Clevo S3100, S3100M User guide

V10.4.00

Preface

Notice

The company reserves the right to revise this publication or to change its contents without notice. Information
contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or
any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear
in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse)
of this publication.
This publication and any accompanying software may not, in whole or in part, be reproduced, translated, trans­mitted or reduced to any machine readable form without prior consent from the vendor, manufacturer or creators
of this publication, except for copies kept by the user for backup purposes.
Brand and product names mentioned in this publication may or may not be copyrights and/or registered trade­marks of their respective companies. They are mentioned for identification purposes only and are not intended
as an endorsement of that product or its manufacturer.
©August 2010

Trademarks

Intel, Celeron, and Intel Core are trademarks/registered trademarks of Intel Corporation.

I

Preface

R&TTE Directive

This device is in compliance with the essential requirements and other relevant provisions of the R&TTE Direc­tive 1999/5/EC.

This device will be sold in the following EEA countries: Austria, Italy, Belgium, Liechtenstein, Denmark, Lux­embourg, Finland, Netherlands, France, Norway, Germany, Portugal, Greece, Spain, Iceland, Sweden, Ireland,
United Kingdom, Cyprus, Czech Republic, Estonia, Hungary, Latvia, Lithuania, Malta, Slovakia, Poland, Slov­enia.

CE Marking

This device has been tested to and conforms to the regulatory requirements of the European Union and has at­tained CE Marking. The CE Mark is a conformity marking consisting of the letters “CE”. The CE Mark applies
to products regulated by certain European health, safety and environmental protection legislation. The CE Mark
is obligatory for products it applies to: the manufacturer affixes the marking in order to be allowed to sell his
product in the European market.

This product conforms to the essential requirements of the R&TTE directive 1999/5/EC in order to attain CE
Marking. A notified body has determined that this device has properly demonstrated that the requirements of the
directive have been met and has issued a favorable certificate of expert opinion. As such the device will bear the
notified body number 0560 after the CE mark.

The CE Marking is not a quality mark. Foremost, it refers to the safety rather than to the quality of a product.
Secondly, CE Marking is mandatory for the product it applies to, whereas most q uality marking s are vo lu ntary.

II

Preface

FCC Statement

(Federal Communications Commission)

You are cautioned that changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not in­stalled and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Re orient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the service representative or an experienc ed radio/TV technician for help.

Operation is subject to the following two conditions:

1. This device may not cause interference.
And

2. This device must accept any interference, including interfer ence that may cause undesired operation of the

device.

III

Preface



Warning

Use only shielded cables to connect I/O devices to this equipment. You are cautioned that changes or modifications not ex­pressly approved by the manufacturer for compliance with the above standard s could void your authority to operate the
equipment.

If your purchase option includes both Wireless LAN and 3.75G modules, then the appropriate antennas will be installed.
Note that In order to comply with FCC RF exposure compliance requirements, the antenna must not be co-located or operate
in conjunction with any other antenna or transmitter.

Important Notice - 3.75G/HSPA & Bluetooth/Wireless LAN Modules

In order to comply with FCC regulations you should NOT operate the 3.75G/HSPA module and the Bluetooth/Wireless LAN
modules at the same time as this may disrupt radio frequency, and cause interference. When the 3.75G/HSPA module is
powered on, make sure that the Bluetooth/Wireless LAN modules are powered off.

FCC RF Radiation Exposure Statement:

1. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

2. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This

equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator
and your body.

IV

Preface

IMPORTANT SAFETY INSTRUCTIONS

Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury
to persons when using any electrical equipment:

1. Do not use this product near water, for example n ear a ba th tub, wash bowl, kitchen sink or laundry tu b, in a wet

basement or near a swimming pool.

2. Avoid using this equipment with a telephone line (other than a cordless type) during an electrical storm. There

may be a remote risk of electrical shock from lightning.

3. Do not use the telephone to report a gas leak in the vicinity of the leak.

4. Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may

explode. Check with local codes for possible special disposal instructions.

5. This product is intended to be supplied by a Listed Power Unit (Full Range AC/DC Adapter – AC Input 100 -

240V, 50 - 60Hz, DC Output 19V, 3.42A OR 18.5V, 3.5A).

V

Preface

Instructions for Care and Operation

The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions:

1. Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged.

Do not expose the computer
to any shock or vibration.

Do not place it on an unstable
surface.

Do not place anything heavy
on the computer.

2. Keep it dry, and don’t overheat it. Keep the computer and power supply away from any kind of heating ele-

ment. This is an electrical appliance. If water or any other liquid gets into it, the computer could be badly dam­aged.

Do not expose it to excessive
heat or direct sunlight.

Do not leave it in a place
where foreign matter or mois­ture may affect the system.

Don’t use or store the com­puter in a humid environment.

Do not place the computer on
any surface that will block the
Vents/Fan Intakes.

VI

Preface

3. Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other

strong magnetic fields. These can hinder proper performance and damage your data.

4. Follow the proper workin g procedu res for t he computer. Shut the computer down properly and don’t forget

to save your work. Remember to periodically save your data as data may be lost if the battery is depleted.

Do not turn off the power
until you properly shut down
all programs.

Do not turn off any peripheral
devices when the computer is
on.

5. Take care when using peripheral devices.

Use only approved brands of
peripherals.

Do not disassemble the com­puter by yourself.

Unplug the power cord befor e
attaching peripheral devices.

Perform routine maintenance
on your computer.

VII

Preface



Power Safety

Warning

Before you undertake
any upgrade proce­dures, make sure that
you have turned off the
power, and discon­nected all peripherals
and cables (including
telephone lines). It is
advisable to also re­move your battery in
order to prevent acci­dentally turning the
machine on.

Power Safety

The computer has specific power requirements:

• Only use a power adapter approved for use with this computer.

• Your AC/DC adapter may be designed for international travel but it still requires a steady,
uninterrupted power supply. If you are unsure of your local power specifications, consult
your service representative or local power company .

• The power adapter may have either a 2-pr ong or a 3-prong ground ed plug. The third prong
is an important safety feature; do not defeat its purpose. If you do not have access to a
compatible outlet, have a qualified electrician install one.

• When you want to unplug the power cord, be su re to disconnect it by the plug head, not by
its wire.

• Make sure the socket and any extension cord(s) you use can support the total current load
of all the connected devices.

• Before cleaning the computer, make sure it is disconnected from any external power sup­plies (i.e. AC/DC adapter or car adapter).

Do not plug in the power
cord if you are wet.

Do not use the power cord if
it is broken.

Do not place heavy objects
on the power cord.

VIII

Preface

Polymer Battery Precautions

Note the following information which is specific to polymer batteries only, and where applicable, this overrides
the general battery precaution information overleaf.

• Polymer batteries may experience a slight expansion or swelling, however this is part of the battery’s safety mecha­nism and is not a cause for concern.

• Use proper handling procedures when using polymer batteries. Do not use polymer batteries in high ambient tempera­ture environments, and do not store unused batteries for extended periods.

See also the general battery precautionary information overleaf for further information.

IX

Preface



Battery Disposal & Caution

The product that you have purchased contains a rechargeable battery. The battery is recyclable. At the end of its useful life,
under various state and local laws, it may be illegal to dispose of this battery in to the municipal waste stream. Check with
your local solid waste officials for details in your area for recycling options or proper disposal.

Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalen t type recommended by the
manufacturer. Discard used battery according to the manufacturer’s instructions.

Battery Precautions

• Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer.

• Do not remove any batteries from the computer while it is powered on.

• Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even
if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly
result in fire.

• If you do not use the battery for an extended period, then remove the battery from the computer for storage.

• Recharge the batteries using the notebook’s system. Incorrect recharging may make the battery explode.

• Do not try to repair a battery pack. Refer any battery pack repa ir or replacemen t to you r service repre sentati ve or qu al­ified service personnel.

• Keep children away from, and promptly dispose of a damaged battery. Always dispose of batteries carefully. Batteri es
may explode or leak if exposed to fire, or improperly handled or discarded.

• Keep the battery away from metal appliances.

• Affix tape to the battery contacts before disposing of the battery.

• Do not touch the battery contacts with your hands or metal objects.

X

Cleaning



Removal Warning

When removing any cover(s) and screw(s) for the purposes of device upg rade, remember to replace the cover(s) and
screw(s) before turning the computer on.

Do not apply cleaner directly to the computer; use a soft clean cloth.
Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer.

Servicing

Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the
computer to electric shock. Refer all servicing to authorized service personnel. Unplug the computer from the
power supply. Then refer servicing to qualified service personnel under any of the following conditions:

• When the power cord or AC/DC adapter is damaged or frayed.

• If the computer has been exposed to rain or other liquids.

• If the computer does not work normally when you follow the operating instructions.

• If the computer has been dropped or damaged (do not touch the poisonous liquid if the LCD panel breaks).

• If there is an unusual odor, heat or smoke coming from your computer.

Preface

XI

Preface



Power Off Before Traveling

Make sure that your notebook is completely powered off before putting it into a travel bag (or any such container). Putting a
notebook which is powered on in a travel bag may cause the vent(s)/fan intake(s)/outlet(s) to be blocked. To prev ent your
computer from overheating make sure nothing blocks the vent(s)/fan intake(s)/outlet(s) while the computer is in use.

Travel Considerations

Packing

As you get ready for your trip, run through this list to make sure the system is ready to go:

1. Check that the battery pack and any spares are fully charged.

2. Power off the computer and peripherals.

3. Close the display panel and make sure it’s latched.

4. Disconnect the AC/DC adapter and cables. Stow them in the carrying bag.

5. The AC/DC adapter uses volt ages from 100 to 240 volt s so you won’t need a second volt age adapter. However,

check with your travel agent to see if you need any socket adapters.

6. Put the notebook in its carrying bag and secure it with the bag’s straps.

7. If you’re taking any perip herals (e.g. a printer, mouse or digital camera), pack them and those devices’ adapters

and/or cables.

8. Anticipate customs - Some jurisdictions may have import restrictions or req uire proof of ownersh ip for both hard -

ware and software. Make sure your documents are prepared.

