CleanForce CF1400 Instruction Manual
CF1400
DO NOT RETURN PRODUCT TO PLACE OF PURCHASE.
IF YOU HAVE ANY QUESTIONS, CALL OUR TOLL FREE HOTLINE:
1-866-902-9690
8:00 am to 5:00 pm, C.S.T., Monday - Friday
www.ForceToolsUSA.com
1 2
TABLE OF CONTENTS
Technical specifications .......................................................................................................
Warranty ..............................................................................................................................
Important safety instructions ......... ...................................................................................... 1
Safety features .................................................... ................................................................. 4
Parts and diagram list ...........................................................................................................5
Assembly and operating instructions.................................................................................... 6
9
9
Using the accessories ...................................................................................................
Working with detergents ..............................................................................................
Shutting down and cleaning up ....................................................................................11
Taking a break ..............................................................................................................11
Winterizing and long-term storage ......................................................................................12
Cleaning and maintenance .................................................................................................13
Troubleshooting ...................................................................................................................14
17
18
IMPORTANT SAFETY INSTRUCTIONS
Please read all of the safety precautions before operating this machine every time.
Please pay particular attention to all sections with following symbols.
When using this product, basic precautions should always be followed, including:
could cause injury or death if not followed
1 Read all instructions before using the product.
2 To reduce the risk of injury, do not operate the machine near children.
3 Learn how to stop this product and release pressure quickly. Be thoroughly familiar
with the controls.
4 Stay alert - watch what you are doing.
5 Do not operate this product when fatigued or under the influence of alcohol or drugs.
6 Keep operating area clear of all people and pets.
7 Do not stand on unstable surfaces. Do not overreach or stand on unstable support.
Keep good footing and balance at all times.
8 Follow the maintenance instructions specified in the manual.
9 This product is provided with a Ground Fault Circuit Interrupter (GFCI) built into the
power cord. If replacement of the plug or cord is needed, use only identical
replacement parts.
10 This product or its power cord contains lead, a chemical known to cause cancer, birth
defects or other reproductive harm. Wash hands after handling.
WARNING
WARNING
could damage machine if not followed
CAUTION
IMPORTANT SAFETY INSTRUCTIONS
• Equipment can cause serious injury if the spray penetrates the skin.
• Do not point the gun at anyone or any part of the body. In case of penetration, seek
medical aid immediately.
Risk of injury
Injection Hazard
WARNING
• High-pressure jet can be dangerous if misused.
• The jet must not be directed at persons, animals, electrical devices, or the unit itself.
Risk of injury
Do Not direct discharge stream at self or other persons.
WARNING
• Do not spray flammable liquids.
• Do not use acids and solvents in this product.
• These products can cause physical injuries to the operator and irreversible damage to
the machine.
1. Never operate the machine without all components properly connected to the machine
(handle, gun/wand assembly, nozzle, etc.).
2. Never operate pressure washer with broken or missing parts. Check equipment
regularly and repair or replace worn or damaged parts immediately.
3. Never put hand or fingers over the nozzle or spray tip while operating the unit.
4. Never spray flammable liquids or use pressure washer in areas containing combustible
dust, liquids or vapors. An electric spark could cause an explosion.
5. Never leave the wand unattended while the machine is running or switched on.
6. Never disconnect the high pressure discharge hose from the machine while the
system is pressurized. To depressurize machine, turn power and water supply off,
then depress gun trigger 2-3 times.
7. Never cover the pressure washer during operation to allow free air cooling.
Risk of Explosion
WARNING
• Inspect cord before using - do not use if cord is damaged.
• Keep all connections dry and off the ground.
• Do not touch plug with wet hands.
Risk of Electric Shock
• Hold with both hands.
• The trigger gun safety lock prevents the trigger from being engaged accidentally.
• The safety feature DOES NOT lock trigger in the ON position.
Gun Kicks Back
WARNING
CAUTION
GENERAL SAFETY RULES
3 4
IMPORTANT SAFETY INSTRUCTIONS
8. Always wear safety glasses or goggles when operating or performing maintenance.
9. Always move switch on unit to “OFF” position before connecting or disconnecting
cord to electrical outlets.
