Clevo M570U, M575U Concise User's Guide
Introduction (English)
This Concise User’s Guide introduces the main features
of your computer. The English version of this guide begins on page 1. The expanded User’s Manual is on the
Device Drivers & Utilities + User’s Manual CD-ROM.
Einführung (Deutsch)
Dieses Ausführliche Benutzerhandbuch führt Sie in die
Hauptfunktionen des Notebooks ein. Die deutsche Version des Handbuchs beginnt auf Seite 45. Das erweiterte
Benutzerhandbuch finden Sie auf der CD-ROM für die
Gerätetreiber und Hilfsprogramme (CD-ROM Device
Drivers & Utilities + User's Manual).
Présentation (Français)
Ce Guide Utilisateur Concis présente les fonctionnalités
principales de votre ordinateur. La version française de
ce guide commence à la page 89. Le Manuel de l'Utilisa-
teur étendu se trouve sur le CD-ROM de Pilotes & Utilitaires + Manuel de l'Utilisateur (CD-ROM Device
Drivers & Utilities + User's Manual).
Introducción (Español)
Esta Guía del Usuario Concisa le presenta las caracterís-
ticas principales de su ordenador. La versión española de
esta guía comienza en la página 133. El Manual del usua-
rio completo se encuentra en el CD-ROM de Controladores del dispositivo y Utilidades + Manual del usuario
(CD-ROM Device Drivers & Utilities + User's Manual).
Introduzione (Italiano)
La presente Guida Rapida per l'Utente introduce le caratteristiche principali del computer. La versione italiana di
questa guida inizia da pagina 177. Il Manuale utente
completo si trova nel CD contenente driver e utilità +
Manuale utente (CD-ROM Device Drivers & Utilities +
User's Manual).
I
Contents
Notice ................................................................................................1
About this Concise User Guide .........................................................2
Instructions for Care and Operation ..................................................3
System Startup ..................................................................................7
System Map: Front View with LCD Panel Open .............................9
System Map: Front View (Audio "DJ") ..........................................13
Audio "DJ" CD Player ....................................................................14
System Map: Rear View .................................................................15
System Map: Right View ................................................................16
System Map: Left View ..................................................................17
System Map: Bottom View .............................................................18
Windows XP Start Menu & Control Panel .....................................19
Video Features ................................................................................20
Audio Features ................................................................................23
Power Management Features ..........................................................24
Driver Installation ...........................................................................25
Troubleshooting ..............................................................................36
Specifications ..................................................................................37
Inhalt
Hinweis ...........................................................................................45
Über das Ausführliche Benutzerhandbuch .....................................46
Hinweise zu Pflege und Betrieb ......................................................47
Schnellstart ......................................................................................51
Systemübersicht: Ansicht von oben mit geöffnetem
LCD-Bildschirm ..............................................................................53
Systemübersicht: Ansicht von vorne (Audio "DJ") ........................57
Audio “DJ” CD-Player ....................................................................58
Systemübersicht: Rückansicht .........................................................59
Systemübersicht: Ansicht von rechts ..............................................60
Systemübersicht: Ansicht von links ................................................61
Systemübersicht: Ansicht von unten ...............................................62
Windows XP Startmenü und Systemsteuerung ...............................63
Grafikfunktionen .............................................................................64
Audiofunktionen ..............................................................................67
Energieverwaltungsfunktionen ........................................................68
Installation der Treiber ....................................................................69
Fehlerbehebung ................................................................................80
Technische Daten ...........................................................................81
Sommaire
Avertissement ..................................................................................89
A propos de ce Guide Utilisateur Concis ........................................90
Instructions d’entretien et d’utilisation ...........................................91
Guide de démarrage rapide .............................................................95
Carte du système : Vue du dessus avec l’écran LCD ouvert ..........97
Carte du système : Vue du face (Audio "DJ") ...............................101
Carte du système : Vue du arrière .................................................103
Carte du système : Vue droite .......................................................104
Carte du système : Vue gauche .....................................................105
Carte du système : Vue d’en dessous ............................................106
II
Menu Démarrer & Panneau de configuration de Windows XP ....107
Caractéristiques vidéo ...................................................................108
Caractéristiques de gestion de l’alimentation ...............................112
