Preface
R&TTE Directive
This device is in compliance with the essential requirements and other relevant provisions of the R&TTE Directive 1999/5/EC.
This device will be sold in the following EEA countries: Austria, Italy, Belgium, Liechtenstein, Denmark, Luxembourg, Finland, Netherlands, France, Norway, Germany, Portugal, Greece, Spain, Iceland, Sweden, Ireland,
United Kingdom, Cyprus, Czech Republic, Estonia, Hungary, Latvia, Lithuania, Malta, Slovakia, Poland, Slovenia.
EuP-Standby and Off Mode Power Consumption Statement:
The figures below note the power consumption of this computer in compliance with European Commission (EC)
regulations on power consumption in off mode or standby mode:
•Standby Mode < 2W
•Off Mode < 1W
II
Preface
CE Marking
This device has been tested to and conforms to the regulatory requirements of the European Union and has attained CE Marking. The CE Mark is a conformity marking consisting of the letters “CE”. The CE Mark applies
to products regulated by certain European health, safety and environmental protection legislation. The CE Mark
is obligatory for products it applies to: the manufacturer affixes the marking in order to be allowed to sell his
product in the European market.
This product conforms to the essential requirements of the R&TTE directive 1999/5/EC in order to attain CE
Marking. A notified body has determined that this device has properly demonstrated that the requirements of the
directive have been met and has issued a favorable certificate of expert opinion. As such the device will bear the
notified body number 0560 after the CE mark.
The CE Marking is not a quality mark. Foremost, it refers to the safety rather than to the quality of a product.
Secondly, CE Marking is mandatory for the product it applies to, whereas most q uality marking s are vo lu ntary.
III
Preface
FCC Statement
(Federal Communications Commission)
You are cautioned that changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
•Re orient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the service representative or an experienc ed radio/TV technician for help.
Operation is subject to the following two conditions:
1.This device may not cause interference.
And
2.This device must accept any interference, including interfer ence that may cause undesired operation of the
device.
IV
FCC RF Radiation Exposure Statement:
Warning
Use only shielded cables to connect I/O devices to this equipment. You are cautioned that changes or modifications not expressly approved by the manufacturer for compliance with the above standard s could void your authority to operate the
equipment.
If your purchase option includes both Wireless LAN and 3G modules, then the appropriate antenna s will be installed. Note
that In order to comply with FCC RF exposure compliance requirements, the antenna must not be co -located or o perate in
conjunction with any other antenna or transmitter.
Important Notice - 3G & Bluetooth/Wireless LAN Modules
In order to comply with FCC regulations you should NOT operate the 3G module and the Bl uetoo th/Wirele ss LAN modules
at the same time as this may disrupt radio frequency, and cause interference. When the 3G module is p owered on, make
sure that the Bluetooth/Wireless LAN modules are powered off.
1.This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
2.This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator
and your body.
Preface
V
Preface
IMPORTANT SAFETY INSTRUCTIONS
Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury
to persons when using any electrical equipment:
1.Do not use this product near water, for example n ear a ba th tub, wash bowl, kitchen sink or laundry tu b, in a wet
basement or near a swimming pool.
2.Avoid using this equipment with a telephone line (other than a cordless type) during an electrical storm. There
may be a remote risk of electrical shock from lightning.
3.Do not use the telephone to report a gas leak in the vicinity of the leak.
4.Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may
explode. Check with local codes for possible special disposal instructions.
5.This product is intended to be supplied by a Listed Power Unit with an AC Input of 100 - 240V, 50 - 60Hz, DC
Output of 19V, 4.74A (90 Watts) minimum AC/DC Adapter.
This Computer’s Optical Device is a Laser Class 1 Product
VI
Preface
Instructions for Care and Operation
The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions:
1.Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged.
Do not expose the computer
to any shock or vibration.
Do not place it on an unstable
surface.
Do not place anything heavy
on the computer.
2.Keep it dry, and don’t overheat it. Keep the computer and power supply away from any kind of heating ele-
ment. This is an electrical appliance. If water or any other liquid gets into it, the computer could be badly damaged.
Do not expose it to excessive
heat or direct sunlight.
Do not leave it in a place
where foreign matter or moisture may affect the system.
Don’t use or store the computer in a humid environment.
Do not place the computer on
any surface that will block the
Vents/Fan Intakes.
VII
Preface
3.Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other
strong magnetic fields. These can hinder proper performance and damage your data.
4.Follow the proper workin g procedu res for t he computer. Shut the computer down properly and don’t forget
to save your work. Remember to periodically save your data as data may be lost if the battery is depleted.
Do not turn off the power
until you properly shut down
all programs.
Do not turn off any peripheral
devices when the computer is
on.
5.Take care when using peripheral devices.
Use only approved brands of
peripherals.
VIII
Do not disassemble the computer by yourself.
Unplug the power cord befor e
attaching peripheral devices.
Perform routine maintenance
on your computer.
Power Safety
Power Safety
Warning
Before you undertake
any upgrade procedures, make sure that
you have turned off the
power, and disconnected all peripherals
and cables (including
telephone lines and
power cord).
You must also remove
your battery in order to
prevent accidentally
turning the machine
on. Before removing
the battery disconnect the AC/DC
adapter from the
computer.
The computer has specific power requirements:
•Only use a power adapter approved for use with this computer.
•Your AC/DC adapter may be designed for international travel but it still requires a
steady , uninterru pted power suppl y. If you are unsure of your local power specifications,
consult your service representative or local power company.
•The power adapter may have either a 2-prong or a 3-prong grounded plug. The third
prong is an important safety feature; do not defeat its purpose. If you do not have access
to a compatible outlet, have a qualified electrician install one.
•When you want to unplug the power cord, be sure to disconnect it by the plug head, not
by its wire.
•Make sure the socket and any extension cord(s) you use can support the total current
load of all the connected devices.
•Before cleaning the computer, make sure it is disconnected from any external power
supplies (i.e. AC/DC adapter or car adapter).
Do not plug in the power
cord if you are wet.
Do not use the power cord if
it is broken.
Do not place heavy objects
on the power cord.
Preface
IX
Preface
Polymer Battery Precautions
Note the following information which is specific to polymer batteries only, and where applicable, this overrides
the general battery precaution information overleaf.
•Polymer batteries may experience a slight expansion or swelling, however this is part of the battery’s safety mecha-
nism and is not a cause for concern.
•Use proper handling procedures when using polymer batteries. Do not use polymer batteries in high ambient tempera-
ture environments, and do not store unused batteries for extended periods.
See also the general battery precautionary information overleaf for further information.
X
Battery Precautions
Battery Disposal & Caution
The product that you have purchased contains a rechargeable battery. The battery is recyclable. At the end of its useful life,
under various state and local laws, it may be illegal to dispose of this battery in to the municipal waste stream. Check with
your local solid waste officials for details in your area for recycling options or proper disposal.
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalen t type recommended by the
manufacturer. Discard used battery according to the manufacturer’s instructions.
•Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer.
•Do not remove any batteries from the computer while it is powered on.
•Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even
if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly
result in fire.
•If you do not use the battery for an extended period, then remove the battery from the computer for storage.
•Recharge the batteries using the notebook’s system. Incorrect recharging may make the battery explode.
•Do not try to repair a battery pack. Refer any battery pack repa ir or replacemen t to you r service repre sentati ve or qu al-
ified service personnel.
•Keep children away from, and promptly dispose of a damaged battery. Always dispose of batteries carefully. Batteries
may explode or leak if exposed to fire, or improperly handled or discarded.
•Keep the battery away from metal appliances.
•Affix tape to the battery contacts before disposing of the battery.
•Do not touch the battery contacts with your hands or metal objects.
Preface
XI
Preface
Removal Warning
When removing any cover(s) and screw(s) for the purposes of device upg rade, remember to replace the cover(s) and
screw(s) before restoring power to the system.
Also note the following when the cover is removed:
•Hazardous moving parts.
•Keep away from moving fan blades.
Cleaning
Do not apply cleaner directly to the computer; use a soft clean cloth.
Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer.
Servicing
Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the
computer to electric shock. Refer all servicing to authorized service personnel. Unplug the computer from the
power supply. Then refer servicing to qualified service personnel under any of the following conditions:
•When the power cord or AC/DC adapter is damaged or frayed.
•If the computer has been exposed to rain or other liquids.
•If the computer does not work normally when you follow the operating instructions.
•If the computer has been dropped or damaged (do not touch the poisonous liquid if the LCD panel breaks).
•If there is an unusual odor, heat or smoke coming from your computer.
XII
Preface
Power Off Before Traveling
Make sure that your notebook is completely powered off before putting it into a travel bag (or any such container). Putting a
notebook which is powered on in a travel bag may cause the vent(s)/fan intake(s)/outlet(s) to be blocked. To prev ent your
computer from overheating make sure nothing blocks the vent(s)/fan intake(s)/outlet(s) while the computer is in use.
