Intel and Intel Core are trademarks/registered trademarks of Intel Corporation.
I
Preface
R&TTE Directive
This device is in compliance with the essential requirements and other relevant provisions of the R&TTE Directive 1999/5/EC.
This device will be sold in the following EEA countries: Austria, Italy, Belgium, Liechtenstein, Denmark, Luxembourg, Finland, Netherlands, France, Norway, Germany, Portugal, Greece, Spain, Iceland, Sweden, Ireland,
United Kingdom, Cyprus, Czech Republic, Estonia, Hungary, Latvia, Lithuania, Malta, Slovakia, Poland, Slovenia.
CE Marking
This device has been tested to and conforms to the regulatory requirements of the European Union and has attained CE Marking. The CE Mark is a conformity marking consisting of the letters “CE”. The CE Mark applies
to products regulated by certain European health, safety and environmental protection legislation. The CE Mark
is obligatory for products it applies to: the manufacturer affixes the marking in order to be allowed to sell his
product in the European market.
This product conforms to the essential requirements of the R&TTE directive 1999/5/EC in order to attain CE
Marking. A notified body has determined that this device has properly demonstrated that the requirements of the
directive have been met and has issued a favorable certificate of expert opinion. As such the device will bear the
notified body number 0560 after the CE mark.
The CE Marking is not a quality mark. Foremost, it refers to the safety rather than to the quality of a product.
Secondly, CE Marking is mandatory for the product it applies to, whereas most q uality marking s are vo lu ntary.
II
Preface
FCC Statement
(Federal Communications Commission)
You are cautioned that changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
•Re orient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the service representative or an experienc ed radio/TV technician for help.
Operation is subject to the following two conditions:
1.This device may not cause interference.
And
2.This device must accept any interference, including interfer ence that may cause undesired operation of the
device.
III
Preface
Warning
Use only shielded cables to connect I/O devices to this equipment. You are cautioned that changes or modifications not expressly approved by the manufacturer for compliance with the above standard s could void your authority to operate the
equipment.
FCC RF Radiation Exposure Statement:
1.This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
2.This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator
and your body.
EuP Off Mode Power Consumption Statement:
The figures below note the power consumption of this computer in compliance with European Commission (EC)
regulations on power consumption in off mode:
•Off Mode < 1W
IV
Preface
IMPORTANT SAFETY INSTRUCTIONS
Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury
to persons when using any electrical equipment:
1.Do not use this product near water, for example n ear a ba th tub, wash bowl, kitchen sink or laundry tu b, in a wet
basement or near a swimming pool.
2.Avoid using this equipment with a telephone line (other than a cordless type) during an electrical storm. There
may be a remote risk of electrical shock from lightning.
3.Do not use the telephone to report a gas leak in the vicinity of the leak.
4.Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may
explode. Check with local codes for possible special disposal instructions.
5.This product is intended to be supplied by a Listed Power Unit (Full Range AC/DC Adapter - AC Input 100 -
240V, 50 - 60Hz DC Output 19V, 11.57A (220W) minimum).
This Computer’s Optical Device is a Laser Class 1 Product
V
Preface
Instructions for Care and Operation
The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions:
1.Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged.
Do not expose the computer
to any shock or vibration.
Do not place it on an unstable
surface.
Do not place anything heavy
on the computer.
2.Keep it dry, and don’t overheat it. Keep the computer and power supply away from any kind of heating ele-
ment. This is an electrical appliance. If water or any other liquid gets into it, the computer could be badly damaged.
Do not expose it to excessive
heat or direct sunlight.
Do not leave it in a place where
foreign matter or moisture may
affect the system.
Don’t use or stor e the computer
in a humid environment.
Do not place the computer on
any surface that will block the
Vents/Fan Intakes.
VI
Preface
3.Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other
strong magnetic fields. These can hinder proper performance and damage your data.
4.Follow the proper workin g procedu res for t he computer. Shut th e comp uter down pro per ly and don’t for ge t
to save your work. Remember to periodically save your data as data may be lost if the battery is depleted.
Do not turn off the power until
you properly shut down all programs.
Do not turn off any peripheral
devices when the computer is
on.
5.Take care when using peripheral devices.
Use only approved brands of
peripherals.
Do not disassemble the computer by yourself.
Unplug the power cord befor e
attaching peripheral devices.
Perform routine maintenance
on your computer.
VII
Preface
Power Safety
Warning
Before you undertake
any upgrade procedures, make sure that
you have turned off the
power, and disconnected all peripherals
and cables (including
telephone lines). It is
advisable to also remove your battery in
order to prevent accidentally turning the
machine on.
Power Safety
The computer has specific power requirements:
• Only use a power adapter approved for use with this computer.
• Your AC/DC ada pter may be design ed for inte rnational travel but it still requires a steady,
uninterrupted power supply. If you are unsure of your local power specifications, consult
your service representative or local power company .
• The power adapter may have either a 2-pr ong or a 3-prong ground ed plug. The third prong
is an important safety feature; do not defeat its purpose. If you do not have access to a
compatible outlet, have a qualified electrician install one.
• When you want to unplug the power cord, be su re to disconnect it by the plug head, not by
its wire.
• Make sure the socket and any extension cord(s) you use can support the total current load
of all the connected devices.
• Before cleaning the computer, make sure it is disconnected from any external power supplies (i.e. AC/DC adapter or car adapter).
Do not plug in the power
cord if you are wet.
Do not use the power cord if
it is broken.
Do not place heavy objects
on the power cord.
VIII
Preface
Polymer Battery Precautions
Note the following information which is specific to polymer batteries only, and where applicable, this overrides
the general battery precaution information overleaf.
•Polymer batteries may experience a slight expansion or swelling, however this is part of the battery’s safety mechanism and is not a cause for concern.
•Use proper handling procedures when using polymer batteries. Do not use polymer batteries in high ambient temperature environments, and do not store unused batteries for extended periods.
See also the general battery precautionary information overleaf for further information.
IX
Preface
Battery Disposal & Caution
The product that you have purchased contains a rechargeable battery. The battery is recyclable. At the end of its useful life,
under various state and local laws, it may be illegal to dispose of this battery in to the municipal waste stream. Check with
your local solid waste officials for details in your area for recycling options or proper disposal.
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalen t type recommended by the
manufacturer. Discard used battery according to the manufacturer’s instructions.
Battery Precautions
•Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer.
•Do not remove any batteries from the computer while it is powered on.
•Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even
if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly
result in fire.
•If you do not use the battery for an extended period, then remove the battery from the computer for storage.
•Recharge the batteries using the notebook’s system. Incorrect recharging may make the battery explode.
•Do not try to repair a battery pack. Refer any battery pack repa ir or replacemen t to you r service repre sentati ve or qu alified service personnel.
•Keep children away from, and promptly dispose of a damaged battery. Always dispose of batteries carefully. Batteri es
may explode or leak if exposed to fire, or improperly handled or discarded.
•Keep the battery away from metal appliances.
•Affix tape to the battery contacts before disposing of the battery.
•Do not touch the battery contacts with your hands or metal objects.
X
Cleaning
Removal Warning
When removing any cover(s) and screw(s) for the purposes of device upg rade, remember to replace the cover(s) and
screw(s) before turning the computer on.
Do not apply cleaner directly to the computer; use a soft clean cloth.
Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer.
Servicing
Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the
computer to electric shock. Refer all servicing to authorized service personnel. Unplug the computer from the
power supply. Then refer servicing to qualified service personnel under any of the following conditions:
•When the power cord or AC/DC adapter is damaged or frayed.
•If the computer has been exposed to rain or other liquids.
•If the computer does not work normally when you follow the operating instructions.
•If the computer has been dropped or damaged (do not touch the poisonous liquid if the LCD panel breaks).
•If there is an unusual odor, heat or smoke coming from your computer.
Preface
XI
Preface
Power Off Before Traveling
Make sure that your notebook is completely powered off before putting it into a travel bag (or any such container). Putting a
notebook which is powered on in a travel bag may cause the Vents/Fan Intakes to be blocked. To pre vent your computer
from overheating make sure nothing blocks the Vent/Fan Intakes while the computer is in use.
Travel Considerations
Packing
As you get ready for your trip, run through this list to make sure the system is ready to go:
1.Check that the battery pack and any spares are fully charged.
2.Power off the computer and peripherals.
3.Close the display panel and make sure it’s latched.
4.Disconnect the AC/DC adapter and cables. Stow them in the carrying bag.
5.The AC/DC adapter uses volt ages from 100 to 240 volt s so you won’t need a second volt age adapter. However,
check with your travel agent to see if you need any socket adapters.
6.Put the notebook in its carrying bag and secure it with the bag’s straps.
7.If you’re taking any perip herals (e.g. a printer, mouse or digital camera), pack them and those devices’ adapters
and/or cables.
8.Anticipate customs - Some jurisdictions may have import restrictions or req uire proof of ownersh ip for both hard -
ware and software. Make sure your “papers” are handy.
XII
Preface
On the Road
In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting,
keep these points in mind:
Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very
common. Don’t check it with “normal” luggage. Baggage handlers may not be sufficiently careful. Avoid knocking the computer against hard objects.