Installation du pilote .....................................................................113
Dépannage .....................................................................................124
Spécifications ................................................................................125
Contenidos
Aviso .............................................................................................133
Acerca de esta Guía del Usuario Concisa .....................................134
Instrucciones para el cuidado y funcionamiento ...........................135
Guía rápida para empezar .............................................................139
Mapa del sistema:Vista superior con panel LCD abierto .............141
Mapa del sistema: Vista frontal (Audio "DJ") ..............................145
Audio "DJ" CD Player ..................................................................146
Mapa del sistema: Vista posterior .................................................147
Mapa del sistema: Vista derecha ...................................................148
Mapa del sistema: Vista izquierda ................................................149
Mapa del sistema: Vista inferior ...................................................150
Menú Inicio y Panel de control de Windows XP ..........................151
Parámetros de vídeo ......................................................................152
Características de audio ................................................................155
Funciones de administración de energía .......................................156
Instalación de controladores .........................................................157
Solución de problemas ..................................................................168
Especificaciones ............................................................................169
Sommario
Avviso ...........................................................................................177
Informazioni sulla Guida Rapida per l'Utente ...............................178
Istruzioni per la custodia e il funzionamento ................................179
Guida di avvio rapido ....................................................................183
Descrizione del sistema: Vista superiore con pannello LCD aperto ...
185
Descrizione del sistema: Vista anteriore (Audio "DJ") .................189
Lettore CD audio "DJ" ..................................................................190
Descrizione del sistema: Vista posteriore .....................................191
Descrizione del sistema: Vista destra ............................................192
Descrizione del sistema: Vista sinistra ..........................................193
Descrizione del sistema: Vista inferiore ........................................194
Menu Start e Pannello di controllo di Windows XP .....................195
Funzioni video ...............................................................................196
Funzionalità audio .........................................................................199
Funzioni di risparmio energetico ...................................................200
Installazione driver ........................................................................201
Risoluzione dei problemi ..............................................................212
Specifiche tecniche ........................................................................213
III
IV
Concise User’s Guide
Notice
The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this
publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.
This publication and any accompanying software may not, in whole or in part, be reproduced, translated, transmitted
or reduced to any machine readable form without prior consent from the vendor, manufacturer or creators of this publication, except for copies kept by the user for backup purposes.
Brand and product names mentioned in this publication may or may not be copyrights and/or registered trademarks
of their respective companies. They are mentioned for identification purposes only and are not intended as an endorsement of that product or its manufacturer.
©May 2006
Trademarks
This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents
and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home or other limited
viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is
prohibited.
Intel, Pentium, and Intel Core are trademarks/registered trademarks of Intel Corporation.
is a trademark of SRS Labs, Inc.
WOW technology is incorporated under license from SRS Labs, Inc.
English
Notice - 1
Concise User’s Guide
About this Concise User Guide
This quick guide is a brief introduction to getting your system started. This is a supplement, and not a substitute for
the expanded English language User’s Manual in Adobe Acrobat format on the Device Drivers & Utilities + User’s
Manual CD-ROM supplied with your computer. This CD-ROM also contains the drivers and utilities necessary for
English
the proper operation of the computer.
Some or all of the computer’s features may already have been setup. If they aren’t, or you are planning to re-configure
(or re-install) portions of the system, refer to the expanded User’s Manual. The Device Drivers & Utilities + User’s
Manual CD-ROM does not contain an operating system.
Regulatory Information
Regulatory notices and information are contained in the expanded User’s Manual on the Device Drivers & Utilities
+ User’s Manual CD-ROM.
Video Card Options
Note that video card types, specifications and drivers are subject to continual updates and changes. Check with your service center for the latest details on video cards supported (also see the Device Drivers & Utilities + User’s Manual CD-
ROM ).
2 - About this Concise User Guide
Concise User’s Guide
Instructions for Care and Operation
The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions:
1. Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged.
