CONVERGE™ PRO 880/840T/TH20/8i Professional Conferencing Systems

SERIAL COMMAND GUIDE

TECHNICAL SUPPORT

Telephone 1.800.283.5936

1.801.974.3760 Fax 1.801.977.0087 Email tech.support@clearone.com Web www.clearone.com

CONVERGE PRO 880/840T/TH20/8i SERIAL COMMAND GUIDE

CLEARONE PART NO. 800-151-882 (REVISION 1.0) September 2007

© 2007 ClearOne Communications, inc. All rights reserved. No part of this document may be reproduced in any form or by any means without written permission from ClearOne Communications. Printed in the United States of America. ClearOne reserves specific privileges. Information in this document is subject to change without notice.

Flash are either trademarks or registered trademarks in the United States and/or other countries.

SERIAL COMMAND GUIDE

TYPE AND DEVICE IDS

Converge Pro Device Types and Device IDs by model are as follows:

Model Device Type Device ID Range

880 1 0-7

TH20 2 0-F

840T 3 0-7

8i A 0-7

CONVENTIONS

This guide uses the following typographic conventions to describe Converge Pro serial command syntax:

Convention Description

<X> Parameters enclosed in < > indicate a mandatory parameter

[X] Parameters enclosed in [ ] indicate an optional parameter

1-8 Parameters separated by a ‘-‘ indicate a range of allowable values

4,7,9 Parameters separated by a ‘,’ indicate a list of allowable values

EREF Words in UPPERCASE bold indicate command text

Device Indicates the device type and device number on the Expansion Bus. It is

composed of a device type character and a device ID character.

COMMAND FORM DESCRIPTION

The structure of serial commands is as follows:

# <Device Type> <Device ID> <Command> [Values] <Carriage Return>

# indicates the start of a command line, the Carriage Return terminates a command.

NOTE: Converge Pro serial commands can be either UPPERCASE or lowercase. Return values

are always in UPPERCASE. In order for a command to be recognized by the RS-232 serial port, the command must be terminated by a carriage return.

For example, a command to disable mute for Mic 2 (input channel 2) on Converge 880 device “0” would have the command line #10 MUTE 2 M 0.

In this command line, 1 = the Device Type for Converge 880, 0 = the Device ID for unit 0, MUTE = Converge Pro serial command, 2 = MUTE command Value to un-mute mic channel 2, M = MUTE command Value that specifies a microphone input channel, 0 = MUTE command Value specifying that mute is OFF.

If an asterisk (*) is placed in the Device Type or Device ID fields, the command will apply to all units or all devices respectively. For example, a command with a Device Type = 1 and a Device ID = * would apply the command to all Converge 880 units. A command with a Device Type = * and a Device ID = 6 would apply the command to all Converge Pro units with a Device ID of 6.

If a command specifies “(Null to query in text)” in its Value table, leave a blank in the command line to query the current state of that value. For example, the command #10 MUTE 2 M <blank> would return the current mute state of Mic 2 on an Converge Pro 880 with a Device ID of 0.

Converge™ Pro Serial Command Guide 1

GROUPS AND CHANNELS

All Converge Pro serial commands use common alpha and numeric designators to reference channel group, channel types, and other command values. Also, different channel groups have different allowable channel ranges, as shown in the following table.

Group Alpha Number Converge 880

Channel

Range

Unknown ? 0 N/A N/A N/A N/A

Inputs I 1 1-12 1-2 1-8 1-12

Outputs O 2 1-12 1-2

Mic Input M 3 1-8 N/A 1-4 1-8

Gating Group G 4 1-8 N/A 1-8 1-8

Processing P 5 1-8 N/A 1-4 1-8

Expansion Bus Audio Channels

Line Inputs L 7 9-12 1-2 5-8 9-12

Expansion Bus Reference Channels

Unit U 9

GPIO Y 10 0 0 0 0

Matrix X 11 0 0 0 0

Fader F 12 1-4 N/A 1-4 1-4

Presets S 13 1-32 1-32 1-32 1-32

Macros C 14 1-255 1-255 1-255 1-255

Transmit T 16 N/A 1 1 N/A

Receive R 17 N/A 1 1 N/A

Dictionary D 18 0 0 0 0

Phonebook V 19 N/A 0 0 N/A

Virtual Reference

Timed Events Q 21 0 0 0 0

Web W 22 0 0 0 0

E 6 O-Z O-Z O-Z O-Z

A 8 1-4 1-4 1-4 1-4

0 1 = LOG 2 = Site Wide

B 20 1 – 4 N/A 1 – 4 1 – 4

Converge TH20

Channel

Range

0 1 = LOG 2 = Site Wide

Converge

840T Channel

Range

1-9(9 is the

power amp)

0 1 = LOG 2 = Site Wide

Converge

8i Channel

Range

N/A

0 1 = LOG 2 = Site Wide

2 Technical Services: 800-283-5936

METER TYPE DEFINITIONS TABLE

Alpha Numeric Level Position

for Mics

I 1 Input level Input level Input level N/A

Level after gain

T 7 ERL + ERLE N/A N/A N/A N/A

C 9 AGC AGC N/A N/A N/A

adjustment, but before filter

Level after filter but before gate (non-gated level)

Level after gate (gated level)

Echo Return Loss

Echo Return Loss Enhancement

Level Position for Line Inputs

Level after gain adjustment

N/A N/A N/A

N/A N/A N/A N/A N/A

N/A N/A N/A N/A

Level position

for Outputs and

Telco Tx

Level after gain adjustment

Level

Position for

Faders

Level after gain adjustment

Position for Processors

Level into Compressor

Level after Compressor

Level after Gain Stage

Level

Level Position

for Telco Rx

Input Level

Level after gain adjustment

N/A

Telco Echo Return Loss

Telco Echo Return Loss Enhancement

TERL + TERLE

N/A

Y10

Z11

Pre AGC peak level meter

Post AGC peak level meter

Pre AGC peak level meter

Post AGC peak level meter

N/A N/A N/A N/A

Converge™ Pro Serial Command Guide 3

SERIAL COMMAND INDEX

AA – Auto Answer Enable / Disable (840T & TH20 only). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

AAMB – Adaptive Ambient Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

AARINGS – Number of Rings to Auto Answer On (840T & TH20 only). . . . . . . . . . . . . . . . . . . . . . . . . .8

ACONN – Audible Connect / Disconnect Indication (840T & TH20 only) . . . . . . . . . . . . . . . . . . . . . . . .8

ACONNLVL – Audible Connect / Disconnect Level (840T & TH20 only). . . . . . . . . . . . . . . . . . . . . . . . . 9

AD – Auto Disconnect Enable / Disable (840T & TH20 only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

ADCLIP – Audio Clipping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

ADPRESENT – Audio Presence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

AEC – Acoustic Echo Canceller Enable / Disable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

AGC – Automatic Gain Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

AGCSET – Automatic Gain Control Adjust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

AMBLVL – Ambient Level Adjust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

AMXDUET – Use AMX Duet Discovery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

AUDIOMASTER – Expansion Bus Audio Master Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

BAUD – Baud Rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

CALLDUR – Call Duration (840T & TH20 only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

CALLERID – Reports Caller ID Information (840T & TH20 only). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

CGROUP – Compressor Group Select . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

CHAIRO – Chairman Override Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

CLEAREFFECT – Clear Effect Wide Band Telco Emulation (840T & TH20 only) . . . . . . . . . . . . . . . . .13

CLOCK – Clock Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

COMPRESS – Compressor Adjust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

COMPSEL – Compression Select. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

COUNTRY – Country Selection (840T & TH20 Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

CTRLMASTER – Control Master Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

DECAY – Decay Adjust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

DEFAULT – Default The Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

DELAY – Delay Adjust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

DELAYSEL – Delay Select. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

DEVICENAME – Argument Identification Label. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

DEVICESUBTYPE – Sets the Subtype of a Connected Device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

DEVICETYPE – Sets the Type of a Connected Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

DFLTM – Default Meter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

DIAL – DTMF Dialing (840T & TH20 only). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

DID – Device ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

DSPVER – DSP Version. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

DTMFLVL – DTMF Tone Level (840T & TH20 only). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

DTONELVL – Dial Tone Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

DUPDATE – Download Update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

DVER – Command Dictionary Version. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

4 Technical Services: 800-283-5936

ENETADDR – Ethernet Port IP Address. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

ENETDHCP – Ethernet DHCP Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

ENETDNS – Ethernet DNS Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

ENETDNSA – Ethernet DNS Server Address. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

ENETDNSA2 – Ethernet DNS Server Address 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

ENETDOMAIN – Ethernet Domain Argument . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

ENETGATE – Ethernet Default Gateway Address. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

ENETSUBN – Ethernet Subnet Mask. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

EREF – Expansion Bus Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

FILTER – Filter Adjust. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

FILTSEL – Filter Select. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

FLOW – Flow Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

FMP – First Mic Priority Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

FPGAVER – FPGA Version . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

GAIN – Gain Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

GATE – Gate Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

GHOLD – Gate Hold Time Adjust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

