Contents
About this Concise User Guide ..................................... ... ..............................1
System Startup ................................................................................................4
System Map: Front View with LCD Panel Open ..........................................5
LED Indicators ...............................................................................................6
Keyboard & Function Keys ............................................................................7
System Map: Front, Left & Right Views ......................................................8
System Map: Bottom & Rear Views .............................................................9
Control Center ..............................................................................................10
Multi-Color LED Keyboard (Option) ...........................................................11
Windows 10 Start Menu, Context Menu, Taskbar, Control Panel and
Settings ......................................................................................................... 12
Video Features ..............................................................................................13
Audio Features ..............................................................................................15
Power Options ..............................................................................................15
Driver Installation .............................. ... ......................................... ...............16
Wireless LAN Module (Option) ...................................................................17
Bluetooth Module (Option) ..........................................................................17
TPM ................................ ...................................................... ........................ 18
TPM Management in Windows ....................................................................18
Troubleshooting .................... ................................ ............................... ......... 19
Specifications ................................................................................................2 0
Inhalt
Über das Ausführliche Benutzerhandbuch ...................................................23
Schnellstart ................................................................................................... 26
Systemübersicht: Ansicht von vorne mit geöffnetem
LCD-Bildschirm .......................... ............................................................... ..27
LED-Anzeigen ...................... ............................. ............................ ............... 2 8
Tastatur und Funktionstasten ........................................................................29
Systemübersicht: Ansicht von vorne, links und rechts ................................30
Systemübersicht: Ansicht von unten und hinten ..........................................31
Control Center ..............................................................................................32
Mehrfarbige LED-Tastatur (Option) ............................................................33
Start-Menü, Kontextmenü, Taskleiste, Systemsteuerung und Einstellungen
von Windows 10 ................... ...................................... ... ... ............................34
Grafikfunktionen .......................................................................................... 35
Audiofunktionen ................... ......................................... ............................... 37
Energieoptionen ................... ............ ............. ............. ............ ............. .......... 37
Installation der Treiber .................................... ... .... ...................................... 38
Wireless-LAN-Modul (Option) ....................................................................39
Bluetooth-Modul (Option) ........................................... ... ... ... .......................3 9
TPM .................................. ............................... ................................... .......... 4 0
Fehlerbehebung ............................................................................................ 41
Technische Daten ......................................................................................... 42
Sommaire
A propos de ce Guide Utilisateur Concis ..................................................... 45
Guide de démarrage rapide .. ... ... ................................................................... 48
Carte du système: Vue de face avec l’écran LCD ouvert ............................. 49
Indicateurs LED ............................................................................................ 50
Clavier et touches fonction ...........................................................................51
Carte du système: Vues de face, gauche et droite .......................................52
Carte du système: Vues de dessous et arrière ...............................................53
Control Center ..............................................................................................54
Clavier à LED multicolore (Option) .............................................................55
Menu Démarrer, Menu contextuel, Barre des tâches, Panneau de Configura-
tion et Paramètres de Windows 10 ............................................................... 56
Caractéristiques vidéo .................. ... .......................................... ... ................57
Caractéristiques audio .................. ... .......................................... ... ................59
Options d’alimentation ................................................................................. 59
Installation du pilote ..................... ... .......................................... ... ................60
Module LAN sans fil (Option) ........................................... .......................... 61
Module Bluetooth (Option) ....................................... ... ... ............................. 61
TPM .................................. ............................... ................................... .......... 6 2
Dépannage .............................. ............................................................... ....... 63
Spécifications ............................................................................................... 64
Contenidos
Acerca de esta Guía del Usuario Concisa .....................................................67
Guía rápida para empezar .............................................................................70
Mapa del sistema: Vista frontal con panel LCD abierto ..............................71
Indicadores LED ...........................................................................................72
Teclado y teclas de función ..........................................................................73
Mapa del sistema: Vistas frontal, izquierda y derecha ...............................74
Mapa del sistema: Vistas inferior y posterior ...............................................75
Control Center ..............................................................................................76
Teclado LED multicolor (Opción) ...............................................................77
Menú Inicio, Menú contextual, Barra de tareas, Panel de Control y
Configuración de Windows 10 ............................................. ........................78
Parámetros de vídeo ......................................................................................79
Características de audio ................................................................................81
Opciones de energía ......................................................................................81
Instalación de controladores ....................................... ... ...............................82
Módulo LAN Wireless (Opción) .......... ... ......................................... ............83
Módulo Bluetooth (Opción) ........... ... ... ........................................................83
TPM ................................ ...................................................... ........................ 84
Solución de problemas ................. .................................................................85
Especificaciones ........................................................................................... 86
Sommario
Informazioni su questa guida rapida ......................................................... .... 89
Guida di avvio rapido ............................................. ...................................... 92
Descrizione del sistema: Vista anteriore con pannello LCD aperto .............93
Indicatori LED .............................................................................................. 94
Tastiera e tasti funzione ................................................................................95
Descrizione del sistema: Vista anteriore, sinistra e destra ..........................96
Descrizione del sistema: Vista inferiore e posteriore ...... ... ... .... ...................9 7
Control Center ..............................................................................................98
Tastiera LED multicolore (Opzione) ............................................................99
Menu Start, Menu contestuale, Barra delle applicazioni, Pannello di
controllo e Impostazioni di Windows 10 ....................................................100
Funzioni video ............................................................................................101
Funzionalità audio ...................................................................................... 103
Opzioni risparmio energia .......................................................................... 103
Installazione driver .....................................................................................104
Modulo LAN Wireless (Opzione) ..............................................................105
Modulo Bluetooth (Opzione) ..................................................................... 105
TPM .................................. ............................... ................................... ........ 106
Risoluzione dei problemi ........ ... ......................................... ........................10 7
Specifiche tecniche ....................... ... .... ......................................... ..............108
About this Concise User Guide
FCC Statement
This device complies with Part
15 of the FCC Rules. Operation
is subject to the following two
conditions:
1.This device may not cause
harmful interference.