Beware of Electromagnetic fields - Devices such as metal detectors & X-ray machines can damage the computer, hard disk, floppy disks, and other media. They may also destroy any stored data - Pass your computer and
disks around the devices. Ask security officials to hand-inspect them (you may be asked to turn it on). Note:
Some airports also scan luggage with these devices.
Fly safely - Most airlines have regulations about the use of computers and other electronic devices in flight.
These restrictions are for your safety, follow them. If you stow the notebook in an overhead compartment, make
sure it’s secure. Contents may shift and/or fall out when the compartment is opened.
Get power where you can - If an electrical outlet is available, use the AC/DC adapter and keep your battery(ies)
charged.
Keep it dry - If you move quickly from a cold to a warm location, water vapor can condense inside the computer.
Wait a few minutes before turning it on so that any moisture can evaporate.
XIII
Preface
Developing Good Work Habits
Developing good work habits is important if you need to work in fron t of the computer for long periods of time.
Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or
other joints. The following are some tips to reduce the strain:
• Adjust the height of the chair and/or desk so that the keyboard is at or slightly below the
level of your elbow. Keep your forearms, wrists, and hands in a relaxed position.
• Your knees should be slightly higher than your hips. Place your feet flat on the floor or on a
footrest if necessary.
• Use a chair with a back and adjust it to support your lower back comfortably.
• Sit straight so that your kne es, hips and elbows form approximately 90-degree angles when
you are working.
• Take periodic breaks if you are using the computer for long periods of time.
Remember to:
• Alter your posture frequently.
• Stretch and exercise your body several times a day.
• T ake periodic breaks when you work at the computer for long periods of time. Frequent and
short breaks are better than fewer and longer breaks.
XIV
Preface
Lighting
Proper lighting and a comfortable viewing angle can reduce eye strain and shoulder and neck muscle fatigue.
•Position the display to avoid glare or reflections from overhead lighting or outside sources of light.
•Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly.
•Position the display directly in front of you at a comfortable viewing distance.
•Adjust the display-viewing angle to find the best position.
LCD Screen Care
To prevent image persistence on LCD monitors (caused by the continuous display of graphics on the screen for
an extended period of time) take the following precautions:
•Set the Windows Power Plans to turn the screen off after a few minutes of screen idle time.
•Use a rotating, moving or blank screen saver (this prevents an image from being displayed too long ).
•Rotate desktop background images every few days.
•Turn the monitor off when the system is not in use.
LCD Electro-Plated Logos
Note that in computers featuring a raised LCD electro-plated logo, the logo is covered by a protective adhesive.
Due to general wear and tear, this adhesive may deteriorate over time and the exposed logo may develop sharp
edges. Be careful when handling the computer in this case, and avoid touching the raised LCD electro-plated
logo. Avoid placing any other items in the carrying bag which may rub against the top of the computer during
transport. If any such wear and tear develops contact your service center.
This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the
computer and to getting your system started. The remainder of the manual covers the following:
• Chapter 2A guide to using some of the main features of the computer e.g. the storage devices (hard disk,
optical device, Multi-In-1 card reader), Game Keys, TouchPad & Mouse, Audio Features &
Printer.
• Chapter 3 The computer’s power management options.
• Chapter 4The installation of the drivers and utilities essential to the operation or improvement of some of the
computer’s subsystems.
• Chapter 5An outline of the computer’s built-in software or BIOS (Basic Input Output System).
• Chapter 6 Instructions for upgrading your computer.
• Chapter 7 A quick guide to the computer’s RAID, PC Camera, Wireless LAN, Fingerprint and Bluetooth & WLAN Combo modules (some of which may be optional depending on your purchase configu-
ration).
• Chapter 8 A troubleshooting guide.
• Appendix A Definitions of the interface, ports/jacks which allow your computer to communicate with external
devices.
• Appendix B Information on the NVIDIA Video driver controls.
• Appendix C The computer’s specification.
1
Overview 1 - 1
1
Notes
Check the light colored
boxes with the mark
above to find detailed
information about the
computer’s features.
Quick Start Guide
Advanced Users
If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful
to refer to “Drivers & Utilities” on page 4 - 1, “BIOS Utilities” on page 5 - 1 and “Upgrading The Computer”
on page 6 - 1 in the User’s Manual. You may also find the notes marked with a
of interest to you.
Beginners and Not-So-Advanced Users
If you are new to computers (or do not have an advanced knowledge of them) then
the information contained in this Quick Start Guide should be enough to get you up
and running. Eventually you should try to look through all the documentation (more
detailed descriptions of the functions, setup and system controls are covered in the
remainder of the User’s Manual), but do not worry if you do not understand everything the first time. Keep this manual nearby and refer to it to learn as you go. You
may find it useful to refer to the notes marked with a
as indicated in the margin.
For a more detailed description of any of the interface ports and jacks see “Interface
(Ports & Jacks)” on page A - 1.
Warning Boxes
No matter what your level please pay careful attention to the warning and safety information indicated by the
symbol. Also please note the safety and handling instructions as indicated in the Preface.
1 - 2 Overview
Quick Start Guide
Drivers
If you are installing new system software, or are re-configuring your computer for a different system, you will need to install
the appropriate drivers. Drivers are programs which act as an interface between the computer and a hardware component
e.g. a wireless network module. It is very important that you install the drivers in the order listed in Table 4 - 1, on page 4
- 3. You will be unable to use most advanced controls until the necessary drivers and utilities are properly installed. If your
system hasn’t been properly configured (your service representative may have already done that for you), refer to “Drivers
& Utilities” on page 4 - 1 for installation instructions.
Ports and Jacks
See “Ports and Jacks” on page A - 2 for a description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc.
Not Included
Operating Systems (e.g. Windows 7) and applications (e.g. word processing, spreadsheet and database programs)
have their own manuals, so please consult the appropriate manuals.
1
Overview 1 - 3
1
Quick Start Guide
System Software
Your computer may already come with system software pre-installed. Where this is not the case, or where you
are re-configuring your computer for a different system, you will find the Windows 7 (with Service Pack 1 in-stalled) operating system is supported.
Note: In order to run Windows 7 (SP1) without limitations or decreased performance, your computer requires a
minimum 1GB of system memory (RAM).
RAID & AHCI Setup
Note that setting up a RAID, or AHCI mode, needs to be done prior to installing the Windows OS (see“Setting
Up SATA RAID or AHCI Mode” on page 7 - 2).
1 - 4 Overview
Quick Start Guide
Shutdown
Note that you should always shut your computer down by choosing the Shut Down command from the Start menu in Windows 7. This will help prevent hard disk or system problems.
135
System Startup
1. Remove all packing materials, and place the c omp ut er on a stable surface.
2. Securely attach any peripherals you want to use with the notebook (e.g. keyboa rd and mouse) to their ports.
3. Attach the AC/DC adapter to the DC-In jack at the rear of the computer, then plug the AC power cord into an
outlet, and connect the AC power cord to the AC/DC adapter.
4. Use one hand to raise the
the other hand (as illustrated in Figure 1 - 1 below) to support the base of the computer (Note: Never lif t the
computer by the lid/LCD).
5. Raise the lid/LCD to a comfortable viewing angle, and press the power button.
lid/LCD to a comfortable viewing angle (i t is preferable not to exceed
135 degrees
);
1
use
Figure 1 - 1 - Computer with AC/DC Adapter Plugged-In/Opening the Lid/LCD
System Startup 1 - 5
1
Figure 1 - 2
LCD Panel Open
& Top View
1. Optional Built-In PC
Camera
2. Built-in Microphone
3. LCD
4. LED Status Indicators
5. Touch Sensor
Instant Keys
6. 8 * Gaming Keys
7. Keyboard
8. TouchPad and
Buttons
9. Fingerprint Reader
Module (optional)
10. LED Power Indicators
11. LCD Panel Color
LED
See Appendix A for a more
detailed description of the
ports & jacks etc.
2
1
7
8
9
5
6
4
10
11
Wireless Device
Operation Aboard
Aircraft
The use of any portable electronic transmission devices (e.g.
WLAN or Bluetooth) aboard aircraft is usually prohibited. Make
sure any wireless modules are
OFF if you are using the computer aboard aircraft.
Use the appropriate function key
combination/Touch Sensor Key
to toggle power to any wireless
modules, and check the indicators to see if any modules are
powered on or not (see Table 1
- 2, on page 1 - 9).
3
Quick Start Guide
1 - 6 System Map: LCD Panel Open & Top View
System Map: LCD Panel Open & Top View
Quick Start Guide
LED Indicators
The two sets of LED indicators (LED Status Indicators and LED Power Indicators) display helpful information about the current status of the computer.