XII

Preface

On the Road

In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting,
keep these points in mind:

Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very
common. Don’t check it with normal luggage. Baggage handlers may not be sufficiently careful. Avoid knock­ing the computer against hard objects.

Beware of Electromagnetic fields - Devices such as metal detectors & X-ray machines can damage the com­puter, hard disk, floppy disks, and other media. They may also destroy any stored data - Pass your computer and
disks around the devices. Ask security officials to hand-inspect them (you may be asked to turn it on). Note:
Some airports also scan luggage with these devices.

Fly safely - Most airlines have regulations about the use of computers and other electronic devices in flight.
These restrictions are for your safety, follow them. If you stow the notebook in an overhead compartment, make
sure it’s secure. Contents may shift and/or fall out when the compartment is opened.

Get power where you can - If an electrical outlet is available, use the AC/DC adapter and keep your battery(ies)
charged.

Keep it dry - If you move quickly from a cold to a warm location, water vapor can condense inside the computer.
Wait a few minutes before turning it on so that any moisture can evaporate.

XIII

Preface

Developing Good Work Habits

Developing good work habits is important if you need to work in fron t of the computer for long periods of time.
Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or
other joints. The following are some tips to reduce the strain:

• Adjust the height of the chair and/or desk so that the keyboard is at or slightly below the
level of your elbow. Keep your forearms, wrists, and hands in a relaxed position.

• Your knees should be slightly higher than your hips. Pl ace your feet flat on the flo or or on
a footrest if necessary.

• Use a chair with a back and adjust it to support your lower back comfortably.

• Sit straight so that your knees, hips and elbows form approximately 90-degree angles
when you are working.

• Take periodic breaks if you are using the computer for long periods of time.

Remember to:

• Alter your posture frequently.

• Stretch and exercise your body several times a day.

• Take periodic breaks when you work at the computer for long periods of time. Frequent
and short breaks are better than fewer and longer breaks.

XIV

Preface

Lighting

Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and
shoulders.

• Position the display to avoid glare or reflections from overhead lighting or outside sources of light.

• Keep the display screen clean and set the brig htness and contrast to levels that allow you to see the screen clearly.

• Position the display directly in front of you at a comfortable viewing distance.

• Adjust the display-viewing angle to find the best position.

LCD Screen Care

To prevent image persistence on LCD monitors (caused by the continuous display of graphics on the screen for
an extended period of time) take the following precautions:

• Set the Windows Power Plans to turn the screen off after a few minutes of screen idle time.

• Use a rotating, moving or blank screen saver (this prevents an image from being displayed too long ).

• Rotate desktop background images every few days.

• Turn the monitor off when the system is not in use.

XV

Preface

XVI

Contents

Notice .................................................................................I

FCC Statement ................................................................III

FCC RF Radiation Exposure Statement: ........................IV

Instructions for Care and Operation ...............................VI

Power Safety ................................................................ VIII

Polymer Battery Precautions ..........................................IX

Battery Precautions ...................................................... ....X

Cleaning .......................................................................... XI

Servicing .........................................................................XI

Travel Considerations ....................................................XII

Quick Start Guide

Overview ........................................................................1-1

Advanced Users .............................................................1-2

Beginners and Not-So-Advanced Users ........................1-2

Warning Boxes ................................................ ..............1-2

Not Included ..................................................................1-3

System Software ................... .... .....................................1-4

Model Differences .........................................................1-4

System Startup ...............................................................1-5

System Map: LCD Panel Open ......................................1-6

LED Indicators ............................................. .... ..............1-7

Keyboard ........................................................................1-8

Preface

Function Keys & Visual Indicators ...............................1-9

System Map: Front & Rear Views ...............................1-10

System Map: Left & Right Views ...............................1-11

System Map: Bottom View ..........................................1-12

3.75G/HSPA Module USIM Card Installation ............1-13

Windows 7 Start Menu & Control Panel .....................1-14

Video Features .............................................................1-15

Power Options ........................................ .... ..................1-17

MOFA LCD Back Covers ...........................................1-18

Features & Components

Overview ........................................................................2-1

Hard Disk Drive .............................................................2-2

External USB Optical (CD/DVD) Device .....................2-3

Loading Discs ................................................................2-3

Handling CDs or DVDs .................................................2-4

DVD Regional Codes ....................................................2-5

3-in-1 Card Reader .........................................................2-6

Touchpad and Buttons/Mouse .......................................2-7

Gestures and Device Settings ........................................2-8

Audio Features .............................................................2-11

Optimizing Audio Recording .......................................2-12

Adding a Printer ................................................. .... ... ...2-13

XVII

Preface

USB Printer ..................................................................2-13

Parallel Printer .............................................................2-13

Power Management

Overview ........................................................................3-1

The Power Sources ...................................... .... ..............3-2

AC/DC Adapter .............................................................3-2

Battery ............................................................................3-2

Turning On the Computer ..............................................3-3

Power Plans ...................................................................3-4

Power-Saving States ......................................................3-6

Sleep ..............................................................................3-6

Hibernate ........................................................................3-7

Shut down ......................................................................3-7

Configuring the Power Buttons .....................................3-8

Resuming Operation ......................................................3-9

Energy Star Power Saving ...........................................3-10

Battery Information .....................................................3-11

Battery Power ..............................................................3-11

Conserving Battery Power ...........................................3-12

Battery Life .......................................................... ........3-13

New Battery .................................................................3-13

Recharging the Battery with the AC/DC Adapter .......3-13

Proper handling of the Battery Pack ............................3-14

Battery FAQ ............................................. .... ................3-15

Drivers & Utilities

What to Install ........................................................... .....4-1

Module Driver Installation .............................................4 -1

Driver Installation ..........................................................4-2

Updating/Reinstalling Individual Drivers ......................4-4

User Account Control ....................................................4-4

Windows Security Message ...........................................4-4

New Hardware Found ....................................................4-5

Driver Installation Procedure ......................................... 4-5

Chipset ...........................................................................4-5

Video ..............................................................................4-5

LAN ...............................................................................4-5

CardReader ....................................................................4-6

Touchpad .......................................................................4-6

Hot Key ..........................................................................4-6

Intel MEI Driver ............................................................4-6

Audio .............................................................................4-6

Windows Experience Index ...........................................4-7

Optional Drivers ............................................................4-8

Wireless LAN Module ...................................................4-8

PC Camera Module ........................................................4-8

3.75G Module ................................................................4-8

Bluetooth Module ..........................................................4-8

XVIII

Preface

BIOS Utilities

Overview ........................................................................5-1

The Power-On Self Test (POST) ................................... 5-2

Failing the POST ...........................................................5-3

Fatal Errors ....................................................................5-3

Non-Fatal Errors ............................................................5-3

The Setup Utility .................................................. ..........5-4

Entering Setup ...............................................................5-4

Setup Screens .................................................................5-5

Main Menu .....................................................................5-6

System Time & Date (Main Menu) ...............................5-6

SATA Aggress Link Power (Advanced Menu) .............5-7

SATA Port 1/2/3/4 (Main Menu) ..................................5-7

System Memory (Main Menu) ......................................5-7

BIOS Version/KBC/

EC Firmware Revision (Main Menu) ............................5-7

Advanced Menu .............................................................5-8

Legacy USB Support (Advanced Menu) .......................5-8

Boot-time Diagnostic Screen (Advanced Menu) ...........5-9

Legacy OS Boot (Advanced Menu) ..............................5-9

Battery Low Alarm Beep (Advanced Menu) .................5-9

Security Menu ..............................................................5-10

Set Supervisor Password (Security Menu) ..................5-10

Set User Password (Security Menu) ............................5-11

Password on boot (Security Menu) ..............................5-11

Boot Menu ...................................................................5-12

Exit Menu ....................................................................5-13

Upgrading The Computer

Overview ........................................................................6-1

When Not to Upgrade ....................................................6-2

Removing the Battery ....................................................6-3

Upgrading the Hard Disk Drive .....................................6-4

Upgrading the System Memory (RAM) ........................6-6

Changing the Optional LCD Back Covers ..................6-10

Modules & Options

Overview ........................................................................7-1

Wireless LAN Module ...................................................7-2

Intel® Wi-Fi Link Series Driver Installation .................7-3

802.11b/g/n WLAN Driver Installation .........................7-3

Connecting to a Wireless Network ................................7-4

Windows Mobility Center .............................................7-7

PC Camera Module ........................................................7-8

PC Camera Driver Installation .......................................7-9

3.75G/HSPA Module ...................................................7-15

Mobile Partner .............................................................7-19

Mobile Partner Application Installation ......................7-19

Mobile Partner Application .........................................7-20

Profile Management .....................................................7-20

XIX

Preface

Text Messaging Service ...............................................7-24

BandLuxe HSDPA Utility ...........................................7-25

BandLuxe HSDPA Utility Installation ........................7-25

BandLuxe HSDPA - Connection Manager ..................7-26

Creating a Profile .........................................................7-29

Choosing a Profile .......................................................7-32

Editing a Profile ...........................................................7-33

Text Messaging Service (SMS) ...................................7-34

Setting ..........................................................................7-37

Statistics & Information ...............................................7-43

Bluetooth Module ............. .... .... ...................................7-44

Bluetooth Combo Driver Installation ..........................7-45

Bluetooth & WLAN Combo Settings ..........................7-46

Bluetooth Networking Setup .......................................7-49

Bluetooth & WLAN Combo Module Configuration ...7-50

Standard Bluetooth Configuration in Windows 7 .......7-53

Troubleshooting

Overview ........................................................................8-1

Basic Hints and Tips ......................................................8-2

Backup and General Maintenance .................................8-3

Viruses ...........................................................................8-4

Upgrading and Adding New Hardware/Software ..........8-5

Problems and Possible Solutions ...................................8-7

Bluetooth Connection Problems ..................................8-12

Interface (Ports & Jacks)

Overview .......................................................................A-1

Intel Video Driver Controls

Intel Video Driver Installation ...................................... B-1

Dynamic Video Memory Technology ......................B-1

Intel® Graphics & Media Control Panel ......................B-2

Display Devices & Options ......................................B-4

Attaching Other Displays ..............................................B-5

Configuring an External Display in Windows 7 ...........B-7

HDMI Audio Configuration .......................................B-10

Specifications

Processor ....................................................................... C-2

Core Logic .................................................................... C-2

Display .......................................................................... C-2

Memory .........................................................................C-2

Video .............................................................................C-2

BIOS .............................................................................C-2

Storage ..........................................................................C-2

Audio ............................................................................C-2

Keyboard & Pointing Device ........................................C-2

Interface ........................................................................C-3

Card Reader ..................................................................C-3

XX

Slots ..............................................................................C-3

Communication .............................................................C-3

Power Management ......................................................C-3

Power ............................................................................ C-3

Security ......................................................................... C-3

Operating System ..........................................................C-3

Environmental Spec ......................................................C-4

Dimensions & Weight ..................................................C-4

Preface

XXI

Preface

XXII

Quick Start Guide

Chapter 1: Quick Start Guide

Overview

This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the
computer and to getting your system started. The remainder of the manual covers the following:

• Chapter 2 A guide to using some of the main features of the computer e.g. the storage devices (hard disk,
optical device, 3-in-1 card reader), Touchpad & Mouse, Audio & Printer.