Travel Considerations
Packing
As you get ready for your trip, run through this list to make sure the system is ready to go:
1.Check that the battery pack and any spares are fully charged.
2.Power off the computer and peripherals.
3.Close the display panel and make sure it’s latched.
4.Disconnect the AC/DC adapter and cables. Stow them in the carrying bag.
5.The AC/DC adapter uses volt ages from 100 to 240 volt s so you won’t need a second volt age adapter. However,
check with your travel agent to see if you need any socket adapters.
6.Put the notebook in its carrying bag and secure it with the bag’s straps.
7.If you’re taking any perip herals (e.g. a printer, mouse or digital camera), pack them and those devices’ adapters
and/or cables.
8.Anticipate customs - Some jurisdictions may have import restrictions or require proof of ownership for both
hardware and software. Make sure your documents are prepared.
XIII
Preface
On the Road
In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting,
keep these points in mind:
Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very
common. Don’t check it with normal luggage. Baggage handlers may not be sufficiently careful. Avoid knocking the computer against hard objects.
Beware of Electromagnetic fields - Devices such as metal detectors & X-ray machines can damage the computer, hard disk, floppy disks, and other media. They may also destroy any stored data - Pass your computer and
disks around the devices. Ask security officials to hand-inspect them (you may be asked to turn it on). Note:
Some airports also scan luggage with these devices.
Fly safely - Most airlines have regulations about the use of computers and other electronic devices in flight.
These restrictions are for your safety, follow them. If you stow the notebook in an overhead compartment, make
sure it’s secure. Contents may shift and/or fall out when the compartment is opened.
Get power where you can - If an electrical outlet is available, use the AC/DC adapter and keep your battery(ies)
charged.
Keep it dry - If you move quickly from a cold to a warm location, water vapor can condense inside the computer.
Wait a few minutes before turning it on so that any moisture can evaporate.
XIV
Preface
Developing Good Work Habits
Developing good work habits is important if you need to work in fron t of the computer for long periods of time.
Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or
other joints. The following are some tips to reduce the strain:
•Adjust the height of the chair and /or desk so that the ke yboard is a t or slightly below the level
of your elbow. Keep your forearms, wrists, and hands in a relaxed position.
•Your knees should be slight ly higher than your hips. Place your feet flat on the floor or on a
footrest if necessary.
•Use a chair with a back and adjust it to support your lower back comfortably.
•Sit straight so that your knees, hips and elbows form approximately 90-degree angles when
you are working.
•Take periodic breaks if you are using the computer for long periods of time.
Remember to:
•Alter your posture frequently.
•Stretch and exercise your body several times a day.
•Take periodic breaks when you work at the computer for long periods of time. Frequent and
short breaks are better than fewer and longer breaks.
XV
Preface
Lighting
Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and
shoulders.
•Position the display to avoid glare or reflections from overhead lighting or outside sources of light.
•Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly.
•Position the display directly in front of you at a comfortable viewing distance.
•Adjust the display-viewing angle to find the best position.
LCD Screen Care
To prevent image persistence on LCD monitors (caused by the continuous display of graphics on the screen for
an extended period of time) take the following precautions:
•Set the Windows Power Plans to turn the screen off after a few minutes of screen idle time.
•Use a rotating, moving or blank screen saver (this prevents an image from being displayed too long).
•Rotate desktop background images every few days.
•Turn the monitor off when the system is not in use.
LCD Electro-Plated Logos
Note that in computers featuring a raised LCD electro-plated logo, the logo is covered by a protective adhesive.
Due to general wear and tear, this adhesive may deteriorate over time and the exposed logo may develop sharp
edges. Be careful when handling the computer in this case, and avoid touching the raised LCD electro-plated
logo. Avoid placing any other items in the carrying bag which may rub against the top of the computer during
transport. If any such wear and tear develops contact your distributor/supplier.
Instructions for Care and Operation ......................................................................................................... VII
Power Safety ...............................................................................................................................................IX
Cleaning .................................................................................................................................................... XII
Servicing ................................................................................................................................................... XII
Not Included ..............................................................................................................................................1-3
System Software ........................................................................................................................................1-4
System Startup ...........................................................................................................................................1-5
Model Differences .....................................................................................................................................1-6
XVII
Preface
LCD Panel Open - Models A/C .................................................................................................................1-7
LCD Panel Open - Models B/D .................................................................................................................1-8
LED Indicators ...........................................................................................................................................1-9
Control Center .........................................................................................................................................1-13
Front & Left Views - Models A/C ...........................................................................................................1-14
Front & Left Views - Models B/D ...........................................................................................................1-15
Right & Rear Views - Models A/C ..........................................................................................................1-16
Right & Rear Views - Models B/D ..........................................................................................................1-17
Video Features .........................................................................................................................................1-22
Power Options .........................................................................................................................................1-26
Hard Disk Drive .........................................................................................................................................2-2
Audio Features .........................................................................................................................................2-18
The Power Sources ....................................................................................................................................3-2
Turning On the Computer ..........................................................................................................................3-3
Power Plans ...............................................................................................................................................3-4
Power-Saving States ..................................................................................................................................3-6
Shut down ..................................................................................................................................................3-7
Configuring the Power Buttons .................................................................................................................3-8
Power Conservation Modes .....................................................................................................................3-10
Battery Information .................................................................................................................................3-11
Conserving Battery Power .......................................................................................................................3-12
Battery Life ..............................................................................................................................................3-13
New Battery .............................................................................................................................................3-13
Recharging the Battery with the AC/DC Adapter ...................................................................................3-13
Proper handling of the Battery Pack ........................................................................................................3-14
What to Install ............................................................................................................................................4-1
User Account Control ................................................................................................................................4-5
Windows Security Message .......................................................................................................................4-5
New Hardware Found ................................................................................................................................4-5
Video (VGA) .............................................................................................................................................4-6
NVIDIA Video (VGA) ..............................................................................................................................4-6
XX
Preface
LAN ...........................................................................................................................................................4-6
Hot Key ......................................................................................................................................................4-7
USB 3.0 ......................................................................................................................................................4-7
MEI Driver .................................................................................................................................................4-7
The Setup Utility ........................................................................................................................................5-2
Failing the POST .......................................................................................................................................5-3
Main Menu .................................................................................................................................................5-5
System Time & Date (Main Menu) ...........................................................................................................5-5
Advanced Menu .........................................................................................................................................5-7
Advanced Chipset Control (Advanced Menu) ..........................................................................................5-7
Bluetooth Power Setting (Advanced Menu > Advanced Chipset Control) ...............................................5-8
Security Menu ..........................................................................................................................................5-10
Set Supervisor Password (Security Menu) ..............................................................................................5-10
Set User Password (Security Menu) ........................................................................................................5-11
Password on boot: (Security Menu) ........................................................................................................5-11
Boot Menu ...............................................................................................................................................5-12
Exit Menu ................................................................................................................................................5-14
When Not to Upgrade ................................................................................................................................6-2
Removing the Battery ................................................................................................................................6-4
Upgrading the Hard Disk Drive .................................................................................................................6-5
XXII
Preface
Upgrading the Optical (CD/DVD) Device ................................................................................................6-8
Removing the Optical Device for Model A/C Computers ........................................................................6-9
Removing the Optical Device for Model B/D Computers ......................................................................6-11
Upgrading the System Memory (RAM) ..................................................................................................6-13
PC Camera Module ....................................................................................................................................7-2
PC Camera Driver Installation ...................................................................................................................7-3
Wireless LAN Module .............................................................................................................................7-10
3rd Party 802.11b/g/n Driver Installation ................................................................................................7-11
User Options ............................................................................................................................................7-65
Text Messaging Service (SMS) ...............................................................................................................7-67
Basic Hints and Tips ..................................................................................................................................8-2
Backup and General Maintenance .............................................................................................................8-3
Video Driver Installation ..........................................................................................................................C-1
Video (VGA) ............................................................................................................................................C-1
NVIDIA Video (VGA) .............................................................................................................................C-1
Set PhysX® Configuration .....................................................................................................................C-22
Video Settings .........................................................................................................................................C-23
Video Controller .......................................................................................................................................D-4
Communication .........................................................................................................................................D-5
Features .....................................................................................................................................................D-6
Power Management ..................................................................................................................................D-6
Power ........................................................................................................................................................D-6
Operating System ......................................................................................................................................D-6
This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the
computer and to getting your system started. The remainder of the manual covers the following:
• Chapter 2A guide to using some of the main features of the computer e.g. the storage devices (hard disk,
• Chapter 4The installation of the drivers and utilities essential to the operation or improvement of some of the
computer’s subsystems.
• Chapter 5An outline of the computer’s built-in software or BIOS (Basic Input Output System).
• Chapter 6 Instructions for upgrading your computer.
