User manual
Dear clearaudio-customer,
you have purchased a state-of-the-art turntable, the
clearaudio electronic GmbH.
The special resonance-optimised construction, the external motor-unit and the patented
clearaudio - CMB-bearing-technology guarantees absolute speed stability, pure pleasure in
listening and reproduction in accordance to the original.
Thank you very much your confidence.
Please read this guide carefully so that you can enjoy all advantages of your
Ambient
damages.
We hope you will enjoy your new clearaudio
clearaudio electronic GmbH
Please read the warnings before connecting your
-turntable. All information given will help to generate best set up and avoid any possible
Ambient
Ambient
Ambient
, a world class product of
-turntable.
-turntable to the mains supply.
Don’t expose your performance-turntable to rain or humidity.
Don’t handle the mains leads with wet hands.
Don’t place or insert anything into the equipment or through ventilation holes.
No naked flame sources, such as lighted candles, should be placed on the equipment.
CE-MARKING
The clearaudio
(EMC) and low-voltage appliances.
COPYRIGHT
Recording und reproduction of any sound-material may require the consent of the creator.
Please acknowledge the information given in the
- Copyright Act 1956,
- Dramatic and Musical Performers Act 1958,
- Performers Protection Acts 1963 and 1072,
- any more recent legal regulations.
Ambient
meets the regulations concerning electromagnetic disturbance
WARNINGS
Seite 2 clearaudio electronic GmbH 2008
A
t
mbien
User manual
Contents
1. Packaging overview 4
2. Packing contents 5
3. Set-up and operation 7
4. Tonearm mounting 12
5. Special information 20
6. Service 20
7. Technical data 21
Warranty information 22
Seite 3 clearaudio electronic GmbH 2008
A
t
A
1. Packaging Overview
1. floor:
Turntablechassis
2. floor:
Motorunit
Power supply unit
Platter incl. Upper part of bearing
3. floor
Optional, if the Ambient
is ordered in a package:
A: Unify tonearm
B: Satisfy tonearm
(according your order)
cartridge, accessories
mbien
User manual
B
Seite 4 clearaudio electronic GmbH 2008
A
t
2. Package contents
The clearaudio
transport. Please check the contents as per list below:
Ambient
turntable is delivered in a special packaging to ensure its safe
1 2 3
mbien
User manual
1
3
5
4
Motorunit with included
„mini Syncro“ unit
Tonearmbase (preassambled)
Pulley made of acrylic including
fixing screws
2
4
6
5
6
Chassisplate 70-layers wood
sandwich, silver anodised aluminum
top & bottom plate
High-precision turntable platter made
of solid silicon acrylic with patented
CMB bearing
Power supply unit(incl. 3 different plug
units; EU, USA and GB)
Seite 5 clearaudio electronic GmbH 2008
A
t
7/A
mbien
User manual
7/B
8
10
11 9
12
7
9
11
13
13
14
Optional tonearm: (A-Unify/B-Satisfy)
incl. accessory
Clearaudio Clever Clamp
Screwdriver (for fixing the pulley)
Silent Belt Ø 1mm (2 x,
therefrom 1 x spare)
8
10
12
14
15
Groundingcable for the bearingscrew
Shynthetic bearing oil (2.5 ml)
levelgauge
Pair of white gloves
15
Seite 6 clearaudio electronic GmbH 2008
hexkeywrench
16
Warranty card (not shown)
A
t
mbien
User manual
3. Set-up and operation
After you have checked the package contents as described in section 2, lay the parts out on a
clean, safe flat surface for the clearaudio
straight forward as many parts have been preassembled at the factory. Please use the white
gloves provided to prevent scratches and/or fingerprints during assembly. The smallest placing
area for your clearaudio
Pic. 1: Placing area Ambient turntable
11 cm
Ambient
is 530 x 330 mm.
