Clas Ohlson CD-726DAB User Manual

CD Player with DAB Radio

CD-spelare med DAB-radio
CD-spiller med DAB-radio
CD-Player mit DAB-Radio

EnglishSvenskaNorskDeutsch

Art.no Model

38-6607 CD-726DAB
38-6608 CD-726DAB

Ver. 20140910

2

CD Player with DAB Radio

Art.no 38-6607 Model CD-726DAB
38-6608 CD-726DAB

Please read theentire instruction manual before using theproduct and then save it for future
reference. We reserve theright for any errors in text or images and any necessary changes made
to technical data. If you have any questions concerning technical problems please contact our
Customer Services.

Contents

1. Safety ......................................................................................................4

1.1 Safety symbols ................................................................................................................................. 4

2. Description ..............................................................................................5

3. 230 V Mains operation ............................................................................6

4. Battery operation .....................................................................................6

5. Operating instructions .............................................................................6

5.1 Placement ......................................................................................................................................... 6

5.2 Switching on theCD player with DAB radio for thefirst time ........................................................ 6

5.3 Switching theradio on and off and selecting thefunction ............................................................. 6

6. DAB Radio ...............................................................................................7

6.1 Listening to DAB radio ..................................................................................................................... 7

6.2 Activate “Full Scanning” manually for automatic DAB station search .........................................7

6.3 Manual DAB station search .............................................................................................................7

6.4 Saving afound DAB radio station as apreset ................................................................................ 8

6.5 Browsing thesaved DAB radio stations (in DAB mode) ................................................................. 8

6.6 Removing unwanted DAB stations (Pruning) .................................................................................. 8

6.7 DAB station information ................................................................................................................... 8

7. FM radio ...................................................................................................9

7.1 Activating FM mode ......................................................................................................................... 9

7.2 Automatic search for FM stations ...................................................................................................9

7.3 Manual search for FM stations ........................................................................................................ 9

7.4 Saving afound FM radio station as apreset .................................................................................. 9

7.5 Browsing thesaved FM radio stations (in FM mode) ..................................................................... 9

7.6 FM station information ..................................................................................................................... 9

8. CD player ...............................................................................................10

8.1 CD playback ................................................................................................................................... 10

8.2 Skip function ................................................................................................................................... 10

8.3 Programmed playing of CD tracks ................................................................................................ 10

8.4 Repeat atrack on aCD .................................................................................................................. 10

9. AUX mode (external audio source) .......................................................11

10. Setting thetime and date ....................................................................11

11. Resetting theradio to factory settings ...............................................11

13. Care and maintenance ........................................................................11

14. Troubleshooting ...................................................................................12

15. Disposal ...............................................................................................12

16. Specifications ......................................................................................12

English

3

English

ENGLISH

1. Safety

• Theproduct should not be taken apart or modified. Certain non-shielded components inside
thecasing of theCD player/radio carry dangerous current. Contact with these can lead to
fire or electric shock.

• Theproduct is intended for indoor use only.

• Never subject theCD player to high or low temperatures, dust, heavy vibration, impacts,
humidity or moisture.

• Do not place theproduct where it could fall into water or other liquids. Do not place any
objects containing liquid on theproduct, e.g. flower vases or drinks.

• Do not cover theCD player. Adequate ventilation with adistance of at least 10 cm between
ventilation holes and thesurrounding area is necessary to prevent theCD player from
becoming too warm.

• Disconnect theCD player from thepower supply by unplugging it from thewall socket.

• Protect your hearing. Listening on high volume for prolonged periods can lead to permanent
hearing loss.

• Repairs and service should only be performed by qualified tradesmen, and only with original
spare parts.

• TheCD player must not be dismantled or modified in any way.

• TheCD player must not be used close to medical equipment such as in intensive care units.
Neither should it be used in close proximity to someone with animplanted pacemaker,
cardioverter-defibrillator or similar.