• Chapter 3 The computer’s power saving options.

• Chapter 4 The installation of the drivers and utilities essential to the operation or improvement of some of the
computer’s subsystems.

• Chapter 5 An outline of the computer’s built-in software or BIOS (Basic Input Output System).

• Chapter 6 Instructions for upgrading your computer.

• Chapter 7 A quick guide to the computer’s W ireless LAN, PC Camera, 3.75G and Bluetooth modules (some
of which may be optional depending on your purchase configuration).

• Chapter 8 A troubleshooting guide.

• Appendix A Definitions of the interface, ports/jacks which allow your computer to communicate with external
devices.

• Appendix B Information on the Intel Video driver controls.

• Appendix C The computer’s specification.

1

Overview 1 - 1

1



Notes

Check the light colored
boxes with the mark
above to find detailed in­formation about the com­puter’s features.

Quick Start Guide

Advanced Users

If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful
to refer to “What to Install” on page 4 - 1, “BIOS Utilities” on page 5 - 1 and “Upgrading The Computer” on

page 6 - 1 in the reminder of the User’s Manual. You may also find the notes marked with a

 of interest to you.

Beginners and Not-So-Advanced Users

If you are new to computers (or do not have an advanced knowledge of them) then
the information contained in the Quick Start Guide should be enough to get you up
and running. Eventually you should try to look through all the documentation (more
detailed descriptions of the functions, setup and system controls are covered in the
remainder of the User’s Manual), but do not worry if you do not understand every­thing the first time. Keep this manual nearby and refer to it to learn as you go. You
may find it useful to refer to the notes marked with a

 as indicated in the margin.

For a more detailed description of any of the interface ports and jacks see “Interface

(Ports & Jacks)” on page A - 1.

Warning Boxes

No matter what your level please pay careful attention to the warning and safety information indicated by the

 symbol. Also please note the safety and handling instructions as indicated in the Preface.

1 - 2 Overview

Quick Start Guide



Drivers

If you are installing new system software, or are re-configuring your computer for a different system, you will need to install
the drivers listed in “Drivers & Utilities” on page 4 - 1. Drivers are programs which act as an interface between the com­puter and a hardware component e.g. a wireless network module. It is very important that you install the drivers in the order
listed. You will be unable to use most advanced controls until the necessary drivers and utilities are properl y installed. If
your system hasn’t been properly configured (your service representative may have already done that for you); refer to

Chapter 4 for installation instructions.

Ports and Jacks

See “Interface (Ports & Jacks)” on page A - 1 for a description of the interface (ports & jacks) which allow your computer
to communicate with external devices, connect to the internet etc.

Not Included

Operating Systems (e.g. Windows 7) and applications (e.g. word processing, spreadsheet and database programs)
have their own manuals, so please consult the appropriate manuals.

1

Overview 1 - 3

1



Windows OS

In order to run Windows 7 without limitations or decreased performance, your computer requires a minimum 1GB of sys­tem memory (RAM), however if you are running Windows 7 64 bit your computer requires a minimum 2GB of system
memory (RAM).

Quick Start Guide

System Software

Your computer may already come with system software pre-installed. Where this is not the case, or where you
are re-configuring your computer for a different system, you will find that this manual refers to the Windows 7
operating system.

Model Differences

This notebook series includes some model types that differ
cover options for
pearance may appear slightly different from those pictured throughout this manual.

Model B

computers

(see Appendix C

slightly in design style, and in particular the LCD back

for full specification details

).

Note that your model’s ap-

1 - 4 Overview

Quick Start Guide



Shutdown

Note that you should always shut your computer down by choosing the Turn Off Computer command from the Start
menu in Windows. This will help prevent hard disk or system problems.

System Startup

1. Remove all packing materials, and place the computer on a stable surface.

2. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports.

3. Attach the AC/DC adapter to the DC-In jack at the rear of the computer, then plug the AC power cord into an

outlet, and connect the AC power cord to the AC/DC adapter.

4.

Use one hand to raise the
other hand to support the base of the computer (Note: Never lift the computer by the lid/LCD)

5. Press the power button to turn the computer “on”.

lid/LCD to a comfortable viewing angle (do not exceed 120 degrees) while

.

using the

1

Figure 1 - 1 - Computer with AC/DC Adapter Plugged-In & Opening the Lid/LCD

System Startup 1 - 5

1

Figure 1 - 2

LCD Panel Open

1. Built-In PC Camera
(

Optional

)

2. LCD

3. Power Button

4. Keyboard

5. Built-In Microphone

6. Touchpad &
Buttons

7. LED Status &
Power Indicators

Note that the Touchpad and
Buttons valid operational area
is that indicated within the red
dotted lines above.

2

5

1

4

7

3



Wireless Device

Operation Aboard

Aircraft

The use of any portable
electronic transmission de­vices aboard aircraft is usu­ally prohibited. Make sure
the module(s) are OFF if
you are using the computer
aboard aircraft.

Use the key combinations to
toggle power to the 3.75G/
WLAN/Bluetooth mod­ules, and check the LED in­dicator icon to see if the
modules are powered on or
not (see Table 1 - 2, on

page 1 - 9/ Table 1 - 1, on
page 1 - 7).

6

7

Quick Start Guide

1 - 6 System Map: LCD Panel Open

System Map: LCD Panel Open

LED Indicators

The LED indicators display helpful information about the current status of the computer.

Icon Color Description

Orange DC Power is Plugged In

Quick Start Guide

1

(Power Status)

(Battery Status)

Green The Computer is On

Blinking Green The Computer is in Sleep Mode

Orange The Battery is Charging

Green The Battery is Fully Charged

Blinking Orange The Battery Has Reached Critically Low Power Status

Green Hard Disk Activity

Green The (optional) Wireless LAN Module is Powered On

Orange The (optional) Bluetooth Module is Powered On

Table 1 - 1 - LED Indicators

System Map: LCD Panel Open 1 - 7

1



Other Keyboards

If your keyboard is
damaged or you just
want to make a
change, you can use
any standard USB key­board. The system will
detect and enable it
automatically. Howev­er special functions/
hot-keys unique to the
system’s regular key­board may not work.

NumLk & ScrLk

Hold down the Fn Key
and either NumLk or
ScrLk to enable num­ber or scroll lock, and
check the LED indica­tor for status.

Numerical Keypad

Play/Pause Key

Function Keys

Toggle Key

3.5G Module
Power

NumLk &
ScrLk Keys

Fn Key



Special Characters

Some software applications allow the number-keys to be used with Alt to produce special
characters. These special characters can only be produced by using the numeric keypad.
Regular number keys (in the upper row of the keyboard) will not work. Make sure that

NumLk is on.

Quick Start Guide

Keyboard

The keyboard has a numerical keypad for easy numeric data input, and features func­tion keys to allow you to change operational features instantly. See Table 1 - 2, o n

page 1 - 9 for full function key combination details.

1 - 8 Keyboard

Figure 1 - 3 - Keyboard

Quick Start Guide

Function Keys & Visual Indicators

The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. Make sure
the hot key driver is installed (see “Hot Key” on page 4 - 6).

Keys Function/Visual Indicators Keys Function/Visual Indicators

Fn + ~ Play/Pause (in Audio/Video Programs) Fn + F7 Display Toggle

1

Fn + _

Fn + F1 Touchpad Toggle Fn + F10

Fn + F2

Fn + F3 Mute Toggle Fn + F12

Fn + F4 Sleep Toggle Fn + NumLk Number Lock Toggle

Fn +F5/F6

*Make sure that Wireless is ON in the Windows Mobility Center to ensure
proper wireless function key behavior (see page 3 - 12).

3.75G Module Power
Toggle*

(Press a key to or use Touchpad to turn on)

Volume Decrease/

Increase

Turn LCD Backlight Off

Fn +F8/F9

Fn + F11

Fn + ScrLk Scroll Lock Toggle

Caps Lock Caps Lock Toggle

Brightness Decrease/

Increase

PC Camera Power

Toggle*

WLAN Module Power

Toggle*

Bluetooth Module Power

Toggle*

Table 1 - 2 - Function Keys & Visual Indicators

Keyboard 1 - 9

1

Figure 1 - 4

Front & Rear Views

1. LED Indicators

2. External Monitor
Port

3. Vent/Fan Intake/
Outlet

4. Security Lock Slot

5. DC-In Jack

1

4

3

2



Overheating

To prevent your computer from overheating make sure nothing blocks the vent(s)/fan in­take(s) while the computer is in use.

5

Quick Start Guide

System Map: Front & Rear Views

1 - 10 System Map: Front & Rear Views

System Map: Left & Right Views

Figure 1 - 5

Left & Right Views

1. USB 2.0 Ports

2. Microphone-In
Jack

3. Headphone-Out
Jack

4. Speakers

5. 3-in-1 Card
Reader

6. HDMI-Out Port

7. RJ-45 LAN Jack



Optical Device

Drives

To install applications
and drivers etc. you will
need to attach an exter­nal optical CD/DVD de­vice to the USB ports.

