Clay Paky MYTHOS C61390 Instruction Manual

1

MYTHOS

C61390

®

INSTRUCTION MANUAL

Congratulations on choosing a Clay Paky product!
We thank you for your custom.
Please note that this product, as all the others in the rich Clay
Paky range, has been designed and made with total quality to
ensure excellent performance and best meet your expectations
and requirements.

Carefully read this instruction manual in its entirety and keep it
safe for future reference. It is essential to know the information
and comply with the instructions given in this manual to ensure
the fitting is installed, used and serviced correctly and safely.
CLAY PAKY S.p.A. disclaims all liability for damage to the fitting
or to other property or persons deriving from installation, use and
maintenance that have not been carried out in conformity with this
instruction manual, which must always accompany the fitting.
CLAY PAKY S.p.A. reserves the right to modify the
characteristics stated in this instruction manual at any time and
without prior notice.

ENGLISH

PR

ELIMIN

A

RY

INDEX

Page Contents

2 Safety information

3 Unpacking and preparation

4 Installation and start-up

5 Control panel

7 Menu setting

16 Maintenance

19 Technical information

19 Cause and solution of problems

20 Channel functions

2

MYTHOS

• Installation

Make sure all parts for fixing the projector are in a good state of repair.
Make sure the point of anchorage is stable before positioning the projector.
The safety chain must be properly hooked onto the fitting and secured to the framework, so that, if
the primary support system fails, the fitting falls as little as possible.
If the safety chain gets used, it needs to be replaced with a genuine spare.

• MINIMUM DISTANCE OF ILLUMINATED OBJECTS
The projector needs to be positioned so that the objects hit by the beam of light are at least
1

8 metres (59’1”) from the lens of the projector.

• Minimum distance from flammable materials

The projector must be positioned so that any flammable materials are at least 0.20 metres (8") from
every point on the surface of the fitting.

• Mounting surfaces

It is permissible to mount the fitting on normally flammable surfaces.

• Maximum ambient temperature

Do not operate the fixture if the ambient temperature (Ta) exceeds 40° C (104° F).

• IP20 protection rating

The fitting is protected against penetration by solid bodies of over 12mm (0.47”) in diameter (first
digit 2), but not against dripping water, rain, splashes or jets of water (second digit 0).

• Protection against electrical shock

Connection must be made to a power supply system fitted with efficient earthing (Class I appliance
according to standard EN 60598-1).
It is, moreover, recommended to protect the supply lines of the projectors from indirect contact
and/or shorting to earth by using appropriately sized residual current devices.

• Connection to mains supply

Connection to the electricity mains must be carried out by a qualified electrical installer.
Check that the mains frequency and voltage correspond to those for which the projector is designed
as given on the electrical data label.
This label also gives the input power to which you need to refer to evaluate the maximum number
of fittings to connect to the electricity line, in order to avoid overloading.

• Temperature of the external surface

The maximum temperature that can be reached on the external surface of the fitting, in a thermally
steady state, is 100°C (212°F).

• Maintenance

Before starting any maintenance work or cleaning the projector, cut off power from the mains
supply.
After switching off, do not remove any parts of the fitting, to avoid getting burnt for at least 35
minutes. After this time the likelihood of the lamp exploding is virtually nill.
The fitting is designed to hold in any splinters produced by a lamp exploding. The lenses must be
mounted and, if visibly damaged, they have to be replaced with genuine spares.

• Lamp

The fitting mounts a high-pressure lamp that needs an external igniter. This igniter is fitted onto the
apparatus.

- Carefully read the "operating instructions" provided by the lamp manufacturer.

- Immediately replace the lamp if damaged or deformed by heat.

• Battery

This product contains a rechargeable lead-acid or lithium iron tetraphosphate battery. To preserve
the environment, please dispose the battery at the end of its life according to the regulation in force.

NOT FOR RESIDENTIAL USE

SAFETY INFORMATION

The products to which this manual refers comply with the European Directives pursuant to:

• 2006/95/EC - Safety of electrical equipment supplied at low voltage (LVD)

• 2004/108/EC - Electromagnetic Compatibility (EMC)

• 2011/65/EU - Restriction of the use of certain hazardous substances (RoHS)

IP20

18

470W

tc100°C

LiFePO4

Pb

3

MYTHOS

UNPACKING AND PREPARATION

1

M

Y

T

H

OS

C

6

1

3

9

0

®

I

N

S

T

R

U

C

T

I

O

N

M

A

N

U

A

L

C

o

n

g

r

a

t

u

l

a

t

i

o

n

s

o

n

c

h

o

o

s

i

n

g

a

C

l

a

y

P

a

k

y

p

r

o

d

u

c

t

!

W

e

t

h

a

n

k

y

o

u

f

o

r

y

o

u

r

c

u

s

t

o

m

.

P

l

e

a

s

e

n

o

t

e

t

h

a

t

t

h

i

s

p

r

o

d

u

c

t

,

a

s

a

l

l

t

h

e

o

t

h

e

r

s

i

n

t

h

e

r

i

c

h

C

l

a

y

P

a

k

y

r

a

n

g

e

,

h

a

s

b

e

e

n

d

e

s

i

g

n

e

d

a

n

d

m

a

d

e

w

i

t

h

t

o

t

a

l

q

u

a

l

i

t

y

t

o

e

n

s

u

r

e

e

x

c

e

l

l

e

n

t

p

e

r

f

o

r

m

a

n

c

e

a

n

d

b

e

s

t

m

e

e

t

y

o

u

r

e

x

p

e

c

t

a

t

i

o

n

s

a

n

d

r

e

q

u

i

r

e

m

e

n

t

s

.