GMODE – Gating Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

GOVER – Gating Override. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

GPIOSTATUS – General Purpose Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

GRATIO – Gate Ratio Adjust. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

GREPORT – Gate Report . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

GRPSEL – Gating Group Select . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

HOOK – Hook Flash (840T & TH20 only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

HOOKD – Hook Flash Duration (840T & TH20 only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

LABEL – Label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

LCDCONTRAST – LCD Contrast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

LMO – Last Mic On Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

LOCALNUM – Local Number. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

LOCBLDG – Location: Building. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

LOCCITY – Location: City . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

LOCCNTRY – Location: Country. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

LOCCOMP – Location: Company. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

LOCREGION – Location: Region . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

LOCROOM – Location: Room . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

LOCSITENAME – Location: Site Argument . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

LOCSTATE – Location: State . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

LOGMASK – Device Log Mask . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

LVL – Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

LVLREPORT – Level Report . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

LVLREPORTEN – Level Report Enable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

MACRO – Macro Execution/Reporting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Converge™ Pro Serial Command Guide 5

MANUFACTURER – Manufacturer Identification Label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

MAX – Maximum Gain Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

MIN – Minimum Gain Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

MINMAX – Minimum and Maximum Gain Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

MLINE – Mic / Line Coarse Gain Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

MMAX – Maximum Number of Microphones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

MODEL – Model Identification Label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

MTRX – Matrix Routing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

MTRX2 – Matrix 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

MTRXCLEAR – Clear Matrix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

MTRXLVL – Matrix Attenuation Adjust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

MUTE – Mute . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

NAME – Unit & NETBIOS Name . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

NCD – Noise Cancellation Depth Adjust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

NCSEL – Noise Cancellation Select . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

NLP – Non Linear Processing Adjust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

NOM – Number of Open Microphones Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

NTPSRV – NTP Network Time Server Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

NULL – Null the Line (840T & TH20 only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

OFFA – Off Attenuation Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

PAA – PA Adaptive Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

PBDIAL – Dial a PB Entry by Argument (840T & TH20 only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

PHONEBOOKADD – Adds an Entry to the Phonebook (840T & TH20 only). . . . . . . . . . . . . . . . . . . . .32

PHONEBOOKCNT – Counts Entries in the Phonebook (840T & TH20 only) . . . . . . . . . . . . . . . . . . . .33

PHONEBOOKDEL – Deletes an Entry in the Phonebook (840T & TH20 only) . . . . . . . . . . . . . . . . . . .33

PHONEBOOKREAD – Queries the Phonebook by Index (840T & TH20 only) . . . . . . . . . . . . . . . . . . .33

PP – Phantom Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

PRESET – Preset Execution/Reporting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

PRGSTRING – Program String . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

PTTTHRESHOLD – Push to Talk Threshold. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

PUSHTOTALK – Push to Talk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

RAMP – Ramp Gain Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

REDIAL – Redial the Last Number (840T & TH20 only). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

REFSEL – Reference Select for PA Adaptation & AEC (880, 840T, 8i Only) . . . . . . . . . . . . . . . . . . . . . .35

REFSET – Reference Channel Set Up (880, 840T, 8i Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

RESET – Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

RING – Ring Indication (840T & TH20 only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

RINGEREN – Audible Ring Enable (840T & TH20 only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

RINGERLVL – Audible Ring Level (840T & TH20 only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

RINGERSEL – Audible Ring Melody Selection (840T & TH20 only) . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

RINGERTEST – Audible Ring Melody Test (840T & TH20 only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

RXBOOST – Receive Boost (840T & TH20 only). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

6 Technical Services: 800-283-5936

RXBSTEN – Receive Boost Enable (840T & TH20 only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

SERECHO – Serial Echo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

SFTYMUTE – Safety Mute. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

SIGGEN – Signal Generator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

SIGGENEN – Signal Generator Enable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

SIGGENSWEEP – Signal Generator Sweep . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

SIGTOUT – Signal Generator Time Out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

SLVL – Speech Level Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

SMTPSRV – SMTP Mail Server Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

SNMPMNGRIP – SNMP Manager Host IP Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

SNMPMNGRPORT – SNMP Manager Notification Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

SNMPREADCOMM – SNMP Read Community String . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

SNMPWRITECOMM – SNMP Write Community String . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

SPEEDDIAL – Speed Dial a Number (840T & TH20 only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

STRING – String Execution. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40

SYSCHECKS – System Checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40

SYSRESULT – System Check Result . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

TAMODE – Telco Adapt Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41

TE – Telco Enable (840T & TH20 only). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

TELCOLVLCTRL – Telco RX Level Control Enable / Disable (840T & TH20 only) . . . . . . . . . . . . . . . . 42

TIMELOCALE – Time Locale Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

TOUT – Time Out Select . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

UCLOCK – Clock Set by UDT Coordinates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

UID – Unit ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

VER - Version . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

WAITSTATE – Wait State. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Converge™ Pro Serial Command Guide 7

SERIAL COMMANDS

Converge Pro serial commands are shown in bold, followed by the command form and argument details.

AA – Auto Answer Enable / Disable (840T & TH20 only)

This command selects/reports the setting of auto answer.

Command Form: DEVICE AA <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 17 (R) Value Unsigned Integer 2 0 = Off

1 = On 2 = Toggle (Null to query in text)

AAMB – Adaptive Ambient Mode

This command selects/reports the setting of adaptive ambient.

Command Form: DEVICE AAMB <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 3 (M) Value Unsigned Integer 2 0 = Off

1 = On 2 = toggle (Null to query in text)

AARINGS – Number of Rings to Auto Answer On (840T & TH20 only)

This command selects/reports the setting of the number of rings to auto answer.

Command Form: DEVICE AARINGS <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 17 (R) Value Unsigned Integer 2 2 - 4

(Null to query in text)

ACONN – Audible Connect / Disconnect Indication (840T & TH20 only)

This command selects/reports the status of the audible connect / disconnect indication.

Command Form: DEVICE ACONN <Channel> [Value].

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 17 (R) Value Unsigned Integer 2 0 = Off

1 = On 2 = Toggle (Null to query in text)

8 Technical Services: 800-283-5936

ACONNLVL – Audible Connect / Disconnect Level (840T & TH20 only)

This command selects/reports the audible connect / disconnect indicator’s level.

Command Form: DEVICE ACONNLVL <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 17 (R) Value Signed Float 2 -12.00 – 12.00

(Null to query in text)

AD – Auto Disconnect Enable / Disable (840T & TH20 only)

This command selects/reports the setting of auto disconnect.

Command Form: DEVICE AD <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 17 (R) Value Unsigned Integer 2 0 = Off

1 = Loop Drop 2 = Call Progress 3 = Loop Drop + Call Progress (Null to query in text)

ADCLIP – Audio Clipping

This command reports the channels that are currently clipping their audio signals. This command is read only. This command is implemented only for inputs.

Command Form: DEVICE ADCLIP [Values]

Argument Type Size Values

Value Bit Map of

Inputs

Bit Map of Outputs

Bit Map of Processors

Bit Map of Faders

Bit Map of Telco 1 XXXX XXXX

2 XXXX XXXX XXXX XXXX

|……………………|Æ Input 1 (lsb) to 12 (msb) |…….|Æ Reserved (Null to query in text)

2 XXXX XXXX XXXX XXXX

|………………………|Æ Output 1 (lsb) to 13 (msb) |….|Æ Reserved

2 XXXX XXXX XXXX XXXX

|……………|Æ Processor A (lsb) to H (msb) |--------------|Æ Reserved

1 XXXX XXXX

|------|Æ Faders 1 (lsb) to 4 (msb) |-------|Æ Reserved

|Æ Telco RX |Æ Telco TX |-----------|Æ Reserved

Converge™ Pro Serial Command Guide 9

ADPRESENT – Audio Presence

This command displays the channels that currently have valid audio signals present. This command is read only.

Command Form: DEVICE ADPRESENT [Values]

Argument Type Size Values

Value Bit Map of

Inputs

Bit Map of Outputs

Bit Map of Processors

Bit Map of Faders

Bit Map of Telco 1 XXXX XXXX

2 XXXX XXXX XXXX XXXX

|…………………|Æ Input 1 (lsb) to 12 (msb) |…….|Æ Reserved (Null to query in text)

2 XXXX XXXX XXXX XXXX

|……………………|Æ Output 1 (lsb) to 13 (msb) |….|Æ Reserved

2 XXXX XXXX XXXX XXXX

|……………|Æ Processor A (lsb) to H (msb) |--------------|Æ Reserved

1 XXXX XXXX

|------|Æ Faders 1 (lsb) to 4 (msb) |-------|Æ Reserved

|Æ Telco RX |Æ Telco TX |-----------|Æ Reserved

AEC – Acoustic Echo Canceller Enable / Disable

This command selects/reports the setting of Acoustic Echo Canceller.

Command Form: DEVICE AEC <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 3 (M) Value Unsigned Integer 2 0 = Off

1 = On 2 = Toggle (Null to query in text)

AGC – Automatic Gain Control

This command selects/reports the setting of automatic gain control.

