Page 1
TRUCK WHEEL DOLLY
USER INSTRUCTIONS
Model No. CTD135
Part No. 7630209
0900
Page 2
Inspect before use to ensure that all parts are secure and in good condition. If any
supporting it with the other hand.
To Remove A Wheel From A Vehicle
Slide the Dolly underneath the tyre as shown,
and position it so that the tyre sits snugly on
the rollers.
Lift the handle with one hand to take the
weight, then pull off the wheel, whilst
damage is apparent, do not use but have repaired by a qualified technician.
Method of Use
way, or not used for the purpose for which it is intended. The reason for return must
be clearly stated.
• DO NOT exceed the load for which this device was designed (125kg)
Attach the handle to the Wheel Bracket using the nuts and bolts provided.
Little maintenance is required. Oil the roller bearings periodically with a light oil.
Features
• Ensure the wheel is well balanced, using the hand before moving.
from service and repaired by a qualilfied technician.
• ALWAYS inspect before each use, to ensure the frame is not bent or twisted
and that there are no cracked welds etc. Should any damage be apparent,
or if the stand has been subjected to an abnormal shock, it should be removed
Safety Precautions
This guarantee does not affect your statutory rights.
Thank you for purchasing this Clarke Truck Wheel Dolly. Before using please read
these instructions. This is for your own safety and that of others around you, and to
This product is guaranteed against faults in manufacture for 12 months from
purchase date. Please keep your receipt as proof of purchase.
This guarantee is invalid if the product has been abused or tampered with in any
help you achieve long and trouble free service from the Dolly.
Guarantee
6
7
8” Tyre Roller HTLA206
Left Roller Bkt. HTLA207
13
3” Wheel HTLA213
4
5
Lock Nut HTLA204
Hex. Bolt HTLA205
11
12
Axle Bush HTLA211
Axle Bolt HTLA212
2
3
Wheel Bracket HTLA202
Right Roller Bkt. HTLA203
10
9
Lock Nut HTLA209
Axle Lock Nut HTLA210
No.
1
Description Part No. No. Description Part No.
Handle with Grip HTLA201
8
Hex. Bolt HTLA208
Parts List & Diagram
