Clarke PHS 8B, 3402268 User guide

8LITRE HAND SPRAYER

MODEL NO: PHS8B

PART NO: 3402268

USER INSTRUCTIONS

ORIGINAL INSTRUCTIONS GC0217

INTRODUCTION

Thank you for purchasing this CLARKE Sprayer, designed for use with
insecticides or other water-based products only.

Before attempting to use this product, please read this manual thoroughly and
follow the instructions carefully. In doing so you will ensure the safety of yourself
and that of others around you, and you can look forward to your purchase
giving you long and satisfactory service.

GUARANTEE

This product is guaranteed against faulty manufacture for a period of 12
months from the date of purchase. Please keep your receipt which will be
required as proof of purchase.

This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for the purpose for which it was
intended.

Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission. This guarantee does not effect your
statutory rights.

GENERAL SAFETY PRECAUTIONS

1. Always thoroughly familiarise yourself with this product & its operation, and
always read and understand the instructions and warnings in this manual
before use.

2. Never use this sprayer to store or spray flammable solvent-based
chemicals.

3. Empty the contents if the sprayer is not to be used for long periods.

4. If insecticide is being sprayed, always wear a protective mask and gloves
to protect the skin and face. Never spray chemical products facing into
the wind.

5. Never spray pesticide in the direction of other people, animals or
foodstuffs.

6. Never use the sprayer for handling hot liquids and avoid operating in
excessively hot environments.

7. Always comply with any applicable insecticide manufacturers safety
instructions/directives before use.

8. Stop using the sprayer if the container or hose is found to be damaged.

2

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

OVERVIEW

SPECIFICATION

Dimensions D x H 184 x 550 mm

Weight 1.25 kg

Vol u me 8 L i tr e s

Lance Length 515 mm

Hose Length 1.19 m

Piston Material Metal/polymer

Please note that the details and specifications contained herein, are correct
at the time of going to print. However, CLARKE International reserve the right
to change specifications at any time without prior notice.

3

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

ASSEMBLY

1. If not already fitted, clip the
shoulder strap to the attachment
points. Adjust the strap length as
required using the buckles.

2. Screw the lance assembly onto
the trigger/handle assembly.

• The other end of the hose

should already be connected
to the container.

3. Make sure that all connections
are fully hand tightened to
prevent leaks and loss of pressure.

Note: Do not overtighten the
components. Leave a gap as shown.

4

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

OPERATION

1. Unscrew the handle and cap
assembly complete in order to fill
the container with the desired
liquid.

2. Screw the cap and handle back
on firmly.

3. Release the carrying lugs from the
pump body by twisting the handle
anticlockwise.

4. Pressurise the container by
pumping the handle.

5. Squeeze the trigger to begin
spraying. When the spray
weakens, pump the handle to
maintain container pressure.

6. Push the trigger forward to lock in
position to maintain a constant
spray without needing to hold the
trigger. Slide the trigger lock back
to release.

7. Adjust the width of the spray by
twisting the tip of the nozzle.

8. If leaks or poor delivery are experienced, always check the connections.

9. Push the pump handle downward and twist to engage the carrying lugs in
the cap when lifting the unit.

AFTER USE

After use, the sprayer should be flushed thoroughly with clean water to avoid
the possibility of blockages from product residue, or any cross-contamination
between different products. Store in a cool place out of reach of children.

If not used for long periods or used continuously for several days, add a light
smear of vaseline to the sealing washers and moving parts to reduce wear
and assist free movement.

5

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

COMPONENT PARTS

No Description No Description

1 Handle Cap 11 Inner Hose

2Handle 12Hose

3 Aluminium Shaft 13 Tank

4 Pump Cap 14 Trigger

5 O-Ring Base 15 Lance

6 Inner O-Ring 16 Nozzle

7 Pin 17 Strainer

8 Pump 18 Safety Valve

9 Pump O-Ring 19 Safety Valve Gasket

10 Valve

6

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
