Clevo NH77DBQ, NH77DEQ service manual

NH77DBQ / NH77DEQ

Notebook Computer
NH77DBQ / NH77DEQ

Service Manual

Preface

Preface

I

Preface

Preface

Notice

The company reserves the right to revise this publication or to change its contents without notice. Information contained
herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven­dor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are
they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.

This publication and any accompanying software may not, in whole or in part, be reproduced, translated, transmitted or
reduced to any machine readable form without prior consent from the vendor, manufacturer or creators of this publica­tion, except for copies kept by the user for backup purposes.

Brand and product names mentioned in this publication may or may not be copyrights and/or registered trademarks of
their respective companies. They are mentioned for identification purposes only and are not intended as an endorsement
of that product or its manufacturer.

Version 1.0
March 2020

Trademarks

Intel and Intel Core are trademarks of Intel Corporation.
Windows® is a registered trademark of Microsoft Corporation.

Other brand and product names are trademarks and /or registered trademarks of their respective companies.

II

About this Manual

This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and
inspection of personal computers.

It is organized to allow you to look up basic information for servicing and/or upgrading components of the NH77DBQ
/ NH77DEQ series notebook PC.

The following information is included:

Chapter 1, Introduction, provides general information about the location of system elements and their specifications.
Chapter 2, Disassembly, provides step-by-step instructions for disassembling parts and subsystems and how to upgrade
elements of the system.

Preface

Appendix A, Part Lists
Appendix B, Schematic Diagrams

Preface

III

Preface

Preface

IMPORTANT SAFETY INSTRUCTIONS

Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per­sons when using any electrical equipment:

1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet
basement or near a swimming pool.

2. Avoid using a telephone (other than a cordless type) durin g an ele ctrical sto rm. There may be a remote risk of elec­trical shock from lightning.

3. Do not use the telephone to report a gas leak in the vicinity of the leak.

4. Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may
explode. Check with local codes for possible special disposal instructions.

5. This product is intended to be supplied by a Listed Power Unit as follows:

• AC Input of 100 - 240V, 50 - 60Hz, DC Output of 19.5V, 6.15A (120 Watts) minimum AC/DC Adapter.

FCC Statement

IV

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
This device may not cause harmful interference.
This device must accept any interference received, including interference that may cause undesired operation.

Instructions for Care and Operation

The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions:

1. Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged.

Preface

Do not expose the computer
to any shock or vibration.

Do not place it on an unstable
surface.

Do not place anything heavy
on the computer.

2. Keep it dry, and don’t overheat it. Keep the computer and power supply away from any kind of heating element. This
is an electrical appliance. If water or any other liquid gets into it, the co mputer could be badly damaged.

Do not expose it to excessive
heat or direct sunlight.

Do not leave it in a place
where foreign matter or mois­ture may affect the system.

Don’t use or store the com­puter in a humid environment.

Do not place the computer on
any surface which will block
the vents.

3. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save
your work. Remember to periodically save your data as data may be lost if the battery is depleted.

Do not turn off the power
until you properly shut down
all programs.

Do not turn off any peripheral
devices when the computer is
on.

Do not disassemble the com­puter by yourself.

Perform routine maintenance
on your computer.

Preface

V

Preface



Power Safety

Warning

Before you undertake
any upgrade proce­dures, make sure that
you have turned off the
power, and discon­nected all peripherals
and cables (including
telephone lines and
power cord). It is advis­able to also remove
your battery in order to
prevent accidentally
turning the machine
on.

4. Avoid interference. Keep the computer away from high capacity transformers, electric moto rs, and other strong mag-
netic fields. These can hinder proper performance and damage your data.

5. Take care when using peripheral de vices.

Preface

VI

Use only approved brands of
peripherals.

Unplug the power cord befor e
attaching peripheral devices.

Power Safety

The computer has specific power requirements:

• Only use a power adapter approved for use with this computer.

• Your AC adapter may be designed for international travel but it still requ ires a steady, uninterrupted power supply. If you are
unsure of your local power specifications, consult your service representative or local power company.

• The power adapter may have either a 2-prong or a 3-prong grounded plug. The third prong is an important safety feature; do
not defeat its purpose. If you do not have access to a compatible outlet, have a qualified electrician install one.

• When you want to unplug the power cord, be sure to disconn ect it by the plug head, not by its wire.

• Make sure the socket and any extension cord(s) you use can support the total current load of all the connected devices.

• Before cleaning the computer, make sure it is disconnected from any external power supplies.

Do not plug in the power
cord if you are wet.

Do not use the power cord if
it is broken.

Do not place heavy objects
on the power cord.

Battery Precautions



Battery Disposal

The product that you have purchased contains a rechargeable battery. The battery is recyclable. At the end of its useful life, under var­ious state and local laws, it may be illegal to dispose of this battery into the municipal waste stream. Check with your local solid waste
officials for details in your area for recycling options or proper disposal.

Caution

Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer.
Discard used battery according to the manufacturer’s instructions.

Battery Level

Click the battery icon in the taskbar to see the current battery level and charge status. A battery that drops below a level of 10%
will not allow the computer to boot up. Make sure that any battery that drops below 10% is recharged within one week.

• Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer.

• Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the
computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.

• Recharge the batteries using the notebook’s system. Incorrect recharging may make the battery explode.

• Do not try to repair a battery pack. Refer any battery pack repair or replacement to your service representative or qualified service
personnel.

• Keep children away from, and promptly dispose of a damaged battery. Always dispose of batteries carefully. Batteries may explode
or leak if exposed to fire, or improperly handled or discarded.

• Keep the battery away from metal appliances.

• Affix tape to the battery contacts before disposing of the battery.

• Do not touch the battery contacts with your hands or metal objects.

Battery Guidelines

The following can also apply to any backup batteries you may have.

• If you do not use the battery for an extended period, then remove the battery from the computer for storage.

• Before removing the battery for storage charge it to 60% - 70%.

• Check stored batteries at least every 3 months and charge them to 60% - 70%.

Preface

Preface

VII

Preface

Figure 1

Opening the Lid/LCD/

Computer with AC/DC

Adapter Plugged-In

130°



Shut Down

Note that you should always shut your computer down by
choosing the Shut down command in Windows (see be­low). This will help prevent hard disk or system problems.

Click the icon in the Start Screen and
choose Shut down from the menu.

Or

Right-click the Start button

at the bottom of the Start

Screen or the Desktop and choose Shut down or sign out
> Shut down from the context menu.

Related Documents

You may also need to consult the following manual for additional information:

User’s Manual on CD/DVD
This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro­gram. It also describes the installation and operation of the utility programs provided with the notebook PC.

System Startup

1. Remove all packing materials.

2. Place the computer on a stable surface.

3. Insert the battery and make sure it is locked in position.

4. Securely attach any peripherals you want to use with the
computer (e.g. keyboard and mouse) to their ports.

5. When first setting up the computer use the follow-
ing procedure (as to safeguard the computer during
shipping, the battery will be locked to not power the sys-

Preface

tem until first connected to the AC/DC adapter and ini­tially set up as below):

• Attach the AC/DC adapter cord to the DC-In jack on the rear
of the computer , then plu g the AC power cord into an outle t,
and connect the AC power cord to the AC/DC adapter. The
battery will now be unlocked.

6. Use one hand to raise the
angle
illustrated in Figure 1) to support the base of the computer
(Note: Never lift the computer by the lid/LCD).

7. Press the power button to turn the comp ut er “on ”.

lid/LCD to a comfortable viewing

(do not exceed 130 degrees); use the other hand (as

VIII

Contents

Preface

Introduction ..............................................1-1

Overview ......................................................................................... 1-1

Specifications ..................................................................................1-2

External Locator - Top View with LCD Panel Open ......................1-4

External Locator - Front & Right Side Views .................................1-5

External Locator - Left Side & Rear View .....................................1-6

External Locator - Bottom View .....................................................1-7

Mainboard Overview - Top (Key Parts) .........................................1-8

Mainboard Overview - Bottom (Key Parts) ....................................1-9

Mainboard Overview - Top (Connectors) .....................................1-10

Mainboard Overview - Bottom (Connectors) ...............................1-11

Disassembly ...............................................2-1

Overview ......................................................................................... 2-1

Maintenance Tools ..........................................................................2-2

Connections .....................................................................................2-2

Maintenance Precautions .................................................................2-3

Disassembly Steps ...........................................................................2-4

Removing the Battery ......................................................................2-5

Removing the Keyboard ..................................................................2-6

Removing the Hard Disk Drive .......................................................2-7

Removing the System Memory (RAM) ..........................................2-9

Removing the M.2 SSD Module ...................................................2-10

Removing the Wireless LAN Module ...........................................2-11

Wireless LAN, Combo Module Cables .........................................2-12

Removing the CCD .......................................................................2-13

Part Lists ..................................................A-1

Part List Illustration Location ........................................................A-2

Top .................................................................................................A-3

Bottom ............................................................................................ A-4

Main Board ................................................................................... A-5

HDD .............................................................................................. A-6

LCD ............................................................................................... A-7

Schematic Diagrams.................................B-1

System Block Diagram ...................................................................B-2

Processor 1/6 ...................................................................................B-3

Processor 2/6 ...................................................................................B-4

Processor 3/6 ...................................................................................B-5

Processor 4/6 ...................................................................................B-6

Processor 5/6 ...................................................................................B-7

Processor 6/6 ...................................................................................B-8

DDR4 CHA SO-DIMM ..................................................................B-9

DDR4 CHB SO-DIMM ................................................................B-10

VGA PCI Express .........................................................................B-11

GPU Frame Buffer A/B ................................................................B-12

Frame Buffer A .............................................................................B-13

Frame Buffer A .............................................................................B-14

Frame Buffer B .............................................................................B-15

Frame Buffer B .............................................................................B-16

GPU Frame Buffer C/D ................................................................B-17

Frame Buffer C .............................................................................B-18

Frame Buffer C .............................................................................B-19

GPU Decoupling 1 ........................................................................B-20

GPU Decoupling 2 ........................................................................B-21

Straps and XTAL ..........................................................................B-22

IFP I/O Interface ...........................................................................B-23

Misc - GPIO, I2C and ROM .........................................................B-24

NVIDIA Power Sequence .............................................................B-25

GPU NVVDD, FBVDDQ ............................................................B-26

GPU GND .....................................................................................B-27

Preface

IX

Preface

mDP ..............................................................................................B-28

Panel, Inverter .............................................................................. B-29

HDMI ........................................................................................... B-30

PCH 1/9 ........................................................................................ B-31

PCH 2/9 ........................................................................................ B-32

PCH 3/9 ........................................................................................ B-33

PCH 4/9 ........................................................................................ B-34

PCH 5/9 ........................................................................................ B-35

PCH 6/9 ........................................................................................ B-36

PCH 7/9 ........................................................................................ B-37

PCH 8/9 ........................................................................................ B-38

PCH 9/9 ........................................................................................ B-39

M.2 Card .......................................................................................B-40

M.2 WLAN+BT, PCIE 4X SSD .................................................. B-41

USB Charger ................................................................................ B-42

Card Reader / LAN RTL8411B ...................................................B-43

Preface

HDD, Click TP, Audio, Hall Con. ............................................... B-44

LED, CCD, TPM, Power SW Con. ..............................................B-45

KBC-ITE IT5570 ......................................................................... B-46

RGB KB ....................................................................................... B-47

5V, 5VS, 3.3V, 3.3VS .................................................................. B-48

VDD1.05V, VCCIO ..................................................................... B-49

VDD3, VDD5 ...............................................................................B-50

DDR 1.2V / 0.6VS, 2.5V .............................................................B-51

VCore Output Stage .....................................................................B-52

VCC_Core & VCCGT .................................................................B-53

1.05DX_VCCSTG/VCCSFR_OC ............................................... B-54

VCCGT & VCCSA Output Stage ................................................ B-55

AC_In, Charger ............................................................................ B-56

NVVDD1 .....................................................................................B-57

NVVDD2 .....................................................................................B-58

PEX_VDD ....................................................................................B-59

FBVDDQ ......................................................................................B-60

1V8_RUN/AON ...........................................................................B-61

Audio Board ..................................................................................B-62

NH50 PW Board ...........................................................................B-63

Hall Sensor Board .........................................................................B-64

Click Board ...................................................................................B-65

LED Board ....................................................................................B-66

NH70 PW Board ...........................................................................B-67

Power Sequence ............................................................................B-68

X

Chapter 1: Introduction

Overview

This manual covers the information you need to service or upgrade the NH77DBQ / NH77DEQ series notebook com­puter. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. In­formation about dri-vers (e.g. VGA & audio) is also found in the User’s Manual. The manual is shipped with the
computer.

Operating systems (e.g. Windows 10, etc.) have their own manuals as do application softwares (e.g. word processing and
database programs). If you have questions about those programs, you should consult those manuals.

The NH77DBQ / NH77DEQ series notebook is designed to be upgradeable. See Disassembly on page 2 - 1 for a detailed
description of the upgrade procedures for each specific component. Please take note of the warning and safety informa­tion indicated by the “” symbol.

The balance of this chapter reviews the computer’s technical specifications and features.

Introduction

1.Introduction

Overview 1 - 1

Introduction



Latest Specification Information

The specifications listed here are correct at the
time of sending them to the press. Certain items
(particularly processor types/speeds) may be
changed, delayed or updated due to the manu­facturer's release schedule. Check with your
service center for more details.



CPU

The CPU is not a user serviceable part. Ac­cessing the CPU in any way may violate your
warranty.

Specifications

1.Introduction

Processor Options

Intel® Core™ i7 Processor

i7-10750H (2.60GHz)

12MB Smart Cache, 14nm, DDR4-2933MHz, TDP 45W
Intel® Core™ i5 Processor
i5-10300H (2.50GHz)

8MB Smart Cache, 14nm, DDR4-2933MHz, TDP 45W

Core Logic

Mobile Intel® HM470 Express Chipset

BIOS

128Mb SPI Flash ROM
INSYDE BIOS

Memory

Dual Channel DDR4
Two 260 Pin SO-DIMM Sockets
Supporting up to 3200MHz DDR4 Memory
Memory Expandable up to 32GB

Compatible with 4GB, 8GB, 16GB Modules

(The real memory operating frequency depends on the FSB
of the processor.)

Storage

One changeable 2.5" 7.0mm (h) SATA (Serial) Hard Disk

Drive/Solid State Drive (SSD)
(Factory Option) One M.2 2280 SATA Solid State Drive

(SSD)
Or
(Factory Option) Two PCIe Gen3 x4 M.2 2280 SSDs sup-

porting RAID level 0/1

Audio

High Definition Audio Compliant Interface
Sound Blaster™ Cinema 6
Built-In Array Microphone
Two Speakers

LCD Options

17.3" (43.94cm), 16:9, FHD (1920x1080)

Video Adapter

Intel® Integrated GPU and NVIDIA® Discrete GPU
Supports Microsoft Hybrid Graphics

Intel Integrated GPU
Intel® UHD Graphics 630

Dynamic Frequency
Intel Dynamic Video Memory Technology
Microsoft DirectX®12 Compatible

NVIDIA® Discrete GPU
NVIDIA® GeForce GTX 1650
4GB GDDR6 Video RAM on board

Microsoft DirectX® 12 Compatible

NVIDIA® GeForce GTX 1650Ti
4GB GDDR6 Video RAM on board

Microsoft DirectX® 12 Compatible

(NH77DBQ)

(NH77DEQ)

Security

Security (Kensington® Type) Lock Slot
BIOS Password
Intel® PTT for Systems Without TPM Hardware
(Factory Option) TPM 2.0
(Factory Option) Fingerprint Sensor

1 - 2 Specifications

Keyboard

Full-size Multi-Color LED Keyboard (with Numeric Keypad)

Introduction

Pointing Device

Built-In Touchpad (with Microsoft PTP Multi Gesture & Scroll­ing Functionality)

Or
(Factory Option) Built-in Secure Pad (with Microsoft PTP

Multi Gesture & Scrolling Functionality)

Card Reader

Embedded Multi-In-1 Push-Push Card Reader

MMC (MultiMedia Card) / RS MMC
SD (Secure Digital) / Mini SD / SDHC/ SDXC

M.2 Slots

Slot 1 for Combo WLAN and Bluetooth Module
Slot 2 for SATA or PCIe Gen3 x4 SSD
Slot 3 for PCIe Gen3 x4 SSD only

Interface

One USB 2.0 Port
One USB 3.2 Gen 1 Type-A Port
One USB 3.2 Gen 2 Type-A Port
One USB 3.2 Gen 2 Type-C Port
One Mini Display Port 1.4
One HDMI-Out Port
One Microphone-In Jack
One 2- In-1 Audio Jack (Headphone and Microphone)
One RJ-45 LAN Jack
One DC-In Jack

Communication

Built-In 10/100/1000Mb Base-TX Ethernet LAN

1.0M HD PC Camera Module

WLAN/ Bluetooth M.2 Modules:

(Factory Option) Intel® Dual Band Wireless-AC 9560 Wire­less LAN (802.11ac) + Bluetooth

(Factory Option) Intel® Dual Band Wireless-AC 9462 Wire­less LAN (802.11ac) + Bluetooth

(Factory Option) Intel® Dual Band Wi-Fi 6 AX200 Wireless
LAN (802.11ax) + Bluetooth

(Factory Option) Intel® Dual Band Wi-Fi 6 AX201 Wireless
LAN (802.11ax) + Bluetooth

Environmental Spec

Temperature

Operating: 5
Non-Operating: -20°C - 60°C

Relative Humidity

Operating: 20% - 80%
Non-Operating: 10% - 90%

°C - 35°C

Power

Removable 4 Cell Smart Lithium-Ion Battery Pack, 41WH
(Factory Option) Removable 4 Cell Smart Lithium-Ion Bat­tery Pack, 48.96WH

Full Range AC/DC Adapter
AC Input: 100 - 240V, 50 - 60Hz
DC Output: 19.5V, 6.15A (120W)

1.Introduction

Dimensions & Weight

395.9mm (w) * 266.6mm (d) * 25.9mm (h)

2.5kg (Barebone with 41WH Battery)

Specifications 1 - 3

Introduction

Figure 1

Top View

1. PC Camera

2. *PC Camera LED

*When the PC
camera is in use,
the LED will be
illuminated.

3. Built-In Array
Microphone

4. LCD

5. Power Button

6. Keyboard

7. To uchpad &

Buttons

8. Fingerprint Sensor

2 1

7

6

4

5

33

8

1.Introduction

External Locator - Top View with LCD Panel Open

1 - 4 External Locator - Top View with LCD Panel Open

External Locator - Front & Right Side Views

Figure 2

Front View

1. LED Indicators

Figure 3

Right Side View

1. USB 3.2 Gen 2
Type-A Port

2. USB 3.2 Gen 2
Type-C Port

3. Multi-in-1 Card
Reader

4. Vent

FRONT VIEW

1

RIGHT SIDE VIEW

1

2

4

3

Introduction

1.Introduction

External Locator - Front & Right Side Views 1 - 5

Introduction

Figure 4

Left Side View

1. Security Lock Slot

2. Vent

3. USB 3.2 Gen 1
Type-A Port

4. USB 2.0 Port

5. Microphone-In
Jack

6. 2-In-1 Audio Jack
(Headphone and
Microphone)

LEFT SIDE VIEW

1

2

3 4 5 6

Figure 5

Rear View

1. Vent

2. Mini Display Port

1.4

3. HDMI-Out Port

4. RJ-45 LAN Jack

5. DC-In Jack

REAR VIEW

1

2 3 4 5

1.Introduction

External Locator - Left Side & Rear View

/

1 - 6 External Locator - Left Side & Rear View

External Locator - Bottom View



Overheating

To prevent your com­puter from overhea­ting, make sure no­thing blocks any vent
while the computer is
in use.

2

1

3

2

3

2

2

2

Figure 6

Bottom View

1. Battery

2. Vent

3. Speakers

Introduction

1.Introduction

External Locator - Bottom View 1 - 7

Introduction

Figure 7

Mainboard Top

Key Parts

1. KBC-ITE IT5570

1

1.Introduction

Mainboard Overview - Top (Key Parts)

1 - 8 Mainboard Overview - Top (Key Parts)

Mainboard Overview - Bottom (Key Parts)

1

2

3

4

5

6

7

Figure 8

Mainboard Bottom

Key Parts

1. Mini-Card
Connector (WLAN
Module)

2. PCH

3. GPU

4. CPU

5. Memory Slots
DDR4 SO-DIMM

6. M.2 Card
Connector (SATA/
PCIE SSD)

7. M.2 Card
Connector (PCIE
SSD only)

Introduction

1.Introduction

Mainboard Overview - Bottom (Key Parts) 1 - 9

Introduction

Figure 9

Mainboard Top

Connectors

1. USB Connector

2. Keyboard Cable
Connector

3. KB LED
Connector

4. Multi-in-1 Card
Reader

5. Mini Display Port

6. USB 3.2 Gen 2
Type-A Port

10

6

1

2

3

5

4

1.Introduction

Mainboard Overview - Top (Connectors)

1 - 10 Mainboard Overview - Top (Connectors)

Mainboard Overview - Bottom (Connectors)

Figure 10

Mainboard Bottom

Connectors

1. Fan Connector

2. HDD Connector

3. Speaker Connector

4. LED Connector

5. Touchpad
Connector

6. LCD Connector

7. Battery Connector

8. DC-In Jack

9. RJ-45 LAN Jack

10.HDMI-Out Port

11. Mini Display Port

1

2

5

3

4

1

6

7

8

9

1011

Introduction

1.Introduction

Mainboard Overview - Bottom (Connectors) 1 - 11

1.Introduction

Introduction

1 - 12

Chapter 2: Disassembly



Information



Warning

Overview

This chapter provides step-by-step instructions for disassembling the NH77DBQ / NH77DEQ series notebook’s parts
and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated).

We suggest you completely review any procedure before you take the computer apart.

Disassembly

Procedures such as upgrading/replacing the RAM, optical device and hard disk are included in the User’s Manual but are
repeated here for your convenience.

To make the disassembly process easier each section may have a box in the page margin. Information contained under
the figure # will give a synopsis of the sequence of procedures involved in the disassembly procedure. A box with a 
lists the relevant parts you will have after the disassembly process is complete. Note: The parts listed will be for the dis­assembly procedure listed ONLY, and not any previous disassembly step(s) required. Refer to the part list for the previ­ous disassembly procedure. The amount of screws you should be left with will be listed here also.

A box with a  will also provide any possible helpful information. A box with a  contains warnings.

An example of these types of boxes are shown in the sidebar.

2.Disassembly

Overview 2 - 1

Disassembly

2.Disassembly

NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the
battery is removed too).

Maintenance Tools

The following tools are recommended when working on the notebook PC:

• M3 Philips-head screwdriver

• M2.5 Philips-head screwdriver (magnetized)

• M2 Philips-head screwdriver

• Small flat-head screwdriver

• Pair of needle-nose pliers

• Anti-static wrist-strap

Connections

Connections within the computer are one of four types:

Locking collar sockets for ribbon connectors To release these connectors, use a small flat-head screwdriver to

gently pry the locking collar away from its base. When replac­ing the connection, make sure the connector is oriented in the
same way. The pin1 side is usually not indicated.

2 - 2 Overview

Pressure sockets for multi-wire connectors To release this connector type, grasp it at its head and gently

rock it from side to side as you pull it out. Do not pull on the
wires themselves. When replacing the connection, do not try to
force it. The socket only fits one way.

Pressure sockets for ribbon connectors To release these connectors, use a small pair of needle-nose pli-

ers to gently lift the connector away from its socket. When re­placing the connection, make sure the connector is oriented in
the same way. The pin1 side is usually not indicated.

Board-to-board or multi-pin sockets To separate the boards, gently rock them from side to side as

you pull them apart. If the connection is very tight, use a small
flat-head screwdriver - use just enough force to start.

Maintenance Precautions



Power Safety

Warning

Before you undertake
any upgrade proce­dures, make sure that
you have turned off the
power, and discon­nected all peripherals
and cables (including
telephone lines and
power cord). It is advis­able to also remove
your battery in order to
prevent accidentally
turning the machine
on.

The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a removal and/or
replacement job, take the following precautions:

1. Don't drop it. Perform your repairs and/o r upgrades on a st able surface. If the computer falls, the case and other compo nents
could be damaged.

2. Don't overheat it. Note the proximity of any heating elements. Keep the computer ou t of direct sunlight.

3. Avoid interference. Note the proximity of any high capacity transformers, electric motors, and other strong magnetic fields.
These can hinder proper performance and damage components and/or data. You should also monitor the position of magnet­ized tools (i.e. screwdrivers).

4. Keep it dry. This is an electrical appliance. If water or any other liquid gets into it, the computer could be badly damaged.

5. Be careful with power. Avoid accidental shocks, discharges or explosions.

•Before removing or servicing any part from the com pute r, turn the computer off and detach any power supplies.

•When you want to unplug the power cord or any cable/wire, be sure to disconnect it by the plug head. Do not pull on the wire.

6. Peripherals – Turn off and detach any peripherals.

7. Beware of static discharge. ICs, such as the CPU and main support chips, are vu lnerable to static electricity. Before han­dling any part in the computer, discharge any static electricity inside the computer. When handlin g a printed circuit board, do
not use gloves or other materials which allow static electricity buildup. We suggest that you use an anti-static wrist strap
instead.

8. Beware of corrosion. As you perform your job, avoid touching any connector leads. Even the cleanest hands produce oils
which can attract corrosive elements.

9. Keep your work environment clean. Tobacco smoke, dust or other air-born particulate matter is often attr acted to charged
surfaces, reducing performance.

10. Keep track of the components. When removing or replacing any part, be careful not to leave small parts, such as screws,
loose inside the computer.

Cleaning

Do not apply cleaner directly to the computer, use a soft clean cloth.
Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer.
(For Computer Models Supplied with Light Blue Cleaning Cloth) Some computer models in this series come supplied with a
light blue cleaning cloth. To clean the computer case with this cloth follow the instructions below.

• Power off the computer and peripherals.

• Disconnect the AC/DC adapter from the computer.

• Use a little water to dampen the cloth slightly.

• Clean the computer case with the cloth.

• Dry the computer with a dry cloth, or allow it time to dry before turning on.

• Reconnect the AC/DC adapter and turn the computer on.

Disassembly

2.Disassembly

Overview 2 - 3

Disassembly

Disassembly Steps

The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM
THE DISASSEMBLY STEPS IN THE ORDER INDICATED.

2.Disassembly

To remove the Battery:

1. Remove the battery page 2 - 5

To remove the Keyboard:

1. Remove the keyboard page 2 - 6

To remove the HDD:

1. Remove the battery page 2 - 5

2. Remove the HDD page 2 - 7

To remove the System Memory:

1. Remove the battery page 2 - 5

2. Remove the HDD page 2 - 7

3. Remove the system memory page 2 - 9

To remove the M.2 SSD:

1. Remove the battery page 2 - 5

2. Remove the HDD page 2 - 7

3. Remove the SSD page 2 - 10

To remove the Wireless LAN Module:

1. Remove the battery page 2 - 5

2. Remove the HDD page 2 - 7

3. Remove the WLAN page 2 - 11

To remove the CCD Module:

1. Remove the battery page 2 - 5

2. Remove the HDD page 2 - 7

3. Remove the CCD module page 2 - 13

2 - 4 Disassembly Steps

Removing the Battery

122

3

Figure 1

Battery Removal

a. Slide the latch in the

direction of the arrow.
and slide the latch in

the direction of the arrow.
b. Lift the battery.
c. Remove the battery.

1

2

1

a.

b.

3

c.

3

2



3. Battery

1. Turn the computer off, and turn it over.

2. Slide the latch in the direction of the arrow (Figure 1a).

3. Slide the latch in the direction of the arrow.

4. While holding the latch , lift the battery (Figure 1b) out of the compartment (Figure 1c

Disassembly

).

2.Disassembly

Removing the Battery 2 - 5

Disassembly

123456778

6

a. b.

1

2

c.

6

7

8

6

3

4

8

5

7



4. Eject Stick

6. Keyboard

•2 Screws

Figure 2

Keyboard Removal

a. Remove the screws from

the bottom of the compu­ter and then eject the
keyboard using a special
eject stick to push the
keyboard out while re­leasing the keyboard as
shown.

b. Lift the keyboard up and

disconnect the keyboard
ribbon cable from the
locking collar socket.

c. Remove the keyboard.



Re-inserting the Key-

board

When re-inserting the
keyboard firstly , align the
keyboard tabs at the bot­tom of the keyboard with
the slots in the case.

Removing the Keyboard

1. Turn off the computer, turn it over.

2. Remove screws

3. Open it up with the LCD on a flat surface before pressing at point
cial eject stick to do this) while releasing the keyboard in the direction of the arrow

4. Carefully lift the keyboard
board ribbon cable from the locking collar socket by using a flat-head screwdriver to pry the locking collar pins

away from the base (Figure 2b).

5. Carefully lift the keyboard off the computer (Figure 2c).

2.Disassembly

- from the bottom of the computer.

up, being careful not to bend the keyboard ribbon cable . Disconnect the key-

to release the keyboard module (use the spe-

as shown (Figure 2a).

2 - 6 Removing the Keyboard

Removing the Hard Disk Drive

612165

617181920

a.

17

20

c.

b.

17

18

19

5

6

2

1

3

4

5

13

6

7

8

9

11

12

14

15

10

16

Figure 3

HDD Assembly

Removal

a. Remove the SD card

cover and screws.

b. Remove the bottom

case.

c. Locate the HDD.



17.Bottom Case

•15 Screws

The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 7mm
(h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in
Chapter 4 of the User’s Manual) when setting up a new hard disk.

Hard Disk Disassembly Process

1. Turn off the computer, and remove the battery (page 2 - 5).

2. Remove the SD card cover and screws - . Note that screws & should be remove at a 30 degree
angle as shown (Figure 3a).

3. Open it up with the LCD on a flat surface, release the bottom case

).

3b

4. The HDD will be visible at point on the mainboard (Figure 3c

at points and and remove it (Figure

).

Disassembly

2.Disassembly

Removing the Hard Disk Drive 2 - 7

Disassembly

21

2223242526

27

28

d.

e.

f.

23

28



HDD System Warning

New HDD’s are blank. Before you begin
make sure:

You have backed up any data you want
to keep from your old HDD.

You have all the CD-ROMs and FDDs
required to install your operating system
and programs.

If you have access to the internet, down­load the latest application and hardware
driver updates for the operating system
you plan to install. Copy these to a re­movable medium.

g.

21

24

27

25

26

22



23.HDD Assembly

27.Bracket

28.HDD

•3 Screws

Figure 4

HDD Assembly

Removal (cont’d.)

d. Remove the screws.
e. Slightly lift and pull the

HDD in the direction of
the arrow.

f. Lift the HDD assembly

out of the bay.

g. Remove the screws and

bracket from the HDD.

5. Remove the screw from the HDD assembly (Figure 4d).

6. Slightly lift and pull up the tab out to release the hard disk assembly

(Figure 4e).

7. Lift the hard disk assembly out of the bay (Figure 4f).

8. Remove screws - and bracket from the hard disk (Figure 4g).

9. Reverse the process to install a new hard disk (make sure to properly press to seal all sides of the bottom
case especially near the vent area and do not forget to replace the screws).

2.Disassembly

2 - 8 Removing the Hard Disk Drive

Removing the System Memory (RAM)

123

4

b. c.

2 3

1

a.

4



4. RAM Module

Figure 5

RAM Module

Removal

a. The RAM modules

will be visible at point

on the main-

board.

b. Pull the release lat-

ches.

c. Remove the module.



Contact Warning

Be careful not to touch
the metal pins on the
module’s connecting
edge. Even the clean­est hands have oils
which can attract parti­cles, and degrade the
module’s performance.

1

The computer has two memory sockets for 260 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting
DDR4 up to 3200 MHz. The main memory can be expanded up to 32GB. The total memory size is automatically detected
by the POST routine once you turn on your computer.

Memory Upgrade Process

1. Turn off the computer, turn it over, remove the battery (page 2 - 5).

2. The RAM modules will be visible at point

3. Gently pull the two release latches ( & ) on the sides of the memory socket in the direction indicated by the

4. Pull the latches to release the second module if necessary.

5. Insert a new module (for single module only - make sure to install it in the top slot “J_DIMMB_1” as shown in Fig-

6. The module will only fit one way as defined by its pin alignment. Make sure the module is seated as far into the slot

7. Press the module in and down towards the mainboard until the slot levers click into place to secure the module.

8. Replace the bottom cover and the screws

9. Restart the computer to allow the BIOS to register the new memory configuration as it starts up.

on the mainboard (Figure 5a).

arrows (Figure 5b).

ure 5c) by holding it at about a 30° angle and fit the connectors firmly into the memory slot.

as it will go. DO NOT FORCE IT; it should fit without much pressure.

The RAM module will pop-up (Figure 5c), and you can then remove it.

(see page 2 - 7).

Disassembly

2.Disassembly

Removing the System Memory (RAM) 2 - 9

Disassembly

1

2

3

b.

a.

2

1
1

2

c.

3

3

3

SATA/PCIE SSD

PCIE SSD only



3.M2 SSD Module

•1 Screw

Figure 6

M.2 SSD Module

Removal

a. Locate the M.2 SSD.
b. Remove the screw.
c. The M.2 SSD module

will pop up.

Removing the M.2 SSD Module

M.2 SSD Module Removal Procedure

1. Turn off the computer, turn it over, remove the battery (page 2 - 5).

2. The M.2 SSD module will be visible at point on the mainboard (Figure 6a).

3. Remove the screw

4. The M.2 SSD module (Figure 6c) will pop-up, and you can remove it from the computer.

(Figure 6b)

2.Disassembly

2 - 10 Removing the M.2 SSD Module

Removing the Wireless LAN Module

123

4

5

b.

c.

a.

2
3

5

1

5

4



5.Wireless LAN Module

•1 Screw

Figure 7

Wireless LAN

Module Removal

a. Locate the WLAN.
b. Disconnect the cables

and remove the screw.

c. The WLAN module will

pop up.

Note: Make sure you
reconnect the antenna
cable to the “1 + 2”
socket (Figure 7b).

1. Turn off the computer, turn it over, remove the battery (page 2 - 5).

2. The Wireless LAN module will be visible at point on the mainboard (Figure 7a).

3. Carefully disconnect the cables & , and then remove the screw

4. The Wireless LAN module (Figure 7c) will pop-up, and you can remove it from the computer.

(Figure 7b)

Disassembly

2.Disassembly

Removing the Wireless LAN Module 2 - 11

Disassembly

Wireless LAN, Combo Module Cables

Note that the cables for connecting to the antennae on WLAN, WLAN & Bluetooth Combo modules are not labelled.
The cables/covers (each cable will have either a black or transparent cable cover) are color coded for identification as
outlined in the table below.

2.Disassembly

Module Type

WLAN/WLAN & Bluetooth
Combo

Antenna

Type

WL 1 Black Transparent
WL 2 Black White

Cable Color

Cable 1 is usually connected to antenna 1 on the module, and cable 2 to antenna 2.

Cable Cover

Type

2 - 12 Wireless LAN, Combo Module Cables

1

4

5

b.

a.

2

1

5

4

3



5. LCD Front Cover

Figure 8

CCD Removal

a. Carefully release the in-

ner frame of the LCD
panel at the points indi­cated by the arrows.

b. Remove the LCD front

cover.

Disassembly

Removing the CCD

1. Turn off the computer, turn it over to remove the battery (page 2 - 5).

2. Lay the computer down on a flat surface with the top case up forming a 90 degree angle.

3. Carefully run your fingers around the inner frame of the LCD panel to lift at points - as indicated by the
arrows (Figure 8a).

4. Remove the LCD front cover (Figure 8b).

2.Disassembly

Removing the CCD 2 - 13

6

7

8

d.

c.

8

6

7



8. CCD Module

Figure 9

CCD Removal

(cont’d)

c. Disconnect the cable

from the locking collar
socket.

d. Remove the CCD mod-

ule.

2.Disassembly

Disassembly

5. Disconnect the cable from the locking collar socket by using a flat-head screwdriver to pry the locking collar
pins

away from the base (Figure 9c).

6. Remove the CCD module (Figure 9d).

7. Reverse the process to install a new CCD module.

2 - 14 Removing the CCD

Appendix A:Part Lists

This appendix breaks down the NH77DBQ / NH77DEQ series notebook’s construction into a series of illustrations. The
component part numbers are indicated in the tables opposite the drawings.

Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure
to cross-check any relevant documentation.

Note: Some assemblies may have parts in common (especially screws). However, the part lists DO NOT indicate the
total number of duplicated parts used.

Note: Be sure to check any update notices. The parts shown in these illustrations are appropriate for the system at the
time of publication. Over the product life, some parts may be improved or re-configured, resulting in new part numbers.

A.Part Lists

A - 1

Table A - 1

Part List Illustration

Location

Part List Illustration Location

The following table indicates where to find the appropriate part list illustration.

Part

Top

page A - 3

A.Part Lists

Bottom
Main Board
HDD
LCD

page A - 4
page A - 5
page A - 6
page A - 7

A - 2

Top

Figure A - 1

Top

A.Part Lists

Top A - 3

A.Part Lists

Figure A - 2

Bottom

Bottom

A - 4 Bottom

Main Board

Figure A - 3

Main Board

A.Part Lists

Main Board A - 5

A.Part Lists

Figure A - 4

HDD

HDD

A - 6 HDD

LCD

Figure A - 5

LCD

A.Part Lists

LCD A - 7

A.Part Lists

A - 8

Appendix B: Schematic Diagrams

Table B - 1

SCHEMATIC

DIAGRAMS



Version Note

The schematic dia­grams in this chapter
are based upon ver­sion 6-7P-NH5D8-002.
If your mainboard (or
other boards) are a lat­er version, please
check with the Service
Center for updated di­agrams (if required).

This appendix has circuit diagrams of the NH77DBQ / NH77DEQ notebook’s PCB’s. The following table indicates
where to find the appropriate schematic diagram.

System Block Diagram - Page B - 2 NVIDIA Power Sequence - Page B - 25 5V, 5VS, 3.3V, 3.3VS - Page B - 48
Processor 1/6 - Page B - 3 GPU NVVDD, FBVDDQ - Page B - 26 VDD1.05V, VCCIO - Page B - 49
Processor 2/6 - Page B - 4 GPU GND - Page B - 27 VDD3, VDD5 - Page B - 50
Processor 3/6 - Page B - 5 mDP - Page B - 28 DDR 1.2V / 0.6VS, 2.5V - Page B - 51
Processor 4/6 - Page B - 6 Panel, Inverter - Page B - 29 VCore Output Stage - Page B - 52
Processor 5/6 - Page B - 7 HDMI - Page B - 30 VCC_Core & VCCGT - Page B - 53
Processor 6/6 - Page B - 8 PCH 1/9 - Page B - 31 1.05DX_ VCCSTG/VCCSFR_OC - Page B - 54
DDR4 CHA SO-DIMM - Page B - 9 PCH 2/9 - Page B - 32 VCCGT & VCCSA Output Stage - Page B - 55
DDR4 CHB SO-DIMM - Page B - 10 PCH 3/9 - Page B - 33 AC_In, Charger - Page B - 56
VGA PCI Express - Page B - 11 PCH 4/9 - Page B - 34 NVVDD1 - Page B - 57
GPU Frame Buffer A/B - Page B - 12 PCH 5/9 - Page B - 35 NVVDD2 - Page B - 58
Frame Buffer A - Page B - 13 PCH 6/9 - Page B - 36 PEX_VDD - Page B - 59
Frame Buffer A - Page B - 14 PCH 7/9 - Page B - 37 FBVDDQ - Page B - 60
Frame Buffer B - Page B - 15 PCH 8/9 - Page B - 38 1V8_RUN/AON - Page B - 61
Frame Buffer B - Page B - 16 PCH 9/9 - Page B - 39 Audio Board - Page B - 62
GPU Frame Buffer C/D - Page B - 17 M.2 Card - Page B - 40 NH50 PW Board - Page B - 63
Frame Buffer C - Page B - 18 M.2 WLAN+BT, PCIE 4X SSD - Page B - 41 Hall Sensor Board - Page B - 64
Frame Buffer C - Page B - 19 USB Charger - Page B - 42 Click Board - Page B - 65
GPU Decoupling 1 - Page B - 20 Card Reader / LAN RTL8411B - Page B - 43 LED Board - Page B - 66
GPU Decoupling 2 - Page B - 21 HDD, Click TP, Audio, Hall Con. - Page B - 44 NH70 PW Board - Page B - 67
Straps and XTAL - Page B - 22 LED, CCD, TPM, Power SW Con. - Page B - 45 Power Sequence - Page B - 68
IFP I/O Interface - Page B - 23 KBC-ITE IT5570 - Page B - 46
Misc - GPIO, I2C and ROM - Page B - 24 RGB KB - Page B - 47

Schematic Diagrams

Diagram - Page Diagram - Page Diagram - Page

B.Schematic Diagrams

B - 1

Schematic Diagrams

Sheet 1 of 67

System Block

Diagram

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

SHEET 49

GPU NVVDD

SPK-L & SPK-R

SATA

VDD1.05, VCCIO

SHEET 47

5V,3.3V,5VS,3.3VS

VDD3,VDD5

SHEET 48

PCIE PORT 15

(Optional charger)

6-71-NH5D4-D01

BOM:xxx

SHEET 65

NH50 LED BOARD

2VIA
3"~7"

NGFF M Key
PCIE 4X SSD

SHEET 39

PCIE
PORT
21,22,23,24

EC
SPI

SHEET 45

(USB3.1 PORT3)

SHEET 41

USB3.1 GEN2

USB2.0 PORT3

TYPE-C

USB3.1 GEN2

ANX7440

SHEET 68

ANX7411

<4.7"

3VIA
5"

3VIA
3" ~ 12"

<14"

SHEET 69

Tx 3VIA
Rx 2VIA

2.5"~8"

3VIA
3" ~ 12"

2 VIA:3"~8"
4 VIA:3"~9"

DP_E

1 vias <5"

PANEL Connector

SHEET 70

PER-KEY
IT8295

SHEET 28

SHEET 71

VCC_CORE & VCCGT

1.05DX_VCCSTG/

SHEET 53

6-71-NH5D2-D01

BOM:xxx

SHEET 64

NH50 CLICK BOARD

NHxxDC System Block Diagram (Comet lake)

PCIE PORT 14

TOUCH PAD

LPC

SMART
BATTERY

CARD READER

SO-DIMMB

SHEET 55

HP
OUT

SHEET 71

CLICK BOARD

2 vias 1" ~ 7"

PCIE

25x24mm
874 Ball FCBGA

480 Mbps

NGFF E Key
M.2 WLAN+BT

SHEET 2,3,4,5,6,7

DDR4

comet Lake-H

24 MHz

4VIA

2.5"~9"

MIC
IN

SHEET 8

SHEET 47

SHEET 9

128pins LQFP

SO-DIMMA

32.768KHz

EC SMBUS AZALIA LINK

0.1"~13

DDR4 DDR4

SYSTEM SMBUS

LAN

BIOS
SPI

SHEET 30

SATA HDD

SHEET 43

ITE 5570

2 vias 3"~7.5"

H Platform
Controller
Hub (CML-H)
HM470

INT. K/B

EC

Azalia Codec

SHEET 43

0.5"~11"

SHEET 42

USB2.0

SHEET 40

DMI*4

BGA1440
28x42mm

SHEET 41

32.768 KHz

USB3.1 GEN2

10 Gbps

REALTEK

CNVI

SHEET 30,31,32,33,34,35,36,37,38

SHEET 2

SATA I/II/III 6.0Gb/s

2133 MHz
DDR4 /1.2

CCD +D-Mic

SHEET 44

ALC293D

CML-H 62 45W

14*14*1.6mm

100 MHz

THERMAL
SENSOR

33 MHz

SHEET 45

SMART
FAN

SHEET 45

25
MHz

PCIE*8LANE

RTL8411B

USB2.0 PORT2

(USB3.0 PORT2)

USB3.0

SHEET 61

AUDIO BOARD

SHEET 42

SHEET 42

SOCKET

6IN1

RJ-45

USB2.0

USB2.0 PORT6

USB3.1 GEN2

(USB3.1 PORT1)

USB2.0 PORT8

USB2.0 PORT1

SATA III PORT4

Power: 1.05V.1.5V,

3.3V,VCORE(VR12.5)

2666 MHz
DDR4 / 1.2V

SLB9670VQ F/W 7.85

SHEET 44

TPM 2.0

AC-IN

SHEET 54

VCCSA

SHEET 48

3.3VA/VCCSFR_OC/VCCST

SHEET 55

AC_IN Charger

I2C

Nvidia
N18E-G0 -RAM SIZE 6GB DDR6

2228 Balls

SHEET 10,11,12,
13,14,15,16,17,18,19,20,21,22,23,24,25,26

nVIDIA

<10" (4 VIA)

Mini DP(iGPU)
PS8330

SHEET 27

<6.5" (3 VIA)

HDMI(dGPU)

SHEET 29

NGFF M Key
PCIE 4X SSD

SHEET 40

PCIE
PORT
9,10,11,12

TYPE-A

VDDQ(1.2V),VTT_MEM(0.6V)

6-71-NH55S-D01

BOM:xxx

NH55 POWER SWITCH BOARD

SHEET 50

6-71-NH5D8-D11

BOM:xxx

Redriver AUDIO BOARD

6-71-NH771-D02

BOM:xxx

HALL SENSOR,PW BOARD

SHEET 66

SHEET 73

SHEET 74

SHEET 56 57

VCCSFR_OC/1.8VA

SPI

VCCGT/VCORE Output stage

SHEET 51 52

6-71-NH5D0-D02

6-71-NH5D8-D01

6-71-NH5DS-D01

BOM: xxx

BOM:xxx

BOM:xxx

NHxxDC

SHEET 61

PHONE JACK x2;USB2.0 x1;USB3.0 x1

AUDIO BOARD

SHEET 2~60

MAIN BOARD (NH50)

6-7P-NH5D8-002

8IN1

NH50 POWER SWITCH BOARD

SHEET 62

GEN 3

USB2.0 PORT14

USB2.0

Title

Size Document Number Rev

Date: S heet

of

6-7P-NH5D8-002

D02

[01]BLOCK DIAGRAM

A3

174Tuesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: S heet

of

6-7P-NH5D8-002

D02

[01]BLOCK DIAGRAM

A3

174Tuesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: S heet

of

6-7P-NH5D8-002

D02

[01]BLOCK DIAGRAM

A3

174Tuesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

System Block Diagram

B.Schematic Diagrams

B - 2 System Block Diagram

Processor 1/6

Sheet 2 of 67

Processor 1/6

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

PLACE NEAR CPU

CPU HOLD

ŅŅŊġŕŐġŮŅő

ʼnŅŎŊġIJįĵţ

EDP to Panel
(support 4K Panel)

EDP

CLOSE TO CPUWidth = 12mil
Space = 25mil
lengh = 100mil(max)

CLOSE TO CPU

6-36-00180-250

VCCIO

3.3V

VCCIO

3.3V 24,28,41,43,47,48,50,51,54,57,58,59,68,69
VCCIO 6,48

DMI_IT_MR_0_DP31
DMI_IT_MR_0_DN31

DMI_IT_MR_1_DP31
DMI_IT_MR_1_DN31

DMI_IT_MR_2_DP31
DMI_IT_MR_2_DN31

DMI_IT_MR_3_DP31
DMI_IT_MR_3_DN31

PEG_RX#410

PEG_RX#310

PEG_RX#710

PEG_RX#610

PEG_RX#510

PEG_RX510

PEG_RX710

PEG_RX410

PEG_RX310

PEG_RX210

PEG_RX610

PEG_RX010

PEG_RX110

PEG_RX#210

PEG_RX#110

PEG_RX#010

DMI_MT_IR_0_DP 31
DMI_MT_IR_0_DN 31

DMI_MT_IR_1_DP 31
DMI_MT_IR_1_DN 31

DMI_MT_IR_2_DP 31
DMI_MT_IR_2_DN 31

DMI_MT_IR_3_DP 31
DMI_MT_IR_3_DN 31

PEG_TX#2 10

PEG_TX#3 10

PEG_TX#5 10

PEG_TX#0 10

PEG_TX#7 10

PEG_TX#6 10

PEG_TX#1 10

PEG_TX#4 10

PEG_TX3 10

PEG_TX6 10

PEG_TX0 10

PEG_TX7 10

PEG_TX4 10

PEG_TX5 10

PEG_TX1 10

PEG_TX2 10

THERM_VOLT 45

EDP_TXN_0 28

EDP_TXN_1 28

EDP_TXP_1 28

EDP_TXP_0 28

AUD_AZACPU_SCLK 33
AUD_AZACPU_SDO_R 33

AUD_AZACPU_SDI 33

EDP_AUXP 28
EDP_AUXN 28IGPU_AUX_CH_N27

IGPU_AUX_CH_P27

IGPU_LANE0P27
IGPU_LANE0N27

IGPU_LANE1N27

IGPU_LANE1P27

IGPU_LANE2P27
IGPU_LANE2N27

IGPU_LANE3N27

IGPU_LANE3P27

EDP_TXN_2 28

EDP_TXP_2 28

EDP_TXN_3 28

EDP_TXP_3 28

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[02] Processor 1/7-DMI/PEG/DISPLAY

A3

274Tuesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[02] Processor 1/7-DMI/PEG/DISPLAY

A3

274Tuesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[02] Processor 1/7-DMI/PEG/DISPLAY

A3

274Tuesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

R555 20_1%_04

C1013 0.22u_10V_X5R_04

C1010 0.22u_10V_X5R_04

C1005 0.22u_10V_X5R_04

C1002 0.22u_10V_X5R_04

C1004 0.22u_10V_X5R_04

3 OF 13

?

?

?

U37C

CML_H_IP_EXT/BGA

PEG_RXP_0

E25

PEG_RXN_0

D25

PEG_RXP_1

E24

PEG_RXN_1

F24

PEG_RXP_2

E23

PEG_RXN_2

D23

PEG_RXP_3

E22

PEG_RXN_3

F22

PEG_RXP_4

E21

PEG_RXN_4

D21

PEG_RXP_5

E20

PEG_RXN_5

F20

PEG_RXP_6

E19

PEG_RXN_6

D19

PEG_RXP_7

E18

PEG_RXN_7

F18

PEG_RXP_8

D17

PEG_RXN_8

E17

PEG_RXP_9

F16

PEG_RXN_9

E16

PEG_RXP_10

D15

PEG_RXN_10

E15

PEG_RXP_11

F14

PEG_RXN_11

E14

PEG_RXP_12

D13

PEG_RXN_12

E13

PEG_RXP_13

F12

PEG_RXN_13

E12

PEG_RXP_14

D11

PEG_RXN_14

E11

PEG_RXP_15

F10

PEG_RXN_15

E10

DMI_RXP_0

D8

DMI_RXN_0

E8

DMI_RXP_1

E6

DMI_RXN_1

F6

DMI_RXP_2

D5

DMI_RXN_2

E5

DMI_RXP_3

J8

DMI_RXN_3

J9

PEG_TXP_0

B25

PEG_TXN_0

A25

PEG_TXP_1

B24

PEG_TXN_1

C24

PEG_TXP_2

B23

PEG_TXN_2

A23

PEG_TXP_3

B22

PEG_TXN_3

C22

PEG_TXP_4

B21

PEG_TXN_4

A21

PEG_TXP_5

B20

PEG_TXN_5

C20

PEG_TXP_6

B19

PEG_TXN_6

A19

PEG_TXP_7

B18

PEG_TXN_7

C18

PEG_TXP_8

A17

PEG_TXN_8

B17

PEG_TXP_9

C16

PEG_TXN_9

B16

PEG_TXP_10

A15

PEG_TXN_10

B15

PEG_TXP_11

C14

PEG_TXN_11

B14

PEG_TXP_12

A13

PEG_TXN_12

B13

PEG_TXP_13

C12

PEG_TXN_13

B12

PEG_TXP_14

A11

PEG_TXN_14

B11

PEG_TXP_15

C10

PEG_TXN_15

B10

DMI_TXP_0

B8

DMI_TXN_0

A8

DMI_TXP_1

C6

DMI_TXN_1

B6

DMI_TXP_2

B5

DMI_TXN_2

A5

DMI_TXP_3

D4

DMI_TXN_3

B4

PEG_RCOMP

G2

C998 0.22u_10V_X5R_04

H25
H5_7D3_7

R213

24.9_1%_04

C1008 0.22u_10V_X5R_04

4 of 13

?

?

?

U37D

CML_H_IP_EXT/BGA

DDI1_TXP_0

K36

DDI1_TXN_0

K37

DDI1_TXP_1

J35

DDI1_TXN_1

J34

DDI1_TXP_2

H37

DDI1_TXN_2

H36

DDI1_TXP_3

J37

DDI1_TXN_3

J38

DDI1_AUXP

D27

DDI1_AUXN

E27

DDI2_TXP_0

H34

DDI2_TXN_0

H33

DDI2_TXP_1

F37

DDI2_TXN_1

G38

DDI2_TXP_2

F34

DDI2_TXN_2

F35

DDI2_TXP_3

E37

DDI2_TXN_3

E36

DDI2_AUXP

F26

DDI2_AUXN

E26

DDI3_TXP_0

C34

DDI3_TXN_0

D34

DDI3_TXP_1

B36

DDI3_TXN_1

B34

DDI3_TXP_2

F33

DDI3_TXN_2

E33

DDI3_TXP_3

C33

DDI3_TXN_3

B33

DDI3_AUXP

A27

DDI3_AUXN

B27

EDP_TXP_0

D29

EDP_TXN_0

E29

EDP_TXP_1

F28

EDP_TXN_1

E28

EDP_TXP_2

A29

EDP_TXN_2

B29

EDP_TXP_3

C28

EDP_TXN_3

B28

EDP_AUXP

C26

EDP_AUXN

B26

EDP_DISP_UTIL

A33

PROC_AUDIO_CLK

G27

DISP_RCOMP

D37

PROC_AUDIO_SDI

G25

PROC_AUDIO_SDO

G29

H18
H5_7D3_7

C1011 0.22u_10V_X5R_04

C1018 0.22u_10V_X5R_04

C994 0.22u_10V_X5R_04

C1017 0.22u_10V_X5R_04

C1012 0.22u_10V_X5R_04

R236
20K_1%_04

C993 0.22u_10V_X5R_04

H26
H5_7D3_7

R551 24.9_1%_04

C995 0.22u_10V_X5R_04

H17
H5_7D3_7

C1025 0.22u_10V_X5R_04

RT1
EWTF02-104F4F-N

1 2

C999 0.22u_10V_X5R_04

PEG_TX_0
PEG_TX#_0

PEG_TX_1
PEG_TX#_1

PEG_TX_2
PEG_TX#_2

PEG_TX_3
PEG_TX#_3

PEG_TX_4
PEG_TX#_4

PEG_TX_5
PEG_TX#_5

PEG_TX_6
PEG_TX#_6

PEG_TX_7
PEG_TX#_7

PEG_COMP

EDP_DISP_UTIL

EDP_RCOMP

PROC_AUDIO_SDO

Schematic Diagrams

B.Schematic Diagrams

Processor 1/6 B - 3

Schematic Diagrams

Sheet 3 of 67

Processor 2/6

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

CLOSE TO CPU

M_B_CKE0 9
M_B_CKE1 9

M_B_CS#0 9
M_B_CS#1 9

M_B_ODT0 9
M_B_ODT1 9

M_B_RAS# 9
M_B_WE# 9
M_B_CAS# 9

M_B_BA0 9
M_B_BA1 9
M_B_BG0 9

M_B_CLK_DDR0 9
M_B_CLK_DDR#0 9

M_B_CLK_DDR#1 9

M_B_CLK_DDR1 9

M_B_DQ[63:0]9M_A_DQ[63:0]8

M_A_CLK_DDR0 8
M_A_CLK_DDR#0 8

M_A_CLK_DDR#1 8

M_A_CLK_DDR1 8

M_A_CKE0 8
M_A_CKE1 8

M_A_CS#0 8
M_A_CS#1 8

M_A_ODT0 8
M_A_ODT1 8

M_A_RAS# 8
M_A_WE# 8
M_A_CAS# 8

M_A_DQS#[3:0] 8

M_A_DQS[7:4] 8

M_A_DQS[3:0] 8

M_A_DQS#[7:4] 8

M_A_A0 8
M_A_A1 8
M_A_A2 8
M_A_A3 8
M_A_A4 8
M_A_A5 8
M_A_A6 8
M_A_A7 8
M_A_A8 8
M_A_A9 8
M_A_A10 8
M_A_A11 8
M_A_A12 8
M_A_A13 8
M_A_BG1 8
M_A_ACT# 8

DDR0_A_PARITY 8
DDR0_A_ALERT# 8

M_B_A0 9
M_B_A1 9
M_B_A2 9
M_B_A3 9
M_B_A4 9
M_B_A5 9
M_B_A6 9
M_B_A7 9

M_B_A8 9
M_B_A9 9
M_B_A10 9
M_B_A11 9
M_B_A12 9
M_B_A13 9
M_B_BG1 9
M_B_ACT# 9

DDR1_B_PARITY 9
DDR1_B_ALERT# 9

M_B_DQS#[7:4] 9

M_B_DQS[7:4] 9

M_B_DQS#[3:0] 9

M_B_DQS[3:0] 9

DIMM_CA_CPU_VREF_A 8

DIMM_DQ_CPU_VREF_B 9

M_A_BA0 8
M_A_BA1 8
M_A_BG0 8

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[03] Processor 3/7-DDR4

A3

374Tuesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[03] Processor 3/7-DDR4

A3

374Tuesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[03] Processor 3/7-DDR4

A3

374Tuesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

R652 75_1%_04

1 OF 13

DDR CHANNEL A

?

?

?

U37A

CML_H_IP_EXT/BGA

DDR0_DQSN_7/DDR1_DQSN_5

L3

DDR0_DQSN_0/DDR0_DQSN_0

BR5

DDR0_DQ_9/DDR0_DQ_9

BL5

DDR0_DQ_13/DDR0_DQ_13

BK5

DDR0_DQ_17/DDR0_DQ_33

BG5

NC/DDR0_ECC_2

AY4

NC/DDR0_ALERT#

AU5

DDR0_CKN_0/DDR0_CKN_0

AG2

DDR0_CS#_0/DDR0_CS#_0

AD5

DDR0_CAB_1/DDR0_MA_15

AD1

DDR0_DQ_40/DDR1_DQ_8

V5

DDR0_DQ_61/DDR1_DQ_45

M2

DDR0_DQ_5/DDR0_DQ_5

BP6

DDR0_DQSP_2/DDR0_DQSP_4

BF3

NC/DDR0_ECC_3

AY5

DDR0_CKE_3/DDR0_CKE_3

AT5

DDR0_CKE_0/DDR0_CKE_0

AT1

NC/DDR0_CKN_2

AK3

DDR0_ODT_0/DDR0_ODT_0

AD3

NC/DDR0_CS#_2

AD2

DDR0_DQ_38/DDR1_DQ_6

AA2

DDR0_DQSN_5/DDR1_DQSN_1

U3

DDR0_DQ_52/DDR1_DQ_36

R5

DDR0_DQSP_7/DDR1_DQSP_5

M3

DDR0_DQ_1/DDR0_DQ_1

BT6

DDR0_DQSP_0/DDR0_DQSP_0

BP5

DDR0_DQ_31/DDR0_DQ_47

BC2

NC/DDR0_ECC_4

BA5

NC/DDR0_CKN_3

AL1

NC/DDR0_CS#_3

AE5

DDR0_DQ_34/DDR1_DQ_2

AA4

DDR0_DQ_55/DDR1_DQ_39

P1

DDR0_DQ_57/DDR1_DQ_41

M1

NC/DDR0_ECC_5

BA4

DDR0_DQSN_8/DDR0_DQSN_8

BA3

DDR0_CAA_6/DDR0_MA_12

AU4

DDR0_CAA_8/DDR0_ACT#

AU3

DDR0_CAA_4/DDR0_MA_7

AN1

NC/DDR0_CKP_2

AL3

DDR0_CAB_6/DDR0_BA_1

AH1

DDR0_CKP_0/DDR0_CKP_0

AG1

DDR0_DQSP_5/DDR1_DQSP_1

V3

DDR0_DQ_44/DDR1_DQ_12

V1

DDR0_DQ_48/DDR1_DQ_32

R2

DDR0_DQ_22/DDR0_DQ_38

BF1

DDR0_DQ_24/DDR0_DQ_40

BD2

NC/DDR0_ECC_6

AY1

DDR0_CAA_9/DDR0_BG_1

AU2

NC/DDR0_CKP_3

AL2

DDR0_CAB_2/DDR0_MA_14

AG4

DDR0_DQ_47/DDR1_DQ_15

U4

DDR0_DQ_11/DDR0_DQ_11

BM1

DDR0_DQ_8/DDR0_DQ_8

BL4

DDR0_DQ_14/DDR0_DQ_14

BK1

DDR0_DQSN_3/DDR0_DQSN_5

BD3

DDR0_DQ_27/DDR0_DQ_43

BC5

DDR0_DQSP_8/DDR0_DQSP_8

AY3

NC/DDR0_ECC_7

AY2

DDR0_CAA_1/DDR0_MA_9

AT4

DDR0_CS#_1/DDR0_CS#_1

AE2

DDR0_DQ_37/DDR1_DQ_5

AB4

DDR0_DQ_4/DDR0_DQ_4

BN5

DDR0_DQ_18/DDR0_DQ_34

BF4

DDR0_CAA_0/DDR0_MA_5

AP1

DDR0_CKN_1/DDR0_CKN_1

AK1

DDR0_DQ_62/DDR1_DQ_46

L5

DDR0_DQ_0/DDR0_DQ_0

BR6

DDR0_DQSN_1/DDR0_DQSN_1

BL3

DDR0_DQSP_3/DDR0_DQSP_5

BC3

DDR0_CKE_1/DDR0_CKE_1

AT2

NC/DDR0_MA_3

AP5

DDR0_CAA_7/DDR0_MA_11

AN2

DDR0_CAB_7/DDR0_MA_10

AH2

DDR0_DQ_33/DDR1_DQ_1

AB2

DDR0_DQ_50/DDR1_DQ_34

R4

DDR0_DQ_53/DDR1_DQ_37

P2

DDR0_CAA_5/DDR0_BG_0

AU1

NC/DDR0_MA_4

AP2

DDR0_CAB_9/DDR0_MA_0

AH3

NC/DDR0_ODT_1

AE4

DDR0_DQ_58/DDR1_DQ_42

L4

DDR0_DQ_7/DDR0_DQ_7

BN3

DDR0_DQSP_1/DDR0_DQSP_1

BK3

DDR0_DQ_20/DDR0_DQ_36

BG2

DDR0_DQ_23/DDR0_DQ_39

BF2

DDR0_CKP_1/DDR0_CKP_1

AK2

NC/DDR0_ODT_2

AE1

DDR0_DQ_45/DDR1_DQ_13

V4

DDR0_DQ_42/DDR1_DQ_10

U1

DDR0_DQ_49/DDR1_DQ_33

P5

DDR0_DQ_3/DDR0_DQ_3

BR3

DDR0_DQ_28/DDR0_DQ_44

BD5

DDR0_DQ_25/DDR0_DQ_41

BD1

DDR0_CAA_3/DDR0_MA_8

AN3

DDR0_CAB_3/DDR0_MA_16

AH4

DDR0_CAB_0/DDR0_MA_13

AE3

NC/DDR0_ODT_3

AD4

DDR0_DQ_36/DDR1_DQ_4

AB5

DDR0_DQSN_6/DDR1_DQSN_4

P3

DDR0_DQ_12/DDR0_DQ_12

BK4

DDR0_DQ_15/DDR0_DQ_15

BK2

DDR0_DQ_16/DDR0_DQ_32

BG4

DDR0_DQ_19/DDR0_DQ_35

BF5

DDR0_DQ_32/DDR1_DQ_0

AB1

DDR0_DQSP_6/DDR1_DQSP_4

R3

DDR0_DQ_60/DDR1_DQ_44

M5

DDR0_CKE_2/DDR0_CKE_2

AT3

DDR0_DQSN_4/DDR1_DQSN_0

AA3

DDR0_DQ_41/DDR1_DQ_9

V2

DDR0_DQ_51/DDR1_DQ_35

P4

DDR0_DQ_63/DDR1_DQ_47

L1

DDR0_CAA_2/DDR0_MA_6

AP3

DDR0_CAB_4/DDR0_BA_0

AH5

DDR0_DQ_39/DDR1_DQ_7

AA1

DDR0_DQ_54/DDR1_DQ_38

R1

DDR0_DQ_6/DDR0_DQ_6

BP2

DDR0_DQ_30/DDR0_DQ_46

BC1

DDR0_DQSP_4/DDR1_DQSP_0

AB3

DDR0_DQ_35/DDR1_DQ_3

AA5

DDR0_DQ_43/DDR1_DQ_11

U2

DDR0_DQ_56/DDR1_DQ_40

M4

DDR0_DQ_59/DDR1_DQ_43

L2

DDR0_DQ_2/DDR0_DQ_2

BP3

DDR0_DQ_21/DDR0_DQ_37

BG1

NC/DDR0_ECC_0

BA2

DDR0_CAB_8/DDR0_MA_1

AP4

DDR0_CAB_5/DDR0_MA_2

AN4

DDR0_DQ_46/DDR1_DQ_14

U5

DDR0_DQ_10/DDR0_DQ_10

BL2

DDR0_DQSN_2/DDR0_DQSN_4

BG3

DDR0_DQ_29/DDR0_DQ_45

BD4

DDR0_DQ_26/DDR0_DQ_42

BC4

NC/DDR0_ECC_1

BA1

NC/DDR0_PAR

AG3

R653 100_1%_04

R654 121_1%_04

2 OF 13

DDR CHANNEL B

?

