................................................................................3-8

Configuring the Power Buttons .................................................................................................................3-9

XIX

Preface

Resuming Operation ................................................................................................................................3-11

Power Conservation Modes .....................................................................................................................3-12

Battery Information .................................................................................................................................3-14

Battery Power ..........................................................................................................................................3-14

Conserving Battery Power .......................................................................................................................3-15

Battery Life ..............................................................................................................................................3-16

New Battery .............................................................................................................................................3-16

Recharging the Battery with the AC/DC Adapter ...................................................................................3-16

Proper handling of the Battery Pack ........................................................................................................3-17

Battery FAQ .............................................................................................................................................3-18

Drivers & Utilities

What to Install ............................................................................................................................................4-1

Driver Installation ......................................................................................................................................4-2

Updating/Reinstalling Individual Drivers ..................................................................................................4-4

User Account Control ................................................................................................................................4-5

Windows Security Message .......................................................................................................................4-5

New Hardware Found ................................................................................................................................4-5

Driver Installation Procedure .....................................................................................................................4-6

Chipset .......................................................................................................................................................4-6

Video (VGA) .............................................................................................................................................4-6

LAN ...........................................................................................................................................................4-6

Preface

Card Reader ...............................................................................................................................................4-6

TouchPad ...................................................................................................................................................4-6

Airplane .....................................................................................................................................................4-6

Hot Key ......................................................................................................................................................4-6

MEI Driver .................................................................................................................................................4-7

Audio .........................................................................................................................................................4-7

Windows Experience Index .......................................................................................................................4-8

Optional Drivers ........................................................................................................................................4-9

BIOS Utilities

Overview ....................................................................................................................................................5-1

The Setup Utility ........................................................................................................................................5-2

Failing the POST .......................................................................................................................................5-3

Fatal Errors ................................................................................................................................................5-3

Non-Fatal Errors ........................................................................................................................................5-3

Setup Screens .............................................................................................................................................5-4

Main Menu .................................................................................................................................................5-5

System Time & Date (Main Menu) ...........................................................................................................5-5

SATA Port # (Main Menu) ........................................................................................................................5-6

System/Extended Memory: (Main Menu) .................................................................................................5-6

MB Series / BIOS Revision / KBC/EC firmware Revision ......................................................................5-6

Advanced Menu .........................................................................................................................................5-7

XXI

Preface

SATA Mode (Advanced Menu) ................................................................................................................5-7

Boot Logo (Advanced Menu) ....................................................................................................................5-8

Power On Boot Beep (Advanced Menu) ...................................................................................................5-8

Battery Low Alarm Beep (Advanced Menu) .............................................................................................5-8

Security Menu ............................................................................................................................................5-9

Set Supervisor Password (Security Menu) ................................................................................................5-9

Set User Password (Security Menu) ........................................................................................................5-10

Password on boot (Security Menu) ..........................................................................................................5-10

Secure Boot (Security Menu) ..................................................................................................................5-10

Boot Menu ...............................................................................................................................................5-11

Boot Option Priorities (Boot Menu) ........................................................................................................5-12

UEFI Boot (Boot Menu) ..........................................................................................................................5-12

Exit Menu ................................................................................................................................................5-13

Modules & Options

Overview ....................................................................................................................................................6-1

PC Camera Module ....................................................................................................................................6-2

PC Camera Audio Setup ............................................................................................................................6-3

Camera App ...............................................................................................................................................6-4

Camera Options .........................................................................................................................................6-5

Taking Pictures/Capturing Video ..............................................................................................................6-6

Camera Roll ...............................................................................................................................................6-7

XXII

Preface

Wireless LAN Module .............................................................................................................................6-11

3rd Party 802.11b/g/n Driver Installation ................................................................................................6-12

Intel® WLAN Driver Installation ............................................................................................................6-12

WLAN Configuration in Windows .........................................................................................................6-13

Bluetooth & WLAN Combo Module ......................................................................................................6-16

3rd Party Bluetooth (V4.0) Combo Driver Installation ...........................................................................6-17

Intel Bluetooth Combo Driver Installation ..............................................................................................6-17

Bluetooth Configuration in Windows ......................................................................................................6-18

Trusted Platform (Security) Module ........................................................................................................6-21

Enabling & Activating TPM ....................................................................................................................6-22

Trusted Platform Module (TPM) Driver Installation ..............................................................................6-24

Initializing TPM .......................................................................................................................................6-25

Infineon Security Platform Settings Tool ................................................................................................6-27

3G Module ...............................................................................................................................................6-35

3G Configuration in Windows .................................................................................................................6-37

EM820W 3G Module PIN Code & Power-Saving ..................................................................................6-40

Troubleshooting

Overview ....................................................................................................................................................7-1

Basic Hints and Tips ..................................................................................................................................7-2

Backup and General Maintenance .............................................................................................................7-3

Viruses .......................................................................................................................................................7-4

XXIII

Preface

Upgrading and Adding New Hardware/Software ......................................................................................7-5

Problems and Possible Solutions ...............................................................................................................7-7

EM820W 3G Module PIN Code & Power-Saving ..................................................................................7-15

Resolving the “Insert a SIM” issue with the 3G Module (Windows 8.1) ...............................................7-17

Interface (Ports & Jacks)

Notebook Ports and Jacks .........................................................................................................................A-2

Control Center

Overview ...................................................................................................................................................B-1

Intel Video Driver Controls

Intel Video Driver Installation ..................................................................................................................C-1

Video .........................................................................................................................................................C-1

Dynamic Video Memory Technology ......................................................................................................C-1

Intel® Graphics & Media Control Panel ..................................................................................................C-2

Display Devices & Options ......................................................................................................................C-5

Attaching Other Displays .........................................................................................................................C-6

Attaching Other Displays - Devices (Charms Bar) ..................................................................................C-9

Configuring an External Display In Windows .......................................................................................C-10

HDMI Audio Configuration ...................................................................................................................C-12

XXIV

Preface

Specifications

Processor ...................................................................................................................................................D-2

Core Logic ................................................................................................................................................D-2

Display ......................................................................................................................................................D-2

Memory .....................................................................................................................................................D-2

Video Adapter ...........................................................................................................................................D-2

Storage ......................................................................................................................................................D-2

Audio ........................................................................................................................................................D-2

Keyboard & Pointing Device ....................................................................................................................D-2

Interface ....................................................................................................................................................D-3

Card Reader ..............................................................................................................................................D-3

Slot ............................................................................................................................................................D-3

Communication .........................................................................................................................................D-3

Operating Systems ....................................................................................................................................D-3

Security .....................................................................................................................................................D-3

BIOS .........................................................................................................................................................D-3

Power Management ..................................................................................................................................D-3

Power ........................................................................................................................................................D-3

Battery .......................................................................................................................................................D-4

Design Feature ..........................................................................................................................................D-4

LED Indicators ..........................................................................................................................................D-4

Environmental Spec ..................................................................................................................................D-4

XXV

Preface

Dimensions & Weight ..............................................................................................................................D-4

XXVI

Quick Start Guide

Chapter 1: Quick Start Guide

Overview

This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following:

• Chapter 2 A guide to using some of the main features of the computer e.g. the storage devices (hard disk, &

card reader), TouchPad & Mouse, Audio & Printer.

• Chapter 3 The computer’s power saving options.