Command Form: DEVICE AGC <Channel> <Group> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 1, 3, 7 (I, M, L) Value Unsigned Integer 2 0 = Off

1 = On 2 = Toggle (Null to query in text)

10 Technical Services: 800-283-5936

AGCSET – Automatic Gain Control Adjust

This command selects/reports the settings of the Automatic Gain Control.

Command Form: DEVICE AGCSET <Channel> <Group> [Threshold Target Attack Gain]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 1, 3, 7 (I, M, L) Threshold Signed Integer 1 -50 – 0

(Null to query in text) Target Signed Integer 1 -30 – 20 dB Response

Time Gain Unsigned Float 2 0.00 – 18.00 dB

Unsigned Float 2 0.10 – 10.00 S

AMBLVL – Ambient Level Adjust

This command selects/reports the ambient level.

Command Form: DEVICE AMBLVL <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 3 (M) Value Signed Float 2 -80.00 – 0.00

(Null to query in text)

AMXDUET – Use AMX Duet Discovery

This command sets and reports the status of AMX Duet Discovery.

Command Form: DEVICE AMXDUET [Value]

Argument Type Size Values Units

Value Unsigned Integer 4 0 = Off

1 = On 2 = toggle (Null to query in text)

AUDIOMASTER – Expansion Bus Audio Master Mode

This command reports the mode of the unit for control of the expansion bus audio.

Command Form: DEVICE AUDIOMASTER [Value]

Argument Type Size Values Units

Value Unsigned Integer 4 1 = Master

2 = Slave (Null to query in text)

BAUD – Baud Rate

This command selects/reports the baud rate of the serial port.

Command Form: DEVICE BAUD [Value]

Argument Type Size Values Units

Value Unsigned Integer 4 9600, 19200, 38400, 57600, 115200

(Null to query in text)

Converge™ Pro Serial Command Guide 11

CALLDUR – Call Duration (840T & TH20 only)

This command indicates how long a call has lasted. If no call is in session, this will report 0. At the time of call termination, this command will automatically be sent out reporting the duration. This command is read only.

Command Form: DEVICE CALLDUR <Channel> <Duration>

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 17 (R) Reserved 2 0 Duration String 8 String of format HR:MN:SS

CALLERID – Reports Caller ID Information (840T & TH20 only)

This command reports Caller Identification Information. This command is reportable only. It cannot be queried or set.

Command Form: DEVICE CALLERID <Channel> <Number> <Argument>

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 17 (R) Reserved Unsigned Integer 2 0 Number String 16 1 – 16 chars Label String 16 1 – 16 chars

CGROUP – Compressor Group Select

This command selects/reports the setting of the compressor group.

Command Form: DEVICE CGROUP <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 5 (P) Value Unsigned Integer 2 0 = none

1 – 4 (Null to query in text)

Compressor Group

CHAIRO – Chairman Override Mode

This command selects/reports the setting of chairman override.

Command Form: DEVICE CHAIRO <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 3 (M) Value Unsigned Integer 2 0 = Off

1 = On 2 = Toggle (Null to query in text)

12 Technical Services: 800-283-5936

CLEAREFFECT – Clear Effect Wide Band Telco Emulation (840T & TH20 only)

This command enables / disables or reports the current status of the clear effect.

Command Form: DEVICE CLEAREFFECT <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 17 (R) Value Unsigned Integer 2 0 = Off

1 = On 2 = Toggle (Null to query in text)

CLOCK – Clock Set

This command sets or reports the current time.

Command Form: DEVICE CLOCK [Date Month Year Hours Minutes Seconds Day]

Argument Type Size Values Units

Date Unsigned Integer 1 1 – 31 Month Unsigned Integer 1 1 – 12 Year Unsigned Integer 2 2000 – 2099

(NULL to Query in Text) Hours Unsigned Integer 1 00 – 23 Minutes Unsigned Integer 1 00 – 59 Seconds Unsigned Integer 1 00 – 59 Day of

Week

Unsigned Integer 1 1 = Sunday

2 = Monday

3 = Tuesday

4 = Wednesday

5 = Thursday

6 = Friday

7 = Saturday

COMPRESS – Compressor Adjust

This command selects/reports the settings of the compressor.

Command Form: DEVICE COMPRESS <Channel> [Threshold Ratio Attack Release Gain]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 5 (P) Threshold Signed Integer 1 -60 – 20

(Null to query in text) Ratio Unsigned Integer 1 1 – 20 Attack Unsigned Float 2 0.00 – 100.00 Ms Release Unsigned Integer 2 100 – 2000 Ms Gain Unsigned Float 4 0.00 – 20.00 dB

Converge™ Pro Serial Command Guide 13

COMPSEL – Compression Select

This command selects/reports the compressor activation.

Command Form: DEVICE COMPSEL <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 5 (P) Value Unsigned Integer 2 0 = Off

1 = On 2 = Toggle (Null to query in text)

COUNTRY – Country Selection (840T & TH20 Only)

This command sets / reports the country for compliance.

Command Form: DEVICE COUNTRY [Value]

Argument Type Size Values Units

Value Unsigned Integer 4 1 = US / Canada

2 = Europe 3 = Mexico 4 = Australia 5 = South Africa 6 = Japan 7 = Brazil 8 = South Korea 9 = China 10 = Singapore 11 = Taiwan 12 = New Zealand 13 = India 14 = Hong Kong 15 = Malaysia 16 = Argentina

(Null to query in text)

CTRLMASTER – Control Master Mode

This command reports the mode of the unit for SNMP control.

Command Form: DEVICE CTRLMASTER [Value]

Argument Type Size Values Units

Value Unsigned Integer 4 1 = Master

2 = Slave (Null to query in text)

DECAY – Decay Adjust

This command selects/reports the setting of the decay rate.

Command Form: DEVICE DECAY <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 3 (M) Value Unsigned Integer 2 1 = Slow

2 = Medium 3 = Fast (Null to query in text)

14 Technical Services: 800-283-5936

DEFAULT – Default The Unit

Sets the unit to factory defaults. There is no query for this command.

Command Form: DEVICE DEFAULT

No Arguments

DELAY – Delay Adjust

This command selects/reports the setting of delay time.

Command Form: DEVICE DELAY <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 5 (P) Value Unsigned Float 2 0.00 – 250.00

(Null to query in text)

DELAYSEL – Delay Select

This command selects/reports the delay activation of an assignable processing channel.

Command Form: DEVICE DELAYSEL <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 5 (P) Value Unsigned Integer 2 0 = Off

1 = On 2 = Toggle (Null to query in text)

DEVICENAME – Argument Identification Label

This selects/reports the Device Argument identification label of the specific channel.

COMMAND FORM: DEVICE DEVICENAME <Channel> <Group> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 1, 2, 3, 7

(I, O, M, L)

Reserved Unsigned Integer 2 0

Label String 12 1 – 12 characters

CLEAR = clear the label (Null to query in text)

DEVICESUBTYPE – Sets the Subtype of a Connected Device

This command enables/disables or reports the current type of device connected to an input or output.

Command Form: DEVICE DEVICESUBTYPE <Channel> <Group> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 1, 2, 3, 7 (I, O, M, L) Value Unsigned Integer 2 (NULL to query in text)

Converge™ Pro Serial Command Guide 15

DEVICETYPE – Sets the Type of a Connected Device

This command enables / disables or reports the current type of device connected to an input or output.

Command Form: DEVICE DEVICETYPE <Channel> <Group> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 1, 2, 3, 7 (I, O, M, L) Value Unsigned Integer 2 (NULL to query in text)

DFLTM – Default Meter

This command selects/reports the setting of the default meter on the front panel.

Command Form: DEVICE DFLTM [Channel Group Position]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels

(Null to query in text) Group Group 1 1, 2, 3, 7, 16, 17 (I, O, M, L, T, R) Position Meter Type 2 1 – 4, as applicable for group

See Meter Type Definitions

DIAL – DTMF Dialing (840T & TH20 only)

This command dials a DTMF sequence or reports back the last sequence dialed.

Command Form: DEVICE DIAL <Channel> [Number]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 17 (R) Reserved 2 0 Number String 40 1 – 40 Chars of ‘0’ – ‘9’, ‘A’ – ‘D’, ‘*’, ‘#’, ‘,’

(Null to query last number dialed in text)

DID – Device ID

This command reports the device id. This command is read only except through the front panel.

Command Form: DEVICE DID [Value]

Argument Type Size Values Units

Value Unsigned Integer 4 See Type And Device IDs

(Null sent in text, Value returned)

DSPVER – DSP Version

This command reports the version of the DSP code in the unit. This command is read only.

Command Form: DEVICE DSPVER <Value> [Time/Date]

Argument Type Size Values Units

Value Unsigned Integer 4 0 for Host

1 – 8 for Satellite 9 for Telco

Time / Date String 16 (Null to query in text)

16 Technical Services: 800-283-5936

DTMFLVL – DTMF Tone Level (840T & TH20 only)

This command selects/reports the DTMF tone’s level.