?

?

U37B

CML_H_IP_EXT/BGA

DDR_VREF_CA

BN13

DDR1_DQSP_5/DDR1_DQSP_3

V9

DDR1_DQ_55/DDR1_DQ_55

P8

DDR1_DQ_58/DDR1_DQ_58

L7

DDR1_DQ_0/DDR0_DQ_16

BT11

NC/DDR1_ECC_1

AY11

DDR1_CAA_0/DDR1_MA_5

AM6

NC/DDR1_PAR

AJ7

DDR1_DQ_45/DDR1_DQ_29

W10

DDR1_DQ_42/DDR1_DQ_26

V10

DDR1_DQ_49/DDR1_DQ_49

P11

DDR1_DQ_3/DDR0_DQ_19

BR8

DDR1_DQ_5/DDR0_DQ_21

BN11

DDR1_DQ_22/DDR0_DQ_54

BG7

DDR1_DQ_25/DDR0_DQ_57

BC11

NC/DDR1_ECC_2

AY8

DDR1_CAA_5/DDR1_BG_0

AR9

DDR1_DQ_47/DDR1_DQ_31

V8

DDR1_DQ_8/DDR0_DQ_24

BL12

DDR1_DQ_12/DDR0_DQ_28

BJ11

DDR1_DQ_16/DDR0_DQ_48

BG11

DDR1_DQSN_3/DDR0_DQSN_7

BC9

NC/DDR1_ECC_3

AW8

NC/DDR1_CKN_2

AM10

DDR1_CAB_9/DDR1_MA_0

AJ9

NC/DDR1_CS#_2

AF10

DDR1_DQ_33/DDR1_DQ_17

AA10

DDR1_VREF_DQ

BR13

DDR1_DQSN_1/DDR0_DQSN_3

BL9

DDR1_DQ_14/DDR0_DQ_30

BL7

DDR1_DQ_18/DDR0_DQ_50

BG8

DDR1_DQSP_3/DDR0_DQSP_7

BB9

DDR1_DQSN_8/DDR1_DQSN_8

AY9

NC/DDR1_ECC_4

AY10

DDR1_CAA_3/DDR1_MA_8

AN8

NC/DDR1_CKN_3

AJ11

DDR1_CAB_1/DDR1_MA_15

AF8

DDR1_CS#_0/DDR1_CS#_0

AF11

NC/DDR1_CS#_3

AE10

DDR1_DQ_38/DDR1_DQ_22

AC8

DDR1_DQ_62/DDR1_DQ_62

M7

NC/DDR1_ECC_5

AW10

DDR1_CKN_0/DDR1_CKN_0

AN9

NC/DDR1_CKP_2

AM11

DDR1_DQ_50/DDR1_DQ_50

P7

DDR1_DQ_53/DDR1_DQ_53

P10

DDR1_DQSP_1/DDR0_DQSP_3

BJ9

NC/DDR1_ECC_6

AY7

DDR1_DQSP_8/DDR1_DQSP_8

AW9

DDR1_CKE_0/DDR1_CKE_0

AT8

DDR1_CKE_3/DDR1_CKE_3

AT11

NC/DDR1_CKP_3

AJ10

DDR1_ODT_0/DDR1_ODT_0

AF7

DDR1_DQ_40/DDR1_DQ_24

W8

DDR1_DQ_43/DDR1_DQ_27

V11

DDR1_DQ_59/DDR1_DQ_59

M8

DDR1_DQ_56/DDR1_DQ_56

L11

DDR1_DQ_1/DDR0_DQ_17

BR11

DDR1_DQ_23/DDR0_DQ_55

BF7

DDR1_DQ_20/DDR0_DQ_52

BF11

NC/DDR1_ECC_7

AW7

NC/DDR1_ALERT#

AR8

NC/DDR1_MA_3

AL5

DDR1_CAB_4/DDR1_BA_0

AH8

DDR1_DQSN_6/DDR1_DQSN_6

R9

DDR1_DQ_6/DDR0_DQ_22

BP8

DDR0_VREF_DQ

BP13

DDR1_DQ_10/DDR0_DQ_26

BL8

DDR1_DQ_9/DDR0_DQ_25

BL11

DDR1_DQ_28/DDR0_DQ_60

BC10

DDR1_DQ_26/DDR0_DQ_58

BB8

DDR1_CAA_6/DDR1_MA_12

AR10

DDR1_CAA_2/DDR1_MA_6

AN7

DDR1_CKP_0/DDR1_CKP_0

AM9

NC/DDR1_MA_4

AL6

DDR1_CAB_2/DDR1_MA_14

AH11

DDR1_DQ_15/DDR0_DQ_31

BJ7

DDR1_DQ_13/DDR0_DQ_29

BJ10

DDR1_DQ_17/DDR0_DQ_49

BG10

DDR1_CAB_8/DDR1_MA_1

AK6

DDR1_DQSN_4/DDR1_DQSN_2

AC9

DDR1_DQ_34/DDR1_DQ_18

AC11

DDR1_DQ_36/DDR1_DQ_20

AA7

DDR1_DQSP_6/DDR1_DQSP_6

P9

DDR1_DQ_60/DDR1_DQ_60

L10

DDR1_DQ_19/DDR0_DQ_51

BF8

DDR1_CKN_1/DDR1_CKN_1

AM8

DDR1_CAB_5/DDR1_MA_2

AK5

NC/DDR1_ODT_1

AE8

DDR1_CS#_1/DDR1_CS#_1

AE7

DDR1_DQ_39/DDR1_DQ_23

AC7

DDR1_DQ_63/DDR1_DQ_63

L8

DDR1_CKE_1/DDR1_CKE_1

AT10

DDR1_CAB_7/DDR1_MA_10

AH7

NC/DDR1_ODT_2

AE9

DDR1_DQSP_4/DDR1_DQSP_2

AA9

DDR1_DQ_51/DDR1_DQ_51

R8

DDR1_DQ_54/DDR1_DQ_54

R7

DDR1_DQ_57/DDR1_DQ_57

M11

DDR_RCOMP_0

G1

DDR1_DQ_30/DDR0_DQ_62

BC7

DDR1_CAA_7/DDR1_MA_11

AN11

NC/DDR1_ODT_3

AE11

DDR1_DQ_41/DDR1_DQ_25

W7

DDR1_DQ_44/DDR1_DQ_28

W11

DDR_RCOMP_1

H1

DDR1_DQ_2/DDR0_DQ_18

BT9

DDR1_DQ_4/DDR0_DQ_20

BP11

DDR1_DQSN_2/DDR0_DQSN_6

BG9

DDR1_DQ_21/DDR0_DQ_53

BF10

DDR1_DQ_24/DDR0_DQ_56

BB11

DDR1_DQ_46/DDR1_DQ_30

V7

DDR1_DQ_48/DDR1_DQ_48

R11

DDR_RCOMP_2

J2

DDR1_DQ_7/DDR0_DQ_23

BN8

DDR1_DQ_11/DDR0_DQ_27

BJ8

DDR1_DQ_27/DDR0_DQ_59

BC8

DDR1_DQ_29/DDR0_DQ_61

BB10

DDR1_CKP_1/DDR1_CKP_1

AM7

DDR1_CAB_6/DDR1_BA_1

AH9

DDR1_DQ_35/DDR1_DQ_19

AC10

DDR1_DQ_32/DDR1_DQ_16

AA11

DDR1_DQSN_7/DDR1_DQSN_7

M9

DDR1_DQSN_0/DDR0_DQSN_2

BN9

DDR1_DQSP_2/DDR0_DQSP_6

BF9

DDR1_CAA_8/DDR1_ACT#

AT9

DDR1_CAA_9/DDR1_BG_1

AR7

DDR1_CAA_4/DDR1_MA_7

AN10

DDR1_CAB_3/DDR1_MA_16

AH10

DDR1_CAB_0/DDR1_MA_13

AF9

DDR1_DQ_37/DDR1_DQ_21

AA8

DDR1_DQSN_5/DDR1_DQSN_3

W9

DDR1_DQ_61/DDR1_DQ_61

M10

DDR1_DQSP_7/DDR1_DQSP_7

L9

DDR1_DQSP_0/DDR0_DQSP_2

BP9

DDR1_CAA_1/DDR1_MA_9

AR11

DDR1_DQ_52/DDR1_DQ_52

R10

DDR1_DQ_31/DDR0_DQ_63

BB7

NC/DDR1_ECC_0

AW11

DDR1_CKE_2/DDR1_CKE_2

AT7

M_A_DQ9

M_A_DQ36

M_A_DQ25

M_A_DQ51

M_A_DQ10

M_A_DQ37

M_A_DQ26

M_A_DQ52

M_A_DQ11

M_A_DQ38

M_A_DQ27

M_A_DQ53

M_A_DQ12

M_A_DQ39

M_A_DQ28

M_A_DQ54

M_A_DQ13

M_A_DQ40

M_A_DQ29

M_A_DQ55

M_A_DQ14

M_A_DQ41

M_A_DQ30

M_A_DQ15

M_A_DQ56

M_A_DQ1

M_A_DQ42

M_A_DQ31

M_A_DQ16

M_A_DQ57

M_A_DQ43

M_A_DQ32

M_A_DQ17

M_A_DQ58

M_A_DQ0

M_A_DQ2

M_A_DQ44

M_A_DQ18

M_A_DQ59

M_A_DQ3

M_A_DQ45

M_A_DQ19

M_A_DQ60

M_A_DQ4

M_A_DQ46

M_A_DQ20

M_A_DQ61

M_A_DQ5

M_A_DQ47

M_A_DQ21

M_A_DQ6

M_A_DQ62

M_A_DQ33

M_A_DQ48

M_A_DQ22

M_A_DQ7

M_A_DQ63

M_A_DQ34

M_A_DQ49

M_A_DQ23

M_A_DQ8

M_A_DQ35

M_A_DQ50

M_A_DQ24

M_B_DQ0

M_B_DQ33

M_B_DQ18

M_B_DQ48

M_B_DQ34

M_B_DQ19

M_B_DQ49

M_B_DQ57

M_B_DQ35

M_B_DQ20

M_B_DQ50

M_B_DQ36

M_B_DQ58

M_B_DQ21

M_B_DQ2

M_B_DQ51

M_B_DQ37

M_B_DQ3

M_B_DQ22

M_B_DQ59

M_B_DQ52

M_B_DQ11

M_B_DQ4

M_B_DQ38

M_B_DQ23

M_B_DQ60

M_B_DQ53

M_B_DQ12

M_B_DQ5

M_B_DQ24

M_B_DQ39

M_B_DQ61

M_B_DQ54

M_B_DQ6

M_B_DQ25

M_B_DQ40

M_B_DQ62

M_B_DQ55

M_B_DQ26

M_B_DQ41

M_B_DQ63

M_B_DQ27

M_B_DQ42

M_B_DQ28

M_B_DQ43

M_B_DQ13

M_B_DQ29

M_B_DQ44

M_B_DQ14

M_B_DQ7

M_B_DQ30

M_B_DQ45

M_B_DQ15

M_B_DQ56

M_B_DQ1

M_B_DQ8

M_B_DQ31

M_B_DQ46

M_B_DQ16

M_B_DQ9

M_B_DQ32

M_B_DQ17

M_B_DQ47

M_B_DQ10

DDR_RCOMP0
DDR_RCOMP1
DDR_RCOMP2

DIMM_DQ_CPU_VREF_A

M_A_DQS#6

M_A_DQS#5

M_A_DQS#7

M_A_DQS1
M_A_DQS2
M_A_DQS3

M_A_DQS#4

M_A_DQS0

M_A_DQS4

M_A_DQS7

M_A_DQS6

M_A_DQS5

M_A_DQS#1

M_A_DQS#3

M_A_DQS#2

M_A_DQS#0

M_B_DQS0

M_B_DQS6

M_B_DQS4

M_B_DQS1

M_B_DQS7

M_B_DQS2

M_B_DQS5

M_B_DQS3

M_B_DQS#1
M_B_DQS#2

M_B_DQS#7

M_B_DQS#4
M_B_DQS#5

M_B_DQS#3

M_B_DQS#6

M_B_DQS#0

Processor 2/6

B.Schematic Diagrams

B - 4 Processor 2/6

Processor 3/6

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

CFG7

DEFENSIVE PULL DOWN SITE

1: (Default) PEG Train immediately following xxRESETB de ass ertion
0: PEG Wait for BIOS for training

CFG4

1: DISABLED;
NO PHYSICAL DISPLAY PORT ATTACHED
TO EMBEDDED DISPLAY PORT
0: ENABLED;
AN EXTERNAL DISPLAY PORT DEVICE
IS CONNECTED TO THE EMBEDDED
DISPLAY PORT

DISPLAY PORT PRESENCE STRAP

CFG2

1: (DEFAULT)NORMAL OPERATION;
LANE# DEFINITION MATCHES
SOCKET PIN MAP DEFINITION
0: LANE REVERSAL

PCI EXPRESS STATIC LANE REVERSAL FOR ALL PEG PORTS

CFG[6:5]

11: (Default) x16 - Device 1 functions 1 and 2 disabled
10: x8, x8 - Device 1 function 1 enabled ; function 2 disabl ed
01: Reserved - (Device 1 function 1 disabled ; function 2 en abled)
00: x8,x4,x4 - Device 1 functions 1 and 2 enabled

PCIE PORT BIFURCATION STRAPS

CFG[0]: Stall reset sequence after PCU PLL

Ʉ

lock until de-asserted:
— 1 = (Default) Normal Operation; No
stall.
— 0 = Stall.

CFG[1]: Reserved configuration lane.

Ʉ

CFG[2]: PCI Express* Static x16 Lane

Ʉ

Numbering Reversal.
— 1 = Normal operation
— 0 = Lane numbers reversed.

CFG[3]: Reserved configuration lane.

Ʉ

CFG[4]: eDP enable:

Ʉ

— 1 = Disabled.
— 0 = Enabled.

CFG[6:5]: PCI Express* Bifurcation

Ʉ

— 00 = 1 x8, 2 x4 PCI Express*
— 01 = reserved
— 10 = 2 x8 PCI Express*
— 11 = 1 x16 PCI Express*

CFG[7]: PEG Training:

Ʉ

— 1 = (default) PEG Train immediately
following RESET# de assertion.
— 0 = PEG Wait for BIOS for training.

CFG[19:8]: Reserved configuration lanes.

Ʉ

TO EC

NEAR CPU

TO PCH-H

VCCST_PWRGD

CAD Note: Capacitor need to be placed
close to buffer output pin

Configuration Signals: The CFG signals have a
default value of '1' if not terminated on the board.
Refer to the appropriate platform design guide for
pull-down recommendations when a logic low is
desired.

1.05DX_VCCSTG

3.3VA

1.05V_VCCST

1.05V_VCCST

VDD3

1.05DX_VCCSTG

1.05DX_VCCSTG 6,33,53

VDD3 23,30,31,33,36,39,40,42,44,45,46,47,48,49,52,53,55,56,57,58,59,60,63,70,71,72

1.05V_VCCST 6,32,48,52

H_PROCHOT#52

PCH_CPU_BCLK_R_DN35

PCH_CPU_BCLK_R_DP35

PCH_CPU_PCIBCLK_R_DN35

PCH_CPU_PCIBCLK_R_DP35

CPU_24MHZ_R_DN35

CPU_24MHZ_R_DP35

H_PWRGD33

PLTRST_CPU_N32

H_PM_SYNC32

H_SKTOCC_N34,38

DDR_VTT_PG_CTRL50

H_CPU_SVIDCLK52

H_CPU_SVIDDAT52
H_CPU_SVIDALRT#52

PCH_THERMTRIP#32

PCH_PECI32

H_PM_DOWN32

H_PECI45

3.3VA 30,31,32,33,36,38,44,48,53

ALL_SYS_PWRGD28,31,45,52

H_PROCHOT_EC45

VCCIO 2,6,48

H_TCK 33

H_TMS 33

H_TDO 33

H_TDI 33

H_TRST# 38
H_PREQ# 38

H_PRDY# 38

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[04]Processor 4/7-CLK/JTAG/MISC

A3

474Tuesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[04]Processor 4/7-CLK/JTAG/MISC

A3

474Tuesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[04]Processor 4/7-CLK/JTAG/MISC

A3

474Tuesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

R621 *12.1_1%_04

T22

R582 *1K_04

R603 499_1%_04

R516

56.2_1%_04

R604 1K_04

T96

C1039

47p_25V_NPO_02

T25

S

D

G

Q58B
MTDK3S6R

5

34

R592

100K_04

T99

C1032
*0.1u_10V_X7R_04

T97

T98

R581

1K_04

C302
*0.1u_10V_X7R_04

T95

5 OF 13

?

?

?

U37E

CML_H_IP_EXT/BGA

VIDSOUT

BH29

DDR_VTT_CNTL

BT13

VCCST_PWRGD

H13

PM_SYNC

BM34

PM_DOWN

BP31

PECI

BT34

CFG_18

BN22

PROC_TCK

BR28

CFG_19

BP22

THERMTRIP#

J31

PROC_TDO

BT28

CFG_0

BN25

PROC_TRST#

BP30

CFG_1

BN27

PROC_SELECT#

BN1

ZVM#

AT13

SKTOCC#

BR33

CFG_2

BN26

CFG_RCOMP

BT25

CFG_3

BN28

PROC_PREQ#

BL30

CFG_4

BR20

CFG_10

BT23

RESET#

BP35

CFG_5

BM20

CLK24N

D31

PROCPWRGD

BT31

CFG_11

BT22

CFG_6

BT20

BPM#_0

BR27

VIDSCK

BH32

BCLKN

A32

PCI_BCLKN

C36

BPM#_1

BT27

CFG_7

BP20

CFG_12

BM19

CLK24P

E31

CFG_8

BR23

CFG_13

BR19

BPM#_2

BM31

BCLKP

B31

PCI_BCLKP

D35

BPM#_3

BT30

PROCHOT#

BR30

CFG_9

BR22

CFG_14

BP19

RSVD2

AY13

CFG_15

BT19

RSVD1

AU13

PROC_PRDY#

BP27

CFG_16

BP23

CATERR#

BM30

PROC_TDI

BL32

MSM#

AW13

PROC_TMS

BP28

CFG_17

BN23

VIDALERT#

BH31

R578 60.4_1%_04

R622 *0402_short

C1030
*0.1u_10V_X7R_04

R141

220_04

S

D

G

Q58A
MTDK3S6R

2

61

R589 20K_04

R600 20_1%_04

Q59

2SK3018S3

G

DS

R562 100_04

R155

49.9_1%_04

R591

100K_04

T24

R623 51_04

R146 51_04

R624 51_04

R150

100_04

T23

T26

R599 100K_04

R587 1K_04

VIDALERT#

PROCHOT#

H_PROCHOT#

VCCST_PWRGD_CPUVCCST_PWRGD

PM_DOWN
PECI

H_SKTOCC_N

H_TDO
H_TDI
H_TMS
H_TCK

H_TRST#
H_PREQ#
H_PRDY#

CFG_RCOMP

CFG0

CFG3
CFG4
CFG5
CFG6
CFG7

H_TDO

H_TCK

H_SKTOCC_N

CFG8

SYS_PWRGD#

VCCST_PWRGD

H_PROCHOT#

CFG_1

CFG9

CFG11

CFG14
CFG15

H_TDI

H_TMS

Sheet 4 of 67

Processor 3/6

Schematic Diagrams

B.Schematic Diagrams

Processor 3/6 B - 5

Schematic Diagrams

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

128A 128A

128A128A

VCORE

VCORE

VCORE VCORE

VCORE VCORE

VCORE

VCC_VCORE_SENSE 52
VSS_VCORE_SENSE 52

VCORE 51,52

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[05] Processor 5/7-POWER1

A3

574Tuesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[05] Processor 5/7-POWER1

A3

574Tuesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[05] Processor 5/7-POWER1

A3

574Tuesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

C602

1u_6.3V_X6S_04

C482

10u_4V_X6S_06

C271

*1u_6.3V_X6S_04

10 OF 13

?

?

?

U37J

CML_H_IP_EXT/BGA

VCC71

Y32

VCC60

W29

VCC5

N14

VCC70

Y31

VCC4

N13

VCC3

L14

VCC19

P33

VCC2

L13

VCC29

R36

VCC18

P32

VCC1

K14

VCC39

T38

VCC28

R35

VCC17

P31

VCC49

V14

VCC38

T37

VCC27

R34

VCC16

P30

VCC59

W14

VCC48

V13

VCC37

T36

VCC26

R33

VCC15

P29

VCC69

Y30

VCC58

W13

VCC47

U36

VCC36

T35

VCC25

R32

VCC14

P14

VCC68

Y29

VCC57

V38

VCC46

U35

VCC35

T32

VCC24

R31

VCC13

P13

VCC67

W38

VCC56

V37

VCC45

U34

VCC34

T31

VCC23

R13

VCC12

N38

VCC66

W37

VCC55

V36

VCC44

U33

VCC33

T30

VCC22

P36

VCC11

N37

VCC65

W36

VCC54

V35

VCC43

U32

VCC32

T29

VCC21

P35

VCC10

N36

VCC75

Y36

VCC64

W35

VCC53

V34

VCC42

U31

VCC31

R38

VCC20

P34

VCC9

N35

VCC74

Y35

VCC63

W32

VCC52

V33

VCC41

U30

VCC30

R37

VCC8

N32

VCC73

Y34

VCC62

W31

VCC51

V32

VCC40

U29

VCC7

N31

VCC72

Y33

VCC61

W30

VCC50

V31

VCC6

N30

C349

1u_6.3V_X6S_04

C313

1u_6.3V_X6S_04

C371

1u_6.3V_X6S_04

R125 100_04

9 OF 13

?

?

?

U37I

CML_H_IP_EXT/BGA

VCC93

AL36

VCC82

AK34

VCC71

AJ29

VCC60

AG33

VCC5

AA34

VCC92

AL35

VCC81

AK33

VCC70

AJ14

VCC4

AA33

VCC91

AL32

VCC80

AK32

VCC3

AA32

VCC90

AL31

VCC_SENSE

AG37

VCC19

AC14

VCC2

AA31

VCC29

AD14

VCC18

AC13

VCC1

AA13

VCC109

AN32

VCC39

AE14

VCC28

AD13

VCC17

AB38

VCC119

AP32

VCC108

AN31

VCC49

AF31

VCC38

AE13

VCC27

AC36

VCC16

AB37

VCC118

AP31

VCC107

AN14

VCC59

AG32

VCC48

AF30

VCC37

AD38

VCC26

AC35

VCC15

AB36

VCC117

AP30

VCC106

AN13

VCC69

AH32

VCC58

AG31

VCC47

AF29

VCC36

AD37

VCC25

AC34

VCC14

AB35

VCC116

AP13

VCC105

AM36

VCC79

AK31

VCC68

AH31

VCC57

AG14

VCC46

AE38

VCC35

AD36

VCC24

AC33

VCC13

AB32

VCC115

AN38

VCC104

AM35

VCC89

AL30

VCC78

AJ36

VCC67

AH30

VSS_SENSE

AG38

VCC56

AF38

VCC45

AE37

VCC34

AD35

VCC23

AC32

VCC12

AB31

VCC114

AN37

VCC103

AM34

VCC99

AM30

VCC88

AL29

VCC77

AJ35

VCC66

AH29

VCC55

AF37

VCC44

AE36

VCC33

AD34

VCC22

AC31

VCC11

AB30

VCC124

K13

VCC113

AN36

VCC102

AM33

VCC98

AM29

VCC87

AL13

VCC76

AJ34

VCC65

AH14

VCC54

AF36

VCC43

AE35

VCC32

AD33

VCC21

AC30

VCC10

AB29

VCC123

AP38

VCC112

AN35

VCC101

AM32

VCC97

AM14

VCC86

AK38

VCC75

AJ33

VCC64

AH13

VCC53

AF35

VCC42

AE32

VCC31

AD32

VCC20

AC29

VCC9

AA38

VCC122

AP37

VCC111

AN34

VCC100

AM31

VCC96

AM13

VCC85

AK37

VCC74

AJ32

VCC63

AG36

VCC52

AF34

VCC41

AE31

VCC30

AD31

VCC8

AA37

VCC121

AP36

VCC110

AN33

VCC95

AL38

VCC84

AK36

VCC73

AJ31

VCC62

AG35

VCC51

AF33

VCC40

AE30

VCC7

AA36

VCC120

AP35

VCC94

AL37

VCC83

AK35

VCC72

AJ30

VCC61

AG34

VCC50

AF32

VCC6

AA35

C531

10u_4V_X6S_06

C97

10u_4V_X6S_06

C436

10u_4V_X6S_06

C506

10u_4V_X6S_06

R128 100_04

C439

10u_4V_X6S_06

C415

10u_4V_X6S_06

C530

*10u_4V_X6S_06

C441

10u_4V_X6S_06

C268

1u_6.3V_X6S_04

C449

1u_6.3V_X6S_04

C262

1u_6.3V_X6S_04

C324

1u_6.3V_X6S_04

C318

1u_6.3V_X6S_04

C417

10u_4V_X6S_06

R540

*49.9_1%_04

VSS_VCORE_SENSEVCC_VCORE_SENSE

Sheet 5 of 67

Processor 4/6

Processor 4/6

B.Schematic Diagrams

B - 6 Processor 4/6

Processor 5/6

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

AROUND_CPU

PLACE CAP BACKSIDE

PLACE CAP BACKSIDE

PLACE CAP IN BACK SIDE

CPU_BACK_VCCSA

NEAR TO CPU PIN

11.1A

6.4A

3.7A

0.225A

0.225A

place to angle

0.02A

0.17A

D02_1029_Alex

Gary_0218_2019

0.2A

VCCSA VDDQ

VCCIO

VCCSFR_OC

1.05V_VCCST

1.05DX_VCCSTG VCCFUSEPRG

1.05V_VCCST

1.05DX_VCCSTG VCCSFR_OC

1.05V_VCCST 1.05V_VCCST

VDDQ

VDDQ VCCIO

VCCSA VCCSA

VCCSA

CPU_2_PCH_TRIGGER38

PCH_2_CPU_TRIGGER38

VCCSA_SENSE 52
VSSSA_SENSE 52

VDDQ8,9,33,48,50

VCCSA52,54

VCCIO2,48

1.05DX_VCCSTG4,33,53

1.05V_VCCST4,32,48,52

VCCSFR_OC48

VSSIO_SENSE 48

VCCIO_SENSE 48

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[06] Processor 6/7-POWER2

A3

674Tuesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[06] Processor 6/7-POWER2

A3

674Tuesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[06] Processor 6/7-POWER2

A3

674Tuesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

R75 100_04

C613

10u_6.3V_X5R_06

C193

10u_4V_X6S_06

C504

10u_4V_X6S_06

R156 30.1_1%_04

C634

*22u_6.3V_X5R_06

C385

1u_6.3V_X5R_02

C611

1u_6.3V_X5R_02

C631

*10u_4V_X6S_06

C604

*22u_6.3V_X5R_06

13 OF 13

?

?

?

U37M

CML_H_IP_EXT/BGA

VSS_A37

A37

RSVD19

BR35

RSVD29

J3

RSVD18

BR31

RSVD9

BH30

RSVD28

J24

RSVD_TP5

E2

RSVD17

BR2

RSVD8

B38

RSVD27

H24

RSVD_TP4

E1

RSVD16

BP1

RSVD7

B30

RSVD26

G3

RSVD_TP3

D1

RSVD15

BN35

RSVD6

B2

RSVD25

G13

RSVD_TP2

BT2

RSVD14

BN33

RSVD5

AP29

RSVD24

F30

RSVD_TP1

BR1

RSVD13

BL34

RSVD4

AP14

RSVD23

E30

RSVD12

BL31

RSVD3

AJ8

RSVD22

C38

RSVD11

BK28

RSVD2

AE29

PROC_TRIGOUT

J23

RSVD21

C30

RSVD10

BJ28

RSVD1

AA14

RSVD31

R14

PROC_TRIGIN

H23

IST_TRIG

E3

RSVD20

C1

RSVD30

N29

VSS_A36

A36

C281

1u_6.3V_X6S_04

C533

*22u_4V_X6S_06

C633

22u_6.3V_X6S_08

C400

1u_6.3V_X5R_02

C179

22u_6.3V_X5R_06

C605

10u_4V_X6S_06

12 OF 13

?

?

?

U37L

CML_H_IP_EXT/BGA

VCCSA1

J30

VCCSA2

K29

VCCSA3

K30

VCCSA4

K31

VCCSA5

K32

VCCSA6

K33

VCCSA7

K34

VCCSA8

K35

VCCSA9

L31

VCCSA10

L32

VCCSA11

L35

VCCSA12

L36

VCCSA13

L37

VCCSA14

L38

VCCSA15

M29

VCCSA16

M30

VCCSA17

M31

VCCSA18

M32

VCCSA19

M33

VCCSA20

M34

VCCSA21

M35

VCCSA22

M36

VCCIO1

AG12

VCCIO2

G15

VCCIO3

G17

VCCIO4

G19

VCCIO5

G21

VCCIO6

H15

VCCIO7

H16

VCCIO8

H17

VCCIO9

H19

VCCIO10

H20

VCCIO11

H21

VCCIO12

H26

VCCIO13

H27

VCCIO14

J15

VCCIO15

J16

VCCIO16

J17

VCCIO17

J19

VCCIO18

J20

VCCIO19

J21

VCCIO20

J26

VCCIO21

J27

VCCST

H30

VCCSA_SENSE

M38

VCCIO_SENSE

H14

VDDQ18

K12

VDDQ2

AE12

VDDQ17

J6

VDDQ1

AA6

VDDQ16

J5

VDDQ15

AY6

VDDQ25

Y12

VDDQ14

AW6

VDDQ24

W6

VDDQ13

AT12

VDDQ23

T6

VCCSTG2

H29

VDDQ12

AR6

VDDQ22

R6

VCCSTG1

G30

VDDQ11

AR12

VDDQ21

L6

VDDQ10

AP7

VDDQ20

L12

VCCPLL_OC3

G11

VCCPLL_OC2

BJ13

VDDQ9

AP6

VCCPLL_OC1

BH13

VDDQ8

AL11

VDDQ7

AJ12

VCCPLL2

J28

VDDQ6

AG9

VCCPLL1

H28

VDDQ5

AG5

VSSSA_SENSE

M37

VSSIO_SENSE

J14

VDDQ4

AF6

VDDQ19

K6

VDDQ3

AF5

C199

22u_6.3V_X5R_06

C615

*22u_6.3V_X5R_06

C159

22u_6.3V_X6S_08

R143 *28mil short-p

C256

*1u_6.3V_X5R_04

C824

*10u_6.3V_X5R_04

C227
10u_4V_X6S_06

C253

10u_4V_X6S_06

C478

10u_6.3V_X5R_04

C359

1u_6.3V_X5R_02

C636

10u_4V_X6S_06

C630

10u_6.3V_X5R_06

R77 100_04

C390

1u_6.3V_X5R_02

C231

10u_4V_X6S_06

C382

*1u_6.3V_X5R_02

C593

*1u_6.3V_X6S_04

VCCIO_SENSE
VSSIO_SENSE

TP_SKL_G13

TP_SKL_B2

TP_SKL_B38

TP_SKL_BP1

TP_SKL_BR2

TP_SKL_C1

TP_SKL_C38

RSVD_TP[3]

RSVD_TP[4]

IST_TR IG

RSVD_TP[5]

RSVD_TP[1]
RSVD_TP[2]

PROC_TRIGOUT

TP_SKL_BR35
TP_SKL_BR31
TP_SKL_BH30

Sheet 6 of 67

Processor 5/6

Schematic Diagrams

B.Schematic Diagrams

Processor 5/6 B - 7

Schematic Diagrams

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

PLACE CAP IN BACK SIDE

CPU_BACK_VCCGT

32A 32A

Gary_0218_2019

VCCGTVCCGT

VCCGT

VCCGT

VCCGT

VCCGT 52,54

VSSGT_SENSE 52
VCCGT_SENSE 52

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[07] Processor 7/7-POWER/GND

Custom

774Tuesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[07] Processor 7/7-POWER/GND

Custom

774Tuesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[07] Processor 7/7-POWER/GND

Custom

774Tuesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

C374

22u_6.3V_X6S_08

C989

22u_6.3V_X6S_08

C299

*1u_6.3V_X6S_04

C428

*1u_6.3V_X6S_04

C432

10u_4V_X6S_06

C451

1u_6.3V_X6S_04

C384

10u_4V_X6S_06

11 OF 13

?

?

?

U37K

CML_H_IP_EXT/BGA

VCCGT63

BB38

VCCGT64

BC29

VCCGT65

BC30

VCCGT66

BC31

VCCGT67

BC32

VCCGT68

BC35

VCCGT69

BC36

VCCGT70

BC37

VCCGT71

BC38

VCCGT72

BD13

VCCGT73

BD14

VCCGT74

BD29

VCCGT75

BD30

VCCGT76

BD31

VCCGT77

BD32

VCCGT78

BD33

VCCGT79

BD34

VCCGT80

BD35

VCCGT81

BD36

VCCGT82

BE31

VCCGT83

BE32

VCCGT84

BE33

VCCGT129

BK21

VCCGT130

BK23

VCCGT131

BK24

VCCGT132

BK26

VCCGT133

BK27

VCCGT134

BL15

VCCGT135

BL16

VCCGT136

BL17

VCCGT137

BL23

VCCGT138

BL24

VCCGT143

BL36

VCCGT148

BM36

VCCGT149

BM37

VCCGT150

BN15

VCCGT151

BN16

VCCGT152

BN17

VCCGT153

BN36

VCCGT154

BN37

VCCGT155

BN38

VCCGT156

BP15

VCCGT157

BP16

VCCGT158

BP17

VCCGT159

BP37

VCCGT160

BP38

VCCGT161

BR15

VCCGT162

BR16

VCCGT163

BR17

VCCGT164

BR37

VCCGT165

BT15

VCCGT166

BT16

VCCGT167

BT17

VCCGT168

BT37

VCCGT_SENSE

AH38

VSSGT_SENSE

AH37

VCCGT141

BL27

VCCGT57

BB32

VCCGT46

BA29

VCCGT35

AW38

VCCGT24

AV34

VCCGT13

AU31

VCCGT2

AT31

VCCGT140

BL26

VCCGT89

BE38

VCCGT56

BB31

VCCGT45

BA14

VCCGT34

AW37

VCCGT23

AV33

VCCGT12

AU30

VCCGT1

AT14

VCCGT99

BF38

VCCGT88

BE37

VCCGT55

BB14

VCCGT44

BA13

VCCGT33

AW36

VCCGT22

AV32

VCCGT11

AU29

VCCGT98

BF37

VCCGT87

BE36

VCCGT54

BB13

VCCGT43

AY38

VCCGT32

AW35

VCCGT21

AV31

VCCGT10

AU14

VCCGT97

BF36

VCCGT86

BE35

VCCGT53

BA36

VCCGT42

AY37

VCCGT31

AW34

VCCGT20

AV30

VCCGT109

BH34

VCCGT96

BF35

VCCGT85

BE34

VCCGT52

BA35

VCCGT41

AY36

VCCGT30

AW33

VCCGT119

BJ23

VCCGT108

BH33

VCCGT95

BF32

VCCGT62

BB37

VCCGT51

BA34

VCCGT40

AY35

VCCGT118

BJ21

VCCGT107

BG36

VCCGT94

BF31

VCCGT61

BB36

VCCGT50

BA33

VCCGT139

BL25

VCCGT128

BK20

VCCGT117

BJ20

VCCGT106

BG35

VCCGT93

BF30

VCCGT60

BB35

VCCGT127

BK19

VCCGT116

BJ19

VCCGT105

BG34

VCCGT92

BF29

VCCGT126

BK17

VCCGT115

BJ17

VCCGT104

BG33

VCCGT91

BF14

VCCGT9

AT38

VCCGT147

BM17

VCCGT125

BK16

VCCGT114

BJ16

VCCGT103

BG32

VCCGT90

BF13

VCCGT19

AV29

VCCGT8

AT37

VCCGT146

BM16

VCCGT124

BJ38

VCCGT113

BH38

VCCGT102

BG31

VCCGT29

AW32

VCCGT18

AU38

VCCGT7

AT36

VCCGT145

BM15

VCCGT123

BJ37

VCCGT112

BH37

VCCGT101

BG30

VCCGT39

AY32

VCCGT28

AW31

VCCGT17

AU37

VCCGT6

AT35

VCCGT144

BL37

VCCGT122

BJ27

VCCGT111

BH36

VCCGT100

BG29

VCCGT49

BA32

VCCGT38

AY31

VCCGT27

AW14

VCCGT16

AU36

VCCGT5

AT34

VCCGT121

BJ26

VCCGT110

BH35

VCCGT59

BB34

VCCGT48

BA31

VCCGT37

AY30

VCCGT26

AV36

VCCGT15

AU35

VCCGT4

AT33

VCCGT142

BL28

VCCGT120

BJ24

VCCGT58

BB33

VCCGT47

BA30

VCCGT36

AY29

VCCGT25

AV35

VCCGT14

AU32

VCCGT3

AT32

6 OF 13

?

?

?

U37F

CML_H_IP_EXT/BGA

VSS_1

A10

VSS_2

A12

VSS_3

A16

VSS_4

A18

VSS_5

A20

VSS_6

A22

VSS_7

A24

VSS_8

A26

VSS_9

A28

VSS_10

A30

VSS_11

A6

VSS_12

A9

VSS_13

AA12

VSS_14

AA29

VSS_15

AA30

VSS_16

AB33

VSS_17

AB34

VSS_18

AB6

VSS_19

AC1

VSS_20

AC12

VSS_21

AC2

VSS_22

AC3

VSS_23

AC37

VSS_24

AC38

VSS_25

AC4

VSS_26

AC5

VSS_27

AC6

VSS_28

AD10

VSS_29

AD11

VSS_30

AD12

VSS_31

AD29

VSS_32

AD30

VSS_33

AD6

VSS_34

AD8

VSS_35

AD9

VSS_36

AE33

VSS_37

AE34

VSS_38

AE6

VSS_39

AF1

VSS_40

AF12

VSS_41

AF13

VSS_42

AF14

VSS_43

AF2

VSS_44

AF3

VSS_45

AF4

VSS_46

AG10

VSS_47

AG11

VSS_48

AG13

VSS_49

AG29

VSS_50

AG30

VSS_51

AG6

VSS_52

AG7

VSS_53

AG8

VSS_54

AH12

VSS_55

AH33

VSS_56

AH34

VSS_57

AH35

VSS_58

AH36

VSS_59

AH6

VSS_60

AJ1

VSS_61

AJ13

VSS_62

AJ2

VSS_63

AJ3

VSS_64

AJ37

VSS_65

AJ38

VSS_66

AJ4

VSS_67

AJ5

VSS_68

AJ6

VSS_69

W4

VSS_70

W5

VSS_71

Y10

VSS_72

Y11

VSS_73

Y13

VSS_74

Y14

VSS_75

Y37

VSS_76

Y38

VSS_77

Y7

VSS_78

Y8

VSS_79

Y9

VSS_80

AK29

VSS_81

AK30

VSS_82

AK4

VSS_83

AL10

VSS_84

AL12

VSS_85

AL14

VSS_86

AL33

VSS_87

AL34

VSS_88

AL4

VSS_89

AL7

VSS_90

AL8

VSS_91

AL9

VSS_92

AM1

VSS_93

AM12

VSS_94

AM2

VSS_95

AM3

VSS_96

AM37

VSS_97

AM38

VSS_98

AM4

VSS_99

AM5

VSS_100

AN12

VSS_101

AN29

VSS_102

AN30

VSS_103

AN5

VSS_104

AN6

VSS_105

AP10

VSS_106

AP11

VSS_107

AP12

VSS_108

AP33

VSS_109

AP34

VSS_110

AP8

VSS_111

AP9

VSS_112

AR1

VSS_113

AR13

VSS_114

AR14

VSS_115

AR2

VSS_116

AR29

VSS_117

AR3

VSS_118

AR30

VSS_119

AR31

VSS_120

AR32

VSS_121

AR33

VSS_122

AR34

VSS_123

AR35

VSS_124

AR36

VSS_125

AR37

VSS_126

AR38

VSS_127

AR4

VSS_128

AR5

VSS_129

AT29

VSS_130

AT30

VSS_131

AT6

VSS_132

AU10

VSS_133

AU11

VSS_134

AU12

VSS_135

AU33

VSS_136

AU34

VSS_137

AU6

VSS_138

AU7

VSS_139

AU8

VSS_140

AU9

VSS_141

AV37

VSS_142

AV38

VSS_143

AW1

VSS_144

AW12

VSS_145

AW2

VSS_146

AW29

VSS_147

AW3

VSS_148

AW30

VSS_149

AW4

VSS_150

U6

VSS_151

V12

VSS_152

V29

VSS_153

V30

VSS_154

A14

VSS_155

AD7

VSS_156

V6

VSS_157

W1

VSS_158

W12

VSS_159

W2

VSS_160

W3

VSS_161

W33

VSS_162

W34

C981

1u_6.3V_X6S_04

C392

10u_4V_X6S_06

C983

1u_6.3V_X6S_04

C393

10u_4V_X6S_06

C609

*1u_6.3V_X6S_04

7 OF 13

?

?

?

U37G

CML_H_IP_EXT/BGA

VSS_163

AW5

VSS_164

AY12

VSS_165

AY33

VSS_166

AY34

VSS_167

B9

VSS_168

BA10

VSS_169

BA11

VSS_170

BA12

VSS_171

BA37

VSS_172

BA38

VSS_173

BA6

VSS_174

BA7

VSS_175

BA8

VSS_176

BA9

VSS_177

BB1

VSS_178

BB12

VSS_179

BB2

VSS_180

BB29

VSS_181

BB3

VSS_182

BB30

VSS_183

BB4

VSS_184

BB5

VSS_185

BB6

VSS_186

BC12

VSS_187

BC13

VSS_188

BC14

VSS_189

BC33

VSS_190

BC34

VSS_191

BC6

VSS_192

BD10

VSS_193

BD11

VSS_194

BD12

VSS_195

BD37

VSS_196

BD6

VSS_197

BD7

VSS_198

BD8

VSS_199

BD9

VSS_200

BE1

VSS_201

BE2

VSS_202

BE29

VSS_203

BE3

VSS_204

BE30

VSS_205

BE4

VSS_206

BE5

VSS_207

BE6

VSS_208

BF12

VSS_209

BF33

VSS_210

BF34

VSS_211

BF6

VSS_212

BG12

VSS_213

BG13

VSS_214

BG14

VSS_215

BG37

VSS_216

BG38

VSS_217

BG6

VSS_218

BH1

VSS_219

BH10

VSS_220

BH11

VSS_221

BH12

VSS_222

BH14

VSS_223

BH2

VSS_224

BH3

VSS_225

BH4

VSS_226

BH5

VSS_227

BH6

VSS_228

BH7

VSS_229

BH8

VSS_230

BH9

VSS_231

T2

VSS_232

T3

VSS_233

T33

VSS_234

T34

VSS_235

T4

VSS_236

T5

VSS_237

T7

VSS_238

T8

VSS_239

T9

VSS_240

U37

VSS_241

U38

VSS_242

BJ12

VSS_243

BJ14

VSS_244

BJ15

VSS_245

BJ18

VSS_246

BJ22

VSS_247

BJ25

VSS_248

BJ29

VSS_249

BJ30

VSS_250

BJ31

VSS_251

BJ32

VSS_252

BJ33

VSS_253

BJ34

VSS_254

BJ35

VSS_255

BJ36

VSS_256

BK13

VSS_257

BK14

VSS_258

BK15

VSS_259

BK18

VSS_260

BK22

VSS_261

BK25

VSS_262

BK29

VSS_263

BK6

VSS_264

BL13

VSS_265

BL14

VSS_266

BL18

VSS_267

BL19

VSS_268

BL20

VSS_269

BL21

VSS_270

BL22

VSS_271

BL29

VSS_272

BL33

VSS_273

BL35

VSS_274

BL38

VSS_275

BL6

VSS_276

BM11

VSS_277

BM12

VSS_278

BM13

VSS_279

BM14

VSS_280

BM18

VSS_281

BM2

VSS_282

BM21

VSS_283

BM22

VSS_284

BM23

VSS_285

BM24

VSS_286

BM25

VSS_287

BM26

VSS_288

BM27

VSS_289

BM28

VSS_290

BM29

VSS_291

BM3

VSS_292

BM33

VSS_293

BM35

VSS_294

BM38

VSS_295

BM5

VSS_296

BM6

VSS_297

BM7

VSS_298

BM8

VSS_299

BM9

VSS_300

BN12

VSS_301

BN14

VSS_302

BN18

VSS_303

BN19

VSS_304

BN2

VSS_305

BN20

VSS_306

BN21

VSS_307

BN24

VSS_308

BN29

VSS_309

BN30

VSS_310

BN31

VSS_311

BN34

VSS_312

P38

VSS_313

P6

VSS_314

R12

VSS_315

R29

VSS_316

AY14

VSS_317

BD38

VSS_318

R30

VSS_319

T1

VSS_320

T10

VSS_321

T11

VSS_322

T12

VSS_323

T13

VSS_324

T14

C587

1u_6.3V_X6S_04

C986

1u_6.3V_X6S_04

R110 100_04

C471

*1u_6.3V_X6S_04

C583

10u_4V_X6S_06

C982

1u_6.3V_X6S_04

C414

10u_4V_X6S_06

C174

22u_6.3V_X6S_08

C373

22u_6.3V_X6S_08

C988

22u_6.3V_X6S_08

R113 100_04

C563

10u_4V_X6S_06

8 OF 13

?

?

?

U37H

CML_H_IP_EXT/BGA

VSS_325

BN4

VSS_326

BN7

VSS_327

BP12

VSS_328

BP14

VSS_329

BP18

VSS_330

BP21

VSS_331

BP24

VSS_332

BP25

VSS_333

BP26

VSS_334

BP29

VSS_335

BP33

VSS_336

BP34

VSS_337

BP7

VSS_338

BR12

VSS_339

BR14

VSS_340

BR18

VSS_341

BR21

VSS_342

BR24

VSS_343

BR25

VSS_344

BR26

VSS_345

BR29

VSS_346

BR34

VSS_347

BR36

VSS_348

BR7

VSS_349

BT12

VSS_350

BT14

VSS_351

BT18

VSS_352

BT21

VSS_353

BT24

VSS_354

BT26

VSS_355

BT29

VSS_356

BT32

VSS_357

BT5

VSS_358

C11

VSS_359

C13

VSS_360

C15

VSS_361

C17

VSS_362

C19

VSS_363

C21

VSS_364

C23

VSS_365

C25

VSS_366

C27

VSS_367

C29

VSS_368

C31

VSS_369

C37

VSS_370

C5

VSS_371

C8

VSS_372

C9

VSS_373

D10

VSS_374

D12

VSS_375

D14

VSS_376

D16

VSS_377

D18

VSS_378

D20

VSS_379

D22

VSS_380

D24

VSS_381

D26

VSS_382

D28

VSS_383

D3

VSS_384

D30

VSS_385

D33

VSS_386

D6

VSS_387

D9

VSS_388

E34

VSS_389

E35

VSS_390

E38

VSS_391

E4

VSS_392

E9

VSS_393

N3

VSS_394

N33

VSS_395

N34

VSS_396

N4

VSS_397

N5

VSS_398

N6

VSS_399

N7

VSS_400

N8

VSS_401

N9

VSS_402

P12

VSS_403

P37

VSS_404

M14

VSS_405

M6

VSS_406

N1

VSS_407

F11

VSS_408

F13

VSS_409

F15

VSS_410

F17

VSS_411

F19

VSS_412

F2

VSS_413

F21

VSS_414

F23

VSS_415

F25

VSS_416

F27

VSS_417

F29

VSS_418

F3

VSS_419

F31

VSS_420

F36

VSS_421

F4

VSS_422

F5

VSS_423

F8

VSS_424

F9

VSS_425

G10

VSS_426

G12

VSS_427

G14

VSS_428

G16

VSS_429

G18

VSS_430

G20

VSS_431

G22

VSS_432

G23

VSS_433

G24

VSS_434

G26

VSS_435

G28

VSS_436

G4

VSS_437

G5

VSS_438

G6

VSS_439

G8

VSS_440

G9

VSS_441

H11

VSS_442

H12

VSS_443

H18

VSS_444

H22

VSS_445

H25

VSS_446

H32

VSS_447

H35

VSS_448

J10

VSS_449

J18

VSS_450

J22

VSS_451

J25

VSS_452

J32

VSS_453

J33

VSS_454

J36

VSS_455

J4

VSS_456

J7

VSS_457

K1

VSS_458

K10

VSS_459

K11

VSS_460

K2

VSS_461

K3

VSS_462

K38

VSS_463

K4

VSS_464

K5

VSS_465

K7

VSS_466

K8

VSS_467

K9

VSS_468

L29

VSS_469

L30

VSS_470

L33

VSS_471

L34

VSS_472

M12

VSS_473

M13

VSS_474

N10

VSS_475

N11

VSS_476

N12

VSS_477

N2

VSS_478

BT8

VSS_479

BR9

VSS_BT35

BT35

VSS_BT36

BT36

VSS_BR38

BR38

VSS_B37

B37

VSS_D38

D38

VSS_C2

C2

VSS_B3

B3

VSS_A3

A3

VSS_A4

A4

VSS_A34

A34

VSS_BT3

BT3

VSS_BT4

BT4

C293

10u_4V_X6S_06

C603

1u_6.3V_X6S_04

C529

1u_6.3V_X6S_04

C984

1u_6.3V_X6S_04

C520

*1u_6.3V_X6S_04

C168

10u_4V_X6S_06

C372

22u_6.3V_X6S_08

C987

*1u_6.3V_X6S_04

C985

*1u_6.3V_X6S_04

Sheet 7 of 67

Processor 6/6

Processor 6/6

B.Schematic Diagrams

B - 8 Processor 6/6

DDR4 CHA SO-DIMM

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

Channel A SO-DIMM 0[RAM1]

PLACE THE CAP WITHIN 200 MILS FROM THE SODIMM

PLACE THE CAP CLOSE TO SODIMM

PLACE NEAR TO PIN

CHA_DIMM0=000
CHA_DIMM1=001
CHB_DIMM0=010
CHB_DIMM1=011

月

DIMM

䪗㒢㓦

RVS TYPE

H=5.2mm

000

Samuel change RVS H=4MM DIMM

D02_1107_Alex

VDDQ

VDDQ

VTT_MEM

VDDQ

3.3VS

2.5V

VDDQ

2.5V

VTT_MEM

VDDQ

VDDQ

DDR4_DRAMRST#9,33

2.5V9,50

DIMM_CA_CPU_VREF_A3

M_A_CS#13

M_A_CS#03

M_A_ODT13

M_A_ODT03

VDDQ6,9,33,48,50

3.3VS9,23,24,27,28,29,30,31,32,33,34,35,38,39,40,42,43,44,45,47,48,52,59,70,71

VTT_MEM9,50

M_A_A03
M_A_A13

M_A_A53

M_A_A33

M_A_A23

M_A_A73

M_A_A63

M_A_A43

M_A_A103

M_A_A83
M_A_A93

M_A_A123
M_A_A133

M_A_A113

M_A_RAS#3

M_A_WE#3

M_A_CAS#3

M_A_CKE13

M_A_CKE03

M_A_BA03

M_A_BG03
M_A_BG13

M_A_BA13

M_A_DQS#[3:0] 3

M_A_DQS[3:0] 3

M_A_CLK_DDR13

M_A_CLK_DDR#03

M_A_CLK_DDR03

M_A_CLK_DDR#13

DDR0_A_PARITY3

M_A_ACT#3

DDR0_A_ALERT#3

SMB_DATA_MAIN_DDR49,31

SMB_CLK_MAIN_DDR49,31

M_A_DQS[7:4] 3

M_A_DQS#[7:4] 3

M_A_DQ[63:0] 3

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[08] DDR4 CHA SO-DIMM_0

A3

874Tuesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[08] DDR4 CHA SO-DIMM_0

A3

874Tuesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[08] DDR4 CHA SO-DIMM_0

A3

874Tuesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

C813

1u_6.3V_X5R_02

R416 2_1%_04

C785

1u_6.3V_X5R_02

C816

10u_6.3V_X5R_06

C858

10u_6.3V_X5R_06

R417

1K_1%_04

R422

24.9_1%_04

C821

10u_6.3V_X5R_06

C852

10u_6.3V_X5R_06

R415

1K_1%_04

C811

*0.1u_10V_X7R_04

C812

1u_6.3V_X5R_02

C794

0.1u_10V_X7R_04

C817

10u_6.3V_X5R_06

C841

1u_6.3V_X5R_02

C820

10u_6.3V_X5R_06

C814

1u_6.3V_X5R_02

C789

2.2u_6.3V_X5R_04

C834

1u_6.3V_X5R_02

J_DIMMA_1A

D4AR0-26001-1P40

CK0_T

137

CK0_C

139

CK1_T

138

CK1_C

140

CKE0

109

CKE1

110

S0*

149

S1*

157

ODT0

155

ODT1

161

BG0

115

BG1

113

BA0

150

BA1

145

A0

144

A1

133

A2

132

A3

131

A4

128

A5

126

A6

127

A7

122

A8

125

A9

121

A10_AP

146

A11

120

A12

119

A13

158

A14_WE*

151

A15_CAS*

156

A16_RAS*

152

ACT*

114

PARITY

143

ALERT*

116

EVENT*

134

RESET*

108

VREFCA

164

SDA

254

SCL

253

SA2

166

SA1

260

SA0

256

CB0_NC

92

CB1_NC

91

CB2_NC

101

CB3_NC

105

CB4_NC

88

CB5_NC

87

CB6_NC

100

CB7_NC

104

DM0*/DBI0*

12

DM1*/DBI1*

33

DM2*/DBI2*

54

DM3*/DBI3*

75

DM4*/DBI4*

178

DM5*/DBI5*

199

DM6*/DBI6*

220

DM7*/DBI7*

241

DM8*/DBI8*

96

S2*/C0

162

S3*/C1

165

DQ0

8

DQ1

7

DQ2

20

DQ3

21

DQ4

4

DQ5

3

DQ6

16

DQ7

17

DQ8

28

DQ9

29

DQ10

41

DQ11

42

DQ12

24

DQ13

25

DQ14

38

DQ15

37

DQ16

50

DQ17

49

DQ18

62

DQ19

63

DQ20

46

DQ21

45

DQ22

58

DQ23

59

DQ24

70

DQ25

71

DQ26

83

DQ27

84

DQ28

66

DQ29

67

DQ30

79

DQ31

80

DQ32

174

DQ33

173

DQ34

187

DQ35

186

DQ36

170

DQ37

169

DQ38

183

DQ39

182

DQ40

195

DQ41

194

DQ42

207

DQ43

208

DQ44

191

DQ45

190

DQ46

203

DQ47

204

DQ48

216

DQ49

215

DQ50

228

DQ51

229

DQ52

211

DQ53

212

DQ54

224

DQ55

225

DQ56

237

DQ57

236

DQ58

249

DQ59

250

DQ60

232

DQ61

233

DQ62

245

DQ63

246

DQS0_T

13

DQS1_T

34

DQS2_T

55

DQS3_T

76

DQS4_T

179

DQS5_T

200

DQS6_T

221

DQS7_T

242

DQS8_T

97

DQS0_C

11

DQS1_C

32

DQS2_C

53

DQS3_C

74

DQS4_C

177

DQS5_C

198

DQS6_C

219

DQS7_C

240

DQS8_C

95

C810

*0.1u_10V_X7R_04

C791

10u_6.3V_X5R_06

C843

1u_6.3V_X5R_02

C819

0.022u_25V_X7R_04

C815

1u_6.3V_X5R_02

J_DIMMA_1B

D4AR0-26001-1P40

VDD19

163

VDD18

160

VDD17

159

VDD16

154

VDD15

153

VDD14

148

VDD13

147

VDD12

142

VDD11

141

VDD10

136

VDD9

135

VDD8

130

VDD7

129

VDD6

124

VDD5

123

VDD4

118

VDD3

117

VDD2

112

VDD1

111

VSS

251

VSS

247

VSS

243

VSS

239

VSS

235

VSS

231

VSS

227

VSS

223

VSS

217

VSS

213

VSS

209

VSS

205

VSS

201

VSS

197

VSS

193

VSS

189

VSS

185

VSS

181

VSS

175

VSS

171

VSS

167

VSS

107

VSS

103

VSS

99

VSS

93

VSS

89

VSS

85

VSS

81

VSS

77

VSS

73

VSS

69

VSS

65

VSS

61

VSS

57

VSS

51

VSS

47

VSS

43

VSS

39

VSS

35

VSS

31

VSS

27

VSS

23

VSS

19

VSS

15

VSS

9

VSS

5

VSS

1

VTT

258

VPP2

259

VPP1

257

VDDSPD

255

MT1

GND1

MT2

GND2

VSS

252

VSS

248

VSS

244

VSS

238

VSS

234

VSS

230

VSS

226

VSS

222

VSS

218

VSS

214

VSS

210

VSS

206

VSS

202

VSS

196

VSS

192

VSS

188

VSS

184

VSS

180

VSS

176

VSS

172

VSS

168

VSS

106

VSS

102

VSS

98

VSS

94

VSS

90

VSS

86

VSS

82

VSS

78

VSS

72

VSS

68

VSS

64

VSS

60

VSS

56

VSS

52

VSS

48

VSS

44

VSS

40

VSS

36

VSS

30

VSS

26

VSS

22

VSS

18

VSS

14

VSS

10

VSS

6

VSS

2

R411

240_1%_04

C790

10u_6.3V_X5R_06

DDR4_DRAMRST#

DDR_VREFCA_CHA_DIMM

M_A_DQ0

M_A_DQ25

M_A_DQ24

M_A_DQ23

M_A_DQ33

M_A_DQ32

M_A_DQ39

M_A_DQ38

M_A_DQ37

M_A_DQ36

M_A_DQS#4

M_A_DQS#7

M_A_DQS#3

M_A_DQS#1

M_A_DQS#0

M_A_DQS#6

M_A_DQS#5

M_A_DQS#2

M_A_DQS4

M_A_DQS2

M_A_DQS1

M_A_DQS3

M_A_DQS7

M_A_DQS5

M_A_DQS0

M_A_DQS6

DDR4_DRAMRST#

DDR_VREFCA_CHA_DIMM

DDR_VREFCA_CHA_DIMM

M_A_DQ6

M_A_DQ7

M_A_DQ44

M_A_DQ3
M_A_DQ2

M_A_DQ5

M_A_DQ1

M_A_DQ4

M_A_DQ10

M_A_DQ9

M_A_DQ15

M_A_DQ13

M_A_DQ14

M_A_DQ12

M_A_DQ11

M_A_DQ8

M_A_DQ16

M_A_DQ18

M_A_DQ17

M_A_DQ20

M_A_DQ21

M_A_DQ19

M_A_DQ22

M_A_DQ26

M_A_DQ27

M_A_DQ29
M_A_DQ31

M_A_DQ30

M_A_DQ28

M_A_DQ35

M_A_DQ34

M_A_DQ40

M_A_DQ45

M_A_DQ41

M_A_DQ42

M_A_DQ46

M_A_DQ47

M_A_DQ43

M_A_DQ48
M_A_DQ49

M_A_DQ52
M_A_DQ55

M_A_DQ53

M_A_DQ51

M_A_DQ50

M_A_DQ58

M_A_DQ57

M_A_DQ56

M_A_DQ63
M_A_DQ62

M_A_DQ61

M_A_DQ60

M_A_DQ59

M_A_DQ54

DIMM0_CHA_EVENT#

Sheet 8 of 67

DDR4 CHA SO-

DIMM

Schematic Diagrams

B.Schematic Diagrams

DDR4 CHA SO-DIMM B - 9

Schematic Diagrams

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

Channel B SO-DIMM 0[RAM2]

