BELT/DISC SANDER
BELT/DISC SANDER
MODEL NO: CS4-6C
PART No: 6500401
OPERATION & MAINTENANCE
INSTRUCTIONS
0807
CONTENTS
Specifications ...................................................................................... 3
Safety Precautions .............................................................................. 4
Electrical Connections ....................................................................... 6
Pre-Assembly Check .......................................................................... 7
Assembly Instructions .......................................................................... 8
Getting to know your Belt Sander ................................................... 13
Operating Instructions ...................................................................... 15
Maintenance .................................................................................... 18
Troubleshooting................................................................................. 19
Parts Diagram ................................................................................... 20
Parts List ......................................................................................... 21-22
Declaration of Conformity ............................................................... 23
PARTS & SERVICE CONTACTS
For Spare Parts and Service, please contact your nearest dealer,
or CLARKE International, on one of the following numbers.
PARTS & SERVICE TEL: 020 8988 7400
PARTS & SERVICE FAX: 020 8558 3622
or e-mail as follows:
PARTS: Parts@clarkeinternational.com
SERVICE: Service@clarkeinternational.com
When disposing of this product, do not dispose of with general waste. It must be disposed of according to the laws
governing Waste Electrical and Electronic equipment, at a recognised disposal facility.
2
CLARKE International. Hemnall Street, Epping, Essex CM16 4LG
23
PARTS LIST cont.
Item Description Part No
35 Table
36 Support, Table
37 Label, Scale
38 Cord W/Plug
39 Motor (1/3 HP)
40 Connector, Wire
41 Nut, Hex M6 x 1.0
42 Base
43 Belt, Drive
44 Screw Flat M5
45 Washer, Countersunk
46 Drive Pulley
47 Screw, Pan Hd. M6 x 1.0-2.5
48 Washer, M6 x 12 x 1.6
49 Pulley, Drive
50 Screw, Flat Hd. M5 x 0.8-25
51 Support, Bearing
52 Pulley Cover Plate
53 Pulley Cover
54 Nut, Square M8 x 1.25
55 Bumper, Rubber
56 Screw M8 x 1.25
57 Bearing Ball
58 Ring, Retaining M12
59 Shaft, Drive
60 Nut,Hex M5 x 0.8
61 Spacer, Guide
62 Spring, Index
63 Guide, Drum
64 Shaft, Idler
65 Drum, Idler
66 Lever, Tension
67 Spring, Tension
68 Spacer, Lever
69 Washer, MS x 15 x 1.2
70 Mitre Gauge
22
UT819487
UT819490
UT819459
UTB19463
UT821587
UT375007
UT840610
UT8I9498
UT8I40023
UT8202352
UT821586
UT8215851
UT8202441
UT851006
UT821585
UT8102351
UT8I9473
UT819474
UT819482
UT8202584
UT820779
UT820239
UT814101
UT820242
UT821589
UT821557
UI619465
UT63658
UT821582
UT821581
UT819475
UT819470
UT819468
UT819471
UT851005
UT9999
Thank you for purchasing this CLARKE Belt and Disk Sander designed for hobby/
DIY, indoor use, and for sanding wood or wood products ONLY.
Before attempting to use the sander, please read this manual thoroughly and
follow the instructions carefully. In doing so you will ensure the safety of yourself
and that of others around you, and you can look forward to the sander giving you
long and satisfactory service.
These instructions should be retained and used for reference by all those who use
the equipment.
CLARKE GUARANTEE
This CLARKE product is guaranteed against faulty manufacture for a period
of 12 months from the date of purchase. Please keep your receipt as proof
of purchase.
This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for the purpose for which it was
intended.
Faulty goods should be returned to their place of purchase, no product
can be returned to us without prior permission.
This guarantee does not effect your statutory rights.
SPECIFICATIONS
Motor ................................................ 230V, 50Hz, 1ph
Motor Power .................................... 300Watts
Motor Speed .................................... 2800RPM
Fuse Rating ...................................... 5Amp
Sand Disk Size .................................. 5 inch (127mm)
Belt Disk Size ..................................... 1 inch (25mm)
Belt Speed ........................................ 13.5M/s
7
Dust Extraction Port OD .................. 1
Net Weight ....................................... 8kg
Dimensions (LxWxH) ........................ 360x280x390mm
Insulation Class ................................ B
Part No: ............................................ 6500403
Please note that the details and specifications contained herein, are correct at the time of going to print.
