Clevo N650DU User guide

V17.1.00-RS2

Preface

Notice

The company reserves the right to revise this publication or to change its contents without notice. Information
contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or
any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear
in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse)
of this publication.
This publication and any accompanying software may not, in whole or in part, be reproduced, translated, trans­mitted or reduced to any machine readable form without prior consent from the vendor, manufacturer or creators
of this publication, except for copies kept by the user for backup purposes.
Brand and product names mentioned in this publication may or may not be copyrights and/or registered trade­marks of their respective companies. They are mentioned for identification purposes only and are not intended
as an endorsement of that product or its manufacturer.
©June 2017

Trademarks

Intel and Intel Core are trademarks/registered trademarks of Intel Corporation.

I

Preface

R&TTE Directive

This device is in compliance with the essential requirements and other relevant provisions of the R&TTE Direc­tive 1999/5/EC.

This device will be sold in the following EEA countries: Austria, Italy, Belgium, Liechtenstein, Denmark, Lux­embourg, Finland, Netherlands, France, Norway, Germany, Portugal, Greece, Spain, Iceland, Sweden, Ireland,
United Kingdom, Cyprus, Czech Republic, Estonia, Hungary, Latvia, Lithuania, Malta, Slovakia, Poland, Slov­enia.

ErP Off Mode Power Consumption Statement:

The figures below note the power consumption of this computer in compliance with European Commission (EC)
regulations on power consumption in off mode:

• Off Mode < 0.5W

II

Preface

CE Marking

This device has been tested to and conforms to the regulatory requirements of the European Union and has at­tained CE Marking. The CE Mark is a conformity marking consisting of the letters “CE”. The CE Mark applies
to products regulated by certain European health, safety and environmental protection legislation. The CE Mark
is obligatory for products it applies to: the manufacturer affixes the marking in order to be allowed to sell his
product in the European market.

This product conforms to the essential requirements of the R&TTE directive 1999/5/EC in order to attain CE
Marking. A notified body has determined that this device has properly demonstrated that the requirements of the
directive have been met and has issued a favorable certificate of expert opinion. As such the device will bear the
notified body number 0560 after the CE mark.

The CE Marking is not a quality mark. Foremost, it refers to the safety rather than to the quality of a product.
Secondly, CE Marking is mandatory for the product it applies to, whereas most q uality marking s are vo lu ntary.

III

Preface

FCC Statement

(Federal Communications Commission)

You are cautioned that changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not in­stalled and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Re orient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the service representative or an experienc ed radio/TV technician for help.

Operation is subject to the following two conditions:

1. This device may not cause interference.
And

2. This device must accept any interference, including interfer ence that may cause undesired operation of the

device.

IV

Preface



Warning

Use only shielded cables to connect I/O devices to this equipment. You are cautioned that changes or modifications not ex­pressly approved by the manufacturer for compliance with the above standard s could void your authority to operate the
equipment.

FCC RF Radiation Exposure Statement:

1. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

2. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This

equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator
and your body.

V

Preface

IMPORTANT SAFETY INSTRUCTIONS

Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury
to persons when using any electrical equipment:

1. Do not use this product near water, for example n ear a ba th tub, wash bowl, kitchen sink or laundry tu b, in a wet

basement or near a swimming pool.

2. Avoid using this equipment with a telephone line (other than a cordless type) during an electrical storm. There

may be a remote risk of electrical shock from lightning.

3. Do not use the telephone to report a gas leak in the vicinity of the leak.

4. Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may

explode. Check with local codes for possible special disposal instructions.

5. This product is intended to be supplied by a Listed Power Unit:

• Full Range AC/DC Adapter – AC in 100 - 240V, 50 - 60Hz DC Output 19V, 4.74A (90 Watts) minimum

This Computer’s Optical Device is a Laser Class 1 Product

VI

Preface

Instructions for Care and Operation

The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions:

1. Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged.

Do not expose the computer
to any shock or vibration.

Do not place it on an unstable
surface.

Do not place anything heavy
on the computer.

2. Keep it dry, and don’t overheat it. Keep the computer and power supply away from any kind of heating ele-

ment. This is an electrical appliance. If water or any other liquid gets into it, the computer could be badly dam­aged.

Do not expose it to excessive

heat or direct sunlight.

Do not leave it in a place where

foreign matter or moisture may

affect the system.

Don’t use or store the computer

in a humid environment.

Do not place the computer on

any surface that will block the

Vents/Fan Intakes.

VII

Preface

3. Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other

strong magnetic fields. These can hinder proper performance and damage your data.

4. Follow the proper workin g procedu res for t he computer. Shut the computer down properly and don’t forget

to save your work. Remember to periodically save your data as data may be lost if the battery is depleted.

Do not turn off the power until
you properly shut down all pro­grams.

Do not turn off any peripheral
devices when the computer is
on.

5. Take care when using peripheral devices.

Use only approved brands of
peripherals.

VIII

Do not disassemble the com­puter by yourself.

Unplug the power cord befor e
attaching peripheral devices.

Perform routine maintenance
on your computer.

Servicing



Bottom Cover Removal Warning

Users should not remove any cover(s) and /or screw(s) for the purposes of device upgrade as this may violate the terms of
your warranty. If you need to replace/remove the hard disk/RAM/optical device etc., for any reason, please contact your dis­tributor/supplier for further information.

Removal Warning

When removing any cover(s) and screw(s) for the purposes of device upg rade, remember to replace the cover(s) and
screw(s) before restoring power to the system.

Also note the following when the cover is removed:

• Hazardous moving parts.

• Keep away from moving fan blades.

Do not attempt to service the computer yourself. Doing so may violate your warranty and may expose you and
the computer to electric shock. Refer all servicing to authorized service personnel. Unplug the computer from
the power supply. Then refer servicing to qualified service personnel under any of the following conditions:

• When the power cord or AC/DC adapter is damaged or frayed.

• If the computer has been exposed to rain or other liquids.

• If the computer does not work normally when you follow the operating instructions.

• If the computer has been dropped or damaged (do not touch the poisonous liquid if the LCD panel breaks).

• If there is an unusual odor, heat or smoke coming from your computer.

Preface

IX

Preface



Power Safety Warning

Before you undertake
any upgrade proce­dures, make sure that
you have turned off the
power, and disconnect­ed all peripherals and
cables (including tele­phone lines and power
cord).

You must also remove
your battery in order to
prevent accidentally
turning the machine on.

Before removing the
battery disconnect the
AC/DC adapter from
the computer.

Power Safety

The computer has specific power requirements:

• Only use a power adapter approved for use with this computer.

• Your AC/DC adapter may be designed for international travel but it still requires a
steady, uninterrupted power supply. If you are unsure of your local power specifica­tions, consult your service representative or local power company.

• The power adapter may have either a 2-prong or a 3-prong grounded plug. The third
prong is an important safety feature; do not defeat its purpose. If you do not have access
to a compatible outlet, have a qualified electrician install one.

• When you want to unplug the powe r co rd, be sure to di sconn ect it b y the plug head , no t
by its wire.

• Make sure the socket and any extension cord(s) you use can support the total current
load of all the connected devices.

• Before cleaning the computer, make sure it is disconnected from any external power
supplies (i.e. AC/DC adapter or car adapter).

Do not plug in the power
cord if you are wet.

Do not use the power cord if
it is broken.

Do not place heavy objects
on the power cord.

X

Preface

Polymer/Lithium-Ion Battery Precautions

Note the following information which is specific to Polymer/Lithium-Ion batteries only, and where applicable,
this overrides the general battery precaution information overleaf.

• Polymer/Lithium-Ion batteries may experience a slight expansion or swelling, however this is part of the battery’s
safety mechanism and is not a cause for concern.

• Use proper handling procedures when using Polymer/Lithium-Ion batteries. Do not use Polymer/Lithium-Ion batteries
in high ambient temperature environments, and do not store unused batteries for extended periods.

• If you are working in areas of low temperature use the AC/DC adapter to power the computer.

See also the general battery precautionary information overleaf for further information.

XI

Preface



Battery Disposal & Caution

The product that you have purchased contains a rechargeable battery. The battery is recyclable. At the end of its useful life,
under various state and local laws, it may be illegal to dispose of this battery in to the municipal waste stream. Check with
your local solid waste officials for details in your area for recycling options or proper disposal.

Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalen t type recommended by the
manufacturer. Discard used battery according to the manufacturer’s instructions.

General Battery Precautions

• Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer.

• Do not remove any batteries from the computer while it is powered on.

• Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even
if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly
result in fire.

• If you do not use the battery for an extended period, then remove the battery from the computer for storage.

• Recharge the batteries using the notebook’s system. Incorrect recharging may make the battery explode.

• Do not try to repair a battery pack. Refer any battery pack repa ir or replacemen t to you r service repre sentati ve or qu al­ified service personnel.

• Keep children away from, and promptly dispose of a damaged battery. Always dispose of batteries carefully. Batteries
may explode or leak if exposed to fire, or improperly handled or discarded.

• Keep the battery away from metal appliances.

• Affix tape to the battery contacts before disposing of the battery.

• Do not touch the battery contacts with your hands or metal objects.

XII

Preface



Power Off Before Traveling

Make sure that your notebook is completely powered off before putting it into a travel bag (or any such container). Putting a
notebook which is powered on in a travel bag may cause the Vents/Fan Intakes to be blocked. To pre vent your computer
from overheating make sure nothing blocks the Vent/Fan Intakes while the computer is in use.

Cleaning

Do not apply cleaner directly to the computer; use a soft clean cloth.
Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer.

Travel Considerations

As you get ready for your trip, run through this list to make sure the system is ready to go:

1. Check that the battery pack and any spares are fully charged.

2. Power off the computer and peripherals.

3. Close the display panel and make sure it’s latched.

4. Disconnect the AC/DC adapter and cables. Stow them in the carrying bag.

5. The AC/DC adapter uses volt ages from 100 to 240 volt s so you won’t need a second volt age adapter. However,

check with your travel agent to see if you need any socket adapters.