IconColorDescriptionIconColorDescription
Blinking BlueHard Disk ActivityOrangeDC Power is Plugged In
BlueNumber Lock is ActivatedGreenThe Computer is On
BlueCaps Lock is ActivatedBlinking GreenThe Computer is In Sleep Mode
BlueScroll Lock is ActivatedBlinking Orange*The Powered USB Port is On*
OrangeThe Battery is Charging
Blinking Orange
GreenThe Battery is Fully Charged
Table 1 - 1 - LED Status Indicators
*Note: The powered USB 2.0 port (see Figure 1 - 7 on page 1 - 14) may be toggled on /off by means of the Fn + Power
Button key combination. When the powered USB port is on it will supply powe r ( for charging devices only, not for operating devices) when the system is off but still powered by the AC/DC ada pter plugged into a working o utlet, or powered
by the battery with a capacity level above 20% (this may not work with certain devices - see page 8 - 12).
The Battery has Reached Critically
Low Power Status
1
System Map: LCD Panel Open & Top View 1 - 7
1
Quick Start Guide
Game Keys
The eight Game Keys on the left of the computer allow macros to be configured for common keystrokes used
in applications, as long as the driver is installed.
Figure 1 - 3 - Game Key Configuration
1 - 8 System Map: LCD Panel Open & Top View
Quick Start Guide
Touch Sensor Instant Keys
Press the Touch Sensor Instant Keys on the computer to toggle the appropriate function on/off. When a module
is powered on the appropriate icon will be highlighted.
IconDescriptionIconDescription
1
*Light Sensor Toggle
PC Camera Module Power Toggle Activate the Default Internet Browser
Bluetooth Module Power ToggleTHX TruStudio Pro Toggle (see page 7 - 64)
**Silent Mode T oggle
Volume Control Slider (move your finger slowly along the
Table 1 - 2 - Touch Sensor Instant Keys
Wireless LAN Module Power Toggle
Mute Toggle
slider to adjust the system volume)
*When enabled, the Light Sensor will automatically adjust screen brightness according to the background environment.
**When enabled, Silent Mode will reduce fan noise and save power consumption. Note this may reduce computer performance.
Touch Sensor Instant Keys 1 - 9
1
Other Keyboards
If your keyboard is damaged or you just want to
make a change, you can
use any standard USB
keyboard. The system will
detect and enable it automatically. However special functions/hot-keys
unique to the system’s
regular keyboard may not
work.
Num Lk & Scr Lk
Hold down the Fn Key
and Scr Lk/Num Lk to enable scroll lock/number
lock, and check the LED
indicator for status.
Numerical
Play/Pause Key
Function Keys
NumLk &
ScrLk Keys
Fn Key
Keypad
Game Control Keys
Special Characters
Some software applications allow the number-keys to be used with Alt to produce special characters.
These special characters can only be produced by using the numeric keypad. Regular number keys (in
the upper row of the keyboard) will not work. Make sure that NumLk is on.
Quick Start Guide
Keyboard
The keyboard has an embedded numerical keypad for easy numeric data input, and
features function keys to allow you to change operational features instantly. See
1 - 10 Keyboard
Table 1 - 3, on page 1 - 11 for full function key combination details.
Figure 1 - 4 - Keyboard
Quick Start Guide
Function Keys & Visual Indicators
The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition
to the basic function key combinations; visual indicators (see the table below) are available when the Hot Key
driver is installed (see “Hot Key” on page 4 - 7). After installing the driver an icon will appear in the taskbar.
Fn + ~Play/Pause (in Audio/Video Programs)Fn + F8/F9
Fn + F1Touchpad ToggleFn + F10
Fn + F2
Fn + F3Mute ToggleFn + F12
Fn + F4Sleep ToggleFn + NumLkNumber Lock Toggle
Fn + F5/F6
Fn + F7
(Press a key to or use Touchpad to turn on)
Volume Decrease/
Note: DO NOT use the Fn + F7 key combination to toggle
through display options when SLI is enabled (see “SLI Multi
GPU Configuration” on page B - 14).
Turn LCD Backlight Off
Increase
Display Toggle
Fn + F11
Fn + ScrLkScroll Lock Toggle
Fn + Power
Button
Brightness
Decrease/Increase
PC Camera Power
Toggle
WLAN Module
Power Toggle
Bluetooth Module
Power Toggle
Powered USB 2.0 Port Power Toggle
Table 1 - 3 - Function Keys & Visual Indicators
Keyboard 1 - 11
1
Figure 1 - 5
Front View
1. Speakers
2. LED Power
Indicators
3. DC-In Jack
See Appendix A for a more
detailed description of the
ports & jacks etc.
12
3
1
1
1
Quick Start Guide
System Map: Front & Rear Views
1 - 12 System Map: Front & Rear Views
System Map: Right View
Figure 1 - 6
Right View
1. Express Card Slot
2. Headphone-In Jack
3. Microphone-In Jack
4. Line-In Jack
5. S/PDIF-Out Jack
6. Combined eSATA/
USB Port
7. USB 2.0 Port
8. Security Lock Slot
9. Power Button
See Appendix A for a more
detailed description of the
ports & jacks etc.
2 3
6
54
7
8
9
USB Ports
Note that the connections to the USB ports only fit one way, do not force them.
1
ExpressCard Slot
The ExpressCard Slot accepts either ExpressCard/34 or ExpressCard/54 formats.
Quick Start Guide
1
System Map: Right View 1 - 13
1
Figure 1 - 7
Left View
1. DVI-Out Port
2. USB 2.0 Port
3. USB 2.0 Port
(Powered)
4. RJ-45 LAN Jack
5. HDMI-Out Port
6. Multi-In-1 Card
Reader
7. 2 * USB 3.0 Ports
8. Mini-IEEE 1394a
Port
9. Optical Device
Drive Bay
See Appendix A for a more
detailed description of the
ports & jacks etc.
Mini-IEEE 1394a Port
The Mini-IEEE 1394 port
only supports SELF POW-
ERED IEEE 1394 devices.
1
2
4
5
6
7
9
Multi-in-1 Card Reader
The card reader allows you to use the most popular digital storage card formats:
MMC (MultiMedia Card) / RSMMC
SD (Secure Digital) / Mini SD / SDHC / SDXC
MS (Memory Stick) / MS Pro / MS Duo
HDMI Port
Note that theHDMI Port supports video and audio signals to attached external displays (also see “HD-
MI Audio Configuration” on page B - 18). Note that THX TruStudio Pro will be disabled when you are
connecting to an external display through an HDMI connection (see page 7 - 110).
USB 3.0 Ports & USB Port Power
USB 3.0 ports are denoted by their blue color; USB 2.0 ports are colored black. Note that the USB 3.0
port requires a driver installation (see “USB 3.0” on page 4 - 7) and is not operational under DOS.
The
powered USB 2.0 port can supply power (for charging devices only, not for operating de-vices) when the system is off but still powered by the AC/DC ad apter plugged into a working outlet, or powered by the battery with a capacity level above 20% (this may not work with certain
devices - see page 8 - 12). Toggle power to this port by using Fn + power button.
3
8
3
Quick Start Guide
System Map: Left View
1 - 14 System Map: Left View
Disk Eject Warning
Don’t try to eject a CD/DVD while the system is accessing it. This may cause the system to “crash”. Stop
the disk first then eject it, or press the stop button
twice.
CD/DVD Emergency Eject
If you need to manually eject a CD/DVD (e.g. due to
an unexpected power interruption) you may push the
end of a straightened paper clip into the emergency
eject hole. Do not use a sharpened pencil or any object that may break and become lodged in the hole.
Don’t try to remove a floppy disk/CD/DVD while the
system is accessing it. This may cause the system to
“crash”.
Changing DVD Regional Codes
Go to the Control Panel and double-click Device
Manager (Hardware and Sound), then click th e +
next to DVD/CD-ROM drives. Double-click on the
DVD-ROM device to bring up the Properties dialog
box, and select the DVD Region (tab) to bring up the
control panel to allow you to adjust the regional code.
DVD region detection is device dependent, not OSdependent. You can select your module’s region
code 5 times. The fifth selection is pe rmanent. This
cannot be altered even if you change your operating
system or you use the module in another computer.
Quick Start Guide
1
System Map: Left View 1 - 15
1
Figure 1 - 8
Bottom View
1. Sub Woofer
2. Fan Outlet/Intake
3. Component Bay
Cover
4. Battery
5. HDD Bay
.
Overheating
To prevent your computer from overheating make
sure nothing blocks the
vent(s)/fan intake(s)
while the computer is in
use.
1
2
4
5
Battery Information
Always completely discharge, then fully charge, a new battery before using it. Completely
discharge and charge the battery at least once every 30 days or after about 20 partial discharges. See “Battery Information” on page 3 - 10 for full instructions.
3
2
2
Quick Start Guide
System Map: Bottom View
1 - 16 System Map: Bottom View
Quick Start Guide
Figure 1 - 9 - Start Menu & Control Panel
Click here to toggle Category View
Windows 7 Start Menu & Control Panel
Most of the control panels, utilities and programs within Windows 7 (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk
drive, and a shortcut will usually be placed in the Start menu and/or the desktop. Right-click the Start menu
icon , and then select Properties if you want to customize the appearance of the Start menu.
In many instances throughout this manual you will see an instruction to open the Control Panel. The ControlPanel is accessed from the Start menu, and it allows you to configure the settings for most of the key features
in Windows (e.g. power, video, network, audio etc.). Windows 7 provides basic controls for many of the features,
however many new controls are added (or existing ones are enhanced) when you install the drivers. To see all
controls it may be necessary to toggle off Category View to view the control panel icons.