1

76

4



3-in-1 Card Reader

The card reader allows you to use the most popular digital storage card formats:

MMC (MultiMedia Card) / RS MMC

SD (Secure Digital) / Mini SD / SDHC / SDXC Compatible

MS (Memory Stick) / MS Pro / MS Duo

2 3

4 5

1

1

Quick Start Guide

1

System Map: Left & Right Views 1 - 11

1

Figure 1 - 6

Bottom View

1. Battery

2. Hard Disk Bay
Cover

3. Vent/Fan Intake/
Outlet

4. Speakers



CPU

The CPU is not a user ser­viceable part. Opening this
compartment, or accessing
the CPU in any way, may vi­olate your warranty.

Overheating

To prevent your computer
from overheating make
sure nothing blocks the
Vent/Fan Intake while the
computer is in use.l

2

3

1

2

3

4

4



Battery Information

Always completely discharge, then fully charge, a new battery before using it. Completely discharge and
charge the battery at least once every 30 days or after about 20 partial discharges. See “Battery Infor-

mation” on page 3 - 11 for full instructions.

3.75G/HSPA Module USIM Card

The 3.75G/HSPA module’s USIM card location is located under the battery compartment. See

page 1 - 13 for instructions on installing the 3.75G/HSPA USIM card.

3

Quick Start Guide

System Map: Bottom View

1 - 12 System Map: Bottom View

Quick Start Guide

1

3

2

1

2



Battery Note

Latch should be held in place before re­moving the battery, and the 62.16WH bat-
tery has three battery latches to be
unlocked before releasing the battery.

USIM Card Orientation

Note that the USIM card’s readable side
(with the gold-colored contacts) should face
upwards as illustrated.

2

31.08WH

Battery

62.16WH

Battery

3.75G/HSPA Module USIM Card Installation

If you have included an optional 3.75G/HSPA module in your purchase option, follow the instructions below to
install the USIM card (which will be provided by your service provider), and then run the appropriate applica­tion. See “3.75G/HSPA Module” on page 7 - 15 for instructions on installing the program etc.

1. Turn off the computer, and turn it over and then remove the battery (slide the latches in the direction indicated
below and slide the battery out).

2. Insert the USIM card as illustrated below until it clicks fully into position, and replace the battery.

1

Figure 1 - 7 - Battery Removal & USIM Card Installation

3.75G/HSPA Module USIM Card Installation 1 - 13

1

Figure 1 - 8 - Start Menu & Control Panel

Click here to toggle Category View

Quick Start Guide

Windows 7 Start Menu & Control Panel

Most of the control panels, utilities and programs within Windows 7 (and most other Windows versions) are ac­cessed from the Start menu. When you install programs and utilities they will be installed on your hard disk
drive, and a shortcut will usually be placed in the Start menu and/or the desktop. Right-click the Start menu
icon , and then select Properties if you want to customize the appearance of the Start menu.

In many instances throughout this manual you will see an instruction to open the Control Panel. The Control
Panel is accessed from the Start menu, and it allows you to configure the settings for most of the key features
in Windows (e.g. power, video, network, audio etc.). Windows 7 provides basic controls for many of the features,
however many new controls are added (or existing ones are enhanced) when you install the drivers. To see all
controls it may be necessary to toggle off Category View to view the control panel icons.

1 - 14 Windows 7 Start Menu & Control Panel

Quick Start Guide

123

1

3

2

Video Features

You can configure display options from the Display (Control Panel) and Screen Resolution in Windows. For
more detailed video information see Appendix B.

To access Display (Control Panel) and Screen Resolution in Windows:

1. Click Start and click Control Panel.

2. Click Display (icon) - In the Appearance and Personalization category.

3. Click Adjust Screen Resolution/Adjus t resolution.

OR

4. Alternatively you can right-click the desktop and select Screen resolution (Figure 1 - 9).

5. Use the dropbox to select the screen Resolution (Figure 1 - 9).

6. Click Advanced settings (Figure 1 - 9) to bring up the Advanced properties tabs.

1

Figure 1 - 9 - Screen Resolution

Video Features 1 - 15

1

3

4

1

4

Quick Start Guide

To access the Intel(R) Graphics Media Accelerator Driver for mobile control panel:

1. Click Advanced settings (Figure 1 - 9 on page 1 - 15) in the Screen Resolution control panel in Win­dows.

2. Click the Intel(R)... tab and click Graphics Properties (button) (Figure 1 - 10 on page 1 - 16) .

OR

3. Right-click the desktop and select Graphics Properties from the menu.

OR

4. Click the icon in the taskbar and select Graphics Properties from the menu.

Figure 1 - 10 - Intel GMA Driver for Mobile Control Panel

1 - 16 Video Features

Quick Start Guide

Power Options

The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 1 - 14 ) allows you
to configure power management features for your computer. You can conserve power by means of power plans
and configure the options for the power button, sleep button, computer lid (when closed), display and sleep
mode from the left menu. Note that the Power saver plan may have an affect on computer performance.

Click to select one of the existing plans, or click Create a power plan in the left menu and select the options to
create a new plan. Click Change plan settings and click Change advanced power settings to access further con­figuration options.

Pay attention to the instructions on battery care in “Battery Information” on page 3 - 11.

1

Figure 1 - 11 - Power Options

Power Options 1 - 17

1

Quick Start Guide

MOFA LCD Back Covers

MOFA (Magic of Film Art) technology allows fashionable and unique pictorial designs to be printed on the spe­cially designed changeable LCD back covers. If your purchase option includes the specially designed change­able LCD back cover option, then follow the instructions in “Changing the Optional LCD Back Covers” on

page 6 - 12 to change the covers (note these covers are not applicable to all models in this series - consult

your service center for details).

Figure 1 - 12 - Magic Of Film Art Optional LCD Back Covers

1 - 18 MOFA LCD Back Covers

Features & Components

Chapter 2: Features & Components

Overview

Read this chapter to learn more about the following main features and components
of the computer:

•Hard Disk Drive

• External USB Optical (CD/DVD) Device

• 3-in-1 Card Reader

• Touchpad and Buttons/Mouse

• Audio Features

• Adding a Printer

2

Overview 2 - 1

Features & Components



Power Safety

Before attempting to ac­cess any of the internal
components of your
computer please ensure
that the machine is not
connected to the AC
power, and that the ma­chine is turned off. Also
ensure that all peripher­al cables, including
phone lines, are discon­nected from the comput­er.

Figure 2 - 1

Hard Disk Location

Hard Disk Bay

2

Hard Disk Drive

The hard disk drive is used to store your data in the computer. The hard disk can be
taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height
of 9.5 mm.

The hard disk is accessible from the bottom of your computer as seen below. For fur­ther details see “Upgrading the Hard Disk Drive” on page 6 - 4.

2 - 2 Hard Disk Drive

Features & Components



USB Cables

You can connect the op­tional USB optical de­vice using one of the
USB cables. However if
you are experiencing
connection or power
problems, connect both
USB cables from the de­vice to the computer.

External Optical

(CD/DVD) Device

Drives

To install applications
and drivers etc. you will
need to attach an exter­nal optical CD/DVD de­vice to the USB ports.

External USB Optical (CD/DVD) Device

An external USB optical (CD/DVD) device is available as an option for this com­puter. The optical device may be used as a boot device if properly set in the BIOS
(see “Boot Menu” on page 5 - 12).

Loading Discs

To insert a CD/DVD, simply slide the disc into the disc slot with label-side facing
up. The busy indicator will light up while data is being accessed, or while a disc is
playing. If power is unexpectedly interrupted, insert an object such as a straightened
paper clip into the emergency eject hole to eject the disc.

2

External USB Optical (CD/DVD) Device 2 - 3

Features & Components



CD Emergency Eject

If you need to manually
eject a CD (e.g. due to
an unexpected power
interruption) you may
push the end of a
straightened paper clip
into the emergency eject
hole. However please
do NOT use a sharp­ened pencil or similar
object that may break
and become lodged in
the hole.

Disk Eject Warning

Don’t try to remove a
CD/DVD while the sys­tem is accessing it. This
may cause the system
to “crash”.

2

2 - 4 External USB Optical (CD/DVD) Device

Handling CDs or DVDs

Proper handling of your CDs/DVDs will prevent them from being damaged. Please
follow the advice below to make sure that the data stored on your CDs/DVDs can be
accessed.

Note the following:

• Hold the CD or DVD by the edges; do not touch the surface of the disc.

• Use a clean, soft, dry cloth to remove dust or fingerprints.

• Do not write on the surface with a pen.

• Do not attach paper or other materials to the surface of the disc.

• Do not store or place the CD or DVD in high-temperature areas.

• Do not use benzene, thinner, or other cleaners to clean the CD or DVD.

• Do not bend the CD or DVD.

• Do not drop or subject the CD or DVD to shock.

Features & Components

Table 2 - 1

DVD Regional Coding

DVD Regional Codes

Go to the Control Panel and double-click Device Manager (Hardware and
Sound), then click the + next to DVD/CD-ROM drives. Double-click on the DVD-

ROM device to bring up the Properties dialog box, and select the DVD Region
(tab) to bring up the control panel to allow you to adjust the regional code.

DVD region detection is device dependent, not OS-dependent. You can select your
module’s region code 5 times. The fifth selection is permanent. This cannot be al­tered even if you change your operating system or you use the module in another
computer.

DVD Regional Coding

Region Geographical Location

1 USA, Canada
2 Western Europe, Japan, South Africa, Middle East & Egyp t

3

4 South & Central Ameri ca, Mexico, Australia, New Zealand
5 N Korea, Russia, Eastern Europe, India & Most of Africa

6 China

South-East Asia, Taiwan, South Korea, The Philippines,

Indonesia, Hong Kong

2

External USB Optical (CD/DVD) Device 2 - 5

Features & Components



Card Reader Cover

Make sure you keep the
rubber cover provided in
the card reader when
not in use. This will help
prevent foreign objects
and/or dust getting in to
the card reader.

Figure 2 - 2

Right View

1. Card Reader

• MMC (MultiMedia Card) / RS MMC

• SD (Secure Digital) / Mini SD / SDHC / SDXC Compatible

• MS (Memory Stick) / MS Pro / MS Duo

1

2

3-in-1 Card Reader

The card reader allows you to use some of the latest digital storage cards. Push the
card into the slot and it will appear as a removable device, and can be accessed in
the same way as your hard disk (s). Make sure you install the card reader driver (see

“CardReader” on page 4 - 6).