• Chapter 7 A quick guide to the computer’s PC Camera, Wireless LAN, 3G and Bluetooth & WLAN
Combo modules (some of which may be optional depending on your purchase configuration).
• Chapter 8 A troubleshooting guide.
• Appendix A Definitions of the interface, ports/jacks which allow your computer to communicate with external
devices.
• Appendix B Information on the Control Center application.
• Appendix C Information on the videodriver controls.
• Appendix D The computer’s specification.
1
Overview 1 - 1
1
Notes
Check the light colored
boxes with the mark
above to find detailed information about the computer’s features.
Quick Start Guide
Advanced Users
If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful
to refer to “What to Install” on page 4 - 1, “BIOS Utilities” on page 5 - 1 and “Upgrading The Computer” on
page 6 - 1 in the reminder of the User’s Manual. You may also find the notes marked with a
of interest to you.
Beginners and Not-So-Advanced Users
If you are new to computers (or do not have an advanced knowledge of them) then
the information contained in the Quick Start Guide should be enough to get you up
and running. Eventually you should try to look through all the documentation (more
detailed descriptions of the functions, setup and system controls are covered in the
remainder of the User’s Manual), but do not worry if you do not understand everything the first time. Keep this manual nearby and refer to it to learn as you go. You
may find it useful to refer to the notes marked with a
as indicated in the margin.
For a more detailed description of any of the interface ports and jacks see “Interface
(Ports & Jacks)” on page A - 1.
Warning Boxes
No matter what your level please pay careful attention to the warning and safety information indicated by the
symbol. Also please note the safety and handling instructions as indicated in the Preface.
1 - 2 Overview
Quick Start Guide
Drivers
If you are installing new system software, or are re-configuring your computer for a different system, you will need to install
the drivers listed in “Drivers & Utilities” on page 4 - 1. Drivers are programs which act as an interface between the computer and a hardware component e.g. a wireless network module. It is very important that you install the drivers in the order
listed. You will be unable to use most advanced controls until the necessary drivers and utilities are properly installed. If
your system hasn’t been properly configured (your service representative may have already done that for you); refer to
Chapter 4 for installation instructions.
Ports and Jacks
See “Notebook Ports and Jacks” on page A - 2 for a description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc.
Not Included
Operating Systems (e.g. Windows 7) and applications (e.g. word processing, spreadsheet and database programs) have their own manuals, so please consult the appropriate manuals.
1
Overview 1 - 3
1
Windows OS
In order to run Windows 7 without limitations or decreased performance, your computer requires a minimum 1GB of system memory (RAM), however if you are running Windows 7 64 bit your computer requires a minimum 2GB of system
memory (RAM).
Quick Start Guide
System Software
Your computer may already come with system software pre-installed. Where this is not the case, or where you
are re-configuring your computer for a different system, you will find the Windows 7 (with Service Pack 1 in-stalled) operating system is supported.
Note: In order to run Windows 7 (SP1) without limitations or decreased performance, your computer requires a
minimum 1GB of system memory (RAM).
1 - 4 Overview
Quick Start Guide
Shutdown
Note that you should always shut your computer down by choosing the
Shut Down command
from the bottom right of
the Start menu in Win-dows. This will help
prevent hard disk or
system problems.
130°
System Startup
1.Remove all packing materials.
2.Place the computer on a stable surface.
3.Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports.
4.Attach the AC/DC adapter to the DC-In jack on the left of the computer, then plug the AC power cord into an
outlet, and connect the AC power cord to the AC/DC adapter.
5.Use one hand to raise the
hand (as illustrated in Figure 1 - 1 below) to support the base of the computer (Note: Never lift the computer by
the lid/LCD).
lid/LCD to a comfortable viewing angle (
Figure 1 - 1 - Opening the Lid/LCD & Computer with AC/DC Adapter Plugged-In
do not exceed 130 degrees
);
use the other
1
System Startup 1 - 5
1
Quick Start Guide
Model Differences
This notebook series includes five models that vary slightly in color and general appearance. The main differences between the models are indicated in the table below (see “Specifications” on page D - 1 for full details).
Both models also include distinct design styles that may appear slightly different from those pictured in this manual.
FeatureModel AModel BModel CModel D
Display
Type
Video
Controller
3G Module
Dimensions
& Weight
15.6” / 39.62cm
16:9 Backlit Panel
Intel® Integrated GPU and NVIDIA® GeForceGT 635M Intel® Integrated GPU and NVIDIA® GeForceGT 645M
UMTS/HSPDA-based 3G
Module
374mm (w) * 250mm (d)
* 14.3 - 37.2mm (h)
OR (Design Style
Dependent)
374mm (w) * 25.0mm (d)
* 20 - 37.2mm (h)
2.6 kg with ODD &
48.84WH Battery
1 - 6 Model Differences
17.3” / 43.94cm
16:9 Backlit Panel
N/A
413mm (w) * 270mm (d)
* 14 - 40.5mm(h)
3kg with ODD &
48.84WH Battery
15.6” / 39.62cm
16:9 Backlit Panel
UMTS/HSPDA-based 3G
374mm (w) * 250mm (d)
* 14.3 - 37.2mm (h)
OR (Design Style
374mm (w) * 25.0mm (d)
* 20 - 37.2mm (h)
2.6 kg with ODD & 48.84WH
Table 1 - 1 - Model Differences
Module
Dependent)
Battery
17.3” / 43.94cm
16:9 Backlit Panel
N/A
413mm (w) * 270mm (d)
* 14 - 40.5mm(h)
3kg with ODD &
48.84WH Battery
LCD Panel Open - Models A/C
Figure 1 - 2
LCD Panel Open
Models A/C
1.Built-in PC Camera
(
Optional
)
2.LCD
3.Power Button
4.LED Status
Indicators
5.Keyboard
6.*Built-In
Microphone
*Note that the
microphone location is
dependent upon your
model design
7.Touchpad &
Buttons
7
2
4
1
6
7
3
5
Wireless Device
Operation Aboard
Aircraft
The use of any portable electronic
transmission devices aboard aircraft is usually prohibited. Make
sure the module(s) are OFF if you
are using the computer aboard
aircraft.
Use the key combinations to toggle power to the 3G/WLAN/Blue-tooth modules, and check the
LED indicator or on-screen icon to
see if the modules are powered
on or not (see
Table , on
page 1 - 12
/ Table 1 - 2, on
page 1 - 9
).
Note that the Touchpad and Buttons valid operational area is that indicated within the red dotted lines
indicated on the right.
4
6
Quick Start Guide
1
LCD Panel Open - Models A/C 1 - 7
1
Figure 1 - 3
LCD Panel Open
Models B/D
1.Built-In PC Camera
(
Optional
)
2.LCD
3.Power Button
4.LED Status
Indicators
5.Keyboard
6.Built-In Microphone
7.Touchpad &
Buttons
Note that the Touchpad and
Buttons valid operational area
is that indicated within the red
dotted lines above.
7
2
1
7
3
5
Wireless Device
Operation Aboard
Aircraft
The use of any portable electronic transmission devices
aboard aircraft is usually prohibited. Make sure the module(s) are OFF if you are using
the computer aboard aircraft.
Use the key combinations to
toggle power to the WLAN/Bluetooth modules, and
check the LED indicator or onscreen icon to see if the modules are powered on or not
(see Table , on page 1 - 12/
Table 1 - 3, on page 1 - 9).
4
6
Quick Start Guide
LCD Panel Open - Models B/D
1 - 8 LCD Panel Open - Models B/D
Quick Start Guide
1
LED Indicators
The LED indicators on the computer display helpful
information about the current status of the computer.
IconColorDescription
OrangeDC Power is Plugged In
GreenThe Computer is On
Blinking Green
OrangeThe Battery is Charging
GreenThe Battery is Fully Charged
Blinking Orange
Table 1 - 2 - LED Power Indicators
The Computer is in Sleep
Mode
The Battery Has Reached
Critically Low Power Status
IconColorDescription
Green
Orange
GreenHard Disk Activity
GreenNumber Lock Activated
Green
GreenCaps Lock Activated
The (optional) Wireless LAN
Module is Powered On
The (optional) Bluetooth Module
is Powered On
Scroll Lock Activated (to activate
press Fn & Scr Lk)
Table 1 - 3 - LED Status Indicators
LED Indicators 1 - 9
1
Other Keyboards
If your keyboard is damaged or you just want to
make a change, you can
use any standard USB
keyboard. The system will
detect and enable it automatically. However special functions/hot-keys
unique to the system’s
regular keyboard may not
work.
NumLk & ScrLk
Hold down the Fn Key
and either NumLk or
ScrLk to enable number
or scroll lock, and check
the LED indicator for status.
Numerical
Play/Pause Key
Function Keys
Toggle Key
3G
Module Power
NumLk &
ScrLk Keys
Fn Key
Keypad
Special Characters
Some software applications allow the number-keys to be used with Alt to produce special characters.