2. Keep it dry, and don’t overheat it. Keep the computer and power supply away from any kind of heating element. This
is an electrical appliance. If water or any other liquid gets into it, the computer could be badly damaged.
3. Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong
magnetic fields. These can hinder proper performance and damage your data.
4. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save
your work. Remember to periodically save your data as data may be lost if the battery is depleted.
5. Take care when using peripheral devices.
Wireless Device Operation Aboard Aircraft
The use of any portable electronic transmission devices aboard aircraft is usually prohibited. Make sure the modules are OFF
if you are using the computer aboard aircraft.
English
Instructions for Care and Operation - 3
Concise User’s Guide
Power Safety
The computer has specific power requirements:
• Only use an AC/DC adapter approved for use with this computer.
• Your AC/DC adapter may be designed for international travel but it still requires a steady, uninterrupted power supply.
English
If you are unsure of your local power specifications, consult your service representative or local power company.
• The AC/DC adapter may have either a 2-prong or a 3-prong grounded plug. The third prong is an important safety
feature; do not defeat its purpose. If you do not have access to a compatible outlet, have a qualified electrician install
one.
• When you want to unplug the power cord, be sure to disconnect it by the plug head, not by its wire.
• Make sure the socket and any extension cord(s) you use can support the total current load of all the connected devices.
• Before cleaning the computer, make sure it is disconnected from any external power supplies.
Power Safety Warning
Before you undertake any upgrade procedures, make sure that you have turned off the power, and disconnected all peripherals
and cables (including telephone lines). It is advisable to also remove your battery in order to prevent accidentally turning the
machine on.
4 - Instructions for Care and Operation
Concise User’s Guide
Cleaning
Do not apply cleaner directly to the computer, use a soft clean cloth. Do not use volatile (petroleum distillates) or
abrasive cleaners on any part of the computer.
Servicing
Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock. Refer all servicing to authorized service personnel. Unplug the computer from the power supply. Refer servicing to qualified service personnel under any of the following conditions:
• When the power cord is damaged or frayed.
• If the computer has been exposed to rain or other liquids.
• If the computer does not work normally when you follow the operating instructions.
• If the computer has been dropped or damaged (do not touch the poisonous liquid if the LCD panel breaks).
• If there is an unusual odor, heat or smoke coming from your computer.
Power Off Before Traveling
Make sure that your notebook is completely powered off before putting it into a travel bag (or any such container). Putting a
notebook which is powered on in a travel bag may cause the vent(s)/fan intake(s) to be blocked. To prevent your computer from
overheating make sure nothing blocks the vent(s)/fan intake(s) while the computer is in use.
English
Instructions for Care and Operation - 5
Concise User’s Guide
Battery Precautions
• Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer.
• Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way.
Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may pos-
English
sibly result in fire.
• Recharge the batteries using the notebook’s system. Incorrect recharging may make the battery explode.
• Do not try to repair a battery pack. Refer any battery pack repair or replacement to your service representative or qualified service personnel.
• Keep children away from, and promptly dispose of a damaged battery. Always dispose of batteries carefully. Batteries
may explode or leak if exposed to fire, or improperly handled or discarded.
• Keep the battery away from metal appliances.
• Affix tape to the battery contacts before disposing of the battery.
• Do not touch the battery contacts with your hands or metal objects.
Battery Disposal & Caution
The product that you have purchased contains a rechargeable battery. The battery is recyclable. At the end of its useful life, under
various state and local laws, it may be illegal to dispose of this battery into the municipal waste stream. Check with your local
solid waste officials for details in your area for recycling options or proper disposal.
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Discard used battery according to the manufacturer’s instructions.
6 - Instructions for Care and Operation
Concise User’s Guide
System Startup
1. Remove all packing materials.
2. Place the computer on a stable surface.
3. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports.
4. Attach the AC/DC adapter to the DC-In jack at the rear of the computer, then plug the AC power cord into an outlet,
and connect the AC power cord to the AC/DC adapter.
5. Move the LCD latches at the front of the computer outwards towards the
sides of the computer, and hold the right latch in place to release the top
cover.