• Chapter 4 The installation of the drivers and utilities essential to the operation or improvement of some of the

computer’s subsystems.

• Chapter 5 An outline of the computer’s built-in software or BIOS (Basic Input Output System).

• Chapter 6 A quick guide to the computer’s PC Camera, Wir eless LAN, Combination Bluetooth & WLAN,

Trusted Platform (security) and 3G modules (some of which may be optional depending on your purchase configuration).

• Chapter 7 A troubleshooting guide.

• Appendix A Definitions of the interface, ports/jacks which allow your computer to communicate with external

devices.

• Appendix B Information on Control Center.

• Appendix C Information on the Intel Video driver controls.

• Appendix D The computer’s specification.

Overview 1 - 1



Notes

Check the light colored boxes with the mark above to find detailed information about the computer’s features.

Quick Start Guide

Advanced Users

If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “What to Install” on page 4 - 1 and “BIOS Utilities” on page 5 - 1 in the reminder of the User’s Manual. You may also find the notes marked with a

 of interest to you.

Beginners and Not-So-Advanced Users

If you are new to computers (or do not have an advanced knowledge of them) then the information contained in the Quick Start Guide should be enough to get you up and running. Eventually you should try to look through all the documentation (more detailed descriptions of the functions, setup and system controls are covered in the remainder of the User’s Manual), but do not worry if you do not understand everything the first time. Keep this manual nearby and refer to it to learn as you go. You may find it useful to refer to the notes marked with a

 as indicated in the margin.

For a more detailed description of any of the interface ports and jacks see “Interface

(Ports & Jacks)” on page A - 1.

Warning Boxes

No matter what your level please pay careful attention to the warning and safety information indicated by the

 symbol. Also please note the safety and handling instructions as indicated in the Preface.

1 - 2 Overview

Quick Start Guide



Drivers

If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the drivers listed in “Drivers & Utilities” on page 4 - 1. Drivers are programs which act as an interface between the computer and a hardware component e.g. a wireless network module. It is very important that you install the drivers in the order listed. You will be unable to use most advanced controls until the necessary drivers and utilities are properl y installed. If your system hasn’t been properly configured (your service representative may have already done that for you); refer to

Chapter 4 for installation instructions.

You will need to attach an optical device drive to the computer in order to access the drivers on the Device Drivers & Utilities + User’s Manual disc. This contains the drivers and utilities necessary for the proper operation of the computer.

Ports and Jacks

See “Notebook Ports and Jacks” on page A - 2 for a description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc.

Not Included

Operating Systems (e.g. Windows 8.1) and applications (e.g. word processing, spreadsheet and database programs) have their own manuals, so please consult the appropriate manuals.

Overview 1 - 3



Windows Versions

Note that the information included on the following pages is for Windows 8.1 only. The Windows 8 interface is slightly different in appearance and in methods of navigation, and a separate manual is pro -

vided on the Device Drivers & Manual Disc for Windows 8.

Windows OS

In order to run Windows 8/8.1 (32 Bit) without limitations or decreased performance, yo ur computer requires a minimum

1GB of system memory (RAM), however if you are running Windows 8/8.1 (64 bit) your computer requires a minimum 2GB of system memory (RAM).

Quick Start Guide

System Software

Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find the Windows 8.1 o perating system is supported.

Note: In order to run Windows without limitations or decreased performance, your computer requires a mini- mum 1GB of system memory (RAM).

1 - 4 Overview

Quick Start Guide

Model Differences

This notebook series includes different models that vary slightly in design style, color and general appearance. Not all the model variants, colors, configurations, buttons etc., are pictured in this manual. Note th at though your computer may look slightly different from that pictured throug hout this manual, all ports, jacks and general functions are the same for all the design styles (see “Specifications” on page D - 1 for further details). Model B com-

puters feature a Multi Touch screen.

Overview 1 - 5

130°



Shutdown

Note that you should always shut your computer down by choosing the Shut Down command in Windows (see page 1 - 36). This will help prevent hard disk or system problems.

Quick Start Guide

System Startup

1. Remove all packing materials.

2. Place the computer on a stable surface.

3. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports.

4. Attach the AC/DC adapter to the DC-In jack on the left of the computer, then plug the AC power cord into an

outlet, and connect the AC power cord to the AC/DC adapter.

5. Use one hand to raise the

hand (as illustrated in Figure 1 - 1 below) to support the base of the computer (Note: Never lift the computer by the lid/LCD).

lid/LCD to a comfortable viewing angle (

Figure 1 - 1 - Opening the Lid/LCD

do not exceed 130 degrees

);

use the other

1 - 6 System Startup

System Map: LCD Panel Open

Figure 1 - 2

LCD Panel Open

1. Built-In PC Camera (

Optional

)

2. *PC Camera LED

3. Built-In Microphone

4. LCD

5. Power Button

6. Keyboard

7. TouchPad & Buttons

*Note that the PC Camera LED functions with the 1.0HD camera only

TouchPad Buttons (valid operation area)

Note that the TouchPad and Buttons valid operational area is that indicated within the red dotted lines indicated on the left.



Wireless Device

Operation Aboard

Aircraft

The use of any portable electronic transmission devices aboard aircraft is usually prohibited. Make sure the 3G/WLAN/Blue- tooth module(s) are OFF if you are using the computer aboard aircraft.

Use Fn + F11 Airplane Mode key combination to toggle Airplane Mode On/ Off, and check the LED indicator for the power status (see Table 1 - 3, on

page 1 - 11/ Table 1 - 1, on page 1 - 8).

Quick Start Guide

System Map: LCD Panel Open 1 - 7

Quick Start Guide

LED Indicators

The LED indicators display helpful information about the current status of the computer.

Icon Color Description

Orange DC Power is Plugged In

Green The Computer is On

Blinking Green The Computer is in Sleep Mode

Orange The Battery is Charging

Green The Battery is Fully Charged

Blinking Orange The Battery Has Reached Critically Low Power Status

Green Airplane Mode is ON (the WLAN & Bluetooth Modules are OFF)

Green HDD/ODD Activity

Table 1 - 1 - LED Indicators

1 - 8 LED Indicators

Keyboard



Other Keyboards

If your keyboard is damaged or you just want to make a change, you can use any standard USB keyboard. The system will detect and enable it automatically. However special functions/ hot-keys unique to the system’s regular keyboard may not work.

NumLK & Scr LK

Hold down the Fn Key and either NumLK or Scr LK to enable number or scroll lock, and check the indicator for status.

Numerical Keypad

Play/Pause Key

Function Keys

NumLK & Scr LK Keys

Fn Key

Windows Logo Key

Menu/Application Key



Special Characters

Some software applications allow the number-keys to be used with Alt to produce special characters. These special characters can only be produced by usi ng the numeric keypad. Regular number keys (in the upper row of the keyboard) will not work. Make sure that NumLK is on.

The keyboard has an embedded numerical keypad for easy numeric data input, and function keys to change operational features instantly.

Figure 1 - 3 - Keyboard

Quick Start Guide

Keyboard 1 - 9



Windows Logo

Keyboard Shortcut

Use the Windows logo key + D key com- bination to switch between the Start screen and Windows Desktop.

Menu/Application

Keyboard Shortcut

When the Desktop app is running you can use the Menu/Application key on the keyboard to display the context menu as per a mouse right-click. In the Start screen this function is useful to quickly display the All

Apps icon.

