User Manual
CATALOG
1.Product overview ..............................................................................................3
1.1 Introduction: .............................................................................................3
1.2 Features ： ............................................................................................. 3
1.3 Accessories： .......................................................................................... 3
2. Function Introduction ..................................................................................... 4
2.1 Main Interface ......................................................................................... 4
2.1.1 How to connect to internet .............................................................. 4
2.1.2 mini USB Function ......................................................................... 4
2.1.3 2*USB Function .............................................................................. 5
2.1.4 TF card interface function ............................................................... 5
3. How to connect WI-FI ............................................................................... 5
4. Language Setting ....................................................................................... 6
5. Time Setting .............................................................................................. 6
6.Explorer Application .................................................................................. 7
7.Copy,Paste, Install Application .................................................................. 7
7.1Copy,Paste： ....................................................................................... 7
7.2 Install application ............................................................................... 8
CATALOG .......................................................................................................... 2
1.Product overview
1.1 Introduction:
Android system(Including wifi and Rj45 connection function), Quad core CPU 1GB(RAM)
1.2 Features ：
1.3 Accessories：
S/N
Material name
Specification/Model
Quantity
1
B11-01
360MM Pole and Bracket
1
2
Rotatable Bracket
Rotatable Bracket
1
3
Baseboard
B11-01 Baseboard
1
4
Adapter
Desktop type 12V/3A
1
5
Power cable
American standardPower
cable length: 1.8m
1
6
Wifi antenna
Wifi antenna 20DB
1
7
Plate cover
I/0 port plate cover
1
8
Screws
M6*12 Countersink screws
3
9
Screws
M4*6 Black Cap screws
4
8GB Flash memory. LED energy saving, support application software or network remote
management, high sensitivity touch screen, high resolution, full viewing angle, bring
fantastic visual enjoyment.
High performance, stability, integration, extensibility.
10
Screws
M3*4Countersink screws
2
11
Spanner
M4 Allen wrench
1
2. Function Introduction
2.1 Main Interface
2.1.1 How to connect to internet
Insert network cable in LAN port, select more..., and click
2.1.2 mini USB Function
Ethernet.
mini USB Interface is used for the firmware update, connect the
computer file transfer.
2.1.3 2*USB Function
Connect Mouse,keyboard, U disk and other external device.
2.1.4 TF card interface function
3. How to connect WI-FI
Extend the machine memory
Install WI-FI antenna.
Enter Setting,Turn Wi-Fi ON ，The right option for the search to
the wi-fi signal source,select the right one,and input the right
wifi password and then connection is successful.
4. Language Setting
Enter Setting,select Language&input option ， check right side
5. Time Setting
options，select Language can change the display language, as below
pictures.
Enter Setting,select Date&time option ， check the right side
options,select Automatic date&time can auto correct the system
time/zone.
6.Explorer Application
1）Enter explorer application
7.Copy,Paste, Install Application
2）SD Card for check the TF card contends 3）
NAND FLASH for check the system storage 4）
USB for check the external U disk contends
8.1Copy,Paste：
1）Enter Explorer application
2）Select the file which need to copy, and click on the left editor
option，then appear copy/paste option, or left click the mouse
few sec.also will show the editor option.
8.2 Install application
1）Enter Explorer application
2）Find the application which need to be installed，and double
click the file for install.