PLACE NEAR TO PIN

PLACE THE CAP WITHIN 200 MILS FROM THE SODIMM

PLACE THE CAP CLOSE TO SODIMM

H=5.2mm

STD TYPE

CHA_DIMM0=000
CHA_DIMM1=001
CHB_DIMM0=010
CHB_DIMM1=011

010

月

DIMM

䪗㒢㓦

Samuel change RVS H=8MM DIMM

D02_1107_Alex

VDDQ

VTT_MEM

2.5V

3.3VS

VDDQ

VDDQ

2.5V

3.3VS

VDDQ

VDDQ

VDDQ

VTT_MEM

SMB_DATA_MAIN_DDR48,31

SMB_CLK_MAIN_DDR48,31

M_B_ODT03
M_B_ODT13

M_B_CS#03
M_B_CS#13

M_B_CKE03
M_B_CKE13

M_B_CLK_DDR13

M_B_CLK_DDR#13

M_B_CLK_DDR03

M_B_CLK_DDR#03

M_B_RAS#3

M_B_CAS#3

M_B_WE#3

M_B_BG13

M_B_BG03

M_B_BA03
M_B_BA13

5VS27,29,31,43,44,45,46,47,70,71,72

M_B_A13

M_B_A03

M_B_A23
M_B_A33

M_B_A53

M_B_A43

M_B_A63
M_B_A73

M_B_A93

M_B_A83

M_B_A103
M_B_A113

M_B_A133

M_B_A123

DDR1_B_PARITY3

M_B_ACT#3

DDR1_B_ALERT#3

DDR4_DRAMRST#8,33

M_B_DQ[63:0] 3

M_B_DQS[3:0] 3

M_B_DQS#[3:0] 3

VDDQ6,8,33,48,50

VTT_MEM8,50

DIMM_DQ_CPU_VREF_B3

3.3VA4,30,31,32,33,36,38,44,48,53

3.3VS8,23,24,27,28,29,30,31,32,33,34,35,38,39,40,42,43,44,45,47,48,52,59,70,71

2.5V8,50

M_B_DQS[7:4] 3

M_B_DQS#[7:4] 3

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[09] DDR4 CHB SO-DIMM_0

A3

974Tuesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[09] DDR4 CHB SO-DIMM_0

A3

974Tuesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[09] DDR4 CHB SO-DIMM_0

A3

974Tuesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

C832

1u_6.3V_X5R_02

C827

1u_6.3V_X5R_02

R430

1K_1%_04

C829

1u_6.3V_X5R_02

C859

*0.1u_10V_X7R_04

R431 2_1%_04

R423

240_1%_04

J_DIMMB_1A

D4AR0-26001-1P80

_

CK0_T

137

CK0_C

139

CK1_T

138

CK1_C

140

CKE0

109

CKE1

110

S0*

149

S1*

157

ODT0

155

ODT1

161

BG0

115

BG1

113

BA0

150

BA1

145

A0

144

A1

133

A2

132

A3

131

A4

128

A5

126

A6

127

A7

122

A8

125

A9

121

A10_AP

146

A11

120

A12

119

A13

158

A14_WE*

151

A15_CAS*

156

A16_RAS*

152

ACT*

114

PARITY

143

ALERT*

116

EVENT*

134

RESET*

108

VREFCA

164

SDA

254

SCL

253

SA2

166

SA1

260

SA0

256

CB0_NC

92

CB1_NC

91

CB2_NC

101

CB3_NC

105

CB4_NC

88

CB5_NC

87

CB6_NC

100

CB7_NC

104

DM0*/DBI0*

12

DM1*/DBI1*

33

DM2*/DBI2*

54

DM3*/DBI3*

75

DM4*/DBI4*

178

DM5*/DBI5*

199

DM6*/DBI6*

220

DM7*/DBI7*

241

DM8*/DBI8*

96

S2*/C0

162

S3*/C1

165

DQ0

8

DQ1

7

DQ2

20

DQ3

21

DQ4

4

DQ5

3

DQ6

16

DQ7

17

DQ8

28

DQ9

29

DQ10

41

DQ11

42

DQ12

24

DQ13

25

DQ14

38

DQ15

37

DQ16

50

DQ17

49

DQ18

62

DQ19

63

DQ20

46

DQ21

45

DQ22

58

DQ23

59

DQ24

70

DQ25

71

DQ26

83

DQ27

84

DQ28

66

DQ29

67

DQ30

79

DQ31

80

DQ32

174

DQ33

173

DQ34

187

DQ35

186

DQ36

170

DQ37

169

DQ38

183

DQ39

182

DQ40

195

DQ41

194

DQ42

207

DQ43

208

DQ44

191

DQ45

190

DQ46

203

DQ47

204

DQ48

216

DQ49

215

DQ50

228

DQ51

229

DQ52

211

DQ53

212

DQ54

224

DQ55

225

DQ56

237

DQ57

236

DQ58

249

DQ59

250

DQ60

232

DQ61

233

DQ62

245

DQ63

246

DQS0_T

13

DQS1_T

34

DQS2_T

55

DQS3_T

76

DQS4_T

179

DQS5_T

200

DQS6_T

221

DQS7_T

242

DQS8_T

97

DQS0_C

11

DQS1_C

32

DQS2_C

53

DQS3_C

74

DQS4_C

177

DQS5_C

198

DQS6_C

219

DQS7_C

240

DQS8_C

95

J_DIMMB_1B

D4AR0-26001-1P80

VDD19

163

VDD18

160

VDD17

159

VDD16

154

VDD15

153

VDD14

148

VDD13

147

VDD12

142

VDD11

141

VDD10

136

VDD9

135

VDD8

130

VDD7

129

VDD6

124

VDD5

123

VDD4

118

VDD3

117

VDD2

112

VDD1

111

VSS

251

VSS

247

VSS

243

VSS

239

VSS

235

VSS

231

VSS

227

VSS

223

VSS

217

VSS

213

VSS

209

VSS

205

VSS

201

VSS

197

VSS

193

VSS

189

VSS

185

VSS

181

VSS

175

VSS

171

VSS

167

VSS

107

VSS

103

VSS

99

VSS

93

VSS

89

VSS

85

VSS

81

VSS

77

VSS

73

VSS

69

VSS

65

VSS

61

VSS

57

VSS

51

VSS

47

VSS

43

VSS

39

VSS

35

VSS

31

VSS

27

VSS

23

VSS

19

VSS

15

VSS

9

VSS

5

VSS

1

VTT

258

VPP2

259

VPP1

257

VDDSPD

255

MT1

GND1

MT2

GND2

VSS

252

VSS

248

VSS

244

VSS

238

VSS

234

VSS

230

VSS

226

VSS

222

VSS

218

VSS

214

VSS

210

VSS

206

VSS

202

VSS

196

VSS

192

VSS

188

VSS

184

VSS

180

VSS

176

VSS

172

VSS

168

VSS

106

VSS

102

VSS

98

VSS

94

VSS

90

VSS

86

VSS

82

VSS

78

VSS

72

VSS

68

VSS

64

VSS

60

VSS

56

VSS

52

VSS

48

VSS

44

VSS

40

VSS

36

VSS

30

VSS

26

VSS

22

VSS

18

VSS

14

VSS

10

VSS

6

VSS

2

C830

1u_6.3V_X5R_02

C828

*1u_6.3V_X5R_02

C856

10u_6.3V_X5R_06

C818

10u_6.3V_X5R_06

R429

1K_1%_04

C793

10u_6.3V_X5R_06

C826

1u_6.3V_X5R_02

R433

24.9_1%_04

C865

0.1u_10V_X7R_04

C825

1u_6.3V_X5R_02

C855

2.2u_6.3V_X5R_04

C798

10u_6.3V_X5R_06

C849

1u_6.3V_X5R_02

C854

10u_6.3V_X5R_06

C860

*0.1u_10V_X7R_04

C853

10u_6.3V_X5R_06

C864

0.022u_25V_X7R_04

C836

10u_6.3V_X5R_06

C857

*10u_6.3V_X5R_06

C846

1u_6.3V_X5R_02

M_B_DQS0
M_B_DQS1
M_B_DQS2
M_B_DQS3
M_B_DQS4
M_B_DQS5
M_B_DQS6
M_B_DQS7

M_B_DQS#0
M_B_DQS#1
M_B_DQS#2
M_B_DQS#3
M_B_DQS#4
M_B_DQS#5
M_B_DQS#6
M_B_DQS#7

DIMM0_CHB_EVENT#
DDR4_DRAMRST#

DDR_VREFCA_CHB_DIMM

DDR4_DRAMRST#

DDR_VREFCA_CHB_DIMM

M_B_DQ26

M_B_DQ48
M_B_DQ49

M_B_DQ14

M_B_DQ15
M_B_DQ8

M_B_DQ11

DDR_VREFCA_CHB_DIMM

M_B_DQ0

M_B_DQ2

M_B_DQ5

M_B_DQ7

M_B_DQ4

M_B_DQ1

M_B_DQ3

M_B_DQ6

M_B_DQ9

M_B_DQ10

M_B_DQ12

M_B_DQ13

M_B_DQ16

M_B_DQ18

M_B_DQ21

M_B_DQ19

M_B_DQ22

M_B_DQ23

M_B_DQ20

M_B_DQ31
M_B_DQ29

M_B_DQ17

M_B_DQ30

M_B_DQ24

M_B_DQ25

M_B_DQ27

M_B_DQ28

M_B_DQ35

M_B_DQ39

M_B_DQ32

M_B_DQ37

M_B_DQ34

M_B_DQ38

M_B_DQ36

M_B_DQ33

M_B_DQ41

M_B_DQ45

M_B_DQ46
M_B_DQ43

M_B_DQ40

M_B_DQ44

M_B_DQ42

M_B_DQ47

M_B_DQ54

M_B_DQ53
M_B_DQ50

M_B_DQ52

M_B_DQ61

M_B_DQ62

M_B_DQ60

M_B_DQ59

M_B_DQ57

M_B_DQ56
M_B_DQ63

M_B_DQ58

M_B_DQ51

M_B_DQ55

Sheet 9 of 67

DDR4 CHB SO-

DIMM

DDR4 CHB SO-DIMM

B.Schematic Diagrams

B - 10 DDR4 CHB SO-DIMM

VGA PCI Express

1

1

2

2

3

3

4

4

5

5

A A

B B

C C

D D

NV PCI EXPRESS

6-34-T80VS-023

Place Under GPU

Place between
GPU and PS

GND

1V8_AONNV3V3

1V8_RUN

1V8_RUN

PEX_VDD

PEG_TX12

PEG_TX22

PEG_TX#72

PEG_RX22

PEG_TX#02

PEG_TX32

PEG_TX#22

PEG_RX12

PEG_RX72

PEG_RX42

PEG_TX#12

PEG_TX#52

PEG_TX#42

PEG_RX#62

PEG_RX#02

PEG_RX62

PEG_RX32

PEG_RX#52

PEG_RX#12

PEG_TX62

PEG_RX#72

PEG_RX52

PEG_RX02

PEG_TX42

PEG_TX72

PEG_RX#22

PEG_RX#32

PEG_TX52

PEG_RX#42

PEG_TX02

PEG_TX#32

PEG_TX#62

VGA_PEXCLK35
VGA_PEXCLK#35

PEG_CLKREQ#35

GPU_PEX_RST#23,24

3.3V2,24,28,41,43,47,48,50,51,54,57,58,59,68,69

PEX_VDD22,58

NV3V323,29,56,59,60,72

NVVDD_PWRGD24,56

1V8_AON12,13,14,15,17,18,20,21,22,23,24,25,56,59,60,72

1V8_RUN11,21,23,60

Title

Size Document Nu mber Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[10] VGA PCI Express

Custom

10 74Tuesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Nu mber Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[10] VGA PCI Express

Custom

10 74Tuesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Nu mber Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[10] VGA PCI Express

Custom

10 74Tuesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

C215

1u_6.3V_X6S_02

NV_0201_LARGE

C170

1u_6.3V_X6S_02

NV_0201_LARGE

C103 0.22u_10V_X5R_04

C116 0.22u_10V_X5R_04

C153

1u_6.3V_X6S_02

NV_0201_LARGE

R518 2.49K_1%_04

C210

1u_6.3V_X6S_02

NV_0201_LARGE

C386

10U_4V_X6S_06

NV_0603

C217

1u_6.3V_X6S_02

NV_0201_LARGE

C220

*0.47u_4V_X6S_02

NV_0201_LARGE

R63

10K_04

C218

*0.47u_4V_X6S_02

NV_0201_LARGE

C206

1u_6.3V_X6S_02

NV_0201_LARGE

C110 0.22u_10V_X5R_04

C107 0.22u_10V_X5R_04

C207

1u_6.3V_X6S_02

NV_0201_LARGE

C358

10U_4V_X6S_06

NV_0603

C162

*0.47U_4V_X6S_02

NV_0201_LARGE

C204

1u_6.3V_X6S_02

NV_0201_LARGE

C317

*0.47u_4V_X6S_02

NV_0201_LARGE

C109 0.22u_10V_X5R_04

C102 0.22u_10V_X5R_04

C78

4.7u_6.3V_X6S_06

NV_0603

C341

*0.47u_4V_X6S_02

NV_0201_LARGE

C410

4.7u_6.3V_X6S_06

NV_0603

C214

4.7u_6.3V_X6S_06

NV_0603

C161

1u_6.3V_X6S_02

NV_0201_LARGE

C118 0.22u_10V_X5R_04

C399

10U_4V_X6S_06

NV_0603

C120 0.22u_10V_X5R_04

C377

22u_4V_X6S_06

NV_0603

C953

4.7u_6.3V_X6S_06

NV_0603

C114 0.22u_10V_X5R_04

C205

*0.47u_4V_X6S_02

NV_0201_LARGE

C80

10U_4V_X6S_06

NV_0603

C320

22u_4V_X6S_06

NV_0603

C105 0.22u_10V_X5R_04

H22

H5_7D3_7

C208

*0.47U_4V_X6S_02

NV_0201_LARGE

C197

*0.47u_4V_X6S_02

NV_0201_LARGE

C70

22u_4V_X6S_06

NV_0603

C191
*0.47u_4V_X6S_02

NV_0201_LARGE

R61

*10K_04

C950

10U_4V_X6S_06

NV_0603

C108 0.22u_10V_X5R_04

C117 0.22u_10V_X5R_04

Q13
2SK3018S3

G

D S

H15

H5_7D3_7

C209
1u_6.3V_X6S_02

NV_0201_LARGE

C195

0.47U_4V_X6S_02

NV_0201_LARGE

C75

10U_4V_X6S_06

NV_0603

C146

*0.47u_4V_X6S_02

NV_0201_LARGE

C115 0.22u_10V_X5R_04

H16

H5_7D3_7

R62

*10K_04

C176

1u_6.3V_X6S_02

NV_0201_LARGE

C353

4.7u_6.3V_X6S_06

NV_0603

C196

1u_6.3V_X6S_02

NV_0201_LARGE

1/22 PCI_EXPRESS

BGA2228

?

G1A

COMMON

BK42

PEX_RX15

BL42

PEX_RX15

BG41

PEX_TX15

BH41

PEX_TX15

BM42

PEX_RX14

BM41

PEX_RX14

BG39

PEX_TX14

BF39

PEX_TX14

BL41

PEX_RX13

BK41

PEX_RX13

BE38

PEX_TX13

BF38

PEX_TX13

BK39

PEX_RX12

BL39

PEX_RX12

BH38

PEX_TX12

BG38

PEX_TX12

BM39

PEX_RX11

BM38

PEX_RX11

BG36

PEX_TX11

BF36

PEX_TX11

BL38

PEX_RX10

BK38

PEX_RX10

BE35

PEX_TX10

BF35

PEX_TX10

BK36

PEX_RX9

BL36

PEX_RX9

BH35

PEX_TX9

BG35

PEX_TX9

BM36

PEX_RX8

BM35

PEX_RX8

BG33

PEX_TX8

BF33

PEX_TX8

BL35

PEX_RX7

BK35

PEX_RX7

BE32

PEX_TX7

BF32

PEX_TX7

BK33

PEX_RX6

BL33

PEX_RX6

BH32

PEX_TX6

BG32

PEX_TX6

BM33

PEX_RX5

BM32

PEX_RX5

BG30

PEX_TX5

BF30

PEX_TX5

BL32

PEX_RX4

BK32

PEX_RX4

BE29

PEX_TX4

BF29

PEX_TX4

BK30

PEX_RX3

BL30

PEX_RX3

BH29

PEX_TX3

BG29

PEX_TX3

BM30

PEX_RX2

BM29

PEX_RX2

BG27

PEX_TX2

BF27

PEX_TX2

BL29

PEX_RX1

BK29

PEX_RX1

BE26

PEX_TX1

BF26

PEX_TX1

BK27

PEX_RX0

BL27

PEX_RX0

BH26

PEX_TX0

BG26

PEX_TX0

BM27

PEX_REFCLK

BM26

PEX_REFCLK

BL26

PEX_CLKREQ

BK26

PEX_RST

BK44

PEX_WAKE

BL44

PEX_TERMP

BB30

PEX_PLL_HVDD

BD30

PEX_HVDD

BD27

PEX_HVDD

BC32

PEX_HVDD

BC30

PEX_HVDD

BC29

PEX_HVDD

BC27

PEX_HVDD

BC26

PEX_HVDD

BB32

PEX_HVDD

BB29

PEX_HVDD

BB27

PEX_HVDD

BB26

PEX_HVDD

BC33

PEX_CVDD

BB33

PEX_CVDD

BD36

PEX_DVDD

BD33

PEX_DVDD

BC36

PEX_DVDD

BC35

PEX_DVDD

BB36

PEX_DVDD

BB35

PEX_DVDD

C955

22u_6.3V_X6S_08

M-C0805

C119 0.22u_10V_X5R_04

C221

1u_6.3V_X6S_02

NV_0201_LARGE

C344

4.7u_6.3V_X6S_06

NV_0603

H21

H5_7D3_7

C79

4.7u_6.3V_X6S_06

NV_0603

C211

*0.47U_4V_X6S_02

NV_0201_LARGE

C323

1u_6.3V_X6S_02

NV_0201_LARGE

C104 0.22u_10V_X5R_04

C113 0.22u_10V_X5R_04

C194

*0.47u_4V_X6S_02

NV_0201_LARGE

R134 0_04

NV_0402

C172

*0.47u_4V_X6S_02

NV_0201_LARGE

C219

1u_6.3V_X6S_02

NV_0201_LARGE

PEX_TERMP

PEX_RX3#

PEX_RX2#PEX_RX2#

PEX_RX6#

PEX_RX4#

PEX_RX1#

PEX_RX5#

PEX_RX0#

PEX_RX4

PEX_RX3

PEX_RX7

PEX_RX6

PEX_RX7#

PEX_RX5

PEX_RX1

PEX_RX2

PEX_RX0

VGA_PEXCLK
VGA_PEXCLK#

PEX_CLKREQ#

PEX_PLL_HVDD

Sheet 10 of 67

VGA PCI Express

Schematic Diagrams

B.Schematic Diagrams

VGA PCI Express B - 11

Schematic Diagrams

1

1

2

2

3

3

4

4

5

5

6

6

7

7

8

8

A A

B B

C C

D D

PAGE3: GPU FRAME BUFFER PARTITION A/B

CMD3 RAS*

A5_BA1

WE*

CMD9

CAS*

CKE*

RST*

A1_A9

A0_A10

A12_RFU

ABI*

A6_A11

A7_A8

A5_BA1

A4_BA2

A2_BA0

A3_BA3

CS*

CMD26

CMD27

CMD28

CMD30

CMD31

ch1 32..63ch0 0..31

CMD0

CMD7

CAS*

A12_RFU

RST*

RAS*

A1_A9

A0_A10

WE*

A7_A8

CMD11

CMD12

CMD13

CMD14

CMD15

CMD16

CMD20

CMD21

CMD24

CMD1

CMD2

CMD4

CMD5

CMD6

CMD8

CMD10

CMD22

CMD25

CMD29

CMD17

CMD18

ABI*

A6_A11

CMD23

CS*

CMD19

A4_BA2

A3_BA3

A2_BA0

CKE*

PLACE AT BALLS

GB3B-256

GDDR5 Mode F Mapping

※

P6xxRA Frame A,Bᶵᶲẞ(㔜枩 ␐怲暞ẞᶵᶲẞ )

PLACE AT BALLS

1.55V

1.55V

Place near GPU

GND

GND

FBVDDQ

FBVDDQ

GND

GND

GND

FBVDDQ

GND

FBVDDQ

1V8_RUN

FBA_CMD[33..0] 12,13

FBA_EDC[7..0] 12,13

FBA_DBI[7..0] 12,13

FBA_D[63..0] 12,13

FBA_CLK0 12
FBA_CLK0* 12
FBA_CLK1 13
FBA_CLK1* 13

FBB_EDC[7..0] 14,15

FBB_CMD[33..0] 14,15

FBB_DBI[7..0] 14,15

FBB_D[63..0] 14,15

FBB_CLK1* 15

FBB_CLK0* 14

FBB_CLK0 14

FBB_CLK1 15

FB_PLL_AVDD 16

FBVDDQ12,13,14,15,16,17,18,19,25, 59

1V8_RUN10,21,23,60

FBA_WCK01 12
FBA_WCK01* 12

FBA_WCK23 12
FBA_WCK23* 12

FBA_WCK45 13
FBA_WCK45* 13

FBA_WCK67 13
FBA_WCK67* 13

FBA_WCKB01 12
FBA_WCKB01* 12

FBA_WCKB23 12
FBA_WCKB23* 12

FBA_WCKB45 13
FBA_WCKB45* 13

FBA_WCKB67 13
FBA_WCKB67* 13

FBB_WCK23* 14

FBB_WCK01* 14

FBB_WCK67 15

FBB_WCK45 15

FBB_WCK23 14

FBB_WCK01 14

FBB_WCK67* 15

FBB_WCK45* 15

FBB_WCKB01* 14

FBB_WCKB01 14

FBB_WCKB23* 14

FBB_WCKB23 14

FBB_WCKB45 15
FBB_WCKB45* 15

FBB_WCKB67 15
FBB_WCKB67* 15

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[11] GPU Frame Buffer Partition

Custom

11 74T uesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[11] GPU Frame Buffer Partition

Custom

11 74T uesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[11] GPU Frame Buffer Partition

Custom

11 74T uesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

L7

HCB1608KF-300T60

R242
10K_04

C492

22u_4V_X6S_06

NV_0603

R539

60.4_1%_04

3/22 FBB

COMMON

BGA2228

?

G1C

Y23

GND

Y22

GND

Y21

GND

Y20

GND

Y19

GND

Y18

GND

Y17

GND

Y16

GND

F51

FBB_DQS_WP7

D51

FBB_DQS_WP6

J48

FBB_DQS_WP5

P50

FBB_DQS_WP4

H38

FBB_DQS_WP3

G44

FBB_DQS_WP2

E35

FBB_DQS_WP1

B33

FBB_DQS_WP0

H50

FBB_DQM7

D50

FBB_DQM6

L48

FBB_DQM5

P49

FBB_DQM4

G39

FBB_DQM3

E44

FBB_DQM2

E33

FBB_DQM1

C32

FBB_DQM0

H52

FBB_D63

H49

FBB_D62

J51

FBB_D61

H51

FBB_D60

H48

FBB_D59

J50

FBB_D58

D52

FBB_D57

F50

FBB_D56

F48

FBB_D55

F49

FBB_D54

E50

FBB_D53

E49

FBB_D52

C49

FBB_D51

C48

FBB_D50

C50

FBB_D49

D48

FBB_D48

M47

FBB_D47

M48

FBB_D46

L47

FBB_D45

M46

FBB_D44

L49

FBB_D43

L52

FBB_D42

L51

FBB_D41

L50

FBB_D40

P46

FBB_D39

R46

FBB_D38

P52

FBB_D37

P47

FBB_D36

M49

FBB_D35

M51

FBB_D34

P48

FBB_D33

M50

FBB_D32

E36

FBB_D31

D36

FBB_D30

E38

FBB_D29

F38

FBB_D28

D39

FBB_D27

E39

FBB_D26

F39

FBB_D25

E41

FBB_D24

H41

FBB_D23

F42

FBB_D22

E42

FBB_D21

D42

FBB_D20

G45

FBB_D19

F45

FBB_D18

D45

FBB_D17

E45

FBB_D16

G33

FBB_D15

J32

FBB_D14

D33

FBB_D13

F33

FBB_D12

F36

FBB_D11

J36

FBB_D10

G36

FBB_D9

H36

FBB_D8

F32

FBB_D7

J30

FBB_D6

G32

FBB_D5

E32

FBB_D4

B32

FBB_D3

A33

FBB_D2

D32

FBB_D1

H32

FBB_D0

L38

FBB_PLL_AVDD

J46

FBB_WCKB67

J47

FBB_WCKB67

H46

FBB_WCK67

H47

FBB_WCK67

M45

FBB_WCKB45

M44

FBB_WCKB45

L45

FBB_WCK45

L46

FBB_WCK45

G41

FBB_WCKB23

F41

FBB_WCKB23

H39

FBB_WCK23

J39

FBB_WCK23

H35

FBB_WCKB01

G35

FBB_WCKB01

H33

FBB_WCK01

J33

FBB_WCK01

E47

FBB_CLK1

F47

FBB_CLK1

G42

FBB_CLK0

H42

FBB_CLK0

J41

FBB_DBG_RFU2

J35

FBB_DBG_RFU1

B50

FBB_CMD35

C35

FBB_CMD34

A42

FBB_CMD33

D41

FBB_CMD32

B42

FBB_CMD31

C42

FBB_CMD30

C44

FBB_CMD29

B44

FBB_CMD28

A44

FBB_CMD27

D44

FBB_CMD26

A45

FBB_CMD25

B45

FBB_CMD24

C45

FBB_CMD23

C47

FBB_CMD22

B47

FBB_CMD21

A47

FBB_CMD20

D47

FBB_CMD19

A48

FBB_CMD18

A49

FBB_CMD17

B49

FBB_CMD16

A41

FBB_CMD15

B41

FBB_CMD14

C41

FBB_CMD13

C39

FBB_CMD12

B39

FBB_CMD11

A39

FBB_CMD10

D38

FBB_CMD9

A38

FBB_CMD8

B38

FBB_CMD7

C38

FBB_CMD6

C36

FBB_CMD5

B36

FBB_CMD4

A36

FBB_CMD3

D35

FBB_CMD2

A35

FBB_CMD1

B35

FBB_CMD0

C454

4.7U_6.3V_X6S_06

NV_0603

R215

60.4_1%_04

C574

0.47u_4V_X6S_02

NV_0201_LARGE

R684
10K_04

R164

60.4_1%_04

R136
10K_04

R179
10K_04

R617
10K_04

2/22 FBA

COMMON

BGA2228

?

G1B

L29

FB_REFPLL_AVDD1

AF42

FB_REFPLL_AVDD0

Y15

GND

Y14

GND

W8

GND

W6

GND

W51

GND

W49

GND

W47

GND

W45

GND

AR51

FBA_DQS_WP7

AK48

FBA_DQS_WP6

AT50

FBA_DQS_WP5

BB52

FBA_DQS_WP4

AA48

FBA_DQS_WP3

AF44

FBA_DQS_WP2

V48

FBA_DQS_WP1

R48

FBA_DQS_WP0

AR49

FBA_DQM7

AM48

FBA_DQM6

AV50

FBA_DQM5

BB51

FBA_DQM4

AC48

FBA_DQM3

AG47

FBA_DQM2

Y48

FBA_DQM1

U47

FBA_DQM0

AR46

FBA_D63

AR47

FBA_D62

AN47

FBA_D61

AR48

FBA_D60

AN46

FBA_D59

AN45

FBA_D58

AM45

FBA_D57

AM44

FBA_D56

AN49

FBA_D55

AN48

FBA_D54

AM46

FBA_D53

AM47

FBA_D52

AK49

FBA_D51

AJ47

FBA_D50

AJ46

FBA_D49

AJ48

FBA_D48

AV49

FBA_D47

AV52

FBA_D46

AV51

FBA_D45

AT46

FBA_D44

AT48

FBA_D43

AT47

FBA_D42

AT49

FBA_D41

AV48

FBA_D40

AW49

FBA_D39

BA49

FBA_D38

BB50

FBA_D37

BA50

FBA_D36

BA51

FBA_D35

AW50

FBA_D34

BA52

FBA_D33

AW51

FBA_D32

Y44

FBA_D31

AA45

FBA_D30

AA46

FBA_D29

AA47

FBA_D28

AC47

FBA_D27

AC46

FBA_D26

AD48

FBA_D25

AD49

FBA_D24

AD47

FBA_D23

AF48

FBA_D22

AF47

FBA_D21

AF46

FBA_D20

AG49

FBA_D19

AJ45

FBA_D18

AG48

FBA_D17

AJ44

FBA_D16

V51

FBA_D15

U52

FBA_D14

V47

FBA_D13

V50

FBA_D12

Y46

FBA_D11

Y47

FBA_D10

Y45

FBA_D9

V46

FBA_D8

U46

FBA_D7

R47

FBA_D6

R50

FBA_D5

R51

FBA_D4

U49

FBA_D3

U50

FBA_D2

U48

FBA_D1

U51

FBA_D0

AN42

FBA_PLL_AVDD

AT44

FBA_WCKB67

AT45

FBA_WCKB67

AR44

FBA_WCK67

AR45

FBA_WCK67

AW47

FBA_WCKB45

AW48

FBA_WCKB45

AV46

FBA_WCK45

AV47

FBA_WCK45

AD45

FBA_WCKB23

AD46

FBA_WCKB23

AC44

FBA_WCK23

AC45

FBA_WCK23

V44

FBA_WCKB01

V45

FBA_WCKB01

U44

FBA_WCK01

U45

FBA_WCK01

AK45

FBA_CLK1

AK46

FBA_CLK1

AG46

FBA_CLK0

AG45

FBA_CLK0

AN44

FBA_DBG_RFU2

AA44

FBA_DBG_RFU1

AR50

FBA_CMD35

Y50

FBA_CMD34

AG52

FBA_CMD33

AF49

FBA_CMD32

AG51

FBA_CMD31

AG50

FBA_CMD30

AJ50

FBA_CMD29

AJ51

FBA_CMD28

AJ52

FBA_CMD27

AJ49

FBA_CMD26

AK52

FBA_CMD25

AK51

FBA_CMD24

AK50

FBA_CMD23

AM50

FBA_CMD22

AM51

FBA_CMD21

AM52

FBA_CMD20

AM49

FBA_CMD19

AN52

FBA_CMD18

AN51

FBA_CMD17

AN50

FBA_CMD16

AF52

FBA_CMD15

AF51

FBA_CMD14

AF50

FBA_CMD13

AD50

FBA_CMD12

AD51

FBA_CMD11

AD52

FBA_CMD10

AC49

FBA_CMD9

AC52

FBA_CMD8

AC51

FBA_CMD7

AC50

FBA_CMD6

AA50

FBA_CMD5

AA51

FBA_CMD4

AA52

FBA_CMD3

Y49

FBA_CMD2

Y52

FBA_CMD1

Y51

FBA_CMD0

R300
10K_04

C481

4.7U_6.3V_X6S_06

NV_0603

R609
10K_04

R222

60.4_1%_04

C573

0.47u_4V_X6S_02

NV_0201_LARGE

C391

1u_6.3V_X6S_02

NV_0201_LARGE

C581

0.47u_4V_X6S_02

NV_0201_LARGE

R105
10K_04

FBA_CLK0

DP_FBA_CLK0

FB_CLK

FBA_CLK0#

DP_FBA_CLK0

FB_CLK

FBA_CLK1

DP_FBA_CLK1

FB_CLK

FBA_CLK1#

DP_FBA_CLK1

FB_CLK

FBA_CMD0

FBA_CMD10
FBA_CMD11
FBA_CMD12
FBA_CMD13
FBA_CMD14
FBA_CMD15
FBA_CMD16
FBA_CMD17
FBA_CMD18
FBA_CMD19

FBA_CMD1

FBA_CMD20
FBA_CMD21
FBA_CMD22
FBA_CMD23
FBA_CMD24
FBA_CMD25
FBA_CMD26
FBA_CMD27
FBA_CMD28
FBA_CMD29

FBA_CMD2

FBA_CMD30

FBA_CMD[33..0]

FBA_CMD31

FBA_CMD3
FBA_CMD4
FBA_CMD5
FBA_CMD6
FBA_CMD7
FBA_CMD8
FBA_CMD9

FBA_D0

FBA_D10
FBA_D11
FBA_D12
FBA_D13
FBA_D14
FBA_D15
FBA_D16
FBA_D17
FBA_D18
FBA_D19

FBA_D1

FBA_D20
FBA_D21
FBA_D22
FBA_D23
FBA_D24
FBA_D25
FBA_D26
FBA_D27
FBA_D28
FBA_D29

FBA_D2

FBA_D30
FBA_D31
FBA_D32
FBA_D33
FBA_D34
FBA_D35
FBA_D36
FBA_D37
FBA_D38
FBA_D39

FBA_D3

FBA_D40
FBA_D41
FBA_D42
FBA_D43
FBA_D44
FBA_D45
FBA_D46
FBA_D47
FBA_D48
FBA_D49

FBA_D4

FBA_D50
FBA_D51
FBA_D52
FBA_D53
FBA_D54
FBA_D55
FBA_D56
FBA_D57
FBA_D58
FBA_D59

FBA_D5

FBA_D60
FBA_D61
FBA_D62
FBA_D63

FBA_D6
FBA_D7
FBA_D8
FBA_D9

FBA_DBI0
FBA_DBI1
FBA_DBI2
FBA_DBI3
FBA_DBI4
FBA_DBI5
FBA_DBI6
FBA_DBI7

FBA_EDC0
FBA_EDC1
FBA_EDC2
FBA_EDC3
FBA_EDC4
FBA_EDC5
FBA_EDC6
FBA_EDC7

FBB_CLK0

DP_FBB_CLK0 FB_CLK

FBB_CLK0#

DP_FBB_CLK0 FB_CLK

FBB_CLK1

DP_FBB_CLK1 FB_CLK

FBB_CLK1#

DP_FBB_CLK1 FB_CLK

FBB_CMD0

FBB_CMD10
FBB_CMD11
FBB_CMD12
FBB_CMD13
FBB_CMD14
FBB_CMD15
FBB_CMD16
FBB_CMD17
FBB_CMD18
FBB_CMD19

FBB_CMD1

FBB_CMD20
FBB_CMD21
FBB_CMD22
FBB_CMD23
FBB_CMD24
FBB_CMD25
FBB_CMD26
FBB_CMD27
FBB_CMD28
FBB_CMD29

FBB_CMD2

FBB_CMD30
FBB_CMD31

FBB_CMD3
FBB_CMD4
FBB_CMD5
FBB_CMD6
FBB_CMD7
FBB_CMD8
FBB_CMD9

FBB_D0

FBB_D10
FBB_D11
FBB_D12
FBB_D13
FBB_D14
FBB_D15
FBB_D16
FBB_D17
FBB_D18
FBB_D19

FBB_D1

FBB_D20
FBB_D21
FBB_D22
FBB_D23
FBB_D24
FBB_D25
FBB_D26
FBB_D27
FBB_D28
FBB_D29

FBB_D2

FBB_D30
FBB_D31
FBB_D32
FBB_D33
FBB_D34
FBB_D35
FBB_D36
FBB_D37
FBB_D38
FBB_D39

FBB_D3

FBB_D40
FBB_D41
FBB_D42
FBB_D43
FBB_D44
FBB_D45
FBB_D46
FBB_D47
FBB_D48
FBB_D49

FBB_D4

FBB_D50
FBB_D51
FBB_D52
FBB_D53
FBB_D54
FBB_D55
FBB_D56
FBB_D57
FBB_D58
FBB_D59

FBB_D5

FBB_D60
FBB_D61
FBB_D62
FBB_D63

FBB_D6
FBB_D7
FBB_D8
FBB_D9

FBB_DBI0
FBB_DBI1
FBB_DBI2
FBB_DBI3
FBB_DBI4
FBB_DBI5
FBB_DBI6
FBB_DBI7

FBB_EDC0
FBB_EDC1
FBB_EDC2
FBB_EDC3
FBB_EDC4
FBB_EDC5
FBB_EDC6
FBB_EDC7 FB_PLL_AVDD

FB_PLL_AVDD

FBA_EDC[7..0]

FBA_DBI[7..0]

FBA_D[63..0]

FBB_EDC[7..0]

FBB_DBI[7..0]

FBB_D[63..0]

FBB_CMD[33..0]

FBA_DEBUG0
FBA_DEBUG1

FBB_DEBUG0
FBB_DEBUG1

FBB_CMD26

FBB_CMD18

FBB_CMD10

FBB_CMD2

FBA_CMD26

FBA_CMD18

FBA_CMD10

FBA_CMD2

FBA_WCK01

80DIFF_NETCLASS1FBA_WCK01

FBA_WCK01#

FBA_WCK01 80DIFF_NETCLASS1

FBA_WCK23

FBA_WCK23 80DIFF_NETCLASS1

FBA_WCK23#

80DIFF_NETCLASS1FBA_WCK23

FBA_WCK45

FBA_WCK45 80DIFF_NETCLASS1

FBA_WCK45#

80DIFF_NETCLASS1FBA_WCK45

FBA_WCK67

FBA_WCK67 80DIFF_NETCLASS1

FBA_WCK67#

FBA_WCK67 80DIFF_NETCLASS1

FBA_WCKB01

FBA_WCKB01 80DIFF_NETCLASS1

FBA_WCKB01#

FBA_WCKB01 80DIFF_NETCLASS1

FBA_WCKB23

80DIFF_NETCLASS1FBA_WCKB23

FBA_WCKB23#

80DIFF_NETCLASS1FBA_WCKB23

FBA_WCKB45

FBA_WCKB45 80DIFF_NETCLASS1

FBA_WCKB45#

80DIFF_NETCLASS1FBA_WCKB45

FBA_WCKB67

FBA_WCKB67 80DIFF_NETCLASS1

FBA_WCKB67#

80DIFF_NETCLASS1FBA_WCKB67

FBB_WCK01

80DIFF_NETCLASS1FBB_WCK01

FBB_WCK01#

80DIFF_NETCLASS1FBB_WCK01

FBB_WCK23

80DIFF_NETCLASS1FBB_WCK23

FBB_WCK23#

FBB_WCK23 80DIFF_NETCLASS1

FBB_WCK45

80DIFF_NETCLASS1FBB_WCK45

FBB_WCK45#

80DIFF_NETCLASS1FBB_WCK45

FBB_WCK67

80DIFF_NETCLASS1FBB_WCK67

FBB_WCK67#

80DIFF_NETCLASS1FBB_WCK67

FBB_WCKB01

80DIFF_NETCLASS1FBB_WCKB01

FBB_WCKB01#

80DIFF_NETCLASS1FBB_WCKB01

FBB_WCKB23

80DIFF_NETCLASS1FBB_WCKB23

FBB_WCKB23#

80DIFF_NETCLASS1FBB_WCKB23

FBB_WCKB45

80DIFF_NETCLASS1FBB_WCKB45

FBB_WCKB45#

80DIFF_NETCLASS1FBB_WCKB45

FBB_WCKB67

FBB_WCKB67 80DIFF_NETCLASS1

FBB_WCKB67#

FBB_WCKB67 80DIFF_NETCLASS1

FBA_CMD32
FBA_CMD33

FBB_CMD33

FBB_CMD32

FB_PLL_AVDD

Sheet 11 of 67

GPU Frame Buffer

A/B

GPU Frame Buffer A/B

B - 12 GPU Frame Buffer A/B

B.Schematic Diagrams

Frame Buffer A

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

FRAME BUFFER PARTITION A 31..0

VRAM=K4G80325FB-HC03, HC28

FBVDDQ

Close to DRAM

Around DRAM

Right under DRAM

Around DRAM

OPTION, Under DRAM

Right under DRAM

Close to DRAM

Close to DRAM

FBVDDQ

FBVDDQ

FBVDDQ

1V8_AON

FBVDDQ

FBVDDQ

FBVDDQ

FBVDDQ

FBVDDQ

1V8_AON

FBVDDQ

FBVDDQ

FBVDDQ

GPIO10_FBVREF_SEL14,17,23

FBA_CLK0*11
FBA_CLK011

FBA_VREFC 13

FBA_WCK0111
FBA_WCK01*11
FBA_WCK2311
FBA_WCK23*11

FBA_WCKB0111
FBA_WCKB01*11
FBA_WCKB2311
FBA_WCKB23*11

FBA_D[31..0]11

FBA_CMD[15..0]11

FBA_DBI[3..0]11

FBA_EDC[3..0]11

FBVDDQ11,13,14,15,16,17,18,19,25,59

1V8_AON10,13,14,15,17,18,20,21,22,23,24,25,56,59,60,72

FBA_CMD3211

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

A3

12 74Tuesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

[12]MEMORY FBA 31..0

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

A3

12 74Tuesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

[12]MEMORY FBA 31..0

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

A3

12 74Tuesday, February 18, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

[12]MEMORY FBA 31..0

C526

1u_6.3V_X6S_04

C347

1u_6.3V_X6S_04

C730

10u_4V_X6S_06

T34

C1044

1u_6.3V_X6S_04

M6C

U_MEM_SG_GDDR6

P/N =

J10

CLK_t

K10

CLK_c

J1

RESET

M10

CKE_B

K5

CABI_B

K3

CA9_B

K4

CA8_B

K11

CA7_B

K12

CA6_B

L10

CA5_B

L5

CA4_B

L12

CA3_B

M4

CA2_B

M11

CA1_B

L3

CA0_B

G10

CKE_A

J5

CABI_A

J3

CA9_A

J4

CA8_A

J11

CA7_A

J12

CA6_A

H10

CA5_A

H5

CA4_A

H12

CA3_A

G4

CA2_A

G11

CA1_A

H3

CA0_A

M5

RFU_B

G5

RFU_A

K14

ZQ_B

J14

ZQ_A

F5

TMS

N10

TDO

F10

TDI

N5

TCK

K1

VREFC

C741

22u_6.3V_X6S_08

T33

C1119

1u_6.3V_X6S_04

C282

1u_6.3V_X6S_04

NC

NC

x16

NC

NC

NC

NC

NC

NC

NC

NC

NC

x8

GND

NORMAL

M6A

U_MEM_SG_GDDR6

P/N =

D10

WCK1_c_A

D11

WCK1_t_A

D13

DBI1_A

C13

EDC1_A

A12

DQ9_A

B13

DQ11_A

B12

DQ10_A

E12

DQ12_A

F13

DQ14_A

E13

DQ13_A

G13

DQ15_A

B11

DQ8_A

D5

WCK0_c_A

D4

WCK0_t_A

D2

DBI0_A

C2

EDC0_A

B3

DQ2_A

B2

DQ3_A

E3

DQ4_A

G2

DQ7_A

B4

DQ0_A

E2

DQ5_A

F2

DQ6_A

A3

DQ1_A

M6D

U_MEM_SG_GDDR6

P/N =

V4

VSS

V2

VSS

V13

VSS

V11

VSS

U14

VSS

U1

VSS

T5

VSS

T3

VSS

T12

VSS

T10

VSS

R3

VSS

R14

VSS

R12

VSS

R1

VSS

P4

VSS

P11

VSS

N3

VSS

N14

VSS

N12

VSS

N1

VSS

M3

VSS

M14

VSS

M12

VSS

M1

VSS

L4

VSS

L11

VSS

H4

VSS

H11

VSS

G3

VSS

G14

VSS

G12

VSS

G1

VSS

F3

VSS

F14

VSS

F12

VSS

F1

VSS

E4

VSS

E11

VSS

D3

VSS

D14

VSS

D12

VSS

D1

VSS

C5

VSS

C3

VSS

C12

VSS

C10

VSS

B14

VSS

B1

VSS

A4

VSS

A2

VSS

A13

VSS

A11

VSS

V5

VPP

V10

VPP

A5

VPP

A10

VPP

U5

VDDQ

U10

VDDQ

T4

VDDQ

T14

VDDQ

T11

VDDQ

T1

VDDQ

P14

VDDQ

P1

VDDQ

N4

VDDQ

N11

VDDQ

L14

VDDQ

L1

VDDQ

K2

VDDQ

K13

VDDQ

J2

VDDQ

J13

VDDQ

H14

VDDQ

H1

VDDQ

F4

VDDQ

F11

VDDQ

E14

VDDQ

E1

VDDQ

C4

VDDQ

C14

VDDQ

C11

VDDQ

C1

VDDQ

B5

VDDQ

B10

VDDQ

V14

VDD

V1

VDD

P5

VDD

P10

VDD

L2

VDD

L13

VDD

H2

VDD

H13

VDD

E5

VDD

E10

VDD

A14

VDD

A1

VDD

C1045

1u_6.3V_X6S_04

T29

NC

NC

NC

GND

NORMAL

NC

NC

NC

x16

NC

NC

x8

NC

NC

NC

M6B

U_MEM_SG_GDDR6

P/N =

R10

WCK1_c_B

R11

WCK1_t_B

R13

DBI1_B

T13

EDC1_B

M13

DQ15_B

N13

DQ14_B

P13

DQ13_B

P12

DQ12_B

U13

DQ11_B

U12

DQ10_B

V12

DQ9_B

U11

DQ8_B

R5

WCK0_c_B

R4

WCK0_t_B

R2

DBI0_B

T2

EDC0_B

M2

DQ7_B

N2

DQ6_B

P2

DQ5_B

P3

DQ4_B

U2

DQ3_B

U3

DQ2_B

V3

DQ1_B

U4

DQ0_B

C142

1u_6.3V_X6S_04

C1053

10u_4V_X6S_06

C645

22u_6.3V_X6S_08

R108

*931_1%_04

C973

1u_6.3V_X6S_04

C201

1u_6.3V_X6S_04

C1000

1u_6.3V_X6S_04

C337

4.7u_6.3V_X6S_06

C496

1u_6.3V_X6S_04

C1054

22u_4V_X6S_06

C1007

1u_6.3V_X6S_04

R107

*549_1%_04

C1058

22u_4V_X6S_06

C644

22u_6.3V_X6S_08

T28

C473

1u_6.3V_X6S_04

C1027

1u_6.3V_X6S_04

C1057

10u_4V_X6S_06

C580

1u_6.3V_X6S_04

C249

1u_6.3V_X6S_04

C1056

10u_4V_X6S_06

C455

1u_6.3V_X6S_04

C1001

1u_6.3V_X6S_04

C152

*820p_50V_X7R_04

C577

1u_6.3V_X6S_04

C1079

10u_4V_X6S_06

T31

C426

1u_6.3V_X6S_04

C1006

1u_6.3V_X6S_04

C1055

22u_4V_X6S_06

Q52
*MTN2002ZS3

G

DS

R106

1K_1%_04

R561

121_1%_04

C576

1u_6.3V_X6S_04

C416

1u_6.3V_X6S_04

C726

1u_6.3V_X6S_04

R157

121_1%_04

C310

1u_6.3V_X6S_04

T30

C534

1u_6.3V_X6S_04

C383

1u_6.3V_X6S_04

C1061

1u_6.3V_X6S_04

C1059

10u_4V_X6S_06

FBA_CMD9

FBA_CMD0

FBA_CMD3

FBA_CMD14

FBA_CMD11

FBA_CMD8

FBA_CMD10

FBA_CMD1
FBA_CMD6

FBA_CMD32

FBA_DBI0

FBA_EDC0

FBA_D4
FBA_D7
FBA_D1
FBA_D5
FBA_D3
FBA_D6
FBA_D2
FBA_D0

FBA_D8
FBA_D15

FBA_EDC1

FBA_WCKB01
FBA_WCKB01*

FBA_D13
FBA_D14
FBA_D12
FBA_D10
FBA_D11
FBA_D9

FBA_DBI1

FBA_WCK01
FBA_WCK01*

FBA_WCK23
FBA_WCK23*

FBA_WCKB23
FBA_WCKB23*

FBA_D30
FBA_D29
FBA_D28
FBA_D31
FBA_D25
FBA_D27
FBA_D24
FBA_D26

FBA_DBI2

FBA_EDC2

FBA_DBI3

FBA_EDC3

FBA_D23
FBA_D22
FBA_D20
FBA_D17
FBA_D21
FBA_D16
FBA_D19
FBA_D18

FBA_CMD7

FBA_CMD15

FBA_VREFC

FBA_CMD2

FBA_CMD4
FBA_CMD12
FBA_CMD5
FBA_CMD13
FBA_CMD7
FBA_CMD11
FBA_CMD15
FBA_CMD14
FBA_CMD3
FBA_CMD1
FBA_CMD6
FBA_CMD10

FBA_VREFC

SNN_FBAL_TCK_M
SNN_FBAL_TDI_M
SNN_FBAL_TDO_M
SNN_FBAL_TMS_M

FBA_ZQ_1_A
FBA_ZQ_1_B

SNN_FBAL_RFU_A_M
SNN_FBAL_RFU_B_M

FBA_WCK01
FBA_WCK01*
FBA_WCK23
FBA_WCK23*

FBA_WCKB01
FBA_WCKB01*
FBA_WCKB23
FBA_WCKB23*

FBA_DBI[3..0]

FBA_EDC[3..0]

FBA_CMD[15..0]

FBA_D[31..0]

FBA_CMD32

Sheet 12 of 67

Frame Buffer A

Schematic Diagrams

B.Schematic Diagrams

Frame Buffer A B - 13

Schematic Diagrams

Sheet 13 of 67

Frame Buffer A

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

FRAME BUFFER PARTITION A 63..32

VRAM=K4G80325FB-HC03, HC28

FBVDDQ

FBVDDQ

1V8_AON

FBA_CLK1*11
FBA_CLK111

FBA_WCK4511
FBA_WCK45*11
FBA_WCK6711
FBA_WCK67*11

FBA_WCKB4511
FBA_WCKB45*11
FBA_WCKB6711
FBA_WCKB67*11 FBA_D[63..32]11

FBA_CMD[31..16]11

FBA_DBI[7..4]11

FBA_EDC[7..4]11

FBA_VREFC 12

FBVDDQ11,12,14,15,16,17,18,19,25,59

1V8_AON10,12,14,15,17,18,20,21,22,23,24,25,56,59,60,72

FBA_CMD3311

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

A3

13 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

[13]MEMORY FBA 63..32

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

A3

13 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

[13]MEMORY FBA 63..32

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

A3

13 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

[13]MEMORY FBA 63..32

R154

121_1%_04

NC

NC

NC

GND

NORMAL

NC

NC

NC

x16

NC

NC

x8

NC

NC

NC

M5B

U_MEM_SG_GDDR6

P/N =

R10

WCK1_c_B

R11

WCK1_t_B

R13

DBI1_B

T13

EDC1_B

M13

DQ15_B

N13

DQ14_B

P13

DQ13_B

P12

DQ12_B

U13

DQ11_B

U12

DQ10_B

V12

DQ9_B

U11

DQ8_B

R5

WCK0_c_B

R4

WCK0_t_B

R2

DBI0_B

T2

EDC0_B

M2

DQ7_B

N2

DQ6_B

P2

DQ5_B

P3

DQ4_B

U2

DQ3_B

U3

DQ2_B

V3

DQ1_B

U4

DQ0_B

T14

M5C

U_MEM_SG_GDDR6

P/N =

J10

CLK_t

K10

CLK_c

J1

RESET

M10

CKE_B

K5

CABI_B

K3

CA9_B

K4

CA8_B

K11

CA7_B

K12

CA6_B

L10

CA5_B

L5

CA4_B

L12

CA3_B

M4

CA2_B

M11

CA1_B

L3

CA0_B

G10

CKE_A

J5

CABI_A

J3

CA9_A

J4

CA8_A

J11

CA7_A

J12

CA6_A

H10

CA5_A

H5

CA4_A

H12

CA3_A

G4

CA2_A

G11

CA1_A

H3

CA0_A

M5

RFU_B

G5

RFU_A

K14

ZQ_B

J14

ZQ_A

F5

TMS

N10

TDO

F10

TDI

N5

TCK

K1

VREFC

R153

121_1%_04

T16

M5D

U_MEM_SG_GDDR6

P/N =

V4

VSS

V2

VSS

V13

VSS

V11

VSS

U14

VSS

U1

VSS

T5

VSS

T3

VSS

T12

VSS

T10

VSS

R3

VSS

R14

VSS

R12

VSS

R1

VSS

P4

VSS

P11

VSS

N3

VSS

N14

VSS

N12

VSS

N1

VSS

M3

VSS

M14

VSS

M12

VSS

M1

VSS

L4

VSS

L11

VSS

H4

VSS

H11

VSS

G3

VSS

G14

VSS

G12

VSS

G1

VSS

F3

VSS

F14

VSS

F12

VSS

F1

VSS

E4

VSS

E11

VSS

D3

VSS

D14

VSS

D12

VSS

D1

VSS

C5

VSS

C3

VSS

C12

VSS

C10

VSS

B14

VSS

B1

VSS

A4

VSS

A2

VSS

A13

VSS

A11

VSS

V5

VPP

V10

VPP

A5

VPP

A10

VPP

U5

VDDQ

U10

VDDQ

T4

VDDQ

T14

VDDQ

T11

VDDQ

T1

VDDQ

P14

VDDQ

P1

VDDQ

N4

VDDQ

N11

VDDQ

L14

VDDQ

L1

VDDQ

K2

VDDQ

K13

VDDQ

J2

VDDQ

J13

VDDQ

H14

VDDQ

H1

VDDQ

F4

VDDQ

F11

VDDQ

E14

VDDQ

E1

VDDQ

C4

VDDQ

C14

VDDQ

C11

VDDQ

C1

VDDQ

B5

VDDQ

B10

VDDQ

V14

VDD

V1

VDD

P5

VDD

P10

VDD

L2

VDD

L13

VDD

H2

VDD

H13

VDD

E5

VDD

E10

VDD

A14

VDD

A1

VDD

T12

T19
T11

NC

NC

x16

NC

NC

NC

NC

NC

NC

NC

NC

NC

x8

GND

NORMAL

M5A

U_MEM_SG_GDDR6

P/N =

D10

WCK1_c_A

D11

WCK1_t_A

D13

DBI1_A

C13

EDC1_A

A12

DQ9_A

B13

DQ11_A

B12

DQ10_A

E12

DQ12_A

F13

DQ14_A

E13

DQ13_A

G13

DQ15_A

B11

DQ8_A

D5

WCK0_c_A

D4

WCK0_t_A

D2

DBI0_A

C2

EDC0_A

B3

DQ2_A

B2

DQ3_A

E3

DQ4_A

G2

DQ7_A

B4

DQ0_A

E2

DQ5_A

F2

DQ6_A

A3

DQ1_A

T13

FBA_CMD28

FBA_CMD20

FBA_CMD19

FBA_CMD31

FBA_CMD27

FBA_CMD21

FBA_CMD26

FBA_CMD17
FBA_CMD22

FBA_CMD29

FBA_DBI4

FBA_EDC4

FBA_D39
FBA_D35
FBA_D32
FBA_D38
FBA_D34
FBA_D33
FBA_D37
FBA_D36

FBA_D43
FBA_D46

FBA_EDC5

FBA_WCKB45
FBA_WCKB45*

FBA_D44
FBA_D42
FBA_D45
FBA_D40
FBA_D41
FBA_D47

FBA_DBI5

FBA_WCK45
FBA_WCK45*

FBA_WCK67
FBA_WCK67*

FBA_WCKB67
FBA_WCKB67*

FBA_D57
FBA_D56
FBA_D59
FBA_D58
FBA_D61
FBA_D60
FBA_D63
FBA_D62

FBA_DBI6

FBA_EDC6

FBA_DBI7

FBA_EDC7

FBA_CMD23

FBA_CMD30

FBA_CMD18

FBA_CMD16
FBA_CMD25
FBA_CMD24
FBA_CMD33
FBA_CMD23
FBA_CMD27
FBA_CMD30
FBA_CMD31
FBA_CMD19
FBA_CMD17
FBA_CMD22
FBA_CMD26

SNN_FBAU_TCK_M
SNN_FBAU_TDI_M
SNN_FBAU_TDO_M
SNN_FBAU_TMS_M

FBA_ZQ_2_A
FBA_ZQ_2_B

SNN_FBAU_RFU_A
SNN_FBAU_RFU_B

FBA_WCK45
FBA_WCK45*
FBA_WCK67
FBA_WCK67*

FBA_WCKB45
FBA_WCKB45*
FBA_WCKB67
FBA_WCKB67*

FBA_DBI[7..4]

FBA_EDC[7..4]

FBA_CMD[31..16]

FBA_D[63..32]

FBA_CMD33

FBA_D49

FBA_D48

FBA_D50
FBA_D53

FBA_D52
FBA_D51
FBA_D54
FBA_D55

Frame Buffer A

B.Schematic Diagrams

B - 14 Frame Buffer A

Frame Buffer B

Sheet 14 of 67

Frame Buffer B

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

FRAME BUFFER PARTITION B 31..0

VRAM=K4G80325FB-HC03, HC28

FBVDDQ

Close to DRAM

Around DRAM

Right under DRAM

Around DRAM

OPTION, Under DRAM

Right under DRAM

Close to DRAM

Close to DRAM

FBVDDQ

FBVDDQ

FBVDDQ

1V8_AON

FBVDDQ

FBVDDQ

FBVDDQ

FBVDDQ

FBVDDQ

1V8_AON

FBVDDQ

FBVDDQ

FBVDDQ

GPIO10_FBVREF_SEL12,17,23

FBB_CLK0*11
FBB_CLK011

FBB_VREFC 15

FBB_WCK0111
FBB_WCK01*11
FBB_WCK2311
FBB_WCK23*11

FBB_WCKB0111
FBB_WCKB01*11
FBB_WCKB2311
FBB_WCKB23*11

FBB_D[31..0]11

FBB_CMD[15..0]11

FBB_DBI[3..0]11

FBB_EDC[3..0]11

FBVDDQ11,12,13,15,16,17,18,19,25,59

1V8_AON10,12,13,15,17,18,20,21,22,23,24,25,56,59,60,72

FBB_CMD3211

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

A3

14 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

[14]MEMORY FBB 31..0

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

A3

14 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

[14]MEMORY FBB 31..0

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

A3

14 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

[14]MEMORY FBB 31..0

C311

1u_6.3V_X6S_04

C705

1u_6.3V_X6S_04

C476

1u_6.3V_X6S_04

M8D

U_MEM_SG_GDDR6

P/N =

V4

VSS

V2

VSS

V13

VSS

V11

VSS

U14

VSS

U1

VSS

T5

VSS

T3

VSS

T12

VSS

T10

VSS

R3

VSS

R14

VSS

R12

VSS

R1

VSS

P4

VSS

P11

VSS

N3

VSS

N14

VSS

N12

VSS

N1

VSS

M3

VSS

M14

VSS

M12

VSS

M1

VSS

L4

VSS

L11

VSS

H4

VSS

H11

VSS

G3

VSS

G14

VSS

G12

VSS

G1

VSS

F3

VSS

F14

VSS

F12

VSS

F1

VSS

E4

VSS

E11

VSS

D3

VSS

D14

VSS

D12

VSS

D1

VSS

C5

VSS

C3

VSS

C12

VSS

C10

VSS

B14

VSS

B1

VSS

A4

VSS

A2

VSS

A13

VSS

A11

VSS

V5

VPP

V10

VPP

A5

VPP

A10

VPP

U5

VDDQ

U10

VDDQ

T4

VDDQ

T14

VDDQ

T11

VDDQ

T1

VDDQ

P14

VDDQ

P1

VDDQ

N4

VDDQ

N11

VDDQ

L14

VDDQ

L1

VDDQ

K2

VDDQ

K13

VDDQ

J2

VDDQ

J13

VDDQ

H14

VDDQ

H1

VDDQ

F4

VDDQ

F11

VDDQ

E14

VDDQ

E1

VDDQ

C4

VDDQ

C14

VDDQ

C11

VDDQ

C1

VDDQ

B5

VDDQ

B10

VDDQ

V14

VDD

V1

VDD

P5

VDD

P10

VDD

L2

VDD

L13

VDD

H2

VDD

H13

VDD

E5

VDD

E10

VDD

A14

VDD

A1

VDD

C637

10u_4V_X6S_06

T52

C701

1u_6.3V_X6S_04

T57

R296

121_1%_04

C277

1u_6.3V_X6S_04

C627

10u_4V_X6S_06

C288

1u_6.3V_X6S_04

C722

1u_6.3V_X6S_04

C716

22u_6.3V_X6S_08

R700

*549_1%_04

C355

1u_6.3V_X6S_04

NC

NC

NC

GND

NORMAL

NC

NC

NC

x16

NC

NC

x8

NC

NC

NC

M8B

U_MEM_SG_GDDR6

P/N =

R10

WCK1_c_B

R11

WCK1_t_B

R13

DBI1_B

T13

EDC1_B

M13

DQ15_B

N13

DQ14_B

P13

DQ13_B

P12

DQ12_B

U13

DQ11_B

U12

DQ10_B

V12

DQ9_B

U11

DQ8_B

R5

WCK0_c_B

R4

WCK0_t_B

R2

DBI0_B

T2

EDC0_B

M2

DQ7_B

N2

DQ6_B

P2

DQ5_B

P3

DQ4_B

U2

DQ3_B

U3

DQ2_B

V3

DQ1_B

U4

DQ0_B

C405

1u_6.3V_X6S_04

C480

1u_6.3V_X6S_04

R703

*931_1%_04

C643

1u_6.3V_X6S_04

T68

C620

10u_4V_X6S_06

C742

22u_6.3V_X6S_08

C1110

*820p_50V_X7R_04

C409

1u_6.3V_X6S_04

C586

1u_6.3V_X6S_04

R290

1K_1%_04

C592

1u_6.3V_X6S_04

C394

1u_6.3V_X6S_04

C407

1u_6.3V_X6S_04

C653

4.7u_6.3V_X6S_06

C715

22u_6.3V_X6S_08

C183

1u_6.3V_X6S_04

T70

C729
1u_6.3V_X6S_04

C255

22u_6.3V_X6S_08

C735

22u_6.3V_X6S_08

R307

121_1%_04

C625

1u_6.3V_X6S_04

C569

10u_4V_X6S_06

Q69
*MTN2002ZS3

G

DS

C327

1u_6.3V_X6S_04

C610

1u_6.3V_X6S_04

NC

NC

x16

NC

NC

NC

NC

NC

NC

NC

NC

NC

x8

GND

NORMAL

M8A

U_MEM_SG_GDDR6

P/N =

D10

WCK1_c_A

D11

WCK1_t_A

D13

DBI1_A

C13

EDC1_A

A12

DQ9_A

B13

DQ11_A

B12

DQ10_A

E12

DQ12_A

F13

DQ14_A

E13

DQ13_A

G13

DQ15_A

B11

DQ8_A

D5

WCK0_c_A

D4

WCK0_t_A

D2

DBI0_A

C2

EDC0_A

B3

DQ2_A

B2

DQ3_A

E3

DQ4_A

G2

DQ7_A

B4

DQ0_A

E2

DQ5_A

F2

DQ6_A

A3

DQ1_A

C572

10u_4V_X6S_06

C626

1u_6.3V_X6S_04

C564

1u_6.3V_X6S_04

C727

1u_6.3V_X6S_04

C474

10u_4V_X6S_06

C408

1u_6.3V_X6S_04

T50

C683

1u_6.3V_X6S_04

C678

22u_4V_X6S_06

M8C

U_MEM_SG_GDDR6

P/N =

J10

CLK_t

K10

CLK_c

J1

RESET

M10

CKE_B

K5

CABI_B

K3

CA9_B

K4

CA8_B

K11

CA7_B

K12

CA6_B

L10

CA5_B

L5

CA4_B

L12

CA3_B

M4

CA2_B

M11

CA1_B

L3

CA0_B

G10

CKE_A

J5

CABI_A

J3

CA9_A

J4

CA8_A

J11

CA7_A

J12

CA6_A

H10

CA5_A

H5

CA4_A

H12

CA3_A

G4

CA2_A

G11

CA1_A

H3

CA0_A

M5

RFU_B

G5

RFU_A

K14

ZQ_B

J14

ZQ_A

F5

TMS

N10

TDO

F10

TDI

N5

TCK

K1

VREFC

C725

1u_6.3V_X6S_04

C617

1u_6.3V_X6S_04

T72

FBB_CMD9

FBB_CMD0

FBB_CMD3

FBB_CMD14

FBB_CMD11

FBB_CMD8

FBB_CMD10

FBB_CMD1
FBB_CMD6

FBB_CMD32

FBB_DBI0

FBB_EDC0

FBB_D1
FBB_D6
FBB_D2
FBB_D4
FBB_D5
FBB_D3
FBB_D0
FBB_D7

FBB_D13
FBB_D14

FBB_EDC1

FBB_WCKB01
FBB_WCKB01*

FBB_D12
FBB_D11
FBB_D15
FBB_D8
FBB_D9
FBB_D10

FBB_DBI1

FBB_WCK01
FBB_WCK01*

FBB_WCK23
FBB_WCK23*

FBB_WCKB23
FBB_WCKB23*

FBB_D24
FBB_D30
FBB_D29
FBB_D31
FBB_D25
FBB_D26
FBB_D27
FBB_D28

FBB_DBI2

FBB_EDC2

FBB_DBI3

FBB_EDC3

FBB_D21
FBB_D16
FBB_D20
FBB_D17
FBB_D18
FBB_D22
FBB_D23
FBB_D19

FBB_CMD7

FBB_CMD15

FBB_VREFC

FBB_CMD2

FBB_CMD4
FBB_CMD12
FBB_CMD5
FBB_CMD13
FBB_CMD7
FBB_CMD11
FBB_CMD15
FBB_CMD14
FBB_CMD3
FBB_CMD1
FBB_CMD6
FBB_CMD10

FBB_VREFC

SNN_FBBL_TCK_M
SNN_FBBL_TDI_M
SNN_FBBL_TDO_M
SNN_FBBL_TMS_M

FBB_ZQ_1_A
FBB_ZQ_1_B

SNN_FBBL_RFU_A_M
SNN_FBBL_RFU_B_M

FBB_WCK01
FBB_WCK01*
FBB_WCK23
FBB_WCK23*

FBB_WCKB01
FBB_WCKB01*
FBB_WCKB23
FBB_WCKB23*

FBB_DBI[3..0]