Quick Start Guide

Keyboard Shortcuts

The following Windows Logo Key (Winkey) keyboard shortcuts are useful for navigation/operation in

Windows 8.1

1 - 10 Keyboard

Windows Logo

Key +

Tap Winkey

CDisplay Charms menu D Switch to the Windows Desktop and toggle show Desktop

F Display file Search

I Open the Settings charm

K Open the Connect charm

L Lock the computer and display the Lock screen P Display the Second Screen menu (see Figure 1 - 26 on page 1 - 33) R Switch to the Windows Desktop and display the Run dialog box Z Access the Customize Bar (see Figure 1 - 17 on page 1 - 25)

Description

Toggle between the Start screen and the foremost running app or the

Windows Desktop

Switch to the Windows desktop and launch Windows Explorer with

Computer displayed

Table 1 - 2 - Keyboard Shortcuts

Quick Start Guide

Function/Hot Key Indicators

The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the basic function key combinations; visual indicators are available (from the Desktop) when the hot key utility is installed.

Keys Function Keys Function

Fn + ~ Play/Pause (in Audio/Video Programs) Fn + F8/F9 Brightness Decrease/Increase

Fn + F1 TouchPad Toggle Fn + F10

Fn + F2

Fn + F3 Mute Toggle Fn + NumLK Number Lock Toggle

Fn + F4 Sleep Toggle Fn + Scr LK Scroll Lock Toggle

Fn + F5/F6 Volume Decrease/Increase Caps Lock Caps Lock Toggle

Fn + F7 Display Toggle

(Press a key to or use TouchPad to turn on)

Turn LCD Backlight Off

Table 1 - 3 - Function & Hot Key Indicators

Fn + F11 Airplane Mode Toggle

PC Camera Power

Toggle

Function/Hot Key Indicators 1 - 11



Control Center

Click on any button to turn any of the modules (e.g. TouchPad, Camera) on/off.

Click on the power conservation modes to switch between Performance, Balanced or Energy Star modes. To remove the Power Conservation Modes screen just click in a blank area of the icon or press a key on the keyboard.

Click on the buttons (or just click and hold the mouse button) to adjust the slider for Brightness/Volume.

Click on Display Switch and click to choose a display mode from the menu.

Quick Start Guide

Control Center

When in the Windows Desktop application (not in the Start screen) press the Fn + Esc key combination, or double-click the icon trol Center gives quick access to frequently used controls and enables you to quickly turn the camera/Touch

Pad on/off (see Appendix B for full details).

in the notification area of the taskbar to toggle the Control Center on/off. The Con-

Figure 1 - 4 - Control Center - Control Center

1 - 12 Control Center

System Map: Front & Left Views

Figure 1 - 5

Front & Left Views

1. LED Indicators (see

Table 1 - 1,

on page 1 - 8)

2. Security Lock Slot

3. DC-In Jack

4. RJ-45 LAN Jack

5. External Monitor Port

6. HDMI-Out Port

7. 2 * USB 2.0 Ports

8. Multi-in-1 Card Reader



Multi-In-1 Card Reader

The card reader allows you to use the most popular digital storage card formats:

MMC (MultiMedia Card) / RSMMC

SD (Secure Digital) / Mini SD / SDHC / SDXC

MS (Memory Stick) / MS Pro / MS Duo

Optical Device Drives

To install applications and drivers etc. you will need to attach an external optical CD/DVD device to the USB ports.

Quick Start Guide

System Map: Front & Left Views 1 - 13

Figure 1 - 6

Right & Rear Views

1. Microphone-In

Jack

2. Headphone-Out

Jack

3. 1 * USB 2.0 Port

4. Battery

5. Vent/Fan Intake/

Outlet

1 2



Battery Information

Always completely discharge, then fully charge, a new battery before using it. Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges. See “Battery Information” on page 3 - 14 for full instructions.

Optical Device Drives

To install applications and drivers etc. you will need to attach an external optical CD/DVD device to the USB ports.

Quick Start Guide

System Map: Right & Rear Views

1 - 14 System Map: Right & Rear Views

System Map: Bottom View

Figure 1 - 7

Bottom View

1. Battery

2. Fan Intake/Vent

3. Speakers



3G USIM Card

Installation

If your model includes the 3G option then remove the battery to access the USIM card slot (see 1 - 17).

CPU

The CPU is not a user serviceable part.



Bottom Cover Removal Warning

Do not remove any cover(s) and /or screw(s) for the purposes of device upgrade as this may violate the terms of your warranty.

If you need to replace/remove the hard disk or RAM for any reason, please contact your distributor/supplier for further information.



Overheating

To prevent your computer from overheating make sure nothing blocks the Vent/Fan Intake while the computer is in use.

Quick Start Guide

System Map: Bottom View 1 - 15



Warranty Warning

Please check with your service representative before undertaking any upgrade procedures to find out if this will VOID your warranty.

Figure 1 - 8

Battery Removal

123

Quick Start Guide

Removing the Battery

If you are confident in undertaking upgrade procedures yourself, for safety reasons it is best to remove the battery.

1.Turn the computer off, and turn it over.

2.Slide the latch in the direction of the arrow.

3.Slide the latch in the direction of the arrow, and hold it in place.

4.Slide the battery out in the direction of the arrow .

1 - 16 Removing the Battery

3G Module USIM Card Installation



Power Safety

Warning

Before you undertake any installation procedures, make sure that you have turned off the power, and disconnected all peripherals and cables (including telephone lines). It is advisable to also remove your battery in order to prevent accidentally turning the machine on.

USIM Card Orientation

Note that the USIM card’s readable side (with the gold-colored contacts) should face upwards as illustrated.

Figure 1 - 9

Battery Removal &

USIM Card Insertion

123

If you have included an optional 3G module, follow the instructions below to install the USIM card (which will be provided by your service provider). See page 6 - 37 for configuration instructions.

1. Turn off the computer, and turn it over.

2. Slide the latch in the direction of the arrow .

3. Slide the latch in the direction of the arrow, a nd hold it in place.

4. Remove the battery .

5. Insert the USIM card (at the rear of the battery compartment) as illustrated below until it clicks fully into position, and replace the battery.

Quick Start Guide

3G Module USIM Card Installation 1 - 17

Quick Start Guide

Windows Touch Screen Controls/Gestures

(For Model B Touch Screens Only)

Model B computers incorporate a Touch Screen and this can be used to navigate through he interface in much the same way as a mouse, touchpad and keyboard. Where you see the instruction to click/double-click an item in this manual, you can choose to tap/double tap the appropriate area of the screen instead. The following gestures are useful when navigating the Windows interface.

• Swipe from the right (Access the Charms Bar) - Pull your finger from the right side of the screen (in the

black area) to the left a little bit to bring up the Charms Bar.

Figure 1 - 10 - Swipe from Right & Left

• Swipe from the left (Switch apps) - If multiple apps are running you can slide your finger from the left side

of the screen (in the black area) to the right to switch between apps.

• Swipe slowly from the left (Snap apps) - Perform the same action above more slowly, to drag one app out

and display it side-by-side with the app that was already on your screen.

1 - 18 Windows Touch Screen Controls/Gestures

Quick Start Guide

• Swipe from left and back (Display running apps) - Slide your finger fr om the left and quickly drag it back

towards the right to display a list of apps that are currently running. Tap any app to switch to it.