6. Put the notebook in its carrying bag and secure it with the bag’s straps.

7. If you’re taking any perip herals (e.g. a printer, mouse or digital camera), pack them and those devices’ adapters

and/or cables.

8. Anticipate customs - Some jurisdictions may have import restrictions or req uire proof of ownersh ip for both hard -

ware and software. Make sure your “papers” are handy.

XIII

Preface



Power Off Before Traveling

Make sure that your notebook is completely powered off before putting it into a travel bag (or any such container). Putting a
notebook which is powered on in a travel bag may cause the vent(s)/fan intake(s)/outlet(s) to be blocked. To prev ent your
computer from overheating make sure nothing blocks the vent(s)/fan intake(s)/outlet(s) while the computer is in use.

Packing

As you get ready for your trip, run through this list to make sure the system is ready to go:

1. Check that the battery pack and any spares are fully charged.

2. Power off the computer and peripherals.

3. Close the display panel and make sure it’s latched.

4. Disconnect the AC/DC adapter and cables. Stow them in the carrying bag.

5. The AC/DC adapter uses volt ages from 100 to 240 volt s so you won’t need a second volt age adapter. However,

check with your travel agent to see if you need any socket adapters.

6. Put the notebook in its carrying bag and secure it with the bag’s straps.

7. If you’re taking any perip herals (e.g. a printer, mouse or digital camera), pack them and those devices’ adapters

and/or cables.

8. Anticipate customs - Some jurisdictions may have import restrictions or req uire proof of ownersh ip for both hard -

ware and software. Make sure your documents are prepared.

XIV

Preface

On the Road

In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting,
keep these points in mind:

Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very
common. Don’t check it with “normal” luggage. Baggage handlers may not be sufficiently careful. Avoid knock­ing the computer against hard objects.

Beware of Electromagnetic fields - Devices such as metal detectors & X-ray machines can damage the com­puter, hard disk, floppy disks, and other media. They may also destroy any stored data - Pass your computer and
disks around the devices. Ask security officials to hand-inspect them (you may be asked to turn it on). Note:
Some airports also scan luggage with these devices.

Fly safely - Most airlines have regulations about the use of computers and other electronic devices in flight.
These restrictions are for your safety, follow them. If you stow the notebook in an overhead compartment, make
sure it’s secure. Contents may shift and/or fall out when the compartment is opened.

Get power where you can - If an electrical outlet is available, use the AC/DC adapter and keep your battery(ies)
charged.

Keep it dry - If you move quickly from a cold to a warm location, water vapor can condense inside the computer.
Wait a few minutes before turning it on so that any moisture can evaporate.

XV

Preface

Developing Good Work Habits

Developing good work habits is important if you need to work in fron t of the computer for long periods of time.
Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or
other joints. The following are some tips to reduce the strain:

• Adjust the height of the chair and/or desk so that the keyboard is at or slightly below the
level of your elbow. Keep your forearms, wrists, and hands in a relaxed position.

• Y our knees sho uld be sligh tly higher th an your hips. Place yo ur feet flat on the floor or on
a footrest if necessary.

• Use a chair with a back and adjust it to support your lower back comfortably.

• Sit straight so that your knees, hips and elbows form approximately 90-degree angles
when you are working.

• Take periodic breaks if you are using the computer for long periods of time.

Remember to:

• Alter your posture frequently.

• Stretch and exercise your body several times a day.

• Take periodic breaks when you work at the computer for long periods of time. Frequent
and short breaks are better than fewer and longer breaks.

XVI

Preface

Lighting

Proper lighting and a comfortable viewing angle can reduce eye strain and shoulder and neck muscle fatigue.

• Position the display to avoid glare or reflections from overhead lighting or outside sources of light.

• Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly.

• Position the display directly in front of you at a comfortable viewing distance.

• Adjust the display-viewing angle to find the best position.

LCD Screen Care

To prevent image persistence on LCD monitors (caused by the continuous display of graphics on the screen for
an extended period of time) take the following precautions:

• Set the Windows Power Plans to turn the screen off after a few minutes of screen idle time.

• Use a rotating, moving or blank screen saver (this prevents an image from being displayed too long).

• Rotate desktop background images every few days.

• Turn the monitor off when the system is not in use.

LCD Electro-Plated Logos

Note that in computers featuring a raised LCD electro-plated logo, the logo is covered by a protective adhesive.
Due to general wear and tear, this adhesive may deteriorate over time and the exposed logo may develop sharp
edges. Be careful when handling the computer in this case, and avoid touching the raised LCD electro-plated
logo. Avoid placing any other items in the carrying bag which may rub against the top of the computer during
transport. If any such wear and tear develops contact your distributor/supplier.

XVII

Preface

XVIII

Preface

Contents

Notice .............................................................................................................................................................I

ErP Off Mode Power Consumption Statement: ...........................................................................................II

FCC Statement ............................................................................................................................................IV

FCC RF Radiation Exposure Statement: .....................................................................................................V

Instructions for Care and Operation ......................................................................................................... VII

Servicing .....................................................................................................................................................IX

Power Safety ................................................................................................................................................X

Polymer/Lithium-Ion Battery Precautions ..................................................................................................XI

General Battery Precautions ..................................................................................................................... XII

Cleaning ...................................................................................................................................................XIII

Travel Considerations ..............................................................................................................................XIII

Quick Start Guide

Overview ....................................................................................................................................................1-1

Advanced Users .........................................................................................................................................1-2

Beginners and Not-So-Advanced Users ....................................................................................................1-2

Warning Boxes ..........................................................................................................................................1-2

Not Included ..............................................................................................................................................1-3

System Software ........................................................................................................................................1-4

System Startup ...........................................................................................................................................1-5

LCD Panel Open ........................................................................................................................................1-6

XIX

Preface

LED Indicators ...........................................................................................................................................1-7

Keyboard ....................................................................................................................................................1-8

Keyboard Application Settings ..................................................................................................................1-9

Control Center .........................................................................................................................................1-10

Keyboard Shortcuts .................................................................................................................................1-11

Function Keys & Visual Indicators .........................................................................................................1-12

Front & Rear Views .................................................................................................................................1-13

Right & Left Views .................................................................................................................................1-14

Bottom View ............................................................................................................................................1-17

Removing the Battery ..............................................................................................................................1-18

Windows 10 Start Menu ..........................................................................................................................1-19

Right-Clicking the Windows Logo In Start Menu ..................................................................................1-20

Start Menu Apps & Tiles .........................................................................................................................1-21

Windows 10 Control Panel ......................................................................................................................1-23

Settings ....................................................................................................................................................1-24

Windows 10 Taskbar ...............................................................................................................................1-25

Action Center ...........................................................................................................................................1-26

Video Features .........................................................................................................................................1-27

Power Options .........................................................................................................................................1-31

Storage Devices, Mouse, & Audio

Overview ....................................................................................................................................................2-1

XX

Preface

Hard Disk Drive/Solid State Drive ............................................................................................................2-2

Optical (CD/DVD) Device ........................................................................................................................2-3

Loading Discs ............................................................................................................................................2-3

Handling CDs or DVDs .............................................................................................................................2-4

DVD Regional Codes ................................................................................................................................2-5

Multi-in-1 Card Reader ..............................................................................................................................2-6

Audio Features ...........................................................................................................................................2-7

Setup for Audio Recording ........................................................................................................................2-8

Touchpad and Buttons/Mouse ...................................................................................................................2-9

Touchpad Sensitivity ...............................................................................................................................2-10

Touchpad Configuration ..........................................................................................................................2-11

Gestures and Device Settings ..................................................................................................................2-12

Power Management

Overview ....................................................................................................................................................3-1

The Power Sources ....................................................................................................................................3-2

AC/DC Adapter .........................................................................................................................................3-2

Battery ........................................................................................................................................................3-2

Turning On the Computer ..........................................................................................................................3-3

Shutting the Computer Down ....................................................................................................................3-4

Power Plans ...............................................................................................................................................3-5

Power-Saving States ..................................................................................................................................3-7

XXI

Preface

Sleep ..........................................................................................................................................................3-7

Hibernate ....................................................................................................................................................3-8

Shut down ..................................................................................................................................................3-8

Configuring the Power Buttons .................................................................................................................3-9

Resuming Operation ................................................................................................................................3-11

Power Conservation Modes .....................................................................................................................3-12

Settings Menu Power Controls ................................................................................................................3-14

Battery Information .................................................................................................................................3-17

Battery Power ..........................................................................................................................................3-17

Conserving Battery Power .......................................................................................................................3-18

Battery Life ..............................................................................................................................................3-19

New Battery .............................................................................................................................................3-19

Recharging the Battery with the AC/DC Adapter ...................................................................................3-19

Proper handling of the Battery Pack ........................................................................................................3-20

Battery FAQ .............................................................................................................................................3-21

Removing the Battery ..............................................................................................................................3-25

Drivers & Utilities

What to Install ............................................................................................................................................4-1

Module Driver Installation ........................................................................................................................4-1

Driver Installation ......................................................................................................................................4-2

Updating/Reinstalling Individual Drivers ..................................................................................................4-5

XXII

Preface

User Account Control ................................................................................................................................4-6

Windows Security Message .......................................................................................................................4-6

New Hardware Found ................................................................................................................................4-6

Driver Installation Procedure .....................................................................................................................4-7

Chipset .......................................................................................................................................................4-7

Video (VGA) .............................................................................................................................................4-7

LAN ...........................................................................................................................................................4-7

Card Reader ...............................................................................................................................................4-7

Touchpad ...................................................................................................................................................4-7

Control Center ...........................................................................................................................................4-8

Airplane .....................................................................................................................................................4-8

MEI Driver .................................................................................................................................................4-8

Audio .........................................................................................................................................................4-8

Optional Drivers ........................................................................................................................................4-9

