USER MANUAL
PM 100 PAGING MICROPHONE (5 ZONE)
Order code: CRMIC01
www.cleveracoustics.co.uk
WARNING
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY
BEFORE YOUR INITIAL START-UP!
CAUTION!
Keep this equipment away from rain,
moisture and liquids.
SAFETY INSTRUCTIONS
Every person involved with the installation, operation & maintenance of this
equipment should:
- Be competent
- Follow the instructions of this manual
CAUTION! TAKE CARE USING THIS EQUIPMENT!
HIGH VOLTAGE-RISK OF ELECTRIC SHOCK!!
Before your initial start-up, please make sure that there is no damage caused during
transportation. Should there be any, consult your dealer and do not use the equipment.
To maintain the equipment in good working condition and to ensure safe operation, it is
necessary for the user to follow the safety instructions and warning notes written in this
manual.
Please note that damages caused by user modications to this equipment are not
subject to warranty.
1
2
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused
by the non-observance of this manual or any unauthorised modication to the
equipment.
• Never let the power-cable come into contact with other cables. Handle the
power-cable and all mains voltage connections with particular caution!
• Never remove warning or informative labels from the equipment.
• Do not open the equipment and do not modify the equipment.
• Do not switch the equipment on and off in short intervals, as this will reduce the
system’s life.
• Only use the equipment indoors.
• Do not expose to ammable sources, liquids or gases.
• Do not carry the unit with only one handle. Always carry using both handles.
• Always disconnect the power from the mains when equipment is not in use or
before cleaning! Only handle the power-cable by the plug. Never pull out the plug
by pulling the power-cable.
• Make sure that the available voltage is DC 24V.
• Make sure that the power-cable is never crimped or damaged. Check the
equipment and the power-cable periodically.
• If the equipment is dropped or damaged, disconnect the mains power supply
immediately.
Have a qualied engineer inspect the equipment before operating again.
• If the equipment has been exposed to drastic temperature uctuation (e.g. after
transportation), do not switch it on immediately. The arising condensation might
damage the equipment. Leave the equipment switched off until it has reached
room temperature.
• If your product fails to function correctly, discontinue use immediately. Pack the
unit securely (preferably in the original packing material), and return it to your
Prolight dealer for service.
• Only use fuses of same type and rating.
• Repairs, servicing and power connection must only be carried out by a qualied
technician. THIS UNIT CONTAINS NO USER SERVICEABLE PARTS.
• WARRANTY; One year from date of purchase.
• If this equipment is operated in any other way, than those described in this
manual, the product may suffer damage and the warranty becomes void.
• Incorrect operation may lead to danger e.g.: short-circuit, burns, electric shocks,
lamp failure etc.
• Do not endanger your own safety and the safety of others!
Incorrect installation or use can cause serious damage to people and property.
The PM 100 Paging microphone is designed to be used in conjunction with the MA 240Z5
Mixer Amplier (5 Zone).
Features
• Remote paging microphone with input priority over MIC 1, siren and chime except for
EMC and telephone input
• Condenser gooseneck microphone
• 2/4 tone selectable chimes
• 5 zone, all zone, talk and chime buttons
• Volume control over chime, mic and master
•LED amplier output level meter
3
Pin 1: Remote amplier input signal hot (+)
Pin 2: Remote amplier input signal cold (-)
Pin 3: Signal ground
Pin 4: Remote control 1 (zone 1)
Pin 5: Remote control 2 (zone 2)
Pin 6: Remote control 3 (zone 3)
Pin 7: Remote control 4 (zone 4)
Pin 8: Remote control 5 (zone 5)
Pin 9: Remote control ground
Pin 10: DC +24V
Pin 11: Input chime
Pin 12, 13, 14, 15: Not used
Port pin conguration:
Specications PM 100
Microphone Inputs: Mic 1-4 in @ 1kHz
Sensitivity: -50dB/600Ω balanced
Frequency response:
30Hz-16kHz (±3dB)
THD: < 0.1%
S/N ratio: >65dB
Power supply: 24V DC
Dimensions (H x W x D): 197 x 115 x 43.5mm
Weight: 0.9kg
Order code: CRMIC01
4
Identication:
1. 3-pin XLR mic input - Use this socket to connect the supplied microphone
2. LED Output level meter - Displays amplier output level.
3. Zone selector buttons - Use these button to select the desired zone
4. Talk LED - When the talk button has been pressed the LED will light up.
5. Chime LED - When the chime button has been pressed the LED will light up.
6. Chime button - Use this button to activate the chime tone
7. Talk button - Use this button activate the talk function
8. All call button - Use this button to activate all 5 zones to page out to.
9. All call LED - When All Call has been selected this LED will light up.
10. Zone LEDs - These LEDs will light up according to which zone has been selected
11. DC 24V input - This power input is only required if the mic is on 50m+ of cable
12. On/off power switch - Use the switch to power the unit on or off
13. Communication port - Use this socket to connect to the MA 240Z5 amplier.
14. Chime volume control - Use this control to increase or decrease the chime volume
15. Mic volume control - Use this control to increase or decrease the mic volume
16. Master volume control - Use this control to increase or decrease the master volume
17. 2/4 tone selector switch - Use this switch to select between the two tone options.
0 10
0 10
0 10
OPTIONAL
POWER
24V DC
ON
OFF
CHIME VOL
OUTPUT TO ZONE AMPLIFIER
MASTER VOLMIC VOL
CHIME
2 TONE 4 TONE
ZONE 1 ALL CALLZONE 2 ZONE 3 ZONE 4 ZONE 5
CHIMETALK
-18 -15
-12
-9 -6 -3 0 +3 +6 PEAK
OUTPUT LEVEL
12
3
PUSH
1
2
3
1 - GND
2 - GND
3 - +24V DC
ON
OFF
PM 100 PAGING MICROPHONE
5
PM 100 (CRMIC01)
Back Panel
MA 240Z5
XLR BAL
1-GND
2-HOT+
3-COLD-
CHIME ACTIVE
+48V PHANTOM
ON OFF ON OFF ON OFF ON OFFPRIORITY
MIC 1
GAIN
CHIME
2 TONE 4 TONE
REMOTE MIC
240V 50Hz
T6.3AL 250V
MIC 2
GAIN
+48V PHANTOM
MIC 3
GAIN
+48V PHANTOM
MIC 4
GAIN
+48V PHANTOM
TEL
VOLUME
INPUT
LINE 1
OUT
LINE 2
LINE
TEL
EMC
INPUT
OUTPUT
ZONE 5ZONE 4ZONE 3ZONE 2ZONE 1
COM
100V
COM
100V
COM
100V
COM
100V
COM
100V
100V48Ω 70V
COM
BATTERY SUPPLY
24V
16A
Panel Connections:
6
Cleaning and Maintenance
We recommend a frequent cleaning of the product. Please use a soft lint free and moistened
cloth. Never use alcohol or solvents.
There are no serviceable parts inside the product except for the fuse. Maintenance and service
operations are only to be carried out by authorised dealers.
Should you need any spare parts, please use genuine parts.
Should you have any further questions, please contact your dealer.
CAUTION - DANGER TO LIFE
DISCONNECT FROM THE MAINS BEFORE
STARTING MAINTENANCE OPERATION
Problem Chart
CAUSE
The power supply is not connected
The power supply of the respective
product is not connected properly or
not at all.
The connection socket or the plug
is dirty.
The input signal is too strong
Input is too strong
REMEDY
Check the power supply and any
extension cables
Check the power supply and if the
plugs are properly connected with
the sockets.
Clean the socket and/or the plug.
Reduce the input signal via the
gain control.
Ensure the user is not shouting into
the microphone or positioning the
microphone too close to the users
mouth.
PROBLEM
No Power
No Sound
Noise
Distorted Sound
www.cleveracoustics.co.uk