C

a

r

e

f

u

l

l

y

r

e

a

d

t

h

i

s

i

n

s

t

r

u

c

t

i

o

n

m

a

n

u

a

l

i

n

i

t

s

e

n

t

i

r

e

t

y

a

n

d

k

e

e

p

i

t

s

a

f

e

f

o

r

f

u

t

u

r

e

r

e

f

e

r

e

n

c

e

.

I

t

i

s

e

s

s

e

n

t

i

a

l

t

o

k

n

o

w

t

h

e

i

n

f

o

r

m

a

t

i

o

n

a

n

d

c

o

m

p

l

y

w

i

t

h

t

h

e

i

n

s

t

r

u

c

t

i

o

n

s

g

i

v

e

n

i

n

t

h

i

s

m

a

n

u

a

l

t

o

e

n

s

u

r

e

t

h

e

f

i

t

t

i

n

g

i

s

i

n

s

t

a

l

l

e

d

,

u

s

e

d

a

n

d

s

e

r

v

i

c

e

d

c

o

r

r

e

c

t

l

y

a

n

d

s

a

f

e

l

y

.

C

L

A

Y

P

A

K

Y

S

.

p

.

A

.

d

i

s

c

l

a

i

m

s

a

l

l

l

i

a

b

i

l

i

t

y

f

o

r

d

a

m

a

g

e

t

o

t

h

e

f

i

t

t

i

n

g

o

r

t

o

o

t

h

e

r

p

r

o

p

e

r

t

y

o

r

p

e

r

s

o

n

s

d

e

r

i

v

i

n

g

f

r

o

m

i

n

s

t

a

l

l

a

t

i

o

n

,

u

s

e

a

n

d

m

a

i

n

t

e

n

a

n

c

e

t

h

a

t

h

a

v

e

n

o

t

b

e

e

n

c

a

r

r

i

e

d

o

u

t

i

n

c

o

n

f

o

r

m

i

t

y

w

i

t

h

t

h

i

s

i

n

s

t

r

u

c

t

i

o

n

m

a

n

u

a

l

,

w

h

i

c

h

m

u

s

t

a

l

w

a

y

s

a

c

c

o

m

p

a

n

y

t

h

e

f

i

t

t

i

n

g

.

C

L

A

Y

P

A

K

Y

S

.

p

.

A

.

r

e

s

e

r

v

e

s

t

h

e

r

i

g

h

t

t

o

m

o

d

i

f

y

t

h

e

c

h

a

r

a

c

t

e

r

i

s

t

i

c

s

s

t

a

t

e

d

i

n

t

h

i

s

i

n

s

t

r

u

c

t

i

o

n

m

a

n

u

a

l

a

t

a

n

y

t

i

m

e

a

n

d

w

i

t

h

o

u

t

p

r

i

o

r

n

o

t

i

c

e

.

E

N

G

L

I

S

H

P

R

E

L

I

M

I

N

A

R

Y

I

N

D

E

X

P

a

g

e

C

o

n

t

e

n

t

s

2

S

a

f

e

t

y

i

n

f

o

r

m

a

t

i

o

n

3

U

n

p

a

c

k

i

n

g

a

n

d

p

r

e

p

a

r

a

t

i

o

n

4

I

n

s

t

a

l

l

a

t

i

o

n

a

n

d

s

t

a

r

t

-

u

p

5

C

o

n

t

r

o

l

p

a

n

e

l

7

M

e

n

u

s

e

t

t

i

n

g

1

6

M

a

i

n

t

e

n

a

n

c

e

1

9

T

e

c

h

n

i

c

a

l

i

n

f

o

r

m

a

t

i

o

n

1

9

C

a

u

s

e

a

n

d

s

o

l

u

t

i

o

n

o

f

p

r

o

b

l

e

m

s

2

0

C

h

a

n

n

e

l

f

u

n

c

t

i

o

n

s

IST00L/001

2 x 183102/805

1

UNLOCKED

9

0

°

9

0

°

9

0

°

9

0

°

LOCKED

PAN Mechanism Lock and Release (every 90°) - Fig. 2

TILT Mechanism Lock and Release (every 45°) - Fig. 3

2 3

Packing contents - Fig. 1

LOCKED

UNLOCKED

4

5

°

4

5

°

4

5

°

4

5

°

4

5

°

4

5

°

4

5

°

4

MYTHOS

4

2

1

1

2

3

5

INSTALLATION AND START-UP

Connecting and disconnecting power cable - Fig. 5

Installing the projector - Fig. 4

The projector can be installed on the floor resting on special rubber feet, on a truss or on the ceiling or wall.

WARNING: with the exception of when the projector is positioned on the floor, the safety cable must be fitted. (Cod. 105041/003 available on request).
This must be securely fixed to the support structure of the projector and then connected to the fixing point at the centre of the base.

5

MYTHOS

Switching on the projector - Fig. 8
Press the switch. The projector starts resetting the effects. At the same time, the following information scrolls on the display:

Model Firmware xxx (Fixture ID) System errors

MYTHOS Version X.X.X Dmx Address xxx E: .........................

Date - Hour W: .........................

On conclusion of resetting in case of absence of the dmx signal, Pan and Tilt move to the “Home” position (Pan 50% - Tilt 50%). The control panel
(Fig. 8) has a display and buttons for the complete programming and management of the projector menu. The display can be in one of two
conditions: rest status and setting status. When it is in the rest status, the display shows the projector’s DMX address and the Fixture ID address
(if set).
During menu setting status, after a wait time (about 30 seconds) without any key having been pressed, the display automatically returns to rest status.
It should be noted than when this condition occurs, any possible value that has been modified but not yet confirmed with the

F

key will be cancelled.