Command Form: DEVICE DTMFLVL <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 17 (R) Value Signed Float 2 -12.00 – 12.00

(Null to query in text)

DTONELVL – Dial Tone Level

This command selects/reports the audible dial tone’s level.

Command Form: DEVICE DTONELVL <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 17 (R) Value Signed Float 2 -12.00 – 12.00

(Null to query in text)

DUPDATE – Download Update

This command reports the status of download updates.

Command Form: DEVICE DUPDATE [Channel Group Status Percent Done Message]

Argument Type Size Values Units

Channel Unsigned Integer 1 Group Unsigned Integer 1 Status Unsigned Integer 1 (Null to query in text) Percent Done Unsigned Integer 1 Message Char 60

DVER – Command Dictionary Version

This command reports the version of the command dictionary being used by the unit. This command is read only.

Command Form: DEVICE DVER [Value]

Argument Type Size Values Units

Value Unsigned Integer 4 (Sent with a Null in text)

ENETADDR – Ethernet Port IP Address

This command selects/reports the IP address of the Ethernet port on the unit.

Command Form: DEVICE ENETADDR [Value]

Argument Type Size Values Units

Value IP Address 4 (Null to query in text)

Converge™ Pro Serial Command Guide 17

ENETDHCP – Ethernet DHCP Selection

This command selects/reports the use of DHCP of the Ethernet port on the unit.

Command Form: DEVICE ENETDHCP [Value]

Argument Type Size Values Units

Value Unsigned Integer 4 0 = On

1 = Off 2 = Toggle (Null to query in text)

ENETDNS – Ethernet DNS Selection

This command selects/reports the use of DNS of the Ethernet port on the unit.

Command Form: DEVICE ENETDNS [Value]

Argument Type Size Values Units

Value Unsigned Integer 4 0 = On

1 = Off 2 = Toggle (Null to query in text)

ENETDNSA – Ethernet DNS Server Address

This command selects/reports the DNS server IP address of the Ethernet port on the unit.

Command Form: DEVICE ENETDNSA [Value]

Argument Type Size Values Units

Value IP Address 4 (Null to query in text)

ENETDNSA2 – Ethernet DNS Server Address 2

This command selects/reports the alternate DNS server IP address of the Ethernet port on the unit.

Command Form: DEVICE ENETDNSA2 [Value]

Argument Type Size Values Units

Value IP Address 4 (Null to query in text)

ENETDOMAIN – Ethernet Domain Argument

This command selects/reports the Domain Argument of the Ethernet port on the unit.

Command Form: DEVICE ENETDOMAIN [Value]

Argument Type Size Values Units

Value String 64 (Null to query in text)

ENETGATE – Ethernet Default Gateway Address

This command selects/reports the default gateway of the Ethernet port on the unit.

Command Form: DEVICE ENETGATE [Value]

Argument Type Size Values Units

Value IP Address 4 (Null to query in text)

18 Technical Services: 800-283-5936

ENETSUBN – Ethernet Subnet Mask

This command selects/reports the Subnet mask of the Ethernet port on the unit.

Command Form: DEVICE ENETSUBN [Value]

Argument Type Size Values Units

Value IP Address 4 (Null to query in text)

EREF – Expansion Bus Reference

This command selects an output or reports which output is the expansion bus reference.

Command Form: DEVICE EREF <Channel> [Value Channel Value Group]

Argument Type Size Values Units

Channel Channel 1 See Reference Channels in Groups and Channels Group Group 1 8 (A) Value Channel 1 0 = none

See 2, 20 (O, B) in Groups and Channels

(Null to query in text)

Value Group 1 0 for none or 2, 20 (N for none or O, B)

FILTER – Filter Adjust

This command selects/reports the settings of a filter.

Command Form: DEVICE FILTER <Channel> <Group> <Node> [Type Frequency Gain/Slope Bandwidth/

Subtype]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 3, 5 (M, P) Node Unsigned

Integer

Type Unsigned

Integer

Frequency Unsigned

Float

Gain/Slope Signed Float 2 Type 0 – 3, 7, 11 0 (Null in text) dB /

Bandwidth/Subtype Unsigned

Float

1 Group 3 1 – 4

Group 5 1 – 15

1 0 = None

1 = All Pass 2 = Low Pass 3 = High Pass 4 = Low Shelving 5 = High Shelving 6 = Parametric Equalizer 7 = CD Horn 8 = Bessel Crossover 9 = Butterworth Crossover 10 = Linkwitz-Riley Crossover 11 = Notch (Null to query in text)

4 Type 0 0 (Null in text) Hz

Type 1 – 6, 8 – 11 20.00 – 20000.00 Type 7 500.00 – 5000.00

Type 4 – 6 -15.00 – 15.00 Type 8 – 9 12, 18, 24 Type 10 12, 24

2 Type 0 – 5, 7 0 (Null in text) Octaves /

Type 6, 11 0.05 – 5.00 Type 8 – 10 2 = Low Pass

3 = High Pass

dB per Octave

Type

Converge™ Pro Serial Command Guide 19

FILTSEL – Filter Select

This command turns on and off the filters.

Command Form: DEVICE FILTSEL <Channel> <Group> <Node> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 3, 5 (M, P) Node Unsigned Integer 1 Group 3 1 – 4

0xFF for all (* text)

Group 5 1 – 15

0xFF for all (* text)

Value Unsigned Integer 1 0 = Off

1 = On 2 = Toggle (Null to query in text)

FLOW – Flow Control

This command selects/reports the flow control of the serial port on the unit. Hardware flow control is implemented using DTR and DSR.

Command Form: DEVICE FLOW [Value]

Argument Type Size Values Units

Value Unsigned Integer 4 0 = Off

1 = On 2 = Toggle (Null to query in text)

FMP – First Mic Priority Mode

This command selects/reports first Mic priority mode.

Command Form: DEVICE FMP <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 4 (G) Value Unsigned Integer 2 0 = Off

1 = On 2 = Toggle (Null to query in text)

FPGAVER – FPGA Version

This command reports the version of the FPGA code in the unit. This command is read only.

Command Form: DEVICE FPGAVER [Value]

Argument Type Size Values Units

Value String 12 (Sent with a Null in text)

20 Technical Services: 800-283-5936

GAIN – Gain Adjustment

This command changes or reports back the gain for a channel.

Command Form: DEVICE GAIN <Channel> <Group> [Value] [Absol/Rel]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 1, 2, 3, 5, 7, 12, 16, 17 (I, O, M, P, L, F, T, R) Value Signed

Float

Absol / Rel 0 A = Absolute

NOTE: Values indicate entry range only. Actual internal range of the gain stage is from –65 to 20.

Absolute values will be limited to the internal gain range.

2 -99.90 – 99.90 **

(Null to query in text)

R = Relative Null = Relative

GATE – Gate Status

This command reports the gate status of Mics. This command is read only.

Command Form: DEVICE GATE [Value]

Argument Type Size Values Units

Value Hexadecimal 4 Bits 0 – 7 represent gate status on Mics 1 – 8

(Null sent in text, Value returned)

GHOLD – Gate Hold Time Adjust

This command selects/reports the setting of hold time.

Command Form: DEVICE GHOLD <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 3 (M) Value Unsigned Float 2 0.10 – 8.00

(Null to query in text)

GMODE – Gating Mode

This command selects/reports the setting of gating mode.

Command Form: DEVICE GMODE <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 3 (M) Value Unsigned Integer 2 1 = Auto

2 = Manual On 3 = Manual Off (Null to query in text)

Converge™ Pro Serial Command Guide 21

GOVER – Gating Override

This command selects/reports the setting of gating override.

Command Form: DEVICE GOVER <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 3 (M) Value Unsigned Integer 2 0 = Off

1 = On 2 = Toggle (Null to query in text)

GPIOSTATUS – General Purpose Status

This command sets the state of a General Purpose Status Pin.

Command Form: DEVICE GPIOSTATUS Pin Port [Value]

Argument Type Size Values Units

Pin Unsigned

Integer

1 1 – 24 (Only user definable status pins.

Port Unsigned

Integer

Value Unsigned

Integer

1 1 – 2

2 0 = High

1 = Low 2 = Toggle (NULL to query in text)

GRATIO – Gate Ratio Adjust

This command selects/reports the setting of the gate ratio.

Command Form: DEVICE GRATIO <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 3 (M) Value Unsigned Integer 2 0 – 50

(Null to query in text)

GREPORT – Gate Report

This command selects/reports the mode of gate and audio presence status reporting.

Command Form: DEVICE GREPORT [Value]

Argument Type Size Values Units

Value Unsigned Integer 4 0 = Off

1 = On 2 = Toggle (Null to query in text)

22 Technical Services: 800-283-5936

GRPSEL – Gating Group Select

This command selects/reports which Gating Group a microphone input is assigned.

Command Form: DEVICE GRPSEL <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 3 (M) Value Channel 2 See 4 (G) in Groups and Channels

(Null to query in text)

HOOK – Hook Flash (840T & TH20 only)

This command sends a hook flash. There is no query for this command.