However, CLARKE International reserve the right to change specifications at any time without prior notice.
3
/8” (47mm)
SAFETY PRECAUTIONS
WARNING:
As with all machinery, there are certain hazards involved with their operation
and use. Exercising respect and caution will considerably lessen the risk of
personal injury. However, if normal safety precautions are overlooked or
ignored, personal injury to the operator or damage to property, may result.
1. ALWAYS Learn the machines applications, limitations and the
specific potential hazards peculiar to it. Read and become familiar
with the entire operating manual.
2. ALWAYS use a face or dust mask if operation is particularly dusty.
3. ALWAYS check for damage. Before using the machine, any
damaged part, should be checked to ensure that it will operate
properly and perform its intended function. Check for alignment
of moving parts, breakage of parts, mountings and any other
condition that may affect the machines operation. Any damage should be properly
repaired or the part replaced. If in doubt, DO NOT use the machine. Consult your
local dealer.
4. ALWAYS disconnect the machine from the power supply before servicing and when
changing accessories.
5. ALWAYS wear safety goggles, manufactured to the latest European Safety Standards.
Everyday eyeglasses do not have impact resistant lenses, they are not safety
glasses.
6. ALWAYS keep work area clean. Cluttered areas and
benches invite accidents.
7. ALWAYS ensure that adequate lighting is available. A
minimum intensity of 300 lux should be provided. Ensure
that lighting is placed so that you will not be working in
your own shadow.
8. ALWAYS keep children away. All visitors should be kept a safe distance from the
work area, especially whilst operating the machine.
9. ALWAYS maintain machine in top condition. Keep tools/machines
clean for the best and safest performance. Follow maintenance
instructions.
10. ALWAYS handle with extreme care do not carry the tool/machine
by its’ electric cable, or yank the cable to disconnect it from the
power supply.
11. ALWAYS ensure the switch is off before plugging in to mains. Avoid
accidental starting.
12. ALWAYS concentrate on the job in hand, no matter how
trivial it may seem. Be aware that accidents are caused
by carelessness due to familiarity.
13. ALWAYS keep your proper footing and balance at all
times - don’t overreach. For best footing, wear rubber
soled footwear. Keep floor clear of oil, scrap wood, etc.
PARTS LIST
WARNING: The use of spare parts, other that those supplied by CLARKE
International or one of its recognised dealers, may be hazardous and could
invalidate the guarantee.
Item Description Part No
1 Knob
2 Washer, Rubber
3 Washer, Shakeproof
4 Bed
5 Screw, Flat Cross M5 x 0.8-35
6 Screw, Hex M6 x 1.0-12
7 Lockwasher, Ext. M6
8 Washer, 6.5 x 17.8 x 1.6
9 Support, Work
10 Belt, Sanding 4" x 36"
11 Lockwasher, Helical M5
12 Screw, Pan Hd MS x 0.8-8
13 Drum, Drive
14 Screw, Socket Set M6 x 1.0-10
15 Cap, Bearing
16 Bearing, Ball
17 Spacer, Bearing
18 Housing Switch
19 Lockwasher, Ext. MS5
20 Screw, Pan Hd. MS x 0.8-1
21 Key, Switch
22 Switch, Locking
23 Lead
24 Screw, Pan Cross
25 Cover, Switch Box
26 Relay
27 Pad, 6" Sandpaper
28 Screw, Pan Cross M6 x 1.0-12
29 Lockwasher Helical M6
30 Disc
31 Screw, Pan Hd Type “AB” M4.2 x 1.4-12
32 Guard, Disk
33 Shroud Disk
34 Collector, Dust
UT820247
UT820175
UT821156
UT8I9496
UT820235
UT820249
UT852006
UT820238
UT819481
UT928394
UT8203834
UT8202401
UT819476
UT8203822
UT820243
UT821584
UT820618
UT819491
UT852005
UT820240
UT922256
UT816113
UT819461
UT8202481
UT819479
UT814589
UT928308
UT820244
UT8203835
UT821588
UT820248
UT819484
UT819497
UT819495
4
21
PARTS DIAGRAM
14. ALWAY S wear proper apparel. Loose clothing or jewellery may
get caught in moving parts. Wear protective hair covering to
contain long hair.
15. ALWAY S guard against electric shock. Avoid contact with
earthed surfaces..pipes, radiators etc.