These special characters can only be produced by using the numeric keypad. Regular number keys (in
the upper row of the keyboard) will not work. Make sure that NumLk is on.
Quick Start Guide
Keyboard - Models A/C
The keyboard has an embedded numerical keypad for easy numeric data input, and
features function keys to allow you to change operational features instantly. See
1 - 10 Keyboard - Models A/C
Table , on page 1 - 12 for full function key combination details.
Figure 1 - 4 - Keyboard - Models A/C
Keyboard - Models B/D
Other Keyboards
If your keyboard is damaged or you just want to
make a change, you can
use any standard USB
keyboard. The system will
detect and enable it automatically. However special functions/hot-keys
unique to the system’s
regular keyboard may not
work.
NumLk & ScrLk
Hold down the Fn Key
and either NumLk or
ScrLk to enable number
or scroll lock, and check
the LED indicator for status.
Numerical
Play/Pause Key
Function Keys
NumLk &
ScrLk Keys
Fn Key
Keypad
Special Characters
Some software applications allow the number-keys to be used with Alt to produce special characters.
These special characters can only be produced by using the numeric keypad. Regular number keys (in
the upper row of the keyboard) will not work. Make sure that NumLk is on.
The keyboard has an embedded numerical keypad for easy numeric data input, and
features function keys to allow you to change operational features instantly. See
Table , on page 1 - 12 for full function key combination details.
Figure 1 - 5 - Keyboard - Models B/D
Quick Start Guide
Keyboard - Models B/D 1 - 11
1
1
Quick Start Guide
Function/Hot Key Indicators
The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition
to the basic function key combinations; visual indicators are available when the hot key utility is installed.
KeysFunctionKeysFunction
Fn + ~Play/Pause (in Audio/Video P ro g r am s)Fn + F8/F9Brightness Decrease/Incr e ase
Fn +
Fn + F1TouchPad Toggle Fn + F11WLAN Module Power Toggle
Fn + F2
Fn + F3Mute Toggle Fn + NumLkNumber Lock Toggle
Fn + F4Sleep ToggleFn + ScrLkScroll Lock Toggle
Fn + F5/F6
Fn + F7Display ToggleFn + EscToggle Control Center On/Off (see over)
3G Module Power Toggle*
(Press a key to or use TouchPad to turn on)
Volume Decrease/
Increase
Turn LCD Backlight Off
Fn + F10PC Camera Power Toggle
Fn + F12Bluetooth Module Power Toggle
Caps LockCaps Lock Toggle
Table 1 - 4 - Function & Hot Key Indicators
1 - 12 Function/Hot Key Indicators
Quick Start Guide
Control Center
Click on any button to turn any of the modules (e.g.
TouchPad, Camera) on/off.
Click on the power conservation modes to switch
between Performance, Balanced or Energy Star
modes (see page 3 - 10). To remove the Power
Conservation Modes screen just click in a blank
area of the icon or press a key on the keyboard.
Click on the buttons (or just click and hold the
mouse button) to adjust the slider for Brightness/
Volume.
Click on Display Switch and click to choose a display mode from the menu (see page C - 12).
Control Center
Press the Fn + Esc key combination, or double-click the icon in the notification area of the taskbar to
toggle the Control Center on/off. The Control Center gives quick access to frequently used controls and enables you to quickly turn modules on/off (see Appendix B for full details).
1
Table 1 - 5 - Control Center
Control Center 1 - 13
1
Figure 1 - 6
Front & Left Views
Models A/C
1.LED Power Indicators (see
Table 1 -
2, on page 1 - 9)
2.DC-In Jack
3.External Monitor
Port
4.RJ-45 LAN Jack
5.HDMI-Out Port
6.2 * USB 3.0 Ports
7.Vent/Fan Intake
8.e-SATA Port
9.Multi-In-1 Card
Reader
2
7
4
1
8
3
Multi-In-1 Card Reader
The card reader allows you to use the most popular digital storage card formats:
MMC (MultiMedia Card) / RS MMC
SD (Secure Digital) / Mini SD / SDHC / SDXC
MS (Memory Stick) / MS Pro / MS Duo
USB 3.0 Port OR USB 2.0 Port
This computer model series has two USB 3.0 ports on the left side of the computer. USB
3.0 ports are denoted by their blue color; USB 2.0 ports are colored black.
Note that USB 3.0 ports require a driver installation (see “USB 3.0” on page 4 - 7) and
does not support wake on USB.
9
5
6
6
Quick Start Guide
Front & Left Views - Models A/C
1 - 14 Front & Left Views - Models A/C
Front & Left Views - Models B/D
Figure 1 - 7
Front & Left Views
Models B/D
1.LED Power Indicators (see
Table 1 -
2, on page 1 - 9)
2.DC-In Jack
3.External Monitor
Port
4.RJ-45 LAN Jack
5.HDMI-Out Port
6.2 * USB 3.0 Ports
7.Vent/Fan Intake
8.e-SATA Port
9.Multi-In-1 Card
Reader
Multi-In-1 Card Reader
The card reader allows you to use the most popular digital storage card formats:
MMC (MultiMedia Card) / RS MMC
SD (Secure Digital) / Mini SD / SDHC / SDXC
MS (Memory Stick) / MS Pro / MS Duo
USB 3.0 Port OR USB 2.0 Port
This computer model series has two USB 3.0 ports on the left side of the computer. USB
3.0 ports are denoted by their blue color; USB 2.0 ports are colored black.
Note that USB 3.0 ports require a driver installation (see “USB 3.0” on page 4 - 7) and
does not support wake on USB.
3
4
5
6
7
6
9
2
8
1
Quick Start Guide
1
Front & Left Views - Models B/D 1 - 15
1
Figure 1 - 8
Right & Rear Views
Models A/C
1.Microphone-In
Jack
2.Headphone-Out
Jack
3.USB 2.0 Port
4.Optical Device
Drive Bay
5.Security Lock Slot
6.Battery
1 23
4
5
6
CD/DVD Emergency Eject
If you need to manually eject a CD/DVD (e.g. due to an unexpected power interruption) you may
push the end of a straightened paper clip into the emergency eject hole. Do not use a sharpened
pencil or any object that may break and become lodged in the hole. Don’t try to remove a floppy disk/
CD/DVD while the system is accessing it. This may cause the system to “crash”.
Disk Eject Warning
Don’t try to eject a CD/DVD while the system is accessing it. This may cause the system to “crash”.
Stop the disk first then eject it, or press the stop button twice.
Quick Start Guide
Right & Rear Views - Models A/C
1 - 16 Right & Rear Views - Models A/C
Right & Rear Views - Models B/D
Figure 1 - 9
Right & Rear Views
Models B/D
1.Microphone-In
Jack
2.Headphone-Out
Jack
3.USB 2.0 Port
4.Optical Device
Drive Bay
5.Security Lock Slot
6.Battery
CD/DVD Emergency Eject
If you need to manually eject a CD/DVD (e.g. due to an unexpected power interruption) you may
push the end of a straightened paper clip into the emergency eject hole. Do not use a sharpened
pencil or any object that may break and become lodged in the hole. Don’t try to remove a floppy disk/
CD/DVD while the system is accessing it. This may cause the system to “crash”.
Disk Eject Warning
Don’t try to eject a CD/DVD while the system is accessing it. This may cause the system to “crash”.
Stop the disk first then eject it, or press the stop button twice.
12
3
4
5
6
Quick Start Guide
1
Right & Rear Views - Models B/D 1 - 17
1
Figure 1 - 10
Bottom View
Models A/C
1.Battery
2.Component Bay
Cover
3.Vent/Fan Intake/
Outlet
4.Hard Disk Bay
Cover
5.Speakers
CPU
The CPU is not a user
serviceable part.
Overheating
To prevent your computer from overheating
make sure nothing blocks
the Vent/Fan Intake while
the computer is in use.
2
1
4
3
3
5
3
3
3
Battery Information
Always completely discharge, then fully charge, a new battery before using it. Completely
discharge and charge the battery at least once every 30 days or after about 20 partial discharges. See “Battery Information” on page 3 - 11 for full instructions.
5
Quick Start Guide
Bottom View - Models A/C
1 - 18 Bottom View - Models A/C
Bottom View - Models B/D
Figure 1 - 11
Bottom View
Models B/D
1.Battery
2.Component Bay
Cover
3.Fan Intake/Vent
4.Hard Disk Bay
Cover
5.Speakers
CPU
The CPU is not a user
serviceable part.
Overheating
To prevent your computer from overheating
make sure nothing
blocks the Vent/Fan Intake while the computer
is in use.
2
1
4
3
55
3
3
Battery Information
Always completely discharge, then fully charge, a new battery before using it. Completely
discharge and charge the battery at least once every 30 days or after about 20 partial discharges. See “Battery Information” on page 3 - 11 for full instructions.