FBB_EDC[3..0]

FBB_CMD[15..0]

FBB_D[31..0]

FBB_CMD32

Schematic Diagrams

B.Schematic Diagrams

Frame Buffer B B - 15

Schematic Diagrams

Sheet 15 of 67

Frame Buffer B

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

FRAME BUFFER PARTITION B 63..32

VRAM=K4G80325FB-HC03, HC28

FBVDDQ

FBVDDQ

1V8_AON

FBB_CLK1*11

FBB_CLK111

FBB_WCK4511
FBB_WCK45*11
FBB_WCK6711
FBB_WCK67*11

FBB_WCKB4511
FBB_WCKB45*11
FBB_WCKB6711
FBB_WCKB67*11 FBB_D[63..32]11

FBB_CMD[31..16]11

FBB_DBI[7..4]11

FBB_EDC[7..4]11

FBB_VREFC 14

FBVDDQ11,12,13,14,16,17,18,19,25,59

1V8_AON10,12,13,14,17,18,20,21,22,23,24,25,56,59,60,72

FBB_CMD3311

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

A3

15 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

[15]MEMORY FBB 63..32

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

A3

15 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

[15]MEMORY FBB 63..32

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

A3

15 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

[15]MEMORY FBB 63..32

NC

NC

x16

NC

NC

NC

NC

NC

NC

NC

NC

NC

x8

GND

NORMAL

M7A

U_MEM_SG_GDDR6

P/N =

D10

WCK1_c_A

D11

WCK1_t_A

D13

DBI1_A

C13

EDC1_A

A12

DQ9_A

B13

DQ11_A

B12

DQ10_A

E12

DQ12_A

F13

DQ14_A

E13

DQ13_A

G13

DQ15_A

B11

DQ8_A

D5

WCK0_c_A

D4

WCK0_t_A

D2

DBI0_A

C2

EDC0_A

B3

DQ2_A

B2

DQ3_A

E3

DQ4_A

G2

DQ7_A

B4

DQ0_A

E2

DQ5_A

F2

DQ6_A

A3

DQ1_A

R266

121_1%_04

T43

T41

T40

R269

121_1%_04

T42

M7C

U_MEM_SG_GDDR6

P/N =

J10

CLK_t

K10

CLK_c

J1

RESET

M10

CKE_B

K5

CABI_B

K3

CA9_B

K4

CA8_B

K11

CA7_B

K12

CA6_B

L10

CA5_B

L5

CA4_B

L12

CA3_B

M4

CA2_B

M11

CA1_B

L3

CA0_B

G10

CKE_A

J5

CABI_A

J3

CA9_A

J4

CA8_A

J11

CA7_A

J12

CA6_A

H10

CA5_A

H5

CA4_A

H12

CA3_A

G4

CA2_A

G11

CA1_A

H3

CA0_A

M5

RFU_B

G5

RFU_A

K14

ZQ_B

J14

ZQ_A

F5

TMS

N10

TDO

F10

TDI

N5

TCK

K1

VREFC

NC

NC

NC

GND

NORMAL

NC

NC

NC

x16

NC

NC

x8

NC

NC

NC

M7B

U_MEM_SG_GDDR6

P/N =

R10

WCK1_c_B

R11

WCK1_t_B

R13

DBI1_B

T13

EDC1_B

M13

DQ15_B

N13

DQ14_B

P13

DQ13_B

P12

DQ12_B

U13

DQ11_B

U12

DQ10_B

V12

DQ9_B

U11

DQ8_B

R5

WCK0_c_B

R4

WCK0_t_B

R2

DBI0_B

T2

EDC0_B

M2

DQ7_B

N2

DQ6_B

P2

DQ5_B

P3

DQ4_B

U2

DQ3_B

U3

DQ2_B

V3

DQ1_B

U4

DQ0_B

M7D

U_MEM_SG_GDDR6

P/N =

V4

VSS

V2

VSS

V13

VSS

V11

VSS

U14

VSS

U1

VSS

T5

VSS

T3

VSS

T12

VSS

T10

VSS

R3

VSS

R14

VSS

R12

VSS

R1

VSS

P4

VSS

P11

VSS

N3

VSS

N14

VSS

N12

VSS

N1

VSS

M3

VSS

M14

VSS

M12

VSS

M1

VSS

L4

VSS

L11

VSS

H4

VSS

H11

VSS

G3

VSS

G14

VSS

G12

VSS

G1

VSS

F3

VSS

F14

VSS

F12

VSS

F1

VSS

E4

VSS

E11

VSS

D3

VSS

D14

VSS

D12

VSS

D1

VSS

C5

VSS

C3

VSS

C12

VSS

C10

VSS

B14

VSS

B1

VSS

A4

VSS

A2

VSS

A13

VSS

A11

VSS

V5

VPP

V10

VPP

A5

VPP

A10

VPP

U5

VDDQ

U10

VDDQ

T4

VDDQ

T14

VDDQ

T11

VDDQ

T1

VDDQ

P14

VDDQ

P1

VDDQ

N4

VDDQ

N11

VDDQ

L14

VDDQ

L1

VDDQ

K2

VDDQ

K13

VDDQ

J2

VDDQ

J13

VDDQ

H14

VDDQ

H1

VDDQ

F4

VDDQ

F11

VDDQ

E14

VDDQ

E1

VDDQ

C4

VDDQ

C14

VDDQ

C11

VDDQ

C1

VDDQ

B5

VDDQ

B10

VDDQ

V14

VDD

V1

VDD

P5

VDD

P10

VDD

L2

VDD

L13

VDD

H2

VDD

H13

VDD

E5

VDD

E10

VDD

A14

VDD

A1

VDD

T37
T38

FBB_CMD28

FBB_CMD20

FBB_CMD19

FBB_CMD31

FBB_CMD27

FBB_CMD21

FBB_CMD26

FBB_CMD17
FBB_CMD22

FBB_CMD29

FBB_DBI4

FBB_EDC4

FBB_D35
FBB_D33
FBB_D32
FBB_D36
FBB_D39
FBB_D34
FBB_D37
FBB_D38

FBB_D42
FBB_D43

FBB_EDC5

FBB_WCKB45
FBB_WCKB45*

FBB_D40
FBB_D45
FBB_D41
FBB_D44
FBB_D46
FBB_D47

FBB_DBI5

FBB_WCK45
FBB_WCK45*

FBB_WCK67

FBB_WCK67*

FBB_WCKB67

FBB_WCKB67*

FBB_D62

FBB_D59

FBB_D57

FBB_D63

FBB_D56

FBB_D61

FBB_D60

FBB_D58

FBB_DBI6

FBB_EDC6

FBB_DBI7

FBB_EDC7

FBB_D55

FBB_D48

FBB_D52

FBB_D50

FBB_D49

FBB_D51

FBB_D53

FBB_D54

FBB_CMD23

FBB_CMD30

FBB_CMD18

FBB_CMD16
FBB_CMD25
FBB_CMD24
FBB_CMD33
FBB_CMD23
FBB_CMD27
FBB_CMD30
FBB_CMD31
FBB_CMD19
FBB_CMD17
FBB_CMD22
FBB_CMD26

SNN_FBBU_TCK_M
SNN_FBBU_TDI_M
SNN_FBBU_TDO_M
SNN_FBBU_TMS_M

FBB_ZQ_2_A
FBB_ZQ_2_B

SNN_FBBU_RFU_A
SNN_FBBU_RFU_B

FBB_WCK45
FBB_WCK45*
FBB_WCK67
FBB_WCK67*

FBB_WCKB45
FBB_WCKB45*
FBB_WCKB67
FBB_WCKB67*

FBB_DBI[7..4]

FBB_EDC[7..4]

FBB_CMD[31..16]

FBB_CMD33

FBB_D[63..32]

Frame Buffer B

B.Schematic Diagrams

B - 16 Frame Buffer B

GPU Frame Buffer C/D

Sheet 16 of 67

GPU Frame Buffer

C/D

1

1

2

2

3

3

4

4

5

5

6

6

7

7

8

8

A A

B B

C C

D D

GPU FRAME BUFFER PARTITION C/D

※P6xxRE Frame Dᶵᶲẞ

GND

FBVDDQ

FBVDDQ

GND GND

GND

GND

FBC_EDC[7..0] 17,18

FBC_CMD[33..0] 17,18

FBC_DBI[7..0] 17,18

FBC_D[63..0] 17,18

FBC_CLK1* 18

FBC_CLK0* 17

FBC_CLK0 17

FBC_CLK1 18

FB_PLL_AVDD 11,16

FBVDDQ11,12,13,14,15,17,18,19,25,59

FB_PLL_AVDD 11,16

FBC_WCK23* 17

FBC_WCK01* 17

FBC_WCK67 18

FBC_WCK45 18

FBC_WCK23 17

FBC_WCK01 17

FBC_WCK67* 18

FBC_WCK45* 18

FBC_WCKB01* 17

FBC_WCKB01 17

FBC_WCKB23 17
FBC_WCKB23* 17

FBC_WCKB45 18
FBC_WCKB45* 18

FBC_WCKB67 18
FBC_WCKB67* 18

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[16] GPU Frame Buffer Partition

A3

16 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[16] GPU Frame Buffer Partition

A3

16 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[16] GPU Frame Buffer Partition

A3

16 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

4/22 FBC

COMMON

BGA2228

?

G1D

Y31

GND

Y30

GND

Y29

GND

Y28

GND

Y27

GND

Y26

GND

Y25

GND

Y24

GND

E24

FBC_DQS_WP7

G21

FBC_DQS_WP6

B29

FBC_DQS_WP5

E30

FBC_DQS_WP4

E12

FBC_DQS_WP3

E17

FBC_DQS_WP2

D8

FBC_DQS_WP1

D5

FBC_DQS_WP0

E26

FBC_DQM7

F20

FBC_DQM6

E27

FBC_DQM5

D29

FBC_DQM4

F12

FBC_DQM3

J18

FBC_DQM2

C8

FBC_DQM1

A5

FBC_DQM0

C26

FBC_D63

B26

FBC_D62

D26

FBC_D61

F26

FBC_D60

G26

FBC_D59

F24

FBC_D58

H26

FBC_D57

G24

FBC_D56

E23

FBC_D55

D21

FBC_D54

E21

FBC_D53

F23

FBC_D52

E20

FBC_D51

G20

FBC_D50

D18

FBC_D49

H20

FBC_D48

G29

FBC_D47

A27

FBC_D46

B27

FBC_D45

C27

FBC_D44

G27

FBC_D43

F27

FBC_D42

J26

FBC_D41

D27

FBC_D40

C30

FBC_D39

H30

FBC_D38

A30

FBC_D37

B30

FBC_D36

G30

FBC_D35

H29

FBC_D34

F30

FBC_D33

J29

FBC_D32

E11

FBC_D31

F11

FBC_D30

G11

FBC_D29

H11

FBC_D28

F14

FBC_D27

E14

FBC_D26

H15

FBC_D25

J15

FBC_D24

H17

FBC_D23

G17

FBC_D22

E15

FBC_D21

D15

FBC_D20

H18

FBC_D19

E18

FBC_D18

G18

FBC_D17

F18

FBC_D16

E6

FBC_D15

F6

FBC_D14

A8

FBC_D13

B8

FBC_D12

B9

FBC_D11

E9

FBC_D10

C9

FBC_D9

D9

FBC_D8

C4

FBC_D7

B3

FBC_D6

A4

FBC_D5

B4

FBC_D4

B6

FBC_D3

A6

FBC_D2

D6

FBC_D1

C6

FBC_D0

L17

FBC_PLL_AVDD

J24

FBC_WCKB67

H24

FBC_WCKB67

H23

FBC_WCK67

G23

FBC_WCK67

F29

FBC_WCKB45

E29

FBC_WCKB45

H27

FBC_WCK45

J27

FBC_WCK45

H14

FBC_WCKB23

G14

FBC_WCKB23

G12

FBC_WCK23

H12

FBC_WCK23

F9

FBC_WCKB01

G9

FBC_WCKB01

G8

FBC_WCK01

F8

FBC_WCK01

J21

FBC_CLK1

H21

FBC_CLK1

F15

FBC_CLK0

G15

FBC_CLK0

J23

FBC_DBG_RFU2

J14

FBC_DBG_RFU1

C24

FBC_CMD35

A9

FBC_CMD34

D17

FBC_CMD33

A17

FBC_CMD32

A18

FBC_CMD31

B18

FBC_CMD30

C18

FBC_CMD29

C20

FBC_CMD28

B20

FBC_CMD27

A20

FBC_CMD26

D20

FBC_CMD25

A21

FBC_CMD24

B21

FBC_CMD23

C21

FBC_CMD22

C23

FBC_CMD21

B23

FBC_CMD20

A23

FBC_CMD19

D23

FBC_CMD18

A24

FBC_CMD17

B24

FBC_CMD16

B17

FBC_CMD15

C17

FBC_CMD14

C15

FBC_CMD13

B15

FBC_CMD12

A15

FBC_CMD11

D14

FBC_CMD10

A14

FBC_CMD9

B14

FBC_CMD8

C14

FBC_CMD7

C12

FBC_CMD6

B12

FBC_CMD5

A12

FBC_CMD4

D11

FBC_CMD3

A11

FBC_CMD2

B11

FBC_CMD1

C11

FBC_CMD0

R285
10K_04

C447

0.47U_4V_X6S_02

NV_0201_LARGE

R163 0_04

R301
10K_04

C301

0.47U_4V_X6S_02

NV_0201_LARGE

N/AFBD

5/22 FBD

N18E-G3

G1E

?
BGA2228
COMMON

Y39

GND

Y38

GND

Y37

GND

Y36

GND

Y35

GND

Y34

GND

Y33

GND

Y32

GND

M5

FBD_DQS_WP7

U6

FBD_DQS_WP6

H2

FBD_DQS_WP5

E3

FBD_DQS_WP4

AF4

FBD_DQS_WP3

AA9

FBD_DQS_WP2

AG2

FBD_DQS_WP1

AJ3

FBD_DQS_WP0

M9

FBD_DQM7

U5

FBD_DQM6

H3

FBD_DQM5

D3

FBD_DQM4

AD5

FBD_DQM3

AA7

FBD_DQM2

AG1

FBD_DQM1

AJ1

FBD_DQM0

L5

FBD_D63

L4

FBD_D62

L6

FBD_D61

L7

FBD_D60

P5

FBD_D59

P4

FBD_D58

R9

FBD_D57

P6

FBD_D56

U8

FBD_D55

R6

FBD_D54

R5

FBD_D53

U4

FBD_D52

V9

FBD_D51

V6

FBD_D50

V8

FBD_D49

V7

FBD_D48

H5

FBD_D47

H4

FBD_D46

F2

FBD_D45

F1

FBD_D44

J2

FBD_D43

L8

FBD_D42

J4

FBD_D41

J5

FBD_D40

C2

FBD_D39

C3

FBD_D38

D1

FBD_D37

D2

FBD_D36

F5

FBD_D35

F3

FBD_D34

E1

FBD_D33

F4

FBD_D32

AF3

FBD_D31

AF2

FBD_D30

AF8

FBD_D29

AF7

FBD_D28

AD6

FBD_D27

AF6

FBD_D26

AC6

FBD_D25

AD7

FBD_D24

AC4

FBD_D23

AC5

FBD_D22

AA5

FBD_D21

AA6

FBD_D20

Y4

FBD_D19

V5

FBD_D18

Y5

FBD_D17

Y6

FBD_D16

AG5

FBD_D15

AJ6

FBD_D14

AJ5

FBD_D13

AJ4

FBD_D12

AG7

FBD_D11

AG6

FBD_D10

AF9

FBD_D9

AG4

FBD_D8

AK7

FBD_D7

AK9

FBD_D6

AK6

FBD_D5

AK5

FBD_D4

AK3

FBD_D3

AK2

FBD_D2

AK4

FBD_D1

AK8

FBD_D0

V11

FBD_PLL_AVDD

M8

FBD_WCKB67

M7

FBD_WCKB67

P7

FBD_WCK67

P8

FBD_WCK67

H6

FBD_WCKB45

H7

FBD_WCKB45

J7

FBD_WCK45

J6

FBD_WCK45

AC8

FBD_WCKB23

AC7

FBD_WCKB23

AD9

FBD_WCK23

AD8

FBD_WCK23

AG9

FBD_WCKB01

AG8

FBD_WCKB01

AJ7

FBD_WCK01

AJ8

FBD_WCK01

R7

FBD_CLK1

R8

FBD_CLK1

Y7

FBD_CLK0

Y8

FBD_CLK0

P9

FBD_DBG_RFU2

AC9

FBD_DBG_RFU1

J3

FBD_CMD35

AD3

FBD_CMD34

U1

FBD_CMD33

V4

FBD_CMD32

U2

FBD_CMD31

U3

FBD_CMD30

R3

FBD_CMD29

R2

FBD_CMD28

R1

FBD_CMD27

R4

FBD_CMD26

P1

FBD_CMD25

P2

FBD_CMD24

P3

FBD_CMD23

M3

FBD_CMD22

M2

FBD_CMD21

M1

FBD_CMD20

M4

FBD_CMD19

L1

FBD_CMD18

L2

FBD_CMD17

L3

FBD_CMD16

V1

FBD_CMD15

V2

FBD_CMD14

V3

FBD_CMD13

Y3

FBD_CMD12

Y2

FBD_CMD11

Y1

FBD_CMD10

AA4

FBD_CMD9

AA1

FBD_CMD8

AA2

FBD_CMD7

AA3

FBD_CMD6

AC3

FBD_CMD5

AC2

FBD_CMD4

AC1

FBD_CMD3

AD4

FBD_CMD2

AD1

FBD_CMD1

AD2

FBD_CMD0

R214

60.4_1%_04

R217

60.4_1%_04

R686
10K_04

R664
10K_04

FBC_CLK0

DP_FBC_CLK0 FB_CLK

FBC_CLK0#

DP_FBC_CLK0 FB_CLK

FBC_CLK1

DP_FBC_CLK1 FB_CLK

FBC_CLK1#

DP_FBC_CLK1 FB_CLK

FBC_CMD0

FBC_CMD10
FBC_CMD11
FBC_CMD12
FBC_CMD13
FBC_CMD14
FBC_CMD15
FBC_CMD16
FBC_CMD17

FBC_CMD26

FBC_CMD18

FBC_CMD18

FBC_CMD19

FBC_CMD1

FBC_CMD10

FBC_CMD20
FBC_CMD21
FBC_CMD22
FBC_CMD23
FBC_CMD24
FBC_CMD25
FBC_CMD26
FBC_CMD27
FBC_CMD28
FBC_CMD29

FBC_CMD2

FBC_CMD2

FBC_CMD30
FBC_CMD31

FBC_CMD3
FBC_CMD4
FBC_CMD5
FBC_CMD6
FBC_CMD7
FBC_CMD8
FBC_CMD9

FBC_D0

FBC_D10
FBC_D11
FBC_D12
FBC_D13
FBC_D14
FBC_D15
FBC_D16
FBC_D17
FBC_D18
FBC_D19

FBC_D1

FBC_D20
FBC_D21
FBC_D22
FBC_D23
FBC_D24
FBC_D25
FBC_D26
FBC_D27
FBC_D28
FBC_D29

FBC_D2

FBC_D30
FBC_D31
FBC_D32
FBC_D33
FBC_D34
FBC_D35
FBC_D36
FBC_D37
FBC_D38
FBC_D39

FBC_D3

FBC_D40
FBC_D41
FBC_D42
FBC_D43
FBC_D44
FBC_D45
FBC_D46
FBC_D47
FBC_D48
FBC_D49

FBC_D4

FBC_D50
FBC_D51
FBC_D52
FBC_D53
FBC_D54
FBC_D55
FBC_D56
FBC_D57
FBC_D58
FBC_D59

FBC_D5

FBC_D60
FBC_D61
FBC_D62
FBC_D63

FBC_D6
FBC_D7
FBC_D8
FBC_D9

FBC_DBI0
FBC_DBI1
FBC_DBI2
FBC_DBI3
FBC_DBI4
FBC_DBI5
FBC_DBI6
FBC_DBI7

FBC_EDC0
FBC_EDC1
FBC_EDC2
FBC_EDC3
FBC_EDC4
FBC_EDC5
FBC_EDC6
FBC_EDC7

FBC_EDC[7..0]

FBC_DBI[7..0]

FBC_D[63..0]

FBC_CMD[33..0]

FBC_DEBUG1

FBC_DEBUG0

FBC_WCK01

FBC_WCK01 80DIFF_NETCLASS1

FBC_WCK01#

FBC_WCK01 80DIFF_NETCLASS1

FBC_WCK23

FBC_WCK23 80DIFF_NETCLASS1

FBC_WCK23#

FBC_WCK23 80DIFF_NETCLASS1

FBC_WCK45

FBC_WCK45 80DIFF_NETCLASS1

FBC_WCK45#

FBC_WCK45 80DIFF_NETCLASS1

FBC_WCK67

FBC_WCK67 80DIFF_NETCLASS1

FBC_WCK67#

FBC_WCK67 80DIFF_NETCLASS1

FBC_WCKB01

FBC_WCKB01 80DIFF_NETCLASS1

FBC_WCKB01#

FBC_WCKB01 80DIFF_NETCLASS1

FBC_WCKB23

FBC_WCKB23 80DIFF_NETCLASS1

FBC_WCKB23#

80DIFF_NETCLASS1FBC_WCKB23

FBC_WCKB45

FBC_WCKB45 80DIFF_NETCLASS1

FBC_WCKB45#

FBC_WCKB45 80DIFF_NETCLASS1

FBC_WCKB67

80DIFF_NETCLASS1FBC_WCKB67

FBC_WCKB67#

FBC_WCKB67 80DIFF_NETCLASS1

FBC_CMD32
FBC_CMD33

Schematic Diagrams

B.Schematic Diagrams

GPU Frame Buffer C/D B - 17

Schematic Diagrams

Sheet 17 of 67

Frame Buffer C

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

FRAME BUFFER PARTITION C 31..0

VRAM=K4G80325FB-HC03, HC28

FBVDDQ

Close to DRAM

Around DRAM

Right under DRAM

Around DRAM

OPTION, Under DRAM

Right under DRAM

Close to DRAM

Close to DRAM

FBVDDQ

FBVDDQ

FBVDDQ

1V8_AON

FBVDDQ

FBVDDQ

FBVDDQ

FBVDDQ

FBVDDQ 1V8_AON

FBVDDQ

FBVDDQ

FBVDDQ

GPIO10_FBVREF_SEL12,14,23

FBC_CLK0*16
FBC_CLK016

FBC_VREFC 18

FBC_WCK0116
FBC_WCK01*16
FBC_WCK2316
FBC_WCK23*16

FBC_WCKB0116
FBC_WCKB01*16
FBC_WCKB2316
FBC_WCKB23*16

FBC_D[31..0]16

FBC_CMD[15..0]16

FBC_DBI[3..0]16

FBC_EDC[3..0]16

FBVDDQ11,12,13,14,15,16,18,19,25,59

1V8_AON10,12,13,14,15,18,20,21,22,23,24,25,56,59,60,72

FBC_CMD3216

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

A3

17 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

[17]MEMORY FBC 31..0

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

A3

17 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

[17]MEMORY FBC 31..0

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

A3

17 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

[17]MEMORY FBC 31..0

C717

1u_6.3V_X6S_04

C470

10u_4V_X6S_06

C714

1u_6.3V_X6S_04

M10D

U_MEM_SG_GDDR6

P/N =

V4

VSS

V2

VSS

V13

VSS

V11

VSS

U14

VSS

U1

VSS

T5

VSS

T3

VSS

T12

VSS

T10

VSS

R3

VSS

R14

VSS

R12

VSS

R1

VSS

P4

VSS

P11

VSS

N3

VSS

N14

VSS

N12

VSS

N1

VSS

M3

VSS

M14

VSS

M12

VSS

M1

VSS

L4

VSS

L11

VSS

H4

VSS

H11

VSS

G3

VSS

G14

VSS

G12

VSS

G1

VSS

F3

VSS

F14

VSS

F12

VSS

F1

VSS

E4

VSS

E11

VSS

D3

VSS

D14

VSS

D12

VSS

D1

VSS

C5

VSS

C3

VSS

C12

VSS

C10

VSS

B14

VSS

B1

VSS

A4

VSS

A2

VSS

A13

VSS

A11

VSS

V5

VPP

V10

VPP

A5

VPP

A10

VPP

U5

VDDQ

U10

VDDQ

T4

VDDQ

T14

VDDQ

T11

VDDQ

T1

VDDQ

P14

VDDQ

P1

VDDQ

N4

VDDQ

N11

VDDQ

L14

VDDQ

L1

VDDQ

K2

VDDQ

K13

VDDQ

J2

VDDQ

J13

VDDQ

H14

VDDQ

H1

VDDQ

F4

VDDQ

F11

VDDQ

E14

VDDQ

E1

VDDQ

C4

VDDQ

C14

VDDQ

C11

VDDQ

C1

VDDQ

B5

VDDQ

B10

VDDQ

V14

VDD

V1

VDD

P5

VDD

P10

VDD

L2

VDD

L13

VDD

H2

VDD

H13

VDD

E5

VDD

E10

VDD

A14

VDD

A1

VDD

C695

22u_6.3V_X6S_08

T58

T55

C638

1u_6.3V_X6S_04

R292

121_1%_04

C713

1u_6.3V_X6S_04

C710

1u_6.3V_X6S_04

T62

R693

*931_1%_04

C686

1u_6.3V_X6S_04

C690

22u_6.3V_X6S_08

C704

10u_4V_X6S_06

C679

1u_6.3V_X6S_04

C641

1u_6.3V_X6S_04

NC

NC

NC

GND

NORMAL

NC

NC

NC

x16

NC

NC

x8

NC

NC

NC

M10B

U_MEM_SG_GDDR6

P/N =

R10

WCK1_c_B

R11

WCK1_t_B

R13

DBI1_B

T13

EDC1_B

M13

DQ15_B

N13

DQ14_B

P13

DQ13_B

P12

DQ12_B

U13

DQ11_B

U12

DQ10_B

V12

DQ9_B

U11

DQ8_B

R5

WCK0_c_B

R4

WCK0_t_B

R2

DBI0_B

T2

EDC0_B

M2

DQ7_B

N2

DQ6_B

P2

DQ5_B

P3

DQ4_B

U2

DQ3_B

U3

DQ2_B

V3

DQ1_B

U4

DQ0_B

C723

1u_6.3V_X6S_04

R690

*549_1%_04

C673

1u_6.3V_X6S_04

C687

4.7u_6.3V_X6S_06

C216

22u_6.3V_X6S_08

C733

*820p_50V_X7R_04

C181

1u_6.3V_X6S_04

R299

1K_1%_04

C728

22u_4V_X6S_06

C639

1u_6.3V_X6S_04

C652

22u_6.3V_X6S_08

C712

1u_6.3V_X6S_04

C585

10u_4V_X6S_06

C180

1u_6.3V_X6S_04

T67

C672

1u_6.3V_X6S_04

C663

1u_6.3V_X6S_04

C642

1u_6.3V_X6S_04

C469

10u_4V_X6S_06

R306

121_1%_04

Q68
*MTN2002ZS3

G

DS

C187

1u_6.3V_X6S_04

C662

10u_4V_X6S_06

C640

1u_6.3V_X6S_04

C748

1u_6.3V_X6S_04

C721

1u_6.3V_X6S_04

NC

NC

x16

NC

NC

NC

NC

NC

NC

NC

NC

NC

x8

GND

NORMAL

M10A

U_MEM_SG_GDDR6

P/N =

D10

WCK1_c_A

D11

WCK1_t_A

D13

DBI1_A

C13

EDC1_A

A12

DQ9_A

B13

DQ11_A

B12

DQ10_A

E12

DQ12_A

F13

DQ14_A

E13

DQ13_A

G13

DQ15_A

B11

DQ8_A

D5

WCK0_c_A

D4

WCK0_t_A

D2

DBI0_A

C2

EDC0_A

B3

DQ2_A

B2

DQ3_A

E3

DQ4_A

G2

DQ7_A

B4

DQ0_A

E2

DQ5_A

F2

DQ6_A

A3

DQ1_A

C706

22u_6.3V_X6S_08

C186

1u_6.3V_X6S_04

C700

1u_6.3V_X6S_04

C746

1u_6.3V_X6S_04

T51

C185

1u_6.3V_X6S_04

M10C

U_MEM_SG_GDDR6

P/N =

J10

CLK_t

K10

CLK_c

J1

RESET

M10

CKE_B

K5

CABI_B

K3

CA9_B

K4

CA8_B

K11

CA7_B

K12

CA6_B

L10

CA5_B

L5

CA4_B

L12

CA3_B

M4

CA2_B

M11

CA1_B

L3

CA0_B

G10

CKE_A

J5

CABI_A

J3

CA9_A

J4

CA8_A

J11

CA7_A

J12

CA6_A

H10

CA5_A

H5

CA4_A

H12

CA3_A

G4

CA2_A

G11

CA1_A

H3

CA0_A

M5

RFU_B

G5

RFU_A

K14

ZQ_B

J14

ZQ_A

F5

TMS

N10

TDO

F10

TDI

N5

TCK

K1

VREFC

C684

1u_6.3V_X6S_04

T61

C720

1u_6.3V_X6S_04

C629

10u_4V_X6S_06

C699

1u_6.3V_X6S_04

FBC_CMD9

FBC_CMD0

FBC_CMD3

FBC_CMD14

FBC_CMD11

FBC_CMD8

FBC_CMD10

FBC_CMD1
FBC_CMD6

FBC_CMD32

FBC_DBI0

FBC_EDC0

FBC_D1
FBC_D7
FBC_D5
FBC_D4
FBC_D6
FBC_D3
FBC_D0
FBC_D2

FBC_D14
FBC_D15

FBC_EDC1

FBC_WCKB01
FBC_WCKB01*

FBC_D8
FBC_D12
FBC_D13
FBC_D9
FBC_D11
FBC_D10

FBC_DBI1

FBC_WCK01
FBC_WCK01*

FBC_WCK23
FBC_WCK23*

FBC_WCKB23
FBC_WCKB23*

FBC_D25
FBC_D29
FBC_D28
FBC_D31
FBC_D26
FBC_D24
FBC_D30
FBC_D27

FBC_DBI2

FBC_EDC2

FBC_DBI3

FBC_EDC3

FBC_D23
FBC_D20
FBC_D22
FBC_D21
FBC_D18
FBC_D19
FBC_D17
FBC_D16

FBC_CMD7

FBC_CMD15

FBC_VREFC

FBC_CMD2

FBC_CMD4
FBC_CMD12
FBC_CMD5
FBC_CMD13
FBC_CMD7
FBC_CMD11
FBC_CMD15
FBC_CMD14
FBC_CMD3
FBC_CMD1
FBC_CMD6
FBC_CMD10

FBC_VREFC

SNN_FBCL_TCK_M
SNN_FBCL_TDI_M
SNN_FBCL_TDO_M
SNN_FBCL_TMS_M

FBC_ZQ_1_A
FBC_ZQ_1_B

SNN_FBCL_RFU_A_M
SNN_FBCL_RFU_B_M

FBC_WCK01
FBC_WCK01*
FBC_WCK23
FBC_WCK23*

FBC_WCKB01
FBC_WCKB01*
FBC_WCKB23
FBC_WCKB23*

FBC_DBI[3..0]

FBC_EDC[3..0]

FBC_CMD[15..0]

FBC_D[31..0]

FBC_CMD32

Frame Buffer C

B.Schematic Diagrams

B - 18 Frame Buffer C

Frame Buffer C

Sheet 18 of 67

Frame Buffer C

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

FRAME BUFFER PARTITION C 63..32

VRAM=K4G80325FB-HC03, HC28

FBVDDQ

FBVDDQ

1V8_AON

FBC_CLK1*16

FBC_CLK116

FBC_WCK4516
FBC_WCK45*16
FBC_WCK6716
FBC_WCK67*16

FBC_WCKB4516
FBC_WCKB45*16
FBC_WCKB6716
FBC_WCKB67*16 FBC_D[63..32]16

FBC_CMD[31..16]16

FBC_DBI[7..4]16

FBC_EDC[7..4]16

FBC_VREFC 1 7

FBVDDQ11,12,13,14,15,16,17,19,25,59

1V8_AON10,12,13,14,15,17,20,21,22,23,24,25,56,59,60,72

FBC_CMD3316

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

A3

18 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

[18]MEMORY FBC 63..32

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

A3

18 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

[18]MEMORY FBC 63..32

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

A3

18 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

[18]MEMORY FBC 63..32

T59
T49

R303

121_1%_04

R286

121_1%_04

T46

NC

NC

NC

GND

NORMAL

NC

NC

NC

x16

NC

NC

x8

NC

NC

NC

M9B

U_MEM_SG_GDDR6

P/N =

R10

WCK1_c_B

R11

WCK1_t_B

R13

DBI1_B

T13

EDC1_B

M13

DQ15_B

N13

DQ14_B

P13

DQ13_B

P12

DQ12_B

U13

DQ11_B

U12

DQ10_B

V12

DQ9_B

U11

DQ8_B

R5

WCK0_c_B

R4

WCK0_t_B

R2

DBI0_B

T2

EDC0_B

M2

DQ7_B

N2

DQ6_B

P2

DQ5_B

P3

DQ4_B

U2

DQ3_B

U3

DQ2_B

V3

DQ1_B

U4

DQ0_B

M9D

U_MEM_SG_GDDR6

P/N =

V4

VSS

V2

VSS

V13

VSS

V11

VSS

U14

VSS

U1

VSS

T5

VSS

T3

VSS

T12

VSS

T10

VSS

R3

VSS

R14

VSS

R12

VSS

R1

VSS

P4

VSS

P11

VSS

N3

VSS

N14

VSS

N12

VSS

N1

VSS

M3

VSS

M14

VSS

M12

VSS

M1

VSS

L4

VSS

L11

VSS

H4

VSS

H11

VSS

G3

VSS

G14

VSS

G12

VSS

G1

VSS

F3

VSS

F14

VSS

F12

VSS

F1

VSS

E4

VSS

E11

VSS

D3

VSS

D14

VSS

D12

VSS

D1

VSS

C5

VSS

C3

VSS

C12

VSS

C10

VSS

B14

VSS

B1

VSS

A4

VSS

A2

VSS

A13

VSS

A11

VSS

V5

VPP

V10

VPP

A5

VPP

A10

VPP

U5

VDDQ

U10

VDDQ

T4

VDDQ

T14

VDDQ

T11

VDDQ

T1

VDDQ

P14

VDDQ

P1

VDDQ

N4

VDDQ

N11

VDDQ

L14

VDDQ

L1

VDDQ

K2

VDDQ

K13

VDDQ

J2

VDDQ

J13

VDDQ

H14

VDDQ

H1

VDDQ

F4

VDDQ

F11

VDDQ

E14

VDDQ

E1

VDDQ

C4

VDDQ

C14

VDDQ

C11

VDDQ

C1

VDDQ

B5

VDDQ

B10

VDDQ

V14

VDD

V1

VDD

P5

VDD

P10

VDD

L2

VDD

L13

VDD

H2

VDD

H13

VDD

E5

VDD

E10

VDD

A14

VDD

A1

VDD

T66

T48

T53

NC

NC

x16

NC

NC

NC

NC

NC

NC

NC

NC

NC

x8

GND

NORMAL

M9A

U_MEM_SG_GDDR6

P/N =

D10

WCK1_c_A

D11

WCK1_t_A

D13

DBI1_A

C13

EDC1_A

A12

DQ9_A

B13

DQ11_A

B12

DQ10_A

E12

DQ12_A

F13

DQ14_A

E13

DQ13_A

G13

DQ15_A

B11

DQ8_A

D5

WCK0_c_A

D4

WCK0_t_A

D2

DBI0_A

C2

EDC0_A

B3

DQ2_A

B2

DQ3_A

E3

DQ4_A

G2

DQ7_A

B4

DQ0_A

E2

DQ5_A

F2

DQ6_A

A3

DQ1_A

M9C

U_MEM_SG_GDDR6

P/N =

J10

CLK_t

K10

CLK_c

J1

RESET

M10

CKE_B

K5

CABI_B

K3

CA9_B

K4

CA8_B

K11

CA7_B

K12

CA6_B

L10

CA5_B

L5

CA4_B

L12

CA3_B

M4

CA2_B

M11

CA1_B

L3

CA0_B

G10

CKE_A

J5

CABI_A

J3

CA9_A

J4

CA8_A

J11

CA7_A

J12

CA6_A

H10

CA5_A

H5

CA4_A

H12

CA3_A

G4

CA2_A

G11

CA1_A

H3

CA0_A

M5

RFU_B

G5

RFU_A

K14

ZQ_B

J14

ZQ_A

F5

TMS

N10

TDO

F10

TDI

N5

TCK

K1

VREFC

FBC_CMD28

FBC_CMD20

FBC_CMD19

FBC_CMD31

FBC_CMD27

FBC_CMD21

FBC_CMD26

FBC_CMD17
FBC_CMD22

FBC_CMD29

FBC_DBI4

FBC_EDC4

FBC_D38
FBC_D34
FBC_D36
FBC_D39
FBC_D35
FBC_D32
FBC_D33
FBC_D37

FBC_D40
FBC_D43

FBC_EDC5

FBC_WCKB45
FBC_WCKB45*

FBC_D46
FBC_D42
FBC_D44
FBC_D45
FBC_D47
FBC_D41

FBC_DBI5

FBC_WCK45
FBC_WCK45*

FBC_WCK67
FBC_WCK67*

FBC_WCKB67
FBC_WCKB67*

FBC_D56
FBC_D57
FBC_D58
FBC_D59
FBC_D60
FBC_D61
FBC_D62
FBC_D63

FBC_DBI6

FBC_EDC6

FBC_DBI7

FBC_EDC7

FBC_D51
FBC_D50
FBC_D48
FBC_D49
FBC_D53
FBC_D52
FBC_D55
FBC_D54

FBC_CMD23

FBC_CMD30

FBC_CMD18

FBC_CMD16
FBC_CMD25
FBC_CMD24
FBC_CMD33
FBC_CMD23
FBC_CMD27
FBC_CMD30
FBC_CMD31
FBC_CMD19
FBC_CMD17
FBC_CMD22
FBC_CMD26

SNN_FBCU_TCK_M
SNN_FBCU_TDI_M
SNN_FBCU_TDO_M
SNN_FBCU_TMS_M

FBC_ZQ_2_A
FBC_ZQ_2_B

SNN_FBCU_RFU_A
SNN_FBCU_RFU_B

FBC_WCK45
FBC_WCK45*
FBC_WCK67
FBC_WCK67*

FBC_WCKB45
FBC_WCKB45*
FBC_WCKB67
FBC_WCKB67*

FBC_DBI[7..4]

FBC_EDC[7..4]

FBC_CMD[31..16]

FBC_D[63..32]

FBC_CMD33

Schematic Diagrams

B.Schematic Diagrams

Frame Buffer C B - 19

Schematic Diagrams

1

1

2

2

3

3

4

4

5

5

6

6

7

7

8

8

A A

B B

C C

D D

X) X)

6x 1uF and 2x 10uF

Place Close to GPU

Partition A

6x 1uF and 2x 10uF

Partition C

Place Close to GPU

6x 1uF and 2x 10uF

Partition D

FBVDDQ_GPU

Partition B

6x 1uF and 2x 10uF

NVVDD

under GPU

under GPU

GND

GND

GND

GND

GND

GND

GND

GND

GND

NVVDD

GND

GND

GND

GND

GND

NVVDD

FBVDDQ

GND

GND

GND

GND

GND

GND

GND

GND

GND

GND

GND

NVVDD19,20,25,56,57

FBVDDQ11,12,13,14,15,16,17,18,25,59

1V8_AON10,12,13,14,15,17,18,20,21,22,23,24,2 5,56,59,60,72

NVVDD19,20,25,56,57

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

A2

19 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

[19] GPU Decoupling1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

A2

19 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

[19] GPU Decoupling1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

A2

19 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

[19] GPU Decoupling1

C425

*0.47u_4V_X6S_02

C736

22u_6.3V_X6S_08

C272

1u_6.3V_X6S_02

C273

*0.47u_4V_X6S_02

C420

1u_6.3V_X6S_02

C228

1u_6.3V_X6S_02

C500

1u_6.3V_X6S_02

C494

*0.47u_4V_X6S_02

C363

*0.47u_4V_X6S_02

C223

1u_6.3V_X6S_02

C338

*0.47u_4V_X6S_02

C269

1u_6.3V_X6S_02

C1066

10u_4V_X6S_06

C389

*0.47u_4V_X6S_02

C334

*0.47u_4V_X6S_02

C431

*0.47u_4V_X6S_02

C590

1u_6.3V_X6S_02

C547

1u_6.3V_X6S_02

C251

*0.47u_4V_X6S_02

C350

*0.47u_4V_X6S_02

C335

1u_6.3V_X6S_02

C357

*0.47u_4V_X6S_02

C402

*0.47u_4V_X6S_02

C360

1u_6.3V_X6S_02

C739

22u_6.3V_X6S_08

C259

*0.47u_4V_X6S_02

C145

1u_6.3V_X6S_02

C388

*0.47u_4V_X6S_02

C591

1u_6.3V_X6S_02

C298

1u_6.3V_X6S_02

C370

*0.47u_4V_X6S_02

C175

1u_6.3V_X6S_02

C433

*0.47u_4V_X6S_02

C202

1u_6.3V_X6S_02

C267

*0.47u_4V_X6S_02

C502

*0.47u_4V_X6S_02

C240

*0.47u_4V_X6S_02

C412

*0.47u_4V_X6S_02

C578

*0.47u_4V_X6S_02

C307

*0.47u_4V_X6S_02

C557

*0.47u_4V_X6S_02

C446

*0.47u_4V_X6S_02

C265

1u_6.3V_X6S_02

C192

*0.47u_4V_X6S_02

C429

1u_6.3V_X6S_02

C514

*0.47u_4V_X6S_02

C472

1u_6.3V_X6S_02

C419

*0.47u_4V_X6S_02

C537

*0.47u_4V_X6S_02

C331

*0.47u_4V_X6S_02

C229

*0.47U_4V_X6S_02

C543

*0.47u_4V_X6S_02

C294

1u_6.3V_X6S_02

C463

1u_6.3V_X6S_02

C440

*0.47u_4V_X6S_02

C312

1u_6.3V_X6S_02

C309

1u_6.3V_X6S_02

C329

*0.47u_4V_X6S_02

C445

*0.47u_4V_X6S_02

C486

*0.47u_4V_X6S_02

C554

*0.47u_4V_X6S_02

C551

*0.47u_4V_X6S_02

C464

*0.47u_4V_X6S_02

C135

1u_6.3V_X6S_02

C322

*0.47u_4V_X6S_02

C241

1u_6.3V_X6S_02

C345

1u_6.3V_X6S_02

C222

*0.47u_4V_X6S_02

C546

*0.47u_4V_X6S_02

C536

1u_6.3V_X6S_02

C443

*0.47u_4V_X6S_02

C467

*0.47u_4V_X6S_02

C332

1u_6.3V_X6S_02

C224

1u_6.3V_X6S_02

C351

1u_6.3V_X6S_02

C488

*0.47u_4V_X6S_02

C286

1u_6.3V_X6S_02

C519

*0.47u_4V_X6S_02

C545

*0.47u_4V_X6S_02

C352

1u_6.3V_X6S_02

C511

1u_6.3V_X6S_02

C339

1u_6.3V_X6S_02

C404

*0.47u_4V_X6S_02

C598

1u_6.3V_X6S_02

C435

1u_6.3V_X6S_02

C330

1u_6.3V_X6S_02

C693

22u_6.3V_X6S_08

C1060

10u_4V_X6S_06

C553

1u_6.3V_X6S_02

C568

1u_6.3V_X6S_02

C376

*0.47u_4V_X6S_02

C380

*0.47u_4V_X6S_02

C403

*0.47u_4V_X6S_02

C260

*0.47u_4V_X6S_02

C348

1u_6.3V_X6S_02

C387

*0.47u_4V_X6S_02

C452

*0.47u_4V_X6S_02

C364

*0.47u_4V_X6S_02

C466

1u_6.3V_X6S_02

C465

*0.47u_4V_X6S_02

C365

*0.47u_4V_X6S_02

C244

1u_6.3V_X6S_02

C238

*0.47u_4V_X6S_02

C236

1u_6.3V_X6S_02

C462

*0.47u_4V_X6S_02

C243

1u_6.3V_X6S_02

C501

1u_6.3V_X6S_02

C489

*0.47u_4V_X6S_02

C516

*0.47u_4V_X6S_02

C556

*0.47u_4V_X6S_02

C588

*0.47u_4V_X6S_02

C702

10u_4V_X6S_06

C423

1u_6.3V_X6S_02

C343

1u_6.3V_X6S_02

C261

1u_6.3V_X6S_02

C375

*0.47u_4V_X6S_02

C346

*0.47u_4V_X6S_02

C362

*0.47u_4V_X6S_02

C1003
22u_6.3V_X6S_08

C232

1u_6.3V_X6S_02

C280

1u_6.3V_X6S_02

C314

*0.47u_4V_X6S_02

C411

1u_6.3V_X6S_02

C448

1u_6.3V_X6S_02

C697

10u_4V_X6S_06

C513

*0.47u_4V_X6S_02

C234

*0.47u_4V_X6S_02

C274

*0.47u_4V_X6S_02

C601

1u_6.3V_X6S_02

C321

1u_6.3V_X6S_02

C297

*0.47u_4V_X6S_02

C479

*0.47u_4V_X6S_02

C461

1u_6.3V_X6S_02

C233

*0.47u_4V_X6S_02

C538

*0.47u_4V_X6S_02

C246

*0.47u_4V_X6S_02

C509

1u_6.3V_X6S_02

C264

1u_6.3V_X6S_02

C718

10u_4V_X6S_06

C540

1u_6.3V_X6S_02

C427

0.47u_4V_X6S_02

C398

*0.47u_4V_X6S_02

C278

*0.47u_4V_X6S_02

C738

22u_6.3V_X6S_08

C444

*0.47u_4V_X6S_02

C694

10u_4V_X6S_06

C515

1u_6.3V_X6S_02

C304

*0.47u_4V_X6S_02

C596

1u_6.3V_X6S_02

C369

1u_6.3V_X6S_02

C252

1u_6.3V_X6S_02

C308

*0.47u_4V_X6S_02

C548

*0.47u_4V_X6S_02

C418

1u_6.3V_X6S_02

C245

*0.47u_4V_X6S_02

C559

*0.47u_4V_X6S_02

C635
22u_6.3V_X6S_08

C544

*0.47u_4V_X6S_02

C457

*0.47u_4V_X6S_02

C510

1u_6.3V_X6S_02

C242

*0.47u_4V_X6S_02

C438

*0.47u_4V_X6S_02

C257

*0.47u_4V_X6S_02

C422

*0.47u_4V_X6S_02

C190

1u_6.3V_X6S_02

C395

*0.47u_4V_X6S_02

C368

0.47u_4V_X6S_02

C366

1u_6.3V_X6S_02

C1076

10u_4V_X6S_06

C316

*0.47u_4V_X6S_02

C560

*0.47u_4V_X6S_02

C458

*0.47u_4V_X6S_02

C430

*0.47u_4V_X6S_02

C248

*0.47u_4V_X6S_02

C521

*0.47u_4V_X6S_02

C434

1u_6.3V_X6S_02

C381

*0.47u_4V_X6S_02

C333

*0.47u_4V_X6S_02

C295

1u_6.3V_X6S_02

C575

1u_6.3V_X6S_02

C1120

10u_4V_X6S_06

C525

1u_6.3V_X6S_02

C579

1u_6.3V_X6S_02

C483

1u_6.3V_X6S_02

C406

*0.47u_4V_X6S_02

C336

*0.47u_4V_X6S_02

C1109

10u_4V_X6S_06

C155

*0.47u_4V_X6S_02

C424

1u_6.3V_X6S_02

C503

*0.47u_4V_X6S_02

C453

*0.47u_4V_X6S_02

C491

*0.47u_4V_X6S_02

C497

1u_6.3V_X6S_02

C173

1u_6.3V_X6S_02

C247

1u_6.3V_X6S_02

C367

1u_6.3V_X6S_02

C421

1u_6.3V_X6S_02

C541

*0.47u_4V_X6S_02

C361

1u_6.3V_X6S_02

C342

*0.47u_4V_X6S_02

C628

10u_4V_X6S_06

C157

1u_6.3V_X6S_02

C401

*0.47u_4V_X6S_02

C437

1u_6.3V_X6S_02

C595

*0.47u_4V_X6S_02

C396

1u_6.3V_X6S_02

C239

*0.47u_4V_X6S_02

C512

*0.47u_4V_X6S_02

C292

*0.47u_4V_X6S_02

C442

1u_6.3V_X6S_02

C594

1u_6.3V_X6S_02

C539

*0.47u_4V_X6S_02

C561

1u_6.3V_X6S_02

C740

22u_6.3V_X6S_08

C522

1u_6.3V_X6S_02

C254

*0.47u_4V_X6S_02

C550

*0.47u_4V_X6S_02

C468

*0.47u_4V_X6S_02

C413

1u_6.3V_X6S_02

C283

*0.47u_4V_X6S_02

C303

0.47u_4V_X6S_02

C305

*0.47u_4V_X6S_02

C450

1u_6.3V_X6S_02

C306

*0.47u_4V_X6S_02

C485

*0.47u_4V_X6S_02

C315

*0.47u_4V_X6S_02

C319

*0.47u_4V_X6S_02

C524

*0.47u_4V_X6S_02

C235

*0.47u_4V_X6S_02

C523

*0.47u_4V_X6S_02

C597

*0.47u_4V_X6S_02

C225

*0.47u_4V_X6S_02

C290

*0.47u_4V_X6S_02

C555

*0.47u_4V_X6S_02

C459

1u_6.3V_X6S_02

C1112

22u_6.3V_X6S_08

C599

*0.47u_4V_X6S_02

C552

*0.47u_4V_X6S_02

C655

10u_4V_X6S_06

C542

*0.47u_4V_X6S_02

C379

*0.47u_4V_X6S_02

C456

1u_6.3V_X6S_02

C549

*0.47u_4V_X6S_02

C991

10u_4V_X6S_06

C558

*0.47u_4V_X6S_02

C737

22u_6.3V_X6S_08

C263

*0.47u_4V_X6S_02

C326

1u_6.3V_X6S_02

C258

1u_6.3V_X6S_02

C266

*0.47u_4V_X6S_02

C237

*0.47u_4V_X6S_02

C487

*0.47u_4V_X6S_02

C354

*0.47u_4V_X6S_02

C279

0.47u_4V_X6S_02

Sheet 19 of 67

GPU Decoupling 1

GPU Decoupling 1

B.Schematic Diagrams

B - 20 GPU Decoupling 1

GPU Decoupling 2

1

1

2

2

3

3

4

4

5

5

6

6

7

7

8

8

A A

B B

C C

D D

Near the GPU

Under the GPU

1V8_AON

X) X)

X) X)

GPU DECOUPLING

Near the GPU

Near the GPU

Near the GPU

Near the GPU

Near the GPU

Raven modfiy 0919

GND

GND

1V8_AON

1V8_AON

GND

GND

NVVDD

GND

GND

NVVDD

GND

NVVDD

NVVDD

GND

1V8_AON

GND

1V8_AON

GND

FBVDDQ11,12,13,14,15, 16,17,18,19,25,59

1V8_AON10,12,13,14,15, 17,18,21,22,23,24,25,56,59,60,72

1V8_RUN10,11,21,23,60

NVVDD19,25,56,57

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

A2

20 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

[20] GPU Decoupling2

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

A2

20 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

[20] GPU Decoupling2

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

A2

20 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

[20] GPU Decoupling2

C1067

4.7u_6.3V_X6S_06

C668

*0.47U_4V_X6S_02

C692

0.47u_4V_X6S_02

C84

10u_4V_X6S_06

C91

10u_4V_X6S_06

C122

10u_4V_X6S_06

C654

0.47u_4V_X6S_02

C527

0.47u_4V_X6S_02

C1126

0.47u_4V_X6S_02

C112

10u_4V_X6S_06

C76

10u_4V_X6S_06

C98

10u_4V_X6S_06

C1127

0.47u_4V_X6S_02

C106

10u_4V_X6S_06

C90

10u_4V_X6S_06

C965

10u_4V_X6S_06

C685

0.47u_4V_X6S_02

+

PC56

470u_2V_SMD-V

C101

10u_4V_X6S_06

C73
10u_4V_X6S_06

C675

1u_6.3V_X6S_02

C671

1u_6.3V_X6S_02

C83

22u_4V_X6S_06

C250

0.47u_4V_X6S_02

C184

1u_6.3V_X6S_02

C975

4.7u_6.3V_X6S_06

C974

22u_4V_X6S_06

C961

47u_2.5V_X6S_08

C85

10u_4V_X6S_06

C535

0.47u_4V_X6S_02

C674

*0.47U_4V_X6S_02

C141

1u_6.3V_X6S_02

C88

10u_4V_X6S_06

C325

0.47u_4V_X6S_02

C959

47u_2.5V_X6S_08

C681

0.47u_4V_X6S_02

C86

10u_4V_X6S_06

C691

0.47u_4V_X6S_02

C1128

0.47u_4V_X6S_02

C92

10u_4V_X6S_06

C198

10u_4V_X6S_06

C87

10u_4V_X6S_06

C682

0.47u_4V_X6S_02

C89

10u_4V_X6S_06

C1131

4.7u_6.3V_X6S_06

C96

10u_4V_X6S_06

C969

22u_6.3V_X6S_08

C1130

4.7u_6.3V_X6S_06

C82

10u_4V_X6S_06

C140

*0.47u_4V_X6S_02

C606

0.47u_4V_X6S_02

C77

22u_4V_X6S_06

C289

0.47u_4V_X6S_02

C167
47u_2.5V_X6S_08

C978

10u_4V_X6S_06

C74
10u_4V_X6S_06

C680

0.47u_4V_X6S_02

C976

4.7u_6.3V_X6S_06

C589

4.7u_6.3V_X6S_06

C99

10u_4V_X6S_06

Sheet 20 of 67

GPU Decoupling 2

Schematic Diagrams

B.Schematic Diagrams

GPU Decoupling 2 B - 21

Schematic Diagrams

1

1

2

2

3

3

4

4

5

5

A A

B B

C C

D D

XTAL

XTAL

6-22-27R00-1BG

MULTI-LEVEL STRAPS

Rf

Re

Rd

Rc

Setting RAM type

Strap 5 Strap 4 Strap 3 SMB_ALT_ADDR

000 0
001 0
010 0
011 0
100 0
101 0
110 0
111 0
111 0
00M 1
0M0 1
0M1 1
01M 1
M00 1
M01 1
M10 1

DEVID_SEL PCIE_CFG0VGA_DEVICE

0
0001
01
10
0

0

1
10
1

0

0
11
11
00
00
01
01
10
10
11

1
0
1
0
1
0
1
0
1
0
1
0

1 = HIGH : Tied to 1.8V

0 = Low : Tied to 0V

M = Middle : Tied to 0.9V

1:Enable 0:Disable
SOR 0/1/2/3 ENABLE

1= SMB_ALT_ADDR Enable
0= SMB_ALT_ADDR Disable

1= DEVID_SEL Rebrand
0= DEVID_SEL Orignal

1= PCIE_CFG Low Power
0= PCIE_CFG High Power

1= VGA_DEVICE Enable
0= VGA_DEVICE Disable

M11 1 1 11

Strap 2 Strap 1 Strap 0 RAMCFG[4:0]

0 0 0 00000
0 1 0 00010
0 1 1 00011
1 1 0 00110
1 1 1 00111

ROM_SO ROM_SI ROM_SCLK SOR_EXPOSED[3:0]

0 0 0 1111
0 0 1 1110
0 1 0 1101
0 1 1 1100
1 0 0 1011
1 0 1 1010
1 1 1 1000
1 1 M 0000

M 0 M 21 (0x0015)
M M 0 22 (0x0016)
M M 1 23 (0x0017)
M 1 M 24 (0x0018)
1 M M 25 (0x0019)

1 0 M 16 (0x0010)
1 M 0 17 (0x0011)
1 M 1 18 (0x0012)
1 1 M 19 (0x0013)
0 M M 20 (0x0014)

0 1 M 11 (0x000B)
M 0 0 12 (0x000C)
M 0 1 13 (0x000D)
M 1 0 14 (0x000E)
M 1 1 15 (0x000F)

1 1 0 6 (0x0006)
1 1 1 7 (0x0007)
0 0 M 8 (0x0008)
0 M 0 9 (0x0009)
0 M 1 10 (0x000A)

0 0 1 1 (0x0001)
0 1 0 2 (0x0002)
0 1 1 3 (0x0003)
1 0 0 4 (0x0004)
1 0 1 5 (0x0005)

Strap 2 Strap 1 Strap 0 RAMCFG[4:0]

0 0 0 0 (0x0000)

M M M 26 (0x001A)

eDP ID

GSYNC ID

Strap
Samsung K4G41325FE-HC25 E-die 0 X 7 4000MHz 128Mx32

Setting RAM type

default

DG P.65 recommend strap resistor 5%
or better , voltage use 1V8_AON

DG P.73 recommend Pull down resistor 100k

Strap5
eDP = L
Gsync= H

6-22-27R00-1BH

Co-Lay

D03 Raven modfiy 0417

40mil

20mil

GPU under

GPU near

Near to GPU

30ohm ESR 10mohm bead

40mil

GPU under

SAMSUNG

MICRON

GND

GND GND

GND

GND

GND

GND

GND

1V8_AON

1V8_AON

1V8_AON

GND

GND

GND

1V8_RUN

1V8_RUN

1V8_RUN10,11,23,60

VGA_ROM_SCLK23

VGA_ROM_SO23

VGA_ROM_SI23

STRAP023

STRAP123

STRAP223

STRAP323

STRAP423

STRAP523

1V8_AON10,12,13,14,15,17,18,20,22,23,24,25,56,59,60,72

GPU_PLLVDD22

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[21] STRAPS and XTAL

A3

21 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[21] STRAPS and XTAL

A3

21 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[21] STRAPS and XTAL

A3

21 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

R538
*100K_1%_04

R96
100K_1%_04

R519

*100K_04

R527

*100K_04

13/22 XTAL/PLL

COMMON

BGA2228

?

G1V

BL6

XTALIN

BJ6

EXT_REFCLK_FL

BB24

XSN_PLLVDD

AF11

GPCPLL_AVDD1

U42

GPCPLL_AVDD0

BC12

VID_PLLVDD

BD12

SP_PLLVDD

BM6

XTALOUT

BK6

XTALOUTBUFF

C276

4.7u_6.3V_X6S_06

R528

100K_04

R520

100K_04

R88
100K_04

.