Command Form: DEVICE HOOK <Channel>

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 17 (R) Reserved 2 0

HOOKD – Hook Flash Duration (840T & TH20 only)

This command selects/reports the hook flash duration.

Command Form: DEVICE HOOKD <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 17 (R) Value Unsigned Integer 2 50 – 2000

(Multiples of 10 Ms only) (Null to query in text)

LABEL – Label

This selects/reports the label of the specific channel or the unit.

Command Form: DEVICE LABEL <Channel> <Group> [In/Out] [Value]

Argument Type Size Values

Channel Channel 1 See Groups and Channels Group Group 1 1, 2, 3, 4, 5, 6, 7, 8, 12, 13, 14, 16, 17, 20

(I, O, M, G, P, E, L, A, F, S, C, T, R, B)

Input / Output to Matrix

Label String 20 1 – 20 characters

Unsigned Integer 2 Groups all but 6 0

Groups 6 0 = output

1 = input

CLEAR = clear the label (Null to query in text)

LCDCONTRAST – LCD Contrast

This command selects/reports the LCD Contrast Setting.

Command Form: DEVICE LCDCONTRAST [Value]

Argument Type Size Values Units

Value Unsigned Integer 4 0 (lightest) – 63 (darkest)

(Null to query in text)

Converge™ Pro Serial Command Guide 23

LMO – Last Mic On Mode

This command selects/reports last Mic on mode.

Command Form: DEVICE LMO <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 4 (G) Value Unsigned Integer 2 0 = Off

1 - 8 = Mic 1 – 8 to be the last mic 0xFF (* in text) = Last Mic to stay on (Null to query in text)

LOCALNUM – Local Number

This command sets or reports back the current value of the local number.

Command Form: DEVICE LOCALNUM <Channel> [Number]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 17 (R) Reserved 2 0 Number String 16 1 – 16 Chars of ‘0’ – ‘9’, ‘A’ – ‘D’, ‘*’, ‘#’, ‘,’

(Null to query in text)

LOCBLDG – Location: Building

This command sets/reports the location of the unit: Building string.

Command Form: DEVICE LOCBLDG [Value]

Argument Type Size Values Units

Value String 80 CLEAR = Clear current value

1 – 63 Characters (Null to query in text)

LOCCITY – Location: City

This command sets/reports the location of the unit: City string.

Command Form: DEVICE LOCCITY [Value]

Argument Type Size Values Units

Value String 80 CLEAR = Clear current value

1 – 63 Characters (Null to query in text)

LOCCNTRY – Location: Country

This command sets/reports the location of the unit: Country string.

Command Form: DEVICE LOCCNTRY [Value]

Argument Type Size Values Units

Value String 80 CLEAR = Clear current value

1 – 63 Characters (Null to query in text)

24 Technical Services: 800-283-5936

LOCCOMP – Location: Company

This command sets/reports the location of the unit: Company string.

Command Form: DEVICE LOCCOMP [Value]

Argument Type Size Values Units

Value String 80 CLEAR = Clear current value

1 – 63 Characters (Null to query in text)

LOCREGION – Location: Region

This command sets/reports the location of the unit: Region string.

Command Form: DEVICE LOCREGION [Value]

Argument Type Size Values Units

Value String 80 CLEAR = Clear current value

1 – 63 Characters (Null to query in text)

LOCROOM – Location: Room

This command sets/reports the location of the unit: Room string.

Command Form: DEVICE LOCROOM [Value]

Argument Type Size Values Units

Value String 80 CLEAR = Clear current value

1 – 63 Characters (Null to query in text)

LOCSITENAME – Location: Site Argument

This command sets/reports the location of the unit Site name.

Command Form: DEVICE LOCSITENAME [Value]

Argument Type Size Values Units

Value String 80 CLEAR = Clear current value

1 – 64 Characters (Null to query in text)

LOCSTATE – Location: State

This command sets/reports the location of the unit: State/Prefecture string.

Command Form: DEVICE LOCSTATE [Value]

Argument Type Size Values Units

Value String 80 CLEAR = Clear current value

1 – 63 Characters (Null to query in text)

Converge™ Pro Serial Command Guide 25

LOGMASK – Device Log Mask

This command sets or reports the device event log mask.

Command Form: DEVICE LOGMASK [Value]

Argument Type Size Values Units

Value Hexadecimal 4 X X X X X X X X X X X X X X X X

LVL – Level

This command reports the level of a channel. This command is read only.

Command Form: DEVICE LVL <Channel> <Group> <Position> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 1, 2, 3, 5, 7, 12, 16, 17, 20

(I, O, M, P, L, F, T, R, B) Position Meter Type 2 See Meter Type Definitions Value Signed Float 4 -99.99 – 99.99

(Sent with Null in text, Value returned)

LVLREPORT – Level Report

This command selects/reports the status of level reporting for the specified channel.

Command Form: DEVICE LVLREPORT <Channel> <Group> <Position> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 1, 2, 3, 5, 7, 12, 16, 17

(I, O, M, P, L, F, T, R) Position Meter Type 2 See Meter Type Definitions Value Unsigned Integer 4 0 = Off (Delete from list being reported)

1 = On (Add to list being reported)

2 = Toggle

(Null to query in text)

LVLREPORTEN – Level Report Enable

Enables level reporting for the unit.

Command Form: DEVICE LVLREPORTEN [Value]

Argument Type Size Values Units

Value Unsigned Integer 4 0 = Turn off reporting but leave current list

1 = Turn on reporting 2 = Turn off reporting and clear the list (Null to query in text)

26 Technical Services: 800-283-5936

MACRO – Macro Execution/Reporting

This command executes a specified macro or reports the last macro executed.

Command Form: DEVICE MACRO [Value]

Argument Type Size Values Units

Value Channel 4 See 14 (C) in Groups and Channels

(Null to query last macro ran in text)

NOTE: The response will indicate successful execution of the macro, but it does not guarantee

that each command in the macro was executed.

MANUFACTURER – Manufacturer Identification Label

This command selects/reports the model identification label of the specified channel.

Command Form: DEVICE MANUFACTURER <Channel> <Group> <Reserved>[Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 1, 2, 3, 7

(I, O, M, L)

Reserved Unsigned

Integer

Label String 16 1-16 characters

dB CLEAR = clear the label (Null to query in text)

MODEL – Model Identification Label

This command selects/reports the model identification label of the specified channel.

Command Form: DEVICE MODEL <Channel> <Group> <Reserved>[Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 1, 2, 3, 7

(I, O, M, L)

Reserved Unsigned

Integer

Label String 16 1-16 characters

dB CLEAR = clear the label (Null to query in text)

MAX – Maximum Gain Setting

This command changes or reports back the maximum gain setting for an input, output or assignable processing block.

Command Form: DEVICE MAX <Channel> <Group> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 1, 2, 3, 5, 7, 12, 16, 17 (I, O, M, P, L, F, T, R) Value Signed Float 2 -65.00 – 20.00

(Null to query in text)

Converge™ Pro Serial Command Guide 27

MIN – Minimum Gain Setting

This command changes or reports back the minimum gain setting for a channel.

Command Form: DEVICE MIN <Channel> <Group> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 1, 2, 3, 5, 7, 12, 16, 17 (I, O, M, P, L, F, T, R) Value Signed Float 2 -65.00 – 20.00

(Null to query in text)

MINMAX – Minimum and Maximum Gain Setting

This command changes or reports back the minimum and maximum gain setting for a channel.

Command Form: DEVICE MINMAX <Channel> <Group> [Min Max]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 1, 2, 3, 5, 7, 12, 16, 17 (I, O, M, P, L, F, T, R) Min Signed Float 2 -65.00 – 20.00

(Null to query in text)

Max Signed Float 4 -65.00 – 20.00 dB

MLINE – Mic / Line Coarse Gain Setting

This command selects/reports the setting of coarse gain.

Command Form: DEVICE MLINE <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 3 (M) Value Unsigned Integer 2 0 = 0 dB

7 = 7 dB 14 = 14 dB 21 = 21 dB 28 = 28 dB 35 = 35 dB 41 = 41 dB 50 = 50 dB 56 = 56 dB (Null to query in text) (No other values are valid and accepted)

MMAX – Maximum Number of Microphones

This command selects/reports the maximum number of microphones for a Gating Group.

Command Form: DEVICE MMAX <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 4 (G) Value Unsigned Integer 2 0 = Unlimited

1 - 8 = Maximum # of Mics (Null to query in text)

28 Technical Services: 800-283-5936

MTRX – Matrix Routing

This command selects/reports the matrix routing of an input to an output.

Command Form: DEVICE MTRX <Src. Ch.> <Src. Gp.> <Dest. Ch.> <Dest. Gp.> [Value]

Argument Type Size Values Units

Source Channel Channel 1 See Groups and Channels Source Group Group 1 1, 3, 5, 6, 7, 12, 17

(I, M, P, E, L, F, R) Destination Channel Channel 1 See Groups and Channels Destination Group Group 1 2, 5, 6, 12, 16, 20

(O, P, E, F, T, B) Value Unsigned Integer 4 0 = Cross point off

1 = Cross point on (Not Valid for Mic

Sources)

2 = Toggle (Not Valid for Mic Sources)

3 = Non Gated (Mic Sources Only)

4 = Gated (Mic Sources Only)

5 = Pre-AEC (Mic Sources Only)

6 = Routing Prohibited (Cross point is

off and may not be turned on)

(Null to query in text)

MTRX2 – Matrix 2

This command sets the cross points for an entire input.