CONTROL PANEL

1

2

Dmx Address

Warning Message

Fixture ID

18m

8

Continue

➔

Connecting to the control signal line (DMX) - Fig. 7
Use a cable conforming to specifications EIA RS-485: 2-pole twisted, shielded, 120Ohm characteristic impedance, 22-24 AWG, low capacity. Do not use
microphone cable or other cable with characteristics differing from those specified. The end connections must be made using XLR type 3 or 5-pin male/female
connectors. A terminating plug must be inserted into the last projector with a resistance of 120Ohm (minimum 1/4 W) between terminals 2 and 3.
IMPORTANT: The wires must not make contact with each other or with the metal casing of the connectors. The casing itself must be connected to the
shield braid and to pin 1 of the connectors.

C

onnecting to the mains supply - Fig. 6

Mains

6

7

MYTHOS

6

28

28

Reversal of the display - Fig. 9
To activate this function, press UP

B

and DOWN Ckeys simultaneously while the display is in the rest mode. This status will be memorised and

maintained even for the next time it will be switched on. To return to the initial state, repeat the operation all over again.

Setting the projector starting address

On each projector, the starting address must be set for the control signal (addresses from 1 to 512).
The address can also be set with the projector switched off.
Setting the address: see pag. 8.

Setting the projector Fixture ID

On each projector, the Fixture ID address must be set for an easy identification of the fixtures in an installation (ID from 1 to 255).
The Fixture ID address can be set with the projector switched off.
Setting the Fixture ID: see pag. 8.

9

Functions of the buttons - Using the menu

Setting addresses and options with the projector disconnected

The projector’s DMX address, as well as other possible operating options, can also be set when the appliance is disconnected from the electricity supply.
All that is needed is to press

F

to momentarily activate the display and thus access the settings. Once the required operations have been carried out,

the display will switch off again after a wait time of 30 seconds.

USING THE MENU:

1) Press

F

once – “Main Menu” appears on the display.

2) Use the UP

B

and DOWN Ckeys to select the menu to be used:

• Setup (Setup Menu): To set the setting options.

• Option (Option Menu): To set the operating options

• Informations (Informations Menu): To read the counters, software version and other information.

• Manual Control (Manual control Menu): To trigger the test and manual control functions.

• Test (Test Menu): To check the proper functionning of effects

• Advanced (Advanced Menu): Access to the "Advanced menu" is recommended for a trained technical personnel.
To enable the "Advanced" see pag.13

3) Press

F

to display the first item in the selected menu.

4) Use the UP

B

and DOWN Ckeys to select the MENU items.

Confirms the displayed value, or activates the displayed function, or enters the successive
menu.

Decreases the value displayed (with auto-repetitions) or passes to the next item in the menu.

Increases the value displayed (with auto-repetitions) or passes to the previous item in a menu.

Return to the top level

Commute from units, tens, hundreds, in the "Address", "Fixture ID" and "Calibration" menù.

F

C

DOWN

B

UP

D

LEFT

E

RIGHT

7

MYTHOS

MENU SETTING

Continue

➔

Main Menu Level 1 Level 2 Level 3 Choices / Values

SET UP

D

MX Address

0

01-512

Channel Mode

Standard

Vector

Fixture ID 000-255

Ethernet Interface

Control Protocol

Disabled

Art-net IP 2.x.x.x.

Art-net IP 10.x.x.x.

Repeat on DMX

Disabled

Enabled on primary

Universe 000-255

OPTIONS

Lamp DMX On / Off

Safety Black Out On / Off

Pan / Tilt

Invert Pan

On / Off
Invert Tilt On / Off
Swap Pan-Tilt On / Off
Encoder Pan-Tilt On / Off

P/T Homing mode

Standard

Sequenced

Pan Home Def Pos

0 degree

90 degrees
180 degrees
270 degrees

Tilt Home Def Pos

0 %

12.5 %
25 %
50 %
75 %

87.5 %

100 %

Color

CMY Shortcut

On / Off

Linear Movement On / Off

Shutter

Shutter On Error

On / Off

Dimmer on Shutter On / Off

Dimmer Filter Type

DMX follower

Position dependent

Macro Effects

Macro group size 02-15

Macro fixture ID

Auto by DMX Addr.

Fixed to 1-15
Display On / Off

Safety Beam On / Off

Settings

Default Preset

Reset To Default

Go Back

User Preset 1

Load preset 1

Save to preset 1

User Preset 2

Load preset 2

Save to preset 2

User Preset 3

Load preset 3

Save to preset 3

8

MYTHOS

Main Menu Level 1 Level 2 Level 3 Choices / Values

INFORMATION

System Errors Read / Reset

Fixture Hours

Total Hours Read
P

artial Hours Read / Reset

Lamp Hours

Total Hours Read
Partial Hours Read / Reset

Lamp Strikes

Total Strikes Read
Partial Strikes Read / Reset

System Version

CPU brd Fw.rev. / Hw.rev.
com.dev Fw.rev.
0:PT-3f Fw.rev. / Hw.rev.
1:8-Ch Fw.rev. / Hw.rev.
2:8-Ch Fw.rev. / Hw.rev.

Board Diagnostic

0:PT-3f Status / Err%
1:8-Ch Status / Err%
2:8-Ch Status / Err%

DMX Monitor Channels Value / Percentage

Fans Monitor

PwrSp Speed (RPM)
PwrSp Speed (RPM)
Lamp Speed (RPM)
Lamp Speed (RPM)
Lamp Speed (RPM)

Head Position

X
Y
Z

Good Pkt

Bad Pkt

Uart Err
Sensor status Channels n.a / On / Off

Rot Gobs Indexing

Network parameters

IP Address
IP Mask
MAC Address

MANUAL

CONTROL

Lamp

On/Off
Reset

Yes/No

Channels

Value / Percentage

TEST

ADVANCED

Access Code 1234

Service Mode

On/Off

Upload Firmware

Yes/No

Setup Model

Yes/No
Calibration Channels 000 - 255
Rot. Gobo Indexing

Yes/No

9

MYTHOS

SET UP MENU

DMX ADDRESS

P

LEASE NOTE: Without the DMX input signal, the displayed address (DMX Address) blinks.