1.1 Safety symbols

Note thefollowing safety symbols:

Warning: Do not open thehousing. Thecasing contains hazardous
unshielded live components which if touched could start afire or give you
anelectric shock.

CLASS 1 LASER PRODUCT

CLASS1

LASER PRODUCT

Warning: Do not open thehousing. Theproduct contains invisible laser

beams which can cause eye damage. Do not look directly into thelaser
beam or look directly at it using anoptical instrument.

4

2. Description

Package contents:
CD player with DAB radio, mains lead and instruction manual.

11

English

1

10
2 9
3

8
4 7
5 6

12

13
14
15
16

17

1. Speaker

2. [ MODE, DAB+/FM ] Select certain functions for theCD player, select DAB or FM radio

3. [ PRESET/PROG ] Save stations as presets

4. [ MENU ] Press in thebutton on theleft to display themenu

5. [ SELECT ] Press in thebutton on theright to confirm

6. [ SKIP/TUNE< ] Press in thebutton on theleft to change to alower frequency or submenu

7. [ SKIP/TUNE> ] Press in thebutton on theright to change to ahigher frequency or submenu

8. [ STOP/INFO ] Stop CD playback or display information about theradio station

9. [ PLAY/PAUSE FULL SCAN ] Start playback/pause playback or start astation search in
DAB mode (Full Scan)

10. LCD display

11. CD tray

12. Handle

13. Telescopic aerial for FM radio

14. [ OFF/AUX/CD/DAB+/FM ] Function selector

- OFF

- AUX (for listening to anexternal audio source such as atelephone, MP3 player)

- CD

- DAB+/FM (for listening to theradio (DAB+ or FM)

15. [ VOLUME ] Volume control

16. AUX IN line-in for external audio source (3.5 mm)

17. Battery compartment

18. AC socket for mains lead

18

5

English

3. 230 V Mains operation

Plug thepower lead into theAC socket (18) and into anelectrical socket.

• Do not touch themains lead with wet hands.

• Disconnect thepower lead if theCD player is not be used for anextended period.

• Do not pull on themains lead when unplugging theCD player, grip theplug and pull it out of
thesocket.

4. Battery operation

1. Open thebattery compartment (17) by pressing it
down at thearrows (where “OPEN” is written).
Press and slide thebattery cover outwards in
thedirection of thearrows.

2. Insert 6×C/LR14 batteries (sold separately)
observing thepolarity markings in thebattery
compartment.

A

5. Operating instructions

5.1 Placement

TheCD player should be placed on aflat surface indoors where it is not in direct sunlight or close
to aheat source, and not in ahumid atmosphere such as in abathroom.

5.2 Switching on theCD player with DAB radio for thefirst time

1. Make sure that thefunction selector is set to OFF.

2. Completely extend thetelescopic aerial and lift it up. It is important that optimum reception is
achieved thefirst time theradio is used and scans for DAB and FM stations.

3. Connect themains lead to theAC socket (18).

4. Connect theplug to awall socket.

5. Set thefunction selector (14) to theDAB+/FM position to turn theradio on. “Welcome to
Digital Radio” will appear on thedisplay.

6. Theradio will automatically begin searching for DAB stations. “Autotune Full Scan” will appear
on thedisplay and anevent indicator will show that searching is in progress and how many
stations have been found. When thescan has finished, theradio will start playing thefirst station
found. If no DAB stations are found “No DAB Station” will appear on thedisplay.

7. All theDAB stations found will be saved in thememory, next time theradio is switch on it will
not need to perform anautomatic scan. However, amanual station search can be made by
pressing [ PLAY/PAUSE FULL SCAN ] (9) whilst in DAB mode.

