Preface
R&TTE Directive
This device is in compliance with the essential requirements and other relevant provisions of the R&TTE Directive 1999/5/EC.
This device will be sold in the following EEA countries: Austria, Italy, Belgium, Liechtenstein, Denmark, Luxembourg, Finland, Netherlands, France, Norway, Germany, Portugal, Greece, Spain, Iceland, Sweden, Ireland,
United Kingdom, Cyprus, Czech Republic, Estonia, Hungary, Latvia, Lithuania, Malta, Slovakia, Poland, Slovenia.
ErP Off Mode Power Consumption Statement:
The figures below note the power consumption of this computer in compliance with European Commission (EC)
regulations on power consumption in off mode:
•Off Mode < 0.5W
II
Preface
CE Marking
This device has been tested to and conforms to the regulatory requirements of the European Union and has attained CE Marking. The CE Mark is a conformity marking consisting of the letters “CE”. The CE Mark applies
to products regulated by certain European health, safety and environmental protection legislation. The CE Mark
is obligatory for products it applies to: the manufacturer affixes the marking in order to be allowed to sell his
product in the European market.
This product conforms to the essential requirements of the R&TTE directive 1999/5/EC in order to attain CE
Marking. A notified body has determined that this device has properly demonstrated that the requirements of the
directive have been met and has issued a favorable certificate of expert opinion. As such the device will bear the
notified body number 0560 after the CE mark.
The CE Marking is not a quality mark. Foremost, it refers to the safety rather than to the quality of a product.
Secondly, CE Marking is mandatory for the product it applies to, whereas most q uality marking s are vo lu ntary.
III
Preface
FCC Statement
(Federal Communications Commission)
You are cautioned that changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
•Re orient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the service representative or an experienc ed radio/TV technician for help.
Operation is subject to the following two conditions:
1.This device may not cause interference.
And
2.This device must accept any interference, including interfer ence that may cause undesired operation of the
device.
IV
Preface
Warning
Use only shielded cables to connect I/O devices to this equipment. You are cautioned that changes or modifications not expressly approved by the manufacturer for compliance with the above standard s could void your authority to operate the
equipment.
FCC RF Radiation Exposure Statement:
1.This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
2.This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator
and your body.
V
Preface
IMPORTANT SAFETY INSTRUCTIONS
Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury
to persons when using any electrical equipment:
1.Do not use this product near water, for example n ear a ba th tub, wash bowl, kitchen sink or laundry tu b, in a wet
basement or near a swimming pool.
2.Avoid using this equipment with a telephone line (other than a cordless type) during an electrical storm. There
may be a remote risk of electrical shock from lightning.
3.Do not use the telephone to report a gas leak in the vicinity of the leak.
4.Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may
explode. Check with local codes for possible special disposal instructions.
5.This product is intended to be supplied by a Listed Power Unit:
•Full Range AC/DC Adapter – AC in 100 - 240V, 50 - 60Hz DC Output 19.5V, 6.15A (120 Watts) minimum
VI
Preface
Instructions for Care and Operation
The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions:
1.Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged.
Do not expose the computer
to any shock or vibration.
Do not place it on an unstable
surface.
Do not place anything heavy
on the computer.
2.Keep it dry, and don’t overheat it. Keep the computer and power supply away from any kind of heating ele-
ment. This is an electrical appliance. If water or any other liquid gets into it, the computer could be badly damaged.
Do not expose it to excessive
heat or direct sunlight.
Do not leave it in a place where
foreign matter or moisture may
affect the system.
Don’t use or store the computer
in a humid environment.
Do not place the computer on
any surface that will block the
Vents/Fan Intakes.
VII
Preface
3.Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other
strong magnetic fields. These can hinder proper performance and damage your data.
4.Follow the proper workin g procedu res for t he computer. Shut the computer down properly and don’t forget
to save your work. Remember to periodically save your data as data may be lost if the battery is depleted.
Do not turn off the power until
you properly shut down all programs.
Do not turn off any peripheral
devices when the computer is
on.
5.Take care when using peripheral devices.
Use only approved brands of
peripherals.
VIII
Do not disassemble the computer by yourself.
Unplug the power cord befor e
attaching peripheral devices.
Perform routine maintenance
on your computer.
Servicing
Bottom Cover Removal Warning
Users should not remove any cover(s) and /or screw(s) for the purposes of device upgrade as this may violate the terms of
your warranty. If you need to replace/remove the hard disk/RAM/optical device etc., for any reason, please contact your distributor/supplier for further information.
Removal Warning
When removing any cover(s) and screw(s) for the purposes of device upg rade, remember to replace the cover(s) and
screw(s) before restoring power to the system.
Also note the following when the cover is removed:
•Hazardous moving parts.
•Keep away from moving fan blades.
Do not attempt to service the computer yourself. Doing so may violate your warranty and may expose you and
the computer to electric shock. Refer all servicing to authorized service personnel. Unplug the computer from
the power supply. Then refer servicing to qualified service personnel under any of the following conditions:
•When the power cord or AC/DC adapter is damaged or frayed.
•If the computer has been exposed to rain or other liquids.
•If the computer does not work normally when you follow the operating instructions.
•If the computer has been dropped or damaged (do not touch the poisonous liquid if the LCD panel breaks).
•If there is an unusual odor, heat or smoke coming from your computer.
Preface
IX
Preface
Power Safety Warning
Before you undertake
any upgrade procedures, make sure that
you have turned off the
power, and disconnected all peripherals and
cables (including telephone lines and power
cord).
You must also remove
your battery in order to
prevent accidentally
turning the machine on.
Before removing the
battery disconnect the
AC/DC adapter from
the computer.
Power Safety
The computer has specific power requirements:
• Only use a power adapter approved for use with this computer.
• Your AC/DC adapter may be designed for international travel but it still requires a
steady, uninterrupted power supply. If you are unsure of your local power specifications, consult your service representative or local power company.
• The power adapter may have either a 2-prong or a 3-prong grounded plug. The third
prong is an important safety feature; do not defeat its purpose. If you do not have access
to a compatible outlet, have a qualified electrician install one.
• When you want to unplug the powe r co rd, be sure to di sconn ect it b y the plug head , no t
by its wire.
• Make sure the socket and any extension cord(s) you use can support the total current
load of all the connected devices.
• Before cleaning the computer, make sure it is disconnected from any external power
supplies (i.e. AC/DC adapter or car adapter).
Do not plug in the power
cord if you are wet.
Do not use the power cord if
it is broken.
Do not place heavy objects
on the power cord.
X
Preface
Polymer/Lithium-Ion Battery Precautions
Note the following information which is specific to Polymer/Lithium-Ion batteries only, and where applicable,
this overrides the general battery precaution information overleaf.
•Polymer/Lithium-Ion batteries may experience a slight expansion or swelling, however this is part of the battery’s
safety mechanism and is not a cause for concern.
•Use proper handling procedures when using Polymer/Lithium-Ion batteries. Do not use Polymer/Lithium-Ion batteries
in high ambient temperature environments, and do not store unused batteries for extended periods.
•If you are working in areas of low temperature use the AC/DC adapter to power the computer.
See also the general battery precautionary information overleaf for further information.
XI
Preface
Battery Disposal & Caution
The product that you have purchased contains a rechargeable battery. The battery is recyclable. At the end of its useful life,
under various state and local laws, it may be illegal to dispose of this battery in to the municipal waste stream. Check with
your local solid waste officials for details in your area for recycling options or proper disposal.
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalen t type recommended by the
manufacturer. Discard used battery according to the manufacturer’s instructions.
General Battery Precautions
•Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer.
•Do not remove any batteries from the computer while it is powered on.
•Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even
if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly
result in fire.
•If you do not use the battery for an extended period, then remove the battery from the computer for storage.
•Recharge the batteries using the notebook’s system. Incorrect recharging may make the battery explode.
•Do not try to repair a battery pack. Refer any battery pack repa ir or replacemen t to you r service repre sentati ve or qu alified service personnel.