Note: Some of these cards require PC adapters that are usually supplied with the
cards.

2 - 6 3-in-1 Card Reader

Features & Components



Touchpad Scrolling

This computer model se­ries may feature different
Touchpad versions.

These Touchpads may
differ in their vertical
scrolling function in most
scrollable windows.

Some Touchpads require
sliding the finger up and
down on the right of the
Touchpad to scroll the
window. Other versions
require tapping/holding
down the finger at the top
right or bottom right of the
Touchpad to scroll the
window.

Figure 2 - 3

Mouse Properties

Touchpad and Buttons/Mouse

The Touchpad is an alternative to the mouse; however, you can also add a mouse to
your computer through one of the USB ports. The Touchpad buttons function in
much the same way as a two-button mouse.

Once you have installed the Touchpad driver (see “Touchpad” on page 4 - 6) you
can configure the functions by double-clicking the Touchpad driver icon on the
taskbar. You may then configure the Touchpad tapping, buttons, scrolling, pointer
motion and sensitivity options to your preferences. You will find further information
at www.synaptics.com.

2

Touchpad and Buttons/Mouse 2 - 7

Features & Components



Show Video

You can get a clearer
view of the gestures in­volved by clicking the
Show Video option for
each gesture item.

Select the gesture (Pinch

Zoom, Rotating, Three
Fingers Down and
Three Finger Flick) in the
Device Settings > Set­tings left tree menu

and click the Show Video
button to see the demon­stration video.

For more details on any of
the gestures see the help
in the lower part of the
right menu window.

Figure 2 - 4

Mouse Properties -

Device Settings

2

Gestures and Device Settings

The Synaptics Gestures Suite application allows you to use a specific gesture (ac­tion) on the surface of the Touchpad to perform specific actions to manipulate doc­uments, objects and applications.

You can configure the settings from the Device Settings tab in Mouse Properties:

1. Click

2. Click Mouse (Hardware and Sound).

3. Click Device Settings (tab) and click Settings.

4. Use the menu tree on the lef t to access the user configurable settings.

Start

, and click

Control Panel

(or point to

Settings

and click

Control Panel

).

2 - 8 Touchpad and Buttons/Mouse

Scrolling

Figure 2 - 5

Scrolling Gesture



Mouse Driver

If you are using an ex­ternal mouse your op­erating system may be
able to auto-configure
your mouse during its
installation or only en­able its basic functions.
Be sure to check the
device’s user docu­mentation for details.

Figure 2 - 6

Zooming Gesture

The Two-Finger scrolling feature works in most scrollable windows and allows you
to scroll horizontally and vertically. Place two fingers, slightly separated, on the
Touchpad surface and slide both fingers in the direction required (in a straight con­tinuous motion).

Zooming

The Pinch Zoom gesture can be used to perform the same function as a scroll wheel
in Windows applications that support CTRL + scroll wheel zoom functionality.
Place two fingers on the Touchpad (for best results use the tips of the fingers) and
slide them apart to zoom in, or closer together to zoom out.

Features & Components

2

Touchpad and Buttons/Mouse 2 - 9

Features & Components

Figure 2 - 7

Rotating Gesture

Figure 2 - 8

Flick/Press

Gesture

2

Rotating

Use the Pivot Rotate gesture to rotate objects (e.g. photos) in 90 degree increments.
Place a finger down on the left “target” zone and keep it stationary. Place another
finger near the middle of the Touchpad and slide it in a circular motion around the
stationary finger (clockwise or counterclockwise) to rotate the object.

Three Finger-Flick/Three Fingers Down (Press)

The Three Finger-Flick gesture may be used to enhance navigation with a variety of
applications such as browsing the Internet or scrolling through a photo viewer. The
Three Fingers Down gesture may be used to launch user-selectable applications.

2 - 10 Touchpad and Buttons/Mouse

Features & Components



Sound Volume

Adjustment

The sound volume level
is set using the volume
control within Windows
(and the volume func­tion keys on the comput­er). Click the volume
icon in the taskbar to
check the setting.

Figure 2 - 9

Realtek Audio

Manager

Right-click the icon
to access the menu
above.

Audio Features

You can configure the audio options on your computer from the Sound control
panel in Windows, or from the Realtek HD Audio Manager icon in the taskbar/
control panel (right-click the taskbar icon to bring up an audio menu). The volume
may also be adjusted by means of the Fn + F5/F6 key combination.

2

Audio Features 2 - 11

Features & Components

Figure 2 - 10

Optimizing Audio

Recording

2

Optimizing Audio Recording

Follow these instructions to optimize your audio recording.

1. Double-click the taskbar icon to bring up the Realtek HD Audio Manager.

2. Click the Microphone tab.

3. Click the Noise Suppression button to prevent any background noise or
feedback.

4. Click OK to close the Realtek HD Audio Manager.

2 - 12 Audio Features

Features & Components



Parallel Printer

After setting up the print­er attach the parallel ca­ble to the printer.

Connect the printer’s
parallel cable to the Par­allel to USB converter,
and then plug the con­verter into the USB port.

Turn ON the printer,
then turn ON the com­puter.

Windows will identify the
printer and either load
one of its own drivers or
ask you to supply one.
Follow the on-screen in­structions.

Adding a Printer

The most commonly used peripheral is a printer. The following conventions will
help you to add a printer; however it is always best to refer to the printer manual for
specific instructions and configuration options.

USB Printer

Most current printers have a USB interface connection. You may use any one of the
ports to connect the printer.

Install Instructions:

1. Set up the printer according to its instructions (unp acking, p aper tr ay, toner/ink car­tridge etc.).

2. Turn ON the computer.

3. Turn ON the printer.

4. Connect the printer’s USB cable to one of the USB ports on the computer.

5. Windows will identify the printer and either load one of its own drivers or ask you
to supply one. Follow the on-screen instructions.

Parallel Printer

This is still a very common type of printer. The install instructions are in the sidebar,
however you will need to purchase a parallel to USB converter.

2

Adding a Printer 2 - 13

Features & Components

2

2-14

Chapter 3: Power Management



OS Note

Power management
functions will vary slight­ly depending on your
operating system. For
more information it is
best to refer to the user’s
manual of your operat­ing system.

Power Management

Overview

To conserve power, especially when using the battery, your computer power man­agement conserves power by controlling individual components of the computer
(the monitor and hard disk drive) or the whole system. This chapter covers:

• The Power Sources

• Turning On the Computer

• Power Plans

• Power-Saving States

• Configuring the Power Buttons

• Energy Star Power Saving

• Battery Information

The computer uses enhanced power saving techniques to give the operating system
(OS) direct control over the power and thermal states of devices and processors. For
example, this enables the OS to set devices into low-power states based on user set­tings and information from applications.

3

Overview 3 - 1

Power Management

The Power Sources

The computer can be powered by either an AC/DC adapter or a battery pack.

3

AC/DC Adapter

Use only the AC/DC adapter that comes with your computer. The wrong type of AC/
DC adapter will damage the computer and its components.

1. Attach th e AC/DC adapter to the DC-in jack at the rear of the computer.

2. Plug the AC power cord into an outlet, and then conne ct the AC power co rd to the
AC/DC adapter.

3. Raise the lid/LCD to a comfortable viewing angle.

4. Press the power button to turn “On”.

Battery

The battery allows you to use your computer while you are on the road or when an
electrical outlet is unavailable. Battery life varies depending on the applications and
the configuration you're using. To increase battery life, let the battery discharge
completely before recharging (see “How do I completely discharge the battery?”

on page 3 - 15).

We recommend that you do not remove the battery. For more information on the bat­tery, please refer to “Resuming Operation” on page 3 - 9.

3 - 2 The Power Sources

Turning On the Computer



Forced Off

If the system “hangs”,
and the Ctrl + Alt + Del
key combination doesn’t
work, press the power
button for 4 seconds, or
longer, to force the sys­tem to turn itself off.

Power Button as

Stand by or

Hibernate Button

You can use the OS’s
“Power Options” control
panel to set the power
button to send the sys­tem into Stand by or Hi­bernate mode (see your
OS’s documentation, or

“Configuring the Pow­er Buttons” on page 3

- 8 for details).



Shut Down

Note that you should always shut your computer down by choosing the Shut Down com­mand from the bottom right of the Start menu in Windows. This will help prevent hard disk
or system problems.

Now you are ready to begin using your computer. To turn it on simply press the pow­er button on the front panel.

When the computer is on, you can use the power button as a Stand by/Hibernate/
Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and
holding the power button for longer than this will shut the computer down). Use
Power Options in the Windows control panel to configure this feature.

Power Management

3

Turning On the Computer 3 - 3

Power Management



Resuming
Operation

See Table 3 - 1, on

page 3 - 9 for informa-

tion on how to resume
from a power-saving
state.

Password

It is recommended that
you enable a password
on system resume in or­der to protect your data.

Figure 3 - 1

Power Plan

Advanced Settings

Power Plans

The computer can be configured to conserve power by means of power plans. You

3

can use (or modify) an existing power plan, or create a new one.

3 - 4 Power Plans

The settings may be adjusted to set the display to turn off after a specified time, and
to send the computer into Sleep after a period of inactivity.

Click Change plan settings and then click Change advanced power settings to ac­cess further configuration options in Advanced Settings.

Each Windows power plan will also adjust the processor performance of your ma-

Figure 3 - 2

Power Plans

Click to Show/Hide
additional
power plans

chine in order to save power. This is worth bearing in mind if you are experiencing
any reduced performance (especially under DC/battery power).

Choose High performance (you may need to click Show additional plans to view
the High performance plan) for maximum performance when the computer is pow­ered from an AC power source. Choose the Power saver (bear in mind that this
scheme may slow down the overall performance of the computer in order to save
power) for maximum power saving when the computer is battery (DC power) pow­ered.

Power Management

3

Power Plans3-5

Power Management

Power-Saving States

You can use power-saving states to stop the computer’s operation and restart where

3

you left off. Win 7 uses the Sleep, Hibernate and Shut Down power-saving states.

