Clarke PS 75, 7230160 User guide

ENGINE DRIVEN SEMI TRASH 3” PUMP

MODEL NO: PS75

PART NO: 7230160

FULL PARTS LISTS AND DIAGRAMS

LS0817 - ISS 1

EXPLODED DIAGRAMS AND PARTS LIST

FIG 1 - HEAD SUBASSEMBLY, CYLINDER / PLUG,SPARK

NUMBER DESCRIPTION PART NUMBER

4 GASKET, CYLINDER HEAD ZG12131Z530320

5 CYLINDER HEAD COVER SUBASSEMBLY, ZG12410Z440210

6 CYLINDER HEAD COVER GASKET, ZG12004Z440210

7 BREATHER TUBE, ZG17004Z440110

8 BOLT ZG90001061201

9 STUD ZG90204Z010310

10 STUD ZG90203Z010110

11 PIN ZG90502111400

12 CYLINDER HEAD BOLT, ZG12003Z010110

13 SPARK PLUG, ZG30010Z010210

14 CYLINDER HEAD SUBASSEMBLY ZG12140Z440420

2

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

FIG 2 - CRANKCASE. / GEAR ASSEMBLY, GOVERNOR

NUMBER DESCRIPTION PART NUMBER

1 CRANKCASE SUBASSEMBLY. ZG11310Z530410

2 ENGINE OIL SENSOR, ZG37060Z010110

3 GOVERNOR GEAR ASSEMBLY, ZG16400Z010110

7 GOVERNOR ARM, ZG16061Z010110

8 DRAIN PLUG BOLT, ZG11007Z010110

9 WASHER ZG90408Z010110

12 BEARING ZG905470205CL

13 OIL SEAL, ZG90682Z300110

16 WASHER ZG90408Z010210

17 PIN ZG90501Z010110

18 BOLT ZG90001061401

3

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

FIG 3 - COVER SUBASSEMBLY, CRANKCASE

NUMBER DESCRIPTION PART NUMBER

1 CRANKCASE COVER, ZG11411Z440210

2 BEARING ZG905470205CL

3 OIL SEAL, ZG90682Z300110

4 CRANKCASE GASKET, ZG11001Z440110

5 PIN ZG90502081200

6 OIL DIPSTICK SUBASSEMBLY, ZG15010Z010120

8 ENGINE OIL PLUG SUBASSEMBLY, ZG15030Z010120

9 BOLT ZG90001083201

4

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

FIG 4 - VALVE TRAIN / CAMSHAFT SUBASSEMBLY

NUMBER DESCRIPTION PART NUMBER

1 CAMSHAFT ASSEMBLY. ZG14200Z530110

3 EXHAUST VALVE, ZG12121Z010120

4 INTAKE VALVE, ZG12111Z010110

5 VALVE SPRING SEAT, ZG12112Z010110

6 EXHAUST VALVE RETAINER ZG12107Z010110

7 VALVE R0TATOR, ZG12104Z010110

8 SEAL GUIDE, ZG12101Z020110

9 VALVE TAPPET, ZG14081Z040110

10 VALVE LIFTER, ZG14071Z440110

11 LIFTER STOPPER PLATE SUBASSEMBLY, ZG14090Z010110

12 VALVE ADJUSTING BOLT, ZG14313Z010110

13 VALVE ROCKER, ZG14311Z010110

14 VALVE ADJUSTING NUT? ZG14314Z010110

15 VALVE LOCK NUT, ZG14312Z010110

16 SPRING, VALVE ZG12103Z010110

5

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

FIG 5 - OIL RING SET / CRANKSHAFT CONNETING ROD

NUMBER DESCRIPTION PART NUMBER

1 PISTON PIN CLIP, ZG13122Z010110

2 PISTON ZG13111Z140220

3 PISTON PIN, ZG13121Z010110

4 CONNECTING ROD, ZG13010Z440210

6 THE FIRST RING, ZG13201Z140210

7 THE SECOND RING, ZG13202Z140210

8 OIL RING SET, ZG13210Z140220

FIG 6 - CRANKSHAFT CONNETING ROD

NUMBER DESCRIPTION PART NUMBER

1 CRANKSHAFT ASSEMBLY ZG13300Z530210

6

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

FIG 7 - RECOIL STARTER

NUMBER DESCRIPTION PART NUMBER

1 RECOIL STARTER ASSEMBLY, ZG28200Z440110

2 BOLT ZG90001060803

3 RECOIL STARTER REEL END CAP ZG90722Z300110

7

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

FIG 8 - SHROUD / LOWER SHIELD

NUMBER DESCRIPTION PART NUMBER

1 SHROUD ZG28110Z010410

2 CYLINDER BODY SHROUD, ZG19304Z010110

3 LOWER SHIELD, ZG19340Z010120

4 OIL PROTECTOR, ZG37050Z010210

5 SWITCH SUBASSEMBLY, STOP ENGINE ZG35540Z060120

6 BOLT ZG90001061001

7 BOLT ZG90001061001

8 COLLAR ZG90740Z010110

9 BOLT ZG90001061601

10 BOLT ZG90001061201

8

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