BIOS Utilities

Overview ....................................................................................................................................................5-1

The Power-On Self Test (POST) ...............................................................................................................5-2

Failing the POST .......................................................................................................................................5-3

Fatal Errors ................................................................................................................................................5-3

Non-Fatal Errors ........................................................................................................................................5-3

The Setup Utility ........................................................................................................................................5-4

XXIII

Preface

Entering Setup ...........................................................................................................................................5-4

Setup Screens .............................................................................................................................................5-5

Main Menu .................................................................................................................................................5-6

System Time & Date (Main Menu) ...........................................................................................................5-6

SATA Port # (Main Menu) ........................................................................................................................5-7

OffBoard SATA/NVme Controller Configuration (Main Menu) .............................................................5-7

CPU/ ME FW Version / System/ Extended Memory: (Main Menu) ........................................................5-7

MB Series / BIOS Revision / KBC/EC firmware Revision / Mac Address (Main Menu) ........................5-7

Advanced Menu .........................................................................................................................................5-8

Advanced Chipset Control (Advanced Menu) ..........................................................................................5-8

FlexiCharger (Advanced Menu > Advanced Chipset Control) .................................................................5-9

SATA Mode (Advanced Menu) ..............................................................................................................5-10

Boot Logo (Advanced Menu) ..................................................................................................................5-10

Power On Boot Beep (Advanced Menu) .................................................................................................5-10

Battery Low Alarm Beep (Advanced Menu) ...........................................................................................5-10

Security Menu ..........................................................................................................................................5-11

Set Supervisor Password (Security Menu) ..............................................................................................5-11

Set User Password (Security Menu) ........................................................................................................5-12

Password on boot: (Security Menu) ........................................................................................................5-12

Secure Boot Control (Security Menu) .....................................................................................................5-13

TPM Configuration (Security Menu) ......................................................................................................5-14

Boot Menu ...............................................................................................................................................5-15

XXIV

Preface

Boot Option Priorities (Boot Menu) ........................................................................................................5-16

UEFI Boot (Boot Menu) ..........................................................................................................................5-16

Exit Menu ................................................................................................................................................5-17

Modules

Overview ....................................................................................................................................................6-1

Wireless LAN Module ...............................................................................................................................6-2

3rd Party 802.11b/g/n Driver Installation ..................................................................................................6-3

Intel® WLAN Driver Installation ..............................................................................................................6-3

WLAN Configuration in Windows ...........................................................................................................6-4

Bluetooth & WLAN Combo Module ........................................................................................................6-7

3rd Party Bluetooth (V4.0) Combo Driver Installation .............................................................................6-8

Intel Bluetooth Combo Driver Installation ................................................................................................6-8

Bluetooth Configuration in Windows ........................................................................................................6-9

To Make your Computer Discoverable to Bluetooth Devices .................................................................6-12

Intel® Rapid Storage Technology ...........................................................................................................6-13

IRST Driver Installation ..........................................................................................................................6-13

PC Camera ...............................................................................................................................................6-14

Camera App .............................................................................................................................................6-15

Taking Pictures/Capturing Video ............................................................................................................6-18

Trusted Platform Module .........................................................................................................................6-20

Enabling & Managing TPM ....................................................................................................................6-21

XXV

Preface

TPM Management in Windows ...............................................................................................................6-22

TPM Actions ............................................................................................................................................6-24

3G/4G Module .........................................................................................................................................6-26

3G/4G Configuration ..............................................................................................................................E-28

Troubleshooting

Overview ....................................................................................................................................................7-1

Basic Hints and Tips ..................................................................................................................................7-2

Backup and General Maintenance .............................................................................................................7-3

Viruses .......................................................................................................................................................7-4

Upgrading and Adding New Hardware/Software ......................................................................................7-5

Problems and Possible Solutions ...............................................................................................................7-7

Resolving the “Can’t connect to this network” issue with the 3G/4G Module .......................................7-15

Interface (Ports & Jacks)

Overview ...................................................................................................................................................A-1

Notebook Ports and Jacks .........................................................................................................................A-2

Card Reader Port .......................................................................................................................................A-2

DC-In Jack ................................................................................................................................................A-2

External Monitor (VGA) Port ...................................................................................................................A-2

HDMI-Out Port .........................................................................................................................................A-2

Headphone-Out Jack .................................................................................................................................A-2

Microphone-In Jack ..................................................................................................................................A-2

XXVI

Preface

RJ-45 LAN Jack .......................................................................................................................................A-3

Security Lock Slot ....................................................................................................................................A-3

USB 2.0/1.1 Port .......................................................................................................................................A-3

USB 3.0 Ports

(USB 3.1 Gen 1 - Type A or C) ................................................................................................................A-3

USB 3.1 Ports

(USB 3.1 Gen 2 - Type A or C) ................................................................................................................A-3

..................................................................................................................................................................A-3

Control Center

Overview ...................................................................................................................................................B-1

Power Modes ............................................................................................................................................B-2

Control Center Menus ...............................................................................................................................B-3

Power Status (System Program) .............................................................................................................B-4

CPU Temperature (System Program) ......................................................................................................B-4

Brightness (System Program) ..................................................................................................................B-4

Volume (System Program) .......................................................................................................................B-4

Fan Speed (System Program) ...................................................................................................................B-4

This system supports Energy Star power .............................................................................................B-5

Sleep Button (System Program) ..............................................................................................................B-5

Display Switch (System Program) ...........................................................................................................B-5

Time Zone (System Program) .................................................................................................................B-5

XXVII

Preface

Desktop Background (System Program) .................................................................................................B-6

Backlight Keyboard (Device) ...................................................................................................................B-6

TouchPad/PC Camera (Device) ...............................................................................................................B-6

Caps Lock/Scroll Lock/ Number Lock/Airplane Mode ...........................................................................B-6

Video Driver Controls

Video Driver Installation ..........................................................................................................................C-1

Dynamic Video Memory Technology ......................................................................................................C-1

Intel® HD Graphics Control Panel ...........................................................................................................C-2

Display Devices & Options ....................................................................................................................C-15

Attaching Other Displays .......................................................................................................................C-16

Configure Other Displays Using Project ................................................................................................C-18

You can configure attached displays from Project. ................................................................................C-18

Configuring an External Display In Windows .......................................................................................C-19

HDMI Audio Configuration ...................................................................................................................C-20

Wireless Display .....................................................................................................................................C-23

Wireless Display Configuration .............................................................................................................C-24

Specifications

Core Logic ................................................................................................................................................D-2

Display ......................................................................................................................................................D-2

Memory .....................................................................................................................................................D-2

Storage ......................................................................................................................................................D-2

XXVIII

Preface

Audio ........................................................................................................................................................D-2

Keyboard & Pointing Device ....................................................................................................................D-2

Interface ....................................................................................................................................................D-2

Card Reader ..............................................................................................................................................D-3

Slots ..........................................................................................................................................................D-3

Communication .........................................................................................................................................D-3

Operating System ......................................................................................................................................D-3

Features .....................................................................................................................................................D-3

Indicators ..................................................................................................................................................D-3

Security .....................................................................................................................................................D-3

BIOS .........................................................................................................................................................D-3

Power Management ..................................................................................................................................D-3

Power ........................................................................................................................................................D-3

Environmental Spec ..................................................................................................................................D-4

Physical Dimensions & Weight ................................................................................................................D-4

XXIX

Preface

XXX

Quick Start Guide

Chapter 1: Quick Start Guide

Overview

This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the
computer and to getting your system started. The remainder of the manual covers the following:

• Chapter 2 A guide to using some of the main features of the computer e.g. the storage devices (hard disk and
card reader), TouchPad & Mouse and Audio Features.

• Chapter 3 The computer’s power management options.

• Chapter 4 The installation of the drivers and utilities essential to the operation or improvement of some of the
computer’s subsystems.

• Chapter 5 An outline of the computer’s built-in software or BIOS (Basic Input Output System).

• Chapter 6 A quick guide to the computer’s PC Camera, Wireless LAN, Bluetooth & WLAN Combo,
Sound Blaster Audio and Intel modules (some of which may be optional depending on your pur-
chase configuration).

• Chapter 7 A troubleshooting guide.

• Appendix A Definiti ons of the interface, ports/jacks which allow your computer to c ommun icat e with ex te rnal
devices.

• Appendix B Information on the Control Center .

• Appendix C Information on the Video driver controls.

• Appendix D The computer’s specification.

1

Overview 1 - 1

1



Notes

Check the light colored
boxes with the mark
above to find detailed
information about the
computer’s features.

Quick Start Guide

Advanced Users

If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful
to refer to “Drivers & Utilities” on page 4 - 1 and “BIOS Utilities” on page 5 - 1 in the User’s Manual. You
may also find the notes marked with a

 of interest to you.

Beginners and Not-So-Advanced Users

If you are new to computers (or do not have an advanced knowledge of them) then
the information contained in this Quick Start Guide should be enough to get you up
and running. Eventually you should try to look through all the documentation (more
detailed descriptions of the functions, setup and system controls are covered in the
remainder of the User’s Manual), but do not worry if you do not understand every­thing the first time. Keep this manual nearby and refer to it to learn as you go. You
may find it useful to refer to the notes marked with a

 as indicated in the margin.

For a more detailed description of any of the interface ports and jacks see “Interface

(Ports & Jacks)” on page A - 1.

Warning Boxes

No matter what your level please pay careful attention to the warning and safety information indicated by the

 symbol. Also please note the safety and handling instructions as indicated in the Preface.

1 - 2 Overview

Quick Start Guide



Drivers

If you are installing new system software, or are re-configuring your computer for a different system, you will need to install
the appropriate drivers. Drivers are programs which act as an interface between the computer and a hardware component
e.g. a wireless network module. It is very important that you install the drivers in the order listed in Table 4 - 1, on page 4

- 4. You will be unable to use most advanced controls until the necessary drivers and utilities are properly installed. If your

system hasn’t been properly configured (your service representative may have already done that for you), refer to “Drivers

& Utilities” on page 4 - 1 for installation instructions.