System Map: Bottom View 1 - 17
1
1
1
2
NVIDIA Video Driver Controls
More detailed video controls are provided by the NVIDIA Control Panel. For more detailed information see “NVIDIA Con-
trol Panel” on page 1 - 20 and Appendix B.
You can also access the control panels by right-clicking the desktop and selecting NVIDIA Control Panel (Figure 1 - 11
on page 1 - 20).
Quick Start Guide
Video Features
You can switch display devices, and configure display options, from the Display control panel (in Appearances
and Personalization) in Windows 7 (see over). For more detailed video information see “NVIDIA Video Driver
Controls” on page B - 1.
To access Display (Control Panel) and Screen Resolution in Windows:
1.Click Start and click Control Panel.
2.Click Display (icon) - In the Appearances and Personalization category.
3.Click Adjust Screen Resolution/Adjus t resolution.
OR
4.Alternatively you can right-click the desktop and select Screen resolution (Figure 1 - 10 on page 1 - 19).
5.Use the dropbox to select the screen Resolution (Figure 1 - 10 on page 1 - 19).
1 - 18 Video Features
Screen Resolution
2
Video Options
Note that card types, specifications and drivers are subject to continual updates and
changes. Check with your
service center for the latest
details on video cards supported.
1
Quick Start Guide
1
Figure 1 - 10 - Screen Resolution
Video Features 1 - 19
1
1
2
2
1
Quick Start Guide
NVIDIA Control Panel
You can access the NVIDIA Control Panel as follows:
1.Click
2.Click NVIDIA Control Panel (Figure 1 - 11) - In the Appearances and Personalization category.
3.See “NVIDIA Video Driver Controls” on page B - 1 for full details on control panels etc.
4.You can also access the control panel by right-clicking the desktop and selecting NVIDIA Control Panel .
OR
Start
, and click
Control Panel
.
Figure 1 - 11 - NVIDIA Control Panel
1 - 20 Video Features
Quick Start Guide
Power Options
The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 1 - 17 ) allows you
to configure power management features for your computer. You can conserve power by means of power plans
and configure the options for the power button, sleep button, computer lid (when closed), display and sleep
mode from the left menu. Note that the Power saver plan may have an affect on computer performance.
Click to select one of the existing plans, or click Create a power plan in the left menu and select the options to
create a new plan. Click Change plan settings and click Change advanced power settings to access further configuration options.
Pay attention to the instructions on battery care in “Battery Information” on page 3 - 10.
Read this chapter to learn more about the following main features and components
of the computer:
•Hard Disk Drive
•Optical Device
•Multi-In-1 Card Reader
•ExpressCard Slot
•Game Keys
•Audio Features
•TouchPad and Buttons/Mouse
•Adding a Printer
2
Overview 2 - 1
Storage Devices, Mouse, Audio & Printer
Power Safety
Before attempting to access any of the internal
components of your
computer please ensure
that the machine is not
connected to the AC
power, and that the machine is turned off. Also
ensure that all peripheral cables, including
phone lines, are disconnected from the computer.
Figure 2 - 1
Hard Disk Bay
1
1
HDD Bay
2
Hard Disk Drive
The hard disk drive(s) is(are) used to store your data in the computer. The hard
disk(s) can be taken out to accommodate other 2.5" serial (SATA) hard disk drives
with a height of 9.5 mm. The hard disk bay is accessible from the bottom of your
computer as seen below.
The computer can accommodate up to three hard disks (two in the primary bay, and
one under the optical device),and these may be configured in RAID, AHCI or IDE
modes. Further details on removing and inserting the hard disk are available in “Up-
grading the Hard Disk Drive(s)” on page 6 - 5.
2 - 2 Hard Disk Drive
Storage Devices, Mouse, Audio & Printer
Sound Volume
Adjustment
How high the sound volume can be set depends
on the setting of the volume control within Win-dows. Click the Volume
icon on the taskbar to
check the setting.
Peripherals must be
connected before you
turn on the system.
Figure 2 - 2
Optical Device
123
1
2
3
Optical Device
There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual device will depend on the model you purchased (see “Storage” on page C - 3). The
optical device is usually labeled “Drive D:” and may be used as a boot device if
properly set in the BIOS (see“Boot Menu” on page 5 - 12).
Loading Discs
To insert a CD/DVD, press the open button and carefully place a CD/DVD onto
the disc tray with label-side facing up (use just enough force for the disc to click onto
the tray’s spindle). Gently push the CD/DVD tray in until its lock “clicks” and you
are ready to start. The busy indicator will light up while data is being accessed,
or while an audio/video CD, or DVD, is playing. If power is unexpectedly interrupted, insert an object such as a straightened paper clip into the emergency eject hole
to open the tray.
2
Optical Device 2 - 3
Storage Devices, Mouse, Audio & Printer
CD Emergency Eject
If you need to manually
eject a CD (e.g. due to
an unexpected power
interruption) you may
push the end of a
straightened paper clip
into the emergency eject
hole. However please
do NOT use a sharpened pencil or similar
object that may break
and become lodged in
the hole.
Disk Eject Warning
Don’t try to remove a
CD/DVD while the system is accessing it. This
may cause the system
to “crash”.
2
2 - 4 Optical Device
Handling CDs or DVDs
Proper handling of your CDs/DVDs will prevent them from being damaged. Please
follow the advice below to make sure that the data stored on your CDs/DVDs can be
accessed.
Note the following:
•Hold the CD or DVD by the edges; do not touch the surface of the disc.
•Use a clean, soft, dry cloth to remove dust or fingerprints.
•Do not write on the surface with a pen.
•Do not attach paper or other materials to the surface of the disc.
•Do not store or place the CD or DVD in high-temperature areas.
•Do not use benzene, thinner, or other cleaners to clean the CD or DVD.
•Do not bend the CD or DVD.
•Do not drop or subject the CD or DVD to shock.
Storage Devices, Mouse, Audio & Printer
Table 2 - 1
DVD Regional Coding
DVD Regional Codes
To change the DVD regional codes see “Changing DVD Regional Codes” on
page 1 - 15.
DVD Regional Coding
RegionGeographical Location
1USA, Canada
2
3
4
5
6China
Western Europe, Japan, South
Africa, Middle East & Egypt
South-East Asia, Taiwan, South
Korea, The Philippines, Indonesia,
Hong Kong
South & Central America, Mexico,
Australia, New Zealand
N Korea, Russia, Eastern Europe,
India & Most of Africa
2
Optical Device 2 - 5
Storage Devices, Mouse, Audio & Printer
Card Reader Cover
Make sure you keep the
cover in the card reader
when not in use. This
will help prevent foreign
objects and/or dust getting in to the card reader.
Figure 2 - 3
Right View
1.Card Reader
•MMC (MultiMedia Card) / RSMMC
•SD (Secure Digital) / Mini SD / SDHC / SDXC
•MS (Memory Stick) / MS Pro / MS Duo
1
2
Multi-In-1 Card Reader
The card reader allows you to use some of the latest digital storage cards. Push the
card into the slot and it will appear as a removable device, and can be accessed in
the same way as your hard disk (s). Make sure you install the Card Reader driver
(see “Card Reader” on page 4 - 7).
PC adapters may be required for some of these cards and are usually supplied with
them.
2 - 6 Multi-In-1 Card Reader
Storage Devices, Mouse, Audio & Printer
ExpressCard
Slot Cover
Make sure you keep the
cover in the ExpressCard slot when not in
use. This will help prevent foreign objects and/
or dust getting in to the
ExpressCard Slot.
Figure 2 - 4
Express Card Slot
ExpressCard Slot
The computer is equipped with an ExpressCard/34/54 slot that reads Express Card/
34 and ExpressCard/54 formats. ExpressCards are the successors to PCMCIA (PC
Cards).
ExpressCard/54 is used for applications which require a larger interface slot, e.g.
CompactFlash card reader. The number denotes the card width; 54mm for the Express Card/54 and 34mm for the ExpressCard/34. Make sure you install the ExpressCard driver (see “Card Reader/ExpressCard” on page 4 - 6).
Inserting and Removing ExpressCards
•Align the ExpressCard with the slot and push it in until it locks into place.
•To remove an ExpressCard, simply press the card to eject it.
2
ExpressCard Slot 2 - 7
Storage Devices, Mouse, Audio & Printer
Figure 2 - 5
Game Key
Configuration
2
Game Keys
The eight game hot keys on the left of the computer allow macros to be configured
for common keystrokes used in applications (the keys can assigned macros for any
program, not only games). To configure the keys follow the instructions below
(make sure you have installed the GameKey Utility driver - see “GameKey Utility”
on page 4 - 7).
1.Run the Game Key Configuration program from the desktop icon (or from
C:\Program Files\Chicony\GameKeys\GmKeyCfgUtl.exe).
2.Double-click the button for the appropriate key (it will turn red ).
3.When the button is red you may then recor d the keystrokes to be assigned to
the Game Key.
4.Click OK.
5.Repeat the procedure for the other Game Key if required.
6.Close the Game Key Configuration window.
