Cleveland
™
P
roject ________________________________
I
tem __________________________________
Quantity _______________________________
FCSI Section ____________________________
A
pproval _______________________________
D
ate __________________________________
1333 East 179 St.,
Cleveland, Ohio, U.S.A. 44110
Tel: 1-216-481-4900
Fax: 1-216-481-3782
Web Site: www.ClevelandRange.com
Email: [email protected]
MODULAR BASES
SINK SPACER MODULE WITH DRAIN
WIDTHS OF 300, 450, 600 or 900MM
ENCLOSED TYPE
Cleveland Standard Features
n Type 430 Stainless Steel exterior enclosure; table top and
sink with #4 finish
n 6" Stainless Steel Legs with level adjustment
n Hot and Cold w
n Drain outlet connection with 1 1/2" drain spud and strainer
n Enclosed cabinet styling
Options & Accessories
p Double joint swing spout for extended reach, up to 18
inches
p Cold only single faucet with swing spout (450mm)
p Removable storage shelf
p 10" adjustable legs (LF10)
p Flanged Feet (FF)
p Stainless Steel base frame (FSS)
ater faucet with swing spout
MODELS: c 300-SSM c 600-SSM
c 450-SSM c 900-SSM
Shall be CLEVELAND Model
connection, hot and cold water faucet with swing spout. Type 430 Stainless
Steel sink, Table Top, exterior enclosure and 6" level adjustable legs.
Short Form Specifications
-SSM with sink having 1 1/2" spud drain
_____
SECT. VII PAGE 19
0707
Page 2
3/8" NPT
Right - 0
Left - 0
Rear - 0
NOTES:
Cleveland Range reserves right of design improvement or modification, as warranted.
Many regional, state and local codes exist and it is the responsibility of the owner and installer to comply with the codes.
Cleveland Range equipment is built to comply with applicable standards for manufacturers. Included among those approval agencies are UL/NSF#4.
(NOT TO SCALE)
.
SECT
VII P
Litho in U.S.A.
GE
A
20
0707