Ports and Jacks

See “Notebook Ports and Jacks” on page A - 2 for a description of the interface (ports & jacks) which allow your com­puter to communicate with external devices, connect to the internet etc.

Not Included

Operating Systems (e.g. Windows 10) and applications (e.g. word processing, spreadsheet and database pro­grams) have their own manuals, so please consult the appropriate manuals.

1

Overview 1 - 3

1



Windows OS

Note that the information included on the following pages is for Windows 10 only.
In order to run Windows 10 (64-bit) your computer requires a minimum 2GB of system memory (RAM).

Quick Start Guide

System Software

Your computer may already come with system software pre-installed. Where this is not the case, or where you
are re-configuring your computer for a different system, you will find the Windows 10 (64-bit) operating system
is supported.

1 - 4 Overview

Quick Start Guide

135°



Shutdown

Note that you should al­ways shut your comput­er down by choosing the
Shut Down command
in Windows (see page

1 - 31). This will help

prevent hard disk or
system problems.

Figure 1 - 1 - AC/DC Adapter In / Opening the Lid/LCD

System Startup

1. Remove all packing materials, and place the computer on a stable surface, and securely attach any peripherals

you want to use with the notebook (e.g. keyboard and mouse) to their ports.

2. When first setting up the computer use the following procedure (as to safeguard the computer during

shipping, the battery will be locked to not power the system until first connected to the AC/DC adapter and
initially set up as below):

• Attach the AC/DC adapter cord to the DC-In jack on the right of the computer, then plug the AC power cord into an outlet, and connect
the AC power cord to the AC/DC adapter and leave it there for 6 seconds or longer.

• Remove the adapter cord from the computer’s DC-In jack, and then plug it back in again; the battery will now be unlocked.

3. Use one hand to raise the
the other hand to support the base of the computer (Note: Never lift the computer by the lid/LCD).

4. Press the power button on the top of the computer for about 2 - 3 seconds to turn the computer “on” (note that
the power LED on the front of the computer will turn from orange to green when the computer powers on).

lid/LCD to a comfortable viewing angle (it is preferable not to exceed 135 degrees);

System Startup 1 - 5

use

1

1

Figure 1 - 2

LCD Panel Open

1. Built-In PC Camera

2. PC Camera LED

3. Built-In Array
Microphone

4. LCD

5. Power Button

6. Keyboard

7. TouchPad & Buttons

Note that the Touchpad/
Clickpad and Buttons has a
valid operational area indi­cated within the dotted lines
above.

4

5

7



Wireless Device

Operation Aboard

Aircraft

The use of any portable
electronic transmission de­vices (e.g. WLAN, Blue­tooth or 3G/4G) aboard
aircraft is usually prohibited.
Make sure any wireless
modules are OFF (i.e. the
system is in Airplane
Mode) if you are using the
computer aboard aircraft.

Use Fn + F11 Airplane
Mode key combination to
toggle Airplane Mode On/
Off, and check the LED indi­cator for the power status.

6

1

2 33

Quick Start Guide

LCD Panel Open

1 - 6 LCD Panel Open

Quick Start Guide

LED Indicators

The LED indicators at the front of the computer display helpful information about the current status of the sys­tem.

Icon Color Description

Orange The Battery is Charging

Blinking Orange The Battery has Reached Critically Low Power Status

Green The Battery is Fully Charged

Orange AC/DC Power is Plugged In

Green The Computer is On

Blinking Green The Computer is in Sleep Mode

Green HDD Activity

Green Airplane Mode is ON (the WLAN, Bluetooth & 3G/4G Modules are OFF)

Table 1 - 1 - LED Indicators

1

LCD Panel Open 1 - 7

1



Other Keyboards

If your keyboard is dam­aged or you just want to
make a change, you can
use any standard USB
keyboard. The system will
detect and enable it auto­matically. However spe­cial functions/hot-keys
unique to the system’s
regular keyboard may not
work.

Scr Lk

Hold down the Fn Key
and Scr Lk to enable
scroll lock and check the
LED indicator for status.

Numerical

Play/Pause Key

Function Keys

ScrLk &
NumLk Keys

Fn Key

Keypad

Windows Logo Key

Menu/Application Key



Special Characters

Some software applications allow the number-keys to be used with Alt to produce special characters.
These special characters can only be produced by using the numeric keypad. Regular number keys (in
the upper row of the keyboard) will not work. Make sure that NumLk is on.

Quick Start Guide

Keyboard

The keyboard (or the factory option white illuminated LED keyboard) has an embed­ded numerical keypad for easy numeric data input, and features function keys to al­low you to change operational features instantly. See Table 1 - 3, on page 1 - 12 for
full function key combination details.

1 - 8 Keyboard

Figure 1 - 3 - Keyboard

Quick Start Guide

Right-click and select Keyboard Settings.

Keyboard Application Settings

(Illuminated Keyboard Option)
If your computer includes an illuminated keyboard (factory option), you will need to install the keyboard Con-
trol Center application driver (see “Control Center” on page 4 - 8) and you can then select the type of keyboard
as appropriate for your model’s configuration (you can only select keyboards supported by your system). After
the driver has been installed, and the system restarts, the control panel below will pop-up to allow you to select
the illuminated white keyboard for your system. Click Save to retain the setting chosen.

If you wish to change the setting at any time then right-click on the Control Center icon and select Key-
board Settings to return to the keyboard select control panel.

1

Figure 1 - 4 - Keyboard Settings for Illuminated Keyboard Option

Keyboard Application Settings 1 - 9

1



Control Center Access

To run the
Control Cen­ter press the
Fn + Esc key
combination,
or double­click the icon

in the noti­fication area
of the taskbar.

Close the Control Center by clicking
the close icon in the top right of the
panel (move the cursor onto the top
right corner of the panel to highlight it).

Quick Start Guide

Control Center

When in the Windows Desktop application (not in the Start screen) press the Fn + Esc key combination, or
double-click the icon
trol Center gives quick access to frequently used controls and enables you to quickly turn the camera/touch pad

on/off (see Appendix B for full details).

1 - 10 Control Center

in the notification area of the taskbar to toggle the Control Center on/off. The Con-

Figure 1 - 5 - Control Center

Keyboard Shortcuts



Windows Logo

Keyboard Shortcut

Use the Windows logo
key + D key com-
bination to switch be­tween the Start screen
and Windows Desktop.

Menu/Application

Keyboard Shortcut

When the Desktop app
is running you can use
the Menu/Application
key on the key­board to display the
context menu as per a
mouse right-click.

The following Windows Logo Key (Winkey) keyboard shortcuts are useful for navi­gation/operation in

Windows 10

.

Quick Start Guide

1

Windows Logo

+ Number (1, 2, etc) Launch an application from the taskbar (numbered from left to right)

Key +

Tap Winkey Toggle the Start menu

A Open the Action Center
B Select the Taskbar Notification Area
C Launch Cortana (in listening mode)
D Toggle the Desktop
E Launch File Explorer (Quick Access tab)

Description

Table 1 - 2 - Keyboard Shortcuts

Control Center 1 - 11

1

Quick Start Guide

Function Keys & Visual Indicators

The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down.

Keys Function/Visual Indicators Keys Function/Visual Indicators

Fn +

Fn +

Fn +

Fn +

Fn + Mute Toggle

Fn +

Fn +

Fan Control Toggle

Automatic / Full

Power

Play/Pause (in Audio/Video Programs)

Touchpad Toggle

(Press a key to or use Touchpad to turn on)

Keyboards Only T oggle

Turn LCD Backlight Off

For Backlight
Off/High/Low

Volume Decrease/Increase

1 - 12 Control Center

Fn +

Fn +

Fn +

Fn +

Fn +

Fn +

Table 1 - 3 - Function Keys & Visual Indicators

Control Center Toggle

Display Toggle

Brightness Decrease/Increase

PC Camera

Power T oggle

Airplane

Mode Toggle

Sleep Toggle

Front & Rear Views

Figure 1 - 6

Front & Rear Views

1. Multi-In-1 Card
Reader

2. LED Indicators

3. Battery

1

3

2



Multi-in-1 Card Reader

The card reader allows you to use the most popular digital storage card formats:

MMC (MultiMedia Card) / RSMMC

SD (Secure Digital) / Mini SD / SDHC / SDXC

2

Quick Start Guide

1

Front & Rear Views 1 - 13

1

Figure 1 - 7

Right & Left Views

1. S/PDIF-Out Jack

2. Microphone Jack

3. Headphone Jack

4. 1 * USB 2.0 Port

5. Optical Device Drive
Bay (for DVD Device)

6. DC-In Jack

7. Security Lock Slot

8. HDMI-Out Port

9. RJ-45 LAN Jack

10. External Monitor Port

1 1. Vent/Fan Intake

12. 1 * USB 3.0 Port (USB

3.1 Gen 1 - Type C)

13. 2 * USB 3.0 Ports (USB

3.1 Gen 1 -

Type A

)

OR

1 * USB 3.1 Port (USB

3.1 Gen 2 -

Type C

) &

1 * USB 3.1 Port (USB

3.1 Gen 2 -

Type A

)

(

Factory Option

)

1 * USB 3.0 Port (USB

3.1 Gen 1 -

Type A

)

12.

13a.

13b.

1

3

4

2

5



USB 3.0 / 3.1 Port OR USB 2.0 Port

This model includes 2 * USB 3.0 ports (USB 3.1 Gen 1 Type A), 1 * USB 3.0 port (USB 3.1
Gen 1 Type C) and 1 * USB 2.0 port.

Note: 1 * USB 3.1 (Gen 2 Type C) and 1 * USB 3.1 (Gen 2 Type A) ports are
available as a factory option for this computer model series. The USB 3.1 ports are shared
with the USB 3.0 ports in this option.