•Keep children away from, and promptly dispose of a damaged battery. Always dispose of batteries carefully. Batteries
may explode or leak if exposed to fire, or improperly handled or discarded.
•Keep the battery away from metal appliances.
•Affix tape to the battery contacts before disposing of the battery.
•Do not touch the battery contacts with your hands or metal objects.
XII
Preface
Power Off Before Traveling
Make sure that your notebook is completely powered off before putting it into a travel bag (or any such container). Putting a
notebook which is powered on in a travel bag may cause the Vents/Fan Intakes to be blocked. To pre vent your computer
from overheating make sure nothing blocks the Vent/Fan Intakes while the computer is in use.
Cleaning
Do not apply cleaner directly to the computer; use a soft clean cloth.
Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer.
Travel Considerations
As you get ready for your trip, run through this list to make sure the system is ready to go:
1.Check that the battery pack and any spares are fully charged.
2.Power off the computer and peripherals.
3.Close the display panel and make sure it’s latched.
4.Disconnect the AC/DC adapter and cables. Stow them in the carrying bag.
5.The AC/DC adapter uses volt ages from 100 to 240 volt s so you won’t need a second volt age adapter. However,
check with your travel agent to see if you need any socket adapters.
6.Put the notebook in its carrying bag and secure it with the bag’s straps.
7.If you’re taking any perip herals (e.g. a printer, mouse or digital camera), pack them and those devices’ adapters
and/or cables.
8.Anticipate customs - Some jurisdictions may have import restrictions or req uire proof of ownersh ip for both hard -
ware and software. Make sure your “papers” are handy.
XIII
Preface
Power Off Before Traveling
Make sure that your notebook is completely powered off before putting it into a travel bag (or any such container). Putting a
notebook which is powered on in a travel bag may cause the vent(s)/fan intake(s)/outlet(s) to be blocked. To prev ent your
computer from overheating make sure nothing blocks the vent(s)/fan intake(s)/outlet(s) while the computer is in use.
Packing
As you get ready for your trip, run through this list to make sure the system is ready to go:
1.Check that the battery pack and any spares are fully charged.
2.Power off the computer and peripherals.
3.Close the display panel and make sure it’s latched.
4.Disconnect the AC/DC adapter and cables. Stow them in the carrying bag.
5.The AC/DC adapter uses volt ages from 100 to 240 volt s so you won’t need a second volt age adapter. However,
check with your travel agent to see if you need any socket adapters.
6.Put the notebook in its carrying bag and secure it with the bag’s straps.
7.If you’re taking any perip herals (e.g. a printer, mouse or digital camera), pack them and those devices’ adapters
and/or cables.
8.Anticipate customs - Some jurisdictions may have import restrictions or require proof of ownership for both
hardware and software. Make sure your documents are prepared.
XIV
Preface
On the Road
In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting,
keep these points in mind:
Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very
common. Don’t check it with “normal” luggage. Baggage handlers may not be sufficiently careful. Avoid knocking the computer against hard objects.
Beware of Electromagnetic fields - Devices such as metal detectors & X-ray machines can damage the computer, hard disk, floppy disks, and other media. They may also destroy any stored data - Pass your computer and
disks around the devices. Ask security officials to hand-inspect them (you may be asked to turn it on). Note:
Some airports also scan luggage with these devices.
Fly safely - Most airlines have regulations about the use of computers and other electronic devices in flight.
These restrictions are for your safety, follow them. If you stow the notebook in an overhead compartment, make
sure it’s secure. Contents may shift and/or fall out when the compartment is opened.
Get power where you can - If an electrical outlet is available, use the AC/DC adapter and keep your battery(ies)
charged.
Keep it dry - If you move quickly from a cold to a warm location, water vapor can condense inside the computer.
Wait a few minutes before turning it on so that any moisture can evaporate.
XV
Preface
Developing Good Work Habits
Developing good work habits is important if you need to work in fron t of the computer for long periods of time.
Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or
other joints. The following are some tips to reduce the strain:
•Adjust the height of the chair and/or desk so that the keyboard is at or slightly below the
level of your elbow. Keep your forearms, wrists, and hands in a relaxed position.
•Y our knees sho uld be sligh tly higher th an your hips. Place yo ur feet flat on the floor or on
a footrest if necessary.
•Use a chair with a back and adjust it to support your lower back comfortably.
•Sit straight so that your knees, hips and elbows form approximately 90-degree angles
when you are working.
•Take periodic breaks if you are using the computer for long periods of time.
Remember to:
•Alter your posture frequently.
•Stretch and exercise your body several times a day.
•Take periodic breaks when you work at the computer for long periods of time. Frequent
and short breaks are better than fewer and longer breaks.
XVI
Preface
Lighting
Proper lighting and a comfortable viewing angle can reduce eye strain and shoulder and neck muscle fatigue.
•Position the display to avoid glare or reflections from overhead lighting or outside sources of light.
•Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly.
•Position the display directly in front of you at a comfortable viewing distance.
•Adjust the display-viewing angle to find the best position.
LCD Screen Care
To prevent image persistence on LCD monitors (caused by the continuous display of graphics on the screen for
an extended period of time) take the following precautions:
•Set the Windows Power Plans to turn the screen off after a few minutes of screen idle time.
•Use a rotating, moving or blank screen saver (this prevents an image from being displayed too long).
•Rotate desktop background images every few days.
•Turn the monitor off when the system is not in use.
LCD Electro-Plated Logos
Note that in computers featuring a raised LCD electro-plated logo, the logo is covered by a protective adhesive.
Due to general wear and tear, this adhesive may deteriorate over time and the exposed logo may develop sharp
edges. Be careful when handling the computer in this case, and avoid touching the raised LCD electro-plated
logo. Avoid placing any other items in the carrying bag which may rub against the top of the computer during
transport. If any such wear and tear develops contact your distributor/supplier.
