Page 1

USER MANUAL

Page 2

Switch On-Off

Main Unit and transparent tank

Battery door

Disposable Reservoir Nozzle tip

Batteries

GENERAL DESCRIPTION

Page 3

IMPORTANT SAFEGUARDS

READ ALL INSTRUCTIONS BEFORE USE

CLEANOZ® has been carefully engineered for both efcacy and safety.

However, basic safety precautions should always be followed when

using any electrical device, especially intended for baby’s care.

WARNING

Use this product only for its intended use as described in this booklet. Do not use attachments not recommended by Ubimed®.

RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT

TYPE. REPLACE ONLY WITH ALKALINE BATTERIES AAA LR03.

For any question regarding Cleanoz®, please contact Ubimed Customer

Service Department online at [email protected] or our Call Center: 1-866-5-UBIMED.

MEDICAL WARNING

CAUTION: THE DISPOSABLE RESERVOIR NOZZLE PIECE CONTAINS

A LATEX BAG WHICH MAY CAUSE ALLERGENIC REACTIONS.

1) Wash your hands before and after using Cleanoz®.

2) Do not push nozzle deep into baby’s nostril. Use Cleanoz® in the recommended direction.

3) For the baby’s security, aspiration time is limited to few seconds.

4) Do not use Cleanoz® in case of nasal irritation or hemorrhage.

5) In the case of infection, fever, nasal irritation or hemorrhage, please

consult a doctor.

6) Do not use Cleanoz® without disposable nozzle piece or with a

deteriorated bag.

7) Use Cleanoz® only with Ubimed’s disposable nozzle piece.

8) Change the disposable nose piece after each use.

SAVE THESE INSTRUCTIONS

Page 4

INSTRUCTIONS FOR USE

Cleanoz® is an electric nose cleaner for babies

1) For the rst use: Open the battery compartment by removing the cover from the nose cleaner (use a screwdriver to unscrew). Insert three AAA

LR3 Alkaline batteries then shut the compartment: Use only Alkaline batte-

ries and respect the polarity.

2) Insert a new Disposable Reservoir Nozzle Piece: Align the front of the transparent tank with the front of the disposable nose piece (Be careful:

do not damage the bag). Match the line of the dolphin eye with the line on the tank.

3) Position the disposable nozzle just at the opening of the nostril. To improve the efciency of Cleanoz®, it is recommended to irrigate nasal passages with saline solution before aspirating secretions.

To optimize the nose-cleaning, it is recommended to close the other nostril

with your index nger while using Cleanoz® on the other nostril.

4) Switching on: Press the switch.

(The secretions are collected in the single use

secretion bag).

5) Switching off: The suction stops automati-

cally a few seconds later when the bag is full.

6) For cleaning the opposite nostril, use a new

nozzle piece .

When necessary , empty the reservoir (away from the baby) by pushing the nozzle tip

with the thumb.

Page 5

CLEANING AFTER USE

1) The nozzle piece is single use only; discard it after use. Do not try to open or re-use it.

Re-using nose piece is not hygienic (infectious risk) and will damage the

Cleanoz®.

2) Cleaning the main unit: Make sure that the battery compartment is shut

before cleaning the main unit. Do not clean the nose cleaner with solvents or abrasive products.

3) Do not immerse the nose cleaner. Do not aspirate any other product, but water, with Cleanoz®.

4) To help protect our environment, we encourage you to recycle at ap-

proved recycling locations. Do not dispose batteries in normal household waste.

7) Remove and discard the single use reservoir nozzle piece after use.It is recommended to empty the reservoir nozzle piece before discarding it.

STORAGE

1) Store Cleanoz® in a dry place at room temperature. Cleanoz® and the

Disposable reservoir Nozzle pieces must be stored in appropriate

conditions: temp between 41°F and 113°F ( 5 ° C and 45 ° C).

2) If not used for several months, it is recommended to remove the batteries.

PRECAUTIONS

1) Cleanoz® is not a toy. Cleanoz® must be used by adults after reading this manual.

2) Keep Cleanoz® and Nozzle pieces out of children’s reach.

3) Cleanoz® is designed for household use, only to aspirate baby’s nasal

secretions.

4) Cleanoz ® is designed for an intermittent use. (15seconds/ minute max). Using the appliance without a nozzle piece or keeping the switch on when the reservoir bag is full will use batteries prematurely.