5.3 Switching theradio on and off and selecting thefunction

Thefunction selector [ OFF/AUX/CD/DAB+/FM ] (14) switches theradio on/off. Thefunction
selector has four positions:

• OFF

• AUX (for listening to anexternal audio source such as atelephone, MP3 player)

• CD

• DAB+/FM (for listening to radio, DAB starts first (press [ MODE, DAB+/FM ] (2) if you wish
to change to FM (or from FM to DAB))

6

6. DAB Radio

DAB – Digital Audio Broadcasting

DAB radio is not thesame as analogue radio. In DAB mode, thesignals from several broadcasters
are combined and sent on thesame frequency. These groups of signals are called Multiplexes
and Ensembles. Each time agroup has been found, its name appears at thebottom of thedisplay.

DAB mode - secondary services

Sometimes, a “>” symbol can be seen after thename of astation. This indicates that thestation has
asecondary service. This secondary service could be in theform of asports commentary for example.

Automatic standby (after long period of inactivity)

TheCD player automatically switches to standby mode after along period of inactivity. This occurs
when theCD player is in stop mode for along time or if theDAB radio receives no signal.

To re-activate theCD player, first switch thefunction selector to OFF and then switch it back to
thedesired function, CD or DAB+/FM.

6.1 Listening to DAB radio

Activate DAB mode

1. Set thefunction selector to DAB+/FM. “Welcome to Digital Radio” will appear on thedisplay.

2. When theradio is turned on for thefirst time it automatically enters DAB mode and performs
anautoscan. During thescanning process, thewords “Full Scanning” and thenumber of
stations found will appear on thedisplay.

3. When thescan is complete, theradio starts playing thestation with thelowest frequency.

4. If no DAB stations are found “No DAB Station” will appear on thedisplay.

6.2 Activate “Full Scanning” manually for automatic DAB station search

1. Set thefunction selector to DAB+/FM. “Welcome to Digital Radio” will appear on thedisplay.

2. Press [ PLAY/PAUSE FULL SCAN ] (9) (in DAB mode) to start a “Full Scan” search.

3. “Searching” is shown on thedisplay whilst thesearch is in progress. Note: Thesearch can
take 1 or 2 minutes.

4. When stations are found they are saved automatically. To listen to thesaved stations, press
[ SKIP/TUNE< ] or [ SKIP/TUNE> ] to select astation. Press [ SELECT ] to confirm.

English

6.3 Manual DAB station search

1. Press [ MENU ] (4) to display themenu.

2. Press [ SKIP/TUNE< ] (6) or [ SKIP/TUNE> ] (7) and select Manual Tune.
Press [ SELECT ] to confirm.

3. Press [ SKIP/TUNE< ] or [ SKIP/TUNE> ] to browse theDAB channels (5A to 13F).

4. Press [ SELECT ] to confirm your choice of channel. Thechosen multiplex will then be
shown on thedisplay.

7

English

6.4 Saving afound DAB radio station as apreset

Theradio can save up to 10 different DAB radio stations as presets. DAB presets are not saved
over FM presets. Save aDAB radio station as follows (In DAB mode):

1. Tune theradio into thedesired station.

2. Push and hold [ PRESET/PROG ] (2) for 2 seconds. Thepreset station and “P#” (where # is
thepreset station number) will appear on thedisplay.

3. Press [ SKIP/TUNE< ] or [ SKIP/TUNE> ] to select which preset number thestation is to have (1–10).

4. Press [ SELECT ] to confirm.

Note: If apreviously saved station already occupies thechosen preset slot it will be replaced by
thenew one.

6.5 Browsing thesaved DAB radio stations (in DAB mode)

1. Press [ PRESET/PROG ] (3) to show thepreset station and its preset number (P#).

2. Press [ SKIP/TUNE< ] or [ SKIP/TUNE> ] to select astation.

3. Press [ SELECT ] to confirm.

Note: Theradio might become silent for amoment whilst thestations are changing.