2. This device must accept any
interference received, including interference that may
cause undesired operation.
This quick guide is a brief introduction to getting your system started. This is a s upplement, and not a substitute for the
expanded English language User’s Manual in Adobe Acrobat format on the Device Drivers & Utilities + User’s Manual
disc supplied with your computer. This disc also contains the drivers and utilities necessary for the proper oper ation of
the computer (Note: The company reserves the right to revise this publication or to change its contents without notice).
Some or all of the computer’s features may already have been setup. If they aren’t, or you are planning to re-configure
(or re-install) portions of the system, refer to the expanded User’s Manual. The Device Drivers & Utilities + User’s
Manual disc does not contain an operating system.
Regulatory and Safety Information
Please pay careful attention to the full regulatory notices and safety information contained in the expanded User’s Manual on the Device Drivers & Utilities + User’s Manual disc.
©
September 2019
Trademarks
Intel is a trademark/registered trademark of Intel Corporation.
Windows is a registered trademark of Microsoft Corporation.
English
1
Instructions for Care and Operation
The computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions:
• Don’t drop it, or expose it to shock. If the computer falls, the
case and the components could be damaged.
• Keep it dry, and don’t overheat it. Keep the computer and
power supply away from any kind of heating element. This is an
electrical appliance. If water or any other liquid gets into it, the
English
computer could be badly damaged.
• Avoid interfer ence. Keep the computer away from high capacity
transformers, electric motors, and other strong magnetic fields.
These can hinder proper performance and damage your data.
• Follow the proper working procedures for the computer. Shut
the computer down properly and don’t forget to save your work.
Remember to periodically save your data as data may be lost.
Servicing
Do not attempt to service the computer yourself. Doing so may
violate your warranty and expose you and the computer to
electric shock. Refer all servicing to authorized service personnel. Unplug the computer from the power supply. Then refer
servicing to qualified service personnel under any of the fo llowing conditions:
• When the power cord or AC/DC adapter is damaged or frayed.
• If the computer has been exposed to any liquids.
• If the computer does not work normally when you follow the
operating instructions.
• If the computer has been dropped or damaged (do not touch the
poisonous liquid if the LCD panel breaks).
• If there is an unusual odor, heat or smoke coming from your computer.
Safety Information
• Only use an AC/DC adapter approved for use with this computer.
• Use only the power cord and batteries indicated in this manual.
Do not dispose of batteries in a fire. They may explode. Check
with local codes for possible special disposal instructions.
• Do not continue to use a battery that has been dropped, or that
appears damaged (e.g. bent or twisted) in any way. Even if the
computer continues to work with a damaged battery in place, it
may cause circuit damage, which may possibly result in fire.
• Make sure that your computer is completely powered off before
putting it into a travel bag (or any such container).
• Before cleaning the computer, make sure it is disconnected from
any external power supplies, peripherals and cables.
• Use a soft clean cloth to clean the computer, but do not apply
cleaner directly to the computer. Do not use volatile (petroleum
distillates) or abrasive cleaners on any part of the computer.
• Do not try to repair a battery pack. Refer any battery pack repair
or replacement to your service representative or qualified service
personnel.
• Note that in computer’s featuring a raised LCD electro-plated
logo, the logo is covered by a protective adhesive. Due to general
wear and tear, this adhesive may deteriorate over time and the
exposed logo may develop sharp edges. Be careful when handling
the computer in this case, and avoid touching the raised LCD
electro-plated logo. Avoid placing any other items in the carrying
bag which may rub against the top of the computer during transport. If any such wear and tear develops contact your service center.
2
Polymer Battery Precautions
Battery Disposal & Caution
The product that you have purchased contains a rechargeable battery. The battery is recyclable. At the end of its useful life, under various state and local laws, it may be illegal
to dispose of this battery into the municipal waste stream.
Check with your local solid waste officials for details in your
area for recycling options or proper disposal.
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended
by the manufacturer. Discard used battery a ccording to the
manufacturer’s instructions.
Note the following information which is specific to polymer batteries only, and where applicable, this overrides the general battery precaution information.
• Polymer batteries may experience a slight expansion or swelling, however this is part of the battery’s safety mechanism and is not a cause
for concern.
• Use proper handling procedures when using polymer batteries. Do not use polymer batteries in high ambient temperature environments,
and do not store unused batteries for extended periods.
English
3
System Startup
Figure 1 - Opening the Lid/LCD/Computer with AC/
DC Adapter Plugged-In
Shut Down
Note that you should always shut your
computer down by choosing the Shut
down command in Windows (see below). This will help prevent hard disk or
system problems.