• Pull down from the top (Close app) - Close any running app by starting at the top area of the screen and

quickly pulling your finger about halfway down the screen.

• Swipe down/up (Customize menu) - Swiping the finger a little bit down from the top, or up from the bot-

tom of the Start screen will bring up the menu with the Customize icon. Tap the Customize icon and then select the app tiles, and slide them to any selected position to rearrange them.

Figure 1 - 11 - Swipe Up and Tap, Hold & Release (Desktop Right-Click)

• Swipe down on an item (Select/right-click) - Swipe down on any tile in the Start screen to select it and

bring up additional options.

• Tap, Hold & Release (Desktop right-click) - Tap the Desktop, hold until a square icon appears, and then

release to access the right click menu.

Windows Touch Screen Controls/Gestures 1 - 19

Touch Keyboard Desktop app taskbar Icon

Select Keyboard or Writing Pad Input

Quick Start Guide

Touch Keyboard

(For Model B Touch Screens Only)

If you need to type on screen then the Touch Keyboard will pop up when required (e.g. when you need to type in an internet URL address in Internet Explorer). When the Touch Keyboard is displayed you have several display/input options and these can be accessed from the icon at the bottom right of the keyboard. To access the Touch Keyboard from the Desktop app click/tap the keyboard icon in the taskbar .

1 - 20 Touch Keyboard

Figure 1 - 12 - Touch Keyboard

Quick Start Guide

Click Help

The Touch Keyboard allows you to input text without the use of an actual keyboard., and you can use writing pad to write (continuously or one character at a time) or touch keyboard to input text. Use the Help menu for further information.

Figure 1 - 13 - Touch Keyboard, Writing Pad Input & Help

Touch Keyboard 1 - 21



Windows Versions

Note that the information included on the following pages is for Windows 8.1 only.

The Windows 8 interface is slightly different in appearance and in methods of navigation, and a separate manual is provided on the De-

vice Drivers & Manual Disc with reference to

Windows 8.

Move the mouse to the bottom left

Start ScreenDesktop app

of the screen and right-click to access the menu.

Quick Start Guide

Windows 8.1 Control Panel

Throughout this manual you will see an instruction to open the Control Panel. R

ight-click the lower left hot corner to bring up the context menu (or use the Win-

dows Logo Key + X key combination)

Desktop app or Start screen.

and select Control Panel in both the

1 - 22 Windows 8.1 Control Panel

Figure 1 - 14 - Windows Context Menu

Right-click the Start button in the Desktop app (or use the Windows Logo Key



Display Most

Recently Used

Apps

If you are in the Start screen, Desktop or an app you can move your mouse to the upper left corner of the screen to get back to the most recently used app.

To view all the most recently used Apps hover over the top left of the screen and then move the mouse down along the left side of the screen to display the list.

Move the mouse to the bottom left of the screen

and right-click the Start button to access the menu.

+ X key combination) to bring up an advanced context menu of useful features

such as Control Panel, Programs and Features, Power Options, Task Manager, Search, File Explorer, Command Prompt, Device Manager and Network Connections etc.

Figure 1 - 15 - Advanced Context Menu (Right-Click Start Button)

Quick Start Guide

Windows 8.1 Control Panel 1 - 23

Desktop App

Quick Start Guide

Windows 8.1 Start Screen & Desktop

The Apps, control panels, utilities and programs within Windows are accessed from the Start screen and/or Windows Desktop app. The Desktop (which runs as an app within the Start screen) can be accessed by clicking

the Desktop item in the Start screen (or by using the Windows Logo Key + D key combination). Click the arrow at the bottom of the Start screen to access Apps.

Figure 1 - 16 - Windows Start Screen

1 - 24 Windows 8.1 Start Screen & Desktop

Quick Start Guide

Click the arrow at the bottom of the screen to access All Apps

Apps & Tiles

The Start screen will contain a number of apps, and many more will be installed as you add more applications etc. Not all of these apps can fit on one screen so you will often need use the slider at the bottom of the screen in order to view all the necessary Apps.

Accessing Pining/Unpinning All Apps

You can add and remove the tiles for apps and control panels in the Start screen. Right-click on a blank area of the Start screen, and you will see the Customize icon. Click the Customize icon to display all the installed

applications etc. Right-click any icon to bring up the menu at the bottom of the screen and you can then click the appropriate icon to pin the App to (or unpin from) the Start screen, or to the taskbar in the Desktop applica- tion (you can also open the app in a new window, run as administrator or open the file location).

Figure 1 - 17 - Customize Apps

Windows 8.1 Start Screen & Desktop 1 - 25

Move the mouse to the bottom left of the screen and click to switch back to the Start screen.

Quick Start Guide

Desktop Application

When the Desktop app is running (click the app in the Start screen or use the Windows Logo Key + D key combination) you can use lower left hot corner to switch between the Start screen and the Windows Desktop app. To do so move your mouse to hover over the bottom left corner of the Desktop app and left-click.

When you move to the lower left hot corner in the Start screen it will take you back to your most recently used app (if one is running).

Figure 1 - 18 - Desktop

1 - 26 Windows 8.1 Start Screen & Desktop

The Charms Bar

Move the mouse over a Charms Bar icon to activate the menu

Move the mouse to the top/lower right icons to activate the Charms Bar

The right side of the screen displays the Charms Bar. The Charms Bar contains the Search, Share, Start, Devices and Settings menus. To access up the Charms Bar move the cursor to the upper or lower right corners of

the screen, and then hover over one of the items in the Charms Bar to activate it (the bar will be black when it is active), or use the Windows Logo Key + C key combination.

Quick Start Guide

Figure 1 - 19 - Start Screen with Charms Bar

Windows 8.1 Start Screen & Desktop 1 - 27



Charms Bar - TouchPad Access

To quick access the Charms Bar using the TouchPad:

1. Place your finger off the TouchPad (slightly to the right of the pad resting on the computer).

2. Move your finger across to the left on to the TouchPad.

3. The Charms Bar will then pop-up.

Quick Start Guide

Charms Bar Items

• Search : You can search for any file, application, Apps and control panel settings with instantaneous

results.

•Share : This button is used to share information with people via mail or social networks.

•Start : Click to bring up the Start screen (the same function as pressing the Windows Logo Key or click-

ing the bottom left of the screen).

• Devices : Click this button to change connected peripheral device settings e.g. an external display.

• Settings : This button gives instant access to the computer settings, such as Network, Audio, Notifications, Power and Keyboard (click Change PC Settings to activate the PC Settings menu).

Figure 1 - 20 - Settings Menu

1 - 28 Windows 8.1 Start Screen & Desktop

Quick Start Guide

Windows 8.1 Control Panel

In many instances throughout this manual you will see an instruction to open the Control Panel. The Control Panel can be accessed in a number of ways in Windows 8.1.

•Click Search in the Windows Charms Bar (see previous page) and the search pane will pop out. Type

Control Panel and select it from the results to the left.

Figure 1 - 21 - Search (Control Panel)

• Click on This PC (in Apps, or you can to pin This PC to the Start screen), click on Computer in the

top menu and select Open Control Panel from the ribbon.

Figure 1 - 22 - Open Control Panel (Computer)

Windows 8.1 Control Panel 1 - 29

Quick Start Guide

• When in the Desktop app (this does not apply to the Start screen) click on Settings in the Windows

Charms Bar and select Control Panel from the menu.