6.6 Removing unwanted DAB stations (Pruning)

1. In DAB mode, press [ MENU ] (4).

2. Press [ SKIP/TUNE< ] or [ SKIP/TUNE> ] to select PRUNE.

3. Press [ SELECT ] to confirm.

4. “PRUNE” will appear on thedisplay, press [ SKIP/TUNE< ] or [ SKIP/TUNE> ] and select NO to
quit or YES to remove thestation in question.

5. Press [ MENU ] (4) to exit and return to normal DAB mode.

6.7 DAB station information

By pressing [ STOP/INFO ] (8) repeatedly, you can display thefollowing information:

• Frequency – Thefrequency is displayed as for example “11C 220.352MHz”.

• Audio Bite Rate – Thedisplay shows theradio mode (DAB) and thedigital audio bit rate of
thecurrent reception.

• Scrolling text – Text from theDAB station you are listening to. Theinformation can for
example include facts about themusic being played.

• Programme Type: shows which type of programme you are listening to, “Rock”, “Pop”,
“News” etc. If there is no information, thetext “Programme Type” is displayed.

• Ensemble: This is agroup of radio stations sent on thesame frequency. There are both
national and local multiplexes. Thelocal ones contain stations specific for your area.

• Signal Strength: Thesignal strength is displayed graphically by means of aslide bar.
Thestronger thesignal, thelonger thebar.

• Date: shows thecurrent date.

• Time: shows thecurrent time.

8

7. FM radio

Completely extend thetelescopic aerial and lift it up. This is important in order to get thebest
reception when theradio is scanning for FM stations.

Once theradio is switched on, it will start playing thesame programme it was set to when it was
last switched off.

7.1 Activating FM mode

1. Set thefunction selector to DAB+/FM. “Welcome to Digital Radio” will appear on thedisplay
(theradio always starts in DAB mode).

2. Press [ MODE DAB+/FM ] (2) to select FM.

3. Set thedesired volume using [ VOLUME ] (15).

7.2 Automatic search for FM stations

1. Press [ PLAY/PAUSE FULL SCAN ] (9) or hold in [ SKIP/TUNE< ] or [ SKIP/TUNE> ] for about
1 second to start anautomatic search for thenext available FM station.

2. Thesearch stops when astation with astrong signal reception has been found.

Note: Stations with weak signal reception must be tuned in manually.

7.3 Manual search for FM stations

Press [ SKIP/TUNE< ] (6) or [ SKIP/TUNE> ] (7) to browse thefrequency range.

7.4 Saving afound FM radio station as apreset

Theradio can save up to 10 different FM radio stations as presets. FM presets are not saved
over DAB presets.

FM radio stations are saved as follows:

1. Tune theradio into thedesired station.

2. Push and hold [ PRESET/PROG ] (3) for 2 seconds. Thepreset station and “P#” (where # is
thepreset station number) will appear on thedisplay.

3. Press [ SKIP/TUNE< ] (6) or [ SKIP/TUNE> ] (7) to select which preset number thestation is to have
(1–10). If there is already astation saved on preset 1, its name and frequency will be displayed,
if no station has previously been saved as preset 1, “Empty” will appear on thedisplay.

4. Press [ SELECT ] to confirm.

5. “Preset # stored” will appear in thedisplay once thestation is saved.

Note: If apreviously saved station already occupies thechosen preset slot it will be replaced by
thenew one.

English

7.5 Browsing thesaved FM radio stations (in FM mode)

1. Press [ PRESET/PROG ] (3), thecurrent station and its preset number (#) will be displayed.

2. Press [ SKIP/TUNE< ] (6) or [ SKIP/TUNE> ] (7) to select one of thepreset stations (1–10).

3. Press [ SELECT ] to confirm that you want to listen to that station.

7.6 FM station information

By pressing [ STOP/INFO ] (8) repeatedly, you can display thefollowing information:

1. Audio Type: shows whether thesignal is mono or stereo.

2. Scrolling text: Text from theFM station you are listening to. Theinformation can for example
include facts about themusic being played.