12

13a

6

7

8

9

10

Right

Left

11

12



USB 3.1 Port Speed

Note that when a single USB device is plugged in to a USB 3.1 (Gen 2) port the data tra nsfer speed
will be 10Gbps, however when two devices are plugged in to both USB 3.1 (Gen 2) ports, this band­width will be shared between the ports..

13b

13a

Quick Start Guide

Right & Left Views

1 - 14 Right & Left Views



Disk Eject Warning

Don’t try to eject a CD/DVD while the system is ac­cessing it. This may cause the system to “crash”. Stop
the disk first then eject it, or press the stop button
twice.

CD/DVD Emergency Eject

If you need to manually eject a CD/DVD (e.g. due to
an unexpected power interruption) you may push the
end of a straightened paper clip into the emergency
eject hole. Do not use a sharpened pencil or any ob­ject that may break and become lodged in the hole.
Don’t try to remove a floppy disk/CD/DVD while the
system is accessing it. This may cause the system to
“crash”.



Changing DVD Regional Codes

Go to the Control Panel and double-click Device Man­ager (Hardware and Sound), then click the + next to
DVD/CD-ROM drives. Double-click on the DVD-ROM
device to bring up the Properties dialog box, and se­lect the DVD Region (tab) to bring up the control pan­el to allow you to adjust the regional code).

DVD region detection is device dependent, not OS­dependent. You can select your module’s region
code 5 times. The fifth selection is permanent. This
cannot be altered even if you change your operating
system or you use the module in another computer
(see “DVD Regional Codes” on page 2 - 5).

Quick Start Guide

1

Right & Left Views 1 - 15

1



USIM Card

Orientation

Note that the USIM
card’s readable side
(with the gold-colored
contacts) should face
downwards as illustrat­ed.

Figure 1 - 8

USIM Card Insertion

1



USIM Card Ejection

Simply press on the USIM card to eject it, however do not do this while a connection is in progress. If
you do eject the card while a 3G/4G connection is ongoing, you will need to shut down the system, re­insert the USIM card, restart the system and then reestablish the 3G/4G connection.

If you wish to change USIM cards then you will need to shut the system down, reinsert the USIM card,
restart the system and then reestablish the 3G/4G connection.

1

Quick Start Guide

3G/4G Module USIM Card Installation

Remove the battery (see “Removing the Battery” on page 1 - 18) and insert the
USIM card as illustrated below (pay careful attention to the orientation of the card
as the gold contact side of the card should face downwards) until it clicks fully into
position. To eject the card simply press it until it ejects, but do not attempt to eject
the card while connected to a 3G/4G network (see below).

1 - 16 Right & Left Views

Bottom View

Figure 1 - 9

Bottom View

1. Fan Outlet/Intake

2. Speakers

3. Component Bay
Cover

3



Battery Information

Always completely discharge, then fully charge, a new battery
before using it. Completely discharge and charge the battery
at least once every 30 days or after about 20 partial discharg­es.



Overheating

To prevent your comput­er from overheating
make sure nothing
blocks the vent(s)/fan in­take(s) while the com­puter is in use.

Bottom Cover Removal

Warning

Do not remove any cov­er(s) and /or screw(s) for
the purposes of device
upgrade as this may vio­late the terms of your
warranty.

If you need to replace/re­move the hard disk/
RAM/optical device etc.,
for any reason, please
contact your distributor/
supplier for further infor­mation.

2

1

1

1

1

2

Quick Start Guide

Bottom View 1 - 17

1

1

12345

1

2

3

4

5

5



Bottom Cover Removal

Warning

Do not remove any cover(s)
and /or screw(s) for the pur­poses of device upgrade as
this may violate the terms of
your warranty.

If you need to replace/re­move the hard disk/RAM/op­tical device etc., for any
reason, please contact your
distributor/supplier for further
information.

Quick Start Guide

Removing the Battery

It is possible to remove the battery from the computer, however we recommend that you do not remove the bat­tery yourself. If you do need to remove the battery for any reason (e.g. long term storage) see below.

1. Turn the computer off, and turn it over.

2. Slide the latch in the direction of the arrow.

3. Slide the latch in the direction of the arrow, and hold it in place.

4. Slide the battery out in the direction of the arrow .

5. Reinsert the battery as illustrated below

6. Make sure the latches are returned to the lock position .

Figure 1 - 10 - Battery Removal & Insertion

1 - 18 Removing the Battery

.

Quick Start Guide

Desktop



Windows Screens

Note that the Win­dows screens on the

following pages are
included as a basic
guide and introduc­tion to navigating
around Windows 10.

However note that
these screens are al­ways subject to
change, upgrade and
redesign. Check the
Microsoft website for
details.

Windows 10 Start Menu

Most of the apps, control panels, utilities and programs within Windows 10 can be accessed from the Start
Menu by clicking the icon in the taskbar in the lower left corner of the screen (or by pressing the Windows
Logo Key on the keyboard).

Figure 1 - 11 - Windows Start Menu

Windows 10 Start Menu 1 - 19

1

1

Right-Click Icon

Quick Start Guide

Right-Clicking the Windows Logo In Start Menu

Right-click the Start Menu icon (or use the Windows Logo Key + X key combination) to bring up an
advanced Context Menu of useful features such as Apps and Features, Power Options, Task Manager, Search,
File Explorer, Device Manager, Computer Management and Network Connections etc.

Figure 1 - 12 - Right-Click Windows Logo in Start Menu

1 - 20 Windows 10 Start Menu

Quick Start Guide

Start Menu Apps & Tiles

The Windows 10 Start Menu will contain a number of apps, and many more will be installed as you add more
applications etc. Not all of these apps can fit on the screen so may need click and drag the handles at the edge of
the screen to expand the menu in order to view all the apps (you can use the scroll bar to mov e up and down the
screen).

1

Figure 1 - 13 - Expanding the Start Menu

Windows 10 Start Menu 1 - 21

1

Quick Start Guide

Pining/Unpinning Apps & Programs to/from the Start Menu

To make things easy to find you can add and remove tiles for apps and programs to the Start Menu. Right-Click
on a program’s icon and select Pin to Start from the drop-down menu. To remove an app or program from the
Start Menu right-click the icon and select Unpin from Start. You can use the same method to pin apps/pro-
grams to/from the taskbar (select pin to taskbar/unpin this program from the taskbar).

Figure 1 - 14 - Pin to Start/Unpin from Start

1 - 22 Windows 10 Start Menu

Windows 10 Control Panel

• Select Control Panel
under the Windows

System item in the
Start Menu.

• Type Control Panel
into the Search box in
the taskbar and click on
the icon when it pops
up.

• You can pin the Con-
trol Panel tile to Start
or taskbar.

In many instances throughout this manual you will see an instruction to open the Control Panel. The Control
Panel can be accessed in a number of ways in Windows 10.

Quick Start Guide

1

Figure 1 - 15 - Windows 10 Control Panel Access

Windows 10 Control Panel 1 - 23

1

Quick Start Guide

Settings

The Settings item in the Start Menu (and also as an App) gives you quick access to a number of system settings
control panels allowing you to adjust settings for System, Devices, Network & internet, Personalization, Apps,
Accounts, Time & language, Gaming, Ease of Access, Privacy and Update & security.

Figure 1 - 16 - Settings

1 - 24 Windows 10 Control Panel

Quick Start Guide

Taskbar

Taskbar - Pinned Programs and Apps

Notification Area

Windows 10 Taskbar

In many instances throughout this manual you will see an instruction to access the notification area of the task­bar. The notification area of the taskbar in the bottom right of the screen. Some of the Control Panels and appli-

cations referred to throughout the course of this manual can be accessed from here.

Figure 1 - 17 - Taskbar

You can pin/unpin apps to/from the taskbar in much the same way as you can to the Start screen (see “Pining/

Unpinning Apps & Programs to/from the Start Menu” on page 1 - 22).

1

Windows 10 Control Panel 1 - 25

1

Quick Start Guide

Action Center

The Action Center appears as a vertical panel on the right side of the screen when you swipe in from the right
or click the button in the notification tray. This gives you access to commonly needed functions like Network,
All Settings, Airplane Mode, and Project etc.

1 - 26 Windows 10 Control Panel

Figure 1 - 18 - Action Center

Video Features

1. Attach your display to the appropriate
port, and turn it on.

2. Press the + P key combination.

3. Click on any one of the options from
the menu to select PC screen only,

Duplicate, Extend or Second
screen only.

4. You can also click Connect to a
wireless display at the bottom of the
Project screen and follow the steps

to connect to any wireless enabled
display.

You can switch display devices, and configure display options, from the Display settings ( click the Start Menu
and click Settings > System or right-click the desktop and select Display settings) control panel. In Windows
10 it is possible to quickly configure external displays from the Project menu (

on your keyboard and the P key or Fn + F7).

To Configure Displays using Project

Figure 1 - 19 - Project (Devices)

Quick Start Guide

press the Windows logo key

1

Video Features 1 - 27

1

Quick Start Guide

To access the Display Settings:

1. You can quickly adjust the display by right-clicking the desktop and selecting Display Settings.

2. Adjust the settings for Brightness and color, Scale and layout, Resolution and Orientation from the menus.

3. When and external display is attached you can arrange the display configuration from the Multiple Displays
menu, and arrange the configuration fr om Select and rearrange displays.