Sleep

In Sleep all of your work, settings and preferences are saved to memory before the
system sleeps. When you are not using your computer for a certain length of time,
which you specify in the operating system, it will enter Sleep to save power.

The PC wakes from Sleep within seconds and will return you to where you last left
off (what was on your desktop) without reopening the application(s) and file(s) you
last used.

If your mobile PC in Sleep is running on battery power the system will use only a
minimum amount of power. After an extended period the system will save all the
information to the hard disk and shut the computer down before the battery becomes
depleted.

3 - 6 Power-Saving States

Hibernate

Figure 3 - 3

Start Menu Power

Hibernate uses the least amount of power of all the power-saving states and saves
all of your information on a part of the hard disk before it turns the system off. If a
power failure occurs the system can restore your work from the hard disk; if a power
failure occurs when work is saved only to memory, then the work will be lost. Hi-
bernate will also return you to where you last left off within seconds. You should
put your mobile PC into Hibernate if you will not use the computer for a period of
time, and will not have the chance to charge the battery.

Shut down

You should Shut down the computer if you plan to install new hardware (don’t for­get to remove the battery and follow all the safety instructions in Chapter 6), plan
to be away from the computer for several days, or you do not need it to wake up and
run a scheduled task. Returning to full operation from Shut down takes longer than
from Sleep or Hibernate.

Power Management

3

Power-Saving States 3 - 7

Power Management



Password

Protection

It is recommended that
you enable a password
on wake up in order to
protect your data.

However you can dis­able this setting from the
Power Options menu
by clicking Require a

password on wakeup

in the left menu, and se­lecting the options (click

Change settings that
are currently unavail­able).

Figure 3 - 4

Power Options

Define Power

Buttons

3

Configuring the Power Buttons

The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the
computer in to a power-saving state. Click Choose what the power buttons do on
the left menu in Power Options to bring up the menu.

3 - 8 Configuring the Power Buttons

Resuming Operation



Closing the Lid

If you have chosen to
send the computer to
Sleep when the lid is
closed, raising the lid
will wake the system up.

Table 3 - 1

Resuming
Operation



3.75G/HSPA

Modules & System

Wake Up

Note that the 3.75G mod­ules

DO NOT

support

system wake up on

3.75G/HSPA modem ac­tivity.



Power Button

When the computer is on, you can use the power button as a Sleep/Hibernate/Shut Down
hot key button when it is pressed for less than 4 seconds (pressing and holding the power
button for longer than this will force the computer to shut down).

You can resume operation from power-saving states by pressing the power button,
or in some cases pressing the sleep button (Fn + F4 key combo).

Power Status

Power Off Off Press the Power Button

Sleep Blinking Green

Hibernate

Display Turned Off Green Press a Key or Move the Mouse/Touchpad

Icon Color

Press the Sleep Button (Fn + F4 Key Combo)

Off (battery)

Orange (AC/DC adapter)

To Resume

Press the Power Button

Press the Power Button

Configuring the Power Buttons 3 - 9

Power Management

3

Power Management



Taskbar Icon

If the taskbar icon does
not appear then click the
taskbar arrow and select

Customize.

Select Show icon and
notifications alongside

the Hotkey icon and
click OK. The icon
will now appear in the
taskbar.

Figure 3 - 5

Energy Star Menu



Conservation Modes

The default Energy Star setting
will result in maximum power sav­ing, but with the possible loss of
some performance.
Setting the mode to Balance will
give power saving matched with
performance.
Performance will give optimum
computer performance but with
less power conservation.

Energy Star Power Saving

This system supports Energy Star power management features that place comput-

3

ers (CPU, hard drive, etc.) into a low-power sleep modes after a designated period
of inactivity. If you want to enable Energy Star power saving then follow these in­structions:

3 - 10 Configuring the Power Buttons

1. Right-click the taskbar icon (see sidebar).

2. Select Power Conservation Modes.

3. Select Energy St ar to use the Energy Star power management and override other
power saving settings.

Battery Information



Low Battery

Warning

When the battery is criti­cally low, immediately
connect the AC/DC
adapter to the computer
or save your work, oth­erwise, the unsaved
data will be lost when
the power is depleted.

Figure 3 - 6

Battery Icon

(Taskbar) & Battery

Advanced Settings

Follow these simple guidelines to get the best use out of your battery.

Battery Power

Your computer’s battery power is dependent upon many factors, including the pro­grams you are running, and peripheral devices attached. You can set actions to be
taken (e.g. Shut down, Hibernate etc.), and set critical and low battery levels from
power plan Change plan settings > Change advanced power settings (see Figure

3 - 2 on page 3 - 5).

Click the battery icon in the taskbar to see the current battery level and charge
status.

Power Management

3

Battery Information 3 - 11

Power Management



Wireless Hot Keys

The computer’s wireless
function keys will not func­tion properly if Wireless is
turned OFF in the Win-

dows Mobility Center

control panel.

The wireless indicators

may show that
the WLAN module is pow­ered on, however if wire­less is OFF in the Mobility
Center, the module will not
be powered on.

Make sure that Wireless is
ON in the Mobility Center to
ensure proper function key
behavior.

Figure 3 - 7

Windows Mobility

Center



Windows Mobility

Center

The Windows Mobili­ty Center control pan-

el provides an easy
point of access for in­formation on battery
status, power plans
used and wireless de­vice status etc.

Make sure Wireless is ON to ensure proper function key behavior.

3

Conserving Battery Power

•Use a power plan that conserves power (e.g Power saver), however note that

this may have an affect on computer performance.

• Lower the brightness level of the LCD display. The system will decrease LCD
brightness slightly to save power when it is not powered by the AC/DC adapter.

• Reduce the amount of time before the display is turned off.

• Close wireless, Bluetooth, modem or co mmunication applications when they are
not being used.

• Disconnect/remove any unnecessary external devices e.g. USB devices,
ExpressCards etc.

3 - 12 Battery Information

Battery Life

Battery life may be shortened through improper maintenance. To optimize the life
and improve its performance, fully discharge and recharge the battery at least
once every 30 days.

We recommend that you do not remove the battery yourself. If you do need to re­move the battery for any reason (e.g. long term storage) see “Removing the Battery”

on page 6 - 3.

New Battery

Always completely discharge, then fully charge, a new battery (see “Battery FAQ”

on page 3 - 15 for instructions on how to do this).

Recharging the Battery with the AC/DC Adapter

The battery pack automatically recharges when the AC/DC adapter is attached and
plugged into an electrical outlet. If the computer is powered on, and in use, it will
take several hours to fully recharge the battery. When the computer is turned off but
plugged into an electrical outlet, battery charge time is less. (Refer to “LED Indica-

tors” on page 1 - 9 for information on the battery charge status, and to “Resuming
Operation” on page 3 - 9 for more information on how to maintain and properly re-

charge the battery pack.)

Power Management

3

Battery Information 3 - 13

Power Management



Caution

Danger of explosion if
battery is incorrectly re­placed.

Replace only with the
same or equivalent type
recommended by the
manufacturer. Discard
used battery according
to the manufacturer’s in­structions.



Damaged Battery Warning

Should you notice any physical defects (e.g. the battery is bent ou t of shape after being
dropped), or any unusual smells emanating from the notebook battery, shut your computer
down immediately and contact your service center. If the battery has bee n d roppe d we do
not recommend using it any further, as even if the computer continues to work with a dam­aged battery in place, it may cause circuit damage, which may possibly result in fire . It is
recommended that you replace your computer battery every two years.

Proper handling of the Battery Pack

• DO NOT disassemble the battery pack under any circumstances

• DO NOT expose the battery to fire or high temperatures, it may explode

3

• DO NOT connect the metal terminals (+, -) to each other

3 - 14 Battery Information

Battery FAQ

Figure 3 - 8

Power Plan Create

How do I completely discharge the battery?

Use the computer with battery power until it shuts down due to a low battery. Don’t
turn off the computer even if a message indicates the battery is critically low, just let
the computer use up all of the battery power and shut down on its own.

1. Save and close all files and applications.

2. Create a power plan for discharging the battery and set all the options to Never.

Power Management

3

Battery Information 3 - 15

Power Management

Figure 3 - 9

Change Plan

Settings / Change

Advanced Power

Settings

3

3. Click Change plan settings (after creating it) and click Change plan settings >

Change advanced power settings.

3 - 16 Battery Information

4. Scroll down to Battery and click + to expand the ba ttery options.

Figure 3 - 10

Power Options

Advanced Settings -

Battery

5. Choose the options below (click Yes if a warning appears):

• Low battery levels = 0%

• Critical battery Levels = 0%

• Low battery action = Do Nothing

• Critical battery action (On battery) = Shut Down

• Critical battery action (Plugged in) = Do Nothing

Power Management

3

Battery Information 3 - 17

Power Management

How do I fully charge the battery?

When charging the battery, don’t stop until the LED charging indicator light changes
from orange to green.

3

How do I maintain the battery?

Completely discharge and charge the battery at least once every 30 days or after
about 20 partial discharges.

3 - 18 Battery Information

Chapter 4: Drivers & Utilities

Drivers & Utilities

This chapter deals with installing the drivers and utili­ties essential to the operation or improvement of some
of the computer’s subsystems. The system takes ad­vantage of some newer hardware components for
which the latest versions of most available operating
systems haven’t built in drivers and utilities. Thus,
some of the system components won’t be auto-config­ured with an appropriate driver or utility during oper­ating system installation. Instead, you need to
manually install some system-required drivers and
utilities.

What to Install

You will need to attach a DVD drive to the computer
in order to access the drivers on the Device Drivers &
Utilities + User’s Manual disc. This contains the driv­ers and utilities necessary for the proper operation of
the computer.

Table 4 - 1, on page 4 - 3 lists what you need to install

and it is very important that the drivers are in-
stalled in the order indicated.

Module Driver Installation

The procedures for installing drivers for the PC Cam­era, Wireless LAN, 3.75G and Bluetooth & WLAN
Combo modules are provided in “Modules & Op-

tions” on page 7 - 1.