Power Safety ................................................................................................................................................X
Not Included ..............................................................................................................................................1-3
System Software ........................................................................................................................................1-4
System Startup ...........................................................................................................................................1-5
Model Differences .....................................................................................................................................1-6
XIX
Preface
LCD Panel Open - Model A ......................................................................................................................1-7
LCD Panel Open - Model B ......................................................................................................................1-8
LCD Panel Open - Model C ......................................................................................................................1-9
LED Indicators .........................................................................................................................................1-10
Illuminated White LED Keyboard ...........................................................................................................1-11
Illuminated Color LED Keyboard ...........................................................................................................1-12
Control Center .........................................................................................................................................1-14
Keyboard Backlight LED ........................................................................................................................1-15
Function Keys & Visual Indicators .........................................................................................................1-24
Front & Rear Views - All Models ...........................................................................................................1-25
Right Views .............................................................................................................................................1-26
Left Views ...............................................................................................................................................1-27
3G/4G Module USIM Card Installation (for Models A & B) .................................................................1-29
Bottom View - Model A ..........................................................................................................................1-32
Bottom View - Model B ..........................................................................................................................1-33
Bottom View - Model C ..........................................................................................................................1-34
Windows 10 Start Menu ..........................................................................................................................1-35
Right-Clicking the Windows Logo In Start Menu ..................................................................................1-36
XX
Preface
Start Menu Apps & Tiles .........................................................................................................................1-37
Windows 10 Control Panel ......................................................................................................................1-39
Windows 10 Taskbar ...............................................................................................................................1-41
Video Features .........................................................................................................................................1-42
Microsoft Hybrid Graphics ......................................................................................................................1-42
Power Options .........................................................................................................................................1-48
Audio Features ...........................................................................................................................................2-4
Setup for Audio Recording ........................................................................................................................2-5
Touchpad and Buttons/Mouse ...................................................................................................................2-6
The Power Sources ....................................................................................................................................3-2
Turning On the Computer ..........................................................................................................................3-3
Shutting the Computer Down ....................................................................................................................3-4
Power Plans ...............................................................................................................................................3-5
Power-Saving States ..................................................................................................................................3-7
Shut down ..................................................................................................................................................3-8
Configuring the Power Buttons .................................................................................................................3-9
Power Conservation Modes .....................................................................................................................3-12
Settings Menu Power Controls ................................................................................................................3-14
Battery Information .................................................................................................................................3-17
Battery Power ..........................................................................................................................................3-17
Conserving Battery Power .......................................................................................................................3-18
Battery Life ..............................................................................................................................................3-19
New Battery .............................................................................................................................................3-19
Recharging the Battery with the AC/DC Adapter ...................................................................................3-19
Proper handling of the Battery Pack ........................................................................................................3-20
What to Install ............................................................................................................................................4-1
User Account Control ................................................................................................................................4-6
Windows Security Message .......................................................................................................................4-6
New Hardware Found ................................................................................................................................4-6
Video (VGA) .............................................................................................................................................4-7
NVIDIA Video (VGA) ..............................................................................................................................4-7
LAN ...........................................................................................................................................................4-7
Control Center ...........................................................................................................................................4-8
MEI Driver .................................................................................................................................................4-8
The Power-On Self Test (POST) ...............................................................................................................5-2
Failing the POST .......................................................................................................................................5-3
The Setup Utility ........................................................................................................................................5-4
Main Menu .................................................................................................................................................5-6
SATA Port # (Main Menu) ........................................................................................................................5-6
Advanced Menu .........................................................................................................................................5-8
Advanced Chipset Control (Advanced Menu) ..........................................................................................5-8
GPU Performance Scaling (Advanced Menu > Advanced Chipset Control) ............................................5-8
FlexiCharger (Advanced Menu > Advanced Chipset Control) .................................................................5-9
Software Guard Extensions (Advanced Menu > Advanced Chipset Control) ..........................................5-9
VT-d (Advanced Menu > Advanced Chipset Control) ..............................................................................5-9
SATA Mode (Advanced Menu) ..............................................................................................................5-10
XXIV
Preface
Power On Boot Beep (Advanced Menu) .................................................................................................5-10
Security Menu ..........................................................................................................................................5-11
Set Supervisor Password (Security Menu) ..............................................................................................5-11
Set User Password (Security Menu) ........................................................................................................5-12
Password on boot: (Security Menu) ........................................................................................................5-12
Secure Boot Control (Security Menu) .....................................................................................................5-13
Boot Menu ...............................................................................................................................................5-15
Exit Menu ................................................................................................................................................5-17
Sound Blaster Cinema 3 SBX Pro Studio ................................................................................................6-23
PC Camera ...............................................................................................................................................6-28
Camera App .............................................................................................................................................6-29
Taking Pictures/Capturing Video ............................................................................................................6-31
Basic Hints and Tips ..................................................................................................................................7-2
Backup and General Maintenance .............................................................................................................7-3
Ports and Jacks ..........................................................................................................................................A-2
DC-In Jack ................................................................................................................................................A-2
External Monitor (VGA) Port ...................................................................................................................A-2
HDMI-Out Port .........................................................................................................................................A-2
Headphone-Out Jack .................................................................................................................................A-2
Microphone-In Jack ..................................................................................................................................A-3
Mini DisplayPort 1.2 ................................................................................................................................A-3
RJ-45 LAN Jack .......................................................................................................................................A-3
USB 2.0/1.1 Port .......................................................................................................................................A-4
XXVII
Preface
USB 3.0 (USB 3.1 Gen 1 Type A) Port ....................................................................................................A-4
USB 3.0 (USB 3.1 Gen 1 Type C) Port ....................................................................................................A-4
Control Center ..........................................................................................................................................B-1
Power Modes ............................................................................................................................................B-3
Control Center Menus ...............................................................................................................................B-4
Power Status (System Program) .............................................................................................................B-5
Language Interface ...................................................................................................................................B-9
Video Driver Installation ..........................................................................................................................C-1
Video (VGA) ............................................................................................................................................C-1
NVIDIA Video (VGA) .............................................................................................................................C-1
Microsoft Hybrid Graphics .......................................................................................................................C-2
XXIX
Preface
Intel® Dynamic Video Memory Technology ...........................................................................................C-4
Configure Other Displays Using Project ..................................................................................................C-5
Configuring an External Display In Windows .........................................................................................C-6
Communication .........................................................................................................................................D-3
Operating System ......................................................................................................................................D-3
Features (Depends on Model Type) .........................................................................................................D-3
Power Management ..................................................................................................................................D-4
Power ........................................................................................................................................................D-4
This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the
computer and to getting your system started. The remainder of the manual covers the following:
• Chapter 2A guide to using some of the main features of the computer e.g. the storage devices (hard disk and
card reader), TouchPad & Mouse and Audio Features.
• Chapter 3 The computer’s power management options.
• Chapter 4The installation of the drivers and utilities essential to the operation or improvement of some of the
computer’s subsystems.
• Chapter 5An outline of the computer’s built-in software or BIOS (Basic Input Output System).
• Chapter 6 A quick guide to the computer’s PC Camera, Wireless LAN, Bluetooth & WLAN Combo, Sound Blaster Audio and Intel modules (some of which may be optional depending on your pur-
chase configuration).
• Chapter 7 A troubleshooting guide.
• Appendix A Definiti ons of the interface, ports/jacks which allow your computer to c ommun icat e with ex te rnal
devices.
• Appendix B Information on the Control Center .
• Appendix C Information on the Video driver controls.
• Appendix D The computer’s specification.
1
Overview 1 - 1
1
Notes
Check the light colored
boxes with the mark
above to find detailed
information about the
computer’s features.
Quick Start Guide
Advanced Users
If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful
to refer to “Drivers & Utilities” on page 4 - 1 and “BIOS Utilities” on page 5 - 1 in the User’s Manual. You
may also find the notes marked with a
of interest to you.
Beginners and Not-So-Advanced Users
If you are new to computers (or do not have an advanced knowledge of them) then
the information contained in this Quick Start Guide should be enough to get you up
and running. Eventually you should try to look through all the documentation (more
detailed descriptions of the functions, setup and system controls are covered in the
remainder of the User’s Manual), but do not worry if you do not understand everything the first time. Keep this manual nearby and refer to it to learn as you go. You
may find it useful to refer to the notes marked with a
as indicated in the margin.
For a more detailed description of any of the interface ports and jacks see “Interface
(Ports & Jacks)” on page A - 1.
Warning Boxes
No matter what your level please pay careful attention to the warning and safety information indicated by the
symbol. Also please note the safety and handling instructions as indicated in the Preface.
1 - 2 Overview
Quick Start Guide
Drivers
If you are installing new system software, or are re-configuring your computer for a different system, you will need to install
the appropriate drivers. Drivers are programs which act as an interface between the computer and a hardware component
e.g. a wireless network module. It is very important that you install the drivers in the order listed in Table 4 - 1, on page 4
- 4. You will be unable to use most advanced controls until the necessary drivers and utilities are properly installed. If your
system hasn’t been properly configured (your service representative may have already done that for you), refer to “Drivers
& Utilities” on page 4 - 1 for installation instructions.
Ports and Jacks
See “Ports and Jacks” on page A - 2 for a description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc.
Not Included
Operating Systems (e.g. Windows 10) and applications (e.g. word processing, spreadsheet and database programs) have their own manuals, so please consult the appropriate manuals.
1
Overview 1 - 3
1
Windows OS
Note that the information included on the following pages is for Windows 10 only.
In order to run Windows 10 (64-bit) your computer requires a minimum 4GB of system memory (RAM).
Quick Start Guide
System Software
Your computer may already come with system software pre-installed. Where this is not the case, or where you
are re-configuring your computer for a different system, you will find the Windows 10 (64-bit) operating system
is supported.
1 - 4 Overview
Quick Start Guide
135°
Shutdown
Note that you should
always shut your
computer down by
choosing the Shut
Down command in
Windows (see page
1 - 48). This will help
prevent hard disk or
system problems.