Figure 1 - 23 - Settings Charms Bar (Desktop App Only)

• Click the arrow at the bottom of the Start screen and click Control Panel in Apps (Windows System).

Figure 1 - 24 - All Apps - Control Panel

1 - 30 Windows 8.1 Control Panel

Quick Start Guide



Keyboard Shortcut to Control Panel

You can also use keyboard shortcuts to access the Contro l Pa nel. Press th e Win dows logo key an d X to b ring up the context menu, and then press P to bring up the Control Panel. Alternatively press the Windows logo key and R to bring up the Run dialog box, and then type “Control Panel” and press Enter to access the Control Panel.

• Right-c lick the Start button to bring up the menu and select Control Panel (see Figure 1 - 15 on page 1

- 23).

Windows 8.1 Control Panel 1 - 31

Quick Start Guide

Windows 8.1 Taskbar

In many instances throughout this manual you will see an instruction to access the notification area of the taskbar (system tray). In Windows 8.1 the taskbar is accessed from the Desktop application; if you are in the Start

screen you will need to switch to the Desktop. The taskbar is displayed at the bottom of the Desktop screen, and you can see the notification area (system

tray) of the taskbar in the bottom right of the screen. Some of the control panels and applications referred to during the course of this manual can be accessed from here.

Figure 1 - 25 - Desktop Taskbar & Notification Area (System Tray)

You can pin/unpin apps to/from the taskbar in much the same way as you can to the Start screen (see “Accessing

Pining/Unpinning All Apps” on page 1 - 25).

1 - 32 Windows 8.1 Control Panel

Quick Start Guide

Video Features

You can switch display devices, and configure display options, from the Display control panel (in Appearances and Personalization) in Windows when running the Desktop app (see “Desktop Application” on page 1 - 26 and Appendix C). It is possible to quickly configure external displays from the Devices menu item in the Charms Bar (see “The Charms Bar” on page 1 - 27).

To Configure Displays from Devices (Charms Bar):

1. Attach your display to the appropriate port, and turn it on.

2. Go the Charms Bar, select Devices.

3. Click Project (you may need to click Second Screen).

4. Click on any one of the options from the menu to select PC screen only, Duplicate, Extend or Second screen

only.

Figure 1 - 26- Devices (Project)

Video Features 1 - 33



Right-Click Desktop

App

1. You can right-click the desktop and select Screen reso- lution (Figure 1 -

27).

2. Use the dropbox to select the screen

Resolution

(Figure 1 - 27).

3. Click Advanced settings (Figure

1 - 27) to bring up the

Advanced properties tabs.

123

Quick Start Guide

To access Display (Control Panel) and Screen Resolution in Windows 8:

1. Go to the Control Panel.

2. Click Display (icon) - In the Appearance and Personalization category.

3. Adjust resolution.

Figure 1 - 27 - Screen Resolution

1 - 34 Video Features

Quick Start Guide

To access the Intel(R) Graphics Media Accelerator Driver for mobile control panel:

1. Click Advanced settings (Figure 1 - 27 on page 1 - 34) in the Screen Resolution control panel in Windows.

2. Click the Intel(R)... tab and click Graphics Properties (button) (Figure 1 - 28 on page 1 - 35) .

3. Right-click the desktop and select Graphics Properties from the menu.

4. Click the icon in the notification area of the Desktop taskbar and select Graphics Properties from the menu.

Figure 1 - 28 - Intel GMA Driver for Mobile Control Panel

Video Features 1 - 35

Charms Bar Desktop App Start Screen

Quick Start Guide

Power Options

Power Options (Hardware and Sound) can be accessed from the Control Panel. The Power Menu item in Set- tings in the Charms Bar in Windows 8.1 may be used to Shut down or Restart (you can also add Hibernate/ Sleep to the menu - see “Adding Hibernate/Sleep to the Power Menu” on page 3 - 10). You can also use the context menu (Shut down or sign out) shut the computer down/restart etc.

Shut Down, Restart or Sleep (Charms Bar)

1. Go to the Charms Bar and click Settings.

2. Click Power .

3. Select Sleep, Shut Down or Restart.

1 - 36 Power Options

Figure 1 - 29 - Shut Down/Restart

Quick Start Guide



Screen Resolution for Apps

(Windows 8/8.1)

The minimum resolution in which Apps will run is 1024x768. The minimum resolution required to support a ll the features of

Windows 8 (including multitasking with snap) is 1366x768. These specs are the minimum screen resolution that supports

all the features of Windows 8.1 on a useful physical size.

Running Apps

To run apps in Windows 8.1 you will need to check that the Screen Resolution and User Account Control Settings are compatible with the system requirements.

Screen Resolution Settings

1. Switch to the Windows Desktop (click the app or use the Windows logo key + D key combination).

2. Right-click a blank area of the Windows Desktop and select Screen Resolution. Adjust the Resolution to make sure that it is at least 1024 * 768, although preferably 1366 * 768 or above (see sidebar).

Figure 1 - 30 - Screen Resolution

Running Apps 1 - 37

Quick Start Guide

User Account Control Settings

If your computer meets the minimum screen resolution requirements, and still you can't run apps, then that you have to check the status of User Account Control (UAC). Apps may fail to open when the UAC is turned off. To check whether the UAC is on or off, follow the instructions below.

1. Open the Control Panel.

2. Click on User Accounts and then click on Change User Account Control settings (or click System and Security and click Change User Account Control Settings under Action Center).

3. If the slider is in the Never notify position, then the UAC is disabled.

4. To enable or turn on the UAC, move the slider to Always not ify or Notify me when apps try to make changes

to my computer (default) position, and then click OK.

1 - 38 Running Apps

Figure 1 - 31 - User Account Control

Features & Components

Chapter 2: Features & Components

Overview

Read this chapter to learn more about the following main features and components of the computer:

•Hard Disk Drive

• Multi-In-1 Card Reader

• Touchpad and Buttons/Mouse

• Audio Features

Overview 2 - 1

Features & Components



Bottom Cover

Removal Warning

Do not remove any cover(s) and /or screw(s) for the purposes of device upgrade as this may violate the terms of your warranty.

If you need to replace/ remove the hard disk for any reason, please contact your distributor/supplier for further information.

Hard Disk Drive

The hard disk drive is used to store your data in the computer. The hard disk can be taken out to accommodate other serial (SATA) hard disk drives (see “Storage” on

page D - 2 for specification information), however you will need to contact your dis-

tributor/supplier to do this in order to avoid violating the terms of your warranty.

2 - 2 Hard Disk Drive

Features & Components



Card Reader Cover

Make sure you keep the rubber cover provided in the card reader when not in use. This will help prevent foreign objects and/or dust getting in to the card reader.

Figure 2 - 1

Left View

1. Card Reader

• MMC (MultiMedia Card) / RS MMC

• SD (Secure Digital) / Mini SD / SDHC / SDXC

• MS (Memory Stick) / MS Pro / MS Duo

Multi-In-1 Card Reader

The card reader allows you to use some of the latest digital storage cards. Push the card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s). Make sure you install the card reader driver (see

“Card Reader” on page 4 - 6).

Note: Some of these cards require PC adapters that are usually supplied with the cards.