6. Raise the lid/LCD to a comfortable viewing angle, and press the power
button (make sure the Audio "DJ" player is turned off) to turn the
computer “on”.
7. Adjust the LCD panel to a comfortable viewing angle.
8. The LED indicators show the power and battery status of the computer,
give notification of e-mail received, and display information on the power
status of the PC Camera, Bluetooth and Wireless LAN modules.
Figure 1 - Computer With AC/DC Adapter Plugged In
Shutdown
Please note that you should always shut your computer down by choosing the Turn Off Computer command from the Start menu
in Windows. This will help prevent hard disk or system problems.
English
System Startup - 7
Concise User’s Guide
Model Differences
This notebook series includes two different design types, however only one design is pictured in this guide.
System Software
Operating Systems (e.g. Windows XP etc.) and applications (e.g. word processing, spreadsheet and database pro-
English
grams) have their own manuals, so please consult the appropriate manuals. Your computer may already come with
system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find this manual refers to the following operating systems:
• Microsoft Windows XP Home & Professional Editions (with Service Pack 2)
• Microsoft Windows XP Media Center Edition
Further information on installing the drivers and utilities is available in Chapters 4 & 7 of the expanded User’s Man-
ual on the Device Drivers & User’s Manual CD-ROM.
Drivers
If you are installing/re-installing new system software, you will need to install the appropriate drivers. Drivers are programs which
act as an interface between the computer and a hardware component e.g. a wireless network module. It is very important that
you install the drivers in the order listed in Table 5 on page 25. You will be unable to use most advanced controls until the necessary drivers and utilities are properly installed.
8 - System Startup
Concise User’s Guide
System Map: Front View with LCD Panel Open
Wireless Device
Operation Aboard
Aircraft
The use of any portable
electronic transmission
devices (e.g. WLAN or
Bluetooth) aboard aircraft is usually prohibited.
Make sure any wireless
modules are OFF if you
are using the computer
aboard aircraft.
Use the key combinations to toggle power to
the WLAN/Bluetooth
modules, and check the
status indicator/taskbar
icon to see if the modules
are powered on or not
(see Table 1, on
page 10).
1
2
3
4
5
6
7
9
7
1. Optional Built-In PC Camera
2. LCD
3. Hot Key Buttons
4. Power Button
5. Keyboard
6. TouchPad and Buttons
7. Audio "DJ" Controls
8. Built-In Microphone
9. Audio "DJ" LED Display Panel
(Including LED Indicators)
Audio "DJ" & Power Button
Make sure that the Audio "DJ"
player is off before pressing the
power button to turn the computer
on.
8
English
Figure 2 - Front View with LCD Panel Open
System Map: Front View with LCD Panel Open - 9
Concise User’s Guide
LED Indicators
The LED indicators on the computer display helpful information about the current status of the computer.
Icon Color Description
Orange The Battery is Charging
English
Icon Color Description
Green The Computer is On
Blinking
Green
Green The AC/DC Adapter is Plugged In
Green Number Lock is Activated
Green Caps Lock is Activated
Green Scroll Lock is Activated
The Computer is In Stand by Mode
10 - System Map: Front View with LCD Panel Open
Blinking
Orange
Green The Battery is Fully Charged
Green Hard Disk Activity
Green
Green The Bluetooth Module is Powered On
Green The WLAN Module is Powered On
Blinking
Amber
The Battery has Reached Critically
Low Power Status
Second Battery Indicator
(Colors Displayed as Above)
The PC Camera Module is Powered
On
New Mail Has Arrived
Table 1 - LED Indicators
Concise User’s Guide
Hot-Key Buttons
These buttons give instant access to the default Internet
browser and e-mail program, and to a user-defined application, with one quick button press. To use the “user-defined application Hot-Key Button”, you must install the
driver (see “Hot-Key Buttons” on page 30).