Figure 1 - 1 - AC/DC Adapter In / Opening the Lid/LCD
135°
System Startup
1. Remove all packing materials, and place the computer on a stable surface, and securely attach any peripherals you want to
use with the notebook (e.g. keyboard and mouse) to their ports.
2. Attach the AC/DC adapter to the DC-In jack on the left of the computer, then plug the AC power cord into an outlet, and
connect the AC power cord to the AC/DC adapter (make sure you use the adapter when first setting up the computer, as
to safeguard the computer during shipping, the battery will be locked to not power the system until first connected to the AC/
DC adapter).
3. Use one hand to raise the
hand to support the base of the computer (Note: Never lift the computer by the lid/LCD).
4. Press the power button on the top of the computer for about 2 - 3 seconds to turn the computer “on” (note that the power
LED on the front of the computer will turn from orange to green when the computer powers on).
lid/LCD to a comfortable viewing angle (it is preferable not to exceed 135 degrees);
use the other
1
System Startup 1 - 5
1
Quick Start Guide
Model Differences
This notebook series includes three different models that vary slightly in design style, color and general appearance. Note that though your computer may look slightly different from that pictured throughout this manual, all
ports, jacks (other than those indicated below and in specification) and general functions are the same for all the
design styles (see Appendix D for further details).
Note that the Touchpad/
Clickpad and Buttons has
a valid operational area
indicated within the dotted lines above.
*A colored LED keyboard is available as an
option for this model.
4
6
Wireless Device
Operation Aboard
Aircraft
The use of any portable electronic transmission devices
(e.g. WLAN, Bluetooth or 3G/
4G) aboard aircraft is usually
prohibited. Make sure any
wireless modules are OFF (i.e.
the system is in AirplaneMode) if you are using the
computer aboard aircraft.
Use Fn + F11 Airplane Mode
key combination to toggle Airplane Mode On/Off, and check
the LED indicator for the power
status.
5
7
1
233
Quick Start Guide
1
LCD Panel Open - Model A 1 - 7
1
Figure 1 - 3
LCD Panel Open
Model B
1. Built-In PC Camera
2. PC Camera LED
3. Built-In Array
Microphone
4. LCD
5. Power Button
6. *Illuminated (White)
LED Keyboard
7. TouchPad & Buttons
Note that the Touchpad/
Clickpad and Buttons has
a valid operational area
indicated within the dotted lines above.
*A colored LED keyboard is available as an
option for this model.
4
6
Wireless Device
Operation Aboard
Aircraft
The use of any portable electronic transmission devices
(e.g. WLAN, Bluetooth or 3G/
4G) aboard aircraft is usually
prohibited. Make sure any
wireless modules are OFF (i.e.
the system is in AirplaneMode) if you are using the
computer aboard aircraft.
Use Fn + F11 Airplane Mode
key combination to toggle Airplane Mode On/Off, and check
the LED indicator for the power
status.
5
7
1
233
Quick Start Guide
LCD Panel Open - Model B
1 - 8 LCD Panel Open - Model B
LCD Panel Open - Model C
Figure 1 - 4
LCD Panel Open
Model C
1. Built-In PC Camera
2. PC Camera LED
3. Built-In Array
Microphone
4. LCD
5. Power Button
6. *Illuminated (White)
LED Keyboard
7. TouchPad & Buttons
Note that the Touchpad/
Clickpad and Buttons has
a valid operational area
indicated within the dotted lines above.
*A colored LED keyboard is available as an
option for this model.
4
6
Wireless Device
Operation Aboard
Aircraft
The use of any portable electronic transmission devices
(e.g. WLAN, Bluetooth or 3G/
4G) aboard aircraft is usually
prohibited. Make sure any
wireless modules are OFF (i.e.
the system is in AirplaneMode) if you are using the
computer aboard aircraft.
Use Fn + F11 Airplane Mode
key combination to toggle Airplane Mode On/Off, and check
the LED indicator for the power
status.
5
7
1
233
Quick Start Guide
1
LCD Panel Open - Model C 1 - 9
1
Quick Start Guide
LED Indicators
The LED indicators at the front of the computer display helpful information about the current status of the system.
IconColor Description
OrangeAC/DC Power is Plugged In
GreenThe Computer is On
Blinking GreenThe Computer is in Sleep Mode
OrangeThe Battery is Charging
Blinking OrangeThe Battery has Reached Critically Low Power Status
GreenThe Battery is Fully Charged
GreenAirplane Mode is ON (the WLAN, Bluetooth & 3G/4G Modules are OFF)
GreenHDD Activity
1 - 10 LCD Panel Open - Model C
Table 1 - 2 - LED Indicators
Illuminated White LED Keyboard
Other Keyboards
If your keyboard is damaged or you just want to
make a change, you can
use any standard USB
keyboard. The system will
detect and enable it automatically. However special functions/hot-keys
unique to the system’s
regular keyboard may not
work.
Scr Lk
Hold down the Fn Key
and Scr Lk to enable
scroll lock and check the
LED indicator for status.
Numerical
Play/Pause Key
Function Keys
ScrLk &
NumLk Keys
Fn Key
Keypad
Windows Logo Key
Menu/Application Key
Special Characters
Some software applications allow the number-keys to be used with Alt to produce special characters.
These special characters can only be produced by using the numeric keypad. Regular number keys (in
the upper row of the keyboard) will not work. Make sure that NumLk is on.
The illuminated white LED keyboard has an embedded numerical keypad for easy
numeric data input, and features function keys to allow you to change operational
features instantly. See Table 1 - 6, on page 1 - 24 for full function key combination
details.
Figure 1 - 5 - Illuminated White LED Keyboard
Illuminated White LED Keyboard 1 - 11
Quick Start Guide
1
1
Other Keyboards
If your keyboard is damaged or you just want to
make a change, you can
use any standard USB
keyboard. The system will
detect and enable it automatically. However special functions/hot-keys
unique to the system’s
regular keyboard may not
work.
Scr Lk
Hold down the Fn Key
and Scr Lk to enable
scroll lock and check the
LED indicator for status.
Numerical
Play/Pause Key
Function Keys
Scr Lk Key
Fn Key
Game Control Keys
Num Lk Key
Windows Logo Key
Menu/Application Key
Numerical
Keypad
Special Characters
Some software applications allow the number-keys to be used with Alt to produce special characters.
These special characters can only be produced by using the numeric keypad. Regular number keys (in
the upper row of the keyboard) will not work. Make sure that NumLk is on.
Quick Start Guide
Illuminated Color LED Keyboard
The illuminated colored keyboard has an embedded numerical keypad for easy numeric data input, and features function keys to allow you to change operational features instantly. See Table 1 - 6, on page 1 - 24 for full function key combination
details. and see “Keyboard Backlight LED” on page 1 - 15.
1 - 12 Illuminated Color LED Keyboard
Figure 1 - 6 - Illuminated Color LED Keyboard
Quick Start Guide
Keyboard Application Settings
(Illuminated Keyboard Option)
If your computer includes an illuminated keyboard (factory option), you will need to install the keyboard Con-trol Center application driver and you can then select the type of keyboard as appropriate for your model’s configuration (you can only select keyboards supported by your system). After the driver has been installed, and the
system restarts, the control panel below will pop-up to allow you to select the illuminated white keyboard for
your system. Click Save to retain the setting chosen.
To run the
Control Center
press the Fn +Esc key combination, or
double-click
the icon in
the notification area of the
taskbar.
Close the Control Center by clicking
the close icon in the top right of the
panel (move the cursor onto the top
right corner of the panel to highlight it).
Quick Start Guide
Control Center
When in the Windows Desktop application (not in the Start screen)press the Fn + Esc key combination, or
double-click the icon
trol Center gives quick access to frequently used controls and enables you to quickly turn the camera/Touch
Pad on/off (see Appendix B for full details).