Multi-In-1 Card Reader 2 - 3

Features & Components

Figure 2 - 2

Touchpad Area of

Sensitivity

Touchpad and Buttons/Mouse

The Touchpad is an alternative to the mouse; however, you can also add a mouse to your computer through one of the USB ports. The Touchpad buttons function in much the same way as a two-button mouse.

Touchpad Sensitivity

Note that the Touchpad has a defined valid operational area of sensitivity indicated within the red area of the illustration below (i.e. 1mm from the top, 2.19mm from the left/right sides and 5.25mm from the button area of the touchpad).

2 - 4 Touchpad and Buttons/Mouse

Once you have installed the Touchpad driver (see “TouchPad” on page 4 - 6) you



Tray Icon

Make sure that the Touchpad driver icon

in the notification area of the Desktop taskbar.

Go to the control panel (Mouse control panel in Windows), click

Finger Sensing Pad

(tab), click Tray Icon and then make sure Show Tray Icon is clicked.

Figure 2 - 3

Mouse Properties

can configure the functions by double-clicking the Touchpad driver icon in the notification area of the Desktop taskbar, or from the Mouse control panel in Win- dows. You may then configure the Touchpad tapping, buttons, scrolling (see sidebar), pointer motion and sensitivity options to your preferences.

Features & Components

Touchpad and Buttons/Mouse 2 - 5

Features & Components



Configuration

Click Defaults to restore all the factory settings.

Press OK to save the changes and close the configurator.

Click Apply to save changes but remain in the configurator.

Figure 2 - 4

Finger Sensing

Pad Configurator

Finger Sensing Pad Configurator

The Finger Sensing Pad Configurator allows you to use a configure the settings for the Finger Sensing Pad device and software. The left pane in the control panel contains all the configurable items, and you can click the “+” to expand the menu selections.

1. Go to the

2. Click Mouse (Hardware and Sound).

3. Click Finger Sensing Pad (tab) and click Configure.

4. Use the menu tree on the lef t to access the user configurable settings.

Control Panel

2 - 6 Touchpad and Buttons/Mouse

Disabling the Touchpad

Figure 2 - 5

Mouse Detection

If you need to disable the Touchpad for any reason (e.g. you may find that when using the computer’s internal keyboard you accidentally trigger the Touchpad when resting your wrists or palms on it) you can do so by using Fn + F1 key combination.

You can also set the system to automatically disable the internal Touchpad when an external USB pointing device (e.g. a USB mouse) is attached, or while you are typing (see over).

1. Go to the Mouse control panel and click to select Finger Sensing Pad (tab).

2. Click to place a tick in the “

3. Click OK to save the setting.

Disable pad while external mouse is plugged in

Features & Components

” box.

Touchpad and Buttons/Mouse 2 - 7

Features & Components

Figure 2 - 6

Disable Pad While

Typing

You can also enable Typing Detection to disable the pad while you are typing. The pad will be disabled while typing is detected, and will be reactivated after a set interval of time when typing is not detected. You can use the slider to adjust the reactivation time for an appropriate interval.

2 - 8 Touchpad and Buttons/Mouse

On-pad Functions



Traditional or

Reverse Scrolling

With traditional scrolling, when you

want to scroll up a web page, you put fingers on the pad and them move upwards. When you want to scroll down, you move your fingers down.

Reverse scrolling reverses the process; to make a webpage scroll down, you have to move fingers up on the pad, and to scroll up you move your fingers down.

Figure 2 - 7

Enable Reverse

Scrolling Direction

Put a tick in the appropriate box to enable the function.

• On-pad Click - The same function as a left mouse click.

• Vertical/Horizontal Scrolling - This will enable sensing zones on the pad to

allow you to touch to enable scrolling.

• On-pad Click Page Slider - This will enable sensing zones on the pad to allow

you to touch to enable sliding up and down the pad.

• On-pad Cursor Speed - Use the slider to adjust the pad pointer speed.

• Two Finger Scrolling - You can enable/disable reverse two-finger scrolling

(see below) from this item.

Features & Components

Touchpad and Buttons/Mouse 2 - 9

Features & Components



Play Video

You can get a clearer view of the gestures involved by clicking the Play Video option for each gesture item.

Figure 2 - 8

Finger Sensing

Pad - Gestures

Gestures

Click Gestures and make sure that the Enable Gestures tickbox is clicked. Double- click Gestures and then double-click Tailor-made or Applications to open the sub- menu. You can enable/disable and configure any of the Tailor-made gestures from these submenus.

2 - 10 Touchpad and Buttons/Mouse

Features & Components

Figure 2 - 9

2F Straight Up/

Down

Figure 2 - 10

2F Straight Right/

Left

Figure 2 - 11

2F Zoom In/Out

• Two Fingers Straight Up/Down - Place two fingers side by side on the pad,

slightly apart. Slide the fingers upwards/downwards in a continuous motion.

• Two Fingers Straight Right/Left - Place two fingers side by side on the pad,

slightly apart. Slide the fingers right/left in a continuous motion.

• Two Fingers Zoom In/Out - Place two fingers side by side on the pad, slightly

apart. Slide the fingers apart in a continuous motion to zoom in, or slide the fingers closer together to zoom out.

Touchpad and Buttons/Mouse 2 - 11

Features & Components

Figure 2 - 12

2F Click

Figure 2 - 13

1F Edge Swipe Top

• Two Fingers Click - Tap the pad with two slightly separated fingers. This simu-

lates the use of a middle mouse button often used in the most common internet browsers.

• One Finger Edge Swipe Top - Place a single finger on the top edge of the pad and slide the finger downwards onto the pad. This is used to open the App bar in the Windows Start menu (not the desktop).

2 - 12 Touchpad and Buttons/Mouse

Features & Components

Figure 2 - 14

1F Edge Swipe

Right

Figure 2 - 15

1F Edge Swipe Left

• One Finger Edge Swipe Right - Place a single finger on the right edge of the pad and slide the finger to the left onto the pad. This is used to open the Charms bar.

• One Finger Edge Swipe Left - Place a single finger on the left edge of the pad and slide the finger to the right onto the pad. This is used to switch to the last used application.

Touchpad and Buttons/Mouse 2 - 13

Features & Components

Figure 2 - 16

Applications

A number of programs/applications support gestures which trigger functions within the program. The Program List displays the programs/applications supporting these functions, and you can use the scroll bar to the right to scroll up/down the list. Click to select the program/application and click View (or just double-click) to see the gestures supported.

2 - 14 Touchpad and Buttons/Mouse

Features & Components



Sound Volume

Adjustment

The volume level is set using the volume control within Windows (and the volume function keys on the computer). Click the volume icon in the Desktop taskbar to check the setting.

Figure 2 - 17

VIA HD Audio Deck

Click Expert Mode to access the Advanced menus

Audio Features

You can configure the audio options on your computer from the Sound control panel in Windows, from the HD VDeck icon on the desktop or VIA HD Audio Deck control panel .

The volume may also be adjusted by means of the Fn + F5/F6 key combination.

Audio Features 2 - 15

Features & Components



Syncing Left & Right

Volume Balance

If you wish to adjust the left and right channel volume levels separately, you will need to adjust this from the

VIA HD Audio Deck in Expert Mode.

Click Speaker in VIA HD Audio Deck (in Expert Mode) and click the Sync Left and Right volume

button (see left). You can then adjust the volume sliders independently (this setting also controls the Balance setting in the Windows Sound control panel).