7.The keystroke order will be repeated with the appropriate button press in any
application program.
2 - 8 Game Keys
Storage Devices, Mouse, Audio & Printer
Volume Adjustment
The sound volume level
is set using the volume
control within Windows
(and the volume function keys on the computer). Click the volume
icon in the notification
area to check the setting.
Headphone
Configuration
It is recommended that
you set the Speaker
Configuration to Stereo (not to 5.1 or 7.1
Speaker) when listening
through headphones in
order to maximize audio
quality.
Figure 2 - 6
Realtek Audio
Manager
Right-click the icon
to access the menu
above.
See “HDMI Audio Configuration” on page B - 18 for a description of the audio configuration when connecting an HDMI supported display device.
See “THX TruStudio Pro Audio” on page 7 - 64 for more information on the THX TruStudio
Pro Audio setup.
Audio Features
You can configure the audio options on your computer from the Sound control
panel in Windows, or from the Realtek HD Audio Manager icon in the notification area/control panel (right-click the notification area icon to bring up an audio menu). The volume may also be adjusted by means of the Fn + F5/F6 key
combination (see Table 1 - 3, on page 1 - 11).
2
Audio Features 2 - 9
Storage Devices, Mouse, Audio & Printer
Figure 2 - 7
Realtek Audio
Manager -
Recording Setup
2
Setup for Audio Recording
To record audio sources on your computer at optimum quality follow the instructions below:
1.Click
2.Click Realtek HD Audio Manager (or right-click the notification area icon and
3.Click Microphone Effects (tab) in Microphone (tab), and then click to select
4.Click OK to close the control panel and save the settings.
Start
, and click
and make sure you are in
select Sound Manager).
Noise Suppression (button), or adjust the Recording Volume level to arou nd 60,
to obtain the optimum recording quality.
Control Panel
Classic View
(or point to
.
Settings
and click
Control Panel
)
2 - 10 Audio Features
Storage Devices, Mouse, Audio & Printer
Figure 2 - 8
Realtek Audio
Manager
Suppressing Audio Background Noise
A background noise may occur when audio power management is enabled, and the
system resumes from power saving. To solve this problem you can disable Realtek
HD Audio Manager Power Management.
1.Click
2.Click Realtek HD Audio Manager (or right-click the taskbar icon and select
3.Click the Power Management icon .
Start
, and click
and make sure you are in
Sound Manager).
Control Panel
(or point to
Classic View
Settings
.
and click
Control Panel
2
)
Audio Features 2 - 11
Storage Devices, Mouse, Audio & Printer
Figure 2 - 9
Realtek Audio
Manager
Power Management
The black icon indicates that
Power Management is disabled.
2
4.Make sure that Power Management is disabled (when disabled the icon will be
black ; when enabled the icon will be blue ).
5.Click OK to save the setting and close the control panel.
2 - 12 Audio Features
Storage Devices, Mouse, Audio & Printer
THX Audio & HDMI
Note that the THX audio
effects do not apply to
audio generated
through an HDMI connection (see page 7 -
67).
Press the THX TruStudio Pro Touch Sensor
Instant Key to toggle the THX TruStudioAP On/Off.
Figure 2 - 10
Speaker
Configuration (7.1)
Auto Popup Dialog
You should enable the
auto popup dialog to automatically detect when a
device has been
plugged-in. If disabled,
double-click connectorsettings and click the
box to enable the auto
popup detection of
plugged-in devices.
Connector Settings
Setup for 5.1 or 7.1 Surround Sound
To setup your system for 5.1 or 7.1 surround sound you will need to connect the audio cables to the Headphone-Out, Line-In, Microphone-In jack and S/PDIF-Out
jacks (note: the S/PDIF jack is used for 7.1 surround sound only).
1.Click
2.Click Realtek HD Audio Manager (or right-click the notification area icon and
3.Click Speakers (tab) and click Speaker Configuration (tab).
4.Select 5.1 or 7.1 Speaker from the Speaker Configuration pull-down menu.
Start
and make sure you are in
select Sound Manager).
, and click
Control Panel
Classic View
(or point to
.
Settings
and click
Control Panel
2
)
Audio Features 2 - 13
Storage Devices, Mouse, Audio & Printer
Figure 2 - 11
Connected Device
Auto Popup
Note: Side Speaker Out is required for 7.1 Surround only.
2
5.Plug the front speaker cables into the Headphone-Out Jack.
6.Plug in the other cables (you may require an adapter to connect each cable to the
appropriate jack e.g a stereo mini to dual RCA adapter) from your speakers as
follows:
•Line-In Jack = Rear Speaker Out
•Microphone-In Jack = Center/Subwoofer Speaker Out
•S/PDIF-Out Jack = Side Speaker Out (for 7.1 Surround Sound Only)
7.As you plug in each cable a dialog box will pop up (see “Auto Popup Dialog” on
page 2 - 13).
8.Click to put a tick in the appropriate box according to the speaker plugged-in (e.g.
Rear Speaker Out), and then click OK to save the setting.
9.Click OK to exit Realtek HD Audio Manager.
2 - 14 Audio Features
Storage Devices, Mouse, Audio & Printer
TouchPad Scrolling
This computer model series may feature different
TouchPad versions.
These TouchPads may
differ in their vertical
scrolling function in most
scrollable windows.
Some TouchPads require
sliding the finger up and
down on the right of the
TouchPad to scroll the
window. Other versions
require tapping/holding
down the finger at the top
right or bottom right of the
TouchPad to scroll the
window.
Figure 2 - 12
Mouse Properties
TouchPad and Buttons/Mouse
The TouchPad is an alternative to the mouse; however, you can also add a mouse to
your computer through one of the USB ports. The TouchPad buttons function in
much the same way as a two-button mouse.
Once you have installed the TouchPad driver (see “TouchPad” on page 4 - 7) you
can configure the functions from the Mouse control panel in Windows, or by d oubleclicking the TouchPad driver icon on the taskbar. You may then configure the
TouchPad tapping, buttons, scrolling, pointer motion and sensitivity options to your
preferences. Use the Fn + F1 key combination to toggle the TouchPad on/off.
2
TouchPad and Buttons/Mouse 2 - 15
Storage Devices, Mouse, Audio & Printer
Show Video
You can get a clearer
view of the gestures involved by clicking the
Show Video option for
each gesture item.
Select the gesture (Pinch
Zoom, Rotating, Three
Fingers Down and
Three Finger Flick) in the
Device Settings > Settings left tree menu
and click the Show Video
button to see the demonstration video.
For more details on any of
the gestures see the help
in the lower part of the
right menu window.
Figure 2 - 13
Mouse Properties -
Device Settings
2
Gestures and Device Settings
The Synaptics Gestures Suite application allows you to use a specific gesture (action) on the surface of the Touchpad to perform specific actions to manipulate documents, objects and applications.
You can configure the settings from the Device Settings tab in Mouse Properties:
1.Click
2.Click Mouse (Hardware and Sound).
3.Click Device Settings (tab) and click Settings.
4.Use the menu tree on the lef t to access the user configurable settings.
Start
, and click
Control Panel
(or point to
Settings
and click
Control Panel
).
2 - 16 TouchPad and Buttons/Mouse
Scrolling
Figure 2 - 14
Scrolling Gesture
Mouse Driver
If you are using an external mouse your operating system may be
able to auto-configure
your mouse during its
installation or only enable its basic functions.
Be sure to check the
device’s user documentation for details.
Figure 2 - 15
Zooming Gesture
The Two-Finger scrolling feature works in most scrollable windows and allows you
to scroll horizontally and vertically. Place two fingers, slightly separated, on the
TouchPad surface and slide both fingers in the direction required (in a straight continuous motion).
Zooming
The Pinch Zoom gesture can be used to perform the same function as a scroll wheel
in Windows applications that support CTRL + scroll wheel zoom functionality.
Place two fingers on the TouchPad (for best results use the tips of the fingers) and
slide them apart to zoom in, or closer together to zoom out.
Storage Devices, Mouse, Audio & Printer
2
TouchPad and Buttons/Mouse 2 - 17
Storage Devices, Mouse, Audio & Printer
Figure 2 - 16
Rotating Gesture
Figure 2 - 17
Flick/Press
Gesture
2
Rotating
Use the Pivot Rotate gesture to rotate objects (e.g. photos) in 90 degree increments.
Place a finger down on the left “target” zone and keep it stationary. Place another
finger near the middle of the TouchPad and slide it in a circular motion around the
stationary finger (clockwise or counterclockwise) to rotate the object.
Three Finger-Flick/Three Fingers Down (Press)
The Three Finger-Flick gesture may be used to enhance navigation with a variety of
applications such as browsing the Internet or scrolling through a photo viewer. The
Three Fingers Down gesture may be used to launch user-selectable applications.
2 - 18 TouchPad and Buttons/Mouse
Storage Devices, Mouse, Audio & Printer
Parallel Printer
After setting up the printer attach the parallel cable to the printer.
Connect the printer’s
parallel cable to the Parallel to USB converter,
and then plug the converter into the USB port.
Turn ON the printer,
then turn ON the computer.