1 - 14 Control Center
in the notification area of the taskbar to toggle the Control Center on/off. The Con-
Figure 1 - 8 - Control Center
Quick Start Guide
2
1
1
23
4
1
2
3
4
Keyboard Backlight LED
(For Illuminated Colored Keyboards Only)
Press Fn plus the key to toggle the keyboard LED on/off. The keyboard LED may be configured using
the Fn + key combination outlined in the table below. In addition press Fn plus the
keyboard backlight application to configure the settings (see overleaf).
Main Keyboard Colored LED Function key Combinations
The Keyboard Backlight application can be accessed by pressing the Fn plus key (or by clicking the
Flexikey button in the Gaming section of the Control Center, and then clicking the Backlight tab).
Figure 1 - 9 - Keyboard Backlight Application
1 - 16 Keyboard Backlight LED
Quick Start Guide
Full Color Swatch256 Color Scheme Swatch
Brightness
Click on any of the numbers (0 - 3) on the brightness bar to set the brightness level of the keyboard backlight.
Color Swatch
The color swatch in the top right of the screen allows you to select a range of colors for your keyboard backligh t
by clicking on the color required. You can choose to display the swatch either in Full Color or as a 256 ColorScheme. Click the Custom mode button to select any colors from the swatch and to apply your chosen colors
to parts of the keyboard (and Top Case Logo LED if applicable).
1
Figure 1 - 10 - Keyboard Backlight Color Swatches
Keyboard Backlight LED 1 - 17
1
Illumination Keys
Note that the keyboard illumination (increase/decrease)
keys may be used to configure the keyboard LED in Cus-
tom Mode only.
Quick Start Guide
Modes
The buttons surrounding the swatch allow you to alter the effects of the keyboard backligh t. Click on any of the
buttons to view the effects on the keyboard. Click Save when exiting the application to retain the setting.
Mode Buttons
Random Color
Custom - Display & Configure
Keyboard Sections & Colors
Breathe (All Colors)
Cycle Colors
1 - 18 Keyboard Backlight LED
Wave Up/Down
Dancing Effect
Tempo Beat
Flashing
Table 1 - 4 - Mode Buttons
Quick Start Guide
Preview
The bottom left section of the application allows you to preview setting changes made to colors on the keyboard.
Keyboard LED Sections
The bottom right section of the application allows you to select partial areas, or all, of the keyboard on which to
apply the color changes and effects.
1
Figure 1 - 11 - Preview & Keyboard LED Sections
Keyboard Backlight LED 1 - 19
1
Quick Start Guide
Sets
The application allows you to save up to 3 sets of color and effect combinations. Click Save when exiting the
application to retain the settings.
Figure 1 - 12 - Sets
Save & Exit
Click Exit to quit the application without saving, or Save to exit and retain the settings.
Figure 1 - 13 - Save & Exit
1 - 20 Keyboard Backlight LED
Quick Start Guide
Flexikey® Enabled
Flexikey® Disabled
Flexikey® Application
The Flexikey® application is a quick hotkey configuration application, which allows you to assign a single key
to launch multiple key combinations, or to launch programs and applications, to create text macros and to
disable certain keys. The application can also be used to configure the mouse buttons to create hotkeys for
gaming etc. All the configuration settings are retained under (up to12) profiles to which the settings are applied.
Click Flexikey® in the Gaming section of the Control Center, or the click the icon in the noti fication
area of the taskbar, to launch the application (see Appendix B for full details).
1
Figure 1 - 14 - Flexikey® Hotkey Application
Flexikey® Application 1 - 21
1
Quick Start Guide
Flexikey® Application Features:
For full details see “Flexikey® Application” on page B - 8.
•EXPRESS KEY - This feature allows you to configure a single key (or mouse click) to send multiple key
combinations, or to create more useful shortcut keys This is useful in gaming or when using applications
which have a complex set of keyboard shortcuts.
•LAUNCH APP - This simply assigns single keys (or mouse clicks) to launch any program’s or applica-
tion’s executable file.
•EXPRESS TEXT - With this you can assign single keys (or mouse clicks) to send commonly used strings
of text.
•DISABLE - Use this function to disable any keyboard keys or mouse buttons.
•STATISTICS - Use this to quickly record keys in use in any application, and to disable unused keys.
1 - 22 Flexikey® Application
Keyboard Shortcuts
Windows Logo
Keyboard Shortcut
Use the Windows logo
key + D key com-bination to switch between the Start screen
and Windows Desktop.
Menu/Application
Keyboard Shortcut
When the Desktop app
is running you can use
the Menu/Application
key on the keyboard to display the
context menu as per a
mouse right-click.
The following Windows Logo Key (Winkey) keyboard shortcuts are useful for navigation/operation in
Windows 10
.
Quick Start Guide
1
Windows Logo
+ Number (1, 2, etc)Launch an application from the taskbar (numbered from left to right)
Key +
Tap WinkeyToggle the Start menu
AOpen the Action Center
BSelect the Taskbar Notification Area
C Launch Cortana (in listening mode)
DToggle the Desktop
ELaunch File Explorer (Quick Access tab)
Description
Table 1 - 5 - Keyboard Shortcuts
Flexikey® Application 1 - 23
1
Quick Start Guide
Function Keys & Visual Indicators
The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down.
To prevent your computer from overheating
make sure nothing
blocks the vent(s)/fan intake(s) while the computer is in use.
1
2
1
Model A
Model B
2
22
Model A
Model B
Model C
Model C
1
22
Quick Start Guide
1
Front & Rear Views - All Models 1 - 25
1
Figure 1 - 16
Right Views
1. Headphone Jack
2. Microphone Jack
3. 1 * USB 2.0 Port
4. 1 * Type-A USB 3.0
Port (USB 3.1 Gen1)
5. Vent/Fan Intake
6. Security Lock Slot
(Models A & B Only)
USB Ports
Note that the connections to the USB ports
only fit one way, do not
force them.
1342
5
USB 3.0 (USB 3.1, Gen1) Type A OR C Ports OR USB 2.0 Port
This model includes 3 * USB 3.0 (USB 3.1, Gen1 ports) ports and 1* USB 2.0 port. The USB 2.0 port
is the larger black port
. The Type-A USB 3.0 (USB 3.1, Gen 1 ports) ar e the larger blue color ports.
The Type-C USB 3.0 (USB 3.1, Gen 1 ports) is the smaller black port. 2 * USB 3.1 (Gen 2) ports are
available as a factory option (see page
A - 4).
6
Model A
Model C
1342
5
6
Model B
1342
5
Quick Start Guide
Right Views
1 - 26 Right Views
Left Views
Figure 1 - 17
Left Views
1. D C-I n Jack
2. R J-4 5 LAN Jack
3. Mini DisplayPort 1
4. Mini DisplayPort 2
5. HDMI-Out Port
6. 1 * Type-C USB 3.0
Port (USB 3.1 Gen1)
7. 1 * Type-A USB 3.0
Port (USB 3.1 Gen1)
8. Multi-In-1 Card
Reader
9. Security Lock Slot
(Model C Only)
HDMI Port
Note that the HDMI Port support
video and audio signals to attached external displays.
Note that Sound Blaster Cine-ma audio will be disabled when
you are connecting to an external display through an HDMI
connection.
5
2
6
Multi-in-1 Card Reader
The card reader allows you to use the most popular digital storage card formats:
MMC (MultiMedia Card) / RSMMC
SD (Secure Digital) / Mini SD / SDHC / SDXC
USB 3.0 (USB 3.1, Gen1) Type A OR C Ports OR USB 2.0 Port
This model includes 3 * USB 3.0 (USB 3.1, Gen1 ports) ports and 1* USB 2.0 port. The USB 2.0 port
is the larger black port
. The Type-A USB 3.0 (USB 3.1, Gen 1 ports) are the larger blue color ports.
The Type-C USB 3.0 (USB 3.1, Gen 1 ports) is the smaller black port. 2 * USB 3.1 (Gen 2) ports are
available as a factory option (see page
A - 4).