1. Click the Start Menu icon .
2. Click the Power item .
3. Choose Shut down from the menu.
130°
1. Remove all packing materials.
2. Place the computer on a stable surface.
3. Insert the battery and make sure it is locked in position.
4. Securely attach any peripherals you want to use with the computer
(e.g. keyboard and mouse) to their ports.
5. When first setting up the computer use the following
procedure (as to safeguard the computer during shipping, the
English
battery will be locked to not power the system until first connected
to the AC/DC adapter and initially set up as below):
• Attach the AC/DC adapter cord to the DC-In jack on the left of
the computer, then plug the AC power cord into an outlet, and
connect the AC power cord to the AC/DC adapter. The battery
will now be unlocked.
6. Use one hand to raise the
(do not exceed 130 degrees); use the other hand (as illustrated in
Figure 1) to support the base of the computer (Note: Never lift the
computer by the lid/LCD).
7. Press the power button to turn the computer “on”.
lid/LCD to a comfortable viewing angle
System Software
Your computer may already come with system software
pre-installed. Where this is not the case, or where you are reconfiguring your computer for a different system, you will
find this manual refers to Microsoft Windows 10.
4
System Map: Front View with LCD Panel Open
Note that the Touchpad
and Buttons valid operational area is that indicated within the red
dotted lines above.
Figure 2
Front View with LCD Panel
Open
1. PC Camera
2. *PC Camera LED
*When the PC camera is in
use, the LED will be
illuminated.
3. Built-In Array Microphone
4. LCD
5. Power Button
6. Keyboard
7. Touchpad & Buttons
5
7
6
7
4
Wireless Device
Operation Aboard
Aircraft
The use of any portable electronic
transmission devices aboard aircraft is
usually prohibited.
Make sure the wireless modules are
OFF if you are using the computer
aboard aircraft by
putting the system
in to Airplane Mode.
7
213
3
English
5
LED Indicators
Wireless Device
Operation Aboard
Aircraft
The use of any portable
electronic transmission
devices aboard aircraft is
usually prohibited.
Make sure the wireless
modules are OFF if you
are using the computer
aboard aircraft by putting
the system in to Airplane
Mode.
The LED indicators on the computer display helpful information about the current status
of the computer.
Icon Color Description
English
Orange The AC/DC Adapter is Plugged In
Green The Computer is On
6
Blinking Green The Computer is in Sleep Mode
Orange The Battery is Charging
Green The Battery is Fully Charged
Blinking Orange The Battery Has Reached Critically Low Power Status
Green The Hard Disk/Optical Device is in use
Table 1 - LED Indicators
Keyboard & Function Keys
Numeric
Keypad
Fn Key
Windows Logo Key
Scr Lk &
Num Lk
Function Keys
The keyboard includes a numeric keypad for easy numeric data input. Pressing Num Lk turns on/off the numeric keypad. It also features function keys to allow you
to change operational features instantly. The function
keys (F1 - F12 etc.) will act as hot keys when pressed
while the Fn key is held down. In addition to the basic
function key combinations, some visual indicators are
available when the Control Center driver is installed.
Keys Function/Visual Indicators Keys Function/Visual Indicators
English
Fn +
Fn +
Fn +
Fn +
Fn +
Fn +
Fn +
Fn +
Play/Pause (in Audio/Video Programs)
Touchpad Toggle
Turn LCD Backlight Off
(Press a key to or use Touchpad to turn on)
Mute Toggle
Volume Decrease/
Increase
Change Display Configuration (see page 14)
Brightness Decrease/
Increase
PC Camera Power
Toggle
Table 2 - Function Keys & Visual Indicators
Fn +
Fn +
Fn +
Fn +
Fn +
*Note: It is recommended that you use Maximum fan speed when
playing games.
Airplane Mode Toggle
Sleep Toggle
Number Lock Toggle
Scroll Lock Toggle
Caps Lock Toggle
Control Center Toggle (see page 10)
Fan Automatic Control/
Full Power
7
System Map: Front, Left & Right Views
Figure 3 - Front, Left & Right Views
1. LED Indicators
2. Multi-in-1 Card Reader
3. DC-In Jack
4. RJ-45 LAN Jack
5. External Monitor Port
6. USB 3.0 (USB 3.1 Gen 1)
Type-C Port
7. Vent
8. HDMI-Out Port
9. USB 3.0 (USB 3.1 Gen 1) Type-A
Port
10. 2-In-1 Audio Jack (Headphone and
Microphone)
11. Microphone-In Jack
12. USB 2.0 Ports
13.
(Factory Option) Dummy ODD/
DVD Writer/2nd HDD/SSD Caddy
14. Security Lock Slot
4
5
6
1
8
10
2
7
9
Front
Left
Right
11
12
13
12
A
Disc Emergency Eject
If you need to manually eject a disc
(e.g. due to an unexpected power interruption) you may push the end of a
straightened paper clip into the emergency eject hole. Do not use a sharpened pencil or similar object that may
break and become lodged in the hole.
Overheating
To prevent your computer from overheating make sure nothing blocks any
vent while the computer is in use.