10.Always turn water supply “on” before turning pressure washer “on” unless draining
for storage. Running pump dry causes serious damage.
11.Always hold gun and wand firmly when starting and operating the machine.
12.Always follow detergent manufacturer’s label recommendations for proper use of
detergents. Always protect eyes, skin and respiratory system from detergent if used.
13.Always lock the trigger of spray gun in the safety position when not in use.
14.Do not use pressure that exceeds the operating pressure of any of the parts (hoses,
fittings, etc.) in the pressurized system. Never use with any other manufacturer’s
accessories or components.
15.Do not spray electrical apparatus and wiring or the machine itself.
16.Do not operate the pressure washer with the inlet water filter removed. Keep filter
clear of debris and sediment.
17.Discharge residual pressure by depressing the trigger until no more water comes out
of the nozzle.
18.Keep clear of nozzle. Never direct high pressure spray at any person, animal or self.
19.To minimize the amount of water getting into the pressure washer, the unit should be
placed as far as possible from the cleaning site during operation.
This pressure washer is provided with a Ground Fault Circuit Interrupter (GFCI) built into
the power supply cord. This device provides additional protection from the risk of
electrical shock. Should replacement of the plug or cord become necessary, use only
identical replacement parts that include GFCI protection. See Page 4 for testing
procedure.
Connect directly to outlet. Do not use machine with extension cord. The use of an
extension cord will override the GFCI built into the plug of the power supply cord
resulting in the risk of electrical shock.
WARNING
GROUND FAULT CIRCUIT INTERRUPTER PROTECTION
SAVE THESE INSTRUCTIONS
In a double-insulation product, two systems of insulation are provided instead
of grounding. No grounding is provided on a double-insulated product, nor
should a means for grounding be added to the product.
Servicing a double-insulated product requires extreme care and knowledge of
the system, and should be done only by qualified service personnel.
Replacement parts of a double-insulated product must be identical to the parts
they replace. A double-insulated product is marked with the words
“DOUBLE-INSULATION” or “DOUBLE-INSULATED”. The symbol “ ”
may also be marked on the product.
DOUBLE-INSULATION INSTRUCTION
SAFETY FEATURES
Total stop system (TSS)
The pressure washer is equipped with a total stop system (TSS) that will sense when the
trigger on the gun is depressed or released. It will open the power circuit to the motor,
and cause the pressure washer motor to stop. The motor will start again when the trigger
is depressed.
Ground Fault Circuit Interrupter Protection
Extension Cords
This device provides additional protection from the
risk of electrical shock. Plug the Ground Fault Circuit
Interrupter (GFCI) into a power outlet. Indicator
should turn red. TEST BEFORE EACH USE. Press
the “TEST” button. Red indicator should disappear.
Press “RESET” button again for use. Do not use if
above test fails.
Use a sufficient gauge:
Maximum cable length: 50’ (15.2 m). Only use 12 or 14 AWG rated extension cords.
• Use only extension cords that are intended for outdoor use. These extension cords are
identified by a marking that reads “Acceptable for use with outdoor appliances; store
indoors while not in use.”
• Use only extension cords having an electrical rating not less than the rating of the
product.
• Do not use damaged extension cords. Examine extension cord before using and
replace if damaged. Do not abuse extension cord and do not yank on any cord to
disconnect.
• Keep cord away from heat and sharp edges.
• Always disconnect the extension cord from the receptacle before disconnecting the
product from the extension cord.
• To reduce the risk of electric shock, keep all connections dry and off the ground. Do
not touch plug with wet hands.
If possible, do not use extension cords with this product. However, if you must use one,
observe all of the warnings and instructions listed below:
The pressure washer is also equipped with a main power “ON/OFF” switch located
on the unit. It should always be moved to the “OFF” position when the pressure
washer is not being used to prevent possible injury or damage.
WARNING
Extension cords are not recommended unless they are plugged into a ground fault
circuit-interrupter (GFCI) found in circuit boxes or protected receptacles.
WARNING
This machine has been designed for use with detergents that are specifically
approved for pressure washer use. The use of other cleaning detergents may
affect the operation of the machine and void the warranty.
CAUTION