9

English

3. Programme Type: shows which type of programme you are listening to, “Rock”, “Pop”,
“News” etc. If there is no information, thetext “Programme Type” is displayed.

4. Signal Strength: Thesignal strength is displayed graphically by means of aslide bar.
Thestronger thesignal, thelonger thebar.

5. Date: shows thecurrent date.

6. Time: shows thecurrent time.

7. Frequency: displays thefrequency of thecurrent station.

8. CD player

8.1 CD playback

1. Set thefunction selector [ OFF/AUX/CD/DAB+/FM ] (14) to CD.

2. Open theCD door by carefully lifting it.

3. Place aCD onto thespindle in themiddle of theCD compartment.

4. Shut thedoor by carefully pushing it down.

5. TheCD player will start reading thedisc and display thetotal number of tracks.

6. Press [ PLAY/PAUSE FULL SCAN ] (9) to start playing theCD.

7. Press [ PLAY/PAUSE FULL SCAN ] (9) again if you wish to pause theplayback.
Press thesame button again to resume playback.

8. Press [ STOP/INFO ] (8) to stop playback or set thefunction selector
[ OFF/AUX/CD/DAB+/FM ] (14) to adifferent position than CD to stop theplayback.

8.2 Skip function

1. Press [ SKIP/TUNE> ] (7) once to skip to thenext track.

2. Press [ SKIP/TUNE< ] (6) once to return to thebeginning of thecurrent track.

3. Press [ SKIP/TUNE< ] (6) repeatedly to skip back to previous tracks.

8.3 Programmed playing of CD tracks

Atotal of 20 tracks can be programmed.

1. Press [ STOP/INFO ] (8). Press [ PRESET/PROG ]. “PROG” will begin flashing on thedisplay.

2. Press [ SKIP/TUNE< ] (6) or [ SKIP/TUNE> ] (7) to select which track is to be saved.

3. Press [ PRESET/PROG ] to store thedesired track into theplay list memory. “PROG02”
appears on thedisplay.

4. Repeat steps 2–3 to add more tracks to theplay list.

5. Press [ PLAY/PAUSE FULL SCAN ] once you have finished programming your tracks onto your
play list. Thetracks on theCD will now be played in theorder programmed on your play list.

6. Press [ STOP/INFO ] (8) to stop playback.

7. To clear theprogrammed play list, either press [ STOP/INFO ] (8) twice, open theCD door,
set thefunction selector to adifferent position or switch theCD player off.

8.4 Repeat atrack on aCD

1. During playing of aCD, press [ MODE, DAB+/FM ] (2) once to repeat thetrack that is playing.
“REP 1” is shown on thedisplay.

2. Press [ MODE, DAB+/FM ] asecond time to repeat all thetracks on theCD. “REP ALL” is
shown on thedisplay.

3. Press [ MODE, DAB+/FM ] (2) athird time to begin playing thetracks in random order.
“RAND” is shown on thedisplay.

4. Press [ MODE, DAB+/FM ] (2) afourth time to exit therepeat playback mode. No text is
shown on thedisplay when therepeat function is shut off.

10

9. AUX mode (external audio source)

1. Set thefunction selector [ OFF/AUX/CD/DAB+/FM ] (14) to AUX.

2. Connect anexternal audio source to AUX IN (16) using asuitable cable with a3.5 mm stereo plug.

3. Playback is controlled from theexternal audio source. Adjust thevolume on both theexternal
audio device and theradio to achieve thebest sound quality.

4. Set thefunction selector [ OFF/AUX/CD/DAB+/FM ] (14) in adifferent position than AUX to
stop listening to theexternal audio source.

10. Setting thetime and date

1. While in DAB or FM mode: Press [ MENU ] (4) to display themenu.

2. Press [ SKIP/TUNE< ] (6) or [ SKIP/TUNE> ] (7) and Set Time/Date. Press [ SELECT ] to confirm.

3. “Set 12/24 hour” will appear on thedisplay. Press [ SELECT ].