Ambient
53,5 cm
assembly. Assembly is fairly simple and
40 cm
33 cm
Seite 7 clearaudio electronic GmbH 2008
A
t
Place the premounted chassisplate on a good turntable rack area optimised for low sensitivity of
acoustical feedback.
Unpack the turntable platter with the upper part of the platter bearing. Remove the protective
security tape from the bearing housing and place this unit carefully over the spindle mounted in
the turntable chassis. Do not use too much pressure for this step otherwise you will
cause damage to the bearing. Caution: pay attention not to place any of the grease
on the acrylic surface of the chassis!
Due to the high precision machining there could be left some air inside the bearing. The air will
flow out after several turns of the platter. Please make sure that the two markings on the
turntable platter and on the bearing are in one line (as shown in figure below). The correct
position of these markings is very important, because they had been calibrated at the factory.
Pic. 3: Placing the turntable platter
Pic. 2: Placing the Ambient turntable
mbien
User manual
Pic. 4: Correct position of turntable platter and bearing
Seite 8 clearaudio electronic GmbH 2008
A
t
Place the pulley on the motor spindle. The distance between the pulley and the motor housing
should be approx. 3 mm. Tighten the three little screws inside the pulley with the aluminium
screwdriver provided.
Place now the motorunit beside your Ambient turntable. The distance between the motorunit and
the turntable should be 2 - 2,5 cm!
3 mm
Pic. 5: Placing the pulley on the motor spindle
2 – 2.5 cm
mbien
User manual
Pic. 6: Distance between motor unit and Ambient turntable
Seite 9 clearaudio electronic GmbH 2008
A
t
Place the belt on the pulley of the motor unit. Please turn with your hand the platter some turns,
that the belt is parallel.
The following adjustment is very important:
Should the air bubble in the level gauge not be in the black circle (see at the blow up), please
ensure then that your underground so will be according aligned. Only if the turntable will be
aligned you will receive the optimum on sound.
Pic. 7: Placing the belt on the pulley
mbien
User manual
Pic. 8: To align the turntable
Seite 10 clearaudio electronic GmbH 2008
A
t
g
)
Connect now the power supply unit with the motorunit. After starting the motor unit, can you
exact calibrate the turning speed with the included screwdriver
(shown in the pictures below)!
Start
33 1/3
45
Calibration for 33 1/3 rpm.
Exactly 33 1/3 rpm shows the
display 33.3! (left LED is
glowing at 33 1/3)
mbien
User manual
Calibration for 45 rpm.
Exactly 45 rpm shows the
display 45.0! (right LED is
lowing at 45
Pic. 9: Calibrating the turning speed
Seite 11 clearaudio electronic GmbH 2008
A
t
mbien
User manual
4 Tonearm mounting
4.1 Unify mounting
To mount the tonearm base to the Ambient armboard, please use the screws without
nuts (M4x20) and place it like the red marked screws.
Carefully remove the security zip tie and unwrap the arm tube. Caution:
security zip tie is removed not to inadvertently pull it out of the armwand.
Place the arm tube on to the pivot point and lock it into it´s arm rest. Use the cable
strain relief screw (M4x10) and washer (red marked screw in the picture below) to
secure the cable to the tonearm base.
Pic. 11: Mounting the tonearm
Insure that the distance from the spindle to the pivot point of the tonearm is exactly 222
mm. Moving the armboard in one direction or another will allow you to locate the correct
position. Once located, tighten the armboard down. Shown in the picture below. You can
also use the optional clearaudio cartridge alignment gauge.
Seite 12 clearaudio electronic GmbH 2008
Pic. 10: Mounting the tonearm base
Once the
A
t
For the exact adjustemts should be the cartridge mounted! Please follow
therefor the instructions of the cartridge user manual!
mbien
User manual
Pic. 12: Mounting the tonearm
Seite 13 clearaudio electronic GmbH 2008
A
t
mbien
User manual
Attach the clearaudio Turbo Weight on the end of the tonearm (1). Set tracking force
using the clearaudio Exact stylus preassure gauge (see cartridge instructions for
recommended tracking force renge). Adjusting tracking force is accomplished by moving
the weight towards or away from the pivot point on the shaft (to 1). Note:
When
tightening the counter-weight, insure that the weight is perfectly vertical otherwise this
may affect your cartridges azimuth settings.
