Clevo C4100 User guide

V10.1.20

Preface

Notice

The company reserves the right to revise this publication or to change its contents without notice. Information
contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or
any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear
in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse)
of this publication.
This publication and any accompanying software may not, in whole or in part, be reproduced, translated, trans­mitted or reduced to any machine readable form without prior consent from the vendor, manufacturer or creators
of this publication, except for copies kept by the user for backup purposes.
Brand and product names mentioned in this publication may or may not be copyrights and/or registered trade­marks of their respective companies. They are mentioned for identification purposes only and are not intended
as an endorsement of that product or its manufacturer.
©March 2010

Trademarks

Intel, Celeron, and Intel Core are trademarks/registered trademarks of Intel Corporation.

I

Preface

R&TTE Directive

This device is in compliance with the essential requirements and other relevant provisions of the R&TTE Direc­tive 1999/5/EC.

This device will be sold in the following EEA countries: Austria, Italy, Belgium, Liechtenstein, Denmark, Lux­embourg, Finland, Netherlands, France, Norway, Germany, Portugal, Greece, Spain, Iceland, Sweden, Ireland,
United Kingdom, Cyprus, Czech Republic, Estonia, Hungary, Latvia, Lithuania, Malta, Slovakia, Poland, Slov­enia.

II

Preface

FCC Statement

(Federal Communications Commission)

You are cautioned that changes or modifications not expressly approved by the party responsible for comp liance
could void the user's authority to operate the equipment.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not in­stalled and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Re orient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the service representative or an experienced radio/TV technician for help.

Operation is subject to the following two conditions:

1. This device may not cause interference.
And

2. This device must accept any interference, including interference that may cause undesired operation of the

device.

III

Preface

FCC RF Radiation Exposure Statement:

1. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

2. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This

equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator
and your body.



Warning

Use only shielded cables to connect I/O devices to this equipment. You are cautioned that changes or modifications not ex­pressly approved by the manufacturer for compliance with the above standard s could void your authority to operate the
equipment.

If your purchase option includes both Wireless LAN and 3.75G modules, then the appropriate antennas will be installed.
Note that In order to comply with FCC RF exposure compliance requirements, the antenna must not be co-located or operate
in conjunction with any other antenna or transmitter.

IV

Preface

IMPORTANT SAFETY INSTRUCTIONS

Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury
to persons when using any electrical equipment:

1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sin k or laundry tub, in a wet

basement or near a swimming pool.

2. Avoid using this equipment with a telephone line (other than a cordless type) during an electrical storm. There

may be a remote risk of electrical shock from lightning.

3. Do not use the telephone to report a gas leak in the vicinity of the leak.

4. Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may

explode. Check with local codes for possible special disposal instructions.

5. This product is intended to be supplied by a Listed Power Unit with an AC Input of 100 - 240V, 50 - 60Hz, DC

Output of 19V, 3.42A or 18.5V, 3.5A (65 Watts) minimum AC/DC Adapter.

CAUTION

Always disconnect all telephone lines from the wall outlet before servicing or disassembling this equipment.

TO REDUCE THE RISK OF FIRE, USE ONLY NO. 26 AWG OR LARGER,

TELECOMMUNICATION LINE CORD

This Computer’s Optical Device is a Laser Class 1 Product

V

Preface

Instructions for Care and Operation

The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions:

1. Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged.

Do not expose the computer
to any shock or vibration.

Do not place it on an unstable
surface.

Do not place anything heavy
on the computer.

2. Keep it dry, and don’t overheat it. Keep the computer and power supply away from any kind of heating ele-

ment. This is an electrical appliance. If water or any other liquid gets into it, the computer could be badly dam­aged.

Do not expose it to excessive
heat or direct sunlight.

Do not leave it in a place
where foreign matter or mois­ture may affect the system.

Don’t use or store the com­puter in a humid environment.

Do not place the computer on
any surface that will block the
Vents/Fan Intakes.

VI

Preface

3. Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other

strong magnetic fields. These can hinder proper performance and damage your data.

4. Follow the proper workin g procedu res for t he comput er. Shut the computer down properly and don’t for ge t

to save your work. Remember to periodically save your data as data may be lost if the battery is depleted.

Do not turn off the power
until you properly shut down
all programs.

Do not turn off any peripheral
devices when the computer is
on.

5. Take care when using peripheral devices.

Use only approved brands of
peripherals.

Do not disassemble the com­puter by yourself.

Unplug the power cord befor e
attaching peripheral devices.

Perform routine maintenance
on your computer.

VII

Preface

Power Safety

The computer has specific power requirements:

•Only use a power adapter approved for use with this computer.



Power Safety

Warning

Before you undertake
any upgrade proce­dures, make sure that
you have turned off the
power, and discon­nected all peripherals
and cables (including
telephone lines). It is
advisable to also re­move your battery in
order to prevent acci­dentally turning the
machine on.

•Your AC/DC adapter may be designed for international travel but it still requires a steady,
uninterrupted power supply. If you are unsure of your local power specifications, consult
your service representative or local power company.

•The power adapter may have either a 2-prong or a 3-prong grounded plug. The third prong
is an important safety feature; do not defeat its purpose. If you do not have access to a com­patible outlet, have a qualified electrician install one.

•When you want to unplug the power cord, be sure to disconnect it by the plug head, not by
its wire.

•Make sure the socket and any extension cord(s) you use can support the total current load
of all the connected devices.

•Before cleaning the computer, make sure it is disconnected from any external power sup­plies (i.e. AC/DC adapter or car adapter).

Do not plug in the power
cord if you are wet.

Do not use the power cord if
it is broken.

Do not place heavy objects
on the power cord.

VIII

Preface

Battery Precautions

• Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer.

• Do not remove any batteries from the computer while it is powered on.

• Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even

if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly
result in fire.

• If you do not use the battery for an extended period, then remove the battery from the computer for storage.

• Recharge the batteries using the notebook’s system. Incorrect recharging may make the battery explode.

• Do not try to repair a battery pack. Refer any battery pack repair or replacement to your service repre sent ative or qual-

ified service personnel.

• Keep children away from, and promptly dispose of a damaged battery. Always dispose of batteries carefully. Batteries

may explode or leak if exposed to fire, or improperly handled or discarded.

• Keep the battery away from metal appliances.

• Affix tape to the battery contacts before disposing of the battery.

• Do not touch the battery contacts with your hands or metal objects.



Battery Disposal & Caution

The product that you have purchased contains a rechargeable battery. The battery is recyclable. At the end of its useful life,
under various state and local laws, it may be illegal to dispose of this battery in to the municipal waste stream. Check with
your local solid waste officials for details in your area for recycling options or proper disposal.

Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalen t type recommended by the
manufacturer. Discard used battery according to the manufacturer’s instructions.

IX

Preface

Cleaning

Do not apply cleaner directly to the computer; use a soft clean cloth.
Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer.

Servicing

Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the
computer to electric shock. Refer all servicing to authorized service personnel. Unplug the computer from the
power supply. Then refer servicing to qualified service personnel under any of the following conditions:

• When the power cord or AC/DC adapter is damaged or frayed.

• If the computer has been exposed to rain or other liquids.

• If the computer does not work normally when you follow the operating instructions.

• If the computer has been dropped or damaged (do not touch the poisonous liquid if the LCD panel breaks).

• If there is an unusual odor, heat or smoke coming from your computer.



Removal Warning

When removing any cover(s) and screw(s) for the purposes of device upg rade, remember to replace the cover(s) and
screw(s) before turning the computer on.

X

Preface

Travel Considerations

Packing

As you get ready for your trip, run through this list to make sure the system is ready to go:

1. Check that the battery pack and any spares are fully charged.

2. Power off the computer and peripherals.

3. Close the display panel and make sure it’s latched.

4. Disconnect the AC/DC adapter and cables. Stow them in the carrying bag.

5. The AC/DC adapter uses volt ages from 100 to 240 volt s so you won’t need a second volt age adapter. However ,

check with your travel agent to see if you need any socket adapters.

6. Put the notebook in its carrying bag and secure it with the bag’s straps.

7. If you’re taking any perip herals (e.g. a printer, mouse or digital camera), pack them and those devices’ adapters

and/or cables.

8. Anticipate customs - Some jurisdictions may have import restrictions or requ ire proof of ownershi p for both hard -

ware and software. Make sure your documents are prepared.



Power Off Before Traveling

Make sure that your notebook is completely powered off before putting it into a travel bag (or any such container). Putting a
notebook which is powered on in a travel bag may cause the vent(s)/fan intake(s)/outlet(s) to be blocked. To prev ent your
computer from overheating make sure nothing blocks the vent(s)/fan intake(s)/outlet(s) while the computer is in use.

XI

Preface

On the Road

In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting,
keep these points in mind:

Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very
common. Don’t check it with normal luggage. Baggage handlers may not be sufficiently careful. Avoid knock­ing the computer against hard objects.

Beware of Electromagnetic fields - Devices such as metal detectors & X-ray machines can damage the com­puter, hard disk, floppy disks, and other media. They may also destroy any stored data - Pass your computer and
disks around the devices. Ask security officials to hand-inspect them (you may be asked to turn it on). Note:
Some airports also scan luggage with these devices.

Fly safely - Most airlines have regulations about the use of computers and other electronic devices in flight.
These restrictions are for your safety, follow them. If you stow the notebook in an overhead compartment, make
sure it’s secure. Contents may shift and/or fall out when the compartment is opened.

Get power where you can - If an electrical outlet is available, use the AC/DC adapter and keep your battery(ies)
charged.

Keep it dry - If you move quickly from a cold to a warm location, water vapor can condense inside the computer.
Wait a few minutes before turning it on so that any moisture can evaporate.

