Clarke CMUS 3, 7630141 User guide

MECHANICS UTILITY SEAT & 3 DRAWER TOOLBOX

MODEL NO: CMUS3

PART NO: 7630141

USER INSTRUCTIONS

DL1221

INTRODUCTION

Thank you for purchasing this CLARKE Mechanics Utility Seat & 3 Drawer
Toolbox.

Before attempting to use the product, it is essential that you read this manual
thoroughly and carefully follow all instructions given. In doing so you will ensure
the safety of yourself and that of others around you, and you can also look
forward to the product giving you long and satisfactory service.

GUARANTEE

This CLARKE product is guaranteed against faulty manufacture for a period of
12 months from the date of purchase. Please keep your receipt as proof of
purchase. This guarantee is invalid if the product is found to have been
abused or tampered with in any way, or not used for its intended purpose.
Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission. This guarantee does not effect your
statutory rights.

SAFETY PRECAUTIONS

1. Use your mobile seat for any task where you would normally sit or kneel.
Place on level ground and the floor surface is hard enough that the castors
do not sink in.

2. DO NOT leave the mobile seat where it may accidentally become a trip
hazard.

3. Have any damaged parts repaired or replaced immediately. Use genuine
CLARKE parts only. The use of unauthorised parts may be dangerous and
will invalidate the guarantee.

4. NEVER climb on, stand on, or attempt to ride on the mobile seat or use it to
transport heavy objects.

5. DO NOT exceed the safe working load of the seat (136kg/300lbs).

UNPACKING & ASSEMBLY

Unpack and lay out all components, checking for any damage which may
have occurred during transit, and ensuring that all parts are accounted for by

2

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

checking against the parts list. Should there be any deficiency or damage,
please contact your CLARKE dealer immediately.

PARTS LIST

1 1 x 3 Drawer Set and Seat Frame 3 4 x M8 Inner Hexagon Nuts

2 1 x Tool Tray 4 4 x 3” Castor Wheels

ASSEMBLY

1. Place the tool tray in the slot on
the side of the seat frame.

2. Place the M8 inner hexagon nuts
in the holes on each corner of the
frame and screw the castor
wheels into the nuts, making sure
the 2 nuts on the tool tray side
clamp the tray to the frame.

Check that all nuts are tight and
secure before using this seat.

Your mobile seat is now ready for use.

SPECIFICATIONS

The seat has 3 drawers with ball
bearing runners built in and 3 circular
holders for aerosols. The 3 drawers have
a length of 300mm, with a clearance of
250mm, width of 150mm and depth of
40mm. The
aerosol holders are 70mm in diameter
with a depth of 52mm.

Model Number CMUS3

Dimensions (D x W x H, Incl. Casters) 400mm x 400mm x 400mm

Weight 8.55kg

Underside Clearance 95mm

Safe Working Load 136kg/300lbs