1
3
to 1
to 2
Pic. 13: Mounting the tonearm
2
to 3
Feed the anti-skate weight through the anti-skate support wand and secure it to the
threaded shaft at the top of the tonearm bell (to 3). Note:
Attaching the string to the
position closes to the pivot point is equal to approx 0.5 gramms of anti-skate. Each
additional 1/8” out on the shaft will give you another 0.5 gramms of anti-skate force with
a maximum of 3.0 gramms if affixed to the end of the shaft.
antiskating / red arrow = more antiskating).
(green arrow = lesser
Seite 14 clearaudio electronic GmbH 2008
A
t
VTA adjustments are accomplished by loosening the two lock screws an the side of the
armboard base (shown in picture 1 and 2). Once loose, you can moove the arm up or
down to achieve the desired VTA. Tighten both screws when finished. Re-check tracking
force after adjusting VTA.
1 2
Pic. 14: VTA-adjustment
Azimuth adjustments are facilitated through the small (1,5 mm) Allen screw (red marked
screw) on the bottom side of the armwand where the headshell enters the carbon fiber.
Once you loosen this screw, you´ll be able to rotate the headshell a small amount in
either direction. Be sure to tighten the screw when done.
mbien
User manual
Pic. 15: Azimuth adjustment
Seite 15 clearaudio electronic GmbH 2008
A
t
mbien
User manual
4.2 Satisfy mounting
To mount the tonearm base to the Ambient armboard please use the screws without
nuts (M4x20) and place it like the red marked screws.
Please put careful the cables and the tonearm through the armboard, pay attention that
no wire will be damaged! Now fix the tonearm with the 2 screws ont the right and the
left side, not to much, so that you can adjust it in the next steps!
Pic. 17: Mounting the clearaudio Satisfy tonearm
Pic. 16: Mounting the tonearm base for Satisfy
Seite 16 clearaudio electronic GmbH 2008
A
t
mbien
User manual
Insure that the distance from the spindle to the pivot point of the tonearm is exactly 222
mm. Moving the armboard in one direction or another will allow you to locate the correct
position. Once located, tighten the armboard down. Shown in the picture below. You can
also use the optional clearaudio cartridge alignment gauge.
For the exact adjustemts should be the cartridge mounted!
Pic. 18: Mounting the clearaudio Satisfy tonearm
VTA adjustments are accomplished by loosening the two lock screws an the side of the
armboard base (shown in picture 1 and 2). Once loose, you can moove the arm up or
down to achieve the desired VTA. Tighten both screws when finished. Re-check tracking
force after adjusting VTA.
1 2
Pic. 19: VTA adjustment
Seite 17 clearaudio electronic GmbH 2008
A
t
Azimuth adjustments are facilitated through the small (1,5 mm) Allen screw (red marked
screw) on the bottom side of the armwand where the headshell enters the carbon fiber.
Once you loosen this screw, you´ll be able to rotate the headshell a small amount in
either direction. Be sure to tighten the screw when done.
Pic. 20: Azimuth adjustment
mbien
User manual
Wind the counterweight on the tonearm-tube. You can adjust the tracking force of your
cartridge by turning the counterweight (shown in the picture below) (green arrow =
more tracking force / red arrow = lesser tracking force).
Pic. 21: Adjustment of the tracking force
Seite 18 clearaudio electronic GmbH 2008
A
t
mbien
User manual
Now you are ready for the antiskating adjustment. This also depends on the tracking
force of the cartridge and the diamond shape.
alignment of the antiskating tracking force position of the antiskating-screw
minimal antiskating → 10 – 15mN → see illustration 1
medium antiskating → 15 – 20mN → see illustration 2
maximum antiskating → 20mN and more → see illustration 3
Illustration 1 Illustration 2 Illustration 3
(minimal Antiskating) (medium Antiskating) (maximum Antiskating)
Pic. 21: Alignment of the antiskating
The general set-up is now finished.