XII

Preface

Developing Good Work Habits

Developing good work habits is important if you need to work in front of the computer for long periods of time.
Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or
other joints. The following are some tips to reduce the strain:

• Adjust the height of the chair and/or desk so that the keyboard is at or slightly belo w the

level of your elbow. Keep your forearms, wrists, and hands in a relaxed position.

• Your knees should be slightly higher than your hips. Place your feet flat on the floor or on

a footrest if necessary.

• Use a chair with a back and adjust it to support your lower back comfortably.

• Sit straight so that your knees, hips and elbows form approximately 90-degree angles

when you are working.

• Take periodic breaks if you are using the computer for long periods of time.

Remember to:

• Alter your posture frequently.

• Stretch and exercise your body several times a day.

• Take periodic breaks when you work at the computer for long periods of time. Frequent

and short breaks are better than fewer and longer breaks.

XIII

Preface

Lighting

Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and
shoulders.

• Position the display to avoid glare or reflections from overhead lighting or outside sources of light.

• Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly.

• Position the display directly in front of you at a comfortable viewing distance.

• Adjust the display-viewing angle to find the best position.

LCD Screen Care

To prevent image persistence on LCD monitors (caused by the continuous display of graphics on the screen for
an extended period of time) take the following precautions:

• Set the Windows Power Plans to turn the screen off after a few minutes of screen idl e time.

• Use a rotating, moving or blank screen saver (this prevents an image from being displayed too long).

• Rotate desktop background images every few days.

• Turn the monitor off when the system is not in use.

XIV

Preface

XV

Preface

XVI

Contents

Notice ................................................................................. I

FCC Statement ................................................................III

FCC RF Radiation Exposure Statement: ........................IV

Instructions for Care and Operation ...............................VI

Power Safety ................................................................ VIII

Battery Precautions .........................................................IX

Cleaning ........................................................................... X

Servicing .......................................................................... X

Travel Considerations .....................................................XI

Preface

Function/Hot Key Indicators .......................................1-10

System Map: Front & Left Views ................................1-11

System Map: Right & Rear Views ..............................1-12

System Map: Bottom View ..........................................1-13

Windows Vista Start Menu & Control Panel ...............1-15

Video Features - Win 7 ................................................1-16

Video Features - Win Vista .........................................1-18

Power Options ............................................ .... .... ..........1-20

MOFA LCD Back Covers ...........................................1-21

Quick Start Guide

Overview ........................................................................1-1

Advanced Users .............................................................1-2

Beginners and Not-So-Advanced Users ........................1-2

Warning Boxes ..............................................................1-2

Not Included ..................................................................1-3

System Startup ...............................................................1-4

System Software ...................................................... .... ..1-5

Changeable LCD Back Covers ......................................1-5

System Map: LCD Panel Open ......................................1-6

LED Indicators ................................................. .... ..........1-7

Hot Key Buttons & Keyboard .......................................1-8

Keyboard ........................................................................1-9

Features & Components

Overview ........................................................................2-1

Hard Disk Drive .............................................................2-2

Optical (CD/DVD) Device ............................................2-3

Loading Discs ................................................................2-3

Handling CDs or DVDs .................................................2-4

DVD Regional Codes ................................ .... .... ............2-5

7-in-1 Card Reader .........................................................2-6

ExpressCard Slot ............................................................2-7

Inserting and Removing ExpressCards .......................... 2-7

TouchPad and Buttons/Mouse .......................................2-8

Synaptics Driver ............................................................2-9

Gestures and Device Settings ......................................2-10

XVII

Preface

Sentelic Driver .............................................................2-13

Finger Sensing Pad Configurator .................................2-14

Gestures .......................................................................2-15

Audio Features .............................................................2-16

Optimizing Audio Recording ......................................2-17

Adding a Printer ...........................................................2-18

USB Printer ..................................................................2-18

Parallel Printer .............................................................2-18

Power Management

Overview ........................................................................3-1

The Power Sources ........................................................3-2

AC/DC Adapter .............................................................3-2

Battery ............................................................................3-2

Turning On the Computer ..............................................3-3

Power Plans ...................................................................3-4

Power-Saving States ......................................................3-7

Sleep ..............................................................................3-7

Hibernate ........................................................................3-8

Shut down ......................................................................3-8

Configuring the Power Buttons .....................................3-9

Resuming Operation ....................................................3-10

Energy Star Power Saving ...........................................3-11

Battery Information ................................................. ....3-12

Conserving Battery Power ...........................................3-13

Battery Life ..................................................................3-14

New Battery .................................................................3-14

Recharging the Battery with the AC/DC Adapter .......3-14

Proper handling of the Battery Pack ............................3-15

Battery FAQ .................................................................3-16

Drivers & Utilities

What to Install ............................................................... .4-1

Module Driver Installation .............................................4-1

Windows 7/Vista Driver Installation .............................4-2

Updating/Reinstalling Individual Drivers ......................4-4

User Account Control ....................................................4-5

Windows Security Message ...........................................4-5

New Hardware Found ....................................................4-5

Driver Installation Procedure ......................................... 4-6

Chipset ...........................................................................4-6

Video ..............................................................................4-6

LAN ...............................................................................4-6

CardReader ....................................................................4-6

Modem ...........................................................................4 -6

TouchPad .......................................................................4-6

Hot Key ..........................................................................4-7

Audio .............................................................................4-7

Windows Experience Index ...........................................4 -8

Optional Drivers ............................................................4-9

XVIII

Preface

Wireless LAN Module ...................................................4-9

PC Camera Module ........................................................4-9

3.75G/HSPA Module .....................................................4-9

Matrix Manager .............................................................4-9

BIOS Utilities

Overview ........................................................................5-1

The Power-On Self Test (POST) ................................... 5-2

Failing the POST ...........................................................5-3

Fatal Errors ....................................................................5-3

Non-Fatal Errors ............................................................5-3

The Setup Utility ............................................................5-4

Entering Setup ...............................................................5-4

Setup Screens .................................................................5-5

Main Menu .....................................................................5-6

System Time & Date (Main Menu) ...............................5-6

SATA Port 1/2/4 (Main Menu) ......................................5-7

System/Extended Memory (Main Menu) ......................5-7

BIOS Revision/KBC/

EC Firmware Revision (Main Menu) ............................5-7

VGA Card/VBIOS Revision/VBIOS Build Date (Main

Menu) ............................................................................. 5-7

Advanced Menu .............................................................5-8

Advanced Chipset Control (Advanced Menu) ..............5-8

Installed O/S (Advanced Menu) ....................................5-9

SATA Mode Selection (Advanced Menu) .....................5-9

DFOROM (Robson) Support (Advanced Menu > SATA

Mode Selection) .............................................................5-9

Legacy USB Support (Advanced Menu) .......................5-9

Boot-time Diagnostic Screen (Advanced Menu) ...........5-9

Legacy OS Boot: (Advanced Menu) ...........................5-10

Reset Configuration Data (Advanced Menu) ..............5-10

Power on Boot Beep (Advanced Menu) ......................5-10

Battery Low Alarm Beep (Advanced Menu) ...............5-10

Security Menu ..............................................................5-11

Set Supervisor Password (Security Menu) ..................5-11

Set User Password (Security Menu) ............................5-12

Fixed disk boot sector: (Security Menu) ......................5-12

Password on boot: (Security Menu) .............................5-12

Boot Menu ...................................................................5-13

Exit Menu ....................................................................5-14

Upgrading The Computer

Overview ........................................................................6-1

When Not to Upgrade ....................................................6-2

Removing the Battery ....................................................6-3

Upgrading the Hard Disk Drive .....................................6-4

Upgrading the Optical (CD/DVD) Device ....................6-7

Upgrading the System Memory (RAM) ........................6-9

Changing the Optional LCD Back Covers ..................6-12

XIX

Preface

Modules & Options

Overview ........................................................................7-1

Bluetooth Module ................................................ .... .... ..7-2

Bluetooth Configuration in Windows Vista ..................7-7

Wireless LAN Module .................................................7-10

802.11b/g/n Driver Installation ....................................7-10

Connecting to a Wireless Network in Windows 7 .......7-11

Connecting to a Wireless Network in Windows Vista 7-14

PC Camera Module ......................................................7-18

PC Camera Driver Installation .....................................7-19

3.75G/HSPA Module ...................................................7-26

HSPA Modem Interface ..............................................7-30

HSPA Modem Interface Installation ...........................7-30

HSPA Modem Interface ..............................................7-31

Adding a Profile ...........................................................7-33

Contacts .......................................................................7-35

Messages ...................................................................... 7-36

Settings ........................................................................7-37

Mobile Partner .............................................................7-39

Mobile Partner Application Installation ......................7-39

Mobile Partner Application .........................................7-40

Profile Management ................................................. ....7-40

Text Messaging Service ...............................................7-45

Troubleshooting

Overview ........................................................................8-1

Basic Hints and Tips ......................................................8-2

Backup and General Maintenance .................................8-3

Viruses ...........................................................................8-4

Upgrading and Adding New Hardware/Software .......... 8-5

Problems and Possible Solutions ...................................8-7

Bluetooth Connection Problems ..................................8-12

Interface (Ports & Jacks)

Overview ....................................................................... A-1

Notebook Ports and Jacks .............................................A-2

Intel Video Driver Controls

Intel Video Driver Installation ......................................B-1

Video .............................................................................B-1

Dynamic Video Memory Technology ......................B-1

Intel GMA Driver for Mobile ....................................... B-2

Scheme Options ........................................................B-4

Display Devices & Options ......................................B-5

Configuring an External Display - Intel GMA .............B-6

Configuring an External Display - Win 7 .....................B-8

Intel Clear Video Technology .....................................B-13

HDMI Audio Configuration .......................................B-14

XX

Specifications

Processor .......................................................................C-2

Processor (Cont’d) ........................................................ C-2

Core Logic ................................................................... .C-2

Display ..........................................................................C-2

Memory .........................................................................C-2

Video .............................................................................C-2

BIOS ............................................................................. C-2

Storage .......................................................................... C-2

Audio ............................................................................ C-3

Keyboard & Pointing Device ........................................C-3

Interface ........................................................................ C-3

Card Reader ..................................................................C-3

Slots .............................................................................. C-3

Communication ............................................................. C-3

Communication (Cont’d) ..............................................C-3

Power Management ......................................................C-3

Power ............................................................................ C-3

Security ......................................................................... C-3

Operating System .......................................................... C-4

Environmental Spec ......................................................C-4

Dimensions & Weight ..................................................C-4

Preface

XXI

Preface

XXII

Quick Start Guide

Chapter 1: Quick Start Guide

Overview

This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the
computer and to getting your system started. The remainder of the manual covers the following:

• Chapter 2 A guide to using some of the main features of the computer e.g. the storage devices (hard disk,

optical device, 7-in-1 card reader, ExpressCard/34), TouchPad & Mouse, Audio & Printer.