7
8
Model A
Model B
1
3
5
2
6
7
8
1
3
Model C
4
4
5
2
6
7
8
1
34
9
Quick Start Guide
Left Views 1 - 27
1
1
Mini Display Ports / HDMI Port
Depending on the port being connected to, external displays can be configured using either the Intel HD Graphics control panel, Project menu (press the Windows logo key on your keyboard and the P key), Display Settings or NVIDIA
Control Panel.
Mini Display Port 1 ; If you wish to configure an external display connected to Mini Display Port 1 you must use the
Intel HD Graphics control panel menu to configure the display configuration.
Mini Display Port 2 : If you wish to configure an external display connected to Mini Display Port 2 you must use Project Menu, Display Settings in Windows (see Figure C - 4 on pag e C - 8) or the NVIDIA Control Panel (see “NVIDIA
Control Panel” on page C - 34) to configure the display configuration.
HDMI Port : If you wish to configure an external display connected to the HDMI Port you must use the Intel HD Graphics control panel menu to configure the display configuration.
In a multiple display environment, external displays connected to Mini Display Port 2 will be in Extended mode only.
See Appendix C for full information on external display configuration.
Figure 1 - 18 - Left Side View (Mini Display Ports & HDMI Port Highlighted) - Single Model Pictured
123
2
12
3
Quick Start Guide
1 - 28 Left Views
3G/4G Module USIM Card Installation (for Models A & B)
Power Safety
Warning
Before you undertake any
installation procedures,
make sure that you have
turned off the power, and
disconnected all peripherals and cables (including
telephone lines).
Figure 1 - 19
Battery Removal &
USIM Card Insertion
1223456
1
2
3
4
5
6
Follow the instructions below to install the USIM card (which will be supplied by
your service provider) which requires the removal of the battery first.
1.Turn the computer off, and turn it over.
2.Slide the latch in the direction of the arrow, and then slide latch in the
direction of the arrow and hold it in place.
3.While holding the latch in place, pull the battery up at point
the arrow to remove the battery .
4.Insert the USIM card (see overleaf).
5.Reinsert the battery (see page 1 - 31).
Quick Start Guide
1
in the direction of
3G/4G Module USIM Card Installation (for Models A & B) 1 - 29
1
USIM Card
Orientation
Note that the USIM
card’s readable side
(with the gold-colored
contacts) should face
downwards as illustrated.
Figure 1 - 20
USIM Card Insertion
1
USIM Card Ejection
Simply press on the USIM card to eject it, however do not do this while a connection is in
progress. If you do eject the card while a 3G/4G connection is ongoing, you will need to shut
down the system, reinsert the USIM card, restart the system and then reestablish the 3G/4G
connection.
If you wish to change USIM cards then you will need to shut the system down, reinsert the
USIM card, restart the system and then reestablish the 3G/4G connection.
1
Quick Start Guide
3G/4G Module USIM Card Installation
Insert the USIM card as illustrated below (pay careful attention to the orientation
of the card as the gold contact side of the card should face downwards) until it clicks
fully into position. To eject the card simply press it until it ejects, but do not attempt
to eject the card while connected to a 3G/4G network (see below).
1 - 30 3G/4G Module USIM Card Installation (for Models A & B)
Battery Insertion
Figure 1 - 21
Battery Insertion
123
1
2
3
1.Orientate the battery as illustrated below and align it with the edges of the battery compartment.
2.Push the battery in the direction of the arr ow
should click into place).
3.Slide the latch in the direction of the arrow into the lock position.
to insert it into the compartment (it
Quick Start Guide
1
3G/4G Module USIM Card Installation (for Models A & B) 1 - 31
1
Figure 1 - 22
Bottom View
Model A
1. Battery
2. Fan Outlet/Intake
3. Speakers
Bottom Cover Removal
Warning
Do not remove any cover(s)
and /or screw(s) for the purposes of device upgrade as
this may violate the terms
of your warranty.
If you need to replace/remove the hard disk/RAM/
optical device etc., for any
reason, please contact your
distributor/supplier for further information.
1
Battery Information
Always completely discharge, then fully charge, a new battery before using it. Completely
discharge and charge the battery at least once every 30 days or after about 20 partial discharges.
2
2
3
3
Overheating
To prevent your computer from overheating
make sure nothing
blocks the vent(s)/fan intake(s) while the computer is in use.
Quick Start Guide
Bottom View - Model A
1 - 32 Bottom View - Model A
Bottom View - Model B
Figure 1 - 23
Bottom View
Model B
1. Battery
2. Fan Outlet/Intake
3. Speakers
Bottom Cover Removal
Warning
Do not remove any cover(s)
and /or screw(s) for the purposes of device upgrade as
this may violate the terms
of your warranty.
If you need to replace/remove the hard disk/RAM/
optical device etc., for any
reason, please contact your
distributor/supplier for further information.
1
Battery Information
Always completely discharge, then fully charge, a new battery before using it. Completely
discharge and charge the battery at least once every 30 days or after about 20 partial discharges.
2
2
33
Overheating
To prevent your computer from overheating
make sure nothing
blocks the vent(s)/fan intake(s) while the computer is in use.
Quick Start Guide
Bottom View - Model B 1 - 33
1
1
Figure 1 - 24
Bottom View
Model C
1. Battery
2. Fan Outlet/Intake
3. Speakers
Battery Removal
Note that the built-in
battery is not user removable. Removing the
battery will violate the
terms of your warranty.
If you need to remove the
battery for any reason,
please contact your distributor/supplier for further information.
1
Battery Information
Always completely discharge, then fully charge, a new battery
before using it. Completely discharge and charge the battery
at least once every 30 days or after about 20 partial discharges.
Overheating
To prevent your computer from overheating
make sure nothing
blocks the vent(s)/fan intake(s) while the computer is in use.
Bottom Cover Removal
Warning
Do not remove any cover(s) and /or screw(s) for
the purposes of device
upgrade as this may violate the terms of your
warranty.
If you need to replace/remove the hard disk/
RAM/optical device etc.,
for any reason, please
contact your distributor/
supplier for further information.
3
2
3
2
Quick Start Guide
Bottom View - Model C
1 - 34 Bottom View - Model C
Quick Start Guide
Desktop
Windows 10 Start Menu
Most of the apps, control panels, utilities and programs within Windows 10 can be accessed from the Start
Menu by clicking the icon in the taskbar in the lower left corner of the screen (or by pressing the Windows
Logo Key on the keyboard).
1
Figure 1 - 25 - Windows Start Menu
Windows 10 Start Menu 1 - 35
1
Right-Click Icon
Quick Start Guide
Right-Clicking the Windows Logo In Start Menu
Right-click the Start Menu icon (or use the Windows Logo Key + X key combination) to bring up an
advanced Context Menu of useful features such as Control Panel, Programs and Features, Power Options, Task
Manager, Search, File Explorer, Command Prompt, Device Manager and Network Connections etc.
Figure 1 - 26 - Right-Click Windows Logo in Start Menu
1 - 36 Windows 10 Start Menu
Quick Start Guide
Start Menu Apps & Tiles
The Windows 10 Start Menu will contain a number of apps, and many more will be installed as you add more
applications etc. Not all of these apps can fit on the screen so may need click and drag the handles at the edge of
the screen to expand the menu in order to view all the apps (you can use the scroll bar to mov e up and down the
screen).
1
Figure 1 - 27 - Expanding the Start Menu
Windows 10 Start Menu 1 - 37
1
Quick Start Guide
Pining/Unpinning Apps & Programs to/from the Start Menu
To make things easy to find you can add and remove tiles for apps and programs to the Start Menu. Right-Click
on a program’s icon and select Pin to Start from the drop-down menu. To remove an app or program from the
Start Menu right-click the icon and select Unpin from Start. You can use the same method to pin apps/pro-grams to/from the taskbar (select pin to taskbar/unpin this program from the taskbar).
Figure 1 - 28 - Pin to Start/Unpin from Start
1 - 38 Windows 10 Start Menu
Windows 10 Control Panel
•Right-click the Start Menu icon
in the taskbar in the lower left
corner of the screen and select
Control Panel from the menu.