L6 HCB1608KF-300T60

R531

100K_04

R524
*100K_04

X3

U83-076_27MHZ

fsx3m

21

34

R534

*100K_04

R537
100K_1%_04

R529

*100K_04

C970

10p_50V_NPO_04

C144

0.47u_4V_X6S_02

R526

100K_04

R89
100K_04

C490

*0.47u_4V_X6S_02

R98
100K_1%_04

R523
100K_04

R533

100K_04

C169

0.47u_4V_X6S_02

R95
*100K_1%_04

C971

10p_50V_NPO_04

R97
*100K_1%_04

C203

0.47u_4V_X6S_02

C328

22u_6.3V_X6S_08

R114
*100K_1%_04

C160

0.47u_4V_X6S_02

R532

*100K_04

R115
10K_04

XTALOUT

XTALOUTBUFF

XTALSSIN

XTALIN

GPU_PLLVDD

Sheet 21 of 67

Straps and XTAL

Straps and XTAL

B.Schematic Diagrams

B - 22 Straps and XTAL

IFP I/O Interface

1

1

2

2

3

3

4

4

5

5

A A

B B

C C

D D

IFP I/O INTERFACE

HDMI

PLACE Near GPU

PLACE AT BALLS

ʼnŅŎŊ

40 mil

40 mil

eDP

DP

DP

ŮŪůŪġġŅőŠŇ

PLACE AT BALLS

PLACE Under GPU

20 mil

PLACE Under GPU

PLACE AT BALLS

modification 0507 Biaggi

Raven del 0628

modification 0517 Biaggi
RAVEN modfiy 0816

Need check NV USB3.1 OUTPUT

-0517 Biaggi

Raven del 0628

Raven 0628

PLACE Near GPU PLACE close GPU

40 mil

PLACE Near GPU PLACE under GPU

Near the GPU Under the GPU

GND

PEX_VDD

GND

GND

GND

GND

GND

GND

GND

GND

GND

GND

PEX_VDD

GND

PEX_VDD

GND GND GND

1V8_AON

GND

PEX_VDD

GND

PEX_VDD10,58

GPU_PLLVDD21

HDMI_DATA2P 29

HDMI_DATA2N 29

HDMI_DATA0N 29
HDMI_DATA0P 29

HDMI_DATA1N 29
HDMI_DATA1P 29

HDMI_CLOCKN 29
HDMI_CLOCKP 29

HDMI_CTRLCLK 29

HDMI_CTRLDATA 29

DP_E3 68

DP_E#3 68

DP_E2 68

DP_E#2 68

DP_E1 68

DP_E#1 68

DP_E#0 68
DP_E0 68

DP_E_AUX# 68
DP_E_AUX 68

VDD34,23,30,31,33,36,39,40,42,44,45,46,47,48,49,52,53,55,56,57,58,59,60,63,70,71,72

1V8_AON10,12,13,14,15,17,18,20,21,23,24,25,56,59,60,72

Title

Size Document Nu mber Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[22] IFP I/O Interface

Custom

22 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Nu mber Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[22] IFP I/O Interface

Custom

22 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Nu mber Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[22] IFP I/O Interface

Custom

22 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

C275

1u_6.3V_X6S_02

R90 2.49K_1%_04

C65

*0.47U_4V_X6S_02

C166

0.47U_4V_X6S_02

NV_0201_LARGE

R132

10K_04

C63

4.7u_6.3V_X6S_06

C137

*0.47u_4V_X6S_02

C213

1u_6.3V_X6S_02

C178

*0.47u_4V_X6S_02

R553 2.49K_1%_04

7/22 IFPAB

TXD1

IFPAB

TXD3

TXD2

TXD3

TXD4

TXD5

TXD5

TXD1

TXD0

TXD0

TXC

TXC

SCL

SDA

TXD4

TXD2

TXC
TXC

SCL

SDA

TXD2

TXD2

TXD1

TXD1

TXD0

TXD0

TXD2

TXC
TXC

SCL

TXD1
TXD1

SDA

DVI/HDMI DP

TXD2

TXD0

TXD0

DL-DVI

COMMON

BGA2228

?

G1N

BB21

IFP_IOVDD

BB20

IFP_IOVDD

BB17

IFP_IOVDD

BB18

IFP_IOVDD

BD21

IFPAB_PLLVDD

BD23

IFPAB_RSET

BK21

IFPB_L0

BL21

IFPB_L0

BM21

IFPB_L1

BM20

IFPB_L1

BL20

IFPB_L2

BK20

IFPB_L2

BK18

IFPB_L3

BL18

IFPB_L3

BH12

IFPB_AUX

BG12

IFPB_AUX

BG24

IFPA_L0

BF24

IFPA_L0

BE23

IFPA_L1

BF23

IFPA_L1

BH23

IFPA_L2

BG23

IFPA_L2

BG21

IFPA_L3

BF21

IFPA_L3

BG11

IFPA_AUX

BH11

IFPA_AUX

C66

*0.47u_4V_X6S_02

C177

1u_6.3V_X6S_02

R116 1K_1%_04

IFPD

9/22 IFPD

TXC

TXD0
TXD0

TXD2

TXD2

TXD1

TXD1

TXC

DVI/HDMI

SCL

SDA

DP

G1P

?
BGA2228
COMMON

BC20

IFP_IOVDD

BC18

IFP_IOVDD

BM18

IFPD_L0

BM17

IFPD_L0

BL17

IFPD_L1

BK17

IFPD_L1

BK15

IFPD_L2

BL15

IFPD_L2

BM15

IFPD_L3

BM14

IFPD_L3

BE11

IFPD_AUX

BF11

IFPD_AUX

R112 1K_1%_04

R109 1K_1%_04

C129

1u_6.3V_X6S_02

C64

1u_6.3V_X6S_02

C127

0.1u_10V_X7R_04

C212

1u_6.3V_X6S_02

C188

*0.47u_4V_X6S_02

C165

0.47u_4V_X6S_02

R117

10K_04

C61

4.7u_6.3V_X6S_06

.

L5

HCB1608KF-300T60

USB-C

SBU2
SBU1

TX2
TX2

RX1

6/22 IFPF/USB-C

TX1
TX1

RX1

DP

IFPF/USB-C

RX2
RX2

COMMON

BGA2228

?

G1R

BA6

USB_RBIAS

BH6

USB_TERMP1

BG6

USB_TERMP0

BE12

USB_VDDP

AW9

USB_PLL_HVDD

AW11

USB_HVDD

AW10

USB_HVDD

BC15

USB_DVDD

BB15

USB_DVDD

BB7

USB_SDA

BB8

USB_SCL

BA8

USB_L1

BA7

USB_L1

BA2

USB_L0

BA1

USB_L0

BL14

IFPF_L0

BK14

IFPF_L0

BK12

IFPF_L1

BL12

IFPF_L1

BM12

IFPF_L2

BM11

IFPF_L2

BL11

IFPF_L3

BK11

IFPF_L3

BM8

IFPF_AUX

BM9

IFPF_AUX

R137

10K_04

C156

*0.47u_4V_X6S_02

R122

10K_04

C158

0.47u_4V_X6S_02

IFPE

10/22 IFPE

TXC
TXC

DP

TXD2

TXD2

TXD1

TXD1

TXD0

TXD0

SCL

SDA

DVI/HDMI

BGA2228
COMMON

?

G1Q

BC23

IFP_IOVDD

BC21

IFP_IOVDD

BD15

IFPE_PLLVDD

BD17

IFPE_RSET

BH17

IFPE_L0

BG17

IFPE_L0

BG15

IFPE_L1

BF15

IFPE_L1

BE14

IFPE_L2

BF14

IFPE_L2

BH14

IFPE_L3

BG14

IFPE_L3

BK8

IFPE_AUX

BL8

IFPE_AUX

C136

1u_6.3V_X6S_02

R103 1K_1%_04

C300

22u_4V_X6S_06

11/22 NVHS

N/A

N18E-G3

NVHS RX/TX

BGA2228
COMMON

?

G1S

AM3

NVHS_TERMP

AN9

NVHS_PLL_HVDD

AR11

NVHS_HVDD

AN11

NVHS_HVDD

AN10

NVHS_HVDD

AM11

NVHS_HVDD

AM10

NVHS_HVDD

AT11

NVHS_CVDD

AR10

NVHS_CVDD

AV11

NVHS_DVDD

AV10

NVHS_DVDD

AT9

NVHS_DVDD

AT10

NVHS_DVDD

AM2

EXT_REFCLK_SLI

AM5

NVHS_REFCLK

AM6

NVHS_REFCLK

AW6

NVHS_TX7

AW7

NVHS_TX7

AV8

NVHS_TX6

AV7

NVHS_TX6

AV5

NVHS_TX5

AV6

NVHS_TX5

AT6

NVHS_TX4

AT7

NVHS_TX4

AR8

NVHS_TX3

AR7

NVHS_TX3

AR5

NVHS_TX2

AR6

NVHS_TX2

AN6

NVHS_TX1

AN7

NVHS_TX1

AM8

NVHS_TX0

AM7

NVHS_TX0

AW3

NVHS_RX7

AW2

NVHS_RX7

AW1

NVHS_RX6

AV1

NVHS_RX6

AV2

NVHS_RX5

AV3

NVHS_RX5

AT3

NVHS_RX4

AT2

NVHS_RX4

AT1

NVHS_RX3

AR1

NVHS_RX3

AR2

NVHS_RX2

AR3

NVHS_RX2

AN3

NVHS_RX1

AN2

NVHS_RX1

AN1

NVHS_RX0

AM1

NVHS_RX0

C182

*0.47u_4V_X6S_02

C60

4.7u_6.3V_X6S_06

R104

10K_04

R138

0_04

C147

0.47u_4V_X6S_02

C284
1u_6.3V_X6S_04

C171

1u_6.3V_X6S_02

R123

0_04

C287

*0.47u_4V_X6S_02

R140

10K_04

C285

1u_6.3V_X6S_04

C133

1u_6.3V_X6S_02

R82 2.49K_1%_04

SCL

TXC

TXD2

TXD2

TXD1

TXD1

TXD0

TXD0

8/22 IFPC

IFPC

DVI/HDMI

SDA

TXC

DP

COMMON

BGA2228

?

G1O

BC17

IFP_IOVDD

BB23

IFP_IOVDD

BD18

IFPCD_PLLVDD

BD20

IFPCD_RSET

BE20

IFPC_L0

BF20

IFPC_L0

BH20

IFPC_L1

BG20

IFPC_L1

BG18

IFPC_L2

BF18

IFPC_L2

BE17

IFPC_L3

BF17

IFPC_L3

BK9

IFPC_AUX

BL9

IFPC_AUX

C139
1u_6.3V_X6S_02

C62

4.7u_6.3V_X6S_06

IF_PLLVDD

IF_PLLVDD

NVHS00_TERMP

IF_PLLVDD

Sheet 22 of 67

IFP I/O Interface

Schematic Diagrams

B.Schematic Diagrams

IFP I/O Interface B - 23

Schematic Diagrams

1

1

2

2

3

3

4

4

5

5

6

6

7

7

8

8

A A

B B

C C

D D

MISC: GPIO, I2C, and ROM

DG P.279 Note: GPIO can 3V3 input ,
and can not drive a 3V3 levelin push-pull mode.

DG P.261 use 2.2k pull-up
on both I2C_SDA/SCL

DP_E

VBIOS ROM 1M
(OPTIMUS)

L: 0Bx to Ax
H: 1Bx to Ax

Zdiff=50Ω

HDMI

NV

⺢嬘

The GPU does not support multiple
masters on its I2C Buses.

master

slave

The error was caused by PB50EF_D01_20180521A.DSN
0606 Biaggi

The error was caused by PB50EF_D01_20180521A.DSN
0606 Biaggi

Raven modfiy 0726

Raven modfiy 0726

19UHVHUYH

HDMI

1V8_AON

1V8_RUN

1V8_AON

NV3V3

GND

GND

1V8_AON

GND

1V8_RUN

1V8_AON

1V8_AON

VDD3

1V8_AON

1V8_AON

1V8_AON

1V8_AON

3.3VS

1V8_AON

1V8_AON

NV3V3

1V8_RUN

1V8_AON

NV3V3

STRAP021
STRAP121
STRAP221
STRAP321
STRAP421
STRAP521

VDD34,30,31,33,36,39,40,42,44,45,46,47,48,49,52,53,55,56,57,58,59,60,63,70,71,72

3.3V2,24,28,41,43,47,48,50,51,54,57,58,59,68,69

1V8_RUN10,11,21,60

1V8_AON10,12,13,14,15,17,18,20,21,22,24,25,56,59,60,72

VGA_ROM_SO 21
VGA_ROM_SCLK 21

VGA_ROM_SI 21

GPIO0_NVVDD_PWM_VID 56

GPIO1_GC6_FB_EN_R 24

SMC_VGA_THERM 45,70

SMD_VGA_THERM 45,70

AC/BATL# 55

VBATT_BOOST# 45

NV3V310,29,56,59,60,72

OVERT#24

GPIO8_MEM_VDD_CTL 59

GPIO28_OC_WARN# 72

GPIO10_FBVREF_SEL 12,14,17

GPIO4_1V8_MAIN_EN 24

3.3VS8,9,24,27,28,29,30,31,32,33,34,35,38,39,40,42,43,44,45,47,48,52,59,70,71

MDP_E_HPD 34,69

d_GPIO9_ALERT_FAN 45

dGPU_GPIO8_OVERT 45

GPU_PEX_RST# 10,24

HDMI_HPD 29,34

FP_FUSE_GPU 25

ADC_IN_P72
ADC_IN_N72

GPIO6_NVVDD_PSI#_R 56

GPIO25_FBVDD_PSI#_R 59

I2CC_SCL_PP 24,56,59

I2CC_SDA_PP 24,56,59

GPU_EVENT# 34

DGPU_RST#_PCH24,34

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[23] Misc-GPIO_I2C_ROM

Custom

23 74Thursday, February 27, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet of

6-71-NH5D0-D02

D02

[23] Misc-GPIO_I2C_ROM

Custom

23 74Thursday, February 27, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet of

6-71-NH5D0-D02

D02

[23] Misc-GPIO_I2C_ROM

Custom

23 74Thursday, February 27, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

C990 220p_50V_NPO_04

S

D

G

Q55B

MTDK3S6R

5

34

R119 *10K_04

R194
*10K_1%_04

R167 *300K_1%_04

C125 *470p_50V_X7R_04

S

D

G

Q19B
MTDK3S6R

5

34

R101

10K_04

C972

0.1u_6.3V_X5R_02

R543 10K_04

R571 0_04

R168 100K_04

R193 *10K_1%_04

C600
*0.1u_6.3V_X5R_04

R525 100K_04

R522 33.2_1%_04

R545

10K_04

R554 0_04

R131 33.2_1%_04

R546 10K_04

R549 0_04

R195 *300K_1%_04

R135 1.5K_1%_04

R120 *10K_04

R126 4.75K_1%_04

R144
*10K_04

R148
10K_04

Q22
*BTN3904

B

E C

C230*0.1u_10V_X7R_04

C607
*0.1u_6.3V_X5R_04

R149 100K_04

R559

10K_04

R91 1.5K_1%_04

Q23
*BTN3904

B

E C

R84 1.5K_1%_04

C484 *220p_50V_NPO_04

R542 10K_04

R547 33.2_1%_04

R81 33.2_1%_04

R127

*0_04

12/22 MISC 1

G1T

?
BGA2228
COMMON

BK23

NVJTAG_SEL

BL24

JTAG_TRST

BM24

JTAG_TDO

BM23

JTAG_TDI

BL23

JTAG_TMS

BK24

JTAG_TCK

BJ11

ADC_IN

BJ9

ADC_IN

BJ2

THERMDP

BJ1

THERMDN

BF12

TS_VREF

BG5

OVERT

BB3

GPIO30

BA3

GPIO29

BB4

GPIO28

BA4

GPIO27

BE7

GPIO26

BB2

GPIO25

BD5

GPIO24

BG3

GPIO23

BB6

GPIO22

BA5

GPIO21

BE5

GPIO20

BD4

GPIO19

BE3

GPIO18

BH1

GPIO17

BE2

GPIO16

BG1

GPIO15

BG4

GPIO14

BB1

GPIO13

BE6

GPIO12

BH3

GPIO11

BD3

GPIO10

BJ3

GPIO9

BH4

GPIO8

BD7

GPIO7

BD2

GPIO6

BG2

GPIO5

BE1

GPIO4

BE4

GPIO3

BD1

GPIO2

BB5

GPIO1

BD6

GPIO0

BF8

I2CB_SDA

BG8

I2CB_SCL

BH9

I2CC_SDA

BG9

I2CC_SCL

BH8

I2CS_SDA

BJ8

I2CS_SCL

C296

2.2u_6.3V_X5R_04

R92 33.2_1%_04

R548

10K_04

R76 33.2_1%_04

R130 4.75K_1%_04

R161 100K_04

S

D

G

Q21B
MTDK3S6R

5

34

R166
0_04

C996

2.2u_6.3V_X5R_04

R118 10K_04

R521 33.2_1%_04

R558 10K_04

C460 220p_50V_NPO_04

R145 10K_04

14/22 MISC 2

COMMON

BGA2228

?

G1U

BJ5

STRAP5

BK5

STRAP4

BM5

STRAP3

BM4

STRAP2

BL4

STRAP1

BL3

STRAP0

BF9

BUFRST

BK3

ROM_SCLK

BK4

ROM_SO

BK2

ROM_SI

BJ4

ROM_CS

R133 10K_04

R196
0_04

R85 33.2_1%_04

R536 100K_04

R556

2.2K_04

R517
10K_04

S

D

G

Q19A
MTDK3S6R

2

61

R124 33.2_1%_04

R173
10K_1%_04

S

D

G

Q21A
MTDK3S6R

2

61

R550
10K_04

R147 10K_04

U36

FA7609A6

P/N = 6-15-76096-7E0

VIN

2

GND

1

NC

3

ON

6

VOUT

4

VBIAS

5

D34 RB751V-40(lision)

A C

C1182

*10u_6.3V_X5R_06

R552

10K_04

R158
10K_04

S

D

G

Q55A
MTDK3S6R

2

61

INS28107254
SO8

U35

SO8
COMMON

MX25U8033EM1I-12G

1

CS

2

SO

3

WP

4

GND

5

SI

6

SCK

7

HOLD8VCC

R535 100K_04

C134 *470p_50V_X7R_04

R175
10K_1%_04

R129

0_04

R139 1.5K_1%_04

U9
SN74LV1T32DCKR

4

53

1

2

R159
10K_04

R570 *10K_04

R121 100K_04

Q20
BTN3904

M-SOT23-CBE

B

E C

R197
*10K_1%_04

R541 100K_04

R182 *10K_1%_04

Q53

BTN3904

M-SOT23-CBE

B

E C

R557 10K_04

C997

0.1u_6.3V_X5R_02

VGA_ROM_CS#

VGA_ROM_SO

VGA_ROM_SI

VGA_ROM_SCLK

GPU_BUFRST#

OVERT#

GPIO12_AC_DETECT_R

GPIO5_FRAME_LOCK#

GPIO4_1V8_MAIN_EN

GPIO9_THERM_ALERT#

I2CC_SCL
I2CC_SDA

GPIO10_ALT_MEM_VREF

GPIO11_PPEN

GPIO1_GC6_FB_EN
GPIO2_GPU_EVENT#

OVERT#

SMC_VGA_THERM

SMD_VGA_THERMSMD_VGA_THERM1

JTAG_TRST

TS_VREF

GPIO12_AC_DETECT_R

GPIO8_MEM_VDD_CTL

GPIO7_BL_PWM_GPU

GPIO21_RASTER_SYNC0

GPIO20_FL_SYNC_GPU_FGC6

GPIO28_OC_WARN#

GPIO5_FRAME_LOCK#

GPIO11_PPEN

GPIO7_BL_PWM_GPU

GPIO9_THERM_ALERT#

GPIO10_ALT_MEM_VREF

GPIO6_NVVDD_PSI#

GPIO12_AC_DETECT_R

GPIO4_1V8_MAIN_EN

GPIO8_MEM_VDD_CTL

GPIO16_FAN_A_PWM

GPIO18_IFPE_HPD_R

GPIO21_RASTER_SYNC0

GPIO27_IFPC_HPD_R

GPIO18_IFPE_HPD_R

OVERT#

GPIO9_THERM_ALERT#

GPU_PEX_RST#

GPU_PEX_RST#

IVGA_ROM_SI

IVGA_ROM_CS#_R

IVGA_ROM_SCLK

VGA_ROM_CS#

VGA_ROM_SI

VGA_ROM_SCLK

VGA_ROM_SO IVGA_ROM_SO_R

GPIO27_IFPC_HPD_R

GPIO16_FAN_A_PWM

GPIO26_FP_FUSE

GPIO25_FBVDD_PSI#

I2CC_SCL
I2CC_SDA

GPIO29_IDLE_IN_SW

GPIO26_FP_FUSE

GPIO29_IDLE_IN_SW

GPIO6_NVVDD_PSI#

GPIO25_FBVDD_PSI#

GPIO6_NVVDD_PSI# GPIO6_NVVDD_PSI#_R

GPIO25_FBVDD_PSI# GPIO25_FBVDD_PSI#_R

I2CC_SCL

I2CC_SDA

GPIO20_FL_SYNC_GPU_FGC6

SMC_VGA_THERM1

I2CB_SCL
I2CB_SDA

I2CB_SCL
I2CB_SDA

Sheet 23 of 67

Misc - GPIO, I2C,

and ROM

Misc - GPIO, I2C and ROM

B.Schematic Diagrams

B - 24 Misc - GPIO, I2 C and ROM

NVIDIA Power Sequence

1

1

2

2

3

3

4

4

5

5

6

6

7

7

8

8

A A

B B

C C

D D

HW POWER DOWN SEQUENCE

NVIDIA GPIO LEVEL SHIFT

DEFAULT HW POWER SEQUENCE

EC SM_BUS

GPU SM_BUS

From EC

3.3VS

3.3VS

3.3VS

3.3VS

3.3V

1V8_AON

NV_EN_DOWN24,33

NV3V310,23,29,56,59,60,72

3.3V2,28,41,43,47,48,50,51,54,57,58 ,59,68,69

1V8_AON10,12,13,14,15,17,18,20,21,22,23,25,56,59,60,72

1V8_RUN10,11,21,23,60

DGPU_PWRGD 59

DGPU_PWRGD_R34

GPIO4_1V8_MAIN_EN 23,24

GPIO4_1V8_MAIN_EN_R38

NV_PEXVDD_EN 58

NV_FBVDDQ_EN 59

GPIO4_1V8_MAIN_EN 2 3,24

DGPU_PWR_EN 34,45

NV_NV3V3_EN 60

NV_1V8RUN_EN 57,60

NV_1V8AON_EN 60

NV_EN_DOWN24,33

GPIO1_GC6_FB_EN_R23

GC6_FB_EN_PCH34,45

OVERT#23

1V8_AON_PWRGD60

GPU_PEX_RST#10,23

PLT_RST#30,31,44

DGPU_RST#_PCH23,34

NV_NVVDD_EN 56,57

3.3VS8,9,23,27,28,29,30,31,32,33,34,35,38,39,40,42,43, 44,45,47,48,52,59,70,71

EC_GPIO45,52,56,59

SMC_BAT45,52,55,56

SMD_BAT45,52,55,56

NVVDD_PWRGD10,56

I2CC_SDA_PP 23,56,59

I2CC_SCL_PP 23,56,59

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[24] NVIDIA POWER SEQUENCE

Custom

24 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[24] NVIDIA POWER SEQUENCE

Custom

24 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[24] NVIDIA POWER SEQUENCE

Custom

24 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Q6

*2SK3018S3

G

DS

R816 *1K_04

Q9
2SK3018S3

G

DS

R263 0_04

R567
*100K_04

Q10
*2SK3018S3

G

DS

R817 *1K_04

Q12
*2SK3018S3

G

DS

R59 *100K_04

R57 *100K_04

S

D

G

Q74A

MTDK3S6R

2

6 1

C95

*0.1u_10V_X7R_04

R58 100K_04

S

D

G

Q57B
*MTDK3S6R

5

34

C71

*0.1u_10V_X7R_04

S

D

G

Q74B
MTDK3S6R

5

34

Q7

2SK3018S3

G

DS

Q8
*2SK3018S3

G

DS

R564
*100K_04

S

D

G

Q54A
*MTDK3S6R

2

61

S

D

G

Q57A
*MTDK3S6R

2

61

R55 100K_04

U6

SLG4U41681

VDD

1

VIN_DOWN

2

OVERT#

3

SUSB#

4

NVVDDS_PWRGD

5

GC6_FB_EN

6

GC6_FB_EN_PCH

7

PLT_RST#

8

dGPU_RST#_PCH

9

GPU_PEX_RST#

10

FBVDDQ_EN

20

PEX_VDD_EN

19

NVVDDS_EN

18

NVVDD_EN

17

3V3_SYS_EN

16

1V8_MAIN_EN

15

1V8_AON_EN

14

GPIO4_1V8_MAIN_EN

13

dGPU_PWR_EN

12

GND

11

S

D

G

Q54B
*MTDK3S6R

5

34

S

D

G

Q73A

MTDK3S6R

2

6 1

S

D

G

Q73B
MTDK3S6R

5

34

C81

*0.1u_10V_X7R_04

R575
*100K_04

R60 10K_04

C67

*0.1u_10V_X7R_04

R560
*100K_04

C68

*0.1u_10V_X7R_04

C72

*0.1u_10V_X7R_04

C1183 *0.1u_10V_X7R_04

NV_EN_DOWN

NV_1V8RUN_EN

NV_NV3V3_EN

NV_EN_DOWN

NV_NVVDD_EN

NV_EN_DOWN

NV_NVVDDS_EN

NV_EN_DOWN

NV_EN_DOWN

NV_PEXVDD_EN

NV_EN_DOWN

NV_FBVDDQ_EN

GC6_FB_EN_PCH

DGPU_RST#_PCH

DGPU_PWR_EN

GPU_PEX_RST#

GPU_PEX_RST#

NV_NVVDDS_EN

SMC_BAT

SMD_BAT

Sheet 24 of 67
NVIDIA Power

Sequence

Schematic Diagrams

B.Schematic Diagrams

NVIDIA Power Sequence B - 25

Schematic Diagrams

1

1

2

2

3

3

4

4

5

5

6

6

7

7

8

8

A A

B B

C C

D D

GPU NVVDD, FBVDDQ

PLACE NEAR G1 PIN E52

PLACE WEST EDGE OF FBD

FBVDDQ FBVDDQ

GND

GND

FBVDDQ

NVVDD

NVVDD

NVVDDNVVDD

NVVDD NVVDD

1V8_AON

FBVDDQ

FBVDDQ_SENSE 59

FBVDDQ_SENSE_RTN 59

1V8_AON10,12,13,14,15,17,18,20,21,22,23,24,56,59,60,72

FBVDDQ11,12,13,14,15,16,17,18,19,59
NVVDD19,20,56,57

GPU_GND_SENSE 56

GPU_NVVDD_SENSE 56

FP_FUSE_GPU23

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[25] GPU NVVDD, FBVDDQ

Custom

25 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[25] GPU NVVDD, FBVDDQ

Custom

25 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[25] GPU NVVDD, FBVDDQ

Custom

25 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

R204 *2.2_04

R169 40.2_1% _04

R177 49.9_1% _04

22/22 VDD_3/3

COMMON

BGA2228

?

G1M

R22

VDD

R21

VDD

R20

VDD

R19

VDD

R18

VDD

R17

VDD

R16

VDD

R15

VDD

R14

VDD

R13

VDD

P40

VDD

P13

VDD

N40

VDD

N39

VDD

N38

VDD

N37

VDD

N36

VDD

N35

VDD

N34

VDD

N33

VDD

N32

VDD

N31

VDD

N30

VDD

N29

VDD

N28

VDD

N27

VDD

N26

VDD

N25

VDD

N24

VDD

N23

VDD

N22

VDD

N21

VDD

N20

VDD

N19

VDD

N18

VDD

N17

VDD

N16

VDD

N15

VDD

N14

VDD

N13

VDD

BM51

VDD

BM50

VDD

BM49

VDD

BM48

VDD

BM47

VDD

BL52

VDD

BL51

VDD

BL50

VDD

BL49

VDD

BL48

VDD

BL47

VDD

BL46

VDD

BK52

VDD

BK51

VDD

BK50

VDD

BK49

VDD

BK48

VDD

BK47

VDD

BJ52

VDD

BJ51

VDD

BJ50

VDD

BJ49

VDD

BJ48

VDD

BJ47

VDD

BJ46

VDD

BJ45

VDD

BJ44

VDD

BH52

VDD

BH51

VDD

BH50

VDD

BH49

VDD

BH48

VDD

BH47

VDD

BH45

VDD

BH44

VDD

BG52

VDD

BG51

VDD

BG50

VDD

BG49

VDD

BG48

VDD

BG47

VDD

BG46

VDD

BG45

VDD

Y40

VDD

Y13

VDD

W40

VDD

W39

VDD

W38

VDD

W37

VDD

W36

VDD

W35

VDD

W34

VDD

W33

VDD

W32

VDD

W31

VDD

W30

VDD

W29

VDD

W28

VDD

W27

VDD

W26

VDD

W25

VDD

W24

VDD

W23

VDD

W22

VDD

W21

VDD

W20

VDD

W19

VDD

W18

VDD

W17

VDD

W16

VDD

W15

VDD

W14

VDD

W13

VDD

V40

VDD

V13

VDD

U40

VDD

U39

VDD

U38

VDD

U37

VDD

U36

VDD

U35

VDD

U34

VDD

U33

VDD

U32

VDD

U31

VDD

U30

VDD

U29

VDD

U28

VDD

U27

VDD

U26

VDD

U25

VDD

U24

VDD

U23

VDD

U22

VDD

U21

VDD

U20

VDD

U19

VDD

U18

VDD

U17

VDD

U16

VDD

U15

VDD

U14

VDD

U13

VDD

T40

VDD

T13

VDD

R40

VDD

R39

VDD

R38

VDD

R37

VDD

R36

VDD

R35

VDD

R34

VDD

R33

VDD

R32

VDD

R31

VDD

R30

VDD

R29

VDD

R28

VDD

R27

VDD

R26

VDD

R25

VDD

R24

VDD

R23

VDD

R181 40.2_1% _04

18/22 VDD_2/3

G1J

?
BGA2228
COMMON

BE47

VDD

BE46

VDD

BE43

VDD

BE42

VDD

BE41

VDD

BD51

VDD

BD50

VDD

BD49

VDD

BD48

VDD

BD47

VDD

BD46

VDD

BD41

VDD

AP22

VDD

AP21

VDD

AP20

VDD

AP19

VDD

AP18

VDD

AP17

VDD

AP16

VDD

AP15

VDD

AP14

VDD

AP13

VDD

AN40

VDD

AN13

VDD

AM40

VDD

AM39

VDD

AM38

VDD

AM37

VDD

AM36

VDD

AM35

VDD

AM34

VDD

AM33

VDD

AM32

VDD

AM31

VDD

AM30

VDD

AM29

VDD

AM28

VDD

AM27

VDD

AM26

VDD

AM25

VDD

AM24

VDD

AM23

VDD

AM22

VDD

AM21

VDD

AM20

VDD

AM19

VDD

AM18

VDD

AM17

VDD

AM16

VDD

AM15

VDD

AM14

VDD

AM13

VDD

AL40

VDD

AL13

VDD

AK40

VDD

AK39

VDD

AK38

VDD

AK37

VDD

AK36

VDD

AK35

VDD

AK34

VDD

AK33

VDD

AK32

VDD

AK31

VDD

AK30

VDD

AK29

VDD

AK28

VDD

AK27

VDD

AK26

VDD

AK25

VDD

AK24

VDD

AK23

VDD

AK22

VDD

AK21

VDD

AK20

VDD

AK19

VDD

AK18

VDD

AK17

VDD

AK16

VDD

AK15

VDD

AK14

VDD

AK13

VDD

AJ40

VDD

AJ13

VDD

AH40

VDD

AH39

VDD

BL45

GND_SENSE

BK45

NVVDD_SENSE

BG44

VDD

BG43

VDD

BF51

VDD

BF49

VDD

BF47

VDD

BF45

VDD

BF44

VDD

BF42

VDD

BE52

VDD

BE51

VDD

BE50

VDD

BE49

VDD

BE48

VDD

BD39

VDD

BC49

VDD

BC47

VDD

BC45

VDD

BC41

VDD

BC40

VDD

BC39

VDD

BC38

VDD

BB48

VDD

BB47

VDD

BB46

VDD

BB45

VDD

BB39

VDD

BB38

VDD

BA47

VDD

BA46

VDD

BA45

VDD

BA44

VDD

BA43

VDD

AY45

VDD

AY43

VDD

AY40

VDD

AY39

VDD

AY38

VDD

AY37

VDD

AY36

VDD

AY35

VDD

AY34

VDD

AY33

VDD

AY32

VDD

AY31

VDD

AY30

VDD

AY29

VDD

AY28

VDD

AY27

VDD

AY26

VDD

AT29

VDD

AT28

VDD

AT27

VDD

AT26

VDD

AT25

VDD

AT24

VDD

AT23

VDD

AT22

VDD

AT21

VDD

AT20

VDD

AT19

VDD

AT18

VDD

AT17

VDD

AT16

VDD

AT15

VDD

AT14

VDD

AT13

VDD

AR40

VDD

AR13

VDD

AP40

VDD

AP39

VDD

AP38

VDD

AP37

VDD

AP36

VDD

AP35

VDD

AP34

VDD

AP33

VDD

AP32

VDD

AP31

VDD

AP30

VDD

AP29

VDD

AP28

VDD

AP27

VDD

AP26

VDD

AP25

VDD

AP24

VDD

AP23

VDD

20/22 NC/1V8

G1K

?
BGA2228
COMMON

BM45

NC

BM44

NC

BD24

NC

BC14

1V8_AON

BB14

1V8_AON

BA10

1V8_AON

BD14

FP_FUSE_SRC

C566 *3.9pF_50V_02

19/22 FBVDDQ

G1L

?

COMMON

BGA2228

Y43

FBVDDQ

Y42

FBVDDQ

Y11

FBVDDQ

Y10

FBVDDQ

V43

FBVDDQ

V42

FBVDDQ

V10

FBVDDQ

U43

FBVDDQ

U11

FBVDDQ

U10

FBVDDQ

R43

FBVDDQ

R42

FBVDDQ

AR43

FBVDDQ

AR42

FBVDDQ

AN43

FBVDDQ

AM43

FBVDDQ

AM42

FBVDDQ

AK43

FBVDDQ

AK42

FBVDDQ

AK11

FBVDDQ

AK10

FBVDDQ

AJ43

FBVDDQ

AJ42

FBVDDQ

AJ11

FBVDDQ

AJ10

FBVDDQ

AG43

FBVDDQ

AG42

FBVDDQ

AG11

FBVDDQ

AG10

FBVDDQ

AF43

FBVDDQ

AF10

FBVDDQ

AD43

FBVDDQ

AD42

FBVDDQ

AD11

FBVDDQ

AD10

FBVDDQ

AC43

FBVDDQ

AC42

FBVDDQ

AC11

FBVDDQ

AC10

FBVDDQ

AA43

FBVDDQ

AA42

FBVDDQ

AA11

FBVDDQ

AA10

FBVDDQ

R45

FB_CALTERM_GND

P44

FB_CAL_PU_GND

R44

FB_CAL_PD_VDDQ

P45

FB_VREF

E52

FBVDDQ_SENSE

R11

FBVDDQ

R10

FBVDDQ

P43

FBVDDQ

P42

FBVDDQ

P11

FBVDDQ

P10

FBVDDQ

M43

FBVDDQ

M10

FBVDDQ

L39

FBVDDQ

L36

FBVDDQ

L35

FBVDDQ

L33

FBVDDQ

L32

FBVDDQ

L30

FBVDDQ

L27

FBVDDQ

L26

FBVDDQ

L24

FBVDDQ

L23

FBVDDQ

L21

FBVDDQ

L20

FBVDDQ

L18

FBVDDQ

L15

FBVDDQ

L14

FBVDDQ

K41

FBVDDQ

K39

FBVDDQ

K38

FBVDDQ

K36

FBVDDQ

K35

FBVDDQ

K33

FBVDDQ

K32

FBVDDQ

K30

FBVDDQ

K29

FBVDDQ

K27

FBVDDQ

K26

FBVDDQ

K24

FBVDDQ

K23

FBVDDQ

K21

FBVDDQ

K20

FBVDDQ

K18

FBVDDQ

K17

FBVDDQ

K15

FBVDDQ

K14

FBVDDQ

K12

FBVDDQ

AT43

FBVDDQ

R203 2.2_04

R172 40.2_1% _04

R577 2.2_04

17/22 VDD_1/3

COMMON

BGA2228

?

G1I

AV27

VDD

AV26

VDD

AV25

VDD

AV24

VDD

AV23

VDD

AV22

VDD

AV21

VDD

AV20

VDD

AV19

VDD

AV18

VDD

AV17

VDD

AV16

VDD

AV15

VDD

AV14

VDD

AV13

VDD

AU43

VDD

AU40

VDD

AU13

VDD

AT42

VDD

AT40

VDD

AT39

VDD

AT38

VDD

AT37

VDD

AT36

VDD

AT35

VDD

AT34

VDD

AT33

VDD

AT32

VDD

AT31

VDD

AT30

VDD

AE27

VDD

AE26

VDD

AE25

VDD

AE24

VDD

AE23

VDD

AE22

VDD

AE21

VDD

AE20

VDD

AE19

VDD

AE18

VDD

AE17

VDD

AE16

VDD

AE15

VDD

AE14

VDD

AE13

VDD

AD40

VDD

AD13

VDD

AC40

VDD

AC39

VDD

AC38

VDD

AC37

VDD

AC36

VDD

AC35

VDD

AC34

VDD

AC33

VDD

AC32

VDD

AC31

VDD

AC30

VDD

AC29

VDD

AC28

VDD

AC27

VDD

AC26

VDD

AC25

VDD

AC24

VDD

AC23

VDD

AC22

VDD

AC21

VDD

AC20

VDD

AC19

VDD

AC18

VDD

AC17

VDD

AC16

VDD

AC15

VDD

AC14

VDD

AC13

VDD

AB40

VDD

AB13

VDD

AA40

VDD

AA39

VDD

AA38

VDD

AA37

VDD

AA36

VDD

AA35

VDD

AA34

VDD

AA33

VDD

AA32

VDD

AA31

VDD

AA30

VDD

AA29

VDD

AA28

VDD

AA27

VDD

AA26

VDD

AA25

VDD

AA24

VDD

AA23

VDD

AA22

VDD

AA21

VDD

AA20

VDD

AA19

VDD

AA18

VDD

AA17

VDD

AA16

VDD

AA15

VDD

AA14

VDD

AA13

VDD

AY25

VDD

AY24

VDD

AY23

VDD

AY22

VDD

AY21

VDD

AY20

VDD

AY19

VDD

AY18

VDD

AY17

VDD

AY16

VDD

AY15

VDD

AY14

VDD

AY13

VDD

AW45

VDD

AW44

VDD

AW43

VDD

AW42

VDD

AW40

VDD

AW13

VDD

AV44

VDD

AV43

VDD

AV42

VDD

AV40

VDD

AV39

VDD

AV38

VDD

AV37

VDD

AV36

VDD

AV35

VDD

AV34

VDD

AV33

VDD

AV32

VDD

AV31

VDD

AV30

VDD

AV29

VDD

AV28

VDD

AH38

VDD

AH37

VDD

AH36

VDD

AH35

VDD

AH34

VDD

AH33

VDD

AH32

VDD

AH31

VDD

AH30

VDD

AH29

VDD

AH28

VDD

AH27

VDD

AH26

VDD

AH25

VDD

AH24

VDD

AH23

VDD

AH22

VDD

AH21

VDD

AH20

VDD

AH19

VDD

AH18

VDD

AH17

VDD

AH16

VDD

AH15

VDD

AH14

VDD

AH13

VDD

AG40

VDD

AG39

VDD

AG38

VDD

AG37

VDD

AG36

VDD

AG35

VDD

AG29

VDD

AG28

VDD

AG27

VDD

AG23

VDD

AG22

VDD

AG21

VDD

AG20

VDD

AG19

VDD

AG13

VDD

AF40

VDD

AF34

VDD

AF33

VDD

AF32

VDD

AF31

VDD

AF30

VDD

AF26

VDD

AF25

VDD

AF24

VDD

AF18

VDD

AF17

VDD

AF16

VDD

AF15

VDD

AF14

VDD

AF13

VDD

AE40

VDD

AE39

VDD

AE38

VDD

AE37

VDD

AE36

VDD

AE35

VDD

AE34

VDD

AE33

VDD

AE32

VDD

AE31

VDD

AE30

VDD

AE29

VDD

AE28

VDD

FB_CAL_PD_VDDQ

FB_CAL_PU_GND

FB_CAL_TERM_GND

FB_VREF_PROBE

FBVDDQ_SENSE_R49

FBVDDQ_SENSE_RTN

FBVDDQ_SENSE

Sheet 25 of 67

GPU NVVDD,

FBVDDQ

GPU NVVDD, FBVDDQ

B.Schematic Diagrams

B - 26 GPU NVVDD, FBVDDQ

GPU GND

1

1

2

2

3

3

4

4

5

5

6

6

7

7

8

8

A A

B B

C C

D D

GPU GND

GND GND GNDGND

GND

GND

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[26] GPU GND

Custom

26 74Fri day, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[26] GPU GND

Custom

26 74Fri day, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[26] GPU GND

Custom

26 74Fri day, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

15/22 GND_1/3

COMMON

BGA2228

?

G1F

AH51

GND

AH49

GND

AH47

GND

AH45

GND

AH43

GND

AH4

GND

AH2

GND

AH10

GND

AG44

GND

AG34

GND

AG33

GND

AG32

GND

AG31

GND

AG30

GND

AG3

GND

AG26

GND

AG25

GND

AG24

GND

AG18

GND

AG17

GND

AG16

GND

AG15

GND

AG14

GND

AF5

GND

AF45

GND

AF39

GND

AF38

GND

AF37

GND

AF36

GND

AF35

GND

AF29

GND

AF28

GND

AF27

GND

AF23

GND

AF22

GND

AF21

GND

AF20

GND

AF19

GND

AF1

GND

AE8

GND

AE6

GND

AE51

GND

AE49

GND

AE47

GND

AE45

GND

AE43

GND

AE4

GND

AE2

GND

AE10

GND

AD44

GND

AD39

GND

AD38

GND

AD37

GND

AD36

GND

AD35

GND

AD34

GND

AD33

GND

AD32

GND

AD31

GND

AD30

GND

AD29

GND

AD28

GND

AD27

GND

AD26

GND

AD25

GND

AD24

GND

AD23

GND

AD22

GND

AD21

GND

AD20

GND

AD19

GND

AD18

GND

AD17

GND

AD16

GND

AD15

GND

AD14

GND

AB8

GND

AB6

GND

AB51

GND

AB49

GND

AB47

GND

AB45

GND

AB43

GND

AB4

GND

AB39

GND

AB38

GND

AB37

GND

AB36

GND

AB35

GND

AB34

GND

AB33

GND

AB32

GND

AB31

GND

AB30

GND

AB29

GND

AB28

GND

AB27

GND

AB26

GND

AB25

GND

AB24

GND

AB23

GND

AB22

GND

AB21

GND

AB20

GND

AB2

GND

AB19

GND

AB18

GND

AB17

GND

AB16

GND

AB15

GND

AB14

GND

AB10

GND

AA8

GND

AA49

GND

A51

GND

A50

GND

A32

GND

A3

GND

A29

GND

A26

GND

A2

GND

BC24

GND

BL34

GND

AR19

GND

AR18

GND

AR17

GND

AR16

GND

AR15

GND

AR14

GND

AP8

GND

AP6

GND

AP51

GND

AP49

GND

AP47

GND

AP45

GND

AP43

GND

AP4

GND

AP2

GND

AP10

GND

AN8

GND

AN5

GND

AN4

GND

AN39

GND

AN38

GND

AN37

GND

AN36

GND

AN35

GND

AN34

GND

AN33

GND

AN32

GND

AN31

GND

AN30

GND

AN29

GND

AN28

GND

AN27

GND

AN26

GND

AN25

GND

AN24

GND

AN23

GND

AN22

GND

AN21

GND

AN20

GND

AN19

GND

AN18

GND

AN17

GND

AN16

GND

AN15

GND

AN14

GND

AM9

GND

AM4

GND

AL8

GND

AL6

GND

AL51

GND

AL49

GND

AL47

GND

AL45

GND

AL43

GND

AL4

GND

AL39

GND

AL38

GND

AL37

GND

AL36

GND

AL35

GND

AL34

GND

AL33

GND

AL32

GND

AL31

GND

AL30

GND

AL29

GND

AL28

GND

AL27

GND

AL26

GND

AL25

GND

AL24

GND

AL23

GND

AL22

GND

AL21

GND

AL20

GND

AL2

GND

AL19

GND

AL18

GND

AL17

GND

AL16

GND

AL15

GND

AL14

GND

AL10

GND

AK47

GND

AK44

GND

AK1

GND

AJ9

GND

AJ39

GND

AJ38

GND

AJ37

GND

AJ36

GND

AJ35

GND

AJ34

GND

AJ33

GND

AJ32

GND

AJ31

GND

AJ30

GND

AJ29

GND

AJ28

GND

AJ27

GND

AJ26

GND

AJ25

GND

AJ24

GND

AJ23

GND

AJ22

GND

AJ21

GND

AJ20

GND

AJ2

GND

AJ19

GND

AJ18

GND

AJ17

GND

AJ16

GND

AJ15

GND

AJ14

GND

AH8

GND

AH6

GND

16/22 GND_2/3

COMMON

BGA2228

?

G1G

B48

GND

B46

GND

B43

GND

B40

GND

B37

GND

B34

GND

B31

GND

B28

GND

B25

GND

B22

GND

B2

GND

B19

GND

B16

GND

B13

GND

B10

GND

B1

GND

AY8

GND

AY6

GND

AY51

GND

AY49

GND

AY47

GND

AY4

GND

AY2

GND

AY10

GND

AW8

GND

AW52

GND

AW5

GND

AW46

GND

AW4

GND

AW39

GND

AW38

GND

AW37

GND

AW36

GND

AW35

GND

AW34

GND

AW33

GND

AW32

GND

AW31

GND

AW30

GND

AW29

GND

AW28

GND

AW27

GND

AW26

GND

AW25

GND

AW24

GND

AW23

GND

AW22

GND

AW21

GND

AW20

GND

AW19

GND

AW18

GND

AW17

GND

AW16

GND

AW15

GND

AW14

GND

AV9

GND

AV45

GND

AV4

GND

AU8

GND

AU6

GND

AU51

GND

AU49

GND

AU47

GND

AU45

GND

AU4

GND

AU39

GND

AU38

GND

AU37

GND

AU36

GND

AU35

GND

AU34

GND

AU33

GND

AU32

GND

AU31

GND

AU30

GND

AU29

GND

AU28

GND

AU27

GND

AU26

GND

AU25

GND

AU24

GND

AU23

GND

AU22

GND

AU21

GND

AU20

GND

AU2

GND

AU19

GND

AU18

GND

AU17

GND

AU16

GND

AU15

GND

AU14

GND

AU10

GND

AT8

GND

AT52

GND

AT51

GND

AT5

GND

AT4

GND

AR9

GND

AR52

GND

AR4

GND

AR39

GND

AR38

GND

AR37

GND

AR36

GND

AR35

GND

AR34

GND

AR33

GND

AR32

GND

AR31

GND

AR30

GND

AR29

GND

AR28

GND

AR27

GND

AR26

GND

AR25

GND

AR24

GND

AR23

GND

AR22

GND

AR21

GND

AR20

GND

B51

GND

B5

GND

BL31

GND

BL28

GND

BL25

GND

BL22

GND

BL2

GND

BL19

GND

BL16

GND

BL13

GND

BL10

GND

BL1

GND

BK1

GND

BJ7

GND

BJ43

GND

BJ42

GND

BJ41

GND

BJ40

GND

BJ39

GND

BJ38

GND

BJ37

GND

BJ36

GND

BJ35

GND

BJ34

GND

BJ33

GND

BJ32

GND

BJ31

GND

BJ30

GND

BJ29

GND

BJ28

GND

BJ27

GND

BJ26

GND

BJ25

GND

BJ24

GND

BJ23

GND

BJ22

GND

BJ21

GND

BJ20

GND

BJ19

GND

BJ18

GND

BJ17

GND

BJ16

GND

BJ15

GND

BJ14

GND

BJ13

GND

BJ12

GND

BJ10

GND

BH5

GND

BH42

GND

BH39

GND

BH36

GND

BH33

GND

BH30

GND

BH27

GND

BH24

GND

BH21

GND

BH2

GND

BH18

GND

BH15

GND

BG7

GND

BG42

GND

BG40

GND

BG37

GND

BG34

GND

BG31

GND

BG28

GND

BG25

GND

BG22

GND

BG19

GND

BG16

GND

BG13

GND

BG10

GND

BF6

GND

BF41

GND

BF4

GND

BF2

GND

BE40

GND

BE39

GND

BE37

GND

BE36

GND

BE34

GND

BE33

GND

BE31

GND

BE30

GND

BE28

GND

BE27

GND

BE25

GND

BE24

GND

BE22

GND

BE21

GND

BE19

GND

BE18

GND

BE16

GND

BE15

GND

BE13

GND

BE10

GND

BD52

GND

BD38

GND

BD35

GND

BD32

GND

BD29

GND

BD26

GND

BC8

GND

BC6

GND

BC51

GND

BC4

GND

BC37

GND

BC34

GND

BC31

GND

BC28

GND

BC25

GND

BC22

GND

BC2

GND

BC19

GND

BC16

GND

BC13

GND

BB49

GND

BA9

GND

BA48

GND

B7

GND

B52

GND

21/22 GND_3/3

G1H

?
BGA2228
COMMON

BL37

GND

N49

GND

N47

GND

N45

GND

N43

GND

N4

GND

N2

GND

N10

GND

M6

GND

M52

GND

K8

GND

K6

GND

K51

GND

K49

GND

K47

GND

K45

GND

K40

GND

K4

GND

K37

GND

K34

GND

K31

GND

K28

GND

K25

GND

K22

GND

K2

GND

K19

GND

K16

GND

K13

GND

J52

GND

J49

GND

J38

GND

J20

GND

J17

GND

J12

GND

J1

GND

H43

GND

H40

GND

H37

GND

H34

GND

H31

GND

H28

GND

H25

GND

H22

GND

H19

GND

H16

GND

H13

GND

H10

GND

H1

GND

G6

GND

G51

GND

G49

GND

G47

GND

G4

GND

G38

GND

G2

GND

F7

GND

F52

GND

F46

GND

F44

GND

F43

GND

F40

GND

F37

GND

F35

GND

F34

GND

F31

GND

F28

GND

F25

GND

F22

GND

F21

GND

F19

GND

F17

GND

F16

GND

F13

GND

F10

GND

E8

GND

E51

GND

E5

GND

E48

GND

E4

GND

E2

GND

D7

GND

D49

GND

D46

GND

D43

GND

D40

GND

D4

GND

D37

GND

D34

GND

D31

GND

D30

GND

D28

GND

D25

GND

D24

GND

D22

GND

D19

GND

D16

GND

D13

GND

D12

GND

D10

GND

C52

GND

C51

GND

C5

GND

C33

GND

C29

GND

C1

GND

BM3

GND

BM2

GND

BL7

GND

BL5

GND

BL43

GND

BL40

GND

Y9

GND

W43

GND

W4

GND

W2

GND

W10

GND

V52

GND

V49

GND

V39

GND

V38

GND

V37

GND

V36

GND

V35

GND

V34

GND

V33

GND

V32

GND

V31

GND

V30

GND

V29

GND

V28

GND

V27

GND

V26

GND

V25

GND

V24

GND

V23

GND

V22

GND

V21

GND

V20

GND

V19

GND

V18

GND

V17

GND

V16

GND

V15

GND

V14

GND

U9

GND

U7

GND

T8

GND

T6

GND

T51

GND

T49

GND

T47

GND

T45

GND

T43

GND

T4

GND

T39

GND

T38

GND

T37

GND

T36

GND

T35

GND

T34

GND

T33

GND

T32

GND

T31

GND

T30

GND

T29

GND

T28

GND

T27

GND

T26

GND

T25

GND

T24

GND

T23

GND

T22

GND

T21

GND

T20

GND

T2

GND

T19

GND

T18

GND

T17

GND

T16

GND

T15

GND

T14

GND

T10

GND

R52

GND

R49

GND

P51

GND

P39

GND

P38

GND

P37

GND

P36

GND

P35

GND

P34

GND

P33

GND

P32

GND

P31

GND

P30

GND

P29

GND

P28

GND

P27

GND

P26

GND

P25

GND

P24

GND

P23

GND

P22

GND

P21

GND

P20

GND

P19

GND

P18

GND

P17

GND

P16

GND

P15

GND

P14

GND

N8

GND

N6

GND

N51

GND

Sheet 26 of 67

GPU GND

Schematic Diagrams

B.Schematic Diagrams

GPU GND B - 27

Schematic Diagrams

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

DESIGN NOTE:PEQ

Programmalbe input equalization levels;internal pull
down at~150k ,3.3v I/O

L: default, LEQ, compensate channel loss up to 12dB at
HBR2

H: HEQ, compensate channel loss up to 15dB at HBR2

M:LLEQ, compensate channel loss up to 5dB at HBR2

4/2/2018

MINI DISPLAY PORT A(PS8330B)

0715 0715

11/24/2017

PDB PIN:
L:Chip power down
H:Normal operation(default)

月

PS8330B

月

Mini DP Conn

Modify,3/19 Tim

Footprint M-SOT23-5

ᾖ㓡䁢

M-SOT23-5A

6/14 Tim

For Safety LPS.

Raven add 0809

DESIGN NOTE:CFG0

Configuration pin for automatic EQ and
Aux interception; Internal pull down at
~150Kohm,3.3V I/O
L: default, automatic EQ enable and Aux interception enable

H: automatic EQ disable and AUX interception enable
M: automatic EQ disable and AUX interception

disable,no pre-emphasis, 600mVpp swing

DESIGN NOTE:CFG1

Configuration pin for auto test and input offset
cancellation,3.3V IO, internal pull up at~150K
H: default, auto test disable and input offset cancellation
enable

L: auto test enable and input offset cancellation enable
M: auto test disable and input offset cancellation disable

Gary 2/18/2019

MDP_I_PWR

3.3VS

3.3VS3.3VS

3.3VS

3.3VS

3.3VS

3.3VS 3.3VS

3.3VS

MDP_I_PWR

3.3VS

3.3VS

MDP_I_PWR

5VS

5VS

3.3VS

5VS

3.3VS

3.3VS

3.3VS

3.3VS8,9,23,24,28,29,30,31,32, 33,34,35,38,39,40,42,43,44,45,47, 48,52,59,70,71

5VS29,31,43,44,45,46,47,70,71,72

IGPU_LANE0P2

IGPU_LANE2P2

IGPU_LANE1P2

IGPU_LANE1N2

IGPU_LANE3N2

IGPU_LANE0N2

IGPU_LANE2N2

IGPU_LANE3P2

SUSB29,43,47

I_MDP_HPD34

I_MDP_CLK34

IGPU_AUX_CH_P2

IGPU_AUX_CH_N2

I_MDP_DATA34

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[27] mDP (iGPU)

Custom

27 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[27] mDP (iGPU)

Custom

27 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[27] mDP (iGPU)

Custom

27 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

C1141 0.1u_10V_X7R_04

C1105 0.1u_10V_X7R_04

R697

*100K_1%_04

C1140 0.1u_10V_X7R_04

C1145

220p_50V_NPO_04

C1095 0.1u_10V_X7R_04

D15

*TVUDF1004AD0

5

1

2

3

4

10

9

8

7

6

T123

C1090 0.1u_10V_X7R_04

C1096 0.1u_10V_X7R_04

C1107 0.1u_10V_X7R_04

C1089 0.1u_10V_X7R_04

S

D

G

Q64A

MTDK3S6R

2

6 1

C1138 0.1u_10V_X7R_04

R691

4.99K_1%_04

C1088 2.2u_6.3V_X5R_04

R341

*100K_04

R683*4.7K_04

R698

100K_04

C1147 0.1u_10V_X7R_04

R699

1M_04

R678*4.7K_04

D38
BAV99 RECTIFIER

A

C

AC

C1151

10u_6.3V_X5R_06

C1146 0.1u_10V_X7R_04

R687*4.7K_04

R722 1K_04

C1137 0.1u_10V_X7R_04

C1136 0.1u_10V_X7R_04

R688*4.7K_04

Q66

2SK3018S3

G

DS

S

D

G

Q67A

MTDK3S6R

2

61

R692

*100K_1%_04

C1093 0.1u_10V_X7R_04

R682*4.7K_04

D17

*TVUDF1004AD0

5

1

2

3

4

10

9

8

7

6

PS8330B

U44
PS8330B

VDD331CEXT2I2C_ADDR3SCL_CTLPEQ4SDA_CLTCFG05VDD336REXT7CAD_SRC8HPD_SRC9CAD_SNK10HPD_SNK11VDD33

12

OUT3n

13

OUT3p

14

NC

15

OUT2n

16

OOUT2p

17

GND

18

OUT1n

19

OUT1p

20

NC

21

OUT0n

22

OUT0p

23

GND

24

VDD33

36

RST#

35

SDA_DDC

34

SCL_DDC

33

VDD33

32

GND

31

AUX_SRCp30AUX_SRCn

29

AUX_SNKp28AUX_SNKn

27

PD#

26

VDD33

25

IN3n

48

IN3p

47

NC

46

IN2n

45

IN2p

44

NC

43

IN1n

42

IN1p

41

CFG1

40

IN0n

39

IN0p

38

NC

37

EPAD

49

R704

100K_1%_04

C1139 0.1u_10V_X7R_04

S

D

G

Q65B

MTDK3S6R

5

34

S

D

G

Q64B

MTDK3S6R

5

34

C1124

0.01u_16V_X7R_04

R675*4.7K_04

12

20

13

15

10

8

4

3

16

2

6

14

18

1

5

7

9

11

19

17

COMMON

C17737-120A9-L

J_MDP1

PCB Footprint = c-909jd20fstc6-1

P/N = 6-21-11Y20-020

1

GND

2

HPD

3

LANE_0P

4

CONFIG15LANE_0N

6

CONFIG2

7

GND

8

GND

9

LANE_1P

10

LANE_3P11LANE_1N

12

LANE_3N

13

GND

14

GND

15

LANE_2P

16

AUX_CHP

17

LANE_2N

18

AUX_CHN

19

GND

20

PWR

GND4

SHIELD6

GND3

SHIELD5

GND2

SHIELD2

GND1

SHIELD1

R677

100K_04

S

D

G

Q67B

MTDK3S6R

5

34

R705

100K_04

C1103 2.2u_6.3V_X5R_04

U47

SY6288D20AAC

PCB Footprint = M-SOT23-5A

VOUT

1

VIN

5

GND2EN#

4

OC#

3

S

D

G

Q65A
MTDK3S6R

2

61

C765

10u_6.3V_X5R_06

C1091 0.1u_10V_X7R_04

R685 10K_04

R708

100K_1%_04

C1092 0.1u_10V_X7R_04

C1094 0.1u_10V_X7R_04

C1086

0.1u_6.3V_X5R_02

I_MDP_D2J

I_MDP_D#2J

I_MDP_D3J

I_MDP_D#3J

I_MDP_D1J

I_MDP_HPD_R

I_MDP_D#0J

I_MDP_AUX#_R

I_MDP_AUX_R

I_MDP_MODE

I_MDP_D#1J

I_MDP_D0J

I_MDPC_CEC

I_MDP_D#2JI_MDP_D#2

I_MDP_D2JI_MDP_D2

I_MDP_D3JI_MDP_D3

I_MDP_D#3 I_MDP_D#3J

I_MDP_D0 I_MDP_D0J
I_MDP_D#0 I_MDP_D#0J

I_MDP_D#1 I_MDP_D#1J

I_MDP_D1 I_MDP_D1J

I_MDP_MODE

PS8330B_CFG1

PS8330B_CFG0

IN_CAD_SRC

PS8330B_PEQ

I_MDP_HPD_R

IN0P_R

IN0N_R

IN1N_R

IN1P_R

IN2N_R

IN2P_R

IN3N_R

IN3P_R

I_MDP_D#0

I_MDP_D0

I_MDP_D#1

I_MDP_D1

I_MDP_D#2

I_MDP_D2

I_MDP_D#3

I_MDP_D3

I_MDP_AUX#_R

I_MDP_AUX#_R

I_MDP_AUX_R

I_MDP_AUX_R

I_MDP_HPD_R

PS8330B_CFG0

PS8330B_CFG1

PS8330B_PEQ

I_MDP_AUX_R

I_MDP_AUX#_R

I_MDP_MODE

Sheet 27 of 67

mDP

mDP

B.Schematic Diagrams

B - 28 mDP

Panel, Inverter

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

PANEL POWER

PANEL CONNECTOR

INV_BLON

D02A

6-06-75140-068

SHORT

2A

LED PANEL (EDP Channel).