• Chapter 3 The computer’s power saving options.

• Chapter 4 The installation of the drivers and utilities essential to the operation or improvement of some of the

computer’s subsystems.

• Chapter 5 An outline of the computer’s built-in software or BIOS (Basic Input Output System).

• Chapter 6 Instructions for upgrading your computer.

• Chapter 7 A quick guide to the computer’s Bluetooth, Wireless LAN, PC Camera and 3.75G/HSPA mod-

ules (some of which may be optional depending on your purchase configuration).

• Chapter 8 A troubleshooting guide.

• Appendix A Definitions of the interface, ports/jacks which allow your computer to communicate with external

devices.

• Appendix B Information on the Intel Video driver controls.

• Appendix C The computer’s specification.

1

Overview 1 - 1

1

Quick Start Guide

Advanced Users

If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful
to refer to “What to Install” on page 4 - 1, “BIOS Utilities” on page 5 - 1 and “Upgrading The Computer” on

page 6 - 1 in the reminder of the User’s Manual. You may also find the notes marked with a

 of interest to you.

Beginners and Not-So-Advanced Users

If you are new to computers (or do not have an advanced knowledge of them) then



Notes

Check the light colored
boxes with the mark
above to find detailed in­formation about the com­puter’s features.

the information contained in the Quick Start Guide should be enough to get you up
and running. Eventually you should try to look through all the documentation (more
detailed descriptions of the functions, setup and system controls are covered in the
remainder of the User’s Manual), but do not worry if you do not understand every­thing the first time. Keep this manual nearby and refer to it to learn as you go. You
may find it useful to refer to the notes marked with a

 as indicated in the margin.

For a more detailed description of any of the interface ports and jacks see “Interface

(Ports & Jacks)” on page A - 1.

Warning Boxes

No matter what your level please pay careful attention to the warning and safety information indicated by the

 symbol. Also please note the safety and handling instructions as indicated in the Preface.

1 - 2 Overview

Quick Start Guide

Not Included

Operating Systems (e.g. Windows Vista/Windows 7) and applications (e.g. word processing, spreadsheet and da­tabase programs) have their own manuals, so please consult the appropriate manuals.



Drivers

If you are installing new system software, or are re-configuring your computer for a different system, you will need to install
the drivers listed in “Drivers & Utilities” on page 4 - 1. Drivers are programs which act as an interface between the com­puter and a hardware component e.g. a wireless network module. It is very important that you install the drivers in the order
listed. You will be unable to use most advanced controls until the necessary drivers and utilities are properly installed. If
your system hasn’t been properly configured (your service representative may have already done that for you); refer to

Chapter 4 for installation instructions.

Ports and Jacks

See “Notebook Ports and Jacks” on page A - 2 for a description of the interface (ports & jacks) which allow your com­puter to communicate with external devices, connect to the internet etc.

1

Overview 1 - 3

1

Quick Start Guide

System Startup

1. Remove all packing materials.

2. Place the computer on a st able surface.

3. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports.

4. Attach the AC/DC adapter to the DC-In jack on the left of the computer, then plug the AC power cord into an

outlet, and connect the AC power cord to the AC/DC adapter.

5. Use one hand to raise the

hand (as illustrated in Figure 1 - 1 below) to support the base of the computer (Note: Never lift the computer by
the lid/LCD).

Note that you should always shut your computer down by choosing the Shut Down command from the bottom right of the
Start menu in Windows. This will help prevent hard disk or system problems.

lid/LCD to a comfortable viewing angle (



Shutdown

do not exceed 130 degrees

);

use the other

Figure 1 - 1 - Opening the Lid/LCD & Computer with AC/DC Adapter Plugged-In

1 - 4 System Startup

Quick Start Guide

System Software

Your computer may already come with system software pre-installed. Where this is not the case, or where you
are re-configuring your computer for a different system, you will find that this manual refers to the Windows 7
operating system (however where necessary notes are provided on the Windows Vista OS).



Windows OS

In order to run Windows Vista/ Windows 7 without limitations or decreased performance, your computer requires a min­imum 1GB of system memory (RAM), however if you are running Windows 7 64 bit your computer requires a minimum

2GB of system memory (RAM).

Windows Vista Service Pack 2

Make sure you install Windows Vista Service Pack 2 (or a Windows Vista version which includes Service Pack 2) be­fore installing any driver s. Go to the Microsoft website for download details, or contact your service center.

Changeable LCD Back Covers

Note that this computer series includes some model designs with specially designed changeable LCD back cover
options. Follow the instructions in “Changing the Optional LCD Back Covers” on page 6 - 12 to change the
covers (note these covers are not applicable to all models in this series - consult your service center for details).

1

System Startup 1 - 5

1

Quick Start Guide

Figure 1 - 2

LCD Panel Open

1. Built-In PC Camera
(

Optional

)

2. LCD

3. Power Button

4. Hot Key Buttons

5. LED Status
Indicators (see

Table 1 - 2, on
page 1 - 7)

6. Keyboard

7. Built-In Microphone

8. Touchpad &
Buttons

8

Touchpad Buttons
(valid operation area)

System Map: LCD Panel Open

1

2

4

5

6

7

8

3



Wireless Device

Operation Aboard

Aircraft

The use of any portable elec­tronic transmission devices
aboard aircraft is usually pro­hibited. Make sure the mod­ule(s) are OFF if you are
using the computer aboard
aircraft.

Use the key combinations to
toggle power to the 3.75G/

HSPA/WLAN/Bluetooth

modules, and check the LED
indicator or on-screen icon to
see if the modules are pow­ered on or not (see Table 1 -

4, on page 1 - 10/ Table 1 ­1, on page 1 - 7).

1 - 6 System Map: LCD Panel Open

Quick Start Guide

1

LED Indicators

The LED indicators on the computer display helpful
information about the current status of the computer.

Icon Color Description

1 2

Orange DC Power is Plugged In

Green The Computer is On

1

Blinking Green

Orange The Battery is Charging

Green The Battery is Fully Charged

2

Blinking Orange

Table 1 - 1 - LED Power Indicators

The Computer is in Sleep

Mode

The Battery Has Reached

Critically Low Power Status

Icon Color Description

34567

Green

3

Green Caps Lock Activated

4

Green Number Lock Activated

5

Green Hard Disk Activity

6

Green

7

Orange

Table 1 - 2 - LED Status Indicators

Scroll Lock Activated (to activate

press Fn & Scr Lk)

The (optional) Wireless LAN

Module is Powered On

The (optional) Bluetooth Module

is Powered On

LED Indicators 1 - 7

1

Quick Start Guide

Hot Key Buttons & Keyboard

These buttons give instant access to the default Internet browser and e-mail program, and allow you to toggle
the Silent Mode on/off with one quick button press.

Hot Key Function

123

1

2

Activate the Default E-Mail Browser (Note that in Windows 7 without Outlook/Outlook
Express installed this button has no funct ion. If Ou tlook /Outlo ok Express ar e inst al led

3

then the button will activate the application)

Toggle *Silent Mode (for power saving)

Activate the Default Internet Program

Table 1 - 3 - Hot Key Buttons

*When enabled, Silent Mode will reduce fan noise and save power consumption. Note this may reduce comput­er performance.

1 - 8 Hot Key Buttons & Keyboard

Quick Start Guide

1

Keyboard

The keyboard has an embedded numerical keypad for easy numeric data input, and
features function keys to allow you to change operational features instantly. See

Table 1 - 4, on page 1 - 10 for full function key combination details.

Function Keys

Play/Pause Key

Numerical Keypad

Fn Key

Figure 1 - 3 - Keyboard



Special Characters

Some software applications allow the number-keys to be used with Alt to produce special characters.
These special characters can only be produced by using the numeric keypad. Regular number keys (in
the upper row of the keyboard) will not work. Make sure that NumLk is on.

NumLk &
ScrLk Keys

3.75G/HSPA
Module Power

Toggle Key



Other Keyboards

If your keyboard is dam­aged or you just want to
make a change, you can
use any standard USB
keyboard. The system will
detect and enable it auto­matically. However spe­cial functions/hot-keys
unique to the system’s
regular keyboard may not
work.

NumLk & ScrLk

Hold down the Fn Key
and either NumLk or Scr­Lk to enable number or
scroll lock, and check the
LED indicator for status.

Keyboard 1 - 9

1

Quick Start Guide

Function/Hot Key Indicators

The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition
to the basic function key combinations; visual indicators are available when the hot key utility is installed.

Keys Function Keys Function

Fn + ~ Play/Pause (in Audio/Video Programs) Fn + F7 Display Toggle

3.75G Module Power Toggle*

Fn +

Fn + F8/F9

Brightness Decrease/Increase

Fn + F1

Fn + F2

Fn + F3

Fn + F4 Sleep Toggle

Fn + F5/F6

TouchPad Toggle

(Press a key to or use TouchPad to turn on)

Turn LCD Backlight Off

Mute Toggle

Volume Decrease/Increase

Table 1 - 4 - Function & Hot Key Indicators

1 - 10 Function/Hot Key Indicators

Fn + F10

Fn + F11

Fn + F12

*When enabled, Silent Mode will reduce fan noise and save power

PC Camera Power Toggle

WLAN Module Power Toggle

Bluetooth Module Power Toggle

*Silent Mode Toggle

consumption. Note this ma y re d uc e co m pu t er pe r formance.