•Press the Windows logo key
on your keyboard and X to bring
up the context menu, and then
press P to bring up the Control
Panel.
•Type Control Panel into the
Search box in the taskbar and
click on the icon when it pops up.
In many instances throughout this manual you will see an instruction to open the Control Panel. The Control
Panel can be accessed in a number of ways in Windows 10.
Quick Start Guide
1
Figure 1 - 29 - Windows 10 Control Panel Access
Windows 10 Control Panel 1 - 39
1
Quick Start Guide
Settings
The Settings item in the Start Menu (and also as an App) gives you quick access to a number of system settings
control panels allowing you to adjust settings for System, Devices, Network & internet, Personalization, Accounts, Time & language, Ease of Access, Privacy and Update & security.
Figure 1 - 30 - Settings
1 - 40 Windows 10 Control Panel
Quick Start Guide
Taskbar
Taskbar - Pinned Programs and Apps
Notification Area
Windows 10 Taskbar
In many instances throughout this manual you will see an instruction to access the notification area of the taskbar. The notification area of the taskbar in the bottom right of the screen. Some of the Control Panels and appli-
cations referred to throughout the course of this manual can be accessed from here.
Figure 1 - 31 - Taskbar
You can pin/unpin apps to/from the taskbar in much the same way as you can to the Start screen (see “Pining/
Unpinning Apps & Programs to/from the Start Menu” on page 1 - 38).
1
Windows 10 Control Panel 1 - 41
1
Quick Start Guide
Video Features
You can switch display devices, and configure display options, from the Display control panel (in Appearance
and Personalization). Click Adjust resolution to make changes to the appearance of the display and to detect
and configure any attached displays. In Windows 10 it is possible to quickly configure external displays from
the Project menu (
Microsoft Hybrid Graphics
Your computer will feature Microsoft Hybrid Graphics switchable graphics technology. This seamless technology is designed to get best performance from the graphi cs system while allowing longer battery life, without
having to manually change settings. The computer’s operating system (and some applications) will automati-cally switch between the integrated UMA (Unified Memory Architecture) GPU (iGPU) and the discrete GPU
(dGPU) when required by the applications in use. This switch is seamless to the user.
press the Windows logo key on your keyboard and theP key).
The basic video features for this computer can be configured using the Intel
Further video configuration is available through the NVIDA control panel (see the information on the following
pages and Appendix C).
1 - 42 Video Features
® HD Graphics Control Panel.
To Configure Displays using Project
1.Attach your display to the appropriate port, and turn it on.
2.Press the + P key combination.
3.Click on any one of the options from the menu to select PC screen only,
Duplicate, Extend or Second screen only.
4.You can also click Connect to a wireless di splay at the bottom of the
Project screen and follow the steps to connect to any wireless enabled
display.
Intel or NVIDIA Video Driver Controls
More detailed video controls are provided by the Intel/NVIDIA Control Panel
(for more detailed information see Appendix C).
You can also access the control panel by right-clicking the desktop and selecting Intel(R) Graphics Properties/NVIDIA Control Panel.
Quick Start Guide
1
Figure 1 - 32 - Project (Devices)
Video Features 1 - 43
1
2
1
Screen Resolution
1.Use the dropbox to select
the screen Resolution
(Figure 1 - 33).
2.Click Advancedsettings
(Figure 1 - 33) to bring
up the Advanced properties
tabs.
3.Click Apply to save any
changes made.
1
2
Quick Start Guide
To access Display (Control Panel) and Screen Resolution in Windows:
1.Go to the Control Panel.
2.Click Display (icon) - In the Appearance and Personalization category.
3.Make and changes required from the Display, Resolution, Orientation or Multiple display menus.
4.Click Apply to save the settings.
Figure 1 - 33 - Screen Resolution
1 - 44 Video Features
Quick Start Guide
1
2
2
1
Display Settings:
1.You can quickly adjust the display by right-clicking the desktop and selecting Display Settings (Figure 1 -
34).
2.Adjust the settings using the sliders in the menu or click Adv anced display settings (Figure 1 - 34) to
change resolution.
3.Click Apply to save any changes made to resolution.
1
Figure 1 - 34 - Display Settings
Video Features 1 - 45
1
Quick Start Guide
To access the Intel(R) HD Graphics Control Panel:
1.Right-click the desktop and select Intel(R) Graphics Settings from the menu.
OR
2.Click the icon in the notification area of the Desktop taskbar and select Intel(R) Graphics Settings from the
menu.
1 - 46 Video Features
Figure 1 - 35 - Intel® HD Graphics Control Panel
To access the NVIDIA Control Panel:
1
2
1
2
1.Right-click the desktop and select NVIDIA Control Panel (Figure 1 - 36).
OR
2.Double-click the icon (Figure 1 - 36) in the Windows control panel.
Quick Start Guide
1
Figure 1 - 36 - NVIDIA Control Panel
Video Features 1 - 47
1
Using the Power Button
1.Go to the Start Menu.
2.Click the Power button .
3.Select the power state required
from the menu.
Quick Start Guide
Power Options
Power Options (Hardware and Sound) can be accessed from the Control Panel. The Power button item in
Start Menu (or the context menu) may be used to Shut down or Restart (you can also add Hibernate/Sleep tothe menu - see page 1 - 49). To fully control all the power options (including Hibernate mode) go to the Power
Options control panel and configure the power button, sleep button and lid to perform the function selected.
1 - 48 Power Options
Figure 1 - 37 - Shut Down/Restart
Quick Start Guide
Adding Hibernate/Sleep to the Power Men
1.Go to the Power Options (Hardware and Sound)
control panel.
2.Click Choose what the power buttons do.
3.Click “Change settings that are currently unavailable” .
4.Click to put a check in the Hibernate/Sleep box
under Shutdown settings.
5.Click Save Changes and close the control panel.
You can also use the context menu (right-click the Start Menu icon or press the Windows logo + X key
combination) to Sign out, Sleep, Hibernate, Shut down, and Restart.
Figure 1 - 38 - Context Menu Shut Down or sign out
Ctrl + Alt + Delete Key Combination
You can use the CTRL + ALT + DEL key combination to bring up a full-screen displaying Lock, Sign out,
Change a password, Task Manager and Switch User. If you click the Power icon in the lower right corner of
the screen a power management option menu appears to display Sleep, Hibernate, Shut down, and Restart.
1
Power Options 1 - 49
1
Quick Start Guide
Minimum Screen Resolution Settings
1.Windows 10 has minimum screen resolution requirements.
2.Right-click a blank area of the Desktop and select Screen Resolution (or go to the Display control panel).
3.Adjust the Resolution to make sure that it is at least 1024 * 768, although preferably 1366 * 768 or above.
1 - 50 Power Options
Figure 1 - 39 - Screen Resolution
Storage Devices, Mouse, & Audio
Chapter 2: Storage Devices, Mouse, & Audio
Overview
Read this chapter to learn more about the following main features and components
of the computer:
•Hard Disk Drive/Solid State Drive
•Multi-in-1 Card Reader
•Audio Features
•Touchpad and Buttons/Mouse
2
Overview 2 - 1
Storage Devices, Mouse, & Audio
Bottom Cover
Removal Warning
Do not remove any cover(s) and /or screw(s) for
the purposes of device
upgrade as this may violate the terms of your
warranty.
If you need to replace/
remove the hard disk for
any reason, please contact your distributor/supplier for further
information.
2
Hard Disk Drive/Solid State Drive
The hard disk drive (HDD) and/or solid state drive (SSD) is used to store your data
in the computer. The hard disk can be taken out to accommodate other serial (SATA)
hard disk drives (see “Storage” on page D - 2 for specification information), however you will need to contact your distributor/supplier to do this in order to avoid
violating the terms of your warranty.
