CLC PLUMZ403 Users Manual
User Manual
Axe PLUS
User Manual
Brand Name: plum
Model Name: Z403
FCC ID: Y7WPLUMZ403
1
User Manual
Contents
1．APPEARANCE AND KEYPAD OPERATIONS .......................... 3
2．USING MEMORY CARD AS U DISK ........................... 4/5/6
3．WIFI .................................................... 7
4．BLUETOOTH ................................................ 8
5．MAIL .................................................... 9
5.1 GMAIL ...................................................................................................................... 9
5.2 EMAIL .......................................................................................................................... 10
6．DIALLING ........................................ 11/12/13/14
7．MESSAGING .......................................... 15/16/17
8. CONTACTS .......................................... 18/19/20
9. INTENET EXPLOR .......................................... 21
10．RECORDER ............................................... 22
11．CLOCK ................................................. 23
12. CACULATOR .............................................. 24
13．CAMERA ............................................. 25/26
13.1 IMAGE MODE .................................................................................................................. 25
13.2 VIDEO MODE ................................................................................................................. 26
14．IMAGES ........................................... 27/28/29
15．MUSIC .............................................. 30/31
16. CALENDER............................................... 32
17. FM RADIO............................................... 33
18. SETTINGS....................................... 34/35/36/37
19. NOTICES FOR THE USE OF PHONE ............................ 38
2
Keys
Functions
Home
Long press it to open recently opened application window.
menu
Press it to start the menu，which allows you to perform actions in the current
interface or options’ menu.
back
Press it to return to the previous interface，or to close dialog box 、
options’ menu、notification panel or the keypad.
up
Press it to increase the volume
Press it to turn the phone to vibration mode from the silent mode.
down
Press it to decrease the volume.
Power key
Power on/off the phone via long press the power key
Cover it, and then the phone’s backlight will turn off
1 . Appearance and Keypad Operations
User Manual
2. Using Memory Card as U Disk
If you want to send music, pictures or other files to the phone’s memory card from the computer，you should set memory card as u
disk first.
Set memory card as u disk
1) Connect the phone to the computer with USB cable. The notification icon will appear in the status box.
2) Use USB mobile transmission line will connected to the computer
3) In the notification panel, touch USB is connected ，then touch“Open the USB Storage Device”
Uninstall the U Disk from computer
3
User Manual
The Methods as the same as connection, see the following picture:
1） cell phone connections media equipment (MTP)
2） In the Settings, developers in closed USB debugging options.
3） Use USB mobile transmission line will connected to the computer
4） In the notification panel, the choice of "media equipment (MTP)" connection mode, can be in the PC for SD card
Notice：If you in the cell phone connections to the computer playing media equipment, the mobile phone will
not be able to identify memory CARDS. You will not be able to use some of the mobile phone applications, like
4
User Manual
camera.
The phone connection camera (PTP)
1） Using the USB mobile transmission line will connected to the computer. You don't have to shut down USB
debugging, see below. Only under the camera view images
2）After the connection can be directly in the PC check images captured on camera。
Notice: different PC operating system to how to operate to normal use the U disk.
1） WIN7 Can directly use
5
User Manual
2） XP update windows media player to 11
3） Install wpdmtp.inf driver
4） Vista Unconfirmed
Notice :On the PC operation assistant tool such as mobile phone, Must be open the USB debugging.
3.WIFI
Wi-Fi provides as far as 300feet (100M) range of wireless network access. If you use cell phone to connect wifi, you should connect to
the wireless access point or 「hot spots」.
Notices：The availability and coverage of Wi-Fi signal depend on the number, infrastructure and other objects
penetrated by the signal.
Open Wi-fi and to connect to the wireless network
1) Press home>menu，then touch settings>wifi and internet
2) Select the wi-fi box，to open Wi-Fi. Phone will automatically scan for available wireless networks.
