EDGE
PULSE
QUICK START GUIDE
EDGE
QUICK START GUIDE
1
S, M, L silicon ear tips
2
Wearing instruction
1. Wrap the loop around your ear.
2. Plug the ear tips into your ear.
3. Adjust the cable length adjuster.
EDGE
QUICK START GUIDE
3
Long press to power ON/OFF
>2.5s
4
First time pairing with new device
>5s
Turn ON NFC on
your device and
place it near the
left earbud.
Cleer EDGE
EDGE
QUICK START GUIDE
5
Charging
Full Charge
1. Pull o the cover.
2. Plug the cable.
6
Heart beat monitoring
Your Cleer EDGE Pulse is compatible
with fitness apps that support heart rate
sensors, like MapMyRun™, Endomondo
and Codoon.
After pairing Cleer EDGE Pulse, follow
the app instructions to connect the heart
rate sensor.
*Premium membership may be required
for in-app heart rate function.
EDGE
Heart rate sensor is located inside the
LEFT earbud, activation button is on the
RIGHT.
Please stay still and avoid movements
during the calibration process.
QUICK START GUIDE
1. Long touch to activate/
deactivate sensor.
2. Short Touch to hear
voice prompt.
EDGE
Tap the heart rate button on the RIGHT
side of the earcup for an instant audible
heart rate BPM reading.
QUICK START GUIDE
128 bpm
7
LED Behavior.
Blinking Steady
State
No device connected
Pairing mode
Device connected
Low battery
Charging battery
LED
behaviors
EDGE
QUICK START GUIDE
8
Specs.
EN
• Premium 5.8mm Dynamic Driver
• Frequency Response : 20Hz-20kHz
• Connecting : Micro USB cable for charging
• Support : BT 4.2, A2DP v1.3, AVRCP v1.5,
HFP v1.6, HSP v1.2
• Bluetooth transmitter frequency range :
2.402-2.480GHz
• Bluetooth transmitter power : <4dBm
• Bluetooth transmitter modulation : GFSK, π/4
DQPSK, 8DPSK
• Battery type : Rechargeable Lithium Ion
rectangle Cell ( 3.7V 120 mAh)
• Quick Charge Battery : 5 mins for one hour
EDGE
QUICK START GUIDE
Cleer Limited Warranty
(United States Only)
Cleer Limited warrants this product against defects
in material or workmanship for (1) year as set forth
below when purchased directly from Cleer Limited
or a Cleer Limited retailer. Pursuant to this Limited
Warranty, Cleer Limited will, at its option, (i) repair the
product using new or refurbished parts or (ii) replace
the product with a new or refurbished product. For
purposes of this Limited Warranty, “refurbished”
means a product or part that has been returned to its
original specifications. In the event of a defect, these
are your exclusive remedies.
Labor: For a period of (1) year from the original date
of purchase of the product (“Labor Warranty”), Cleer
Limited will, at its option, repair or replace with new
or refurbished product, product determined to be
defective. If Cleer Limited elects to replace the product
after this Labor Warranty has expired but while the
parts warranty is still in eect, it will do so for the
applicable labor charge.
Parts: For a period of (1) year from the original date
of purchase of the product (“Parts Warranty”), Cleer
Limited will supply new or refurbished replacement
parts in exchange for parts determined to be defective.
This Limited Warranty covers only the hardware
components packaged with the Product. It does not
cover technical assistance for hardware or software
usage and it does not cover any software products
whether or not contained in the Product; any such
software is provided “AS IS” unless expressly provided
for in any enclosed software Limited Warranty. Please
refer to the End User License Agreements included
with the Product for your rights and obligations with
respect to the software.
Instructions: To obtain warranty service, you must
deliver the Product, freight prepaid, in either its original
packaging or packaging aording an equal degree of
EDGE
protection to the original Cleer Limited retailer (point of
purchase) or Cleer Limited Customer Service. It is your
responsibility to backup any data, software or other
materials you may have stored or preserved on your
unit. It is unlikely that such data, software or other
materials will be lost or reformatted during service
and Cleer Limited will not be responsible for any
such damage or loss. A dated purchase receipt from
Cleer Limited or a Cleer Limited retailer is required. For
specific instructions on how to obtain warranty service
for your product,
Visit the Cleer Limited website: www.cleer.us
Or call Cleer Limited Customer Service at:
1 888 672 5337 (67 CLEER)
For an accessory or part not available from your
authorized dealer call: 1 888 672 5337 (67 CLEER)
Following warranty service your original Product or a
replacement Product will be returned to you as your
Product was configured when originally purchased.