4

What to Install 4 - 1

Drivers & Utilities

Driver Installation

Insert the Device Drivers & Utilities + User’s Manual
disc into an attached DVD drive and click Install Driv-
ers/Option Drivers (button).

4

Follow the instructions to install the driver. Alterna­tively click Start, navigate (Browse..) to the execut­able file and then follow the manual setup instructions.

1. Check the driver installation order from Table 4 - 1,

on page 4 - 3 (the drivers must be installed in

this order) which is the same as that listed in the

Drivers Installer menu below.

2. Click to select the driver you wish to install, (you
should note down the drivers as you install them).

3. Follow the instructions for each individual driver
installation procedure as listed on the following
pages.

Note: If you need to reinstall any driver, you should uninstall the
driver first.

Figure 4 - 1 - Drivers Installer Screen 1

4 - 2 Driver Installation

Figure 4 - 2 - Drivers Installer Screen 2

Driver - Windows 7 Page #

Chipset Page 4 - 5
Video Page 4 - 5
LAN Page 4 - 5
CardReader Page 4 - 6
Touchpad Page 4 - 6
Hot Key Page 4 - 6

Intel MEI Driver Page 4 - 6
Audio Page 4 - 6
Wireless LAN Module Page 7 - 3

PC Camera Module Page 7 - 9

Drivers & Utilities

Manual Driver Installation

Click Browse CD/DVD (button) in the Drivers Install­er application and browse to the executable file in the

appropriate driver folder.

Windows Update

After installing all the drivers make sure you enable
Windows Update in order to get all the latest security
updates etc. (all updates will include the latest hotfixes
from Microsoft). See “Windows 7 Update” on page 4

- 7 for instructions.

4

3.75G/HSPA Module

Bluetooth Module (driver required

for Combo BT & WLAN module only)

Table 4 - 1 - Driver Installation

Page 7 - 19
Page 7 - 25

Page 7 - 45

Driver Installation 4 - 3

Drivers & Utilities

Updating/Reinstalling Individual Drivers

If you wish to update/reinstall individual drivers it
may be necessary to uninstall the original driver.To do
this go to the Control Panel in the Windows OS and
double-click the Programs and Features icon (Pro-

4

grams > Uninstall a program). Click to select the
driver (if it is not listed see below) and click Uninstall,
and then follow the on screen prompts (it may be nec­essary to restart the computer). Reinstall the driver as
outlined in this chapter.

If the driver is not listed in the Programs and Fea-
tures menu:

1. Click Start, and click Control Panel (or point to
Settings and click Control Panel).

2. Double-click Device Manager (Hardware and
Sound > Device Manager).

3. Double-click the device you wish to update/reinstall
the driver for (you may need to click “+” to expand
the selection).

4. Click Driver (tab) and click the Update Driver or

Uninstall button and follow the on screen prompts.

User Account Control

If a User Account Control prompt appears as part of
the driver installation procedure, click Continue or
Allow, and follow the installation procedure as direct­ed.

Windows Security Message

If you receive a Windows security message as part of
the driver installation process. Just click “Install this
driver software anyway” or “Install” to continue the
installation procedure.

You will receive this message in cases where the driv­er has been released after the version of Windows you
are currently using. All the drivers provided will have
already received certification for Windows.

4 - 4 Driver Installation

Drivers & Utilities



Driver Installation General Guidelines

The driver installation procedure outlined in this Chapter
(and in Chapter 7 Options & Modules), are accurate at
the time of going to press.

Drivers are always subject to upgrade and revision so
the exact procedure for certain drivers may differ slight­ly. As a general guide follow the default on screen in­structions for each driver (e.g. Next > Next > Finish)
unless you are an advanced user. In many cases a re­start is required to install the driver.

Make sure any modules (e.g. PC Camera, WLAN or

3.75G/HSPA) are ON before installing the appropriate
driver.

New Hardware Found

If you see the message “New Hardware Found” dur-
ing the installation procedure (other than when out-
lined in the driver install procedure), click Cancel
to close the window, and follow the installation proce­dure.

Driver Installation Procedure

Insert the Device Drivers & Utilities + User’s Manual
disc into your attached CD/DVD drive and click In-
stall Drivers (button).

Chipset

1. Click 1.Install Chipset Driver > Yes.

2. Click Next > Yes > Next > Next.

3. Click Finish.

Video

1. Click 2.Install VGA Driver > Yes.

2. Click Next > Yes > Next > Next.

3. Click Finish to restart the computer.

LAN

1. Click 3.Install LAN Driver > Yes.

2. Click Install > Finish.

3. The network settings can now be configured.

4

Driver Installation 4 - 5

Drivers & Utilities

CardReader

1. Click 4.Install CardReader Driver > Yes.

2. Click Install > Finish.

Touchpad

4

1. Click 5.Install Touchpad Driver > Yes.

2. Click Next.

3. Click the button to accept the license agreement

and click Next.

4. Click Finish > Restart Now to restart the com-

puter.

Hot Key

1. Click 6.Install Hotkey AP > Yes.

2. Click Next > Next.

3. Click Finish > Finish to restart the computer.

Intel MEI Driver

1. Click 7.Install MEI Driver > Yes.

2. Click Next > Yes > Next > Next.

3. Click Finish to restart the computer.

Audio

1. Click 8.Install Audio Driver > Yes.

2. Click Next.

3. Click Finish to restart the computer.

Note that after installing the audio driver the system
will not return to the Drivers Installer screen. To in­stall any of the optional drivers listed overleaf, eject
the Device Drivers & Utilities + User’s Manual disc
and then reinsert it (or double-click the disc icon in My
Computer), and click Option Drivers (button) to ac­cess the optional driver menu.

4 - 6 Driver Installation

(See Over)

Windows Experience Index



Windows 7 Update

After installing all the drivers make sure you enable Win­dows Update in order to get all the latest security up-

dates etc. (all updates will include the latest hotfixes
from Microsoft).

To enable Windows Update make sure you are con-
nected to the internet:

1. Click Start, and click Control Panel (or point to
Settings and click Control Panel).

2. Click Window s Update (System and Security).

3. Click Check for updates (button).

4. The computer will now check for updates (you
need to be connected to the internet).

5. Click Install now (button) to begin checking for the
updates.

6. Click Install updates (button) to install the
updates.

After the drivers are installed follow this procedure to
ensure an accurate rating from the Windows Experi-
ence Index:

Drivers & Utilities

1. Click Start, and click Control Panel.

2. Click Performance Information and Tools

3. Click “Rate this computer”.

4. The computer will take a few minutes to assess

5. Close the control panel.

(System and Security > System > Check the
Windows Experience Index).

the system performance.

4

Driver Installation 4 - 7

Drivers & Utilities

Optional Drivers

See the pages indicated for the driver installation pro­cedures for any modules included in your purchase op­tion.

4

Figure 4 - 3 - Drivers Installer - Option Drivers Menu

Wireless LAN Module

See the introduction in “Wireless LAN Module” on

page 7 - 2, and check the installation procedure.

PC Camera Module

See the introduction in “PC Camera Module” on

page 7 - 8, and check the installation procedure.

3.75G Module

See the introduction in “3.75G/HSPA Module” on

page 7 - 15, and check the installation procedure ap-

propriate for your module.

Bluetooth Module

A driver is only required for the Combination
Wireless LAN & V3.0 Bluetooth. See “Bluetooth

Combo Driver Installation” on page 7 - 45.

The operating system is the default setting for Blue­tooth control for the standard V2.0 Bluetooth mod­ule in Windows 7 and does not require a driver. See

“Standard Bluetooth Configuration in Windows 7”
on page 7 - 53 for instructions.

4 - 8 Driver Installation

Chapter 5: BIOS Utilities



BIOS Screens

Note that the BIOS
screens pictured on
these pages are intend­ed for guidance in set­ting up your system’s
BIOS.

BIOS versions are sub­ject to constant change
and revision, therefore
your computer’s actual
screens may appear
slightly different from
those pictured on these
pages.

Overview

This chapter gives a brief introduction to the computer’s built-in software:

Diagnostics: The POST (Power-On Self Test)

Configuration: The Phoenix Setup utility

If your computer has never been set up, or you are making impo rtant changes to the
system (e.g. hard disk setup), then you should review this chapter first and note the
original settings found in Setup. Even if you are a beginner, keep a record of the set­tings you find and any changes you make. This information could be useful if your
system ever needs servicing.

There is one general rule: Don’t make any changes unless you are sure of what you
are doing. Many of the settings are required by the system, and changing them could
cause it to become unstable or worse. If you have any doubts, consult your service
representative.

BIOS Utilities

5

Overview 5 - 1

BIOS Utilities



POST Screen

1.BIOS information

2.CPU type

3.Memory status

4.Enter Setup prompt
appears only during

POST

Note:

The

POST

screen
as pictured right is for
guideline purposes only.
The

POST

screen on
your computer may ap­pear slightly different. If
you disable the

Boot-

time Diagnostic Screen

,
the POST screen will not
appear.

Figure 5 - 1

POST Screen

1

2

3

4

5

The Power-On Self Test (POST)

Each time you turn on the computer, the system takes a few seconds to conduct a
POST, including a quick test of the on-board RAM (memory).

As the POST proceeds, the computer will tell you if there is anything wrong. If there
is a problem that prevents the system from booting, it will display a system summary
and prompt you to run Setup.

If there are no problems, the Setup prompt will disappear and the system will load
the operating system. Once that starts, you can’t get into Setup without rebooting.

5 - 2 The Power-On Self Test (POST)

Failing the POST

Errors can be detected during the POST. There are two categories, “fatal” and “non­fatal”.

Fatal Errors

These stop the boot process and usually indicate there is something seriously wrong
with your system. Take the computer to your service representative or authorized
service center as soon as possible.

Non-Fatal Errors

This kind of error still allows you to boot. You will get a message identifying the
problem (make a note of this message!) followed by the prompt:

• Press <F1> to resume

• <F2> to enter Setup

Press F1 to see if the boot process can continue. It may work, without the correct
configuration.

BIOS Utilities

5

Press F2 to run the Setup program and try to correct the problem. If you still get an
error message after you change the setting, or if the “cure” seems even worse, call
for help.