Quick Start Guide

1

System Map: Front & Left Views

1

2

The card reader allows you to use the most popular digital storage card formats:

3

MMC (MultiMedia Card) / SD (Secure Digital) / MS (Memory Stick) /

MS Pro (Memory Stick Pro) / MS Duo (requires PC adapter) /

Mini SD (requires PC adapter) / RS MMC (requires PC adapter)

4

5

7-in-1 Card Reader

6



6

7

Figure 1 - 4

Front & Left Views

1. LED Power Indica­tors (see

1, on page 1 - 7)

2. DC-In Jack

8

9

3. External Monitor
Port

4. RJ-45 LAN Jack

5. HDMI-Out Port

6. 2 * USB 2.0 Ports

7. Vent/Fan Intake/
Outlet

8. ExpressCard 34 Slot
(see page

9. 7-in-1 Card Reader

Table 1 -

2 - 7

)

System Map: Front & Left Views 1 - 11

1

Quick Start Guide

Figure 1 - 5

Right & Rear Views

1. Microphone-In
Jack

2. Headphone-Out
Jack

3. USB 2.0 Port

4. Modem Port

5. Optical Device
Drive Bay (for CD/
DVD Device)

6. Security Lock Slot

7. Battery



Disk Eject Warning

Don’t try to eject a CD/DVD
while the system is access­ing it. This may cause the
system to “crash”. Stop the
disk first then eject it, or
press the stop button twice.

System Map: Right & Rear Views

152

CD/DVD Emergency Eject

If you need to manually eject a CD/
DVD (e.g. due to an unexpected
power interruption) you may push
the end of a straightened paper clip
into the emergency eject hole. Do
not use a sharpened pencil or any
object that may break and become
lodged in the hole. Don’t try to re­move a floppy disk/CD/DVD while
the system is accessing it. This may
cause the system to “crash”.

3



4

7



Changing DVD Regional Codes

Go to the Control Panel and double-click Device
Manager (Hardware and Sound), then click the +

next to DVD/CD-ROM drives. Double-click on the
DVD-ROM device to bring up the Properties dialog
box, and select the DVD Region (tab) to bring up the
control panel to allow you to adjust the regional code.

DVD region detection is device dependent, not OS­dependent. You can select your module’s region code
5 times. The fifth selection is permanent. This cannot
be altered even if you change your operating system
or you use the module in another computer.

6

1 - 12 System Map: Right & Rear Views

Quick Start Guide

1

System Map: Bottom View



Battery Information

Always completely dis­charge, then fully charge, a
new battery before using it.
Completely discharge and
charge the battery at least
once every 30 days or after
about 20 partial discharges.
See “Battery Information”

on page 3 - 12 for full in-

structions.



Bottom Covers

If your model includes the 3.75G option then a
small cover to enable you to access the
module’s USIM card will be included (see

“3.75G/HSPA Module” on page 7 - 26).

5

4

Figure 1 - 6

Bottom View

1

1. Battery

2. Component Bay
Cover

3. Vent/Fan Intake/

3

2

3

Outlet

4. Hard Disk Bay
Cover

5. 3.75G USIM Card
Cover (Optional)

3



CPU

The CPU is not a user
serviceable part.

Overheating

To prevent your comput­er from overheating
make sure nothing blocks
the Vent/Fan Intake while

5

the computer is in use.

System Map: Bottom View 1 - 13

1

Quick Start Guide

Windows 7 Start Menu & Control Panel

Most of the control panels, utilities and programs within Windows 7 (and most other Windows versions) are ac­cessed from the Start menu. When you install programs and utilities they will be installed on your hard disk
drive, and a shortcut will usually be placed in the Start menu and/or the desktop. Right-click the Start menu
icon , and then select Properties if you want to customize the appearance of the Start menu.

Click here to toggle Category View

Figure 1 - 7 - Start Menu & Control Panel

In many instances throughout this manual you will see an instruction to open the Control Panel. The Control
Panel is accessed from the Start menu, and it allows you to configure the settings for most of the key features

in Windows (e.g. power, video, network, audio etc.). Windows 7 provides basic controls for many of the features,
however many new controls are added (or existing ones are enhanced) when you install the drivers. To see all
controls it may be necessary to toggle off Category View to view the control panel icons.

1 - 14 System Map: Bottom View

Quick Start Guide

Windows Vista Start Menu & Control Panel

Windows Vista has a similar Start menu and set of control panels to that of Windows 7. To see all the Windows
Vista controls it may be necessary to toggle to Classic View on.

Click here to toggle Classic View

Figure 1 - 8 - Start Menu & Control Panel

1

Windows Vista Start Menu & Control Panel 1 - 15

1

Quick Start Guide

Video Features - Win 7

You can configure display options from the Display (Control Panel) and Screen Resolution in Windows. For
more detailed video information see Chapter B“Intel Video Driver Controls” from

page B - 1.

To access Display (Control Panel) and Screen Resolution in Windows:

1. Click Start and click Control Panel.

2. Click Display (icon) - In the Appearances and Personalization category.

3. Click Adjust Screen Resolution/Adjust resolution.

OR

4. Alternatively you can right-click the desktop and select Screen resolution (see right).

5. Use the dropbox to select the screen Resolution (Figure 1 - 9 on page 1 - 17).

6. Click Advanced settings (Figure 1 - 9 on page 1 - 17) to bring up the Advanced
properties tabs.

2

To access the Intel(R) Graphics Media Accelerator Driver for mobile control panel:

1. Click Advanced settings (Fig ure 1 - 9 on page 1 - 17) in the Screen Resolution control panel in Win­dows.

2. Click the Intel(R)... tab (Figure 1 - 9 on page 1 - 17) and click Graphics Properties (button).

2

3

OR

3. Right-click the desktop and select Graphics Properties from the menu.

OR

4. The Intel GMA control panel can also be accessed by clicking the icon in the taskbar and selecting Graphics
Properties (Figure 1 - 9 on page 1 - 17) from the menu.

4

1

1 - 16 Video Features - Win 7

Quick Start Guide

3

1

2

4

1

Figure 1 - 9 - Screen Resolution & Intel GMA Driver for Mobile

Video Features - Win 7 1 - 17

1

Quick Start Guide

Video Features - Win Vista

You can configure display options from the Display Settings control panel (in Personalization) in Windows
Vista. For more detailed video information see Chapter B“Intel Video Driver Controls” from page B - 1.

To access Display Settings in Windows Vista:

1. Click Start, and click Control Panel (or point to Settings and click Control Panel).

2. Click Adjust screen resolution under the Appearance and Personalization menu (or double-click
Personalization > Display Settings).

3. Move the slider to the preferred setting in Resolution: (Figure 1 - 10 on page 1 - 19).

4. Click the arrow, and scroll to the preferred setting In Colors: (Figure 1 - 10 on page 1 - 19).

To access the Intel(R) Graphics Media Accelerator Driver for mobile control panel:

1. Click Advanced settings (Figure 1 - 9 on page 1 - 17) in the Display Settings control panel in Windows.

2. Click the Intel(R)... tab (Figure 1 - 9 on page 1 - 17) and click Graphics Properties (button).

2

3

OR

3. The Intel GMA control panel can also be accessed by clicking the icon in the taskbar and selecting Graphics
Properties (Figure 1 - 9 on page 1 - 17) from the menu.

4

OR

4. Right-click the desktop and select Graphics Properties from the menu.

1

2

1 - 18 Video Features - Win Vista

Quick Start Guide

3

1

2

4

1

Figure 1 - 10 - Display Settings & Video Control Panel

Video Features - Win Vista 1 - 19

1

Quick Start Guide

Power Options

The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 1 - 14 ) allows you
to configure power management features for your computer. You can conserve power by means of power plans
and configure the options for the power button, sleep button, computer lid (when closed), display and sleep
mode from the left menu. Note that the Power saver plan may have an affect on computer performance.

Click to select one of the existing plans, or click Create a power plan in the left menu and select the options to
create a new plan. Click Change plan settings and click Change advanced power settings to access further con­figuration options.

Pay attention to the instructions on battery care in “Battery Information” on page 3 - 12.

1 - 20 Power Options

Figure 1 - 11 - Power Options

Quick Start Guide

MOFA LCD Back Covers

MOFA (Magic of Film Art) technology allows fashionable and unique pictorial designs to be printed on the spe­cially designed changeable LCD back covers. If your purchase option includes the specially designed change­able LCD back cover option, then follow the instructions in “Changing the Optional LCD Back Covers” on

page 6 - 12 to change the covers (note these covers are not applicable to all models in this series - consult

your service center for details).

1

Figure 1 - 12 - Magic Of Film Art Optional LCD Back Covers

MOFA LCD Back Covers 1 - 21

1

Quick Start Guide

1 - 22

Features & Components

Chapter 2: Features & Components

Overview

Read this chapter to learn more about the following main features and components
of the computer:

•Hard Disk Drive

• Optical (CD/DVD) Device

• 7-in-1 Card Reader

• ExpressCard Slot

• TouchPad and Buttons/Mouse

• Audio Features

• Optimizing Audio Recording

2

Overview 2 - 1

Features & Components

2

Before attempting to ac­cess any of the internal
components of your
computer please ensure
that the machine is not
connected to the AC
power, and that the ma­chine is turned off. Also
ensure that all peripher­al cables, including
phone lines, are discon­nected from the comput­er.