4. Select 12- or 24-hour clock (“Set 12 hour” or “Set 24 hour”) using [ SKIP/TUNE< ] or
[ SKIP/TUNE> ]. Press [ SELECT ] to confirm.

5. Press [ SKIP/TUNE< ] or [ SKIP/TUNE> ] to select Set Time/Date and then press [ SELECT ].

6. “Set time 00:00” is displayed (hours flashing), adjust to thecorrect time using [ SKIP/TUNE< ]
or [ SKIP/TUNE> ]. Press [ SELECT ] to confirm. Theminutes will now be flashing, set them in
thesame way as thehours. Press [ SELECT ] to confirm.

7. “Set Date” will flash, set thedate thesame way as you set thetime. Press [ SELECT ] to confirm.
“Time saved” will appear on thedisplay when thetime and date have been set.
Note: All thetime and date settings must be made before thesettings are saved automatically.

8. Select thedate format by pressing [ SKIP/TUNE< ] (6) or [ SKIP/TUNE> ] (7) select Set Time/Date
and then Set date format. Press [ SELECT ] to confirm. Choose either DD–MM–YYYY or

MM–DD–YYYY by pressing [ SKIP/TUNE< ] or [ SKIP/TUNE> ]. Press [ SELECT ] to confirm.

11. Resetting theradio to factory settings

1. In DAB+/FM mode, hold in [ MODE DAB+/FM ] until “Press ENTER key to reset” is displayed.

2. Press [ SELECT ] (5) to start thereset process. “Press ENTER key OK” is displayed.

3. Once theunit has reset, theradio starts playing in DAB mode and performs an “Auto scan”.

Note: All preset stations will also be lost if theradio is reset, as explained below.

English

13. Care and maintenance

Clean theproduct using asoft, dry cloth. Never use solvents or abrasive cleaning agents.

11

English

14. Troubleshooting

Poor radio reception

• Extend theaerial completely.

• Move theradio. Remember to scan for stations again after moving.

• Check that theradio is not close to any sources of interference such as microwaves,
fluorescent lights, etc.

No sound

• Check thevolume setting.

• Check that thepower switch is not set to OFF and that themains lead is connected correctly.

• Try changing to another station.

Thecontrols are not working

• Check that thepower switch is not set to OFF and that themains lead is connected correctly.

• Turn theunit off, unplug themains lead, wait about 1 minute. Plug themains lead back in.

• Reset theradio to its factory settings, see Resetting theradio to factory settings.

15. Disposal

This product should be disposed of in accordance with local regulations.
If you are unsure how to proceed, contact your local council.

16. Specifications

Mains voltage 230 V AC, 50Hz
Frequency range DAB+/DAB 174–240 MHz

FM 87.5–108 MHz
AUX socket 3.5 mm
Battery type 6×C/LR14 (sold separately)
Size 25×13.5×21.5 cm

12

CD-spelare med DAB-radio

Art.nr 38-6607 Modell CD-726DAB
38-6608 CD-726DAB

Läs igenom hela bruksanvisningen före användning och spara den sedan för framtida bruk.
Vi reserverar oss för ev. text- och bildfel samt ändringar av tekniska data.
Vid tekniska problem eller andra frågor, kontakta vår kundtjänst.