Connect your
Satisfy
-tonearm now with the phono input of your phono-preamplifier.
(More information on adequate phono-preamplifiers and interconnects you can find on
our Website www.clearaudio.com).
You can now place a record on the platter, affix it with the
enclosed clever-clamp and finish your cartridge adjustments.
Now you are finally ready to play your vinyl records.
We wish you a lot of pleasure with your new
Ambient
-turntable.
Seite 19 clearaudio electronic GmbH 2008
A
t
mbien
User manual
5. Special information
To achieve the full clearaudio warranty, it is necessary that you fill out and send the
corresponding part of the warranty registration card back to clearaudio, within two weeks after
purchase. Only if the product is returned in it’s original packing clearaudio can provide the
warranty.
Transportation advice: If any transportation of the
please always remove the turntable platter. Otherwise serious damage can occur!
The bearing hole needs to be covered as well, to avoid any dust coming into the bearing. Always
take of the pulley of the motor unit as well, to prevent the motor shaft from any damages.
If the
Ambient
supply.
Every two years you can lubricate (only if you will recognize speed variations) the bearing of the
turntable platter with the delivered oil. In this case it is enough to put 4 or 5 drops of the oil into
bearing.
Please take special caution to any damages of the power cord. Any damages should only be
repaired only by authorized personal. A damaged power cord must be exchanged immediately!
-turntable is a longer time not in use, please disconnect the motor from the mains
Ambient
-turntable should be necessary,
6. Service
If any service or repair on all clearaudio products is necessary, please contact your dealer /
distributor or contact clearaudio directly. We will inform you about your nearest service location.
PLEASE RETAIN ALL ORIGINAL PACKAGING. You will need it if this unit has to be transported
and/or shipped. Any further questions you may have about this turntable should be directed to
the distributor or directly to clearaudio at
clearaudio electronic GmbH
Spardorfer Str 150
91054 Erlangen
Germany
Tel/Phone: +49-(0)1805/059595
www.clearaudio.de
www.analogshop.de
info@clearaudio.de
Seite 20 clearaudio electronic GmbH 2008
A
t
mbien
User manual
7. Technical data
Construction principle: Resonance optimised chassis’s shape, belt driven, 70-layers
wood sandwich, silver anodised aluminum top & bottom
plate
Speed possibillities: 33 1/3 U/min or 45 U/min
(optional with pulley 78 U/min)
Drive unit: Decoupled synchronious motor, belt drive
Rumble: DIN IEC 98 procedure A / 83 dB
Bearing: CMB, clearaudio patended Magnetic ceramic bearing
Platter: Silicon acrylic, surface absolutely plain, 40 mm
Speed variation: +- 0,1 %
Weight: approx 12 kg, incl. motor
Dimensions: approx 535 mm x 330 mm x 150 mm
Warranty: 5 years* (see chapter 5)
Illustrations and technical information not binding
Subject to change without notice.
* Only if the warranty card is filled out correctly and sent back to clearaudio.
Stand: April 08
Seite 21 clearaudio electronic GmbH 2008
A
t
mbien
User manual
To achieve the full clearaudio warranty (
send the corresponding part of the warranty registration certificate /card back to clearaudio,
within two weeks after purchase. Only if the product is returned in it’s original packing
clearaudio can provide the warranty of 5 years.
ENGLISH
WARRANTY
For warranty information, contact your local clearaudio distributor.
RETAIN YOUR PURCHASE RECEIPT
Your purchase receipt is your permanent record of a valuable purchase.
It should be kept in a safe place to be referred to as necessary for insurance purposes or when corresponding with clearaudio.
IMPORTANT
When seeking warranty service, it is the responsibility of the consumer to establish proof and date of purchase. Your purchase receipt or invoice is
adequate for such proof.
