DIGITAL MULTIMETER
Model No: CDM3
Part No. 4500030
Operating Instructions
WARNING
Before using this instrument, you should
read and fully understand this
instruction leaflet.
Failure to understand and comply with
the warnings and operating instructions
can result in serious or even fatal injury
and/or damage to property.
0507
Page 2
Battery - 1.5V Size AA: Fuse - 0.5V 240V fast blow
Replacement Parts
1. Test Leads Part No.CH301
2. Fuse Part No.CH302
Parts and Service
For spare parts and serviceing, please
contact your nearest dealer,
or CLARKE International
as follows:
Parts & Service
TEL: 020 8988 7400
or e-Mail:
Page - 7 Page - 2
DO NOT dispose of this product with general household waste. It must
be disposed of according to all laws governing waste electrical and
electronic products at a recognised disposal facility
Page 3
Resistance
Before testing a resistor in a circuit, make sure that all
power is removed from that circuit, and that all
1. Plug the test leads into their respective sockets.
2. Select the required range.
3. Short out the leads, and turn the adjuster located on the
side of the meter, until a zero reading is obtained.
4. Connect the leads to the resistor to be tested and take the
reading from the scale.
NOTE: If the range is changed, the needle must be re-zeroed before
taking a reading.
WARNING:
capacitors are discharged.
Battery Test
1. Plug the test leads into their respective sockets.
2. Connect the red test lead to the positive terminal of the
battery, and the black test lead to the negative.
3. The meter will indicate whether battery is serviceable or not.
Battery and Fuse replacement.
1. Disconnect test leads to ensure there is no possibility of them
being connected to a circuit.
2. Remove the single retaining screw from theback cover, and
remove cover.
3. Prise out Battery or Fuse from their holders, and replace with
one of the same size and rating.
Page - 6 Page - 3
Introduction
Thank you for purchasing this CLARKE Analogue Multimeter,
designed to measure A/C, D/C Volts, D/C Current, and
Resistance, with a built in Battery Tester. It is ideal for use in
workshops, laboratories, and for the hobbyist, and used with care
and consideration, will give years of satisfactory service.
Guarantee
This product is guaranteed against faults in manufacture from 12
months from purchase date. Keep your receipt as proof of
purchase. This guarantee is invalid if the product has been
abused or tampered with in any way, or not used for the purpose
for which it was intended. The reason for return must be clearly
stated. This guarantee does not affect your statutory rights.
Features
● 16 position Rotary Switch for Function and Range selection.
● All ranges fully protected.
● Needle Zeroing facility.
● Zero resistance needle adjust facility.
● D/C Voltage measurement from 0.05V to 500V.
● A/C Voltage Measurement from 0.2V to 500V
● D/C Current measurement from 0.1uA to 250mA.
● Resistance measurement from 0.1ohms to 1Kohms.
● 1.5V and 9V Battery tester.
Page 4
Specifications
● D/C Voltage range - 2.5, 10, 50, 250, 500V
● A/C Voltage range - 10, 50, 250, 500V
● D/C Current range - 500µA, 10mA, 250mA
● Resistance - 1Ohm to 2kOhm
● Max. common mode voltage - 500V DC/AC rms
● Power supply - 1 x 1.5V size AA battery
● Battery test - 1.5V - 9V
● Accessories - Set of test leads, fuse.
Operation
Before operating this meter, and to ensure accurate readings, the
needle must be set to zero, by turning the adjuster screw, in the
centre of the meter,as necessary.
On no account must the voltage under test exceed 500V D/C
WARNING:
A/C rms
D/C Voltage
1. Plug the black test lead into the “-” socket, the red lead into
the “+” socket.
2. Set range selector to D/C volt range required
IMPORTANT: If the voltage is not known beforehand, then select the
highest range and work down until a satisfactory reading is obtained.
3. Connect red test lead to the positive polarity of the circuit,
and black test lead to the negative.
4. Take the reading from the appropriate scale.
Page - 4
A/C Voltage
1. Plug the test leads into their sockets.
2. Set the range selector to the A/C voltage range required.
IMPORTANT: If the voltage is not known beforehand, then select
the highest range and work down until a satisfactory reading is
obtained.
3. Connect the test leads to the circuit regardless of polarity.
4. Take the reading from the appropriate scale.
D/C Current
Maximum current must not exceed 250mA
1. Plug the black test lead into the “-” socket, the red lead into
the “+” socket.
2. Set the range selector to the D/C current range required.
IMPORTANT: If the Current is not known beforehand, then select
the highest range and work down until a satisfactory reading is
obtained.
3. Switch off the current to the circuit, and break where
required.
4. Connect the test leads in series with the circuit, the red
lead to the positive polarity, and black test lead to negative,
and switch on the current.
5. Take the reading from the appropriate scale.
WARNING:
Page - 5