3
Quick Start Guide
1
Bottom View - Models B/D 1 - 19
1
USIM Card
Orientation
Note that the USIM
card’s readable side
(with the gold-colored
contacts) should face
upwards as illustrated.
Quick Start Guide
3G Module USIM Card Installation
If you have included an optional 3G module in your purchase option (Factory Option for Model A & C Computers Only), follow the instructions below to install the USIM card (which will be provided by your service
provider), and then run the Wireless Manager application. See “Wireless Manager” on page 7 - 34 for instructions on installing the program etc.
1.Turn off the computer, and turn it over and then remove the battery (slide the latches in the direction indicated
below and slide the battery out).
2.Insert the USIM card (at the rea r of the batter y comp artment ) as ill ustrated below until it clicks fully into position,
and replace the battery.
Most of the control panels, utilities and programs within Windows 7 (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk
drive, and a shortcut will usually be placed in the Start menu and/or the desktop. Right-click the Start menu
icon , and then select Properties if you want to customize the appearance of the Start menu.
In many instances throughout this manual you will see an instruction to open the Control Panel. The ControlPanel is accessed from the Start menu, and it allows you to configure the settings for most of the key features
in Windows (e.g. power, video, network, audio etc.). Windows 7 provides basic controls for many of the features,
however many new controls are added (or existing ones are enhanced) when you install the drivers. To see all
controls it may be necessary to toggle off Category View to view the control panel icons.
3G Module USIM Card Installation 1 - 21
1
1
Quick Start Guide
Video Features
NVIDIA® Optimus™ Technology
NVIDIA® Optimus™ technology is a seamless technology designed to get best performance from the graphics
system while allowing longer battery life, without having to manually change settings. The computer will auto-matically switch between the integrated UMA (Unified Memory Architecture) GPU (iGPU) and the discrete
GPU (dGPU) when required by the applications in use.
You can switch display devices, and configure display options, from the Display control panel (in Appearances
and Personalization) in Windows 7 (see over). For more detailed video information see “Video Driver Con-
trols” on page C - 1.
1 - 22 Video Features
To access Display (Control Panel) and Screen Resolution in Windows:
1
2
1
2
1.Click Start and click Control Panel.
2.Click Display (icon) - In the Appearances and Personalization category.
3.Click Adjust Screen Resolution/Adjus t resolution.
4.Alternatively you can right-click the desktop and select Screen resolution.
5.Use the dropbox to select the screen Resolution (Figure 1 - 14).
6.Click Advancedsettings (Figure 1 - 14) to bring up the Advanced properties tabs.
Quick Start Guide
1
Figure 1 - 14 - Screen Resolution
Video Features 1 - 23
1
234
3
4
Quick Start Guide
To access the Intel(R) Graphics and Media Control Panel:
1.Click Advancedsettings (Figure 1 - 14 on page 1 - 23) in the Display Settings control panel in Windows.
2.Click Graphics Properties (button) (Figure 1 - 15) in the Intel Graphics & Media Control Panel tab.
OR
3.Right-click the desktop and select Graphics Properties from the menu.
OR
4.Click the icon (Figure 1 - 15) in the taskbar and select Graphics Properties from the menu.
OR
5.Access the Intel(R) Graphics and Media Control Panel from the Windows control panel in Classic V iew.
6.Choose the application mode (Basic, Advanced or Wizard) required.
Figure 1 - 15 - Intel Graphics and Media Control Panel
1 - 24 Video Features
To access the NVIDIA Control Panel:
5
6
5
6
1.Right-click the desktop and select NVIDIA Control Panel (Figure 1 - 16).
OR
2.Double-click the icon (Figure 1 - 16) in the Windows control panel.
Quick Start Guide
1
Figure 1 - 16 - NVIDIA Control Panel
Video Features 1 - 25
1
Quick Start Guide
Power Options
The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 1 - 19 ) allows you
to configure power management features for your computer. You can conserve power by means of power plans
and configure the options for the power button, sleep button, computer lid (when closed), display and sleep
mode from the left menu. Note that the Power saver plan may have an affect on computer performance.
Click to select one of the existing plans, or click Create a power plan in the left menu and select the options to
create a new plan. Click Change plan settings and click Change advanced power settings to access further configuration options.
Pay attention to the instructions on battery care in “Battery Information” on page 3 - 11.
1 - 26 Power Options
Figure 1 - 17 - Power Options
Features & Components
Chapter 2: Features & Components
Overview
Read this chapter to learn more about the following main features and components
of the computer:
•Hard Disk Drive
•Optical (CD/DVD) Device
•Multi-In-1 Card Reader
•TouchPad and Buttons/Mouse
•Audio Features
2
Overview 2 - 1
Features & Components
Power Safety
Before attempting to access any of the internal
components of your
computer please ensure
that the machine is not
connected to the AC
power, and that the machine is turned off. Also
ensure that all peripheral cables, including
phone lines, are disconnected from the computer.
Figure 2 - 1
Hard Disk Location
HDD Bay
Models A/C
Models B/D
HDD Bay
2
Hard Disk Drive
The hard disk drive is used to store your data in the computer. The hard disk can be
taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height
of 9.5 mm.
The hard disk is accessible from the bottom of your computer as seen below.For further details see “Upgrading the Hard Disk Drive” on page 6 - 5.
2 - 2 Hard Disk Drive
Features & Components
Sound Volume
Adjustment
How high the sound volume can be set depends
on the setting of the volume control within Win-dows. Click the Volume
icon on the taskbar to
check the setting (see
“Audio Features” on
page 2 - 18).
Figure 2 - 2
Optical Device
123
1
2
3
Optical (CD/DVD) Device
There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual device will depend on the module you purchased (see “Storage” on page D - 5). Th e
optical device is usually labeled “Drive D:” and may be used as a boot device if
properly set in the BIOS (see “Boot Menu” on page 5 - 12).
Loading Discs
To insert a CD/DVD, press the open button and carefully place a CD/DVD onto
the disc tray with label-side facing up (use just enough force for the disc to click onto
the tray’s spindle). Gently push the CD/DVD tray in until its lock “clicks” and you
are ready to start. The busy indicator will light up while data is being accessed,
or while an audio/video CD, or DVD, is playing. If power is unexpectedly interrupted, insert an object such as a straightened paper clip into the emergency eject hole
to open the tray.
2
Optical (CD/DVD) Device 2 - 3
Features & Components
CD Emergency Eject
If you need to manually
eject a CD (e.g. due to
an unexpected power
interruption) you may
push the end of a
straightened paper clip
into the emergency eject
hole. However please
do NOT use a sharpened pencil or similar
object that may break
and become lodged in
the hole.
Disk Eject Warning
Don’t try to remove a
CD/DVD while the system is accessing it. This
may cause the system
to “crash”.
2
2 - 4 Optical (CD/DVD) Device
Handling CDs or DVDs
Proper handling of your CDs/DVDs will prevent them from being damaged. Please
follow the advice below to make sure that the data stored on your CDs/DVDs can be
accessed.
Note the following:
•Hold the CD or DVD by the edges; do not touch the surface of the disc.
•Use a clean, soft, dry cloth to remove dust or fingerprints.
•Do not write on the surface with a pen.
•Do not attach paper or other materials to the surface of the disc.
•Do not store or place the CD or DVD in high-temperature areas.
•Do not use benzene, thinner, or other cleaners to clean the CD or DVD.
•Do not bend the CD or DVD.
•Do not drop or subject the CD or DVD to shock.
Features & Components
DVD Region Note
DVD region detection is
device dependent, not
OS-dependent. You can
select your module’s region code 5 times. The
fifth selection is permanent. This cannot be altered even if you change
your operating system
or you use the module in
another computer.
Figure 2 - 3
DVD Region Codes
•Region 1 - USA & Canada
•Region 2 - Western Europe, Japan,
South Africa, Middle East & Egypt
•Region 3 - South-East Asia, Taiwan,
South Korea, The Philippines, Indonesia, Hong Kong
•Region 4 - South & Central Amer-
ica, Mexico, Australia, New Zealand
•Region 5 - N Korea, Russia, Eastern
Europe, India & Most of Africa
•Region 6 - China
DVD Regional Codes
To change the DVD regional codes:
1.Go to the Control Panel
2.Double-click Device Manager (Hardware and Sound), then click the + next to DVD/CD-ROM drives.
3.Double-click on the DVD-ROM device to bring up the Properties dialog box, and
select the DVD Region (tab) to bring up the control p anel to allow you to adjust the
regional code.
2
Optical (CD/DVD) Device 2 - 5
Features & Components
Card Reader Cover
Make sure you keep the
rubber cover provided in
the card reader when
not in use. This will help
prevent foreign objects
and/or dust getting in to
the card reader.
