Page 1
SAFETY PACK
MODEL NO: SPK1
PART NO: 8133820
USER INSTRUCTIONS
ORIGINAL INSTRUCTIONS DL0722 - ISS 3
Page 2
INTRODUCTION
Thank you for purchasing this CLARKE product. Before attempting to use this
product, please read these instructions carefully. In doing so you will ensure
your safety and you can look forward to your purchase giving you long and
satisfactory service.
The SPK1 Safety Pack consists of the following:
•Ear Defenders
• Safety Goggles
•Dust Mask
GUARANTEE
This product is guaranteed against faulty manufacture for a period of 12
months from the date of purchase. Please keep your receipt which will be
required as proof of purchase.
This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for its intended purpose. Faulty goods
should be returned to their place of purchase, no product can be returned to
us without prior permission.
This guarantee does not effect your statutory rights.
SPECIFICATIONS
Ear Defenders
Weight 156 g
Product dimensions 230 x 80 x 200 mm (L x D x W)
Dust mask
Product dimensions 140 x 64 x 130mm (L x D x W)
Goggles
Weight 72 g
Product dimensions 85 x 80 x 160 mm (L x D x W)
MATERIALS DECLARATION
No parts of this product is made of materials that are known to cause skin
irritation. However, materials that come into contact with the skin can cause
allergic reactions to certain susceptible individuals.
2
Parts & Service: 020 8988 7400 / E-mail: [email protected] or [email protected]
Page 3
THE EAR DEFENDERS
APPLICATION AND USE
Always ensure that the ear defenders are correctly fitted, adjusted and
maintained.
Extend the headband and place the cups over the ears with the headband
passing over the head. Settle into position while adjusting the height of the ear
cups until comfortable with the headband providing support.
• The ear cushions should be a snug fit against the head.
Adjust the pressure on the head by bending of the headband and ensure an
effective noise seal.
Wear the ear defenders throughout all periods of exposure to noise.
ATTENUATION VALUES
SNR: 25dB H: 28dB M: 22dB L: 16dB
Frequency (Hz) 125 250 500 1000 2000 4000 8000
Mean Attenuation dB 15.7 14.9 22.5 32 29.5 32.8 32.8
Standard Deviation dB 3.6 2.4 3.1 2.5 3.3 3.4 3.7
APV dB 12.1 12.5 19.4 29.5 26.2 29.4 29.1
CLEANING, MAINTENANCE AND STORAGE
Clean only with warm soapy water as this product may be adversely affected
by certain chemical substances such as organic solvents or alcohol.
Occasionally disinfect any part of the ear defenders in contact with the
wearer if there are multiple users. Use a product not harmful to the wearer.
Ear defenders should be regularly inspected for condition as the protection
afforded may eventually become impaired. The ear cushions may deteriorate
with use and should be examined at frequent intervals for cracking.
In order to avoid the possibility of deterioration in the materials quality and
performance, we suggest replacing the ear defenders after 2-3 years of
regular use.
When not in use, it is recommended to store this product in a clean, dry
polythene bag.
3
Parts & Service: 020 8988 7400 / E-mail: [email protected] or [email protected]
Page 4
THE DUST MASK
APPLICATION
Before using the mask, check and confirm that the mask is suitable for the
intend use, based on the following criteria.
Single use masks are classified according to one of three categories, FFP1,
FFP2 and FFP3. Before preceding, please check the category to which the
mask belongs as indicated either on the packaging or on the mask and
confirm that it is suitable for the intended task.
• FFP1:- Protection against non-toxic solid and liquid aerosols (e.g. oil
mists) in concentrations up to 4.5XMAC/OEL/TLV or 4xAPF.
• FFP2:-Protection against non-toxic and low to average toxicity solid
and liquid aerosols in concentrations up to 12XMAC/OEL/TLV or
10XAPF.
• FFP3:-Protection against non-toxic and low to average toxicity and
high toxicity solid and liquid aerosols (e.g. oil mists) in concentrations
up to 50XMAC/OEL/TLV or 20XAPF.