Repair / Replacement Warranty: This Limited
Warranty shall apply to any repair, replacement part or
replacement product for the remainder of the original
Limited Warranty period or for (90) days, whichever
is longer. Any parts or product replaced under this
Limited Warranty will become property of Cleer Limited
This Limited Warranty shall not apply to: (a)
consumable parts, such as batteries that are designed
to diminish over time, unless failure has occurred due
to a defect in materials or workmanship; (b) cosmetic
damage, including but not limited to scratches, dents
and broken plastic on ports; (c) defects caused by
normal wear and tear or otherwise due to the normal
aging of the device; (d) damage caused by accident,
negligence, abuse, misuse, fire, earthquakes, acts of
God or damage resulting from liquid outside of the
approved levels; (e) damage caused by operating the
device outside Cleer Limited published guidelines;
QUICK START GUIDE
EDGE
(f) damage caused by service performed by anyone
who is not a representative of Cleer Limited or a Cleer
Limited authorized service provider; (g) Products
whose seals are tampered; (h) Products whose
serial numbers have been removed or defaced
from such Product; (i) modications, alterations or
repairs to the Product made by a party other than
Cleer Limited or a party authorized by Cleer Limited;
(j) any failure by End User or a third party to comply
with environmental and storage requirements for the
Product specified by Cleer Limited, including, without
limitation, temperature or humidity ranges; or (k) use
of the Product in combination with any third-party
devices or products that have not been provided or
recommended by Cleer Limited. This Limited Warranty
is valid only in the United States.
LIMITATION ON DAMAGES: CLEER LIMITED
SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES FOR BREACH OF
ANY EXPRESS OR IMPLIED WARRANTY ON THIS
PRODUCT.
DURATION OF IMPLIED WARRANTIES: EXCEPT
TO THE EXTENT PROHIBITED BY APPLICABLE LAW,
ANY IMPLIED WARRANTY OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE ON THIS
PRODUCT IS LIMITED TO THE DURATION OF THIS
WARRANTY.
DISCLAIMER: THE LIMITED WARRANTY SET FORTH
HEREIN IS EXCLUSIVE AND IN LIEU OF ALL OTHER
WARRANTIES OR CONDITIONS RELATING TO
THE PRODUCT, WHETHER EXPRESS OR IMPLIED,
AND CLEER LIMITED EXPRESSLY DISCLAIMS ALL
OTHER WARRANTIES AND CONDITIONS WHETHER
EXPRESS, IMPLIED OR STATUTORY, INCLUDING
ANY IMPLIED WARRANTIES OF MERCHANTABILITY,
NON-INFRINGEMENT, FITNESS FOR A PARTICULAR
PURPOSE, AND ANY WARRANTIES ARISING OUT
OF COURSE OF DEALING OR USAGE OF TRADE
AND AGAINST HIDDEN DEFECTS, TO THE FULLEST
EXTENT PERMITTED BY LAW. CLEER LIMITED DOES
NOT WARRANT THAT THE PRODUCT WILL MEET
CUSTOMER’S REQUIREMENTS OR THAT USE OF
THE PRODUCT WILL BE UNINTERRUPTED OR ERROR
FREE. NO ADVICE OR INFORMATION, WHETHER
ORAL OR WRITTEN, OBTAINED FROM CLEER LIMITED
QUICK START GUIDE
EDGE
OR ELSEWHERE WILL CREATE ANY WARRANTY NOT
EXPRESSLY STATED IN THIS WARRANTY.
Some states do not allow the exclusion or limitation
of incidental or consequential damages, or allow
limitation on how long an implied warranty lasts, so the
above limitations or exclusions may not apply to you.
This Limited Warranty gives you specific legal rights
and you may have other rights which vary from state
to state.
QUICK START GUIDE
NOTICE
Recycing
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused. When
you see the crossed-out wheel bin symbol
attached to a product, it means the product is covered
by the European Directive 2002/96 EC:
Never dispose of your product with other
household waste. Please inform yourself
about the local rules on the separate
collection of electrical and electronic
products. The correct disposal of your
old product helps prevent potentially negative
consequences on the environment and human
health. Your product contains batteries covered by
the European Directive 2006/66/EC, which cannot be
disposed of with normal household waste.
Compliance with FCC rules
1. This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference
received, including interference that may cause
undesired operation.
2. Changes or modifications not expressly approved
by the party responsible for compliance could void the
user’s authority to operate the equipment.
EDGE
NOTE: This equipment has been tested and found
to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation.If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment o
and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet on a circuit di
erent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure
requirement.
The device can be used in portable exposure condition
without RF striction.
QUICK START GUIDE
Register your product and get
support at www.cleer.us
©2017 Cleer Limited. All rights reserved
The Bluetooth® word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc. and any
use of such marks by Cleer Limited is under license.
Other trademarks and trade names are those of their
respective owners.
MADE IN CHINA