3) Touch Wi-Fi settings. Then a list of Wi-Fi network will show the founded network name and security settings. (open
network or WEP、WPA/WPA2 with password).If you enable the notification in Wi-Fi settings, The status box will show this
icon ( ) when open available wireless network founded.
4) Touch one of the Wi-Fi choices to connect the network. When you choose open network, phone will connect
to it automatically. If you choose WEP、WPA/WPA2 with password, you should type the password first, then
touch to connect it.
Notices：when the phone is connected to the wireless network,
The status box will show this Wi-Fi icon（ ）, and the approximate
signal strengthen (the number of lit bars).If touch the connected
network，will display the name of Wi—Fi network, status, speed, signal,
strength, security, information and IP address.
If you want to delete the wireless settings, please touch “not reserve”
as in the right picture. If you want to connect to this network, you
should re-enter these settings.
Notices：
Unless you choose not to reserve the network, otherwise, there is no need to re-enter the corresponding password when next time
connecting to the previously encrypted wireless network. Wi-Fi will search automatically, that is, phone needn’t to perform additional
steps to connect Wi-Fi networks.
Notices：
Unless you choose not to reserve the network with password, otherwise, there is no need to re-enter the corresponding password
when next time connecting to the previously encrypted wireless network. Wi-Fi will search automatically, that is, phone needn’t to
perform additional steps to connect Wi-Fi networks.
Connect to other Wi-Fi networks
1) In the interface of wireless and network, touch Wi-Fi settings. The founded Wi-Fi networks will show on the Wi-Fi
network list.
2) Touch other Wi-Fi networks, and then you can connect to this network.
Notices：in addition, you can surf the internet via GPRS. We default that the GPRS in SIM1 is opened after started,
6
User Manual
users can select manually ,the specific location is “settings>wireless and internet>data connection”， touch
“SIM1、SIM2、no data connection”， when the dot turns green, it’s already opened.。
7
User Manual
4. Bluetooth
Turn on Bluetooth or set the phone can be detected
1) Press home>menu, the touch settings.
2) Touch wireless and internet, then choose Bluetooth box to open the Bluetooth function. After started, the status box will
show this icon ( ). Touch “scan for devices”the it starts to scan for all devices within range.
3) Touch Bluetooth settings, all the devices founded will display in the list under the icon.
（select the box “can be detected”, set it to be detected, the other Bluetooth devices will be able to find the phone.）
important：the maximum detecting time of the phone is 2 minutes.
Pairing and connection of Bluetooth headset
1) Press home>menu, then touch settings.
2)Touch wireless and internet>Bluetooth settings, then select Bluetooth box, then your phone will scan for the
Bluetooth devices within range ,and show the founded devices in the list under the icon.
Tips：
a. If the list can’t find your equipment, touch scanning equipment to re-scan it.
b. Make sure that the devices wanted are under the detected mode.
3) Touch headset in the equipment list to finish the connection.
Notices：generally Bluetooth devices need password to be paired, often use「0000」as the default password.4)The
pairing and connecting status will show under the headset in the Bluetooth devices list. When the headset
connected to your phone, the status box will show this icon（ ）means connected. Then you can use the
headset to make or receive callings.
Cut the connection to the Bluetooth
1) Press home>menu>settings>wireless and internet>Bluetooth settings.
2) In the list of Bluetooth equipment, touch or tap and hold the connected hand-free headset.
3) Press and select “cancel the pairing”.
Bluetooth proximity sensor
After pairing the two device,you can test out the signal is strong or weak by the Bluetooth proximity sensor device
8
User Manual
5.Mail
5.1 Gmail
Create an electronic mail account
Select mail> settings. You can activate or edit existing e-mail accounts as well as create a new e-mail account.
a. Select mail, Google account setting interface appears. Then touch‘next step’> create account>enter name，last
name and e-mail account.
b. Google servers determine whether the name can be used, if so, new interface appears prompting enter
password, then judge the password’ security, users who doesn’t meet the requirements need to re-enter the
password.
c. Successfully register a new Gmail account, a messenger created automatically for testing.