Hot-Key Button Function
Activate the Default E-Mail Browser
Activate the Default Internet Program
Activate the user specified application
e.g. Microsoft Word or Excel
Table 2 - Hot Key Buttons
Function Keys & Numeric Keypad
The Fn key (on the bottom-left of the keyboard) allows
you to change operational features instantly. To use the
functions press and hold the Fn key, then press the appropriate function key (F1 - F11 etc.) located on your keyboard (see Table 3
includes a numerical keypad (on the right side of the keyboard) for easy numeric data input. Pressing the Num Lk
key turns on/off the numeric keypad (see Figure 3
page 12).
on page 12). The keyboard also
on
English
System Map: Front View with LCD Panel Open - 11
Concise User’s Guide
Keys Description
Fn + F1 TouchPad Toggle
English
Fn + F2
Fn + F3 Mute Toggle
Fn + F4 Sleep Toggle
Fn + F5 Decrease Audio Volume
Fn + F6 Increase Audio Volume
Fn + F7 Display Toggle
Fn + F8 Decrease LCD Brightness
Fn + F9 Increase LCD Brightness
Fn + F10 PC Camera Toggle
Fn + F11 WLAN Module Toggle
Fn + F12 Bluetooth Module Toggle
Fn + Scr
Fan Automatic Control / Full
Power
Lk
Scroll Lock Toggle
Table 3 - Function Keys
Figure 3 - Keyboard
Function Keys
Num Lk / Scr Lk Key
Numeric
Keypad
Fn Key
Other Keyboards
If your keyboard is damaged or you just want to make a change, you can use any
standard USB keyboard. The system will detect and enable it automatically.
However special functions/hot keys unique to the system’s regular keyboard may
not work.
12 - System Map: Front View with LCD Panel Open
Concise User’s Guide
System Map: Front View (Audio "DJ")
1 2 3 4 5 6 7 8 9
10
11
Audio "DJ" MP3 Track Limit
There is a track limit of 256 tracks on any MP3 CD/
DVD. This means that only the first 256 tracks may be
played on any MP3 CD/DVD.
Audio "DJ" & Power Button
Make sure that the Audio "DJ" player is off before
pressing the power button to turn the computer on.
12 13
Figure 4 - Front View (Audio "DJ")
1. Audio "DJ" Power Button
2. Volume Down
3. Volume Up
4. Repeat
5. LED Display
6. Previous Track
7. Next Track
8. Play/Pause
9. Stop (Press Twice To Eject The CD/DVD)
10. Repeat Mode Indicator
11. Track Indicator
12. Time Indicator
13. Disc Indicator
English
System Map: Front View (Audio "DJ") - 13
Concise User’s Guide
Audio "DJ" CD Player
The built-in standalone audio CD player gives direct
hardware control for audio CDs/DVDs when the computer is shut down, but has a working power source.
English
1. Make sure that the computer is shut down (i.e. the
operating system is not running) but you have a working power source (either battery or AC Power).
2. Press the Audio "DJ" power button.
3. Press the open button on your CD/DVD device (or
press the stop button twice) and carefully place an
audio CD onto the disc tray with label-side facing up
(DVD drives will also play audio CDs).
4. Gently push the CD/DVD tray in until its lock “clicks”
and you are ready to start.
5. The Disc Indicator will flash while data is being
accessed.
6. The LED will display the number of tracks.
7. Press the play/pause button to start the CD/DVD.
8. Control the CD/DVD tracking and volume from the
control panel.
9. Use the stop button to stop the disc, or press it twice to
eject the disk.
10. Press the power button again to turn the player off.
9
TV Tuner Option
If you have included the optional TV Tuner in your purchase configuration, you can use the supplied remote
control unit to control the Audio "DJ".
Disk Eject Warning
Don’t try to eject a CD/DVD while the system is accessing it. This may cause the system to “crash”. Stop the
disk first then eject it, or press the stop button twice.
14 - Audio "DJ" CD Player
Concise User’s Guide
System Map: Rear View
1
243
Overheating
To prevent your computer from overheating make sure nothing blocks the Vent/
Fan Intake while the computer is in use.
USB Ports
Note that the connections to the USB ports only fit one way, do not force them.
7-Pin S-Video-Out Jack
The 7-pin S-Video Out Jack requires an adapter cable (7-pin S-Video plug to 4-pin
S-Video jack adapter) in order to connect to a standard S-Video cable.
