Page 1
MECHANICS UTILITY SEAT & 3 DRAWER
TOOLBOX
MODEL NO: CMUS3-B
PART NO: 7630139
USER INSTRUCTIONS
DL0525 -rev 1
Page 2
INTRODUCTION
Thank you for purchasing this CLARKE product. Before attempting to use the product,
it is essential that you read this manual thoroughly and carefully follow all instructions
given. In doing so you will ensure the safety of yourself and that of others around
you, and you can also look forward to the product giving you long and satisfactory
service.
SAFETY PRECAUTIONS
1. Use your mobile seat for any task where you would normally sit or kneel. Place on
level ground and the floor surface is hard enough that the castors do not sink in.
2. DO NOT leave the mobile seat where it may become a trip hazard.
3. Have any damaged parts repaired or replaced immediately. Use genuine CLARKE
parts only. The use of unauthorised parts may be dangerous and will invalidate
the guarantee.
4. NEVER climb on, stand on, or attempt to ride on the mechanic’s seat or use it to
transport heavy objects.
5. DO NOT exceed the safe working load of the seat (150kg/330lbs).
SPECIFICATIONS
The seat has 3 drawers with ball
bearing runners built in and 3 circular
holders for aerosol cans. The drawers
have a length of 300mm with a width of
150mm and depth of 37mm. The
aerosol holders are 70mm in diameter
with a depth of 50mm.
Dimensions (D x W x H, Incl. Casters) 410mm x 365mm x 390mm
Weight 8.1 kg
Safe Working Load (inc drawers) Total 150kg/330lbs
2
Parts & Service: 020 8988 7400 / E-mail: [email protected] or [email protected]
Page 3
UNPACKING & ASSEMBLY
Unpack and lay out all components, checking for any damage which may have
occurred during transit and ensuring that all parts are accounted for by checking
against the parts list. Should there be any deficiency or damage, please contact your
CLARKE dealer immediately.
COMPONENT PARTS
1 1 x Seat frame c/w 3 drawers
2 1 x Tool Tray
3 4 x M8 socket nuts
4 4 x Castor wheels
ASSEMBLY
1. Place the tool tray in the slot on the
side of the seat frame.
2. Fit the socket nuts into the holes on
each corner of the frame and screw
the castor wheels to the nuts.
• The nuts on the tool tray side
clamp the tray to the frame.
Check that all nuts are tight and
secure before using this seat.
Your mobile seat is now ready for use.
GUARANTEE
This CLARKE product is guaranteed against faulty manufacture for a period of 12
months from the date of purchase. Please keep your receipt as proof of purchase.
This guarantee is invalid if the product is found to have been abused or tampered
with in any way, or not used for its intended purpose. Faulty goods should be
returned to their place of purchase, no product can be returned to us without prior
permission.
This guarantee does not effect your statutory rights.