16. NEVER operate machine while under the influence of drugs, alcohol
or any medication.
17. NEVER leave machine running unattended. Turn power off. Do
not leave the machine until it comes to a complete stop.
18. NEVER force the machine, it will do a better and safer job at
the rate for which it was designed.
19. NEVER use power tools in damp or wet locations or expose
them to rain. Keep your work area well illuminated. Do not use
in an explosive atmosphere (around paint, flammable liquids
etc.). Avoid dangerous environments.
ADDITIONAL PRECAUTIONS FOR BELT AND DISK SANDERS
1. ALWAYS wear ear protectors/defenders when using this machine.
2. ALWAYS wear a dust mask when using this machine. Be aware that harmful or
toxic dusts could be produced when sanding some woods, lead paint etc.
3. ALWAYS use the sandbelt support or table to support the workpiece.
4. ALWAYS check to ensure the table, sand belt support and attachments are
secure before starting.
5. ALWAYS maintain a clearance of 2-3mm between table and sanding belt or disc.
6. ALWAYS hold the workpiece firmly so that it cannot be ripped from your hands
7. ALWAYS feed the workpiece against the direction of rotation of the disc. i.e the LEFT
side of the disk
8. ALWAYS keep the mains cable well away from the machine and ensure an
adequate electrical supply is close at hand so that the operation is not
restricted by the length of the cable.
9. ALWAYS use a dust extraction device, properly connected to the dust
extraction port
10. ALWAYS ensure that nails or any foreign objects have been removed from a
workpiece beforehand. Nails etc., will destroy the belt or disk.
11. NEVER allow the ventilation slots in the motor to become blocked.
12. NEVER sand pieces which cannot be held firmly by hand.
WARNING! Use ONLY for sanding WOOD. DO NOT DO NOT USE for sanding asbestos,
or materials containing asbestos, painted surfaces, or materials which produce toxic
20
5
ELECTRICAL CONNECTIONS
Connect the mains lead to a standard, 230 volt (50Hz) electrical supply through a
fused good quality 13 amp BS 1363 plug, or a suitable fused isolator switch.
WARNING: THIS APPLIANCE MUST BE EARTHED
IMPORTANT: The wires in the mains lead are coloured in accordance with the
following code:
Green & Yellow - Earth
Blue - Neutral
Brown - Live
As the colours of the flexible cord of this appliance may not correspond with the
coloured markings identifying terminals in your plug, proceed as follows:
• Connect GREEN & YELLOW cord to terminal marked with a letter “E” or Earth
symbol “ ” or coloured GREEN or GREEN & YELLOW.
• Connect BROWN cord to terminal marked letter “L” or coloured RED.
• Connect BLUE cord to terminal marked letter “N” or coloured BLACK.
We strongly recommend that this unit is fitted with a Residual Current Device (RCD).
FUSE RATING
The fuse in the plug for this appliance must be rated at 5 amps and any
replacement must be ASTA approved to BS 1362.
4. Slightly tighten (3) screws. Adjust
tension of belt by putting blade
screwdriver in adjusting hole. Push up
on screwdriver to tighten tension
between pulleys.
5. Tighten screws fully, being careful not
to disturb the belt.
6. Test belt tension by placing fingers on
either side of belt and squeeze.
There should be about a 1/4" give to
the belt.
NOTE: Excessive tightness on pulley belt
may cause increased noise and over load
motor. Excessive looseness on pulley belt
may cause belt to fail prematurely.
7. Locate the pulley cover and position it inside the relief edges of pulley housing.
8. Using a cross head screwdriver, reinstall and tighten the flat head screw.
TROUBLESHOOTING
Trouble Probable cause Remedy
Motor will not run. 1. Defective On-Off switch 1. Replace defective parts before
Defective switch lead using belt/disc sander again.
Defective switch box.
2. Burnt out motor or relay. 2. Any attempt to repair this motor
or relay may create a HAZARD
unless repair is carried out by a
qualified electrician.
IMPORTANT NOTICE
If this appliance is fitted with a plug which is moulded on to the electric cable (i.e.
non rewireable) please note:
1. This plug must be thrown away if it is cut from the electric cable. There is a
danger of electric shock if it is subsequently inserted in a socket outlet.
2. Never use the plug without the fuse cover fitted.
3. Should you wish to replace a detachable fuse carrier, ensure that the correct
replacement is used (as indicated by marking or colour code).