Innehållsförteckning

1. Säkerhet ................................................................................................14

1.1 Säkerhetssymboler .........................................................................................................................14

2. Beskrivning ............................................................................................15

3. Nätanslutning 230 V ..............................................................................16

4. Batteridrift ..............................................................................................16

5. Användning ............................................................................................16

5.1 Placering ......................................................................................................................................... 16

5.2 Slå på CD-spelaren med DAB-radio första gången ...................................................................... 16

5.3 Slå på och stäng av radion och välj funktion ................................................................................ 16

6. DAB-radio ..............................................................................................17

6.1 Lyssna på DAB-radio .....................................................................................................................17

6.2 Aktivera ”Full Scanning” manuellt för automatisk sökning efter DAB-radiostationer ................ 17

6.3 Manuell sökning efter DAB-radiostationer .................................................................................... 17

6.4 Spara en hittad DAB-radiostation som snabbval ......................................................................... 18

6.5 Stega mellan de hittade DAB-radiostationerna (i DAB-läge) ....................................................... 18

6.6 Rensa bort oönskade DAB-radiostationer (PRUNE) (i DAB-läge) ................................................ 18

6.7. DAB-displayinformation ................................................................................................................ 18

7. FM-radio ................................................................................................19

7.1 Aktivera FM-läge ............................................................................................................................ 19

7.2 Automatisk sökning av nästa FM-radiostation (i FM-läge) ...........................................................19

7.3 Manuell sökning av FM-radiostation (i FM-läge) ..........................................................................19

7.4 Spara en hittad FM-radiostation som snabbval ...........................................................................19

7.5 Stega mellan de hittade FM-radiostationerna (i FM-läge) ............................................................ 19

7.6 FM-displayinformation ................................................................................................................... 19

8. CD-spelare .............................................................................................20

8.1 Spela upp en CD-skiva...................................................................................................................20

8.2 Gå till början eller till nästa spår på skivan ...................................................................................20

8.3 Programmerad avspelning av en CD-skiva ................................................................................... 20

8.4 Repetera ett spår ............................................................................................................................ 20

9. Använd AUX-läge (extern ljudkälla) ......................................................21

10. Inställning av tid och datum ................................................................21

11. Reset – återställa radion till fabriksinställningarna ............................21

12. Skötsel och underhåll ..........................................................................21

13. Felsökning ...........................................................................................22

14. Avfallshantering ...................................................................................22

15. Specifikationer .....................................................................................22

Svenska

13

ENGLISH

1. Säkerhet

• CD-spelaren får inte demonteras eller ändras. Farlig spänning finns oskyddad på komponenter

• CD-spelaren är endast avsedd för inomhusbruk.

• Utsätt aldrig CD-spelaren för höga eller låga temperaturer, dammig miljö, starka vibrationer,

• Placera inte CD-spelaren så att den kan falla ner i vatten eller annan vätska. Ställ inte några

• Täck inte över CD-spelaren. Tillräcklig ventilation, med ett minsta avstånd på ca 10 cm

• Bryt strömmen till CD-spelaren genom att dra ur dess stickpropp ur vägguttaget.

Svenska

• Skydda din hörsel. Lyssning med hög volym under lång tid kan leda till bestående

• Låt behörig personal utföra service och reparationer och endast med originalreservdelar.

• CD-spelaren får inte demonteras eller modifieras på något sätt.

• CD-spelaren får inte användas i närheten av medicinsk utrustning i intensivvård etc. Den får

1.1 Säkerhetssymboler

Lägg märke till dessa säkerhetssymboler:

inuti CD-spelarens hölje. Kontakt med dessa kan leda till brand eller ge elektriska stötar.

stötar, fukt eller väta.

föremål som innehåller vätska på CD-spelaren, t.ex. en blomvas eller dryck.

mellan ventilationshålen och omgivande ytor, är nödvändig för att förhindra att CD-spelaren
blir för varm.

hörselskador.

inte heller användas i närheten av någon som har en inopererad pacemaker eller liknande.

Varning! Öppna inte höljet! Farlig spänning finns oskyddad på
komponenter inuti produktens hölje, kontakt med dessa kan leda
till brand eller ge elektriska stötar.

LASERAPPARAT KLASS 1

CLASS1

LASER PRODUCT

Varning! Öppna inte höljet! Osynlig laserstrålning som kan orsaka

ögonskador. Rikta inte blicken in mot strålen och titta inte direkt
på den genom optiska instrument.

14