The Power-On Self Test (POST) 5 - 3

BIOS Utilities



BIOS Settings

Warning

Incorrect settings can
cause your system to
malfunction. To correct
mistakes, return to Set-

up and restore the Set­up Defaults with <F9>.

5

The Setup Utility

The Phoenix Setup Utility tells the system how to configure itself and manage basic
features and subsystems (e.g. port configuration).

Entering Setup

To enter Setup, turn on the computer and press F2 during the POST. The prompt
(Press F2 to Enter Setup) seen on page 5 - 2 is usually present for a few seconds
after you turn on the system. If you get a “Keyboard Error”, (usually because you
pressed F2 too quickly) just press F2 again.

If the computer is already on, reboot using the Ctrl + Alt + Delete combination and
then hold down F2 when prompted. The Setup main menu will appear.

5 - 4 The Setup Utility

Setup Screens



Setup Menus

The Setup menus
shown in this section are
for reference only. Your
computer’s menus will
indicate the configura­tion appropriate for your
model and options.

The following pages contain additional advice on portions of the Setup.

Along the top of the screen is a menu bar with menu headings. When you select a
heading, a new screen appears. Scroll through the features listed on each screen to
make changes to Setup.

BIOS Utilities

Instructions on how to navigate each screen are in the box along the bottom of the
screen. If these tools are confusing, press F1 to call up a General Help screen, and
then use the arrow keys to scroll up or down the page.

The Item Specific Help on the right side of each screen explains the highlighted
item and has useful messages about its options.

If you see an arrow next to an item, press Enter to go to a sub-menu on that sub­ject. The sub-menu screen that appears has a similar layout, but the Enter key may
execute a command.

5

The Setup Utility 5 - 5

BIOS Utilities

Figure 5 - 2

Main Menu

Main Menu

5

System Time & Date (Main Menu)

The hour setting uses the 24-hour system (i.e., ØØ = midnight; 13 = 1 pm). If you
can change the date and time settings in your operating system, you will also change
these settings. Some applications may also alter data files to reflect these changes.

5-6Main Menu

SATA Aggress Link Power (Advanced Menu)

This item is only available if AHCI is set as the SATA Mode. Aggressive Link Pow­er Management (ALPM) allows the SATA AHCI controller to put the link to the
disk into a very low power mode when the IO is not being used. The controller au­tomatically puts the link back into an active power mode when required.

SATA Port 1/2/3/4 (Main Menu)

Pressing Enter opens the sub-menu to show the configuration of a HDD or optical
device on the computer’s Serial ATA Port 1/2. Use the Auto (Type:) setting to have
the items configured automatically for you.

System Memory (Main Menu)

This item contains information on the system memory, and is not user configurable.
The system will auto detect the amount of memory installed.

BIOS Version/KBC/EC Firmware Revision (Main Menu)

This item contains information on the BIOS version.

BIOS Utilities

5

Main Menu 5 - 7

BIOS Utilities

Figure 5 - 3

Advanced Menu

5

Advanced Menu

Legacy USB Support (Advanced Menu)

Choose “Enabled” if you intend to use USB devices in systems which do not nor­mally support USB functionality (e.g. DOS). The default setting is “Enabled” and
does not need to be changed if you intend to use your USB devices in Windows.

5 - 8 Advanced Menu

Boot-time Diagnostic Screen (Advanced Menu)

Use this menu item to enable/disable the Boot-time Diagnostic Screen or POST
screen (see “The Power-On Self Test (POST)” on page 5 - 2).

Legacy OS Boot (Advanced Menu)

If “Enabled” the system will attempt to load the Legacy OS (e.g. Vista/Windows
XP) first. If set to “Disabled” the system will attempt to EFI (Extensible Firmware

Interface) boot before the Legacy OS.

Battery Low Alarm Beep (Advanced Menu)

Use this menu item to enable/disable the audible warning when the battery has
reached low power status.

BIOS Utilities

5

Advanced Menu 5 - 9

BIOS Utilities



Security Menu

The changes you
make here affect the
access to the Setup
utility itself, and also
access to your ma­chine as it boots up af­ter you turn it on.
These settings do not
affect your machine or
network passwords
which will be set in
your software OS.

Figure 5 - 4

Security Menu

5

Security Menu

Set Supervisor Password (Security Menu)

You can set a password for access to the Phoenix SecureCore Setup Utility. This
will not affect access to the computer OS (only the Phoenix SecureCore Setup
Utility).

5 - 10 Security Menu

Set User Password (Security Menu)



Password Warning

If you set a boot pass­word (Password on boot
is “Enabled“), NEVER
forget your password.

The consequences of
this could be serious. If
you cannot remember
your boot password you
must contact your ven­dor and you may lose all
of the information on
your hard disk.

You can set a password for user mode access to the Phoenix SecureCore Setup
Utility. This will not affect access to the computer OS, (only the Setup utility) unless
you choose to set a Password on Boot (see below). Many menu items in the Phoenix
SecureCore Setup Utility cannot be modified in user mode. You can only set the

user password after you have set the supervisor password.

Password on boot (Security Menu)

Specify whether or not a password should be entered to boot the computer (you may
only set a password on boot if a supervisor password is enabled). If “Enabled”
is selected, only users who enter a correct password can boot the system (see the
warning in the sidebar). The default setting is “Disabled”.

Note: To clear existing passwords press Enter and type the existing password, then

press Enter for the new password (without typing any password entry) and Enter
again to confirm the password clearance.

BIOS Utilities

5

Security Menu 5 - 11

BIOS Utilities



BIOS Screens

Note that the BIOS
screens pictured on
these pages are intend­ed for guidance in set­ting up your system’s
BIOS.

BIOS versions are sub­ject to constant change
and revision, therefore
your computer’s actual
screens may appear
slightly different from
those pictured on these
pages.

Figure 5 - 5

Boot Menu

5

Boot Menu

When you turn the computer on it will look for an operating system (e.g. Windows
Vista) from the devices listed in this menu, and in this priority order. If it cannot

find the operating system on that device, it will try to load it from the next device in
the order specified in the Boot priority order. Item specific help on the right is
available to help you move devices up and down the order.

5 - 12 Boot Menu

Exit Menu

Figure 5 - 6

Exit Menu

Choosing to Discard Changes, or Exit Discarding Changes, will wipe out any
changes you have made to the Setup. You can also choose to restore the original Set-
up defaults that will return the Setup to its original state, and erase any previous
changes you have made in a previous session.

BIOS Utilities

5

Exit Menu 5 - 13

BIOS Utilities

5

5-14

Chapter 6: Upgrading The Computer



Warranty Warning

Please check with your
service representative
before undertaking any
upgrade procedures to
find out if this will VOID
your warranty.

The CPU is not a user
serviceable part. Open­ing this compartment, or
accessing the CPU in
any way, may violate
your warranty.

Unauthorized tampering
with the HDD may also
violate your warranty.

Overview

This chapter contains information on upgrading the computer. Follow the steps out­lined to make the desired upgrades. If you have any trouble or problems you can con­tact your service representative for further help. Before you begin you will need:

• A small crosshead or Phillips screwdriver

• A small regular slotted (flathead) screwdriver

• An antistatic wrist strap
Before working with the internal components you will need to wear an antistatic

wrist strap to ground yourself because static electricity may damage the compo­nents.

The chapter includes:

• Removing the Battery

• Upgrading the Hard Disk Drive

• Upgrading the System Memory (RAM)

• Changing the Optional LCD Back Covers

Upgrading The Computer

6

Please make sure that you review each procedure before you perform it.

Overview 6 - 1

Upgrading The Computer



Power Safety

Warning

Before you undertake
any upgrade proce­dures, make sure that
you have turned off the
power, and disconnect­ed all peripherals and
cables (including tele­phone lines). It is advis­able to also remove your
battery in order to pre­vent accidentally turning
the machine on.



Removal Warning

When removing any cover(s) and screw(s) for the purposes of device upgrade, remember
to replace the cover(s) and screw(s) before turning the computer on.

When Not to Upgrade

These procedures involve opening the system’s case, adding and sometimes replac­ing parts.

You should not perform any of these upgrades if:

• Your system is still under warranty or a service contract

• You don’t have all the necessary equipment

• You’re not in the correct environment

6

6 - 2 Overview

• You doubt your abilities

Under any of these conditions, contact your service representative to purchase or re­place the component(s).

Removing the Battery



Warranty Warning

Please check with your
service representative
before undertaking any
upgrade procedures to
find out if this will VOID
your warranty.

Battery Note

Latch should be held
in place before remov­ing the battery, and the

62.16WH battery has
three battery latches to

be unlocked before re­leasing the battery.

Figure 6 - 1

Battery Removal

21132

4

3

2 1

2

1

4

4

31.08WH

Battery

62.16WH

Battery

If you are confident in undertaking upgrade procedures yourself, for safety reasons
it is best to remove the battery.

1. Turn off the computer, and turn it over.

2. Slide the latch in the direction of the arrow (or latches & in the direction
of the arrow if you are using for 62.16WH battery).

3. Slide the latch in the direction of the arrow, and hold it in place.

4. Slide the battery in the direction of the arrow and then lift the battery up out of
the computer.

Upgrading The Computer

6

Removing the Battery 6 - 3

Upgrading The Computer



HDD System

Warning

New HDD’s are blank. Be­fore you begin make sure:
You have backed up any
data you want to keep from
your old HDD.
You have all the CD-ROMs
and FDDs required to in­stall your operating system
and programs.
If you have access to the in­ternet, download the latest
application and hardware
driver updates for the oper­ating system you plan to in­stall. Copy these to a
removable medium.

Figure 6 - 2

Hard Disk Bay &

Screws

1

2

2

1

3

6

Upgrading the Hard Disk Drive

The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard
disk drives with a height of 9.5mm (h) (see “Storage” on page C - 2). Follow your
operating system’s installation instructions, and install all necessary drivers and util­ities (see “Driver Installation” on page 4 - 2), when setting up a new hard disk.

1. Turn off the computer, and turn it over and remo ve th e ba tt er y.

2. Locate the hard disk bay cover an d remove screws & .

3. Remove the hard disk bay cover.

6 - 4 Upgrading the Hard Disk Drive