4. Replacement fuse covers can be obtained from your local dealer, or an
electrical stockist.
6
Machine slows down 1. Drive belt too tight. 1. Decrease belt tension, see
when sanding. Maintenance section,
“Removing Pulley Cover and
Installing Drive Belt’.
2. Too much pressure applied 2. Ease up on pressure.
to workpiece.
Sanding Belt runs off 1. Not tracking properly. 1. Adjust tracking, see Assembly
pulleys. Instructions, “Installing the
Sanding Belt Tensioning and
Tracking’.
Wood burns while 1. Sanding disc or belt is 1. Replace disc or belt.
sanding glazed with sap.
Excessive noise. 1. Drive belt too tight. 1. Decrease belt tension, see
Maintenance Section
“Removing Pulley Cover and
Installing Drive Belt’.
19
MAINTENANCE
PRE-ASSEMBLY CHECK
WARNING: For your own safety, switch “OFF” and remove plug from power source
before adjusting, maintaining, or lubricating your belt and disc sander.
WARNING: To avoid electrocution or fire, any repairs to electrical systems should be
done only by qualified service technicians. The unit must be reassembled exactly to
factory specifications.
If the mains lead is worn or cut, or damaged in any way, have it replaced immediately.
Frequently blow out or vacuum any dust that may accumulate inside the motor.
A coat of wax applied to the worktable will make it easier to feed the work while finishing.
Do not apply wax to the abrasive belt table because the belt could pick up the wax and
deposit it on the pulleys, causing the belt to slip.
Lubrication
The BALL BEARINGS in this machine are packed with grease at the factory. They require
no further lubrication. Sleeve bearings should be lubricated with 30 weight oil or equivalent
after each 10 hours of operation.
Removing Pulley Cover And Installing Drive Belt
1. Using a cross head screwdriver,
remove the screw located in the
middle of the cover.
2. Remove the cover.
3. Loosen (3) screws to allow pulleys
to move enough to place the belt
around them. Place belt around
the motor pulley and drive pulley as
shown.
Separate all parts from packing materials and check each item with the “Table of
Loose Parts.” Make certain all items are accounted for, before discarding any packing
material.
WARNING: If any parts are missing, do not attempt to assemble the Belt and Disc
Sander, plug in the mains lead, or switch until the missing parts are obtained and
Installed correctly.
WARNING: For your own safety, never connect plug to power source until all assembly
steps are complete and until you have read and understood the entire owners manual.
LOOSE PARTS
TABLE OF LOOSE PARTS
Item Description Qty.
A Belt and Disc Sander Assembly 1
B Owner’s Manual 1
C Table 1
D Sanding Disc I
E Table Support 1
F Disc Guard 1
G Work Stop 1
H Mitre Gauge 1
Should any of the components be missing or damaged then please contact your
CLARKE dealer immediately for a replacement.
WARNING: The use of any accessory/attachment, other than those
recommended in this instruction manual, may present a risk of
personal injury.
Item Description Qty.
I Bag contents
Knob 1
Washer, 6.5 x 17.8 x 1.6 5
Screw, Pan Hd. M4. 2
Switch Key 1
Lockwasher, Ext. M6 4
Scale Label 1
Screw, Hex Hd. M6 4
Hex “L” Wrench 6mm 1
18
7
ASSEMBLY
Tools Required
Mounting To Workbench
If Belt and Disc Sander is to be used in a permanent location, it should be fastened securely
to a firm supporting surface such as a workbench.
If mounting to a workbench, holes should be drilled through supporting surface of the
workbench using dimensions illustrated.
1. The unit should be bolted securely using 5/16" screws, flat washers and hex nuts (not
included). Screw length should be 1½" plus the thickness of the bench top.
2. Locate and mark the holes where belt and disc sander is to be mounted.
3. Drill (2) 3/8" diameter holes through workbench.
4. Place the machine on the workbench aligning holes on base with holes drilled in
workbench.
5. Insert two 5/16" screws, thread on the washers and nuts, then tighten the nuts.
Always sand outside curves on the left
side of centre on the sanding disc as
shown.
WARNING: Applying the workpiece to
the right side of the disc could cause
workpiece to fly up (kick-back) and
result In an Injury.
Sanding Small End Surfaces On The Sanding Disc
NOTE: Use of a Mitre Gauge is
recommended for this operation.
