COOK CHILL SYSTEMS

CYCLE-MATIC SYSTEM

VERTICAL FORM-FILL-SEAL MACHINE, FOOD
TRANSFER PUMP & EXITING CONVEYOR

Cleveland General Specifications

The Cycle-Matic System is an auto­matic Form-Fill-Seal Machine, Food
Transfer Pump and Exiting Conveyor
for higher volume operations. It pro­vides a hands free solution for pack­aging any hot or cold pumpable
product (soups, stews, sauces, chili,
salad dressings, etc.) into heat
sealed pouches.

This system converts rolls of film into
heat sealed pouches while automati­cally filling them.

The pouch and portion size can eas­ily be changed with the user friendly
controls.

To change product portion adjust
the food transfer pump.

Accepted for use in U.S.D.A.
Inspected Facilities

Cook/Chill Systems

For detailed specifications see:

Item Section Pages

Vertical Form-Fill-Seal Machine XIV 29-30

Food Transfer Pump XIV 31-32

Exiting Conveyor XIV 33-34

SECT. XIV PAGE 27

0907

2

3

1

1

4

4

2

D

1 D 2

B

D

1 D 2

B

Equipment

1. Vertical Form-Fill-Seal Machine

2. Exiting Conveyor

3. Food Transfer Pump

4. Casing Convey (ref. only)

Cleveland Range reserves right of design improvement or modification, as warranted.

Utilities

AIR ELECTRICAL

1/2" NPT 208/220V-1PH-50/60HZ

NOTE: AIR MUST BE DRY, CLEAN
AND FREE OF OIL

(NOT TO SCALE)

SECT. XIV PAGE 28

0907