Figure 2 - 4
Left View
1.Card Reader
•MMC (MultiMedia Card) / RS MMC
•SD (Secure Digital) / Mini SD / SDHC / SDXC
•MS (Memory Stick) / MS Pro / MS Duo
1
Models A/C
1
Models B/D
2
Multi-In-1 Card Reader
The card reader allows you to use some of the latest digital storage cards. Push the
card into the slot and it will appear as a removable device, and can be accessed in
the same way as your hard disk (s). Make sure you install the card reader driver (see
“CardReader” on page 4 - 6.
Note: Some of these cards require PC adapters that are usually supplied with the
cards.
2 - 6 Multi-In-1 Card Reader
Features & Components
TouchPad Scrolling
This computer model series may feature different
TouchPad versions.
These TouchPads may
differ in their vertical
scrolling function in most
scrollable windows.
Some TouchPads require
sliding the finger up and
down on the right of the
TouchPad to scroll the
window. Other versions
require tapping/holding
down the finger at the top
right or bottom right of the
TouchPad to scroll the
window.
TouchPad and Buttons/Mouse
The TouchPad is an alternative to the mouse; however, you can also add a mouse to
your computer through one of the USB ports. The TouchPad buttons function in
much the same way as a two-button mouse. Install the driver as instructed in
“Touchpad” on page 4 - 6 and the appropriate application software version will be
installed for your computer.
2
TouchPad and Buttons/Mouse 2 - 7
Features & Components
Mouse Driver
If you are using an external mouse your operating system may be
able to auto-configure
your mouse during its
installation or only enable its basic functions.
Be sure to check the
device’s user documentation for details.
Figure 2 - 5
Mouse Properties
(ELAN tab) &
Taskbar Icon
2
Elan TouchPad
Once you have installed the TouchPad driver (see “Touchpad” on page 4 - 6) you
can configure the functions by double-clicking the TouchPad driver icon in the
notification area of the taskbar (or from Options in the ELAN tab in the Mouse
control panel in Windows). You may then configure the gestures and options to your
preferences.
2 - 8 TouchPad and Buttons/Mouse
The Elan Smart-Pad control panel allows you to use a specific gesture (action) on
Figure 2 - 6
Smart-Pad Control
Panel (Button)
the surface of the TouchPad to perform specific actions to manipulate documents,
objects and applications.
Click the menu tabs (One-finger, Multi-finger or Additional) and then the function
button on the left to access the Configuration controls in the right panel. Click the
checkbox to Enable most of the controls and click Apply to save the settings. Click
the close icon or Yes to close the control panel.
Features & Components
2
TouchPad and Buttons/Mouse 2 - 9
Features & Components
Figure 2 - 7
Smart-Pad Control
Panel with
Function
Description
2
Click the Function Description button to get a detailed description of any function.
Click the Default button to set any of the functions to the default setting.
2 - 10 TouchPad and Buttons/Mouse
Features & Components
Figure 2 - 8
Tapping
Figure 2 - 9
Button
One-Finger
Tapping
The Smart-Pad supports one, two and three finger tapping, all configured from the
Tapping control panel in the One-fingertab. You can configure two or three finger
tapping to perform a number of different functions by selecting them from the dropdown menus provided.
Button
The left and right TouchPad buttons may be configured to perform any action listed
in the Button drop-down menu.
2
TouchPad and Buttons/Mouse 2 - 11
Features & Components
Figure 2 - 10
Drag and Drop
Figure 2 - 11
Edge Scroll
2
Drag and Drop
You can select the different drag and drop methods from the menu provided. The object can be released when you lift the finger off the TouchPad, when you tap again
or after a set time delay.
Edge Scroll
Edge Scroll can be configured to use a single finger to scroll vertically or horizontally. To scroll vertically, tap the right edge of the TouchPad and drag the finger up
and down. To scroll horizontally, tap the bottom edge of the TouchPad and drag your
finger left or right.
2 - 12 TouchPad and Buttons/Mouse
Features & Components
Figure 2 - 12
Zooming
Figure 2 - 13
Scrolling
Multi-Finger
Zooming
Place two fingers on the TouchPad (for best results use the tips of the fingers) and
slide them apart to zoom in, or closer together to zoom out.
Scrolling
The Two-Finger scrolling feature works in most scrollable windows and allows you
to scroll horizontally and vertically. Tap the pad surface and slide both fingers in the
direction required (vertically or horizontally as long as the option is selected).
2
TouchPad and Buttons/Mouse 2 - 13
Features & Components
Figure 2 - 14
Rotation
Figure 2 - 15
Swipe Page
2
Rotation
You can rotate objects by using a two-finger gesture. Touch and rotate using two fingers on the pad in the direction required. Alternatively place a finger down on the
pad and rotate the other finger around it in a circular motion (clockwise or counterclockwise).
Swipe Page
This gesture is used to activate a Page Up/Page Down operation. Swipe three fingers
quickly to the left to go to the previous page, or to the right to go to the next page.
After you release your fingers from the pad the page changes, and make sure to lift
your fingers immediately after the page change.
2 - 14 TouchPad and Buttons/Mouse
Fast Keys
Figure 2 - 16
Fast Keys
The Fast Keys gesture allows you to switch windows or open My Computer.
My Computer (Fast Keys)
Tap three fingers simultaneously on the pad and then move them up until you get to
the My Computer window, you can then release the fingers from the pad.
Switch Windows (Fast Keys)
Tap three fingers simultaneously on the pad and then move them down until the active window switches, you can then use a single finger to select the window required.
Features & Components
2
TouchPad and Buttons/Mouse 2 - 15
Features & Components
Figure 2 - 17
Palm Tracking
Figure 2 - 18
Smart Motion
2
Additional
Palm Tracking
This feature helps guard against accidental contact such as palms resting on the pad.
Use the slider to adjust the sensitivity of the feature as appropriate.
Smart Motion
Smart Motion makes it easier to drag objects across the screen or move the pointer
across long distances. When a finger reaches the edge of the TouchPad, holding the
finger on the edge of the TouchPad will allow the cursor to continue moving until
the finger is lifted.
2 - 16 TouchPad and Buttons/Mouse
Slow Motion
Figure 2 - 19
Slow Motion
Slow Motion allows you to slow down the cursor movement for more precise control. Pressing and holding key (configured from the drop-down menu) will enable
this feature.
Features & Components
2
TouchPad and Buttons/Mouse 2 - 17
Features & Components
Sound Volume
Adjustment
The sound volume level
is set using the volume
control within Windows
(and the volume function keys on the computer). Click the volume
icon in the taskbar to
check the setting.
Figure 2 - 20
VIA HD Audio Deck
Click Expert Mode to access the Advanced menus
2
Audio Features
You can configure the audio options on your computer from the Sound control
panel in Windows, from the HD VDeck icon on the desktop or VIA HD AudioDeck control panel .
The volume may also be adjusted by means of the Fn + F5/F6 key combination.
2 - 18 Audio Features
Expert Mode will allow you to access more advanced configuration menus for
Syncing Left & Right
Volume
Balance
If you wish to adjust the left
and right channel volume
levels separately, you will
need to adjust this from the
VIA HD Audio Deck in Expert Mode.
Click Speaker in VIA HD
Audio Deck (in ExpertMode) and click the Sync
Left and Right volume
button (see left). You can
then adjust the volume sliders independently (this setting also controls the
Balance setting in the Windows Sound control panel).
Figure 2 - 21
VIA HD Audio Deck
(Expert Mode)
Note that to adjust the Left & Right volume ba lance independently click th e Sync
Left and Right Volume icon (it should be faded) and adjust the slider as required.
Speaker, Microphone and Stereo Mix.
Features & Components
2
Audio Features 2 - 19
Features & Components
2
2-20
Chapter 3: Power Management
OS Note
Power management
functions will vary slightly depending on your
operating system. For
more information it is
best to refer to the user’s
manual of your operating system.
(Note: All pictures used
on the following pages
are from the Windows 7
OS.)
Power Management
Overview
To conserve power, especially when using the battery, your computer power management conserves power by controlling individual components of the computer
(the LCD and hard disk drive) or the whole system. This chapter covers:
•The Power Sources
•Turning On the Computer
•Power Plans
•Power-Saving States
•Configuring the Power Buttons
•Power Conservation Modes
•Battery Information
The computer uses enhanced power saving techniques to give the operating system
(OS) direct control over the power and thermal states of devices and processors. For
example, this enables the OS to set devices into low-power states based on user settings and information from applications.
3
Overview 3 - 1
Power Management
The Power Sources
The computer can be powered by either an AC/DC adapter or a battery pack.
3
AC/DC Adapter
Use only the AC/DC adapter that comes with your computer. The wrong type of AC/
DC adapter will damage the computer and its components.
1.Attach the AC/DC adapter to the DC-in jack on the left of the computer.