Command Form:

DEVICE MTRX2 <Src. Ch.> <Src. Gp.> [<Cross Point 1 H><Cross Point 1 L><Cross Point 2

H><Cross Point 2 L><Cross Point 3 H><Cross Point 3 L>]

Argument Type Size Values Units

Source Channel Channel 1 See Groups and Channels Source Group Group 1 1, 3, 5, 6, 7, 12, 17, 20

(I, M, P, E, L, F, R, B) Reserved 2 0 Cross point 1 High

(Gated Mics & all other inputs) Cross point 1 Low

(Gated Mics & all other inputs) Cross point 2 High

(Non Gated Mics) Cross point 2 Low

(Non Gated Mics) Cross point 3 High

(Pre-AEC Mics) Cross point 3 Low

(Pre-AEC Mics)

NOTE: A microphone cannot be routed in more than one way to the same output.

Hexadecimal 4 Bit mask of columns 31 - max

Hexadecimal 4 Bit mask of columns 0 – 31

Hexadecimal 4 Bit mask of columns 31 - max

Hexadecimal 4 Bit mask of columns 0 – 31

Hexadecimal 4 Bit mask of columns 31 - max

Hexadecimal 4 Bit mask of columns 0 – 31

MTRXCLEAR – Clear Matrix

Clears the ENTIRE matrix for the unit. There is no query for this command.

Command Form: DEVICE MTRXCLEAR

No Arguments

Converge™ Pro Serial Command Guide 29

MTRXLVL – Matrix Attenuation Adjust

This command selects/reports the matrix level at the cross point.

Command Form:

DEVICE MTRXLVL <Src. Ch.> <Src. Gp.> <Dest. Ch.> <Dest. Gp.> [Value] [A/R]

Argument Type Size Values Units

Source Channel Channel 1 See Groups and Channels Source Group Group 1 1, 3, 5, 6, 7, 12, 17

(I, M, P, E, L, F, R) Destination Channel Channel 1 See Groups and Channels Destination Group Group 1 2, 5, 6, 12, 16,

(O, P, E, F, T,) Value Signed Float 4 -99.00 – 99.00 **

(Null to query in text) Absol / Rel 0 A = Absolute

R = Relative

Null = Relative

NOTE: Values indicate entry range only. Actual internal range of the matrix attenuation is from –60

to +12dB, and absolute values are limited to the internal gain range.

MUTE – Mute

This command selects/reports the setting of mute on a channel.

Command Form: DEVICE MUTE <Channel> <Group> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 1, 2, 3, 5, 7, 12, 16, 17 (I, O, M, P, L, F, T, R) Value Unsigned Integer 2 0 = Off

1 = On 2 = Toggle (Null to query in text)

NAME – Unit & NETBIOS Name

This command sets/reports the name of the unit which is also used for its NETBIOS name.

Command Form: DEVICE NAME [Value]

Argument Type Size Values Units

Value String 16 1 – 15 Characters

(Null to query in text)

NCD – Noise Cancellation Depth Adjust

This command selects/reports the setting of the Noise Cancellation.

Command Form: DEVICE NCD <Channel> <Group> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 3, 17 (M, R) Value Unsigned Integer 2 6 – 15

(Null to query in text)

30 Technical Services: 800-283-5936

NCSEL – Noise Cancellation Select

This command selects/reports the setting of the Noise Cancellation for each microphone channel.

Command Form: DEVICE NCSEL <Channel> <Group> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 3, 17 (M, R) Value Unsigned Integer 2 0 = Off

1 = On 2 = Toggle (Null to query in text)

NLP – Non Linear Processing Adjust

This command selects/reports the setting of the Non-linear processing for each microphone channel.

Command Form: DEVICE NLP <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 3 (M) Value Unsigned Integer 2 0 = Off

1 = Soft 2 = Medium 3 = Aggressive (Null to query in text)

NOM – Number of Open Microphones Mode

This command selects/reports the setting of Number of Open Microphones (NOM) on output channels.

Command Form: DEVICE NOM <Channel> <Group> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 2, 16 (O, T) Value Unsigned Integer 2 0 = Off

1 = On 2 = Toggle (Null to query in text)

NTPSRV – NTP Network Time Server Address

This command selects/reports the IP addresses of the NTP Time Server the unit’s NTP client requests time status from.

Command Form: DEVICE NTPSRV [Value 1 Value 2]

Argument Type Size Values Units

Value 1 IP Address 4 (Null to query in text) Value 2 IP Address 4

Converge™ Pro Serial Command Guide 31

NULL – Null the Line (840T & TH20 only)

This command nulls the line. There is no query for this command.

Command Form: DEVICE NULL <Channel>

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 17 (R) Reserved 2 0

OFFA – Off Attenuation Mode

This command selects/reports the off attenuation value of a Mic channel.

Command Form: DEVICE OFFA <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 3 (M) Value Unsigned

Float

2 0.00 – 60.00

(Null to query in text)

PAA – PA Adaptive Mode

This command selects/reports PA adaptive mode for the specified Mic.

Command Form: DEVICE PAA <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 3 (M) Value Unsigned Integer 2 0 = Off

1 = On 2 = Toggle (Null to query in text)

PBDIAL – Dial a PB Entry by Argument (840T & TH20 only)

This command dials a speed dial number by name. There is no query for this command.

Command Form: DEVICE PBDIAL <Channel> <Label>

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 17 (R) Reserved Unsigned Integer 2 0 Label String 16 1 – 16 chars

PHONEBOOKADD – Adds an Entry to the Phonebook (840T & TH20 only)

This command saves an entry in the phonebook. There is no query for this command. No two entries can share the same label. An argument error will be returned if an entry already has the name. To change an entry, you must first delete it and then add it again. If label is blank, the first 20 characters of the number will be used as the label. The Number argument must not be blank. If an entry already exists with the assigned speed dial it will be overwritten. The entries are alphabetized based on Label.

Command Form: DEVICE PHONEBOOKADD <ID Number Label>

Argument Type Size Values Units

Speed Dial Unsigned Integer 4 0 for not assigned to a speed dial

1 – 20 Number String 44 1 – 44 chars ‘0’ – ‘9’, ‘A’ – ‘D’, ‘*’, ‘#’ Label String 16 1 – 16 chars

32 Technical Services: 800-283-5936

PHONEBOOKCNT – Counts Entries in the Phonebook (840T & TH20 only)

This command queries the number of entries in the phonebook. This command is query only.

Command Form: DEVICE PHONEBOOKCNT <Value>

Argument Type Size Values Units

Value Unsigned Integer 4 0 – 20

PHONEBOOKDEL – Deletes an Entry in the Phonebook (840T & TH20 only)

This command deletes an entry in the phonebook. There is no query for this command.

Command Form: DEVICE PHONEBOOKDEL <Label>

Argument Type Size Values Units

Label String 16 1 – 16 chars

PHONEBOOKREAD – Queries the Phonebook by Index (840T & TH20 only)

This command queries an entry in the phonebook. This command is query only.

Command Form: DEVICE PHONEBOOKREAD <Index> [Speed Number Label]

Argument Type Size Values Units

Index Unsigned Integer 2 0 – 19 (Must be less than the Number of Phone

Book Entries)

Speed Dial Unsigned Integer 2 0 for not assigned to a speed dial

1 – 20

(NULL to query in text) Number String 44 1 – 44 chars ‘0’ – ‘9’, ‘A’ – ‘D’, ‘*’, ‘#’ Label String 16 1 – 16 chars

PP – Phantom Power

This command selects/reports the setting of phantom power.

Command Form: DEVICE PP <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 3 (M) Value Unsigned Integer 2 0 = Off

1 = On 2 = Toggle (Null to query in text)

PRESET – Preset Execution/Reporting

This command selects/reports the state of a preset.

Command Form: DEVICE PRESET <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 0 (Binary)/Null (Text) = Query Last Preset Ran

See Groups and Channels Group Group 1 13 (S) Value Unsigned Integer 2 0 = Set preset state to off

1 = Set state to on and execute if not already on

2 = Execute and return state to off

(Null to query current state in text)

Converge™ Pro Serial Command Guide 33

PRGSTRING – Program String

This command sets/reports a programmed string.

COMMAND FORM: DEVICE PRGSTRING <ID> [Value]

Argument Type Size Values Units

ID Unsigned Integer 4 0 – 7 Value String 80 CLEAR = Clear current value

1 – 80 Chars (Null to query in text) Special Characters: \a = alert \b = backspace \f = form feed \n = new line \r = carriage return \t = horizontal tab \v = vertical tab \\ = backslash

PTTTHRESHOLD – Push to Talk Threshold

This command selects/reports the setting of the push to talk threshold for a microphone.