A
3
14
English
8
System Map: Bottom & Rear Views
Figure 4
Bottom & Rear Views
1. Battery
2. Vent
3. Speakers
1
2
Overheating
To prevent your computer from overheating make sure nothing blocks any
vent while the computer is in use.
Bottom Cover Removal Warning
Do not remove any cover(s) and/or
screw(s) for the purposes of device upgrade as this may violate the terms of
your warranty.
If you need to replace/remove the hard
disk/RAM etc., for any reason, please
contact your distributor/supplier for further information.
3
3
2
1
English
9
Control Center
Figure 6 - FAN Speed Control
Run the Control Center from the Start menu in Windows
. You can also press th e Fn + Esc key com-
bination, or double-click the icon in the notification
area of the taskbar to access the Control Center. The
Control Center provides quick access to Fan settings
and LED Keyboard configuration (for the optional
multi-color LED keyboard).
English
Figure 5 - Control Center
FAN Speed Control
You can set the fan speed to Maximum (full power) or
Automatic/Slient. The fan speed will adjust itself auto-
matically to control the heat of the CPU/GPU. You can
use the Offset slider to adjust the settings to your preference. However you can adjust the setting to Maximum if
you prefer.
All these settings can be overidden by the system, as a
safety precaution, if it requires heavier use of the fan.
10
Multi-Color LED Keyboard (Option)
The LED Keyboard application can be accessed by click-
ing LED Keyboard in the Control Center (or by pressing the Fn plus key) or from the Start menu in
Windows .
Figure 7 - LED Keyboard Application
The keyboard LED may be configured using the Fn + key
combination outlined in the table below.
Keyboard LED Function key Combinations
Color Swatch
The color swatch in the middle of the screen allows you to
select a range of colors for your keyboard backlight by
clicking on the color required. Click to select any color
from the swatch to apply to the keyboard.
KB Sleep Timer
Enable and then select the amount of time for which the
system is idle before the keyboard LED enters sleep mode
(i.e. the LED keyboard illumination will turn off to save
power).
KB Brightness
You can adjust the keyboard brightness using the Brightness slider.
English
Fn +
Fn +
Fn +
Fn +
Launch the LED Keyboard Application
Toggle the Keyboard LED On/Off
Keyboard LED Illumination Decrease
Keyboard LED Illumination Increase
Table 3 - Keyboard LEDs
11
Windows 10 Start Menu, Context Menu,
Figure 8
Start Menu,
Context Menu,
Taskbar, Control Panel and
Settings
Taskbar, Control Panel and Settings
Most of the apps, control panels, utilities and programs within Windows 10 can be
accessed from the Start Menu by clicking the icon in the taskbar in the lower
left corner of the screen (or by pressing the Windows Logo Key on the keyboard).
Right-click the Start Menu icon (or use the Windows Logo Key + X key
English
combination) to bring up an advanced Context Menu of useful features such as
Apps and Features, Power Options, Task Manager, Search, File Explorer, Device
Manager and Network Connections etc.
The notification area of the taskbar is in the bottom right of the screen. Some of the
control panels and applications referred to throughout the course of this manual can
be accessed from here.
Throughout this manual you will see an instruction to open the Control Panel. To
access the Control Panel, select Control Panel under the Windows System item in
the Start Menu.
The Settings item in the Start Menu (and also as an App) gives you quick access to
a number of system settings control panels allowing you to adjust settings for System, Devices, Phone, Network & Internet, Personalization, Apps, Accounts, Time
& Language, Gaming, Ease of Access, Search, Cortana, Privacy and Update & Security.
12
Video Features
The system features an Intel integrated GPU. You can
switch display devices, and configure display options,
from the Display control panel in Windows as long as the
video driver is installed.
To access the Display control panel in Windows:
1. Right-click the desktop and select Display settings from the
menu.
2. Choose the required display settings from the menus.
To access the Intel® UHD Graphics Control Panel:
1. Access the Intel® UHD Graphics Control Panel from the Start
menu in Windows.
OR
2. Use the Ctrl + Alt + F12 key combination shortcut to open the
Intel® UHD Graphics Control Panel.
English
13
Display Devices
Figure 9
Project
Figure 10
Display
(Multiple
displays)
3 Connected Displays
Note that when 3 displays are connected, only 2 displays
may be configured in Duplicate mode.
Note that you can use external displays connected to the
HDMI-Out port and/or external monitor port. See your
display device manual to see which formats are supported.
Configuring the Displays in Windows
All external and internal displays (up to 3 active displays)
can be configured from Windows by using the Display or
English
System (in Settings) control panel or the Project menu.
To configure the displays using the Project menu:
1. Attach your external display(s) to the
appropriate port, and turn it(them) on.
2. Press the + P (or Fn + F7) key
combination.
3. Click on any one of the options from the
menu to select PC screen only,
Duplicate, Extend or Second screen
only.
4. You can also click Connect to a
wireless display at the bottom of the
Project screen and follow the steps to
connect to any wireless enabled display.
To configure the displays using the Display control panel:
1. Attach your external display(s) to the appropriate port, and turn
it(them) on.
2. Right-click the desktop and select Display settings from the
menu.
3. Click the Detect button.
4. The computer will then detect any attached displays.
5. You can configure up to 3 displays from the Multiple displays
menu.