Always move the work across left side of
centre on the sanding disc face as
shown.
The table may be tilted for bevelled
work.
Always position the workpiece to the left
of centre on sanding disc with disc
rotating anticlockwise as shown.
WARNING: Applying the workpiece
to the right side of the disc first could
cause workpiece to fly up (kickback)
Mounting To A Board
An alternate method of mounting is to fasten belt and disc sander to a mounting board.
The board should be of sufficient size to avoid tipping of sander while in use. Any good
grade of plywood or chipboard with a 3/4" minimum thickness is recommended. (Thinner
chipboard can break.)
CAUTION: To avoid Injury from tool
movement, use
nuts.
1. Follow instructions for mounting to
workbench, substituting a board 18" x
24" minimum size and using 5/16 inch flat
head screws, Iockwashers, and hex nuts
(not included). Screw length should be
1-1/2" plus the thickness of the mounting
board.
NOTE: For proper stability, holes must be
counter sunk so screw heads are flush with
the bottom surface of supporting board.
5/16"
or larger screws and
8
and result in an Injury.
WARNING: For your own safety,
turn switch “OFF” and remove plug
from power source outlet before
adjusting your sander.
NOTE: Use a combination square
to square the mitre gauge to the
face of the disc (combination
square must be “true” - See
“Unpacking - Tools Required”
section on page 8 for checking
this method). If it is not square,
loosen the mitre gauge knob and
move the mitre gauge slightly
until it is square. Without moving
the mitre gauge, tighten the
knob securely.
17
Surface Sanding On The Sanding Belt
WARNING: To avoid injury from slips, jams or thrown
pieces, adjust the backstop to clear the sanding
surface by no more than 1/16”. When checking
clearance between the belt and work support,
press the belt flat against the bed beneath it.
Hold the workpiece firmly with both hands,
keeping fingers away from the sanding belt.
Keep the end up against the backstop
and move the work evenly across the
sanding belt. Use extra caution when
sanding very thin pieces.
For sanding long pieces, remove the work support.
Apply only enough pressure to allow the sanding belt to remove
material.
Clamping To Workbench
The belt and disc sander can be
clamped directly to the board using two
or more “G” clamps on base of unit (one
clamp on each end).
Installing Sanding Disc And Guard
End Sanding On The Sanding Belt
It is more convenient to sand the ends of long workpieces with sanding belt in a vertical position.
See “Basic Operation - Positioning Belt Bed” for
adjusting the belt bed, and see “Assembly Installing Table Assembly” for adjusting worktable.
Move the work evenly across the sanding belt. For
accuracy, use a mitre gauge.
Sanding Curved Edges
Always sand inside curves on the idler
pulley as shown.
WARNING: Never attempt to sand
the ends of a workpiece on the idler
pulley. Applying the end of the
workpiece to the idler pulley could
cause the workpiece to fly up and
result in an injury.
1. Locate sanding disc and peel
backing from disc. Align perimeter of
disc with plate and press disc firmly
into position all the way around.
2. Locate disc guard and two M4 pan
head screws, from loose parts bag.
3. Position disc guard against lower 1/3
of disc aligning holes as shown.
4. Using a cross head type screwdriver,
fasten the pan head screws securely
applying slight pressure to thread the
holes.
Installing Work Support Stop
1. Locate the work support and M6 hex
screw, washer and lockwasher.
2. Hold work support into position and
fasten as shown. Do not overtighten.
16
9
Installing Table Assembly
1. Locate table support and (3) M6 hex
head screws, flat washers and
lockwashers among loose parts.
2. Position table support against table,
aligning holes as shown.
3. Fasten table support to table as shown.
OPERATING INSTRUCTIONS
Bevel Sanding
The worktable can be tilted from 00 to 450 for
bevel sanding. Loosen the table lock knob and
tilt the work-table to desired angle as shown.
Retighten table lock knob.
4. Locate washer 6.5 x 17.8 x 1.6 and knob
among loose parts.
5. Position table support in corresponding
holes on side of base as shown. Make
sure the 9.5mm diameter index pin
aligns with upper hole.
6. Place washer on threaded shaft of
knob and insert through slot into
threaded holes of base
WARNING: To avoid trapping the work or
fingers between the table and sanding
surface, the table should be repositioned
on the table support to retain a maximum
of 1/16 Inch distance between sanding
surface and table.
Raising Belt Bed
A bed locking hex socket head screw locks the belt bed in a vertical or horizontal position.