Loading mail account
a. Open Gmail skip introduction screen>loading interface appears >select load
b. Enter name, password then load
E-mail account initialization ,prompting “login successful” All Google accounts will be synchronized.
Creating and sending ,mails
When creating mails, select mail > creating mails. Enter the address(recipient)、theme and contents. Press MENU you
could ‘append’、‘Add Cc/Bcc’, select send or discarded.
Receive mails
There is tone for new mails, in the status box will show this button ， Press Menu >‘refresh’， refresh and
update the number of the unread mails in a proper way.
Delete mails
When loading a mail account，if you want to delete it，you need to restore factory settings . When loading a second
one，you could press the menu button to delete it.
Notices：many functions depend on Gmail Account，for example：Electronic Market、Google Talk、Sync Contact and
Calendar.
9
User Manual
5.2 Email
Load Email.
c. Open network connection，
d. In setting the account interface, input the correct email address and password and click next mobile
phone automatically complete the sending and receiving server Settings. Pop-up mail find
frequency, and user Settings interface, complete Settings, click next.
e. For account creation name, the editor of the law that email user name, and click next. Complete set,
synchronous mailbox.
Create and send Email
When creating mails, select mails > create mails. Enter the address(recipient)、theme and contents.
Press MENU you could „append‟、„Add Cc/Bcc‟, select send or discarded or save as draft.
Check the Email files
Click on the bottom folder options, list all folder options
10
User Manual
6.Dialling
When the icon of internet server appears in the screen, you could dial or receive callings. The signal bar on the top
right corner show the strength of network signal (the maximum with 4 signal bars) .
Start dialing
Open application’s main menu>dial. You could choose SIM1 or SIM2 to do the dialing.
Dialling
At the dialing Keboard ，enter the phone number，and then click the dialing key , after that,you should choose
one SIM card or internet call. If needed to call the extension,you could click the “dial pad” in the bottom of the screen
to open the interface or press menu key to select “delay 2 seconds”，and then enter the number of the extension.
The dialup keyboard input number, click Menu can IP dial-up or speed dial
Video call: video call usually refers to the Internet and mobile Internet based on (3 G Internet) end, through
the phone between the speech of the real-time transmission and image (user of bust, photographs, items, etc.)
of a way to communicate. Only 3 G to support this function. Input a number click video dial-up, each other
answers the phone after both can through camera for video calls.
Telephone calls in the call log
Every telephone number called and received in“SIM1、SIM2”will reserved in phone’s menu of call log. On the top
left of every call record will show“SIM1 or SIM2”
All numbers in the call log can be dialed by clicking the button ”dial” on the right side of the screen.
When number list appearing，click it to catch details；press it for long you could dial via “SIM1 or SIM 2”， meanwhile
you can edit, delete, save the number or do other operations.
11
User Manual
Receive callings
When calling comes（top left will show from which SIM card）press“Answer”and slide towards right until the middle
button, then you can receive callings.
Proximity sensor
According to the distance between phone and human body，it will adjust automatically the switch of the backlight.
During the call, close the phone to the ear, the backlight will turn off automatically，which could save batteries
and prevent inadvertently touching.
Refuse to answer the phone
a. When standby, calling comes，press “refuse”button and slide towards left side until the middle button, then
you could refuse the calling.
b. When using,calling comes,click on the “refuse”button to refuse the calling.
Two-way call/multiparty call(conference call)
Notices：this function needs that SIM card open multiparty call features.
1) Already exist a call in the phone
2) Click“Add calls”， dial another call（or receive another call，phone default open ”call waiting”
（settings–dialing settings–other dialing settings）， after both connected，could view the status of
calling.
Telephone recording
During the call，more>start record，you could record the dialog of the call.
12
3）select“combine call”– you can combine two calls into one way.
4）after multiparty call connected ，you could separate the calls or hang up one of them via“the small
arrow of conference call”.
Loading...