14
Audio Features
Figure 11 - Power Options
You can configure the audio options on your computer
from the Sound control panel in Windows.
The volume may be adjusted by means of the Fn + F5/F6
key combination. The sound volume level can also be set
using the volume control within Windows. Click the
Speaker icon in the taskbar to check the setting.
Power Options
The Power Options (Hardware and Sound menu) control panel icon in Windows allows you to configure power
management features for your computer. You can conserve power by means of power plans and configure the
options for the power button, sleep button (Fn + F12),
computer lid (when closed), display and sleep mode
(the default power saving state) from the left menu.
Click Create a power plan in the left menu and select the
options to create a new plan. Click Change Plan Settings
and click Change advanced power settings to access further configuration options.
English
15
Driver Installation
Driver Installation & Power
When installing drivers make
sure your computer is powered
by the AC/DC adapter connected to a working power source.
Some drivers draw a significant
amount of power during the installation procedure, and if the
remaining battery capacity is not
adequate this may cause the
system to shut down and cause
system problems (note that
there is no safety issue involved
here, and the battery will be rechargeable within 1 minute).
Figure 12 - Install Drivers
Driver Installation
General Guidelines
As a general guide follow
the default on-screen instructions for each driver
(e.g. Next > Next > Fin-
ish) unless you are an advanced user. In many
cases a restart is required
to install the driver.
Make sure any modules
(e.g. WLAN or Bluetooth)
are ON before installing
the appropriate driver.
The Device Drivers & Utilities + User’s Manual disc contains the drivers and utilities necessary for the proper operation
of the computer. This setup will probably have already been done for you. If this is not the case, insert the disc and click
Install Drivers (button), or Option Drivers (button) to access the Optional driver menu. Install the drivers in the order indicated in Figure 12. Click to select the drivers you wish to install (you should note down the drivers as you
install them). Note: If you need to reinstall any driver, you should uninstall the driver first
Latest Updates
English
After installing all the drivers make sure you enable Check for updates (Settings > Update & Security > Check for
updates) and go to the Microsoft Store and click Downloads and updates > Get updates to update all Apps etc.
.
16
Wireless LAN Module (Option)
Make sure the Wireless LAN module is turned on (and not
in Airplane Mode) before configuration begins.
Bluetooth Module (Option)
Make sure the Bluetooth module is turned on (and not in
Airplane Mode) before configuration begins.
WLAN Configuration in Windows
1. Click the icon in the notification area of the taskbar.
2. A list of available access points will appear.
3. Double-click an access point to connect to it (or click it and click
Connect).
4. Enter a network security key (password) if required, and click
Next.
5. You can choose to find other devices or not.
6. When you are connected to the network access point it will
display Connected.
7. Select any connected network and click Disconnect to
disconnect from a connected access point.
8. You can click the Airplane Mode button to turn the mode On or
Off.
9. Alternatively you can click the Wi-Fi button to turn just the Wi-Fi
On or Off.
Bluetooth Configuration in Windows
1. Click the Settings it em in the Start Menu and then click Devices.
2. Click Bluetooth & other devices.
3. Click Add Bluetooth & other device > Bluetooth and a list of
discovered devices will appear.
4. Double-click the device you want to pair with the computer and
click Connect.
5. Select a device and click Remove Device > Yes to disconnect
from any device.
English
17
TPM
Figure 13
Security -
Trusted
Computing
Figure 14
BitLocker Drive
Encryption
(TPM Administra-
tion)
Figure 15
Trusted Plat-
form Module
(TPM) Manage-
ment on Local
Computer Ad-
ministration
Before setting up the TPM (Trusted Platform Module)
functions you must initialize the security platform.
Activating TPM
1. Restart the computer.
2. Enter the BIOS pressing F2 during the POST/startup.
3. Click Setup Utility and select the Security menu.
English
4. Click TPM Configuration and select Enable for Security
Device Support.
5. You will then need to press/click F10 to save the changes and
restart the computer.
TPM Management in Windows
You can manage your TPM settings from within Windows:
1. Go to the Control Panel.
2.
Click
18
BitLocker Drive Encryption (System and Security).
3. Click TPM Administration.
4. The TPM Management window allows you to configure the TPM
within Windows. As TPM is usually administered within large
enterprises and organizations, your system administrator will
need to assist you in managing the information here.
TPM Actions
1. Click Prepare the TPM and follow the instructions in the Wizard
to prepare the TPM (this will probably require a restart of the
computer and confirmation of the setting changes after restart by
pressing the appropriate F key).
2. After the restart the TPM will be prepared and you can then use
the Actions menu to T urn TPM off, Change Owner Password,
Clear TPM or Reset TPM Lockout.
3. A wizard will help take you through any setup steps.
Troubleshooting
Problem Possible Cause - Solution
The Wireless LAN/Bluetooth
modules cannot be detected.
The PC Camera module cannot be
detected.
Gaming performance is slow. It is recommended that you use Maximum fan speed when playing games. Use the
The modules are off as the computer is in Airplane Mode. Use the Fn + F11 key
combination to toggle Airplane Mode on/off (see Table 2 on page 7).
The module is off. Press the Fn + F10 key comb inati on in order to enab le th e module (see
Table 2 on page 7). Run the camera application to view the camera picture.