To adjust vertical position:
1. Remove the work support.
2. Loosen the hex socket head locking screw using a 6mm
hex. wrench
WARNING: To avoid trapping the
work or fingers between the
table and sanding surface, the
table edge should be a
maximum of 1/16 inch from
sanding surface.
7. Loosen the (3) hex head screws
and adjust table so ,that a gap of
1/16” ONLY exists between the
table and the disc..
10
3. Position belt bed vertically as shown and tighten the
hex. socket head screw.
15
ON-OFF Switch
The ON/OFF switch has a locking feature. This
feature is intended to help prevent
unauthorised and possibly hazardous use by
children and others.
1. To turn machine “ON’ insert key into
switch.
NOTE: Key is made of yellow plastic, located
in loose parts bag
2. Insert finger under switch lever and PULL
end of switch out.
.
Auxiliary Mounting For Vertical Sanding
1. Remove backstop lock bolt and remove
work support.
2. Remove table assembly by removing table
lock knob and washer.
NOTE: Belt bed may be raised to vertical
position by loosening hex socket screw and
raising bed. See “Positioning Belt Bed” on page
16.
3. Attach table assembly to auxiliary holes in
belt bed. Make sure index pin is in the
upper hole when sanding table is in the
vertical position.
Squaring Table Assembly
WARNING: To avoid injury from accidental start,
make sure tool is unplugged before aligning.
1. Using a combination square, check the
angle of the worktable with the disc.
NOTE: The combination square must be “true”
- See “Assembly - Tools Needed” section on
page 8 for checking method
2. If the table is not 90º with the disc, loosen
table lock knob screw and tilt table.
3. Adjust worktable square to the disc and
retighten table lock knob.
4. Attach scale label to 0º mark on dust guard.
.
3. To turn machine “OFF”... PUSH lever in.
NEVER LEAVE THE MACHINE UNATTENDED
UNTIL IT COMES TO A COMPLETE STOP.
4. To lock switch in OFF position.., hold switch
IN with one hand... REMOVE key with
other hand.
WARNING: For your own safety, always lock
the switch “OFF” when machine Is not In use
... remove key and keep It In a safe place...
also... In the event of a power failure (all of
your lights go out) turn switch off.., remove
the key and store It remote from the machine.
Installing the Sanding Belt -Tensioning And Tracking
WARNING: To avoid injury from accidental start,
switch “OFF”, remove key and disconnect from power
outlet before removing or installing sanding belt.
On the smooth side of the sanding belt, is a “directional
arrow.” The sanding belt must run in the direction of this
arrow so that the splice does not come apart.
1. Slide tension lever to the right to release the belt
tension.
2. Place the sanding belt over the pulleys with the
directional arrow pointing as shown.
Make sure the belt is centred on both pulleys.
14
11
3. Slide tension lever to the left to apply belt
tension.
4. Tighten hex socket screw when bed is in
desired position.
5. Plug in the power cord. Turn switch “ON” and
immediately “OFF,” noting if the belt
tends to slide off the idler pulley or drive pulley.
If it did not tend to slide off, it is TRACKING
properly.
6. If the sanding belt moves toward
the disc, turn the tracking knob
clockwise 1/4 turn.
7. If the sanding belt moves away
from the disc, turn the tracking
knob anticlockwise 1/4 turn.
8. Turn switch “ON” and immediately
“OFF” again, noting belt
movement. Readjust tracking
knob if necessary.
GETTING TO KNOW YOUR BELT/DISC SANDER
WARNING: To avoid injury from accidental start, switch “OFF” and disconnect from power
source before making any adjustments.
1. Work Support. Supports the workpiece on the sanding belt.
2. Hex Socket Head Screw. Loosening screw allows belt bed to be raised to the vertical
position.
3. Tracking Knob. Turning knob anticlockwise causes sanding belt to move towards
the disc; turning knob clockwise causes sanding belt to move away from the disc.
4. Tension Lever. Sliding lever to the right releases the sanding belt tension; sliding lever
to the left applies belt tension.
5. Table Lock Knob. Loosening knob allows the work table to be tilted for bevel sanding.
(Scale pointer on table trunnion; scale attached to base.)
6. Auxiliary Mounting Hole. Allows table assembly to be mounted for end sanding when
the bed is placed in vertical position.
7. On-Off Switch.
12
13
Loading...