5) Before using Cleanoz®, make sure that all parts are correctly assem-

bled.

6) Respect the expiration date of the disposable reservoir nozzle pieces.

7) Do not attempt to disassemble the nose cleaner unit or the nozzle

pieces.

8) Do not strike, bend or drop the unit.

Page 6

9) Use only UBIMED® single use reservoir nozzle pieces for Cleanoz®

MB01. They are designed to be used only with Cleanoz® MB01.

10) The Reservoir Nozzle piece is not sterile.

11) Do not use or store the unit or the disposable nozzle pieces under the following conditions:

*Hot locations such as the inside of a car parked outside in hot weather. *Under direct sunlight. * Humid or corrosive locations. *Keep away from hot surfaces, inammable substances or explosive gas

12) The nose cleaner should not be used in any conditions other than

those described above .

WARRANTIES AND SERVICES

A LIMITED WARRANTY FOR THE TIME STATED ON THE PACKAGE IS PROVIDED FROM THE DATE OF PURCHASE TO THE CONSUMER

WHO BOUGHT THIS PRODUCT.

WARRANTY RESTRICTIONS: WHAT IS NOT COVERED UNDER WARRANTY?:

DISPOSABLE NOSE PIECES, BATTERIES. DAMAGE CAUSED BY MISUSE, ABUSE, NEGLECT OR ALTERATONS.NORMAL WEAR AND

TEAR, INCLUDING CHIPS, SCRATCHES, ABRASION, DISCOLORATION

OR FADING.

IMPLIED WARRANTIES: ANY IMPLIED WARRANTIES INCLUDING IMPLIED WARRANTIES OF MERCHANDABILITTY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF THE EXPRESS

WARRANTIES SET FORTH IN THIS LIMITED WARRANTY. SOME

STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO

YOU.

LIMITATION OF REMEDIES:

IN NO EVENT SHALL UBIMED®,Inc. OR ANY OF ITS AFFILIATED OR

SUBSIDARY COMPANIES BE LIABLE FOR ANY SPECIAL, INCIDENT OR CONSEQUENTIAL DAMAGES BASED UPON MISUSE , BREACH OF WARRANTY, BREACH OF CONTRACT, NEGLIGENCE, TORT, OR ANY

OTHER LEGAL THEORY. SUCH DAMAGES INCLUDE, WITHOUT

LIMITATION, LOSS OF SAVINGS OR REVENUE; LOSS OF PROFIT; LOSS OF USE; THE CLAIMS OF THIRD PARTIES AND COST OF ANY

SUBSTITUTE EQUIPMENT OR SERVICES. SOME STATES DO NOT

ALLOW THE EXCLUSION OF LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU

Page 7

TROUBLEHOOTING GUIDE

If you are unable to solve your problem by means of the troubleshooting guide below, contact Online Customer Service at customer-service@ ubimed.com or CALL CENTER: 1-866-5-UBIMED (9 AM to 5 PM PST, Monday to

Friday).

PROBLEM

The Cleanoz® does not work

If the problem persists

The disposable nose piece doesn’t

t correctly:

If a damaged bag lets secretions penetrate inside the vacuum pump of Cleanoz®

SOLUTION

Check the polarity of the batteries.

Remove and change the batteries;

buy new ones.

Align the front of the tank with the

front of the nose piece. Match the

Line of the dolphin eye with the line

on the tank.

Remove the damaged disposable nose piece and aspirate clear water for 5 seconds with the Cleanoz®, then aspirate air for 5 seconds to

dry the pump. Dry the transparent tank with a soft cloth.

Your Cleanoz® is now ready to be used with a new disposable Nozzle

Piece.

To avoid this incident, be careful not to damage the reservoir bag when

putting a new nozzle piece.

www.cleanoz.com

Your advice is very important to us; for all questions and comments,

contact Ubimed® at www.Ubimed.com or call 1-866-5-UBIMED

Page 8

Protected by US and International Patents Pending; Design Patent Pending.

Ubimed® and CLEANOZ ® are registered trademarks of UBIMED®

UBIMED Inc, Beverly Hills , California 90212 -1601 US

www.ubimed.com call center: 1-866-5-UBIMED

PUCHASE DATE: ………………….. SERIAL NUMBER :………………….

RETAILER STAMP