Figure 2 - 18

VIA HD Audio Deck

(Expert Mode)

Note that to adjust the Left & Right volume ba lance independently click th e Sync Left and Right Volume icon (it should be faded) and adjust the slider as required.

Expert Mode will allow you to access more advanced configuration menus for

Speaker, Microphone and Stereo Mix.

2 - 16 Audio Features

Chapter 3: Power Management



OS Note

Power management functions will vary slightly depending on your operating system. For more information it is best to refer to the user’s manual of your operating system.

Power Management

Overview

To conserve power, especially when using the battery, your computer power management conserves power by controlling individual components of the computer (the monitor and hard disk drive) or the whole system. This chapter covers:

• The Power Sources

• Turning On the Computer

• Power Plans

• Power-Saving States

• Configuring the Power Buttons

• Battery Information

The computer uses enhanced power saving techniques to give the operating system (OS) direct control over the power and thermal states of devices and processors. For example, this enables the OS to set devices into low-power states based on user settings and information from applications.

Overview 3 - 1



Forced Off

If the system “hangs”, and the Ctrl + Alt + Del key combination doesn’t work, press the power button for 4 seconds, or longer, to force the system to turn itself off.

Power Management

The Power Sources

The computer can be powered by either an AC/DC adapter or a battery pack.

AC/DC Adapter

Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ DC adapter will damage the computer and its components.

3 - 2 The Power Sources

1. Attach the AC/DC adapter to the DC-in jack on the left of the computer.

2. Plug the AC power cord into an outlet, and then conne ct the AC power co rd to the AC/DC adapter.

3. Raise the lid/LCD to a comfortable viewing angle.

4. Press the power button to turn “On”.

Battery

The battery allows you to use your computer while you are on the road or when an electrical outlet is unavailable. Battery life varies depending on the applications and the configuration you're using. To increase battery life, let the battery discharge completely before recharging (see “Battery FAQ” on page 3 - 18).

We recommend that you do not remove the battery. For more information on the battery, please refer to “Battery Information” on page 3 - 14.

Turning On the Computer



Power Button as Stand by or Hibernate Button

You can use the OS’s “Power Options” control panel to set the power button to send the system into Stand by or Hibernate mode (see your OS’s documentation, or “Configuring

the Power Buttons” on page 3 - 9 for details).

Now you are ready to begin using your computer. To turn it on simply press the power button on the front panel.

When the computer is on, you can use the power button as a Stand by/Hibernate/ Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and holding the power button for longer than this will shut the computer down). Use Power Options (Hardware and Sound) in the Windows control panel to configure this feature.

Power Management

Turning On the Computer 3 - 3

Power Management

Figure 3 - 1

Shut Down/Restart

Charms Bar Desktop App Start Screen

Shutting the Computer Down

Note that you should always shut your computer down by choosing the Shut down

command as this will help prevent hard disk or system problems. Use the Shut down or sign out item in the Context Menu (right-click the lower left corner of the screen

to bring up the menu). You can also use the Power Menu in Settings in the Windows 8.1 Charms Bar. If

you want to add Hibernate/Sleep to the Power Menu see “Adding Hibernate/Sleep

to the Power Menu” on page 3 - 10.

3 - 4 Shutting the Computer Down

Power Plans



Resuming

Operation

See Table 3 - 1, on

page 3 - 11 for informa-

tion on how to resume from a power-saving state.

Password

It is recommended that you enable a password on system resume in order to protect your data.

Figure 3 - 2

Power Plan

Advanced Settings

The computer can be configured to conserve power by means of power plans. You can use (or modify) an existing power plan, or create a new one.

The settings may be adjusted to set the display to turn off after a specified time, and to send the computer into Sleep after a period of inactivity.

Click Change plan settings and then click Change advanced power settings to access further configuration options in Advanced Settings.

Power Management

Power Plans3-5

Power Management

Figure 3 - 3

Power Plans

Click to Show/Hide additional power plans

Each Windows power plan will also adjust the processor performance of your machine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power).

Choose High performance (you may need to click Show additional plans to view the High performance plan) for maximum performance when the computer is powered from an AC power source. Choose the Power saver (bear in mind that this scheme may slow down the overall performance of the computer in order to save power) for maximum power saving when the computer is battery (DC power) powered.

3 - 6 Power Plans

Power-Saving States



Wake On LAN

Support

Wake-On-LAN is only supported from Sleep or

Hibernate states in Windows.

If you require your computer to wake up from network activity in Windows then make sure that the computer is either in Sleep or Hiber- nate.

Wake-On-LAN is not supported from Shutdown states in Win- dows .

You can use power-saving states to stop the computer’s operation and restart where you left off. Win 8.1 uses the Sleep, Hibernate and Shut Down power-saving states.

Sleep

In Sleep all of your work, settings and preferences are saved to memory before the system sleeps. When you are not using your computer for a certain length of time, which you specify in the operating system, it will enter Sleep to save power.

The PC wakes from Sleep within seconds and will return you to where you last left off (what was on your desktop) without reopening the application(s) and file( s) you last used.

If your mobile PC in Sleep is running on battery power the system will use only a minimum amount of power. After an extended period the system will save all the information to the hard disk and shut the computer down before the battery becomes depleted.

To add Sleep to the Power Menu see “Adding Hibernate/Sleep to the Power

Menu” on page 3 - 10.

Power Management

Power-Saving States 3 - 7

Power Management

Figure 3 - 4

Power Menu

Hibernate

Hibernate uses the least amount of power of all the power-saving states and saves

all of your information on a part of the hard disk before it turns the system off. If a power failure occurs the system can restore your work from the hard disk; if a power failure occurs when work is saved only to memory, then the work will be lost. Hi- bernate will also return you to where you last left off within seconds. You should put your mobile PC into Hibernate if you will not use the computer for a period of time, and will not have the chance to charge the battery. To add Hibernate to the Power Menu see “Adding Hibernate/Sleep to the Power Menu” on page 3 - 10.

Shut down

You should Shut down the computer if you plan to install new hardware (don’t forget to remove the battery and follow all the safety instructions in Chapter 6), plan to be away from the computer for several days, or you do not need it to wake up and run a scheduled task. Returning to full operation from Shut down takes longer than from Sleep or Hibernate.

3 - 8 Power-Saving States

Configuring the Power Buttons



Password

Protection

It is recommended that you enable a password on wake up in order to protect your data.

However you can disable this setting from the Power Options menu by clicking Require a

password on wakeup

in the left menu, and selecting the options (click

Change settings that are currently unavailable).

Figure 3 - 5

Power Options

Define Power

Buttons

The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the computer in to a power-saving state. Click Choose what the power buttons do on the left menu in Power Options to bring up the menu.

Power Management

Configuring the Power Buttons 3 - 9

Power Management

Figure 3 - 6

Power Options

Define Power

Buttons - Shutdown

Settings

Adding Hibernate/Sleep to the Power Menu

Add Hibernate/Sleep to the Power Menu as follows.

1. Go to the Power Options (Hardware and Sound) control panel.

2. Click “Change settings that are currently unavailable” .

3. Click Choose what the power buttons do.

4. Click to put a tick in the Hibernate/Sleep box under Shutdown settings.

5. Click Save Changes and close the control panel.

3 - 10 Configuring the Power Buttons

Resuming Operation

Table 3 - 1

Resuming

Operation



Closing the Lid

If you have chosen to send the computer to Sleep when the lid is closed, raising the lid will wake the system up.



