Cleveland
™
P
roject ________________________________
I
tem __________________________________
Quantity _______________________________
FCSI Section ____________________________
A
pproval _______________________________
D
ate __________________________________
1333 East 179 St.,
Cleveland, Ohio, U.S.A. 44110
Tel: 1-216-481-4900
Fax: 1-216-481-3782
Web Site: www.ClevelandRange.com
Email: Steam@ClevelandRange.com
COOK CHILL SYSTEMS
C
ook/Chill Systems
AIR COOLED
CONDENSING UNITS
Cleveland Standard Features
n Air cooled condensing unit for outdoor installation
n For operation with R-22, 404A or R507 refrigerant
(please specify)
n Liquid line filter with replaceable core and sight glass
n High ef
n Galvalume weather housing with raised base compressor
n Thermally protected
n Permanently lubricated condenser fan motor(s)
n Access panels for easy servicing of internal components
n Electrical controls are mounted in control box with hinged
n Receivers include service valves
n Suction and discharge vibration eliminators
n 180 lbs. head pressure valve
n Crankcase heater for cold temperature operation
n Suction filter with replaceable core
n Suction accumulator
n Oil separator
n Low ambient kit
n Anti short cycle timer
n Liquid line solenoid valve (shipped loose)
n Dry contacts for compressor alarm
n Accepted for use in U.S.D.A. Inspected Facilities
Options & Accessories
ficiency Copeland discus compressor
door
MODELS:
c
BLH7.5H2cBLH25H2cJLD50H2*
LH10H2
c
B
c
BLH15H2
c
BLH20H2
hese units have two (2) compressors
T
*
and are not supplied with fused disconnects
c
B
c
BLH35H2
c
BLH40H2
LH30H2
c
LD60H2*
J
Short Form Specifications
Shall be CLEVELAND, Model BLH or JLD - ______- H2, Outdoor,
____ HP, AIR COOLED CONDENSING UNIT for Ice Builder.
Weather housing with raised Base Compressor; Receiver with
Discharge and Suction Line Vibration eliminators; Pressure Control;
Drier//Sight Glass Kit; Liquid Line Solenoid Valve; replaceable Core
Suction Line Filter, Suction Line Accumulator; Oil Separator and Oil
Failure Safety Control; Head Pressure Control Valve; Control Panel
with hinged door housing Low Ambient Kit, Compressor Contactor,
and Control Circuit Fusing.
ater Cooled Condensing Units
p W
p Larger models available upon request
p Extended four (4) year compr
(domestic only)
p Ice Water Control Panel for location in production area
p Ice Builders
essor warranty
SECT. XIV PAGE 49
0707
REAR VIEW
B
LH-7.5-H2 thru BLH-10-H2
A
35 3/8"
B
C
55 5/8"
B
LH-15-H2 thru BLH-40-H2
REAR VIEW
PLAN VIEW
44 1/2"
SUCTION
LINE
LIQUID
LINE
LINE
SUCTION
LIQUID
LINE
KNOCKOUTS
FOR
ELECTRICAL
CONNECTIONS
39 1/8"
F
USED
DISCONNECT
SWITCH
SIDE VIEW
P
LAN VIEW
REAR VIEW
PLAN VIEW
55 5/8"
D
87 1/16"
J
DL-50-H2 thru JDL-60-H2
LINE
SUCTION
LINE
LIQUID
KNOCKOUTS
FOR
ELECTRICAL
CONNECTIONS
KNOCKOUTS
FOR
ELECTRICAL
CONNECTIONS
MINIMUM CLEARANCE
RONT 24" MIN
F
SIDE 24" MIN
REAR 24" MIN
DIMENSIONS
ICE BUILDER SHIPPING WEIGHTS
MODEL MODEL A B C D LBS / KG
BLH-7.5-H2 IBC-50 67 3/4" - - - 1350 / 614
BLH-10-H2 IBC-75 67 3/4" - - - 1650 / 750
BLH-15-H2 IBC-100 - 144" - - 1900 / 864
BLH-20-H2 IBC-125 - 144" - - 1980 / 900
BLH-25-H2 IBC-150 - 170 3/4" - - 2170 / 987
BLH-30-H2 IBC-175 - 170 3/4" - - 2260 / 1028
BLH-35-H2 IBC-200 - - 225 3/4" - 2760 / 1255
BLH-40-H2 IBC-250 - - 225 3/4" - 2860 / 1300
JLD-50-H2 IBC-300 - - - 171" 4060 / 1846
JLD-60-H2 IBC-350 - - - 171" 4520 / 2055
UTILITY CONNECTIONS ELECTRICAL 208 / 3PH
MODEL LBS LINE LINE LOAD AMPS QTY LOAD
BLH-7.5-H2 162 1/2" 1 1/8" 28.3 2 38.1
BLH-10-H2 227
BLH-15-H2
BLH-20-H2
BLH-25-H2 444 1 1/8" 2 1/8" 82.8 2 116.8
BLH-30-H2 444 1 1/8" 2 1/8" 94 2 131.5
BLH-35-H2
BLH-40-H2 672 1 1/8" 2 1/8" 142 3 198.5
JLD-50-H2 (2) 444 1 1/8" 2 1/8" * 82.2 4 201.0
JLD-60-H2
REFRIGERANT NO
AIR COOLED CONDENSING UNITS ARE FOR OUTDOOR INST
WATER COOLED CONDENSING UNITS ARE FOR INDOOR INSTALLATION.
Cleveland Range reserves right of design improvement or modification, as warranted.
RECEIVER
CAPACITY LIQUID SUCTION RATED FAN MOTOR AMP
275 7/8" 1 5/8" 59.9 2 82.5
275 7/8" 1 5/8" 66 2 90.5
672
(2) 444
7/8" 1 3/8"
1 1/8" 2 1/8" 107 3 154.8
1 1/8"
T SUPPLIED BY CLEVELAND RANGE.
2 1/8"
ALLA
COMPRESSOR CONDENSER TOTAL
39.1 2 54.3
* 94
4
*PER SIDES
TION.
239.5
O SCALE)
T
(NOT
SECT. XIV PAGE 50
0707
Litho in USA