FOR U.K. ONLY
This undertaking is in addition to a consumer's statutory rights and does not affect those rights in any way.
FRANÇAIS
GARANTIE
Pour des informations sur la garantie, contacter le distributeur local clearaudio.
CONSERVER L'ATTESTATION D'ACHAT
L'attestation d'achat est la preuve permanente d'un achat de valeur. La conserver en lieu sur pour s'y reporter aux fins d'obtention d'une couverture
d'assurance ou dans le cadre de correspondances avec clearaudio.
IMPORTANT
Pour l'obtention d'un service couvert par la garantie, il incombe au client d'établir la preuve de l'achat et d'en corroborer la date. Le reçu ou la facture
constituent des preuves suffisantes.
DEUTSCH
GARANTIE
Bei Garantiefragen wenden Sie sich bitte zunächst an Ihren clearaudio-Händler.
Heben Sie Ihren Kaufbeleg gut auf.
WICHTIG!
Die Angaben auf Ihrer Quittung erlauben uns die Identifizierung Ihres Gerätes und belegen mit dem Kaufdatum die Dauer Ihrer Garantie-Ansprüche.
Für Serviceleistungen benötigen wir stets die Gerätenummer.
Diese finden Sie auf dem Typenschild auf der Rückseite des Gerätes oder auch in der beigefügten Garantie-Registrierkarte.
NEDERLANDS
GARANTIE
Voor inlichtingen omtrent garantie dient u zich tot uw plaatselijke clearaudio.
UW KWITANTIE, KASSABON E.D. BEWAREN
Uw kwitantie, kassabon e.d. vormen uw bewijs van aankoop van een waardevol artikel en dienen op een veilige plaats bewaard te worden voor evt,
verwijzing bijv, in verbend met verzekering of bij correspondentie met clearaudio.
BELANGRIJK
Bij een evt, beroep op de garantie is het de verantwoordelijkheid van de consument een gedateerd bewijs van aankoop te tonen. Uw
kassabon of factuurzijn voldoende bewijs.
ITALIANO
GARANZIA
L’apparecchio è coperto da una garanzia di buon funzionamento della durata di un anno, o del periodo previsto dalla legge, a partire dalla data di
acquisto comprovata da un documento attestante il nominativo del Rivenditore e la data di vendita. La garanzia sarà prestata con la sostituzione o la
riparazione gratuita delle parti difettose.
Non sono coperti da garanzia difetti derivanti da uso improprio, errata installazione, manutenzione effettuata da personale non autorizzato o, comunque,
da circostanze che non possano riferirsi a difetti di funzionamento dell’apparecchio. Sono inoltre esclusi dalla garanzia gli interventi inerenti l’installazione
e l’allacciamento agli impianti di alimentazione.
Gli apparecchi verranno riparati presso i nostri Centri di Assistenza Autorizzati. Le spese ed i rischi di trasporto sono a carico del cliente. La casa
costruttrice declina ogni responsabilità per danni diretti o indiretti provocati dalla inosservanza delle prescrizioni di installazione, uso e manutenzione
dettagliate nel presente manuale o per guasti dovuti ad uso continuato a fini professionali.
ESPAÑOL
GARANTIA
Para obtener información acerca de la garantia póngase en contacto con su distribuidor clearaudio.
GUARDE SU RECIBO DE COMPRA
Su recibo de compra es su prueba permanente de haber adquirido un aparato de valor, Este recibo deberá guardarlo en un lugar seguro y utilizarlo
como referencia cuando tenga que hacer uso del seguro o se ponga en contacto con clearaudio.
IMPORTANTE
Cuando solicite el servicio otorgado por la garantia el usuario tiene la responsabilidad de demonstrar cuándo efectuó la compra. En este caso, su recibo
de compra será la prueba apropiada.
Ambient
5 years), it is necessary that you fill out and
Seite 22 clearaudio electronic GmbH 2008
Loading...
