EDGE SPOT WELD DRILL

EDGE SPOT WELD DRILL

MODEL NO: CAT68

PART No: 3110740

OPERATION & MAINTENANCE

INSTRUCTIONS

0602

0502

Fig. 1

Fig. 2

Please note that the details and specifications contained herein are correct at the time of going to

print. However CLARKE International reserve the right to change specifications at any time without

prior notice. Always consult the machines data plate

Please read these instructions carefully before operating the tool

Thank you for purchasing this CLARKE Air Edge Spot Weld Drill.
Before using the device, please read this manual thoroughly and carefully follow
all instructions given. This is for your own safety and that of others around you, and
is also to help you achieve long and trouble free service from your new tool.

CLARKE GUARANTEE

This CLARKE product is guaranteed against faulty manufacture for a pe­riod of 12 months from the date of purchase. Please keep your receipt as
proof of purchase.

This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for the purpose for which it was
intended.

Faulty goods should be returned to their place of purchase, no product
can be returned to us without prior permission.

This guarantee does not affect your statutory rights.

PARTS & SERVICE TEL: [phone]

or e-mail as follows:

PARTS: [e-mail]

SERVICE: [e-mail]

ACCESSORIES

A wide range of Airline accessories is available, including Filter/Regulators, Lubricators, High
Pressure Hoses from 5 to 100 Metres, etc. Contact your CLARKE dealer for further informa­tion, or CLARKE International Sales Department on 01992 565300

SAFETY PRECAUTIONS

IMPORTANT

Failure to follow these precautions could

result in personal injury, and/or damage to

property.

❐ When operating this tool, ALWAYS wear:

a. approved impact resistant SAFETY
GOGGLES. (Eye glasses are NOT
safety glasses)

b. a DUST MASK
c. EAR DEFENDERS
d. a good pair of INDUSTRIAL GLOVES

❐ ALWAYS disconnect the tool when not

in use, and before carrying out any
maintenance

❐ ALWAYS keep a safe distance between

yourself and other people when using
the tool.

❐ ALWAYS maintain the tool with care. Keep

it clean for best and safest performance.

❐ NEVER wear ill fitting clothing, remove

watches and rings.

❐ Quick change couplings should not be

located at the tool. They add weight
and could fail due to vibration.

❐ DO NOT overreach. Keep your proper

footing and balance at all times.

❐ DO NOT force or misuse the tool. It will

do a better and safer job at the rate for
which it was designed.

❐ DO NOT abuse hoses or connectors.

NEVER carry a tool by the hose, or yank
it to disconnect from the air supply. Keep
hoses away from heat, oil and sharp
edges. Check hoses for leaks or worn
condition before use, and ensure that
all connections are secure.

❐ DO NOT exceed 90 PSI at the tool.
❐ DO NOT modify the tool in any way.
❐ DO NOT remove any labels. Damaged

labels should be replaced.

❐ This tool vibrates with use. Vibration may

be harmful to your hands or arms. Stop
using the tool if discomfort, a tingling
feeling or pain occurs. Seek medical
advice before resuming use.

❐ ALWAYS use screens to protect people

in the vicinity from flying debris.

❐ NEVER point the tool at anyone.

AIR SUPPLY

Tools of this type, operate on a wide range
of air pressures. It is recommended that air
pressure to this tool does not exceed 90 PSI
(6.2bar), at the tool when running. Higher
pressure and unclean air, will shorten the tools’
life because of faster wear, and could be a
safety hazard.
Water in the air line will cause damage to the
tool, ensure it is properly maintained at all
times.

The recommended procedure to connect
this tool to an air supply, is shown at fig. 1 on
inside front cover.

The air inlet used for connecting air supply,
has a standard ¼” BSP thread.

Line pressure, or hose inside diameter, should
be increased to compensate for unusually
long air hoses (over 10m). Minimum hose di­ameter should be 6mm (¼") ID., and fittings
should have the same inside dimensions.

ASSEMBLY

Connect a suitable hose to the Drill using a
¼” hose adapter, (A whip hose with Quick Fit
coupling is available from your CLARKE
dealer). then connect the other end to the
airline. NOTE: ensure the airline is turned off.

Your Drill is now ready for use.

WARNING

Compressed air can be dan-

gerous. Ensure that you are

thoroughly familiar with all

precautions relating to the use

of compressors and com-

pressed air supply.

OPERATING INSTRUCTIONS

Before starting work drain any water from the
air tank and blow condensation from the air
line. Drain compressor more frequently in hot
humid weather.

1. Disconnect tool from airline

2. Ensure that drill bit (Item 44) is properly
located in drill and grub screw (Item 33) is
fully tightened against flat portion on drill
bit. Slacken depth stop nut (Item 42) and
screw depth stop (Item 41) away from the
drill bit. Depress grip handle fully and then
adjust depth stop to required depth of cut
(see figure 2), Inside front cover.