2.Plug the AC power cord into an outlet, and then conne ct the AC power co rd to the
AC/DC adapter.
3.Raise the lid/LCD to a comfortable viewing angle.
4.Press the power button to turn “On”.
Battery
The battery allows you to use your computer while you are on the road or when an
electrical outlet is unavailable. Battery life varies depending on the applications and
the configuration you're using. To increase battery life, let the battery dischargecompletely before recharging (see “How do I completely discharge the battery?”
on page 3 - 15).
We recommend that you do not remove the battery. For more information on the battery, please refer to “Battery Information” on page 3 - 11.
3 - 2 The Power Sources
Turning On the Computer
Forced Off
If the system “hangs”,
and the Ctrl + Alt + Del
key combination doesn’t
work, press the power
button for 4 seconds, or
longer, to force the system to turn itself off.
Power Button as
Stand by or
Hibernate Button
You can use the OS’s
Power Options control
panel to set the power
button to send the system into Stand by or Hibernate mode (see your
OS’s documentation, or
“Configuring the Power Buttons” on page 3
- 8 for details).
Shut Down
Note that you should always shut your computer down by choosing the Shut Down command from the bottom right of the Start menu in Windows. This will help prevent hard disk
or system problems.
Now you are ready to begin using your computer. To turn it on simply press the power button on the front panel.
When the computer is on, you can use the power button as a Stand by/Hibernate/
Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and
holding the power button for longer than this will shut the computer down). Use
Power Options in the Windows control panel to configure this feature.
Power Management
3
Turning On the Computer 3 - 3
Power Management
Resuming
Operation
See Table 3 - 1, on
page 3 - 9 for informa-
tion on how to resume
from a power-saving
state.
Password
It is recommended that
you enable a password
on system resume in order to protect your data.
Figure 3 - 1
Power Plan
Advanced Settings
(Win 7)
Power Plans
The computer can be configured to conserve power by means of power plans. You
3
can use (or modify) an existing power plan, or create a new one.
3 - 4 Power Plans
The settings may be adjusted to set the display to turn off after a specified time, and
to send the computer into Sleep after a period of inactivity.
Click Change plan settings and then click Change advanced power settings to access further configuration options in Advanced Settings.
Each Windowspower plan will also adjust the processor performance of your ma-
UMA Mode Power Plan
UMA Mode is used for con-
stant power-saving with the
integrated GPU only. The
UMA Mode power plan’s
standard settings are also
configured to save the
maximum amount of power
if selected.
Figure 3 - 2
Power Plans
Click to Show/Hide
additional
power plans
chine in order to save power. This is worth bearing in mind if you are experiencing
any reduced performance (especially under DC/battery power).
Choose High performance (you may need to click Show additional plans to view
the High performance plan) for maximum performance when the computer is powered from an AC power source. Choose the Power saver (bear in mind that this
scheme may slow down the overall performance of the computer in order to save
power) for maximum power saving when the computer is battery (DC power) powered (see sidebar for UMA Mode power plan information). The recommended Bal-anced power plan will balance power saving and performance.
Power Management
3
Power Plans3-5
Power Management
Power-Saving States
You can use power-saving states to stop the computer’s operation and restart where
3
you left off. Win 7 uses the Sleep, Hibernate and Shut Down power-saving states.
Sleep
In Sleep all of your work, settings and preferences are saved to memory before the
system sleeps. When you are not using your computer for a certain length of time,
which you specify in the operating system, it will enter Sleep to save power.
The PC wakes from Sleep within seconds and will return you to where you last left
off (what was on your desktop) without reopening the application(s) and file(s) you
last used.
If your mobile PC in Sleep is running on battery power the system will use only a
minimum amount of power. After an extended period the system will save all the
information to the hard disk and shut the computer down before the battery becomes
depleted.
3 - 6 Power-Saving States
Hibernate
Figure 3 - 3
Start Menu Power
Hibernate uses the least amount of power of all the power-saving states and saves
all of your information on a part of the hard disk before it turns the system off. If a
power failure occurs the system can restore your work from the hard disk; if a power
failure occurs when work is saved only to memory, then the work will be lost. Hi-bernate will also return you to where you last left off within seconds. You should
put your mobile PC into Hibernate if you will not use the computer for a period of
time, and will not have the chance to charge the battery.
Shut down
You should Shut down the computer if you plan to install new hardware (don’t forget to remove the battery and follow all the safety instructions in Chapter 6), plan
to be away from the computer for several days, or you do not need it to wake up and
run a scheduled task. Returning to full operation from Shut down takes longer than
from Sleep or Hibernate.
Power Management
3
Power-Saving States 3 - 7
Power Management
Password
Protection
It is recommended that
you enable a password
on wake up in order to
protect your data.
However you can disable this setting from the
Power Options menu
by clicking Require a
password on wakeup
in the left menu, and selecting the options (click
Change settings that
are currently unavailable).
Figure 3 - 4
Power Options
Define Power
Buttons
3
Configuring the Power Buttons
The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the
computer in to a power-saving state. Click Choose what the power buttons do on
the left menu in Power Options to bring up the menu.
3 - 8 Configuring the Power Buttons
Resuming Operation
Closing the Lid
If you have chosen to
send the computer to
Sleep when the lid is
closed, raising the lid
will wake the system up.
Table 3 - 1
Resuming
Operation
3G Modules &
System Wake Up
Note that the 3G modules
DO NOT
support system
wake up on 3G modem
activity.
Power Button
When the computer is on, you can use the power button as a Sleep/Hibernate/Shut Down
hot key button when it is pressed for less than 4 seconds (pressing and holding the power
button for longer than this will force the computer to shut down).
You can resume operation from power-saving states by pressing the power button,
or in some cases pressing the sleep button (Fn + F4 key combo).
Power Status
Power OffOffPress the Power Button
SleepBlinking Green
Hibernate
Display Turned OffGreenPress a Key or Move the Mouse/Touchpad
Icon Color
Off (battery)
Orange (AC/DC adapter)
Power Management
3
To Resume
Press the Power Button
Press the Sleep Button (Fn + F4 Key Combo)
Press the Power Button
Configuring the Power Buttons 3 - 9
Power Management
Power Conservation
Modes
The Energy Star setting
will result in maximum
power saving, but with
the possible loss of
some performance.
Setting the mode to Bal-ance will give power
saving matched with
performance.
Performance will give
optimum computer performance but with less
power conservation.
Figure 3 - 5
Control Center
3
Power Conservation Modes
This system supports Energy Star power management features that place computers (CPU, hard drive, etc.) into a low-power sleep modes after a designated period
of inactivity. Adjust Power Conservation Modes from the Control Center:
1.Press the Fn + Esc key combination to toggle the Control Center on/off.
2.Click either the Performance, Balanced or Energy Star button.
3.Click in a blank area of the icon or press a key on the keyboard to exit Power
Conservation Mode without making any changes.
3 - 10 Configuring the Power Buttons
Battery Information
Low Battery
Warning
When the battery is critically low, immediately
connect the AC/DC
adapter to the computer
or save your work, otherwise, the unsaved
data will be lost when
the power is depleted.
Figure 3 - 6
Battery Icon
(Taskbar) & Battery
Advanced Settings
Follow these simple guidelines to get the best use out of your battery.
Battery Power
Your computer’s battery power is dependent upon many factors, including the programs you are running, and peripheral devices attached. You can set actions to be
taken (e.g. Shut down, Hibernate etc.), and set critical and low battery levels from
power plan Change plan settings > Change advanced power settings (see Figure
3 - 1 on page 3 - 4).
Click the battery icon in the taskbar t o see the current battery level and charge
status.
Power Management
3
Battery Information 3 - 11
Power Management
Windows Mobility
Center
The Windows Mobility
Center control panel
provides an easy point
of access for information
on battery status, power
plans used and wireless
device status etc.
Figure 3 - 7
Windows Mobility
Center
3
Conserving Battery Power
•Use a power plan that conserves power (e.g Power saver), however note that
this may have an affect on computer performance.
•Lower the brightness level of the LCD display. The system will decrease LCD
brightness slightly to save power when it is not powered by the AC/DC adapter.
•Reduce the amount of time before the display is turned off.
•Close wireless, Bluetooth, modem or co mmunication applications when they are
not being used.
•Disconnect/remove any unnecessary external devices e.g. USB devices,
ExpressCards etc.
3 - 12 Battery Information
Battery Life
Battery life may be shortened through improper maintenance. To optimize the life
and improve its performance, fully discharge and recharge the battery at least
once every 30 days.
We recommend that you do not remove the battery yourself. If you do need to remove the battery for any reason (e.g. long term storage) see “Removing the Battery”
on page 6 - 4.
New Battery
Always completely discharge, then fully charge, a new battery (see “Battery FAQ”
on page 3 - 15 for instructions on how to do this).