Windows will identify the
printer and either load
one of its own drivers or
ask you to supply one.
Follow the on-screen instructions.
Adding a Printer
The most commonly used peripheral is a printer. The following conventions will
help you to add a printer; however it is always best to refer to the printer manual for
specific instructions and configuration options.
USB Printer
Most new printers have a USB interface connection. You may use any one of the
ports to connect the printer.
Install Instructions:
1.Set up the printer according to its instructions (unp acking, p aper tr ay, toner/ink cartridge etc.).
2.Turn ON the computer.
3.Turn ON the printer.
4.Connect the printer’s USB cable to one of the USB ports on the computer.
5.Windows will identify the printer and either load one of its own drivers or ask you
to supply one. Follow the on-screen instructions.
Parallel Printer
This is still a very common type of printer. The install instructions are in the sidebar
(you will need to purchase a parallel to USB converter).
2
Adding a Printer 2 - 19
Storage Devices, Mouse, Audio & Printer
2
2-20
Chapter 3: Power Management
OS Note
Power management
functions will vary slightly depending on your
operating system. For
more information it is
best to refer to the user’s
manual of your operating system.
(Note: All pictures used
on the following pages
are from the Windows 7
OS.)
Power Management
Overview
To conserve power, especially when using the battery, your computer power management conserves power by controlling individual components of the computer
(the LCD and hard disk drive) or the whole system.
This chapter covers:
•The Power Sources
•Turning On the Computer
•Power Plans
•Power-Saving States
•Configuring the Power Buttons
•Battery Information
The computer uses enhanced power saving techniques to give the operating system
(OS) direct control over the power and thermal states of devices and processors. For
example, this enables the OS to set devices into low-power states based on user settings and information from applications.
3
Overview 3 - 1
Power Management
The Power Sources
The computer can be powered by either an AC/DC adapter or a battery pack.
3
AC/DC Adapter
Use only the AC/DC adapter that comes with your computer. The wrong type of AC/
DC adapter will damage the computer and its components (see page C - 4).
1.Attach the AC/DC adapter to the DC-In jack at the rear of the computer.
2.Plug the AC power cord into an outlet, and then conne ct the AC power co rd to the
AC/DC adapter.
3.Raise the lid/LCD to a comfortable viewing angle.
4.Press the power button to turn “On”.
Battery
The battery allows you to use your computer while you are on the road or when an
electrical outlet is unavailable. Battery life varies depending on the applications and
the configuration you're using. To increase battery life, let the battery dischargecompletely before recharging (see “How do I completely discharge the battery?”
on page 3 - 14).
We recommend that you do not remove the battery. For more information on the battery, please refer to “Battery Information” on page 3 - 10.
3 - 2 The Power Sources
Turning On the Computer
Forced Off
If the system “hangs”,
and the Ctrl + Alt + Del
key combination doesn’t
work, press the power
button for 4 seconds, or
longer, to force the system to turn itself off.
Power Button as
Stand by or
Hibernate Button
You can use the OS’s
Power Options control
panel to set the power
button to send the system into Stand by or Hibernate mode (see your
OS’s documentation, or
“Configuring the Power Buttons” on page 3
- 8 for details).
Shut Down
Note that you should always shut your computer down by choosing the Shut Down command from the bottom right of the Start menu in Windows. This will help prevent hard disk
or system problems.
Now you are ready to begin using your computer. To turn it on simply press the power button on the front panel.
When the computer is on, you can use the power button as a Stand by/Hibernate/
Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and
holding the power button for longer than this will shut the computer down). Use
Power Options in the Windows control panel to configure this feature.
Power Management
3
Turning On the Computer 3 - 3
Power Management
Resuming
Operation
See Table 3 - 1, on
page 3 - 9 for informa-
tion on how to resume
from a power-saving
state.
Password
It is recommended that
you enable a password
on system resume in order to protect your data.
Figure 3 - 1
Power Plan
Advanced Settings
(Win 7)
Power Plans
The computer can be configured to conserve power by means of power plans. You
3
can use (or modify) an existing power plan, or create a new one.
3 - 4 Power Plans
The settings may be adjusted to set the display to turn off after a specified time, and
to send the computer into Sleep after a period of inactivity.
Click Change plan settings and then click Change advanced power settings to access further configuration options in Advanced Settings.
Each Windowspower plan will also adjust the processor performance of your ma-
Figure 3 - 2
Power Plans (Win 7)
Click to Show/Hide
additional
power plans
chine in order to save power. This is worth bearing in mind if you are experiencing
any reduced performance (especially under DC/battery power).
Choose High performance (you may need to click Show additional plans to view
the High performance plan) for maximum performance when the computer is powered from an AC power source. Choose the Power saver (bear in mind that this
scheme may slow down the overall performance of the computer in order to save
power) for maximum power saving when the computer is battery (DC power) powered.
Power Management
3
Power Plans3-5
Power Management
Power-Saving States
You can use power-saving states to stop the computer’s operation and restart where
3
you left off. Win 7 uses the Sleep, Hibernate and Shut Down power-saving states.
Sleep
In Sleep all of your work, settings and preferences are saved to memory before the
system sleeps. When you are not using your computer for a certain length of time,
which you specify in the operating system, it will enter Sleep to save power.
The PC wakes from Sleep within seconds and will return you to where you last left
off (what was on your desktop) without reopening the application(s) and file(s) you
last used.
If your mobile PC in Sleep is running on battery power the system will use only a
minimum amount of power. After an extended period the system will save all the
information to the hard disk and shut the computer down before the battery becomes
depleted.
3 - 6 Power-Saving States
Hibernate
Silent Mode
You can use Silent
Mode to reduce power
consumption and fan
noise. Use the SilentMode Touch Sensor Instant Key to toggle
this mode on/off.
On screen visual indicators and the
Touch Sensor Instant
Key will display the
Silent Mode status (see
Table 1 - 2, on page 1 -
9).
Note Silent Mode may
reduce computer performance.
Figure 3 - 3
Start Menu Power
Hibernate uses the least amount of power of all the power-saving states and saves
all of your information on a part of the hard disk before it turns the system off. If a
power failure occurs the system can restore your work from the hard disk; if a power
failure occurs when work is saved only to memory, then the work will be lost. Hi-bernate will also return you to where you last left off within seconds. You should
put your mobile PC into Hibernate if you will not use the computer for a period of
time, and will not have the chance to charge the battery.
Shut down
You should Shut down the computer if you plan to install new hardware (don’t forget to remove the battery and follow all the safety instructions in Chapter 6), plan
to be away from the computer for several days, or you do not need it to wake up and
run a scheduled task. Returning to full operation from Shut down takes longer than
from Sleep or Hibernate.
Power Management
3
Power-Saving States 3 - 7
Power Management
Password
Protection
It is recommended that
you enable a password
on wake up in order to
protect your data.
However you can disable this setting from the
Power Options menu
by clicking Require a
password on wakeup
in the left menu, and selecting the options (click
Change settings that
are currently unavailable).
Figure 3 - 4
Power Options
Define Power
Buttons
3
Configuring the Power Buttons
The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the
computer in to a power-saving state. Click Choose what the power buttons do on
the left menu in Power Options to bring up the menu.
3 - 8 Configuring the Power Buttons
Resuming Operation
Closing the Lid
If you have chosen to
send the computer to
Sleep when the lid is
closed, raising the lid
will wake the system up.
Table 3 - 1
Resuming
Operation
Power Button
When the computer is on, you can use the power button as a Sleep/Hibernate/Shut Down
hot key button when it is pressed for less than 4 seconds (pressing and holding the power
button for longer than this will force the computer to shut down).
You can resume operation from power-saving states by pressing the power button,
or in some cases pressing the sleep button (Fn + F4 key combo).
Power Management
3
Power Status
Power OffOffPress the Power Button
SleepBlinking Green
Hibernate
Display Turned OffGreenPress a Key or Move the Mouse/Touchpad
Icon Color
Off (battery)
Orange (AC/DC adapter)
To Resume
Press the Power Button
Press the Sleep Button (Fn + F4 Key Combo)
Press the Power Button
Configuring the Power Buttons 3 - 9
Power Management
Low Battery
Warning
When the battery is critically low, immediately
connect the AC/DC
adapter to the computer
or save your work, otherwise, the unsaved
data will be lost when
the power is depleted.
Figure 3 - 5
Battery Icon
(Taskbar) & Battery
Advanced Settings
3
Battery Information
Follow these simple guidelines to get the best use out of your battery.
Battery Power
Your computer’s battery power is dependent upon many factors, including the programs you are running, and peripheral devices attached. You can set actions to be
taken (e.g. Shut down, Hibernate etc.), and set critical and low battery levels from
power plan Change plan settings > Change advanced power settings (see Figure
3 - 1 on page 3 - 4).
Click the battery icon in the taskbar to see the current battery level and charge
status.
3 - 10 Battery Information
Conserving Battery Power
Windows Mobility
Center
The Windows Mobility
Center control panel
provides an easy point
of access for information
on battery status, power
plans used and wireless
device status etc.
Figure 3 - 6
Windows Mobility
Center
•Use a power plan that conserves power (e.g Power saver), however note that
this may have an affect on computer performance.