Command Form: DEVICE PTTTHRESHOLD <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 3 (M) Value Float 2 -100 to 0

(Null to query in text)

PUSHTOTALK – Push to Talk

This command selects/reports the setting of push-to-talk for a microphone.

Command Form: DEVICE PUSHTOTALK <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 3 (M) Value Unsigned Integer 2 0 = Off

1 = On

2 = Toggle

(Null to query in text)

RAMP – Ramp Gain Adjustment

This command starts / stops the gain ramp for an input, output or assignable processing block. There is no query associated with this command.

Command Form: DEVICE RAMP <Channel> <Group> <Rate> [Target]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 1, 2, 3, 5, 7, 12, 16, 17 (I, O, M, P, L, F, T, R) Rate Signed Integer 1 -50 – 50

If value=0, the ramp will stop. If value< 0, the gain will ramp down. If value>0, the gain will ramp up.

Target Signed Integer 1 -65 – 20

If NULL in text or 0x80 in binary, the ramp will use the channel’s maximum and minimum for a target.

dB / s

34 Technical Services: 800-283-5936

REDIAL – Redial the Last Number (840T & TH20 only)

This command redials the last number. There is no query for this command.

Command Form: DEVICE REDIAL <Channel>

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 17 (R) Reserved 2 0

REFSEL – Reference Select for PA Adaptation & AEC (880, 840T, 8i Only)

This command selects/reports which output or expansion bus reference is used for a Mic input as a reference for power amp adaptation mode and acoustic echo cancellation where applicable.

Command Form: DEVICE REFSEL <Channel> [Ref. Group Ref. Channel]

Argument Type Size Values Units

Channel Channel 1 See 3 (M) in Groups and Channels Group Group 1 3 (M) Reference Group Group 1 2, 8, 20 (O, A, B) Reference Channel Channel 1 See Groups and Channels

(Null to query in text)

REFSET – Reference Channel Set Up (880, 840T, 8i Only)

This command selects/reports the output the reference channel tracks.

Command Form: DEVICE REFSET <Channel> [Reference Output]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 20 (B) Value Reference Output 2 0 = none

See 2 (O) in Groups and Channels (Null to query in text)

RESET – Reset

Resets the unit. There is no query for this command.

Command Form: DEVICE RESET

No Arguments

RING – Ring Indication (840T & TH20 only)

This command indicates a ringing line. This command is reportable only. It cannot be queried or set.

Command Form: DEVICE RING <Channel><Value>

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 17 (R) Value Unsigned

Integer

2 0 = Ring Cycle Ended

1 = Ring Cycle Started

Converge™ Pro Serial Command Guide 35

RINGEREN – Audible Ring Enable (840T & TH20 only)

This command sends/reports the use of an audible ring.

Command Form: DEVICE RINGEREN <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 17 (R) Value Unsigned Integer 2 0 = Off

1 = On

2 = Toggle

(Null to query in text)

RINGERLVL – Audible Ring Level (840T & TH20 only)

This command selects/reports the audible ring’s level.

Command Form: DEVICE RINGERLVL <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 17 (R) Value Signed Float 2 -12.00 – 12.00 (dB)

(Null to query in text)

RINGERSEL – Audible Ring Melody Selection (840T & TH20 only)

This command sends/reports the audible ring melody.

Command Form: DEVICE RINGERSEL <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 17 (R) Value Unsigned Integer 2 1 – 3

(Null to query in text)

RINGERTEST – Audible Ring Melody Test (840T & TH20 only)

This command plays the current audible ringer melody. This command is executable only. There is no query.

Command Form: DEVICE RINGERTEST <Channel>

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 17 (R) Reserved Unsigned Integer 2 0

RXBOOST – Receive Boost (840T & TH20 only)

This command selects/reports the receive boost status.

Command Form: DEVICE RXBOOST <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 17 (R) Value Unsigned Integer 2 0, 3, 6, 9, or 12

(Null to query in text)

36 Technical Services: 800-283-5936

RXBSTEN – Receive Boost Enable (840T & TH20 only)

This command selects/reports the receive boost status.

Command Form: DEVICE RXBSTEN <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 17 (R) Value Unsigned Integer 2 0 = Off

1 = On

2 = Toggle

(Null to query in text)

SERECHO – Serial Echo

This command selects/reports the serial echo of the RS-232 port.

Command Form: DEVICE SERECHO [Value]

Argument Type Size Values Units

Value Unsigned Integer 4 0 = Off

1 = On 2 = Toggle (Null to query in text)

NOTE: The unit will return the updated state of the last selection in the same form as the

command.

SFTYMUTE – Safety Mute

This command selects/reports the state of the safety mute. Safety mute holds all outputs in a muted state. It used for syncing to a site document to avoid feedback or blown speakers until the unit is in a settled state.

Command Form: DEVICE SFTYMUTE [Value]

Argument Type Size Values Units

Value Channel 4 0 = off

1 = on 2 = toggle (Null to query in text)

SIGGEN – Signal Generator

This command selects/reports of the signal generator activation.

Command Form: DEVICE SIGGEN [Channel Group Type Amplitude Frequency]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels

(Null to query in text) Group Group 1 1, 3, 7 (I, M, L) Type Unsigned Integer 2 1 = Pink Noise

2 = White Noise

3 = Tone Amplitude Signed Float 4 -60.00 – 20.00 dB

Frequency Unsigned Float 4 Type 1 – 2 0 (Null in text) Hz

Type 3 20.00 – 20000.00

Converge™ Pro Serial Command Guide 37

SIGGENEN – Signal Generator Enable

This command selects/reports of the signal generator activation.

Command Form: DEVICE SIGGENEN [Value]

Argument Type Size Values Units

Value Unsigned Integer 4 0 = Off

1 = On

2 = Toggle

(Null to query in text)

SIGGENSWEEP – Signal Generator Sweep

This command starts the signal generator with a tone and does a sweep. If Repeat is 0, the signal generator will turn off after the sweep. If Repeat is 1, the signal generator will turn off after signal generator timeout. To stop the sweep, send a SIGGENEN command with a 0. During the sweep, the box will send out updated SIGGEN commands.

Command Form:

DEVICE SIGGENSWEEP <Channel> <Group> <Amplitude> <Start Frequency> <End Frequency>

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 1, 3, 7 (I, M, L) Amplitude Signed Float 2 -60.00 – 20.00 dB Start

Frequency End

Frequency Increment

Frequency Rate Unsigned Integer 2 10 – 2000 ms Hz

Repeat Unsigned Integer 2 0 = repeat off

Unsigned Float 4 20.00 – 20000.00 Hz

Unsigned Float 4 20.00 – 20000.00 (must be greater than the

start)

Unsigned Float 4 1.00 – 20000.00 Hz

1 = repeat on

SIGTOUT – Signal Generator Time Out

Sets the signal generator time out for the unit.

Command Form: DEVICE SIGTOUT [Value]

Argument Type Size Values Units

Value Unsigned Integer 4 0 = Disable

SLVL – Speech Level Control

This command selects/reports the setting of Speech Level Control.

Command Form: DEVICE SLVL <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 3 (M) Value Unsigned Integer 2 0 = Off

38 Technical Services: 800-283-5936

Min 1 – 30 (Null to query in text)

1 = On 2 = Toggle (Null to query in text)

SMTPSRV – SMTP Mail Server Address

This command selects/reports the IP address of the SMTP Mail server, and the Email Address the unit’s SMTP client sends messages to.

Command Form: DEVICE SMTPSRV [Value Address]

Argument Type Size Values Units

Value IP Address 4 (Null to query in text)

(0.0.0.0 Clears IP and String)

Address String 40 1 – 40 characters

(Null to query in text)

SNMPMNGRIP – SNMP Manager Host IP Address

This command selects/reports the IP address of the SNMP Manager.

Command Form: DEVICE SNMPMNGRIP [Value]

Argument Type Size Values Units

Value IP Address 4 IP Address of SNMP Manager to send Traps to

(Null to query in text)

SNMPMNGRPORT – SNMP Manager Notification Port

This command selects/reports the SNMP Trap port for SNMP Manager.

Command Form: DEVICE SNMPMNGRPORT [Value]

Argument Type Size Values Units

Value Unsigned Integer 4 1-255

(Null to query in text)

SNMPREADCOMM – SNMP Read Community String

This command selects/reports the SNMP read community string.

Command Form: DEVICE SNMPREADCOMM [Value]

Argument Type Size Values Units

Value String 30 Read Community validation string (GET data)

(Null to query in text: defaults to “public”)

SNMPWRITECOMM – SNMP Write Community String

This command selects/reports the SNMP Write Community String.

Command Form: DEVICE SNMPWRITECOMM [Value]

Argument Type Size Values Units

Value String 30 Write Community validation string (SET data)

(Null to query in text: Default = “private”)

SPEEDDIAL – Speed Dial a Number (840T & TH20 only)

This command dials a speed dial number.

Command Form: DEVICE SPEEDDIAL <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 17 (R) Value Unsigned Integer 2 1 – 20

(Null to query in text)

Converge™ Pro Serial Command Guide 39

STRING – String Execution

This command sends the specified string out the serial port.