4. Click Apply to save any changes made.

1 - 28 Video Features

Figure 1 - 20 - Display Settings

Quick Start Guide

To access the Intel(R) HD Graphics Control Panel:

1. Right-click the desktop and select Intel(R) Graphics Settings from the menu.

OR

2. Click the icon in the notification area of the Desktop taskbar and select Intel(R) Graphics Settings from the
menu.

1

Figure 1 - 21 - Intel Graphics Control Panel

Video Features 1 - 29

1

Quick Start Guide

Minimum Screen Resolution Settings

1. Windows 10 has minimum screen resolution requirements.

2. Right-click a blank area of the Desktop and select Display Settings.

3. Adjust the Resolution to make sure that it is at least 1024 * 768, although preferably 1366 * 768 or above.

1 - 30 Video Features

Figure 1 - 22 - Display (Resolution)

Power Options

Using the Power Button

1. Go to the Start Menu.

2. Click the Power button .

3. Select the power state required from
the menu.

Power Options (Hardware and Sound) can be accessed from the Control Panel. The Power button item in
Start Menu (or the context menu) may be used to Shut down or Restart (you can also add Hibernate/Sleep to
the menu - see page 1 - 32). To fully control all the power options (including Hibernate mode) go to the Power
Options control panel and configure the power button, sleep button and lid to perform the function selected.

Quick Start Guide

1

Figure 1 - 23 - Shut Down/Restart

Power Options 1 - 31

1



Adding Hibernate/Sleep to the Power Men

1. Go to the Power Options (Hardware and Sound) control
panel (or go to Windows Settings > Power & sleep >
Additional power settings).

2. Click Choose what the power buttons do.

3. Click “Change settings that are currently unavailable”

.

4. Click to put a check in the Hibernate/Sleep box under
Shutdown settings.

5. Click Save Changes and close the control panel.

Quick Start Guide

You can also use the context menu (right-click the Start Menu icon or press the Windows logo + X key
combination) to Sign out, Sleep, Hibernate, Shut down, and Restart.

Figure 1 - 24 - Context Menu Shut Down or sign out

Ctrl + Alt + Delete Key Combination
You can use the CTRL + ALT + DEL key combination to bring up a full-screen displaying Lock, Sign out,
Change a password, Task Manager and Switch User. If you click the Power icon in the lower right corner of
the screen a power management option menu appears to display Sleep, Hibernate, Shut down, and Restart.

1 - 32 Power Options

Storage Devices, Mouse, & Audio

Chapter 2: Storage Devices, Mouse, & Audio

Overview

Read this chapter to learn more about the following main features and components
of the computer:

• Hard Disk Drive/Solid State Drive

• Optical (CD/DVD) Device

• Multi-in-1 Card Reader

• Audio Features

• Touchpad and Buttons/Mouse

2

Overview 2 - 1

Storage Devices, Mouse, & Audio



Bottom Cover

Removal Warning

Do not remove any cov­er(s) and /or screw(s) for
the purposes of device
upgrade as this may vio­late the terms of your
warranty.

If you need to replace/
remove the hard disk for
any reason, please con­tact your distributor/sup­plier for further
information.

2

Hard Disk Drive/Solid State Drive

The hard disk drive (HDD) and/or solid state drive (SSD) is used to store your data
in the computer. The hard disk can be taken out to accommodate other serial (SATA)
hard disk drives (see “Storage” on page D - 2 for specification information), how­ever you will need to contact your distributor/supplier to do this in order to avoid
violating the terms of your warranty.

2 - 2 Hard Disk Drive/Solid State Drive

Storage Devices, Mouse, & Audio



Sound Volume

Adjustment

How high the sound vol­ume can be set depends
on the setting of the vol­ume control within Win-
dows. Click the Volume
icon on the taskbar to
check the setting (see

“Audio Features” on
page 2 - 7).

Figure 2 - 1

Optical Device

123

1

2

3

Optical (CD/DVD) Device

There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual de­vice will depend on the module you purchased (see “Storage” on page D - 2). The
optical device is usually labeled “Drive D:” and may be used as a boot device if
properly set in the BIOS (see “Boot Menu” on page 5 - 15).

Loading Discs

To insert a CD/DVD, press the open button and carefully place a CD/DVD onto
the disc tray with label-side facing up (use just enough force for the disc to click onto
the tray’s spindle). Gently push the CD/DVD tray in until its lock “clicks” and you
are ready to start. The busy indicator will light up while data is being accessed,
or while an audio/video CD, or DVD, is playing. If power is unexpectedly interrupt­ed, insert an object such as a straightened paper clip into the emergency eject hole

to open the tray.

2

Optical (CD/DVD) Device 2 - 3

Storage Devices, Mouse, & Audio



CD Emergency Eject

If you need to manually
eject a CD (e.g. due to
an unexpected power
interruption) you may
push the end of a
straightened paper clip
into the emergency eject
hole. However please
do NOT use a sharp­ened pencil or similar
object that may break
and become lodged in
the hole.

Disk Eject Warning

Don’t try to remove a
CD/DVD while the sys­tem is accessing it. This
may cause the system
to “crash”.

2

2 - 4 Optical (CD/DVD) Device

Handling CDs or DVDs

Proper handling of your CDs/DVDs will prevent them from being damaged. Please
follow the advice below to make sure that the data stored on your CDs/DVDs can be
accessed.

Note the following:

• Hold the CD or DVD by the edges; do not touch the surface of the disc.

• Use a clean, soft, dry cloth to remove dust or fingerprints.

• Do not write on the surface with a pen.

• Do not attach paper or other materials to the surface of the disc.

• Do not store or place the CD or DVD in high-temperature areas.

• Do not use benzene, thinner, or other cleaners to clean the CD or DVD.

• Do not bend the CD or DVD.

• Do not drop or subject the CD or DVD to shock.

Storage Devices, Mouse, & Audio



DVD Region Note

DVD region detection is
device dependent, not
OS-dependent. You can
select your module’s re­gion code 5 times. The
fifth selection is perma­nent. This cannot be al­tered even if you change
your operating system
or you use the module in
another computer.

Figure 2 - 2

DVD Region Codes

• Region 1 - USA & Canada

• Region 2 - Western Europe, Japan,

South Africa, Middle East & Egypt

• Region 3 - South-East Asia, T aiwan,

South Korea, The Philippines, Indo­nesia, Hong Kong

• Region 4 - South & Central Amer-

ica, Mexico, Australia, New Zealand

• Region 5 - N Korea, Russia, Eastern

Europe, India & Most of Africa

• Region 6 - China

DVD Regional Codes

To change the DVD regional codes:

1. Go to the Control Panel

2. Double-click Device Manager (Hardware and Sound), then click the + next to
DVD/CD-ROM drives.

3. Double-click on the DVD-ROM device to bring up the Properties dialog box, and
select the DVD Region (tab) to bring up the control p anel to allow you to adjust the
regional code.

2

Optical (CD/DVD) Device 2 - 5

Storage Devices, Mouse, & Audio



Push-Push Card

Reader

The card reader fea­tures a push-in/push-out
card insertion and ejec­tion mechanism. Simply
push the card to insert
and eject it, however Ms
Duo cards require an
adapter.

Figure 2 - 3

Front View

1. Card Reader

• MMC (MultiMedia Card) / RSMMC

• SD (Secure Digital) / Mini SD / SDHC / SDXC

1

2

Multi-in-1 Card Reader

The card reader allows you to use some of the latest digital storage cards. Push the
card into the slot and it will appear as a removable device, and can be accessed in
the same way as your hard disk (s). Make sure you install the Card Reader driver
(see “Card Reader” on page 4 - 7).

Note: Some of these cards require PC adapters that are usually supplied with the
cards.

2 - 6 Multi-in-1 Card Reader

Storage Devices, Mouse, & Audio



Volume Adjustment

The sound volume level
can be clicking using the
volume control icon
in the notification area
of the taskbar.

Figure 2 - 4

Realtek Audio

Manager

Right-click the icon
to access the menu
above.

See “HDMI Audio Configuration” on page C - 20 for a description of the audio configuration
when connecting an HDMI supported display device.

Audio Features

You can configure the audio options on your computer from the Sound control
panel in Windows, or from the Realtek HD Audio Manager icon in the taskbar
notification area/control panel (right-click the taskbar notification area icon to
bring up an audio menu). The volume may also be adjusted by means of the volume
icon in the taskbar or the audio slider in the Settings menu (see sidebar).

2

Audio Features 2 - 7

Storage Devices, Mouse, & Audio



Disabling Front Jack

Detection

It is recommended that

you do not disable front
panel jack detection in

Connector Settings .
Disabling front panel jack

detection may cause
your internal microphone
to become disabled, and
audio may continue to
play through the sys­tem’s internal speakers
even when headphones
are plugged-in to the
headphone jack (see
page 7 - 12).

Figure 2 - 5

Realtek Audio

Manager - Recording

Setup

2

Setup for Audio Recording

To record audio sources on your computer at optimum quality follow the instruc­tions below:

1. Go to the

2. Click Realtek HD Audio Manager (Hardware and Sound), or right-click the
taskbar icon and select Sound Manager.

3. Click Microphone Effects (tab) in Microphone (tab), and then click to select
Noise Suppression (button), or adjust the Recording Volume level to around 60,
to obtain the optimum recording quality.

4. Click OK to close the control panel and save the settings.

Control Panel

.

2 - 8 Audio Features

Storage Devices, Mouse, & Audio



Touchpad Cleaning

In order to improve pad
performance it is neces­sary to keep the surface
clean and free of finger­prints and marks etc.

Use a soft dry cleaning
cloth to keep the pad
surface clean.

Disabling the Pad

Use the Fn + F1 or Con­trol Center button to dis­able the Touchpad.

Touchpad and Buttons/Mouse

The Touchpad is an alternative to the mouse; however, you can also add a mouse to
your computer through one of the USB ports. The Touchpad buttons function in
much the same way as a two-button mouse.

2

Touchpad and Buttons/Mouse 2 - 9

Storage Devices, Mouse, & Audio



TouchPad Scrolling

This computer model se­ries may feature different
TouchPad versions.

These TouchPads may
differ in their vertical
scrolling function in most
scrollable windows.

Some TouchPads require
sliding the finger up and
down on the right of the
TouchPad to scroll the
window. Other versions
require tapping/holding
down the finger at the top
right or bottom right of the
TouchPad to scroll the
window.