It lets you select the address (DMX Address) for the control signal. A DMX address between 001 and 512 can
be selected.

CHANNEL MODE

This lets you select the projector operating mode, selecting one of the two available modes:

x Standard (29 DMX channels occupied, see Channel Function)
x Vector (33 DMX channels occupied, see Channel Function)

FIXTURE ID

It lets you set the “Fixture ID” to be assigned to the projector. An “ID” between 000 and 255 can be assigned.

ETHERNET INTERFACE

It lets you set Ethernet settings to be assigned to the projector as indicated below:

Control Protocol

It lets you select the “Control Protocol” Art-net to be assigned according to the control unit used; the options
available are the following:

x Disabled:
x Art-net on IP 2
x Art-net on IP 10

Repeat on DMX

It lets you enable/disable the transmission of the Ethernet protocol by DMX signal to all the connected
projectors.

x Disabled: DMX transmission disabled.
x Enabled on primary: DMX transmission enabled.

Universe

It lets you set the “DMX Universe” to be assigned to a series of projectors with values between 000 and 255.

Continue

➔

10

MYTHOS

OPTIONS MENU

LAMP DMX

It lets you enable (ON) the lamp remote control channel. Select OFF to turn off or disable this option.

S

AFETY BLACK OUT

This allows the Dimmer's automatic lock option to be activated (ON) after 3 seconds with no incoming DMX
signal. Select OFF to turn off or disable this option.

PAN / TILT
Invert Pan

It lets you enable (ON) Pan reverse movement. Select OFF to turn off or disable this option.

Invert Tilt

It lets you enable (ON) Tilt reverse movement. Select OFF to turn off or disable this option.

Swap Pan-Tilt

It lets you enable (ON) Pan and Tilt channel inversion (and simultaneously Pan fine and Tilt fine). Select OFF
to turn off or disable this option.

Encoder Pan-Tilt

It lets you enable (ON) or disable (OFF) Pan and Tilt Encoder operations.

P/T Homing Mode

It lets you set the initial Pan and Tilt Reset mode.

x Standard: Pan & Tilt are simultaneously reset.
x Sequenced: Tilt is reset first followed by Pan.

Pan Home Def Pos

It lets you assign the Pan channel “home” position at the end of Reset (without a DMX input signal), selecting
one from the 4 available positions:

x 0 degree
x 90 degrees
x 180 degrees
x 270 degrees (default)

Tilt Home Def Pos

It lets you assign the Tilt channel “home” position at the end of Reset (without a DMX input signal), selecting
one from the 7 available positions:

x 0%
x 12.5%
x 25%
x 50% (default)
x 75%
x 87.5%
x 100%

11

MYTHOS

C

OLOR

CMY short-cut

It lets you optimise (ON) the color change time of the color wheel since the disk rotates in the direction that
requires the shortest and thus quickest movement. Select OFF to turn off or disable this option.

Linear Movement

It lets you enable (ON) the linear color wheel movement. Select OFF to turn off or disable this option.

SHUTTER
Shutter on error

It lets you activate (ON) automatic "Stopper/Strobe" closing in the event of Pan/Tilt positioning error. Select
OFF to turn off or disable this option.

Dimmer on Shutter

Select ON to enable automatic Dimmer closing when the Strobe is fully closed. Select OFF to disable this
option.

DIMMER FILTER TYPE

It lets you best optimise the "Dimmer curve" according to that set on the control panel. One of the following 2
options can be selected:

DMX follower
Dimmer movement speed/linearity follows the DMX values set by the panel.
Position dependent

Dimmer movement speed follows the DMX values set by the panel taking into account the physical Dimmer
starting position.

MACRO EFFECTS

It allows you to select one of the 2 following options:

Macro Group size: Lets you select the number of projectors (minimum 2 and maximum 15) to be included in
the “Macro Effects” channel operation.

Macro fixture ID: It lets you attribute an ID address to the projector for the phase displacement for the scene’s
starting time in Macro Effects channel.

x Fixed to 1-15: (to assign to all the projectors to be included in the Macro Effects operation).
x Auto by DMX Address: According to the DMX address, it automatically detects the starting sequence of

the scene in the Macro mode (to assign to all the projectors to be included in the Macro Effects channel
operation).

DISPLAY

It lets you activate (ON) display brightness reduction after about 30 seconds in idle status. Select OFF to turn
off or disable this option.

SAFETY BEAM

It lets you turn ON a light beam temperature reduction when Focus movement is 50% over its stroke, if no
CMY colour wheels are inserted, Frost is automatically inserted on the Cyan wheel.

Continue

➔

12

MYTHOS

S

ETTINGS

Used to save 3 different settings of the items in the option menu and relevant submenus.

x Default preset (*)
x U

ser preset 1

x User preset 2
x User Preset 3

- L

oad preset 'X’ is used to recall a previously stored configuration.

- Save to preset ‘X’ is used to save the current configuration.

(*) DEFAULT PRESET
It lets you restore default values on all option menu items and relevant submenus.

Press the left and right arrows/keys simultaneously in the "main menu” to quickly restore default
values (DEFAULT PRESET).