Power Button

When the computer is on, you can use the power button as a Sleep/Hibernate/Shut Down hot key button when it is pressed for less than 4 seconds (pressing and holding the power button for longer than this will force the computer to shut down).

You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (Fn + F4 key combo).

Power Status

Power Off Off Press the Power Button

Icon Color

To Resume

Power Management

Sleep Blinking Green

Press the Sleep Button (Fn + F4 Key Combo)

Off (battery)

Hibernate

Orange (AC/DC adapter)

Display Turned Off Green Press a Key or Move the Mouse/Touchpad

Press the Power Button

Configuring the Power Buttons 3 - 11

Power Management



Power Conservation

Modes

The Energy Star setting will result in maximum power saving, but with the possible loss of some performance.

Setting the mode to Bal- ance will give power saving matched with performance.

Performance will give optimum computer performance but with less power conservation.

Figure 3 - 7

Control Center

Power Conservation Modes

This system supports Energy Star power management features that place computers (CPU, hard drive, etc.) into a low-power sleep modes after a designated period of inactivity. Adjust Power Conservation Modes from the Control Center:

1. Press the Fn + Esc key combination to toggle the Control Center on/off.

2. Click either the Performance, Balanced or Energy Star button.

3. Click in a blank area of the icon or press a key on the keyboard to exit Power

Conservation Mode without making any changes.

3 - 12 Configuring the Power Buttons

Ctrl + Alt + Delete Key Combination

Figure 3 - 8

Ctrl + Alt + Delete

You can use the CTRL + ALT + DEL key combination from almost any of the Windows 8 interfaces/Apps to bring up a full-screen displaying Lock, Switch User, Log

off, Change a password and Task Manager options. If you click the Power icon in the lower right corner of the screen a power management option menu appears to display Sleep, Shut down, and Restart.

Power Management

To fully control all the power options (including Hibernate mode) go to the Power Options control panel and configure the power button, sleep button and lid to per-

form the function selected.

Configuring the Power Buttons 3 - 13

Power Management



Low Battery

Warning

When the battery is critically low, immediately connect the AC/DC adapter to the computer or save your work, otherwise, the unsaved data will be lost when the power is depleted.

Figure 3 - 9

Battery Icon

(Notification Area) &

Battery Advanced

Settings

Battery Information

Follow these simple guidelines to get the best use out of your battery.

Battery Power

Your computer’s battery power is dependent upon many factors, including the programs you are running, and peripheral devices attached. You can set actions to be taken (e.g. Shut down, Hibernate etc.), and set critical and low battery levels from power plan Change plan settings > Change advanced power settings (see Figure

3 - 3 on page 3 - 6).

Click the battery icon in the notification area to see the current battery level and charge status.

3 - 14 Battery Information

Conserving Battery Power



Windows Mobility

Center

The Windows Mobility Center control panel

provides an easy point of access for information on battery status, power plans used and wireless device status etc.

Figure 3 - 10

Windows Mobility

Center

•Use a power plan that conserves power (e.g Power saver), however note that

this may have an affect on computer performance.

• Lower the brightness level of the LCD display. The system will decrease LCD brightness slightly to save power when it is not powered by the AC/DC adapter.

• Reduce the amount of time before the display is turned off.

• Close wireless, Bluetooth, modem or communication applications when they are not being used.

• Disconnect/remove any unnecessary external devices e.g. USB devices, ExpressCards etc.

Power Management

Battery Information 3 - 15

Power Management



Bottom Cover

Removal Warning

Do not remove any cover(s) and /or screw(s) for the purposes of device upgrade as this may violate the terms of your warranty.

If you need to replace/ remove the hard disk for any reason, please contact your distributor/supplier for further information.

Battery Life

Battery life may be shortened through improper maintenance. To optimize the life

and improve its performance, fully discharge and recharge the battery at least once every 30 days.

3 - 16 Battery Information

We recommend that you do not remove the battery yourself (see sidebar).

New Battery

Always completely discharge, then fully charge, a new battery (see “Battery FAQ”

on page 3 - 18 for instructions on how to do this).

Recharging the Battery with the AC/DC Adapter

The battery pack automatically recharges when the AC/DC adapter is attached and plugged into an electrical outlet. If the computer is powered on, and in use, it will take several hours to fully recharge the battery. When the computer is turned off but plugged into an electrical outlet, battery charge time is less. Refer to “LED Indica-

tors” on page 1 - 8 for information on the battery charge status, and to “Battery Information” on page 3 - 14 for more information on how to maintain and properly

recharge the battery pack.

Proper handling of the Battery Pack



Caution

Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type recommended by the manufacturer. Discard used battery according to the manufacturer’s instructions.



Damaged Battery Warning

Should you notice any physical defects (e.g. the battery is bent ou t of shape after being dropped), or any unusual smells emanating from the notebook battery, shut your computer down immediately and contact your distributor/supplier. If the battery has been dropped we do not recommend using it any further, as even if the comp uter continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire. It is recommended that you replace your computer battery every two years.

• DO NOT disassemble the battery pack under any circumstances

• DO NOT expose the battery to fire or high temperatures, it may explode

• DO NOT connect the metal terminals (+, -) to each other

Power Management

Battery Information 3 - 17

Power Management

Figure 3 - 11

Power Plan Create

Battery FAQ

How do I completely discharge the battery?

Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.

1. Save and close all files and application s.

2. Create a power plan for discharging the battery and set all the options to Never.

3 - 18 Battery Information

Clevo W310CZ User guide For Windows 8.1

Specifications and Main Features

Frequently Asked Questions

User Manual

Preface

Trademarks

R&TTE Directive

ErP Off Mode Power Consumption Statement:

CE Marking

FCC Statement

(Federal Communications Commission)

FCC RF Radiation Exposure Statement:

Instructions for Care and Operation

Power Safety

Polymer Battery Precautions

Battery Precautions

Cleaning

Servicing

Travel Considerations

Packing

On the Road

Developing Good Work Habits

Lighting

LCD Screen Care

LCD Electro-Plated Logos

Chapter 1: Quick Start Guide

Overview

Advanced Users

Beginners and Not-So-Advanced Users

Warning Boxes

Not Included

System Software

Model Differences

System Startup

System Map: LCD Panel Open

LED Indicators

Keyboard

Keyboard Shortcuts

Function/Hot Key Indicators

Control Center

System Map: Front & Left Views

System Map: Right & Rear Views

System Map: Bottom View

Removing the Battery

3G Module USIM Card Installation

Windows Touch Screen Controls/Gestures

Touch Keyboard

Windows 8.1 Control Panel

Windows 8.1 Start Screen & Desktop

Apps & Tiles

Desktop Application

The Charms Bar

Windows 8.1 Control Panel

Windows 8.1 Taskbar

Video Features

Power Options

Running Apps

Chapter 2: Features & Components

Overview

Hard Disk Drive

Multi-In-1 Card Reader

Touchpad and Buttons/Mouse

Finger Sensing Pad Configurator

Audio Features

Chapter 3: Power Management

Overview

The Power Sources

AC/DC Adapter

Battery

Turning On the Computer

Shutting the Computer Down

Power Plans

Power-Saving States

Sleep

Hibernate

Shut down

Configuring the Power Buttons

Resuming Operation

Power Conservation Modes

Battery Information