Figure 2 - 6

Touchpad

Sensitivity



Mouse Driver

If you are using an external
mouse your operating system
may be able to auto-configure
your mouse during its installa­tion or only enable its basic
functions. Be sure to check
the device’s user documenta­tion for details.

2

Touchpad Sensitivity

The mouse button zones at the bottom of the pad measure about 15mm fr om the
bottom of the pad, and the left and right buttons are divided roughly down the mid-

dle as illustrated below. Press the left button zone for a left click, and right button
zone for a right click action.

2 - 10 Touchpad and Buttons/Mouse

Storage Devices, Mouse, & Audio



TouchPad Scrolling

This computer model se­ries may feature different
TouchPad versions.

These TouchPads may
differ in their vertical
scrolling function in most
scrollable windows.

Some TouchPads require
sliding the finger up and
down on the right of the
TouchPad to scroll the
window. Other versions
require tapping/holding
down the finger at the top
right or bottom right of the
TouchPad to scroll the
window.

Figure 2 - 7

Mouse Properties

Touchpad Configuration

Once you have installed the TouchPad driver (see “Touchpad” on page 4 - 7) you
can configure the functions from the Mouse control panel in Windows, or by d ouble­clicking the TouchPad driver icon in the notification area of the taskbar in the
Desktop app. You may then configure the TouchPad tapping, buttons, scrolling,
pointer motion and sensitivity options to your preferences. You will find further in­formation at www.synaptics.com.

2

Touchpad Configuration 2 - 11

Storage Devices, Mouse, & Audio



Show Video

You can get a clearer
view of the gestures in­volved by clicking the
Show Video option for
each gesture item.

Select the gesture (Pinch

Zoom, Rotating, Three
Fingers Down and
Three Finger Flick) in the
Device Settings > Set­tings left tree menu

and click the Show Video
button to see the demon­stration video.

For more details on any of
the gestures see the help
in the lower part of the
right menu window.

Figure 2 - 8

Mouse Properties -

Device Settings

2

Gestures and Device Settings

The Synaptics Gestures Suite application allows you to use a specific gesture (ac­tion) on the surface of the Touchpad to perform specific actions to manipulate doc­uments, objects and applications.

You can configure the settings from the Device Settings tab in Mouse Properties:

1. Go to the

2. Click Mouse (Hardware and Sound).

3. Click Device Settings (tab) and click Settings.

4. Use the menu tree on the lef t to access the user configurable settings.

Control Panel

.

2 - 12 Touchpad Configuration

Disabling the Touchpad

Figure 2 - 9

Mouse Properties

(Disable Touchpad)

If you need to disable the Touchpad for any reason (e.g. you may find that when us­ing the computer’s internal keyboard you accidentally trigger the Touchpad when
resting your wrists or palms on it) you can do so by using Fn + F1 key combination.

You can also set the system to automatically disable the internal Touchpad when an
external USB point device (e.g a USB mouse) is attached.

1. Go to the Mouse Properties control panel.

2. Click to select Device Settings (tab).

3. Click to place a check in the “Disable internal pointing device when external
USB pointing device is attached” check box.

4. Click OK to save the setting.

Storage Devices, Mouse, & Audio

2

Touchpad Configuration 2 - 13

Storage Devices, Mouse, & Audio



PalmCheck™

In order to improve
Clickpad/Touchpad
scrolling responsive­ness when using one­finger scrolling, you can
adjust the PalmCheck™
slider towards “Mini­mum” as per your pref­erence.

However bear in mind
that adjusting the slider
too far towards “Mini­mum” can turn off Palm­Check™ altogether.

Figure 2 - 10

PalmCheck™ Slider

2

PalmCheck™

The PalmCheck™ feature (Device Settings > Settings > Pointing > Sensitivity)
helps prevent operating the Clickpad/Touchpad by accident, by recognizing when
your palm is resting on it or brushing its surface while you are typing.

2 - 14 Touchpad Configuration

Storage Devices, Mouse, & Audio

Figure 2 - 11

Scrolling Gesture

Figure 2 - 12

Zooming Gesture

Scrolling

The Two-Finger scrolling feature works in most scrollable windows and allows you
to scroll horizontally and vertically. Place two fingers, slightly separated, on the
TouchPad surface and slide both fingers in the direction required (in a straight con­tinuous motion).

Zooming

The Pinch Zoom gesture can be used to perform the same function as a scroll wheel
in Windows applications that support CTRL + scroll wheel zoom functionality.
Place two fingers on the TouchPad (for best results use the tips of the fingers) and
slide them apart to zoom in, or closer together to zoom out.

2

Touchpad Configuration 2 - 15

Storage Devices, Mouse, & Audio

Figure 2 - 13

Rotating Gesture

Figure 2 - 14

Flick/Press

Gesture

2

Rotating

Use the Pivot Rotate gesture to rotate objects (e.g. photos) in 90 degree increments.
Place a finger down on the left “target” zone and keep it stationary. Place another
finger near the middle of the TouchPad and slide it in a circular motion around the
stationary finger (clockwise or counterclockwise) to rotate the object.

Three Finger-Flick/Three Fingers Down (Press)

The Three Finger-Flick gesture may be used to enhance navigation with a variety of
applications such as browsing the Internet or scrolling through a photo viewer. The
Three Fingers Down gesture may be used to launch user-selectable applications.

2 - 16 Touchpad Configuration

Chapter 3: Power Management



OS Note

Power management
functions will vary slight­ly depending on your
operating system. For
more information it is
best to refer to the user’s
manual of your operat­ing system.

Power Management

Overview

To conserve power, especially when using the battery, your computer power man­agement conserves power by controlling individual components of the computer
(the monitor and hard disk drive) or the whole system. This chapter covers:

• The Power Sources

• Turning On the Computer

• Power Plans

• Power-Saving States

• Configuring the Power Buttons

• Battery Information

The computer uses enhanced power saving techniques to give the operating system
(OS) direct control over the power and thermal states of devices and processors. For
example, this enables the OS to set devices into low-power states based on user set­tings and information from applications.

3

Overview 3 - 1

Power Management



Forced Off

If the system “hangs”,
and the Ctrl + Alt + Del
key combination doesn’t
work, press the power
button for 4 seconds, or
longer, to force the sys­tem to turn itself off.

3

The Power Sources

The computer can be powered by either an AC/DC adapter or a battery pack.

AC/DC Adapter

Use only the AC/DC adapter that comes with your computer. The wrong type of AC/
DC adapter will damage the computer and its components.

1. When first setting up the computer use the following procedure (as to
safeguard the computer during shipping, the battery will be locked to not power the
system until first connected to the AC/DC adapter and initially set up as below):

• Attach the AC/DC adapter cord to the DC-In jack on the right of the computer , then plug the AC

power cord into an outlet, and connect the AC power cord to the AC/DC a dapter and leave it there
for 6 seconds or longer.

• Remove the adapter cord from the computer’s DC-In jack, and then plug it back in again; the bat-

tery will now be unlocked.

2. Raise the lid/LCD to a comfortable viewing angle.

3. Press the power button to turn “On”.

Battery

The battery allows you to use your computer while you are on the road or when an
electrical outlet is unavailable. Battery life varies depending on the applications and
the configuration you're using. To increase battery life, let the battery discharge
completely before recharging (see “Battery FAQ” on page 3 - 21).

We recommend that you do not remove the battery. For more information on the bat­tery, please refer to “Battery Information” on page 3 - 17.

3 - 2 The Power Sources

Turning On the Computer



Power Button as Stand by or Hibernate Button

You can use the OS’s “Power Options” control panel to set the power button to send the
system into Stand by or Hibernate mode (see your OS’s documentation, or “Configuring

the Power Buttons” on page 3 - 9 for details).

Now you are ready to begin using your computer. To turn it on simply press the pow­er button on the front panel.

When the computer is on, you can use the power button as a Stand by/Hibernate/
Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and
holding the power button for longer than this will shut the computer down). Use
Power Options (Hardware and Sound) in the Windows control panel to configure
this feature.

Power Management

3

Turning On the Computer 3 - 3

Power Management

Figure 3 - 1

Shut Down/Restart

Shutting the Computer Down

Note that you should always shut your computer down by choosing the Shut down

3

command as this will help prevent hard disk or system problems. Use the Power
item in the Start Menu and select Shut down. If you want to add Hibernate/Sleep
to the Power Menu see “Adding Hibernate/Sleep to the Power Menu” on page 3 -

10.

You can also use the context menu (right-click the Start Menu
Windows logo + X key combination) to Sign out, Sleep, Hibernate, Shut
down, and Restart.

3 - 4 Shutting the Computer Down

icon or press the

Power Plans



Resuming

Operation

See Table 3 - 1, on

page 3 - 11 for informa-

tion on how to resume
from a power-saving
state.

Password

It is recommended that
you enable a password
on system resume in or­der to protect your data.

Figure 3 - 2

Power Plan

Advanced Settings

The computer can be configured to conserve power by means of power plans (Con­trol Panel > Power Options). You can use (or modify) an existing power plan, or

create a new one.
The settings may be adjusted to set the display to turn off after a specified time, and

to send the computer into Sleep after a period of inactivity.
Click Change plan settings and then click Change advanced power settings to ac-

cess further configuration options in Advanced Settings.

Power Management

3

Power Plans3-5

Power Management

Figure 3 - 3

Power Plans

Click to Show/Hide
additional
power plans

3

Each Windows power plan will also adjust the processor performance of your ma­chine in order to save power. This is worth bearing in mind if you are experiencing
any reduced performance (especially under DC/battery power).

Choose High performance (you may need to click Show additional plans to view
the High performance plan) for maximum performance when the computer is pow­ered from an AC power source. Choose the Power saver (bear in mind that this
scheme may slow down the overall performance of the computer in order to save
power) for maximum power saving when the computer is battery (DC power) pow­ered.