Default options

x Lamp DMX ĺ On
x Invert Pan ĺ Off
x Invert Tilt ĺ Off
x Swap Pan-Tilt ĺ Off
x Encoder Pan-Tilt ĺ On
x P/T Homing Mode ĺ Standard
x Pan Home Def Pos ĺ 270 degrees
x Tilt Home Def Pos ĺ 50%
x CMY Shortcut ĺ On
x Linear Movement ĺ Off
x Shutter on error ĺ Off
x Dimmer on shutter ĺ Off
x Dimmer filter type ĺ DMX follower
x Display ĺ On
x Safety Beam ĺ Off

13

MYTHOS

INFORMATION MENU

SYSTEM ERRORS

It displays a list of errors that occurred when the projector was turned on.
To reset the SYSTEM ERRORS list, press OK. A confirmation message appears (Are you sure you want to
clear error list?). Select YES to confirm reset.
From the menu

FIXTURE HOURS

It lets you view projector working hours (total and partial).

Total counter

It counts the number of projector working life hours (from construction to date).

Partial counter

It counts the number of projector partial working life hours from the last reset to date.

Press OK to reset the partial counter. A confirmation message appears on the display (Are you sure ?)
Select YES to confirm reset.

LAMP HOURS

It lets you view lamp working hours (total and partial).

Total counter

It counts the number of projector working hours with the lamp on (from construction to date).

Partial counter

It counts the number of lamp partial working hours from the last reset to date.

Press OK to reset the partial counter. A confirmation message appears on the display (Are you sure ?)
Select YES to confirm reset.

LAMP STRIKES

It lets you view how many times the lamp was turned on (total and partial).

Total counter

It counts the number of times the lamp was turned on (from construction to date).

Partial counter

It counts the number of times the lamp was turned on from the last reset to date.

Press OK to reset the partial counter. A confirmation message appears on the display (Are you sure ?)
Select YES to confirm reset.

SYSTEM VERSION

It lets you view the hardware and software versions for each electronic board in the projector.

x CPU brd (CPU board)
x 0: PT-3f (Pan / Tilt board)
x 1: 6-Ch (6-channel board)
x 2: 6-Ch (6-channel board)

BOARD DIAGNOSTIC

It lets you view the percent errors for each electronic board installed in the projector

x 0: PT-3f (Pan / Tilt board)
x 1: 6-Ch (6-channel board)
x 2: 6-Ch (6-channel board)

14

MYTHOS

D

MX MONITOR

It lets you view the level of projector DMX channels in bit (Val) and in percent.

F

ANS MONITOR

I

t lets you view the speed of each fan installed in the projector:

x Lamp (lamp cooling fan)
x Pwr.Sup (PSU cooling fan)

HEAD POSITION

It lets you view the projector head position with reference to the X, Y and Z axes. It also provides further
information on:

x Good pkt: number of correctly received signal packets
x Bad pkt: number of incorrectly received signal packets
x Uart Err.: UART reception errors

SENSOR STATUS

It lets you check the correct operations of each "sensor” installed in the projector, each channel is associated
with one of the following three parameters:

x n.a.= sensor not available
x ON= sensor working
x OFF= sensor defective

ROT GOBOS INDEXING

It lets you check whether the rotating gobo wheel gobo indexing procedure should be run, if indexed, "Indexing
Active" appears on the display, otherwise "Indexing required!” appears

If necessary, indexing should be activated from the Advanced menu.

NETWORK PARAMS

Lets you view the projector "Network" parameters meaning:

IP address: Internet Protocol address (two projectors must not have the same IP address)
IP mask: 255.0.0.0
Mac address: Media Access Control; the projector’s Ethernet Address.

15

MYTHOS

MANUAL CONTROL

L

AMP

It lets you turn the lamp on (ON) or off (OFF) from the projector control panel.

RESET

It lets you reset the projector from the projector control panel.

CHANNEL

It lets you set the channel DMX levels from the projector control panel (value between 0 and 255 bit or
between 0% and 100%).

TEST MENU

It lets you test the correct operations of effects using saved Tests.
Available test sequences:

ADVANCED MENU

To open the “Advanced Menu”, enter the code (1234)

SERVICE MODE

It lets you disable (ON) the projector Beam operating mode.

UP LOAD FIRMWARE

It lets you transfer "firmware" from one projector to all other connected projectors. A confirmation message
appears on the display (Are you sure ?) Select YES to confirm or NO to abort this operation.

SETUP MODEL

It lets you change the projector model (operation probably necessary after replacing the CPU during repairs).
A confirmation message (Are you sure ?) appears on the display Select YES to confirm (the list of available
and selectable projectors appears) or NO to abort this operation.

CALIBRATION

It lets you make small mechanical adjustments on some effects to perfectly align projectors from the control
panel.

Factory default

It lets you restore default "Calibration” values (128 bit) on all channels.

ROT GOBOS INDEXING

It lets you run the rotating gobo wheel gobo indexing procedure. This operation may be necessary after
projector maintenance/cleaning.

16

MYTHOS

Locking and releasing Pan and Tilt movements - Refer to the instructions in the UNPACKING AND PREPARATION section.
Opening the head covers - Fig. 10.

Closing the head covers - Fig. 11.

2

4

1

1/4 Turn

1

1/4 Turn

3

2

10 11

MAINTENANCE

17

MYTHOS

12

IMPORTANTE:
Before switch off the fixture, is necessary to keep closed the dimmer channel for at least 5 seconds, this is to ensure a better working /
reliability of the lamp itself (it is recommended to turn off the lamp when it is dimmed).

GOD007-004

GOD007-005

GOD007-002

GOD007-001

GOD007-003

GOD007-006

13

ATTENTION:

- Before use custom gobos contact Clay Paky;

- The original gobos have a special coating designed specifically to resist to the high temperatures in the Prima Supersharpy;

- The rotating gobo wheel only use dichroic glass gobos (it is not possible to use metal gobos);

- For more information contact Clay Paky; - Fig. 13

18

MYTHOS

Battery removal - Fig. 14

This product contains a rechargeable lead-acid or lithium iron tetraphosphate battery. To preserve the environment, please dispose the battery
at the end of its life according to the regulation in force.