2A

BRIGHTNESS

PANEL POWER

PLVDD 3.3V 3A

ON

Entire trace of Panel VCC should be wider than 80-mil

modidication 0604 biaggi

modidication 0604 biaggi

Raven del 0712

Raven del 0712

3.3V

3.3V

3.3V

3.3V

VIN VLED

3.3V

VIN

VLED

PLVDD

3.3VS

PLVDD

PLVDD

3.3VS

PLVDD

5V

BKL_EN45

ALL_SYS_PWRGD4,31,45,52

LID_SW#43,44,45,63

SB_BLON38

BLON32

SUSB#31,33,41,45,47,48,50,53,60

3.3VS8,9,23,24,27,29,30,31,32,33,34,35,38,39,40,42,43,44,45,47,48,52,59,70,71

5VS27,29,31,43,44,45,46,47,70,71,72

3.3V2,24,41,43,47,48,50,51,54,57,58,59,68,69

VIN33,47,48,49,50,51,52,53,54,55,57,72

EDP_TXP_02

EDP_TXN_02

EDP_AUXP2

EDP_AUXN2

EDP_TXN_12
EDP_TXP_12

EDP_TXN_22
EDP_TXP_22

EDP_TXN_32
EDP_TXP_32

EDP_BRIGHTNESS 32

EDP_HPD 34

5V41,43,47,48,50,53,58,69

NB_ENAVDD 32,45

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[28] PANEL,INVERTER

A3

28 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[28] PANEL,INVERTER

A3

28 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[28] PANEL,INVERTER

A3

28 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

C226

1000p_50V_X7R_04

C947 0.1u_10V_X7R_04

R111 *0_04

C956 0.1u_10V_X7R_04

R69 *0402_short

R93

*100K_04

R86 *100K_04

R68 100K_04

C9630.01u_50V_X7R_04

C948 0.1u_10V_X7R_04

U13B
74LVC08APW

4

5

6

147

C957 0.1u_10V_X7R_04

R142

100K_04

G5016U8

CT2

10

OUT2

8

EN25VBIAS

4

IN2

6

GND11EN1

3

CT1

12

OUT1

13

IN1

1

IN1

2

OUT1

14

IN2

7

OUT2

9

GND

15

C949 0.1u_10V_X7R_04

C131

*0.22u_50V_X7R_04

R184

100K_04

R99

*10K_04

C962*0.1u_50V_X5R_04

R218 *0402_short

R152 1K_04

R87

*4.7K_06

C951 0.1u_10V_X7R_04

R220 *100K_04

C967

0.01u_50V_X7R_04

D12

BAV99 RECTIF IER

A

C

AC

C291

1u_6.3V_X5R_02

R219 100K_04

C356

*220p_50V_X7R_04

Q17

*UK3018

G

DS

R151
100K_04

C163

*22u_6.3V_X5R_06

R70 *10K_04

U13D
74LVC08APW

12

13

11

147

R100 *0_04

PJ32

OPEN_2A

12

Q15

*MTP3403N3

G

DS

U13C
74LVC08APW

9

10

8

147

C612

0.1u_10V_X7R_04

C189

*22u_6.3V_X5R_06

J_LCD1

LVDFH-03008-TP00+

PCB Footprint = lvdfh-030xx-tx00

current = 0.3A

30

30

29

29

28

28

27

27

26

26

25

25

24

24

23

23

22

22

21

21

20

20

19

19

18

18

17

17

16

16

15

15

14

14

13

13

12

12

11

11

10

10

9

9

8

8

7

7

6

6

5

5

4

4

3

3

2

2

1

1

GND1

GND1

GND2

GND2

GND3

GND3

GND4

GND4

GND5

GND5

C952 0.1u_10V_X7R_04

C164

*1u_6.3V_X5R_02

U13A
74LVC08APW

1

2

3

147

C958 0.1u_10V_X7R_04

R83

*150K_04

S

D

G

Q18A

*MTDK5S6R

2

6

1

S

D

G

Q18B

*MTDK5S6R

5

3

4

C270

1u_6.3V_X5R_02

C954 0.1u_10V_X7R_04

C966

1000p_50V_X7R_04

C340
1u_6.3V_X5R_02

C960 0.1u_10V_X7R_04

BLON1

SB_BLON

BLON2

INV_BLON

LID_SW#1

LVDD_EN#1

LVDD_EN

NB_ENAVDD

eDPHPD

BRIGHTNESS_R
INV_BLON

BRIGHTNESS_R

eDPHPD

G5016_CT1G5016_CT1

NB_ENAVDD

Sheet 28 of 67

Panel, Inverter

Schematic Diagrams

B.Schematic Diagrams

Panel, Inverter B - 29

Schematic Diagrams

Sheet 29 of 67

HDMI

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

HDMI CONNECTOR

SCL/SDA 暨PULL HIGH (CHECK PCH䪗)

Output from PS8409.
Connect to 1.2V power IC for 1.2V power cut down if desired

PIN GND1~4=GND

For ESD

HDMI ESD W/O LEVELSHIFT 暨ᶲ, NET ⎗SWAP

6-02-75495-9C0
only uP7549UMA-20

modidication 0604 biaggi

⮵⛘旣ῤ

BY PLATFROM

ᾖ㬋

ᶵ䓐

COMMON CHOKE 䚜㍍SHORT,modify net name

EMI

㓡䁢

COMMON CHOKE SHORT

暞ẞ

枸䔁暣旣嶐

-+

ℑ䪗

3/7/2016

11/9/2017

暣旣ῤ

by platform

婧㔜

0701

Rd

EMI

㓡䁢

COMMON CHOKE SHORT

暞ẞ

枸䔁暣旣嶐-+ℑ䪗

ᶵ䓐

COMMON CHOKE 䚜㍍SHORT,modify net name

3/7/2016

9/23/2014

11/9/2017

暣旣ῤ

by platform

婧㔜

Rd

Raven add 0809

3.3VS

HDMI_5VS

5VS

HDMI_5VS

NV3V3

3.3VS

3.3VS

5VS

GND_HDMI

GND_HDMI

3.3V2,24,28,41,43,47,48,50,51,54,57,58,59,68,69
5V28, 41,43,47,48,50,53,58,69

3.3VS8,9,23,24,27,28,30,31,32,33,34,35,38,39,40,42,43,44,45, 47,48,52,59,70,71
5VS27,31,43,44,45,46,47,70,71,72

NV3V310,23,56,59,60,72

HDMI_DATA2N22
HDMI_DATA2P22

HDMI_DATA0P22

HDMI_DATA0N22

HDMI_CTRLCLK22,29

HDMI_CTRLDATA22,29

HDMI_CLOCKP22
HDMI_CLOCKN22

SUSB27,43,47

HDMI_DATA1P22
HDMI_DATA1N22

HDMI_HPD23,34

HDMI_CTRLCLK22,29

HDMI_CTRLDATA22,29

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[29] HDMI 2.0

Custom

29 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[29] HDMI 2.0

Custom

29 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[29] HDMI 2.0

Custom

29 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

R10

*0_04

J_HDMI1

116E-1C001-20Y

P/N = 6-21-13K20-019

SHIELD2

2

TMDS DATA1+

4

TMDS DATA1-

6

SHIELD0

8

TMDS CLOCK+

10

TMDS CLOCK-

12

RESERVED

14

SDA

16

+5V

18

TMDS DATA2+

1

TMDS DATA2-

3

SHIELD1

5

TMDS DATA0+

7

TMDS DATA0-

9

CLK SHIELD

11

CEC

13

SCL

15

DDC/CEC GND

17

HOT PLUG DETECT

19

GND

GND1

GND

GND2

GND

GND3

GND

GND4

R16

*0_04

R14

2K_04

R72 *0_06

R496

6.04_1%_04

C926 0.1u_10V_X7R_04

R71 0_06

R494

6.04_1%_04

Q3
2SK3018S3

G

DS

C925 0.1u_10V_X7R_04

R79

47K_04

D7

RB551V-30S2

AC

C10

22u_6.3V_X5R_06

R505 499_1%_04

R501

*180_1%_04

C924 0.1u_10V_X7R_04

S

D

G

Q11B

MTDK5S6R

5

34

D32 *RB551V-30S2

A C

R491

6.04_1%_04

R504 499_1%_04

S

D

G

Q11A
MTDK5S6R

2

61

R489

6.04_1%_04

R487 *0.5_1%_04

R509 499_1%_04

R510 499_1%_04

C922 0.1u_10V_X7R_04

D30

ESDPSA2510V05

5

1

2

3

4

10

9

8

7

6

R1
20K_04

U33

APL3517A

VIN

3

VOUT

2

GND

1

R488 *0.5_1%_04

R508 499_1%_04

R507 499_1%_04

Q1

2SK3018S3

G

DS

C923 0.1u_10V_X7R_04

TP1

*TEST

R499

*180_1%_04

R492

6.04_1%_04

R502

*180_1%_04

D31

ESDPSA2510V05

5

1

2

3

4

10

9

8

7

6

C16

22u_6.3V_X5R_06

R8

1M_04

R490

6.04_1%_04

R506 499_1%_04

C928 0.1u_10V_X7R_04

R511 499_1%_04

D50

ESDPSA2510V05

5

1

2

3

4

10

9

8

7

6

R495

6.04_1%_04

R15

2K_04

R500

*180_1%_04

U2

*uP7549UMA5-20

OC#

3

VIN

5

EN#

4

VOUT

1

GND

2

C927 0.1u_10V_X7R_04

C929 0.1u_10V_X7R_04

R493

6.04_1%_04

R78

47K_04

TMDS_CLOCK#_R

TMDS_CLOCK_R

TMDS_DATA1#J

TMDS_DATA1J

TMDS_CLOCK#J

TMDS_CLOCKJ

TMDS_DATA2#J

TMDS_DATA0J

TMDS_DATA2J

TMDS_DATA0#J

HDMI_CEC

HDMI_SCL-C-D

HDMI_SDA-C-D

HDMI_HPD-C-D

HDMI_HPD-C

HDMI_SCL-C
HDMI_SDA-C

TMDS_DATA2#J
TMDS_DATA2J

TMDS_DATA1J

TMDS_DATA1# TMDS_DATA1#J

TMDS_CLOCK# TMDS_CLOCK#J

TMDS_DATA1

TMDS_DATA2

TMDS_DATA2#

TMDS_CLOCK

TMDS_DATA0

TMDS_DATA0# TMDS_DATA0#J

TMDS_DATA0J

TMDS_CLOCKJ

TMDS_DATA1_R
TMDS_DATA1#_R

HDMI_HPD-C

HDMI_SDA-C

HDMI_SCL-C

TMDS_CLOCK#_R

TMDS_CLOCK_R

TMDS_DATA1#_R

TMDS_DATA1_R

TMDS_DATA1_R

TMDS_CLOCK#_R

TMDS_DATA1#_R

TMDS_CLOCK_R

TMDS_DATA2#_R

TMDS_DATA2_R

TMDS_DATA0_R

TMDS_DATA0#_R

TMDS_DATA0_R

TMDS_DATA2_R

TMDS_DATA2#_R

TMDS_DATA0#_R

TMDS_CLOCK#

TMDS_CLOCK

TMDS_DATA1#

TMDS_DATA1

TMDS_DATA0#

TMDS_DATA0

TMDS_DATA2#

TMDS_DATA2

TMDS_DATA0#_R
TMDS_DATA0_R

TMDS_DATA2_R

TMDS_DATA2#_R

HDMI_SDA-C-D

HDMI_HPD-C-D

HDMI_SCL-C-D

HDMI

B.Schematic Diagrams

B - 30 HDMI

PCH 1/9

Sheet 30 of 67

PCH 1/9

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

RTC Wake UP

ME+BIOS ROM 16MB

BOOT HALT
ENABLED IF LOW
PCH HAS
INTERNAL WEAK
PU

CONSENT STRAP IS
ENABLED IF LOW
PCH HAS NO
INTERNAL
TERMINATION

JTAG ODT
DISABLE:LOW
(INTERNAL WEAK PU)

GPP_K_14_GSXDIN:
DMI AC COUPLING FULL VOLTAGE MODE
WHEN SAMPLED LOW

SPI_* = 1"~6.5"

PESONALITY STRAP
IS ENABLED IF LOW
PCH HAS NO
INTERNAL
TERMINATION

ESPI FLASH SHARING MODE
MASTER ATTACHED FLASH SHARING:LOW
SLAVE ATTACEHD FLASH SHARING:HIGH
(INTERNAL WEAK PD)

SHORT

JTAG ODT IS DISABLED IF LOW
PCH HAS INTERNAL WEAK PU

GPP_H15

For ITE IT5570 CO-LAY

W/O TPM 天ᶲẞ

D02_102518_Alex_MOW

22ohm o/w TPM
33ohm w TPM

22ohm o/w TPM

5.1ohm w TPM

Co-lay

Co-lay

VCC_RTC

SPI_3.3V

3.3VA

3.3VS

VDD3

SPI_3.3V SPI_3.3V

3.3VA

SPI_3.3V SPI_3.3V

PLT_RST# 24,31,44

VDD3 4,23,31,33,36,39,40,42,44,45,46,47,48,49,52,53,55,56,57,58,59,60,63,70,71,72

3.3VS 8,9,23,24,27,28,29,31,32,33,34,35,38,39,40,42,43,44,45,47,48,52,59,70,71

VCC_RTC 33,36

LAN_WAKEUP#33,42,45

3.3VA 4,31,32,33,36,38,44,48,53
SPI_3.3V 36

SPI0_CS2#44

ALSPI_CE#45

ALSPI_MSI45
ALSPI_MSO45
ALSPI_SCLK45

GPP_K14_TEST_R 69

TP_ATTN# 43

SPI_SO_R44

SPI_SI_R44

SPI_SCLK_R44

BT_EN 40,45

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[30] PCH 1/12-SPI/SMBUS

A3

30 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[30] PCH 1/12-SPI/SMBUS

A3

30 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[30] PCH 1/12-SPI/SMBUS

A3

30 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

R751

100K_04

R729 100K_04

PJ46 OPEN_1mm

12

R736
100K_04

T80

R757 0_04

W/O TPM

1 OF 13

?

?

?

?

U43A

CML_PCH_H_IP_EXT/BGA

SPI0_CLK

AW47

GPP_D22/SPI1_IO3

BC17

SPI0_MISO

BA45

SPI0_MOSI

AU41

GPP_K14/GSXDIN

W46

GPP_E3/CPU_GP0

AL47

GPP_H16/SML4CLK

AE43

GPP_B4/CPU_GP3

BC33

GPP_K16/GSXCLK

Y47

GPP_B3/CPU_GP2

BF32

GPP_E7/CPU_GP1

AM45

GPP_H17/SML4DATA

AJ46

SPI0_IO2

AY48

GPP_B13/PLTRST#

AV29

GPP_H14/SML3DATA

AD48

SPI0_IO3

BA46

SPI0_CS2#

AT40

GPP_H10/SML2CLK

AE48

GPP_H11/SML2DATA

AD47

SPI0_CS1#

AW48

GPP_K12/GSXDOUT

Y46

GPP_D21/SPI1_IO2

BD17

SPI0_CS0#

AY47

GPP_H18/SML4ALERT#

AE44

TP

AN35

GPP_H15/SML3ALERT#

AC47

GPP_K15/GSXSRESET#

AA45

GPP_K13/GSXSLOAD

Y48

RSVD1

R13

GPP_H13/SML3CLK

AF47

GPP_H12/SML2ALERT#

AB47

INTRUDER#

BB44

GPP_D0/SPI1_CS#/SBK0/BK0

BF19

GPP_D1/SPI1_CLK/SBK1/BK1

BE19

GPP_D3/SPI1_MOSI/SBK3/BK3

BF18

VSS_AL37

AL37

GPP_D2/SPI1_MISO/SBK2/BK2

BE18

RSVD2

R15

GPP_A11/PME#/SD_VDD2_PWR_EN#

BE36

R772 5.1_1%_04 TPM

R761

*4.7K_04

R702 *0_04

R760 33_04

T79

R776 0_04

W/O TPM

R778 5.1_1%_04 TPM

R718

*4.7K_04

T76

R765 0_04

W/O TPM

T65

R766 5.1_1%_04 TPM

R764 22_04 W/O TPM

C1149

0.1u_6.3V_X5R_02

R750 56_04 TPM

R724

*4.7K_04

T77

R756 0_04

W/O TPM

R747 22_04 W/O TPM

R762 20K_04

R768 22_04 W/O TPM

R815 0_04

R728 10K_04

T75

R749 20K_04

R743 56_04 TPM

R763

100K_04

R716

100K_04

T129

R334 1M_1%_04

R746 22_04 W/O TPM

R759 22_04 W/O TPM

R294 *10K_04

R748 33_04

R720

*1K_04

R730 20K_04

U46

GD25B127DSIGR

CE#

1

SO

2

WP#

3

VSS

4

SI

5

SCK

6

HOLD#

7

VDD

8

T78

R752

*4.7K_04

R754

100K_04

R721 56_04 TPM

R719 22_04 W/O TPM

T128

R731 *20K_04

SPI_SI_M

SPI_SO_M

SPI_SCLK_M

SPI_WP#

SPI_IO2 SPI_IO3

SPI_SI_R SPI_SO_R

LAN_WUP#

SPI_IO2
SPI_IO3

SPI_WP#
SPI_HOLD#

GPP_K14_TEST_R

SML4ALERT#
SML4DATA
SML4CLK
SML3ALERT#

SML3CLK

SML2DATA
SML2CLK

INTRUD ER#

SML3DATA

GPP_H_12

EXTTS_SNI_DRV0

SPI_HOLD#

EXTTS_SNI_DRV1

GPP_H_12

SML3ALERT#

SML3ALERT#

SML3CLK

SPI0_MISO

SPI0_MOSI

SPI0_CLK

SPI_SI_R

SPI_CS_0#

SPI_SCLK_R

SPI_SO_R

ALSPI_MSI
ALSPI_MSO
ALSPI_SCLK
ALSPI_CE#

SPI_CS_0#

SPI_SO_R

SPI_SI_R

SPI_SCLK_R

SPI_CS_0#

SPI_CS_0#

SPI_SI_R

SPI_SO_R

SPI_SCLK_R

SPI0_MOSI

SPI0_MISO

SPI0_CLK

BT_EN_PCH

Schematic Diagrams

B.Schematic Diagrams

PCH 1/9 B - 31

Schematic Diagrams

Sheet 31 of 67

PCH 2/9

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

EC DELAY 99ms(UP)

USB2 COMP RES: PLACE WITHIN 1 INCH

DESIGN NOTE:

6- Audio USB2.0 Con.

1- USB3 Port 1 Charger

8- CCD

WLAN

14- BT

USB TABLE

USB2.0

DEVICE

USB3.0

Charger, PORT 1

Type-C

BT

CCD

3G/LTE

3

5

6

7

8

14

11

7

TO VR_ON & EC

ON

DEL ASM x142 USB3.1

BUF_PLT_RST#

1/10

DESIGN NOTE:

㚫㚱⸚㒦䘬 ⓷柴婳㉱ GND⊭央
⣏VIA㗪␐怕婳 怈暊20mil

SM BUS

7-3G NGFF M.2 B Key

XTAL INPUT
HIGH -> DIFFERENTIAL
LOW -> SINGLE ENDED

3,4

5

Audio USB3.0 Con.

Audio USB2.0 Con.

2- Audio USB3.0 Con.

D03 Raven modfiy 0417

3. Type-C CON.

Raven DEL 3G 0629

M2. PCIE (21~24) J_SSD2

raven add 0629

9- Perkey
10- Finger printer

D02_102518_Alex_M.2

VDD3

VDD3

3.3VA

VDD3

VDD3

3.3VA

5VS

3.3VS

3.3VS

VDD3

PM_PCH_PWROK 31,33

PM_PWROK45

SYS_PWROK 33

VDD34,23,30,33,36,39,40,42,44,45,46,47,48,49,52,53,55,56,57,58,59,60,63,70,71,72

DMI_MT_IR_0_DN2
DMI_MT_IR_0_DP2

DMI_MT_IR_1_DN2
DMI_MT_IR_1_DP2

DMI_MT_IR_2_DN2
DMI_MT_IR_2_DP2

DMI_MT_IR_3_DN2
DMI_MT_IR_3_DP2

DMI_IT_MR_0_DN2

DMI_IT_MR_0_DP2

DMI_IT_MR_1_DN2

DMI_IT_MR_1_DP2

DMI_IT_MR_2_DN2

DMI_IT_MR_2_DP2

DMI_IT_MR_3_DN2

DMI_IT_MR_3_DP2

USB_PP1 41

USB_PN1 41

USB_PN14 40
USB_PP14 40

3.3VA4,30,32,33,36,38,44,48,53

PCH_DPWROK33

SUSB#28,33,41,45,47,48,50,53,60

VCCIO_PWRGD48

ALL_SYS_PWRGD 4,28,45,52

USB_PN8 44
USB_PP8 44

USB_PN6 43
USB_PP6 43

VCORE_PG52

PLT_RST#24,30,44

BUF_PLT_RST# 39,40,42,45

PM_PCH_PWROK31,33

SMB_DATA_MAIN_DDR4 8,9

SMB_CLK_MAIN_DDR4 8,9

SMB_CLK 33,50

SMB_DATA 33,50

5VS27,29,43,44,45,46,47,70,71,72

3.3VS8,9,23,24,27,28,29,30,32,33,34,35,38,39,40,42,43,44,45,47,48,52,59,70,71

USB_PN2 43
USB_PP2 43

USB_P9# 70
USB_P9 70

USB_PN3 41
USB_PP3 41

USB_PN10 43
USB_PP10 43

PCIE_TXP23_SSD 39
PCIE_TXN23_SSD 39

PCIE_RXN23_SSD 39

PCIE_RXP23_SSD 39

PCIE_TXP24_SSD 39
PCIE_TXN24_SSD 39

PCIE_RXN24_SSD 39

PCIE_RXP24_SSD 39

PCIE_TXP22_SSD 39
PCIE_TXN22_SSD 39

PCIE_RXN22_SSD 39

PCIE_RXP22_SSD 39

PCIE_TXP21_SSD 39

PCIE_RXN21_SSD 39

PCIE_RXP21_SSD 39

PCIE_TXN21_SSD 39

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[31] PCH 2/12-DMI/PCIE/USB2.0

A3

31 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[31] PCH 2/12-DMI/PCIE/USB2.0

A3

31 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[31] PCH 2/12-DMI/PCIE/USB2.0

A3

31 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

C1158 *1u_6.3V_X5R_02

C1142 0.22u_10V_X5R_04

RN7

*10K_8P4R_04

1

2

3

4 5

6
7
8

S

D

G

Q70A

MTDK3S6R

2

61

C1148 0.22u_10V_X5R_04

S

D

G

Q71B

MTDK3S6R

5

34

C1134 0.22u_10V_X5R_04

C1144 0.22u_10V_X5R_04

U27D
74LVC08APW

12

13

11

147

R641 *1K_04

R791 1K_04

U27C
74LVC08APW

9

10

8

147

R405 1K_04

PJ11 *1mm

1 2

R397

10K_04

C1135 0.22u_10V_X5R_04

C1159 *1u_6.3V_X5R_02

R793

1K_04

C786

*0.1u_10V_X7R_04

R412

*10K_04

R639 *1K_04

U27A
74LVC08APW

1

2

3

147

C1129 0.22u_10V_X5R_04

R404

*10K_04

S

D

G

Q71A

MTDK3S6R

2

61

R388

100K_04

C1143 0.22u_10V_X5R_04

R640 113_1%_04

C1132 0.22u_10V_X5R_04

R789

1K_04

2 OF 13

?

?

?

?

U43B

CML_PCH_H_IP_EXT/BGA

USB2N_1

J3

USB2P_1

J2

USB2N_2

N13

USB2P_2

N15

USB2N_3

K4

USB2P_3

K3

USB2N_4

M10

USB2P_4

L9

USB2N_5

M1

USB2P_5

L2

USB2N_6

K7

USB2P_6

K6

USB2N_7

L4

USB2P_7

L3

USB2N_8

G4

USB2P_8

G5

USB2N_9

M6

USB2P_9

N8

USB2N_10

H3

USB2P_10

H2

USB2N_11

R10

USB2P_11

P9

USB2N_12

G1

USB2P_12

G2

USB2N_13

N3

USB2P_13

N2

USB2N_14

E5

USB2P_14

F6

USB2_COMP

F4

USB2_VBUSSENSE

F3

USB2_ID

G3

RSVD_K29

K29

RSVD_G26

G26

RSVD_E28

E28

DMI2_TXP

B31

PCIE1_TXN/USB31_7_TXN

A17

RSVD_R24

R24

RSVD_L26

L26

RSVD_C27

C27

DMI3_TXP

B29

PCIE4_RXP/USB31_10_RXP

R18

RSVD_F26

F26

RSVD_D29

D29

RSVD_B26

B26

GPP_F17/USB2_OC6#

AR37

RSVD_P24

P24

PCIE3_RXP/USB31_9_RXP

J18

RSVD_B27

B27

RSVD_B25

B25

RSVD_C26

C26

PCIE3_TXP/USB31_9_TXP

C19

RSVD_A25

A25

PCIE21_RXN

T43

PCIE3_RXN/USB31_9_RXN

K18

GPP_E10/USB2_OC1#

AL40

GPP_E9/USB2_OC0#

AH36

PCIE22_RXN

U40

PCIE2_RXP/USB31_8_RXP

P21

PCIE5_RXN

F20

PCIE23_RXN

W43

PCIE21_RXP

R44

PCIE6_RXN

K21

PCIE21_TXN

G47

PCIE4_TXN/USB31_10_TXN

D20

PCIE3_TXN/USB31_9_TXN

B19

GPP_F16/USB2_OC5#

AR35

PCIE22_RXP

U41

PCIE7_RXN

L24

PCIE22_TXN

H47

PCIE5_RXP

G20

PCIE2_TXP/USB31_8_TXP

C18

PCIE5_TXN

B21

PCIE6_RXP

J21

PCIE21_TXP

F46

PCIE8_RXN

F24

PCIE6_TXN

D21

GPP_E12/USB2_OC3#

AL41

PCIE24_RXP

Y41

PCIE2_RXN/USB31_8_RXN

R21

DMI0_RXN

K34

PCIE7_RXP

J24

PCIE22_TXP

H48

PCIE24_TXN

G46

PCIE7_TXN

C23

PCIE5_TXP

A22

PCIE23_TXP

G48

DMI1_RXN

G33

PCIE8_RXP

G24

PCIE1_RXP/USB31_7_RXP

F16

PCIE6_TXP

C21

PCIE4_TXP/USB31_10_TXP

C20

PCIE8_TXN

B24

GPP_F18/USB2_OC7#

AV43

DMI2_RXN

K32

DMI0_RXP

J35

PCIE24_TXP

G45

DMI0_TXN

C33

GPD7

BE41

PCIE7_TXP

B23

PCIE2_TXN/USB31_8_TXN

B18

PCIE1_TXP/USB31_7_TXP

B17

DMI3_RXN

G30

DMI1_RXP

F34

DMI1_TXN

C32

PCIE8_TXP

C24

RSVD1

U13

PCIE4_RXN/USB31_10_RXN

N18

RSVD_M29

M29

DMI2_RXP

J32

PCIE1_RXN/USB31_7_RXN

G17

DMI2_TXN

C31

DMI0_TXP

B33

GPP_F15/USB2_OC4#

AV47

RSVD_M26

M26

DMI3_RXP

F30

DMI3_TXN

C29

DMI1_TXP

B32

GPP_E11/USB2_OC2#

AJ44

PCIE24_RXN

Y40

PCIE23_RXP

W44

PCIE23_TXN

G49

U27B
74LVC08APW

4

5

6

147

R792 1K_04

RN6 *10K_8P4R_04

1
2
3
4 5

6

7

8

S

D

G

Q70B

MTDK3S6R

5

34

R696 100K_04

USB_OC0#
USB_OC1#
USB_OC2#
VISACH2_D3

USB_OC4#
USB_OC5#
USB_OC6#
USB_OC7#

USB2_COMP
USB2_VBUSSENSE
TP_PCH_U13
USB2_ID

SYS_PWROK_R

ALL_SYS_PWRGD

USB_OC0#

USB_OC1#

USB_OC2#
VISACH2_D3

USB_OC6#

USB_OC7#

ALL_SYS_PWRGD

USB_OC4#

USB_OC5#

GPD_7

GPD_7
PCIE24_TXP
PCIE24_TXN

PCIE23_TXP
PCIE23_TXN

PCIE22_TXP
PCIE22_TXN

PCIE21_TXP
PCIE21_TXN

PCH 2/9

B.Schematic Diagrams

B - 32 PCH 2/9

PCH 3/9

Sheet 32 of 67

PCH 3/9

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

BIOS RECOVERY
ENABLE :LOW

PCH_RSVD

M2. PCIE/SATA
(9~12)

MFG_MODE

嶇

BIOS 䡢

娵

SATAGP0 & SATAGP1
L: SATA
H: PCIe

GFX SELECT TABLE
NORMAL GFX:LOW
CUSTOMER GFX:HIGH

Main HDD

M2. PCIE/SATA
(9~12)

M2. PCIE/SATA

(9~12)

WLAN

RTL8411 GLAN

raven add 0629

raven add 0629

raven add 0918

raven add 0918

SSD2 PCIE lan port change

SSD2 PCIE lan port change

D02_102518_Alex_2.5" SATA issue

D02_1107_Alex

3.3VS 3.3VS 3.3VS

1.05V_VCCST

3.3VS

3.3VS

3.3VA

SCI#45

3.3VS8,9,23,24,27,28,29,30,31,33,34,35,38,39,40,42,43,44,45,47,48,52,59,70,71

1.05V_VCCST4,6,48,52

PCIE_RXP11_SSD40
PCIE_RXN11_SSD40

PCIE_TXP11_SSD40
PCIE_TXN11_SSD40

EDP_BRIGHTNESS 28
BLON 28
NB_ENAVDD 28,45

SATAGP1 40

SATA_LED# 44

PLTRST_CPU_N 4

H_PM_DOWN 4

PCH_PECI 4

H_PM_SYNC 4

PCH_THERMTRIP# 4

PCIE_TXP12_SSD40
PCIE_TXN12_SSD40

PCIE_RXN12_SSD40

PCIE_RXP12_SSD40

SWI#45

SATA_RXP4 43

SATA_TXP4 43

SATA_TXN4 43

SATA_RXN4 43

PCIE_TXP10_SSD 40

PCIE_RXP10_SSD 40

PCIE_RXN10_SSD 40

PCIE_TXN10_SSD 40

PCIE_TXP9_SSD 40

PCIE_RXP9_SSD 40

PCIE_RXN9_SSD 40

PCIE_TXN9_SSD 40

3.3VA4,30,31,33,36,38,44,48,53

PCIE_TXP14_WLAN40

PCIE_TXN14_WLAN40

PCIE_RXP14_WLAN40

PCIE_RXN14_WLAN40

PCIE_TXP15_GLAN 42

PCIE_TXN15_GLAN 42

PCIE_RXP15_GLAN 42

PCIE_RXN15_GLAN 42

CLINK_CLK40
CLINK_DATA40
CLINK_RESET40

SATA_M2_PWR_EN139
SATA_M2_PWR_EN239

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[32] PCH 3/12-PCIE/SATA/HOST

A3

32 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[32] PCH 3/12-PCIE/SATA/HOST

A3

32 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[32] PCH 3/12-PCIE/SATA/HOST

A3

32 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

R332 10K_04

R733 10K_04

C1100 0.22u_10V_X5R_04

T132

RN5 10K_8P4R_04

1
2
3
4 5

6

7

8

R725 *10mil_short

R638 619_1%_04

3 OF 13

?

?

?

?

U43C

CML_PCH_H_IP_EXT/BGA

PECI

AF2

PM_SYNC

AF3

PM_DOWN

AE2

GPP_K3

U47

PCIE12_RXN/SATA1A_RXN

H42

PCIE20_TXP/SATA7_TXP

B44

PCIE16_TXN/SATA3_TXN

B41

GPP_K4

N48

PCIE13_RXP/SATA0B_RXP

C46

PCIE17_TXP/SATA4_TXP

B42

PCIE11_TXN/SATA0A_TXN

B36

GPP_F19/EDP_VDDEN

AV44

CL_RST#

AU4

GPP_K5

N47

PCIE19_TXP/SATA6_TXP

D43

PCIE18_TXN/SATA5_TXN

C42

GPP_E2/SATAXPCIE2/SATAGP2

AK47

GPP_E0/SATAXPCIE0/SATAGP0

AH41

GPP_K6

P47

PCIE15_RXP/SATA2_RXP

E45

PCIE14_RXP/SATA1B_RXP

C47

GPP_K7

R46

PCIE20_RXP/SATA7_RXP

R37

PCIE16_RXN/SATA3_RXN

L41

PCIE17_RXP/SATA4_RXP

K44

PCIE12_TXN/SATA1A_TXN

D38

PCIE13_TXP/SATA0B_TXP

C38

GPP_F12/SATA_SDATAOUT1

AU46

THRMTRIP#

AD3

GPP_K8

P48

GPP_F10/SATA_SCLOCK

AR42

GPP_K9

V47

PCIE18_RXN/SATA5_RXN

P41

PCIE19_RXP/SATA6_RXP

N42

PCIE10_RXN

K37

PCIE13_RXN/SATA0B_RXN

C45

GPP_F21/EDP_BKLTCTL

AU48

PCIE14_TXP/SATA1B_TXP

D39

GPP_F13/SATA_SDATAOUT0

AU47

GPP_F2/SATAXPCIE5/SATAGP5

AM43

PLTRST_CPU#

AG5

PCIE10_RXP

J37

PCIE16_TXP/SATA3_TXP

C41

PCIE10_TXN

C35

GPP_F4/SATAXPCIE7/SATAGP7

AM48

PCIE11_RXP/SATA0A_RXP

F39

PCIE14_RXN/SATA1B_RXN

D46

PCIE13_TXN/SATA0B_TXN

B38

GPP_F11/SATA_SLOAD

AR48

PCIE20_TXN/SATA7_TXN

A44

PCIE18_TXP/SATA5_TXP

D42

PCIE10_TXP

B35

GPP_F20/EDP_BKLTEN

AV46

CL_DATA

AT5

GPP_E1/SATAXPCIE1/SATAGP1

AJ43

PCIE17_TXN/SATA4_TXN

A42

GPP_K10

V48

PCIE9_RXN

G36

PCIE19_TXN/SATA6_TXN

C44

GPP_K11

W47

PCIE16_RXP/SATA3_RXP

M40

PCIE15_RXN/SATA2_RXN

F44

PCIE14_TXN/SATA1B_TXN

C39

PCIE11_TXP/SATA0A_TXP

C36

PCIE20_RXN/SATA7_RXN

R35

PCIE17_RXN/SATA4_RXN

K43

PCIE12_RXP/SATA_1A_RXP

J41

PCIE9_RXP

F36

PCIE9_TXN

C34

PCIE18_RXP/SATA5_RXP

R40

GPP_K0

L47

PCIE11_RXN/SATA0A_RXN

G38

CL_CLK

AR2

PCIE19_RXN/SATA6_RXN

M44

GPP_K1

L46

PCIE12_TXP/SATA1A_TXP

E37

PCIE9_TXP

D34

GPP_K2

U48

PCIE15_TXP/SATA2_TXP

C40

GPP_F3/SATAXPCIE6/SATAGP6

AM47

GPP_F1/SATAXPCIE4/SATAGP4

AM46

GPP_F0/SATAXPCIE3/SATAGP3

AN47

PCIE15_TXN/SATA2_TXN

B40

GPP_E8/SATALED#

AK48

R737

10K_04

C1104 0.22u_10V_X5R_04

C1101 0.22u_10V_X5R_04

T69

R636
*10K_04

C1108 0.1u_10V_X7R_04

R614
1K_04

C1087 0.22u_10V_X5R_04

C1113 0.1u_10V_X7R_04

R339

100K_04

R740

10K_04

R613 30.1_1%_04

C1098 0.22u_10V_X5R_04

T81

R739

*10K_04

C1085 0.22u_10V_X5R_04

C1111 0.1u_10V_X7R_04

C1097 0.22u_10V_X5R_04

C1106 0.1u_10V_X7R_04

C1084 0.22u_10V_X5R_04

R738

*10K_04

R726 10K_04

R331 *10mil_short

MFG_MODEPCH_RSVDBIOS_REC

PCH_PECI
H_PM_SYNC_R

PCH_THERMTRIP#PCH_THERMTRIP#_R

PCIE12_TXP
PCIE12_TXN

PCIE11_TXP
PCIE11_TXN

BIOS_REC
PCH_RSVD

SCI#_R

ODD_DA#_R

GP39_GFX_CRB_DETECT

SWI#_R

PCIE9_TXN
PCIE9_TXP

MFG_MODE

GP39_GFX_CRB_DETECT

SATAGP0

SATAGP2

SATAGP3

SATA_LED#

SCI#_R

SWI#_R

PCH_GPPK1_PCH_FBVDDQ_EN

PCH_GPPK0_PCH_PEXVDD_EN

PCH_GPPK10_PCH_NVVDD_EN
PCH_GPPK11_PCH_NVVDDS_EN

PCH_GPPK2_PCH_1V8RUN_EN

PCIE10_TXP

PCIE10_TXN

SATA_LED#

SATAGP1

SATAGP3

PCIE14_TXN
PCIE14_TXP

PCIE15_TXP

PCIE15_TXN

SATAGP0

SATAGP2

Schematic Diagrams

B.Schematic Diagrams

PCH 3/9 B - 33

Schematic Diagrams

Sheet 33 of 67

PCH 4/9

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

ESPI/LPC SELECT STRAP
IF SAMPLED HIGH, ESPI
IS SELECTED ELSE LPC
PCH HAS INTERNAL WEAK
PD

TOP SWAP OVERRIDE STRAP
HIGH:TOP SWAP ENABLED
LOW:TOP SWAP DISABLED(DEFAULT)
PCH HAS INTERNAL WEAK PD

DCI BSSB MODE
PCH HAS INTERNAL WEAK PD

OD PLL VR ENABLE DISABLED WHEN
SAMPLED LOW

ijıŮŪŭŴ

ijıŮŪŭŴ

IJıŮŪŭŴ

CLOSE TO PCH

DSX

Flash Descriptor Security Overide
Low = Disabled-(Default)
High = Enabled

DRAM_RST#

6-06-00054-06F

VCC_3P3DSW_PWRGD Design Note:

PCH_DPWROK > 10ms Delay

DDR GPIO OUTPUT VOLTAGE SELECT

TLS CONFIDENTIALITY ENABLED

IF SAMPLED HIGH(DEFAULT)

PCH HAS INTERNAL WEAK PD

D03 Raven modfiy 0417

D02_102518_Alex_Typec DP issue

D02_102518_Alex_HDA

3.3VS 3.3VA

VCC_RTC

VDDQ

3.3VA

3.3VA

VDD3

VDD3

VDD3

VDD3

VIN

VDD3

3.3VS

1.05DX_VCCSTG

SUS_PWR_ACK# 45

AUD_AZACPU_SCLK2

AUD_AZACPU_SDO_R2

AUD_AZACPU_SDI2

HDA_BITCLK71

HDA_SDOUT33,71
HDA_SYNC71

HDA_RST#71

HDA_SDIN071

SMB_CLK31,50

SMB_DATA31,50

PM_PCH_PWROK31

H_PWRGD 4

SYS_PWROK 31

AC_PRESENT 45

PWR_BTN# 45

PCIE_WAKE# 42

SUSC# 45,48,50

SUSB# 28,31,41,45,47,48,50,53,60

SUS_CLK 40

SUS_WARN# 45

HDA_SDOUT 33,71

ME_WE 45

DDR4_DRAMRST# 8,9

VDD3 4,23,30,31,36,39,40,42,44,45,46,47,48,49,52,53,55,56,57,58,59,60,63,70,71,72

3.3VS 8,9,23,24,27,28,29,30,31,32,34,35,38,39,40,42,43,44,45,47,48,52,59,70,71

VDDQ 6,8,9,48,50

VCC_RTC 30,36

1.05DX_VCCSTG 4,6,53

3.3VA 4,30,31,32,36,38,44,48,53

SLP_S0# 48,52

PCH_DPWROK31

EC_RSMRST#45

VIN 28,47,48,49,50,51,52,53,54,55,57,72

PCH_SPKR 71

NV_EN_DOWN24

LAN_WAKEUP# 30,42,45

CNVI_RF_RST#40

XTAL_CLKREQ40

H_TCK 4

H_TMS 4
H_TDO 4

H_TDI 4

SKIN_THRM_SNSR_ALERT_N40

TPM_PIRQ# 44

MIC_CLK_PCH44

MIC_DATA_PCH44

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[33] PCH 4/12-HDA/SMBUS/RTC

A3

33 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[33] PCH 4/12-HDA/SMBUS/RTC

A3

33 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[33] PCH 4/12-HDA/SMBUS/RTC

A3

33 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

R245 33_04

Q34

2SK3018S3

G

DS

R288 8.2K_04

C731

*0.1u_25V_X5R_04.

D14

ZD5231BS2

AC

JOPEN1
*OPEN_10mil-1MM

12

R426
470_04

R310

100K_04

R281 1K_04

R262*100K_04

RN2 10K_8P4R_04

1
2
3
4 5

6

7

8

R322 100K_04

J_RTC1
50271-0020N-001

PCB Footprint = 85204-02R

P/N = 6-20-43130-102

2

1

R825

*27p_50V_NPO_04

C749

1u_6.3V_X5R_02

R287 90.9K_1%_04

U17

TC7SZ08FU

1

2

5

4

3

R243 33_04

R706 *100K_04

R324 33_04

R305 *0_04

R320 *1.5K_04

C844

*0.1u_10V_X7R_04

R637 100_04

C

A

A

D21

BAT54CS3

1

2

3

R632 30.1_1%_04

R325

100K_04

R311 1K_04

R295

20K_1%_04

R672 1K_04

R252 33_04

R221 *51_04

R818 *33_04

C747
1u_6.3V_X5R_02

R414
20K_1%_04

R819 *33_04

R319 100K_04

R824

*100K_04

R239 33_04

R427 *45.3K_1%_04R424 0_04

R421

1K_04

R679 10K_04

R289

150K_1%_04

C822

10u_6.3V_X5R_06

Q33

MMBT3904H

B

E C

4 OF 13

?

?

?

?

U43D

CML_PCH_H_IP_EXT/BGA

HDACPU_SDO

AM2

HDACPU_SDI

AN3

HDACPU_SCLK

AM3

PCH_PWROK

AY42

DSW_PWROK

AW41

SYS_PWROK

AU3

CPUPWRGD

AE3

ITP_PMODE

AL3

GPD0/BATLOW#

BF44

GPD3/PWRBTN#

BE46

GPD5/SLP_S4#

BE42

GPP_C4/SML0DATA

BE24

GPP_D19/DMIC_CLK0/SNDW4_CLK

BD16

I2S1_SFRM/SNDW2_CLK

BD12

GPP_B11/I2S_MCLK

AP29

HDA_BCLK/I2S0_SCLK

BD11

HDA_SDO/I2S0_TXD

BF12

SRTCRST#

BD46

RSMRST#

BA47

GPP_D17/DMIC_CLK1/SNDW3_CLK

AW15

GPP_D8/I2S2_SCLK

AV18

GPD4/SLP_S3#

BF42

GPP_C3/SML0CLK

BF25

GPD11/LANPHYPC

BF41

PCH_JTAGX

AH4

HDA_SYNC/I2S0_SFRM

BG13

GPP_C0/SMBCLK

BE26

HDA_RST#/I2S1_SCLK

BE10

SYS_RESET#

AU2

GPP_A12/BM_BUSY#/ISH_GP6/SX_EXIT_HO LDOFF#

BF36

HDA_SDI0/I2S0_RXD

BE11

GPD9/SLP_WLAN#

BD42

SLP_LAN#

BF40

GPP_C5/SML0ALERT#

BF24

GPP_D20/DMIC_DATA0/SNDW4_DATA

BF15

GPP_D6/I2S2_TXD/MODEM_CLKREQ

BA17

RTCRST#

BE47

GPD6/SLP_A#

BE40

GPP_A15/SUSACK#

BE35

GPP_B2/VRALERT#

BE32

GPP_D5/I2S2_SFRM/CNV_RF_RESET#

BE16

GPP_B1/GSPI1_CS1#/TIME_SYNC1

BF33

GPP_C6/SML1CLK

BF27

GPD10/SLP_S5#

BC42

GPP_A8/CLKRUN#

AV32

PCH_JTAG_TDI

AH2

GPD8/SUSCLK

BE45

GPP_C2/SMBALERT#

BE25

PCH_JTAG_TMS

AJ4

GPP_K17/ADR_COMPLETE

R47

GPP_C1/SMBDATA

BF26

GPP_B23/SML1ALERT#/PCHHOT#

BD33

WAKE#

BB47

DRAM_RESET#

BB46

GPP_D18/DMIC_DATA1/SNDW3_DATA

AV16

HDA_SDI1/I2S1_RXD

BF10

PCH_JTAG_TCK

AJ3

GPP_B0/GSPI0_CS1#

BE29

GPP_B14/SPKR

AW29

GPD2/LAN_WAKE#

BG44

GPD1/ACPRESENT

BG42

GPP_C7/SML1DATA

BE27

I2S1_TXD/SNDW2_DATA

BE12

SLP_SUS#

BD39

GPP_A13/SUSWARN#/SUSPW RDNACK

BC37

GPP_B12/SLP_S0#

BC28

GPP_D7/I2S2_RXD

AW18

PCH_JTAG_TDO

AH3

D37

RB751S-40H

A C

R309 *1K_04

R681 1K_04

R633 30.1_1%_04

R328 *20mil short-p

R282 *10mil_short

RN1 1K_8P4R_04

1
2
3
4 5

6

7

8

R284

*4.7K_04

R326 0_04

R420
20K_1%_04

R316 *0_04

R715 1K_04

SUS_CLK

PCH_HOT_GNSS_DISABLESPKR_SMC_EXTSMI

SUS_PWR_ACK#_R

AUD_AZACPU_SDO

AUD_AZACPU_SCLK_R

RSMRST#

SKIN_THRM_SNSR_ALERT_N

SML0_DATA
PCH_HOT_GNSS_DISABLE
SMC_CPU_THERM

PCH_DPWROK

ISH_GP_6_R

PM_CLKRUN#

LAN_DISABLE_N

DDR4_DRAMRST#

VRALERTB#
GPP_B1

PCIE_WAKE#

SLP_A#

PM_SLP_LAN#

PM_BATLOW#

SUSWARN#

AC_PRESENT

SLP_SUS#_R

PWR_BTN#
SYS_RESET#

SPKR_SMC_EXTSMI

ITP_PMODE

PCH_JTAG_TCK

RTC_VBAT_1

RTC_RST#
SRTC_RST#

HDA_SDOUT

DDR4_DRAMRST#

SKIN_THRM_SNSR_ALERT_N

PCIE_WAKE#

SML0_CLK
SML0_DATA

SUSWARN#

PM_BATLOW#
AC_PRESENT

PM_CLKRUN#

SYS_RESET#

SMB_CLK
SMB_DATA

SMC_CPU_THERM
SMD_CPU_THERM

RTC3.2V

RSMRST#

RSMRST#

RSMRST#

SMD_CPU_THERM

PCH_SLP_WLAN#

RTC_VBAT

LAN_WAKEUP#

SUSWARN#

SUS_PWR_ACK#_R

PCH_DPWROK

SML0_CLK

SUS_CLK_R

PWR_BTN#

GPP_C5

SMB_DATA

SMB_CLK

TPM_PIRQ#

H_TDO

MIC_DATA_PCH_R

MIC_CLK_PCH_R

PCH 4/9

B.Schematic Diagrams

B - 34 PCH 4/9

PCH 5/9

Sheet 34 of 67

PCH 5/9

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

24 Mhz

嶇

BIOS 䡢

娵

1-USB3.1(II) Port 1 Charger

MDP OUT (B) (iGPU)
HDMI OUT(C)

嶇

BIOS 䡢

娵

GPIO
H: W/KBLED
L: W/O KBLED

H: R154--N8 70RC L: R177 --N850RC

H: R154--N8 70RN L: R177 --N850RN

2-USB3.0 Port2(Audio B'd)

3,4

5

Audio USB3.0 Con.

Audio USB2.0 Con.

USB TABLE

USB2.0

DEVICE

USB3.0

Charger, PORT 1

Type-C

BT

CCD

3G/LTE

3

5

6

7

8

14

11

7

D03 Raven modfiy 0417

Remove Biaggi 0507

Biaggi 0507

modification 0507 Biaggi

USB3.1 G2 Port3 to ANX7440

modfication 0517 Biaggi

raven add 0629

DP OUT(E port) (dGPU)

raven del 0731

raven del 0731

3.3VS

3.3VS

3.3VS

3.3VS

5VS27,29,31,43,44,45,46,47,70,71,72

3.3VS8,9,23,24,27,28,29,30,31,32,33,35,38,39,40,42,43,44,45,47,48,52,59,70,71

EDP_HPD28

HDMI_HPD23,29

GC6_FB_EN_PCH 24,45

DGPU_PWRGD_R 24

DGPU_PWR_EN 24,45

H_SKTOCC_N 4,38

USB3_RXP141

USB3_RXN141

USB3_TXP141

USB3_TXN141

LPC_AD0 45
LPC_AD1 45
LPC_AD2 45
LPC_AD3 45

LPC_FRAME# 45
SERIRQ 45

PCLK_KBC 45

SB_KBCRST# 45

SMI# 45

3.3VA4,30,31,32,33,36,38,44,48,53

I_MDP_ HPD27

DEVSLP0 39

USB3_RXP243

USB3_RXN243

USB3_TXP243

USB3_TXN243

MDP_E_HPD23,69

1V8_AON10,12,13,14,15,17,18,20,21,22,23,24,25,56,59,60,72

DGPU_RST#_PCH 23,24

ANX7440_SSTXP68
ANX7440_SSTXN68
ANX7440_SSRXP68
ANX7440_SSRXN68

DEVSLP1 40

GPU_EVENT# 23

I_MDP_ DATA 27

I_MDP_ CLK 27

INTP_OUT 69

DEVSLP4 43

LIGHT_KB_DET# 45

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[34] PCH 5_6/12-DPP/ESPI/USB3.0

A3

34 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[34] PCH 5_6/12-DPP/ESPI/USB3.0

A3

34 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[34] PCH 5_6/12-DPP/ESPI/USB3.0

A3

34 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

R333 10K_04

R297 0_04

R233 10K_04

R337 22_04

R732
*10K_04

RN3

10K_8P4R_04

1
2
3
4 5

6

7

8

R741 0_04

R734 *10K_04

R327 22_04

R253 1K_04

R745 *10mil_short

RN33

2.2K_8P4R_04

1
2
3
4 5

6

7

8

R727 0_04

R694
100K_04

5 OF 13

?

?

?

?

U43E

CML_PCH_H_IP_EXT/BGA

GPP_K22/IMGCLKOUT0

L48

GPP_F22/DDPF_CTRLCLK

AT49

GPP_I1/DDPC_HPD1/DISP_MISC1

AN10

GPP_I10/DDPD_CTRLDATA

AR3

GPP_K23/IMGCLKOUT1

M45

GPP_I6/DDPB_CTRLDATA

AR8

GPP_I2/DDPD_HPD2/DISP_MISC2

AP9

GPP_I9/DDPD_CTRLCLK

AL9

GPP_I0/DDPB_HPD0/DISP_MISC0

AT6

GPP_I4/EDP_HPD/DISP_MISC4

AN6

GPP_F23/DDPF_CTRLDATA

AN40

GPP_I7/DDPC_CTRLCLK

AN13

GPP_K20

T46

GPP_I8/DDPC_CTRLDATA

AL10

GPP_K21

T45

GPP_I5/DDPB_CTRLCLK

AL13

GPP_H23/TIME_SYNC0

AJ47

GPP_I3/DDPF_HPD3/DISP_MISC3

AL15

GPP_F14/PS_ON#

AP41

R336 22_04

R308 10K_04

R742
*10K_04

R695 *10K_04

R244

*100K_04

R234

100K_04

R330 22_04

R241
100K_04

R254

*100K_04

R315 22_04

6 OF 13

?

?

?

?

U43F

CML_PCH_H_IP_EXT/BGA

USB31_1_TXN

F9

USB31_1_TXP

F7

USB31_1_RXN

D11

USB31_1_RXP

C11

USB31_2_TXN

C3

USB31_2_TXP

D4

USB31_2_RXN

B9

USB31_2_RXP

C9

USB31_6_TXN

C17

USB31_6_TXP

C16

USB31_6_RXN

G14

USB31_6_RXP

F14

USB31_5_TXN

C15

USB31_5_TXP

B15

USB31_5_RXN

J13

USB31_5_RXP

K13

USB31_3_TXP

G12

USB31_3_TXN

F11

USB31_3_RXP

C10

USB31_3_RXN

B10

USB31_4_TXP

C14

USB31_4_TXN

B14

USB31_4_RXP

J15

USB31_4_RXN

K16

GPP_A1/LAD0/ESPI_IO0

BB39

GPP_K18/NMI#

T47

GPP_A6/SERIRQ/ESPI_CS1#

AW35

GPP_A14/SUS_STAT#/ESPI_RESET#

BF38

GPP_F5/SATA_DEVSLP3

AP48

GPP_A4/LAD3/ESPI_IO3

BA38

GPP_F6/SATA_DEVSLP4

AR47

GPP_A9/CLKOUT_LPC0/ESPI_CLK

BB36

GPP_F7/SATA_DEVSLP5

AN46

GPP_A3/LAD2/ESPI_IO2

AV37

GPP_A5/LFRAME#/ESPI_CS0#

BE38

GPP_F8/SATA_DEVSLP6

AN37

GPP_E4/SATA_DEVSLP0

AL48

GPP_A10/CLKOUT_LPC1

BB34

GPP_E5/SATA_DEVSLP1

AH35

GPP_A0/RCIN#/ESPI_ALERT1#

BE39

GPP_A7/PIRQA#/ESPI_ALERT0#

BA36

GPP_A2/LAD1/ESPI_IO1

AW37

GPP_F9/SATA_DEVSLP7

AP47

GPP_K19/SMI#

T48

GPP_E6/SATA_DEVSLP2

AH40

R250 *1K_04

T73

R249
100K_04

R338 *10K_04

DGPU_SELECT#
DGPU_PRSNT#

SERIRQ

SB_KBCRST#

S4_STATE#

PCH_MUTE#

KBLED_DET

KBLED_DET

S4_STATE#

SMI#_RR

SERIRQ

SB_KBCRST#

DGPU_PWR_EN

SMI#_RR

DGPU_SELECT#

GPU_EVENT#

GC6_FB_EN_PCH

DGPU_PWRGD_R

DGPU_PRSNT#

DGPU_PWR_EN

DGPU_RST#_PCH

CLK_PCI_KBC_R

GPP_F9

GPP_F9

GPP_F8

GPP_F8

I_MDP_ CLK

I_MDP_ DATA

I_MDP_ CLK
I_MDP_ DATA

INTP_O UT

LIGHT_KB_DET#

Schematic Diagrams

B.Schematic Diagrams

PCH 5/9 B - 35

Schematic Diagrams

Sheet 35 of 67

PCH 6/9

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

RTC(10M RES): DON'T CHANGE TO 0402

PCIe* 100 MHz

32.768KHZ
6-22-32R76-0B2
6-22-32R76-0BJ

100 MHz

24 MHz

100 MHz

100 MHz

100 MHz

100 MHz

6-07-18034-1A0

SPEC: 20PPM

2015.9.11

32.768KHz 暨␴ PCH

⎴ᶨ朊ᶵ⎗ㇻ

VIA

XTAL

ᶳ㕡ᶵ⎗㚱

POWER OR

ᾉ嘇

1 ASM x142 USB 3.1
5 GLAN
6 WLAN
8 PEG(NV)
9 SSD (X 4 LANE)

PCI-E CLK Usage

CLK_REQ1_ASM_CLKREQ_N

D03 Raven modfiy 0417

D03 Raven modfiy 0417

raven add 0629

100 MHz

3.3VS

VDD1.05

3.3VS

PCH_CPU_BCLK_R_DP4

PCH_CPU_BCLK_R_DN4

CPU_24MHZ_R_DP4
CPU_24MHZ_R_DN4

3.3VS 8,9,23,24,27,28,29,30,31,32,33,34,38,39,40,42,43,44,45,47,48,52,59,70,71
VDD1.05 36,48,53

PCH_CPU_PCIBCLK_R_DP 4

PCH_CPU_PCIBCLK_R_DN 4

VGA_PEXCLK# 10
VGA_PEXCLK 10

CLK_PCIE_GLAN# 42
CLK_PCIE_GLAN 42

CLK_PCIE_MINI 40

CLK_P CIE_MIN I# 40

CLK_PCIE_SSD# 40
CLK_PCIE_SSD 40

PEG_CLKREQ#10

SSD_CLKREQ#40

LAN_CLKREQ#42
WLAN_CLKREQ#40

VCC_RTC 30,33,36
VDD3 4,23,30,31,33,36,39,40,42,44,45,46,47,48,49,52,53,55,56,57,58,59,60,63,70,71,72

CLKIN_XTAL_LCP 40

1V8_AON 10,12,13,14,15,17,18,20,21,22,23,24,25,56,59,60,72

CLK_PCIE_SSD2# 39
CLK_PCIE_SSD2 39

SSD2_CLKREQ#39

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[35] PCH 7/12-CLKOUT

A3

35 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[35] PCH 7/12-CLKOUT

A3

35 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[35] PCH 7/12-CLKOUT

A3

35 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

R231

10K_04

L8

FCM1005KF-121T03

C1122 15p_50V_NPO_04

C1133 15p_50V_NPO_04

R723

10K_04

R618 *2.7K_1%_04

7 OF 13

?

?

?

?

U43G

CML_PCH_H_IP_EXT/BGA

GPP_A16/CLKOUT_48

BE33

CLKOUT_CPUBCLK_P

B8

CLKOUT_CPUNSSC

C6

CLKOUT_CPUBCLK

C8

XCLK_BIASREF

T3

XTAL_IN

U10

GPP_B7/SRCCLKREQ2#

AR32

GPP_H2/SRCCLKREQ8#

AE41

GPP_H1/SRCCLKREQ7#

AC48

GPP_H0/SRCCLKREQ6#

AE47

GPP_B10/SRCCLKREQ5#

AN29

GPP_B9/SRCCLKREQ4#

BA30

GPP_B8/SRCCLKREQ3#

BB30

GPP_B6/SRCCLKREQ1#

BE31

GPP_B5/SRCCLKREQ0#

BF31

RTCX2

BA48

RTCX1

BA49

CLKOUT_CPUNSSC_P

D7

XTAL_OUT

U9

CLKOUT_ITPXDP_P

Y4

CLKOUT_CPUPCIBCLK_P

A6

CLKOUT_PCIE_P0

AJ7

CLKOUT_PCIE_N1

AH9

CLKOUT_PCIE_N0

AJ6

CLKOUT_CPUPCIBCLK

B6

CLKOUT_ITPXDP

Y3

CLKOUT_PCIE_P13

Y2

CLKOUT_PCIE_P10

AC11

CLKOUT_PCIE_N10

AC9

CLKOUT_PCIE_N9

U2

CLKOUT_PCIE_P9

U3

CLKOUT_PCIE_N6

W4

CLKOUT_PCIE_P6

W3

CLKOUT_PCIE_N7

W7

CLKOUT_PCIE_P7

W6

CLKOUT_PCIE_N8

AC14

CLKOUT_PCIE_P8

AC15

CLKOUT_PCIE_P15

V3

CLKOUT_PCIE_P1

AH10

CLKOUT_PCIE_P2

AE15

CLKOUT_PCIE_P3

AE7

CLKOUT_PCIE_N2

AE14

CLKOUT_PCIE_P4

AC3

CLKIN_XTAL

R6

CLKOUT_PCIE_N3

AE6

CLKOUT_PCIE_P5

AB3

CLKOUT_PCIE_N4

AC2

GPP_H9/SRCCLKREQ15#

AC43

CLKOUT_PCIE_N5

AB2

GPP_H6/SRCCLKREQ12#

AE39

GPP_H8/SRCCLKREQ14#

AC44

GPP_H5/SRCCLKREQ11#

AC39

GPP_H7/SRCCLKREQ13#

AB48

CLKOUT_PCIE_N11

AE9

GPP_H4/SRCCLKREQ10#

AC41

CLKOUT_PCIE_N12

AC7

CLKOUT_PCIE_P11

AE11

CLKOUT_PCIE_N13

AA1

CLKOUT_PCIE_N14

T2

CLKOUT_PCIE_P12

AC6

CLKOUT_PCIE_N15

V2

GPP_H3/SRCCLKREQ9#

AF48

CLKOUT_PCIE_P14

T1

R642 0_04

R619

1M_1%_04

R6430_04

X5

CM200C_32.768KHZ

CM200S

14

3 2

C1047 15p_50V_NPO_04

RN4 10K_8P4R_04

1
2
3
4 5

6

7

8

R709

10M_06

R717 0_04

C1046 15p_50V_NPO_04

C649
5p_50V_NPO_04

R634 60.4_1%_04

X4

FSX3M_24MHZ

2 1

3 4

RTC_X2

RTC_X1

XTAL24_O
XTAL24_IN

PCH_XDP_CLK_DN

PCH_XDP_CLK_DP

LAN_CLKREQ#
WLAN_CLKREQ#

PEG_CLKREQ#

SSD_CLKREQ#

XCLK_RBIAS

LAN_CLKREQ#

PEG_CLKREQ#
WLAN_CLKREQ#

SSD_CLKREQ#

XCLK_RBIAS

SSD2_CLKREQ#

SSD2_CLKREQ#

PCH 6/9

B.Schematic Diagrams

B - 36 PCH 6/9

PCH 7/9

Sheet 36 of 67

PCH 7/9

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

CLOSE TO PCH

0.182A

0.97A

0.174A

0.00767A

0.145A

eSPI:1.8V
LPC:3.3V

CLOSE TO PCH
(1-3 mm)

CLOSE TO PCH
(1-3 mm)

CLOSE TO PCH
(1-3 mm)

5.95A

6.66A

0.42A

0.0012A

0.2A

0.109A

0.015A

0.213A

0.00428A

0.169A

0.0198A

0.0085A

0.021A

0.095A

0.05A

0.000416A

0.262A

0.14A

0.343A

0.101A

0.106A

0.113A

0.766A

0.882A

0.0859A

0.193A

D03 Raven modfiy 0417

D03 Raven modfiy 0417

D03 Raven modfiy 0417

VDD1.05

VDD1.05

VDD3

3.3VA

3.3VA

3.3VA

3.3VA

3.3VA

SPI_3.3V

3.3VA

VCC_RTC

VDD1.05

VDD1.05

VDD1.05

VDD1.05

VDD1.05

VDD1.05

VDD1.05

VDD1.05

VDD1.05

VDD1.05

3.3VA

1.8VA

3.3VA

3.3VA

3.3VA

1P8_LDO

1P8_LDO
VDD1.05

VDD1.05

1.8VA

PCH1.8VA

VDD1.0535,48,53

3.3VS8,9,23,24,27,28,29,30,31,32,33,34,35,38,39,40,42,43,44,45,47,48,52,59,70,71

VDD34,23,30,31,33,39,40,42,44,45,46,47,48,49,52,53,55,56,57,58,59,60,63,70,71,72

VCC_RTC30,33

3.3VA4,30,31,32,33,38,44,48,53

SPI_3.3V30

1.8VA53,59,60,68

PCH1.8VA38

VCCMPHY_SENSE48VSSMPHY_SENSE

48

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[36] PCH 8/12-POWER

A3

36 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[36] PCH 8/12-POWER

A3

36 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[36] PCH 8/12-POWER

A3

36 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

R216 *20mil_04

R251 *20mil_04

R235 *20mil_04

C647
1u_6.3V_X5R_02

C689
*0.1u_10V_X7R_04

R240 *20mil_04

C732
*1u_6.3V_X5R_02

C1041
1u_6.3V_X5R_02

R280 *20mil_04

R255 *0_06

C1051
1u_6.3V_X5R_02

C1117
1u_6.3V_X5R_02

C696
1u_6.3V_X5R_02

R304 *20mil_04

C1118

1u_6.3V_X5R_02

R264 0_06

C744

0.1u_10V_X7R_04

C661

0.1u_10V_X7R_04

R314 *20mil_04

C745

0.1u_10V_X7R_04

C698
1u_6.3V_X5R_02

C676

4.7u_6.3V_X5R_06

C658
1u_6.3V_X5R_02

R267 *20mil_04

C734
*1u_6.3V_X5R_02

C750
1u_6.3V_X5R_02

R602 *20mil_04

R612 *20mil_04

R293 *20mil_04

8 OF 13

?