Power Safety

Hard Disk Drive

The hard disk drive is used to store your data in the computer. The hard disk can be
taken out to accommodate other serial (SATA) hard disk drives (see “Storage” on

page C - 2 for specification information).

The hard disk is accessible from the bottom of your computer as seen below. For fur­ther details see “Upgrading the Hard Disk Drive” on page 6 - 4.

Figure 2 - 1

Hard Disk Location

2 - 2 Hard Disk Drive

Features & Components

Optical (CD/DVD) Device

There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual de­vice will depend on the module you purchased (see “Storage” on page C - 2). The
optical device is usually labeled “Drive D:” and may be used as a boot device if
properly set in the BIOS (see “Boot Menu” on page 5 - 13).

Loading Discs

To insert a CD/DVD, press the open button and carefully place a CD/DVD onto
the disc tray with label-side facing up (use just enough force for the disc to click onto
the tray’s spindle). Gently push the CD/DVD tray in until its lock “clicks” and you
are ready to start. The busy indicator will light up while data is being accessed,
or while an audio/video CD, or DVD, is playing. If power is unexpectedly interrupt­ed, insert an object such as a straightened paper clip into the emergency eject hole

3

to open the tray.

1

2

1

2

3



Sound Volume

Adjustment

How high the sound vol­ume can be set depends
on the setting of the vol­ume control within Win-
dows. Click the Volume
icon on the taskbar to
check the setting (see

“Audio Features” on
page 2 - 16).

Figure 2 - 2

Optical Device

2

Optical (CD/DVD) Device 2 - 3

Features & Components

2

CD Emergency Eject

If you need to manually
eject a CD (e.g. due to
an unexpected power
interruption) you may
push the end of a
straightened paper clip
into the emergency eject
hole. However please
do NOT use a sharp­ened pencil or similar
object that may break
and become lodged in
the hole.

Disk Eject Warning

Don’t try to remove a
CD/DVD while the sys­tem is accessing it. This
may cause the system
to “crash”.



Proper handling of your CDs/DVDs will prevent them from being damaged. Please
follow the advice below to make sure that the data stored on your CDs/DVDs can be
accessed.

Note the following:

• Hold the CD or DVD by the edges; do not touch the surface of the disc.

• Use a clean, soft, dry cloth to remove dust or fingerprints.

• Do not write on the surface with a pen.

• Do not attach paper or other materials to the surface of the disc.

• Do not store or place the CD or DVD in high-temperature areas.

• Do not use benzene, thinner, or other cleaners to clean the CD or DVD.

• Do not bend the CD or DVD.

• Do not drop or subject the CD or DVD to shock.

Handling CDs or DVDs

2 - 4 Optical (CD/DVD) Device

Features & Components

DVD Regional Codes

To change the DVD regional codes see “Changing DVD Regional Codes” on

page 1 - 12.

.

DVD Regional Coding

Region Geographical Location

1 USA, Canada

2

3

4

5

6China

Western Europe, Japan, South

Africa, Middle East & Egypt

South-East Asia, Taiwan, South

Korea, The Philippines, Indonesia,

Hong Kong

South & Central America, Mexico,

Australia, New Zealand

N Korea, Russia, Eastern Europe,

India & Most of Africa

2

Table 2 - 1

DVD Regional Coding

Optical (CD/DVD) Device 2 - 5

Features & Components

2

Card Reader Cover

Make sure you keep the
rubber cover provided in
the card reader when
not in use. This will help
prevent foreign objects
and/or dust getting in to
the card reader.



7-in-1 Card Reader

The card reader allows you to use some of the latest digital storage cards. Push the
card into the slot and it will appear as a removable device, and can be accessed in
the same way as your hard disk (s). Make sure you install the Card Reader driver
(see “CardReader” on page 4 - 6).

• MMC (MultiMedia Card)

• SD (Secure Digital)

• MS (Memory Stick)

• MS Pro (Memory Stick Pro)

• MS Duo (requires PC adapter*)

• Mini SD (requires PC adapter*)

• RS MMC (requires PC adapter*)

*Note: The PC adapters are usually supplied with these cards.

Figure 2 - 3

Left View

1. Card Reader

1

2 - 6 7-in-1 Card Reader

Features & Components

ExpressCard Slot

The computer is equipped with an ExpressCard 34 slot that reads Express Card/34
formats. ExpressCards are the successors to PCMCIA (PC Cards). Make sure you
install the Card Reader driver

Inserting and Removing ExpressCards

• Align the ExpressCard with the slot and push it in until it locks into place.

• To remove an ExpressCard, simply press the card to eject it.

(see

“CardReader” on page 4 - 6

).

1



ExpressCard

Slot Cover

Make sure you keep the
rubber cover provided in
the ExpressCard slot
when not in use. This
will help prevent foreign
objects and/or dust get­ting in to the Express­Card Slot.

Figure 2 - 4

Left View

1. Express Card
Slot

2

ExpressCard Slot 2 - 7

Features & Components

2

TouchPad and Buttons/Mouse

The TouchPad is an alternative to the mouse; however, you can also add a mouse to
your computer through one of the USB ports. The TouchPad buttons function in
much the same way as a two-button mouse.

There are two TouchPad drivers available for this computer model series. The fol­lowing pages contain information on both drivers.

2 - 8 TouchPad and Buttons/Mouse

Features & Components

Synaptics Driver

Once you have installed the TouchPad driver (see “TouchPad” on page 4 - 6) you
can configure the functions by double-clicking the TouchPad driver icon in the
taskbar. You may then configure the TouchPad tapping, buttons, scrolling, pointer
motion and sensitivity options to your preferences. You will find further information
at www.synaptics.com.



Mouse Driver

If you are using an ex­ternal mouse your op­erating system may be
able to auto-configure
your mouse during its
installation or only en­able its basic functions.
Be sure to check the
device’s user docu­mentation for details.

Figure 2 - 5

Mouse Properties

2

TouchPad and Buttons/Mouse 2 - 9

Features & Components

2

You can get a clearer
view of the gestures in­volved by clicking the
Show Video option for
each gesture item.

Select the gesture (Pinch

Zoom, Rotating, Three
Fingers Down and
Three Finger Flick) in the
Device Settings > Set­tings left tree menu

and click the Show Video
button to see the demon­stration video.

For more details on any of
the gestures see the help
in the lower part of the
right menu window.

Mouse Properties -

Device Settings



Show Video

Figure 2 - 6

The Synaptics Gestures Suite application allows you to use a specific gesture (ac­tion) on the surface of the TouchPad to perform specific actions to manipulate doc­uments, objects and applications.

You can configure the settings from the Device Settings tab in Mouse Properties:

1. Click

2. Click Mouse (Hardware and Sound).

3. Click Device Settings (tab) and click Settings.

4. Use the menu tree on the left to access the user configurable settings.

Start

, and click

Control Panel

(or point to

Settings

and click

Control Panel

).

Gestures and Device Settings

2 - 10 TouchPad and Buttons/Mouse

Features & Components

Scrolling

The Two-Finger scrolling feature works in most scrollable windows and allows you
to scroll horizontally and vertically. Place two fingers, slightly separated, on the
TouchPad surface and slide both fingers in the direction required (in a straight con­tinuous motion).

Zooming

The Pinch Zoom gesture can be used to perform the same function as a scroll wheel
in Windows applications that support CTRL + scroll wheel zoom functionality.
Place two fingers on the TouchPad (for best results use the tips of the fingers) and
slide them apart to zoom in, or closer together to zoom out.

2

Figure 2 - 7

Scrolling Gesture

Figure 2 - 8

Zooming Gesture

TouchPad and Buttons/Mouse 2 - 11

Features & Components

Rotating

2

Use the Pivot Rotate gesture to rotate objects (e.g. photos) in 90 degree in cr ements.
Place a finger down on the left “target” zone and keep it stationary. Place another
finger near the middle of the TouchPad and slide it in a circular motion around the
stationary finger (clockwise or counterclockwise) to rotate the object.

Figure 2 - 9

Rotating Gesture

Three Finger-Flick/Three Fingers Down (Press)

The Three Finger-Flick gesture may be used to enhance navigation with a variety of
applications such as browsing the Internet or scrolling through a photo viewer. The
Three Fingers Down gesture may be used to launch user-selectable applications.

Figure 2 - 10

Flick/Press

Gesture

2 - 12 TouchPad and Buttons/Mouse

Features & Components

Sentelic Driver

Once you have installed the TouchPad driver (see “TouchPad” on page 4 - 6) you
can configure the functions by double-clicking the TouchPad driver icon in the
taskbar. You may then configure the buttons, pointers and finger-sensing pad op­tions to your preferences.



Mouse Driver

If you are using an ex­ternal mouse your op­erating system may be
able to auto-configure
your mouse during its
installation or only en­able its basic functions.
Be sure to check the
device’s user docu­mentation for details.

Figure 2 - 11

Mouse Properties

2

TouchPad and Buttons/Mouse 2 - 13

Features & Components

2

Figure 2 - 12

Finger Sensing

Pad

The Finger Sensing Pad Configurator allows you to use a configure the settings
for the Finger Pad device and software. The left pane in the control panel contains
all the configurable items, and you can click the “+” to expand the menu selections.

You can configure the settings from the Device Settings tab in Mouse Properties:

1. Click

2. Click Mouse (Hardware and Sound).

3. Click Finger Sensing Pad (tab) and click Configure.

4. Use the menu tree on the left to access the user configurable settings.

Start

, and click

Control Panel

(or point to

Settings

and click

Control Panel

).

Finger Sensing Pad Configurator

2 - 14 TouchPad and Buttons/Mouse

Features & Components

Gestures

Click Gestures and make sure that the Enable Gestures tickbox is clicked. Double­click Gestures and then double-click Advanced to open the submenu. You can con-
figure any of the gestures from this submenu.