MAC = Maximum Admissible Concentration
OEL = Occupational Exposure Limit
TLV = Threshold Limit Value
APF = Assigned Protection Factor
SAFETY WARNINGS
1. Failure to follow all instructions and limitations on the use of the mask could
reduce its effectiveness with resultant health risks.
2. A correctly selected mask is essential to protect your heath and an
occupational safety professional may be consulted to determine the
suitability for your intended purpose.
3. This mask should only be used in adequately ventilated areas containing
sufficient oxygen for the needs of the user.
4. Do not use when the concentration of contaminants are immediately
dangerous to health and do not use in explosive atmospheres.
5. Leave the work are immediately and seek fresh air if breathing becomes
difficult or if dizziness or other form of distress occurs.
6. Beards or other facial hair may reduce the effectiveness of the mask.
7. Never alter or modify this mask in any way.
4
Parts & Service: 020 8988 7400 / E-mail: [email protected] or [email protected]
Page 5
8. Discard and replace this mask at the end of the working shift. This is a single
use mask with no scope for maintenance.
9. Keep the mask stored in its packaging until ready for use.
10. Store and transport the mask in its original packaging and kept in cool dry
environment until ready for use. Protect it against dust, chemicals, moisture,
UV light or accidental damage.
11. The headstrap is made from a rubber material which could cause an
allergic reaction in certain individuals. Discard the mask if irritation should
occur.
12. Before using the mask always check for visible damage and any “Use by”
date displayed. Damaged masks or any that are soiled on the inner side
should not be used.
FITTING INSTRUCTIONS
1. Hold the mask in one hand with the nosepiece at your fingertips. Allow the
headbands to hang freely below the hand.
2. Cup the mask firmly against your face with the nosepiece on the bridge of
your nose.
3. Stretch and pull the lower headband over the head and position below
the ears. Stretch and pull the top headband on the back of your head
above your ears.
4. Press soft nosepiece to conform snuggly around the nose.
5. To test fit the mask, cup both hands over the respirator and exhale
vigorously. If air flows around your nose, tighten the nosepiece. If air leaks
around the edges, reposition the headband for a better fit.
6. Change the mask immediately if breathing becomes difficult or the mask
becomes damaged or distorted or if a proper face fit cannot be
maintained.
Careful observation of these instructions is important for safe use.
5
Parts & Service: 020 8988 7400 / E-mail: [email protected] or [email protected]
Page 6
THE SAFETY GOGGLES
APPLICATION
These goggles are designed for eye protection against moderate impact
hazards but are not unbreakable and do not provide unlimited eye
protection. They are designed to protect the user against eye injuries through
impact of flying particles or droplets.
The goggles have been designed for your personal safety and must be worn
for the whole duration of exposure to hazards. You should leave the work area
if dizziness or eye irritation occurs or if the goggles become damaged.
The goggles can be worn over normal spectacles and the strap can be
adjusted for a secure, comfortable fit.
SAFETY WARNINGS
1. Do no modify or alter the goggles in any way.
2. Pitted or scratched lenses reduce vision, seriously reduce protection and
should be replaced immediately.
3. Materials that come into contact with the skin can cause allergic reactions
to certain susceptible individuals.
4. If in doubt, check with supervisory personnel to ensure you have the
correct level of protection relative to working conditions. If necessary
consult relevant European Standards.
CLEANING, MAINTENANCE AND STORAGE
1. Do not use abrasive materials. Always clean with warm soapy water, rinse
and dry with a soft cloth. Parts that come into contact with the users skin
should be regularly disinfected.
2. It is recommended to store in a clean, dry polythene bag when not in use.
6
Parts & Service: 020 8988 7400 / E-mail: [email protected] or [email protected]
Page 7
DECLARATION OF CONFORMITY
7
Parts & Service: 020 8988 7400 / E-mail: [email protected] or [email protected]