?

?

?

U43H

CML_PCH_H_IP_EXT/BGA

VCCPRIM_1P051

AA22

VCCPRIM_1P052

AA23

VCCPRIM_1P053

AB20

VCCPRIM_1P054

AB22

VCCPRIM_1P055

AB23

VCCPRIM_1P056

AB27

VCCPRIM_1P057

AB28

VCCPRIM_1P058

AB30

VCCPRIM_1P059

AD20

VCCPRIM_1P0510

AD23

VCCPRIM_1P0511

AD27

VCCPRIM_1P0512

AD28

VCCPRIM_1P0513

AD30

VCCPRIM_1P0514

AD31

VCCPRIM_1P0515

AE17

VCCPRIM_1P0516

AF23

VCCDUSB_1P051

W22

VCCDUSB_1P052

W23

VCCDSW_1P051

BG45

VCCDSW_1P052

BG46

VCCAMPHYPLL_1P051

C49

VCCAMPHYPLL_1P052

D49

VCCAMPHYPLL_1P053

E49

VCCA_XTAL_1P051

P2

VCCA_XTAL_1P052

P3

VCCA_SRC_1P051

W19

VCCA_SRC_1P052

W20

VCCPGPPHK1

AC35

VCCPGPPHK2

AC36

VCCPGPPEF1

AE35

VCCPGPPEF2

AE36

VCCPGPPD

AN24

VCCPGPPBC1

AN26

VCCPGPPBC2

AP26

VCCPGPPA

AN32

VCCPRIM_1P81

AG19

VCCPRIM_1P82

AG20

VCCPRIM_1P83

AN15

VCCPRIM_1P84

AR15

VCCPRIM_1P85

BB11

VCCDPHY_1P241

AJ22

VCCDPHY_1P242

AJ23

VCCDPHY_1P243

AK22

VCCMPHY_SENSE

K47

VSSMPHY_SENSE

K46

VCCAPLL_1P055

C2

VCCDSW_3P32

BE49

VCCHDA

BB14

VCCAPLL_1P054

C1

VCCDSW_3P31

BE48

VCCAPLL_1P053

B3

VCCAPLL_1P052

B2

VCCPRIM_MPHY_1P05

W31

VCCAPLL_1P051

B1

VCCPRIM_1P0519

AF31

VCCPRIM_1P0529

V31

VCCPRIM_1P0518

AF30

VCCPRIM_1P0528

V30

VCCPRIM_1P0517

AF27

VCCPRIM_1P0527

V28

VCCSPI

AN44

VCCPRIM_1P0526

V27

VCCPRIM_1P0525

V25

VCCPRIM_1P0524

U29

VCCPRIM_1P0523

U26

VCCRTC2

BD49

VCCPRIM_3P35

V23

VCCPRIM_1P0522

E1

VCCRTC1

BC49

VCCPRIM_1P0521

D1

VCCPRIM_3P34

BB7

VCCPGPPG_3P3

AN21

DCPRTC2

BG47

VCCPRIM_3P33

AY8

VCCPRIM_1P0520

AG31

DCPRTC1

BF47

VCCPRIM_3P32

AW9

VCCA_BCLK_1P05

V19

VCCPRIM_3P31

AT44

VCCDPHY_1P245

BG5

VCCDPHY_1P244

AK23

VCCPHVLDO_1P82

AF20

VCCPHVLDO_1P81

AF19

C1116
*22u_6.3V_X5R_08

R302 *20mil_04

R318

100_04

R620 *20mil_04

R753 *20mil_04

C751
*1u_6.3V_X5R_02

C1125
*0.1u_10V_X7R_04

R711 *20mil_04

C724
22u_6.3V_X5R_08

C1115
*22u_6.3V_X5R_08

R317

100_04

R275 *20mil_04

C1121

*0.1u_10V_X7R_04

C709

*0.1u_10V_X7R_04

R232 *20mil_04

R298 *20mil_04

R256 *20mil_04

R277 *20mil_04

C1048

4.7u_6.3V_X5R_06

R313 *20mil_04

C1040
*22u_6.3V_X5R_08

R335 *20mil_04

C743

*22u_6.3V_X5R_06

R323 *20mil_04

C656
1u_6.3V_X5R_02

R312 *20mil_04

R257 *20mil_04

R274 *20mil_04

C657

4.7u_6.3V_X5R_06

VCCPRTC3P3

V3.3A_V1.8A_VCCPSPI

VCCDSW_1P05

VCC_RTCEXT_CAP

V3.3A_VCCPGPPHK

V3.3A_VCCPGPPEF

PCH1.8VA

Schematic Diagrams

B.Schematic Diagrams

PCH 7/9 B - 37

Schematic Diagrams

Sheet 37 of 67

PCH 8/9

5

4

3

2

1

D D

C C

B B

A

A

M/B PCH

GND

GND

GND GND GND

GND GND

GND GND

GND

GND GND

GND GND

GND GND GND

GND GND

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[37] PCH 9_12/12-VSS,Holes

A3

37 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[37] PCH 9_12/12-VSS,Holes

A3

37 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[37] PCH 9_12/12-VSS,Holes

A3

37 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

H20
*H8_5D6_5

1

H27

*MTH7_0D2_8

2

3 5

4

M2
*M-MARK

H31
*C111D111N

H6
*h2_8d1_8

1

H19

*MTH7_0D2_8

2

3 5

4

1

H30

*MTH7_0D2_8

2

3 5

4

M3
*M-MARK

H23
*H8_5D6_5

H1
*h2_8d1_8

12 OF 13

?

?

?
?

U43L

CML_PCH_H_IP_EXT/BGA

VSS_157

D16

VSS_168

E24

VSS_179

G44

VSS_201

N12

VSS_234

V22

VSS_145

BG3

VSS_156

D12

VSS_167

E22

VSS_178

F47

VSS_189

J48

VSS_200

M5

VSS_233

V20

VSS_155

C5

VSS_166

E19

VSS_177

F43

VSS_188

J47

VSS_199

M49

VSS_232

U38

VSS_243

Y17

VSS_154

C48

VSS_165

E17

VSS_176

F41

VSS_187

J46

VSS_198

M34

VSS_220

T18

VSS_231

U33

VSS_153

C4

VSS_164

E15

VSS_175

E8

VSS_186

J40

VSS_197

M32

VSS_230

U24

VSS_196

M24

VSS_152

C30

VSS_163

E13

VSS_174

E42

VSS_185

J4

VSS_240

W30

VSS_195

M21

VSS_151

C25

VSS_162

E10

VSS_173

E40

VSS_184

J29

VSS_150

C12

VSS_161

D8

VSS_172

E35

VSS_183

J26

VSS_194

M18

VSS_160

D33

VSS_171

E33

VSS_182

J10

VSS_193

M16

VSS_181

H8

VSS_192

K39

VSS_209

P4

VSS_180

G6

VSS_191

K11

VSS_208

P29

VSS_190

J9

VSS_207

P26

VSS_218

R4

VSS_229

U21

VSS_206

N38

VSS_228

U17

VSS_239

W28

VSS_238

W27

VSS_149

BG48

VSS_237

W25

VSS_148

BG4

VSS_159

D30

VSS_147

BG37

VSS_158

D17

VSS_244

Y33

VSS_245

Y38

VSS_246

Y9

VSS_242

Y12

VSS_241

Y10

VSS_235

V4

VSS_236

V46

VSS_227

U15

VSS_226

U12

VSS_225

T7

VSS_224

T5

VSS_219

T17

VSS_217

R38

VSS_216

R34

VSS_213

R26

VSS_214

R29

VSS_215

R3

VSS_170

E31

VSS_169

E26

VSS_221

T32

VSS_222

T4

VSS_223

T49

VSS_203

N34

VSS_202

N16

VSS_205

N37

VSS_204

N35

VSS_146

BG33

VSS_210

P46

VSS_211

R12

VSS_212

R16

1

H28

*MTH7_0D2_8

2

3 5

4

1

H11

*MTH7_0D2_8

2

3 5

4

M14
*M-MARKM4*M-MARK

1

H32

*MTH7_0D2_8

2

3 5

4

H5
*nh_C111D111N

H9
*C111D111N

1

H29

*MTH7_0D2_8

2

3 5

4

H10
*C111D111N

M1
*M-MARK

9 OF 13

?

?

?

?

U43I

CML_PCH_H_IP_EXT/BGA

VSS_136

BF2

VSS_125

BC19

VSS_114

BA12

VSS_103

AT34

VSS_90

AP46

VSS_19

AA31

VSS_137

BF3

VSS_126

BC24

VSS_115

BA14

VSS_104

AT45

VSS_91

AR12

VSS_80

AL38

VSS_138

BF48

VSS_127

BC26

VSS_116

BA44

VSS_105

AV11

VSS_92

AR16

VSS_81

AM1

VSS_70

AK31

VSS_139

BF49

VSS_128

BC31

VSS_117

BA5

VSS_106

AV39

VSS_93

AR34

VSS_82

AM18

VSS_71

AK4

VSS_60

AJ27

VSS_129

BC35

VSS_118

BA6

VSS_107

AW10

VSS_94

AR38

VSS_83

AM32

VSS_72

AK46

VSS_61

AJ28

VSS_50

AG28

VSS_119

BB41

VSS_108

AW4

VSS_95

AT1

VSS_84

AM49

VSS_73

AL12

VSS_62

AJ30

VSS_51

AG30

VSS_40

AE4

VSS_109

AW40

VSS_96

AT16

VSS_85

AN12

VSS_74

AL17

VSS_63

AJ31

VSS_52

AG49

VSS_41

AE46

VSS_30

AC46

VSS_1

A2

VSS_97

AT18

VSS_86

AN16

VSS_75

AL21

VSS_64

AK19

VSS_53

AH12

VSS_42

AF22

VSS_31

AD1

VSS_20

AA49

VSS_2

A28

VSS_98

AT21

VSS_87

AN34

VSS_76

AL24

VSS_65

AK20

VSS_54

AH17

VSS_43

AF25

VSS_32

AD19

VSS_21

AA5

VSS_10

A48

VSS_3

A3

VSS_99

AT24

VSS_88

AN38

VSS_77

AL26

VSS_66

AK25

VSS_55

AH33

VSS_44

AF28

VSS_33

AD2

VSS_22

AB19

VSS_11

A5

VSS_4

A33

VSS_140

BG17

VSS_89

AP4

VSS_78

AL29

VSS_67

AK27

VSS_56

AH38

VSS_45

AG1

VSS_34

AD22

VSS_23

AB25

VSS_12

A8

VSS_5

A37

VSS_141

BG2

VSS_130

BC40

VSS_79

AL33

VSS_68

AK28

VSS_57

AJ19

VSS_46

AG22

VSS_35

AD25

VSS_24

AB31

VSS_13

AA19

VSS_6

A4

VSS_142

BG22

VSS_131

BC45

VSS_120

BB43

VSS_69

AK30

VSS_58

AJ20

VSS_47

AG23

VSS_36

AD49

VSS_25

AC12

VSS_14

AA20

VSS_7

A45

VSS_143

BG25

VSS_132

BC8

VSS_121

BB9

VSS_110

AW46

VSS_59

AJ25

VSS_48

AG25

VSS_37

AE12

VSS_26

AC17

VSS_15

AA25

VSS_8

A46

VSS_144

BG28

VSS_133

BD43

VSS_122

BC10

VSS_111

B47

VSS_100

AT26

VSS_49

AG27

VSS_38

AE33

VSS_27

AC33

VSS_16

AA27

VSS_9

A47

VSS_134

BE44

VSS_123

BC13

VSS_112

B48

VSS_101

AT29

VSS_39

AE38

VSS_28

AC38

VSS_17

AA28

VSS_135

BF1

VSS_124

BC15

VSS_113

B49

VSS_102

AT32

VSS_29

AC4

VSS_18

AA30

1

H14

*MTH7_0D2_8

2

3 5

4

1

H12

*MTH7_0D2_8

2

3 5

4

M11
*M-MARK

H24

H6_0D3_7

H7
*h2_8d1_8

1

H33

*MTH7_0D2_8

2

3 5

4

M12
*M-MARK

H8
*h2_8d1_8

M17
*M-MARK

H4
*H8_5D6_5

1

H13

*MTH7_0D2_8

2

3 5

4

PCH 8/9

B.Schematic Diagrams

B - 38 PCH 8/9

PCH 9/9

Sheet 38 of 67

PCH 9/9

5

4

3

2

1

D D

C C

B B

A

A

NO REBOOThis signal has an integrated weak
pull-down resistor (20 KΩ nominal) to
disable the no reboot strap functionality
by default.

To enable no reboot on TCO Timer
expiration, this signal should be
pulled-up to V3.3S through a 1k to 2.2 KΩ
±5% resistor.

BOOT STARP
This signal has an integrated weak
pull-down resistor (20 KΩ nominal)
to default boot from SPI.

To enable boot to LPC, this signal
should be pulled up to V3.3S through
a 1k to 2.2 KΩ ±5% resistor.

嶇

BIOS 䡢

娵

嶇

BIOS 䡢

娵

DEBUG
TX -> D+
RX -> D-

嶇

BIOS 䡢

娵

GPIO
H: W / TPM
L: W/O TPM

Differential between RCOMPN/RCOMPP.

Length matched to less than 1% trace.

DEL ASM_SMI#

XTAL SELECT-1
HIGH -> 24 MHZ
LOW -> 38.4 MHZ

M.2 CNVI STRAP
HIGH -> DISABLE
LOW -> ENABLE

Leakage

D01A for CNVI samuel

D01A for CNVI samuel

Raven add 0731

D02_102518_Alex_Typec DP issue

D02_1109_Alex

3.3VS

3.3VA

3.3VS

3.3VS

3.3VS

PCH1.8VA

PCH1.8VA

PCH1.8VA

3.3VS

PCH1.8VA PCH1.8VA

3.3VS8,9,23,24,27,28,29,30,31,32,33,34,35,39,40,42,43,44,45,47,48,52,59,70,71

VDD34,23,30,31,33,36,39,40,42,44,45,46,47,48,49,52,53,55,56,57,58,59,60,63,70,71,72

CPU_2_PCH_TRIGGER 6

PCH_2_CPU_TRIGGER 6

SB_BLON 28

3.3VA4,30,31,32,33,36,44,48,53

SATA_PWR_EN 43

CNVI_MFUART2_RXD40

CNVI_GNSS_PA_BLANKING40

CNVI_WGR_CLKP 40

CNVI_WGR_CLKN 40

CNVI_WGR_D0N 40
CNVI_WGR_D0P 40
CNVI_WGR_D1N 40
CNVI_WGR_D1P 40

CNVI_WT_CLKN 40
CNVI_WT_CLKP 40

CNVI_WT_D0N 40
CNVI_WT_D0P 40
CNVI_WT_D1N 40
CNVI_WT_D1P 40

CNVI_BRI_DT40

CNVI_RGI_DT40

CNVI_MFUART2_TXD40

H_SKTOCC_N4,34

PCH1.8VA36

GPP_J148,53

H_TRST# 4

H_PREQ# 4
H_PRDY# 4

GPIO4_1V8_MAIN_EN_R24

CNVI_BRI_RSP40

CNVI_RGI_RSP40

SMD_741169

SMC_741169

I2C_SCL_TP43
I2C_SDA_TP43

I2C2_SDA56,59
I2C2_SCL56,59

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[38] PCH 10_11/12-UART/I2C/GPIO

A3

38 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[38] PCH 10_11/12-UART/I2C/GPIO

A3

38 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[38] PCH 10_11/12-UART/I2C/GPIO

A3

38 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

R625200_1%_04

R261
100K_04

W/O TPM

R279 *0_06

R278

*4.7K_04

10 OF 13

?

?

?

?

U43J

CML_PCH_H_IP_EXT/BGA

TRIGGER_OUT

AK3

TRIGGER_IN

AK2

CPU_TRST#

AM4

PREQ#

AL2

RSVD4

R32

RSVD3

N32

PRDY#

AM5

RSVD2

AH15

RSVD1

AH14

RSVD8

Y15

RSVD7

Y14

RSVD6

U37

RSVD5

U35

T71

R628150_1%_04

R223200_1%_04

T63

R208

*10K_04

R630100K_04

R207

4.7K_04

11 OF 13

?

?

?

?

U43K

CML_PCH_H_IP_EXT/BGA

GPP_C22/UART2_RTS#

AW21

GPP_C20/UART2_RXD

BD20

GPP_D13/ISH_UART0_RXD/I2C2 _SDA

BE17

GPP_C23/UART2_CTS#

AV21

GPP_D12/ISH_SPI_MOSI/GP_BSSB_DI /GSPI2_MOSI

AN18

GPP_C18/I2C1_SDA

BF21

GPP_C19/I2C1_SCL

BE21

GPP_C13/UART1_TXD/ISH_UART1_T XD

AP21

GPP_D14/ISH_UART0_TXD/I2C2 _SCL

BF17

GPP_H20/ISH_I2C0_SCL

AG45

GPP_A17/SD_VDD1_PWR_EN#/ISH_G P7

BD38

GPP_C12/UART1_RXD/ISH_UART1_RXD

AU24

GPP_B16/GSPI0_CLK

BF29

GPP_D16/ISH_UART0_CTS#/CNV_W CEN

BF14

GPP_B15/GSPI0_CS0#

BB26

GPP_A23/ISH_GP5

AV34

GPP_D10/ISH_SPI_CLK/GSPI2_CLK

BB20

GPP_H22/ISH_I2C1_SCL

AH47

GPP_A22/ISH_GP4

AW32

GPP_D15/ISH_UART0_RTS#/GSPI 2_CS1#/CNV_WFEN

AR18

GPP_H19/ISH_I2C0_SDA

AH46

GPP_C17/I2C0_SCL

BC22

GPP_C16/I2C0_SDA

BF23

GPP_D23/ISH_I2C2_SCL/I 2C3_SCL

BE14

GPP_A19/ISH_GP1

BD34

GPP_D11/ISH_SPI_MISO/GP_BSSB_CLK/GSPI2_MISO

BB16

GPP_A21/ISH_GP3

BA33

GPP_D9/ISH_SPI_CS#/GSPI2_CS0#

BA20

GPP_H21/ISH_I2C1_SDA

AH48

GPP_C21/UART2_TXD

BE20

GPP_C15/UART1_CTS#/ISH_UART1_CTS#

BD21

GPP_A18/ISH_GP0

BF35

GPP_A20/ISH_GP2

BE34

GPP_C14/UART1_RTS#/ISH_UART1_RTS#

AW24

GPP_C11/UART0A_CTS#

AP24

GPP_C8/UART0A_RXD

BE23

GPP_D4/ISH_I2C2_SDA/I2C3_SDA/SBK4/ BK4

BE15

GPP_C10/UART0A_RTS#

BA24

GPP_C9/UART0A_TXD

BB24

GPP_B21/GSPI1_MISO

BD30

GPP_B22/GSPI1_MOSI

BA26

GPP_B17/GSPI0_MISO

BD29

GPP_B19/GSPI1_CS0#

AW26

GPP_B18/GSPI0_MOSI

BE30

GPP_B20/GSPI1_CLK

AU26

R212

*100K_04

R649*10K_04

R616

20K_04

R25810K_04NH77

R635 30.1_1%_04

R657*10K_04

R629

10K_04

R626200_1%_04

R237100K_04

R268

*0402_short

R211

100K_04

R61522_04

R631

20K_04

R66210K_04

R276

*0402_short

R260
10K_04

TPM

R24875K_1%_04

T64

13 OF 13

?

?

?

?

U43M

CML_PCH_H_IP_EXT/BGA

CNV_WR_CLKN

BD4

CNV_WR_CLKP

BE3

CNV_WR_D0N

BB3

CNV_WR_D0P

BB4

CNV_WR_D1N

BA3

CNV_WR_D1P

BA2

CNV_WT_CLKN

BC5

CNV_WT_CLKP

BB6

CNV_WT_D0N

BE6

CNV_WT_D0P

BD7

CNV_WT_D1N

BG6

CNV_WT_D1P

BF6

CNV_WT_RCOMP

BA1

GPPJ_RCOMP_1P81

BD1

GPPJ_RCOMP_1P82

BE1

GPP_J0/CNV_PA_BLANKING

AV6

GPP_I11/M2_SKT2_CFG0

AP3

GPP_G7/SD_WP

AV13

GPP_G5/SD_CD#

BE8

GPP_I12/M2_SKT2_CFG1

AP2

PCIE_RCOMPN

B12

GPP_J9/CNV_MFUART2_TXD

AU9

GPP_I13/M2_SKT2_CFG2

AN4

GPP_I14/M2_SKT2_CFG3

AM7

PCIE_RCOMPP

A13

GPP_G6/SD_CLK

BD8

GPP_J8/CNV_MFUART2_RXD

AW2

GPP_J10

AV7

TP

AL35

RSVD2

Y35

GPP_J11/A4WP_PRESENT

AR13

RSVD1

BC1

GPP_J2

AW3

GPP_G4/SD_DATA3

BG8

GPP_J3

AT10

GPP_J7/CNV_RGI_RSP/UART0B_CTS#

AV3

GPP_J1/CPU_C10_GATE#

AY3

GPP_J4/CNV_BRI_DT/UART0B_RTS#

AV4

SD_1P8_RCOMP

BE5

GPP_J5/CNV_BRI_RSP/UART0B_RXD

AY2

GPP_J6/CNV_RGI_DT/UART0B_TXD

BA4

SD_3P3_RCOMP

BE4

GPP_G3/SD_DATA2

BF9

GPPJ_RCOMP_1P83

BE2

GPP_G2/SD_DATA1

BF8

RSVD3

Y36

GPP_G0/SD_CMD

AW13

GPP_G1/SD_DATA0

BE9

R283

*0402_short

R62722_04

R22810K_04

R265 *0402_short

R259*10K_04

R665100_1%_04

R270 *0_06

R689

*4.7K_04

LPSS_GSPI0_MOSI

LPSS_GSPI1_MOSI

PCH_2_CPU_TRIGGER_R

BOARD_ID2

DGPU_PWM_SELECT#

3G_CONFIG2

LPSS_GSPI1_MOSI

LPSS_GSPI0_MOSI

SB_BLON

UART2_TXD
UART2_RXD

TPM_DET

TPM_DET

PCIECOMP_N
PCIECOMP_P

BOARD_ID1

CNV_WT_RCOMP

SD3_RCOMP_1P8
SD3_RCOMP_3P3
GPPJ_RCOMP_1P8

CNVI_BRI_DT

CNVI_RGI_DT

GPP_J1

SMI#_R

SMI#_R

SMD_7411_I2C

SMC_7411_I2C

Schematic Diagrams

B.Schematic Diagrams

PCH 9/9 B - 39

Schematic Diagrams

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

SSD_CLKREQ# Pu 10K near to PCH-H.

Reserved

H: PCIe

DEBUG PORT

>120 mil

NGFF_M (M2) SSD (PCIE 4X)

>120 mil

PCB Footprint

婳䡢娵㨇㥳ἧ䓐䘬

Connector

80 mils

raven Del 0629

RTD3 POWER

M2. PCIE change(21~24)

6A 6A

D02_1101_Alex

M2_SSD2_3.3VS

M2_SSD2_3.3VS

M2_SSD2_3.3VS

GND GNDGND

GND

GND GND

GND

GND

GND

GND

3.3VS

3.3VS 3.3VS

VDD3

M2_SSD2_3.3VS

M2_SSD1_3.3VS

3.3VS

3.3VS

3.3VS

M2_SSD2_3.3VS

3.3VS

BUF_PLT_RST# 31,40,42,45

SSD2_CLKREQ# 35

CLK_PCIE_SSD2#35

CLK_PCIE_SSD235

PCIE_TXP23_SSD31

PCIE_TXN23_SSD31

PCIE_TXN22_SSD31

PCIE_TXP22_SSD31

PCIE_TXP21_SSD31
PCIE_TXN21_SSD31

PCIE_TXN24_SSD31

PCIE_TXP24_SSD31

PCIE_RXP24_SSD31

PCIE_RXN24_SSD31

PCIE_RXP23_SSD31

PCIE_RXN23_SSD31

PCIE_RXP22_SSD31

PCIE_RXN22_SSD31

PCIE_RXN21_SSD31

PCIE_RXP21_SSD31

VDD3 4,23,30,31,33,36,40,42,44,45,46,47,48,49,52,53,55,56,57,58,59,60,63,70,71,72

3.3VS 8,9,23,24,27,28,29,30,31,32,33,34,35,38,40,42,43,44,45,47,48,52,59,70,71

3.3V 2,24,28,41,43,47,48,50,51,54,57,58,59,68,69

DEVSLP0 34

M2M_SSD2_LED# 44

5V 28,41,43,47,48,50,53,58,69

SATA_M2_PWR_EN232

SATA_M2_PWR_EN1 32

M2_SSD1_3.3VS 40

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[39] M.2 3G Card

A3

39 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[39] M.2 3G Card

A3

39 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[39] M.2 3G Card

A3

39 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

M KEY

J_SSD2

NFSM0-S6701-TP40

PCB Footprint = NXSM0-S67XX-XX40

P/N = 6-21-84KE0-075

SUSCLK(32Khz)(O)

68

CLKREQ#(IO)

52

GND11

71

REFCLKP

55

REFCLKN

53

PEWake#(IO)

54

PEDET(NC-PCIe/GND-SATA)

69

GND10

57

DAS/DSS#(I)(OD)

10

GND12

73

3.3V2

12

NC18

67

NC1

8

NC0

6

DEVSLP(O)

38

PERST#(O)

50

GND9

51

3.3V0

2

GND0

1

3.3V1

4

GND1

3

GND2

9

PERp0/SATA-B-

43

PETp0/SATA-A+

49

PETn0/SATA-A-

47

PERn0/SATA-B+

41

GND7

39

GND8

45

GND13

75

3.3V3

14

3.3V4

16

PERn3

5

PERp3

7

3.3V5

18

GND3

15

PETn3

11

PETp3

13

GND5

27

PETn2

23

GND4

21

PERn2

17

PERp2

19

PETp2

25

NC3

22

NC2

20

NC5

26

NC4

24

NC7

30

NC9

34

NC6

28

NC8

32

NC10

36

NC12

42

NC13

44

NC15

48

NC14

46

NC11

40

PETp1

37

PETn1

35

PERp1

31

PERn1

29

GND6

33

NC16

56

NC17

58

3.3V6

70

3.3V7

72

3.3V8

74

C891

22u_6.3V_X5R_06

C767
*470p_50V_X7R_04

R348
*10K_04

C850

*0.1u_10V_X7R_02

C887

22u_6.3V_X5R_06

C845

0.1u_16V_X5R_02

C756

*0.1u_6.3V_X5R_02

C764

*0.1u_6.3V_X5R_02

R795 *10mil_short

R461 0_06

R383 10K_04

R794 *10mil_short

C840

0.1u_16V_X5R_02

C758

*0.1u_6.3V_X5R_02

C842

0.1u_10V_X7R_04

R455 0_06

R790

10K_04

C766

*470p_50V_X7R_04

C831

*0.1u_10V_X7R_04

C759

*0.1u_6.3V_X5R_02

R350 *10K_04

C755
*1u_6.3V_X5R_02

C768

*0.1u_6.3V_X5R_02

C754

*0.1u_6.3V_X5R_02

C835
*0.1u_10V_X7R_02

C823

0.1u_6.3V_X5R_02

*G5016U18

CT2

10

OUT2

8

EN25VBIAS

4

IN2

6

GND11EN1

3

CT1

12

OUT1

13

IN1

1

IN1

2

OUT1

14

IN2

7

OUT2

9

GND

15

Sheet 39 of 67

M.2 Card

M.2 Card

B.Schematic Diagrams

B - 40 M.2 Card

M.2 WLAN+BT, PCIE 4X SSD

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

WLAN+BT

PCB Footprint

婳䡢娵㨇㥳ἧ䓐䘬

Connector

40 mil

40 mil

>120 mil

NGFF_M (M2) SSD (PCIE 4X)

>120 mil

PCB Footprint

婳䡢娵㨇㥳ἧ䓐䘬

Connector

80 mils

Reserved

SATAGP1
H: PCIe
L: SATA

普󰵶㷔溆

SSD_CLKREQ# Pu 10K near to PCH-H.

L: CNVi
H: W/O CNVi

DEBUG PORT

D02 for CNVI samuel

>120 mil>120 mil

㍍⇘

EC ,枰冯EC

䡢娵

M: NCT3522U -- 6-02-03522-9C0
S: AP2821KTR-G1 6-02-02821-9C0

D01A for CNVI samuel

D02 for CNVI samuel

ADD Biaggi 0514

Remove 0 ohm
Biaggi 0514

Follow
07 PCH _ 07-03-2 M.2 WLAN+BT,CN.pdf
Biaggi 0514

3A

D02_102518_Alex_M.2

D02_1112_Alex

WLAN_3.3V

WLAN_3.3V

WLAN_3.3V

M2_SSD1_3.3VS

M2_SSD1_3.3VS

GND GNDGND

GND GND

GND

GND

3.3VS

GND

VDD3

VDD3

WLAN_3.3V

VDD3

M2_SSD1_3.3VS

GND

3.3VS

3.3VS

M2_SSD1_3.3VS

GND

USB_PP1431

USB_PN1431

BT_EN 30, 45

WLAN_EN 45

PCIE_TXP14_WLAN32

PCIE_TXN14_WLAN32

PCIE_RXN14_WLAN32

PCIE_RXP14_WLAN32

CLK_PCIE_MINI35

CLK_PCIE_MINI#35

WLAN_CLKREQ#35 BUF_PLT_RST# 31, 39,40,42,45

BUF_PLT_RST# 31, 39,40,42,45

SSD_CLKREQ# 35

CLK_PCIE_SSD#35

CLK_PCIE_SSD35

PCIE_TXP10_SSD32
PCIE_TXN10_SSD32

PCIE_TXN11_SSD32

PCIE_TXP11_SSD32

PCIE_TXP12_SSD32

PCIE_TXN12_SSD32

SATAGP132

PCIE_TXN9_SSD32

PCIE_TXP9_SSD32

PCIE_RXP9_SSD32
PCIE_RXN9_SSD32

PCIE_RXP10_SSD32

PCIE_RXN10_SSD32

PCIE_RXP11_SSD32
PCIE_RXN11_SSD32

PCIE_RXN12_SSD32

PCIE_RXP12_SSD32

VDD3 4,23,30,31,33,36,39,42,44,45,46,47,48,49,52, 53,55,56,57,58,59,60,63,70,71,72

3.3VS 8,9,23,24,27,28,29,30,31,32,33,34,35,38,39,42,43,44, 45,47,48,52,59,70,71

3.3V 2,24,28,41,43,47,48,50,51,54,57,58,59,68,69

DEVSLP1 34

SUS_CLK 33

M2M_SSD1_LED# 44

CNVI_WT_D1N38

CNVI_WT_D1P38

CNVI_WT_D0P38
CNVI_WT_D0N38

CNVI_WT_CLKN38

CNVI_WT_CLKP38

CNVI_WGR_D1P38

CNVI_WGR_D1N38

CNVI_WGR_CLKN38

CNVI_WGR_CLKP38

CNVI_WGR_D0P38

CNVI_WGR_D0N38

CNVI_DET#45

CNVI_GNSS_PA_BLANKING 38

CNVI_MFUART2_RXD 38
CNVI_MFUART2_TXD 38

CNVI_RGI_RSP 38

CNVI_BRI_RSP 38

CNVI_RF_RST# 33

CLKIN_XTAL_LCP 35

XTAL_CLKREQ 33

3IN1 45
80CLK 45

CNVI_RGI_DT 38

CNVI_BRI_DT 38

SLP_SUS#45,48,53,72

WLAN_PWR_EN45

SKIN_THRM_SNSR_ALE RT_N 33

CLINK_CLK 32

CLINK_RESET 32

CLINK_DATA 32

5V 28,41,43, 47,48,50,53,58,69

M2_SSD1_3.3VS 39

Title

Size Doc ument Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[40] M.2 WLAN+BT, PCIE4X SSD

Custom

40 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Doc ument Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[40] M.2 WLAN+BT, PCIE4X SSD

Custom

40 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Doc ument Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[40] M.2 WLAN+BT, PCIE4X SSD

Custom

40 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

R661 *0_04

R676 0_04

C1099

0.1u_6.3V_X5R_02

R382 0_06

R670 *33_04

R658 22_04

R648 0_04

C1062

*22u_6.3V_X5R_06

C1065

22u_6.3V_X5R_06

R663 *0_04

R673 *33_04

R770

10K_04

C787
*0.1u_10V_X7R_04

R650 0_04

R666 *0_04

C784

*0.1u_10V_X7R_04

R655 22_04

C779

*0.1u_10V_X7R_02

R647

75K_1%_04

R291 10K_04

R273 0_04

C801

22u_6.3V_X5R_06

C773

0.1u_6.3V_X5R_02

R645

10K_04

C799

22u_6.3V_X5R_06

R651 *0_04

M KEY

J_SSD1

NFSM0-S6701-TP40

PCB Footprint = NXSM0-S67XX-XX40

P/N = 6-21-84KE0-075

SUSCLK(32Khz)(O)

68

CLKREQ#(IO)

52

GND11

71

REFCLKP

55

REFCLKN

53

PEWake#(IO)

54

PEDET(NC-PCIe/GND-SATA)

69

GND10

57

DAS/DSS#(I)(OD)

10

GND12

73

3.3V2

12

NC18

67

NC1

8

NC0

6

DEVSLP(O)

38

PERST#(O)

50

GND9

51

3.3V0

2

GND0

1

3.3V1

4

GND1

3

GND2

9

PERp0/SATA-B-

43

PETp0/SATA-A+

49

PETn0/SATA-A-

47

PERn0/SATA-B+

41

GND7

39

GND8

45

GND13

75

3.3V3

14

3.3V4

16

PERn3

5

PERp3

7

3.3V5

18

GND3

15

PETn3

11

PETp3

13

GND5

27

PETn2

23

GND4

21

PERn2

17

PERp2

19

PETp2

25

NC3

22

NC2

20

NC5

26

NC4

24

NC7

30

NC9

34

NC6

28

NC8

32

NC10

36

NC12

42

NC13

44

NC15

48

NC14

46

NC11

40

PETp1

37

PETn1

35

PERp1

31

PERn1

29

GND6

33

NC16

56

NC17

58

3.3V6

70

3.3V7

72

3.3V8

74

R780 *10mil_short

C788

0.1u_16V_X5R_02

C1049

22u_6.3V_X5R_06

R366 *10mil_short

U41

UP7553PMA5-25

EN

3

VIN

5

VIN/SS

4

VOUT

1

GND

2

R781 *10mil_short

R735 *10K_04

R375 0_06

C1102

0.1u_6.3V_X5R_02

C796

0.1u_6.3V_X5R_02

R362 *10mil_short

*TESTT119

C1068

1u_6.3V_X5R_02

R646

75K_1%_04

C792

0.1u_6.3V_X5R_02

R680 10K_04

*TESTT118

E KEY

J_WLAN1

NFSE0-S6701-AP64

PCB Footprint = argosy_nfse0-s6701-tp64

P/N = 6-21-84K03-075

SUSCLK(32Khz)(O)

50

CLKREQ0_N

53

GND12

69

REFCLKP0

47

REFCLKN0

49

PEWAKE0_N

55

WT_D0N

65

WT_D0P

67

WT_D1N

59

WT_D1P

61

GND11

63

GND6

33

GND13

75

3.3V2

72

UART_CTS/RGI_RSP

34

I2C CLK(O)

60

UART_TX/RGI_DT

32

USB_DN

5

USB_DP

3

I2C DATA(IO)

58

COEX1_TXD(I/O)1.8V

48

PERST0_N(O)

52

COEX3(I/O)1.8V

44

GND10

57

LED2_N(OD)

16

3.3V0

2

CLINK_RESET

38

GND1

1

LED1_N(OD)

6

WGR_D0P

17

W_DISABLE1_N(O)

56

3.3V1

4

GND2

7

GND4

18

CLINK_DATA

40

GND7

39

PETP0

35

PERP0

41

PERN0

43

PETN0

37

GND8

45

GND9

51

IRQ_N(I)

62

COEX2_RXD(I/O)1.8V

46

3.3V3

74

GND5

19

WGR_CLKN

21

WGR_CLKP

23

UART_WAKE_N

20

UART_RX/BRI_RSP

22

UART_RTS/BRI_DT

36

CLINK_CLK

42

W_DISABLE2_N(O)

54

REFCLK0

64

PERST1_N

66

CLKREQ1_N

68

PEWAKE1_N

70

WT_CLKN

71

WT_CLKP

73

PCM_OUT/CLKREQ0

14

PCM_IN

12

PCM_SYNC/LCP_RSTN

10

PCM_CLK

8

WGR_D0N

15

GND3

13

WGR_D1P

11

WGR_D1N

9

*TESTT117

R352 *10mil_short

R669 *33_04

SATA0_RXN_SSD
SATA0_RXP_SSD

WLAN_EN

BT_EN

WLAN_PWR_EN

WLAN_3.3V

3IN1
80CLK

CNVI_WAKE#

CL_RST#

CL_DATA

CL_CLK

CLKIN_XTAL_LCP_R

Sheet 40 of 67

M.2 WLAN+BT,

PCIE 4X SSD

Schematic Diagrams

B.Schematic Diagrams

M.2 WLAN+BT, PCIE 4X SSD B - 41

Schematic Diagrams

Sheet 41 of 67

USB Charger

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

USB3.1 PORT(PORT3,4)

TYPE-C

MAIN 6-21-B4K30-024

close to connector

To Con.

To Con.

To Con.

Remove 3831 CC lOGIC IC_0507 Biaggi

Raven modfiy 0824

Raven modfiy 0824

Raven modfiy 0824

Raven modfiy 0824

D03 Raven modfiy 0417

Raven modfiy 0824

Raven modfiy 0824

Default Low

SLG55583VTR : 6-02-55583-9D0 P2P
SLG55593VTR : 6-02-55593-9D0

80 mil

80 mil

USB3.1 PORT(PORT1)

6-02-75495-9C0

W/O USB CHARGER

暞ẞ伖㕤妲嘇↮㓗嗽

暞ẞ伖㕤妲嘇↮㓗嗽

Smart CDP
pin4

Function

0X

1

11

0

DCP autodetect with
mouse/keyboard wake up

S0 Charging with SDP

S0 Charging with CDP

CB
pin8

USB3.0/3.1 PORT(PORT3)

Remove 0507 Biaggi

Remove CC to EC 0507 Biaggi

close to connector

Raven Add VBUS 0629

modification 0517 Biaggi

modification 0507 Biaggi

Close to Connector

modification 0509 Biaggi

Modification 0516 Biaggi

Remove ASM1562 0522 Biaggi

Raven modfiy 0628

100 MIL

D02_1110_Alex

USBVCC3.1_1

VDD5VDD5

VDD5 USBVCC_CH

GND

GND

GND

GND

GND

USBVCC_CH

USBVCC3.1_1

USBVCC3.1_1

VBUS_USB_TYPE_C

5V USBVCC3.1_1

3.3V

VBUS_USB_TYPE_C

NV_RX_1_P_J68
NV_RX_1_N_J68

NV_TX_1_P_J68
NV_TX_1_N_J68

NV_RX_2_P_J68
NV_RX_2_N_J68

NV_TX_2_P_J68
NV_TX_2_N_J68

VDD547,49

3.3VS8,9,23,24,27,28,29,30,31,32,33,34,35,38,39,40,42,43,44,45,47,48,52,59,70,71

5V28,43,47,48,50,53,58,69

3.3V2,24,28,43,47,48,50,51,54,57,58,59,68,69

1.8VA36,53,59,60,68

SUSB#28,31,33,45,47,48,50,53,60

DD_ON45,47,49,72

USB_PN131

USB_PP131

DD_ON#47,50

USB_PP331

USB_PN331

NV_SBU1_J68
NV_SBU2_J68

CCG2_CC269

CCG2_CC169

USB3_TXP134
USB3_TXN134

USB3_RXN134

USB3_RXP134

SOURCE_CTRL69

DISCHARGE_CTRL69

VBUS_USB_TYPE_C69

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[41] USB3.0/3.1 CON,USB CHARGER

Custom

41 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[41] USB3.0/3.1 CON,USB CHARGER

Custom

41 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[41] USB3.0/3.1 CON,USB CHARGER

Custom

41 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

D42

ESDPSA0402V12

_

12

U1

SY6288E1AAC

6-02-62881-9C0

OUT

1

GND

2

OCB3EN

4

IN

5

R370 100K_04

CHARGER

R6

0_04

R407

10K_04

CHARGER

L12

*WCM2012F2S-161T03-short

142

3

D41

ESDPSA0402V12

_

12

R5 220K_1%_04

R483 220K_1%_04

D1

ESDPSA0402V12

_

12

U24

uP7549UMA5-20

OC#

3

VIN

5

EN#

4

VOUT

1

GND

2

R4 220K_1%_04

R786 0_04

W/O CHARGER

R484 220K_1%_04

D2

ESDPSA0402V12

_

12

C775
10u_6.3V_X5R_06

U25

SLG55593VTR

TDFN8-2X2MM

CHARGER

PRE#

1

DM

2

DP

3

CDP4VCC

5

TDP

6

TDM

7

CB

8

GND

9

D43

CESD2510UC5VB

5

1
2
3
4

10

9
8
7
6

C19

10u_25V_X6S_08

R787 0_04

W/O CHARGER

C803

*0.1u_6.3V_X5R_02

R485 220K_1%_04

C802

0.1u_6.3V_X5R_02

C808 0.1u_10V_X7R_04

C7

*0.1u_6.3V_X5R_02

D45

ESDPSA0402V12

_

12

D26

ESDPSA0402V12

_

12

C5 1u_6.3V_X5R_02

C13

10u_6.3V_X5R_06

D44

ESDPSA0402V12

_

12

L24

*WCM2012F2S-161T03-short

142

3

R486 220K_1%_04

D25

ESDPSA0402V12

_

12

C4 1u_6.3V_X5R_02

D27

DT1140-04LP-7

5

1
2
3
4

10
9
8
7
6

R11

0_04

C2 1u_6.3V_X5R_02

R7 *10K_04

C797 *22u_6.3V_X5R_06

D3

ESDPSA0402V12

_

12

Q5

*2SK3018S3

G

DS

C1 1u_6.3V_X5R_02

R3 220K_1%_04

R408

*10K_04

D4

ESDPSA0402V12

_

12

C3

0.1u_25V_X5R_04

C11

*0.1u_6.3V_X5R_02

R385 0_04

CHARGER

C1156 0.22u_10V_X5R_04

R45
*100_04

T1

D28

ESDPSA0402V12

_

12

Standard-A

J_USB1

C107NC-90939-L

VBUS

1

D-

2

D+

3

GND_D

7

SSRX-

5

SSRX+

6

GND

4

SSTX-

8

SSTX+9SHIELD

GND1

SHIELD

GND2

SHIELD

GND3

SHIELD

GND4

J_TYPEC1
UCF3T-21S01-0P11

Y

_

GND

A1

TX0_P

A2

TX0_N

A3

VBUS

A4

CC1

A5

USB2_P_T

A6

USB2_N_T

A7

SBU1

A8

VBUS

A9

RX1_N

A10

RX1_P

A11

GND

A12

GND

B12

RX0_P

B11

RX0_N

B10

VBUS

B9

SBU2

B8

USB2_N_B

B7

USB2_P_B

B6

CC2

B5

VBUS

B4

TX1_N

B3

TX1_P

B2

GND

B1

GND1

GND1

GND2

GND2

GND3

GND3

GND4

GND4

GND5

GND5

GND6

GND6

GND7

GND7

GND8

GND8

R2 220K_1%_04

C771

0.1u_6.3V_X5R_02

CHARGER

C1157 0.22u_10V_X5R_04

D29

ESDPSA0402V12

_

12

D5

DT1140-04LP-7

5

1
2
3
4

10
9
8
7
6

R371 0_04

W/O CHARGER

R384 *0_04

C800 22u_6.3V_X5R_06

C12

1u_25V_X5R_06

TYPEC_UDP_J
TYPEC_UDN_J TYPEC_UDP_J

TYPEC_UDN_J

3831_CC1_J

3831_CC2_J

TYPEC_SBU2

3831_CC2_J

3831_CC1_J

USB3_TXP1_RJ
USB3_TXN1_RJ

USB3_RXP1
USB3_RXN1

B_UDN

B_UDP

CDP

USB_DD_ON#

USB_PN1

USB_PP1

DD_ON#

USB_PP1

USB_PN1

USB_DD_ON#

B_UDN

B_UDP

USB_PN1R

USB_PP1R USB_PP1RJ

USB3_RXP1
USB3_RXN1

B_UDP

USB_PN1RJ

USB3_TXN1_RJ

USB3_TXP1_RJ

B_UDN

TYPEC_UDN_J
TYPEC_UDP_J

TYPEC_SBU1
TYPEC_SBU2

TYPEC_SBU1

NV_RX_2_P_J

NV_RX_2_N_J

NV_RX_1_N_J

NV_TX_1_P_J

NV_TX_2_P_J

NV_TX_2_N_J

NV_RX_1_P_J

NV_TX_1_N_J

NV_RX_1_N_J

NV_RX_1_P_J

NV_RX_2_N_J

NV_RX_2_P_J

NV_TX_2_N_J

NV_TX_2_P_J

NV_TX_1_N_J

NV_TX_1_P_J

USB Charger

B.Schematic Diagrams

B - 42 USB Charger

Card Reader / LAN RTL8411B

Sheet 42 of 67

Card Reader /

LAN RTL8411B

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

Co-Lay

Gary_For common design

6-06-75140-068

6 IN 1 SOCKET - MMC / RSMMC

- SD / mini SD / SDHC / SDXC

6-21-A4450-111

⼭

EMI

䡢娵⬴,㓡

SHORT

崘ℏⰌ.

Close to chip

PIN11 PIN32 PIN48

LDO Mode

60 mil

PIN27

6-14-0R23F-01B-1

0.2_06

䔞斄攱

host暣㸸/ CARD

㉼㍺㗪

,VCC_CARD

暣⡻ㅱỶ㕤

0.5ặ䈡,

㚨⮹暨天

1ms

㛇攻

PIN13

40 mil

1013
modify

ℙ䓐䶂嶗

GIGA LAN (RTL8411)

LAN POART

㓦伖

TOP

朊

㓦伖

BOT

朊

EMI

6-07-5R074-1A0

SPEC:30PPM

PCBfootprint:
HSX321G

Ra

Ca Cb

慷䓊䡢娵

LDO MODE OK⼴,

㓡

SHORT

暞ẞ

慷䓊䡢娵⼴暣旣

,㓡SHORT

暞ẞ

Switching Regulator close to PIN48

(>20mil)

(>20mil)

PULL HIGH: SWR Mode

PULL LOW: LDO Mode

LDO Mode

㗪

: La,Ca,Cb

ᶵᶲẞ

,Ra

ᶲẞ

D03 Raven modfiy 0417

PIN32PIN3 PIN8 PIN46

6-03-08411-032

LAN (RTL8411B)

TO EC8587 PIN123 LAN_WAKEUP#

TO SB PCH WAKE#.

FOR S5 WAKE UP ON LAN

Near Cardreader CONN

Remind that R109 using the
main power (S0 power).

LAN_CLKREQ#

⤪ᶵἧ䓐⎗㕟攳,㕤

PCH

䪗䚜㍍

PULL DOWN

BIOS pulls high or low to GPO pin,
Pkease refer to LAN/PHY Disable
Application Note.

PIN12

Crystal 㓡䓐HSX321S(3.2X2.5X0.65)
meet realtek Freq tolerance 50ppm

VDD3 meet rising time
>1ms

PIN20 PIN20

6-21-B40A0-008

D02_1107_Alex

D02_1107_Alex

D02_1114_Alex

AVDD33

LAN_GND

VDD10

VDD10 VDD10 VDD10VDD10

LAN_GND

VDD10

VDD10

AVDD33

CARD_3V3

EVDD10

AVDD33

VDD10

REGOUT
D3V3

VDD10

VDD33/18

AVDD33

VCC_CARD

3.3VS

3.3VS

VDD10

EVDD10

VCC_CARD

VDD3

D3V3

AVDD33

VDD33/18

VCC_CARD

CARD_3V3

LAN_GND

PCIE_WAKE# 33

PCIE_RXN15_GLAN 32
PCIE_RXP15_GLAN 32

CLK_PCIE_GLAN 35

CLK_PCIE_GLAN# 35

PCIE_TXP15_GLAN 32

PCIE_TXN15_GLAN 32

LAN_CLKREQ# 35

BUF_PLT_RST# 31,39,40,45

LAN_WAKEUP# 30,33,45

3.3VS8,9,23,24,27,28,29,30,31,32,33,34,35,38,39,40,43,44,45,47,48,52,59,70,71

3.3V2,24,28,41,43,47,48,50,51,54,57,58,59,68,69

VDD34,23,30,31,33,36,39,40,44,45,46,47,48,49,52,53,55,56,57,58,59,60,63,70,71,72

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[42] CARD READER/ LAN RTL8411B

A3

42 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[42] CARD READER/ LAN RTL8411B

A3

42 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[42] CARD READER/ LAN RTL8411B

A3

42 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

R200 *10mil_short

C498 *5p_50V_NPO_04

R1860_04

R183 1M_04

R209

*28mil short-p

C1028

0.1u_16V_X5R_02

C1024

0.1u_6.3V_X5R_02

R180 33_04

R17 75_04

C582

5p_50V_NPO_04

R206

*28mil short-p

C608

5p_50V_NPO_04

C624

0.1u_16V_X5R_02

R170 33_04

ER4

*10mil_short

R205

*28mil short-p

C517

0.1u_6.3V_X5R_02

C688

22u_6.3V_X5R_06

R201
15K_04

C1036

0.1u_6.3V_X5R_02

R165 33_04

C665

*0.1u_10V_X7R_04

ER1

*10mil_short

R586

*20mil_04

R189 *1K_04

R598 *15mil_short_06

R188 33_04

C622 0.1u_10V_X7R_04

ER3

*10mil_short

C21

100PF 2KV 1206

C1026

1u_6.3V_X5R_02

R202

*20mil_04

C1029

0.1u_6.3V_X5R_02

R174 33_04

R22 75_04

ER2

*10mil_short

QFN48

U12

.\RTL8411B

RTL8411B

MDIP0

1

MDIN0

2

MDIP1

4

MDIN1

5

MDIP2

6

MDIN2

7

AVDD10

8

MDIP3

9

MDIN3

10

HV_GIGA

11

VDD3

12

REG_OUT

36

VDDREG

35

VDD1

33

ISOLATEBPIN

31

PERSTBPIN

30

CLKREQBPIN

29

MS_BS/SD_WP#

28

DV33_18

27

HSON

26

HSOP

25

HV_GIGA

48

RSET

47

CKXTAL245CKXTAL1

44

MS_CD#

43

SD_CD#

42

LED0

41

LED_CR

40

LANWAKEB

39

LED1/GPO

38

LED2

37

CARD_3V313SD_D114SD_D0/MS_D115SD_CLK/MS_D016SD_CMD/MS_D217SD_D3/MS_D318SD_D2/MS_CLK19VDDTX20HSIP21HSIN22REFCLK_P23REFCLK_N

24

E_PAD

49

AVDD10

3

VD33

32

ENSWREG

34

LV_CEN

46

R247 0.2R_5%_06

R185 33_04R199 0_04

R20 75_04

C667

*0.1u_16V_X7R_04

C666

*0.1u_25V_X5R_04

C1022

0.1u_16V_X5R_02

C621 0.1u_10V_X7R_04

C38

0.1u_6.3V_X5R_02

L2

*WCM2012F2S-161T03-short

1

4

2

3

J_CARD-REV1

CM2S-061-H-N

PCB Footprint = SD-10395-001-3

SD_C/D

P11

SD_DATA1

P8

SD_DATA0

P7

SD_VSS2

P6

SD_CLK

P5

SD_VDD

P4

SD_VSS1

P3

SD_CMD

P2

SD_DATA3

P1

GND1

GND1

GND2

GND2

SD_DATA2

P9

SD_WP

P10

GND3

GND3

GND4

GND4

R605 1K_04

R21 75_04

C623

0.1u_6.3V_X5R_02

R198 *10mil_short

L1

*WCM2012F2S-161T03-short

1

4

2

3

C1020

*0.1u_6.3V_X5R_02

R171 2.49K_1%_04

D13 *RB751S-40H

AC

L3

*WCM2012F2S-161T03-short

1

4

2

3

X2 FSX3L 25MHZ

1 2

34

C495

0.1u_6.3V_X5R_02

R192 10K_04

C10217-10839

J_RJ_1

DD-

8

DD+

7

DB-

6

DC-

5

DC+

4

DB+

3

DA-

2

DA+1shield

GND1

shield

GND2

L17

GST5009 LF

TCT1

1

2

TD1+

3

TD1-

TCT2

4

5

TD2+

6

TD2-

TCT3

7

8

TD3+

9

TD3-

TCT4

10

11

TD4+

12

TD4-13MX4-

14

MX4+

MCT4

15

16

MX3-

17

MX3+

MCT3

18

19

MX2-

20

MX2+

MCT2

21

22

MX1-

23

MX1+

MCT1

24

L4

*WCM2012F2S-161T03-short

1

4

2

3

C1021

0.1u_6.3V_X5R_02

SD_D2/MS_CLK_R

SD_CLK/MS_D0_R

SD_D1_R

SD_D3/MS_D3_R

SD_CMD/MS_D2_R

MS_BS/SD_WP#

SD_D0/MS_D1_R

SD_CD#

SD_CMD/MS_D2 SD_CMD/MS_D2_R

SD_D0/MS_D1_R
SD_D1_R

SD_CLK/MS_D0_R
SD_D3/MS_D3_R

SD_D1

SD_CLK/MS_D0
SD_D3/MS_D3

SD_D0/MS_D1

SD_D2/MS_CLK

CARD_3V3

LMX1+

NMCT_4

LMX3+

LMX1-

NMCT_3

NMCT_1

LMX4+

LMX2-

LMX4-

NMCT_2

LMX2+

LMX3-

NMCT_R

DLMX4-

DLMX3-

DLMX3+

DLMX2+

DLMX1+

DLMX4+

DLMX1-

LAN_MDIN3

LAN_MDIP2

LAN_MDIN0

LAN_MDIN2

LAN_MDIP0

LAN_MDIP1
LAN_MDIN1

LAN_MDIP3

DLMX2-

SD_D2/MS_CLK_R

XTAL1

VDD10

ENSWREG

REGOUT

XTAL2

RTL8411B_HSOP

ISOLATEB

RTL8411B_HSON

LAN_WAKEUP#

ENSWREG

LAN_MDIP1

CLKREQB

LAN_MDIN1

MS_BS/SD_WP#

REGOUT

SD_CD#

LAN_MDIP2
LAN_MDIN2

LAN_MDIP3
LAN_MDIN3

SD_D1

SD_CMD/MS_D2

SD_CLK/MS_D0

SD_D0/MS_D1

EECS

RSET

PERSTB

SD_D3/MS_D3

LAN_MDIP0

XTAL2

XTAL1

SD_D2/MS_CLK

LAN_MDIN0

Schematic Diagrams

B.Schematic Diagrams

Card Reader / LAN RTL8411B B - 43

Schematic Diagrams

Sheet 43 of 67

HDD, Click TP,

Audio, Hall Con.

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

Gen3

HDD CONNECT1 (MASTER)

CLICK PAD

FOR AUDIO BOARD

6-21-C4790-122 (7.0mm HDD)

BY

ἧ䓐䘬廠↢暣⡻ 婧㔜

,

ὅ≇䌯( 旣ῤ &⊭墅⣏⮷

)

㓦暣徜嶗 枸䔁ᶵᶲ

SATA_5VS

ON

FOR SUPPORT OPTANE project, SATA HDD≈POWER GATEING

暣嶗

modification 0508
Biaggi

Raven modfiy 0629

Raven HALL CHANGE FINGER 0731

Raven modfiy AUDG 0716

6-20-94A40-004

Tommy 0419

30mil

MAIN 6-20-94K00-006

change to SY6288E1AAC

2.5A

RTD3 POWER

3A

2.5A

D02_102518_Alex

D02_Gary

3.3VS

SATA_5VS

5V

AUDG

SATA_5VS

GND

5V

AUDG

AUDG

3.3VS

3.3VS

TP_VCC

3.3VS

TP_VCC

3.3VS

3.3V

5VS SATA_5VS

SATA_RXN4 32
SATA_RXP4 32

SATA_TXN4 32

SATA_TXP4 32

3.3VS8,9,23,24,27,28,29,30,31,32,33,34,35,38,39,40,42,44,45,47,48,52,59,70,71

VDD34,23,30,31,33,36,39,40,42,44,45,46,47,48,49,52,53,55,56,57,58,59,60,63,70,71,72

5V28,41,47,48,50,53,58,69
5VS27,29,31,44,45,46,47,70,71,72

SATA_PWR_EN38

SUSB27,29,47

USB3_TXP2 34

USB3_RXN2 34

USB3_RXP2 34

USB_PP2 31
USB_PN2 31

USB3_TXN2 34

MIC1_R 71

MIC1_L 71

MIC_SENSE 71

HP_SENSE 71

HEADPHONE_R_DEPOP 71

HEADPHONE_L_DEPOP 71

SLEEVE_CON 71

SPDIFO 71

USB_PN10 31
USB_PP10 31

TP_ATTN# 30

TP_DATA 45

TP_CLK 45

I2C_SCL_TP 38
I2C_SDA_TP 38

LID_SW# 28,44,45,63

3.3V2,24,28,41,47,48,50,51,54,57,58,59,68,69

DEVSLP4 34

USB_PN6 31

USB_PP6 31

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[43]HDD,CLICK TP,AUDIO,HALL CON

A3

43 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[43]HDD,CLICK TP,AUDIO,HALL CON

A3

43 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[43]HDD,CLICK TP,AUDIO,HALL CON

A3

43 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

J_AUD1

FP201H-040S10M

PCB Footprint = FP201-040X1-0M

_

1
2
3
4
5
6
7
8

9
10
11
12

GND1GND2

13
14
15
16

18

17

19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40

U26

SY6288E1AAC

6-02-62881-9C0

OUT

1

GND

2

OCB

3

EN

4

IN

5

C861 0.01u_50V_X7R_04

C1171 0.1u_6.3V_X5R_02

R805

10K_04

C1167
*47p_25V_NPO_02

C781

10u_6.3V_X5R_06

C1168

*47p_25V_NPO_02

C1050

0.1u_10V_X7R_04

D39

*TEA10402V15A0

12

C1166
47p_25V_NPO_02

R418

*220_06

C1165
47p_25V_NPO_02

C806

10u_6.3V_X5R_06

D40

*TEA10402V15A0

12

R810100K_04

C882 0.01u_50V_X7R_04

C868 0.01u_50V_X7R_04

C804

*1u_6.3V_X5R_02

C1172 1u_6.3V_X5R_02

Q41

*2SK3018S3

G

DS

PJ12 *OPEN-3mm

1 2

R782

0_04

.

L23

FCM1005KF-121T03

D46

RB751S-40C2

A C

D47

*DT1140-04LP-7

5

1
2
3
4

10
9
8
7
6

R419 0_04

w/o medion

R798

100K_04

R413 0_04

w/o medion

J_FP1

FP225H-006S10M

PCB Footprint = fp225h-006xxxm

1
2
3
4
5
6

R804

*0603_short

J_HDD1

AT22J36BAA207

S1
S2
S3
S4
S5
S6
S7

P1
P2
P3
P4
P5
P6
P7
P8
P9
P10
P11
P12
P13
P14
P15

C805

0.1u_6.3V_X5R_02

L10

WCM2012F2S-161T03

medion

1

4

2

3

C795

0.1u_6.3V_X5R_02

C1173

*10u_6.3V_X5R_06

C807

22u_6.3V_X5R_06

R799

1K_04

J_TP1

FP225H-008S11M

fp225h-008gxxxm_L

1
2
3
4
5
6
7
8

C1123
1u_6.3V_X5R_02

R396 4.7K_04

C885 0.01u_50V_X7R_04

D48

*ESDPSA0402V12

12

R802

10K_04

R800

1K_04

JHDD_SATA_TXP4
JHDD_SATA_TXN4

JHDD_SATA_RXN4
JHDD_SATA_RXP4

SUSB

TP_DATATP_DATA_CON

TP_CLKTP_CLK_CON

I2C_SDA_TPTP_I2C_DAT_CON

I2C_SCL_TPTP_I2C_CLK_CON

LID_SW#_L
TP_ATTN#

TP_CLK

TP_DATA

LID_SW#_L

I2C_SCL_TP
I2C_SDA_TP

HDD, Click TP, Audio, Hall Con.

B.Schematic Diagrams

B - 44 HDD, Click TP, Audio, Hall Con.

LED, CCD, TPM, Power SW Con.

