CLC PLUMD105 User Manual

Flipper

Brand Name: plum

Model Name: D105

FCC ID: Y7WPLUMD105

2

Chapter 1 Brief knowledge

1.1 Brief introduction

It is very pleasure that you choose this color-screen and
GSM/GPRS digital phone. This phone is double screen clamshell
mobile phones.

Before you use and fix our products, please read carefully all
the information of our manual, it will help you using our products
well and knowing the utility of the phone and enjoying its perfect
functions and easy operation means.

This kind of color-screen phone are designed for the specific
environment GSM/GPRS and provide for you such functions as
stereo bell with high quality, clock/alarm, stopwatch, calculator,
bluetooth, MP3 player, dual SIM and dual standby except the
basic function of making calls to meet your various needs.

This phone meets the GSM/GPRS technical standards, and is

certificated by the relative authorized organizations.

We reserve the right to make changes to this manual without

making acknowledgements.

1.2 Safety and Precautions

 If your phone has been stolen, please note the telecom

company which provides you the SIM card to acquire
their help to prohibit the phone to make call from your
missing SIM card.

 The telecom company may need the IMEI number of

your missing phone when you turn to them for help.
You can find this number when you take off the battery.
Please make a copy of such an IMEI to make you know
it when you need it.

 In order to protect your phone from being used in a

wrong way, please notice the following suggestions:
Preset the PIN code for your SIM card and make sure
keep it to yourself
Take your phones close to you

3

1.3 General notice items

Preset call prohibition

Please use the battery and charger designated by our

company. It will lead to leek, burst, fire by using other products.

Please don’t crush, hit or throw the phone to avoid

breaking the phone or causing fire.

Keep the phone, battery and the charger away from

microwave oven or other high-pressure apparatus.

Switch off the phone in the vicinity of chemical plants, gas

stations and other locations containing explosive objects.

Avoid using the phone in too high or too low temperature
environments. Never leave the phone exposed under direct
sunlight or in high humidity or dusty environment.

Keep the phone away from children to avoid causing harm
to them.

Don’t put the phone on the uneven or unstable places to

avoid its falling off and being broken.

1.4 Notice items for using phone

Please turn off your phone in such places as hospital,
air-plane. Your phone will interrupt the normal work of the
electric machine and medical machine. Please observe the
prescription. the phone have the auto-open function in designed
time, please check your alarm set and make sure that it will not
open in improper time.

Please don’t use your phone nearing the weak signal or

electric machine .radio waves will make the wrong work and
other problems. Pay attention to such machine as pacemakers,
hearing aids and other electro-medical equipments, fire dictator,
auto-door and other automatic machine. Please consult the
producer or local retailer about the impaction on the medical
machine made by phone.

Please do not strike the LCD screen or use the phone hit
other things , or the LCD panel will be broken and cause the leak
of the liquid. It will cause your eyes blind for the leak of the LCD

4

liquid. Washing your eyes immediately, don’t rub with your hands

and go to hospital at once.

Please do not disassemble the phone, or it will cause the
broken, leakage and circuit fault.

At scare time, the phone will cause ill condition to the

electric apparatus in the car. Please, don’t use your phone lest it

lost security.

Please don't press the keypad by using the needle, pen or
other sharp things, or it will cause wrong operation or damage
your phone.

Please don't use your phone in case the broken of the
antenna to avoid damaging to others health.

Please don't contact with such magnetic things as the
credit card, saving cards and soft disk to avoiding the lost of
information.

Please keep the pushing away from your phone. The
magnetic loudspeaker will insult the little metal things when it
work ,that will cause the damage of your body or broken your
phone.

Please avoid water or other liquid fluid in your phone
resulting in the overheating, leakage or failure.

1.5 Notice items for using the battery

Please don't put your battery in fire which will lead to
explosion.

Please don't push hard with force when install the battery
or it will cause the leakage and overheating and explosion.

Please don’t short circuit the battery, and avoid putting the

battery together with necklace, needles or other metal things.
Short circuit can cause liquid leak, overheat, explosion and fire

Please don't join the ends of the battery, or liquid leak,
overheat, explosion and fire might happen.

It will have the risk of losing your eyesight for the liquid
splash in eyes and don't rub your eyes, washing with water and
going to hospital.

5

Don't dissemble the battery, or it will lead to leakage ,
overheating or explosion of the battery.

Please don't use or lay your batter near fire or other high
temperature place, or the overheating, leakage or explosion will
happen.

Please stop use the high temperature and changing color or
deformed battery and exchange the new one.

It will harmful to your skin if the battery liquid splash your
body, you must wash by use of water and go to hospital.

Please take the battery away from fire if it emits strange
smell or leakage liquid to avoid explosion.

Please don't make your battery damped, or it will cause
overheating, smoke or corrode your battery.

Please don't expose your battery under the sunlight or
close to the high temperature place to avoid the leakage or
overheating, or it will shorten the span of your battery.

Please don't charge your phone over 24 hours.

1.6 Notice items for using the charger

Don’t short-circuit the charger or you can get an electricity
shock or damage the charger.

Don’s use the charger when the cable is broken, which

might cause fire or electricity shock.

Please clean the dust on the electrical outlet.

Please don't use the container with water nearing the

charger lest it splashing water to make overheating and leakage
your charger.

Please take off your charger from the socket if it spot with
water or other liquid to avoid the overheating

Please don't dissemble or modify your charger or it will
harm others health, electric shock or damage the charger.