Command Form: DEVICE STRING [ID]

Argument Type Size Values Units

ID Unsigned Integer 4 0 – 7

(Null to query last string in text)

SYSCHECKS – System Checks

Initiates the system checks. There is no query for this command.

The System Check integer bits determine which tests are run. Each bit set generates a separate SYSRESULT response.

COMMAND FORM: DEVICE SYSCHECKS <System Check>

Argument Type Size Values

System Check

Hexadecimal Integer

4 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00

Network

Telephone

Mic 1

Mic 2

Mic 3

Mic 4

Mic 5

Mic 6

Mic 7

Mic 8

All other bits reserved

40 Technical Services: 800-283-5936

SYSRESULT – System Check Result

This command reports the results of the system check. This command is reportable only. It cannot be queried or set. The System Check integer bits determine which test result will be reported. Each test results in a separate

SYSRESULT message.

Argument Type Size Values

System Check

Hexadecimal Integer

4 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00

Network

Telephone

Mic 1

Mic 2

Mic 3

Mic 4

Mic 5

Mic 6

Mic 7

Mic 8

All other bits reserved

Status Unsigned

Integer

2 0 = Fail

1 = Pass 2 = NULL <Not Tested or Test Disabled in SYSCONFIG>

Message String 40 For the telephone on hook: the message will report the line

voltage, the line current, other results, and if dial tone is detected. For the telephone off hook: the message will report the line current, other results, and if dial tone is detected. The bit mask for the other results is x x x x x x x x | | | | | | | |--> set if switched from CTR21 to FCC because of low current | | | | | | |--> set if used DIAL bit while dialing | | | | | |--> set if switch from Low Voltage to Japan because of current | | | | |--> set if switch from Low Voltage to FCC because of current | | | |--> DAA OVL status | | |--> DAA DOD status | |--> DAA OPD status |--> Not used

For the network check: the box will report if no IP address is set. If it is set, the box will ping the gateway. The message will say the ping failed if it is not returned in 5 s. Otherwise, the message will report how many seconds it took to return the ping.

TAMODE – Telco Adapt Mode

This command selects/reports the Telco adapt mode.

Command Form: DEVICE TAMODE <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 17 (R) Value Unsigned Integer 2 0 = Auto

1 = Burst (Null to query in text)

Converge™ Pro Serial Command Guide 41

TE – Telco Enable (840T & TH20 only)

This command selects/reports the hook status.

Command Form: DEVICE TE <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 17 (R) Value Unsigned Integer 2 0 = Off

1 = On 2 = Toggle (Null to query in text)

TELCOLVLCTRL – Telco RX Level Control Enable / Disable (840T & TH20 only)

This command selects/reports the setting of Telco Rx level control.

Command Form: DEVICE TELCOLVLCTRL <Channel> [Value]

Argument Type Size Values Units

Channel Channel 1 See Groups and Channels Group Group 1 17 (T) Value Unsigned Integer 2 0 = Off

1 = On 2 = Toggle (Null to query in text)

TIMELOCALE – Time Locale Settings

This command sets or reports the time locale settings.

Command Form: DEVICE TIMELOCALE [DaylightSavings TimeZone TimeZoneName]

Argument Type Size Values Units

Daylight Savings Unsigned Integer 4 0 = Do not use Daylight Savings

1 = Use Daylight Savings (NULL to Query in Text)

Time Zone Unsigned Integer 4 The number of seconds from UDT. (-86400

– 86400)

Time Zone Argument

String 32 Description of time zone

TOUT – Time Out Select

This command selects/reports the inactivity time out before returning to the unit title screen on the front panel.

Command Form: DEVICE TOUT [Value]

Argument Type Size Values Units

Value Unsigned Integer 4 0 = No Time Out

1 – 15 (Null to query in text)

Min

UCLOCK – Clock Set by UDT Coordinates

This command sets or reports the current time.

Command Form: DEVICE UCLOCK [UDT time]

Argument Type Size Values Units

UDT time Unsigned Integer 4

42 Technical Services: 800-283-5936

UID – Unit ID

This command reports the unit id. This command is read only.

Command Form: DEVICE UID [Value]

Argument Type Size Values Units

Value Hexadecimal 4 (Sent with a Null, value returned in text)

VER - Version

This command reports the version of the unit. This command is read only.

Command Form: DEVICE VER [Value]

Argument Type Size Values Units

Value String 8 Version of format MM.mm.rr

(Sent with a Null in text, value returned)

WAITSTATE – Wait State

This command defines a delay within macros and presets in ½ second increments from ½ second to 5 seconds. This command can only be included in a macro. It will be ignored from other sources.

Command Form: DEVICE WAITSTATE <Value>

Argument Type Size

Value Unsigned Float 1 0.50 – 5.00 S

Values

Units

Converge™ Pro Serial Command Guide 43

Serial Command Support Table

The following table shows serial command support by Converge Pro device type.

Command Name

Converge Pro

880

Converge Pro

840T

Converge Pro

TH20

Converge Pro

AA X X AAMB X X X AARINGS X X ACONN X X ACONNLVL X X AD X X ADCLIP X X X X ADPRESENT X X X X AEC X X X AGC X X X X AGCSET X X X X AMBLVL X X X AMXDUET X X X X AUDIOMASTER X X X X BAUD X X X X CALLDUR X X CALLERID X X CGROUP X X X CHAIRO X X X CLEAREFFECT X X CLOCK X X X X COMPRESS X X X COMPSEL X X X COUNTRY X X X X CTRLMASTER X X X X DECAY X X X DEFAULT X X X X DELAY X X X DELAYSEL X X X DEVICENAME X X X X DEVICESUBTYPE X X X X DEVICETYPE X X X X DFLTM X X X X DIAL X X DID X X X X DSPVER X X X X DTMFLVL X X DTONELVL X X DUPDATE X X X X DVER X X X X

44 Technical Services: 800-283-5936

Command Name

Converge Pro

880

Converge Pro

840T

Converge Pro

TH20

Converge Pro

ENETADDR X X X X ENETDHCP X X X X ENETDNS X X X X ENETDNSA X X X X ENETDNSA2 X X X X ENETDOMAIN X X X X ENETGATE X X X X ENETSUBN X X X X EREF X X X FILTER X X X FILTSEL X X X FLOW X X X X FMP X X X FPGAVER X X X X GAIN X X X X GATE X X X GHOLD X X X GMODE X X X GOVER X X X GPIOSTATUS X X X X GRATIO X X X GREPORT X X X X GRPSEL X X X HOOK X X HOOKD X X LABEL X X X X LCDCONTRAST X X X X LMO X X X LOCALNUM X X LOCBLDG X X X X LOCCITY X X X X LOCCNTRY X X X X LOCCOMP X X X X LOCREGION X X X X LOCROOM X X X X LOCSITENAME X X X X LOCSTATE X X X X LOGMASK X X X X LVL XXXX LVLREPORT X X X X LVLREPORTEN X X X X MACRO X X X X MANUFACTURER X X X X

Converge™ Pro Serial Command Guide 45

Command Name

Converge Pro

880

Converge Pro

840T

Converge Pro

TH20

Converge Pro

MAX X X X X MIN X X X X MINMAX X X X X MLINE X X X MMAX X X X MTRX X X X X MTRX2 X X X X MTRXCLEAR X X X X MTRXLVL X X X X MUTE X X X X NAME X X X X NCD X X X X NCSEL X X X X NLP X X X NOM X X X NTPSRV X X X X NULL X X OFFA X X X PAA X X X PBDIAL X X PHONEBOOKADD X X PHONEBOOKCNT X X PHONEBOOKDEL X X PHONEBOOKREAD X X PP X X X PRESET X X X X PRGSTRING X X X X PTTTHRESHOLD X X X PUSHTOTALK X X X RAMP X X X X REDIAL X X REFSEL X X X REFSET X X RESET X X X X RING X X RINGEREN X X RINGERLVL X X RINGERSEL X X RINGERTST X X RXBOOST X X RXBSTEN X X SERECHO X X X X SFTYMUTE X X X X

46 Technical Services: 800-283-5936

Command Name

Converge Pro

880

Converge Pro

840T

Converge Pro

TH20

Converge Pro

SIGGEN X X X X SIGGENEN X X X X SIGGENSWEEP X X X X SIGTOUT X X X X SLVL X X X SMTPSRV X X X X SNMPMNGRIP X X X X SNMPMNGRPORT X X X X SNMPREADCOMM X X X X SNMPWRITECOMM X X X X SPEEDDIAL X X STRING X X X X SYSCHECKS X X X X SYSRESULT X X X X TAMODE X X TE X X TELCOLVLCTRL X X TIMELOCALE X X X X TOUT X X X X UCLOCK X X X X UID X X X X VER X X X X WAITSTATE X X X X

Converge™ Pro Serial Command Guide 47

ClearOne CONVERGE PRO 880, CONVERGE PRO 840T, CONVERGE PRO TH20, CONVERGE 8i Serial Command Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