5
English
7 8
6
9
10 11
Figure 5 - Rear View
1. Vent/Fan Intake
2. S/PDIF-Out Jack
3. Line-In Jack
4. 2 * USB 2.0 Ports
5. DVI-Out Port
6. TV Antenna Jack (Enabled With
TV Tuner Only)
7. RJ-11 Phone Jack
8. RJ-45 LAN Jack
9. 7-Pin S-Video-Out Jack
10. DC-In Jack
11. Serial Port
System Map: Rear View - 15
Concise User’s Guide
System Map: Right View
Figure 6 - Right View
1. Headphone-Out Jack
English
2. Microphone-In Jack
3. 7-in-1 Card Reader
4. Express Card Slot
5. Mini-IEEE 1394 Port
6. 2 * USB 2.0 Ports
7. Speaker
4
1 2 3
5 6
Mini-IEEE 1394 Port
Both Mini-IEEE 1394 ports only support SELF POWERED IEEE 1394 devices.
ExpressCard Slot
7
USB Ports
Note that the connections to
the USB ports only fit one
way, do not force them.
16 - System Map: Right View
The ExpressCard Slot accepts either ExpressCard/34 or ExpressCard/54 formats.
7-in-1 Card Reader
The card reader allows you to use the most popular digital storage card formats:
MMC (MultiMedia Card) / SD (Secure Digital) / MS (Memory Stick) /
MS Pro (Memory Stick Pro) / MS Duo (requires PC adapter) /
Mini SD (requires PC adapter) / RS MMC (requires PC adapter)
Concise User’s Guide
System Map: Left View
2
1
2nd Battery Notes
Note that the 2nd battery is designed to optimize and boost the
power performance of the system.
The system WILL NOT boot up from the 2nd battery alone. Use
either the AC/DC adapter or main battery to boot up the system.
The system DOES NOT support the Hot Swap function. Save
your work and shut the system down before swapping batteries.
CD/DVD Emergency Eject
If you need to manually eject a CD/DVD (e.g. due to an unexpected power interruption) you may push the end of a straightened paper clip into the emergency eject hole. Do not use a sharpened
pencil or any object that may break and become lodged in the
hole.
Don’t try to remove a floppy disk/CD/DVD while the system is accessing it. This may cause the system to “crash”.
Figure 7 - Left View
1. Security Lock Slot
3
2. Speaker
3. Device Bay
(for Optical Device, or 2nd SATA
Hard Disk, or 2nd Battery)
Changing DVD Regional Codes
Go to the Control Panel and double-click System > Hardware
(tab), click Device Manager, then click the + next to DVD/CD-
ROM drives. Double-click on the DVD-ROM device to bring up
the Properties dialogue box, and select the DVD Region (tab)
to bring up the control panel to allow you to adjust the regional
code.
DVD region detection is device dependent, not OS-dependent.
You can select your module’s region code 5 times. The fifth selection is permanent, and cannot be altered.
SATA RAID Configuration
See the Device Drivers & Utilities + User’s Manual CD-ROM
for details on setting up the SATA RAID configuration.
English
System Map: Left View - 17
Concise User’s Guide
System Map: Bottom View
Figure 8 - Bottom View
1. Vent/Fan Intake
English
2. Battery
3. Optical Device Release Latches
4. Video Card / HDD / RAM Bay Cover
5. Infrared & Consumer Infrared Transceiver
6. Sub Woofer
6
1
2
1
4
3
5
3
Battery Information
Always completely discharge, then fully charge, a new battery before using it. Completely discharge and charge the battery at
least once every 30 days or after about 20 partial discharges.
18 - System Map: Bottom View
Concise User’s Guide
Windows XP Start Menu & Control Panel
Most of the control panels, utilities and programs within Windows XP (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a
shortcut will usually be placed in the Start menu and/or the desktop. You can customize the look of the Start menu
by right-clicking the Start menu and selecting Properties from the menu.
