Clarkson
™
Tiered Spare Parts Kits
OEM parts to extend the exceptional performance life of your Clarkson Knife Gate Valves
Your Challenge
Is your valve maintenance event ever delayed or extended because you
don’t have the replacement parts on hand? Or perhaps you’re looking
to better identify, manage and protect the spares inventory for your
critical valve assets?
Your Opportunity
Emerson’s genuine OEM-quality spare parts kits for Clarkson Knife Gate Valves
solve these issues. Emerson’s spare part kits are available under a single part
number and packaged for protection, with all components required for a
standard maintenance event. That means you can:
Simplify your spare parts ordering
Improve inventory management
Ensure all components are available when needed
Receive rapid delivery with locally stocked kits
Prepare for Your Maintenance Event
Clarkson spare parts kits are available with
tiered options to match your maintenance
event plan with the genuine OEM parts you
need. Kits are available with:
• Sleeves
• Secondary seal
• Retainer anges
• Secondary seal retainer
• Fasteners and hardware
• Gate
Frequently Asked Questions
For which products will kits be
available?
Clarkson Tiered Spare Parts Kits will
initially be available for Model KGD and
KGA+ Knife Gate Valves in sizes NPS 2 - 24
(DN 50 - 600).
Can I still buy individual components?
Components that are part of a kit will only
be available for purchase as a complete
kit. Non-kitted critical components
are available; please contact your local
Emerson representative for support
options.
Can I still buy spare parts with special
materials?
Special material sleeves and gates are still
available for purchase separately.
What if I do not need all parts of the kit?
Emerson recommends changing all
tiered kit parts at the same time as good
maintenance practice. Many of the
components interact, wear at the same
rates, and will impact the service life of
other parts.
Will prices change?
No. Kit list prices are equal to the sum of
their included components’ current prices
and any existing discount agreements will
be honoured.
© 2020 Emerson Electric Co. All rights reserved.
Visit Emerson.com for more information.
Clarkson™ Tiered Spare Parts Kits
Why OEM Quality Matters
Your choice of Knife Gate Valve replacement parts can be the difference between a productive, protable
process, and a decommissioned unit. Don’t risk the safety of your people, your equipment or the
environment with inferior imitation parts – when you can get the right parts, right now.
Achieve extended valve life with optimized sleeve durometer
that allows sufcient elastomer memory for ideal compression
on the gate while ensuring 100% man-safe, positive isolation.
Run your processes for longer with sleeves supported by a fully
encapsulated stiffener ring that resists heavy shearing forces
during actuation, while remaining protected from corrosion.
Rest assured of the highest quality every time you see the
Clarkson name. Each sleeve is rigorously tested by our elastomer
experts to ensure identical, industry-leading performance.
Bank on longer performance with patented compound
formulations that maximize resistance to compression-set, tear,
wear, rolling, bursting and chemical attack.
Tiered Spare Parts Kits
Emerson’s Clarkson Spare Parts Kits are tiered to improve valve
service life while optimizing your spare parts inventory. Kits are
tiered in order of expected frequency of use and should cover
the vast majority of your standard maintenance requirements.
Clarkson kits are composed of parts that should always be fully
consumed, as one component’s condition will affect the wear
and service life of other components.
Tier Component Qty. Item
Sleeves*
2 A
1
Secondary Seal
1 B
Gate
G
Secondary seal
D
bolts & washers
Secondary seal
C
retainer
B
Secondary seal
Sleeve
A
Learn more about
the benets of
genuine Clarkson
sleeves over low
cost imitators.
Download
F
Retainer ange hardware
Retainer ange
E
Secondary Seal Retainer
Secondary Seal Retainer Hardware
1 C
1 set D
2
Retainer Flanges
Retainer Flange Hardware
3
Gate°
Contact your local Emerson representative to discuss your maintenance interval and recommended tiered kits strategy.
If you want to ensure OEM quality repairs, click here to learn more about Emerson’s Lifecycle Services.
© 2020 Emerson Electric Co. All rights reserved.
Neither Emerson, Emerson Automation Solutions, nor any of their afliated entities assumes responsibility for the selection, use or maintenance of
any product. Responsibility for proper selection, use, and maintenance of any product remains solely with the purchaser and end user.
Clarkson is a mark owned by one of the companies in the Emerson Automation Solutions business unit of Emerson Electric Co. Emerson Automation Solutions, Emerson and the Emerson logo are trademarks and service marks of Emerson Electric Co. All other marks are the property of their
respective owners.
The contents of this publication are presented for informational purposes only, and while every effort has been made to ensure their accuracy,
they are not to be construed as warranties or guarantees, express or implied, regarding the products or services described herein or their use or
applicability. All sales are governed by our terms and conditions, which are available upon request. We reserve the right to modify or improve the
designs or specications of such products at any time without notice.
2 E
2 sets F
1 G
*Available in Natural Rubber and EPDM
° Available in 316 Stainless Steel
Other materials available as individual components