3 - 6 Power Plans

Power-Saving States



Wake On LAN

Support

Wake-On-LAN is only
supported from Sleep or

Hibernate states in
Windows.

If you require your com­puter to wake up from
network activity in Win­dows then make sure
that the computer is ei­ther in Sleep or Hiber-
nate.

Wake-On-LAN is not
supported from Shut­down states in Win-

dows.

You can use power-saving states to stop the computer’s operation and restart where
you left off. Windows 10 uses the Sleep, Hibernate and Shut Down power-saving
states.

Sleep

In Sleep all of your work, settings and preferences are saved to memory before the
system sleeps. When you are not using your computer for a certain length of time,
which you specify in the operating system, it will enter Sleep to save power.

The PC wakes from Sleep within seconds and will return you to where you last left
off (what was on your desktop) without reopening the application(s) and file( s) you
last used.

If your mobile PC in Sleep is running on battery power the system will use only a
minimum amount of power. After an extended period the system will save all the
information to the hard disk and shut the computer down before the battery becomes
depleted.

To add Sleep to the Power Menu see “Adding Hibernate/Sleep to the Power

Menu” on page 3 - 10.

Power Management

3

Power-Saving States 3 - 7

Power Management

Figure 3 - 4

Power Button &

Start Menu Power

Hibernate

Hibernate uses the least amount of power of all the power-saving states and saves

3

all of your information on a part of the hard disk before it turns the system off. If a
power failure occurs the system can restore your work from the hard disk; if a power
failure occurs when work is saved only to memory, then the work will be lost. Hi-
bernate will also return you to where you last left off within seconds. You should
put your mobile PC into Hibernate if you will not use the computer for a period of
time, and will not have the chance to charge the battery. To add Hibernate to the
Power Menu see “Adding Hibernate/Sleep to the Power Menu” on page 3 - 10.

Shut down

You should Shut down the computer if you plan to install new hardware, plan to be
away from the computer for several days, or you do not need it to wake up and run
a scheduled task. Returning to full operation from Shut down takes longer than from
Sleep or Hibernate.

3 - 8 Power-Saving States

Configuring the Power Buttons



Password

Protection

It is recommended that
you enable a password
on wake up in order to
protect your data.

However you can dis­able this setting from the
Power Options menu
by clicking Require a

password on wakeup

in the left menu, and se­lecting the options (click

Change settings that
are currently unavail­able).

Figure 3 - 5

Power Options

Define Power

Buttons

The power/sleep button (Fn + F12 key combo) and closed lid may be set to send the
computer in to a power-saving state. Click Choose what the power buttons do on
the left menu in Power Options to bring up the menu.

Power Management

3

Configuring the Power Buttons 3 - 9

Power Management

Figure 3 - 6

Power Options

Define Power

Buttons - Shutdown

Settings

3

Adding Hibernate/Sleep to the Power Menu

Add Hibernate/Sleep to the Power Menu as follows.

1. Go to the Power Options (Hardware and Sound) control panel.

2. Click “Change settings that are currently unavailable” .

3. Click Choose what the power buttons do.

4. Click to put a check in the Hibernate/Sleep box under Shutdown settings.

5. Click Save Changes and close the control panel.

3 - 10 Configuring the Power Buttons

Resuming Operation

Table 3 - 1

Resuming

Operation



Closing the Lid

If you have chosen to
send the computer to
Sleep when the lid is
closed, raising the lid
will wake the system up.



Power Button

When the computer is on, you can use the power button as a Sleep/Hibernate/Shut Down
hot key button when it is pressed for less than 4 seconds (pressing and holding the power
button for longer than this will force the computer to shut down).

You can resume operation from power-saving states by pressing the power button,
or in some cases pressing the sleep button (Fn + F12 key combo).

Power Status Icon Color T o Resume

Power Off Off Press the Power Button

Press the Power Button

Sleep Blinking White

Off (battery)

Hibernate

Orange (AC/DC adapter)

Display Turned Off White Press a Key or Move the Mouse/Touchpad

Press the Sleep Button (Fn + F12 Key

Combo)

Press the Power Button

Power Management

3

Configuring the Power Buttons 3 - 11

Power Management



Power Conservation

Modes

The Power Saving set-
ting will result in maxi­mum power saving, but
with the possible loss of
some performance.

Setting the mode to Bal-
ance will give power
saving matched with
performance.

Performance will give
optimum computer per­formance but with less
power conservation.

Note that the Energy
Star setting will put the
display into sleep after
no more than 15 min­utes of user inactivity.

Figure 3 - 7

Control Center

3

Power Conservation Modes

This system supports Power Saving power management features that place comput­ers (CPU, hard drive, etc.) into a low-power sleep modes after a designated period
of inactivity. Adjust Power Conservation Modes from the Control Center:

1. Press the Fn + Esc key combination to toggle the Control Center on/off.

2. Click either the Performance, Balanced or Power Saving button.

3 - 12 Configuring the Power Buttons

Ctrl + Alt + Delete Key Combination

Figure 3 - 8

Ctrl + Alt + Delete

Menu

You can use the CTRL + ALT + DEL key combination from almost any of the Win­dows 10 interfaces/Apps to bring up a full-screen displaying Lock, Switch User,

Sign out, Change a password and Task Manager options. If you click the Power
icon in the lower right corner of the screen a power management option menu ap­pears to display Sleep, Shut down, and Restart.

Power Management

3

To fully control all the power options (including Hibernate mode) go to the Power
Options control panel and configure the power button, sleep button and lid to per-

form the function selected.

Configuring the Power Buttons 3 - 13

3

Figure 3 - 9

Settings

Power Management

Settings Menu Power Controls

The Settings item in the Start Menu (or via the Action Center) gives you access to
a number of power settings control panels which enable you to quickly adjust power
options. Click System to access the menu including the power option settings.

3 - 14 Settings Menu Power Controls

Battery Saver

Figure 3 - 10

Settings > Battery >

Battery Saver

Battery in Settings will display the battery level, and by clicking Battery usage by
app you can see the current state of battery usage by application etc. The Battery
saver can be level can be adjust ed to be turned on if the battery level falls below a

certain level to limit background activity and push notifications.

Power Management

3

Settings Menu Power Controls 3 - 15

Power Management

Figure 3 - 11

Settings > Power &

Sleep

3

Power & Sleep

Power & sleep gives you quick access to Screen and Sleep settings. Click Addi­tional power settings to go to the main power options control panel.

3 - 16 Settings Menu Power Controls

Battery Information



Low Battery

Warning

When the battery is criti­cally low, immediately
connect the AC/DC
adapter to the computer
or save your work, oth­erwise, the unsaved
data will be lost when
the power is depleted.

Figure 3 - 12

Battery Icon

(Notification Area) &

Battery Advanced

Settings

Follow these simple guidelines to get the best use out of your battery.

Battery Power

Your computer’s battery power is dependent upon many factors, including the pro­grams you are running, and peripheral devices attached. You can set actions to be
taken (e.g. Shut down, Hibernate etc.), and set critical and low battery levels from
power plan Change plan settings > Change advanced power settings (see Figure

3 - 3 on page 3 - 6).

Click the battery icon in the notification area to see the current battery level and
charge status (you can also click Power & sleep settings to access the Settings
menu to quickly adjust power settings).

Power Management

3

Battery Information 3 - 17

Power Management



Windows Mobility

Center

The Windows Mobility
Center control panel

provides an easy point
of access for information
on battery status, power
plans used and wireless
device status etc.

Figure 3 - 13

Windows Mobility

Center

(Control Panel)

3

Conserving Battery Power

•Use a power plan that conserves power (e.g Power saver), however note that

this may have an affect on computer performance.

• Lower the brightness level of the LCD display. The system will decrease LCD

brightness slightly to save power when it is not powered by the AC/DC adapter.

• Reduce the amount of time before the display is turned off.

• Close wireless, Bluetooth, modem or co mmunication applications when they are

not being used.

• Disconnect/remove any unnecessary external devices e.g. USB devices,

ExpressCards etc.

3 - 18 Battery Information

Battery Life



Battery Removal

Note that the built-in
battery is not user re­movable. Removing the

battery will violate the
terms of your warranty.

If you need to remove
the battery for any rea­son, please contact your
distributor/supplier for
further information.

Battery life may be shortened through improper maintenance. To optimize the life
and improve its performance, fully discharge and recharge the battery at least
once every 30 days.

We should not remove the built-in battery yourself (see sidebar).

Power Management

3

New Battery

Always completely discharge, then fully charge, a new battery (see “Battery FAQ”

on page 3 - 21 for instructions on how to do this).

Recharging the Battery with the AC/DC Adapter

The battery pack automatically recharges when the AC/DC adapter is attached and
plugged into an electrical outlet. If the computer is powered on, and in use, it will
take several hours to fully recharge the battery. When the computer is turned off but
plugged into an electrical outlet, battery charge time is less. Refer to “LED Indica-

tors” on page 1 - 7 for information on the battery charge status, and to “Battery
FAQ” on page 3 - 21 for more information on how to maintain and properly re-

charge the battery pack.

Battery Information 3 - 19

Power Management



Caution

Danger of explosion if
battery is incorrectly re­placed.

Replace only with the
same or equivalent type
recommended by the
manufacturer. Discard
used battery according
to the manufacturer’s in­structions.



Damaged Battery Warning

Should you notice any physical defects (e.g. the battery is bent ou t of shape after being
dropped), or any unusual smells emanating from the notebook battery, shut your computer
down immediately and contact your distributor/supplier. If the battery has been dropped we
do not recommend using it any further, as even if the comp uter continues to work with a
damaged battery in place, it may cause circuit damage, which may possibly result in fire. It
is recommended that you replace your computer battery every two years.

Proper handling of the Battery Pack

• DO NOT disassemble the battery pack under any circumstances

• DO NOT expose the battery to fire or high temperatures, it may explode

3

• DO NOT connect the metal terminals (+, -) to each other

3 - 20 Battery Information