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

CCD+DMIC

婳

EC PIN24

復↢ầ

SSD

LED

≽ἄ䘬㊯䣢炻德忶AP忂䞍

BIOS

⛐⏲䞍

EC

 ↢≽ἄ

NGFF B & M KEY

LED

⤪

PCIE SSD LED

⭂佑⎴

SATA

LED

≽ἄ㗪炻婳䓐㬌䶂嶗

POWER SWITCH BOARD

6-52-55001-021

Windows 7

WLAN LED

Airplane OFF

Airplane ON

WLAN OFF

WLAN ON

Windows 8

ᶵṖ

Ṗ

ᶵṖ

Ṗ

NHx0 LED BOARD

EMI, Close to connector

㬌㕁嘇䁢

3A,⤪䓐2nd source

㗪天㲐シㅱ䓐

⤪

CCD_5V 2A

⎗䓐ẍᶳ㕁

M: G5243A ---- 6-02-05243-9C0
S: AP2821KTR-G1 6-02-02821-9C0

1A1A

48 mil

0616

EVT

ᶲẞ炻

DVT

⼴㓡䁢

SHORT

⤪

AUDIO

SOURCE

⶙㚱㬌

LC(EMI

Solution)

⇯⎗ᶵ≈

炻ᾉ嘇䚜㍍⇘⇘

CONNECT

10/5/2017

Raven change 0731

DEL R740

DEL R713

D02_102518_Alex

6-21-62D00-112

D02_1109_Alex

䦣军⮷㜧

Co-lay

3.3VS

3.3VS

GND

3.3VS

3.3VS

GND

GND GND

3.3VS

GNDGND

3.3VS
CCD_PWR

5VS

3.3VS

3.3VA

VDD3

GND

VDD3

GND

GND

3.3VS

M_BTN#44,47

3.3VS8,9,23,24,27,28,29,30,31,32,33,34,35,38,39,40,42,43,45,47,48,52,59,70,71

3.3V2,24,28,41,43,47,48,50,51,54,57,58,59,68,69

VDD34,23,30,31,33,36,39,40,42,45,46,47,48,49,52,53,55,56,57,58,59,60,63,70,71,72

5VS27,29,31,43,45,46,47,70,71,72

5V28,41,43,47,48,50,53,58,69

SATA_LED# 32

AIRPLAN_LED#45

LED_BAT_FULL45

LED_BAT_CHG45

LED_PWR45

LED_ACIN45

M2M_SSD1_LED# 40

USB_PN831

CCD_EN45

USB_PP831

SPI_SO_R30

SPI_SI_R30

SPI_SCLK_R30

SPI0_CS2#30

TPM_PIRQ#33

PLT_RST#24,30,31

3.3VA4,30,31,32,33,36,38,48,53

M2M_SSD2_LED# 39

LID_SW#28,43,45,63
M_BTN#44,47

MIC_DATA_PCH33

MIC_CLK_PCH33

MIC_CLK71

MIC_DATA71

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[44]LED,CCD,T PM,POWER SW CON.

Custom

44 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[44]LED,CCD,T PM,POWER SW CON.

Custom

44 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[44]LED,CCD,T PM,POWER SW CON.

Custom

44 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

J_CCD1

50207-01271-001

1

2

3

4

5

6

7

8

9

10

11

12

C11840.01u_50V_X7R_04

R775 10K_04

TPM

C1154
*1u_6.3V_X5R_02

TPM

U48

SLB9670VQ F/W 7.85

TPM_W

TPM

RST#

17

NC_C

26

VSS_3

23

SPI_CS#

20

NC_4

10

NC_7

13

SPI_MISO

24

SPI_CLK

19

VDD

22

SPI_MOSI

21

NC_A

16

NC_D

27

NC_9

15

NC_2

4

NC_5

11

PIRQ#

18

NC_B

25

GPIO0

6

VSS_1

2

NC_8

14

VDD

8

VSS_2

9

PP

7

VDD

1

NC_1

3

NC_6

12

NC_E

28

NC_3

5

NC_F

29

NC_G

30

NC_H

31

VSS_4

32

GND

33

R821 *0_04

D33

*TVUDF1004AD0

5

1

2

3

4

10

9

8

7

6

C11850.01u_50V_X7R_04

.

L20 FCM1005KF-121T03R822 *0_04

C143

0.01u_50V_X7R_04

C939

47p_25V_NPO_02

C93

*0.01u_50V_X7R_04

R784
*4.7K_04

J_SW2

FP225H-008S11M

fp22 5h- 008 gxxxm_r
P/N = 6-20-94K30-108

NH77

1
2
3
4
5
6
7
8

C938

2.2u_6.3V_X5R_04

R788 *0_04

R823 0_04

C138

*0.01u_50V_X7R_04

R785 *4.7K_04

R783 0_04

TPM

D20

RB751S-40H

A C

EMC6

0.01u_50V_X7R_04

.

L21 FCM1005KF-121T03

J_LED2

FP225H-012S10M

1
2
3
4
5
6
7
8
9
10
11
12

NC1

NC2

L22

*WCM2012F2S-161T03-short

142

3

U23

TC7SZ08FU

1

2

5

4

3

C1150

0.1u_6.3V_X5R_02

TPM

R771 56_04

TPM

J_SW1

FP226H-004S10M

NH50

1
2
3
4

C1152

0.1u_6.3V_X5R_02

TPM

R773 0_04

TPM

U34

UP7553PMA5-25

VIN

4

VIN

5

EN

3

VOUT

1

GND

2

R767 *20K_04

R774 56_04

TPM

C934

1u_6.3V_X5R_02

R779 56_04

TPM

C940

47p_25V_NPO_02

C1155

0.1u_6.3V_X5R_02

TPM

R102 *1K_04

C94

*0.01u_50V_X7R_04

R820 0_04

C1153

0.1u_6.3V_X5R_02

TPM

LED_HDD#

AIRPLAN_LED#

LED_BAT_CHG

LED_BAT_FULL

LED_PWR

LED_ACIN

LED_HDD#
AIRPLAN_LED#
LED_BAT_FULL
LED_BAT_CHG
LED_PWR
LED_ACIN

M_BTN#

USB_PP8_J

MIC_DATA_C

USB_PN8_J

MIC_DATA_R
MIC_CLK_R

USB_PN8_C
USB_PP8_C

MIC_DATA_L
MIC_CLK_L

USB_PN8_J

USB_PP8_CUSB_PP8_J

USB_PN8_C

MIC_DATA_R
MIC_CLK_R

MIC_DATA_L
MIC_CLK_L

VDD_TPM

TPM_GPIO

TPM_PP

VDD_TPM

VDD_TPM

VDD_TPM

MIC_CLK_C

Sheet 44 of 67

LED, CCD, TPM,

Power SW Con.

Schematic Diagrams

LED, CCD, TPM, Power SW Con. B - 45

B.Schematic Diagrams

Schematic Diagrams

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

Gary_Add N870 White LED Keyboard

⇌㕟usb charger ≇傥 ,
Pull low 㗪, 㚱, pull high 㗪㰺㚱

6-20-94AF0-124

Raven del change conn 0709

FOR 50

EC ROM

CPU FAN CONTROL

J_FAN1

1

4

CPU_FAN

6-20-43130-104

ὅℙ䓐䶂嶗ᾖ㓡

VGA FAN CONTROL

J_FAN2

VGA_FAN

6-20-41120-104

1

4

1Mbit

ALSPI_* = 1.5"~5.8"

LIGHT_KB_DET# H

䘥

NET

ℐ

RGBKB-DET#

䃉

HLL

HH

⼑ 󱂒 䘤 󱂒

R250

R262

NC

NC

NH50ED

RBMODEL_ID RA

NH70ED

Voltage

3.3V

0V

xxxxx

xxxxxx

10K_1%6.49K_1% 2V

12K_1% 10K_1% 1.5V

RB

RA

Debug Port

DEBUG PORT

OPTION (

⎗ẍ怠㑯㗗⏎枸䔁

)

4/2/2018

4/2/2018

6-20-94AF0-124

FOR 70

KBC_AGND

VDD3

3.3VS

VDD3

5VS

3.3VS

3.3VS

5VS

VDD3

VDD3

VDD3

VDD3

3.3VS

KBC_AGND

VDD3

KBC_AVDD

VDD3

VDD3

KBC_AGND

VREG3

VDD3

SMD_BAT24,45,52,55,56

H_PECI 4

SMC_BAT24,45,52,55,56

BAT_DET45,55

VIN28,33,47,48,49,50,51,52,53,54,55,57,72

VDD34,23,30,31,33,36,39,40,42,44,46,47,48,49,52,53,55,56,57,58,59,60,63,70,71,72

3.3VS8,9,23,24,27,28,29,30,31,32,33,34,35,38,39,40,42,43,44,47,48,52,59,70,71

5VS27,29,31,43,44,46,47,70,71,72

3IN140
80CLK40

BUF_PLT_RST#31,39,40,42

LPC_FRAME#34

PCLK_KBC34

SERIRQ34

LPC_AD234
LPC_AD334

LPC_AD134

LPC_AD034

AC_IN#55

AC_PRESENT33

LED_ACIN44

SMI#34
SCI#32

KBC_MUTE#71

ME_WE 33

EC_GPIO 24,52,56,59

BAT_VOLT55

BAT_DET45,55

THERM_VOLT2

TOTAL_CUR55

VBATT_BOOST# 23

LIGHT_KB_DET# 34

SMC_BAT24,45,52,55,56
SMD_BAT24,45,52,55,56

SMC_VGA_THERM23,70
SMD_VGA_THERM23,70

d_GPIO9_ALERT_FAN 23

GC6_FB_EN_PCH 24,34

DGPU_PWR_EN24,34

dGPU_GPIO8_OVERT 23

KBC_BEEP71

EC_PWM_PIN_2446
EC_PWM_LEDKB_R46
EC_PWM_LEDKB_G46
EC_PWM_LEDKB_B46

TP_CLK43

TP_DATA43

USB_CHARGE_EN49

BT_EN30,40

PWR_SW#47
LID_SW#28,4 3,44,63

PWR_BTN#33

H_PROCHOT_EC4

DD_ON 41,47,49,72

ALSPI_CE# 30
ALSPI_MSI 30
ALSPI_MSO 30
ALSPI_SCLK 30

AIRPLAN_LED# 44

CCD_EN44

LED_BAT_CHG 44

LED_BAT_FULL44

LED_PWR44

BKL_EN 28

SUSB# 28,31,33,41,47,48,50,53,60
SUSC# 33,48,50

PERKB_ID2#_R70

CNVI_DET# 40

RGBKB-DET#46

SUS_WARN# 33

NB_ENAVDD 28,32

LAN_WAKEUP# 30,33,42

SWI# 32

EC_RSMRST# 33

SB_KBCRST# 34

PM_PWROK 31

ALL_SYS_PWRGD 4,28,31,52

SLP_SUS# 40,48,53,72

PERKB-DET#_R 46,70

WLAN_PWR_EN40

WLAN_EN 40

SUS_PWR_ACK#33

PERKB_ID1#_R70

VREG347,49,55

XLP_OUT 49

Title

Size D ocument Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[45] KBC-ITE IT5570

Custom

45 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size D ocument Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[45] KBC-ITE IT5570

Custom

45 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size D ocument Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[45] KBC-ITE IT5570

Custom

45 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

R373

100K_04

W/O CHARGER

C760

0.1u_6.3V_X5R_02

R701 0_04

TPM

C777

0.1u_6.3V_X5R_02

R814 *0_04

C528

*1u_6.3V_X5R_02

C780

0.1u_6.3V_X5R_02

R777 75_04

W/O TPM

R360

100K_04

CHARGER

.

L9
HCB1005KF-121T20

C778

0.1u_6.3V_X5R_02

C980 100p_25V_NP O_02

R712 33_04

TPM

R389 100K_04

R358 1.5K_04

R386 10K_04

C770

0.1u_6.3V_X5R_02

C977 100p_25V_NP O_02

C776

10u_6.3V_X5R_06

R393 *10mil_short

C782 *0.1u_10V_ X7R_04

R354 47_04

R530 4.7K_04

C772

0.1u_6.3V_X5R_02

D19

BAV99 RECTIFIER

A

C

AC

R359 47_04

R769 75_04

W/O TPM

J_KB2

FP226H-026S10M

NH50 KB

24

23

22

14

12

11

21

8

20

19

6

5

18

4

17

10

9

7

3

2

1

16

15

13

25
26

U45

GD25D10BTIGR

PCB Footprint = M-SO8

TPM

CE#

1

SO

2

WP#

3

VSS

4

SI

5

SCK

6

HOLD#

7

VDD

8

D18

BAV99 RECTIFIER

A

C

AC

J_FAN1

50273-0040N-001

PCB Footprint = 85205-0400M

1
2
3
4

J_80DEBUG1
50273-0040N-001

PCB Footprint = 85205-0400M

80DEBUG1

1

2

3

4

R376 1.5K_04

C562

10u_6.3V_X5R_06

R744 10K_04

R713 33_04

TPM

R364 0_04

R403 0_04

J_KB1

FP226H-026S10M

NH77 KB

24

23

22

14

12

11

21

8

20

19

6

5

18

4

17

10

9

7

3

2

1

16

15

13

25
26

R329 10K_04

R351 10K_04

NH77

R391 *10mil_short

R367 10K_04

R544 4.7K_04

R390 0_04

R392 *10mil_short

D16

BAV99 RECTIFIER

A

C

AC

R400 4.7K_04

R398 *0_04

R357 *10mil_short

R707

3.3K_1%_04

TPM

C397

10u_6.3V_X5R_06

_

IT5570

U19B

IT5570E-128/CX

GPJ1/TACH2B

77

GPD1/RI2#/5VT

21

GPJ2/DAC2/TACH0B

78

GPC1/SMCLK1/5VT

115

GPC2SMDAT1/5VT

116

GPF7/SMDAT2/PECIRQT#

118

GPA0/PWM0/5VT

24

GPA2/PWM2/5VT

28

GPA3/PWM3/5VT

29

GPA4/SMCLK5/PWM4/5VT

30

DAC3/TACH1B/GPJ3

79

5VT/SSCE0#/GPG2

100

DAC4/DCD0#/GPJ4

80

ADC2/GPI2

68

5VT/ID3/GPH3

96

5VT/ID4/GPH4

97

5VT/ID5/GPH5

98

KSO16/SMOSI/GPC3

56

KSO17/SMISO/GPC5

57

GPI6/ADC6/DSR1#

72

GPJ0/TACH2A

76

TACH1A/TMA1/GPD7

48

DAC5/RIG0#/GPJ5

81

GPJ7

2

GPJ6

128

GPA5/SMDAT5/PWM5/5VT

31

GPA6/PWM6/SSCK/5VT

32

GPA7/PWM7/RIG1#/5VT

34

GPI5/ADC5/DCD1#

71

R347 10K_1%_04

R401 4.7K_04

C378

*1u_6.3V_X5R_02

LPC

GPIO

SMBUS

PS/2

K/B MATRIX

IT5570

ADC

U19A

IT5570E-128/CX

GPM0/EIO0/LAD0

10

GPM1/EIO1/LAD1

9

GPM2/EIO2/LAD2

8

GPM3/EIO3/LAD3

7

GPM4/ESCK/LPCCLK

13

GPM5/ECS#/LFRAME#

6

GPM6/ALERT#/SERIRQ

5

GPD2/ERST#/LPCRST#/5VT

22

WRST#

14

GPE1/EGAD/5VT

82

GPB0/AC_IN#

108

GPC7/RXD/SIN0/PWUREQ#/BBO/SM CLK2ALT

16

GPD0/RI1#

18

GPD4/ECSMI#

15

GPD3/ECSCI#/5VT

23

GPI0/ADC0

66

GPI1/ADC1

67

GPI3/ADC3

69

GPI4/ADC4

70

GPI7/ADC7/CTS1#

73

KSI0/STB#

58

KSI1/AFD#

59

KSI2/INIT#

60

KSI3/SLIN#

61

KSI4

62

KSI5

63

KSI6

64

KSI7

65

KSO0/PD0

36

KSO1/PD1

37

KSO2/PD2

38

KSO3/PD3

39

KSO4/PD4

40

KSO5/PD5

41

KSO6/PD6

42

KSO7/PD7

43

KSO8/ACK#

44

KSO9/BUSY

45

KSO10/PE

46

KSO11/ERR#

51

KSO12/SLCT

52

KSO13

53

KSO14

54

KSO15

55

GPE0/SMCLK4/L80HLAT/BAO/5VT

19

GPE7/SMDAT4/L80LLAT/5VT

20

GPF6/PECI/SMCLK2

117

GPA1/PWM1/5VT

25

GPF0/PS2CLK0/CEC/TMB0/5VT

85

GPF2/SMCLK0/5VT

87

GPF1/PS2DAT0/TMB1/5VT

86

GPF3/SMDAT0/5VT

88

GPF4/PS2CLK2/5VT

89

GPF5/PS2DAT2/5VT

90

GPB3/PWRSW

110

GPB1/LID_SW#

109

GPD5/GINT/CTS0#/5VT

33

GPB6/KBRST#

4

GPG6/DSR0#

119

VCORE12VSS1VSS27VSS49VSS91GPC0/CRX0/5VT

113

GPG1/DTR1#/SBUSY/ID7

122

AVSS

75

11

VCC

VSTBY26VSTBY50VSTBY92VSTBY

114

VSTBY

121

VSTBY(PLL)

127

GPH7

3

AVCC

74

VSTBY_FSPI

106

SSCE1#/GPG0

125

5VT/CTX1/SOUT1/SMDAT3/ID2/ GPH2

95

5VT/RTS1#/GPE5

35

5VT/TXD/SOUT0/LPCPD#/GPE6

17

TACH0A/GPD6

47

TMRI0/GPC4

120

TMRI1/GPC6

124

CTX0/TMA0/GPB2

123

GA20/GPB5

126

5VT/CLKRUN#/ID0/GPH0

93

5VT/ID6/GPH6

99

5VT/CRX1/SIN1/SMCLK3/ID1/GPH1

94

FSCE#/GPG3

101

FMOSI/GPG4

102

FMISO/GPG5

103

FSCK/GPG7

105

VSS

104

BTN#/GPE4

107

VSTBY0

112

XLP_OUT/GPB4

111

GPE2/EGCS#/5VT

83

GPE3/EGCLK/5VT

84

R381 *10mil_short

R349 10K_04

NH50

C1114

0.1u_6.3V_X5R_02

TPM

C1009 100p_25V_NPO_02

R372 100K_04

R368 10K_04

J_FAN2

50273-0040N-001

PCB Footprint = 85205-0400M

1
2
3
4

C992 100p_25V_NPO_02

R714

3.3K_1%_04

TPM

R363

100K_04

R369 0_04

R387 *10mil_short

R402 33_04

R755 75_04

W/O TPM

C753 1u_6.3V_X5 R_02

R710 33_04

TPM

R394 *10mil_short

C757

0.1u_6.3V_X5R_02

C783 *5p _50V_NPO_04

R758 75_04

W/O TPM

C769

0.1u_50V_X5R_04

KBC_MUTE#

LIGHT_KB_DET#

KB-SI3

KB-SI2

KB-SO5

KB-SI1

KB-SO3
KB-SO4

KB-SO11

KB-SI6

KB-SI4

KB-SO8

KB-SO7

KB-SO6

KB-SO14

KB-SO2

KB-SO15

KB-SI0

KB-SI5

KB-SO12

KB-SO1

KB-SO10

KB-SO0

KB-SI7

KB-SO9

KB-SO13

KB-SO16
KB-SO17

VBATT_BOOST#

EC_PECI

CPU_FANSEN

RGBKB-DET#

PERKB-DET#_R

BAT_DET

SMC_BAT
SMD_BAT

BAT_VOLT
CPU_FAN

AC_IN#

CPU_FAN

CPU_FANSEN

VGA_FAN

VGA_FANSEN

FDIO2

FDIO3

ALSPI_MS I_L

ALSPI_MSO_L

ALSPI_SCLK_L

ALSPI_CE#_L

VGA_FAN
VGA_FANSEN

MODEL_ID

3IN1
80CLK

KBC_WRESET#

KBC_WRESET#

KBC_MUTE#

BAT_VOLT

BAT_DET

VBATT_BOOST#

MODEL_ID

LIGHT_KB_DET#

EC_PECI

VGA_FAN

CPU_FAN

3IN1

80CLK

KB-SI3

KB-SI2

KB-SO5

KB-SI1

KB-SO3
KB-SO4

KB-SO11

KB-SI6

KB-SI4

KB-SO8

KB-SO7

KB-SO6

KB-SO14

KB-SO2

KB-SO15

KB-SI0

KB-SI5

KB-SO12

KB-SO1

KB-SO10

KB-SO0

KB-SI7

KB-SO9

KB-SO13

AUTO_LOAD_PWR

ALSPI_SCLK_L

ALSPI_MSO_L

ALSPI_MS I_L

ALSPI_CE#_L

KB-SO16
KB-SO17

CPU_FANSEN

VGA_FANSEN

KB-SO16
KB-SO17

SMD_VGA_THERM

SMC_VGA_THERM

BT_EN_EC

Sheet 45 of 67

KBC-ITE IT5570

KBC-ITE IT5570

B.Schematic Diagrams

B - 46 KBC-ITE IT5570

RGB KB

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

N85

ᶲẞ

N87

ᶲẞ

RGB KB Only

KB_5VS/3A

2018/6/29

2018/6/28

2018/6/29

2018/6/28

Raven change conn 0709

D02_102618_Alex_Common design

D02_102618_Alex_Common design

2A 2A

D02_102618_Alex_Common design

5VS

VDD3

RGBKB_PWR

RGBKB_PWR

RGBKB_PWR

5VS RGBKB_PWR

RGBKB-DET# 45

EC_PWM_LEDKB_G45

PERKB-DET#_R45,70

EC_PWM_LEDKB_R45

EC_PWM_LEDKB_B45

EC_PWM_PIN_2445

VDD34,23,30,31,33,36,39,40,42,44,45,47,48,49,52,53,55,56,57,58,59,60,63,70,71,72

VIN28,33,47,48,49,50,51,52,53,54,55,57,72
5VS27,29,31,43,44,45,47,70,71,72

3.3V2,24,28,41,43,47,48,50,51,54,57,58,59,68,69

3.3VS8,9,23,24,27,28,29,30,31,32,33,34,35,38,39,40,42,43,44,45,47,48,52,59,70,71

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[46] RGB KB

46 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Custom

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[46] RGB KB

46 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Custom

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[46] RGB KB

46 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Custom

Q37
MTA90N03ZN3

KB-LED-RGB

G

DS

R345
*100K_04

NH50_RGB

R356

1K_04

NH77_RGB

PJ10

*OPEN_2mm

1 2

C761 4.7u_6.3V_X5R_04

NH77_RGB

Q36
MTA90N03ZN3

KB-LED-RGB

G

DS

J_KBLED1

FP225H-008S11M

fp225h-008gxxxm_r

P/N = 6-20-94K30-108

NH50_RGB

1
2
3
4
5
6
7
8

R343

1K_04

NH50_RGB

Q39
2SK3018S3

KB-LED-RGB

G

DS

R344 0_06

KB-LED-RGB

R321 *1K_04

KB-LED-RGB

Q38
AO3415

KB-LED-RGB

G

DS

C774

4.7u_6.3V_X5R_04

KB-LED-RGB

R355

1K_04

NH77_RGB

R361
1K_04

KB-LED-RGB

C752 4.7u_6.3V_X5R_04

NH50_RGB

J_KBLED2

FP225H-008S11M

fp225h-008gxxxm_r

P/N = 6-20-94K30-108

NH77_RGB

1
2
3
4
5
6
7
8

R340 0_06

KB-LED-RGB

R365

2.7K_04

KB-LED-RGB

R342

1K_04

NH50_RGB

R353

4.7K_04

KB-LED-RGB

Q35
MTA90N03ZN3

KB-LED-RGB

G

DS

R346 0_06

KB-LED-RGB

KBZONE_B
KBZONE_R
KBZONE_G

KBZONE_B
KBZONE_R
KBZONE_G

RGBKBSW_R KBZONE_R

RGBKBSW_G KBZONE_G

RGBKBSW_B KBZONE_B

Sheet 46 of 67

RGB KB

Schematic Diagrams

B.Schematic Diagrams

RGB KB B - 47

Schematic Diagrams

Sheet 47 of 67

5V, 5VS, 3.3V,

3.3VS

1

1

2

2

3

3

4

4

5

5

A A

B B

C C

D D

EMI EMI

ON

6A

5V

6A

5VS

ON

6A

3.3V

6A

3.3VS

Clost to P2808B0

DD_ON#

SUSB

SHORTSHORT

D02_1107_Alex

VDD3

VDD3

VIN

VIN VINVIN

VDD5

5V

VDD3

VDD5

5VS

VDD5

VDD3

3.3V

VDD3

3.3VS

VDD3

VAVIN

VREG3

VREG3

VREG3

VA55

VIN28,33,48,49,50,51,52,53,54,55,57,72

VDD541,49

3.3V2,24,28,41,43,48,50,51,54,57,58,59,68,69

5VS27,29,31,43,44,45,46,70,71,72

3.3VS8,9,23,24,27,28,29,30,31,32,33,34,35,38,39,40,42,43,44,45,48,52,59,70,71

DD_ON41,45,49,72

DD_ON# 41,50 SUSB 27,29,43

SUSB#28,31,33,41,45,48,50,53,60

VDD34,23,30,31,33,36,39,40,42,44,45,46,48,49,52,53,55,56,57,58,59,60,63,70,71,72

VDDQ6,8,9,33,48,50

5V28,41,43,48,50,53,58,69

SUSB#_EN 48

PWR_SW# 45

M_BTN#44

VREG345,49,55

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[47] 5V,5VS,3.3V,3.3VS

A3

47 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[47] 5V,5VS,3.3V,3.3VS

A3

47 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[47] 5V,5VS,3.3V,3.3VS

A3

47 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

C943

0.1u_50V_X5R_04

PQ8

2SK3018S3

G

DS

R444 10K_04

C907

470p_50V_X7R_04

G5016U32

CT2

10

OUT2

8

EN25VBIAS

4

IN2

6

GND11EN1

3

CT1

12

OUT1

13

IN1

1

IN1

2

OUT1

14

IN2

7

OUT2

9

GND

15

R395

47K_04

R466
10K_04

C837
220p_50V_NPO_04

C919

0.1u_50V_X5R_04

PR123

100K_04

C906
220p_50V_NPO_04

R399

47K_04

C838

330p_50V_NPO_04

C848

0.1u_6.3V_X5R_02

PR112

10K_04

R409 1K_04

R445
10K_04

C920

0.1u_50V_X5R_04

C40

0.1u_50V_X5R_04

Q45
2SK3018S3

G

DS

G5016U29

CT2

10

OUT2

8

EN25VBIAS

4

IN2

6

GND11EN1

3

CT1

12

OUT1

13

IN1

1

IN1

2

OUT1

14

IN2

7

OUT2

9

GND

15

PC92

*0.1u_6.3V_X5R_02

R410

1M_04

C905

0.1u_6.3V_X5R_02

C862

0.22u_10V_X5R_02

PJ21 OPEN_1mm

1 2

PJ22 OPEN_1mm

12

C901

0.1u_6.3V_X5R_02

PR120 10K_04

S

D

G

Q40A

MTDK3S6R

2

61

C903
1u_6.3V_X5R_02

R452
47_04

PQ7

2SK3018S3

G

DS

PR121

100K_04

PJ23 *CV-40mil

12

C847

0.1u_6.3V_X5R_02

R467
10K_04

D11
*AVL18S02015

12

C893

*0.1u_10V_X7R_04

S

D

G

Q40B
MTDK3S6R

5

34

C851
1u_6.3V_X5R_02

PC96

*0.1u_6.3V_X5R_02

C910

0.1u_6.3V_X5R_02

C833

0.1u_6.3V_X5R_02

C1016

0.1u_50V_X5R_04

C902

0.1u_6.3V_X5R_02

C1063

1000p_50V_X7R_04

PJ20 *CV-40mil

1 2

C839

0.1u_6.3V_X5R_02

PR116

100K_04

C863

*0.1u_10V_X7R_04

R406

200K_04

C892

*0.1u_10V_X7R_04

DD_ON#

DD_ON DD_ON_EN

SUSB#

VDD3_R

SUSB#_EN

DD_ON_EN SUSB#_EN

VDD3_R

SUSB

SUSB

DD_ON_EN

5V, 5VS, 3.3V, 3.3VS

B.Schematic Diagrams

B - 48

VDD1.05V, VCCIO

1

1

2

2

3

3

4

4

5

5

A A

B B

C C

D D

VTT_SELECT VTT VR Output Voltages
low 1.1 V
high (V1.1S_VTT) 1.05 V

1.05V

VDD1.05

SHORT

1.05V_VCCST

SHORT

3A

NOTE:

3.3VA Ton need <65us
M5938 TURON-ON TIME=60us

3.3VA

6A

VCCIO

SHORT

VCCIO

0

C1PART NUMBER !LPM

X

1

0

C0

X

0

01

1

110

VOUT (V)

0(LPM)

0.85V

0.875V

0.95V

11

1 0.975V

SHORT

VCCST

2A

SHORT

1A

SHORT

VCCSFR_OC

SHORT

Floating O.C.P 12A

10A

SHORT

1V/8A

20180502 Follow common design

SHORT

SHORT

VDD1.05

VDD3

1.05V_VCCST

VDD3

3.3VA

VDD3

3.3V

VCCIOGND

VIN

3.3V

VCCIO

VCCIOGND

GND

VDD3

VDD3

3.3VS

VCCIOGND

VCCIOGND

VDD1.05

5V

VDD3

VDDQ

VCCSFR_OC

VDD3

VDD3

VIN

V1.0A

VDD3

VDD3

5V 28,41,43,47, 50,53,58,69

1.05V_VCCST 4,6,32,52

VCCIO 2,6

VDD5 41,47,49

VIN 28,33,47,49,50,51,52,53,54,55,57,72

VDD1.05 35,36,53

VDD3 4,23,30,31,33,36,39,40,42,44,45,46,47, 49,52,53,55,56,57,58,59,60,63,70 ,71,72

3.3V 2,24, 28,41,43,47,50,51,54,57,58,59, 68,69

VREG5 49,53

SLP_SUS# 40,45, 48,53,72

3.3VA 4,30, 31,32,33,36,38,44,53

VCCIO_PWRGD31

SUSB#28,31,33,41,45,47,50,53,60

DDR 1.35V_PWRGD50

SLP_S0#33,52

GPP_J138,53

3.3VS 8,9, 23,24,27,28,29,30,31,32,33,34,35, 38,39,40,42,43,44,45,47,52,59, 70,71

VSSIO_SENSE 6

VCCIO_SENSE 6

SUSC#33,45,50

SUSB#_EN47

VCCSTG_EN53

VDDQ 6,8,9,33,50

VCCSFR_OC 6

1.8VA_PGD53

SLP_SUS#40,45,48,53,72

VCCMPHY_SENS E 3 6

VSSMPHY_SENSE 36

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[48] VDD1.05V,VCCIO,3.3VA,VCCST

A2

48 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[48] VDD1.05V,VCCIO,3.3VA,VCCST

A2

48 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[48] VDD1.05V,VCCIO,3.3VA,VCCST

A2

48 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

PR239 0_04

PC228

22u_6.3V_X6S_08

PR76
*20K_04

R644

*100_04

PR84*0_04

R671

*100_04

G5016 U42

CT2

10

OUT2

8

EN25VBIAS

4

IN2

6

GND11EN1

3

CT1

12

OUT1

13

IN1

1

IN1

2

OUT1

14

IN2

7

OUT2

9

GND

15

PC30

0.1u_25V_X7R_06

PR230 0_04

R656 *0_04

PJ37

OPEN_8mm

1 2

PC60

22u_6.3V_X5R_06

PC222

22u_6.3V_X6S_08

R191

*100K_04

PU18

NB681GD-Z

VIN

1

C0

4

AGND

11

SW

8

VOUT

12

3V3

10

C1

3

EN

5

PG

13

PGND

2

LP#

6

MODE

7

BST

9

PU3

TC7SZ08FU

1

2

5

4

3

PC212

0.1u_25V_X7R_06

PC216

22u_6.3V_X6S_08

PL16

BCIHP0730-1R0M

PCB Footprint = BCIHP0735A

1 2

PJ5 1mm

1 2

PJ35 *CV-40mil

1 2

PL14

BCIHP-0735-0R68M-NL

PCB Footprint = BCIHP0735A

PJ36 * 1mm

1 2

PC59

22u_6.3V_X5R_06

PR79
100_04

Q63

2SK3018S3

G

DS

PC31

10u_25V_X5R_08

PR278
100_04

C1042

1u_6.3V_X5R_02

C1074

*1u_6.3V_X5R_02

PR232

100K_04

PR263 23.2K_1%_04

PC67

10u_25V_X5R_08

PJ34 OPEN_40mil

1 2

Q62

*2SK3018S3

G

DS

PC55

0.1u_10V_X7R_04

PR80
10K_04

R66010K_04

PC205

*0.01u_50V_X7R_04

C1064

*0.1u_10V_X7R_04

Q24

*2SK3018S3

G

DS

PR273
30K_1%_04

PR68

0_04

PJ42 OPEN_1mm

1 2

PJ45 OPEN_3mm

1 2

PR75
*20K_04

U40

FA7609A6

NC

3

GND

1

VIN2VOUT

4

VBIAS

5

ON

6

PJ38 1mm

1 2

PC224

*0.01u_25V_X7R_04

Q61

*2SK3018S3

G

DS

C1071

10u_6.3V_X5R_06

C1075

*10u_6.3V_X5R_06

PC237

*330p_50V_NPO_04

+

PC64

*330U_2V_D2_D

C1077

1u_6.3V_X5R_02

C1073

*0.1u_10V_X7R_04

PR78
100_1%_04

PJ7

1mm

12

PJ44OPEN_1mm

12

PR262
*1K_1%_04

C1082

220p_50V_NPO_04

C1070

10u_6.3V_X5R_06

C1069

10u_6.3V_X5R_06

R659 0_04

PC214

22u_6.3V_X6S_08

PC40

10u_25V_X5R_08

PR73
10K_04

PJ6 1mm

1 2

PR81
10K_04

C1080

10u_6.3V_X5R_06

C1083

10u_6.3V_X5R_06

PR221

3.3_06

PR279
100_04

PR72

5.1_1%_04

PR268
*100K_04

C1043

0.1u_10V_X7R_04

PU20

SY8288RAC

qfn20-3x3mmc

6-02-05068-4Q0

FB

14

GND

7

BS

1

IN

5

LX

20

BYP

15

EN

11

PG

9

ILMT

13

VCC

17

IN

4

IN

3

IN

2

LX

19

LX

6

GND8GND18PAD

21

NC

10

NC

12

NC

16

PC44

1u_6.3V_X5R_04

C1078

*1u_6.3V_X5R_02

PR258 100K_04

Q60

2SK3018S3

G

DS

PC66

10u_25V_X5R_08

PC234

4.7u_6.3V_X6S_06

PC204

0.22u_16V_X7R_06

PJ8 6mm

1 2

PC57

22u_6.3V_X5R_06

PR222
0_04

PJ41 1mm

1 2

PC213 0.1u_16V_X7R_04

PR250

47K_1%_04

R674

100_04

R668

100K_04

PC53

0.1u_10V_X7R_04

C1072*0.1u_10V_X7R_04

PJ33

*CV-40mil

OPEN

12

C1052

*10u_6.3V_X5R_06

Q25

*2SK3018S3

G

DS

C1081

220p_50V_NPO_04

PR261
*100K_04

PC54*0.1u_10V_X7R_04

R667

*100K_04

R610
0_04

C1038*0.1u_10V_X7R_04

PC238

4.7u_6.3V_X6S_06

3.3VA_ON

3.3VA_ON

C1_VCCIO_VR

C0_VCCIO_VR

VCCIO_R

C1_VCCIO_VR

C0_VCCIO_VR

VCCST_EN

VCCST_EN

SUSB#_EN

Sheet 48 of 67

VDD1.05V, VCCIO

Schematic Diagrams

B.Schematic Diagrams

VDD1.05V, VCCIO B - 49

Schematic Diagrams

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

S478!Opu!T uvgg!-!S74 4!Tuvgg... .Opo.Wqsp- !BD!JO!WEE 4!Bmxbzt!P O/

S478-S744! Opu!Tuvgg. ..Wqsp-!BD !JO!WEE4-

WEE6!Bmxbz t!PO/

Qpxfs!po!W EE40WEE6!Q XN

CV Test

SHORT

SHORT

8A

R1

R2

Vout=2*(1+R1/R2)

=2*(1+14K/20K)
=3.4V

R2

R1

=2*(1+30K/19.1K)
=5.1927

Vout=2*(1+R1/R2)

VDD5

2.5A

for EMI

14A

2.5A

VDD3

D03 Raven modfiy 0417

D02_1115_Power

VREG5

VIN

VDD3

VREG3

VDD5

VIN

SYS3V

VREG5

VIN

SYS5V

VREG5

VDD5_LDO5

DD_ON41,45,47,72

USB_CHARGE_EN45

VDD34,23,30,31,33,36,39,40,42,44,45,46,47,48,52,53,55,56,57,58,59,60,63,70,71,72
VDD541,47

VIN28,33,47,48,50,51,52,53,54,55,57,72
VREG553
VREG345,47,55

XLP_OUT45

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[49] VDD3,VDD5

A3

49 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[49] VDD3,VDD5

A3

49 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[49] VDD3,VDD5

A3

49 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

PJ48

5mm

12

PC277

*4.7u_25V_X5R_08

PC276

4.7u_25V_X5R_08

PR297 0_06

+

PC279

EEEFZ1E101P

12

S

D

G

Q51A

MTDK3S6R

2

6

1

PR114

34.8K_1%_04

R478

*10mil_short

PR117

19.1K_1%_06

PR113
30K_1%_06

PD12

CSOD140BSH

A C

PQ19

AON6992

1

283

4

9

567

PR295 0_06

PJ19

*CV-40mil

1 2

PC273

*4.7u_25V_X5R_08

PC93

1000p_50V_X7R_04

PC271

0.1u_25V_X7R_06

PC272

4.7u_25V_X5R_08

PL22

BCIHP0730-2R2M

12

R479

200K_04

+

PC281

EEEFZ1E101P

12

PR122

20K_1%_06

EMC5
1000p_50V_X7R_04

PC270

0.1u_10V_X7R_04

R470

2M_1%_04

PC283

0.1u_10V_X7R_04

PR115

0_06

PR293
200K_04

PC274

0.1u_10V_X7R_04

+

PC280

220u_6.3V_6.3*4.4

PJ24 1mm

1 2

PR294 0_06

PC88

0.1u_10V_X7R_04

R480

200K_04

PR118

2.2_06

PC282 *100p_50V_NPO_04

EMR2

5.1_06

PL21

BCIHP0730-4R7M

12

PR296
14K_1%_06

PJ49

5mm

1 2

PC275

0.1u_25V_X7R_06

PC278

4.7u_25V_X5R_08

Q46

2SK3018S3

G

DS

PC95

1u_6.3V_X5R_04

S

D

G

Q51B

MTDK3S6R

5

3

4

+

PC269

220u_6.3V_6.3*4.4

PC89

*1000p_50V_X7R_04

PD14

CSOD140BSH

A C

PQ18

AON6992

1

283

4

9

567

PU24

TPS51275B-1RUKR

EN1

20

VFB1

2

VREG5

13

DRVL1

15

SW1

18

VFB2

4

DRVH2

10

VCLK

19

VBST2

9

EN2

6

VREG3

3

SW2

8

DRVL2

11

VIN

12

DRVH1

16

VBST1

17

PGOOD

7

VO1

14

GND PAD

21

CS11CS2

5

PC94
1u_6.3V_X5R_04

PJ25
*CV-40mil

12

PR298 0_06

PR119

34.8K_1%_04

DD_ON_EN_VDD

EN_5VEN_3V5V

EN_5V

EN_3V

EN_3V

Sheet 49 of 67

VDD3, VDD5

VDD3, VDD5

B.Schematic Diagrams

B - 50 VDD3, VDD5

DDR 1.2V / 0.6VS, 2.5V

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

R1

R2

Modify, Ivy 03/01

DEL R1058

For CV test

3A

Ra

3A

Rb

Vout = 0.8V ( 1 + Ra / Rb )

Layout trace 2A after jumper

2.52V = 0.8V ( 1 + 21.5/ 10 )

天月

PIN4

儛

DDR4

1.2V/0.6VS

2A

1.2V

13A

VTT_MEM(0.6V)

2A

Hi 1.35V

DDR GPIO OUTPUT VOLTAGE SELECT

GPIO DDR Vout

Lo 1.2V

暣⡻堐

SHORT

SHORT

SHORT

2.5V

CV Test

ON

CV Test

⮔⹎≈⣏䁢

8mil

D02_1107_Alex

D02_1112_Alex

5V

5V

VDDQ_R

5V

VIN

VDDQ_R

VDDQ

VTT_MEM

3.3V

3.3V

5V

2.5V

3.3V

VIN

5V

5V

5V

2.5V8,9

VDDQ6,8,9,33,48

VIN28,33,47,48,49,51,52,53,54,55,57,72

3.3V2,24,28,41,43,47,48,51,54,57,58,59,68,69

VTT_MEM8,9

5V28,41,43,47,48,53,58,69

PEX_VDD10,22,58

3.3VS8,9,23,24,27,28,29,30,31,32,33,34,35,38,39,40,42,43,44,45,47,48,52,59,70,71

5VS27,29,31,43,44,45,46,47,70,71,72

SMB_DATA 31,33

SMB_CLK 31,33

DDR 1.35V_PWRGD 48

SUSC#33,45,48,50

VDD34,23,30,31,33,36,39,40,42,44,45,46,47,48,49,52,53,55,56,57,58,59,60,63,70,71,72

DDR_VTT_PG_CTRL4

SUSB#28,31,33,41,45,47,48,53,60

DD_ON#41,47

SUSC#33,45,48,50

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[50] DDR 1.2V/0.6VS,2.5V

A3

50 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[50] DDR 1.2V/0.6VS,2.5V

A3

50 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[50] DDR 1.2V/0.6VS,2.5V

A3

50 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

PU5

G9661-25ADJF11U

GND

8

VCNTL

4

NC

5

VIN

3

VOUT

6

VFB

7

POK

1

EN

2

GND

9

PJ15 OPEN_1mm

1 2

R425 *10mil_short

PR111 47K_04

C809

*1u_6.3V X5R_04

PR107
*15mil_short

C886

0.1u_6.3V_X5R_02

PC82 0.1u_10V_X7R_04

PC79

1u_6.3V_X6S_04

PC84 *100p_50V_NPO_04

PC78

0.1u_10V_X7R_04

+

PC264

390uF_2.5V_10m_6.3*6

R428 *10mil_short

PC75

0.1u_25V_X7R_06

PJ16 *CV-40mil

1 2

PC76

*10u_6.3V_X5R_06

PR108 560K_1%_04

R456 100K_04

EMC4

220p_50V_NPO_04

PC266

4.7u_25V_X7R_08

U28

*UP1804AMA8

VCC

1

BUS_SEL

2

GND

3

SDA4SCL

5

NC

6

NC

7

OUT

8

PJ13 OPEN_2mm

12

Q47

2SK3018S3

G

DS

PD11

RB0540S2

A C

R481 *10K_04

PC267

4.7u_25V_X7R_08

C867

*0.1u_6.3V_X5R_02

PJ18

*CV-40mil

12

R436

10K_04

Q50
2SK3018S3

G

DS

PC80

82p_25V_NPO_02

PR110 5.1K_1%_04

Q44

2SK3018S3

G

DS

PC83

1u_6.3V_X6S_04

PR102

21.5K_1%_04

PR109 8.06K_1%_06

PR104
*15mil_short

PJ47 6mm

1 2

EMR3

0_06

R447 47K_04

PD10 CSOD140BSH

A C

PC265

0.1u_25V_X7R_06

PR105 4.7K_1%_04

PC81

10u_6.3V_X5R_06

PJ17

*CV-40mil

12

R482 1K_04

R448 10K_04

PC77

22u_6.3V_X5R_06

PC268

10u_6.3V_X5R_06

R438

*10_04

R446 10K_04

Q49
*2SK3018S3

G

DS

ERM1 0_06

PC74

22u_6.3V_X5R_06

PL20

BCIHP0730-1R0M

PCB Footprint = BCIHP0735A

1 2

C866

*0.22u_10V_X5R_02

PC90

0.1u_10V_X7R_04

R435

*10K_04

C908

0.01u_16V_X7R_04

PC91

1u_6.3V_X5R_04

PR106

2.2_1%_06

R432

*0_04

PU4
G5616BRZ1U

VTTGND

1

VLDOIN

19

VTT

20

VTTSNS

2

GND

3

TON

9

VTTREF4VCC5

11

PGOOD

10

S5

8

S3

7

VDDQSET

6

VDDQSNS

5

CS

13

PGND

14

DRVL

15

LL

16

DRVH

17

VBST

18

PVCC5

12

GND

21

Q48

MMBT3904H

B

E C

PR103

10K_1%_04

EMR1

5.1_06

PQ17

AON6992

1

283

4

9

567

C876

*1u_6.3V_X5R_02

R464 10K_04

R437 *10mil_short

VDDQSET

2.5V_PG

VDDQSET

Sheet 50 of 67

DDR 1.2V / 0.6VS,

2.5V

Schematic Diagrams

B.Schematic Diagrams

DDR 1.2V / 0.6VS, 2.5V B - 51

Schematic Diagrams

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

Co-lay

Co-lay

Co-lay

DIPLF! DNNF17 4U.S26 NT1S:1 8
Jsnt>4 9B!Jtb u>56B! EDS>1/ :1nS

5.5A

VCORE 4Phase

VCORE OUTPUT STAGE

140A

5.5A

DIPLF! DNNF17 4U.S26 NT1S:1 8
Jsnt>4 9B!Jtb u>56B! EDS>1/ :1nS

DIPLF! DNNF17 4U.S26 NT1S:1 8
Jsnt>4 9B!Jtb u>56B! EDS>1

/:1nS

DIPLF! DNNF17 4U.S26 NT1S:1 8
Jsnt>4 9B!Jtb u>56B! EDS>1/ :1nS

Co-lay

5.5A

5.5A

D02_102518_Power

EMI_1121

3.3V

VIN

3.3V

VIN

3.3V

3.3V

VIN

VCORE

VIN

VIN

VRACPU_PWM 152

VRACPU_CS152

VRA_STB51,52, 54

VRA_VTEMP51,52,54

VRACPU_PWM 252

VRACPU_CS252

VRA_STB51,52, 54

VRA_VTEMP51,52,54

VRACPU_PWM 352

VRACPU_CS352

VRA_STB51,52, 54

VRA_VTEMP51,52,54

VRACPU_PWM 452

VCORE5,51,52

VRACPU_CS452

VRA_STB51,52, 54

VRA_VTEMP51,52,54

VCORE5,51,52

VIN28,33,47,48,49,50, 52,53,54,55,57,72

3.3V2,24,28,41,43,47,48,50,54,57,58,59,68,69

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[51] VCORE OUTPUT STAGE

A2

51 7 4Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[51] VCORE OUTPUT STAGE

A2

51 7 4Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[51] VCORE OUTPUT STAGE

A2

51 7 4Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

PR44 0_04

PR205

2.2_06

PR36 0_04

PR197 0_04

C477

47u_2.5V_X6S_08

C9450.01u_50V_X7R_04

PL12

CMME063T-R15MS0R907

12

+

C200

PSLB30E227M

C968

22u_2.5V_X6S_08

PC154

10u_25V_X6S_08

PC169
1u_6.3V_X6S_04

PC162

10u_25V_X6S_08

PC180

1u_25V_X7R_06

PC184
1u_16V_X7R_06

C505

47u_2.5V_X6S_08

C9440.01u_50V_X7R_04

C979

22u_2.5V_X6S_08

PR35 0_04

PC161

10u_25V_X6S_08

PC160

10u_25V_X6S_08

PC171
1u_6.3V_X6S_04

C532

47u_2.5V_X6S_08

PC179
1u_16V_X7R_06

+

C100

*PSLB30E227M

PC182
1u_16V_X7R_06

C964

22u_2.5V_X6S_08

PC175

2200p_50V_X7R_04

PL11

CMME063T-R15MS0R907

12

C11860.01u_50V_X7R_04

+

PC155

*25TQC15MYFB

PU14 MP86941GQVT-Z

VCC

20

AGND

19

PWM

15

VTEP/FLT

17

SYNC

16

CS

18

PGND15PGND26PGND37PGND48PGND5

9

PGND6

10

PGND7

11

PGND8

12

PGND9

13

SW1

2

SW2

3

SW3

4

BST

21

VIN1

1

VIN2

14

+

PC156

*25TQC15MYFB

PC152

10u_25V_X6S_08

PU15 MP86941GQVT-Z

VCC

20

AGND

19

PWM

15

VTEP/FLT

17

SYNC

16

CS

18

PGND15PGND26PGND37PGND48PGND5

9

PGND6

10

PGND7

11

PGND8

12

PGND9

13

SW1

2

SW2

3

SW3

4

BST

21

VIN1

1

VIN2

14

C11870.01u_50V_X7R_04

PC170
1u_6.3V_X6S_04

PR42 0_04

PU13 MP86941GQVT-Z

VCC

20

AGND

19

PWM

15

VTEP/FLT

17

SYNC

16

CS

18

PGND15PGND26PGND37PGND48PGND5

9

PGND6

10

PGND7

11

PGND8

12

PGND9

13

SW1

2

SW2

3

SW3

4

BST

21

VIN1

1

VIN2

14

PC166

2200p_50V_X7R_04

PC172

2200p_50V_X7R_04

PC153

10u_25V_X6S_08

C150

22u_2.5V_X6S_08

+

PC52

330U_2V_D2_D

PR195 0_04

PL13

CMME063T-R15MS0R907

12

PR206

2.2_06

PU16 MP86941GQVT-Z

VCC

20

AGND

19

PWM

15

VTEP/FLT

17

SYNC

16

CS

18

PGND15PGND26PGND37PGND48PGND5

9

PGND6

10

PGND7

11

PGND8

12

PGND9

13

SW1

2

SW2

3

SW3

4

BST

21

VIN1

1

VIN2

14

PC151

10u_25V_X6S_08

PC176

2200p_50V_X7R_04

+

PC157

*25TQC15MYFB

+

PC41

*330U_2V_D2_D

+

PC58

330U_2V_D2_D

PL10

CMME063T-R15MS0R907

12

PR43 0_04

PC188

1u_25V_X7R_06

PR200 0_04

+

PC158

*25TQC15MYFB

PC185

1u_25V_X7R_06

PC187
1u_16V_X7R_06

PR207

2.2_06

+

PC46

330U_2V_D2_D

C475

47u_2.5V_X6S_08

PC163

10u_25V_X6S_08

PC174
1u_6.3V_X6S_04

PC183

1u_25V_X7R_06

+

PC47

330U_2V_D2_D

C151

22u_2.5V_X6S_08

C507

47u_2.5V_X6S_08

PR204

2.2_06

+

PC118

EEEFZ1E101P

BST_PWM1

SW_PWM1

BST_PWM2

SW_PWM2

BST_PWM3

SW_PWM3

BST_PWM4

SW_PWM4

Sheet 51 of 67

VCore Output

Stage

VCore Output Stage

B.Schematic Diagrams

B - 52 VCore Output Stage

VCC_Core & VCCGT

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

Psys setting base on charger spec:

1. 1uA/W information

2. Pmax 65W

Iccmax setting:
Vcore: 128A
VGT:32A
VSA: 11.1A
TDC setting:
Vcore: 80A
VGT:14A
AC/DC LLsetting:
Vcore: 1.8m
VGT:2.7m
VSA: 10.3m

SHORT

D02_102518_Power

D02 POWER ISSUE

D02_102518_Power

D02_1030_Power

D02_1102_Alex

D02_1102_Alex

SHORT

GND_SIGNAL

VCCSA

VDD3

VIN

GND_SIGNAL

VR_VDD18

GND_SIGNAL

GND_SIGNAL

VCCGT

GND_SIGNAL

GND_SIGNAL

GND_SIGNAL

GND_SIGNAL

GND_SIGNAL

GND_SIGNAL

GND_SIGNAL

GND_SIGNAL

GND_SIGNAL

GND_SIGNAL

1.05V_VCCST

3.3VS

VR_VDD18

VDD3

VDD3

VCORE

GND_SIGNAL

VDD3

GND_SIGNAL

SMC_BAT24,45, 55,56

SMD_BAT24,45, 55,56

VCC_VCORE_SENSE 5

VSS_VCORE_SENSE 5

VRACPU_CS1 51

VRACPU_CS2 51

VRAGT_CS1 54

VRASA_CS1 54

VCCGT_SENSE 7

VSSGT_SENSE 7

VCCSA_SENSE 6

VSSSA_SENSE 6

ALL_SYS_PWRGD4,28,31,45

VRACPU_PWM 1 51

VRACPU_PWM 2 51

VRAGT_PWM 1 54

VRASA_PWM1 54

VRA_STB 51,54

VRA_VTEMP51,54

H_CPU_SVIDCLK4

H_CPU_SVIDDAT4

H_CPU_SVIDALRT#4

VCORE_PG31

H_PROCHOT#4

PSYS55

VRACPU_PWM 3 51

VRACPU_PWM 4 51

VRACPU_CS4 51

VRACPU_CS3 51

VCORE5,51

SLP_S0#33,48

VIN28,33,47,48,49,50,51,53,54,55,57,72

VDD34,23,30,31,33,36,39,40,42,44,45,46,47,48,49,53,55, 56,57,58,59,60,63,70,71,72

VCCGT7,54

3.3VS8,9,23,24,27,28,29,30,31,32,33,34,35,38,39,40,42,43, 44,45,47,48,59,70,71

VCCSA6,54

1.05V_VCCST4,6,32,48

EC_GPIO24,45,56, 59

Title

Size Document Number R ev

Date: Sheet

of

6-71-NH5D0-D02

D02

[52] VCC_CORE & VCCGT &VCCSA

A2

52 74F riday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number R ev

Date: Sheet

of

6-71-NH5D0-D02

D02

[52] VCC_CORE & VCCGT &VCCSA

A2

52 74F riday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number R ev

Date: Sheet

of

6-71-NH5D0-D02

D02

[52] VCC_CORE & VCCGT &VCCSA

A2

52 74F riday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

PJ30 1 mm

1 2

PJ1 1mm

1 2

PR186 *100_04

PR65 332K_1%_04

PJ29 1 mm

6-55-JUMP1-010

1 2

PC48

0.1u_16V_X7R_04

PR228

10K_1%_04

PR212

1.47K_1%_04

PC168 *470p _50V_X7R_04

PR209 73.2K_1%_04

PR172 *0_04

PC186 180p_50V_NPO_04

PR196 *0_04

PR225 10K_1%_04 PR34 *0_04

PR56 26.7K 1%_04

PR193 8. 2K_1%_04

PR69 10K_0 4

PR52 *100_04

PC178 820p_50V_X7R_04

PR184 1.5K_1%_04

PC165 0.01u _50V_X7R_04

PC34 0.1u_16V_X7R_04

PC28
1u_16V_X7R_06

PR180 866_1%_04

PR61 20K_04

PR226 0_04

PR218 *1K_1%_04

PR45 0_04

PR38 133K_1%_06

PR183 1.5K_1%_04

PR170 1.5K_1%_04

PJ3

*CV-40mil

12

PR189 *100_04

PR217 0_04

PR213 0_04

PC43 1u_16 V_X7R_06

PJ2 1mm

1 2

PR210

3.32K_1%_04

PR58 118K_1%_04

PR214 49.9_1%_04

PR46 *100_04

PR191 *100_04

PR220

*10K_1%_04

PR216 0_04

PR53

49.9K_1%_04

PR223 45.3_1%_04

PR71
*10K_1%_04

PR203 4.7_1%_06

PR219

*10K_1%_04

PR41 2M_1%_04

PR229 *0_04

PR182 *0_04

PJ31 1 mm

1 2

PC148 *470p _50V_X7R_04

PR70
100K_04

PU17

MP2979AGQKT-0020-Z

SCLK

27

SDIO

28

ALT#

29

VRHOT#

31

VRRDY

30

EN

37

VDD33

44

IMONA

21

IMONB

22

IMONC

23

IREF

24

PSYS

46

PE

36

CS4

2

CS2

4

CS1

5

CS5

1

CS3

3

CS6

48

VIN_SEN

47

STB

34

PWM143PWM242PWM341PWM440PWM539PWM6

38

SLP_S0#

35

SDA_P

32

SCL_P

33

VDD18

26

ADDR_P

25

TEMP

45

CSSUMC

20

CSSUMB

19

CSSUMA

18

VOSENC

16

VFBC15VDIFFC

14

VORTNB

13

VOSENB

12

VFBB

11

VDIFFB

10

VFBA

7

VORTNA

9

VOSENA

8

VDIFFA

6

AGND

49

VORTNC

17

PR211 0_06

PR185 *100_04

PC173 4.7u_6.3V_X5R_04

PJ28 1 mm

6-55-JUMP1-010

1 2

PC45

*0.1u_16V_X7R_04

PR187 1.5K_1%_04

PR215 10_1%_04

PR188 1.5K_1%_04

PJ4 OPEN_4mil

1 2

PR202 0_04

PD3

RB751S-40H

A C

PC150 *470p _50V_X7R_04

PR171 2. 1K_1%_04

PR169 1.5K_1%_04

PC35 68p_50V_NPO_04

PR77 *0_04

PR227 *100_ 1%_04

PR201 8. 25K_1%_04

PR224 100_04

PC23 0. 01u_50V_X7R_04

VRACPU_VDIF F

VRACPU_VINSEN

VRACPU_CS1

VRA_STB

VRAGT_CS1

VRAGT_CSUMB

VRASA_CS1

VRACPU_VFB

VRACPU_CSUMA

VCCSENSE_J

VSSSENSE_J

VRAGT_VFB

VRAGT_VDIFF

VRACPU_CSUMA

VRAGT_VOSEN

VRAGT_VORTN

VGT_VCCSENSE_J

VGT_VSSSENSE_J

VRASA_VOSEN

VRASA_VORTN

VCCSA_VCCSENSE_J

VCCSA_VSSSENSE_J

PSYS

VRASA_VFB

VRASA_VDIFF

VR_EN

VRASA_CSUMC

VRACPU_VORTN

VRACPU_VOSEN

VRAGT_PWM 1

VRASA_PWM1

VRACPU_PWM 2

VRACPU_PWM 1

VRAGT_IMON

VRASA_IMON

SMD_BAT_VR

SMC_BAT_VR

VRAGT_CSUMB

VRACPU_IREF

VRACPU_PE

VRACPU_IMON

VRACPU_CS2

VRASA_CSUMC

VR_SCLK

VR_DSIO

ADDRP

VRA_VTEMP

VR_ALT#

VR_VRRDY

VR_VRHOT#

VRACPU_PWM 3

VRACPU_PWM 4

VRACPU_CS3

VRACPU_CS4

VRACPU_PE

Sheet 52 of 67

VCC_Core &

VCCGT

Schematic Diagrams

B.Schematic Diagrams

VCC_Core & VCCGT B - 53

Schematic Diagrams

5

5

4

4

3

3

2

2

1

1

D D

C C

B B

A A

1.05DX_VCCSTG

1A

NOTE:

1.05DX_VCCSTG Ton need <65us
M5938 TURON-ON TIME=60us

SHORT

VCCSFR_OC Combine with

3.3VA(U16)

1.8VA

SHORT

?

Raven Modfiy 0726

SHORT

D02_102718_Alex

D02_1115_Power

Gary_0218_2019 DEL PJ33

VDD1.05

1.05DX_VCCSTG

5V

VDD3

VDD3

3.3VA

VIN

1.8VA

VREG5

VREG5

3.3VA

1.8VA

VDD1.0535,36,48

1.05DX_VCCSTG4,6,33

5V28,41,43,47,48,50,58,69

VDDQ6,8,9,33,48,50

VDD34,23,30,31,33,36,39,40,42,44,45,46,47,48,49,52,55,56,57,58,59,60,63,70,71,72
VDD541,47,49

3.3VA4,30,31,32,33,36,38,44,48

1.8VA36,59,60,68

GPP_J138,48

3.3V2,24,28,41,43,47,48,50,51,54,57,58,59,68,69

3.3VS8,9,23,24,27,28,29,30,31,32,33,34,35,38,39,40,42,43,44,45,47,48,52,59,70,71

SUSB#28,31,33,41,45,47,48,50,60

VCCSTG_EN

48

1.8VA_PGD48

SLP_SUS#40,45,48,72

VREG549

VIN28,33,47,48,49,50,51,52,54,55,57,72

PWR_SRC_NV_FB58,59,72

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[53]1.05DX_VCCSTG/VCCSFR_OC/1.8VA

A3

53 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[53]1.05DX_VCCSTG/VCCSFR_OC/1.8VA

A3

53 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

Title

Size Document Number Rev

Date: Sheet

of

6-71-NH5D0-D02

D02

[53]1.05DX_VCCSTG/VCCSFR_OC/1.8VA

A3

53 74Friday, February 07, 2020

ᙔ!Ϻ!ႝ!တ!!DMFWP!DP/

SCHEMATIC1

PR259 0_04

PC245

22u_6.3V_X5R_06

PR266
10K_1%_04

C650

*0.1u_10V_X7R_04

PR282

10K_1%_04

PR291 180K_1%_04

PJ43 1mm

1 2

U14

FA7609A6

NC

3

GND

1

VIN

2

VOUT

4

VBIAS

5

ON

6

PC243

22u_6.3V_X5R_06

PC231
1u_16V_X7R_06

R229 *0_04

Q27

*2SK3018S3

G

DS

+

PC251

4.7u_25V_X7R_08

C651

0.1u_10V_X7R_04

PC244

22u_6.3V_X5R_06

Q29

*2SK3018S3

G

DS

+

PC252

4.7u_25V_X7R_08

PC250

22u_6.3V_X5R_06

PL17

BCIHP5420HC-1ROM

12

PR267 100K_04

PC235 100p_50V_NPO_04

PC230

0.1u_25V_X7R_06

PC249

*22u_6.3V_X5R_06

C618

*10u_6.3V_X5R_06

PC239

0.1u_16V_X7R_04

PJ9 1mm

1 2

R230 20K_1%_04

PC232

2200p_50V_X7R_04

C660180p_50V_NPO_04

PJ40 CV-40mil

1 2

PR270 *6.8K_1%_04

PC73*0.1u_10V_X7R_04

PJ39 *1mm

1 2

PR286

10K_1%_04

C632

1u_6.3V_X5R_02

R238

*100_04

PR287

4.99K_1%_04

U15

TC7SZ08FU

1

2

5

4

3

R210

*100K_04

PR269 15K_1%_04

PR274

*10K_1%_04

PR283 *10K_1%_04

PC248

680p_50V_X7R_04

PU22

AOZ2261NQI-11

1

PGOOD

2

EN/DSG

3

PFM*

4

AGND

5

FB

6

TON

7

VIN

8

VIN

9

VIN

10

SW

11

SW

12

PGND

13

PGND

14

PGND

15

PGND

16

SW

17

SW

18

SW

19

ISET

20

BST

21

VCC

22

VIN

23

SS

24

VIN

25

SW

PC229

0.1u_16V_X7R_04

VOUT1_U140

VCCSTG_EN

VCCSTG_EN

1.8VA_PGD

8A

PS_1V8_PFM

Sheet 53 of 67

1.05DX_VCCSTG/ VCCSFR_OC

1.05DX_VCCSTG/VCCSFR_OC

B.Schematic Diagrams

B - 54 1.05DX_ VCCSTG/VCCSFR_OC