FIG 9 - CARBURETOR ASSEMBLY

NUMBER DESCRIPTION PART NUMBER

1 CARBURETOR ASSEMBLY. ZG16100Z530410

2 AIR CLEANER GASKET, ZG17001Z010210

3 CARBURETOR GASKET, ZG16001Z010110

4 CARBURETOR INSULATOR PLATE, ZG16003Z010110

5 CARBURETOR INSULATOR GASKET, ZG16002Z050110

9

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

FIG 10 - AIR CLEANER

NUMBER DESCRIPTION PART NUMBER

1 NUT ZG903050600

2 AIR CLEANER, ZG17100Z440220

FIG 11 - FLYWHEEL / IMPELLER / STARTER PULLEY / IGNITION COIL

NUMBER DESCRIPTION PART NUMBER

1 FLYWHEEL NUT, ZG13501Z010110

10

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

2 STARTER PULLEY, ZG28002Z260210

3 IMPELLER ZG19352Z440110

4 FLYWHEEL SUBASSEMBLY ZG13510Z440110

7 BOLT ZG90001062501

9 IGNITION COIL ZG30400Z300110

FIG 12 - MUFFLER ASSEMBLY

NUMBER DESCRIPTION PART NUMBER

1 EXHAUST OUTLET GASKET, ZG18001Z440110

2 NUT ZG90303080031

3 MUFFLER ASSEMBLY ZG18100Z442310H699

11

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

FIG 13 - FUEL TANK ASSEMBLY

NUMBER DESCRIPTION PART NUMBER

1 FUEL TANK, ZG16620Z440510

2 FUEL STRAINER? ZG16652Z010710

3 FUEL TANK COVER, ZG16730Z440320

4 FUEL TANK OIL OUTLET SUBASSEMBLY, ZG16680Z010110

5 CLAMP ZG90685Z030220

6 TUBE, FUEL ZG90686Z010710

7 BOLT ZG90001063001

8 NUT ZG90305060031

9 RUBBER JACKET, ZG30431Z010110

10 ZG16804Z440210

11 CLAMP ZG90685Z030410

12 ZG15150Z010510

12

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

FIG 14 - THROTTLE CONTROL ASSEMBLY

NUMBER DESCRIPTION PART NUMBER

1 THROTTLE CONTROL ASSEMBLY, ZG16520Z010420

11 BOLT ZG90001061001

12 GOVERNOR SPRING, ZG16063Z050120

13 GOVERNEOR ROD, ZG16062Z010110

14 THROTTLE VALVE RETURNING

ZG16012Z010110

SPRING,

15 GOVERNOR SUPPORT BOLT, ZG16072Z010110

16 NUT ZG90305060031

17 GOVERNOR SUPPORT

16070-Z010110-GMQGZ80-45-30

SUBASSEMBLY,

13

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

FIG 15 - WATER PUMP ASSEMBLY

NUMBER DESCRIPTION PART NUMBER

1 HOSE HOOP ASSEMBLY, ZGGMQGZ804525F6801

2 FILTER COVER, ZGGMQGZ804525F6802

3 FILTER ZGGMQGZ804525F6803

4 BOLT ZG90001082501F6804

5 WASHER ZGGMQGZ804525F6805

6 WASHER ZG90408080001F6806

10 WATER INLET, ZGGMQGZ804525F6810

11 INLET WATER GASKET? ZGGMQGZ804525F6811

12 THREAD PLUG, ZGGMQGZ804525F6812

13 SCREW PLUG WASHER, ZGGMQGZ804525F6813

14 WATER OUTLET ZGGMQGZ804525F6814

15 OUTLET GASKET ZGGMQGZ804525F6815

16 PUMP BODY ZGGMQGZ804525F6816

17 WHORL CASE SEALING RING ZGGMQGZ804525F6817

18 WHORL CASE, ZGGMQGZ804525F6818

19 BOLT ZGGMQGZ804525F6819

20 WASHER ZGGMQGZ804525F6820

21 WATER PUMP IMPELLER, ZGGMQGZ804525F6821

22 KEY ZGGMQGZ804525F6822

23 WATER PUMP JOINT CUSHION, ZGGMQGZ804525F6823

14

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

24 IMPELLER SEAL ZGGMQGZ804525F6824

25 PORCELAIN SEAL, ZGGMQGZ804525F6825

26 MECHANISM SEAL ASSEMBLY, ZGGMQGZ804525F6826

27 WATER PUMP JOINT, ZGGMQGZ804525F6827

28 WASHER ZGGMQGZ804525F6828

29 BOLT ZGGMQGZ804525F6829

30 WATER PUMP ASSEMBLY, ZGGMQGZ804525F6830

FIG 16 - ENGINE FRAME ASSEMBLY

NUMBER DESCRIPTION PART NUMBER

1 ENGINE FRAME ASSEMBLY, ZG51100V010110H700

2 DECORATIVE FRAME ZG210GM720423-0002

3 ENGINE FRAME SHOCK

ZG51014HY450110GMQGZ804525

ABSORPTION SEAT,

4 BOLT ZG90001061201

5 BOLT ZG90001085001

6 NUT ZG90305060031

7 NUT ZG90327080031

15

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