Play Video

You can get a clearer
view of the gestures in­volved by clicking the
Play Video option for
each gesture item.

Figure 2 - 13

Finger Sensing

Pad - Gestures

(Advanced)

2

TouchPad and Buttons/Mouse 2 - 15

Features & Components

2



Audio Features

You can configure the audio options on your computer from the Sound control

Sound Volume

Adjustment

The sound volume level
is set using the volume
control within Windows
(and the volume func­tion keys on the comput­er). Click the volume
icon in the taskbar to
check the setting.

panel in Windows, or from the Realtek HD Audio Manager icon in the taskbar/
control panel (right-click the taskbar icon to bring up an audio menu). The volume
may also be adjusted by means of the Fn + F5/F6 key combination.

Right-click the icon
to access the menu
above.

Figure 2 - 14

Realtek Audio

Manager

2 - 16 Audio Features

Features & Components

Optimizing Audio Recording

Follow these instructions to optimize your audio recording.

1. Double-click the taskbar icon to bring up the Realtek HD Audio Manager.

2. Click the Microphone tab.

3. Click the Noise Suppression button to prevent any background noise or
feedback.

4. Click OK to close the Realtek HD Audio Manager.

2

Figure 2 - 15

Optimizing Audio

Recording

Audio Features 2 - 17

Features & Components

2

After setting up the print­er attach the parallel ca­ble to the printer.

Connect the printer’s
parallel cable to the Par­allel to USB converter,
and then plug the con­verter into the USB port.

Turn ON the printer,
then turn ON the com­puter.

Windows will identify the
printer and either load
one of its own drivers or
ask you to supply one.
Follow the on-screen in­structions.



Parallel Printer

Adding a Printer

The most commonly used peripheral is a printer. The following conventions will
help you to add a printer; however it is always best to refer to the printer manual for
specific instructions and configuration options.

USB Printer

Most current printers have a USB interface connection. You may use any one of the
ports to connect the printer.

Install Instructions:

1. Set up the printer according to its instructions (unp acking, p aper tray, toner/ink car­tridge etc.).

2. Turn ON the computer.

3. Turn ON the printer.

4. Connect the printer’s USB cable to one of the USB ports on the comp uter.

5. Windows will identify the printer and either load one of its own drivers or ask you
to supply one. Follow the on-screen instructions.

Parallel Printer

This is still a very common type of printer. The install instructions are in the sidebar,
however you will need to purchase a parallel to USB converter.

2 - 18 Adding a Printer

Power Management

Chapter 3: Power Management

Overview

To conserve power, especially when using the battery, your computer power man­agement conserves power by controlling individual components of the computer
(the monitor and hard disk drive) or the whole system. This chapter covers:

• The Power Sources

• Turning On the Computer

• Power Plans

• Power-Saving States

• Configuring the Power Buttons

• Energy Star Power Saving

• Battery Information

The computer uses enhanced power saving techniques to give the operating system
(OS) direct control over the power and thermal states of devices and processors. For
example, this enables the OS to set devices into low-power states based on user set­tings and information from applications.



OS Note

Power management
functions will vary slight­ly depending on your
operating system. For
more information it is
best to refer to the user’s
manual of your operat­ing system.

3

Overview 3 - 1

Power Management

The Power Sources

The computer can be powered by either an AC/DC adapter or a battery pack.

3

AC/DC Adapter

Use only the AC/DC adapter that comes with your computer. The wrong type of AC/
DC adapter will damage the computer and its components.

1. Attach th e AC/DC adapter to the DC-in jack on the left of the computer.

2. Plug the AC power cord into an outlet, and then conne ct the AC power co rd to the
AC/DC adapter.

3. Raise the lid/LCD to a comfortable viewing angle.

4. Press the power button to turn “On”.

Battery

The battery allows you to use your computer while you are on the road or when an
electrical outlet is unavailable. Battery life varies depending on the applications and
the configuration you're using. To increase battery life, let the battery discharge
completely before recharging (see “How do I completely discharge the battery?”

on page 3 - 16).

We recommend that you do not remove the battery. For more information on the bat­tery, please refer to “Battery Information” on page 3 - 12.

3 - 2 The Power Sources

Turning On the Computer

Now you are ready to begin using your computer. To turn it on simply press the pow­er button on the front panel.

When the computer is on, you can use the power button as a Stand by/Hibernate/
Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and
holding the power button for longer than this will shut the computer down). Use
Power Options in the Windows control panel to configure this feature.



Shut Down

Note that you should always shut your computer down by choosing the Shut Down com­mand from the bottom right of the Start menu in Windows. This will help prevent hard disk
or system problems.

Win 7

Win Vista

Power Management



Forced Off

If the system “hangs”,
and the Ctrl + Alt + Del
key combination doesn’t
work, press the power
button for 4 seconds, or
longer, to force the sys­tem to turn itself off.

Power Button as

Stand by or

Hibernate Button

You can use the OS’s
“Power Options” control
panel to set the power
button to send the sys­tem into Stand by or Hi­bernate mode (see your
OS’s documentation, or

“Configuring the Pow­er Buttons” on page 3

- 9 for details).

3

Turning On the Computer 3 - 3

Power Management

Power Plans



3

Resuming
Operation

See Table 3 - 1, on

page 3 - 10 for informa-

tion on how to resume
from a power-saving
state.

Password

It is recommended that
you enable a password
on system resume in or­der to protect your data.

Figure 3 - 1

Power Plan

Advanced Settings

(Win 7)

The computer can be configured to conserve power by means of power plans. You
can use (or modify) an existing power plan, or create a new one.

The settings may be adjusted to set the display to turn off after a specified time, and
to send the computer into Sleep after a period of inactivity.

Click Change plan settings and then click Change advanced power settings to ac­cess further configuration options in Advanced Settings.

3 - 4 Power Plans

Each Windows power plan will also adjust the processor performance of your ma­chine in order to save power. This is worth bearing in mind if you are experiencing
any reduced performance (especially under DC/battery power).

Choose High performance (you may need to click Show additional plans to view
the High performance plan) for maximum performance when the computer is pow­ered from an AC power source. Choose the Power saver (bear in mind that this
scheme may slow down the overall performance of the computer in order to save
power) for maximum power saving when the computer is battery (DC power) pow­ered.

Power Management

3

Click to Show/Hide
additional
power plans

Figure 3 - 2

Power Plans (Win 7)

Power Plans3-5

Power Management

3

Figure 3 - 3

Power Plan

Advanced Settings

(Win Vista)

3 - 6 Power Plans

Power-Saving States

You can use power-saving states to stop the computer’s operation and restart where
you left off. Win 7/ Win Vista use the Sleep, Hibernate and Shut Down power-sav­ing states.

Sleep

In Sleep all of your work, settings and preferences are saved to memory before the
system sleeps. When you are not using your computer for a certain length of time,
which you specify in the operating system, it will enter Sleep to save power.

The PC wakes from Sleep within seconds and will return you to where you last left
off (what was on your desktop) without reopening the application(s) and file( s) you
last used.

If your mobile PC in Sleep is running on battery power the system will use only a
minimum amount of power. After an extended period the system will save all the
information to the hard disk and shut the computer down before the battery becomes
depleted.

Power Management

3

Power-Saving States 3 - 7

Power Management

Hibernate



3

Win Vista Power

Button

The Win Vista Power
Button in the Start

Menu (in Classic View
use the Shut Down but­ton ) can be used to
send the computer into
a power-saving state.

Hibernate uses the least amount of power of all the power-saving states and saves
all of your information on a part of the hard disk before it turns the system off. If a
power failure occurs the system can restore your work from the hard disk; if a power
failure occurs when work is saved only to memory, then the work will be lost. Hi-
bernate will also return you to where you last left off within seconds. You should
put your mobile PC into Hibernate if you will not use the computer for a period of
time, and will not have the chance to charge the battery.

Shut down

You should Shut down the computer if you plan to install new hardware (don’t for­get to remove the battery and follow all the safety instructions in Chapter 6), plan
to be away from the computer for several days, or you do not need it to wake up and
run a scheduled task. Returning to full operation from Shut down takes longer than
from Sleep or Hibernate.

Figure 3 - 4

Start Menu Power

Win 7 WinVista

3 - 8 Power-Saving States

Configuring the Power Buttons

The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the
computer in to a power-saving state. Click Choose what the power buttons do on
the left menu in Power Options to bring up the menu.

Win 7

WinVista

Power Management



Password

Protection

It is recommended that
you enable a password
on wake up in order to
protect your data.

However you can dis­able this setting from the
Power Options menu
by clicking Require a

password on wakeup

in the left menu, and se­lecting the options (click

Change settings that
are currently unavail­able).

Figure 3 - 5

Power Options

Define Power

Buttons

3

Configuring the Power Buttons 3 - 9

Power Management

Resuming Operation



3

Closing the Lid

If you have chosen to
send the computer to
Sleep when the lid is
closed, raising the lid
will wake the system up.

Table 3 - 1

Resuming
Operation

You can resume operation from power-saving states by pressing the power button,
or in some cases pressing the sleep button (Fn + F4 key combo).

Power Status

Power Off Off Press the Power Button

Sleep Blinking Green

Hibernate

Display Turned Off Green Press a Key or Move the Mouse/Touchpad

Icon Color

Press the Sleep Button (Fn + F4 Key Combo)

Off (battery)

Orange (AC/DC adapter)

To Resume

Press the Power Button

Press the Power Button



3.75G/HSPA

Modules & System

Wake Up

Note that the 3.75G mod­ules

DO NOT

system wake up on

3.75G/HSPA modem ac­tivity.

support

When the computer is on, you can use the power button as a Sleep/Hibernate/Shut Down
hot key button when it is pressed for less than 4 seconds (pressing and holding the power
button for longer than this will force the computer to shut down).