Fn + 1 key combination to adjust the fan speed.
English
19
Specifications
Latest Specification Information
The specifications listed in this section are correct at the time of going to
press. Certain items (particularly processor types/speeds) may be
changed, delayed or updated due to
the manufacturer's release schedule.
Check with your service center for details.
Note that this computer model series
may support a range of CPUs and/or
video adapters.
To find out which CPU is installed on
your system go to the Start menu and
select Settings, and then select Sys-
tem and click About. This will also
provide information on the amount of
Installed RAM etc.
To get information on your system’s
video adapter go to the Start menu
and select Settings, and then select
System and click Display > Advanced display settings > Display
adapter properties.
English
BIOS
64Mb SPI Flash ROM
INSYDE BIOS
Memory
Dual Channel DDR4
Two 260 Pin SO-DIMM Sockets
Supporting DDR4 2400MHz Memory Mod-
ules
Memory Expandable up to 8GB
Compatible with 4GB or 8GB Modules
(The real memory operating frequency
depends on the FSB of the processor.)
LCD
15.6" (39.62cm), 16:9, FHD (1920x1080)
Security
Security (Kensington® Type) Lock Slot
BIOS Password
Intel® PTT for Systems Without TPM Hard-
ware
Audio
High Definition Audio Compliant Interface
Built-In Array Microphone
Two Speakers
Storage
One Changeable 2.5" 7mm (h) SATA HDD/
SSD
(Factory Option) One 9.0/9.5mm(h) Optical Device Type Drive (DVD Writer)
Or
(Factory Option) Dummy ODD
Or
(Factory Option) 7mm (h) 2nd HDD/SSD
Caddy
(Factory Option) eMMC 64GB/128GB
Keyboard
Full-size keyboard (with numeric keypad)
Or
(Factory Option) Full-size Multi-Color
LED Keyboard (with Numeric Keypad)
Pointing Device
Built-in Touchpad (with Microsoft PTP Multi
Gesture & Scrolling Functionality)
Card Reader
Embedded Multi-In-1 Card Reader
MMC (MultiMedia Card)/RS MMC
SD (Secure Digital)/Mini SD/SDHC/
SDXC
20
Interface
One USB 3.0 (USB 3.1 Gen 1) Type-C Port*
*The maximum amount of current supplied
by USB Type-C ports is 500mA (USB 2.0)/
1500mA (USB 3.1).
One USB 3.0 (USB 3.1 Gen 1) Type-A Port
Two USB 2.0 Ports
One HDMI-Out Port
One External Monitor Port
One Microphone-In Jack
One 2-In-1 Audio Jack (Headphone and
Microphone)
One RJ-45 LAN Jack
One DC-In Jack
M.2 Slots
Slot 1 for Combo WLAN and Bluetooth
Module
(Factory Option) Slot 2 for 4G Module
Communication
Built-In 10/100/1000Mb Base-TX Ethernet
LAN
1.0M HD PC Camera Module
(Factory Option) 4G M.2 Module
WLAN/ Bluetooth M.2 Modules:
(Factory Option) Intel® Dual Band Wire-
less-AC 9260 Wireless LAN (802.11ac) +
Bluetooth
(Factory Option) Intel® Dual Band Wire-
less-AC 9560 Wireless LAN (802.11ac) +
Bluetooth
(Factory Option) Intel® Dual Band Wire-
less-AC 9462 Wireless LAN (802.11ac) +
Bluetooth
(Factory Option) Intel® Dual Band Wi-Fi 6
AX200 Wireless LAN (802.11ax) + Bluetooth
(Factory Option) Realtek Dual Band Wi-Fi
5 RTL8821CE Wireless LAN (802.11ac) +
Bluetooth
Power
Removable 4 Cell Smart Lithium-Ion Battery Pack, 31WH
(Factory Option) Removable 4 Cell Smart
Lithium-Ion Battery Pack, 41WH
Environmental Spec
Temperature
Operating: 5
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%
°C - 35°C
Dimensions & Weight
361mm (w) * 256mm (d) * 24.1mm (h)
(Height Excluding Battery Area)
2.2kg (Barebone with ODD and 31WH Battery)
English
Full Range AC/DC Adapter
AC Input: 100 - 240V, 50 - 60Hz
DC Output: 19V, 2.1A (40W)
21
English
22
Über das Ausführliche Benutzerhandbuch
Diese Kurzanleitung soll einen Überblick über die Schritte geben, die dazu notwendig s ind, das System zu starten. Dieses ist
nur eine Ergänzung und kein Ersatz für das erweiterte englischsprachige Benutzerhandbuch, das auf der mitgelieferten Disc
Device Drivers & Utilities + User's Manual im Adobe-Acrobat-Format vorliegt. Diese Disc enthält auch die Treiber und
Utility-Programme, die für einen einwandfreien Betrieb des Computers notwendig sind (Hinweis: Das Unternehmen behält
sich das Recht vor, diese Publikation ohne Vorankündigung zu überarbeiten und den Inhalt zu verändern).
Einige oder alle Funktionen des Computers sind bereits eingerichtet worden. Falls das nicht der Fall ist oder wenn Sie einzelne Teile des Systems neu konfigurieren (oder neu installieren) möchten, finden Sie eine Anleitung im erweiterten Benut-
zerhandbuch. Die Disc Device Drivers & Utilities + User's Manual enthält nicht das Betriebssystem.