2

1

6

3

4

5

LiFePO4

Pb

1

4

19

MYTHOS

570

(22.44")

404

(15.90")

420

(16.53")

188

(7.40")

396

(15.59")

Zoom IN

611 (24.05")

Zoom OUT

628 (24.72")

Zoom OUT

427 (16.81")

Zoom IN

408 (16.06")

Zoom IN&OUT

455 (17.91")

Power supplies available

115/230V 50/60Hz

Input power

700VA a 230V 50Hz.

Total output

n.a.

Lamp

P

hilips MSD Platinum 20R (LAM00F)

- Output Lamp power: 470 W

- Colour temperature: 8,000 K

- Average lifetime: 1500 h

- Any working position

- Socket: Faston TM 250

- Luminous flux: >23,000 lm

M

otors

20 stepper motors, operating with micro-steps,
totally microprocessor controlled.

Channels

Max 33 control channels.

Inputs

- DMX 512 (5 poles XLR input and output)

- Ethernet

Moving head

• Movement by means of two stepper motors,
controlled by microprocessor.

• Automatic repositioning of PAN and TILT after
accidental movement not controlled by control
unit.

• Angle:

- PAN = 540°

- TILT = 252°

• Resolution:

- PAN = 2.11°

- PAN FINE = 0.008°

- TILT = 0.98°

- TILT FINE = 0.004°

IP20 protection rating

• Protected against the entry of solid bodies larger
than 12mm (0.47”).

• No protection against the entry of liquids.

CE Marking

Complies with the following European Directives

- 2006/95/EC (LVD)

- 2004/108/EC (EMC)

- 2011/65/EU (RoHS).

Safety Devices

• Bipolar circuit breaker with thermal protection.

• Automatic break in power supply in case of
over heating or fail ed operation of cooling
system.

Cooling

F

orced ventilation with axial fans, cooling system

monitoring.

Body

• Aluminum structure with die-cast plastic cover.

• Two side handles for transportation.

• Device locking PAN and TILT mechanisms for
transportation and maintenance.

Working position

Working in any position.

Weights

31 Kg (68lbs, 3ozs).

TECHNICAL INFORMATION

CAUSE AND SOLUTION OF PROBLEMS

THE PROJECTOR WILL NOT SWITCH ON

PROBLEMS

ELECTRONICS NON-OPERATIONAL

DEFECTIVE PROJECTION

REDUCED LUMINOSITY

POSSIBLE CAUSES CHECKS AND REMEDIES

No mains supply.
Lamp exhausted or defective.
Signal transmission cable faulty or disconnected.
Incorrect addressing.
Fault in the electronic circuits.
Lenses or reflector broken
Dust or grease deposited.

Check the power supply voltage.
Replace the lamp. (See instructions).
Replace the cables.
Check addresses (see instructions).
Call an authorised technician.
Call an authorised technician.
Clean (see instructions).

MYTHOS

CHANNEL FUNCTION

20

MYTHOS

NB: To prevent accidental breakage of the effects,
which could collide with each other during transport,
before switching the projector OFF check that all the
projector Channels have been excluded (DMX level = 0%).

CHANNEL

CHANNEL MODE

STANDARD VECTOR

1 CYAN COLOUR WHEEL CYAN COLOUR WHEEL
2 MAGENTA COLOUR WHEEL MAGENTA COLOUR WHEEL
3 YELLOW COLOUR WHEEL YELLOW COLOUR WHEEL
4 COLOUR 1 COLOUR 1
5 COLOUR 2 COLOUR 2
6 COLOUR 3 COLOUR 3
7 STOPPER / STROBE STOPPER / STROBE
8 DIMMER DIMMER

9 STATIC GOBO CHANGE STATIC GOBO CHANGE
10 ANIMATION DISK INSERTION ANIMATION DISK INSERTION
11 ANIMATION DISK ROTATION ANIMATION DISK ROTATION
12 ROTATING GOBO SELECT ROTATING GOBO SELECT
13 GOBO ROTATION GOBO ROTATION
14 FINE GOBO ROTATION FINE GOBO ROTATION
15 PRISMS INSERTION PRISMS INSERTION
16 PRISMS ROTATION PRISMS ROTATION
17 FROST FROST
18 ZOOM ZOOM
19 FOCUS FOCUS
20 FOCUS FINE FOCUS FINE
21 BEAM MODE BEAM MODE
22 PAN PAN
23 FINE PAN FINE PAN
24 TILT TILT
25 FINE TILT FINE TILT
26 FUNCTION FUNCTION
27 RESET RESET
28 LAMP CONTROL LAMP CONTROL
29 MACRO EFFECTS MACRO EFFECTS
30 - PAN-TILT TIME
31 - COLOUR TIME
32 - BEAM TIME
33 - GOBO TIME

MYTHOS

21

Continue

➔

Channel Mode

DMX

Value

Function

Standard Vector

1 1

C

YAN COLOUR WHEEL

0 - 255 Linear Cyan movement

2 2

MAGENTA COLOUR WHEEL

0 - 255 Linear Magenta movement

3 3

YELLOW COLOUR WHEEL

0 - 255 Linear Yellow movement

4 4

COLOUR 1

0 Empty position
28 Empty + Frost
50 Frost
80 Frost + Lavender

100 Lavende

r

129 Lavender + TC246
150 TC246
181 TC 246 + TC260
204 TC260
235 TC260 + UV Filte

r

255 UV filter

5 5

COLOUR 2

0 Empty position
28 Empty + Dark Green
50 Dark Green
75 Dark Green + DL070

100 DL070
129 DL070 + Blue
150 Blue
178 Blue + H.M.Green
200 H.M.Green
235 H.M.Green + Red
255 Red

22

MYTHOS

C

hannel Mode

DMX

Value

Function

Standard Vector

6 6

C

OLOUR 3

0

Empty position
28 Empty + Green
50 Green
77 Green + Pink

100 Pink
129 Pink + Aquamarine
150 Aquamarine
181 Aquamarine + Orange1
200 Orange1
231 Orange1 + Orange2
255 Orange2

7 7

STOPPER / STROBE

0 - 3 Light OFF

4 - 103

Strobe at linearly variable frequency

from low (1 flash/sec) to high (25 flashes/sec)