3. Connect air line to tool, turn air on, check
for air leaks. If any are apparent,
rectify before proceeding.

4. position drill over spot weld (a centre
punch mark in the centre of spot weld may
aid accuracy).

5. Depress grip handle, which will start the
tool, apply a steady, even pressure. Do
not force. Too much pressure can cause
drill to break or overheat. too little pressure
will keep drill from cutting and cause it to
overheat.

6. When grip handle is fully depressed, drilling
is complete.

For lubricating the air motor when in
operation, an air line lubricator should be
used, with Clarke Air Line Oil, adjusted to 2
drops per minute.

Clarke Air Line Oil is available from your
CLARKE dealer, part no. 3050825.

Be aware that factors other than the tool may
effect its operation and efficiency, such as
reduced compressor output, excessive drain
on the airline, moisture or restrictions in the
line, or the use of connectors of improper size
or poor condition which will reduce air supply.

Grit or gum deposits in the tool may also
reduce efficiency. This condition can be
corrected by cleaning the air strainer and
flushing out the tool with gum solvent oil, or
failing this, the tool should be disassembled,
thoroughly cleaned, dried and reassembled.

If the tool runs erratically or becomes
inefficient, and the air supply is sound,
dismantle the air motor and replace worn or
damaged parts, or take the tool to your
CLARKE dealer.

IMPORTANT:

The use of parts other than CLARKE re­placement parts may result in safety haz­ards, decreased tool performance and
may invalidate your warranty.

MAINTENANCE

Daily before use.

1. Drain water from air tank, air line and

compressor.

2. Check and clean, if necessary, the air

inlet gauze filter .

3. Pour a few drops of CLARKE Air Line Oil

(approx 3cc), into the air inlet. This should
be carried out regardless of whether or
not an air line lubricator is used.
If an Air line lubricator is NOT used, this
procedure should be repeated after
every two to three hours of use.

If the drill is to be stored, or is idle for longer
than 24 hours, run a few drops of Clarke Air
Line Oil into the air inlet, and run the tool for 5
seconds in order to lubricate the internal
parts.

SPECIFICATIONS

Model:............................CAT 68

Part No:.......................... 3110740

Max Air Consumption.. 17 CFM

Drill Bit -(Supplied):.........8mm

Rec Air pressure:........... 90 PSI (6.2bar)

Air Inlet Size:...................¼ BSP

Min Hose Size:................8mm

Weight............................1.6 kg

Noise Level 90 dB(A)

PARTS DIAGRAM

PARTS LIST

Index Part Description Index Part Description

No. No. Qty No. No. Qty

1 KL0608001 Valve Screw 1 25 KL0608025 Planet Carrier 1
2 KL0608002 ‘O’ Ring 1 26 KL0608026 Planet Gear 3
3 KL0608003 ‘O’ Ring 1 27 KL0608027 Planet Cage 1
4 KL0608004 Air Controller 1 28 KL0608028 Spindle Shaft 1
5 KL0608005 Valve Spring 1 29 KL0608029 Internal Gear 1
6 KL0608006 Valve Stem 1 30 KL0608030 Ball Bearing 2
7 klL0608007 ‘O’ Ring 1 31 KL0608031 Clamp Nut 1
8 KL0608008 Valve Bushing 1 32 KL0608032 Spindle 1

9 KL0608009 Inlet Bushing 1 33 KL0608033 Screw 1
10 KL0608010 Retainer Ring 1 34 KL0608034 Arm Base 1
11 KL0608011 ‘O’ Ring 1 35 KL0608035 Hexagon Head Bolt 2
12 KL0608012 Exhaust Sleeve 1 36 KL0608036 Hexagon Nut 2
13 KL0608013 Spring-Pin 1 37 KL0608037 Set Screw 1
14 KL0608014 Throttle Lever 1 38 Kl0608038 Spring Niiv 1
15 KL0608015 Motor Housing 1 39 KL0608039 Grip Handle 1
16 KL0608016 Ball Bearing 2 40 KL0608040 Arm 1
17 KL0608017 Rear End Plate 1 41 KL0608041 Cut In Adjusting Bolt 1
18 KL0608018 Spring Pin 3 42 KL0608042 Hexagon Nut 1
19 KL0608019 Cylinder 1 43 KL0608043 Lock Nut 1
20 KL0608020 Rotor Blade 4 44 KL0608044 Drill 1
21 KL0608021 Rotor 1 45 KL0608045 Hexagon Head Bolt 1
22 KL0608020 Internal Gear 1 46 KL0608046 Hexagon Nut 1
23 KL0608023 Planet Gear 3 47 Kl0608047 Clip Washer 2
24 KL0608024 Planet Pin 6 48 Kl0608047 Pin 1