Einhaltung gesetzlicher Vorschriften und Sicherheitshinweise
Beachten Sie sorgfältig die Hinweise zu gesetzlichen Vorschriften und zu Sicherheitshinweisen im erweiterten Benutzerhandbuch auf der Disc Device Drivers & Utilities + User's Manual.
© September 2019
Warenzeichen
Intel ist ein eingetragenes Warenzeichen der Intel Corporation.
Windows ist ein eingetragenes Warenzeichen der Microsoft Corporation.
Deutsch
23
Hinweise zu Pflege und Betrieb
Das Notebook ist zwar sehr stabil, kann aber dennoch beschädigt werden. Damit es nicht dazu kommt, sollten Sie die
folgenden Hinweise beachten:
• Das Gerät darf nicht herunterfallen und in anderer Form Stößen
ausgesetzt werden. Wenn der Computer fällt, können das Gehäuse und
andere Komponenten beschädigt werden.
• Das Gerät darf nicht nass werden und sich nicht überhitzen. Computer und Netzteil dürfen nicht in der Nähe von Wärmequellen stehen oder
gelagert werden. Dies ist ein elektrisches Gerät. Wenn Wasser oder
andere Flüssigkeiten eindringen, kann der Computer stark beschädigt
werden.
• Vermeiden Sie Interferenzen mit anderen Geräten. Halten Sie den
Computer fern von magnetischen Feldern, die von Stromquellen, Moni-
Deutsch
toren, Magneten etc. erzeugt werden. Die können die Leistung beeinträchtigen und Ihre Daten beschädigen.
• Achten Sie auf die richtige Bedienung des Computers. Schalten Sie
ihn erst aus, wenn alle Programme geschlossen wurden (speichern Sie
Ihre Daten!). Speichern Sie regelmäßig Ihre Daten, da diese verloren
gehen können, wenn der Akku verbraucht ist.
Reparatur
Nehmen Sie vor dem Reinigen des Wenn Sie versuchen, den
Computer selbst zu reparieren , können Ihre Garantieansprüche
verloren gehen. Außerdem besteht Stromschlaggefahr für Ihre
Gesundheit und das Gerät durch frei liegende Teile. Lassen Sie
Reparaturarbeiten nur von qualifizierten Reparaturfachleuten
durchführen, insbesondere wenn folgende Umstände vorliegen:
• Wenn das Netzkabel oder der AC/DC-Adapter beschädigt oder ze rsch l is sen sind.
• Wenn der Computer Regen ausgesetzt war oder mit Flüssigkeiten in
Berührung gekommen ist.
• Wenn der Computer unter Beachtung der Bedienungsanweisungen nicht
korrekt arbeitet.
• Wenn der Computer heruntergefallen ist oder beschädigt wurde (berühren Sie nicht die giftige Flüssigkeit des LCD-Bildschirms).
• Wenn ein ungewöhnlicher Geruch, Hitze oder Rauch aus dem Computer
entweicht.
Sicherheitsinformationen
• Verwenden Sie nur einen AC/DC-Adapter, der für die Verwendung mit
diesem Computer zugelassen ist.
• Verwenden Sie nur das Netzkabel und die Akkus, die in diesem Benutzerhandbuch spezifiziert sind
Sie können explodieren. Richten Sie sich nach den regional gültigen Entsorgungsvorschriften.
• Verwenden Sie den Akku nicht mehr, wenn er heruntergefallen ist oder in
anderer Weise beschädigt (z.B. verzogen) ist. Auch wenn der Computer
mit dem beschädigten Akku zu funktionieren schein, können dadurch
Stromkreise beschädigt werden, die schließlich einen Brand verursachen
können.
• Achten Sie darauf, dass Ihr Computer ausgeschaltet ist, wenn Sie es fur
den Transport z.B. wahrend einer Reise in eine Tasche einpakken.
• Stellen Sie vor dem Reinigen des Computers sicher, dass er von allen
externen Stromquellen, Peripheriegeräten und Kabeln getrennt ist.
• Reinigen Sie den Computer mit einem weichen, sauberen Tuch. Tragen
Sie das Reinigungsmittel nicht direkt auf den Computer auf. Verwenden
Sie keine flüchtigen Reinigungsmittel (Petroleumdestillate) oder Scheuermittel zum Reinigen des Computers.
• Versuchen Sie nicht, Akkus zu reparieren. Lassen Sie die Akkupacks
durch den Servicevertreter oder qualifiziertes Fachpersonal reparieren
oder austauschen.
• Beachten Sie, dass das Logo bei den Computern, die über ein galvanisch
beschichtetes LCD-Logo verfügen, von einer Schutzfolie bedeckt ist.
Durch die natürliche Abnutzung kann diese Schutzfolie beschädigt werden oder abgehen und die scharfen Kanten des frei liegenden Logos
freigeben. Seien Sie in solch einem Fall vorsichtig bei der Handhabung
des Computers, und vermeiden Sie es, das herausstehende beschichtete
LCD-Logo zu berühren. Legen Sie keine Gegenstände in die Tragetasche, da diese während des Transports gegen den Computer drücken
können. Wenden Sie sich in einem solchen Fall von Abnutzung an Ihr
Service Center.