Recharging the Battery with the AC/DC Adapter
The battery pack automatically recharges when the AC/DC adapter is attached and
plugged into an electrical outlet. If the computer is powered on, and in use, it will
take several hours to fully recharge the battery. When the computer is turned off but
plugged into an electrical outlet, battery charge time is less. (Refer to “LED Indica-
tors” on page 1 - 9 for information on the battery charge status, and to “Battery
FAQ” on page 3 - 15 for more information on how to maintain and properly re-
charge the battery pack.)
Power Management
3
Battery Information 3 - 13
Power Management
Caution
Danger of explosion if
battery is incorrectly replaced.
Replace only with the
same or equivalent type
recommended by the
manufacturer. Discard
used battery according
to the manufacturer’s instructions.
Damaged Battery Warning
Should you notice any physical defects (e.g. the battery is bent ou t of shape after being
dropped), or any unusual smells emanating from the notebook battery, shut your computer
down immediately and contact your distributor/supplier. If the battery has been dropped we
do not recommend using it any further, as even if the comp uter continues to work with a
damaged battery in place, it may cause circuit damage, which may possibly result in fire. It
is recommended that you replace your computer battery every two years.
Proper handling of the Battery Pack
•DO NOT disassemble the battery pack under any circumstances
•DO NOT expose the battery to fire or high temperatures, it may explode
3
•DO NOT connect the metal terminals (+, -) to each other
3 - 14 Battery Information
Battery FAQ
Figure 3 - 8
Power Plan Create
How do I completely discharge the battery?
Use the computer with battery power until it shuts down due to a low battery. Don’t
turn off the computer even if a message indicates the battery is critically low, just let
the computer use up all of the battery power and shut down on its own.
1.Save and close all files and applications.
2.Create a power plan for discharging the battery and set all the options to Never.
Power Management
3
Battery Information 3 - 15
Power Management
Figure 3 - 9
Change Plan
Settings / Change
Advanced Power
Settings
3
3.Click Change plan settings (after creating it) and click Change plan settings >
Change advanced power settings.
3 - 16 Battery Information
4.Scroll down to Battery and click + to expand the ba ttery options.
Figure 3 - 10
Power Options
Advanced Settings -
Battery
5.Choose the options below (click Yes if a warning appears):
•Low battery levels = 0%
•Critical battery Levels = 1%
•Low battery action = Do Nothing
•Critical battery action (On battery) = Shut Down
•Critical battery action (Plugged in) = Do Nothing
Power Management
3
Battery Information 3 - 17
Power Management
How do I fully charge the battery?
When charging the battery, don’t stop until the LED charging indicator light changes
from orange to green.
3
How do I maintain the battery?
Completely discharge and charge the battery at least once every 30 days or after
about 20 partial discharges.
3 - 18 Battery Information
Chapter 4: Drivers & Utilities
Driver Installation &
Power
When installing drivers make sure your
computer is powered
by the AC/DC adapter
connected to a working power source.
Some drivers draw a
significant amount of
power during the installation procedure, and if
the remaining battery
capacity is not adequate
this may cause the system to shut down and
cause system problems
(note that there is no
safety issue involved
here, and the battery will
be rechargeable within 1
minute).
This chapter deals with installing the drivers and utilities essential to the operation or
improvement of some of the computer’s subsystems. The system takes advantage of
some newer hardware components for which the latest versions of most available operating systems haven’t built in drivers and utilities. Thus, some of the system components won’t be auto-configured with an appropriate driver or utility during
operating system installation. Instead, you need to manually install some system-required drivers and utilities.
What to Install
The Device Drivers & Utilities + Use r’s Manual disc contains the drivers and util-
ities necessary for the proper operation of the computer. Table 4 - 1, on page 4 - 3
lists what you need to install and it is very important that the drivers are installed
in the order indicated.
Module Driver Installation
The procedures for installing drivers for the PC Camera, Wireless LAN, 3G and
Combination Bluetooth & WLAN modules are provided in “Modules & Op tions”
on page 7 - 1.
Drivers & Utilities
4
What to Install 4 - 1
Drivers & Utilities
Driver Installation
Insert the Device Drivers & Utilities + User’s Manual
disc and click Install Drivers (button), or Option Driv-ers (button) to access the Optional driver menu.
4
Figure 4 - 1 - Drivers Installer Screen 1
1.Check the driver installation order from Table 4 - 1,
on page 4 - 3 (the drivers must be installed in
this order) which is the same as that listed in the
Drivers Installer menu below.
2.Click to select the driver you wish to install, (you
should note down the drivers as you install them).
3.Follow the instructions for each individual driver
installation procedure as listed on the following
pages.
4 - 2 Driver Installation
Figure 4 - 2 - Drivers Installer Screen 2
Drivers & Utilities
Windows 7 (SP1) DriverPage #Windows 7 (SP1) DriverPage #
ChipsetPage 4 - 6M EI DriverPage 4 - 7
Video (VGA)Page 4 - 6AudioPage 4 - 7
NVIDIA Video (VGA)Page 4 - 6PC Camera ModulePage 7 - 3
LANPage 4 - 6Wireless LAN ModulePage 7 - 10
Note that you need to install both the WLAN & Bluetooth drivers for the WLAN & Bluetooth Combo modules.
Driver Installation 4 - 3
Drivers & Utilities
Manual Driver Installation
Click Bro wse CD/DVD (button) in the Drivers Installer application and browse to the executable file in the
appropriate driver folder.
4
Windows Update
After installing all the drivers make sure you enable
Windows Update in order to get all the latest securi ty
updates etc. (all updates will include the latest hotfixes
from Microsoft). See “Windows Update” on page 4 -
8 for instructions.
Updating/Reinstalling Individual Drivers
If you wish to update/reinstall individual drivers it
may be necessary to uninstall the original driver.To do
this go to the Control Panel in the Windows OS and
double-click the Programs and Features icon (Pro-grams > Uninstall a program). Click to select the
driver (if it is not listed see below) and click Uninstall,
and then follow the on screen prompts (it may be necessary to restart the computer). Reinstall the driver as
outlined in this chapter.
If the driver is not listed in the Programs and Fea-tures menu:
1.Click Start, and click Control Panel (or point to
Settings and click Control Panel).
2.Double-click Device Manager (Hardware and
Sound > Device Manager).
3.Double-click the device you wish to update/reinstall
the driver for (you may need to click “+” to expand
the selection).
4.Click Driver (tab) and click the Update Driver or
Uninstall button and follow the on screen prompts.
4 - 4 Driver Installation
Drivers & Utilities
Driver Installation General Guidelines
The driver installation procedure outlined in this Chapter
(and in Chapter 7 Options & Modules), are accurate at
the time of going to press.
Drivers are always subject to upgrade and revision so
the exact procedure for certain drivers may differ slightly. As a general guide follow the default on screen instructions for each driver (e.g. Next > Next > Finish)
unless you are an advanced user. In many cases a restart is required to install the driver.
Make sure any modules (e.g. PC Camera, WLAN or 3G)
are ON before installing the appropriate driver.
User Account Control
If a User Account Control prompt appears as part of
the driver installation procedure, click Continue or
Allow, and follow the installation procedure as directed.
Windows Security Message
If you receive a Windows security message as part of
the driver installation process. Just click “Install thisdriver software anyway” or “Install” to continue the
installation procedure.
You will receive this message in cases where the driver has been released after the version of Windows you
are currently using. All the drivers provided will have
already received certification for Windows.
New Hardware Found
If you see the message “New Hardware Found” during the installation procedure (other than when out-lined in the driver install procedure), click Cancel
to close the window, and follow the installation procedure.
4
Driver Installation 4 - 5
Drivers & Utilities
Driver Installation Procedure
Insert the Device Drivers & Utilities + User’s Manual
disc and click Install Drivers (button).
Chipset
4
1.Click 1.Install Chipset Driver > Yes.
2.Click Next > Yes > Next > Next.
3.Click Finish to restart the computer .
Video (VGA)
1.Click 2.Install VGA Driver > Yes.
2.Click Next > Yes > Next > Next.
3.Click Finish to restart the computer .
NVIDIA Video (VGA)
1.Click 3.Install nVIDIA VGA Driver > Yes.
2.Click AGREE AND CONTINUE (button) to
accept the terms of the license agreement.
3.Click Next.
4.Click the RESTART NOW button to restart
the computer.
Note: After installing the video driver go to the Display/Display Settings control panel to adjust the vid-
eo settings to the highest resolution.
LAN
1.Click 4.Install LAN Driver > Yes.
2.Click Next > Install.
3.Click Finish.
CardReader
1.Click 5.Install Cardreader Driver > Yes.
2.Click Finish.
Touchpad
1.Click 6.Install Touchpad Driver > Yes.
2.Click Next.
3.Click the button to accept the license agreement
and click Next.
4.Click Finish > Restart Now to restart the computer.
4 - 6 Driver Installation
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