Click here to toggle Category View
Figure 9 - Start Menu & Control Panel
In many instances throughout this manual you will see an instruction to open the Control Panel. The Control Panel
is accessed from the Start menu, and it allows you to configure the settings for most of the key features in Windows
(e.g. power, video, network, audio etc.). Windows XP provides basic controls for many of the features, however many
new controls are added (or existing ones are enhanced) when you install the drivers listed in Table 5, on page 25. To
see all controls it may be necessary to toggle off Category View.
English
Windows XP Start Menu & Control Panel - 19
Concise User’s Guide
Video Features
This computer features different PCI Express video cards (see the Device Drivers & Utilities + User’s Manual
CD-ROM for the latest details and driver installation instructions etc. for video cards other than that listed
here
), depending on your purchase option. You can switch display devices, and configure display options, from the
English
Display Properties control panel in Windows as long as the appropriate video driver is installed.
To access Display Properties in Windows:
1. Click Start, point to Settings and click Control Panel (or just click Control Panel).
2. Double-click Display (icon) - In the Appearances and Themes category.
3. Click Settings (tab) in the Display Properties dialog box.
4. Move the slider to the preferred setting in Screen area/resolution (Figure 10 on page 21).
5. Click the arrow, and scroll to the preferred setting In Colors/Color quality (Figure 10 on page 21).
6. You can also access Display Properties by right-clicking the desktop and scrolling down and clicking Properties.
Click Settings (tab) and adjust as above.
7. Open the Display Properties control panel, and click Advanced (button) (Figure 10 on page 21) to bring up the
Advanced properties tabs.
8. The most advanced video controls are available from the ATI CATALYST(R) Control Center (tab) control panel.
1
2
3
20 - Video Features
Concise User’s Guide
English
1
2
3
Video Card Options
Note that card types, specifications and drivers are subject to continual updates and changes. Check with your service center for
the latest details on video cards supported (also see the Device Drivers & Utilities + User’s Manual CD-ROM ).
Figure 10 - Display Properties Desktop
Video Features - 21
Concise User’s Guide
Display Devices & Options
Besides the built-in LCD, you can also use an external VGA monitor (CRT)/external Flat Panel Display or TV as
your display device. A VGA monitor/Flat Panel Display connects to the DVI-Out port
a DVI to VGA converter)
, a TV to the 7-pin S-Video-Out jack. The following display modes are available:
(a VGA monitor may require
English
ATI Display Mode Description
Single One display device is used.
Clone Mode Both connected displays output the same view.
Extended Mode Both connected displays are treated as separate devices, and act as a virtual desktop.
Stretched Mode Both connected displays are treated as a single device, and act as a virtual desktop.
Table 4 - Display Options
22 - Video Features
Concise User’s Guide
Audio Features
You can configure the audio options on your computer from the Sounds and Audio Devices Windows control
panel, or from the Realtek HD Audio Manager icon in the taskbar/control panel (double-click the icon to bring
up the Realtek Audio Configuration menus). The volume may also be adjusted by means of the Fn + F5/F6 key combination.
8 Channel Sound Support
If you wish to configure your system for 8 channel sound support,
then the following ports should be used as outputs. Connect the
system cables to the following audio jacks:
• Side Speaker Out - Connect to S/PDIF Out (Black)
• Center/Subwoofer Speaker Out - Connect to Microphone In (Pink)
• Front Speaker Out - Connect to Speaker/Headphone Out (Green)
• Rear Speaker Out - Connect to Line In (Blue)
Sound Volume Adjustment
How high the sound volume can be set depends on the setting of
the volume control within Windows. Click the Volume icon on the
taskbar to check the setting.
Figure 11
Realtek Audio Control Panel
English
Audio Features - 23
Concise User’s Guide
Power Management Features
The Power Options control panel icon in Windows (see page 19) allows you to configure power management features for your computer. You may conserve power through individual components such as the monitor or hard disk
(by means of Power Schemes), or you may use either Stand by or Hibernate mode to conserve power throughout
English
the system (enable Hibernate support from the control panel as pictured in Figure 12).
Figure 12 - Power Options
The computer’s power button, sleep button (Fn + F4 key combination), and lid (closing the lid) may be set to send
the computer in to either Stand by or Hibernate mode.
24 - Power Management Features
Loading...