•Lower the brightness level of the LCD display. The system will decrease LCD
brightness slightly to save power when it is not powered by the AC/DC adapter.
•Reduce the amount of time before the display is turned off.
•Close wireless, Bluetooth, modem or communication applications when they are
not being used.
•Disconnect/remove any unnecessary external devices e.g. USB devices,
ExpressCards etc.
Power Management
3
Battery Information 3 - 11
Power Management
Battery Life
Battery life may be shortened through improper maintenance. To optimize the life
3
and improve its performance, fully discharge and recharge the battery at least
once every 30 days.
We recommend that you do not remove the battery yourself. If you do need to remove the battery for any reason (e.g. long term storage) see “Removing the Battery”
on page 6 - 3.
New Battery
Always completely discharge, then fully charge, a new battery (see “Battery FAQ”
on page 3 - 14 for instructions on how to do this).
Recharging the Battery with the AC/DC Adapter
The battery pack automatically recharges when the AC/DC adapter is attached and
plugged into an electrical outlet. If the computer is powered on, and in use, it will
take several hours to fully recharge the battery. When the computer is turned off but
plugged into an electrical outlet, battery charge time is less. (Refer to “LED Indica-
tors” on page 1 - 7 for information on the battery charge status, and to “Battery Information” on page 3 - 10 for more information on how to maintain and properly
recharge the battery pack.)
3 - 12 Battery Information
Proper handling of the Battery Pack
Damaged Battery Warning
Should you notice any physical defects (e.g. the battery is bent ou t of shape after being
dropped), or any unusual smells emanating from the notebook battery, shut your computer
down immediately and contact your service center. If the battery has bee n d roppe d we do
not recommend using it any further, as even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire . It is
recommended that you replace your computer battery every two years.
Caution
Danger of explosion if
battery is incorrectly replaced.
Replace only with the
same or equivalent type
recommended by the
manufacturer. Discard
used battery according
to the manufacturer’s instructions.
•DO NOT disassemble the battery pack under any circumstances.
•DO NOT expose the battery to fire or high temperatures, it may explode.
•DO NOT connect the metal terminals (+, -) to each other.
Power Management
3
Battery Information 3 - 13
Power Management
Figure 3 - 7
Power Plan Create
3
Battery FAQ
How do I completely discharge the battery?
Use the computer with battery power until it shuts down due to a low battery. Don’t
turn off the computer even if a message indicates the battery is critically low, just let
the computer use up all of the battery power and shut down on its own.
1.Save and close all files and application s.
2.Create a power plan for discharging the battery and set all the options to Never.
3 - 14 Battery Information
3.Click Change plan settings (after creating it) and click Change plan settings >
Figure 3 - 8
Change Plan
Settings / Change
Advanced Power
Settings
Change advanced power settings.
Power Management
3
Battery Information 3 - 15
Power Management
Figure 3 - 9
Power Options
Advanced Settings -
Battery
3
4.Scroll down to Battery and click + to expand the battery options.
5.Choose the options below (click Yes if a warning appears):
•Low battery levels = 0%
•Critical battery Levels = 1%
•Low battery action = Do Nothing
•Critical battery action (On battery) = Shut Down
•Critical battery action (Plugged in) = Do Nothing
3 - 16 Battery Information
How do I fully charge the battery?
SLI Multi GPU Configuration & Battery Power
Note that due to the high power and system demands created by enabling SLI Configu ration, you should not enable SLI configuration if your computer is powered by batteryonly. If you attempt to run an SLI configuration when the comp uter is po wered by the battery only, then system problems may occur.
If the computer is currently powered by battery only do not enable SLI configuration.
If you have currently enabled SLI configuration, an d the computer is powered by the AC/
DC adapter, do not switch to battery power only (or go to the NVIDIA Control Panel and
disable SLI configuration before switching to battery power only).
When charging the battery, don’t stop until the LED charging indicator light changes
from orange to green.
How do I maintain the battery?
Completely discharge and charge the battery at least once every 30 days or after
about 20 partial discharges.
Power Management
3
Battery Information 3 - 17
Power Management
3
3-18
Chapter 4: Drivers & Utilities
Driver Installation &
Power
When installing drivers make sure your
computer is powered
by the AC/DC adapter
connected to a working power source.
Some drivers draw a
significant amount of
power during the installation procedure, and if
the remaining battery
capacity is not adequate
this may cause the system to shut down and
cause system problems
(note that there is no
safety issue involved
here, and the battery will
be rechargeable within 1
minute).
This chapter deals with installing the drivers and utilities essential to the operation or
improvement of some of the computer’s subsystems. The system takes advantage of
some newer hardware components for which the latest versions of most available operating systems haven’t built in drivers and utilities. Thus, some of the system components won’t be auto-configured with an appropriate driver or utility during
operating system installation. Instead, you need to manually install some system-required drivers and utilities.
RAID & AHCI Setup
Note that setting up a RAID, or AHCI mode, needs to be done prior to installing the
Windows OS, and therefore before installing the other drivers listed here (see “Set-
ting Up SATA RAID or AHCI Mode” on page 7 - 2 and page 8 - 21).
What to Install
The Device Drivers & Utilities + User’s Manual disc contains the drivers and utilities necessary for the proper operation of the computer. Table 4 - 1, on page 4 - 3
lists what you need to install and it is very important that the drivers are installed
in the order indicated. The procedures for installing drivers for the PC Camera,
WLAN, Fingerprint, Bluetooth and T HX TruStudio Audio modules are provided
in “Modules” on page 7 - 1.
Drivers & Utilities
4
What to Install 4 - 1
Drivers & Utilities
Driver Installation
Insert the Device Drivers & Utilities + User’s Manual
disc and click Install Drivers (button), or Option Driv-ers (button) to access the Optional driver menu.
4
Figure 4 - 1 - Drivers Installer Screen 1
1.Check the driver installation order from Table 4 - 1,
on page 4 - 3 (the drivers must be installed in
this order) which is the same as that listed in the
Drivers Installer menu below.
2.Click to select the driver you wish to install, (you
should note down the drivers as you install them).
3.Follow the instructions for each individual driver
installation procedure as listed on the following
pages.
4 - 2 Driver Installation
Figure 4 - 2 - Drivers Installer Screen 2
Driver for Windows 7 with Service Pack 1*
Drivers & Utilities
ChipsetPage 4 - 6
Video (VGA)Page 4 - 6PC Camera ModulePage 7 - 15
LANPage 4 - 7Wireless LAN ModulePage 7 - 23
Card ReaderPage 4 - 7Fingerprint Reader ModulePage 7 - 43
TouchPadPage 4 - 7Bluetooth ModulePage 7 - 49
Hot KeyPage 4 - 7THX TruStudio Pro AudioPage 7 - 64
GameKey UtilityPage 4 - 7
USB 3.0Page 4 - 7
MEI DriverPage 4 - 8
AudioPage 4 - 8
Intel Rapid Storage Technology
(for RAID & AHCI mode Hard Disk Drives)
Page 7 - 9
*Note all drivers provided are for Windows 7 with Service Pack 1.
Table 4 - 1 - Driver Installation
Note that you need to install both the WLAN & Bluetooth drivers for Intel and 3rd party WLAN & Bluetooth
Combo modules.
If you are installing Hard Disk Drives with a combined capacity exceeding 2 Terabytes see “Partitioning
HDDs with a Combined Capacity Exceeding 2 TB” on page 8 - 21 for instructions.
4
Driver Installation 4 - 3
Drivers & Utilities
Manual Driver Installation
Click the Browse CD/DVD button in the Drivers Installer application and browse to the executable file in
the appropriate driver folder.
4
Windows Update
After installing all the drivers make sure you enable
Windows Update in order to get all the latest securi ty
updates etc. (all updates will include the latest hotfixes
from Microsoft). See “Windows Update” on page 4 -
9 for instructions.
Updating/Reinstalling Individual Drivers
If you wish to update/reinstall individual drivers it
may be necessary to uninstall the original driver.To do
this go to the Control Panel in the Windows OS and
double-click the Programs and Features icon (Pro-grams > Uninstall a program). Click to select the
driver (if it is not listed see below) and click Uninstall,
and then follow the on screen prompts (it may be necessary to restart the computer). Reinstall the driver as
outlined in this chapter.
If the driver is not listed in the Programs and Fea-tures menu:
1.Click Start, and click Control Panel (or point to
Settings and click Control Panel).
2.Double-click Device Manager (Hardware and
Sound > Device Manager).
3.Double-click the device you wish to update/reinstall
the driver for (you may need to click “+” to expand
the selection).
4.Click Driver (tab) and click the Update Driver or
Uninstall button and follow the on screen prompts.
4 - 4 Driver Installation
Drivers & Utilities
User Account Control
If a User Account Control prompt appears as part of
the driver installation procedure, click Continue/Al-low, and follow the installation procedure as directed.
Windows Security Message
If you receive a Windows security message as part of
the driver installation process. Just click “Install thisdriver software anyway” or Install to continue the installation procedure.
You will receive this message in cases where the driver has been released after the version of Windows you
are currently using. All the drivers provided will have
already received certification for Windows.