3 - 10 Configuring the Power Buttons



Power Button

Energy Star Power Saving

This system supports Energy Star power management features that place comput­ers (CPU, hard drive, etc.) into a low-power sleep modes after a designated period
of inactivity. If you want to enable Energy Star power saving then follow these in­structions:

1. Right-click the taskbar icon (see sidebar).

2. Select Power Conservation Modes.

3. Select Energy Star to use the Energy S t ar power management an d override othe r
power saving settings.

Power Management



Taskbar Icon

If the taskbar icon does
not appear then click the
taskbar arrow and select

Customize.

3



Conservation Modes

The default Energy Star setting
will result in maximum power sav­ing, but with the possible loss of
some performance.
Setting the mode to Balance will
give power saving matched with
performance.
Performance will give optimum
computer performance but with
less power conservation.

Configuring the Power Buttons 3 - 11

Select Show icon and
notifications alongside

the Hotkey icon and
click OK. The icon
will now appear in the
taskbar.

Figure 3 - 6

Energy Star Menu

Power Management

Battery Information



3

Low Battery

Warning

When the battery is criti­cally low, immediately
connect the AC/DC
adapter to the computer
or save your work, oth­erwise, the unsaved
data will be lost when
the power is depleted.

Figure 3 - 7

Battery Icon

(Taskbar) & Battery

Advanced Settings

Follow these simple guidelines to get the best use out of your battery.

Battery Power

Your computer’s battery power is dependent upon many factors, including the pro­grams you are running, and peripheral devices attached. You can set actions to be
taken (e.g. Shut down, Hibernate etc.), and set critical and low battery levels from
power plan Change plan settings > Change advanced power settings (see Figure

3 - 3 on page 3 - 6).

Click the battery icon in the taskbar to see the current battery level and charge
status.

Win 7 WinVista

3 - 12 Battery Information

Conserving Battery Power

•Use a power plan that conserves power (e.g Power saver), however note that

this may have an affect on computer performance.

• Lower the brightness level of the LCD display. The system will decrease LCD
brightness slightly to save power when it is not powered by the AC/DC adapter.

• Reduce the amount of time before the display is turned off.

• Close wireless, Bluetooth, modem or communication applications when they are
not being used.

• Disconnect/remove any unnecessary external devices e.g. USB devices,
ExpressCards etc.

Power Management



Windows Mobility

Center

The Windows Mobility
Center control panel

provides an easy point
of access for information
on battery status, power
plans used and wireless
device status etc.

Figure 3 - 8

Windows Mobility

Center

3

Battery Information 3 - 13

Power Management

Battery Life

Battery life may be shortened through improper maintenance. To optimize the life

3

and improve its performance, fully discharge and recharge the battery at least
once every 30 days.

We recommend that you do not remove the battery yourself. If you do need to re­move the battery for any reason (e.g. long term storage) see “Removing the Battery”

on page 6 - 3.

New Battery

Always completely discharge, then fully charge, a new battery (see “Battery FAQ”

on page 3 - 16 for instructions on how to do this).

Recharging the Battery with the AC/DC Adapter

The battery pack automatically recharges when the AC/DC adapter is attached and
plugged into an electrical outlet. If the computer is powered on, and in use, it will
take several hours to fully recharge the battery. When the computer is turned off but
plugged into an electrical outlet, battery charge time is less. (Refer to “LED Indica-

tors” on page 1 - 7 for information on the battery charge status, and to “Battery In­formation” on page 3 - 12 for more information on how to maintain and properly

recharge the battery pack.)

3 - 14 Battery Information

Proper handling of the Battery Pack

• DO NOT disassemble the battery pack under any circumstances

• DO NOT expose the battery to fire or high temperatures, it may explode

• DO NOT connect the metal terminals (+, -) to each other



Damaged Battery Warning

Should you notice any physical defects (e.g. the battery is bent ou t of shape after being
dropped), or any unusual smells emanating from the notebook battery, shut your computer
down immediately and contact your service center. If the battery has bee n d roppe d we do
not recommend using it any further, as even if the computer continues to work with a dam­aged battery in place, it may cause circuit damage, which may possibly result in fire . It is
recommended that you replace your computer battery every two years.

Power Management



Caution

Danger of explosion if
battery is incorrectly re­placed.

Replace only with the
same or equivalent type
recommended by the
manufacturer. Discard
used battery according
to the manufacturer’s in­structions.

3

Battery Information 3 - 15

Power Management

Battery FAQ

How do I completely discharge the battery?

3

Figure 3 - 9

Power Plan Create

Use the computer with battery power until it shuts down due to a low battery. Don’t
turn off the computer even if a message indicates the battery is critically low, just let
the computer use up all of the battery power and shut down on its own.

1. Save and close all files and applications.

2. Create a power plan for discharging the battery and set all the options to Never.

3 - 16 Battery Information

3. Click Change plan settings (after creating it) and click Change plan settings >

Change advanced power settings.

Power Management

3

Figure 3 - 10

Change Plan

Settings / Change

Advanced Power

Settings

Battery Information 3 - 17

Power Management

4. Scroll down to Battery and click + to expand the battery options.

5. Choose the options below (click Yes if a warning appears):

3

Figure 3 - 11

Power Options

Advanced Settings -

Battery

• Low battery levels = 0%

• Critical battery Levels = 0%

• Low battery action = Do Nothing

• Critical battery action (On battery) = Shut Down

• Critical battery action (Plugged in) = Do Nothing

3 - 18 Battery Information

How do I fully charge the battery?

When charging the battery, don’t stop until the LED charging indicator light changes
from orange to green.

How do I maintain the battery?

Completely discharge and charge the battery at least once every 30 days or after
about 20 partial discharges.

Power Management

3

Battery Information 3 - 19

Power Management

3

3-20

Drivers & Utilities

Chapter 4: Drivers & Utilities

This chapter deals with installing the drivers and utilities essential to the operation or improvement of some of
the computer’s subsystems. The system takes advantage of some newer hardware components for which the lat­est versions of most available operating systems haven’t built in drivers and utilities. Thus, some of the system
components won’t be auto-configured with an appropriate driver or utility during operating system installation.
Instead, you need to manually install some system-required drivers and utilities.

What to Install

The Device Drivers & Utilities + User’s Manual disc contains the drivers and utilities necessary for the proper
operation of the computer.

Table 4 - 1, on page 4 - 3 lists what you need to install and it is very important that the drivers are installed

in the order indicated.

Module Driver Installation

The procedures for installing drivers for the PC Camera, Wireless LAN, and 3.75G/HSPA modules are pro­vided in “Modules & Options” on page 7 - 1.

4

What to Install 4 - 1

Drivers & Utilities

Windows 7/Vista Driver Installation

Insert the Device Drivers & Utilities + User’s Manual disc and click Install Drivers/Option Drivers (button).

4

Figure 4 - 1 - Drivers Installer Screen 1

1. Check the driver installation order from Table 4 - 1, on page 4 - 3 (the drivers must be installed in this order)

which is the same as that listed in the Drivers Installer menu below.

2. Click to select the driver you wish to install, (you should note down the drivers as you install them).

3. Follow the instructions for each individual driver installation procedure as listed on the following pages.

4 - 2 Windows 7/Vista Driver Installation

Drivers & Utilities

Driver Win 7/Vista (SP2)

Chipset Page 4 - 6
Video Page 4 - 6
LAN Page 4 - 6
CardReader Page 4 - 6
Modem Page 4 - 6
TouchPad Page 4 - 6
Hot Key Page 4 - 7
Audio Page 4 - 7

Matrix Manager Page 4 - 9

Figure 4 - 2 - Drivers Installer Screen 2

Wireless LAN Module
PC Camera Module Page 7 - 19

3.75G/HSPA Module

Page 7 - 10

Page 7 - 26

4

Table 4 - 1 - Driver Installation

Windows 7/Vista Driver Installation 4 - 3

Drivers & Utilities

Manual Driver Installation

Click Bro wse CD/DVD (button) in the Drivers Install­er application and browse to the executable file in the

appropriate driver folder.

4

Windows Update

After installing all the drivers make sure you enable
Windows Update in order to get all the latest security
updates etc. (all updates will include the latest hotfixes
from Microsoft). See “Windows Update” on page 4 -

7 for instructions.



Windows Vista Service Pack 2

Make sure you install Windows Vista Service Pack 2
(or a Windows Vista version which includes Service
Pack 2) before installing any drivers. Go to the Micro­soft website for download details, or contact your service
center.

Updating/Reinstalling Individual Drivers

If you wish to update/reinstall individual drivers it
may be necessary to uninstall the original driver.To do
this go to the Control Panel in the Windows OS and
double-click the Programs and Features icon (Pro-
grams > Uninstall a program). Click to select the
driver (if it is not listed see below) and click Uninstall,
and then follow the on screen prompts (it may be nec­essary to restart the computer). Reinstall the driver as
outlined in this chapter.

If the driver is not listed in the Programs and Fea-
tures menu:

1. Click Start, and click Control Panel (or point to
Settings and click Control Panel).

2. Double-click Device Manager (Hardware and
Sound > Device Manager).

3. Double-click the device you wish to update/reinstall
the driver for (you may need to click “+” to expand
the selection).

4. Click Driver (tab) and click the Update Driver or

Uninstall button and follow the on screen prompts.

4 - 4 Windows 7/Vista Driver Installation

Drivers & Utilities

User Account Control

If a User Account Control prompt appears as part of
the driver installation procedure, click Continue or
Allow, and follow the installation procedure as direct­ed.

Windows Security Message

If you receive a Windows security message as part of
the driver installation process. Just click “Install this
driver software anyway” or “Install” to continue the
installation procedure.

You will receive this message in cases where the driv­er has been released after the version of Windows you
are currently using. All the drivers provided will have
already received certification for Windows.

New Hardware Found

If you see the message “New Hardware Found” dur­ing the installation procedure (other than when out-
lined in the driver install procedure), click Cancel
to close the window, and follow the installation proce­dure.



