Page 1
AUTOMOTIVE WHEEL DOLLY
MODEL NO: AWD1
PART NO: 7630205
USER INSTRUCTIONS
GC0216
Page 2
INTRODUCTION
Thank you for purchasing this CLARKE product. Before attempting to use this
product, please read the instructions carefully to ensure the safety of yourself
and that of others around you. In the event of damage, spare parts are
available from the Clarke International parts department.
ASSEMBLY
Attach the castors to each corner of
the dolly. Use the four bolts, nuts and
washers for each castor and tighten
securely.
SAFETY ADVICE
Never use the dollys on an incline.
They are designed for use on a firm,
smooth, level surface ONLY.
Ensure the vehicle engine is off
before moving the dolly into position.
Do not exceed the maximum load for each dolly of 500kg.
DO NOT work on a vehicle whilst it is still supported by the dollys.
Take extra care if the vehicle engine is running. If the drive wheels are
engaged the dollys could be ejected causing damage or personal injury.
INSTRUCTIONS FOR USE
Jack the vehicle until the tyres are clear of the floor. Position the dollys under
the tyres and centre them, then lower the vehicle carefully into place. Repeat
at the other end of the vehicle if two sets are being used. When moving the
vehicle, do so slowly and maintain control at all times. Do not use on sloping
surfaces such as driveways. Occasionally lubricate the swivel bearing and
axles.
GUARANTEE
This CLARKE product is guaranteed against faulty manufacture for a period of
12 months from the date of purchase. Please keep your receipt as proof of
purchase. This guarantee is invalid if the product is found to have been
abused or tampered with in any way, or not used for its intended purpose.
Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission. This guarantee does not effect your
statutory rights.
E-mail: [email protected] [email protected]
CLARKE INTERNATIONAL HEMNALL STREET, EPPING, ESSEX CM16 4LG
2
Parts & Service: 020 8988 7400 / E-mail: [email protected] or [email protected]