104 - 107 Light ON

108 - 207

Pulsation at linearly variable speed

from slow (0.5 flash/sec) to fast (25 flash/sec)

208 - 212 Light ON
213 - 225 Random Strobe at low frequency
226 - 238 Random Strobe at medium frequency
239 - 251 Random Strobe at high frequency
252 - 255 Light ON

8 8

DIMMER

0 - 255

Light output linearly increase from no-light to maximum brightness.

Dimmer blades move from totally closed to totally open in 0.02 seconds at

maximum speed.

23

MYTHOS

Continue

➔

C

hannel Mode

DMX

Value

Function

Standard Vector

9 9

S

TATIC GOBO CHANGE

0

Empty position

4 Gobo 1

8 Gobo 2
12 Gobo 3
16 Gobo 4
19 Gobo 5
23 Gobo 6
27 Gobo 7
31 Gobo 8
35 Gobo 9
38 Gobo 10
42 Gobo 11
46 Gobo 12
50 Gobo 13
54 Gobo 14
57 Gobo 15
61 Gobo 16
65 Gobo 17
69 Gobo 18

72 - 113

Continuous gobo wheel clockwise rotation at linearly variable speed
from fast (60 rpm) to slow (5 rpm)

114 - 117 Stop rotation

118 - 159

Continuous gobo wheel counter-clockwise rotation at linearly variable

speed from slow (5 rpm) to fast (60 rpm)
160 - 165 Gobo 1 shakes at variable speed from slow (24 bpm) to fast (600 bpm)
166 - 170 Gobo 2 shakes at variable speed from slow (24 bpm) to fast (600 bpm)
171 - 175 Gobo 3 shakes at variable speed from slow (24 bpm) to fast (600 bpm)
176 - 181 Gobo 4 shakes …
182 - 186 Gobo 5 shakes …
187 - 191 Gobo 6 shakes …
192 - 197 Gobo 7 shakes …
198 - 202 Gobo 8 shakes …
203 - 207 Gobo 9 shakes …
208 - 214 Gobo 10 shakes …
215 - 218 Gobo 11 shakes …
219 - 223 Gobo 12 shakes …
224 - 229 Gobo 13 shakes …
230 - 234 Gobo 14 shakes …
235 - 239 Gobo 15 shakes …
240 - 245 Gobo 16 shakes …
246 - 250 Gobo 17 shakes …
251 - 255 Gobo 18 shakes …

24

MYTHOS

C

hannel Mode

DMX

Value

Function

Standard Vector

10 10

A

NIMATION DISK INSERTION

0

- 255 Linear Animation Disk Insertion

11 11

ANIMATION DISK ROTATION

0

- 124

Continuous animation disk clockwise rotation at linearly variable speed

from fast (120 rpm) to slow (4.4 rph)
125 - 130 Stop rotation

131 - 255

Continuous animation disk counter-clockwise rotation at linearly

variable speed from slow (4.4 rph) to fast (120 rpm)

12 12

ROTATING GOBO SELECT

0 - 18 Empty position
19 - 37 Gobo 1
38 - 56 Gobo 2
57 - 74 Gobo 3
75 - 92 Gobo 4

93 - 111 Gobo 5
112 - 129 Gobo 6
130 - 150 Gobo 1 shakes at variable speed from slow (xx bpm) to fast (xx bpm)
151 - 171 Gobo 2 shakes at variable speed from slow (xx bpm) to fast (xx bpm)
172 - 192 Gobo 3 shakes …
193 - 213 Gobo 4 shakes …
214 - 234 Gobo 5 shakes …
235 - 255 Gobo 6 shakes …

13 13

GOBO ROTATION

0 - 21 Gobo indexing: 0° to 90° range
21 - 42 Gobo indexing: 90° to 180° range
42 - 63 Gobo indexing: 180° to 270° range
63 - 84 Gobo indexing: 270° to 360° range

84 - 105 Gobo indexing: 360° to 450° range

105 - 127 Gobo indexing: 450° to 540° range

128 - 190

Continuous gobo rotation at linearly variable speed from fast (180 rpm)
to slow (2.2 rph)

191 - 192 Stop rotation

193 - 255

Continuous gobo rotation at linearly variable speed from slow (2.2 rpm)
to fast (180 rpm)

14 14

FINE GOBO ROTATION

0 - 255 Fine Gobo Indexing

15 15

PRISM INSERTION

0 - 10 Prism out

11 - 132 Prism 1 into the light beam

133 - 255 Prism 2 into the light beam

25

MYTHOS

Channel Mode

D

MX

Value

F

unction

Standard Vector

16 16

PRISMS ROTATION

0 - 21 Prism indexing: 0° to 90° range
21 - 42 Prism indexing: 90° to 180° range
42 - 63 Prism indexing: 180° to 270° range
63 - 84 Prism indexing: 270° to 360° range

84 - 105 Prism indexing: 360° to 450° range

105 - 127 Prism indexing: 450° to 540° range

128 - 190

Continuous prism rotation at linearly variable speed from fast (43 rpm)
to slow (1.1 rph)

191 - 192 Stop rotation

193 - 255

Continuous prism rotation at linearly variable speed from slow
(1.1 rpm) to fast (43 rpm)

17 17

FROST

0 - 255

Frost moves linearly into the light beam

Frost blades move from no-diffusion to maximum diffusion in 0.02 seconds at
maximum speed.