2 - 2 Hard Disk Drive/Solid State Drive
Storage Devices, Mouse, & Audio
Push-Push Card
Reader
The card reader features a push-in/push-out
card insertion and ejection mechanism. Simply
push the card to insert
and eject it, however Ms
Duo cards require an
adapter.
Figure 2 - 1
Left View
1.Card Reader
•MMC (MultiMedia Card) / RSMMC
•SD (Secure Digital) / Mini SD / SDHC / SDXC
Model A
Model B
1
1
Model C
1
Multi-in-1 Card Reader
The card reader allows you to use some of the latest digital storage cards. Push the
card into the slot and it will appear as a removable device, and can be accessed in
the same way as your hard disk (s). Make sure you install the Card Reader driver
(see “Card Reader” on page 4 - 7).
Note: Some of these cards require PC adapters that are usually supplied with the
cards.
2
Multi-in-1 Card Reader 2 - 3
Storage Devices, Mouse, & Audio
Volume Adjustment
The sound volume level
can be clicking using the
volume control icon
in the notification areaof the taskbar.
Figure 2 - 2
Realtek Audio
Manager
Right-click the icon
to access the menu
above.
See “HDMI Audio Configuration” on page C - 9 for a description of the audio configuration
when connecting an HDMI supported display device.
See “Sound Blaster Cin ema 3” on page 6 - 16 for more information on the Sound Blaster Audio setup.
2
Audio Features
You can configure the audio options on your computer from the Sound control
panel in Windows, or from the Realtek HD Audio Manager icon in the taskbar
notification area/control panel (right-click the taskbar notification area icon to
bring up an audio menu). The volume may also be adjusted by means of the volumeicon in the taskbar or the audio slider in the Settings menu (see sidebar).
2 - 4 Audio Features
Storage Devices, Mouse, & Audio
Device Advanced
Settings
For the purposes of recording it is recommended that you enable
“Separate all input
jacks as independent
input devices” in Device advanced settings .
This will help prevent a
situation where the internal microphone seems to
be disabled, or where
sound can still be heard
from the speakers even
though the headphones
are plugged into the
headphone jack.
Figure 2 - 3
Realtek Audio
Manager - Recording
Setup
Sound Blaster Cinema 3 Audio
Note that you will need to install the
Sound Blaster Cinema 3 audio application in order to get maximum audio
performance. See
“Sound Blaster
Cinema 3” on page 6 - 16.
Setup for Audio Recording
To record audio sources on your computer at optimum quality follow the instructions below:
1.Go to the
2.Click Realtek HD Audio Manager (Hardware and Sound), or right-click the
taskbar icon and select Sound Manager.
3.Click Microphone Effects (tab) in Microphone (tab), and then click to select Noise Suppression (button), or adjust th e Recording Volume level to around 60,
to obtain the optimum recording quality.
4.Click OK to close the control panel and save the settings.
Control Panel
2
.
Audio Features 2 - 5
Storage Devices, Mouse, & Audio
Touchpad Cleaning
In order to improve pad
performance it is necessary to keep the surface
clean and free of fingerprints and marks etc.
Use a soft dry cleaning
cloth to keep the pad
surface clean.
Disabling the Pad
Use the Fn + F1 or Control Center button to disable the Touchpad.
Mouse Driver
If you are using an external
mouse your operating system
may be able to auto-configure
your mouse during its installation or only enable its basic
functions. Be sure to check
the device’s user documentation for details.
2
2 - 6 Touchpad and Buttons/Mouse
Touchpad and Buttons/Mouse
The Touchpad is an alternative to the mouse; however, you can also add a mouse to
your computer through one of the USB ports. The Touchpad buttons function in
much the same way as a two-button mouse. Make sure you have installed the Touchpad driver (see “Touchpad” on page 4 - 8).
Touchpad Sensitivity
The mouse button zones at the bottom of the pad are defined by the line at the bottom of the pad, and the left and right buttons are divided roughly down the middle.
Press the left button zone for a left click, and right button zone for a right click action.
Storage Devices, Mouse, & Audio
Disabling the
Touchpad
If you need to disable
the Touchpad for any
reason (e.g. you may
find that when using
the computer’s internal
keyboard you accidentally trigger the Touchpad when resting your
wrists or palms on it)
you can do so by using
Fn + F1 key combination.
Figure 2 - 4
Mouse Properties
Control Panel -
Buttons
Mouse Properties Control Panel
You can configure the functions from the Mouse control panel in Windows as follows.
1.Right-click the
2.Select Control Panel.
3.Click Mouse (Hardware and Sound > Devices and Printers).
4.Click the menu headings tabs to adjust your mouse preferences.
Start Menu
2
icon.
Mouse Properties Control Panel 2 - 7
Storage Devices, Mouse, & Audio
Figure 2 - 5
Mouse Properties
Control Panels
2
2 - 8 Mouse Properties Control Panel
Storage Devices, Mouse, & Audio
Figure 2 - 6
Settings > Mouse &
touchpad
Mouse & Touchpad Devices
You can also configure the functions from the Mouse & touchpad control panel in
Devices in the Settings control panel as follows.
1.Click the
the Action Center).
2.Click Devices.
3.Click Mouse& touchpad.
Settings
item in the
Start Menu
(this is also as an App or
All Settings
2
in
Mouse & Touchpad Devices 2 - 9
Storage Devices, Mouse, & Audio
Figure 2 - 7
Mouse & Touchpad
(
Touchpad turned off
when mouse
connected
)
2
Touchpad Settings
You can disable the Touchpad by clicking the Touchpad button to turn it off.
You can set the system to automatically disable the internal Touchpad when an ex-
ternal USB point device (e.g a USB mouse) is attached. Click “Leave touchpad onwhen a mouse is connected” to off.
2 - 10 Mouse & Touchpad Devices
Touchapd Taps
Figure 2 - 8
Mouse & Touchpad
Adjust Delay
Make sure “Allow taps on the touchpad” is on if you want to use the tap feature.
The Delay feature helps prevent recognizing taps on the pad by accident, by recog-
nizing when your palm is resting on it or brushing its surface while you are typing.
Use the drop-down menu to either turn of any delay, or to adjust the delay to your
preference.
Storage Devices, Mouse, & Audio
2
Mouse & Touchpad Devices 2 - 11
Storage Devices, Mouse, & Audio
Figure 2 - 9
Mouse & Touchpad
Taps and Gestures
2
You to use a specific gesture or taps on the surface of the pad to perform specific
actions to manipulate documents, objects and applications, and these may be enabled or disabled by clicking on the appropriate button.
2 - 12 Mouse & Touchpad Devices
Storage Devices, Mouse, & Audio
Figure 2 - 10
Scrolling Gesture
Figure 2 - 11
Zooming Gesture
The two-finger tap acts as a right-click mouse action and can bring up context
menus etc.
The two-finger scrolling feature works in most scrollable windows and allows you
to scroll horizontally and vertically. Place two fingers, slightly separated, on the
Touchpad surface and slide both fingers in the direction required (in a straight continuous motion).
The two-finger pinch to zoom gesture can be used to perform the same function as
a scroll wheel in Windows applications that support CTRL + scroll wheel zoom
functionality. Place two fingers on the pad (for best results use the tips of the fingers)
and slide them apart to zoom in, or closer together to zoom out.
2
Mouse & Touchpad Devices 2 - 13
Storage Devices, Mouse, & Audio
Figure 2 - 12
Mouse & Touchpad
Select Actions
Figure 2 - 13
Slide Gesture
2
The three and four-finger taps may be configured may be used to trigger Cortana
Search or the Action Center.
The three finger-drags & slides gesture may be used to enhance navigation with a
variety of applications such as browsing the Internet or scrolling through a photo
viewer.
2 - 14 Mouse & Touchpad Devices
Storage Devices, Mouse, & Audio
Figure 2 - 14
Touchpad
Gestures
The following is an overview of the main gestures you can use with your Touchpad.
2
Mouse & Touchpad Devices 2 - 15
Storage Devices, Mouse, & Audio
2
2-16
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