. Entsorgen Sie die Akkus nicht in Feuer.
24
Polymer Akku Sicherheitshinweise
Entsorgen der Akkus/ Batterien & Achtung
Das von Ihnen gekaufte Produkt enthält einen aufladbaren
Akku. Dier Akku ist wiederverwertbar. Nach verschiedenen nationalen und regionalen Getzgebungen kann es verboten in,
einen nicht mehr gebrauchsfähigen Akku in den normalen
Hausmüll zu werfen. Informieren Sie sich bei Ihrem regionalen
Entsorgungsunternehmen über Recycling-Möglichkeiten oder
korrekte Entsorgung.
Wenn ein falscher Akku eingesetzt wird, besteht Explosionsgefahr. Tauschen Sie den Akku nur durch den gleichen oder einen
baugleichen Typ aus, der vom Hersteller empfohlen wird. Entsorgen Sie den verbrauchten Akku entsprechend der Anweisungen des Herstellers.
Beachten Sie die folgenden Hinweise, die sich speziell auf Polymer Akkus beziehen. Diese Hinweise haben zudem Vorrang
gegenüber den Allgemeinen Akku Sicherheitshinweisen.
• Polymer Akkus können sich etwas ausdehnen oder anschwellen. Dies ist
Teil des Sicherheitsmechanismus des Akkus und kein Anlass zur Sorge.
• Seien Sie vernünftig im Umgang mit Polymer Akkus. Verwenden Sie
keine Polymer Akkus in Umgebungen mit hohen Temperaturen und
lagern Sie keine ungenutzten Akkus über längere Zeiträume.
Deutsch
25
Schnellstart
Abb. 1 - Öffnen des Dekkels/LCD/Computers mit
angeschlossenem AC/DC-Adapter
Herunterfahren
Bitte beachten Sie, daß der Computer
immer mit dem Befehl Herunterfah-
ren in Windows (siehe unten) herun-
tergefahren werden muß. Dadurch
werden Festplatten- bzw. Systemprobleme vermieden.
1. Klicken Sie auf das Startmenü-Symbol .
2. Klicken Sie auf den Eintrag Ein/Aus
.
3. Wählen Sie aus dem Menü die Option
Herunterfahren.
130°
1. Entfernen Sie das gesamte Verpackungsmaterial.
2. Legen Sie den Computer auf eine stabile Unterlage.
3. Setzen Sie den Akku ein, und stellen Sie sicher, dass sie fest sitzt.
4. Schließen Sie alle Peripheriegeräte, die Sie mit dem Computer verwenden
wollen (z. B. Tastatur und Maus), an die entsprechenden Schnittstellen an.
5. Gehen Sie bei der erstmaligen Einrichtung des Computers wie folgt vor
(um den Computer während des Versands zu schützen, wird der Akku das
System nicht mit Strom versorgen, bis es das erste Mal mit dem AC/DCAdapter verbunden und wie folgt erstmalig eingerichtet worden ist):
• Bringen Sie das AC/DC-Adapterkabel an die DC-Eingangsbuchse an der
linken Seite des Computers an und verbinden Sie das AC-Netzkabel
anschließend mit einer Steckdose. Der Akku wird jetzt entsperrt sein.
6. Klappen Sie den Deckel/LCD vorsichtig mit einer Hand auf, und öffnen Sie
Deutsch
ihn auf einen angenehmen Sichtwinkel (jedoch nicht weiter als 130°). Mit der
anderen Hand halten Sie das Unterteil des Computers fest (siehe Abb. 1)
(Hinweis: Heben Sie den Computer niemals am Deckel/LCD hoch).
7. Drücken Sie auf den Netzschalter, um den Computer einzuschalten.
Systemsoftware
Möglicherweise wurde das Notebook bereits mit vorinstallierter Software ausgeliefert. Ist das nicht der Fall, oder wenn Sie das Notebook
für ein anderes System neu konfigurieren möchten, finden Sie dazu
eine Anleitung in diesem Handbuch zu Microsoft Windows 10.
26
Systemübersicht: Ansicht von vorne mit geöffnetem
7
Beachten Sie, dass der
Funktionsbereich des
Touchpads und der
Tasten innerhalb der rot
gepunkteten Linien liegt.
Abb. 2
Ansicht von vorne mit ge-
öffnetem LCD-Bildschirm
1. PC-Kamera
2. *LED der PC-Kamera
*Wenn die PC-Kamera verwendet wird, leuchtet die
LED.
3. Eingebautes Array-Mikrofon
4. LCD-Bildschirm
5. Netzschalter
6. Tastatur
7. Touchpad mit Tasten
Die Benutzung
drahtlos
angeschlossener
Geräte in
Flugzeugen
In der Regel ist die
Benutzung jeglicher
tragbarer elektronischer Funkgeräte in
Flugzeugen verboten.
Stellen Sie sicher,
dass die drahtlosen
Module durch Aktivieren des Flugzeugmodus ausgeschaltet
sind, wenn Sie sich an
Bord eines Flugzeugs
befinden.
5
7
6
4
213
3
LCD-Bildschirm
Deutsch
27
Loading...