New Hardware Found
If you see the message “New Hardware Found” during the installation procedure (other than when out-lined in the driver install procedure), click Cancel
to close the window, and follow the installation procedure.
4
Driver Installation 4 - 5
Drivers & Utilities
Driver Installation General Guidelines
The driver installation procedure outlined in this
Chapter (and in Chapter 7 Options & Modules),
are accurate at the time of going to press.
Drivers are always subject to upgrade and revision
so the exact procedure for certain drivers may differ
slightly. As a general guide follow the default on
screen instructions for each driver (e.g. Next > Next> Finish) unless you are an advanced user. In many
cases a restart is required to install the driver.
Driver Installation Procedure
Insert the Device Drivers & Utilities + User’s Manual
discand click Install Drivers (button), or Option Driv-ers (button) to access the Optional driver menu.
4
RAID Note: Setting up a RAID, or AHCI mode,
needs to be done prior to installing the Windows OS,
and therefore before installing the other drivers listed
here.
4 - 6 Driver Installation
Chipset
1.Click 1.Install Chipset Driver > Yes.
2.Click Next > Yes > Next > Next.
3.Click Finish to restart the computer.
Video (VGA)
1.Click 2.Install VGA Driver > Yes.
2.Click AGREE AND CONTINUE (button) to
accept the terms of the license agreement.
3.Click Next.
4.Click the REST ART NOW button to restart
the computer.
After the Video (VGA) driver has been installed, and
the system restarted, the OS will automatically run the
"Winsat.exe" to rate the performance. Allow time for
this process to finish and do not restart during this process (if you have restarted the system see “Windows
Update” on page 4 - 9).
Drivers & Utilities
LAN
1.Click 3.Install LAN Driver > Yes.
2.Click Install.
3.Click Finish to complete the installation.
Card Reader
1.Click 4.Install Cardreader Driver > Yes.
2.Click Install.
3.Click Finish to complete the installation.
TouchPad
1.Click 5.Install Touchpad Driver > Yes.
2.Click Next.
3.Click the button to accept the license, and then
click Next.
4.Click Finish > Restart Now to restart the com-
puter.
Hot Key
1.Click 6.InstallHotkey AP > Yes.
2.Click Next > Next.
3.Click Finish > Finish to restart your computer.
GameKey Utility
1.Click 7.InstallGamekey AP > Yes.
2.Click Next.
3.Click Finish to restart the computer.
4.See
“Game Keys” on page 2 - 8
for information.
USB 3.0
1.Click 8.Install USB 3.0 Driver > Yes.
2.Click Next.
3.Click the button to accept the license and then
click Next.
4.Click Install > Finish.
4
Driver Installation 4 - 7
Drivers & Utilities
MEI Driver
1.Click 9.Install MEI Driver > Yes.
2.Click Next > Yes > Next > Next.
3.Click Finish.
4
Audio
1.Click 10. Install Audio Driver > Yes.
2.Click Next.
3.Click Finish to restart the computer.
After installing the audio driver the system will not return to the Drivers Installer screen. To install any of
the optional drivers, eject the Device Drivers & Utili-ties + User’s Manual disc and then reinsert it (or double-click the disc icon in My Computer), and click
Option Drivers (button) to access the optional driver
menu.
It is recommended that you install the THX Tru Stu-dio Pro Audio application (see “THX TruStudio AP
Installation” on page 7 - 110) and Intel Rapid Stor-
age Technology driver (see “IRST Driver Installa-
tion” on page 7 - 8 - required for AHCI & RAID mode
hard disks).
(see over)
4 - 8 Driver Installation
Drivers & Utilities
Windows Update
After installing all the drivers make sure you enable Windows Update in order to get all the latest security up-
dates etc. (all updates will include the latest hotfixes
from Microsoft).
To enable Windows Update make sure you are con-nected to the internet:
1.Click Start, and click Control Panel (or point to
Settings and click Control Panel).
2.Click Check for updates (Security), or doubleclick Security Center and click Windows Update.
3.Double-click Check for updates (button).
4.The computer will now check for updates (you
need to be connected to the internet).
5.Click Install now (button) to install the updates.
Optional Drivers
See the pages indicated for the driver installation procedures for any modules included in your purchase option.
4
Figure 4 - 3 - Optional Drivers Installer Screen
Driver Installation 4 - 9
Drivers & Utilities
RAID Setup
See “Setting Up SATA RAID or AHCI Mode” on
page 7 - 2.
PC Camera
4
See “PC Camera Module” on page 7 - 15.
Wireless LAN
See “Wireless LAN Module” on page 7 - 23.
Fingerprint Reader Module
See “Fingerprint Reader Module” on page 7 - 43.
Bluetooth Module
See “Bluetooth Module” on page 7 - 49.
THX TruStudio AP
See “THX TruStudio Pro Audio” on page 7 - 64.
4 - 10 Driver Installation
Chapter 5: BIOS Utilities
BIOS Screens
Note that the BIOS
screens pictured on
these pages are intended for guidance in setting up your system’s
BIOS.
BIOS versions are subject to constant change
and revision, therefore
your computer’s actual
screens may appear
slightly different from
those pictured on these
pages.
Overview
This chapter gives a brief introduction to the computer’s built-in software:
Diagnostics: The POST (Power-On Self Test)
Configuration: The Setup utility
If your computer has never been set up, or you are making impo rtant changes to the
system (e.g. hard disk setup), then you should review this chapter first and note the
original settings found in Setup. Even if you are a beginner, keep a record of the settings you find and any changes you make. This information could be useful if your
system ever needs servicing.
There is one general rule: Don’t make any changes unless you are sure of what youare doing. Many of the settings are required by the system, and changing them could
cause it to become unstable or worse. If you have any doubts, consult your service
representative.
BIOS Utilities
5
Overview 5 - 1
BIOS Utilities
The Power-On Self Test (POST)
If you enable the Boot-time Diagnostic Screen in the Setup Utility, each time you
turn on the computer the system takes a few seconds to conduct a POST, including
a quick test of the on-board RAM (memory).
As the POST proceeds, the computer will tell you if there is anything wrong. If there
is a problem that prevents the system from booting, it will display a system summary
5
and prompt you to run Setup.
If there are no problems, the Setup prompt will disappear and the system will load
the operating system. Once that starts, you can’t get into Setup without rebooting.
5 - 2 The Power-On Self Test (POST)
Failing the POST
Errors can be detected during the POST. There are two categories, “fatal” and “nonfatal”.
Fatal Errors
These stop the boot process and usually indicate there is something seriously wrong
with your system. Take the computer to your service representative or authorized
service center as soon as possible.
Non-Fatal Errors
This kind of error still allows you to boot. You will get a message identifying the
problem (make a note of this message!) followed by the prompt:
•Press <F1> to resume
•<F2> to enter Setup
Press F1 to see if the boot process can continue. It may work, without the correct
configuration.
Press F2 to run the Setup program and try to correct the problem. If you still get an
error message after you change the setting, or if the “cure” seems even worse, call
for help.
BIOS Utilities
5
The Power-On Self Test (POST) 5 - 3
BIOS Utilities
BIOS Settings
Warning
Incorrect settings can
cause your system to
malfunction. To correct
mistakes, return to Set-
up and restore the Previous Values with
<F2>, or Optimized Defaults with <F3>.
5
The Setup Utility
The Aptio SetupUtility tells the syst em how to configure itself and manage basic
features and subsystems (e.g. port configuration).
Entering Setup
To enter Setup, turn on the computer and press F2 during the POST. The prompt
“Press F2 to Enter Setup” is usually present for a few seconds after you turn on the
system. If you get a “Keyboard Error”, (usually because you pressed F2 too quickly)
just press F2 again.
If the computer is already on, reboot using the Ctrl + Alt + Delete combination and
then hold down F2 when prompted. The Setup main menu will appear.
5 - 4 The Setup Utility
Setup Screens
Setup Menus
The Setup menus
shown in this section are
for reference only. Your
computer’s menus will
indicate the configuration appropriate for your
model and options.
Figure 5 - 1
Navigation Menu
The following pages contain additional advice on portions of the Setup. Along the
top of the screen is a menu bar with menu headings. When you select a heading, a
new screen appears. Scroll through the features listed on each screen to make changes to Setup.
Instructions on how to navigate each screen are in the box at the bottom right side of
the screen.
If these tools are confusing, press F1 to call up a General Help screen, and then use
the arrow keys to scroll up or down the page.
The Item Specific Help on the upper right side of each screen explains the highlight-
ed item and has useful messages about its options.
If you see an arrow next to an item, press Enter to go to a sub-menu on that subject. The sub-menu screen that appears has a similar layout, but the Enter key may
execute a command.
BIOS Utilities
5
The Setup Utility 5 - 5
BIOS Utilities
Figure 5 - 2
Main Menu
Main Menu
5
System Time & Date (Main Menu)
The hour setting uses the 24-hour system (i.e., ØØ = midnight; 13 = 1 pm). If you
can change the date and time settings in your operating system, you will also change
these settings. Some applications may also alter data files to reflect these changes.
5-6Main Menu