Please don’t use the charger in the bathroom or other

high-humidity circumstances, or electric shock, fire or damage to
the charger can be caused.

Please don't use the wet hand touch charger, circuit wire

6

and outlet or it will lead to electric shock.

Don't put the heavy things on the cable or revise the circuit
lines or it will lead to electric shock and fire.

Please pluck out of the socket before cleaning and
maintain .

Please grasp the charger when you pluck or it will damage
the wire line and cause electric shock and fire.

1.7 Cleaning and maintenance

 Please don't use the phone in bathroom and avoid be
damp by rain for the phone ,battery and charger have no
water-proof function

 Please use the dry cloth to clean the phone, battery and
charger.

 Please don't use such liquids as alcohol, thinner or
benzene to wipe your phone.

 Dirt socket might cause bad connection in which
situation the battery cannot be charged. So please clean it on time.

1.8 General notice items

Phone：

 Please use your phone away from such places which
have the TV, radio, telephone and the automatic machines in case
it will influence the effect of these machines and your phone.

Battery：

 Please avoid your phone under the sun and keep it in
the cool and ventilate places.

 The life span of your battery is limited. The using time
of battery will decrease during you charge it. You should change

the definite new battery when you can’t charge it at all which

signify the battery cannot work.

 Please don't dispose the old battery in the normal
dustbin. You should send the used battery to specific space.

7

Chapter 2 Before using the phone

2.1 SIM Card

Before use the phone you must insert in it the valid SIM card
which is the key to help you enter the digital GSM net.

All the concerning information with the net and your calling
record will be signed in plat region of the SIM card and store
personal information, including PIN (Personal Identification
Number), phonebook, message and other additional system
services. Please handle the SIM card with care, twisting or
pressing it may cause damage. SIM card will be taken from your
phone and put into any phone with GSM function ,it will read
automatically the SIM card.

Please avoid touch the metal plane and take the SIM card
away from the electrical and magnetic place. Once the damage of
your card , you can not go into the GSM net.

* Note: Before you take out SIM card, you should turn off
your phone. Don't insert or take out your card during contact with
the outside power or it will be damage.

2.2.1Insert and take out the SIM card

 Please take out carefully the SIM which laid on other card

before you assemble the phone.

 Turn off your phone and remove the battery and other

power supply.

 With the metal contacts of the SIM card downward
and the unfilled corner against the one within the groove, put
the card into the groove gently and push it down until it
doesn't move.
 Before taking out the SIM card, please turn off the

phone first.

2.2.2Insert and take out the T-FLASH card

T-FLASH card should be put into the T-flash card tray.
Before inserting and taking out the T-flash card, you should turn
off the phone first and cut off the outer power supply.

8

Insert the T-flash Card：Push the card into the card tray
with the metal side down; the card will be fixed when you hear a
“click” sound.

Taking out the T-flash Card：Take out the battery first and
push the T-FLASH socket , and then you can take out the T-flash
card.

2.3 Battery

The new battery has about 50% capacity. You can use it
immediately. The new battery must be charged at least 14 hours,
the full performance of a new battery is achieved only after two
or three complete charge and discharge cycles

2.3.1 Insert and take out the battery

 Follow the below procedures to take out the battery

1. Push downward the battery cover away.

2. Take out the battery from the bottom of the battery.

 Follow the below procedures to insert the battery.

1. Press the battery into the battery slot tightly.

2. Push the battery cover into battery tary.

2.3.2 The charge of battery

Contact the charger with power supply.

Insert the joints of charger into the bottom of the phone.

Then the battery capacity sign on the top right corner of

the screen will flash circularly. If you are charging the phone

when it’s turned off, the screen will display the charging

animation. If the battery is completely discharged, it may take a
few minutes before the charging indicator appears on the display
or before any calls can be made.

It means the battery has been fully charged if the battery

capacity sign shows that it’s full and stops flashing. If the phone

turned off, the screen will tell you that the battery is full. This will
need 3 ~4 hours. It’s normal that when charging the battery, the
temperature of the phone, battery and charger will rise.

When the battery is fully charged, disconnect the electric
resource and the phone.

9

 Notes:

- Uses only approved batteries, and recharge your battery

only with approved chargers designated for this device. It’s
dangerous to use un-approved charger, and it violates the after
service terms.

- Please recharge the battery in time, when the phone

turns off automatically or shows” Low Power”. If the battery has

not been totally out of power, the phone will shorten the charging
time automatically.

- The standby time and call time provided by the factory

is based on the ideal working circumstance. During the actual
usage, the working time will differ according to the network
condition, working circumstance and the way to use it.

- Please make sure the battery is perfectly inserted when

charging the battery. The battery cannot be taken off when it’s

been charged.

- Disconnect the charger with the phone when the

charging is done.

- If you haven’t disconnected the charger with the electric

resource and the phone after the charging is done, the phone will
begin to charge again after about 5~8 hours. This is not
recommended, because it will shorten the life of your battery.

2.4Turn on your phone

Please press the hang-up key more than two seconds will
turn on or off the phone.

If you turn on the phone without the SIM card, your phone
will note you insert the SIM card. Your phone will check your
card automatically when you insert it well.

And then ,the display screen will appear following notes
consequently:

- Insert PIN1 if you set the password of the SIM card (the

details learn from chapter 410.5)

- Input the password of your phone if you set (the details

can learn from chapter 4.10.5)