18 18

ZOOM

0 - 255 Zoom linearly moves from narrow to wide beam

19 19

FOCUS

0 - 255

Focus moves linearly from far to near position.

Focus lenses move from farest to nearest position in 1.11 seconds at
maximum speed.

20 20

FOCUS FINE

0 - 255 Fine Focus positioning

21 21

BEAM MODE

0 - 127 Zoom / Autofocus mode

128 - 255 Beam Mode

ZOOM effect (channel 18) disabled if BEAM MODE is workin

g

22 22

PAN

0 - 255 Tilt movement/positioning from 0° to 540° (speed?)

23 23

FINE PAN

0 - 255 Fine Pan positioning

24 24

TILT

0 - 255 Tilt movement/positioning from 0° to 252° (speed?)

25 25

FINE TILT

0 - 255 Fine Tilt positioning

26 26

FUNCTION

0 - 11 Unused range
12 - 24 Fast Pan / Tilt speed (default)
25 - 37 Normal Pan / Tilt speed
38 - 50 Conventional Dimmer curve
51 - 62 Linear Dimmer curve (default)
63 - 75 CMY Full Range (default)
76 - 87 CMY Limited range

88 - 101 CMY shortcut ON (default)
102 - 114 CMY shortcut OFF
115 - 255 Unused range

The functions are activated/selected passing through the unused levels range
and staying in the necessary range for 5 seconds.

Continue

➔

26

MYTHOS

Channel Mode

D

MX

V

alue

F

unction

Standard Vector

27 27

RESET

0

- 25 Unused range

2

6 - 76

Zoom Reset

Zoom Reset sequence is activated passing through the unused levels range
and staying in this range for 5 seconds

77 - 127

Pan / Tilt Reset

Pan/Tilt Reset sequence passing through the unused levels range and staying
in this range for 5 seconds.

128 - 255

Complete Reset

A

ll-effects Reset sequence passing through the unused levels range and

staying in this range for 5 seconds.

28 28

LAMP CONTROL

0 - 25 Unused range

26 - 100

Lamp OFF

Lamp switch-off passing through the unused levels range and staying in this
range for 5 seconds.

101 - 255

Lamp ON

Lamp switch-on passing through the unused levels range and staying in this
range for 5 seconds.

29 29

MACRO EFFECTS

0 – 7 Macro OFF

8 – 11 Standby
12 – 15 Standby black
16 – 45 Zoom IN Faded
46 – 75 Zoom OUT Faded

76 – 105 Zoom IN OUT
106 – 135 Standby Black 1
136 – 165 Zoom IN Faded Random
166 – 195 Zoom OUT Faded Random
196 – 225 Zoom IN OUT Random

226 - 255 Standby Black 2

-

30

PAN-TILT TIME

Pan - Fine Pan - Tilt - Fine Tilt

-

31

COLOUR TIME

Cyan - Magenta –Yellow

-

32

BEAM TIME

Dimmer - Frost - Prism –Focus - Zoom

-

33

GOBO TIME

Static Gobo –Rotating Gobo

27

MYTHOS

BIT Seconds

0 Full
1 0.2
2 0.4
3 0.6
4 0.8
5 1
6 1.2
7 1.4
8 1.6
9 1.8
10 2
11 2.2
12 2.4
13 2.6
14 2.8
15 3
16 3.2
17 3.4
18 3.6
19 3.8
20 4
21 4.2
22 4.4
23 4.6
24 4.8
25 5
26 5.2
27 5.4
28 5.6
29 5.8
30 6
31 6.2
32 6.4
33 6.6
34 6.8
35 7
36 7.2
37 7.4
38 7.6
39 7.8
40 8
41 8.2
42 8.4

BIT Seconds

43 8.6
44 8.8
45 9
46 9.2
47 9.4
48 9.6
49 9.8
50 10
51 10.2
52 10.4
53 10.6
54

11

55
56

12

57
58

13

59
60
61 14
62
63

15

64
65
66 16
67
68

17

69
70
71 18
72
73

19

74
75
76 20
77
78
79 21
80
81

22

82
83
84 23
85

BIT Seconds

86

2

4

87
88
89 25
90
91

2

6

92
93
94 27
95
96

28

97
98
99 29
100
101
102 30
103
104

31

105
106
107 32
108
109

33

110
111
112 34
113
114

35

115
116
117 36
118
119

37

120
121
122 38
123
124
125 39
126
127

40

128

BIT Seconds

129
130 41
131
132

4

2

133
134
135 43
136
137

44

138
139
140 45
141
142

46

143
144
145 47
146
147

48

148
149
150 49
151
152
153 50
154
155

51

156
157
158 52
159
160

53

161
162
163 54
164
165

55

166
167
168 56
169
170

57

171

BIT Seconds

172

173 58
174
175
176 59
177
178

60

179
180
181 65
182
183

70

184
185
186 75
187
188

80

189
190
191 85
192
193

90

194
195
196 95
197
198

100

199
200
201 110
202
203
204 120
205
206

130

207
208
209 140
210
211

150

212
213
214 160
215

BIT Seconds

216

1

70

217
218
219 180
220
221

1

90

222
223
224 200
225
226
227 210
228
229

220

230
231
232 230
233
234

240

235
236
237 250
238
239

260

240
241
242 270
243
244

280

245
246
247 290
248
249

300

250
251
252

310

253
254

255

Follow cue

Data

TIME TABLE