Driver Installation General Guidelines

The driver installation procedure outlined in this Chapter
(and in Chapter 7 Options & Modules), are accurate at
the time of going to press.

Drivers are always subject to upgrade and revision so
the exact procedure for certain drivers may differ slight­ly. As a general guide follow the default on screen in­structions for each driver (e.g. Next > Next > Finish)
unless you are an advanced user. In many cases a re­start is required to install the driver.

Make sure any modules (e.g. PC Camera, WLAN or

3.75G/HSPA) are ON before installing the appropriate
driver.

4

Windows 7/Vista Driver Installation 4 - 5

Drivers & Utilities

Driver Installation Procedure

Insert the Device Drivers & Utilities + User’s Manual
disc and click Install Drivers (button).

Chipset

4

1. Click 1.Install Chipset Driver > Yes.

2. Click Next > Yes > Next > Next.

3. Click Finish to restart the computer.

Video

1. Click 2.Install Video Driver > Yes.

2. Click Next > Yes > Next > Next.

3. Click Finish to restart the computer .

Note: After installing the video driver go to the Dis­play/Display Settings control panel to adjust the vid-

eo settings to the highest resolution.

LAN

1. Click 3.Install LAN Driver > Yes.

2. Click Install.

3. Click Finish.

CardReader

1. Click 4.Install CardReader Driver > Yes.

2. Click Install > Finish.

Modem

1. Click 5.Install Modem Driver > Yes.

2. Click OK.

3. The modem is ready for dial-up configuration.



Modem Country Selection

Go to the Phone and Modem (Options) control panel (Hard­ware and Sound) and make sure the modem country selection

is appropriate for you.

TouchPad

1. Click 6.Install Touchpad Driver > Yes.

2. Click Next.

3. Click the button to accept the license agreement
and click Next.

4. Click Finish > Restart Now to restart the com­puter.

4 - 6 Windows 7/Vista Driver Installation

Hot Key

1. Click 7.Install Hotkey Utility > Yes.

2. Click Next > Next.

3. Click Finish > Finish to restart the computer.

Audio

1. Click 8.Install Audio Driver > Yes.

2. Click Next.

3. Click Finish to restart the computer .

Note that after installing the audio driver the system
will not return to the Drivers Installer screen. To in­stall any of the optional drivers listed overleaf, eject
the Device Drivers & Utilities + User’s Manual disc
and then reinsert it (or double-click the disc icon in My
Computer), and click Option Drivers (button) to ac-
cess the optional driver menu.

Drivers & Utilities



Windows Update

After installing all the drivers make sure you enable Win­dows Update in order to get all the latest security up-

dates etc. (all updates will include the latest hotfixes
from Microsoft).

To enable Windows Update make sure you are con-
nected to the internet:

1. Click Start, and click Control Panel (or point
to Settings and click Control Panel).

2. Click Windows Update (System and
Security/Security).

3. Click Check for updates (button).

4. The computer will now check for updates
(you need to be connected to the internet).

5. Click Install now (button) to begin checking
for the updates.

6. Click Install updates (button) to install the
updates.

4

Windows 7/Vista Driver Installation 4 - 7

Drivers & Utilities

Windows Experience Index

After the drivers are installed follow this procedure to
ensure an accurate rating from the Windows Experi-
ence Index (make sure the AC/DC adapter is plugged
in):

4

For Windows 7:

1. Click Start, and click Control Panel.

2. Click Performance Information and Tools
(System and Security > System > Check the
Windows Experience Index).

3. Click “Rate this computer/Refresh Now/Re-
run the assessment”.

4. The computer will take a few minutes to assess
the system performance.

5. Close the control panel.

For Windows Vista:

1. Click Start, and click Control Panel (or point
to Settings and click Control Panel).

2. Double-click Performance Information and
Tools (in System and Maintenance).

3. Click “Rate this computer/Update my score”.

4. The computer will take a few minutes to assess
the system performance.

5. Close the control panel.

4 - 8 Windows 7/Vista Driver Installation

Drivers & Utilities

Optional Drivers

See the pages indicated for the driver installation pro­cedures for any modules included in your purchase op­tion.

Figure 4 - 3 - Drivers Installer - Option Drivers Menu

Bluetooth Module

Note: The operating system is the default setting for
Bluetooth control in Windows 7/Windows Vista, and

does not require a driver. See “Bluetooth Module” on

page 7 - 2 for configuration instructions.

Wireless LAN Module

See the introduction in “Wireless LAN Module” on

page 7 - 10, and check the installation procedure.

PC Camera Module

See the introduction in “PC Camera Module” on

page 7 - 18, and check the installation procedure.

3.75G/HSPA Module

See the introduction in “3.75G/HSPA Module” on

page 7 - 26, and check the installation procedure.

Matrix Manager

1. Insert the Device Drivers & Utilities + User’s
Manual disc into the CD/DVD drive.

2. Click Option Drivers (button).

3. Click 4.Install Matrix Manager > Yes.

4. Click Next > Yes > Next > Next.

5. Click Finish to restart the computer.

4

Windows 7/Vista Driver Installation 4 - 9

Drivers & Utilities

4

4-10

BIOS Utilities

Chapter 5: BIOS Utilities

Overview

This chapter gives a brief introduction to the computer’s built-in software:

Diagnostics: The POST (Power-On Self Test)

Configuration: The Phoenix SecureCore(tm) Setup Utility

If your computer has never been set up, or you are mak ing important chan ges to the
system (e.g. hard disk setup), then you should review this chapter first and note the
original settings found in Setup. Even if you are a beginner, keep a record of the set­tings you find and any changes you make. This information could be useful if your
system ever needs servicing.

There is one general rule: Don’t make any changes unless you are sure of what you
are doing. Many of the settings are required by the system, and changing them could
cause it to become unstable or worse. If you have any doubts, consult your service
representative.



BIOS Screens

Note that the BIOS
screens pictured on
these pages are intend­ed for guidance in set­ting up your system’s
BIOS.

BIOS versions are sub­ject to constant change
and revision, therefore
your computer’s actual
screens may appear
slightly different from
those pictured on these
pages.

5

Overview 5 - 1

BIOS Utilities

The Power-On Self Test (POST)



POST Screen

1.BIOS information

2.CPU type

3.Memory status

5

4.Enter Setup prompt
appears only during

POST

Note:

The

POST

screen
as pictured right is for
guideline purposes only.

POST

The
your computer may ap­pear slightly different. If
you disable the

time Diagnostic Screen

the POST screen will not
appear.

screen on

Boot-

When the Boot-time Diagnostic Screen is enabled (see page 5 - 9), each time you
turn on the computer, the system takes a few seconds to conduct a POST, including
a quick test of the on-board RAM (memory).

As the POST proceeds, the computer will tell you if there is anything wrong. If there
is a problem that prevents the system from booting, it will display a system summary
and prompt you to run Setup.

If there are no problems, the Setup prompt will disappear and the system will load
the operating system. Once that starts, you can’t get into Setup without rebooting.

1

,

2

3

Figure 5 - 1

POST Screen

5 - 2 The Power-On Self Test (POST)

4

Failing the POST

Errors can be detected during the POST. There are two categories, “fatal” and “non­fatal”.

Fatal Errors

These stop the boot process and usually indicate there is something seriously wrong
with your system. Take the computer to your service representative or authorized
service center as soon as possible.

Non-Fatal Errors

This kind of error still allows you to boot. You will get a message identifying the
problem (make a note of this message!) followed by the prompt:

• Press <F1> to resume

• <F2> to enter Setup

Press F1 to see if the boot process can continue. It may work, without the correct
configuration.

BIOS Utilities



BIOS Settings

Warning

Incorrect settings can
cause your system to
malfunction. To correct
mistakes, return to Set-

up and restore the Set­up Defaults with <F9>.

5

Press F2 to run the Setup program and try to correct the problem. If you still get an
error message after you change the setting, or if the “cure” seems even worse, call
for help.

The Power-On Self Test (POST) 5 - 3

BIOS Utilities

The Setup Utility

The Phoenix SecureCore(tm) Setup Utility tells the system how to configure itself
and manage basic features and subsystems (e.g. port configuration).

Entering Setup

To enter Setup, turn on the computer and press F2 during the POST. The prompt

5

(Press F2 to Enter Setup) seen on page 5 - 2 is usually present for a few seconds
after you turn on the system. If you get a “Keyboard Error”, (usually because you
pressed F2 too quickly) just press F2 again.

If the computer is already on, reboot using the Ctrl + Alt + Delete combination and
then hold down F2 when prompted. The Setup main menu will appear.

5 - 4 The Setup Utility

Setup Screens

The following pages contain additional advice on portions of the Setup.

Along the top of the screen is a menu bar with menu headings. When you select a
heading, a new screen appears. Scroll through the features listed on each screen to
make changes to Setup.

Instructions on how to navigate each screen are in the box along the bottom of the
screen. If these tools are confusing, press F1 to call up a General Help screen, and
then use the arrow keys to scroll up or down the page.

The Item Specific Help on the right side of each screen explains the highlighted
item and has useful messages about its options.

If you see an arrow next to an item, press Enter to go to a sub-menu on that sub-
ject. The sub-menu screen that appears has a similar layout, but the Enter key may
execute a command.

BIOS Utilities



Setup Menus

The Setup menus
shown in this section are
for reference only. Your
computer’s menus will
indicate the configura­tion appropriate for your
model and options.

5

The Setup Utility 5 - 5

BIOS Utilities

Main Menu

Figure 5 - 2

Main Menu

5

System Time & Date (Main Menu)

The hour setting uses the 24-hour system (i.e., ØØ = midnight; 13 = 1 pm). If you
can change the date and time settings in your operating system, you will also change
these settings. Some applications may also alter data files to reflect these changes.

5-6Main Menu
